Retain For Future Reference

“BIG EASY”®

USER GUIDE & CODE BOOK

Universal Remote

URC-2585

ABOUT YOUR BIG EASY

The Keypad 2

INSTALLING THE BATTERIES

4

SETTING UP THE BIG EASY

Setting Up Your Device 5

Using the AUX Key 6

ADVANCED FEATURES

Reassigning the Device Keys 7

Using the Scan key 8

Teletext and Fastext 9

Controlling Colour and Brightness 10

Sleeptimer 11

Punch-Through 13

Preventing Accidental Code Changes 13

TROUBLE-SHOOTING

Searching for Your Code 14

Code Blink Out 15

Helpful Hints 16

Consumer Help-Line 17

Quick Code Reference 18

SET-UP CODES

TVs 19

Videos 23

Satellite Receivers 25

Cable Boxes 27

Note: If you’re having problems operating all the functions

of your device, don’t worry, your ONE FOR ALL may just

need customising for your model type. Just call our

consumer help-line and we’ll get you on the right track.

Table of Contents

1

LED

Power

Scan key

Volume

Mute

Programme

Fast Forward

Pause

Fastext Keys

Record

Device Keys

Magic Key

Number Key

-/-- Key

Teletext Keys

Play

Rewind

Stop

2

Your ONE FOR ALL “Big Easy” Package contains:

Your BIG EASY Remote

Your BIG EASY Manual

Your manual is divided into two parts: set-up instructions and

device codes. You will need your manual to set up your new

BIG EASY so please be sure to keep it.

Your BIG EASY needs four new AAA/LR03 alkaline batteries.

Your BIG EASY can operate four devices: a Television, a Video

Recorder, a Satellite Receiver and a second Television, Video or

Satellite Receiver. Your BIG EASY can also operate Cable

Converters.

The Keypad

Key Function

LED LED

The LED (Light Emitting Diode) flashes red to

show the remote is working.

Power

The Power key controls the same function as on

your original remote.

Device Keys

The TV, VCR, SAT and AUX keys select the home

entertainment device to be controlled. For

example pressing the TV key allows the remote

to control the functions of your Television,

after pressing VCR you can operate your Video

Cassette Recorder and the SAT key operates

your Satellite Receiver or Cable Converter. The

AUX key operates a second Television, Video

Recorder or Satellite Receiver.

MAGIC Key

The MAGIC key is used to set up your BIG EASY

and to access special functions.

Scan

The Scan key allows you to easily browse

through the programmes on your Television,

Video Recorder, Satellite Receiver and Cable

Converter. See page 8 for more information.

Volume, Programme

The Volume and Programme keys control the

two most frequently used functions of your

Television and Satellite Receiver. They operate

just as those on your original remote.

TV

AUX

SAT

VCR

MAGIC

About Your BIG EASY

Key Function

Mute

The Mute key operates the same function it did

on your original remote.

Number Keys

The Number keys (0-9, 10, 20) provide functions

just like your original remote, such as direct

access programme selection. If your original

remote uses one/two digit input switching

(-/-- symbol), this function can be obtained by

pressing the -/-- key, which is the same as the

10 key.

Video Recorder Keys

After pressing the VCR key, the Video Recorder

keys operate the functions of your Video

Recorder. To prevent accidental recording, the

Record key must be pressed twice to start

recording.

Teletext/Fastext Keys

After pressing the TV key, the top row of the

Video Recorder keys are used to operate the

main teletext functions. The symbols above the

keys are for teletext. The Text keys are used to

access the teletext functions of your Television.

Of course, your Television must be teletext

capable. For an explanation of the teletext

symbols, please refer to page 9 of this manual.

After pressing the TV key, the bottom row of

the Video Recorder keys marked red, green,

yellow and blue, allow you to access the fastext

functions of your television. Again, your

television must be fastext capable to operate

these functions. For a more detailed

explanation of teletext and fastext, please refer

to the manual of your television set.

3

REC

STOP

P

A

U

S

E

STOP

STOP

-/--

,

STOP

STOP

REC

(red)

(blue)

(yellow)

(green)

About your BIG EASY

4

Your BIG EASY needs four new AAA/LR03 alkaline batteries.

Remove the battery cover from the

back of your BIG EASY.

Match the batteries to the + and -

marks inside the battery case, then

insert the batteries.

Press the battery cover back into

place.

2

3

Note: In order to avoid having to reprogramme your ONE

FOR ALL after you remove the batteries, you will need to

insert new batteries within 15 minutes. Also it is best that

you do not use rechargable batteries.

Installing the Batteries

1

Setting Up Your Device

To set up the Big Easy for your television:

Find your Television code in the

Set-Up Code section (starting on page

19). Codes are listed by brand name. The

most popular code is listed first. Make

sure your Television is switched on.

Press and release your BIG EASY’s TV key,

then press and hold the MAGIC key

until the red light blinks twice (the light

will blink once then twice).

Enter your three-digit TV code using

the number keys. The red light will blink

twice.

Now, aim your BIG EASY at your

Television and press POWER.

If your Television switches off, your BIG

EASY is ready to run your Television.

Write your code in the three boxes on page 18, for quick, easy

reference.

To control your Television, press TV first.

5

Setting Up The BIG EASY

1

2

3

4

ONE FOR ALL

A-Mark

Admiral

Anam

Anam National

AOC

Archer

All & Howell

003

179, 180, 016, 047, 093

180

055, 161

019, 030, 052, 003, 136

003

016

030, 046, 186, 056

000

000, 000, 000, 046

TV

MAGIC

Important notes:

- To set up your Video Recorder or Satellite, follow the same

instructions above, only press the VCR or SAT key during

step 2.

- To set up your Cable Box, follow the instructions above

only press the SAT key during step 2.

- If your Video’s original remote control does not have a

power key, press PLAY instead of POWER when searching

for your code.

- If your Device does not respond, follow steps 1 - 4 with

each code listed for your brand. If none of the codes listed

for your brand operate your Device, then try the search

method described on page 14, even if your brand is not

listed at all.

6

Setting Up the BIG EASY

Using the AUX Key

The AUX key on your BIG EASY can be used to control a

second Television, Video Recorder or Satellite Receiver.

To set up the AUX key to control a second TV:

Press and hold the MAGIC key until

the red light blinks twice (the light will

blink once then twice).

Press 9 9 2 TV AUX.

Find your Television code in the Set-Up

Code section (starting on page 19). Codes

are listed by brand name. The most

popular code is listed first. Make sure

your Television is switched on.

Press and release your BIG EASY’s AUX

key, then press and hold the MAGIC

key until the BIG EASY’s red light blinks

twice.

Enter your three-digit TV code using

the number keys. The red light will blink

twice.

Now, aim your BIG EASY at your

Television and press POWER.

If your Television switches off, your BIG

EASY is ready to run your Television.

When you want to control your second

TV, press AUX first.

1

2

3

4

ONE FOR ALL

A-Mark

Admiral

Anam

Anam National

AOC

Archer

All & Howell

003

179, 180, 016, 047, 093

180

055, 161

019, 030, 052, 003, 136

003

016

030, 046, 186, 056

000

000, 000, 000, 046

MAGIC

TV

AUX

AUX

MAGIC

5

6

Important notes:

- To set up your Video Recorder or Satellite, follow the same

instructions above, only press the VCR or SAT key during

step 2.

- To set up your Cable Box, follow the instructions above

only press the SAT key during step 2.

- If your Video’s original remote control does not have a

power key, press PLAY instead of POWER when searching

for your code.

- If your device does not respond, follow steps 3 - 6 with

each code listed for your brand. If none of the codes listed

for your brand operate your Television, Video Recorder or

Satellite Receiver, then try the search method described on

page 14, even if your brand is not listed at all.

7

Reassigning the Device Keys

If you want, you can change any of the device keys (TV, VCR,

SAT or AUX) to operate another type of device. The chart

below lists how to change the keys and to set up that device:

To Change: Press:

MAGIC*992 VCR TV,

then TV MAGIC*Code

MAGIC*992 SAT TV,

then TV MAGIC*Code

MAGIC*992 TV VCR,

then VCR MAGIC*Code

MAGIC*992 SAT VCR,

then VCR MAGIC*Code

MAGIC*992 TV SAT,

then SAT MAGIC*Code

MAGIC*992 VCR SAT,

then SAT MAGIC*Code

MAGIC*992 TV AUX,

then AUX MAGIC*Code

MAGIC*992 VCR AUX,

then AUX MAGIC*Code

MAGIC*992 SAT AUX,

then AUX MAGIC*Code

*Hold down the MAGIC key until the red light blinks twice.

To reset a device key to its original function, press:

TV key MA*992

VCR key MA*992

SAT key MA*992

AUX key MA*992

*Hold down the MAGIC key until the red light blinks twice.

Advanced Features

TV

SAT

AUX

VCR

AUX

TV

AUX

VCR

SAT

TV

SAT

SAT

VCR

TV

VCR

SAT

TV

VCR

MAGIC

TV

TV

VCR

SAT

AUX

VCR

SAT

AUX

MAGIC

MAGIC

MAGIC

to

to

to

to

to

to

to

to

to

Using the Scan Key

Your BIG EASY comes with a special Scan key which lets you

go through every programme available on your Television,

Video Recorder, Satellite Receiver or Cable Converter.

For example, to scan through the programmes on your Television:

Aim the BIG EASY at your Television and

press TV, then Scan. You will

automatically move through all the

programmes available on your Television

stopping at each pro-gramme for about

three seconds. Remember, the BIG EASY

must remain aimed at your Television the

entire time you are using Scan.

When you find a programme that you

would like to watch, simply press the

Scan key again to stop the Scan feature.

To use Scan with your Video Recorder, Satellite Receiver or

Cable Converter, simply press the appropriate device key

(VCR, SAT or AUX), then Scan.

8

Advanced Features

1

2

TV

Note: Scan may not function with devices that did not have

a programme +/- key on the original remote.

Teletext and Fastext

The BIG EASY is designed to operate the basic functions of

teletext (text on, text off and mix).

Symbol Title Description

TEXT Puts the Television in the teletext mode

TV Switches the Television back to regular

viewing mode. On some Televisions,

this may be done by pressing the TEXT

key several times.

MIX Shows both teletext and regular

Television simultaneously.

Also used for subtitling. On some

Televisions this function is accessed by

pressing the TEXT key twice.

The keys marked red, green, yellow and blue are used to

access the fastext functions of your TV.

9

Advanced Features

Note: For a more detailed explanation of teletext and

fastext, please refer to the manual of your Television.

Remember, different Televisions control teletext and fastext

features in different ways. Not all of the teletext functions

may be available for your particular model.

Controlling Colour & Brightness

Depending on the functions of your original remote control,

the BIG EASY can operate the colour and brightness settings

of your Television.

To adjust the colour:

Press MAGIC followed by

Volume+ (for colour up) or

Volume- (for colour down).

To adjust the brightness:

Press MAGIC followed by

Programme+ (for brightness up) or

Programme- (for brightness down).

10

Advanced Features

MAGIC

MAGIC

Sleeptimer

Sleeptimer is a feature which comes built into many TVs and

Satellites. It allows you to set your device to turn off within a

certain amount of time. This feature comes in handy if, for

example, you enjoy falling asleep with your television on.

With the ONE FOR ALL, there are two ways to use the

sleeptimer. If your TV or Satellite came with this feature built

in, follow the instructions “Device Sleeptimer” below. If your

device did not come with this feature, follow the instructions

“ONE FOR ALL Sleeptimer”

Device Sleeptimer

If your TV or Satellite has a “Sleeptimer” function built in, you

can access this function with your ONE FOR ALL remote. To do so:

Make sure your TV (or Satellite) is switched on.

Press the device key (TV or SAT).

Point the ONE FOR ALL at your TV (or

Satellite) and press and release MAGIC

then press POWER. You should see the

Sleeptimer activate on your TV screen.

To increase the timer, simply press MAGIC

and POWER until the timer gets to the

desired time.

To deactivate the Sleeptimer, repeat steps 1-3 above. During

step 3, continue pressing Magic then Power until the timer

indicates zero minutes.

11

Advanced Features

Note: Remember, your device must have its own Sleeptimer

function in order for the above instructions to operate. If

your device does not have its own Sleeptimer, follow the

instructions outlined below.

SAT

TV

1

2

3

MAGIC

or

The ONE FOR ALL Sleeptimer

Your ONE FOR ALL remote comes with an internal Sleeptimer

function for those devices (TV or Satellite) which did not come

standard with this function. To use the ONE FOR ALL

Sleeptimer:

Making your ONE FOR ALL ready for Sleeptimer:

Press the device key (TV or SAT).

Then, press and hold MAGIC until the

red light blinks twice. Press 970. The red

light will blink twice again. It is only

necessary to perform steps 1 and 2 once.

Now to set the timer, continue with the

steps below.

Setting the ONE FOR ALL Sleeptimer:

It is possible to set the timer for 15, 30, 45 or 60 minutes. To

do this, first make sure your TV (or Satellite) is switched on.

Then,

Press and release MAGIC then press POWER.

The red light will blink once which indicates the

timer is set for 15 minutes. To increase the

timer, simply press POWER again (this must be

done within 5 seconds). The light will blink

twice indicating the timer is set for 30 minutes

(2x 15). You can press POWER a maximum of

four times which will set the timer to 60

minutes.

Once you have set the timer to the desired time, set your ONE

FOR ALL remote down, pointing it at your device. When the

programmed amount of time has elapsed, the ONE FOR ALL

will send the command for Power, hence turning off your

device.

12

Advanced Features

2

MAGIC

Notes:

- The red light on the ONE FOR ALL will blink every 15

seconds indicating that the remote is in Sleeptimer mode.

- To deactivate the Sleeptimer, simply press any key on the

ONE FOR ALL remote.

- Also, it is only necessary to follow steps 1 and 2 above

one time. For subsequent use of the Sleeptimer, simply

begin with “Setting the Sleeptimer”.

- Remember, when using the ONE FOR ALL Sleeptimer, you

must set the remote so it is pointing to your device.

SAT

TV

1or

MAGIC

(:15)

(:30)

(:45)

(:60)

13

Advanced Features

Punch-Through

You may be able to use some features of your Television,

Video Recorder and Satellite Receiver at the same time. If

you're watching a programme on your Video, you can adjust

the volume (a TV function) without first pressing the TV key.

The chart below lists some of the possibilities:

Last Key Pressed: You Can Control:

VCR TV volume up and down, mute

SAT TV volume up and down, mute

AUX TV volume up and down, mute

Preventing Accidental Code Changes

To prevent the accidental changing of codes in the BIG EASY

(for instance by young children), it is possible to lock in the

code you have set up.

Please remember, this is an optional feature and should only

be used after you have found all the code(s) which operate

your device(s) correctly and have set up your BIG EASY exactly

the way you want it.

To lock in your: Press:

TV code *982

VCR code *982

SAT code *982

AUX code *982

*Hold down the MAGIC key until the red light blinks twice.

To release the lock, simply repeat the same steps.

TV

MAGIC

MAGIC

MAGIC

MAGIC

AUX

SAT

VCR

Note: Once you have locked in a code, you will not be able to enter

a new code or reassign the device key until the lock is released.

14

Searching for Your Code

If your Television, Video Recorder or Satellite Receiver does

not respond to the BIG EASY after you have tried all the codes

listed for your brand, try the Search Method. The Search

Method may also work if your brand is not listed at all.

Let's say you cannot get your BIG EASY to control your

Television:

Switch your Television on.

Press the TV key on your BIG EASY.

Aim the BIG EASY at your Television.

Press and hold MAGIC until the BIG

EASY’s red light blinks twice. Then, press

9 9 1. The red light will blink twice.

Now, alternate between TV and POWER,

over and over, until your Television turns

off. You may have to press these keys

many times, so please be patient.

Remember to keep pointing the BIG

EASY at your Television when you press

the TV and POWER keys.

When your Television turns off,

press MAGIC. Don't forget, press MAGIC

as soon as your Television turns off.

Now your BIG EASY is ready to run your

Television.

To search for the code for your Video Recorder, Satellite or

Cable Box, follow the instructions above, only press the VCR

or SAT key during steps 2 and 4.

Note: If your Video's original remote control does not have

a power key, press PLAY instead of POWER when searching

for your code.

Trouble-Shooting

TV

MAGIC

1

2

3

TV

MAGIC

5

4

Code Blink Out

Even if you have used the Search Method, it is handy to know

your Television, Video, Satellite or Cable code for future

reference. It's easy to get your code after you have set up

your device.

To blink out your Television code:

Press TV.

Press and hold MAGIC until the BIG

EASY’s red light blinks twice. Press 9 9 0.

The red light will blink twice.

For the first digit of your three-digit

code, press 1and count the red blinks.

If there are no blinks, the digit is "0".

For the second digit, press 2and count

the red blinks.

For the third digit, press 3and count the

red blinks. Now you have found your

three-digit code.

Make sure you write your device code in the three boxes on

page 18.

To blink back the code for your Video, Satellite or Cable Box,

follow the instructions above only press VCR or SAT during

step 1.

15

Trouble-Shooting

5

3

4

1

2

TV

MAGIC

Helpful Hints

16

Trouble-Shooting

Problem:

Red light does not

blink when you press

a key?

The ONE FOR ALL

does not respond

after pressing a key?

The ONE FOR ALL

does not operate your

device(s)?

Your brand is not

listed in the ONE FOR

ALL code section?

When following the

set-up instructions,

the red light on the

ONE FOR ALL only

blinks once instead of

twice after you enter

a three-digit code?

The ONE FOR ALL is

not preforming

commands properly?

Press a key but get

the wrong result?

You cannot control

the volume feature of

your Satellite, Cable

Converter or TV/

Video combination or

you cannot control

the volume of your

TV set up on the AUX

key?

Problems changing

channels?

Video not recording?

Scan does not work

on your device?

Solution:

Replace batteries with 4 fresh, new

AAA alkaline batteries.

Make sure you are using new

batteries and are aiming the ONE

FOR ALL at your device.

A) Try all the codes listed for your

brand.

B) Try the search method on page

14.

Try the search method on page 14.

Did you use the Code Lock feature?

You must first unlock the code

before entering a new code. Follow

the instructions on page 13 to do

this.

You may be using the wrong code.

Start the search method over again

to locate the proper code.

Hold MAGIC until the red light

blinks twice, then press 992 and the

device key twice. You will need to

set-up your device again. Try the

codes for your brand or the search

method on page 14.

Hold MAGIC until red light blinks

twice. Then press 993 and VOL+. To

set the volume control back to TV

(Punch Through), hold Magic until

the red light blinks twice, then

press 993 TV.

Enter the programme number

exactly as you would on your

original remote.

As a safety feature on your ONE

FOR ALL, you must press the Record

key twice.

Make sure your original remote had

a programme +/- key.

17

Trouble-Shooting

Consumer Help-Line

If you have any questions about the operation of your new

ONE FOR ALL Universal Remote Control, you may call our

consumer help-line for assistance. Before calling, please read

this manual carefully to find an answer to your question.

If you cannot find a solution in this manual, please complete

the information on the next page on all your equipment

before calling. This way we can better serve you.

In the UK: phone: 0800 966 194

fax: +31 53 432 9816

e-mail: ofahelp@ueic.com

hours: 9 am-7 pm Mon-Fri / 9 am-3 pm Sat

In Ireland: phone: 1-800 553 118

fax: +31 53 4329816

e-mail: ofahelp@ueic.com

hours: 9 am-7 pm Mon-Fri / 9 am-3 pm Sat

In Australia: phone: 1-800 064 472

e-mail: ofahelp@ueic.com

Your ONE FOR ALL model number: URC-2585

Date of purchase: day/month/year

----- ------- -------

day/month/year

Your device:

(The first row is an example of how to complete this table)

TYPE BRAND MODEL NR. REMOTE MODELNR.

TV Sony KVX-2950B RMT-V131B

18

Set-Up Codes

Quick Code Reference

The following pages list the codes for your equipment.

The most popular codes for each brand are listed first.

If your device does not respond to the BIG EASY after you

have tried all the codes for your brand, try the search method

(page 14).

Write down the codes for your devices in the boxes below, for

quick and easy reference.

Device Type Code

1._________________________

2._________________________

3._________________________

4._________________________

■■■■■■

■■■■■■

■■■■■■

■■■■■■

19

Televisions

Acura 009

Admiral 087 093 418 213 264

Adyson 217

Agazi 264

AGB 516

Aiko 216 009 037 371 035

072 361 191

Aim 037 274

Akai 208 361 371 037 191

035 009 072 218 163

Akiba 218 282 455 037

Akura 218 282 276 009 412

264 037

Alba 218 235 009 418 370

355 371 037 216 247

431

Alcyon 076

Allorgan 206 294 217

Allstar 037

Amplivision 217 400 320

Amstrad 177 009 516 264 218

371 362 412 037

Anglo 009 264

Anitech 009 068 076 264

Ansonic 370 102 009 037 374

163 323 411 259 247

012 428

Arc en Ciel 399 501 196 109 568

Arcam 216 399 217

Aristona 037 556 012

Arthur Martin 400

ASA 105 346 070 104 087

Asberg 037 076

Asuka 218 264 216 282 217

Atlantic 037 216 206 320

Atori 009

Audiosonic 037 109 217 370 337

264 218

Audioton 217

Ausind 076

Autovox 087 237 076 217 247

Ayomi. 238

Baird 109 193 343 190 192

072

Bang & Olufsen

087 565

Basic Line 218 009 374 037 282

Bastide 217

Baur 303 535 512 554 361

505 010 037

Bazin. 217

Beko 370

Beon 037

Best 337 370 421

Bestar 037 370 374

Binatone 217

Black Star 247

Blacktron 282

Blackway 282

Blaupunkt 554 535 191 195 200

213 327 328

Blue Sky 218 282 455 037

Blue Star 282

Bondstec 247

Boots 217

BPL 282

Brandt 501 399 237 333 196

198 287 335 568

Brinkmann 418

Brionvega 037 087

Britannia 216 217

Bruns 087

BSR 294

BTC 218

Bush 218 235 009 036 282

037 355 371 374 519

Capsonic 264

Carena 455 037

Carrefour 036 070

Cathay 037

Centurion 037

Century 087 213 247

CGE 074 084 076 247 276

418 370

Cimline 009 235 218

City 009

Clatronic 218 264 370 371 217

076 037 009

Clayton 385 Concorde

009

Condor 216 247 282 320 037

370 009 102

Contec 216 009 157 011 036

Continental

Edison 501 237 196 198 399

333 287 487 568

Cosmel 009 337

Crezar 213

Crosley 087 247 074 084 076

213

Crown 009 370 076 421 037

359

Crystal 431

CS Electronics 247 216 218

CTC 247

Cybertron 218

Daewoo 009 037 216 374 218

217

Dainichi 218

Dansai 037 264

Dawa 037

Daytron 009 374

Decca 072 516 037 249 217

DeGraaf 208

Desmet 320 037

Dixi 009 037

Domland 394

DTS 009

Dual 217 343 259 399 519

Dual-Tec 217 259

Dumont 087 104 102 213 217

070

Dynatron 037

Set-Up Codes - TV

20

Set-Up Codes - TV

Elbe 435 238 259 362 292

370 163 037 218 191

411

Elcit 087 247 516 102

Elekta 264 282

Elin 216 037 105 104

Elite 218 037

Elman 102

Elta 009

Emerson 177 213 087 247

Emperor 282

Erres 037 012

Etron 037 009

Euro-Feel 264

Euromann 216 264 037 217 421

370

Europhon 037 516 102 213 217

247

Expert 206 400

Fenner 374 009

Ferguson 073 287 192 190 335

238 193 109

Fidelity 193 216 371

Finlandia 208 346 359

Finlux 105 104 037 346 217

072 076 516 070 087

102

First Line 294 321 216 037 374

385 247 009 217

Fisher 104 087 217 036 208

370 087 157 361 303

072

Flint 037 455

Forgestone 193

Formenti 087 213 216 320 076

Fortress 093 087

Fraba 370 037

Frontech 247 264 431 217 009

Fujitsu 206 072 217

Funai 264 294

Galaxis 370 418 037

GBC 213 009

GEC 043 072 361 516 037

217 072 349

Geloso 213 009 374

General

Technic 009

Genexxa 218 037 412

Germanvox 213

Goldline 337

Goldstar 037 370 290 009 377

217 247 216 431

Goodmans 036 072 037 009 264

516 290 374 371

Gorenje 370 421

GPM 218

Granada 037 226 356 359 012

072 108 208 217 076

036 339 516

Grandin 282 218 400 037 009

320 455

Grundig 535 195 191 554 487

070 076 237 037

Halifax 264 216 217

Hampton 216 217

Hanseatic 037 292 282 361 394

213 320 428 009 294

217 519

Hantarex 009 213 037 296

HCM 264 009 282 412 217

218 037

Hema 217 009

Hifivox 501 196 399 568

HiLine 264 037

Hinari 208 036 037 218 009

163

Hisawa 282 218 400 455

Hitachi 225 036 349 356 473

043 343 196 198 217

Hoshai 218

Hygashi 217 216

Hornyphon 037

Hyper 009 216 217 247

Hypersonic 361

Hypson 037 264 217 282 455

400

ICE 264 217 037 371 218

216 009

Imperial 037 247 370 418 074

084 076 349

Indesit 237 213

Indiana 037

Ingersol 009

Inno Hit 009 072 037 218 290

217 516 247

Interbuy 009 264 247 068

Interfunk 037 012 087 512 275

327 163 361 370 501

568

Intervision 282 217 455 068 037

394 218 102 264 247

431

Irradio 009 037 218 247 290

076

Isukai 218 037 282

ITC 217

ITS 037 371 218 282 264

216

ITT 163 480 349 361 473

361 339 208

JEC 035

JVC 053 094 190 036 192

193 371 218

Kaisui 009 217 218 282 037

216 455

Kamp 216

Kapsch 206 163 361

Karcher 037 421 282

Kendo 362 235 247 102 037

477 411 428

Kennedy 206 213 435

Kingsley 216

Kneissel 435 259 292

Kolster 037

Konka 218 371

Korpel 037

21

Set-Up Codes - TV

Korting 087 421 320

Kyoto 385

Lenco 009 104

Lenoir 009

Lesa 247

Leyco 264 072 037 294

Lifetec 009 264 519

Lloyds 009

Loewe 512 087 037

Logik 011

Luma 206 037

Lux May 037

Luxor 237 290 357 361 356

M Electronic 346 037 109 343 247

105 104 374 009 217

068 480 492 216

Magnadyne 087 247 516 102

Magnafon 516 213 076 102 216

Mandor 264

Manesth 037 235 217 264 320

276 035

Marantz 037

Marelli 087

Mark 037

Matsui 235 177 009 355 011

072 036 037 487 217

294 371 443

McMichael 043

Mediator 037 556 012

Memorex 009

Memphis 337 072 009

Mercury 037

Metz 087 195 535 447 239

213 554 275 367

Minerva 487 535 070 076 554

237

Minoka 412 037 359

Mitsubishi 108 150 512 087 036

237

Mivar 292 290 291 370 216

Motion 076

MTC 370 349

Multistandard 102

Multitech 217 009 216 247 102

Murphy 104 216

National 237

NEC 036 320

Neckermann 037 191 370 505 200

554 556 327 349 087

213 217 411

NEI 037 337 431

Nesco 247

Newtech 037 009 556 343

New World 218

Nicamagic 216

Nikkai 072 218 037 217 264

035 337 216 009

Nobliko 102 076 070 216

Nogamatic 399 501 196 568

Nokia 163 480 349 359 473

361 339 208

Nordmende 109 501 287 399 196

343 198 213 568

Oceanic 163 400 361 294 563

Okano 370

Onwa 371

Opera 037

Orbit 037

Orion 235 294 177 320 355

011 037 009 321

Osaki 072 218 217 264 276

Oso 218

Osume 157 072

Otto Versand 010 505 036 093 512

037 556 535 195 349

554 191 361 235 109

213 294

Pael 216

Palladium 370 037 191 505 200

554 556 327 349 087

213 217

Panama 009 217 264 216 037

Panasonic 226 250 126 274 213

361 237 367 037

Panavision 037

Pathe Cinema 238 216 400 320 292

Pathe Marconi 213 501 196 198 333

399 237 568

Pausa 009

Perdio 072 320

Perfekt 037

Philco 087 084 074 418 076

213 247 370

Philharmonic 217

Philips 037 556 012 323 554

191 043 087 193

Phoenix 037 087 320 385

Phonola 037 012 087 193 216

Pioneer 037 343 428

Plantron 037 264

Policom 568

Poppy 009

Prandoni-

Prince 247 516 361 213 076

Precision 217

Prima 009 264

Prinz 072

Profex 009

Profi-Tronic 037

Proline 321 072 037 012

Prosonic 037 216 370 374

Protech 037 217 009 247 349

102 264 431 337

Pye 037 556 012

Pymi 009

Quasar 247

Quelle 037 010 011 501 512

535 554 361 036 217

247 074 084

Questa 036

Radialva 109

R-Line 037

Radiola 037 556 012 323

Radiomarelli 087 516 247

Radiotone 009 037 428

Rank 070

22

Set-Up Codes - TV

Rediffusion 361

Revox 037 370

Rex 206 411 259

RFT 087 292 428 072

Roadstar 009 264 218

Robotron 087

Royal Lux 421

RTF 087

Saba 287 213 087 399 163

109 501 516 343 361

498 196 198 335

Sagem 455

Saisho 235 516 177 009 011

217 264

Salora 290 349 356 359 361

516

Sambers 213 516 102

Samsung 037 556 009 217 370

264 090 216 290 072

208

Sandra 216 217

Sansui 037

Sanyo 208 157 292 036 011

370 072 216 217 104

213 339

SBR 037 556 012

Schaub Lorenz 349

Schneider 037 012 217 303 519

394 259 323 343 247

371 218 361

SEG 217 264 009 036 102

362 037

SEI 087 102 010 516 213

294 296 206 037

Seleco 206 226 362 259 411

Sencora 009

Sentra 276 035 218

Sharp 093 157 036 294

Shorai 294

Siarem 087 102 213

Siemens 191 535 554 157 195

200 213 327 328

Sierra 037 556 012

Siesta 370

Silva 216

Silver 036 361

Singer 087 102 400

Sinudyne 177 087 235 102 213

294 296 361

Skantic 357 356

Sogera 320

Solavox 361 072

Sonitron 208 370 339

Sonoko 037 009 264 282 217

Sonolor 208 163 400

Sontec 037 370 294

Sony 010 505 011 036

Sound &

Vision 102 218 374

Soundwave 037 320 418

Standard 218 009 217 320 037

Star Lite 037

Stenway 282 218

Stern 206 259

Sunkai 294 355 321 455 218

235

Sunwood 037 009

Superla 516 216

Supertech 009 037

Supra 374 009

Sutron 009

Sydney 216 217

Tandy 218 072 217 247 276

093

Tashiko 036 043 217 216

Tatung 037 072 516 217 249

011

TEC 217 276 009 247 471

335

Technema 320

Teleavia 109 501 196 399 333

568

Telecor 037 163 218 217 259

Telefunken 109 501 498 471 399

287 074 084 101 335

262 073 343 037

Telegazi 037 163 259 218 264

Telemeister 320

Telesonic 037

Teletech 009 247 337

Teleton 217 275 206 349

Televideon 320 216

Temco 294

Tensai 104 218 037 217 294

320 009 105 374 371

377

Texet 217

Thomson 287 399 109 501 333

471 335 196 198 237

343 037 568

Thorn 193 190 238 073 192

074 084 104

Tokai 072 037 337 163

Tokyo 216 035

Tomashi 282

Toshiba 035 508 036 070 102

Towada 349 102

Trans

Continens 217

Trident 516 217

Triumph 177 516 346 556

Uher 076 037 206 320 303

374 418

Ultravox 087 102 374 216 213

037

Universum 346 105 535 473 361

200 011 512 294 036

157 070 370 492 480

247

Univox 337 087 037

Vestel 037 217

Vexa 009 037

Videologique 216 218 217

VideoSystem 037

Videotechnic 216 320

23

Set-Up Codes - VCR

Visiola 216

Vision 037 320

Vistar 276 206

Vortec 037

Voxson 087 076 037 418

Waltham 217 276 356 418 287

385 037

Watson 037 320 218 213

Watt Radio 213 102 216

Wega 213 036 087 037

Weltblick 037 320

White Wes-

tinghouse 320 216 037 337

Yamashi 282 455 218 037

Yoko 217 037 218 264 009

431

Yorx 218

Zanussi 206 217

VCRs

Aiwa 307 000 041 209 352

037

Akai 106 315 053 041 020

Akiba 072

Akura 072 041

Alba 278 072 333 334 209

352 192 020 295

Allorgan 240

Allstar 322

Ambassador 020

Amstrad 000 325 332

Anitech 072 322

ASA 037 081

Asuka 072 037 081 000

Audiosonic 278

Baird 106 278 104 107 041

000

Bang &

Olufsen 499

Basic Line 278 209 020 072

Bestar 278 020

Black Panther

Line 278

Blaupunkt 226 154 227 162 081

006 195 403

Bondstec 020

Bosch 154

Brandt 041 187 206 320 493

Brionvega 344

Bush 072 278 315 333 334

209 352

Carena 209 081

Carrefour 045

Catron 020

CGE 041 000

Cimline 072 209

Clatronic 020

Combitech 352

Condor 020 278

Crown 278 072 020 322

Daewoo 278 020 045

Dansai 072

Daytron 278

Decca 000 041 081 008 067

DeGraaf 042 166 081 104 048

Dual 041 081

Dumont 000 081 104 105

ESC 278 240

Elcatech 072

Elin 240

Elta 072

Emerson 072

Etzuko 072

Europhon 020

Ferguson 107 041 320 053 493

Fidelity 000 072

Finlandia 104 081 042 166 000

048

Finlux 000 081 104 042 105

First Line 072 209 043 037 045

042

Fisher 047 104 046

Flint 209

Frontech 020 322

Fujitsu 000

Funai 000

Galaxy 000

GBC 020

GEC 081

General 020

Goldhand 072

Goldstar 037 000

Goodmans 000 072 240 278 037

020 081 209

Graetz 041 104 240 344

Granada 104 046 048 081 006

240 037 226 042 000

Grandin 072 037 020 000 278

Grundig 007 195 081 347 226

006 403 320

Hanseatic 037 209

Hantor 020

HCM 072

Hinari 004 072 208 209 352

041 322

Hisawa 209 352

Hitachi 042 105 166 041 000

240 081 004 104

Hypson 072 209 278

Impego 020

Imperial 000 240

Ingersol 004

Inno Hit 020 240 278 322

Interbuy 037 072

Interfunk 081 104

Intervision 000 278 037

Irradio 072 037

ITT 106 041 046 344 384

104 240

ITV 278 037

JVC 041 067 008 206 384

Kaisui 072

Kendo 106 209 315 053

Kenwood 041

24

Set-Up Codes - VCR

Korpel 072

Kuba 047

Leyco 072

Loewe Opta 081 006 037 105 004

Logik 004 240 072 106 209

Luxor 106 046 043 072 104

M Electronic 000 037

Manesth 072 045 081 209

Marantz 081 006 295 209

Matsui 209 004 192 295 037

208 240 352 332

Mediator 081

Memorex 104 000 046 037 048

047

Memphis 072

Metz 195 347 081 162 227

226 006

Migros 000

Minerva 195

Mitsubishi 043 067 081

Multitech 000 072 020 104

Murphy 000

National 226 162

NEC 041 067 040

Neckermann 041 208 006 081 344

Nesco 072

Nikkai 020 072 278

Nokia 104 106 041 278 046

344 240 048 042 081

Nordmende 041 384 320 187 494

Oceanic 000 048 106 081 104

041 046

Okano 315 209 072 322

Orion 209 004 208 352 295

333 334

Orson 000

Osaki 000 037 072

Otto Versand 081

Palladium 072 315 037 041 006

209

Panasonic 226 227 162 225

Pathe Cinema 004 043

Pathe

Marconi 041

Perdio 000

Philco 072

Philips 081 006 403

Phonola 081

Pioneer 067 081 042

Portland 020 278

Prinz 000

Profex 322

Profi-Tronic 081 240

Proline 000

Prosonic 209

Provision 278

Pye 081

Quelle 006 208 081 344

Radialva 037 072 081 048

Radiola 081

Rex 041 384

RFT 020 403 072

Roadstar 240 072 037 278

Royal 322 072

Saba 041 187 206 320 384

494

Saisho 004 209 208 192

Salora 046 043 106 104

Samsung 240 432

Samurai 020

Sansui 041 067 106

Sanwa 004

Sanyo 104 046 047

Saville 352 278 240

SBR 081

Schaub

Lorenz 041 344 106 000 104

Schneider 072 000 037 081 042

SEG 072 240 322 278

SEI-Sinudyne 004 081

Seleco 041 008 384 020 037

Sentron 072

Sentra 020 072

Sharp 048

Shintom 072 104

Shivaki 037

Shorai 004

Siemens 195 006 037 104 007

081

Silva 037

Sinudyne 004 081

Solovox 020

Sonitron 047

Sonoko 278

Sonolor 048

Sontec 037

Sony 033 034 032 106

Standard 278

Starlite 037 104

Sunkai 209 295

Sunstar 000

Suntronic 000

Sunwood 072

Supra 037 240

Symphonic 000 072

Taisho 004 209

Tashiko 000 048 240 081 037

Tatung 000 041 081 053 048

TEC 020

Teleavia 041 187

Telefunken 187 041 320 384 493

494

Teletech 322 072

Tenosal 072

Tensai 000 322 037 072 004

Thomson 041 384 320 206 493

494

Thorn 041 104 037

Tokai 072 037

Toshiba 045 041 384 043 081

403

Towada 322

Towika 072

Triumph 208

TVA 020

Uher 037 240 344

25

Set-Up Codes - SAT

Ultravox 344

Unitech 240

United Quick

Star 278

Universum 000 325 081 240 037

106 195 006

Victor 008 067

Watson 081

Weltblick 037

White Wes-

tinghouse 344

Yamashi 072 278

Yokan 072

Yoko 037 072 020 240

Satellite Receivers

AGS 668

Akai 515 200

Alba 421 515 455 254 362

519 613 713

Aldes 288 362 519 520

Allantide 333

Allsat 067 200 364 183

Allsonic 288 369

Alltech 586

Alpha 668

Altai 396

Amitronica 713

Ampere 368

Amstrad 080 461 252 345 243

338

Ankaro 288 217 369 220 519

713

Anttron 421 183 613

Apollo 421

Arcon 368 217 373

Armstrong 243

ASA 397

ASAT 373 200

AST 351 321

Astacom 668

Aston 458

Astra 108 373 530 539 518

344 513 243

Astro 173 358 520 613 369

Athena 668

Audioton 364 613

Aura 539

Axiel 668

Axis 530 369 366

Barcom 217

Best 217 369

Blaupunkt 173

Boca 243 589 513

Brain Wave 332 692

Broadcast 346

Broco 530 713

BT Satellite 515 668 710

Bush 254 067 328 183 362

Cambridge 344 515

Channel

Master 362

Citycom 394

Clatronic 332

Clemens

Kamphus 502 333

CNT 520

Colombia 668

Columbus 297

Commander 220

Commlink 288

Comtec 288

Condor 369

Connexions 458 396 369

Conrad 589

Contec 394 589 366

Cosat 592

Crown 243 518

Daewoo 373

Dansat 067 183

DDC 362

Dew 366 373

Diamond 586

Discovery 668

Diskxpress 217

Distrisat 200

Ditristrad 592

DNR 692

DNT 200 458 396

Dual 373

Dune 369

Echostar 396 668

EIF 417

Einhell 333 243 421 288 252

513 518 713 501 794

Elekta 520

Elta 364 421 200 369

Emanon 421

Emme Esse 369 502 328

EP Sat 455

Eurieult 417

Eurodec 526

Europa 220 589

Eurosat 243 586

Eurosky 243 369

Eurostar 539

Exator 421 515 613

Extra Sat 519

Fenner 668

Ferguson 067 183 455 336 328

711

Fidelity 252 461

Finlandia 455 108

Finlux 455 344 108 414

Fracarro 421

France

Satellite 297

Freecom 335 421

FTE 368 331 589

Fuba 297 217 369 396 421

417 173 414 172 573

G-Sat 183 333

Galaxi 217

26

Set-Up Codes - SAT

Galaxis 366 288 364 530 592

369 656

Galaxisat 321

GMI 243

Goldstar 335

Goodmans 455

Granada 108

Grundig 173 328 571 750

Hanseatic 605

Hantor 421 332

Hanuri 520

Harting &

Helling 333 502

Heliocom 368

Hinari 362 183 421

Hirschmann 287 333 397 173 573

495 442 502

Hisawa 332

Hitachi 328 455

Houston 592 220 668

Huth 346 332 364 366 288

220 589 502 243

Hypson 417

Imperial 254

Intertronic 243

Intervision 592

ITT/Nokia 328 108 573 172 455

397

Johansson 332 364

JVC 515 571

Kathrein 331 358 173 394 442

504 480 200 622 092

333 658 713

Key West 794

Kolon 421

Kosmos 331 442 335 502

KR 613

Kreiselmeyer 173

Kyostar 421 613

Lasat 513 520 369

Lenco 335 220 373 421 713

692

Lennox 592

Lenson 501

Lexus 200

Leyco 515

Lifesat 605 369

Lion 333

Loewe 243

Lorenzen 220 692 794

Lorraine 335

Lupus 369

Luxor 172 108 345 573

Manhattan 455 592 328 520

Marantz 200

Mascom 442

Maspro 092 336 328 495 750

Matsui 344 571 710

MB 605

Mediamarkt 243

Mediasat 530 501 292

Mega 200

Metronic 519 421 417 243 613

Micro

Technology 333 539

Minerva 571

Mitsubishi 455

Mitsumi 513

Morgans 243 200 513 794 713

Multistar 331

Muratto 335 321

Mysat 713

M & B 539

Navex 332

Network 183

Neuhaus 530 501 220 589 692

592 656 713

Neusat 692 713

Nikko 243 713

Nokia 328 108 573 172 455

397

Nordmende 362 455 520 421

Novis 332

NTC 502

Oceanic 586 333

Octagon 373 421 220 366 613

Okano 243 502 331

Optex 394 592 417 792

Orbit 351 373 333

Orbitech 501 589 541 421

Origo 497

Osat 345

Oxford 344 515 668

Pace 328 067 183 336 455

791 795

Pacific 586

Palcom 297 362

Palladium 243 571

Palsat 501

Panasonic 455 328

Panda 455 067 108

Paristad 417

Patriot 515 668

Philips 200 220 183 292 455

328 667 750 710 613

Phoenix 366 183

Phonotrend 288 592 502 656

PK Sat 333

Polytron 394 396

Predki 332

Preisner 243 513 589

Premier 592

Profile 668

Prosat 254 288 362

Protek 586 333

Proton 333

Provision 520

Quadral 362 519 288 369 589

668

Quelle 252

Radiola 200

Radix 396 458

Rainbow 613

Redpoint 530

Red Star 369

RFT 541 288 220 200

Roadstar 713

Saba 254 183 520 328 336

Sabre 455

Sakura 366

Salora 108 172

Samsung 287 421

SAT 351 321 461 501 362

Satcom 346 605

Satec 183 328

Satford 346

Satmaster 346

Satpartner 332 502 421 335 520

613

Sat Team 368

Schäcke 613

Schneider 667

Schwaiger 394 183 605 504 589

Sedea

Electronique 421

Seemann 396 243 530 515

SEG 421 369 539 332 605

518 519

Seleco 592

Siemens 173

Silva 335

Skantin 713

Skardin 530

SKR 713

Skymaster 288 519 605

Skymax 200 333 539

Skytwin 519

Skyvision 364

SL 692

Sony 704 455

Starion 539

Starring 332

Strong 421 613 369 520

STVI 417

Sumida 243

Sunny Sound 369

Sunsat 713 530

Sunstar 513 243 369 794

Tagra 364

Tantec 297 328 336 455

Techniland 346 592

Technisat 262 501 541 458 518

Teco 373 243 513

Telasat 605

Teleciel 613

Telefunken 421 328 710

Teleka 243 442 613 396 750

Telemaster 520

Telesat 605

Telestar 501

Televes 455 501 328

Telewire 592 656

Tensai 373

Thomson 455

Thorens 586

Thorn 328 455

Tioko 394

Tokai 200

Tonna 346 455 592 668

Toshiba 455

Trendline 513

Trend Plain 513

Triad 351 335 321 333

Triasat 414

Tristar 373

Uniden 194 792

Unisat 366 243

Unitor 217 332

Universum 173 571 397

Variosat 173

Vector 333 518

Ventana 200

Visiosat 351

Viva 220

Vortec 287 421

V-Tech 351 321

Wela 589 713

Wewa 333 455

Winersat 332

Wisi 173 321 396 589 455

351

Woorisat 520

World 332

Xrypton 518

Zaunkönig 692

Zehnder 321 331 520 504 518

369

Zodiac 613

Zwergnase 794

Cable Converters

BT Cable 105

Cabletime 271

Decsat Canal+ 423

Filmnet Cablecrypt 443

Grundig 529

Jerrold 003 276

M-Net 443

Pioneer 144

Salora 382

Samsung 144

Scientific Atlanta 008 277

Tele+1 443

Telepiu 443

United Cable 003

Visiopass 451

Westminster Cable 105

27

Set-Up Codes - CBL

UK

DD-0798

ONE FOR ALL and the ONE FOR ALL “Big Easy” are trademarks of Universal Electronics

Inc.

Copyright 1995, 1996, 1997 by Universal Electronics Inc. All rights are reserved. No part of

this publication may be reproduced, transmitted, transcribed, stored in any retrieval

system, or translated to any language or computer language, in any form or by any

means, electronic, mechanical, magnetic, optical, manual, or otherwise, without the prior

written permission of Universal Electronics Inc.

URC-2585

700620

Guarantee

UNIVERSAL ELECTRONICS INC./ONE FOR ALL warrants to the original purchaser that this

product will be free from defects in materials and workmanship under normal use for a period

of ninety (90) days from the date of the original purchase. Product will be replaced free of

charge if it has been proven to be defective within the 90-day period when said product is

returned at customer expense within the warranty period. THIS WARRANTY DOES NOT

COVER ANY EXPENSES INCURRED IN THE REMOVAL AND REINSTALLATION OF THIS

PRODUCT.

This warranty does not cover damage or failures caused by products or services not supplied

by ONE FOR ALL, or which result from accident, misuse, abuse, neglect, mishandling,

misapplication, faulty installation, set-up adjustment, improper maintenance, alteration,

maladjustment of consumer controls, modifications, commercial use, fire, water, lightning or

other acts of God. This warranty does not cover cartons, carrying cases, batteries, broken or

marred cabinets, or any other items used in connection with the product.

There are no express warranties except as listed above. ONE FOR ALL SHALL NOT BE LIABLE

FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS

PRODUCT OR ARISING OUT OF ANY BREACH OF WARRANTY. ALL EXPRESS AND

IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND

FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE WARRANTY PERIOD SET

FORTH ABOVE. Some countries do not allow the exclusion or limitation of incidental or

consequential damages, or limitation on how long an implied warranty lasts, so the above

exclusions or limitations may not apply to you. This warranty gives you specific legal rights

and you may also have other rights which vary from country to country.

To obtain warranty service during the warranty period, please carefully pack the product and

send it prepaid and adequately insured to the address below, together with your purchase

receipt or other proof of the date of original purchase.

In the UK: In Ireland: In Australia

ONE FOR ALL Ltd. Sherlane Agencies Ltd./OFA KENMARK INDUSTRIAL (A)

PO Box 197 Rockford Works CO.PTY.LTD.

Yateley, Hampshire Deansgrange Rd. 106 Mitchell Street

GU46 6ZR Blackrock, County Dublin Maidstone vic 3012

IMPORTANT:

IF THE UNIT IS RETURNED WITHIN THE WARRANTY PERIOD, YOU MUST

INCLUDE YOUR PURCHASE RECEIPT so that we may establish your eligibility for

service and can replace your unit without cost. It would be helpful if you included a note

detailing the problem. IF THE UNIT IS RETURNED FOR SERVICE OUTSIDE THE

WARRANTY PERIOD, please include a cheque to cover the cost of replacement, handling and

return postage. (Prices may differ per model. Please contact ONE FOR ALL customer service

in your country for exact amount.)

NOTHING IN THIS GUARANTEE AFFECTS YOUR STATUTORY RIGHTS.

Printed on Recycled Paper
