ADVANCE RFID Lock with
DirectKey™ Module
Onity ADVANCE RFID locks feature a two-piece
modular design and an array of attractive options
that allow you to seamlessly blend your guest room
door locks into any hotel decor. ADVANCE RFID
locks with DirectKey module enable a proven
mobile key solution. With a hotel-provided
smartphone app, guests can securely download
their assigned key for easy access to their
assigned room and other access-controlled areas.
Features
• On-board DirectKey module provides secure
wireless communication of credentials from a user’s
smartphone to a locking device via Bluetooth® Smart
communications
• Reading technology: contactless RFID
(ISO14443A, 14443B part 4)
• Multiple opening devices available: keycards,
wristbands, keychains, etc.
• Average battery life: approximately 2 years
• Non-volatile memory: records last 500 openings
including date, time and card used
• Programmable to customer needs (meeting rooms,
offices, housekeeping, etc.)
• LEDs indicate lock status including a low battery
warning
• Corrosion-treated for normal atmospheric conditions
• NXP CRYPTO1 or AES-128 card encryption
Certifications
• FCC & IC
• CE Certificate of Conformity under EN14846 (with
euro 5470H and 5480H mortises)
• Directive 2014/30/EU (electromagnetic
compatibility)
• Directive 1999/5/EC (R&TTE)
• DIN 18273 Certification (under testing)
• BHMA 156.25 & BHMA 156.13
• UL10C (3 hours)
Specifications
• Temperature Tolerance Ranges:
Alkaline batteries: 0º F / 130º F (-18º C / 55º C)
For non-fire rated doors only, lithium batteries:
-40º F / 167º F (-40º C / 75º C)
• Humidity: up to 95% non-condensing
• Power supply: 4 alkaline 1.5-volt AA batteries
• Not for outside use
866.86.ONITY
www.onity.com
© Onity 2016. All rights reserved. Data subject to change without notice.
United States (FCC)
This device complies with part 15 of the FCC rules. Operation
is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
Canada (IC)
This device complies with Industry Canada's licence-exempt
RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of the device.
Cet équipement est conforme á Ia (aux) norme(s)
canadienne(s) d'exemption de licence RSS Industry Canada.
Son opération est sujette aux deux conditions suivantes: (1)
cet équipement ne provoquera aucune interference el (2) cet
équipement doit tolérer toute in interférence pouvant
provoquer une opération indésirable de I'equipement.
European Union (CEl)
This Class B digital apparatus conforms to the requirements
of the foIlowing EU directives:
1. R&TTE Directive (1999/5/EC)
2. WEEE Directive (2012/19/EC)
ADVANCE RFID Lock with
DirectKey™ Module
