Onity HT34RFIDBT HT34 RFID BTLE User Manual HT RFID lock data sheet 11 15
Onity, Inc. HT34 RFID BTLE HT RFID lock data sheet 11 15
Onity >
user manual
866.86.ONITY
www.onity.com
© Onity 2016. All rights reserved. Data subject to change without notice.
The Onity HT RFID lock with DirectKey module
enables a proven mobile key solution out of the box.
High Level of Security
The on-board DirectKey module employs 128-bit AES
encryption technology to complement the security of
existing locks with an added layer of protection.
The Best Guest Experience
With a hotel-provided smartphone app, guests can
securely download their assigned key for easy access
to their assigned room and other access-controlled
areas. Guests can unlock doors easily with the press
of a button on the hotel app.
HT RFID Lock with
DirectKey™ Module
Features
• On-board DirectKey module provides secure wireless
communication of credentials from a user’s
smartphone to a locking device via Bluetooth® Smart
communications
• Reading technology: contactless RFID (ISO14443A,
14443B part 4, NFC)
• Multiple opening devices available: keycards,
wristbands, keychains, etc.
• Average battery life: approximately 2 years
• Non-volatile memory records the last 500 lock
openings – including date, time and card used
• Programmable to customer needs (meeting rooms,
offices, housekeeping, etc.)
• LEDs to indicate lock status including a low battery
warning
• MIFARE® compatibility - no need for proprietary
keycards
• Corrosion-treated for normal atmospheric conditions
• Special weather kits for outdoors
• NXP CRYPTO1 or AES-128 card encryption
Certifications
• FCC & IC
• CE Certificate of Conformity under EN14846 (with
euro 5470H and 5480H mortises)
• Directive 2014/30/EU (electromagnetic compatibility)
• Directive 1999/5/EC (R&TTE)
• DIN 18273 Certification (under testing)
• BHMA 156.25 & BHMA 156.13
• UL10C (3 hours)
Specifications
• Size: 11.2” / 2.8” / 1.9” (285mm / 72mm / 50mm)
• Temperature Tolerance Ranges:
Alkaline batteries: 0º F / 130º F (-18º C / 55º C)
For non-fire rated doors only, lithium batteries:
-40º F / 167º F (-40º C / 75º C)
• Humidity: up to 95% non-condensing
• Power supply: 4 alkaline 1.5-volt AA batteries
866.86.ONITY
www.onity.com
© Onity 2016. All rights reserved. Data subject to change without notice.
HT RFID Lock with
DirectKey™ Module
Simple Upgrade Provides Security & Value
The HT RFID electronic lock upgrade provides great
value by decreasing installation time, maintaining the
UL fire rating for all Onity prepared doors and reducing
time spent cleaning the read heads. The locks are also
compatible with current Onity front desk systems:
HT22, HT24 and OnPoint.
Current HT customers can easily upgrade to the HT
RFID locking system with little interruption to the
property’s daily operations. With existing doors already
prepared for the HT lock, installing the upgrade is
simple – no drilling or cutting of doors, less disruption
to the guests and fewer “out of service” rooms.
There are several ways to upgrade your current HT
lock to RFID, including:
1. Replacing the entire lock and mortise
2. Switching the reader and cover to the new
system
3. Changing the front half of the lock
Onity can help you determine the best upgrade plan
for you by completing a no-cost site survey of your
property. Set up an appointment today.
HT RFID Upgrade Kit
RFID Physical Key Credentials
866.86.ONITY
www.onity.com
© Onity 2016. All rights reserved. Data subject to change without notice.
United States (FCC)
This device complies with part 15 of the FCC rules. Operation
is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
Canada (IC)
This device complies with Industry Canada's licence-exempt
RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
Cet équipement est conforme á Ia (aux) norme(s)
canadienne(s) d'exemption de licence RSS Industry Canada.
Son opération est sujette aux deux conditions suivantes: (1)
cet équipement ne provoquera aucune interference el (2) cet
équipement doit tolérer toute in interférence pouvant
provoquer une opération indésirable de I'equipement.
European Union (CEl)
This Class B digital apparatus conforms to the requirements
of the foIlowing EU directives:
1. R&TTE Directive (1999/5/EC)
2. WEEE Directive (2012/19/EC)
HT RFID Lock with
DirectKey™ Module
