Onkyo Home Entertainment ABXN300 Wireless Music System User Manual ABX N300 En
Onkyo Corporation Wireless Music System ABX N300 En
Users Manual
E
n
Wireless Music System
ABX-N300
Instruction Manual
Thank you for purchasing an Onkyo Wireless Music System.
Please read this manual thoroughly before making any
connections and plugging it in.
Following the instructions in this manual will enable you to obtain
optimum performance and listening enjoyment from your new
Wireless Music System.
Please retain this manual for future reference.
Getting Started............................En-2
Connections.............................. En-13
Basic Operation....................... En-14
Playing Your iPod/iPhone ... En-16
Internet Radio Network
Server ........................................... En-19
Setting the Clock..................... En-24
Using the Timers..................... En-25
Network Setup.......................... En-27
About Internet Radio and
Media Servers........................... En-29
Miscellaneous
(Reset Procedure) ........................ En-30
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-2
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radia-
tors, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are pro-
vided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience recepta-
cles, and the point where they exit from the appara-
tus.
11. Only use attachments/accessories specified by the
manufacturer.
12.
Use only with the cart, stand,
tripod, bracket, or table spec-
ified by the manufacturer, or
sold with the apparatus.
When a cart is used, use cau-
tion when moving the cart/
apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. Damage Requiring Service
Unplug the apparatus from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power-supply cord or plug is damaged,
B. If liquid has been spilled, or objects have fallen
into the apparatus,
C. If the apparatus has been exposed to rain or
water,
D. If the apparatus does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the apparatus to its normal operation,
E. If the apparatus has been dropped or damaged in
any way, and
F. When the apparatus exhibits a distinct change in
performance this indicates a need for service.
16. Object and Liquid Entry
Never push objects of any kind into the apparatus
through openings as they may touch dangerous volt-
age points or short-out parts that could result in a
fire or electric shock.
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases shall be placed on the apparatus.
Don’t put candles or other burning objects on top of
this unit.
17. Batteries
Always consider the environmental issues and fol-
low local regulations when disposing of batteries.
18. If you install the apparatus in a built-in installation,
such as a bookcase or rack, ensure that there is ade-
quate ventilation.
Leave 20 cm (8") of free space at the top and sides
and 10 cm (4") at the rear. The rear edge of the shelf
or board above the apparatus shall be set 10 cm (4")
away from the rear panel or wall, creating a flue-
like gap for warm air to escape.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
AVIS
PORTABLE CART WARNING
S3125A
#$:0A'PDQQM2CIG6JWTUFC[5GRVGODGT2/
En-3
Precautions
1. Recording Copyright—Unless it’s for personal use
only, recording copyrighted material is illegal with-
out the permission of the copyright holder.
2. Care
—Occasionally you should dust the unit all over
with a soft cloth. For stubborn stains, use a soft cloth
dampened with a weak solution of mild detergent and
water. Dry the unit immediately afterwards with a
clean cloth. Don’t use abrasive cloths, thinners, alco-
hol, or other chemical solvents, because they may
damage the finish or remove the panel lettering.
3. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING
SECTION CAREFULLY.
AC outlet voltages vary from country to country.
Make sure that the voltage in your area meets the
voltage requirements printed on the AC adapter.
The AC adapter is used to disconnect this unit from
the AC power source. Make sure that the adapter is
readily operable (easily accessible) at all times.
If you do not intend to use the unit for an extended
period, remove the AC adapter from the AC outlet.
4. Batteries and Heat Exposure
Warning
Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat as sunshine, fire or the like.
5. Never Touch this Unit with Wet Hands
—Never
handle this unit or its power cord while your hands
are wet or damp. If water or any other liquid gets
inside this unit, have it checked by your Onkyo
dealer.
6. Handling Notes
• If you need to transport this unit, use the original
packaging to pack it how it was when you origi-
nally bought it.
• Do not leave rubber or plastic items on this unit
for a long time, because they may leave marks on
the case.
• This unit’s top and rear panels may get warm
after prolonged use. This is normal.
• If you do not use this unit for a long time, it may
not work properly the next time you turn it on, so
be sure to use it occasionally.
For U.S. models
FCC Statement
Federal Communication Commission Interference
Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution:
FCC WARNING
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment. This device complies
with Part 15 of FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause
interference, and (2) this device must accept any
interference, including interference that may cause
undesired operation of this device.
For product available in the USA/Canada market, only
channel 1~11 can be operated. Selection of other
channels is not possible. This device and its antenna(s)
must not be colocated or operation in conjunction with
any other antenna or transmitter.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment and
meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65. This equipment
should be installed and operated keeping the radiator at
least 20 cm or more away from person’s body (excluding
extremities: hands, wrists, feet and ankles).
#$:0A'PDQQM2CIG6JWTUFC[5GRVGODGT2/
En-4
For Canadian Models
IC Statement
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Industry Canada licence-
exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause
interference, and (2) this device must accept any
interference, including interference that may cause
undesired operation of the device.
For product available in the USA/Canada market, only
channel 1~11 can be operated. Selection of other
channels is not possible. This device and its antenna(s)
must not be colocated or operation in conjunction with
any other antenna or transmitter.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure
limits set forth for an uncontrolled environment and
meets RSS-102 of the IC radio frequency (RF) Exposure
rules. This equipment should be installed and operated
keeping the radiator at least 20cm or more away from
person’s body (excluding extremities: hands, wrists, feet
and ankles).
NOTE:
THIS CLASS B DIGITAL APPARATUS COMPLIES
WITH CANADIAN ICES-003.
Modèle pour les Canadien
IC Statement
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de
licence.
L’exploitation est autorisée aux deux conditions
suivantes :
(1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
Cet équipement est conforme aux limites d’exposition
aux rayonnements énoncées pour un environnement non
contrôlé et respecte les règles d’exposition aux
fréquences radioélectriques (RF) CNR-102 de l’IC. Cet
équipement doit être installé et utilisé en gardant une
distance de 20 cm ou plus entre le dispositif rayonnant et
le corps (à l’exception des extrémités : mains, poignets,
pieds et chevilles).
REMARQUE:
CET APPAREIL NUMÉRIQUE DE LA CLASSE B
EST CONFORME À LA NORME NMB-003 DU
CANADA.
For European Models
Hereby, ONKYO SOUND & VISION CORPORATION,
declares that this ABX-N300 is in compliance with the
essential requirements and other relevant provisions of
Directive 1999/5/EC.
С настоящето, ONKYO SOUND & VISION
CORPORATION, декларира, че ABX-N300 е в
съответствие със съществените изисквания и
другитеприложими разпоредби на Директива
1999/5/EC.
ONKYO SOUND & VISION CORPORATION tímto
prohlašuje, že ABX-N300 splňuje základní požadavky a
všechna příslušná ustanoveni Směrnice 1999/5/ES.
Undertegnede ONKYO SOUND & VISION
CORPORATION erklærer herved, at følgende udstyr
ABX-N300 overholder de væsentlige krav og øvrige
relevante krav i direktiv 1999/5/EF.
Hiermit erklärt ONKYO SOUND & VISION
CORPORATION, dass sich das Gerät ABX-N300 in
Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen einschlägigen
Bestimmungen der Richtlinie 1999/5/EG befindet.
Käesolevaga kinnitab ONKYO SOUND &
VISIONCORPORATION seadme ABX-N300 vastavust
direktiivi 1999/5/EÜ põhinõuetele ja nimetatud
direktiivist tulenevatele teistele asjakohastele sätetele.
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Ο ΚΑΤΑΣΚΕΥΑΣΤΗΣ ONKYO
SOUND & VISION CORPORATION ΔΗΛΩΝΕΙ ΟΤΙ
ABX-N300 ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ
ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ
Por la presente, ONKYO SOUND & VISION
CORPORATION, declara que este ABX-N300 cumple
con los requisitos esenciales y otras exigencias relevantes
de la Directiva 1999/5/EC.
Par la présente, ONKYO SOUND & VISION
CORPORATION déclare que l’appareil ABX-N300 est
conforme aux exigences essentielles et aux autres
dispositions pertinentes de la directive 1999/5/CE.
Con la presente ONKYO SOUND & VISION
CORPORATION dichiara che questo ABX-N300 è
conforme ai requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE.
Ar šo ONKYO SOUND & VISION CORPORATION
deklarē, ka ABX-N300 atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītajiem
noteikumiem.
Šiuo ONKYO SOUND & VISION CORPORATION
deklaruoja, kad šis ABX-N300 atitinka esminius
reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
A ONKYO SOUND & VISION CORPORATION
ezzennel kijelenti, hogy a ABX-N300 típusú beren-dezés
teljesíti az alapvető követelményeket és más 1999/5/EK
irányelvben meghatározott vonatkozó rendelkezéseket.
Hierbij verklaart ONKYO SOUND & VISION
CORPORATION dat het toestel l ABX-N300 in
overeenstemming is met de essentiële eisen en de andere
relevante bepalin-gen van richtlijn 1999/5/EG.
#$:0A'PDQQM2CIG6JWTUFC[5GRVGODGT2/
En-5
Niniejszym ONKYO SOUND & VISION
CORPORATION deklaruje że ABX-N300 jest zgodny z
zasadniczymi wymaganiami i innymi właściwymi
postanowieniami Dyrektywy 1999/5/EC.
Eu, ONKYO SOUND & VISION CORPORATION,
declaro que o ABX-N300 cumpre os requisitos
essenciais e outras provisões relevantes da Directiva
1999/5/EC.
Prin prezenta, ONKYO SOUND & VISION
CORPORATION, declară că aparatul ABX-N300 este în
conformitate cu cerinţele esenţiale şi cu alte prevederi
pertinente ale Directivei 1999/5/CE.
ONKYO SOUND & VISION CORPORATION týmto
vyhlasuje, že ABX-N300 a spĺňa základné požiadavky a
všetky príslušné ustanovenia Smernice 1999/5/ES.
ONKYO SOUND & VISION CORPORATION izjavlja,
da je ta ABX-N300 v skladu z bistvenimi zahtevami in
drugimi relevantnimi določili direktive 1999/5/ES.
ONKYO SOUND & VISION CORPORATION
vakuuttaa täten että ABX-N300 tyyppinen laite on
direktiivin 1999/5/EY oleellisten vaatimusten ja sitä
koskevien direktiivin muiden ehtojen mukainen.
Härmed förklarar ONKYO SOUND & VISION
CORPORATION att denna ABX-N300 följer de
väsentliga kraven och andra relevanta stadgar i Direktiv
1999/5/EC.
Hér með lýsir ONKYO SOUND & VISION
CORPORATION því yfir að varan ABX-N300 er í
samræmi við grunnkröfur og aðrar kröfur sem gerðar
eru í tilskipun 1999/5/EC.
ONKYO SOUND & VISION CORPORATION
erklærer herved at
denne ABX-N300 er i overensstemmelse med vesentlige
krav og andre relevante bestemmelser i direktiv 1999/5/
EC.
Declaration of Conformity
We, ONKYO EUROPE
ELECTRONICS GmbH
LIEGNITZERSTRASSE 6,
82194 GROEBENZELL,
GERMANY
GROEBENZELL, GERMANY
ONKYO EUROPE ELECTRONICS GmbH
K. MIYAGI
declare in own responsibility, that the ONKYO product
described in this instruction manual is in compliance with the
corresponding technical standards such as EN60950-1,
EN55022, EN55024 and EN61000-3-2, -3-3.
#$:0A'PDQQM2CIG6JWTUFC[5GRVGODGT2/
En-6
Contents
Important Safety Instructions .......................... 2
Precautions........................................................ 3
Features ............................................................. 7
Supplied Accessories....................................... 7
Using the Remote Controller ........................... 8
Replacing the Battery ....................................... 8
About Your iPod/iPhone................................... 9
iPod/iPhone Models that can be Connected
... 9
Caution .......................................................... 9
Linked Operation with Your iPod/iPhone....... 9
Getting to Know the ABX-N300...................... 10
Top/Front Panel........................................... 10
Rear Panel................................................... 11
Remote Controller (RC-806S) ..................... 12
Connections .................................................... 13
Basic Operation............................................... 14
Turning On the ABX-N300........................... 14
Selecting the Input Source .......................... 14
Adjusting the Volume................................... 14
Muting the ABX-N300
(remote controller only).......................... 14
Changing the Downlight Brightness
(remote controller only).......................... 14
Adjusting the Bass and Treble..................... 14
Using Super Bass
(remote controller only).......................... 15
Playing Your iPod/iPhone .............................. 16
Navigating the iPod/iPhone Menus ............. 17
Select playlists
(remote controller only).......................... 17
Random Playback
(remote controller only).......................... 17
Repeat Playback
(remote controller only).......................... 17
Displaying Song Information
(remote controller only).......................... 17
Using the AirPlay......................................... 17
Listening to Internet Radio............................. 19
Receiving a broadcast ................................. 19
Storing a station (Preset)............................. 20
Listening to a preset station You must first store
a broadcast station. ............................... 21
Playing Music Files from a Network Server or
Computer.................................................... 22
Setting the Clock
(by remote controller only) ....................... 24
Using the Timers
(by remote controller only) ....................... 25
About the Timers ......................................... 25
Programming the Timers............................. 25
Turning Timers On and Off.......................... 26
Using the Snooze Function ......................... 26
Using the Sleep Timer .................................26
Network Setup .................................................27
Connecting to the Network...........................27
Network Requirements ................................27
Connecting via a wired LAN.........................27
Connecting via wireless LAN .......................28
To access the Web Setup screen................28
About Internet Radio and Media Servers ......29
Other Settings (Reset Procedure)..................30
Troubleshooting ..............................................30
Power...........................................................30
Audio............................................................30
iPod/iPhone..................................................31
Remote Controller........................................31
External Components ..................................31
Timers ..........................................................31
Clock............................................................31
Specifications ..................................................32
#$:0A'PDQQM2CIG6JWTUFC[5GRVGODGT2/
En-7
Features
❏iPod/iPhone digital connection
❏Control your iPod/iPhone * with the remote
controller
❏Network capabilirty
• Internet radio
❏AirPlay *
❏Bass and treble tone controls
❏Super Bass (S.Bass) function for deeper bass sounds
❏Line input for external audio source
❏Downlight with adjustable dimmer
❏iPod/iPhone charging capability
❏2 programmable timers
❏Sleep timer
❏Snooze function
Compatible iPod/iPhone models
Made for:
iPod touch (1st, 2nd, 3rd and 4th generation),
iPod classic, iPod nano (2nd, 3rd, 4th, 5th and
6th generation), iPhone 4, iPhone 3GS, iPhone 3G,
iPhone
* AirPlay, the AirPlay logo, iPad, iPhone, iPod, iPod classic,
iPod nano, iPod shuffle, and iPod touch are trademarks of Apple
Inc., registered in the U.S. and other countries.
“Made for iPod” and “Made for iPhone” mean that an electronic
accessory has been designed to connect specifically to iPod or
iPhone, respectively, and has been certified by the developer to
meet Apple performance standards.
Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards.
Please note that the use of this accessory with iPod or iPhone
may affect wireless performance.
Supplied Accessories
Make sure you have the following accessories:
Note:
• The AC adapter supplied with the ABX-N300 is
designed exclusively for use with the ABX-N300. Do
not use it with any another device. Likewise, do not
use any other AC adapter with the ABX-N300. Doing
so may damage the ABX-N300.
• In catalogs and on packaging, the letter at the end of
the product name indicates the color. Specifications
.and operation are the same regardless of color.
Remote controller (RC-806S) and battery (CR2025)
AC adapter (DC output 16V 3A)
(Adapter varies from country to country.)
#$:0A'PA61%HO2CIG6JWTUFC[5GRVGODGT2/
En-8
Using the Remote
Controller
Remove the plastic film before using the remote controller.
When using the remote controller, point it toward the
ABX-N300’s remote control sensor, as shown below.
Replacing the Battery
Use only a battery of the same type (CR2025).
1While sliding the stopper to the side, pull
out the battery holder.
2Insert a lithium button battery in the battery
holder, and then replace the holder.
Notes:
• If the remote controller doesn’t work reliably, try
replacing the battery.
• If you intend not to use the remote controller for a long
time, remove the battery to prevent damage from
leakage or corrosion.
• Expired batteries should be removed as soon as
possible to prevent damage from leakage or corrosion.
ABX-N300
30°
30°
Remote control sensor
Approx. 5 m
(16 ft.)
Back side
Positive (+) side
#$:0A'PDQQM2CIG6JWTUFC[5GRVGODGT2/
En-9
About Your iPod/iPhone
iPod touch (1st, 2nd, 3rd, and 4th generation),
iPod classic, iPod nano (2nd, 3rd, 4th, 5th, and
6th generation), iPhone 4, iPhone 3GS, iPhone 3G,
iPhone
Note:
• Before you begin using it, please update your iPod/
iPhone to the latest version. For details, refer to the
Apple website.
■About the Dock Adaptor
The ABX-N300’s dock uses the Universal Dock system.
By attaching an interchangeable part called a dock
adaptor, you’ll be able to insert your model of supported
iPod/iPhone.
• Use a commercially available dock adaptor or the one
that was included with your iPod/iPhone. If you insert
your iPod/iPhone into the ABX-N300 without the
appropriate dock adapter, excessive strain will be
applied to the connector, damaging the dock
connector or the dock connector port of your iPod/
iPhone.
• If your iPod is a compact and lightweight model, and
has no compatible adapter, you may connect it
directly.
■Removing the Dock Adaptor
As shown in the illustration below, insert a slotted
screwdriver or similar object into the slit of the dock
adaptor, and lift the adapter up.
• If you connect an iPod/iPhone to the ABX-N300
without attaching a dock adapter, you risk straining
and damaging the connector. Even if the dock adapter
is connected, you should avoid straining the connector
by moving or wiggling the connected iPod/iPhone.
• When inserting or removing your iPod/iPhone, take
care to insert or remove it in a straight line with the
angle of the connector, and do not use excessive force.
• Do not forcefully press the controls of your iPod/
iPhone while it is connected to the ABX-N300, or
wiggle your iPod/iPhone forward or backward. Doing
so will cause damage or faulty contacts in the
connector.
• Do not use the system in conjunction with other
accessories such as an FM transmitter or microphone.
Doing so may cause faulty operation.
• If your iPod/iPhone is in a case, it might not be able to
fully connect with the connector, causing failure to
sound or inability to operate the remote control.
Remove your iPod/iPhone from its case before
inserting it in the ABX-N300.
You can perform the following linked operations;
however some of these operations might not work
depending on your model of iPod/iPhone or the content
being played.
• Power on/off (standby) operation
When you switch the ABX-N300’s power on/
standby, your iPod/iPhone will be switched
accordingly.
• Timer operation
The ABX-N300’s timer will cause your iPod/
iPhone to perform timer playback.
iPod/iPhone Models that can be
connected
Move the slide cover
to the left to expose
the dock.
Dock adapter
First align the front
edge of the dock
adaptor, and then
press down on the
rear edge.
Caution
Linked Operation with Your iPod/
iPhone
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-10
Getting to Know the ABX-N300
The page numbers in parentheses show where you can find the main explanation for each item.
aSlide cover
Close the slide cover when transporting the ABX-
N300 or when not using the dock.
biPod/iPhone dock (XX)
Insert your iPod/iPhone here.
cDisplay
dMENU button (XX)
This button accesses the menu. Press it once again to
close the menu.
e[
F
]/[
H
] buttons (XX)
When the menu is displayed, use these buttons to
select a menu item.
fENTER button
Press this button to confirm a setting you've made in
a menu, etc.
g[
O
] button (XX)
This button takes you back to the previous menu.
h[
J
] button (XX)
This button stops playback on the iPod/iPhone.
i[
U
]/[
I
] button (XX)
This button starts playback on the iPod/iPhone.
Pressing this during playback will pause the
playback.
jINPUT button (XX)
This button selects the source that will be heard.
kVOLUME buttons (XX)
These buttons adjust the volume.
lON/STANDBY button (XX)
This button switches the power between on/standby.
mStandby mode indicator
nStand
oDownlight
This will be lit when the power is on, and unlit in
standby mode.
Top/Front Panel
1
4 6 7 8 9 j l
on
2 3
5 k
m
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-11
Getting to Know the ABX-N300—Continued
aWi-Fi antenna (XX)
Raise this antenna if you’re connecting to the
network wirelessly (via Wi-Fi).
bEthernet port (XX)
Connect your Ethernet cable here if you’re
connecting to the network via a cable.
cLINE IN jack (XX)
Use a commercially available mini-plug audio cable
to connect an external device’s audio output to this
jack. This allows the ABX-N300 to play back audio
from a device such as a digital audio player, game
device, television, or record player with built-in
phono equalizer.
dAC adapter jack (DC IN 16V 3A) (XX)
Connect the included AC adapter here.
Rear Panel
1 2 34
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-12
Getting to Know the ABX-N300—Continued
a[
M
] (on/standby) button (XX)
This button switches the power between on/standby.
bTIMER button (XX)
This button lets you set the clock and timer.
cSLEEP button (XX)
This button is used to set the sleep timer.
dSNOOZE button (XX)
Press this button to use the snooze function
(temporarily stopping timer playback).
eDISPLAY button (XX)
The information shown in the display will change
each time you press this button. If you press this
button when the ABX-N300 is in standby mode, the
time will be displayed for eight seconds.
fINPUT button (XX)
This button selects the source that will be heard.
g[
J
] button (XX)
This button pauses playback on the iPod/iPhone.
hTONE button (XX)
To adjust the treble (high-frequency range) or bass
(low-frequency range), press this button to alternate
between treble and bass settings.
iS.BASS (Super Bass) button (XX)
This button lets you make Super Bass settings.
jVOLUME [
F
]/[
H
] buttons (XX)
These buttons adjust the volume.
kMUTING button (XX)
This button temporarily silences the sound.
lREPEAT button (XX)
This button plays the song(s) repeatedly.
mSHUFFLE button (XX)
This button plays the songs randomly.
nPLAYLIST [
F
]/[
H
] buttons (XX)
This button lets you select a playlist on the iPod/
iPhone.
o[
U
]/[
I
] button (XX)
This button starts playback on the iPod/iPhone.
During playback, you can press this button to pause.
p[
O
] button (XX)
This button takes you back to the previous menu.
q[
Q
]/[
R
] buttons
When your iPod/iPhone is playing, these buttons
select the previous or next song. When the radio is
playing, these buttons select stations you've
memorized.
rENTER button (XX)
Press this button to confirm a setting you've made in
a menu, etc.
sMENU button (XX)
This button accesses the menu. Press it once again to
close the menu.
t[
F
]/[
H
] buttons (XX)
When the menu is displayed, use these buttons to
select a menu item.
uDIMMER button (XX)
This button switches the brightness of the downlight.
Remote Controller (RC-806S)
1 2 3 4
k
5
7
8
9
6
j
m
p
s
r
u
l
o
n
q
t
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-13
Connections
Caution
• Don’t use connection cables that contain a built-in resistor.
• If you connect the earphone jack of another device to the ABX-N300, you must first adjust the volume of the
connected device.
Before you make connections
• This illustration is only one example. The connection method is the same even if you’re using other devices. Be sure
to also read the owner’s manual of the device you’re connecting.
• Don’t connect the AC adapter until you’ve finished making all connections.
Raise the antenna if you’re
connecting to the network
wirelessly (via Wi-Fi).
Router or switching hub
Stereo mini-plug
Connect the audio output jacks of your
external device to the LINE IN jack. The
ABX-N300’s jack is a stereo mini-jack.
Use a commercially-available cable
that’s appropriate for the jack(s) of the
device you’re connecting.
Earphone jack or
audio output jack
Stereo
mini-plug Digital audio player etc.
* If the volume is insufficient,
raise the volume of the
connected device.
RCA plug
White
Red
Analog
audio output
jacks
Game console
Record player with built-in
phono equalizer
Television
Included AC adapter
Caution
Use only the included
AC adapter. Do not use
the included AC
adapter with any other
device. Doing so may
cause malfunctions or
accidents.
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-14
Basic Operation
To turn on the ABX-N300, press the [M ON/
STANDBY] button on the ABX-N300 or remote
controller.
Press the [M ON/STANDBY] button again to set the
ABX-N300 to Standby.
If an iPod/iPhone is connected to the ABX-N300, the
iPod/iPhone will be charged.
Press the [INPUT] button of the ABX-N300 or the
remote controller to switch the input.
You can choose from iRadio, Media Server, iPod/
iPhone, or LINE (the connected external device). Each
time you press the INPUT button, the input will cycle
through the following choices.
Press the VOLUME Up [F] button to increase the
volume or the VOLUME Down [H] button to decrease it.
You can also use the remote controller’s VOLUME [F]/
[H] buttons.
You can adjust the volume in the range of Min, 1–49,
Max.
To mute the ABX-N300, press the remote controller’s
[MUTING] button.
“Muting” appears on the display for a few seconds.
To unmute the ABX-N300, press the [MUTING] button again.
Tips:
While the ABX-N300 is muted:
•Press the VOLUME [F]/[H] buttons on the
ABX-N300 or pressing the VOLUME [F]/[H] buttons
on the remote controller will unmute the ABX-N300.
• If you turn the ABX-N300 off, the next time you turn
it on, the ABX-N300 will be unmuted.
You can adjust the brightness of the downlight.
Press the remote controller’s [DIMMER] button.
Each time you press the button, the brightness will cycle
through the following settings.
1Press the [TONE] button to make the
display indicate “Tone Control.”
2Use the [
F
]/[
H
] buttons to adjust the value.
You can adjust the value in the range of –3 to +3.
3Press the [ENTER] button.
The value of the Treble setting will blink.
4Use the [
F
]/[
H
] buttons to adjust the value.
5Press the [ENTER] button.
The original display will reappear.
Note:
• If you press no buttons for eight seconds, the previous
display will appear automatically.
MON/STANDBY
INPUT
O
ENTER
VOLUME F/H
MENU
F/H
M
DIMMER
MENU
ENTER
O
INPUT
C/U
VOLUME
F/H
MUTING
TONE
F/H
Downlight (below the speakers)
Turning On the ABX-N300
Selecting the Input Source
Adjusting the Volume
Muting the ABX-N300
(remote controller only)
Changing the Downlight Brightness
(remote controller only)
Adjusting the Bass and Treble
Bright Normal Dim Off
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-15
Basic Operation—Continued
To turn on Super Bass, press the [S.BASS] button.
The “S.BASS” indication appears on the display.
The strength of the ultra-low range will change each time
you press the [S.BASS] button.
The “S.BASS” indication will disappear when this
setting is off.
Using Super Bass
(remote controller only)
Clock Sapaaaaaa
S
.
BASS
123456789123456
offon
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-16
Playing Your iPod/iPhone
Notes:
• Before using your iPod/iPhone with the ABX-N300,
be sure to update your iPod/iPhone with the latest
software, available from the Apple website.
• If you leave your iPod/iPhone paused when using it on
its own, eventually it will go into hibernation. If you
insert it into the ABX-N300 dock in this state, you’ll
need to wait a few moments before your iPod/iPhone
is ready for use.
• Always remove your iPod/iPhone before moving the
ABX-N300.
• Depending on your iPod/iPhone, or the type of content
being played, some functions may not work as
expected.
1Move the slide cover to the left.
2Insert your iPod/iPhone into the
ABX-N300’s iPod/iPhone Dock.
Insert your iPod/iPhone securely into the ABX-
N300’s dock.
Notes:
• The appropriate model of dock adapter must be
installed in the ABX-N300’s iPod/iPhone dock (see
page 7).
• To prevent damage to the dock connector, do not twist
or force your iPod/iPhone into the dock, and be careful
not to wiggle your iPod/iPhone while inserting it.
• If you use a case with your iPod/iPhone, always
remove it before you insert it. Otherwise, it may not
connect properly and a malfunction may occur.
• Do not close the slider cover while an iPod/iPhone is
inserted. We recommend that you leave the slide cover
closed when not using the ABX-N300.
• Do not use with any iPod/iPhone accessories, such as
FM transmitters and microphones, as they may cause
a malfunction.
3Press the Play/Pause [U/I] button.
Playback starts.
Note:
• The volume level is adjusted by using the VOLUME
[H]/[F] buttons on the ABX-N300 or its remote
controller. Adjusting the volume on your iPod/iPhone
has no effect.
Pausing Playback
To pause playback, press the [U/I] button.
Press the button once again to resume playback from
where you paused.
You can also pause playback by pressing the [J] (stop)
button.
Selecting Songs (remote controller only)
To return to the beginning of the track that’s currently
playing or paused, press the Previous [Q] button.
Press the Previous [Q] button repeatedly to select
earlier songs.
Press the Next [R] button repeatedly to select
subsequent songs.
Fast Forward and Fast Reverse
(remote controller only)
To fast forward or fast reverse during playback or while
playback is paused, press and hold down the Next [R]
or Previous [Q] button, respectively.
JU/I
ENTER
VOLUME
U/I
Q/R
MENU
SHUFFLE
PLAYLIST
REPEAT
F/H
F/H
DISPLAY
F/H
MENU ENTER VLUMEF/H
F/H
Slide cover
Dock for iPod/iPhone
iPod/iPhone
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-17
Playing Your iPod/iPhone—Continued
1Press the [MENU] button on the ABX-N300
or the remote controller to display the menu
on the iPod/iPhone.
2Use the [F]/[H] buttons to select an item on
the menu, and then press [ENTER].
During playlist playback, press the PLAYLIST [F]
button to select the previous playlist; press the
PLAYLIST [H] button to select the next playlist.
Caution
If you’re unable to select a playlist, play back any
playlist on your iPod/iPhone, and then use the
PLAYLIST [F]/[H] buttons.
With random playback, the songs on the iPod/iPhone are
played in random order.
1Press the [SHUFFLE] button.
The % symbol will appear in the screen of the
iPod/iPhone.
2To start random playback, press the Play
[U/I] button.
Cancelling Random Playback
To cancel random playback, press the [SHUFFLE]
button.
The % symbol will disappear from the screen of the
iPod/iPhone.
If you press the [REPEAT] button, the song on the iPod/
iPhone will play repeatedly. The type of repeat playback
will change as follows each time you press the
[REPEAT] button.
: : Repeat one song
< : Repeat all songs
Cancelling Repeat Playback
Press the [REPEAT] button several times until the < or
: symbol disappears from the screen of the iPod/
iPhone.
With this unit, you can enjoy the music of iOS-based
devices or iTunes music library using Apple Inc.’s
AirPlay.
Note:
To use AirPlay, you will need one of the following
equipments.
• iPad, iPhone, iPod touch with iOS 4.2 or greater.
• A personal computer with iTunes 10 (or greater)
installed.
Tip:
For optimal performance, we recommend you always
use the latest version of iOS and iTunes.
For details on AirPlay or how to obtain the latest version
for your software, please visit Apple web site.
AirPlay, the AirPlay logo, iPad, iPhone, iPod,
iPod classic, iPod nano, iPod shuffle, and iPod touch are
trademarks of Apple Inc., registered in the U.S. and other
countries.
Note:
• In order to using the AirPlay, the ABX-N300 must be
connected to a network. For details on connecting to a
network, refer to "Network Settings" (see page XX).
Navigating the iPod/iPhone Menus
Select playlists
(remote controller only)
Random Playback
(remote controller only)
Repeat Playback
(remote controller only)
Using the AirPlay
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-18
Playing Your iPod/iPhone—Continued
Playback
Follow the procedure below to play back.
1Use the ABX-N300’s [INPUT] button to
select “AirPlay”.
2Tap the [8] displayed on the screen of
iTunes or on your iPad/iPhone/iPod touch
device.
Select “ONKYO ABX-N300 ******(default
name)” from the list displayed.
3Select a song to play back.
Tips:
• During AirPlay, press DISPLAY to switch between
song informations.
• When iTunes or your iPad/iPhone/iPod touch device
is not detected (no connection via AirPlay), “No
Source” is displayed on the Tuner.
• For detailed information on iTunes, see the Help
section of iTunes.
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-19
Listening to Internet Radio
You can listen to radio broadcasts that are being distributed via the Internet. The ABX-N300 supports the following
Internet radio services.
• vTuner Internet radio with OEM branded portal
Caution
• In order to listen to Internet radio, the ABX-N300
must be connected to a network. For details on
connecting to a network, refer to “Network Settings”
(see page 27).
1Select “Internet Radio” as the input.
Use the ABX-N300’s INPUT button or the remote
controller’s INPUT [C]/[U] buttons to select
“Internet Radio.”
A list of Internet radio stations will be
automatically loaded from the vTuner radio station
database service.
2Use the [F]/[H] buttons to select “Location,”
and press the [ENTER] button.
3Use the [F]/[H] buttons to select “Asia,” and
press the [ENTER] button.
4Use the [F]/[H] buttons to select “Japan,”
and press the [ENTER] button.
5Use the [F]/[H] buttons to select the genre
that you want to hear, and press the
[ENTER] button.
If you don’t want to choose a genre, leave “All
Stations” selected and simply press the [ENTER]
button.
6Use the [F]/[H] buttons to select a station,
and press the [ENTER] button.
The ABX-N300 will automatically connect to the
station, data will be loaded, and playback will
begin.
If the station is not broadcasting, the broadcast
station that follows the selected station will
automatically be received.
Tip:
While selecting a station, you can press the [O]
button to return to the previous screen.
Note:
• Pause function cannot be used during playback.
MENU F, H
ENTER
INPUT
ENTER
VOLUME
U/I
Q/R
MENU
SHUFFLE
PLAYLIST
REPEAT
F/H
F/H
DISPLAY
F/H
Receiving a broadcast
Internet Radio
+ Favorites
1/ 10
IR
Japan
+ All Stations
1/ 17
IR
Now Playing
BGM
Buffering 70%
IR
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-20
Listening to Internet Radio—Continued
Switching to the previous or next station
Press the remote controller’s [Q] or [R] button.
The [Q] button switches to the previous station, and
the [R] button switches to the next station.
You can store up to twenty favorite stations as presets.
1Receive the station that you want to store.
As described on page 18, receive the station that
you want to store.
2Press the MENU button.
The preset number will be displayed.
3Use the [F]/[H] buttons to select the preset
number in which you want to store the
station.
4Press the ENTER button.
5To store the station, press the ENTER
button.
If you decide to change the preset number in which
to store the station, press the [O] button to
return to step 3.
When the preset has been stored, the following
display will appear.
Storing a station (Preset)
Q, R
MENU F, H
ENTER
Add Preset No10
>FM Palulun76.2FM
Add Preset No1
Are sure Write? Y/N
Add Preset No1
Writing No.1...
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-21
Tentative
Listening to Internet Radio—Continued
Listening to a preset station You must first store a broadcast station (see pages 21 and 22).
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-22
Playing Music Files from a Network Server or
Computer
You can use the ABX-N300 to play back music files
located on a media server or computer on your home
network.
Caution
• The ABX-N300 must be connected to the network in
order to listen to music from a server or computer. For
more about connecting to a network, refer to
“Network Settings” on page 27.
• The server or computer containing the music files you
wish to hear must be powered-on.
1Select “Server” as the input.
Use the [INPUT] button to select “Server.” The
names of the servers on the network will
automatically be displayed.
2If there is more than one server, choose the
desired server.
Use the [F]/[H] buttons to choose the server that
you want to hear. The ABX-N300 will
automatically connected to the server, and the
folder names will be displayed.
If there is only server, simply proceed to step 3.
3Press the ENTER button.
The ABX-N300 will connect to the server, and the
folder names will be displayed.
4Select the file that you want to play.
Use the [F]/[H] buttons to select the song that you
want to hear.
MENU F, H
ENTER
Server 1/8
ONKYO-PC
Server
Serching server...
Server 2/18
Connecting...
Server 2/8
PLATINUM-PC
Server 2/18
+ Jazz
Server 1/18
Connecting...
Server 2/18
+ Aerosmith
Server 1/18
> Eat The Rich
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-23
Playing Music Files from a Network Server or Computer—Continued
5Press the [ENTER] button.
The data will be loaded, and then playback will
begin.
Hint:
While selecting a song, you can press the [O] button
to return to the previous screen.
Selecting the song you want to hear
During playback, pressing the remote controller’s [Q]
button once will return you to the beginning of the
current song, and pressing it again will step backward
one song at a time. Pressing the [R] button will move
forward one song at a time.
Rewinding or fast-forwarding
During playback, hold down the remote controller’s
[Q] or [R] button, and release it at the location that
you want to hear.
Server 1/18
Play 00:00:00
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-24
Setting the Clock (by remote controller only)
Note:
• Clock settings can be made only while the ABX-N300
is in standby mode. If the ABX-N300 is powered-on,
press the [M] button to put the unit in standby mode.
1Press the [TIMER] button.
2Use the [F]/[H] buttons to select “Clock
Setup”.
3Press the [ENTER] button.
4Use the [F]/[H] buttons to enter the current
time.
Hold down the buttons to change the value quickly.
Tip:
• To change the time format between 12-hour and 24-
hour, press the [DISPLAY] button.
5Press the [ENTER] button.
A pixel in the lower right will blink to indicate that
the clock has started.
6Use the [F]/[H] buttons to select the day of
the week.
7Press the [ENTER] button.
Tip:
• If you press the Display button while in standby mode,
the time and date will be displayed for eight seconds.
ENTER
MENU
TIMER
M
F, H
DISPLAY
Timer1 Setup
Timer2 Setup
Clock Setup
Clock Setup
12:09 AM
Sunday
Clock Setup
12:09
Friday
Tentative
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-25
Using the Timers (by remote controller only)
The ABX-N300 has three timers: two programmable
timers for automated playback, and a sleep timer for
turning the ABX-N300 off after a specified period.
The various settings for the two programmable timers
are explained here. For details on the sleep timer, see
page 26.
Repeat Timers
Each timer can be programmed to operate every week or
every day.
• Every
The timer will operate every week on the specified
day and time.
• Everyday
The timer will operate every day at the specified
time.
Notes:
• You must set the clock before you can program the
timers.
• If you don’t operate any buttons for one minute while
programming a timer, the procedure will be cancelled
and the previous display will reappear.
• Timer settings can be made only while the ABX-N300
is in standby mode. If the ABX-N300 is powered-on,
press the [M] button to put the unit in standby mode.
• Connect your iPod/iPhone to the iPod Dock, and make
it ready for playback.
1Press the [TIMER] button.
2Use the [F]/[H] buttons to select “Timer1
Setup” or “Timer2 Setup”.
3Press the [ENTER] button.
4Use the [F]/[H] buttons to select “Timer1
On” or “Timer2 On”, and then press the
[ENTER] button.
5Use the [F]/[H] buttons to specify the On
time, and then press the [ENTER] button.
6Use the [F]/[H] buttons to specify the Off
time, and then press the [ENTER] button.
7Use the [F]/[H] buttons to select “Everyday”
or “Every”, and then press the [ENTER]
button.
If you selected “Everyday”, proceed to step 9.
8
If you selected “Every”, use the [
Q
]/[
R
]
buttons to select the day of the week on
which you don’t want timer playback to
occur; then use the [
F
]/[
H
] buttons to make
the underline character appear in place of
that day of the week, and then press the
[ENTER] button.
About the Timers
Programming the Timers
ENTER
TIMER
M
F, H
DISPLAY
SNOOZE
Q, R
Timer1 Setup
Timer2 Setup
Clock Setup
Timer1 Setup
Off 7:00
Timer1 On
On 6:30
Timer1 Setup
Every
MoTuWeThFr
Tentative
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-26
Using the Timers (by remote controller only)—Continued
9Use the [F]/[H] buttons to specify the
ABX-N300’s volume level, and then press
the [ENTER] button.
The timer symbol and number will appear in the
upper right of the display; this display will
disappear after a few seconds.
Tip:
• You can check the setting by pressing the [TIMER]
button and then pressing [ENTER] repeatedly.
1Press the [TIMER] button.
2Use the [F]/[H] buttons to select “Timer1
Setup” or “Timer2 Setup”, and then press
the [ENTER] button.
3Use the [F]/[H] buttons to select “On” or
“Off”, and then press the [ENTER] button.
4Press the [TIMER] button.
The previous display reappears.
When timer playback is operating, the ABX-N300
provides a snooze feature that temporarily silences the
song playback and sounds the song playback again after
five minutes.
Enabling the snooze feature
When the timer has started song playback on the
ABX-N300, you can press the [SNOOZE] button to use
the snooze feature.
After five minutes, the snooze feature sounds the song
playback again.
With the sleep timer, you can set the ABX-N300 so that
it automatically turns off after a specified period.
Press the [SLEEP] button repeatedly to select
the required sleep time.
With the [SLEEP] button, you can set the sleep time
from 90 to 10 minutes in 10 minute steps.
When the sleep timer has been set, “Sleep 90” appears
on the display. The sleep time appears on the display for
about eight seconds, then the sleep time display
disappears.
The display will indicate [SLEEP] while the sleep timer
is operating.
Checking the Remaining Sleep Time
To check the remaining sleep time, press the [SLEEP]
button.
Note that if you press the [SLEEP] button while the sleep
time is being displayed, you’ll shorten the sleep time by
10 minutes.
Canceling the Sleep Timer
To cancel the sleep timer, press the [SLEEP] button
repeatedly until “Sleep Off” appears.
Turning Timers On and Off
Using the Snooze Function
Clock Setup
12:12
Friday
1
Using the Sleep Timer
SLEEP
Tentative
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-27
Network Setup
The following diagram shows how you can connect the
tuner to your home network. In this example, it’s
connected to a LAN port on a router, which has a 4-port
100 Base-TX switch built-in.
■Ethernet Network
For the best results, a 100 Base-TX switched Ethernet
network is recommended. Although it’s possible to play
music on a computer that’s connected to the network
wirelessly, playback may be unreliable, so it is
recommended to use wired connections.
■Ethernet Router
A router manages the network, data-routing and
supplying of IP addresses. Your router must support the
following:
• NAT (Network Address Translation). NAT allows
several networked computers to access the Internet
simultaneously via a single Internet connection. The
tuner needs Internet access for Internet radio.
• DHCP (Dynamic Host Configuration Protocol).
DHCP supplies IP addresses to the network devices,
allowing them to configure themselves automatically.
• A router with a built-in 100 Base-TX switch is
recommended.
Some routers have a built-in modem, and some ISPs
require you to use specific routers. Please consult your
ISP or computer dealer if you’re unsure.
■CAT5 Ethernet cable
Use a shielded CAT5 Ethernet cable (straight-type) to
connect the tuner to your home network.
■Internet Access (for Internet radio)
To receive Internet radio, your Ethernet network must
have Internet access. A narrowband Internet connection
(e.g., 56 K modem, ISDN) will not provide satisfactory
results, so a broadband connection is strongly
recommended (e.g., cable modem, xDSL modem, etc).
Please consult your ISP or computer dealer if you’re
unsure.
Notes:
• To receive Internet radio with the tuner, your
broadband Internet connection must be working and
able to access the Web.
Consult your ISP if you have any problems with your
Internet connection.
• The tuner uses DHCP to configure its network settings
automatically. If you want to configure these settings
manually, see “Network Setup” ( page XX).
• The tuner does not support PPPoE settings, so if you
have a PPPoE-type Internet connection, you must use
a PPPoEcompatible router.
• Depending on your ISP, you may need to specify a
proxy server to use Internet radio. If your computer is
configured to use a proxy server, use the same settings
for the tuner ( page XX).
1Disconnect the AC adapter, connect the
Ethernet cable, wait ten seconds, and then
reconnect the AC adapter.
2Press the remote controller’s [MENU]
button, select “Standby Mode,” and then
press [ENTER].
3Choose “Network Mode” and press
[ENTER]. (The orange LED will light.)
4Press [MENU], select “Network Setup,” and
press [ENTER].
The display will indicate “initializing...”; please
wait.
5Select “Ethernet” and press [ENTER].
6Choose DHCP “Enable” and press
[ENTER].
Tip:
You can also specify the IP address and other settings
manually. In this case, choose “Disable” in step 6 above,
then press [ENTER], and make the following settings.
Connecting to the Network
Network Requirements
Inter net radio
Modem
Router
Computer or media serverServer
Connecting via a wired LAN
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-28
Network Setup—Continued
IP Address
Class A: “10.0.0.0” to “10.255.255.255”
Class B: “172.16.0.0” to “172.31.255.255”
Class C: “192.168.0.0” to “192.168.255.255”
Enter a static IP address provided by your ISP. Most
routers use Class C IP addresses.
Subnet Mask
Enter the subnet mask address provided by your ISP
(typically 255.255.255.0).
Gateway
Enter the gateway address provided by your ISP.
DNS Server
Enter a DNS server address provided by your ISP.
Proxy URL
To use a Web proxy, enter its URL here.
Proxy Port
If you’re using a Web proxy, enter a proxy port number
here.
1Disconnect the AC adapter and disconnect
the Ethernet cable. Then raise the wireless
LAN antenna, wait ten seconds, and
reconnect the AC adapter.
2Press the remote controller’s [MENU]
button, select “Standby Mode,” and press
[ENTER].
3Select “Network Mode” and press [ENTER].
(The orange LED will light.)
4Press [MENU], select “Network Setup,” and
press [ENTER].
Wait while the display indicates “initializing...”
5Select “Wireless” and press [ENTER].
The ABX-N300 will search for access points.
6Choose the access point that you want to
use, and press [ENTER].
7Choose the security method for that access
point, and press [ENTER].
8Use the following buttons to enter the
passcode.
[Q]/[R]: Move the cursor left/right
[ENTER]: Enter one character
[F]/[H]: Switch between character groups
(uppercase/lowercase/numerals
and symbols)
[O]: Backspace
[ENTER]: long press:Confirm the passcode
9Hold down [ENTER] for three seconds.
The passcode will be confirmed. This completes
the setup.
Tip:
If a connection is not established even though you've
waited three minutes or longer, it may be that the
passcode was incorrect. In this case, try making the
settings once again from the beginning.
However, if you have made the settings several times
without success, disconnect the AC adaptor, wait at least
ten seconds before reconnecting it, and then try making
the settings again.
1Put the ABX-N300 in Standby mode (the
orange LED will be lit).
If the orange LED does not light, perform steps 2
and 3 above.
2Press [MENU], choose “Network Info,” and
press [ENTER].
The ABX-N300’s IP address will be displayed.
3Start up a browser on a computer that’s
connected to the same network, and enter
the IP address of step 2 into the URL field
of your browser to access it.
The Web Setup Menu screen will appear. Here you
can edit the ABX-N300’s name that is shown when
using AirPlay, or update the firmware.
Caution:
• A router (access point) is required.
• Your iPhone and the ABX-N300 must be connected to
the same network within the router. Also when using
AirPlay with iTunes, that computer must be connected
to the same network.
Connecting via wireless LAN
To access the Web Setup screen
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-29
About Internet Radio and Media Servers
Tentative
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-30
Other Settings (Reset Procedure)
When the ABX-N300 is in Standby mode, pressing the
remote’s [MENU] button will display the following items.
The available settings for each item are shown below.
(The default setting is underlined.)
“12/24H Format” 12H 24H
Switches the time format between
12-hour and 24-hour. On models for
the North American market, the
default setting is “12H”; for other
models, the default setting is “24H.”
“Beep” On Off
Switches on/off the beep tone that
sounds when you press a button on
the top panel of the ABX-N300.
“Volume Limit” 10 40
Specifies the maximum volume in
the range of 10–40. The default
setting is 40.
“Reset” Cancel OK
If you select OK and then press the
[ENTER] button, the ABX-N300 will
be reset to its factory-set state.
1Use the [F]/[H] buttons to select a menu
item, and then press the [ENTER] button.
2Use the [F]/[H] buttons to change the
setting.
3Press the [ENTER] button to finalize the
change, and exit the menu.
Note:
• During this procedure, you can press the [MENU]
button to exit the settings.
Troubleshooting
If you experience any problem while using the
ABX-N300, look for a solution in this section.
Can’t turn on the ABX-N300.
• Make sure that the AC adapter is properly plugged
into the wall outlet, and that the DC IN connection has
been made correctly (see page 7).
• Unplug the AC adapter from the wall outlet, wait 10
seconds or more, then plug it in again.
The ABX-N300 turns off unexpectedly.
• If the sleep timer has been set and the SLEEP indicator
is shown on the display, the ABX-N300 will turn off
automatically after a specified period (see page 13).
• When timed playback finishes, the ABX-N300
automatically switches to Standby mode (see
page 12).
There’s no sound.
• Make sure the ABX-N300’s volume is not set too low
(see page 7).
• Make sure the correct input source is selected (see
page 7).
• Make sure the ABX-N300 is not muted (see page 8).
• Check all connections and correct as necessary (see
page 7).
The sound quality is not good.
• The sound quality can be affected by strong magnetic
fields, such as that from a TV. Try moving any such
devices away from the ABX-N300.
• If you have any devices that emit high-intensity radio
waves near the ABX-N300, such as a cellular phone
that’s being used to make a call, the ABX-N300 may
output noise.
Audio output is intermittent when the
ABX-N300 is subjected to vibration.
The ABX-N300 is not a portable device. Use it in a
location that’s not subject to shock or vibration.
12/24H Format
Beep
Volume Limit
Reset
Power
If you can’t resolve the issue yourself, try resetting
the ABX-N300 before contacting your Onkyo dealer.
Reset the ABX-N300 as described in the “Reset”
section of “Other Settings” (this page).
Note that resetting the ABX-N300 will delete your
custom settings.
Audio
Tentative
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-31
Troubleshooting—Continued
There’s no sound.
• Make sure your iPod/iPhone is properly seated in the
ABX-N300’s iPod dock. Even very thin iPod/iPhone
cases can prevent the iPod/iPhone from seating
properly on the dock connector, so always remove any
case before inserting your iPod/iPhone (see page 7).
• Make sure the ABX-N300 is turned on, the input
source is set to iPod, and the volume is not set too low.
• Make sure that your iPod/iPhone is compatible with
the system (see page 4).
Can’t control your iPod with the
ABX-N300’s remote controller.
• Make sure your iPod/iPhone is properly seated in the
ABX-N300’s iPod dock. Even very thin iPod/iPhone
cases can prevent the iPod/iPhone from seating
properly on the dock connector, so always remove any
case before inserting your iPod/iPhone (see page 7).
• You may not be able to control your iPod/iPhone
immediately after inserting it into the ABX-N300’s
iPod dock. In this case, wait a few moments until your
iPod/iPhone wakes up.
• Depending on your iPod/iPhone model, its software
version, or the content your playing, some functions
may not work as expected (see page 9).
• If your iPod/iPhone does not work, remove it, wait a
few moments, and then connect it again.
• Check whether there might be a problem with your
iPod/iPhone. For an iPod touch or iPhone, make sure
that the app is working correctly.
The remote controller doesn’t work
properly.
• Replace the battery with a new one.
• The remote controller is too far away from the
ABX-N300, or there’s an obstacle between them (see
page 5).
• The ABX-N300’s remote control sensor is being
subjected to bright light (inverter-type fluorescent
light or sunlight).
No sound is heard from your turntable.
• Make sure the turntable has a built-in phono equalizer.
If the turntable doesn’t have a phono equalizer built-
in, you must provide one.
The timers don’t work.
• Make sure the clock has been set correctly (see
page 11).
• Timed operation will fail if the ABX-N300 is already
on at the specified On time, so make sure it’s set to
Standby (see page 11).
• The timer may overlap with another timer. If you
program two timers, make sure they don’t overlap.
• If you press the [SLEEP] or [TIMER] button while a
timed operation is in progress, the timer will be
cancelled and the ABX-N300 won’t turn off at the
specified Off time (see page 12).
• Make sure the timer is set to suitable volume setting
(see page 12).
The clock displays “--:--”
• A power outage has occurred and the time setting lost.
Set the clock again (see page 11). The timers will all
be set to Timer Off, so you’ll need to turn on any
necessary timers (see page 12). The timer settings will
be preserved.
iPod/iPhone
Remote Controller
External Components
Timers
Clock
The ABX-N300 contains a microcomputer. In very
rare situations, severe interference, noise from an
external source, or static electricity may cause it to
malfunction or lockup. In the unlikely event that this
should happen, unplug the AC adapter, wait at least 10
seconds, and then plug it back in again. If this doesn’t
resolve the issue, reset the ABX-N300 to its factory
defaults (see page 30).
Tentative
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-32
Specifications
■General
■Amplifier
■Speakers
Specifications and features are subject to change without notice.
Power Supply AC adapter (DC IN 16 V, 3 A)
Power Consumption 18 W
No-sound Power Consumption 3.9 W
Stand-by Power Comsumption 0.5 W (when not charging iPod/iPhone)
Dimensions (W × H × D) 430 × 131 × 143 mm
(16-15/16 × 5-3/16 × 5-5/8 inches)
Weight 2.4 kg (5.3 lbs.)
Analog Input LINE
Power Output 2ch × 10 W (6 Ω, 1 kHz, 1% THD)
Total Harmonic Distortion+N 1 %
Input Sensitivity and Impedance 1000 mV/ 15.6 kΩ
Frequency Response 40 Hz–20 kHz
Tone Control Characteristies +3 dB, –3 dB ,100 Hz (BASS)
+3 dB, –3 dB, 10 kHz (TREBLE)
+3 dB, 80 Hz (S.BASS)
Signal to Noise Ratio 70 dB (LINE, IHF-A)
Type Full-Range bass reflex
Unit 6.4 cm (2-1/2") cone (magnetically shielded)
Tentative
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-33
MEMO
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-34
MEMO
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-35
MEMO
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
En-36
I1110-1
* 2 9 4 0 1 1 2 2 *
SN 29401122
(C) Copyright 2011 ONKYO SOUND & VISION CORPORATION Japan. All rights reserved.
2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 072-831-8023 Fax: 072-831-8163
http://www.onkyo.com/
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: 800-229-1687, 201-785-2600 Fax: 201-785-2650
http://www.us.onkyo.com/
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555
http://www.eu.onkyo.com/
The Coach House 81A High Street, Marlow, Buckinghamshire, SL7 1AB, UK
Tel: +44-(0)1628-473-350 Fax: +44-(0)1628-401-700
Unit 1033, 10/F, Star House, No 3, Salisbury Road, Tsim Sha Tsui Kowloon, Hong Kong.
Tel: 852-2429-3118 Fax: 852-2428-9039
http://www.ch.onkyo.com/
1301, 555 Tower, No.555 West NanJin Road, Jin an, Shanghai,
China 200041, Tel: 86-21-52131366 Fax: 86-21-52130396
#$:0A'PDQQM2CIG6WGUFC[5GRVGODGT2/
