Onkyo and Pioneer Innovations 7BT WIRELESS STEREO HEADPHONES User Manual
Onkyo & Pioneer Innovations Corporation WIRELESS STEREO HEADPHONES Users Manual
User manual
WIRELESS STEREO HEADPHONES
SE-C7BT User manual
BT datas：
Chipset : CSR8640
BT version: V4.1
Offer voltage : DC 3.70V by battery(80mAh)
Working current ::≤20mA
Standby current::≤2mA
Charging current:: 100mA
Wireless transmit distance :10 meter
RF: -80dBm<0.1%BER
Frequency range ：2.402GHz-2.480GHz
Signal to Noise Ratio：≥75dB
distortion factor: ≤0.1%
Temperature: -40ºC to +80ºC
1.Indicator
2 Volume+ / next chart
3． Volume- /previous chart
4． ON/OFF /play/pause
5． Usb 5 V Output
Feature :
Enjoy music through Bluetooth；
Phone call with BT function
Remote control music；
High sensitivity、omnibearing microphone design
Apply for devices：with all BT mobile phone ,iphone，Laptop Etc .
Pairing ：red&blue light blinking
Pairing successful：blue light slow blink
Charging ：red light on ，full charge blue light on
1．BT earphone pairing
1.press and hold （ ）3s open SE-C7BT，Lasting to red &blue light blinking，into paring mode （noted ！
Paring need to finish in 5 minutes，after 5 minutes earphone will shut off automatic ）
2.Open the phone or Bluetooth device , "Bluetooth search" or "add new equipment" search Bluetooth headset
SE-C7BT
3.Click on the device name connection, the connection has a successful connection tone and blue light flashing.
This means that the connection is successful..
2．Answer phone call
incoming call tone or ringtones, short press ( ), you can answer the call. Or use your phone to answer a call.。
3．Reject phone call
Short press ( ) or use the phone to stop the call.
4．Phone call conversion
1.Long press ( ) 3 seconds to transfer calls to the phone , if want to switch back to the headset , just long press
3 seconds again !
5．Last number redial
Double click ( ) to redial last number
6．Music playing
Short press “ ” paly /pause .，long press + to next chart ,short press + volume UP ;long press - to previous
chart ,short press - ,volume down .
FCC Warning:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void
your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable expo
sure condition without restriction.
ISED Statement
- English: This device complies with Industry Canada license‐exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This devi
ce must accept any interference, including interference that may cause undesired operation of the device.
The digital apparatus complies with Canadian CAN ICES‐003 (B)/NMB‐3(B).
- French: Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produ
ire de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouilla
geest susceptible d'encompromettre le fonctionnement.
L'appareil numérique est conforme à la canadienne CAN ICES‐003 (B)/NMB‐3(B).
Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement. The device can be usedin portable
exposure condition without restriction.
L'appareil a été évalué pour répondre aux exigences générales d'exposition aux radiofréquences. L'appareil peut
être utilisé en condition d'exposition portable sans restriction.
