TX-NR636

AV RECEIVER

Advanced Manual

CONTENTS

AM/FM Radio Receiving Function 2

Tuning into a Radio Station 2

Presetting an AM/FM Radio Station 2

Using RDS (European, Australian and Asian models) 3

Playing Content from a USB Storage Device 4

Listening to Internet Radio 5

About Internet Radio 5

TuneIn 5

Pandora®–Getting Started (U.S., Australia and

New Zealand only) 6

SiriusXM Internet Radio (North American only) 7

Slacker Personal Radio (North American only) 8

Registering Other Internet Radios 9

DLNA Music Streaming 11

About DLNA 11

Configuring the Windows Media Player 11

DLNA Playback 11

Controlling Remote Playback from a PC 12

Music Streaming from a Shared Folder 13

About Shared Folder 13

Setting PC 13

Playing from a Shared Folder 13

Using Remote Controller for Playing Music Files 15

About the Remote Controller 15

Remote Controller Buttons 15

Icons Displayed during Playback 15

Using the Listening Modes 16

Selecting Listening Mode 16

Contents of Listening Modes 17

Checking the Input Format 19

Advanced Settings 20

How to Set 20

1.Input/Output Assign 21

2.Speaker Setup 24

3.Audio Adjust 27

4.Source Setup 29

5.Listening Mode Preset 32

6.Miscellaneous 33

7.Hardware Setup 33

8.Remote Controller Setup 39

9.Lock Setup 39

Operating Other Components Using Remote

Controller 40

Functions of REMOTE MODE Buttons 40

Programming Remote Control Codes 40

TV operation 42

Blu-ray Disc player/DVD player/DVD recorder

operation 42

VCR/PVR operation 43

Satellite receiver / Cable receiver operation 43

CD player operation 44

Cassette tape deck operation 44

To operate CEC-compatible components 44

Advanced Speaker Connection 45

Bi-Amping 45

Connecting and Operating Onkyo RI Components 46

About RI Function 46

RI Connection and Setting 46

iPod/iPhone Operation 47

Firmware Update 48

About Firmware Update 48

Updating the Firmware via Network 48

Updating the Firmware via USB 49

Troubleshooting 51

Reference Information 58

E

n

AM/FM Radio Receiving Function

2

AM/FM Radio Receiving Function

Tuning into a Radio Station

 Tuning into stations automatically

1. Press TUNER on the main unit several times to select

either "AM" or "FM".

2. Press TUNING MODE so that the "AUTO" indicator on

the display lights.

3. Press TUNING to start Auto tuning.

• Searching automatically stops when a station is

found. When tuned into a radio station, the "

TUNED " indicator on the display lights. When

tuned into an FM radio station, the "FM STEREO"

indicator lights.

• No sound is output while the " TUNED " indicator

is off.

When the signal from an FM radio station is weak:

Radio wave may be weak depending on the building

structure and environmental conditions. In that case,

manually tune into the radio station of your choice by

referring to the next section.

 Tuning into stations manually

1. Press TUNER on the main unit several times to select

either "AM" or "FM".

2. Press TUNING MODE so that the "AUTO" indicator on

the display goes off.

3. Press TUNING to select the desired radio station.

• The frequency changes by 1 step each time

you press the button. The frequency changes

continuously if the button is held down and stops

when the button is released. Tune by looking at the

display.

To return the indicator to "AUTO": Press TUNING MODE

again on the main unit. The unit automatically tunes into an

FM station. Normally, leave the indicator in "AUTO".

 Tuning into stations by frequency

It allows you to directly enter the frequency of the radio

station you want to listen to.

1. Press TUNER on the remote controller several times to

select either "AM" or "FM".

2. Press D.TUN.

3. Using the number buttons, enter the frequency of the

radio station within 8 seconds.

• To enter 87.5 (FM), for example, press 8, 7, 5, or 8,

7, 5, 0. If you entered a wrong number, you can enter

a correct one after 8 seconds.

Presetting an AM/FM Radio Station

It allows you to register up to 40 of your favorite AM/FM

radio stations. Registering radio stations in advance allows

you to tune into your radio station of choice directly.

 Registering a Station

1. Tune into the AM/FM radio station you want to register.

2. Press MEMORY on the unit so that the preset number

on the display flashes.

3. Repeatedly press PRESET to select a number

between 1 and 40 while the preset number is flashing

(about 8 seconds).

AM/FM Radio Receiving Function

3

4. Press MEMORY again to register the station.

• When registering, the preset number stops flashing.

• Repeat this procedure for all of your favorite AM/FM

radio stations.

 Selecting a Preset Radio Station

1. Press CH +/- on the remote controller to select a preset

number.

• Alternatively you can press PRESET on the

main unit. You can also select by directly entering

the preset number with the number buttons on the

remote controller.

 Deleting a Preset Radio Station

1. Press CH +/- on the remote controller to select the

preset number to delete.

2. Press and hold MEMORY on the main unit and press

TUNING MODE to delete the preset number.

• When deleting, the number on the display goes off.

Using RDS (European, Australian and Asian

models)

RDS stands for Radio Data System and is a method of

transmitting data in FM radio signals.

• RDS works only in areas where RDS broadcasts are

available.

• In some cases, the text information appeared on the

display is not identical to the content transmitted by

the RDS station. Furthermore, unexpected characters

may be displayed when the unit receives unsupported

characters. However, this is not a malfunction.

• If the signal from an RDS station is weak, the RDS data

may be displayed continuously or not at all.

PS (Program Service): Tuning into a radio station

distributing Program Service information displays the

radio station name. Pressing DISPLAY displays the

frequency for 3 seconds.

RT (Radio Text): Tuning into a radio station transmitting

Radio Text information displays text on the display of the

unit.

PTY (Program Type): Allows you to search for RDS

stations by program type.

TP (Traffic Program): Allows you to search for radio

stations transmitting traffic information.

 Displaying Radio Text (RT)

1. Press RT/PTY/TP on the main unit once.

• The Radio Text (RT) is displayed scrolling across

the display. "No Text Data" is displayed when no text

information is available.

 Searching by Type (PTY)

1. Press RT/PTY/TP on the main unit twice.

• The current program type appears on the display.

2. Press PRESET to select the type of program to

search for.

• The following RDS station types are displayed:

None

News (News reports)

Affairs (Current affairs)

Info (Information)

Sport

Educate (Education)

Drama

Culture

Science (Science and technology)

Varied

Pop M (Pop music)

Rock M (Rock music)

Easy M (Middle of the road music)

Light M (Light classics)

Classics (Serious classics)

Other M (Other music)

Weather

Finance

Children (Children’s programmes)

Social (Social affairs)

Religion

Phone In

Tr a ve l

Leisure

Jazz (Jazz music)

Country (Country music)

Nation M (National music)

Oldies (Oldies music)

AM/FM Radio Receiving Function / Playing Content from a USB Storage Device

4

Folk M (Folk music)

Document (Documentary)

3. Press ENTER to search the radio stations of the

selected type.

4. When the desired radio station is found, the station

name on the display flashes. Then, press ENTER again.

• If no stations are found, the message "Not Found" is

displayed.

 Listening to Traffic Information (TP)

1. Press RT/PTY/TP on the main unit thrice.

• When the traffic information is transmitted from the

radio station you selected, "[TP]" is displayed. "TP"

only is displayed if no traffic information is available.

2. Press ENTER to search a radio station distributing traffic

information.

3. When such a radio station is found, the indication on the

display flashes. Then, press ENTER again.

• "Not Found" is displayed if no radio station

distributing traffic information is found.

Playing Content from a USB

Storage Device

 Operation: You can set up by viewing the guidance

displayed on the TV screen. To display the guidance, you

need to make HDMI connection between the unit and

TV. Select the item with the cursor buttons of the remote

controller and press ENTER to confirm your selection. To

return to the previous screen, press RETURN.

 Playing Back

1. Press USB on the remote controller to select "USB".

2. Plug your USB storage device with the music files into

the USB port of the unit so that "USB" lights on the

display.

• If the "USB" indicator flashes, check whether the

USB storage device is plugged in properly.

• Do not unplug the USB storage device while

"Connecting..." is appeared on the display. This may

cause data corruption or malfunction.

3. Press ENTER.

• The list of folders and music files on the USB storage

device is displayed on the screen, select the folder

with the cursors and press ENTER to confirm your

selection.

4. With the cursors, select the music file to play, and then

press ENTER or to start playback.

Listening to Internet Radio

5

Listening to Internet Radio

About Internet Radio

Internet radio, also called net radio, web radio or streaming

radio, is an audio service accessible at the websites of

service providers who distribute music and audio programs

in digital format. There are numerous websites all over the

world, from terrestrial station, special station to personal

website that provide such a service.

The unit comes preset with Internet radio stations ()

such as TuneIn for you to enjoy these services, just by

connecting the unit to the Internet.

½Network services or contents may become unavailable if the service

provider terminates its service.

TuneIn

With more than 70,000 radio stations and 2 million on-

demand programs registered, TuneIn is a service where

you can enjoy music, sports and news from all over the

world.

 Operation: You can set up by viewing the guidance

displayed on the TV screen. To display the guidance, you

need to make HDMI connection between the unit and

TV. Select the item with the cursor buttons of the remote

controller and press ENTER to confirm your selection. To

return to the previous screen, press RETURN.

 Playing Back

1. Press NET on the remote controller to display NET TOP

screen.

• "NET" lights on the display.

• Alternatively you can press Home and select

"Network Service" in the Home menu.

2. With the cursors, select "TuneIn", and then press

ENTER to display TuneIn top screen.

3. With the cursors, select a radio station or program and

press ENTER to start playing.

 Regarding the TuneIn Menu

To display the TuneIn menu, press MENU while playing a

radio station, or select "Go to Menu" and press ENTER.

Selecting the corresponding menu item with the cursors

and pressing ENTER allows you to perform the following

operations:

Add to My Presets: Registers radio stations and

programs in your "My Presets" within TuneIn. This allows

you to play registered radio stations and programs with

a simple operation. ("My Presets" is not displayed if it is

empty.)

Remove from My Presets: Deletes a radio station or

program from your "My Presets" within TuneIn.

Report a problem: Reports a problem or interactively

solves a problem related to TuneIn.

View Schedule: Displays the radio station or program

schedule.

Clear recents: Clears all radio stations and programs

from the "Recents" within TuneIn. (This menu is

displayed only when a radio station or program inside

the "Recents" is being played.)

Add to My Favorites: Registers radio stations and

programs in "My Favorites" of "Network Service".

This allows you to play registered radio stations and

programs with a simple operation.

Listening to Internet Radio

6

 Regarding the TuneIn Account

Creating an account on the TuneIn website (tunein.com)

and logging in it from the unit allows you to automatically

add radio stations and programs to your "My Presets" on

the unit as you save them on the website .

To display a radio station registered in "My Presets", you

must log into TuneIn from the unit. To log in, select "Login" -

"I have a TuneIn account" in the "TuneIn" top list on the unit,

and then enter your user name and password.

• If you associate the device on My Page within the TuneIn

website using the registration code obtained by selecting

"Login" - "Login with a registration code" on the unit, you

can log in without entering the user name and password.

Pandora®–Getting Started (U.S., Australia and

New Zealand only)

Pandora is a free, personalized Internet radio service that

plays the music you know and helps you discover music

you’ll love.

 Operation: You can set up by viewing the guidance

displayed on the TV screen. To display the guidance, you

need to make HDMI connection between the unit and

TV. Select the item with the cursor buttons of the remote

controller and press ENTER to confirm your selection. To

return to the previous screen, press RETURN.

 Playing Back

1. Press NET on the remote controller. The NET TOP

screen displays and the "NET" indicator on the unit’s

display lights. To display the NET TOP screen, you can

alternatively press HOME, select "Network Service" on

the displayed Home menu, and then press ENTER.

2. With the cursors on the remote controller, select

"Pandora", and then press ENTER.

3. Use / to select "I have a Pandora Account" or "I’m new

to Pandora" and then press ENTER.

If you are new to Pandora select "I’m new to Pandora".

You will see an activation code on your TV screen.

Please write down this code. Go to an Internet

connected computer and point your browser to www.

pandora.com/onkyo. Enter your activation code and then

follow the instructions to create your Pandora account

and your personalized Pandora stations. You can create

your stations by entering your favorite tracks and artists

when prompted. After you have created your account

and stations you can return to your Onkyo receiver

and press enter to begin listening to your personalized

Pandora.

If you have an existing Pandora account, you can

add your Pandora account to your Onkyo receiver by

selecting "I have a Pandora Account" and logging in with

your email and password.

• If you want to use multiple user accounts, see "Using

Multiple Accounts". Login can be made from the

"Users" screen.

4. To play a station, use / to select the station from your

station list, and then press ENTER. Playback starts and

the playback screen appears.

 Create a New Station

Enter the name of a track, artist, or genre and Pandora will

create a unique radio station for you based on the musical

qualities of that track, artist, or genre.

I like this track: Give a track "thumbs-up" and Pandora

will play more music like it.

I don’t like this track: Give a track "thumbs-down" and

Pandora will ban that track from the current station.

Why is this track playing?: Discover some of the

musical attributes that Pandora uses to create your

personal radio stations.

I’m tired of this track: If you are tired of a track, you

can put the track to sleep and Pandora will not play it for

one month.

Create station from this artist: Creates a radio station

from this artist.

Create station from this track: Creates a radio station

from this track.

Delete this station: This will permanently delete a

station from your Pandora account. All of your thumbs

feedback will be lost should you choose to re-create the

station with the same track or artist.

Rename this station: Lets you rename the current radio

station.

Bookmark this artist: Pandora will bookmark your

favorite artist for your profile on www.pandora.com.

Bookmark this track: Pandora will bookmark the

current track and allow you to buy them all from Amazon

or iTunes in one step!

Add to My Favorites: Adds a station to My Favorites

list.

PANDORA, the PANDORA logo, and the Pandora trade

dress are trademarks or registered trademarks of Pandora

Media, Inc. Used with permission.

Listening to Internet Radio

7

SiriusXM Internet Radio (North American only)

If you want to listen to the service, you must subscribe. To

subscribe go to www.siriusxm.com/internetradio with your

computer. When you subscribe, you will be provided with

a username and password which has to be entered into

the AV receiver. To use SiriusXM Internet Radio, you must

have your AV receiver connected to the Internet. Using the

remote control, follow these steps:

 Operation: You can set up by viewing the guidance

displayed on the TV screen. To display the guidance, you

need to make HDMI connection between the unit and

TV. Select the item with the cursor buttons of the remote

controller and press ENTER to confirm your selection. To

return to the previous screen, press RETURN.

 Playing Back

1. Press NET on the remote controller to display NET TOP

screen.

• "NET" indicator on the unit’s display lights. To display

the NET TOP screen, you can alternatively press

HOME, select "Network Service" on the displayed

Home menu, and then press ENTER.

2. With the cursors on the remote controller, select

"SiriusXM Internet Radio", and then press ENTER.

3. Select "Sign In", and then press ENTER. If you have an

existing SIRIUS account, you can sign in by selecting

"Sign In". Enter your user name and password in the

next keyboard screen, or in Web Setup. If you don’t

know your username or password, call Sirius XM at

(888) 539-7474 for assistance.

• If you want to use multiple user accounts, see "Using

Multiple Accounts". Login can be made from the

"Users" screen.

Using the keyboard screen

1 Use / / / and ENTER to enter your user name

and password.

2 Select "OK".

3 Press ENTER. The "Confirm your entries" screen

appears.

4 Press ENTER. "Please wait..." appears and then

"SiriusXM Internet Radio" screen appears which

displays the category available for selection.

4. Use / to select the category and then press ENTER.

The channel list screen for the selected category

appears.

5. Use / to select the desired channel and then press

ENTER.

The playback screen for the selected channel appears

and you can listen to SiriusXM Internet Radio. You can

control the tracks with the buttons on the remote control.

Enabled buttons: , , ,

Add to My Favorites: Adds a channel to My Favorites

list.

Add to Presets: Adds the currently playing station to

presets list.

Delete from Presets: Deletes the currently playing

station from presets list.

SiriusXM Internet Radio subscriptions are sold separately

and are governed by the Sirius Terms and Conditions (see

www.sirius.com). Be sure to read this agreement before you

purchase your subscription.

Sirius, XM and all related marks and logos are trademarks

of Sirius XM Radio Inc. and its subsidiaries. All rights

reserved.

Listening to Internet Radio

8

Slacker Personal Radio (North American only)

 Operation: You can set up by viewing the guidance

displayed on the TV screen. To display the guidance, you

need to make HDMI connection between the unit and

TV. Select the item with the cursor buttons of the remote

controller and press ENTER to confirm your selection. To

return to the previous screen, press RETURN.

 Playing Back

1. Press NET on the remote controller to display NET TOP

screen.

• "NET" indicator on the unit’s display lights. To display

the NET TOP screen, you can alternatively press

HOME, select "Network Service" on the displayed

Home menu, and then press ENTER.

2. With the cursors on the remote controller, select

"Slacker Personal Radio", and then press ENTER.

3. If you do not have an account, create one on the Slacker

website (www.slacker.com) with your computer. If you

already have a Slacker account, select "Sign in to your

account" and then press ENTER. The keyboard screen

appears. You can enter information from the remote

control or the keys on the main unit.

4. If there are no mistakes in the information you have

entered, use / / / to select "OK" then press ENTER.

An account information confirmation screen appears.

5. If you do not have an account, select "Access without

Sign In" and press ENTER to use a restricted version of

the service. Note that use will be restricted.

• If you want to use multiple user accounts, see "Using

Multiple Accounts". Login can be made from the

"Users" screen.

6. Use / to select a menu item and then press ENTER.

To sign out, use / to select "Sign out" from this screen

and then press ENTER.

7. Use / to select a station and then press ENTER or

to start playback from the station. The playback screen

appears.

8. You can control the tracks with the buttons on the

remote control.

Enabled buttons: , , ,

Rate Song as Favorite: Stores information to server,

making it more likely that the song will be played again.

Ban Song: Stores information to server, making it less

likely that the song will be played again.

Ban Artist: Stores information to server, making it less

likely that the songs from this artist will be played again.

Mark Favorite: Adds the currently playing station to your

favorites.

Unmark Favorite: Deletes the currently playing station

from your favorites.

Add song to Library: Adds the currently playing track to

your library.

Delete song from Library: Deletes the currently playing

track from your library.

Add to My Favorites: Adds a station or song to My

Favorites list.

Using Multiple Accounts: The AV receiver supports

multiple user accounts, which means you can freely switch

between several logins. After registering user accounts,

login is performed from the "Users" screen.

Press MENU while the Users screen is displayed. "Add

new user", "Remove this user" menu appear. You can either

store a new user account, or delete an existing one.

• Some of the services don’t allow the use of multiple user

accounts.

• You can store up to 10 user accounts.

• To switch between accounts you must first log out from

the current account, and log in again on the "Users"

screen.

Listening to Internet Radio

9

Registering Other Internet Radios

To listen to other Internet radio program, register the

program in the "My Favorites" list on the NET TOP screen

as described below. The unit supports Internet radio stations

stored in the following formats: PLS (URL ending in .pls),

M3U (URL ending in .m3u) and RSS (URL ending in rss/rdf/

xml).

• You can register up to 40 Internet radio stations.

• Depending on the data type and file format for playback,

you may not be able to play an Internet radio station

even when its format is PLS, M3U or Podcast (RSS).

• Available services may vary depending on your area of

residence.

 Operation: You can set up by viewing the guidance

displayed on the TV screen. To display the guidance, you

need to make HDMI connection between the unit and

TV. Select the item with the cursor buttons of the remote

controller and press ENTER to confirm your selection. To

return to the previous screen, press RETURN.

 Registering a Station

Before operation: The name and URL of the additional

radio station will be needed for this procedure. Check the

specifications before use.

1. Press NET on the remote controller to display NET TOP

screen.

• "NET" lights on the display.

2. With the cursors, select "My Favorites", and then press

ENTER to display the "My Favorites" list screen.

3. With the cursors, select a blank area of "My Favorites"

and press MENU to display the menu screen.

4. With the cursors, select "Create new station", and then

press ENTER to display a keyboard screen.

5. Enter the name and URL of the radio station to add.

• Select "Shift" and press ENTER to toggle between

upper and lower case. Select " " or " " and press

ENTER to move the cursor to the selected direction.

Select "Back Space" and press ENTER to remove a

character on the left of the cursor.

 Registering a Station with PC

Before operation: The name and URL of the additional

radio station will be needed for this procedure. Check the

specifications before use.

1. Press RCV on the remote controller.

• Always press RCV first to change the remote

controller to RECEIVER mode (the mode to operate

this unit) since its mode may be changed to operate

another component.

2. Press HOME to display the Home menu.

3. With the cursors, select "Setup", and then press ENTER.

4. With the cursors, select "7.Hardware Setup" - "Network"

- "IP Address" to display the IP address.

• Write down the IP address since you will need it later.

5. Open the Internet browser on your PC or smartphone

and enter the IP address of the unit in the URL field.

Information of the unit is displayed on the browser.

("WEB Setup")

• If you are using Internet Explorer, you can also enter

the URL by selecting "Open..." on the "File" menu.

6. Click "My Favorites" tab, then enter the name and URL

of the Internet radio station.

7. Click "Save" to register the entered Internet radio station

in "My Favorites".

Listening to Internet Radio

10

To rename the registered radio station: While the radio

station is being played or when it is selected from the "My

Favorites" list, press MENU to display the menu screen.

Select "Rename this station" with the cursors and press

ENTER to display the keyboard screen. Rename the station

as desired.

• Radio stations can be renamed also from "WEB Setup".

 Playing a Registered Radio Station

1. Press NET on the remote controller to display NET TOP

screen.

• "NET" lights on the display.

2.

With the cursors, select "My Favorites", and then press

ENTER to display the registered Internet radio stations.

3. With the cursors, select the radio station to delete and

press MENU to display the menu screen.

 Deleting a Registered Radio Station

1. Press NET on the remote controller to display NET TOP

screen.

• "NET" lights on the display.

2. With the cursors, select "My Favorites", and then press

ENTER to display the registered Internet radio stations.

3. With the cursors, select the radio station to delete and

press MENU to display the menu screen.

• You can also display the menu screen by pressing

MENU while the radio station is being played.

4. With the cursors, select "Delete from My Favorites", and

then press ENTER.

• Radio stations can be deleted also from "WEB

Setup".

DLNA Music Streaming

11

DLNA Music Streaming

About DLNA

Digital Living Network Alliance (DLNA) can be referred to

as a technology standard or the industry group to develop

the technology standard to interconnect and use AV

components, PCs and other devices in a home network

(more precisely the technology standard is called the DLNA

guidelines).

The unit allows you to use DLNA to play music files stored

on a PC or a hard disk connected to your home network

(NAS device). Make sure the unit and PC or NAS device

are connected to the same router.

Internet radio

NAS

Router PC

• To play a music file with DLNA, you need a NAS device

or the like with DLNA server functions and a DLNA

player (software) to stream the music. You can also

stream music files using a PC installed with Windows

Media Player 11 or 12 as they are equipped with both

DLNA server and player functions. To enable streaming,

you must first configure the Windows Media Player 11 or

Windows Media Player 12.

• With Windows Media Player 12 Remote Playback

function, you can stream music files stored on your PC

to the unit by operating the PC.

Configuring the Windows Media Player

 Windows Media Player 11

1. Turn on your PC and start Windows Media Player 11.

2. In the "Library" menu, select "Media Sharing" to open a

dialog box.

3. Select the "Share my media" check box, and then click

"OK" to display a list of supported devices.

4. Select this unit, and then click "Allow". The

corresponding icon is checked.

5. Click "OK" to close the dialog.

 Windows Media Player 12

1. Turn on your PC and start Windows Media Player 12.

2. Click "Turn on media streaming" to display a list of

players in the network.

• If media streaming is already turned on, select "More

streaming options..." in the "Stream" menu to list

players in the network. Proceed to step 4.

3. Click "Turn on media streaming". A list of players in the

network is displayed.

4. Select this unit in "Media streaming options" and check

that it is set to "Allow".

5. Click "OK" to close the dialog.

DLNA Playback

 Operation: You can set up by viewing the guidance

displayed on the TV screen. To display the guidance, you

need to make HDMI connection between the unit and

TV. Select the item with the cursor buttons of the remote

controller and press ENTER to confirm your selection. To

return to the previous screen, press RETURN.

 Playing Back

1. Start the server (Windows Media Player 11, Windows

Media Player 12, or NAS device) storing the music files

to play.

2. Press NET on the remote controller to display NET TOP

screen.

• "NET" lights on the display. If the "NET" indicator

flashes, the unit is not properly connected to the

network. When using a wired LAN connection, check

the Ethernet cable connection, and when using a

wireless LAN connection, check whether the "Wi-Fi"

indicator on the left side of the unit stays lit.

3. Select "DLNA" with the cursors and press ENTER.

4. With the cursors, select the target server, and then press

ENTER to display a list of items on the selected server.

• Searching does not work in servers that do not

support search functions.

• The unit cannot access pictures and videos stored

on servers.

• Contents stored on the server may not be displayed

depending on the server sharing settings.

DLNA Music Streaming

12

5. With the cursors, select the music file to play, and then

press ENTER or to start playback.

• If "No Item" is displayed, check whether the network

is properly connected.

Controlling Remote Playback from a PC

You can use this unit to play music files stored on your PC

by operating the PC inside your home network. The unit

supports remote playback with Windows Media Player 12.

To use the remote playback function with Windows Media

Player 12, Windows Media Player 12 must be configured in

advance.

• Using a DLNA-compatible controller (such as an

Android application), you can select a music file stored

on Windows Media Player 12 and stream to this unit

by operating the controller. For information on how to

remotely play using the controller, refer to the controller's

instruction manual.

 Setting PC

1. Turn on your PC and start Windows Media Player 12.

2. In the "Stream" menu, select "Turn on media streaming"

to open a dialog box.

• If media streaming is already turned on, select "More

streaming options..." in the "Stream" menu to list

players in the network. Proceed to step 4.

3. Click "Turn on media streaming" to display a list of

players in the network.

4. Select this unit in "Media streaming options" and check

that it is set to "Allow".

5. Click "OK" to close the dialog box.

6. Open the "Stream" menu and check that "Allow remote

control of my Player..." is checked.

 Remote playback

1. Turn on the power of the unit.

2. Turn on your PC and start Windows Media Player 12.

3. Select the music file to play with Windows Media Player

12 and right-click.

• To remotely play a music file on another server, open

the target server from "Other Libraries" and select

the music file to play.

4. Select this unit in "Play to" and open the "Play to"

window of Windows Media Player 12 to start to playback

music file on the unit.

• Operations during remote playback are possible from

the "Play to" window on the PC. The playback screen

is displayed on the TV connected to the HDMI output

of the unit. If your PC is running on Windows 8, click

"Play to", and then select this unit.

5.

Adjust the volume using the volume bar on the "Play to"

window.

• Some times, the volume displayed on the remote

playback window may differ from that appeared on

the display of the unit.

• When the volume is adjusted from the unit, the value

is not reflected in the "Play to" window.

• This unit cannot play music files remotely in the

following conditions.

– It is using a network service.

– It is playing a music file on a USB storage device.

– "Agree" was not selected in the DISCLAIMER

screen that was displayed when the NET input

was selected on the unit for the first time.

Music Streaming from a Shared Folder

13

Music Streaming from a Shared

Folder

About Shared Folder

A shared folder is configured in a network device such as a

PC or NAS (hard disk connected to your home network) for

access from other users.

You can play music files in a shared folder on your PC or

NAS connected to the same home network as that of the

unit. To play music files in a shared folder, you must first

configure Windows 8 or Windows 7, Make sure the unit and

PC or NAS device are connected to the same router.

Internet radio

NAS

Router PC

• The sharing options must be configured and a shared

folder created on the PC in advance.

• For information on how to configure the NAS device

and create a shared folder, refer to the NAS device's

instruction manual.

Setting PC

 Configuring the Sharing Options

1. Select "Choose Home group and Sharing Options" on

the "Control Panel".

• If the menu is not displayed, check whether "View

by" is set to "Category".

2. Select "Change advanced sharing settings".

3. Check whether the following radio buttons are selected

in "Home or Work":

"Enable network discovery"

"Turn on file and printer sharing"

"Turn on sharing so anyone with network access can

read and write files in the Public folders"

"Turn off password protected sharing"

4. Select "Save Changes" and click "OK" on the dialog box.

 Creating a Shared Folder

1. Select the folder to share and right-click.

2. Select "Properties".

3. Select "Advanced Sharing" on the "Sharing" tab.

4. Select the "Share this folder" check box and click "OK".

5. Select "Share" for "Network File and Folder Sharing".

6. Select "Everyone" from the pull-down menu. Click "Add",

and then "Share".

• To set user name and password to a shared folder,

set "Permissions" in "Advanced Sharing" on the

"Sharing" tab.

• Check whether a workgroup is set.

Playing from a Shared Folder

 Operation: You can set up by viewing the guidance

displayed on the TV screen. To display the guidance, you

need to make HDMI connection between the unit and

TV. Select the item with the cursor buttons of the remote

controller and press ENTER to confirm your selection. To

return to the previous screen, press RETURN.

 Playing Back

1. Press NET on the remote controller to display NET TOP

screen.

• "NET" lights on the display.

• If the "NET" indicator flashes, the unit is not properly

connected to the network. When using a wired LAN

connection, check the Ethernet cable connection,

and when using a wireless LAN connection, check

whether the "Wi-Fi" indicator on the left side of the

unit is lit.

Music Streaming from a Shared Folder

14

2. With the cursors, select "Home Media", and then press

ENTER.

3. With the cursors, select the target server, and then press

ENTER.

• You can check the server name of your PC from the

PC properties.

4. With the cursors, select the target shared folder, and

then press ENTER.

5. If a username and password is required, enter the

necessary login information.

• The login information is the account information set

at the time of creating the shared folder.

• Once entered, the login information will be

remembered from the next time onward.

6. With the cursors, select the music file to play, and then

press ENTER or to start playback.

Using Remote Controller for Playing Music Files

15

Using Remote Controller for

Playing Music Files

About the Remote Controller

The remote controller of this unit allows you to play music

files stored on USB storage devices, Internet radio, PCs

and NAS devices on your home network, as well as on

Bluetooth-enabled devices. It also allows you to view

information of the music file being played and perform

various other operations.

• Available buttons may vary depending on the service

and device to play.

• Some buttons cannot be used with Bluetooth-enabled

devices. Furthermore, the Bluetooth-enabled devices

must support the AVRCP profile. Some devices may not

be operated, even when they support AVRCP profile.

Remote Controller Buttons

1. Press INPUT SELECTOR (PC, NET, USB or

BLUETOOTH) appropriate for the input source on the

remote controller.

2. Operate the remote controller by referring to the name

and function of each of the buttons below.

1

5

6

7

8

9

2

3

4

1 TOP MENU: This button displays the top menu for

each media or server.

2 / , ENTER: These buttons navigate through items

and activate the selected item.

/: These buttons cycle through pages.

3 : This button fast-reverses the current track. This

button is not operable from 10 seconds before the

playback ends.

4 : This button plays the current track from the

beginning. Pressing this button twice plays the

previous track.

5 CH +/- button: Moves the cursor on the Internet

radio stations list in "My Favorites".

6 MENU: This button displays the menu of each

Internet radio service.

7 RETURN: This button returns to the previous screen.

8 : This button fast-forwards the current track. This

button is not operable from 10 seconds before the

playback ends.

9 : This button plays the next track.

FI

J

K

L

G

H

F : This button starts the playback.

G : This button pauses the playback.

H SEARCH: This button toggles between the playback

screen and list screen during playback.

I : This button stops the playback.

J RANDOM: This button performs random playback.

K REPEAT: This button replays the track(or tracks).

Pressing this button repeatedly cycles through the

repeat modes.

L DISPLAY: This button changes the displayed track

information during playback. Pressing this button

when the list screen is displayed toggles the screen

to playback.

• Bluetooth-enabled devices: Usable buttons are

, , , , , , and .

Icons Displayed during Playback

Icons are displayed on the display during music file

playback. The meaning of each icon is as follows:

: Folder

: Tra ck

: Play

: Pause

: Fast-forward

: Fast-reverse

: Artist

: Album

: Repeat One Track

: Repeat within a folder

: Repeat

: Shuffle

Using the Listening Modes

16

Using the Listening Modes

Selecting Listening Mode

The listening modes allow you to select the best sound

effect for your input source.

1. Press RCV on the remote controller.

• Always press RCV first to change the remote

controller to RECEIVER mode (the mode to operate

this unit) since its mode may be changed to operate

another component.

2. Press one of the following buttons depending on your

choice from among the four listening modes.

• Pressing a button changes the listening mode to that

chosen. Set the listening mode of your choice by

listening to the actual sound.

For details on the types and difference of listening

modes, see "Contents of Listening Modes".

 MOVIE/TV button

You can select a mode suitable for movies and TV

programs.

• Selectable listening modes:

All Ch Stereo

Direct

Dolby D

Dolby D+

Dolby EX/Dolby D EX

Dolby TrueHD

DSD

DTS

DTS 96/24

DTS Express

DTS-HD HR

DTS-HD MSTR

ES Discrete

ES Matrix

Full Mono

Mono

Multichannel

Neo:6

Neo:6 Cinema

PLII Movie

PLIIx Movie/PLII Movie

PLIIz Height

T- D

TV Logic

 MUSIC button

You can select a mode suitable for music.

• Selectable listening modes:

All Ch Stereo

Direct

Dolby D

Dolby D+

Dolby EX/Dolby D EX

Dolby TrueHD

DSD

DTS

DTS 96/24

DTS Express

DTS-HD HR

DTS-HD MSTR

ES Discrete

ES Matrix

Full Mono

Multichannel

Neo:6

Neo:6 Music

Orchestra

PLII Music

PLIIx Music/PLII Music

PLIIz Height

Pure Audio

Stereo

Studio-Mix

Unplugged

 GAME button

You can select a mode suitable for games.

• Selectable listening modes:

All Ch Stereo

Direct

Dolby D

Dolby D+

Dolby EX/Dolby D EX

Dolby TrueHD

DSD

DTS

DTS 96/24

DTS Express

DTS-HD HR

DTS-HD MSTR

ES Discrete

ES Matrix

Full Mono

Neo:6

Game-Action

Game-Rock

Game-RPG

Game-Sports

Multichannel

PLII Game

PLIIx Game/PLII Game

PLIIz Height

T- D

17

Using the Listening Modes

 STEREO button

You can select a listening mode for stereo and all channel

stereo sources.

• Selectable listening modes:

All Ch Stereo

Stereo

 PURE AUDIO button (on the main unit only)

(European, Australian and Asian models)

The display and analog video circuit is cut off to switch

the unit to PURE AUDIO mode (European, Australian

and Asian models) and provide purer sound. Selecting

this mode lights the PURE AUDIO indicator on the unit.

Pressing the button again reselects the previous listening

mode.

• Selecting Pure Audio for listening mode turns off the

display and analog video circuitry, but the video signals

input through HDMI input are output from HDMI output.

Contents of Listening Modes

Selectable listening modes will differ depending on the

number of input source channels and the actual speaker

configuration. Listening modes available when headphones

are connected are: Pure Audio (European, Australian and

Asian models), Mono, Direct, and Stereo.

Lists in alphabetic order (A-Z)

 All Ch Stereo

Ideal for background music, this mode fills the entire

listening area with stereo sound from the front, surround,

and surround back speakers.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

 Direct

In this mode, audio from the input source is output as-is.

For example, if a 2 ch source from a music CD is input, the

output will be stereo, or if Dolby Digital signal is input, the

sound field will be controlled in accordance with the number

of channels present.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 2.1 ch, 3.1 ch, 5.1 ch, 7.1 ch

 Dolby D (Dolby Digital)

This mode is for use with Dolby Digital sources. The audio

from the input source is output as-is, without surround

sound processing.

• Input source: 5.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

 Dolby D + (Dolby Digital Plus)

This mode is for use with Dolby Digital Plus sources.

The audio from the input source is output as-is, without

surround sound processing.

• Input source: 5.1 ch, 7.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

• When playing back 5.1 ch sources from Blu-ray Discs,

Dolby Digital is automatically applied.

 Dolby EX/Dolby D EX

This mode expands any 5.1 ch music or movie source for

6.1/7.1 ch playback that can give an effect of surround

back speaker. It is suitable for the Dolby EX soundtrack

containing the matrix-encoded surround back channel.

Adding the surround back effect to 5.1 ch source will

improve spatial representation by creating a moving sound

effect of 360-degree surround sound or overhead sound

and giving a realistic experience.

• Input source: 5.1 ch

• Speaker configuration: 7.1 ch surround back

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

 Dolby Pro Logic IIx/Dolby Pro Logic II

This mode expands any 2 ch source for 7.1-ch playback.

It provides a very natural and seamless surround-sound

experience, keeping the sound clear.

• In case of 5.1 ch without surround back speaker, the

mode becomes Dolby Pro LogicII instead of Dolby Pro

Logic IIx.

– PLIIx Movie/PLII Movie: Use this mode with any 2 ch

movie (e.g., TV, DVD, VHS).

– PLIIx Music/PLII Music: Use this mode with any 2 ch

music source (e.g., CD, radio, cassette, TV, DVD, VHS).

– PLIIx Game/PLII Game: Use this mode with any 2 ch

game source.

• Input source: STEREO, 5.1 ch (PLIIx Movie and PLIIx

Music only)

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch, 7.1 ch

surround back (PLIIx Movie and PLIIx Music only)

 Dolby TrueHD

This mode is for use with Dolby TrueHD sources. The audio

from the input source is output as-is, without surround

sound processing.

• Input source: 7.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

 DSD

This mode is for use with DSD sources. The audio from

the input source is output as-is, without surround sound

processing.

Using the Listening Modes

18

• Input source: 5.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

• This unit supports DSD signals input through HDMI IN.

However, depending on the connected player, better

sound is possible when output from the PCM output of

the player. In that case, configure the player for PCM

output.

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

 DTS

This mode is for use with DTS sources. The audio from

the input source is output as-is, without surround sound

processing.

• Input source: 5.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

 DTS 96/24

This mode is for use with DTS 96/24 sources. The audio

from the input source is output as-is, without surround

sound processing. With 96 kHz sampling rate and 24-bit

resolution, it provides superior fidelity.

• Input source: 5.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

• Depending on the settings, this listening mode becomes

DTS.

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

 DTS Express

This mode is for use with DTS Express sources. The audio

from the input source is output as-is, without surround

sound processing.

• Input source: 5.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

 DTS-HD HR (DTS-HD High Resolution Audio)

This mode is for use with DTS-HD High Resolution Audio

sources. The audio from the input source is output as-is,

without surround sound processing.

• Input source: 5.1 ch, 7.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

 DTS-HD MSTR (DTS-HD Master Audio)

This mode is for use with DTS-HD Master Audio sources.

The audio from the input source is output as-is, without

surround sound processing.

• Input source: 5.1 ch, 7.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

 DTS Neo:6

This mode expands any 2 ch source for 5.1 ch multichannel

surround playback. It offers full-bandwidth on all channels,

with great independence between the channels. There are

two variants for this mode: one ideal for movies and another

ideal for music.

– Neo:6 Cinema: Use this mode with any 2 ch movie (e.g.,

TV, DVD, VHS).

– Neo:6 Music: Use this mode with any 2 ch music source

(e.g., CD, radio, cassette, TV, DVD, VHS).

– Neo:6: Use this mode to expand any 5.1 ch music

source for 6.1 ch or 7.1 ch playback using Neo:6.

• Input source: STEREO (Neo:6 Cinema and Neo:6 Music

only), 5.1 ch (Neo:6 only)

Speakerconfiguration:3.1ch,5.1ch,7.1ch(Neo:6

Cinema and Neo:6 Music only), 7.1 ch surround back

(Neo:6 only)

 ES Discrete (DTS-ES Discrete)

This mode is for use with DTS-ES Discrete sources and

enables 6.1 ch or 7.1 ch playback using surround back

channel. Completely discrete seven channels will improve

spatial imaging and enable 360-degree sound localization

producing a sound crossing between the surround

channels.

• Input source: 6.1 ch

• Speaker configuration: 7.1 ch surround back

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

• Use on the DVD with DTS ES logo, particularly on the

software containing DTS-ES Matrix soundtrack.

• Playback becomes DTS if no surround back speaker is

connected.

 ES Matrix (DTS-ES Matrix)

This mode is for use with DTS-ES Matrix soundtrack and

enables 6.1 ch or 7.1 ch playback using matrix-encoded

back channel.

• Input source: 6.1 ch

• Speaker configuration: 7.1 ch surround back

• This listening mode can be selected only if your Blu-ray

Disc/DVD player is digitally connected to the unit or the

player's output setting is bitstream.

• Use on the CD, DVD or LD with DTS ES logo,

particularly on the software containing DTS-ES Matrix

soundtrack.

• Playback becomes DTS if no surround back speaker is

connected.

 Full Mono

In this mode, all speakers output the same sound in mono,

so the sound you hear is the same regardless of where you

are within the listening room.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

 Game-Action

In this mode, sound localization is distinct with emphasis on

bass.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 5.1 ch, 7.1 ch

 Game-Rock

In this mode, sound pressure is emphasized to heighten

live feel.

19

Using the Listening Modes

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 5.1 ch, 7.1 ch

 Game-RPG

In this mode, the sound has a dramatic feel with a similar

atmosphere to Orchestra mode.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 5.1 ch, 7.1 ch

 Game-Sports

Suitable for audio source with much reverberation.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 5.1 ch, 7.1 ch

 Mono

Use this mode when watching an old movie with a mono

soundtrack, or use it to separately reproduce soundtracks

in two different languages recorded in the left and right

channels of some movies. It is also suitable for DVDs or

other sources containing multiplexed audio.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 2.1 ch, 3.1 ch, 5.1 ch, 7.1 ch

 Multichannel

This mode is for use with PCM multichannel sources.

The audio from the input source is output as-is, without

surround sound processing.

• Input source: 5.1 ch, 7.1 ch

• Speaker configuration: 3.1 ch, 5.1 ch, 7.1 ch

 Orchestra

Suitable for classical or operatic music, This mode

emphasizes the surround channels in order to widen the

stereo image, and simulates the natural reverberation of a

large hall.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 5.1 ch, 7.1 ch

 PLIIz Height (Dolby Pro Logic IIz Height)

This mode allows you to effectively use the existing

programs when height speakers are connected. It is

suitable for various kinds of sources including movie, music

and especially games.

• Input source: STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 7.1 ch height

 Pure Audio (European, Australian and Asian

models)

This mode reproduces the original sound accurately. Since

the audio from the input source is output without surround

sound processing and the display and video circuitry are

turned off, possible noise sources are minimized for a

realistic audio reproduction.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 2.1 ch, 3.1 ch, 5.1 ch, 7.1 ch

• This mode cannot be selected when Zone 2 is

active. Activating Zone 2 when this mode is selected,

automatically switches the listening mode to Direct.

 Stereo

In this mode, sound is output from the front left and right

speakers and subwoofer.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 2.1 ch, 3.1 ch, 5.1 ch, 7.1 ch

 Studio-Mix

Suitable for rock or pop music, Listening to music in this

mode creates a lively sound field with a powerful acoustic

image, like being at a club or rock concert.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 5.1 ch, 7.1 ch

 T-D (Theater-Dimensional)

In this mode, you can enjoy a virtual playback of

multichannel surround sound even with only two or three

speakers. This works by controlling how sounds reach the

listener’s left and right ears.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 2.1 ch, 3.1 ch, 5.1 ch, 7.1 ch

• Good results may not be possible if there is too much

reverb, so we recommend that you use this mode in an

environment with little or no natural reverb.

 TV Logic

Suitable for TV shows produced in a TV studio, This mode

enhances the surround effects to the entire sound to give

clarity to voices and create a realistic acoustic image.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 5.1 ch, 7.1 ch

 Unplugged

Suitable for acoustic instruments, vocals and jazz, This

mode emphasizes the front stereo image, giving the

impression of being right in front of the stage.

• Input source: MONO, STEREO, 5.1 ch, 7.1 ch

• Speaker configuration: 5.1 ch, 7.1 ch

Checking the Input Format

You can check the audio format of the input signals. While

audio from the player is being input, press DISPLAY on the

remote controller several times to switch the information

shown on the main unit display. If "Dolby D 5.1" is displayed

in Signal format, the Dolby Digital 5.1 ch signals are being

input.

Advanced Settings

20

Advanced Settings

How to Set

The unit allows you to configure advanced settings, such as

to remap the input and input selector, or configure various

speaker settings in order to provide even better experience.

Make the settings in "Setup" of the Home menu.

 Operation: You can set up by viewing the guidance

displayed on the TV screen. To display the guidance, you

need to make HDMI connection between the unit and

TV. Select the item with the cursor buttons of the remote

controller and press ENTER to confirm your selection. To

return to the previous screen, press RETURN. To return to

the Home menu, press HOME.

 Operation

1. Press RCV on the remote controller.

• Always press RCV first to change the remote

controller to RECEIVER mode (the mode to operate

this unit) since its mode may be changed to operate

another component.

2. Press HOME to display the Home menu.

3. With the / cursors, select "Setup", and then press

ENTER.

Setup

HOME

4. Press / to select the desired menu, and then press

ENTER.

SETUP

1. Monitor Out

2. HDMI Input

3. Component Video Input

4. Composite Video Input

5. Digital Audio Input

1. Input/Output Assign

5. With the / / / cursors, select the desired item to

configure the settings.

• When "ENTER" is displayed on the setting item,

press ENTER.

Monitor Out

Resolution

Select which HDMI output you connected to TV. HDCP 2. 2 is available for MAIN output.

MAIN

Through

1-1. Monitor Out

To save changes and finish the setting: Press HOME to

exit.

Advanced Settings

21

1.Input/Output Assign

Monitor Out

The video input signals input to the unit will be converted when they are output from the

HDMI OUT jack to the TV so that their resolution can match that of the TV used.

Setting item Default Value Setting Details

Monitor Out MAIN Select the HDMI jack to be connected with the

T V.

"MAIN": When connecting the TV to the HDMI

OUT MAIN jack

"SUB": When connecting the TV to the HDMI

OUT SUB jack

• The resolution of the input signal does not

change when output through HDMI OUT

SUB jack.

"MAIN+SUB": When connecting to both the

MAIN and SUB jacks

• Video signals input to the composite video

input jack or the COMPONENT VIDEO input

jacks will be upconverted to HDMI signals

and then output from the HDMI output jack.

• If "MAIN+SUB" is selected

– Only "Through" or "Auto" can be selected

in "Resolution".

– The resolution of the input signal does not

change when output through HDMI OUT

SUB jack.

• HDCP2.2 protected video from HDMI OUT

SUB will not be displayed.

Setting item Default Value Setting Details

Resolution Through Specify the output resolution of the HDMI OUT

jacks. The image resolution of the unit will be

converted so that it can match the resolution

supported by the TV used.

"Through": The output resolution will be the

same as that of the input signals.

"Auto": The resolution will automatically be

converted according to the resolution supported

by the TV.

"480p (480p/576p)", "720p", "1680×720p",

"1080i", "1080p", "2560×1080p": Select the

desired resolution.

"4K": About four times as high resolution

as 1080p (3840×2160 or 4096×2160 pixels

depending on the resolution supported by the

connected TV)

• If "1080p" is selected, 1080p/24 input signals

will be output with an unchanged resolution.

• If the selected resolution is not supported

by the monitor, the video is displayed in the

same resolution as the input signal.

• If "4K" is selected, video signals may not

be output to some types of TV. For details,

see "Regarding the Video Resolution" in

"Troubleshooting".

• If "Monitor Out" is set to "SUB", this setting

will be set to "Through".

• Press ENTER if you output signals from the

HDMI OUT MAIN jack and check the video

on the TV while making this setting. Press

RETURN if no video is displayed. (except

when "NET", "USB" or "BLUETOOTH" is

selected)

Advanced Settings

22

HDMI Input

It is possible to change assignment of input selector buttons and the HDMI IN jacks.

Setting item Default Value Setting Details

BD/DVD HDMI 1 "HDMI 1" to "HDMI 6": Desired HDMI IN jack

can be assigned to BD/DVD button. If you do not

assign a jack, select "-----". To select an HDMI IN

jack already assigned to another input selector,

change its setting to "-----" first.

CBL/SAT HDMI 2 "HDMI 1" to "HDMI 6": Desired HDMI IN jack

can be assigned to CBL/SAT button. If you do

not assign a jack, select "-----". To select an

HDMI IN jack already assigned to another input

selector, change its setting to "-----" first.

STB/DVR HDMI 3

(HDCP2.2)

"HDMI 1" to "HDMI 6": Desired HDMI IN jack

can be assigned to STB/DVR button. If you do

not assign a jack, select "-----". To select an

HDMI IN jack already assigned to another input

selector, change its setting to "-----" first.

GAME HDMI 4 "HDMI 1" to "HDMI 6": Desired HDMI IN jack

can be assigned to GAME button. If you do not

assign a jack, select "-----". To select an HDMI IN

jack already assigned to another input selector,

change its setting to "-----" first.

PC HDMI 5 "HDMI 1" to "HDMI 6": Desired HDMI IN jack

can be assigned to PC button. If you do not

assign a jack, select "-----". To select an HDMI IN

jack already assigned to another input selector,

change its setting to "-----" first.

AUX FRONT/MHL The setting cannot be changed.

TV/CD ----- "HDMI 1" to "HDMI 6": Desired HDMI IN jack

can be assigned to TV/CD button. If you do not

assign a jack, select "-----". To select an HDMI IN

jack already assigned to another input selector,

change its setting to "-----" first.

PHONO ----- "HDMI 1" to "HDMI 6": Desired HDMI IN jack

can be assigned to PHONO button. If you do not

assign a jack, select "-----". To select an HDMI IN

jack already assigned to another input selector,

change its setting to "-----" first.

Component Video Input

CBL/SAT button is assigned to COMPONENT VIDEO IN jack as factory default setting. This

assignment can be changed if necessary. If you do not assign a jack, select "-----".

Setting item Default Value Setting Details

BD/DVD ----- "COMPONENT": COMPONENT VIDEO IN jack

is assigned to BD/DVD button.

CBL/SAT COMPONENT "COMPONENT": COMPONENT VIDEO IN jack

is assigned to CBL/SAT button.

STB/DVR ----- "COMPONENT": COMPONENT VIDEO IN jack

is assigned to STB/DVR button.

GAME ----- "COMPONENT": COMPONENT VIDEO IN jack

is assigned to GAME button.

PC ----- "COMPONENT": COMPONENT VIDEO IN jack

is assigned to PC button.

AUX ----- The setting cannot be changed.

TV/CD ----- "COMPONENT": COMPONENT VIDEO IN jack

is assigned to TV/CD button.

PHONO ----- "COMPONENT": COMPONENT VIDEO IN jack

is assigned to PHONO button.

• When you convert video signals input to the COMPONENT VIDEO IN jacks and output them from

the HDMI OUT jack, set the output resolution of the player to 480i. If the input has 480p or higher

resolution, an error message will appear.

• When "Monitor Out" is set to "SUB", the 480i/576i component signals only will be output with an

unchanged resolution. Video will not be displayed if the TV does not support the resolution.

• When "Monitor Out" is set to "MAIN" or "MAIN+SUB" and "Resolution" is set to "Through", the

480i/576i component signals will be output with their resolution unchanged. So, TV sets not

supporting these resolutions will not be able to display video.

Advanced Settings

23

Composite Video Input

It is possible to change assignment of input selector buttons and the COMPOSITE VIDEO

IN V1 to 3 jacks.

Setting item Default Value Setting Details

BD/DVD ----- "VIDEO 1" to "VIDEO 3": Desired COMPOSITE

VIDEO IN jack can be assigned to BD/DVD

button. If you do not assign a jack, select "-----".

CBL/SAT VIDEO 1 "VIDEO 1" to "VIDEO 3": Desired COMPOSITE

VIDEO IN jack can be assigned to CBL/SAT

button. If you do not assign a jack, select "-----".

STB/DVR VIDEO 2 "VIDEO 1" to "VIDEO 3": Desired COMPOSITE

VIDEO IN jack can be assigned to STB/DVR

button. If you do not assign a jack, select "-----".

GAME VIDEO 3 "VIDEO 1" to "VIDEO 3": Desired COMPOSITE

VIDEO IN jack can be assigned to GAME

button. If you do not assign a jack, select "-----".

PC ----- "VIDEO 1" to "VIDEO 3": Desired COMPOSITE

VIDEO IN jack can be assigned to PC button. If

you do not assign a jack, select "-----".

AUX ----- The setting cannot be changed.

TV/CD ----- "VIDEO 1" to "VIDEO 3": Desired COMPOSITE

VIDEO IN jack can be assigned to TV/CD

button. If you do not assign a jack, select "-----".

PHONO ----- "VIDEO 1" to "VIDEO 3": Desired COMPOSITE

VIDEO IN jack can be assigned to PHONO

button. If you do not assign a jack, select "-----".

• When "Monitor Out" is set to "SUB", the 480i/576i composite signals only will be output with an

unchanged resolution. Video will not be displayed if the TV does not support the resolution.

• When "Monitor Out" is set to "MAIN" or "MAIN+SUB" and "Resolution" is set to "Through", the

480i/576i composite signals will be output with their resolution unchanged. So, TV sets not supporting

these resolutions will not be able to display video.

Digital Audio Input

It is possible to change assignment of input selector buttons and the DIGITAL IN COAXIAL

1 to 2/OPTICAL jacks.

Setting item Default Value Setting Details

BD/DVD COAXIAL 1 "COAXIAL 1", "COAXIAL 2", "OPTICAL": Desired

DIGITAL IN jack can be assigned to BD/DVD

button. If you do not assign a jack, select "-----".

CBL/SAT COAXIAL 2 "COAXIAL 1", "COAXIAL 2", "OPTICAL": Desired

DIGITAL IN jack can be assigned to CBL/SAT

button. If you do not assign a jack, select "-----".

STB/DVR ----- "COAXIAL 1", "COAXIAL 2", "OPTICAL": Desired

DIGITAL IN jack can be assigned to STB/DVR

button. If you do not assign a jack, select "-----".

GAME ----- "COAXIAL 1", "COAXIAL 2", "OPTICAL": Desired

DIGITAL IN jack can be assigned to GAME button.

If you do not assign a jack, select "-----".

PC ----- "COAXIAL 1", "COAXIAL 2", "OPTICAL": Desired

DIGITAL IN jack can be assigned to PC button. If

you do not assign a jack, select "-----".

AUX ----- The setting cannot be changed.

TV/CD OPTICAL "COAXIAL 1", "COAXIAL 2", "OPTICAL": Desired

DIGITAL IN jack can be assigned to TV/CD button.

If you do not assign a jack, select "-----".

PHONO ----- "COAXIAL 1", "COAXIAL 2", "OPTICAL": Desired

DIGITAL IN jack can be assigned to PHONO

button. If you do not assign a jack, select "-----".

• Supported sampling rates for PCM signals (stereo, mono) from a digital input are 32/44.1/48/88.2/96

kHz/16, 20, 24 bit.

Advanced Settings

24

2.Speaker Setup

Allows you to change the speaker configuration such as existence of subwoofer, crossover

frequency, and so on. Settings are automatically configured if you use the Automatic

Speaker Setup.

Furthermore, you will not be able to select this setting if you have a pair of headphones

connected or you are listening through your TV speakers.

Speaker Settings

Change the impedance of the connected speakers, the type of front speaker connection,

and other speaker settings.

Setting item Default Value Setting Details

Speaker

Impedance

(European,

Australian and

Asian models)

6ohms Set the impedance of the connected speakers.

"4ohms": When any of the connected speakers

have4Ωormoretolessthan6Ωimpedance

"6ohms": When the connected speakers all have 6

Ωormoreimpedance

Front Speakers

Type

Normal Select the type of front speaker connection.

"Normal": When front speakers are connected in a

normal manner

"Bi-Amp": When front speakers are bi-amp

connected

Powered Zone 2 No Set presence of speaker terminal connection of

Zone 2

"Yes": When speakers are connected to ZONE2

speaker terminals

"No": When speakers are not connected to ZONE2

speaker terminals

• If "Front Speakers Type" is set to "Bi-Amp", this

setting will be set to "No".

• For impedance, check the indications on the back of the speakers or their instruction manual.

Speaker Configuration

Allows you to change the speaker configuration such as presence or not of each speaker,

crossover frequency, and so on. Settings are automatically configured if you use the

Automatic Speaker Setup. Audio will not be output while you are making this setting.

Setting item Default Value Setting Details

Subwoofer Ye s Set whether a subwoofer is connected or not.

"Yes": When subwoofer is connected

"No": When subwoofer is not connected

Front 100Hz Select the frequency to start outputting bass

frequencies (crossover frequency) for each

channel from "40Hz" to "200Hz".

"Full Band": Full band will be output.

"None": When no compatible speaker is connected

• "Front" will be fixed to "Full Band" if "Subwoofer"

is set to "No", and the bass frequencies of the

other channels will be output from the front

speakers. To make the settings, refer to the

instruction manual of the speakers used.

Center 100Hz Select the frequency to start outputting bass

frequencies (crossover frequency) for each

channel from "40Hz" to "200Hz".

"Full Band": Full band will be output.

"None": When no compatible speaker is connected

• This setting cannot be set to "Full Band" unless

"Front" is set to "Full Band".

Surround 100Hz Select the frequency to start outputting bass

frequencies (crossover frequency) for each

channel from "40Hz" to "200Hz".

"Full Band": Full band will be output.

"None": When no compatible speaker is connected

• This setting cannot be set to "Full Band" unless

"Front" is set to "Full Band".

Advanced Settings

25

Setting item Default Value Setting Details

Back 100Hz Select the frequency to start outputting bass

frequencies (crossover frequency) for each

channel from "40Hz" to "200Hz".

"Full Band": Full band will be output.

"None": When no compatible speaker is connected

• In the following cases, this setting will be set to

"None":

– "Surround" is set to "None".

– "Front Speakers Type" is set to "Bi-Amp".

– "Powered Zone 2" is set to "Yes" and also

Zone2 is set to on.

• This setting cannot be set to "Full Band" unless

"Surround" is set to "Full Band".

Height None Select the frequency to start outputting bass

frequencies (crossover frequency) for each

channel from "40Hz" to "200Hz".

"Full Band": Full band will be output.

"None": When no compatible speaker is connected

• In the following cases, this setting will be set to

"None":

– "Surround" is set to "None".

– "Front Speakers Type" is set to "Bi-Amp".

– "Powered Zone 2" is set to "Yes" and also

Zone2 is set to on.

• This setting cannot be set to "Full Band" unless

"Front" is set to "Full Band".

Back ch 2ch Select the number of channels of the connected

surround back speaker.

"1ch": When one speaker is connected (Connect to

the BACK or HEIGHT L terminal)

"2ch": When two speakers are connected

• The setting cannot be changed if "Surround" or

"Back" is set to "None".

LPF of LFE 120Hz Set the low-pass filter for LFE (low-frequency

effect) signals in order to pass lower frequency

signals than the set value and thus cancel

unwanted noises. The low-pass filter will be

effective only on sources with LFE channel.

Set a frequency from "80Hz", "90Hz", "100Hz" and

"120Hz".

"Off": Do not use this function

Setting item Default Value Setting Details

Double Bass ----- Boost bass output by feeding bass sounds from

the front left and right, and center speakers to the

subwoofer.

"On": Bass output will be boosted.

"Off": Bass output will not be boosted.

• The setting will not automatically be configured

even if you performed the automatic speaker

setup.

• If "Subwoofer" is set to "No" or if "Front" is set to

other than "Full Band", the setting will be fixed

to "-----".

Advanced Settings

26

Speaker Distance

Set the distance from each speaker to the listening position. Settings are automatically

configured if you use the automatic speaker setup.

Setting item Default Value Setting Details

Unit feet/meters Specify the unit of distance for configuring

settings.

"feet": When setting in feet (0.1 ft to 30.0 ft, in

increments of 0.1 ft)

"meters": When setting in meters (0.03 m to 9.00

m, in increments of 0.03 m)

Front Left 12.0 ft/3.60 m Specify the distance between each speaker and

the listening position.

Center 12.0 ft/3.60 m Specify the distance between each speaker and

the listening position.

Front Right 12.0 ft/3.60 m Specify the distance between each speaker and

the listening position.

Surround Right 7.0 ft/2.10 m Specify the distance between each speaker and

the listening position.

Back Right 7.0 ft/2.10 m Specify the distance between each speaker and

the listening position.

• This setting cannot be changed when

"Powered Zone 2" is set to "Yes" and Zone 2

is turned on.

Back Left 7.0 ft/2.10 m Specify the distance between each speaker and

the listening position.

• This setting cannot be changed when

"Powered Zone 2" is set to "Yes" and Zone 2

is turned on.

Surround Left 7.0 ft/2.10 m Specify the distance between each speaker and

the listening position.

Subwoofer 12.0 ft/3.60 m Specify the distance between each speaker and

the listening position.

Height Left 9.0 ft/2.70 m Specify the distance between each speaker and

the listening position.

• This setting cannot be changed when

"Powered Zone 2" is set to "Yes" and Zone 2

is turned on.

Setting item Default Value Setting Details

Height Right 9.0 ft/2.70 m Specify the distance between each speaker and

the listening position.

• This setting cannot be changed when

"Powered Zone 2" is set to "Yes" and Zone 2

is turned on.

• When the speaker is set to "No" or "None" in "Speaker Configuration", the settings for "Speaker

Distance" cannot be changed:

• Default values vary depending on the regions.

Advanced Settings

27

Level Calibration

Adjust the level of each speaker with the built-in test tone. Settings are automatically

configured if you use the Automatic Speaker Setup.

Setting item Default Value Setting Details

Front Left 0 dB Select a value between "-12 dB" to "+12 dB". A

test tone will be output each time you change

the value. Select the desired level.

Center 0 dB Select a value between "-12 dB" to "+12 dB". A

test tone will be output each time you change

the value. Select the desired level.

Front Right 0 dB Select a value between "-12 dB" to "+12 dB". A

test tone will be output each time you change

the value. Select the desired level.

Surround Right 0 dB Select a value between "-12 dB" to "+12 dB". A

test tone will be output each time you change

the value. Select the desired level.

Back Right 0 dB Select a value between "-12 dB" to "+12 dB". A

test tone will be output each time you change

the value. Select the desired level.

Back Left 0 dB Select a value between "-12 dB" to "+12 dB". A

test tone will be output each time you change

the value. Select the desired level.

Surround Left 0 dB Select a value between "-12 dB" to "+12 dB". A

test tone will be output each time you change

the value. Select the desired level.

Subwoofer 0 dB Select a value between "-15 dB" to "+12 dB". A

test tone will be output each time you change

the value. Select the desired level.

Height Left 0 dB Select a value between "-12 dB" to "+12 dB". A

test tone will be output each time you change

the value. Select the desired level.

Height Right 0 dB Select a value between "-12 dB" to "+12 dB". A

test tone will be output each time you change

the value. Select the desired level.

• In the following cases, the settings for "Level Calibration" cannot be changed:

– The speaker is set to "No" or "None" in "Speaker Configuration".

– Mute (MUTING) is set.

3.Audio Adjust

Configure various settings related to sound, such as settings for listening to multiplex audio

or multilingual TV broadcasts and sound field settings for listening modes.

Multiplex/Mono

Setting item Default Value Setting Details

Multiplex

Input Channel

Main Set the audio channel or language to be output

when playing multiplex audio or multilingual TV

broadcasts etc.

"Main": Main channel only

"Sub": Sub channel only

"Main/Sub": Main and sub channels will be

output at the same time.

• If multiplex audio is being played, "1+1" will

be displayed when DISPLAY is pressed.

Mono

Input Channel

Left+Right Set the input channel to use for playing any 2

ch digital source such as Dolby Digital, or 2-ch

analog/PCM source in the Mono listening mode.

"Left": Left channel only

"Right": Right channel only

"Left + Right": Left and right channels

Dolby

Make the settings for Dolby listening mode.

Setting item Default Value Setting Details

PLIIx Music

(2ch Input)

Panorama

Off Adjust the sound field setting for playing any

2 ch digital source such as Dolby Digital or 2

ch analog/PCM source in the Dolby PrologicII

Music listening mode. Select the width of sound

field.

"On": Width of sound field will be increased.

"Off": Default value

Advanced Settings

28

Setting item Default Value Setting Details

PLIIx Music

(2ch Input)

Dimension

0 Adjust the sound field setting for playing any

2 ch digital source such as Dolby Digital or 2

ch analog/PCM source in the Dolby PrologicII

Music listening mode. Select the depth of sound

field.

"-3" to "+3": The sound field shifts forward as

the set value becomes smaller than "0" and

backward if the set value become larger than

"0".

PLIIx Music

(2ch Input)

Center Width

3 Configure the setting to use for playing any 2

ch digital source such as Dolby Digital, or 2-ch

analog/PCM source in the Dolby PrologicII

Music listening mode. Adjust the width of the

sound from the center speaker).

"0" to "7": The smaller the setting value is, the

more concentrated in the center speaker is

the sound, while the larger the setting value is,

the more distributed to the front left and right

speakers is the sound of the center speaker.

PLIIz Height Gain Mid Adjust the output level of the height speakers

in the Dolby Pro Logic IIz Height listening

mode. The output of the height speakers will be

enhanced in the order of "Low", "Mid" (Middle),

"High":"Low", "Mid" and "High".

• In the following cases, the setting cannot be

changed:

– "Height" is set to "None" in "Speaker

Configuration".

– "Powered Zone 2" is set to "Yes" and also

Zone2 is set to on.

Dolby EX Manual The Dolby Digital EX listening mode will

automatically be selected when Dolby EX

signals are input.

"Auto": Use this function

"Manual": Select the desired listening mode

• In the following cases, the setting cannot be

changed:

– "Back" is set to "None" in "Speaker

Configuration".

– "Powered Zone 2" is set to "Yes" and also

Zone2 is set to on.

Setting item Default Value Setting Details

Loudness

Management

On Enable the Late Night function that allows

you to enjoy surround sound of Dolby TrueHD

playback even in low volume.

"On": Use this function

"Off": Do not use this function

• Depending on the setting of "Back" in "Speaker Configuration", the display will be changed. "PLllx" will

be displayed as "PLllx/PLII"

Advanced Settings

29

DTS

Make the settings for DTS Neo:6 Music listening mode.

Setting item Default Value Setting Details

Neo:6 Music

Center Image

2 Adjust the width of the sound field of the front

channel when playing in the DTS Neo:6 Music

listening mode.

"0" to "5": Selecting a smaller value brings the

sound field of the front channel to the center

while selecting a larger value spreads the sound

field of the front channel to left and right.

Theater-Dimensional

Make the settings for Theater-Dimensional mode.

Setting item Default Value Setting Details

Listening Angle Wide Set the angle of the front left and right speakers

relative to the listening position when playing in

the Theater-Dimensional listening mode.

"Narrow": Less than 30°

"Wide": Greater than 30°

• Values recommended for "Listening Angle" are: 20° when "Narrow" is selected and 40° when "Wide"

is selected.

4.Source Setup

Adjust the volume level difference among the multiple devices connected to this unit,

rename an input selector, or adjust the image quality. The setting can be separately set to

each input selector button. When you select a desired input to check the video or audio,

start playback of the connected device.

AccuEQ Room Calibration

Setting item Default Value Setting Details

AccuEQ Room

Calibration

Off Enable/disable the sound field set in automatic

speaker setup

"On": Enable this function

"Off": Disable this function

• In the following cases, the setting cannot be

changed:

– Automatic speaker setup is not performed.

– Headphones are connected.

IntelliVolume

Setting item Default Value Setting Details

IntelliVolume 0 dB Adjust the volume level difference between the

devices connected to the unit. Select a value

between "-12 dB" to "+12 dB". Set a negative

value if the volume of the target device is larger

than the others and a positive value if smaller.

• This function is not effective in Zone 2.

Advanced Settings

30

Name Edit

Set an easy name to each input. The set name will be shown on the main unit display.

Setting item Default Value Setting Details

Name Input name 1. Select a character or symbol with the

cursors and press ENTER.

Repeat it to input 10 or less characters.

"Shift": Switches between upper and

lower cases. (Pressing +10 on the remote

controller also toggles between upper and

lower cases.)

" " " ": Moves the cursor to the arrow

direction.

"Back Space": Removes a character on the

left of the cursor.

"Space": Puts a space.

• Pressing CLR on the remote controller

will remove all the input characters.

2. After inputting, select "OK" with the cursors

and press ENTER.

The input name will be saved.

• To name a preset radio station, press TUNER on the remote controller, select AM/FM and select the

preset number.

• It cannot be set if the input is "NET", "USB" or "BLUETOOTH".

Picture Adjust

Adjust the image quality. (Possible only when the video player is connected to the HDMI

OUT MAIN jack) If you adjust it by checking the video, press ENTER. Press RETURN to

return the screen to the previous status.

Setting item Default Value Setting Details

Wide Mode Auto Set the aspect ratio.

"Auto": The aspect ratio will automatically be set

according to the input signals and the monitor

output setting.

"4:3":

"Full":

"Zoom":

"Wide Zoom":

• When a 3D or 4K video source is input, this

setting is set to "Full". Furthermore, for some

resolutions, this setting may be disabled and

set to "Full".

Advanced Settings

31

Setting item Default Value Setting Details

Picture Mode Custom An appropriate image quality setting for cinema

or game will be selected. You can also adjust

each item to obtain your favorite image quality.

"Custom": The items from "Game Mode" to

"Color Temperature" below can be adjusted as

desired.

"Cinema": When the video source is cinema

"Game": When the video source is game

"Standard": The resolution will be changed but

the image quality will not be adjusted.

"Bypass": Both the resolution and image quality

will not be adjusted.

• If you select "Bypass", the on-screen display

function will be disabled.

Game Mode Off Change to the setting suitable for game. Also

correct the delay of video signals of the game

console if any.

"On": Use this function

"Off": Do not use this function

• If you select "On", the delay will be corrected

but the image quality will be lower.

• The setting will be fixed to "Off" if

"Resolution" is set to "4K".

Film Mode Auto Change to the setting suitable for film.

"Auto": Image processing suitable for film will be

executed.

"Video": "Film Mode" will not be applied and the

input signals will be processed as video source.

Edge

Enhancement

Off Adjust the sharpness of the outline of image.

Select from "Off", "Low", "Mid" (Middle), and

"High".

• The setting will be fixed to "Off" if "Game

Mode" is set to "On".

• When the horizontal resolution of the output

video is 2,000 TV lines or more, this setting is

set to "Off".

Noise Reduction Off Reduces the noise of the screen. Select from

"Off", "Low", "Mid" (Middle), and "High".

• The setting will be fixed to "Off" if "Game

Mode" is set to "On".

Setting item Default Value Setting Details

Brightness 0 Adjust brightness of the screen. Select a value

between "-50" to "+50".

Contrast 0 Adjust contrast of the screen. Select a value

between "-50" to "+50".

Hue 0 Correct hue of the screen. Select a value

between "-50" to "+50".

Saturation 0 Adjust saturation of the screen. Select a value

between "-50" to "+50".

Color

Temperature

Normal Set color temperature of the screen. Select from

"Warm", "Normal" and "Cool".

• In the following cases, the settings for "Picture Adjust" cannot be changed:

– "NET", "USB" or "BLUETOOTH" is selected.

– "Monitor Out" is set to "SUB".

• Press CLR on the remote controller if you return all the settings from "Game Mode" through "Color

Temperature" to their default value.

Advanced Settings

32

Audio Selector

Make the audio input setting. The setting can be separately set to each input selector

button. Select the input selector to configure.

Setting item Default Value Setting Details

Audio Selector – Allows you to select prior input source.

ARC: When giving priority to input signal from

ARC compatible TV.

• The setting can be selected only when "Audio

Return Channel" is set to "Auto" and also the

"TV/CD" input is selected.

HDMI: When giving priority to input signal from

HDMI jacks

• The setting can be selected only when the

input is assigned to the HDMI IN jack in the

"HDMI Input" setting.

"COAXIAL (Coaxial input)": When giving priority

to input signal from DIGITAL IN COAXIAL jacks.

• The setting can be selected only when the

input is assigned to the COAXIAL jack in the

"Digital Audio Input" setting.

"OPTICAL (Optical input)": When giving priority

to input signal from DIGITAL IN OPTICAL jacks.

• The setting can be selected only when the

input is assigned to the OPTICAL jack in the

"Digital Audio Input" setting.

"Analog": To always output analog audio

independently of the input signal

Fixed Mode Off Specify an input signal when "HDMI", "COAXIAL

(Coaxial input)", or "OPTICAL (Optical input)"

is selected for "Audio Selector". Set this item if

noise is produced, or truncation occurs at the

beginning of a track that follows a gap when

playing PCM or DTS sources.

"Off": To play an analog signal when there is no

digital signal.

"PCM": To fix the input source to PCM.

"DTS": To fix the input source to DTS (except for

DTS-HD)

• Changing "Audio Selector" changes the

setting to "Off".

• The setting cannot be changed when "TUNER", "NET", "USB" or "BLUETOOTH" is selected.

5.Listening Mode Preset

You can preset your favorite listening mode to each input. (For example, you can always

apply straight decode to the Dolby TrueHD source of Blu-ray Disc to play it in unchanged

sound field.) Select the input, signal type and listening mode.

Although it is possible to select the listening mode during playback, the selected mode will

be reset when the unit enters standby mode.

Setting item Default Value Setting Details

Analog/PCM Last Valid Set the listening mode for playing PCM signals

of CD and analog signals of record and cassette

tape.

Mono/

Multiplex Source

Last Valid Set the listening mode for playing Dolby Digital,

AAC and other digital signals recorded in

monaural or multiplex audio.

2ch Source Last Valid Set the listening mode for playing Dolby Digital

and other digital signals recorded in 2 channels.

Dolby D/

Dolby D Plus/TrueHD

Last Valid Set the listening mode for playing Dolby Digital,

Dolby Digital Plus and Dolby TrueHD signals.

DTS/DTS-ES/

DTS-HD

Last Valid Set the listening mode for playing digital audio

signals in DTS and DTS-HD High Resolution

formats. Select the listening mode specified for

Blu-ray or such other DTS-HD Master Audio

source.

Other Multich Source Last Valid Set the listening mode for playing DSD signals

of AAC, DVD-Audio and Super Audio CD that

are input from HDMI IN jack.

• Available listening modes vary depending on the input signal.

• Setting "Last Valid" will always select the last selected mode.

• Only "Analog" can be set to the "TUNER" input.

• "Digital" and "TrueHD" can be set to the "NET" and "USB" inputs.

• Only "Digital" can be set to the "BLUETOOTH" input.

Advanced Settings

33

6.Miscellaneous

Volume Setup

Make the detailed volume setting of the unit.

Setting item Default Value Setting Details

Maximum Volume Off Set the maximum value to avoid too high volume.

Select a value from "Off", "30" to "79".

Power On Volume Last Set the volume level of when the power is turned

on. Select a value from "Last" (Volume level

before entering standby mode), "Min", "1" to "79"

and "Max".

• You cannot set a higher value than that of

"Maximum Volume".

Headphone Level 0 dB Adjust the volume level difference between

speakers and headphones. Select a value

between "-12 dB" to "+12 dB".

OSD Setup

Make the setting of on-screen display function that can display the setting menu screen,

volume operation screen and the like on the TV.

Setting item Default Value Setting Details

On Screen Display On Set whether or not to display the operation

screen on the TV.

"On": The operation screen will be displayed on

the TV.

"Off": The operation screen will not be displayed

on the TV.

• The operation screen may not be displayed

depending on the input signal even if "On"

is selected. If the operation screen is not

displayed, change the resolution of the

connected device.

Language English Select the on-screen display language.

Screen Saver 3min Set the time to start the screen saver. Select a

value from "3min", "5min", "10min" and "Off".

7.Hardware Setup

Tuner

Setting item Default Value Setting Details

AM/FM Frequency

Step (North

American and

Taiwanese models)

10kHz/200kHz Select a frequency step depending on your

area of residence.

Select "10kHz/200kHz" or "9kHz/50kHz".

• When this setting is changed, all radio

presets are deleted.

AM Frequency

Step (European,

Australian and Asian

models)

9kHz Select a frequency step depending on your

area of residence.

Select "10kHz" or "9kHz".

• When this setting is changed, all radio

presets are deleted.

Advanced Settings

34

HDMI

Setting item Default Value Setting Details

HDMI CEC (RIHD) Off Setting to "On" enables the input selection link

and other link functions with HDMI connected

CEC compliant device.

"On": Use this function

"Off": Do not use this function

• Depending on the TV set, a link may need to

be configured on the TV.

• This function is effective only when the

device is connected to the HDMI OUT MAIN

terminal.

• Setting to "On" and closing the on-screen

menu displays the name of the CEC-

compatible components and "RIHD On" on

the display.

• Power consumption in standby mode may

increase if "On" is set. (Depending on the TV

status, the unit will enter the normal standby

mode.)

• If you operate the MASTER VOLUME control

of the unit when this setting is set to "On"

and you are listening to the audio through the

speakers of your TV, audio will be output also

from the speakers connected to the unit. If

you want to output from only either of them,

change the unit or TV settings, or reduce the

volume of the unit.

• If abnormal operation occurs when you set

the setting to "On", set it to "Off".

• When connecting a non-CEC compatible

component, or when you are not sure

whether it is compatible, set the setting to

"Off".

• When changing this setting, turn off and

then on again the power of all connected

components.

Setting item Default Value Setting Details

HDMI Through Off You can display the video of an HDMI connected

player on the TV even if the unit is in standby

mode. This setting is effective only for an input

selector to which an HDMI jack is assigned in

"HDMI Input". It cannot be set to any other input

selector unless an HDMI jack is assigned to it.

"Off": The setting is disabled. Video of device

connected to any jack will not be displayed.

"BD/DVD", "CBL/SAT", "STB/DVR", "GAME",

"PC", "AUX", "TV/CD", "PHONO": Video of the

device connected to the HDMI IN jack assigned

to each input will be displayed on the TV.

"Last": Video of the device connected to the

HDMI IN jack assigned to the input selector that

was selected immediately before the unit enters

standby mode will be displayed on the TV.

"Auto": Video of all the devices connected to the

HDMI IN jacks will be output to the TV.

"Eco": Video of all the devices connected to the

HDMI IN jacks will be output to the TV. If you

select this setting when using a CEC-compatible

TV, you can reduce the power consumption in

standby mode. It cannot be selected if "HDMI

CEC (RIHD)" is set to "Off".

• When "HDMI Through" is enabled, the power

consumption increases even when the unit

is on standby. However, the increase in

power consumption is kept to a minimum

by automatically entering the HYBRID

STANDBY mode, where only the essential

circuit is operating.

• When changing the setting, turn off and

then on again the power of all connected

components.

Advanced Settings

35

Setting item Default Value Setting Details

Audio TV Out (MAIN) Off You can enjoy audio through the speakers of the

HDMI connected TV while this unit is on.

"On": Use this function

"Off": Do not use this function

• If you select "On", set "HDMI CEC (RIHD)" to

"Off."

• The setting is fixed to "Auto" if "HDMI CEC

(RIHD)" is set to "On".

• Listening mode cannot be changed if "Audio

TV Out (MAIN)" is set to "On" and audio is

being output through the speakers of the TV.

• Depending on your TV set or input signal of

the component, audio may not output through

the speakers of the TV even if this setting is

set to "On". In such case, audio is output from

the speakers of the unit.

• If you operate the MASTER VOLUME control

of the unit when "Audio TV Out (MAIN)"

or "HDMI CEC (RIHD)" is set to "On" and

you are listening to the audio through the

speakers of your TV, audio will be output from

the unit. If you do not want to output audio

from the unit, change the unit or TV settings,

or reduce the volume of the unit.

• "Audio TV Out (MAIN)" is fixed to "Off" if

"Monitor Out" is set to "SUB".

Setting item Default Value Setting Details

Audio TV Out (SUB) Off You can enjoy audio through the speakers of the

HDMI connected TV while this unit is on.

"On": Use this function

"Off": Do not use this function

• Listening mode cannot be changed while

"Audio TV Out (SUB)" is set to "On" and

audio is being output through the speakers of

the TV.

• Depending on your TV set or input signal of

the component, audio may not output through

the speakers of the TV even if this setting is

set to "On". In such case, audio is output from

the speakers of the unit.

• If you operate the MASTER VOLUME control

of the unit when "Audio TV Out (SUB)" or

"HDMI CEC (RIHD)" is set to "On" and

you are listening to the audio through the

speakers of your TV, audio will be output from

the unit.. If you do not want to output audio

from the unit, change the unit or TV settings,

or reduce the volume of the unit.

• "Audio TV Out (SUB)" is fixed to "Off" if

"Monitor Out" is set to "MAIN".

Audio Return

Channel

- You can enjoy sound of the HDMI connected

ARC compatible TV through the speakers

connected to the unit. To use this function, set

"HDMI CEC (RIHD)" to "On" in advance.

"Auto": When enjoying the TV sound through the

speakers connected to the unit

"Off": When not using the ARC function

Lip Sync On This setting automatically corrects any

desynchronization between the video and audio

signals based on data from the HDMI LipSync

compatible TV.

"On": Automatic correction will be enabled.

"Off": Automatic correction will be disabled.

InstaPrevue Change the preview display of the video input

through HDMI, which will be displayed using

"InstaPrevue" in the Home menu.

• Depending on the video source, the preview

thumbnails configured in "InstaPrevue" may

not be displayed properly.

Advanced Settings

36

Setting item Default Value Setting Details

Sub Window Multi Set how to display preview thumbnails.

"Multi": Displays all the thumbnails of HDMI IN1,

2, 3, 4 and FRONT at once.

"Single": Displays each thumbnail individually.

Position Bottom/Lower

Right

Set the position to display preview thumbnails.

When "Multi" is selected for "Sub Window":

Select from "Top", "Bottom", "Left" and "Right".

When "Single" is selected for "Sub Window":

Select from "Upper Left", "Upper Right", "Lower

Left" and "Lower Right".

• If "Monitor Out" is set to "MAIN+SUB" and "Audio TV Out (SUB)" is set to "On"

– Set the audio output of the connected device to "2ch PCM".

– If the audio input is via other than HDMI, sound of the TV connected to the HDMI OUT SUB jack

will not be output.

Auto Standby

Setting item Default Value Setting Details

Auto Standby On/Off This setting places the unit on standby

automatically after 20 minutes of inactivity

without any video or audio input.

"On": The unit will automatically enter standby

mode ("ASb" will light).

"Off": The unit will not automatically enter

standby mode.

• "Auto Standby" is appeared on the display

and menu screen 30 seconds before the

Auto Standby comes on.

• "Auto Standby" does not work when Zone 2

is active.

• Default values vary depending on the

regions.

HDMI Through Off Enable or disable "Auto Standby" while "HDMI

Through" is on.

"On": The setting will be enabled.

"Off": The setting will be disabled.

• "HDMI Through" cannot be set to "On" if

"Auto Standby" is set to "Off".

• When "HDMI Through" is used, the power consumption increases even when the unit is on standby.

However, the increase in power consumption is kept to a minimum by automatically entering the

HYBRID STANDBY mode, where only the essential circuit is operating.

Advanced Settings

37

Network

Make the network setting.

• When LAN is configured with a DHCP, set "DHCP" to "Enable" to configure the

setting automatically. ("Enable" is set by default) To assign fixed IP addresses to each

components, you must set "DHCP" to "Disable" and assign an address to this unit in

"IP Address" as well as set information related to your LAN, such as Subnet Mask and

Gateway.

Setting item Default Value Setting Details

Network Standby Off You can turn on the power of the unit via

network using an application such as Onkyo

Remote.

"On": Use this function

"Off": Do not use this function

• When "Network Standby" is used, the power

consumption increases even when the unit

is on standby. However, the increase in

power consumption is kept to a minimum

by automatically entering the HYBRID

STANDBY mode, where only the essential

circuit is operating.

Wi-Fi Off (Wired) Connect the unit to network via wireless LAN

router.

"On": Wireless LAN connection

"Off (Wired)": Wired LAN connection

Wi-Fi Setup – You can configure wireless LAN settings by

pressing ENTER when "Start" is displayed.

Wi-Fi Status – The information of the connected access point

will be displayed.

"SSID": SSID of the connected access point.

"Security": Security method of the connected

access point.

"Signal": Signal strength of the connected

access point.

"Status": Status of the connected access point.

MAC Address – This is the MAC address of the AV receiver.

This value is specific to the component and

cannot be changed.

Setting item Default Value Setting Details

DHCP Enable "Enable": Auto configuration by DHCP

"Disable": Manual configuration without DHCP

• If selecting "Disable", you must set "IP

Address", "Subnet Mask", "Gateway", and

"DNS Server" manually.

IP Address – Displays/Sets the IP address.

Subnet Mask – Displays/Sets the subnet mask.

Gateway – Displays/Sets the gateway.

DNS Server – Displays/Sets the primary DNS server.

Proxy URL – Displays/Sets the proxy server URL.

Proxy Port – Displays/Sets the proxy server port number

when you enter "Proxy URL".

Network Check – You can check the network connection.

Press ENTER when "Start" is displayed.

• Wait for a while if "Network" is not shown on the screen. It will appear when the network function is

started up.

Advanced Settings

38

Bluetooth

Setting item Default Value Setting Details

Bluetooth On Select whether or not to use the Bluetooth

function.

"On": Enables connection with a Bluetooth-

enabled device by using the Bluetooth function.

Select "On" also when making various Bluetooth

settings.

"Off": When not using the Bluetooth function

Direct Change On The input of the unit will automatically be

switched to "BLUETOOTH" when connection is

made from a Bluetooth-enabled device to the

unit.

"On": The input will automatically become

"BLUETOOTH" when a Bluetooth-enabled

device is connected.

"Off": The function is disabled.

• If the input is not switched automatically, set

to "Off" and change the input manually.

Auto Reconnect On This function automatically reconnects to the

Bluetooth-enabled device connected last when

you change the input selector to "BLUETOOTH".

"On": Use this function

"Off": Do not use this function

• This function may not work depending on

your Bluetooth-enabled device.

Wakeup via

Bluetooth

Off This function wakes up the unit on standby by

connecting a Bluetooth-enabled device.

"On": Use this function

"Off": Do not use this function

• Setting to "On" increases the power

consumption even when the unit is on

standby. However, the increase in power

consumption is kept to a minimum by

automatically entering the HYBRID

STANDBY mode, where only the essential

circuit is operating.

• "Wakeup via Bluetooth" is fixed to "Off" if

"Direct Change" is set to "Off".

Setting item Default Value Setting Details

Pairing Information - When paring is performed, the information of

the previous pairing stored in this unit will be

initialized.

Pressing ENTER when "Clear" is displayed

initializes the pairing information stored in this

unit.

• This function does not initialize the pairing

information on the Bluetooth-enabled device.

When pairing the unit again with the device,

be sure to clear the pairing information on

the Bluetooth-enabled device in advance.

For information on how to clear the pairing

information, refer to the Bluetooth-enabled

device's instruction manual.

Device – Displays the name of the Bluetooth-enabled

device connected to the unit.

• The name is not displayed when "Status" is

"Ready" and "Pairing".

Status – Displays the status of the Bluetooth-enabled

device connected to the unit.

"Ready": Not paired

"Pairing": Paired

"Connected": Successfully connected

Firmware Update

Setting item Default Value Setting Details

Update Notice Enable Availability of a firmware update will be notified

via network.

"Enable": Notify updates

"Disable": Do not notify updates

Version – The current firmware version will be displayed.

Update via NET – Press ENTER to select when you want to

update the firmware via network.

• You will not be able to select this setting if

you do not have Internet access or there is

nothing to update.

Advanced Settings

39

Setting item Default Value Setting Details

Update via USB – Press ENTER to select when you want to

update the firmware via USB.

• You will not be able to select this setting if

a USB storage device is not connected or

there is nothing to update in the USB storage

device.

Initial Setup

You can make the initial setup from the setup menu.

• Setting is not possible if "Monitor Out" is set to "SUB".

8.Remote Controller Setup

Setting item Default Value Setting Details

Remote ID 1 Select an ID for the unit's remote controller from

"1", "2", and "3" to prevent interference between

the unit and other Onkyo components that are

installed in the same room. After changing

the ID on the main unit, change the ID on the

remote controller accordingly with the following

procedure.

1. While holding down RCV, press Q SETUP

for about 3 seconds until the remote

indicator lights.

2. With the number buttons, press one of 1, 2,

and 3. The remote indicator flashes twice.

Remote Mode Setup – Input and register the remote controller code of

other devices.

• For registration of the remote control code,

refer to "Operating Other Components with

the Remote Controller".

9.Lock Setup

Setting item Default Value Setting Details

Setup Unlocked The Setup menu will be locked to protect the

settings.

"Locked": The menu is locked.

"Unlocked": The menu is unlocked.

Operating Other Components Using Remote Controller

40

Operating Other Components

Using Remote Controller

Functions of REMOTE MODE Buttons

You can control any other device than this unit by

programming a specified remote control code to a

REMOTE MODE button of the remote controller. Register

a remote control code to a desired REMOTE MODE button

and press it to enter the remote mode that allows you to

operate the corresponding device.

½The RCV and ZONE2 buttons cannot be programmed.

Programming Remote Control Codes

For information on the configuration and operation of

Onkyo components with RI jack, refer to "Connecting

and Operating Onkyo RI Components". Furthermore, the

following REMOTE MODE buttons are preprogrammed with

remote control codes.

BD/DVD: Onkyo Blu-ray Disc/DVD player

TV/CD: Onkyo CD player

STB/DVR: Apple TV

 Searching in the Setup Menu

You can search a remote control code and register it to a

desired REMOTE MODE button in the unit's Setup menu.

1. Press RCV and then press HOME on the remote

controller.

2. With the cursors, select "Setup", and then press ENTER.

3. With the cursors, select "8.Remote Controller Setup" -

"Remote Mode Setup" and press ENTER.

4. With the cursors, select the remote mode for which you

want to search a remote control code and press ENTER

to display the category selection screen.

5. With the cursors, select the target category, and then

press ENTER to display the brand name input screen.

6. Select a character with the cursors and press ENTER.

Repeat it to enter the first three characters of the brand

name.

7. With the cursors, select "Search", and then press

ENTER.

• After a search is done, the list of possible brand

names is displayed. If the brand name list is not

displayed, select "Not Listed" with the cursors and

press ENTER to return to the brand name input

screen in step 6.

8. With the cursors, select the target brand name, and then

press ENTER.

• Once you decided the corresponding brand name,

the remote control code of the brand and how to

register it will be displayed on the TV screen.

9. Follow the guidance displayed on the TV screen.

10.

If the component can successfully be operated with its

registered remote control code, select "OK" with the

cursors and press ENTER.

• Only TV remote control codes can be entered for TV.

• Program a remote control code in accordance

with the input since each button also works as the

input selector. (For example, when the CD player is

connected to the TV/CD jack, program the remote

control code for the CD player to TV/CD)

• If the component cannot be operated, select "Try

Next Code" with the cursors and press ENTER to

display another code.

• It is possible to operate an MHL-enabled mobile

device with the unit's remote controller by registering

the code of the MHL-enabled mobile device below

to the unit's remote controller. Operation may be

unstable or incorrect depending on the mobile device

used.

33101 (North American and Taiwanese models)

32910 (European, Australian and Asian models)

 Consulting the Remote Control Code List

Find the remote control code in the remote control code list.

1. Look up the Remote Control Code List for the

corresponding remote control code.

• The codes in the Remote Control Code List are

those known as of the date of publication and may

be changed.

• Only TV remote control codes can be entered for TV.

• Program a remote control code in accordance

with the input since each button also works as the

input selector. (For example, when the CD player is

connected to the TV/CD jack, program the remote

control code for the CD player to TV/CD)

Operating Other Components Using Remote Controller

41

2. Press DISPLAY for 3 or more seconds while holding

down the REMOTE MODE button to which you want to

register the remote control code.

Once you entered the input mode, the remote indicator

will light.

3. With the number buttons, enter the 5-digit remote control

code within 30 seconds.

• The registration is complete when the remote

indicator flashes twice. The remote indicator flashes

once slowly when registering the remote control

code fails. Try the registration again.

 Remapping the Colored Buttons

The colored button assignment on the AV receiver's remote

controller can be remapped to match that on the remote

controller of the component whose remote control code you

programmed to REMOTE MODE. However, you will not be

able to remap the colored buttons if Zone 2 is selected.

1. Hold down the REMOTE MODE button to map and A

(Red) simultaneously until the remote indicator lights

(about 3 seconds).

• Remapping is possible only for codes included in the

categories of the Remote Control Code List such as

DVD player and TV.

2. Within 30 seconds, press the colored buttons from left to

right, in the order you want to remap.

• For example, if the colored buttons on the remote

controller of the other component are yellow, green,

blue, and red from left to right, press the buttons on

the AV receiver's remote controller in that order.

• Programming is complete when the remote indicator

flashes twice. The remote indicator flashes once

slowly when programming the remote control code

fails. Try the remapping again.

• Pressing any other button than a colored button

cancels the remap operation.

 Resetting the REMOTE MODE Buttons

You can reset the remote control code registered in the

REMOTE MODE button to its default status. This operation

can be executed on a single REMOTE MODE button.

1. Press HOME for 3 or more seconds while holding down

the REMOTE MODE button you want to reset.

The remote indicator will light.

2. Within 30 seconds, press the REMOTE MODE button

again.

• Reset is complete when the remote indicator flashes

twice.

To reset all the remote controller settings, while holding

down RCV, press and hold down HOME until the remote

indicator lights (about 3 seconds). Press RCV again within

30 seconds. Reset is complete when the remote indicator

flashes twice.

Operating Other Components Using Remote Controller

42

TV operation

Press the REMOTE MODE button programmed with

the remote control code for the relevant AV component

to switch the remote controller mode to that for the AV

component. Then, operate by using the corresponding

buttons. Available buttons vary depending on the product

category of the component. Operation may be incorrect or

impossible depending on the product.

1

2

3

4

1 REMOTE MODE

2 , INPUT, VOL /

3 MUTING

4 CH +/-

58

9

6

7

F

5 GUIDE

6 ///, ENTER

7 SETUP

8 PREV CH

9 RETURN

F AUDIO ()

G

H

I

J

G , , , , , , ()

H A (Red) (), B (Green) (), C (Yellow) (), D (Blue) ()

I Number 1 to 9, 0, +10

J CLR, DISPLAY

½Not CEC-compatible.

Blu-ray Disc player/DVD player/DVD recorder

operation

Press the REMOTE MODE button programmed with

the remote control code for the relevant AV component

to switch the remote controller mode to that for the AV

component. Then, operate by using the corresponding

buttons. Available buttons vary depending on the product

category of the component. Operation may be incorrect or

impossible depending on the product.

1

2

3

4

1 REMOTE MODE

2 SOURCE

3 MUTING

4 CH +/-, DISC +/-

58

9

F

6

7

5 TOP MENU

6 ///, ENTER

7 SETUP

8 MENU

9 RETURN

F AUDIO ()

G

H

I

J

G , , , , , ,

H A (Red) (), B (Green), C (Yellow) (), D (Blue) ()

I Number 1 to 9, 0, +10 ()

J CLR, DISPLAY

½Not CEC-compatible. ("A (Red) (), B (Green), C (Yellow) (), D (Blue)

()" are intended only for "DVD player/DVD recorder")

Operating Other Components Using Remote Controller

43

VCR/PVR operation

Press the REMOTE MODE button programmed with

the remote control code for the relevant AV component

to switch the remote controller mode to that for the AV

component. Then, operate by using the corresponding

buttons. Available buttons vary depending on the product

category of the component. Operation may be incorrect or

impossible depending on the product.

1

2

3

4

1 REMOTE MODE

2 SOURCE

3 MUTING

4 CH +/-

58

9

6

7

5 GUIDE

6 / / / , ENTER

7 SETUP

8 PREV CH

9 RETURN

F

G

H

F , , , , , ,

G Number 1 to 9, 0, +10

H CLR, DISPLAY

Satellite receiver / Cable receiver operation

Press the REMOTE MODE button programmed with

the remote control code for the relevant AV component

to switch the remote controller mode to that for the AV

component. Then, operate by using the corresponding

buttons. Available buttons vary depending on the product

category of the component. Operation may be incorrect or

impossible depending on the product.

1

2

3

4

1 REMOTE MODE

2 SOURCE

3 MUTING

4 CH +/-

5

6

7

8

9

F

5 GUIDE

6 / / / , ENTER

7 SETUP

8 PREV CH

9 RETURN

F AUDIO

G

H

I

J

G , , , , , ,

H A (Red) B (Green), C (Yellow), D (Blue)

I Number 1 to 9, 0, +10

J CLR, DISPLAY

Operating Other Components Using Remote Controller

44

CD player operation

Press the REMOTE MODE button programmed with

the remote control code for the relevant AV component

to switch the remote controller mode to that for the AV

component. Then, operate by using the corresponding

buttons. Available buttons vary depending on the product

category of the component. Operation may be incorrect or

impossible depending on the product.

1

2

3

4

1 REMOTE MODE

2 SOURCE

3 MUTING

4 DISC +/-

5

6

5 / / / , ENTER

6 SETUP

7

8

9

F

7 , , , , , ,

8 SEARCH, REPEAT, RANDOM, MODE

9 Number 1 to 9, 0, +10

F CLR, DISPLAY

Cassette tape deck operation

Press the REMOTE MODE button programmed with

the remote control code for the relevant AV component

to switch the remote controller mode to that for the AV

component. Then, operate by using the corresponding

buttons. Available buttons vary depending on the product

category of the component. Operation may be incorrect or

impossible depending on the product.

1

2

3

1 REMOTE MODE

2 SOURCE

3 MUTING

4

4 , (Reverse Playback), , , , ,

To operate CEC-compatible components

The TV and BD/DVD buttons on the remote controller

are preprogrammed with remote control codes for linked

operation of some CEC (Consumer Electronics Control)-

compatible TV sets and Blu-ray Disk players. By connecting

to the unit via HDMI, you may operate them using the AV

receiver's remote controller.

• If you cannot operate your CEC-compatible component,

program one of the following remote control codes to the

TV or BD/DVD button.

TV: 11807/13100/13500 (CEC-compatible TV)

BD/DVD: 32910/33101/33501/31612 (CEC-compatible

BD/DVD player)

45

Advanced Speaker Connection

Advanced Speaker Connection

Bi-Amping

It is possible to connect speakers supporting bi-amping to

improve quality of the low and high pitched ranges. Up to

5.1 ch will be played in bi-amping.

 Connections

1. Connect as below using the FRONT terminals and

BACK or HEIGHT terminals.

Tweeter

(high pitched tone)

Subwoofer

(low pitched tone)

Front R Front L

2. Turn the unit on and set "Speaker Setup" to "Bi-Amp".

1 After pressing RCV, press HOME on the remote

controller.

2 With the cursors, select "Setup", and then press

ENTER.

3 With the cursors, select the order of "2.Speaker

Setup" – "Speaker Settings" – "Front Speakers Type".

4 Select "Bi-Amp" with the cursors and press ENTER.

• Before bi-amping, be sure to remove the short-

circuit connector that connects the tweeter (high

pitched tone) terminal and the subwoofer (low

pitched tone) terminal.

• Use speakers supporting bi-amping only. For

details, refer to the speakers' instruction manual.

Connecting and Operating Onkyo RI Components

46

Connecting and Operating

Onkyo RI Components

About RI Function

Connecting an Onkyo component with RI jack such as the

separately sold RI Dock to the unit by using an RI cable

and an analog audio (RCA) cable enables the following RI

functions:

System On / Auto Power On: Starting playback on a

component connected via RI when the unit is on standby

mode, automatically turns on the unit to select the relevant

component as its input source.

Direct Change: When playback is started on a component

connected via RI, the unit selects that component as the

input source.

Remote Controller Operation: Allows you to operate RI-

compatible Onkyo components using the AV receiver's

remote controller. Point the remote controller at remote

control sensor of the unit. This operation is possible only

when the RI remote control code is programmed.

• Some components may not support all RI functions.

• These functions do not work when Zone 2 is turned on.

• For information on the RI functions, also refer to each

component's instruction manual.

RI Connection and Setting

R

L

Connect an Onkyo component with RI jack to this unit using

an RI cable and an analog audio (RCA) cable. For details,

refer to the instruction manual of the component with RI

jack. The RI cable can be connected in any order. When

there are two RI jacks, both jacks work in the same way

and are interchangeable.

To connect the RI Dock or cassette tape deck via RI, you

must:

 Rename the input selector

To make the RI functions work, you must rename the input

selectors on the unit. Press TV/CD or GAME to display

"TV/CD" or "GAME" on the main unit display. Then press

and hold TV/CD or GAME 3 seconds or more to switch the

display to "DOCK" or "TAPE".

 Program the RI remote control code

Program the remote control code to any REMOTE MODE

button on the remote controller. This will allow you to

operate the component by pointing the remote controller at

the unit instead of the component.

1. Press DISPLAY for 3 or more seconds while holding

down the REMOTE MODE button to which you want to

program the remote control code.

• The remote indicator will light.

• The RCV, ZONE2, and TV buttons cannot be

programmed.

2. With the number buttons, enter the following 5-digit

remote control code within 30 seconds.

RI Dock: 81993

Cassette tape deck with RI jack: 42157

• Programming is complete when the remote indicator

flashes twice. The remote indicator flashes once

slowly when programming the remote control code

fails. Try again.

Change the input selector on the RI Dock to "HDD" or

"HDD/DOC". For details, refer to the RI Dock's instruction

manual.

To operate Onkyo components directly or Onkyo

components that are not connected via RI, use the

following remote control codes:

Onkyo DVD player: 30627

Onkyo CD player: 71817

RI Dock: 82990

• With some models, operation may be not possible in

part or not possible at all.

Connecting and Operating Onkyo RI Components

47

iPod/iPhone Operation

The RI Dock allows you to use the AV receiver's remote

controller to operate and play music on your iPod/iPhone.

Moreover, it also allows you to view videos on your iPod/

iPhone on the screen of your TV, as well as perform RI

operations if connected via RI. This operation is possible

only when the RI remote control code is programmed.

Before Operation: Before performing any operation on

your iPod/iPhone, make sure to have it updated to the

latest version via iTunes. Certain buttons may not work for

some iPod/iPhone models and generations, or RI Dock. For

details on the operation, refer to the RI Dock's instruction

manual.

Switch the remote controller mode by pressing the

REMOTE MODE button programmed with the remote

control code for the iPod/iPhone, and operate by using the

corresponding buttons. Point the remote controller at the

unit.

1

2

3

4

5

1 REMOTE MODE

2 SOURCE

3 MUTING

4 VOL /

5 ALBUM +/-

6

7

8

6 TOP MENU

7 / / / , ENTER, PLAYLIST /

8 MENU

9

FG

H

9 , , , , , ,

F REPEAT, RANDOM

G MODE

H DISPLAY

• Pressing DISPLAY turns on the backlight for a few

seconds.

• MODE allows you to use the Resume function to

resume playing from the song that was playing when

you removed your iPod/iPhone from the DS-A2 RI Dock.

Firmware Update

48

Firmware Update

About Firmware Update

There are two methods for updating the firmware: via

network and via USB.

Use the one that best suits your environment.

• For the latest information on updates, visit the Onkyo

website.

• Before updating, make sure that the speaker setup

microphone is not connected.

• During an update, do not

– Disconnect and reconnect any cable, USB storage

device, speaker setup microphone or headphones,

or perform any operation on the component such as

turn off its power

– Access to this unit from a PC or smartphone using

Android application

• The update may take about 20 minutes to complete for

either method: via network or via USB.

Furthermore, existing settings are guaranteed

regardless of the method used for update.

Disclaimer: The program and accompanying online

documentation are furnished to you for use at your own

risk.

Onkyo will not be liable and you will have no remedy for

damages for any claim of any kind whatsoever concerning

your use of the program or the accompanying online

documentation, regardless of legal theory, and whether

arising in tort or contract.

In no event will Onkyo be liable to you or any third party for

any special, indirect, incidental, or consequential damages

of any kind, including, but not limited to, compensation,

reimbursement or damages on account of the loss of

present or prospective profits, loss of data, or for any other

reason whatsoever.

Updating the Firmware via Network

Before Start:

• Check that the unit is turned on, and the connection to

the Internet is secured.

• Turn off the controller component (PC etc.) connected to

the network.

• Stop any playing Internet radio, USB storage device, or

server content.

• If Zone 2 is active, press OFF on the unit to turn it off.

• If "HDMI CEC (RIHD)" is set to "On", set it to "Off"

(default value).

– After pressing RCV, press HOME on the remote

controller. Select "Setup" with the cursors and press

ENTER. Then, after selecting "7.Hardware Setup"

- "HDMI" and pressing ENTER, select "HDMI CEC

(RIHD)" to select "Off".

½The description may differ from the on-screen display but that will not

change the way to operate or the function.

 Update

1. After pressing RCV, press HOME on the remote

controller.

The Home menu is displayed on the TV screen.

Setup

HOME

2. With the cursors, select "Setup" - "7.Hardware Setup" -

"Firmware Update" - "Update via NET", and then press

ENTER.

• If "7.Hardware Setup" is grayed out and cannot be

selected, wait for a while until it starts up.

• You will not be able to select "Update via NET" if

there is nothing to update.

3. Press ENTER with "Update" selected to start update.

• During the update, the TV screen may go black

depending on the updated program. In that case,

check the progress on the display of the unit. The TV

screen will remain black until the update is complete

and the power is turned on again.

• "Completed!" is displayed when the update is

complete.

4. Press ON/STANDBY on the main unit to turn the

unit into standby mode. This is the end of the firmware

update and you have now the latest firmware installed.

• Do not use RECEIVER on the remote controller.

Firmware Update

49

 If an Error Message is Displayed

Case 1: When an error occurs, "- Error!" is appeared

on the display of the unit. ("" represents an alphanumeric

character.) Check the following:

Error Code

• -01, -10:

Ethernet cable not found. Connect the Ethernet cable

properly.

• -02, -03, -04, -05, -06, -11, -13, -14,

-16, -17, -18, -20, -21:

Internet connection error. Check the following:

– Whether the router is turned on

– Whether this unit and router are connected to the

network

Try to disconnect and then connect again the power

to the unit and router. This may solve the problem. If

you are still unable to connect to the Internet, the DNS

server or proxy server may be temporarily down. Check

the service status with your ISP provider.

• Others:

disconnect then reconnect the AC power cord, from the

beginning.

Updating the Firmware via USB

Before Start:

• Prepare a 64 MB or larger USB storage device.

– Media inserted in a USB card reader may not be

used for this function.

– USB storage devices with security function are not

supported.

– USB hubs and USB devices with hub function are not

supported. Do not connect these devices to the unit.

• Delete any data stored on the USB storage device.

• Turn off the controller component (PC etc.) connected to

the network.

• Stop any playing Internet radio, USB storage device, or

server content.

• If Zone 2 is active, press OFF on the unit to turn it off.

• If "HDMI CEC (RIHD)" is set to "On", set it to "Off"

(default value).

– After pressing RCV, press HOME on the remote

controller. Select "Setup" with the cursors and press

ENTER. Then, after selecting "7.Hardware Setup"

- "HDMI" and pressing ENTER, select "HDMI CEC

(RIHD)" to select "Off".

½ Some USB storage devices may take long to load, may not be loaded

correctly, or may not be correctly fed depending on the device or their

content.

½ Onkyo will not be liable whatsoever for any loss or damage of data, or

storage failure arising from the use of the USB storage device with this

AV receiver. Thank you for your understanding.

½The description may differ from the on-screen display but that will not

change the way to operate or the function.

 Update

1. Connect the USB storage device to your PC.

2. Download the firmware file from the Onkyo website to

your PC and unzip.

Firmware files are named in the following way:

ONKAVR_.zip

Unzip the file on your PC. The number of unzipped files

and folders varies depending on the model.

3. Copy all unzipped files and folders to the root folder of

the USB storage device.

• Make sure to copy the unzipped files.

4. Press USB on the remote controller to select "USB".

5. Connect the USB storage device to the USB port of the

unit.

• If you connect a USB hard disk drive to the USB

port of the unit, we recommend that you use its AC

adapter to power it.

• If the USB storage device has been partitioned, each

section will be treated as an independent device.

Firmware Update

50

6. After pressing RCV, press HOME on the remote

controller.

The Home menu is displayed on the TV screen.

Setup

HOME

7. With the cursors, select "Setup" - "7.Hardware Setup" -

"Firmware Update" - "Update via USB", and then press

ENTER.

• If "7.Hardware Setup" is grayed out and cannot be

selected, wait for a while until it starts up.

• You will not be able to select "Update via USB" if

there is nothing to update.

8. Press ENTER with "Update" selected to start update.

• During the update, the TV screen may go black

depending on the updated program. In that case,

check the progress on the display of the unit. The TV

screen will remain black until the update is complete

and the power is turned on again.

• During the update, do not turn off, or disconnect then

reconnect the USB storage device.

• "Completed!" is displayed when the update is

complete.

9. Disconnect the USB storage device from the unit.

10.

Press ON/STANDBY on the main unit to turn the

unit into standby mode. This is the end of the firmware

update and you have now the latest firmware installed.

• Do not use RECEIVER on the remote controller.

 If an Error Message is Displayed

Case 1: When an error occurs, "- Error!" is appeared

on the display of the unit. ("" represents an alphanumeric

character.) Check the following:

Error Code

• -01, -10:

USB storage device not found. Check whether the USB

storage device or USB cable is correctly inserted to the

USB port of the unit.

Connect the USB storage device to an external power

source if it has its own power supply.

• -05, -13, -20, -21:

The firmware file is not present in the root folder of the

USB storage device, or the firmware file is for another

model. Retry from the download of the firmware file.

• Others:

disconnect then reconnect the AC power cord, from the

beginning.

Troubleshooting

51

Troubleshooting

Before starting the procedure

Problems may be solved by simply turning the power on/off

or disconnecting/connecting the power cord, which is easier

than working on the connection, setting and operating

procedure. Try the simple measures on both the unit and

the connected device. If the problem is that the video or

audio is not output or the HDMI linked operation does not

work, disconnecting/connecting the HDMI cable may solve

it. When reconnecting, be careful not to wind the HDMI

cable since if wound the HDMI cable may not fit well. After

reconnecting, turn off and on the unit and the connected

device.

Resetting the unit

Resetting the unit to the status at the time of shipment may

solve the problem. If the measures above do not solve the

problem, reset the unit with the following procedure. If you

reset the unit status, your preferences will be reset to the

defaults. Note them down before starting reset.

■How to reset

1. While holding down CBL/SAT on the main unit (note

that step 2 must be performed with this button pressed

down)

2. Press ON/STANDBY on the unit.

"Clear" is appeared

on the display and the unit will enter standby mode.

Clear

2

1

■How to reset the remote controller

1. While holding down 1RCV on the remote controller

(note that step 2 must be performed with this button

pressed down)

2. Press and hold down 2HOME until the 3 remote

indicator lights (about 3 seconds). Within 30 seconds,

press 1RCV again.

1

2

3

Power

■Can not turn on the unit

• Make sure that the power cord is properly plugged into

the wall outlet.

• Unplug the power cord from the wall outlet, wait 5

seconds or more, then plug it in again.

■The unit turns off unexpectedly

• The unit will automatically enter standby mode when

Auto Standby has been set and launches.

■The unit turns off and after restoring the power, it

turns off again

• The protection circuit has been activated. Remove

the power cord from the wall outlet immediately. Make

sure that all speaker cables and input sources are

properly connected, and leave the unit with its power

cord disconnected for 1 hour. After that, reconnect the

power cord and turn the power on. If the unit turns off

again, avoid resetting it and unplug the power cord. Then

contact your Onkyo dealer.

Caution: If "CHECK SP WIRE" is appeared on the display,

the speaker cables may be shorting.

WARNING: If smoke, smell or abnormal noise is produced

by the unit, unplug the power cord from the wall outlet

immediately and contact the dealer or Onkyo Support.

Audio

■There is no sound, or it is very quiet

• Make sure that the proper input source is selected.

• Make sure that connecting plugs are pushed in all the

way.

• Make sure that the inputs and outputs of all components

are connected properly.

• Make sure that the polarity of the speaker cables is

correct, and that no bare wires are in contact with the

metal part of speaker terminals.

• Make sure that the input source is properly selected.

• Make sure that the speaker cables are not shorting.

• Check the volume. The volume level is adjustable

between Min, 1 to 79, Max (80) It is normal that the unit

volume level is set up to 40 or around.

• If the MUTING indicator on the display flashes, press

MUTING on the remote controller to unmute the unit.

• While headphones are connected to the PHONES jack,

no sound is output from the speakers.

• If there is no sound from a BD/DVD player connected to

an HDMI IN, check the BD/DVD player’s output settings,

and be sure to select a supported audio format.

• Check the digital audio output setting on the connected

component. On some game consoles, such as those

that support DVD, the default setting is off.

• With some DVD-Video discs, you need to select an

audio output format from a menu.

• If your turntable uses an MC cartridge, you must

connect an MC head amp, or an MC transformer.

• Make sure that none of the connecting cables are bent,

twisted, or damaged.

• Not all listening modes use all speakers.

• Specify the speaker distances and adjust the individual

speaker levels.

• Make sure that the speaker setup microphone is not still

connected.

• If the input signal format is set to "PCM" or "DTS", set it

to "Off".

■Only the front speakers produce sound

• When the Stereo or Mono listening mode is selected,

only the front speakers and subwoofer produce sound.

• Make sure the speakers are configured correctly.

Troubleshooting

52

■Only the center speaker produces sound

• If you use the Dolby Pro Logic II listening mode with

a mono source, such as an AM radio station or mono

TV program, the sound is concentrated in the center

speaker.

• Make sure the speakers are configured correctly.

■The surround speakers produce no sound

• When the T-D (Theater-Dimensional), Stereo or Mono

listening mode is selected, the surround speakers

produce no sound.

• Depending on the source and current listening mode,

not much sound may be produced by the surround

speakers. Try selecting another listening mode.

• Make sure the speakers are configured correctly.

■The center speaker produces no sound

• When the Stereo or Mono listening mode is selected,

the center speaker produces no sound.

• Make sure the speakers are configured correctly.

■The subwoofer produces no sound

• When you play source material that contains no

information in the LFE channel, the subwoofer produces

no sound.

• Make sure the speakers are configured correctly.

■There is no sound with a certain signal format

• When listening to Dolby Digital and/or DTS sound,

digital connection is necessary.

• Check the digital input terminal setting. If the connection

is different from the default, re-setting is necessary.

• Check the digital audio output setting on the connected

component. On some game consoles, such as those

that support DVD, the default setting is off.

■Can not select the Pure Audio listening mode

(European, Australian and Asian models)

• The Pure Audio listening mode can not be selected

while Zone 2 is on.

■Can not select a desired listening mode

• Depending on the connecting status of the speaker,

some listening modes may not be selected. Check the

details in "Using the Listening Modes" section.

■Can not play 5.1ch

• Make sure the speakers are configured correctly.

• Not all listening modes use all speakers.

■Can not get 6.1/7.1 playback

• 6.1/7.1 playback is not possible if surround back

speakers and height speakers are not connected.

• Depending on the number of connected speakers, it is

not always possible to select all of the listening modes.

■The speaker volume cannot be set as required

• Check to see if a maximum volume has been set.

■Noise can be heard

• Using cable ties to bundle analog audio (RCA) cables

with power cords, speaker cables, etc. may degrade the

audio performance, so refrain from doing it.

• An analog audio (RCA) cable may be picking up

interference. Try repositioning your cables.

■The Late Night function does not work

• Make sure the source material is Dolby Digital, Dolby

Digital Plus, or Dolby TrueHD.

■About DTS signals

• When DTS program material ends and the DTS

bitstream stops, the unit remains in DTS listening mode

and the dts indicator remains on. This is to prevent noise

when you use the pause, fast forward, or fast reverse

function on your player. If you switch your player from

DTS to PCM, you may not hear any sound because the

unit does not switch formats immediately. In such case,

you should stop your player for about 3 seconds and

then resume playback.

• With some CD and LD players, you will not be able

to playback DTS material properly even though your

player is connected to a digital input on the unit. This is

usually because the DTS bitstream has been processed

(e.g., output level, sampling rate, or frequency response

changed) and the unit does not recognize it as a

genuine DTS signal. In such cases, you may hear noise.

• Playing DTS program material, using the pause, fast

forward, or fast reverse function on your player may

produce a short audible noise. This is not a malfunction.

■The beginning of audio received by an HDMI IN can

not be heard

• Since it takes longer to identify the format of an HDMI

signal than it does for other digital audio signals, audio

output may not start immediately.

Video

■There is no picture

• Make sure that all video connecting plugs are pushed in

all the way.

• Make sure that each video component is properly

connected.

• If the TV is connected to the HDMI OUT jack of the unit,

set "Monitor Out" to "MAIN" or "SUB" according to the

output jack. If the playback source is connected to the

video (composite) jack or component video jacks and

you want to output the video to the TV via the HDMI

OUT jack, set "HDMI Input" to "-----".

• If the video source is connected to a component video

input, you must assign that input to an input selector,

and your TV must be connected to COMPONENT

VIDEO OUT terminal.

• If the video source is connected to a composite video

input, your TV must be connected to the MONITOR OUT

V terminal.

• If the video source is connected to an HDMI input, you

must assign that input to an input selector, and your TV

must be connected to the HDMI output(s).

• While the Pure Audio (European, Australian and Asian

models) listening mode is selected, the analog video

circuitry is turned off and only video signals input

through HDMI IN can be output.

• Make sure the switching of input screens is proper at the

monitor side such as a TV.

• When the image input from the composite video input

terminal does not get displayed, make sure that the

component video input terminal is not set to the selected

input. If selected, images input from the composite video

input terminal can not be output to this input switching. If

only composite video input terminal connection is used,

set the component video input terminal to "-----".

Troubleshooting

53

• Images of a component connected to the composite

video input terminal can not be output by converting on

the monitor of a TV or other components connected to

COMPONENT VIDEO OUT terminal.

• If the input selector to which the input from the TV

connected to the HDMI OUT SUB jack is connected

is changed on this unit when "Monitor Out" is set to

"MAIN+SUB", or "MAIN" and when outputting to Zone

2, the video from the TV connected to HDMI OUT MAIN

stops displaying.

• "Resolution" is effective only for the HDMI OUT MAIN

jack if "Monitor Out" is set to "MAIN+SUB".

■There is no picture from a source connected to an

HDMI IN

• Reliable operation with an HDMI-to-DVI adapter is not

guaranteed. In addition, video signals from a PC are not

supported.

• Check if "Resolution Error" is displayed on the main

unit display when video input via HDMI IN jack is not

displayed. In this case, the TV does not support the

resolution of the video input from the player. Change the

setting on the player.

■The on-screen menus do not appear

• On your TV, make sure that the video input to which this

unit is connected is selected.

• Set "On Screen Display" to "On" in "OSD Setup".

• When the unit is not connected to a TV via HDMI OUT

MAIN, on-screen menus are not displayed.

Tuner

■Reception is noisy, FM stereo reception is noisy, or

the FM STEREO indicator does not light

• Re-check the antenna connection.

• Relocate your antenna.

• Move the unit away from your TV or PC.

• Passing cars and airplanes can cause interference.

• Concrete walls weaken radio signals.

• Listen to the station in mono.

• When listening to an AM station, operating the remote

controller may cause noise.

• If nothing improves the reception, install an outdoor

antenna.

Remote Controller

■The remote controller does not work

• Before operating this unit using remote controller, be

sure to press RCV.

• Make sure that the batteries are installed with the

correct polarity.

• Install new batteries. Do not mix different types of

batteries, or old and new batteries.

• Make sure that the remote controller is not too far away

from the unit, and that there is no obstruction between

the remote controller and the remote control sensor of

the unit.

• Make sure that the unit is not subjected to direct

sunshine or inverter-type fluorescent lights. Relocate if

necessary.

• If the unit is installed in a rack or cabinet with colored-

glass doors or if the doors are closed, the remote

controller may not work reliably.

• Make sure you have selected the correct remote

controller mode.

• When using the remote controller to control other

manufacturers’ AV components, some buttons may not

work as expected.

• Make sure you have entered the correct remote control

code.

• Make sure to set the same ID on both the unit and

remote controller.

■Operating other Onkyo component by using a RI

remote control code is not available

• Make sure that the Onkyo component is properly

connected with RI cable. When RI cable is used for

connection, make sure to connect analog audio (RCA)

cable as well. (Connecting only an RI cable will not be

enough.)

• Make sure you have selected the correct remote

controller mode.

• Make sure that the input display is correctly set.

• Input the RI remote control code again.

• When the RI remote control code is input, point the

remote controller at remote control sensor of the unit.

■Can not operate Onkyo components (ones without

RI connection) and components of other makers

• Make sure that the connection with other components is

correct.

• Input a correct remote control code again. If there are

several codes, try each code.

• Make sure that the remote controller mode is correctly

selected.

• Operate the remote controller by setting toward the light

receiving section of each component.

• Some components may not start the operation.

RI Dock for iPod/iPhone

■There is no sound

• Make sure your iPod/iPhone is actually playing.

• Make sure your iPod/iPhone is properly inserted in the

Dock.

• Make sure the unit is turned on, the correct input source

is selected, and the volume is turned up.

• Make sure the plugs are pushed in all the way.

• Try resetting your iPod/iPhone.

■There is no video

• Make sure that your iPod/iPhone model’s TV OUT

setting is set to On.

• Make sure the correct input is selected on your TV or the

unit.

• Some versions of the iPod/iPhone do not output video.

■The AV receiver’s remote controller does not control

my iPod/iPhone

• Make sure your iPod/iPhone is properly inserted in the

Dock. If your iPod/iPhone is in a case, it may not connect

properly to the Dock. Always remove your iPod/iPhone

from the case before inserting it into the Dock.

• The iPod/iPhone can not be operated while it is

displaying the Apple logo.

• Make sure you have selected the correct remote

controller mode.

• When you use the AV receiver’s remote controller, point

it toward this unit.

• Before operating with the remote controller, you may

need to play on your iPod/iPhone to make the input

selector be recognized.

• Try resetting your iPod/iPhone.

• Depending on your iPod/iPhone model and generation,

some buttons may not work as expected.

Troubleshooting

54

■The unit unexpectedly selects my iPod/iPhone as the

input source

• Always pause iPod/iPhone playback before selecting

a different input source. If playback is not paused, the

Direct Change function may select your iPod/iPhone

as the input source by mistake during the transition

between tracks.

■iPod/iPhone does not work properly

• Try reconnecting your iPod/iPhone.

Zone Function

■There is no sound

• With Zone function, sound is output only when the signal

input source is an external component connected to

the analog audio input jacks of the unit, "NET", "USB"

or "BLUETOOTH". Zone playback is not possible if the

player and the unit are connected via HDMI cable or

digital cable. Connect the RCA audio output jacks of the

player and the analog audio input jacks of the unit with

analog audio (RCA) cable. Also analog audio output

setting may be necessary on the player.

AUDIO

OUT

Blu-ray Disc player

Wi-Fi (Wireless LAN) Network

■Cannot access to Wi-Fi (Wireless LAN) network or

sound playback is interrupted and communication

does not work

• Try plugging/unplugging the power supply of wireless

LAN router and the unit, check the wireless LAN router

power-on status, and try reboot of the wireless LAN

router.

• The setting of SSID and encryption (WEP, etc.) is not

correct. Make sure the network settings of the unit is

properly set.

• Connection to an SSID that includes multi-byte

characters is not supported. Name the SSID of the

wireless LAN router using single-byte alphanumeric

characters only and try again.

• Can not receive radio wave due to a bad connection.

Shorten the distance from wireless LAN access point

or remove obstacles for a good visibility, and try again.

Place the unit away from microwave ovens or other

access points. 2.4 GHz band for wireless LAN may not

be enough. Connect ETHERNET terminal of the unit

and the router via an Ethernet cable after selecting

"7.Hardware Setup" - "Network" and changing "Wi-Fi" to

"Off (Wired)".

• Place the unit away from the components emitting

electromagnetic waves on the 2.4 GHz band (microwave

ovens, game consoles, etc.). If this does not solve the

problem, stop using other components which emit

electromagnetic waves.

• When other wireless LAN devices are used near the

unit, several issues such as interrupted playback and

communication may occur. You can avoid these issues

by changing the channel of your wireless LAN router. For

instructions on changing channels, see the instruction

manual provided with your wireless LAN router.

• If there is a metallic object near the unit, wireless LAN

connection may not be possible as the metal can effect

on the radio wave.

• If there is more than one access point in the network,

separate each access point.

• It is recommended to place the Wi-Fi router (access

point) and the unit in the same room.

■The connection does not complete even when the

automatic setting button is pressed on the wireless

LAN router

• The wireless LAN router setting may be switched to

Manual. Return the setting to Auto.

• Try the manual set-up. The connection may succeed.

■On the list of SSID on the TV menu screen, there is

no corresponding SSID

• When the wireless LAN router setting is at stealth mode

(mode to hide the SSID key) or when ANY connection is

off, the SSID is not displayed. Change the setting and try

again.

Bluetooth

■Music playback is unavailable on the unit even after

successful Bluetooth connection

• Depending on the characteristics or specifications of

your Bluetooth-enabled device, playback on the unit is

not guaranteed.

• When the audio volume of your Bluetooth-enabled

device is set low, the playback of audio may be

unavailable. Volume up the Bluetooth-enabled device.

• Depending on the Bluetooth-enabled device, Send/

Receive selector switch may be provided. Select Send

mode.

• Even when a music file is playing on the Bluetooth-

enabled device, the sound can not be played if the

connection is not established with the unit. Make sure

that the unit is connected (this unit is selected as the

sound output destination).

■Sound is interrupted

• Problem may be occurring at the Bluetooth-enabled

device. Check the information on a webpage.

■The audio quality is poor after connection with a

Bluetooth-enabled device

• The Bluetooth reception is poor. Move the Bluetooth-

enabled device closer to the unit or remove any obstacle

between the Bluetooth-enabled device and this unit.

■Can not connect with this unit

• Try plugging/unplugging the power of the unit and try

turning on/off the Bluetooth-enabled device. Re-startup

of the Bluetooth-enabled device may be effective.

• The Bluetooth-enabled device does not support the

profiles required for this unit.

• The Bluetooth function of the Bluetooth-enabled

device is not enabled. Refer to the user manual of the

Bluetooth-enabled device for how to enable the function.

• Near components such as microwave oven or cordless

phone, which use the radio wave in the 2.4 GHz range,

a radio wave interference may occur, which disables the

use of this unit.

Troubleshooting

55

■Bluetooth connection can not be built

• When building a Bluetooth connection between this unit

and your Bluetooth-enabled device for the first time,

if the connection fails, select "7.Hardware Setup" - "

Bluetooth", execute "Clear" in "Pairing Information", turn

off and then on again your Bluetooth-enabled device to

clear the device name, and build the connection again.

• If there is a metallic object near the unit, Bluetooth

connection may not be possible as the metal can effect

on the radio wave.

• If the wireless LAN and Bluetooth connections are

used at the same time, try to connect the ETHERNET

port and router with the Ethernet cable after selecting

"7.Hardware Setup" - "Network" and changing "Wi-Fi" to

"Off (Wired)" for a better connection.

■The Bluetooth Auto Reconnect function does not

work

• This function may not work depending on your

Bluetooth-enabled device.

In this case, play on your Bluetooth-enabled device after

pairing with this unit.

NET/USB Function

■Can not access the network server

• When NET is blinking, the AV receiver is not properly

connected to the home network.

• Make sure your network server has been started up.

• Make sure your network server is properly connected to

the home network.

• Make sure your network server is correctly set.

• Make sure that the router LAN side port is properly

connected to the AV receiver.

• Make sure that the correct IP address is allocated in

"7.Hardware Setup" - "Network".

■Playback stops while listening to music files on the

network server

• Make sure the network server is compatible with this

unit.

• When the PC is serving as the network server, try

quitting any application software other than the server

software (Windows Media Player 12 etc.).

• If the PC is downloading or copying large files, the

playback may be interrupted.

■Can not access the Internet radio

• Certain network service or contents available through

the unit may not be accessible in case the service

provider terminates its service.

• If a specific radio station is unavailable for listening,

make sure the registered URL is correct, or whether the

format distributed from the radio station is supported by

the AV receiver.

• When NET is blinking, the AV receiver is not properly

connected to the home network.

• Make sure that your modem and router are properly

connected, and make sure they are both turned on.

• Make sure that connecting to Internet from other

components is possible. If connecting is not possible,

turn off all components connected to the network, wait

for a while, and then turn on the components again.

• Make sure that the router LAN side port is properly

connected to the AV receiver.

• Make sure that the correct IP address is allocated in

"7.Hardware Setup" - "Network".

• Depending on ISP, setting the proxy server is necessary.

• Make sure that the used router and/or modem is

supported by your ISP.

■Can not connect to the AV receiver from a Web

browser

• Make sure that the IP address of the AV receiver is

correctly input to the Internet browser.

• When DHCP is used for allocating the IP address, the IP

address of this AV receiver may have been changed.

• Make sure that both AV receiver and PC are properly

connected to the network.

■USB storage device is not displayed

• Make sure that USB storage device and USB cable are

securely plugged to the USB port of this AV receiver.

• Remove the USB storage device from the AV receiver

once, and then try re-connecting.

• Performance of the hard disk that receives power from

the USB port of the unit is not guaranteed.

• Depending on the type of format, the playback may not

be performed normally. Check the type of the file formats

that is supported.

• USB storage device with security functions may not be

played.

Others

■Power consumption in standby mode

• In the following cases, the power consumption in

standby mode may reach up to a maximum of 5 W:

– When "Network Standby" in "7.Hardware Setup" -

"Network" is set to "On".

– When "HDMI CEC (RIHD)" is set to "On". (Depending

on the TV status, the AV receiver will enter normal

standby mode.)

– The "HDMI Through" setting is set to other than "Off".

– When "Wakeup via Bluetooth" in "7.Hardware Setup"

- "Bluetooth" is set to "On".

• The power consumption in standby mode may be larger

than the value above while the MHL (Mobile High-

definition Link) enabled mobile device connected to the

AUX INPUT HDMI/MHL jack is being charged.

■The sound changes when I connect my headphones

• When a listening mode other than Direct, Pure Audio

(European, Australian and Asian models), or Mono is

selected, connecting a headphone automatically selects

Stereo.

■The display does not work

• The display is turned off when the Pure Audio

(European, Australian and Asian models) listening mode

is selected.

■How do I change the language of a multiplex source

• Select "Main" or "Sub" for "Multiplex Input Channel" in

"3.Audio Adjust" - "Multiplex/Mono".

■The RI functions do not work

• To use RI, you must make an RI connection and an

analog audio (RCA) connection between the component

and AV receiver, even if they are connected digitally.

• While Zone 2 is selected, the RI functions do not work.

■The functions System On/Auto Power On and Direct

Change do not work for components connected via RI

• These functions do not work when Zone 2 is turned on.

■When performing Automatic Speaker Setup, the

measurement fails and the message "Ambient noise is

too high." is displayed.

• This can be caused by a malfunction in your speaker

unit. Check if the unit produces normal sounds.

Troubleshooting

56

■The display is dark

• Make sure that Dimmer function is not working. Press

DIMMER button and change the brightness level of the

display.

■The following settings can be made for the

composite video inputs

• While holding down the input selector button to

configure, press HOME once at a time until "Video ATT:

On" is appeared on the display. To resume the setup,

repeat the above described step until "Video ATT: Off" is

appeared on the display.

This setting is possible for input selectors assigned

with one of the video inputs "VIDEO 1" to "VIDEO 3" in

"1.Input/Output Assign" - "Composite Video Input". If you

have a game console connected to the composite video

input, and the picture is not very clear, you can attenuate

the gain.

Video ATT: Off: (default).

Video ATT: On: (Gain is reduced by 2 dB.)

■If the picture on your TV/monitor connected to the

HDMI output(s) is unstable

• Try turning the DeepColor function off.

To turn off the DeepColor function, press STB/DVR and

ON/STANDBY on the AV receiver simultaneously.

While holding down STB/DVR, press ON/STANDBY

repeatedly until "Deep Color: Off" is appeared on the

display. To reactivate the DeepColor function, repeat the

above described step until "Deep Color: On" is appeared

on the display.

Radio Wave Caution

The AV receiver uses a 2.4 GHz radio wave

frequency, which is a band used by other wireless

systems as 1 and 2 described below.

1. Devices which use a 2.4 GHz radio wave frequency

• Cordless phones

• Cordless facsimiles

• Microwave ovens

• Wireless LAN devices (IEEE802.11b/g/n)

• Wireless AV equipment

• Wireless controllers for game systems

• Microwave oven-based health aids

• Video transmitter

• Specific type of external monitor and LCD display

2. Less common devices which use a 2.4 GHz radio wave

frequency

• Anti-theft systems

• Amateur radio stations (HAM)

• Warehouse logistic management systems

• Discrimination systems for train or emergency

vehicles

If these devices and the AV receiver are used at the same

time, the audio may be undesirably stopped or disturbed

due to a radio wave interference.

Suggestions for improvement

• Switch off the devices which emit the radio wave.

• Place the interfering devices away from the AV

receiver.

• The AV receiver uses radio wave, and a third person can

receive the wave on purpose or accidentally. Do not use

the communication for important or fatal matters.

• We assume no responsibility whatsoever for any error

or damage of network environment or access device

resulting from the use of this apparatus.

Confirm with the provider or access device maker for

more information.

Scope of Operation

Use of the AV receiver is limited to home use.

(Transmission distances may be reduced depending on

communication environment.)

In the following locations, poor condition or inability to

receive radio waves may cause the audio to be interrupted

or stopped:

• In reinforced concrete buildings or steel framed or iron

framed buildings.

• Near large metallic furniture.

• In a crowd of people or near a building or obstacle.

• In a location exposed to the magnetic field, static

electricity or radio wave interference from radio

communication equipment using the same frequency

band (2.4 GHz) as the AV receiver, such as a 2.4 GHz

wireless LAN device (IEEE802.11b/g/n) or microwave

oven.

• If you live in a heavily populated residential area

(apartment, townhouse, etc.) and if your neighbor’s

microwave oven is placed near your AV receiver, you

may experience radio wave interference. If this occurs,

move your AV receiver to a different place.

When the microwave oven is not in use, there will be no

radio wave interference.

Radio Wave Reflections

The radio waves received by the AV receiver include the

radio wave coming directly from the devices and waves

coming from various directions due to reflections by walls,

furniture and building (reflected waves). The reflected

waves (due to obstacles and reflecting objects) further

produce a variety of reflected waves as well as variation

in reception condition depending on locations. If the audio

cannot be received properly due to this phenomenon, try

moving the location of the wireless LAN device a little.

Also note that audio may be interrupted due to the reflected

waves when a person crosses or approaches the space

between the AV receiver and the wireless LAN device.

• We assume no responsibility whatsoever for any

damages resulting from the use of this apparatus except

in the cases deemed acceptable under the applicable

laws and regulations.

• Operation in all environment is not guaranteed for

wireless LAN. The communication may not be possible

or have desirable communication speed.

Precautions

• Do not use this apparatus near an electronic device

handling high-accuracy controls or weak signals. Doing

so may cause an accident due to a malfunction of the

device.

• Do not use this apparatus in use prohibited location

such as an aircraft equipment or a hospital. Doing so

may cause an accident due to a malfunction of an

electronic device or an electro-medical apparatus. Follow

the instructions of the medical facilities.

■Electronic device which requires cautions

Hearing aid, pace maker, other medical electronic devices,

Troubleshooting

57

fire alarm, automatic door, and other automatic control

device.

When using a pace maker or other medical electronic

• devices, confirm with the medical electronic device

• maker or dealer for the effect of the radio wave.

The AV receiver contains a microPC for signal processing

and control functions. In very rare situations, severe

interference, noise from an external source, or static

electricity may cause it to lockup. In the unlikely event that

this happens, unplug the power cord from the wall outlet,

wait at least 5 seconds, and then plug it back in.

Onkyo is not responsible for damages (such as CD rental

fees) due to unsuccessful recordings caused by the unit’s

malfunction.

Before you record important data, make sure that the

material will be recorded correctly.

Before disconnecting the power cord from the wall outlet,

set the AV receiver to standby.

Regarding the Video Resolution

The following shows how video signals at different

resolutions are output by the unit.

Describes as follows as "Input: Output".

■HDMI: HDMI

4K (2): 4K (1/3/4)

1080p/24: 4K (1), 1080p/24 (3)

1080p: 4K (1), 1080p (3)

1080i: 4K (1), 1080p, 1080i (3), 720p

720p: 4K (1), 1080p, 1080i, 720p (3)

480p/576p: 4K (1), 1080p, 1080i, 720p, 480p/576p (3)

480i/576i: 4K (1), 1080p, 1080i, 720p, 480p/576p,

480i/576i (3)

■Component: HDMI

480i/576i: 4K (1), 1080p, 1080i, 720p, 480p/576p,

480i/576i (3)

■Composite: HDMI

480i/576i: 4K (1), 1080p, 1080i, 720p, 480p/576p,

480i/576i (3)

■HDMI: Component

Can not be output.

■Component: Component

1080p: 1080p

1080i: 1080i

720p: 720p

480p/576p: 480p/576p

480i/576i: 480i/576i

■Composite: Composite

480i/576i: 480i/576i

1 Supported resolutions: [3840 × 2160 30 Hz], [3840 × 2160 25 Hz],

[3840 × 2160 24 Hz], [4096 × 2160 24 Hz]

2 The unit is compatible with HDMI IN 1 to HDMI IN 4. However, the

number of the player that outputs video signal at 4K resolution or the

same level at the same time may be up to three.

3 Supported resolutions for HDMI OUT SUB.

4Supportedresolutions:[3840×216060Hz],[4096×216060Hz],

[3840 × 2160 50 Hz] and [4096 × 2160 50 Hz] in YCbCr4:2:0

compliant with HDMI2.0

Reference Information

58

Reference Information

Linked Operation with CEC-compatible

Components

The AV receiver is compatible with the following

components (as of January 2014).

TV (Random order):

• Toshiba TV sets

• Sharp TV sets

Players/Recorders (Random order):

• Onkyo and Integra RIHD-compatible players

• Toshiba players and recorders

• Sharp players and recorders (only when used together

with Sharp TV sets)

Models other than those mentioned above may have some

interoperability if compatible with CEC, which is part of the

HDMI Standard, but operation can not be guaranteed.

Note: For RI functions to work properly, do not connect more RIHD-

compatible components than the quantities specified below, to

the HDMI jack. RI functions are not guaranteed when more RIHD-

compatible components than the below mentioned quantities are

connected. Furthermore, do not connect the AV receiver to another

AV receiver/AV amplifier via HDMI.

• Blu-ray Disc/DVD players: up to 3.

• Blu-ray Disc/DVD recorders: up to 3.

• Cable TV tuner, terrestrial digital tuner, and satellite broadcasting

tuner: up to 4 units.

Checking whether the HDMI Linked Operation

Settings Are Enabled

1. Turn on the power of all connected components.

2. Turn off the power of the TV, and confirm that the power

of the connected components is turned off automatically

with the link operation.

3. Turn on the power of the Blu-ray Disc/DVD player/

recorder.

4. Start playback on the Blu-ray Disc/DVD player/recorder,

and verify the following:

• The AV receiver automatically turns on, and selects the

input to which the Blu-ray Disc/DVD player/recorder is

connected.

• The TV automatically turns on, and selects the input

to which the AV receiver is connected.

5. Following the operating instructions of the TV, select

"Use the TV speakers" from the menu screen of the TV,

and confirm that the audio is output from the speakers of

the TV, and not from the speakers connected to the AV

receiver.

6. Select "Use the speakers connected from the AV

receiver" from the menu screen of the TV, and confirm

that the audio is output from the speakers connected to

the AV receiver, and not from the TV speakers.

Note:

• Even if you set to output audio on the TV speakers, audio will

be output from the speakers connected to the AV receiver when

you adjust the volume or switch the input on the AV receiver.

To output audio from the TV speakers, redo the corresponding

operations on the TV.

• In case of an RIHD connection with RI and RI audio control

compatible components, do not connect the RI cable at the

same time.

• On the TV, when you select anything other than the HDMI jack to

which the AV receiver is connected, the input on the AV receiver

will be switched to "TV/CD".

• The AV receiver will automatically power on in conjunction

when it determines it to be necessary. Even if the AV receiver

is connected to an RIHD compatible TV or player/recorder, it

will not power on if it is not necessary. It may not power on in

conjunction when the TV is set to output audio from the TV.

• Linked system functions with the AV receiver may not work

depending on the component model connected. In such cases,

operate the AV receiver directly.

• When the player/recorder cannot be operated with the remote

controller of the AV receiver, the corresponding component may

not be programmed to support the remote controller operation of

CEC. Program the remote control code of the component maker

to the remote controller for using.

About HDMI

HDMI (High Definition Multimedia Interface) is a digital

interface standard for connecting TVs, projectors, Blu-

ray Disc/DVD players, set-top boxes, and other video

components. Until now, several separate video and audio

cables have been required to connect AV components. With

HDMI, a single cable can carry control signals, digital video,

and digital audio (2-channel PCM, multichannel digital

audio, and multichannel PCM).

The HDMI video stream (i.e., video signal) is compatible

with DVI (Digital Visual Interface) (1), so TVs and displays

with a DVI input can be connected by using an HDMI-to-

DVI adapter cable. (This may not work with some TVs and

displays, resulting in no picture.)

This unit supports HDCP (High-bandwidth Digital Content

Protection) (2), so it can display picture only on HDCP-

compatible components.

The HDMI on this unit supports the following functions:

Audio Return Channel, 3D, x.v.Color, DeepColor, Lip Sync,

4K (Passthrough), DTS-HD Master Audio, DTS-HD High

Resolution Audio, Dolby TrueHD, Dolby Digital Plus, DSD

and Multichannel PCM.

Supported Audio Formats of this Unit:

• 2-channel linear PCM (32 - 192 kHz, 16/20/24 bit)

• Multichannel linear PCM (up to 7.1 ch, 32 - 192 kHz,

16/20/24 bit)

• Bitstream (DSD, Dolby Digital, Dolby Digital Plus, Dolby

TrueHD, DTS, DTS-HD High Resolution Audio, DTS-HD

Master Audio)

Your Blu-ray Disc/DVD player must also support HDMI

output of the above audio formats.

Reference Information

59

About Copyright Protection:

The HDMI jack of this unit is compliant with Revisions 1.4

and 2.2 (HDMI OUT MAIN and HDMI IN3 jacks only) of

the HDCP (High-bandwidth Digital Content Protection)

specification (2), which is a copy-protection system for

digital video signals.

Other devices connected to this unit via HDMI must also be

compliant with HDCP.

1 DVI (Digital Visual Interface): The digital display interface standard set

by the DDWG (3) in 1999.

2 HDCP (High-bandwidth Digital Content Protection): The video

encryption technology developed by Intel for HDMI/DVI. It is designed

to protect video content and requires a HDCP-compatible HDMI/DVI

receiver to display the encrypted video.

3 DDWG (Digital Display Working Group): Lead by Intel, Compaq,

Fujitsu, Hewlett-Packard, IBM, NEC, and Silicon Image, this open

industry group’s objective is to address the industry’s requirements for

a digital connectivity specification for high-performance PC and digital

displays.

Note:

• Some contents are only available for devices compliant with

HDCP Rev. 2.2.

To view and listen to this kind of content, connect the TV or

player compliant with the HDCP Rev. 2.2 specification to the

HDMI OUT MAIN and HDMI IN3 jacks of this unit.

• The HDMI video stream (i.e., video signal) is compatible with

DVI (Digital Visual Interface), so TVs and displays with a DVI

input can be connected by using an HDMI-to-DVI adapter cable.

(Note that DVI connections only carry video, so you will need

to make a separate connection for audio.) However, reliable

operation with such an adapter is not guaranteed. In addition,

video signals from a PC are not supported.

• The HDMI audio signal (sampling rate, bit length, etc.) may be

restricted by the connected source component. If the picture

is poor or there is no sound from a component connected via

HDMI, check its setup. Refer to the connected component’s

instruction manual for details.

Home network (LAN)

The connection of several components via cables enabling

the mutual communication is called a network.

At households, many families create (generally, the term

"build" is used) a network to connect PC and gaming

machines to the Internet and to exchange data between

PC.

The network established in a relatively narrow area such as

one household is called a LAN (Local Area Network).

In this manual, a term "home network" (network for a

family) is used instead of "LAN," so this LAN becomes

more familiar.

By connecting this unit with the network server such as a

PC, playing music files in the network server (in the PC) is

possible. Moreover, by connecting to the Internet, listening

to the Internet radio is also possible.

This unit, PC, and Internet are not directly connected.

When connecting with a PC and/or Internet, several

components (network components) are necessary.

Components necessary for establishing a home

network (LAN):

Components necessary for the home network (LAN) for

using the NET function of this unit are as follows.

■Router

A router is a device that controls information (data) flow

between the unit, PC, and the Internet.

As a network term, the flow of information (data) is called

"traffic". The router has a role to control the information flow

as the traffic control, between connected components.

• A router with a built-in 100Base-TX switch is

recommended.

In addition, if your router has the DHCP function,

facilitating the network setting becomes possible.

• Some routers have a built-in modem, and some Internet

Service Providers (ISP) require you to use specific

routers.

Please consult your ISP or PC dealer if you are unsure.

■CAT5 Ethernet cable

The Ethernet cable is a cable that actually connects

components that comprise the network. There are straight

type and cross type Ethernet cables.

• Use a shielded CAT5 Ethernet cable (straight-type) to

connect the unit to your home network.

Consult your cable store for details of Ethernet cable.

■Network server

(When PC etc./network server is used)

Component that stores music files and provides those files

at the time of playback.

• Requirements for use with this unit depend on the

component that is used as a network server.

• Conditions for pleasant playback of music files on

the unit depend on the using network server (PC

performance). See instruction manuals of using

components.

■Modem (when Internet radio is used)

Device that connects home network (LAN) and Internet

There are many kinds of modems depending on the forms

of Internet connection.

In addition, when connecting to the Internet, it is required

to conclude an agreement with a company that provides

Internet connection service, called ISP (Internet Service

Provider).

Use a modem that is recommended by your ISP company

for the Internet connection.

There are some devices that have both router and modem

functions.

Within above network components, prepare a router,

Ethernet cable, and network server when the NET function

"network server" is used.

For enjoying the NET function "Internet radio," it is

necessary to use the router, Ethernet cable, and modem

(and agreement with ISP).

Reference Information

60

Server Requirements

■Server playback

This unit can play digital music files stored on a PC or

media server and supports the following technologies:

• Windows Media Player 11

• Windows Media Player 12

• DLNA-certified media server

The network server must be connected to the same

network as this unit.

Up to 20,000 folders can be displayed, and folders may be

nested up to 16 levels deep.

Note: Depending on the media server, the unit may not recognize it,

or may not be able to play its music files.

■Remote playback

Remote playback is the function that enables this unit to

play music files saved in different components by operating

the DLNA-compliant controller component and PC in the

home network.

• Windows Media Player 12

• DLNA-certified (within DLNA Interoperability Guidelines

version 1.5) media server or controller component.

½ The setting varies depending on the media server or controller

components. Refer to your components’ instruction manual for details.

If the operating system of your personal PC is Windows 8/

Windows 7, Windows Media Player 12 is already installed.

For more information, see the Microsoft web site.

USB Storage Device Requirements

• USB mass storage device class (but not always

guaranteed).

• FAT16 or FAT32 file system format.

• If the USB storage device has been partitioned, each

section will be treated as an independent device.

• Up to 20,000 folders can be displayed, and folders may

be nested up to 16 levels deep.

• USB hubs and USB storage devices with hub functions

are not supported. Do not connect these devices to the

unit.

Note:

• If the media you connect is not supported, the message "No

Storage" will be displayed.

• Sound files that are protected by copyright can not be played.

• When the USB audio player and this unit are connected, the

audio player screen and the screen of the unit may be different.

In addition, control functions of the audio player (classifying and

sorting music files and adding information, etc.) are not available

on this unit.

• Do not connect a PC to the USB port of the unit. Inputting sound

to the USB port of the unit from a PC is not possible.

• Media inserted to the USB card reader may not be available in

this function.

• Some USB storage devices and its contents may require some

time to be read.

• Depending on the USB storage device, proper reading of the

contents and proper supply of the power supply may not be

possible.

• Onkyo accepts no responsibility whatsoever for the loss or

damage to data stored on a USB storage device when that

device is used with this unit. We recommend that you back up

your important music files beforehand.

• Performance of the hard disk that receive power from the USB

port of the unit is not guaranteed.

• If you connect a USB hard disk drive to the USB port of the unit,

we recommend that you use its AC adapter to power it.

• When an audio player that are operated with batteries is used,

make sure that the batteries have enough remaining power.

• USB storage devices with security functions can not be played.

Supported Audio Formats

• For server playback and playback from a USB storage

device, this unit supports the following music file formats.

• Music files of the following formats that can be played

depend on the network server. For example, when using

Windows Media Player 12, not all music files in the PC

can be played. The music files that can be played are the

ones registered to the Windows Media Player 12 library.

• Variable bit-rate (VBR) files are supported. However,

playback times may not be displayed correctly.

• This unit supports the gapless playback of the USB

storage device in the following conditions.

When WAV, FLAC and Apple Lossless files are

continuously played back with the same format,

sampling frequency, channels and quantization bit rate.

• Remote playback does not support the gapless

playback.

Note:

• With remote playback, this unit does not support the following

music file formats:

– FLAC, Ogg Vorbis, DSD and Dolby TrueHD.

■MP3 (.mp3 or .MP3)

• Supported formats: MPEG-1/MPEG-2 Audio Layer 3

• Supported sampling rates: 8 kHz, 11.025 kHz, 12 kHz,

16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz

• Supported bitrates: Between 8 kbps and 320 kbps and

VBR. Incompatible files can not be played.

Reference Information

61

■WMA (.wma or .WMA)

WMA stands for Windows Media Audio and is an audio

compression technology developed by Microsoft

Corporation. Audio can be encoded in WMA format by

using Windows Media® Player.

• WMA files must have the copyright option turned off.

• Supported sampling rates: 8 kHz, 11.025 kHz, 22.05

kHz, 32 kHz, 44.1 kHz, 48 kHz

• Supported bitrates: Between 5 kbps and 320 kbps and

VBR. Incompatible files can not be played.

• WMA Pro/Voice formats are not supported.

■WMA Lossless (.wma or .WMA)

• Supported sampling rates: 44.1 kHz, 48 kHz, 88.2 kHz,

96 kHz

• Quantization bit: 16 bit, 24 bit

■WAV (.wav or .WAV)

WAV files contain uncompressed PCM digital audio.

• Supported sampling rates: 8 kHz, 11.025 kHz, 12 kHz,

16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz,

64 kHz, 88.2 kHz, 96 kHz, 176.4 kHz and 192 kHz

• Quantization bit: 8 bit, 16 bit, 24 bit

½ For playback from a USB storage device, sampling rates of 176.4 kHz

and 192 kHz are not supported.

■AAC

(.aac/.m4a/.mp4/.3gp/.3g2/.AAC/.M4A/.MP4/.3GP or

.3G2)

• Supported formats: MPEG-2/MPEG-4 Audio

• Supported sampling rates: 8 kHz, 11.025 kHz, 12 kHz,

16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz,

64 kHz, 88.2 kHz, 96 kHz

• Supported bitrates: Between 8 kbps and 320 kbps.

Incompatible files can not be played.

■FLAC (.flac or .FLAC)

FLAC is a file format for lossless audio data

compression.

• Supported sampling rates: 8 kHz, 11.025 kHz, 12 kHz,

16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz,

64 kHz, 88.2 kHz, 96 kHz, 176.4 kHz and 192 kHz

• Quantization bit: 8 bit, 16 bit, 24 bit

½ For playback from a USB storage device, sampling rates of 176.4 kHz

and 192 kHz are not supported.

■Ogg Vorbis (.ogg or .OGG)

• Supported sampling rates: 8 kHz, 11.025 kHz, 16 kHz,

22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz

• Supported bitrates: Between 32 kbps and 500 kbps and

VBR.

• Incompatible files can not be played.

■LPCM (Linear PCM)

• Supported sampling rates: 44.1 kHz, 48 kHz

• Quantization bit: 16 bit

½ Only for playback via DLNA.

■Apple Lossless (.m4a/.mp4/.M4A/.MP4)

• Supported sampling rates: 8 kHz, 11.025 kHz, 12 kHz,

16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz,

64 kHz, 88.2 kHz, 96 kHz

• Quantization bit: 16 bit, 24 bit

■DSD (.dsf or .DSF)

• Supported sampling rates: 2.8224 MHz, 5.6448 MHz

½ For playback from a USB storage device, sampling rates of 5.6448 MHz

is not supported.

■Dolby TrueHD (.vr/.mlp/.VR/.MLP)

• Supported sampling rates: 48 kHz, 64 kHz, 88.2 kHz, 96

kHz, 176.4 kHz, 192 kHz

½ForplaybackfromaUSBstoragedevice,onlysamplingratesof48kHz

is supported.

Reference Information

62

Remote Control Code List

 Television (A to E)

A.R. Systems 10037, 10556

Accent 10037

Acoustic Solutions 11667, 11585,

11037

Action 10650

Addison 10653, 11150

AEG 11037

Aiko 10037

Aim 10037

Akai 10037, 12676,

10208, 10714,

10556, 12414,

13183, 10178

Akiba 10037

Akito 10037

Akura 10037, 10714,

11667, 11585,

10171, 11037

Alba 11037, 12676,

10037, 10714,

11585

Alien 11037

Allstar 10037

Amstrad 10037, 10171,

11037

Anam 10037, 10650

Andersson 11585, 12676

Anitech 10037

Ansonic 10037

AOC 11365, 12769,

10178, 10625,

11150

Apex Digital 12397

Ardem 10714, 10037

Arena 10037

Ario 12397

Aristona 10556, 10037

ART 11037

Art Mito 11585

Asberg 10037

Astra 10037

AT D 10698

Atlantic 10037

Audiosonic 10714, 10037

Audioworld 10698

Autovox 12676

Aventura 10171

Axxon 10714

Baird 10208

Barco 10556

Base 10698

Basic Line 10037, 11037,

10556

Baur 10037, 10195

Beaumark 10178

Beijing 10208

Beko 10714, 10037

Bell & Howell 10017

Belson 10698

Belstar 11037

Beon 10037

Berthen 10556

Bestar 10037

Bexa 12493

BGH 12414

Black Diamond 11037

Blaupunkt 10195

Blue Sky 10714, 10037,

11037, 10556,

10625

BPL 10208, 10037

Brandt 10625, 11585,

10714

Brinkmann 10037

Brionvega 10037

Britania 12414

Bush 11037, 10037,

10714, 12676,

11667, 10208,

10556, 10698,

11585

Byd:sign 12209

Camper 10037

Carad 11037

Carena 10037

Carrefour 10037

Cascade 10037

Casio 10037

Cathay 10037

CCE 13782, 10037

Celcus 12676, 11585

Celebrity 10000

Centrum 11037

Centurion 10037

Changhong 13434, 12769,

10508

Chimei 12769

Chun Yun 10000, 11150

Chung Hsin 11150

Clarivox 10037

Clatronic 10037, 10714

Clayton 11037

Coby 13478

Commercial Solutions 11447

Condor 10037

Conrowa 10698

Contec 10037

Cosmel 10037

CPTEC 10625

Crown 10037, 10714,

10208, 11037

Crypton 11667

Curtis 12397

Cyberpix 11667

D-Vision 10037, 10556

Daewoo 10037, 10556,

10178, 11150

Dansai 10037, 10208

Dantax 11037, 10714,

12676

Datsura 10208

Dawa 10037

Daytron 10037

De Graaf 10208

Decca 10037

Denver 10037

Desmet 10037

Diamant 10037

Diamond 10698

Digatron 10037

Digihome 11667, 12676

Digiline 10037

Digisonic 11826

Digitor 10698, 10037

Dixi 10037

Drean 10037

DSE 10698

Dual 11667, 10037,

11037, 11585,

12676, 10714

Dumont 10017

Durabrand 10171, 10178,

10714, 11037

Dux 10037

DX Antenna 13817

Dynatron 10037

Dynex 12049

E.S.C. 10037

ECE 10037

Elbe 10037, 10556

Electroband 10000

Electrograph 11755

Elektra 10017

Elfunk 11037

ELG 10037

Elin 10037

Elite 10037

Emerson 11864, 10171,

11394, 10178,

10037, 10714

Envision 11365, 11506

Epson 11379

Erres 10037

Reference Information

63

ESA 10171

Euroman 10037

Europa 10037

Europhon 10037

Evesham Technology 11667

Excello 11037

Exquisit 10037

 Television (F to J)

F&U 12676

FairTec 11585

Ferguson 10625, 11037,

10037, 10195,

11585, 12676

Fidelity 10037, 10171

Finlandia 10208

Finlux 11667, 10714,

12676, 10037,

10556

Firstline 10714, 10037,

11037, 10208,

10556

Fisher 10208

Flint 10037

Formenti 10037

Fraba 10037

Freesat 11636

Friac 10037

Frigidaire 11826

Fujitsu 10809

Fujitsu Siemens 10809

Funai 13817, 10171,

11394, 11037,

10714

Gaba 11037

Galaxi 10037

Galaxis 10037

Gateway 11755

GE 11447, 10178,

10625, 11454

GEC 10037

Genesis 10037

Genexxa 10037

GFM 10171, 11864

Gibralter 10017

Gibson 11826

Gintai 11150

Godrej 11585

GoGen 12676

GoldStar 10178, 10037,

10714, 11150

Goodmans 10037, 11037,

11667, 10714,

11585, 10556,

10625, 12676

Gorenje 11585, 12676

Gradiente 10037

Graetz 10714

Granada 10208, 10037

Grandin 10037, 10714,

11037, 10556

Grundig 10195, 11223,

10556, 10037,

11667, 12676

H-Buster 13620

Haier 13620, 10698,

10037, 10508

Hallmark 10178

Hankook 10178

Hannspree 11826

Hanseatic 10037, 10714,

10625, 10556

Hantarex 10037

Hantor 10037

Harwood 10037

Hauppauge 10037

HB 10714

HCM 10037

Heran 11826

Herosonic 11826

Highline 10037

Hinari 10037, 10208

HiPlus 11826

Hisawa 10714

Hisense 10556, 10508,

10208

Hitachi 11643, 12676,

11576, 11585,

11691, 11037,

11667, 10037,

10150, 10178,

10508, 11150,

12170

Hitachi Fujian 10150

Hitec 10698

Hoher 10714

Hornyphon 10037

Hua Tun 11150

Hypson 10037, 10714,

10556, 11037

Hyundai 10698, 12676,

11037

Iberia 10037

ICE 10037

iLo 11394

Imperial 10037

Indiana 10037

Inno Hit 11037, 11585

Innova 10037

Insignia 12049, 10171

Integra 11807, 13100,

13500

Inteq 10017

Interbuy 10037

Interfunk 10037

Internal 10556

Intervision 10037

Irradio 10037

IRT 10698

Isis 12676

Isukai 10037

ITS 10037

ITT 12676, 10208

ITT Nokia 10208

ITV 10037

JCB 10000

Jinfeng 10208

Jinxing 10037, 10556,

10698

JMB 12676, 10556

Jubilee 10556

JVC 11774, 10653,

11601, 12271,

11428, 10508,

10650, 12676

 Television (K to N)

Kaisui 10037

Karcher 10714

Kathrein 10556

Kendo 11037, 11585,

12676, 10037

Kennex 11037

Kioto 10556

Kiton 10037

KLL 10037

Kneissel 10037, 10556

Kolin 10150, 10037,

11150, 11755

Kolster 10037

Konka 10037, 10714

Konnig 10037

Korpel 10037

Kosmos 10037

Kunlun 10208

Kupperbusch 12676

L&S Electronic 10714

Lavis 11037

Lecson 10037

Lenco 10037, 11037

Leyco 10037

Reference Information

64

LG 11840, 11860,

11423, 12731,

12182, 12358,

12362, 10178,

12424, 10037,

10714, 10017,

10556, 10698

LiesenKotter 10037

Lifetec 10037, 11037,

10714

Linetech 12676

Linsar 12676, 11667,

11585

Local India Brand 10208

Local Malaysia Brand 10698

Lodos 11037

Loewe 10633

Logik 11037, 10698,

11585

Luma 11037

Lumatron 10037

Lumenio 10037

Lux May 10037

Luxor 11037, 12676,

10208

LXI 10178

Madison 10037

Magnavox 12372, 11454,

11506, 10171,

11365, 11755,

11867

Magnum 10714, 10037

Manesth 10037

Manhattan 10037, 11037

Marantz 10037, 10556

Mark 10037, 10714

Mastro 10698

Masuda 10037

Matsui 10037, 10195,

10208, 11037,

10714, 10556,

11667, 12676

Matsushita 10650

Maxent 11755

Maxess 12493

Meck 10698

Mediator 10037, 10556

Medion 10714, 10037,

11037, 12676,

11667, 10556,

10698, 11585

Megatron 10178

MEI 11037

Melectronic 10037, 10195,

10714

Memorex 10178, 10150,

11037

Mercury 10037

Mermaid 10037

Metronic 10625

Metz 11037, 10195

MGA 10150, 10178

Micromaxx 10037, 10714,

11037

Midland 10017

Mikomi 11585, 11667

Minato 10037

Minerva 10195

Ministry Of Sound 11667

Minoka 10037

Mitsubishi 10150, 11250,

12313, 10178,

10037, 10556,

11150, 11037,

11171

Moree 10037

Morgan's 10037

Moserbaer 11585

MTlogic 10714

Mudan 10208

Multitec 11037, 10037

Multitech 10037

Myryad 10556

NAD 10037, 10178

Naiko 10037

Nakimura 10037

National 10208, 10508

NEC 12461, 10178,

10508, 10653,

11150

Neckermann 10037, 10556

NEI 10037, 11037

Neoka 11826

Netsat 10037

NetTV 11755

Neufunk 10556, 10714,

10037

Nevir 12676

New Sonic 11826

New Tech 10037, 10556

Newave 10178, 11150

Nikkai 10037

Nikkei 10714

Nikko 10178

Nokia 10208

Norcent 11365

Nordmende 10195, 11585,

10037, 10714,

11667

Normerel 10037

Novatronic 10037

Novita 11585

NPG 13434

 Television (O to S)

Oceanic 10208

OK Line 11037

OK. 13434, 12676

Okano 10037

OKI 11667, 12676,

13434, 11585

Omni 10698

Onei 11667

Onida 10653, 12414

Onimax 10714

Onix 10698

Onkyo 11807, 13100,

13500

Onn 11667

Opera 10037, 10714

Optimus 10650

Orava 11037

Orbit 10037

Orion 10037, 10556,

10714, 11037,

12676

Orline 10037

Ormond 11037

Osaki 10037, 10556

Osio 10037

Osume 10037

Otto Versand 10037, 10556,

10195

Pacic 10714, 11037,

10556

Palladium 10037, 10714,

10556

Palsonic 12461, 10698,

10037

Panama 10037

Panasonic 11636, 11291,

11480, 11650,

10650, 13825,

12170, 10037,

10208, 10508

Panavideo 13825

Panavision 10037

Panda 10208, 10508,

10698

Penney 10178

Perdio 10037

Perfekt 10037

Philco 13426, 12414,

10037, 10178

Reference Information

65

Philips 10037, 12800,

10556, 11887,

11867, 11506,

12372, 12680,

11454, 10171,

11365, 10017,

10000, 10178,

11394

Phocus 10714

Phoenix 10037

Phonola 10037, 10556

Pioneer 11457, 10037,

10698, 11636,

12171

PJ 11506

Plantron 10037

Playsonic 10714, 10037

Polaroid 12676, 11826

Powerpoint 10037, 10698

Prima 12461

Prinston 11037

Pro Vision 10037, 10556,

10714

Protronic 10037

Proline 10625, 10037,

11037, 12676

Proscan 11447

Prosonic 10714, 12676,

10037, 11585,

11667

Protech 10037, 11037

Proton 10178

Pulsar 10017

Pye 10037, 10556

Qingdao 10208

Quadro 11667

Quasar 11291, 10650

Quelle 10037, 11037,

10195

R-Line 10037

Radiola 10037, 10556

Radiomarelli 10037

RadioShack 10037, 10178

Radiotone 10037, 11037

RCA 11447, 12746,

10625, 12434,

12932, 12187,

10000, 10178,

10618, 11454,

13426

Realistic 10178

Recor 10037

Rectiligne 10037

Red Star 10037

Reex 10037, 11037

Relisys 11585

Relon 11826

Remotec 10037, 10171

Reoc 10714

Revox 10037

RFT 10037

Roadstar 11037, 10037,

10714

Rowa 10698, 10037

Runco 10017

Saba 10625, 10714,

12676

Sagem 10618

Saivod 11037, 10037

Salora 10208

Sampo 11755, 10171,

10178, 10650

Samsung 12051, 11632,

10618, 10037,

10556, 10178,

10208, 11150

Sansui 10037, 10714

Sanyo 10208, 11142,

11585, 12676,

12461, 11974,

12769, 10508,

11037, 11150,

11365, 11667

SBR 10037, 10556

Schaub Lorenz 10714, 12676,

11667

Schneider 10037, 10556,

10714, 11037,

11585, 12676

Schontech 11037

Scotch 10178

Scott 10178

Sears 10171, 10178

Seelver 11037

SEG 11037, 10037,

13434

SEI 10037

Sei-Sinudyne 10037

Semp Toshiba 13793

Sencor 10714

Senzu 12493

Serie Dorada 10178

Shanghai 10208

Sharp 11659, 12360,

10818, 11393,

12676, 10650,

11165, 11423

Sheng Chia 11150

Shintoshi 10037

Shivaki 10178, 10037

Siam 10037

Siemens 10195, 10037

Siera 10556, 10037

Silva 10037

Silva Schneider 10037

SilverCrest 12676, 11037

Sinudyne 10037

SKY 10037

Skyworth 12769, 10037,

10698

Solavox 10037

Soniko 10037

Soniq 12493

Sonitron 10208

Sonneclair 10037

Sonoko 10037

Sonolor 10208

Sontec 10037

Sony 12778, 11825,

10810, 10000,

11651, 11505,

11167

Soundesign 10178

Soundwave 10037, 11037

Sowa 10178, 11150

Soyea 10698

Soyo 11826

Squareview 10171

SR Standard 10037, 11037

Starlite 10037

STI 13793

Strato 10037

Sunny 10037

Sunstar 10037

Sunstech 12676

Sunwood 10037

Supersonic 10208

SuperTech 10037, 10556

Supra 10178

Supreme 10000

Svasa 10208

Sylvania 10171, 11864,

11394

Symphonic 10171, 11394

Synco 11755, 10000,

10178, 11826

Sysline 10037

Reference Information

66

 Television (T to Z)

Tacico 10178, 11150

Tai Yi 11150

Talent 10178

Tashiko 10650, 11150

Tatung 10037, 11150

TCL 12434, 13183,

13426, 12414,

10698

TCM 10714

Teac 10037, 11037,

10698, 10714,

11755, 10171,

10178

Te c 10037

Tech Line 10037, 11585

Technica 11037

Technics 10556, 10650

Technika 11667, 12676

TechniSat 10556

Technisson 10714

Techno 11585

Technosonic 10556, 10625

Techwood 11667, 11037,

12676

Tecnimagen 10556

Teco 10178, 10653

Tedelex 10208

Teknika 10150

TELE System 11585

Telecor 10037

Telefunken 10625, 12676,

12414, 10698,

11585, 10037,

10714, 11667

Telefusion 10037

Telegazi 10037

Telemeister 10037

Telesonic 10037

Telestar 10037, 10556

Teletech 10037, 11037

Teleview 10037

Tennessee 10037

Tensai 10037, 11037

Terris 11667

Tesla 11037, 10037,

10556, 10714

Tevion 10714, 11037,

10037, 10556,

11585, 11667

Thomson 10625, 11447,

10037

Thorn 10037

TMK 10178

TNCi 10017

Tokai 10037, 11037

Tokaido 11037

Topline 11037

Toshiba 11508, 11524,

11656, 12676,

10508, 13570,

10650, 11037,

10195, 10618,

11150, 11169

TRANS-continents 10037, 10556,

11037

Transonic 10037, 10698

Triad 10556

Triumph 10037, 10556

TVTEXT 95 10556

Uher 10037

Ultravox 10037

Unic Line 10037

Uniden 12122, 12676,

11667

United 10714, 11037,

10037, 10556

Universal 10037, 10714

Universum 10037, 11037,

10195, 10618

Univox 10037

V7 Videoseven 11755

Vestel 11037, 10037,

11585, 11667

Vexa 10037

Victor 11428, 10650,

10653

Videocon 10508, 10037

VideoSystem 10037

Vidtech 10178

Viewsonic 11755, 12049,

11365

Vision 11826, 10037

VIZIO 11758, 13758,

12209

Vortec 10037

Voxson 10037, 10178,

11667

VU 11365

Walker 12676, 11667,

11585

Waltham 10037, 11037

Wards 10017, 10000,

10178

Watson 11037, 10037,

10714

Wega 10037

Welltech 10714

Weltstar 11037

Westinghouse 11712, 11826,

11755, 12397

Westwood 11585

Wharfedale 11667, 10037,

10556

White Westinghouse 10037

Wilson 10556

Windsor 11037

Windy Sam 10556

Wintel 10714

Wyse 11365

Xiahua 10698

Xiron 11037

XLogic 10698

Xoceco 10037, 12461

Xrypton 10037

Yamaha 11576, 10650

Yamishi 10037

Yokan 10037

Yo k o 10037

YU-MA-TU 10037

Zenith 10017, 10178,

11423, 12731,

11365, 12358,

12362

Zepto 11585

Zonda 10698

 TV DVD Combination

Akai 12676, 32966

Alba 12676, 32966

Black Diamond 11037, 30713

Blue Sky 11037, 30713

Bush 12676, 10698,

11037, 30713,

32966

Centrum 11037, 30713

Crown 11037, 30713

Dual 11037, 30713

Dynex 12049

Elfunk 11037, 30713

Emerson 11864, 11394,

30675

Ferguson 11037, 30713

Funai 11394, 30675

Goodmans 11037, 12676,

30713, 32966

Grandin 30713

Grundig 30539

Hitachi 12676, 11037,

30713, 32966

Insignia 12049

JVC 12271, 11774

LG 11423

Linsar 12676, 32966

Logik 11037, 30713

Luxor 11037, 30713

Magnavox 12372

Reference Information

67

Matsui 11037, 12676,

30713

Medion 12676, 32966

Mitsubishi 34004

OK. 13434

OKI 12676, 32966

Orava 11037, 30713

Panasonic 12170

Philips 10556, 11454,

11394, 12372,

30539

Polaroid 12676, 32966

Powerpoint 10698

Prosonic 12676, 32966

RCA 12187, 12746,

12932, 11447

Samsung 12051

Sanyo 12676

SEG 11037, 30713

Sharp 10818, 12360,

12676, 32966

Soniq 12493

Sony 12778

Sylvania 11864, 11394,

10171, 30675,

30630

Teac 10698

Technica 11037, 30713

Telefunken 10698

Teletech 11037, 30713

Thomson 10625, 30551

Toshiba 11524, 12676,

32966

United 11037, 30713

Universum 30713

Vestel 11037

Viewsonic 12049

Weltstar 11037, 30713

Westinghouse 11712

Xiron 11037, 30713

 DVD

3D LAB 30539

Accurian 30675

Acoustic Solutions 30730, 30713

AEG 30675, 30770,

31233

Aiwa 30533

Akai 32966, 31233,

30675, 30770

Akura 31233

Alba 32966, 30713,

30730, 30539

Amitech 30770

Amstrad 30713, 30770,

32139

AMW 30872

Ansonic 30831

Aristona 30539, 30646

ASDA 32213

Audix 30713

Autovox 30713

Awa 30730, 30872

Axion 30730

Basic Line 30713

Bel Canto Design 31571

Belson 32139

Best Buy 32139

Black Diamond 30713

Blu:sens 31233

Blue Parade 30571

Blue Sky 30713

Brainwave 30770

Brandt 30551, 30503

Bush 30713, 30730,

30831, 32966

Byd:sign 30872

CCE 30730

Celcus 32966

Centrum 30713, 30675

Changhong 30627

Cinea 30831

Cineral 30730

Cinetec 30713, 30872

Classic 30730

Clatronic 30675, 31233

Clayton 30713

Coby 30730

Codex 31233

Continental Edison 30831, 30872

Craig 30831

Crown 30713, 30770

Cybercom 30831

Daenyx 30872

Daewoo 30770, 30872

Dansai 30770

Dantax 30713, 30539,

32966

Datsun 31233

Daytek 30872

Dayton Audio 30872

DCE 30831

Decca 30770

Denon 31634, 32258,

32748, 30490,

33851

Dewo 31634

Digihome 30713, 32966

DigiLogic 30713

DiK 30831

Disney 30675, 30831

DK Digital 30831

Dragon 30831

DSE 30675

Dual 30831, 30713,

30730, 32966

Durabrand 30675, 30713,

30831

Dynex 32596

E:max 30770, 31233

ECC 30730

Elfunk 30713

Elin 30770

Elite 32854

Elta 30770, 31233

Eltax 31233

Emerson 30675, 32213

EuroLine 30675, 31233

Ferguson 30713, 32966

Finlux 32966, 30770,

30741

Firstline 30713

Funai 30675

G-Hanz 32213

G-HanzS 32213

GE 30522

GFM 30675

Go Video 31044, 30741

GoldStar 30741

Goodmans 30713, 30730,

32966

GPX 30741

Gran Prix 30831

Grandin 30713, 31233

Grundig 30539, 30551,

30713, 32966

Grunkel 30770, 30831

GVG 30770

H & B 30713, 31233

Hanseatic 30741

Harman/Kardon 30582

HE 30730

Hello Kitty 30831

Henss 30713

Hitachi 32966, 30573,

30713, 31664

Hoher 30713, 30831

Home Electronics 30730, 30770

Humax 30646

HYD 31233

Hyundai 32966

Inno Hit 30713

Insignia 32596, 30675,

30741

Reference Information

68

Integra 32147, 30627,

31769, 30503,

31612, 30571,

31634

Irradio 31233, 30646

ITT 31233

JDB 30730

JMB 32966

JVC 30623, 31602,

30503, 30539,

32966

Kansas Technologies 31233

Kendo 30713, 30831

Kennex 30713, 30770

Kenwood 30490

Kiiro 30770

Kupperbusch 32966

Leiker 30872

Lenco 30713, 30770

Lexicon 32545

LG 30741, 31602,

31233

Lifetec 30831

Linetech 32966

Linsar 32966

Lodos 30713

Loewe 30741, 30539

Logik 30713

Lumatron 30713, 30741

Lunatron 30741

Luxman 30573

Luxor 30713, 32966

Magnavox 30675, 30503,

30646, 30539,

31354, 30713

Manhattan 30713

Marantz 30539, 32414,

33444

Mark 30713

Marquant 30770

Matsui 30713, 32966

Maxim 30713, 30872

MBO 30730

MDS 30713

Mecotek 30770

Medion 30831, 32966,

30741, 30630

Memorex 30831, 32213

Metz 30713, 30571

Micromedia 30503, 30539

Micromega 30539

Microsoft 31708, 32083,

30522

Microstar 30831

Minax 30713

Minoka 30770

Mitsubishi 34004, 30713

Mizuda 30770

Mustek 30730

Mystral 30831

NAD 30741

Naiko 30770

NEC 30741, 31602

Nevir 30831, 30770

Nisato 31233

Noblex 31233

Norcent 30872

Nordmende 30831

OK. 32966

OKI 32966

Onkyo 30627, 32147,

31612, 31769,

30503, 30571,

31634

Oppo 32545, 30575

Orava 30713

Orbit 30872

Orion 30713, 31233

Ormond 30713

Pacic 30831, 30713

Packard Bell 30831

Palladium 30713

Panasonic 30490, 31579,

31641, 32710,

33641, 33862,

32523

Philco 30675

Philips 32056, 30539,

31354, 32789,

32434, 30646,

31340, 30503,

30675, 32084

Pioneer 31571, 30631,

30571, 32442,

32854, 30142

Polaroid 32966

Polk Audio 30539

Portland 30770

Powerpoint 30872

Presidian 30675

Prinz 30831

Prism 30831

Pro Vision 30730

Proline 32966

Proscan 30522

Proson 30713

Prosonic 32966

Pye 30539, 30646

Radionette 30741

Radiotone 30713

RCA 30522, 32213,

30571, 31769

REC 30490

Red 32213

Red Star 30770

Richmond 31233

Roadstar 30713, 30730

Ronin 30872

Rotel 30623

Rowa 30872

Saba 30551

Saivod 30831

Salora 30741

Samsung 30199, 30573,

33195, 31635,

32369, 32489,

32329, 30490,

31044

Sanyo 32966, 30713,

31233

ScanMagic 30730

Schaub Lorenz 30770

Schneider 30539, 30831,

30646, 30713

Schontech 30713

Scott 31233

SEG 30713, 30872

Semp 30503

Semp Toshiba 30503

Sharp 30630, 32250,

30713, 32966,

30675

Sherwood 30741, 30770

Shinsonic 30533

Sigmatek 32139

Silva Schneider 30831, 30741

Skantic 30713, 30539

Skymaster 30730

SM Electronic 30730

Smart 30713

Sonashi 30831

Soniq 30831

Sony 31633, 31516,

30533, 31033,

31070, 30864,

32861, 31536,

32180

Sound Color 31233

Soundwave 30713

Spectra 30872

SR Standard 30831

Strong 30713

Sunkai 30770

Sunstech 30831, 32139,

32966

Reference Information

69

Supratech 32139

Sylvania 30675, 30630

Symphonic 30675

Sytech 30831

Tandberg 30713

Targa 30741

Tascam 31818

Tatung 30770

TBoston 32139

Tchibo 30741

TCM 30741

Teac 30571, 30675,

30741, 31818,

32139, 34004

Technica 30713

Technics 30490

Technika 30770, 30831

Technosonic 30730

Techwood 30713, 32966

Telefunken 30551, 32966

Teletech 30713

Tensai 30770

Theta Digital 30571

Thomson 30551, 30522,

30831

Tokai 31233

Toshiba 30503, 32705,

32277, 31769,

33157, 32966,

32551

TRANS-continents 30831, 30872,

31233

Transonic 30730

Trevi 30831

TVE 30713

United 30713, 30675,

30730, 31233

Universum 30713, 30741

Urban Concepts 30503

Venturer 31769

Vestel 30713

VIZIO 32563

Voxson 30831, 30730

Waitec 30730, 31233

Walker 32966

Waltham 30713

Welkin 30831

Wellington 30713

Weltstar 30713

Wharfedale 30713

Wilson 31233, 30831

Windsor 30713

Windy Sam 30573

Woxter 32139

X-View 31233

Xbox 31708, 32083,

30522

Xiron 30713

XMS 30770

Yamada 30872, 32139

Yamaha 30539, 30817,

30490, 32298,

31354, 30646

Yamakawa 30872

Yukai 30730

Zenith 30741, 30503

 Blu-ray Disc

Denon 32258, 32748,

33851

Elite 32854

Funai 30675

Insignia 32596, 30675

Integra 32147, 32900,

32910, 33100,

33101, 33500,

33501

Lexicon 32545

LG 31602, 30741

Magnavox 30675

Marantz 32414, 33444

Mitsubishi 34004

Onkyo 32147, 32900,

33101, 33501,

32910, 33100,

33500

Oppo 32545

Panasonic 31641, 33641,

33862, 32523,

32710

Philips 32789, 32434,

32084

Pioneer 32442, 32854,

30142

Samsung 30199, 33195

Sharp 32250

Sony 31516, 32180

Sylvania 30675

Tascam 31818, 34004

Toshiba 32705, 33157,

32551

VIZIO 32563

Yamaha 32298

 DVD-R

Accurian 30675

Aristona 30646

Denon 30490

Emerson 30675

Funai 30675

Go Video 30741

GPX 30741

Hitachi 31664

Humax 30646

Irradio 30646

LG 30741

Loewe 30741

Magnavox 30675, 30646

Medion 30741

Panasonic 30490, 31579,

32710, 32523

Philips 30646, 31340

Pioneer 30631

Pye 30646

RCA 30522

Samsung 31635, 30490,

32489

Schneider 30646

Sharp 30630, 30675

Sony 32861, 31070,

31516, 31033,

31536, 32180,

31633

Sylvania 30675

Targa 30741

Thomson 30551

Toshiba 32277, 32551

Yamaha 30646

Zenith 30741

 VCR

DirecTV 20739

Humax 20739

Panasonic 20616

Philips 20739

RCN 20739

ReplayTV 20616

Sonic Blue 20616

Sony 20636

TiVo 20739, 20636

 Cable Set Top Box (A to E)

3 Rivers Telephone

Cooperative

01376

Accelplus 01376, 01877,

01982

Access Cable

Television

01376, 01877,

01982

Access

Communications

01376, 01877

Ace Communications 02586

ACTV Cablevision 01376, 01877,

01982

Adams Cable TV 01376

Reference Information

70

ADB 02586, 01920,

01481, 01998,

02437, 03028

Advanced Broadband 01376, 01877,

01982

Advanced Telemedia 01376, 01877,

01982

Airwave Networks 01376, 01982

Akado 02043

Alabama Broadband 01376

Alcom 02437

Algona Municipal

Utilities

01376, 01877,

01982

All West

Communications

01376

Alleghany Cablevision 01376, 01877,

01982

Allegiance

Communications

01376

Alliance

Communications

01376

Allied Telesis 01376, 01877,

01982

Almega Cable 01376, 01877,

01982

Alpine Cable 01376, 01877,

01982

Alta Utilities 01877

Alternative Cable 01376, 01877,

01982

Altibox 02437

Altitude

Communications

01376

Americable

International

01877

American Broadband 01376, 01877,

01982

American

Entertainment Network

01376, 01877,

01982

American Telecasting 01376, 01877,

01982

Amherst Telephone 01376, 01877,

01982

Amino 01615, 01481,

01898, 01998,

03028

Anne Arundel

Broadband

01376

Antietam Cable 01376, 01877,

01982

Arc One 01376, 01877,

01982

Arctic Cooperatives 01376, 01877,

01982

Argent

Communications

01376, 01877,

01982

Arialink Broadband 01376, 01877,

01982

Arkwest 01481, 01998,

03028

Arledge Electronics 01376

Armstrong 01376, 01877

Arris 02187

Arvig Communication

Systems

01376, 01982,

01998, 02345

Ashland Home Net 01376, 01877,

01982

Askivision Systems 01376, 01877,

01982

Astound Broadband 01376, 01877

AT&T 00858

ATC Communications 01376

Atlantic Broadband 01877, 01376

ATMC 01376, 01982,

01998, 03028

Atwood Cable 01376, 01877,

01982

Aurora Cable TV 01376, 01877,

01982

Ayrshire

Communications

01376, 01877,

01982

B & C Cablevision 01376, 01877,

01982

B & L Technologies 01376, 01877,

01982

Bailey Cable TV 01376, 01877,

01982

Baja Broadband 01376

Baldwin County

Internet

01376, 01877,

01982

Baldwin Telecom 01877

Ballard Rural

Telephone Cooperative

02586

Barbourville Utility

Commission

01376, 01877,

01982

Bardstown Cable 01376, 01877,

01982

Bascom

Communications

01376, 01877,

01982

Base Cablevision 01376, 01877,

01982

Bay Cablevision 01376, 01877,

01982

Bay City Cablevision 01376, 01877,

01982

Bay Country

Communications

01376, 01877,

01982

Bay Creek

Communications

01376

Bayland

Communications

02586

Bayou Cable 01376, 01877,

01982

Beamspeed 01376, 01877,

01982

Beaver Creek

Telephone

01877, 01982

Beaver Valley Cable 01376, 01877,

01982

Beck's Cable Systems 01376, 01877,

01982

Bee Line Cable 01376

Beeline 03028

BELD Broadband 01376, 01877,

01982

Belgacom TV 02132

Belhaven Cable TV 01376, 01877,

01982

Bell 01998

Bell Aliant 01998

Bell Fibe TV 01998

Bellaire Cable 01376, 01877,

01982

Bellevue Cable 01376, 01877,

01982

Bend Broadband 01376, 02187

Bentleyville Cable 01376, 01877,

01982

Benton Cooperative

Telephone

01376, 01877,

01982

Beresford Cablevision 01376, 01877,

01982

Berkshire Cable Corp 01376, 01877,

01982

Beulah Cable TV 01376, 01877,

01982

Bevcomm 01615, 01898

Beyond

Communications

01376, 01877,

01982

Big Sandy Broadband 01376, 01877,

01982

Biltmore

Communications

01877, 01982

Blakely Cable

Television

01376, 01877,

01982

Bledsoe Telephone

Cooperative

01481, 01998,

03028

Bloomingdale

Communications

01481, 01998,

03028

Blue Mountain TV

Cable

01376, 01877,

01982

Blue Ridge

Communications

01877

Blue Sky Cable 01376, 01877,

01982

Blue Valley

Telecommunications

01898

Bobcaygeon Cable 01376, 01877,

01982

Booher Brothers Cable 01376, 01877,

01982

Bouygues Telecom 03007

Bowen Cablevision 01376, 01877,

01982

Boycom Cablevision 01376

Reference Information

71

Branch Cable 01376, 01877,

01982

Brandenburg Telecom 01481, 01998,

03028

Brandywine

Cablevision

01376, 01877,

01982

Bresnan 01376, 01877

Briand et Moreau

Cable

01376, 01877,

01982

Bright Green

Communications

01376, 01877,

01982

Bright House 01877, 01376

Bristol Tennessee

Essential Services

01877, 01998

Bristol Virginia Utilities 01376, 01877,

01982

British American 01376, 01877,

01982

Broadstar

Communications

01376, 01877,

01982

Broadstripe 01376

Brockway Television 01376, 01877,

01982

Broken Bow Cable TV 01376, 01877,

01982

Brooks Bay Cable 01376, 01877,

01982

Brownwood TV Cable

Service

01376, 01877,

01982

Bryan Municipal

Utilities

01376, 01877,

01982

BT 02294

BTC Broadband 02586

Buckeye Cable System 01877, 01376,

02187

Bulldog Cable 01376, 01877,

01982

Bulloch Telephone

Cooperative

01376, 01877,

01982

Burlington Telecom 01481, 01615

Butler Bremer Mutual

Telephone

01898

Byron Cable TV 01376, 01877,

01982

C & W Cable 01376, 01877,

01982

C.L. Davis Cable

Services

01376, 01877,

01982

Cable &

Communications

01376

Cable America 01376, 01877

Cable Axion Digitel 01376

Cable Communications

of Willsboro

01376, 01877,

01982

Cable Cooperative 01376, 01877,

01982

Cable Development

Corporation

01376, 01877,

01982

Cable Management

Assocication

01376, 01877,

01982

Cable Montana 01376, 01877,

01982

Cable Nebraska 01376, 01877,

01982

Cable Of The

Carolinas

01376, 01877,

01982

Cable One 01376, 01877

Cable Plus 01376, 01877,

01982

Cable Suite 01376

Cable Tech Cable TV 01376, 01877,

01982

Cable TV of Camrose 01376

Cable TV of East

Alabama

01376, 01877,

01982

Cable TV of Slave

Lake

01376, 01877,

01982

Cable TV of St. Paul 01376, 01877,

01982

Cable Vision Services 01877

Cablecom 01582

Cablecom Mexico 01376

Cablemas 01376, 01877

Cablenet 01376, 01877,

01982

CableSouth Media 01376, 01877,

01982

Cableview

Communications

01376, 01877,

01982

Cablevision 01877, 01376

Cablevision du Nord 01376

Cablevision of Marion

County

01376

Cablevision T.R.P. 01376, 01877,

01982

Cabovis 02436

Caiway 02015, 0660

CalNeva Broadband 01376, 01877,

01982

CalTel Connections 02586

Cameron

Communications

01376, 01877,

01982

CAMS Cable 01376, 01877,

01982

Canby Telcom 01481

Cannon Valley

Cablevision

01481, 01998,

03028

Caprock TV 01376, 01877,

01982

Carnegie Cable 01376, 01877,

01982

Carolina Mountain

Cable

01376, 01877,

01982

Carr Communications 01376, 01877,

01982

Carrell

Communications

01376, 01877,

01982

CAS Cable 01376

Cascade

Communications

01376, 01877,

01982

Casey Cable 01376, 01877,

01982

Caspian Community

TV

01376, 01877,

01982

Cass Cable 01376

Castle Cable Service 01376, 01877,

01982

Catalina Cable 01376, 01877,

01982

Catawba Services 01376, 01877,

01982

CBN 01376, 01877,

01982

CBPU Cable 01376, 01877,

01982

CCAP 01877

CDE Lightband 00858, 01615,

02586

Cedar Falls Utilities 01376

Celect

Communications

01376, 01877,

01982

Cencom 01376, 01877,

01982

CentraCom Interactive 01376, 01877,

01982

Central Texas

Communications

01376, 01877,

01982

Central Valley Cable 01376, 01877,

01982

Centre TV Cable 01376, 01877,

01982

Centrovision 01376, 01877,

01982

Century

Communications

01376, 01877,

01982

Century Telephone 01376, 01877,

01982

CenturyLink 01998

CenturyTel TeleVideo 01376, 01877,

01982

Chambers Cable 01376

Champion Broadband 01376, 01877,

01982

Chaparral Cablevision 01376, 01877,

01982

Chariton Valley

Communications

01376, 01877,

01982

Charter 01376, 01877,

02187

Chatmoss Cablevision 01376, 01877,

01982

Chequamegon

Telephone Cooperative

01898, 01615

Chesnee

Communications

01376, 01877,

01982

Reference Information

72

Chester Telephone 01376

Chinook Progressive

Club TV

01376, 01877,

01982

Chippewa Valley Cable 01376, 01877,

01982

Choice Cable TV 01376, 01877,

01982

Choice

Communications

01376, 01877,

01982

Choice Television 01376, 01877,

01982

ChoiceCable 01376

Christy Cablevision 01376, 01877,

01982

CimTel 01376

Cincinnati Bell 01877, 01376

Circle Bar Cable

Television

01376, 01877,

01982

Cisco 01877, 01982,

00858, 02589,

03028, 02132,

02345, 01582,

01883, 02378,

02401, 03265

Citizens Cable 01376

Citizens Cable TV 01376

Citizens Cablevision 01481

Citizens Mutual

Telephone

01376, 01877,

01982

Citizens Telecom 01376, 01877,

01982

Citizens Telephone 02586

City Cablevision 01376, 01877,

01982

City of Barnesville

Cable

01376, 01877,

01982

City of Baxter Springs

Cable

01376, 01877,

01982

City of Hawarden

Cable

01376, 01877,

01982

City of Norway Cable 01376, 01877,

01982

City of Quitman Cable 01376, 01877,

01982

City Of Salisaw 01376

City of Sumas TV

Cable System

01376, 01877,

01982

City West 01376

Citycable 03477

Clarence Telephone 01376, 01877,

01982

Claro 01376

Clear Creek

Communications

01376

Clearview Cable 01376, 01877,

01982

Clearview Partners 01376, 01877,

01982

Clearview TV Cable 01376, 01877,

01982

Clearvision Cable TV 01376, 01877,

01982

Click Network 01376

ClickOne 01376, 01877,

01982

Clinton Cable 01376, 01877,

01982

CLT Communications 01376, 01877,

01982

ClubInternet 02132

CMA Communications 01376

CNS Television 01376, 01877,

01982

Coast Cable

Communications

01376

Coast Cablevision 01376, 01877,

01982

Coast Communications 01376

Coastal Link 01376

Coaxial Cable TV 01376, 01877,

01982

Cobridge 01376

Cobridge

Communications

01376

Cogeco 01376, 01877,

01982

Colane Cable TV 01376, 01877,

01982

Colfax Highline Cable 01376, 01877,

01982

Collinsville Cable 01376, 01877,

01982

Colonial Cablevision 01376, 01877,

01982

ColtonTel 02378

Columbia Power and

Water

01376, 01877

Columbus Telephone 01376

Com Hem 00660, 02015

Com-Link 01376, 01877,

01982

Comcast 01376, 01982,

01877, 02187

Communication

Services

01376, 01877,

01982

Communicomm 01376, 01877,

01982

Community Antenna

Service

01376, 01877,

01982

Community Antenna

System

01376, 01877,

01982

Community Cable &

Broadband

01376

Community Cable

Service

01376, 01877,

01982

Community

Communications

01376, 01877,

01982

Community Telecom 01376, 01877,

01982

Community Television 01376, 01877

Compas Cable 01376, 01877,

01982

Complete

Communication

Services

01376, 01877,

01982

Comserv Ltd 01376, 01877,

01982

ComSouth 01376, 01877,

01982

ComSpan

Communications

01481, 01898

Comstar Cable TV 01376, 01877,

01982

Consolidated Cable 01376, 01877,

01982

Consolidated

Communications

01376

Conuma Cable

Systems

01376, 01877,

01982

Conway Corporation

Cable TV

01376, 01877,

01982

Conxxus 01376, 01877,

01982

Coon Creek Telephone 01376

Coon Rapids Municipal

Utilities

01376, 01877,

01982

Coop CSCF 01376

Cooperative Television

Godahl

01376, 01877,

01982

CoopTel 00858, 01615,

01898

Coosa Cable 01376

Copper Mountain

Metropolitan

01376, 01877,

01982

Country Cable 01376, 01877,

01982

Country Cable TV 01376, 01877,

01982

Country Cablevision 01376

Country Cablevision

Ltd.

01376

Cowley Telecable 01376, 01877,

01982

Cox 01877, 01376

Craig Cable TV 01376, 01877,

01982

Craw-Kan Telephone

Cooperative

02586

Crestview Cable 01376, 01877,

01982

Cross Country TV 01376, 01877,

01982

Crosslake

Communications

01376, 01877,

01982

Reference Information

73

Crow Cable TV 01376, 01877,

01982

CRRS-TV 01376

CRST Telephone

Authority

01481, 01998,

03028

Crystal Cable TV 01376, 01877,

01982

CSI Cable 01376, 01877,

01982

CT & R Cable 01376, 01877,

01982

CTC 01376

Cunningham

Telephone & Cable

01376

Curtis Cable TV 01376, 01877,

01982

CUTV 01376, 01877,

01982

CWA Cable 01376, 01877,

01982

D & D Cable Systems 01376, 01877,

01982

D & P Communications 01376

Daeryung 01877

Dairyland Cable

Systems

01376, 01877,

01982

Dakota Central

Telecommunications

02345

Dalton Cable

Television

01877, 01982

Darty Box 02436

Davis Communications 01376, 01877,

01982

Dawson City Television 01376, 01877,

01982

DCA Cablevision 01376, 01877,

01982

DDD Cablevision 01376, 01877,

01982

Dean Hill Cable 01376, 01877,

01982

Dean's Cablevision 01376, 01877,

01982

Decca Cable 01376, 01877,

01982

Deffner Cable TV 01376, 01877,

01982

Delhi Telephone 01376, 01877,

01982

Delta 02015, 00660

Delta Cable 01376

Demopolis CATV 01376, 01877,

01982

Denali TV 01376, 01877,

01982

Dery Telecom 01376

Deutsche Telekom 02132

Dickey Rural Networks 01376, 01877,

01982

Digeo 02187

Diode Communications 01376, 01877,

01982

Diverse

Communications

01898, 01982

Dixie Cable TV 01376, 01877,

01982

Dixon Telephone 01376, 01877,

01982

DMS Cable 01376, 01877,

01982

Downsville Community

Antenna

01376, 01877,

01982

Doylestown Cable TV 01376, 01877,

01982

Drummond Cable TV 01376, 01877,

01982

DTC 01376, 01877,

01982

Du 02401

Dumont Telephone 01376, 01877,

01982

Duncan Cable TV 01376, 01877,

01982

Eagle Broadband 01481, 01998,

03028

Eagle Cablevision 01376, 01877,

01982

Eagle Communications 01376, 02187

Eagle Valley Telephone 01481, 01998,

03028

EagleVision Wireless

TV Services

01376, 01877,

01982

East Arkansas Video 01376

East Cleveland Cable 01376, 01877,

01982

East Texas Cable 01376, 01877,

01982

Eastern Cable 01376, 01877,

01982

EastLink 01376

Easton Cable 01877

EasyTEL 01481, 01998,

03028

Eatel 01877

Echostar 03452

Electron Enterprises 01376, 01877,

01982

Elk River Cable TV 01376, 01877,

01982

Elkhart TV Cable 01376, 01877,

01982

Emery Telcom Video 01376, 01877,

01982

Emily Coop Telephone 01481, 01615

Enhanced

Telecommunications

01376

EnTouch 01376

EPB of Chattanooga 00858

Escape Broadband 01376, 01877,

01982

Eston CATV

Cooperative

01376, 01877,

01982

ETAN Industries 01376, 01877,

01982

Etex 02586

Execulink 01376

Eyecom 01376, 01877,

01982

 Cable Set Top Box (F to J)

F & B Telephone 02586

FairPoint

Communications

01376, 01877,

01982

Falls Earth Station 01376, 01877,

01982

FamilyView

Cablevision

01376, 01877,

01982

Fannettsburg Cable TV 01376, 01877,

01982

Farmer & Merchant

Mutual

01376, 01877,

01982

Farmer's Telephone

Cooperative

01998, 03028

Farmers Independent

Telephone

01376, 01877,

01982

Farmers Mutual

Telephone

01376, 01877,

01982

Fayetteville Electric

System

01877

Federated Telephone 01376

Fenton Cablevision 01376, 01877,

01982

FiberCast Cable

Communications

01376, 01877,

01982

FiberNet Monticello 01376, 01877,

01982

Fibrant 01376, 01877,

01982

Fidelity

Communications

01376

First Cable Of Missouri 01376, 01877,

01982

FirstMile 01376, 01877,

01982

Flint Cable TV 01376, 01877,

01982

Florida Cable 01376

Foothills Rural

Telephone Cooperative

01877

Forsyth CableNet 01376, 01877,

01982

Reference Information

74

Fort Jennings

Communications

02586

Fort Towson Cable 01376, 01877,

01982

Foster

Communications

01376, 01877,

01982

Frank Howard TV

Cable

01376, 01877,

01982

Frankfort Plant Board

Cable

01376

Freebox 01976

FTC 01877, 01982,

01376

Full Channel TV 01376, 01877,

01982

Full Choice

Communications

01376, 01877,

01982

Fusion Broadband 01376, 01877,

01982

Futuristic Cablevision 01376, 01877,

01982

Galaxy American

Communication

01376, 01877,

01982

Galaxy Cable 01376, 01877,

01982

Gardonville

Cooperative Telephone

01998

Gatehouse Networks 01376, 01877,

01982

Gauthier Cablevision &

Electric

01376, 01877,

01982

GCI 01877

General

Communications

01376

Genext 01376, 01877,

01982

Geraldine Cable TV 01376, 01877,

01982

Get Real Cable 01376, 01877,

01982

GEUS 01376, 01877,

01982

Giant Communications 01376, 01877,

01982

Giles-Craig

Communications

01376, 01877,

01982

Gilmer Cable

Television

01376, 01877,

01982

Glasgow Electric Plant

Board

01376, 01877,

01982

Glass Antenna

Systems

01376, 01877,

01982

Glenwood

Telecommunications

01376

Glide Cablevision 01376, 01877,

01982

Globalcom 01376, 01877,

01982

Golden Belt Telephone 02586

Golden

Communications

01376, 01877,

01982

Golden Rain

Foundation

01376, 01877,

01982

Golden Valley Cable 01376, 01877,

01982

Golden West

Telecommunications

01376, 01877,

01982

Goldeld

Communications

01376, 01877,

01982

Gorham

Communications

01481

Gowrie Cablevision 01376, 01877,

01982

Grafton Cable

Communications

01376, 01877,

01982

Grand River Cable 01376, 01877,

01982

Grande

Communications

01877, 01376

Great Plains

Communications

01376

Green Hills

Communications

01376, 01877,

01982

Greene County Cable

TV

01376, 01877,

01982

Greenlight Community

Broadband

01376, 01877,

01982

Gridley Cable 01376, 01877,

01982

Griswold Cooperative

Telephone

01481, 01998,

03028

Grove Cable 01376, 01877,

01982

Grundy Center Utilities 01376, 01877

GTI 01481, 01998,

03028

Guadalupe Valley 01877

Haefele TV 01376, 01877,

01982

Haines Cable TV 01376, 01877,

01982

Hall Beach

Cooperative

01376, 01877,

01982

Hamilton County Cable

TV

01877, 01982,

01376

Hancel 01376, 01877,

01982

Hargray 01376, 01877,

01982

Harlan Community TV 01376

Harlan Municipal

Utilities

01376

Harmony Cable TV 01376, 01877,

01982

Harris Broadband 01376

Harrisonville

Telephone

02586

Harron Metrocast 01376, 01877

Hart Cable 01376, 01877,

01982

Hart Electric 01376, 01877,

01982

Hartelco 01376, 01877,

01982

Hastings Cable Vision 01376, 01877,

01982

Hathw@y 02043

Hawaiian Telcom 03028

HBC 01376, 01877,

01982

HBL Communications 01376, 01877,

01982

HCS 01376, 01877,

01982

Healthcare Cable

Systems

01376, 01877,

01982

Heart of Iowa

Communications

01376, 01877,

01982

Heartland Cable 01376, 01877,

01982

Heartland Wireless

Communications

01376, 01877,

01982

Heck's TV & Cable 01376, 01877,

01982

Henderson Telephone 01376, 01877,

01982

Hermosa Cablevision 01376, 01877,

01982

Herr Cable 01376, 01877,

01982

HFU Television 01376, 01877,

01982

Hiawatha Broadband 01376, 01877,

01982

HickoryTech 01898

High Plains

Cablevision

01376, 01877,

01982

Highland 01376, 01877,

01982

Hill Top

Communications

01376, 01877,

01982

Hinton CATV 01376, 01877,

01982

HLM Cable Corp 01376, 01877,

01982

HomeTel 01376

Hometown Cable 01376, 01877,

01982

Hometown Utilicom 01376, 01877,

01982

Hood Canal

Cablevision

01376

Hoonah Community

Television

01376, 01877,

01982

Reference Information

75

Hooper Telephone 01376, 01877,

01982

Horizon Cable TV 01376, 02586

Horizon Telecom 02586

Horry Telephone

Cooperative

01376, 01877,

01982

Hospers Telephone 01376, 01877,

01982

Hotwire 02586

Houston Cable 01376, 01877,

01982

Hrvatski Telekom 02132

HTC Communications 01481, 01998,

03028

HTC Services 01376, 01877,

01982

Humax 00660, 02620,

02043, 02165

HunTel Systems 01376

Huxley

Communications

01376, 01877,

01982

Hydaburg Cable TV 01376, 01877,

01982

HYDE County

Cablevision

01376, 01877,

01982

i-CAN 02437

I-Speed 01376, 01877,

01982

ICE Cable Holdings 01376

ICS Communications 01376, 01877,

01982

Illini Cablevision Of

Illinois

01376, 01877,

01982

ImOn Communications 01877

Indco Cable TV 01376, 01877,

01982

Independence Telecom

Utility

01376, 01982

Independent Cable

Systems of Idaho

01376, 01877,

01982

Indevideo 01376, 01877,

01982

Index Cable TV 01376, 01877,

01982

Innovative Cable TV 01376

Innovative Systems 01898

Inotel 02437

Inside Connect Cable 01376

Insight 01376, 01877

Integra Telecom 02345

Inter Mountain Cable 01877

Inter-County Cable 01376, 01877,

01982

Interstate Cablevision 01481, 01998,

03028

Intertech Private Cable 01376, 01877,

01982

InviTV 02437

Iron River Cooperative

TV

01376, 01877,

01982

Irvine Community TV 01376, 01877,

01982

ITV-3 01376, 01877,

01982, 03028

J & L Cable 01376, 01877,

01982

J & N Cable 01376, 01877,

01982

Jack McClanahan

Cable TV

01376, 01877,

01982

Jackson Energy

Authority

01376, 01877,

01982

Jaguar

Communications

01376, 01877,

01982

James Cable Partners 01376, 01877,

01982

James Valley

Cooperative Telephone

02586

Jayroc Cablevision 01376, 01877,

01982

Jefferson County

Cable

01376, 01877,

01982

Jefferson Telecom 01376, 01877,

01982

Jeffersonville Cable TV 01376, 01877,

01982

Jet Broadband 01376

Johnston County

Cable

01376, 01877,

01982

Journeyvision Cable 01376, 01877,

01982

JP PTT 01615

 Cable Set Top Box (K to N)

K-Communications 01376, 01877,

01982

Kabel Deutschland 02165

Kalida Telephone 01376, 01877,

01982

Kalona Cooperative

Telephone

02586

Kaplan Telephone 02586

Karban TV Systems 01376, 01877,

01982

KAS Cable TV 01376, 01877,

01982

Kaslo Cable 01376, 01877,

01982

KBS Cable TV 01376

Keene Valley Video 01376, 01877,

01982

Kelley

Communications

01376, 01877,

01982

Kennebec Telephone 01376, 01877,

01982

Kennedy Cablevision 01376, 01877,

01982

Kentucky

Ridge Country

Communications

01376, 01877,

01982

Keta Cable 01376, 01877,

01982

KFW Communications 01376, 01877,

01982

Kincardine Cable TV 01376

Kings Bay

Communications

01376, 01877,

01982

Kiss 02132

KLiP 01376, 01877,

01982

KM Telecom 01481

Knology 01877, 01376

KoolConnect 01481

Koomiut Cooperative 01376, 01877,

01982

KPN 02952, 02437

Kraus Electronic

Systems

01376, 01877,

01982

Kudzu Cable TV 01376, 01877,

01982

Kugluktuk Cooperative 01376, 01877,

01982

Kuhn Communications 01376, 01877

L & J Cable 01376, 01877,

01982

La Harpe

Communications

01376, 01877,

01982

La Harpe Video and

Data Services

01376, 01877

Lafayette Utilities

System

01376

Laguna Serrano Cable 01376, 01877,

01982

Lake Cable 01376, 01877,

01982

Lakeland Cablevision 01376, 01481,

01877, 01982,

01998

Lakeland Telecom 01481, 01998,

03028

Lakeview Cable 01376, 01877,

01982

Lamont Digital

Systems

01376, 01877,

01982

Lang 01376, 01877,

01982

Laurel Highland 01376, 01877,

01982, 02187

LB Cable 01376, 01877,

01982

Lehigh Valley

Cooperative Telephone

01376, 01877,

01982

Lemonweir Valley

Telephone

01481, 01998,

03028

Reference Information

76

Lexcom Cable

Services

01376, 01877,

01982

Liberty Cablevision 01376

Liberty

Communications

01481, 02586

Limestone Cablevision 01376, 01877,

01982

Lincoln Cable

Television

01376

Lincolnville 01376

Lindsey

Communications

01376, 01877,

01982

LISCO 01376, 01877,

01982

Litestream Holdings 01376, 01877,

01982

LNE Telco 01376, 01877,

01982

Localtel 01376, 01877,

01982

Lockesburg

Cablevision

01376, 01877

Lodgenet

Entertainment

01376, 01877,

01982

Lone Pine Cable TV 01376, 01877,

01982

Longview

Communications

01376, 01877,

01982

Lonsdale Video

Ventures

01481, 01998,

03028

Loretel Cablevision 01376, 01877,

01982

Loretel Systems 01376

Lost Island Cable TV 01376, 01877,

01982

Lumos Networks 01998, 03028

Lycom

Communications

01376, 01877,

01982

M-Tek Systems 01376, 01877,

01982

M.T.C. Cable 01376, 01877,

01982

Maddock Cable TV 01376, 01877,

01982

Madison

Communications

01376, 01982

Madison County Cable 01376, 01877,

01982

Magio Sat 02132

Magnet 01615

Mahaska

Communications

01376, 01877,

01982

Mainstreet

Communications

01376, 01877,

01982

Maitland Cable TV 01376, 01877,

01982

Mallard Cable 01376, 01877,

01982

Manawa Telecom 02586

Manning Municipal

Utilities

01376, 01877,

01982

Manti Telecom 01481, 01998,

03028

Marco Island Cable 01376, 01877,

01982

Markdale Cable TV 01376

Marne & Elk Horn

Telephone

01376, 01877,

01982

Marquette-Adams

Telephone

01376, 01877,

01982

Martelle

Communications

Cooperative

01376, 01877,

01982

Mascon Cable 01376

Masset-Haida TV

Society

01376, 01877,

01982

Massillon Cable 01376

Matanuska Telephone

Association

01481, 02586

Matrix Cablevision 01376, 01877,

01982

Mattawamkeag

Cablevision

01376, 01877,

01982

McDonough Telephone

Cooperative

01376, 01877,

01982

McKee TV Enterprises 01376, 01877,

01982

McNabb Cable 01376, 01877,

01982

MCV Broadband 01877

Media One 01376, 01877,

01982

Mediacom 01376, 01877,

01982

Mediapolis Telephone 01376, 01982

Mediastream 01376

Megacable 01376

Meo 02401

Merrimac

Communications

01376, 01877,

01982

Metlakatla Indian

Community TV

01376, 01877

MetroCast Cablevision 01376, 01982,

01877

MetroNet 01877, 0858

Metropolitan Cable 01376, 01877,

01982

MGS Cablevision 01376, 01877,

01982

MHTC 01481, 01998,

03028

Mi-Connection 01877

Microwave Satellite

Technologies

01481, 01998,

03028

Mid Century Telecom 01481, 01615

Mid Missouri

Broadband & Cable

01376, 01877,

01982

Mid Missouri

Telephone

01376, 01877,

01982

Mid-Coast Cablevision 01376, 01877,

01982

Mid-Hudson Cable 01376

Mid-Rivers

Communications

01376

Mid-South Cablevision 01376, 01877,

01982

Midamerican Cable

Systems

01376, 01877,

01982

Midcontinent

Communications

01376, 01877,

01982

Midstate

Communications

01376, 01877,

01982

Midtel Cable TV 01376, 01877,

01982

Milcom Cable 01376, 01877,

01982

Milford Cable TV 01376, 01877,

01982

Milk River Cable Club 01376, 01877,

01982

Millennium Telecom 01481, 01998,

03028

Millheim TV

Transmission

01376, 01877,

01982

Millington CATV 01376, 01877,

01982

Minburn

Communications

01481, 01998,

03028

Minerva Valley Cable 01376, 01877,

01982

MINET 01877

MLGC Cable TV 01376, 01877,

01982

MM&G Enterprises 01481, 01998,

03028

MMDS Wireless East 01376, 01877,

01982

Mobius

Communications

01376, 01877,

01982

Monroe Cablevision 01376, 01877,

01982

Monroe Utilities 01376, 01877,

01982

Montana Opticom 01376, 01877,

01982

Moosehead

Enterprises

01376, 01877,

01982

Morris Broadband 01376

Morristown Utility

Systems

01877

Mosaic Telecom 01376, 02586

Reference Information

77

Motorola 01376, 02437,

02378, 01998,

00858, 02952,

01562, 01982,

02401

Moultrie

Telecommunications

01376, 01877,

01982

Mountain Shadows

Cable TV

01376, 01877,

01982

Mountain

Telecommunications

01376, 01877,

01982

Mountain Zone TV 01376, 01877,

01982

Movistar 03288

Moxi 02187

Mt. Baker Cable 01376, 01877,

01982

MTC 01376, 01877,

01982

MTC Technologies 01376, 01982

MTS 01998

Multiband Cable 01376, 01877,

01982

Municipality Cable

Operator

01376, 01877,

01982

Murphy Cable 01376, 01877

Murray Electric System 01376, 01877,

01982

Muscatine Power &

Water

01376

N.W. Communications 01376, 01877,

01982

National Cable 01376, 01877,

01982

Naujat Cooperative 01376, 01877,

01982

NDTC 01481, 01998,

03028

Nebraska Central

Telecom

01376, 01877,

01982

NEIT 01376, 01877,

01982

Nelson County

Cablevision

01376, 01877,

01982

Nelsonville TV Cable 01376, 01877,

01982

Nemont

Communications

01376, 01877

NET 01883

New Century

Communication

01376, 01877,

01982

New Day Broadband 01376, 01877,

01982

New England Cable 01376, 01877,

01982

New Jersey

Broadband

01376, 01877,

01982

New Knoxville Cable

Systems

01376, 01877,

01982

New North Networks 01376, 01877,

01982

New Paris Quality

Cablevision

01376, 01877,

01982

New Visions

Communications

01376, 01877,

01982

New Windsor Cable TV 01376, 01877,

01982

Newcastle Cablevision 01376, 01877,

01982

Newpath

Communications

01877, 01982

NewWave

Communications

01376, 02187

NexHorizon

Communications

01376, 01877,

01982

Nexicom

Communications

01376, 01877,

01982

Nextgen

Communications

01376, 01877

Niagara Community

TV Cooperative

01376, 01877,

01982

Nimpkish Valley

Communcations

01376, 01877,

01982

Nittany Media 01376

Nor-Cal Cable

Systems

01376, 01877,

01982

Nortex

Communications

01376, 01877,

01982

North American

Communications

01376, 01877,

01982

North Central

Telephone

02345

North Crossroads

Communications

01376, 01877,

01982

North Dakota

Telephone

02586

North Star Cablevision 01376, 01877,

01982

North State

Communications

00858

North Texas

Broadband

01376, 01877,

01982

North Yellowstone

Cable TV

01376, 01877,

01982

Northern Cable

Holdings

01376, 01877,

01982

Northern Lakes Cable

TV

01376, 01877,

01982

Northland

Communications

01376

Northside TV 01376, 01877,

01982

Northstar Broadband 01376, 01982

Northwest

Communications

01376, 01877,

01982

Northwest Community 01877

Northwest Iowa

Telephone

01877

Northwest Telephone

Cooperative

01376, 01877,

01982

NorthwesTel 01376

Norvado 02586

Norwood Light

Broadband

01376

Nova Cable

Management

01376, 01877,

01982

Nova Cablevision 01376, 01877,

01982

Novus 01376, 01877

NPG Cable 01376

Nsight 02345, 02586

NTC Cable Services 01376, 01877,

01982

nTelos 01998

NTL 01060

NTS Communications 01376, 01877,

01982

NU Telecom 01998, 03028

NuLink 01877, 01376,

01982

Numericable 02436

Nushagak Cooperative 01376, 01877,

01982

 Cable Set Top Box (O to S)

Oak Cable Systems

Of Iowa

01376, 01877,

01982

Oak Hill Cablevision 01376, 01877,

01982

Oasis Communications 01376, 01877,

01982

Oi TV 03452, 03454

Omni III Cable TV 01376, 01877,

01982

Oneida Cablevision 01376, 01877,

01982

OneLink 01376, 01877,

01982

OneSource

Communications

01376

Ono 01562

Open IPTV 01615

Opp Cablevision 01376, 01877,

01982

Optimum 01877

Optimus Clix 02437

Optus 01060

Orange 02407

Orbitel

Communications

01376

Oregon Cable Group 01376, 01877,

01982

Orion Cablesystems 01376, 01877,

01982

Reference Information

78

OTEC

Communications

02586

Our Cable 01376, 01877,

01982

Overton County Cable 01376, 01877,

01982

Oxford Networks 01376, 01877,

01982

Pace 01877, 01060,

02620, 01982,

01582, 01376,

01883, 02401,

03454

Packerland Broadband 01376

Paleajook Cooperative 01376, 01877,

01982

Palmer Mutual

Telephone

01376, 01877,

01982

Palmetto Rural

Telephone Cooperative

00858

Panasonic 01982

Pangnirtung

Cooperative

01376, 01877,

01982

Panhandle Telephone 01376

Panora

Telecommunications

01481

Paragould Light &

Water

01376, 01877,

01982

Parish

Communications

01376, 01877,

01982

Park Region Mutual

Telephone

01481, 01998,

02345, 03028

Park TV & Electronics 01376, 01877,

01982

Partner

Communications

01376, 01877,

01982

Pathway Com-Tel 01376, 01877,

01982

Patterson Cable TV 01376, 01877,

01982

Paul Bunyan

Communications

02586

PBT Cable Services 01376, 01877,

01982

PC One Cable 01376, 01877,

01982

PDQ Cable TV 01376, 01877,

01982

PEC Cablevision 01376, 01877,

01982

Pegasus

Communications

01376, 01877,

01982

Peoples CATV 01376, 01877,

01982

Persona

Communications

01376, 01877,

01982

Philippi

Communications

01376, 01877,

01982

Philips 01582, 02294

Phoenix 01376

Phoenix Cable 01376, 01877,

01982

Phonoscope

Communications

01376, 01877,

01982

Pickwick Cablevision 01376, 01877,

01982

Piedmont Cable

Services

01376, 01877,

01982

Pine Bluff Cable 01376

Pine Island Telephone 01481, 01998,

03028

Pine River Cable 01376, 01877,

01982

Pine Tree Cablevision 01376, 01877,

01982

Pineland Telephone

Cooperative

01481, 01615,

01898, 02586

Pinpoint

Communications

01376, 01877,

01982

Pioneer 01877

Pioneer Cable 01376, 01877,

01982

Pioneer

Communications

01376, 01877,

01982

Pioneer Long Distance 01898, 01615

Pitcairn Community

Cable TV

01376, 01877,

01982

Plantation Cable

System

01376, 01877,

01982

Pleasant Vision 01376, 01877,

01982

Polar Communications 02586

Polaris Cable 01376, 01877,

01982

Ponderosa Cablevision 01376, 01877,

01982

Poplar Bluff Municipal

Utilities

01481, 01998,

03028

Portal Cablevision 01376, 01877,

01982

Portugal Telecom 02401

Post Cablevision 01376, 01877,

01982

Premier

Communications

01376

Premiere 02620

Price County

Telephone

01481, 01998,

03028

Prime Cable

Corporation

01376, 01877,

01982

Prime Time Cable 01376, 01877,

01982

Princetown Cable 01376, 01877,

01982

Private Cable Systems 01376, 01877,

01982

Private Network Cable

Systems

01376, 01877,

01982

Project Mutual

Telephone

01481, 01998,

03028

Project Services 01376, 01877,

01982

PSC 01481, 01998,

03028

PTCI 01376

PVT Networks 01376, 01877,

01982

Quality Cable TV 01376, 01877,

01982

Quality One

Technologies

01481, 01998,

03028

Quinter Cable 01376, 01877,

01982

Qwerty.TV 01898

R & R Cable 01376

Raftview

Communications

01376, 01877,

01982

Rainbow Cable 01376, 01877,

01982

Rainbow

Communications

01376, 01877,

01982

Rainbow Lake Cable

TV

01376, 01877,

01982

Rainier Connect 01376, 01877,

01982

Ramapo Cable 01376, 01877,

01982

Rancho Murieta

Association

01376

Randolph Telephone 02586

Rapid Communications 01376, 01877,

01982

RC Communications 01376, 01877,

01982

RCN 01376

Reach Broadband 01376, 01877,

01982

Readlyn Telephone 02586

Rebeltec

Communications

01376, 01877,

01982

Red River Cable 01376, 01877,

01982

Reds Cable TV 01376, 01877,

01982

Regional Cable TV 01376, 01877,

01982

Reinbeck

Telecommunications

01376, 01877,

01982

Reservation Telephone 01376, 01998,

02345

Reserve Long

Distance

01376, 01877,

01982

Resnet

Communications

01376, 01877,

01982

Resort Cable 01376

Reference Information

79

Reveille Broadband 01376, 01877,

01982

Reynolds Cable 01376, 01877,

01982

RGA Cablle 01376, 01877,

01982

Ridgewood

Cablevision

01376, 01877,

01982

Ringgold Telephone 01376, 01877,

01982

Rio Virgin Telephone 01376, 01877,

01982

Riondel Community

Cable Society

01376, 01877,

01982

Ripley Video Cable 01376, 01877,

01982

Ritter Cable 01376, 01877,

01982

River Road Cable 01376, 01877,

01982

River Valley Cable TV 01376, 01877,

01982

River Valley

Telecommunications

01481, 01998,

03028

Riverside Cablevision 01376, 01877,

01982

Riviera Cable TV 01376, 01877,

01982

Robins Cable TV 01376, 01877,

01982

Rock Port Cablevision 01376, 01877,

01982

Rocky Mountain Cable

Systems

01376, 01877,

01982

Rogers 01877, 01376

Roome

Telecommunications

01376, 01877,

01982

Royal Telephone 01376, 01877,

01982

RTC 01376, 01877,

01982

RTEC

Communications

01376, 01877,

01982

Runestone Telcom 01376, 01877,

01982

Rural Route Video 01376, 01877,

01982

Rural Telephone

Company

01376

RuralWest 01376, 01877,

01982

Russellville Electric

Plant Board

02586

S & K TV Systems 01376, 01877,

01982

S & T Communications 01376, 01877,

01982

S-GO Video 01877, 01982

S.Bryer Cable TV 01376, 01877,

01982

Sagem 02407, 02436,

03288

Sagemcom 02407, 02436,

03007

Sallisaw Municipal

Authority

01376, 01877,

01982

Samsung 02407, 02015,

01877, 03477,

01060, 01987,

02589, 03265

San Bruno Municipal

Cable TV

01376, 01877,

01982

San Carlos

Cablevision

01376, 01877,

01982

San Juan Cable 01376, 01877,

01982

San Simeon

Community Cable

01376, 01877,

01982

Santel Comm

Cooperative

01376, 01877,

01982

Sasktel 01998

Satellite Cable

Services

01376, 01877,

01982

Satview Broadband 01376, 01877,

01982

Saugeen Telecable 01376, 01877,

01982

Savage

Communications

01376, 01877,

01982

Sayward Valley

Communications

01376, 01877,

01982

Schindler Cable TV 01376, 01877,

01982

SCI Cable 01376, 01877,

01982

ScienticAtlanta 01877, 01982,

00858, 01987,

02401, 02436,

02345, 03028

Scio Cablevision 01376, 01877,

01982

Scott Telecom And

Electronics

01376, 01877,

01982

Scottsboro Cable TV 01376, 01877,

01982

Sea Island 01877

Seaside Cable TV 01376, 01877,

01982

Seaview

Communications

01376, 01877,

01982

SecureVision 01376, 01877,

01982

Semo Communications 01376, 01877,

01982

Senior TV 01376, 01877,

01982

Service Electric 01376, 01877,

01982

Service One Cable 01376, 01877,

01982

Shannon Vision 01376, 01877,

01982

Shaw 01376, 01877,

02187

Shawano Municipal

Utilities

01376, 01877,

01982

Shellsburg Cablevision 01376, 01877,

01982

Shen-Heights TV 01376, 01877,

01982

Shenandoah Cable 01376, 01877,

01982

Shenandoah

Telecommunications

01376, 01877,

01982

Shentel 01376, 01877,

01982

Sherburne Cable 01376, 01877,

01982

Sherman Cablevision 01376, 01877,

01982

Shrewsbury Electric &

Cable

01376, 01877

Silver Star

Communications

01481, 01998,

03028

Simpson Country

Cable TV

01376, 01877,

01982

SingTel 01998

Siskiyou Cablevision 01376, 01877,

01982

Sister Lakes Cable 01376, 01877,

01982

Sjoberg's Cable TV 01376

Skisat 01376, 01877,

01982

SKT 01376, 01877,

01982

SKY 02620

Sky Angel 01376, 01877,

01982

Sky Cablevision 01376, 01877,

01982

SKY Deutschland 02620

Skyline Cable 02586

SkyPix 01481, 01998,

03028

Sleepy Eye Telephone 02345

Small Town Cable 01376, 01877,

01982

Smile Content 02437

Smithville 02586

Sogetel 01998

SomereldCableTV 01376, 01877,

01982

Source Cable 01376

Reference Information

80

South Benton

Cablevision

01376, 01877,

01982

South Central

Communications

01376, 01877,

01982

South Holt Cablevision 01376, 01877,

01982

South Slope

Communications

01376, 01877,

01982

Southeast Cable TV 01376, 01877,

01982

Southern Cayuga

County Cable

01376, 01877,

01982

Southern Coastal

Cable

01376, 01877,

01982

Southern Kansas

Telephone

01376

Southern Plains Cable 01376, 01877,

01982

Southern Vermont

Cable

01376, 01982

Southey Cable 01376, 01877,

01982

Southside TV 01376, 01877,

01982

Southwest MN

Broadband

01376, 01877,

01982

Southwestern Bell

Video Services

01376, 01877,

01982

Spanish Fork 01376, 01877,

01982

Spencer Municipal

Utilities

01376, 01877,

01982

Spillway Cablevision 01376, 01877,

01982

Spirit Broadband 01376, 01877,

01982

Spring Creek Cable 01376, 01877,

01982

Springcom 01376, 01877,

01982

SpringeldCablevision 01376, 01877,

01982

Springville Cable 01376, 01877,

01982

St. George Island

Cable

01376, 01877,

01982

St. John Cable 01376, 01877,

01982

Stanley Cablevision 01376, 01877,

01982

Stanton Telecom 01376, 01877,

01982

Star Cablevision 01376, 01877,

01982

Starkville Cablevision 01376, 01877,

01982

Starlight

Communications

01376, 01877,

01982

Starview Cable of

Delaware

01376, 01877,

01982

Starvision 01376, 01877,

01982

Starwest 01376, 01877,

01982

Stellar

Communications

01376, 01877,

01982

Stellar Private Cable

Systems

01376, 01877,

01982

Stofa 02015

Stowe Cablevision 01376, 01877,

01982

Strategic Technologies 01376, 01877,

01982

Stubbs

Communications

01376, 01877,

01982

Suddenlink 01877, 01376

Summit Broadband 01376, 01877,

01982

Summit

Communications

01376, 01877,

01982

Sumner Cable TV 01376, 01877,

01982

Sun Country Cable 01376

Sunrise

Communications

01376, 01877,

01982

Supercanal 01376

Superior Cable & Data 01376, 01877,

01982

Supervision Cable TV 01376, 01877,

01982

SureWest 01481, 01998,

02586

Surry Telephone 02586

SWAT Cooperative 01481, 01998,

03028

Sweetwater Cable TV 01376, 01877,

01982

Swisher Telephone 02345

 Cable Set Top Box (T to Z)

T-Home 02132

TA Communications 01376, 01877,

01982

Taloga Cable 01376, 01877,

01982

TAT Cablevision 01376, 01877,

01982

Tbaytel 03028

TCSI Huntsville 01376, 01877,

01982

TCT 01376, 01877,

01982

TDS 01376, 01877,

01982

TDS Telecom 03028

Technicolor 01982

Tekstar Cablevision 01376, 01877,

01982

Tel-Star Cablevision 01376, 01877,

01982

Tele-Media 01376, 01877,

01982

Tele-Services 01376, 01877,

01982

Tele2 00660

Telecentro 01376

Telecom Cable 01376, 01877,

01982

Teledistribution Amos 01376

Telefonica 03288, 03028

Telenet 01920, 03477

Telepak Networks 01376, 01877,

01982

TelePartners 01376, 01877,

01982

Telerent Leasing

Corporation

01376, 01877,

01982

Telestar Systems 01376, 01877,

01982

Telewest 01987

Telmex 01376

Telsat Systems 01376, 01877,

01982

Telus 03028

Templeton Telephone 01376, 01877,

01982

TeNeT 01898

Tesco Cable TV 01376, 01877,

01982

Texas Mid-Gulf

Cablevision

01376

Thames Valley

Communications

01376, 01877,

01982

The Community

Agency

01376

The Town of Mountain

Village Cable

01376, 01877,

01982

Thomson 01582, 01982,

03007, 02407

Three River Digital

Cable

01376, 01877,

01982

Throckmorton

Cablevision

01376, 01877,

01982

TiftNet 01376, 01877,

01982

Time Warner 01877, 01376,

02187

Tip-Top

Communications

01376, 01877,

01982

TiVo 03265

Tobacco Valley

Communications

01376, 01877,

01982

Tongue River Cable TV 01376, 01877,

01982

Total Cable Service 01376

Reference Information

81

Touchet Valley

Television

01376, 01877,

01982

TP 02407

Trans-Video 01376, 01877,

01982

Trappers Loop

Communications

01376, 01877,

01982

Trenton Cable 01376, 01877,

01982

Tri-County Cable TV 01376

TrioTel

Communications

01376, 01877,

01982

Troy Cablevision 01376

Trust Cable TV 01376, 01877,

01982

TruVista 01376, 01877,

01982

Tudjaat Cooperative 01376, 01877,

01982

Tulalip Broadband 01376, 01877,

01982

Tullahoma Utilities 02586

Tulugak Cooperative 01376, 01877,

01982

Turquoise Turtle TV 01376, 01877,

01982

TV Cable 01376

TV Cable Company of

Andalusia

01376

TV Cable of Winamac 01376, 01877,

01982

TV Northeast 01481, 01998,

03028

TV Service 01376, 01877,

01982

TVB 01615

TVC 01376, 01877,

01982

TVision 01376, 01877,

01982

TVMAX 01376, 01877,

01982

TVS Cable 01376, 01877,

01982

Twin Valley

Communications

02586

Two Creeks Cable 01376, 01877,

01982

Ucluelet Video 01376, 01877,

01982

Uintah Basin

Electronic Telecom

01376, 01877,

01982

UMBC 01376, 01877,

01982

Union Telephone 01376, 01877,

01982

Unitah-Strata

Networks

01376

United

Communications

Association

01376

United States Gypsum 01376, 01877,

01982

United Telephone 01376, 02586

Unitymedia 03477

Universal Cablevision 01376, 01877,

01982

Universal Satellite

Cable

01376, 01877,

01982

UPC 01582, 03477,

00660, 01060

UPC Cablecom 01582, 03477

Upper Peninsula

Communications

01376, 01877,

01982

US Online 01376, 01877,

01982

US Sonet 01376, 01877,

01982

USA Cablesystems 01376, 01877,

01982

USA Companies 01376, 01877,

01982

Utica Cablevision 01376, 01877,

01982

Utilities Board City of

Foley

01376

Utility Systems

Development

01376, 01877,

01982

Uwharrie

Communications

02586

Valley Cable & Satellite

Communications

01376, 01877,

01982

Valley Cable TV 01376, 01877,

01982

Valparaiso

Communications

01376

Venture

Communications

Cooperative

01481, 01998,

03028

Venus Telephone

Cooperative

01376, 01898

Veracity

Communications

01376, 01877,

01982

Verizon 02378

Vernon Telephone

Cooperative

02586

Vicksburg Video 01376

Videotron 01877

Vidia Communications 01376, 01877,

01982

Vidion Cable 01376, 01877,

01982

Viken Fibernett 02437

Viola Communications 01376, 01877,

01982

Virgin Media 01987, 01060,

03265

Vision

Communications

01376

VisionComm 01376, 01877,

01982

Vital Communications 01376, 01877,

01982

Vivo 03288

Vodafone 02401

Vogtmann Engineering 01376, 01877,

01982

Volcano Vision 01376

W.D.B.

Communications

01376, 01877,

01982

Wabash Independent

Networks

01376, 01877,

01982

Wadsworth Cable TV 01376

WaitseldCable 01376

Walnut

Communications

01376, 01982

Walnut Grove Cable

TV

01376, 01877,

01982

Ward Communications 01376, 01877,

01982

Warwick Valley

Telephone

01376, 01877,

01982

Washington County

Rural Telephone

Cooperative

01376, 01877,

01982

Watch TV 01481, 01998,

03028

Waterville Cable TV 01376, 01877,

01982

Watson Cable 01376, 01877,

01982

Wave Broadband 01376

Wavevision 01376, 01877,

01982

WCTA 01376, 01877,

01982

WEHCO Video 01376

Weiss Lake Cable 01376, 01877

West Alabama TV

Cable

01376, 01877,

01982

West Carolina

Telephone

03028

West Central

Telephone

01376, 01877,

01982

West Lake Cablevision 01376, 01877,

01982

West River Cable

Television

01376, 01877,

01982

WesTel Systems 01376, 01877,

01982

Western Broadband 01376, 01877,

01982

Western Cable Service 01376, 01877,

01982

Western Iowa

Telephone

01877

Reference Information

82

Western Telephone

Company

01376, 01877,

01982

Western Wisconsin

Communications

01376, 02586

Westman

Communications

01376, 02187

Westphalia Broadband 02586

Wetherell Satellite

Cable TV

01376, 01877,

01982

WFL Cable Television 01376, 01877,

01982

White County Video 01376

WideOpenWest 01376, 01877,

02187

Wikstrom Systems 01376, 01877,

01982

Wilco Electronic

Systems

01376, 01877,

01982

Wilkes

Telecommunications

01481, 01998,

03028

Willamette Broadband 01376

Windbreak Cable TV 01376, 01877,

01982

Windjammer Cable 01376, 01877

Windom

Communications

01877

Windstream 01376, 01982

Winslow

Communications

01376, 01877,

01982

Wire Tele-View 01376, 01877,

01982

Wireless One 01376, 01877,

01982

Wittenberg Telephone 01376, 01877,

01982

Wood County

Telephone

01376, 01877,

01982

WoodseldMunicipal

Cable

01376, 01877,

01982

Worth Cable TV 01376, 01877,

01982

WT Services 01376, 01877,

01982

WTC Communications 01376, 01877,

01982

WTCI Cable 01376, 01877,

01982

Wyandotte Municipal 01376, 01982

Yadkin Valley Telecom 02345

Ycom Networks 01376, 01877,

01982

Yelcot Video Group 01376, 01877,

01982

Yelo 01376

Ygnition 01376, 01877,

01982

Zampelli Electronics 01376, 01877,

01982

Ziggo 02589, 02015,

00660, 02401

Zito Media 01376, 01982

Zoom Media 01376, 01877,

01982

 Satellite Set top Box

@sat 01300

Acoustic Solutions 01284

ADB 00887

AEG 02738, 02813

Agora 01284

Airis 02813

Airtel 02248

Akira 02738

Alba 01284, 02034

Altech UEC 02059

Amstrad 00847, 01662,

01175, 01693,

02467

AMTC 02738, 02813

Arledge Electronics 00775

Arnion 01300

ASDA 01284

AssCom 00853

Astro 01100, 02026

Aurora 00879

Austar 00879

Auvisio 02738, 02813

Avanit 01631

Axil 02738

Ballard Rural

Telephone Cooperative

00775

Bell 00775

Bell Satellite TV 00775

Biostek 02738

Black Diamond 01284

Boca 02026, 02813

Boshmann 01631

Boxer 02443, 01692

BskyB 01175, 00847,

01662

Bulltech 02738

Bush 02376, 01284,

02034, 02813

Cablecom 01195, 01197

Caiway 02443, 00253

Canal Digitaal 00853, 02957

Canal Digital 00853

Canal+ 00853, 02657,

01195, 01197

CanalSat 00853, 02657

Century 00856

CGV 02034

Chess 02026

Cignal 02835

City of Cawker City

Cable

00775

CityCom 01176

Claro 03787, 03790

Clatronic 02738

Com Hem 01176, 01915

Comag 02026, 02813

Coship 03787, 03790

Country Vision Cable 00775, 00869

Croner 02813

Crown 01284

Cyfra+ 00853, 01409

Cyfrowy Polsat 00253, 0853,

01409

D-box 01114

DASAN 03321

Delta 02443

Denver 02738

Deutsche Telekabel 01195, 01197

Dgtec 01631

Dicra 02738

Digi 02026

Digiality 02813

Digihome 01284, 02034

DigiLogic 01284, 02034

DigiQuest 01300, 02738,

01631

DigitAlb 01195, 01197

DigitalBox 01631, 01100

Digiwave 01631

DirecTV 01377, 00099

Dish Network 00775

Dishpro 00775

DishTV 01300

DMT 03321

DMTech 02738

DRE 01176

Dream Multimedia 01237, 01652,

01923

DSE 02813

DSTV 00879

DTK Deutsche

Telekabel

01195, 01197

Dual 02034

Durabrand 01284, 02034

Dyon 02738, 02813

Echostar 00775, 00853,

01409

Edision 01631

Elta 02738

Energy Sistem 01631, 02813

Etisalat 02443

Evesham Technology 02034

Reference Information

83

Finlux 02034

FinnSat 01195, 01197

Fortec Star 01631

Foxtel 01356, 00879,

01176

Freesat 01692, 02376

Freesat+ 02443

Frontier

Communications

00775

Fuji Onkyo 01631

Galaxis 00853, 00879

General Instrument 00869

General Satellite 01176

Globo 02026, 02957

GoGen 02738

GOI 00775

Gold Box 00853

Gold Vision 01631

Goodmans 01284, 02376,

02034

Gradiente 00887, 00856,

00099

Grocos 01409

Grundig 00847, 02376,

02034, 01284,

00853, 00879

Hanseatic 01100

HD+ 02443

HDT 03321

Hirschmann 02026

Hitachi 02034, 01284

Hornet 01300

HTS 00775

Huawei 03787

Hughes Network

Systems

01377

Humax 01176, 02443,

01808, 01915,

02408, 01377,

03321, 01989,

02616

ibox 01652

ID Digital 01176

Illusion 01631

Imagin 01195, 01197

Imperial 01195, 01197

Indovision 01989, 00856,

00887

iNETBOX 01652, 01237

Innova 00099

IQ 02813

ISkyB 00887

JVC 00775, 01284

Kabel Deutschland 01195, 01197

KabelBW 01195, 01197,

01915

KabelNoord 00253, 02443

Kaon 01300

Kenwood 00853

Koenig 01631

KT 03321

Lava 01631

LG 03321

Linsar 01284

Lodos 01284

Logik 01284, 02034

LogiSat 02026, 02813

Luxor 02034

Macab 00853

Majestic 02738

Manhattan 01300

Maplin 02034

Marusys 03543

Mascom 02738

Matsui 01284

Maximum 02813

Mediabox 00853

MediaSat 00853

Mediascape 02835

Medion 02026

Mega TV 03321

MegaSat 02034, 02813,

01631, 02738

Metronic 02738, 01631

Micro 02813

Micro electronic 02813

Milestone

Communications

00775

Mitsai 02738

Morgan's 02026

Motorola 00869, 00856,

03469

Movistar 01409

Multichoice 00879, 02059,

02060

Murphy 02034

Mysat 02738

NET 01409

Netsat 00099, 00887

Next Level 00869

Nokia 00853

NPG 01631

NTV Plus 01692, 02443

Olleh TV 03321

Olleh-Skylife 03321

Onn 02034, 01284

Opticum 02957

Optus 00879, 01356

Orbitech 01100, 01195,

01197

Orton 02957

Pace 00847, 01356,

00887, 01175,

01693, 00853,

01662, 02467,

02657, 03469,

01377, 02059,

02060, 02211,

03787, 03790,

02620

Pacic 01284

Palcom 01409

Palsonic 02813

Panasat 00879

Panasonic 00847

Philips 00099, 00853,

01114, 02619,

00856, 00887,

02211, 03469

Pioneer 00853

PLDT 02835

Premiere 01114, 01195,

01197

Primacom 01176, 01195,

01197

Pro Basic 00853

Proline 01284

Qook TV 03321

Qook-SkyLife 03321

Qwest 01377

RadioShack 00869

Raduga TV 02957

RiksTV 01692

Roadstar 00853

SAB 01300, 01631

Sagem 01692, 01114

Sagemcom 01692

Samsung 03063, 00253,

01377, 01989,

02467, 00853,

03321, 01662,

01693, 03834

Sat Control 01300

SAT+ 01409

Satellite Operations 00775

Satplus 01100

SatyCon 01631

Schaub Lorenz 02034

Schwaiger 01631, 02813,

02957

Schwaiger CS 01631

Scott 02738

SEG 01284, 02034

Shark 01631

Sharp 02034

Shaw Direct 00869

Sherwood 01409

Reference Information

84

Shinelco 02738

Sigmatek 02738, 02813

SilverCrest 02026

SKY 00856, 00847,

01662, 00887,

01175, 02619,

01693, 00099,

01114, 01377,

01915, 02467,

03469

Sky Brasil 00856, 00887,

01377, 02619

SKY Deutschland 02443, 01114,

01915, 02620

SKY Italia 01693, 02467,

00853, 01356

SKY Mexico 00856, 02619,

00887, 01377,

03469

SKY New Zealand 02211

SKY PerfecTV! 02616

SkyCable 01631

SkyLife 03321

Skylink 02443, 02957

Skymaster 01409

Skyplus 02026, 01175

SkySat 01100

Skyworth 01631, 02835

SL 02026

SM Electronic 01409

Smart 01631

Sony 00847, 00853

Star 00887

Star Choice 00869

Stream System 01300

Strong 01409, 00879,

02813, 01300,

00853, 01284

Sunny 01300

Sunstech 02738

Supernova 00887

T-Mobile 02443

TATA S k y 03575

TDS Telecom 00775

Teac 02813

Technicolor 03469

Technika 01284, 02034

TechniSat 01195, 01197,

01100, 02813

Techwood 01284, 02034

tekComm 02738

TELE System 01409, 02738,

02813

Tele2 01195, 01197

Telefonica 01692, 01409

Telestar 01100, 01197,

01195

Televes 01300

Teleview

Communications

00775

Televisa 00887

Telsey 02738

Telstra 01356

Telus 00775

Tevion 01409, 02026,

02813

Thomson 00847, 01175,

00853, 01662,

02619, 03469

TNT SAT 01692, 01195,

01197

Toshiba 01284

TrekStor 02738

Triangle

Communication

System

00775

Triax 00853, 01631

Tricolor TV 01176

True Visions 02408

TV Vlaanderen 00853

TVA Digital 01692, 01409

TVB 01989

UEC 00879, 01356

United Satellite

America

00775

United States Wireless 00775

Unitymedia 01915

Unixbox 01652

USA Wireless Satellite

TV

00775

Vectra 01195, 01197

Vestel 01284, 02034

Via Embratel 03787

Viasat 01197, 0253,

01195

VisionNet 01631

Viva 00856

Vivo 01409

Voom 00869

VTC 03834

Vu+ 03543

Walker 02034, 01284

Wharfedale 02034

Windstream 00775

Wisi 02957

World Satellite Cable

Systems

00775

Woxter 02813, 02738

Xoro 02813

Xtreme 01300

Ye s 00887, 01631

Zehnder 02034, 03469

Zenith 00856, 00253

Ziggo 02443

Zircon 02957

 Video - Accessory

A.C.Ryan 02709, 03350

ABS 01272

Acer 01272

Alienware 01272

Apple 02615

Boxee 03693

Claritas 01272

CyberPower 01272

D-Link 03693

Daily Media 01272

Dell 01272

Digitech 02260

Elonex 01272

Eminent 02260

Emtec 02709

Fantec 02709

Fujitsu Siemens 01272

Gateway 01272

Hewlett Packard 01272

hFX 01272

Howard Computers 01272

Hush 01272

iBUYPOWER 01272

iconBIT 02709, 03350

ISTAR 02260

Linksys 01272

Mede8er 02709

Media Center PC 01272

Microsoft 01272, 01805

Mind 01272

NiveusMedia 01272

Northgate 01272

Packard Bell 01272

Philips 01272

PopBox 02260

Popcorn Hour 02260

Ricavision 01272

Roku 03061

Sony 02713, 01272

Stack 9 01272

Systemax 01272

Tagar Systems 01272

Toshiba 01272

Touch 01272

Trust 01272

VIA Technologies 01272

Viewsonic 01272

Voodoo 01272

Reference Information

85

Western Digital 02558

Woxter 02709

Xbox 01805, 01272

ZT Group 01272

 CD

Advantage 70032

AH! 70157

Aiwa 70157

Arcam 70157

Atoll Electronique 70157

Audio Research 70157

Audiolab 70157

Audiomeca 70157

Audioton 70157

AVI 70157

Balanced Audio

Technology

70157

Cairn 70157

California Audio Labs 70029, 70303

Cambridge 70157

Cambridge Audio 70157

Carver 70157

CCE 70157

Cyrus 70157

Denon 70766

DKK 70000

DMX Electronics 70157

Dynaco 70157

Genexxa 70032, 70000

Goldmund 70157

Grundig 70157

Harman/Kardon 70157

Hitachi 70032

Integra 71817

JVC 70072

Kenwood 70157, 70036

Krell 70157

Linn 70157

Loewe 70157

Magnavox 70157

Marantz 70157, 70029

Matsui 70157

MCS 70029

Memorex 70032

Meridian 70157

Micromega 70157

Miro 70000

Mission 70157

Myryad 70157

NAD 70721, 70000

Naim 70157

NSM 70157

Onkyo 71817

Optimus 70032, 70000

Panasonic 70303, 70029

Philips 70157

Pioneer 70032

Polk Audio 70157

Primare 70157

Proton 70157

QED 70157

Quad 70157

Quasar 70029

Radiola 70157

RCA 70032

Restek 70157

Revox 70157

Rotel 70157

SAE 70157

Sansui 70157

SAST 70157

Siemens 70157

Silsonic 70036

Simaudio 70157

Sonic Frontiers 70157

Sony 70000, 70490

Sylvania 70157

TAG McLaren 70157

Tandy 70032

Tascam 73095, 73511,

73533

Teac 73531, 73532,

73551

Technics 70303, 70029

Thorens 70157

Thule Audio 70157

Universum 70157

Victor 70072

Wards 70032, 70000,

70157

Yamaha 70036, 70032,

70490

Zonda 70157

 Cassette Deck

Aiwa 40029

Arcam 40076

Audiolab 40029, 40229

Carver 40029

Denon 40076

Grundig 40029

Harman/Kardon 40029

Inkel 40070

JVC 40244

Kenwood 40070

Magnavox 40029

Marantz 40029

Myryad 40029

Onkyo 42157

Optimus 40027

Panasonic 40229

Philips 40029, 40229

Pioneer 40027

Polk Audio 40029

Radiola 40029

RCA 40027

Revox 40029

Sansui 40029

Sony 40243, 40170

Tascam 73095

Technics 40229

Thorens 40029

Victor 40244

Wards 40027, 40029

Yamaha 40097

 Audio - Accessory

Apple 81115

Jamo 82228

Onkyo 81993, 82351,

82990

Polk Audio 82228

 Receiver

Integra 52503

Onkyo 52503

 Cable PVR Combination

Access

Communications

01376, 01877

Adams Cable TV 01376

ADB 01920

Armstrong 01376, 01877

Arris 02187

Atlantic Broadband 01877

ATMC 01376

Bend Broadband 02187

Blue Ridge

Communications

01877

Bright House 01877, 01376

Buckeye Cable System 01376, 01877,

02187

Cable Axion Digitel 01376

Cable One 01376, 01877

Cablecom 01582

Cablevision 01877, 01376

Cablevision du Nord 01376

CCAP 01877

Charter 01376, 01877,

02187

Reference Information

86

Cincinnati Bell 01877, 01376

Cisco 01877, 02589,

01982, 01582,

01883, 02401,

03265

Citycable 03477

Cogeco 01376, 01877,

01982

Comcast 01376, 01877,

01982, 02187

Cox 01877, 01376

Darty Box 02436

Digeo 02187

Freebox 01976

Grande

Communications

01877, 01376

Humax 02620, 02165

ImOn Communications 01877

Insight 01376, 01877

Inter Mountain Cable 01877

Kabel Deutschland 02165

Knology 01877

Mediacom 01376, 01877

MetroCast Cablevision 01877

Midcontinent

Communications

01376, 01877

Motorola 01376

Moxi 02187

NET 01883

NorthwesTel 01376

Novus 01376, 01877

Numericable 02436

Pace 01877, 02620,

01582, 01883

Panasonic 01982

Philips 01582

Pioneer 01877

RCN 01376

Rogers 01877, 01376

Sagem 02436

Samsung 03477, 01877,

01987, 02589,

03265

ScienticAtlanta 01877, 01982,

01987, 02436,

02401

Service Electric 01376, 01877

Shaw 01376, 01877,

02187

SKY 02620

SKY Deutschland 02620

Source Cable 01376

Suddenlink 01877, 01376

Telenet 01920, 03477

Telewest 01987

Thomson 01582

Time Warner 01877, 01376,

02187

TiVo 03265

Unitymedia 03477

UPC 01582, 03477

UPC Cablecom 01582, 03477

Videotron 01877

Virgin Media 01987, 03265

Wave Broadband 01376

Western Iowa

Telephone

01877

Westman

Communications

01376, 02187

WideOpenWest 01877, 01376,

02187

Ziggo 02589

 IPTV

ADB 02586, 01481,

01998, 03028

Alcom 02437

Altibox 02437

Amino 01615, 01481,

01898, 01998,

03028

Arkwest 01481, 01998

Arvig Communication

Systems

01998, 02345

AT&T 00858

ATMC 01998, 03028

Ballard Rural

Telephone Cooperative

02586

Bayland

Communications

02586

Bell 01998

Bell Aliant 01998

Bell Fibe TV 01998

Bledsoe Telephone

Cooperative

01481, 01998

Bloomingdale

Communications

01481, 01998,

03028

Blue Valley

Telecommunications

01898

Bouygues Telecom 03007

Brandenburg Telecom 01481, 01998

BT 02294

BTC Broadband 02586

Burlington Telecom 01481, 01615

Cabovis 02436

CalTel Connections 02586

Canby Telcom 01481

Cannon Valley

Cablevision

01481, 01998

CenturyLink 01998

Cisco 00858, 03028,

02345, 02378

ClubInternet 02132

CoopTel 00858, 01615,

01898

CRST Telephone

Authority

01481, 01998

Dakota Central

Telecommunications

02345

Dalton Cable

Television

01877, 01982

Delta Cable 01376

Diverse

Communications

01898

Du 02401

Eagle Broadband 01481, 01998

Eagle Valley Telephone 01481, 01998

EasyTEL 01481, 01998,

03028

Echostar 03452

Etex 02586

Farmer's Telephone

Cooperative

01998, 03028

Golden Belt Telephone 02586

Gorham

Communications

01481

Griswold Cooperative

Telephone

01481, 01998

GTI 01481, 01998,

03028

Harrisonville

Telephone

02586

Hathw@y 02043

Horizon Cable TV 02586

Hotwire 02586

HTC Communications 01481, 01998

Innovative Systems 01898

Inotel 02437

Integra Telecom 02345

Interstate Cablevision 01481, 01998

JP PTT 01615

Kiss 02132

KM Telecom 01481

KoolConnect 01481

KPN 02952, 02437

Lakeland Cablevision 01481, 01998

Lemonweir Valley

Telephone

01481, 01998

Liberty

Communications

02586

Lonsdale Video

Ventures

01481, 01998

Lumos Networks 01998, 03028

Manawa Telecom 02586

Reference Information

87

Manti Telecom 01481, 01998

Matanuska Telephone

Association

01481, 02586

Meo 02401

MHTC 01481, 01998

Microwave Satellite

Technologies

01481, 01998

Millennium Telecom 01481, 01998

Minburn

Communications

01481, 01998,

03028

MM&G Enterprises 01481, 01998

Motorola 02378, 01998,

02437, 0858,

02952, 01376

Movistar 03288

MTS 01998

NDTC 01481, 01998,

03028

North Central

Telephone

02345

North Dakota

Telephone

02586

North State

Communications

00858

Norvado 02586

Nsight 02345, 02586

NU Telecom 01998, 03028

Oi TV 03452, 03454

Open IPTV 01615

Optimus Clix 02437

Orange 02407

OTEC

Communications

02586

Pace 02401, 03454

Panora

Telecommunications

01481

Paul Bunyan

Communications

02586

Pine Island Telephone 01481, 01998

Polar Communications 02586

Poplar Bluff Municipal

Utilities

01481, 01998

Portugal Telecom 02401

Price County

Telephone

01481, 01998

Project Mutual

Telephone

01481, 01998

PSC 01998

Quality One

Technologies

01481, 01998

Qwerty.TV 01898

Randolph Telephone 02586

Readlyn Telephone 02586

Reservation Telephone 01998, 02345

River Valley

Telecommunications

01481, 01998

S-GO Video 01877

Sagem 02407, 03288

Sagemcom 02407

Samsung 02407

Sasktel 01998

ScienticAtlanta 00858, 02345,

03028

Silver Star

Communications

01481, 01998,

03028

SingTel 01998

SKY Deutschland 02620

Skyline Cable 02586

SkyPix 01481, 01998

Smile Content 02437

Smithville 02586

Sogetel 01998

SureWest 01481, 01998,

02586

Surry Telephone 02586

SWAT Cooperative 01481, 01998,

03028

T-Home 02132

Telefonica 03288, 03028

Telus 03028

TeNeT 01898

Thomson 03007, 02407

TV Northeast 01481, 01998

TVB 01615

Twin Valley

Communications

02586

United Telephone 02586

Venture

Communications

Cooperative

01998

Verizon 02378

Viken Fibernett 02437

Vivo 03288

Watch TV 01481, 01998

West Carolina

Telephone

03028

Western Wisconsin

Communications

02586

Westphalia Broadband 02586

Wilkes

Telecommunications

01481, 01998

Yadkin Valley Telecom 02345

 IPTV PVR Combination

ADB 02437

Altibox 02437

Amino 01615, 01898

AT&T 00858

ATMC 03028

Beeline 03028

Belgacom TV 02132

Bell 01998

Bell Aliant 01998

Bell Fibe TV 01998

Bouygues Telecom 03007

BT 02294

Cabovis 02436

CenturyLink 01998

Cisco 00858, 03028,

02132, 02345,

02378

ClubInternet 02132

Deutsche Telekom 02132

Du 02401

Echostar 03452

Freebox 01976

i-CAN 02437

Innovative Systems 01898

InviTV 02437

Kiss 02132

KPN 02952, 02437

Lumos Networks 01998

Magio Sat 02132

Magnet 01615

Meo 02401

Motorola 02437, 02378,

00858, 01998,

02952, 02401

MTS 01998

Numericable 02436

Oi TV 03452, 03454

Orange 02407

Pace 02401, 03454

Philips 02294

Portugal Telecom 02401

Sagem 02407, 03288

Sagemcom 02436, 02407,

03007

Samsung 02407

Sasktel 01998

ScienticAtlanta 00858, 02345,

02401, 03028

SKY Deutschland 02620

SureWest 01998

T-Home 02132

Telefonica 03028, 03288

Telus 03028

Thomson 03007

Verizon 02378

Vodafone 02401

 PVR

DirecTV 20739

Humax 20739

Panasonic 20616

Philips 20739

Reference Information

88

RCN 20739

ReplayTV 20616

Sonic Blue 20616

Sony 20636

TiVo 20739, 20636

Kitahama Chuo Bldg, 2-2-22 Kitahama, Chuo-ku, OSAKA 541-0041, JAPA N

http://www.onkyo.com/

18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.

For Dealer, Service, Order and all other Business Inquiries:

Tel: 201-785-2600 Fax: 201-785-2650

http://www.us.onkyo.com/

For Product Support Team Only:

1-800-229-1687

Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY

Tel: +49-8142-4401-0 Fax: +49-8142-4208-213

http://www.eu.onkyo.com/

Unit 1033, 10/F, Star House, No 3, Salisbury Road, Tsim Sha Tsui Kowloon, Hong Kong.

Tel: 852-2429-3118 Fax: 852-2428-9039

http://www.hk.onkyo.com/

1301, 555 To wer, No.555 West NanJing Road, Jing’an District, Shanghai, China 200041,

Tel: 86-21-52131366 Fax: 86-21-52130396

http://www.cn.onkyo.com/

The Americas

China

Europe

Asia, Oceania, Middle East, Africa

Please contact an Onkyo distributor referring to Onkyo SUPPORT site.

http://www.intl.onkyo.com/support/

The above-mentioned information is subject to change without prior notice.

Visit the Onkyo web site for the latest update.

(Mainland)

(Hong Kong)

Meridien House, Ground floor, 69 - 71 Clarendon Road, Watford, Hertfordshire, WD17 1DS, United Kingdom

Tel: +44 (0)8712-00-19-96 Fax: +44 (0)8712-00-19-95

Kitahama Chuo Bldg, 2-2-22 Kitahama, Chuo-ku, OSAKA 541-0041, JAPA N

http://www.onkyo.com/

18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.

For Dealer, Service, Order and all other Business Inquiries:

Tel: 201-785-2600 Fax: 201-785-2650

http://www.us.onkyo.com/

For Product Support Team Only:

1-800-229-1687

Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY

Tel: +49-8142-4401-0 Fax: +49-8142-4208-213

http://www.eu.onkyo.com/

Unit 1033, 10/F, Star House, No 3, Salisbury Road, Tsim Sha Tsui Kowloon, Hong Kong.

Tel: 852-2429-3118 Fax: 852-2428-9039

http://www.hk.onkyo.com/

1301, 555 To wer, No.555 West NanJing Road, Jing’an District, Shanghai, China 200041,

Tel: 86-21-52131366 Fax: 86-21-52130396

http://www.cn.onkyo.com/

The Americas

China

Europe

Asia, Oceania, Middle East, Africa

Please contact an Onkyo distributor referring to Onkyo SUPPORT site.

http://www.intl.onkyo.com/support/

The above-mentioned information is subject to change without prior notice.

Visit the Onkyo web site for the latest update.

(Mainland)

(Hong Kong)

Meridien House, Ground floor, 69 - 71 Clarendon Road, Watford, Hertfordshire, WD17 1DS, United Kingdom

Tel: +44 (0)8712-00-19-96 Fax: +44 (0)8712-00-19-95

D1403-0

SN 29401761PDF_EN

(C) Copyright 2014 Onkyo Corporation Japan. All rights reserved. * 2 9 4 0 1 7 6 1 *
