Onset Computer ONST1 Digital Transmission User Manual EM260 Module Installation
Onset Computer Corporation Digital Transmission EM260 Module Installation
User Manual.pdf
91-18296 Module Installation
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Industry Canada Statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of
the device.
Avis de conformité pour l’Industrie Canada
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
91-18296
Soldered onto MX1102 in location shown
91-18296
Installation Orientation
UP
© 2015 Onset Computer Corporation. All rights reserved.
91-18296 BLE Module Installation Manual
Doc No: 19157-A Page 1 of 2
91-18296 Module Installation
Approved antenna:
Onset ¼ wave printed meandering F antenna with a gain of -2 dBi.
OEM Responsibilities to comply with FCC and Industry Canada Regulations
The 91-18296 Module has been certified for integration into products only by Onset Computer
Corporation under the following conditions:
1. The antenna(s) must be installed such that a minimum separation distance of 20cm is
maintained between the radiator (antenna) and all persons at all times.
2. The transmitter module must not be co-located or operating in conjunction with any other
antenna or transmitter.
As long as the two conditions above are met, further transmitter testing will not be required.
However, Onset Computer Corporation is still responsible for testing their end-product for any
additional compliance requirements required with this module installed (for example, digital
device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for certain
configurations or co-location with another transmitter), then the FCC and Industry Canada
authorizations are no longer considered valid and the FCC ID and IC Certification Number
can not be used on the final product. In these circumstances, Onset Computer Corporation
will be responsible for re-evaluating the end product (including the transmitter) and
obtaining a separate FCC and Industry Canada authorization.
End Product Labeling
The 91-18296 Module is labeled with its own FCC ID and IC Certification Number. If the FCC ID
and IC Certification Number are not visible when the module is installed inside another device,
then the outside of the device into which the module is installed must also display a label
referring to the enclosed module. In that case, the final end product must be labeled in a visible
area with the following:
"Contains Transmitter Module FCC ID: WXF-ONST1"
"Contains Transmitter Module IC: 7936A-ONST1"
or
"Contains FCC ID: WXF-ONST1"
"Contains IC: 7936A-ONST1"
Onset Computer Corporation must only use the approved antenna(s) listed above, which have
been certified with this module.
Onset Computer Corporation has to be aware not to provide information to the end user
regarding how to install or remove this RF module or change RF related parameters in the user
manual of the end product.
© 2015 Onset Computer Corporation. All rights reserved.
91-18296 BLE Module Installation Manual
Doc No: 19157-A Page 2 of 2
