USER MANUAL

READ CAREFULLY BEFORE OPERATION

Blu-ray Disc Player BDP-103

Table of Contents

IMPORTANT INFORMATION .......................................................1

Important Safety Instructions .................................................................................... 1

Precautions ................................................................................................................. 2

FCC Statement ............................................................................................................ 2

Trademarks ................................................................................................................. 3

Compatible Disc Types ............................................................................................... 3

Discs that cannot be played.............................................................................................................4

Notes about BD-ROM compatibility .................................................................................................4

Disc care and handling ....................................................................................................................4

Copyright Protection ................................................................................................... 4

Cinavia Notice ............................................................................................................. 4

Gracenote Notice ........................................................................................................ 5

Region management information ............................................................................... 5

Accessories ................................................................................................................. 5

INSTALLATION ...........................................................................6

Front Panel Controls ................................................................................................... 6

Front Panel Display Windows ..................................................................................... 6

Rear Panel Connectors ............................................................................................... 7

Remote Control ........................................................................................................... 8

Remote Control Buttons...................................................................................................................8

Back Side.........................................................................................................................................9

Battery Installation ...........................................................................................................................9

Using the Remote Control................................................................................................................9

Changing the Remote Code...........................................................................................................10

Changing the Backlight Method .....................................................................................................10

Common Connection Methods.................................................................................. 11

Connecting to an A/V Receiver via HDMI ......................................................................................11

Connecting to a TV and A/V Receiver via Dual HDMI...................................................................12

Connecting to a TV via HDMI ........................................................................................................13

Connecting to Two TVs via HDMI ..................................................................................................14

Connecting to a TV via DVI............................................................................................................15

Alternate Audio Connections.................................................................................... 16

Connecting to an A/V Receiver or Amplifier via Analog Outputs ...................................................16

Connecting to an A/V Receiver or Amplifier via S/PDIF (Coaxial / Optical)...................................17

HDMI / MHL INPUT to BDP-103 ................................................................................. 18

Connecting to the Internet ....................................................................................... 19

Internet connection through Ethernet cable ...................................................................................19

Custom Installation ...................................................................................................21

External IR (Infrared Remote) Installation......................................................................................21

RS232 Control................................................................................................................................21

Quick Start Guide ......................................................................................................22

Power On and Play ........................................................................................................................22

Select the Best Output Resolution .................................................................................................22

Determine the Display Aspect Ratio ..............................................................................................23

BASIC OPERATIONS ................................................................24

Disc Playback ............................................................................................................24

OPTION Menu.............................................................................................................24

Fast Playback ............................................................................................................25

Pause and Frame-by-Frame .......................................................................................25

Slow Playback............................................................................................................26

Blu-ray Disc Menu Playback ......................................................................................26

DVD Menu Playback...................................................................................................26

On-Screen Display......................................................................................................27

Volume Control ..........................................................................................................27

Mute............................................................................................................................28

Audio Language/Track Selection ..............................................................................28

Subtitle Selection ......................................................................................................28

HDMI / MHL INPUT Selection ....................................................................................29

Audio Return Channel (ARC) Selection.....................................................................29

BD-Live .......................................................................................................................30

ADVANCED OPERATIONS ........................................................31

Output Resolution ......................................................................................................31

Zooming and Aspect Ratio Control ...........................................................................32

Zoom Levels for HDMI Output .......................................................................................................32

Subtitle Shift ..............................................................................................................34

Repeat Playback ........................................................................................................34

Repeat a Selected Section........................................................................................35

Shuffle and Random Playback ..................................................................................35

Playback by Chapter or Track Number.....................................................................35

Playback from a Specific Location ...........................................................................36

DVD and Blu-ray Discs ..................................................................................................................36

CD and SACD discs.......................................................................................................................37

Memory and Automatic Resume ...............................................................................38

Viewing Pictures on DVD-Audio Discs ......................................................................38

Pure Audio Mode ........................................................................................................38

Internet connection through wireless adaptor ................................................................................20

iii

Playback from USB Flash Drive ................................................................................ 40

In-home Network Media Sharing .............................................................................. 41

Internet Streaming on HOME Menu.......................................................................... 42

Playing Music Files ................................................................................................... 43

Playing Movie Files ................................................................................................... 45

Viewing Photo Files .................................................................................................. 46

Adding Background Music ........................................................................................ 47

SETUP MENU OPTIONS .......................................................... 48

Using the Setup Menu System.................................................................................. 48

Playback Setup ......................................................................................................... 51

Video Setup ............................................................................................................... 53

Picture Adjustment.........................................................................................................................56

HDMI Options ................................................................................................................................59

Audio Format Setup .................................................................................................. 61

Audio Signal Reference Chart .......................................................................................................64

Recommended Audio Format Options ..........................................................................................65

Audio Processing Setup ............................................................................................ 67

Speaker Configuration ...................................................................................................................67

Other Audio Processing Settings ...................................................................................................71

Device Setup ............................................................................................................. 72

Network Setup .......................................................................................................... 76

REFERENCES........................................................................... 80

Useful Notes.............................................................................................................. 80

Troubleshooting ........................................................................................................ 80

Specifications ........................................................................................................... 82

User Manual Updates Online .................................................................................... 82

Language Code List .................................................................................................. 83

Gracenote Terms of Use ............................................................................................84

LIMITED WARRANTY................................................................85

OPPO Digital, Inc. Limited Two Years Warranty...................................................... 85

MEDIA FILE PLAYBACK ...........................................................40

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN.

WARNING:

CAUTION:

This label is located on the laser protective housing inside the

product.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug

has two blades and a third grounding prong. The wide

blade or the third prong is provided for your safety. If

the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or

pinched, particularly at plug, receptacle, and the point

where it exits from the apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the

apparatus. When a cart is used, use

caution when moving the

cart/apparatus combination to avoid

injury from tip-over.

13) Unplug this apparatus during lightning storms or when

unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug

is damaged, liquid has been spilled or objects have fallen

into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been

dropped.

15) Batteries (battery pack or batteries installed) shall not be

exposed to excessive heat such as sunshine, fire or the

like.

IMPORTANT INFORMATION

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN

OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE

PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN

THE CABINET. REFER SERVICING TO QUALIFIED

PERSONNEL ONLY.

THE APPARATUS SHALL NOT BE EXPOSED TO

DRIPPING OR SPLASHING AND THAT NO OBJECTS

FILLED WITH LIQUIDS, SUCH AS VASES SHALL BE

PLACED ON THE APPARATUS.

DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. REPLACE ONLY WITH THE SAME OR

EQUIVALENT TYPE.

THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS

OR ADJUSTMENTS OR PERFORMANCE OF

PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN

MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND DO NOT REPAIR

YOURSELF. REFER SERVICING TO QUALIFIED

PERSONNEL.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE

PERSONNEL.

The exclamation point within an equilateral triangle

is intended to alert the user to the presence of

important operation and maintenance (servicing)

instruction in the literature accompanying the appliance.

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to

the presence of uninsulated “dangerous voltage”

within the product's enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to persons.

IMPORTANT INFORMATION

Precautions

xBefore connecting the AC power cord to the appliance,

make sure the voltage designation of the appliance

corresponds to the local electrical supply. If you are

unsure of your power supply, contact your local power

company. The acceptable power input range is AC ~

100V-240V, 50/60Hz.

xThe apparatus with CLASS I construction shall be

connected to a MAINS socket outlet with a protective

earthing connection.

xThe player is still receiving power from the AC power

source as long as it is connected to the wall outlet,

even if the player itself has been turned off.

xUnplug the power cord if you are not going to use the

product for an extended period of time. Hold the power

plug when unplugging. Do not pull on the cord.

xThe main plug is used as the mechanism for cutting off

power, therefore make sure it is easy to unplug.

xTo ensure proper ventilation around this product, do not

place this product on a sofa, bed or rug. When installing

this product on a wall or bookshelf, you need to provide

appropriate space: we recommend leaving 4 inches (10

cm) of free space at the top, the sides and the rear.

xHigh temperature will lead to abnormal operation of this

unit. Do not expose this unit or batteries to direct sunlight

or near other heating objects.

xWhen moving the player from a cold location to a warm

one, or vice versa, moisture may condense on the laser

pickup unit inside the player. Should this occur, the

player may not operate properly. In such a case please

turn the unit on for 1-2 hours (without a disc) to facilitate

moisture evaporation.

FCC Statement

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

xReorient or relocate the receiving antenna.

xIncrease the separation between the equipment and

receiver.

xConnect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

xConsult the dealer or an experienced radio/TV technician

for help.

Any unauthorized changes or modifications to this equipment would

void the user’s authority to operate this device.

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

IMPORTANT INFORMATION

Trademarks

x“Blu-ray Disc”, “Blu-ray 3D”, “BONUSVIEW” and “BD-

Live” are trademarks of Blu-ray Disc Association.

xJava and all Java-based trademarks and logos are

trademarks or registered trademarks of Sun

Microsystems, Inc. in the United States and other

countries.

xDVD Logo is a trademark of DVD Format/Logo Licensing

Corp., registered in the U.S., Japan and other countries.

xSuper Audio CD, SACD and the SACD logo are joint

trademarks of Sony Corporation and Philips Electronics

N.V. Direct Stream Digital (DSD) is a trademark of Sony

Corporation.

x“AVCHD” and the “AVCHD” logo are trademarks of

Panasonic Corporation and Sony Corporation.

xDesigned for Windows Media, Microsoft, HDCD, and the

HDCD logo are trademarks or registered trademarks of

Microsoft Corporation in the United States and/or other

countries.

x“Netflix” is a registered trademark of Netflix, Inc.

x“Qdeo” is trademark of Marvell or its affiliates.

xManufactured under license under U.S. Patent Nos:

5,956,674; 5,974,380; 6,226,616; 6,487,535;

7,212,872; 7,333,929; 7,392,195; 7,272,567 & other

U.S. and worldwide patents issued & pending. DTS-

HD, the Symbol, & DTS-HD and the Symbol together

are registered trademarks & DTS-HD Master Audio is

a trademark of DTS, Inc. Product includes software.

xManufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of

Dolby Laboratories.

xHDMI, the HDMI logo and High-Definition Multimedia

Interface are trademarks or registered trademarks of

HDMI Licensing LLC.

x“Pandora” is trademark of Pandora, Inc.

x“Gracenote” is trademark of Gracenote, Inc.

x“Cinavia” is trademark of Verance Corporation.

xAll other trademarks are the properties of their

respective owners.

Compatible Disc Types

nocIlaunaMserutaeFogoL

BD: Supports Blu-ray with Bonus View and BD-Live content, including Blu-ray

3D discs. A 3D-capable display with compatible glasses is required for 3D

playback. BD-R/RE, both single- and dual-layer are also supported.

DVD: Plays commercially-released DVDs, as well as finalized DVD±R/RW.

DVD-A: High-resolution stereo or multi-channel audio. Some DVD-Audio discs

also contain a DVD-Video portion.

DVD-A

SACD: High-resolution stereo or multi-channel audio. Note: some SACDs use

a hybrid format with both a CD and a high resolution DSD layer.

SACD

CD: Supports standard Red Book CDs, as well as HDCD and CD-R/RW.

AVCHD: High-definition digital video camera format, often in the form of a

DVD±R or flash memory.

“480i/480p/720p/1080i/1080p” up-converting arrow logo,

“Source Direct” and “True 24p” logos are trademarks of

OPPO Digital, Inc.

IMPORTANT INFORMATION

Discs that cannot be played

BDs with cartridge

DVD-RAMs

HD-DVDs

Data portion of CD-Extras

DVDs / Blu-Rays with a region code other than 1 or A

Some Dual-Discs: A Dual-Disc is a two-sided disc with

DVD-video on one side and digital audio on the other

side. The digital audio side does not meet the technical

specifications of the Red Book CD format so playback is

not guaranteed.

Audio discs with copy-protection may not be playable.

Notes about BD-ROM compatibility

Since the Blu-ray Disc specifications are new and evolving, some discs may not play properly depending on the disc type, version

and encoding. It is possible that a Blu-ray Disc manufactured after the player uses new features of the Blu-ray Disc specifications.

To ensure the best possible viewing experience, the player may need a firmware or software update from time to time. Please visit

OPPO Digital’s web site www.oppodigital.com to check if updates are available.

Disc care and handling

To keep the disc clean from scratches or fingerprints,

handle the disc by its edge. Do not touch the recorded

surface.

Blu-ray Discs record data in very high density and the

recorded layer is very close to the disc surface. For this

reason, Blu-ray Discs are more sensitive to dust and

fingerprints than DVD. Should you encounter playback

problems and see dirty spots on the disc surface, clean

the disc with a cleaning cloth. Wipe the disc from the

center out along the radial direction. Do not wipe the

disc in a circular motion.

Do not use record cleaning sprays or solvents such as

benzene, thinner and anti-static spray.

Do not attach labels or stickers to discs as this may

cause the disc to warp or become too thick, resulting in

playback issues and a potentially stuck disc.

Avoid exposing the discs to direct sunlight or heat

sources.

Do not use the following discs:

oDiscs with exposed adhesive from removed stickers

or labels. The disc may get stuck inside the player.

oWarped or cracked discs.

oIrregularly shaped discs, such as heart or business

card shapes.

Cinavia Notice

This product uses Cinavia technology to limit the use of unauthorized copies of some commercially-produced film and videos and their

soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be

interrupted.

More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at http://www.cinavia.com.To

request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Center,

P.O. Box 86851, San Diego, CA, 92138, USA.

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights of Rovi

Corporation. The use of Rovi Corporation's copyright protection technology in the product must be authorized by Rovi Corporation. Reverse

engineering and disassembly are prohibited.

IMPORTANT INFORMATION

Region management information

This player is designed and manufactured to respond to the region management information. If the region number of a BD-Video or

DVD disc does not correspond to the region number of this player, this player cannot play the disc.

BD-Video: This player plays Blu-Ray Discs with marks containing the region code A.

DVD-Video: This player plays DVDs with marks containing the region code 1 and ALL.

Accessories

Please check that the following parts are included in your BDP-103 package:

User Manual HDMI 1.4 Cable, about 6 feet

USB Wireless-N Adapter (up to 150Mbps,

802.11b/g/n compatible, 2.4GHz)

USB Extension Cable, about 4.5 feet

Power Cable, about 4.5 feet Remote Control with AA Batteries

Music and Video recognition technology and related data are provided by Gracenote®. Gracenote is the industry standard in music

and video recognition technology and related content delivery. For more information visit www.gracenote.com.

See the Gracenote website for a non-exhaustive list of applicable Gracenote patents. Gracenote, CDDB, MusicID, the Gracenote

logo and logotype, and the "Powered by Gracenote" logo are either registered trademarks or trademarks of Gracenote in the United

States and/or other countries.

Gracenote Notice

INSTALLATION

Front Panel Controls

1 32 4 5 6 7 8 10 119

1. POWER Button

2. POWER Status

Indicator

3. Front Panel Display

Window

4. Disc Tray

5. OPEN/CLOSE Tray

Button (with backlight)

6. IR Sensor Window

7. USB 2.0 Input

8. 3D Output Active

Indicator

9. 4K x 2K Output

Active Indicator

10. MHL-Compatible

HDMI Input

11. Playback Control

and Navigation

Buttons

Front Panel Display Windows

35 6 7 8 913

10 11

21 13

1. Mute Icon – Indicates that the audio is muted

2. Audio Type Indication – Indicates the type of audio

tracks being played

3. Disc Type Indication – Indicates the currently

playing disc type

4. Main Display – Text messages and numeric display

5. Title – When illuminated, the displayed time applies to

a title

6. Group – When illuminated, the displayed time applies

to a group

7. Chapter – When illuminated, the displayed time

applies to a chapter

8. Track – When illuminated, the displayed time applies to

a track

9. Audio Channel Indication – Indicates whether the audio

being played is 2ch stereo or multi-channel surround

10. Remaining – When illuminated, the displayed time is

the remaining play time

11. Playback Status – Indicates playback status such as

Play, Pause, Repeat, Repeat All, and Random Mode

12. Ethernet – Indicates that an active Ethernet cable is

attached

13. Wireless – Indicates that the player is connected to a

wireless network

INSTALLATION

Rear Panel Connectors

245678 10 12

911

1. Ethernet LAN Port

2. HDMI Input (Back)

3. Diagnostic Video Output

4. Coaxial Digital Audio Output

5. Optical Digital Audio Output

6. HDMI 2 Output (3D Compatible)

7. HDMI 1 Output (3D Compatible)

8. USB 2.0 Input

9. USB 2.0 Input

10. IR (Infrared) Signal Input

11. RS-232C Serial Control Port

12. 7.1CH / 5.1CH / Stereo Analog

Audio Outputs

In addition to the above connectors, the AC power inlet is also located on the rear panel. The inlet is the IEC60-

320 C14 type. Only the included AC power cord or an approved power cord with an IEC60-320 C14 type plug

should be used.

INSTALLATION

Remote Control

Remote Control Buttons

1. POWER: Toggle power

STANDBY and ON

2. NETFLIX: Netflix access

button

3. PURE AUDIO: Turn

off/on video

4. NUMBER Buttons:

Enter numeric values

5. CLEAR: Clear numeric

input

6. TOP MENU: Show BD

top menu or DVD title

7. ARROW and ENTER

Buttons: Navigate menu

selection

8. OPTION: Brings up the

context-related menu

9. COLOR Buttons:

Function varies by

content

10. PLAY: Start playback

11. STOP: Stop playback

12. REV: Fast reverse play

13. PREV: Skip to previous

14. AUDIO: Change audio

language or channel

15. SUBTITLE: Change

subtitle language

16. SETUP: Enter the

player Setup Menu

17. A-B REPLAY: Repeat

play the selected

section

18. RESOLUTION: Switch

output resolution

19. OPEN: Open/close the

disc tray

20. INPUT: Select the input

source

21. VUDU: VUDU access

button

22. MUTE: Mute audio

23. VOLUME +/-:

Increase/Decrease

volume

24. HOME: Go to Home

Menu to select media

source

25. PAGE UP/DOWN:

Show the previous/next

page

26. INFO: Show/hide the

On-Screen Display

27. GOTO: Play from a

specified location

28. POP-UP MENU: Show

BD pop-up menu or

DVD menu

29. RETURN: Return to the

previous menu or mode

30.PAUSE: Pause

playback

31. FWD: Fast forward play

32. NEXT: Skip to the next

33. 3D: Enable 2D->3D

conversion or bring the

3D adjustment menu

34. ZOOM: Zoom in/out

and adjust aspect ratio

35. DIMMER: Dim the front

panel display

36. REPEAT: Repeat play

37. LIGHT: Activate the

back light for the

remote control

NOTE

When a button is pressed but its function is invalid or unavailable at the moment, the TV screen

displays a circle with a diagonal line:

INSTALLATION

Back Side

With Battery Cover Battery Cover Removed

1. Index Finger Notch 1: When your index finger is

placed at this notch while holding the remote control,

your thumb is within easy reach of the navigation

buttons (ARROW, ENTER, TOP MENU and POP-UP

MENU).

2. Index Finger Notch 2: When your index finger is

placed at this notch while holding the remote control,

your thumb is within easy reach of the playback

control buttons (STOP, PLAY, PAUSE, PREV, NEXT,

REV, FWD).

3. Battery Cover: Remove to replace batteries or set

remote code.

4. Batteries: Use 2 AA or LR6 batteries.

5. Remote Code Switch: Adjust the position of the

switch to set the remote control to use the indicated

remote code (see details on page 10).

Battery Installation

1. Remove the battery

compartment cover

2. Insert batteries 3. Replace the battery

compartment cover

Using the Remote Control

When using the remote control, the front window of the remote control should be pointed to the infrared sensor

on the front panel within an angle of ±30° and a range of about 26 ft.

Within about 26ft

INSTALLATION

Changing the Remote Code

The remote control contains three OPPO remote codes. The default is “Code 1”. If you have other OPPO

products placed close to the BDP-103, they may inadvertently respond to the BDP-103 remote control. To

prevent this, you can select a different remote code.

To select a new remote code, open the battery compartment cover of the remote control, and then use a ball

point pen to flip the switch to one of the positions marked as “1”, “2”, or “3”. Close the battery compartment

cover. Make sure that the BDP-103 player is turned on and that the disc tray is ejected. Aim the remote control

at the player. Press and hold the ENTER button for 5 seconds. The player will start using the new remote code.

Remote Code Switch

Battery Compartment

Changing the Backlight Method

The remote control supports one of two backlight methods. By default, pressing the LIGHT button will

turn on the backlight, and pressing any other button within 10 seconds will keep the backlight on. The

alternative method will activate the backlight whenever any button is pressed; in this mode, the light will

stay on for 10 seconds, and pressing any other button will keep the backlight on. To switch between

these two backlight methods, press and hold the LIGHT button for 5 seconds.

CAUTION

xNever drop the remote control or expose it to moisture.

xNever expose the infrared remote sensor on the front panel to direct sunlight or other

strong light sources.

xRemote may not operate consistently when batteries become low. Replace them if

operation deteriorates.

xIf the remote control will not be used for a long time, please remove the batteries.

xUse the batteries correctly to avoid possible leakage and corrosion. Do not leave the

batteries exposed to direct sunlight or in a high temperature environment for a long period

of time. Do not heat or expose to flame. Do not mix old and new batteries. Do not use

batteries of different types at the same time. Do not attempt to recharge the batteries.

xIf battery leakage occurs, do not touch the liquid with bare hands. Wipe out any liquid inside

the battery compartment, and insert new batteries.

INSTALLATION

Common Connection Methods

Connecting to an A/V Receiver via HDMI

HDMI Cable

(to HDMI 1 or 2)

HDMI In

Rear Panel

HDMI INHDMI OUT

AUDIO/VIDEO MULTI- CHANNEL

RECEIVER

xIf you have an HDMI-capable receiver that can support HDMI audio, you can simply run an HDMI

cable from the player to your receiver and enable HDMI audio on the receiver (see your receiver’s

owner’s manual for more information). The receiver usually has an HDMI output that you can

connect to your TV to pass the video signal.

xEither of the HDMI output terminals (HDMI 1 OUT and/or HDMI 2 OUT) on the rear panel of the

BDP-103 can be connected to your receiver. Preference should be given to the HDMI 1 output for

video since it is the only output to benefit from the superior Marvell QDEO video processor.

NOTE

HDMI (High-Definition Multimedia Interface) is a single cable that can transport both audio and

video from your player to your display. Be aware, however, that HDMI is an evolving standard, and

there may be compatibility issues. A receiver that supports audio input over HDMI is required.

Some receivers offer HDMI ports solely for video switching. If your receiver does not have audio

input capability, please read the following sections regarding other connection methods.

In order to play multi-channel audio for all formats, the receiver must support HDMI v1.1 or later.

For Blu-ray Discs, a receiver that supports HDMI v1.4 with decoding capability for Dolby TrueHD

and DTS-HD Master Audio is preferred. Please check the specifications of your receiver to ensure

that it meets these requirements.

The HDMI outputs on the BDP-103 are HDMI v1.4, which are compatible with HDMI v1.3 and

earlier versions.

INSTALLATION

Connecting to a TV and A/V Receiver via Dual HDMI

HDMI IN

HDMI Cable 1

HDMI Cable 2

Rear Panel

AUDIO/ VIDEO M ULTI- CHANNEL

RECEIVER

HDMI IN

xThe BDP-103 provides a “Dual HDMI” connection to make sure you can enjoy the highest possible

video quality and resolution, in addition to high bit rate audio content. You can use the included

HDMI cable to connect the HDMI 1 output to your HDTV and use another HDMI cable (not included)

to connect the HDMI 2 output to your receiver by setting the Dual HDMI Output option in the

Setup Menu to Split A/V (see page 53 for details). In this way you can utilize the dedicated video

processor available for the HDMI 1 output, and allow your receiver which has no HDMI 1.4 inputs

to work without any loss to the digital audio signals.

xThis configuration is recommended when you have a 3D-compatible display, but your receiver is

not 3D-compatible. This allows you to send the video signal (3D, in this case) directly to the TV and

the audio signal to the receiver to be distributed to your speakers as it normally would.

NOTE

xPlease refer to the notes on HDMI connections available on page 11.

xIf your receiver does not have HDMI audio input capability, please try the alternate

connection methods discussed on pages 16 and 17.

INSTALLATION

Connecting to a TV via HDMI

HDMI Cable (to HDMI 1 or 2)

HDMI In

Video In

Rear Panel

Composite Cable (Optional)

xIf your TV has an HDMI input, you can use the included HDMI cable to connect the player directly to

the TV. This connection method delivers both video and audio in a pure digital format via a single

cable. The HDMI output of the player allows for the highest possible video quality and audio

resolution.

xThere are two HDMI output terminals (HDMI 1 OUT and HDMI 2 OUT) on the rear panel of BDP-

103, both of which can be connected to your TV. We recommend using HDMI 1 OUT since it

benefits from the dedicated Marvell QDEO video processor.

xYou may remove the HDMI cable and connect the DIAG (diagnostic) output to the TV through a

regular composite video cable (not included) when there is a problem with HDMI video. Only the

Setup Menu will be visible on the TV when using this connection, so it is limited to troubleshooting

purposes only.

NOTE

xThis connection method will output sound via the TV’s speakers. For optimal sound

quality, it is recommended that audio be transferred from the BDP-103 to an A/V

receiver with connected speakers.

xIf your A/V receiver does not accept audio via HDMI, or if your receiver does not have

HDMI inputs at all, see pages 16 and 17 for instructions on how to output audio to a

receiver using different connection types.

INSTALLATION

Connecting to Two TVs via HDMI

HDMI In HDMI In

Rear Panel

HDMI Cables

TV 1

TV 2

xThe two HDMI outputs (HDMI 1 OUT and HDMI 2 OUT) available on the rear panel of BDP-103 can

be connected to two TVs at the same time, and each output can deliver both digital video and audio

signals.

xWe recommend that you connect your main TV (the one with larger screen size or the one that you

would watch more often) to HDMI 1 OUT in order to benefit from the dedicated video processor, and

set the Dual HDMI option in the Setup Menu to Dual Display to make sure that the HDMI 2 OUT can

also send out audio and video signals (see more details on page 53).

xYou may connect the DIAG (diagnostic) output to one of your TVs for troubleshooting purposes.

Refer to page 13 for more details.

INSTALLATION

Connecting to a TV via DVI

HDMI (from HDMI 1 or 2) - DVI Cable

Rear Panel

Audio Cable

DVI Audio

DVI

xIf your TV has a DVI input that supports HDCP, you can purchase an HDMI-DVI cable to connect the

player to the TV. This connection method delivers digital video to the TV without any signal

degradation. We recommend that you use HDMI 1 OUT since it benefits from the dedicated video

processor.

xPlease use Red/White audio cables (not included) to connect the FL (Front Left) and FR (Front Right)

terminals of the player to the TV. Make sure the audio cables are connected to the same input

terminal group on the TV as the DVI input. Usually, the input terminals are marked as “DVI Audio” or

“PC Audio”. On some TVs you may need to use an RCA-3.5mm Mini-Jack adapter cable to connect

the audio.

xYou may connect the DIAG (diagnostic) output to one of your TVs for troubleshooting purpose. Refer

to page 13 for more details.

NOTE

HDCP stands for High-bandwidth Digital Content Protection. The HDMI outputs of the BDP-103 use

HDCP to encrypt the digital audio and video content. The TV must support HDCP in order to

decrypt and properly display the content.

INSTALLATION

Alternate Audio Connections

Connecting to an A/V Receiver or Amplifier via Analog Outputs

Audio Interconnect Cables

Rear Panel

AUDIO/ VIDEO M ULTI- CHANNEL

RECEIVER

Receiver/Amplifier with 7.1ch Audio Input

FRONT SURROUND SUBWOOFER S. BACK

CENTER

xPlease use up to 8 RCA-style audio interconnect cables (not included) to connect the FL (Front Left),

FR (Front Right), SL (Surround Left), SR (Surround Right), C (Center), SW (SubWoofer), SBL

(Surround Back Left) and SBR (Surround Back Right) analog output terminals of the BDP-103 to the

corresponding multi-channel analog audio input jacks of your A/V receiver or amplifier.

xIf the A/V receiver or amplifier only has 5.1ch audio inputs, do not connect the SBL (Surround Back

Left) and SBR (Surround Back Right) terminals, and set the Down Mix option in the Setup Menu to

5.1 to make sure that any 7.1 channel signals are converted to 5.1 channels (refer to Down Mix Mode

on page 68).

xIf your audio system offers only stereo audio inputs, or if you would like to connect a dedicated stereo

audio system in addition to the surround audio system which is already connected to the HDMI or

S/PDIF outputs, you can connect the dedicated stereo audio system to the FL (Front Left) and FR

(Front Right) terminals of the player.

xFor the stereo outputs, if the audio system you are connecting to does not have surround speakers,

set the Down Mix option in the Setup Menu to Stereo. If the audio system has surround speakers

and Dolby Pro Logic or other surround audio decoding capabilities, set the down mix mode to “LT/RT”.

(For more information, refer to “Down Mix Mode” on page 68).

INSTALLATION

Connecting to an A/V Receiver or Amplifier via S/PDIF (Coaxial / Optical)

xPlease use either a 75-Ohm coaxial digital audio cable with RCA-style connectors or an S/PDIF

optical digital audio cable to connect one of the digital audio outputs to the corresponding input

terminal on your A/V receiver. For detailed setup of coaxial/optical signals, refer to page 66.

NOTE

xDue to bandwidth limitations, high resolution audio formats such as Dolby Digital Plus, Dolby

TrueHD, DTS-HD High Resolution and DTS-HD Master Audio cannot be sent through the

coaxial or optical digital audio output. A reduced resolution version of the same audio track

will be output instead. To listen to high resolution audio formats in their best quality, please

use the HDMI connection if you have a receiver that handles HDMI audio (see page 11) or

use the multi-channel analog outputs if you do not (see page 16).

xDue to copyright restrictions, SACD audio cannot be sent through the coaxial or optical

digital audio output. To listen to SACDs, please use the HDMI or analog audio connections.

xDue to copyright restrictions and bandwidth limitations, full resolution audio from DVD-Audio

discs cannot be sent through the coaxial or optical digital audio output. To listen to DVD-

Audio in full resolution, please use the HDMI or analog audio connections.

Rear Panel

AUDIO/VIDEO MULTI -CHANNEL

RECEIVER

Receiver/Amplifier with Dolby Digital or DTS Decoder

Coaxial In

Optical In

Connect one of these cables:

Optical Digital Audio Cable

Coaxial Digital Audio Cable

INSTALLATION

HDMI / MHL INPUT to BDP-103

HDMI Cable

Front Panel Rear Panel

Audio/Video Source

HDMI Cable

or HDMI/MHL Cable

xThe BDP-103 provides two HDMI input ports, located on the front panel and the back panel separately,

both of which can accept up to 1080p high-definition video and digital audio. You can use the included

HDMI cable to connect a source device such as a digital TV box, mobile phone or camcorder to the

HDMI IN port(s). You can use the INPUT button on the OPPO remote to open the Input Source Menu,

which allows you to select the corresponding HDMI IN port.

xKeep in mind that the HDMI IN port on the front panel is MHL (Mobile High-definition Link) compatible,

which means if it is connected to another MHL-enabled device (like a smartphone) through a MHL

cable or adaptor (not included), then this port is not only capable of accepting high-resolution digital

signals, but can also simultaneously charge the connected device.

INSTALLATION

Connecting to the Internet

The BDP-103 has significantly improved its internet streaming capabilities compared to its predecessors.

Currently, it supports both Netflix and VUDU, as well as in-home network media sharing via My Network which

is capable of connecting with DLNA and SMB/CIFS clients. Additional online streaming applications may also

be added with future firmware updates.

The BDP-103 also supports the BD-Live feature offered on some Blu-ray Disc titles. BD-Live offers extra

downloadable content and additional online interactive programs. Content available on BD-Live varies by disc

and studio, and may include additional subtitles, commentaries, movie trailers, games, and online chat.

Connecting the player to the Internet will also allow the player to obtain firmware updates. (See pages 4 and 72

for more information regarding firmware updates.)

In order to utilize the BD-Live feature or to update the firmware via the Internet, the player needs to be

connected to a broadband Internet connection. It is not necessary to connect to the Internet if you do not intend

to use the network streaming, BD-Live or online firmware update features.

The BDP-103 provides two network connection methods: through Ethernet cable or through the external

wireless adaptor included with the player. For the fastest and most stable network connection, we recommend

using an Ethernet cable whenever possible.

Internet connection through Ethernet cable

Broadband Internet

Connection

WAN 1 2 LAN 3 4

Internet

Network Cable

(Ethernet)

Broadband Router/Modem

Rear Panel

xPlug one end of a network cable (Category 5/5E straight Ethernet cable) into the LAN port on the

back of the BDP-103.

xPlug the other end of the network cable into a LAN port on the broadband router or modem.

xAfter physically connecting the player to a broadband Internet connection, some network

configuration may be required. Refer to the Network Setup section on page 76 for details.

INSTALLATION

xRefer to the operating instructions supplied with the broadband router or modem, or contact the

Internet service provider for questions related to setting up the router or modem.

NOTE

xOnly connect the LAN port of the player to an Ethernet port that supports 10BASE-T or

100BASE-TX. Connecting to any other ports or jacks, such as a phone jack, can damage the

player.

xStreaming services such as Netflix and VUDU may require membership and may also be

limited to service in the US only.

Internet connection through wireless adaptor

Broadband Internet

Connection

Internet

Wireless Router/Access Point

Rear Panel

Internet 1 2 LAN 3 4

WiFi

Wireless Dongle

USB IN

xThe wireless adaptor included in the BDP-103 package has been pre-configured to work with your

player. It is compatible with 802.11B, G, and N (2.4GHz) wireless networks.

xMake sure a broadband Internet connection is available and the Wi-Fi function on your wireless router

or access point has been turned on, and plug the adaptor into one of the three USB ports available on

your BDP-103 (one on the front panel, two on the back).

xAfter connecting the adaptor, some network configuration is required. Refer to the Network Setup

section on page 76 for details.

xA USB extension cable is also included in the package. Connect it between the USB port on the player

and your wireless adaptor if needed.

INSTALLATION

Custom Installation

External IR (Infrared Remote) Installation

The BDP-103 features an IR IN port on its back panel. If the player is to be installed in an equipment cabinet

where direct line-of-sight is not available for the remote control, you can purchase an external IR Remote

Sensor and plug it into the IR IN port. Place the sensor head at a location where there is direct line-of-sight to

ensure reliable operation.

3.5mm Mono Cable

Rear Panel

External IR Remote Signal

IR IN Signal Identifications

Tip: IR carrier signal

Sleeve: Ground

3.5mm Mono Plug

NOTE

xWhen an external IR sensor is plugged in, the original IR sensor window on the front panel

will be disabled.

xThe IR port on the BDP-103 is NOT compatible with the prior generation of external IR

Remote Sensor (IR-ES1) which is used on BDP-83.

xOPPO cannot guarantee that the IR IN port will be compatible with devices that are not

manufactured by OPPO. Connecting the IR IN port to an incompatible device may result in

damage to the connected device or the player.

xPlease contact OPPO customer support if you plan to integrate the player into an IR

distribution system. Customer support can provide recommendations on how to properly

connect the control signals.

RS232 Control

The BDP-103 has an RS232 control port and can be integrated into most custom home theater control systems.

Please ask your custom installer to contact OPPO for the RS232 control protocol, or check the OPPO Digital

website (www.oppodigital.com) for the latest version of RS-232 protocol document.

INSTALLATION

Quick Start Guide

Power On and Play

The BDP-103 is pre-configured with settings that have been optimized for most home theater systems, so it

can fit into your audio/video system without any additional adjustment. To begin, please follow these steps:

1. Connect the OPPO player into your system.

2. Turn on the TV and/or receiver/amplifier, and then turn on the player.

3. Switch the input selection on your TV or receiver so that the TV displays the signal from the

player.

Within a few seconds, the player will load the factory default settings and you will see the Home Menu with an

OPPO logo. The player is now ready for use. Enjoy your new OPPO Blu-ray Disc Player!

Please follow the rest of the user manual for information on basic and advanced operations.

Select the Best Output Resolution

One of the major advantages of the BDP-103 is its ability to play high-definition Blu-ray video and also up-

convert standard definition video stored on DVD discs to high definition. The sophisticated video processor

inside the player ensures that the video will have the best possible color, detail and motion. The player offers

several standard and high definition video output resolutions. For best results, it is important to select an output

resolution that best matches your TV or display.

The rule of thumb when selecting an output resolution is to match the “native resolution” of your TV or display

as closely as possible. The “native resolution” is the resolution of the actual display component in the TV, such

as the Plasma panel, LCD panel, or DLP™ chip. The TV may accept input signals with lower or higher

resolutions than its native resolution. In such cases, the electronics in the TV will upscale or downscale the

video to fit its display component. Unfortunately, many TVs on the market only do an average job of scaling the

video. On the other hand, if you set the BDP-103 to output a resolution that matches or is very close to the

native resolution of the TV, you are more likely to get a great picture.

For most new displays on the market, the best output resolution will be 1080p. A few early model “1080p”

displays did not accept a 1080p signal. For these displays, the best output resolution is 1080i. For small screen

digital TVs this will likely be 720p. For even earlier CRT tube or rear projection TVs this will likely be 1080i. For

EDTV displays (very rare if they have HDMI or DVI) this will be 480p (NTSC) or 576p (PAL). These are general

recommendations that work for most users, but there can be exceptions. Advanced users may want to try all

supported resolutions and choose the one that provides the best result visually.

The BDP-103 supports a special Source Direct mode through its HDMI outputs. This resolution is

recommended for use with external video processors or high-end TVs. In Source Direct mode, the player

works as a “transport”. It decodes video from the discs and then sends the raw video signal in its native

resolution and format, without extra processing, to the external video processor or TV. The actual output

resolution varies by content:

noituloseRtuptuOtceriDecruoStnetnoC

i084DVDCSTN

i675DVDLAP

Most Blu-ray Movies (film-source) 1080p 23.976Hz or 1080p 24Hz

Most Blu-ray TV shows or Concerts

(video-source) 1080i

SACD and DVD-Audio 1080p

INSTALLATION

For both HDMI outputs, the following output resolutions are available: 4Kx2K,Auto,1080p,1080i,720p,

480p/576p,480i/576i, and Source Direct. If Auto is selected, the player will determine the output resolution

based on the best signal resolution that the TV can display.

To change the output resolution, press the RESOLUTION button on the remote to bring the Resolution Menu,

then press the UP/DOWN ARROW buttons to highlight the desired one, and press the ENTER button to

confirm and return. If your TV does not support the selected resolution, you may see a black screen or an error

message. In this case, try a different resolution that your TV can support.

Determine the Display Aspect Ratio

Standard Definition, or 4:3 TV Wide screen, or 16:9 TV

The TV Aspect Ratio is the proportional ratio of a TV screen’s width and height. Older television sets generally

have a 4:3 aspect ratio – the width is 4/3 (or 1.33) times the height. Newer wide screen television sets have a

16:9 aspect ratio – the width is 16/9 (or 1.78) times the height. For best performance, the video output of your

player needs to match the screen aspect ratio of your TV. Since most Blu-ray discs and many DVD discs are

released in the wide screen format, it is highly recommended to use a wide screen TV with the BDP-103.

The Aspect Ratio selections are 16:9 Wide and 16:9 Wide/Auto. Depending on your selection and the video

format recorded on the discs, image appearance on the TV screen can be one of the following:

Original Content

TV Screen Appearance

16:9

4:3

16:9

Wide Wide/Auto

If you have a widescreen (16:9) display, select one of these options:

x16:9 Wide – 16:9 (widescreen) sources will be displayed in their native aspect ratio, and 4:3

sources will be horizontally stretched.

x16:9 Wide/Auto – 16:9 (widescreen) as well as 4:3 sources will be displayed in their native aspect

ratio. Please note that in this mode, 4:3 sources will be displayed with black borders on both left

and right sides to maintain the correct 4:3 aspect ratio.

BASIC OPERATIONS

Disc Playback

OPENPOWER

PLAYSTOP

1Press the POWER button to turn on the player.

2Press the OPEN/CLOSE button to eject the disc tray.

3Place the disc with the label side facing up and the recorded

side facing down.

4Press the OPEN/CLOSE button again to retract the tray.

5The player will read the disc information and begin playback.

6Depending on the content of the disc, a menu or navigation

screen may appear. Use the navigation ARROW and SELECT

buttons to select the content to play.

7To stop playback, press the STOP button.

8To turn off the player, press the POWER button.

OPTION Menu

OPTION

1. During media file navigation and playback, press the OPTION

button on the remote to open the OPTION MENU, which allows

you to conveniently access various settings and playback

features.

2. When the OPTION MENU is displayed, press the LEFT/RIGHT

ARROW buttons on the remote to highlight a particular item, then

press the ENTER button to confirm.

The OPTION MENU selections may differ depending on content type. A summary of the selections and

their functionality is described as follows:

Within Disc Playback (CD, DVD, BD):

Disc info: Searches the Gracenote online database and display the available disc information (an

active internet connection is required).

DVD-A

SACD

DVD-A

SACD

Repeat: Repeat the track or all tracks. See details on page 34.

Within Music File Playback:

Music info: As with “Disc info”; searches and displa

Shuffle/Random: Activate Shuffle or Random mode. See details on page 35.

ys available music information from Gracenote.

BASIC OPERATIONS

Within Video Discs (DVD, BD) and Video File Playback:

Subtitle shift: Adjusts the position of subtitles on the screen. See details on page 34.

Picture adjustment: Opens the Picture Adjustment menu. See details on page 56.

Zoom: Opens the image zoom level menu. See details on page 32.

Angle: Changes the viewing angle. This function is only available when the DVD/BD is recorded

with multiple angles.

Within Photo File playback:

Zoom: Displays the image at different zoom levels.

Rotate – Left / Right / Mirror / Flip: Rotates the image on the screen.

Within HDMI INPUT playback:

Picture adjustment: Opens the Picture Adjustment menu. See details on page 56.

Fast Playback

REV FWD

You may fast forward or reverse during playback.

1. Pressing the FWD button on the remote control to start fast

forwarding playback. Each press of the FWD button increases

the playback speed in the following increments:

2. Pressing the REV button on the remote control starts fast reverse playback. Each press of the REV

button reverses the playback speed in the following increments:

NOTE

Certain Blu-ray Discs utilizing BD-Java technology may have their own fast forwarding and

reversing control. The actual speed varies by disc, and a progress scale may be displayed by

the disc.

Pause and Frame-by-Frame

PAUSEPLAY

PREV NEXT

1. During playback, pressing the PAUSE button temporarily pauses

the program. In this mode, a PAUSE icon will appear on the TV

screen.

2. While a DVD or Blu-ray Disc is paused, pressing the PREV or

NEXT button reverses or advances the video frame-by-frame.

3. Pressing the PLAY button resumes normal playback.

DVD-A

SACD

DVD-A

SACD

123 4 5

BASIC OPERATIONS

Slow Playback

PLAY PAUSE

REV FWD

To play the video in slow-motion, follow these steps:

1. Press the PAUSE button on the remote control to pause

playback.

2. Press the FWD button to select a forward slow playback speed.

Each press of the FWD button increases the playback speed in

the following increments:

1/16 1/8

1/41/2

3. Press the REV button to select a reverse slow playback speed. Each press of the REV button

reverses the playback speed in the following increments:

1/16 1/8

1/41/2

4. To exit the slow playback mode, press the PLAY button.

NOTE

xCertain Blu-ray Discs utilizing BD-Java technology may not support slow playback.

Blu-ray Disc Menu Playback

TOP

POP-UP

ENTER

ARROW

BUTTONS

COLOR

BUTTONS

1. Blu-ray Discs usually contain a Top Menu and a Pop-up

Menu. The Top Menu normally appears at the beginning of

playback, after the previews and copyright messages. The

Pop-up Menu can be accessed during the movie without

interrupting playback.

2. During playback, press the POP-UP MENU button to

access the Pop-up Menu. Press the TOP MENU button to

access the Top Menu.

3. Navigate the menu using the ARROW buttons, and then

press the ENTER button to make a selection.

4. Some menus make use of the COLOR buttons. You can

select menu functions by pressing the corresponding

COLOR button on the remote control.

DVD Menu Playback

TOP

(TITLE)

POP-UP

(MENU)

ENTER

RETURN

ARROW

BUTTONS

1. Some DVDs contain title menu or chapter menu functions.

2. During playback, press the TOP MENU button to return to

the disc title menu. Press the POP-UP MENU button to

display the chapter menu. Depending on the disc, one or

both menus may not exist.

3. Navigate the menu using the ARROW buttons, and then

press the ENTER button to make the selection.

4. Press the RETURN button to return to the previous menu.

The return location varies by disc.

DVD-A

BASIC OPERATIONS

On-Screen Display

1. During the playback of a DVD or Blu-ray Disc, press the

INFO button on the remote control to show its status

information. For CDs and SACDs, the status information is

shown automatically.

2. When the status information is shown, press the PAGE

UP/DOWN buttons to scroll through several different display

formats. The playback time information displayed on the

front panel changes together with the on-screen display.

3. Press the INFO button again to hide the on-screen display.

The playback time information display on the front panel will

remain in the selected format.

The following display formats are available:

DVD and Blu-ray Disc:

- Title elapsed time - Chapter elapsed time

–- Title remaining time – - Chapter remaining time

CD and SACD:

- Track elapsed time - Disc elapsed time

–- Track remaining time – - Disc remaining time

In addition to the playback time, the on-screen display may also contain the following information about

the content currently playing:

xPlayback status: an icon indicating play, pause, and fast forward/reverse status.

xBit rate meter: an indication of the bit rate of the audio and video stream.

xCurrent and total title numbers. (DVD and Blu-ray Discs)

xCurrent and total chapter numbers of the current title. (DVD and Blu-ray Discs)

xCurrent and total tracks. (CDs and SACDs)

xAudio information: current and total available number of audio tracks, language, format, and

channels.

xSubtitle information: current and total available number of subtitle tracks and language.

Video format information: encoding type, frame rate and original aspect ratio.

Volume Control

VOL - VOL +

1. On the BDP-103, the volume control only affects the analog

audio output. It does not apply to digital audio output (HDMI,

Coaxial and Optical) either in bitstream format or in LPCM

format.

2. The VOL +/- buttons on the player remote control are

provided as an alternative way of controlling the audio

volume. It is recommended that you use this control to make

the audio volume from the player the same as from other

sources, such as TV programs or a VCR.

xPress the VOL – button to decrease the volume.

xPress the VOL + button to increase the volume.

DVD-A

SACD

DVD-A

SACD

HDMI output information: connection status, video resolution, frame rate, color space, audio

format and channels.

BASIC OPERATIONS

Mute

MUTE

1. Press the MUTE button on the remote control during

content playback to turn off audio output. The TV screen

displays a mute icon. The front panel MUTE indicator will

also light up.

2. Press the MUTE button again to resume audio output.

NOTE

Check the MUTE status on the front panel display of the player when there is no audio output. You

may also press the MUTE button to verify the MUTE status.

Audio Language/Track Selection

AUDIO

1. To select the audio language or track, press the AUDIO button on

the remote control during playback.

2. Repeat pressing the AUDIO button or use the UP/DOWN

ARROW buttons to choose from all available language or audio

tracks.

NOTE

Availability of languages and audio channels varies by disc. Some DVD-Audio discs allow audio

track selection with the AUDIO button, while others require the user to choose from the audio setup

menu of the disc. When playing an SACD with both multi-channel and stereo contents, the AUDIO

button can be used to switch between the two formats.

DVD-A

SACD

DVD-A

SACD

Subtitle Selection

SUBTITLE

1. When playing a DVD, Blu-ray Disc or other video programs

recorded with subtitles, press the SUBTITLE button on the

remote control to select the desired subtitle.

2. Repeatedly press the SUBTITLE button or use the UP/DOWN

ARROW buttons to choose from all available subtitles.

3. To turn off subtitles, select Off from the list.

BASIC OPERATIONS

HDMI / MHL INPUT Selection

1. When sending external media sources to the BDP-103

through the front and back HDMI IN ports, press the INPUT

button on the remote to bring the “Input Source” menu.

2. Use the UP/DOWN ARROW buttons to choose the required

HDMI input port.

3. You can always select the BLU-RAY PLAYER to return to

OPPO HOME menu.

NOTE

The front HDMI IN port is MHL (Mobile High-definition Link) compatible. Please refer to page 18 for

more details. A dedicated MHL cable or adapter is required (not included) and some

configuration may be required on the mobile device.

Audio Return Channel (ARC) Selection

1. When sending a digital audio signal from the TV back to the

BDP-103 through an HDMI connection, press the INPUT

button on the remote to bring the Input Source menu.

2. Use the UP/DOWN ARROW buttons to choose the required

ARC channel.

3. You can always select BLU-RAY PLAYER to return to OPPO

HOME menu.

NOTE

Audio Return Channel (ARC) is a feature introduced in HDMI v1.4, which allows you to send

digital audio signals from the television back to the player or receiver. Instead of listening

through TV speakers, ARC allows the sound to be processed and produced by the home

theater audio system.

A HDMI 1.4 cable is required (included) and you need to make sure the HDMI input port on

the TV is ARC capable. Usually, ARC has to be enabled in the TV’s settings.

BASIC OPERATIONS

BD-Live

Some Blu-ray Disc titles are released with the BD-Live feature. BD-Live offers extra

downloadable content and additional online interactive programs. BD-Live content varies by

disc and studio, and may include additional subtitles, commentaries, preview trailers, games,

and online chat. A Broadband internet connection is required to enjoy BD-Live content (see page 19).

Depending on how the studios organize their BD-Live content, some Blu-ray Discs may start downloading BD-

Live content when playback starts, have a BD-Live selection on the main menu, show a prompt asking whether

you would like to start downloading, or ask you to sign up for a membership or account. Please follow the

instructions that come with the disc to enjoy BD-Live contents.

Your Internet connection speed and the capacity of the BD-Live content servers can all affect how fast BD-Live

content is downloaded. If you encounter slow downloading or intermittent playback, please play the disc without

accessing the BD-Live features, or try again at a different time.

When you use the BD-Live feature, the player or disc ID and your IP (Internet Protocol) address may be sent to

the content provider via the Internet. Generally, no personally identifiable information is sent. However

technologies exist to match your IP address to a certain geographical area or service provider. Your Internet

service provider also has the knowledge of who is using a particular IP address. If the BD-Live content provider

requires you to log in using a membership or account, the content provider will have access to your

membership or account information. Check with your Internet service provider and the BD-Live content

providers for their privacy policy.

You can choose to restrict BD-Live Network Access in the Setup Menu (details on page 76).

ADVANCED OPERATIONS

Output Resolution

RESOLUTION

The BDP-103 supports multiple output resolutions. For a detailed

discussion on how to choose the best output resolution, please

refer to the Select the Best Output Resolution section on page

22 of this manual.

If you would like to change the output resolution, you may do so by

pressing the RESOLUTION button on the remote.

1. Make sure the HDMI cable is properly connected.

2. Turn on the TV and adjust the TV to use its HDMI input port.

3. Make sure that the player is turned on. Although the output resolution can be changed while a disc is

playing, it is recommended that you stop playback and take out the disc before changing the output

resolution. Press the RESOLUTION button. The Resolution Menu appears on the TV screen. If the

TV does not support the current resolution and you cannot see the Resolution Menu, the current

resolution is also displayed on the player’s front panel.

4. Use the UP/DOWN ARROW buttons to select the new output resolution. You may also press the

RESOLUTION button multiple times to cycle through the available output resolutions.

5. Press the ENTER button to apply the selected output resolution. If you do not want to change the

output resolution, press the RETURN button to exit and return.

The following output resolutions are available:

NTSC output:

4Kx2K Auto 1080p(60Hz/24Hz) 1080i 60Hz 720p 60Hz 480p 480i Source Direct

PAL output:

4Kx2K Auto 1080p(50Hz/24Hz) 1080i 50Hz 720p 50Hz 576p 576i Source Direct

NOTE

xSome TV sets may not support one or more output resolutions. If an incompatible output

resolution is selected, you will get a blank screen or an error message. If this occurs, please

select an output resolution that is supported by the TV.

xIf you cannot get a picture using HDMI, please remove the HDMI cable and connect the

player’s DIAG (diagnostic) output to the TV using a regular composite video cable, and then

use the Setup Menu to adjust the player settings.

xDue to the “Analog Sunset” provision, as of January 1, 2011 all Blu-ray Disc players made

and sold going forward will not be able to pass high definition video (720p, 1080i, or 1080p)

via Component Video outputs. Because of this, we have removed the Component and

ADVANCED OPERATIONS

Composite video outputs on the BDP-103, and only kept a standard definition DIAG video

output for troubleshooting purposes.

Zooming and Aspect Ratio Control

ZOOM

This feature zooms in and out of the displayed frame and also

changes the aspect ratio (image width vs. height).

To change the zoom level, press the ZOOM button on the remote

control. Each press of the ZOOM button will switch the zoom level in

sequence.

Zoom Levels for HDMI Output

The available zoom levels depend on the TV Aspect Ratio setting in the Setup Menu and the encoded

aspect ratio on the BD/DVD Disc:

1:1 (No zoom), Stretch/Compress, Full Screen, Under Scan, 1.2X, 1.3X, 1.5X, 2X, 1/2X

The zoom level is reset to 1:1 when the disc is ejected, or when the player is turned off.

The following zoom levels may be useful for specific applications:

1) Playing 16:9 BD or DVD when TV Aspect Ratio is set to 16:9 Wide or 16:9 Wide/Auto

xStretch – The image is vertically stretched 1.33 times. For movies with 2.35:1 aspect ratio, this zoom

level cuts off the black borders at the top and bottom of the image. Users of a projector with an

anamorphic lens may find this mode helpful.

Original 2.35:1

Widescreen Movie

“Stretch” Zoom Projected through

an Anamorphic Lens

xFull Screen – The image is stretched by 1.33 times for both vertical and horizontal directions. For

movies with 2.35:1 aspect ratio, this zoom level cuts off the black borders at the top and bottom of the

image while maintaining the correct aspect ratio. The left/right sides of the image are slightly cropped.

Original 2.35:1 Widescreen Movie “Full Screen” Zoom

ADVANCED OPERATIONS

2) Playing 4:3 BD or DVD when TV Aspect Ratio is set to 16:9 Wide

x1:1 – The image fills up the entire 16:9 screen but is horizontally stretched. Figures may look shorter

and wider than they should be.

xCompress – The player maintains the correct 4:3 aspect ratio and adds borders to the left and right

sides of the image.

xFull Screen – This zoom level maintains the correct aspect ratio but crops the top and bottom slightly

in order to fit the 4:3 image to the 16:9 screen.

mooZ”neercSlluF“mooZ”sserpmoC“1:1

3) Playing 4:3 BD or DVD when TV Aspect Ratio is set to 16:9 Wide/Auto

x1:1 – The player maintains the correct 4:3 aspect ratio and adds borders to the left and right sides of

the image.

xStretch – The image is horizontally stretched 1.33 times. This zoom level fills up the 16:9 screen, but

figures may look shorter and wider than they should be.

xFull Screen – This zoom level maintains the correct aspect ratio but crops the top and bottom slightly

in order to fit the 4:3 image to the 16:9 screen.

mooZ”neercSlluF“mooZ”hctertS“1:1

The “Under Scan” zoom level shrinks the image by 5%. This zoom level may be used to compensate for

TVs that over scan, so the viewer can see the entire image area with no cropping. All other zoom levels

are indicated by their respective zoom ratio.

NOTE

xSome early DVD titles (released from 1997 until early 2000’s) use a 4:3 non-anamorphic

widescreen aspect ratio. When played on a 16:9 display, the content is shown in a small window

with black borders on all four sides. The top and bottom borders are encoded into the video. The

left and right borders are added by the player to maintain the correct aspect ratio. For these types

of discs, the Full Screen zoom mode can be used to eliminate the borders.

xThe ZOOM feature may not be available when certain DVD or Blu-ray Discs are played if the

disc’s author has chosen to disable ZOOM.

ADVANCED OPERATIONS

Subtitle Shift

SUBTITLE

For customers using a 2.35:1 “Constant Image Height” video

projection system, subtitles may get cut off because they are

positioned outside of the active video area.

The Subtitle Shift feature can be used to shift subtitles up or down so

they are displayed within the active video area.

To shift the display position of subtitles, please follow these steps:

1. When playing a DVD, Blu-ray Disc or other video programs recorded with subtitles, select the desired

subtitle from the disc menu or by using the remote. (Refer to page 28 for more information.)

2. Press and hold the SUBTITLE button on the remote control until the Shift Subtitle Position prompt

appears on the screen.

3. Wait until subtitle text is shown on the screen, and then use the UP/DOWN ARROW buttons to move

the subtitle text to the desired position.

4. Press the ENTER button to set the subtitle display position.

Once the Subtitle Shift position is set, it is saved by the player in the Video Setup > Display Options >

Subtitle Shift setup menu option. The setting will be applied to subtitles of all future DVD and Blu-ray

Discs. You can also change the setup menu item directly. Refer to the Video Setup section beginning on

page 53 for more information.

Repeat Playback

REPEAT

To repeat a certain chapter, title, track or disc, press the REPEAT button

on the remote control.

Each press of the REPEAT button changes the repeat mode using the

following sequence:

DVD and DVD-Audio:

Repeat Chapter Repeat Title Repeat OffRepeat All

Blu-ray Disc:

Repeat Chapter Repeat Title Repeat Off

CD and SACD:

Repeat One Repeat All Repeat Off

NOTE

Certain Blu-ray Discs may not allow for repeating.

DVD-A

SACD

ADVANCED OPERATIONS

Repeat a Selected Section

AB REPLAY

To repeatedly play a specific section, please follow these steps:

1. During normal playback, press the AB REPLAY button on

the remote at the desired beginning point (Point A) for the

repeat play. The TV screen displays “A-”.

2. When playback reaches the desired ending point (Point B)

for the repeat play, press the AB REPLAY button again.

The player now repeatedly plays back the specified section

(A-B). The TV screen displays “A-B”.

3. Press the AB REPLAY button for the third time to resume normal playback.

NOTE

Not available for all disc formats or content. Certain Blu-ray Discs may not allow for repeating.

Shuffle and Random Playback

BLUE

When playing a CD or SACD, press the BLUE button on the remote

control to activate the Shuffle and Random modes. Each press of the

BLUE button switches the playback mode in the following sequence:

Shuffle Random Normal

In normal playback mode, each track is played back in sequential order. As the name implies, the

Random playback mode randomly selects a track to play. The Shuffle mode also plays back the tracks

in random order, but it ensures that each track is played only once.

Selecting the Shuffle or Random mode cancels any Repeat mode you may be using. Similarly,

selecting a Repeat mode cancels any Shuffle or Random mode.

Playback by Chapter or Track Number

NUMBER

BUTTONS

During the playback of a disc, you can use the NUMBER buttons on

the remote control to directly jump to a specified chapter or track

number. For example:

xTo select the seventh track, press the [7] button.

xTo select the 16th track, press [1] followed by [6] in quick

succession:

NOTE

xCertain DVD-Audio and Blu-ray Discs may not allow for direct chapter selection.

DVD-A

SACD

DVD-A

SACD

ADVANCED OPERATIONS

Playback from a Specific Location

DVD and Blu-ray Discs

During the playback of a DVD or Blu-ray Disc, you may specify a

location to start playback by entering the title, chapter or time

directly. Press the GOTO button to bring up the on-screen display.

1 / 7 5 / 25 00:22:14 00:40:06

On top of the video screen, the on-screen display information has

the following components (from left to right): Playing Status, Title,

Chapter, Time Counter, Progress Indicator, and Total Time. After

pressing the GOTO button for the first time, the cursor will be

positioned at the Time Counter. This is the Time Search mode.

Each subsequent press of the GOTO button will switch the search

mode in the following sequence:

(Title or Chapter) Time Search Chapter Search

Title Search

On-Screen Display

1. Title time search. Searches for a specific time within the currently playing title.

xPress the GOTO button to bring up the on-screen display. The cursor will be positioned at the

Time Counter. Use the NUMBER or ARROW buttons to enter the hours, minutes and seconds for

your specific search and press the ENTER button.

1 / 7 5 / 25 00:22:14 00:40:06

2. Chapter time search. Searches for a specific time within the currently playing chapter.

xPress the INFO button to bring up the on-screen display. Use the PAGE UP or PAGE DOWN

button to switch the display to Chapter Time mode (note the icon placed on the left of the Time

Counter changes from the Title icon to the Chapter icon). Press the GOTO button to position the

cursor at the Time Counter, then use the NUMBER or ARROW buttons to enter the hours,

minutes and seconds for your specified search and press the ENTER button.

1 / 7 5 / 25 00:06:48 00:08:33

3. Chapter search. Allows you to search for a particular chapter.

xRepeatedly press the GOTO button until the cursor is positioned at the Chapter location. Use the

NUMBER or ARROW buttons to enter or select the chapter number and press the ENTER button.

1 / 7 5 / 25 00:22:14 00:40:06

4. Title search. Allows you to search for a particular title.

xRepeatedly press the GOTO button until the cursor is positioned at the Title location. Use the

NUMBER or ARROW buttons to enter or select the title number and press the ENTER button.

DVD-A

SACD

1 / 7 5 / 25 00:22:14 00:40:06

ADVANCED OPERATIONS

NOTE

xSome discs may prohibit the search operation. You will not be able to select a search location,

or you may get an “invalid operation” icon after specifying a search location.

xSome Blu-ray Discs feature their own search function. Follow the on-screen instructions to use

the search function provided by such discs.

CD and SACD discs

You may specify a point to start playback by entering the disc elapsed time, track elapsed time or track

number directly. When playing CDs and SACDs, the on-screen display automatically shows on the TV

screen:

1 / 8 00:08:16 00:12:33

The on-screen display has the following components (from left to right): Playing Status, Track Number,

Time Counter, Progress Indicator, and Total Time.

To specify a playback location using one of the following search modes, press the GOTO button. Each

press of the GOTO button switches the search mode in the following sequence:

(Track or Disc)Time Search Track Search

On-screen Display

1. Track time search. Searches for a specific time within the currently playing track.

xPress the GOTO button to place the cursor on the track Time Counter. Use the NUMBER or

ARROW buttons to enter the hours, minutes and seconds for your specified search and press the

ENTER button.

33:21:008/1 00:08:16

2. Disc time search. Navigates you to a particular timestamp.

xWhile the on-screen display is shown, press the PAGE UP or PAGE DOWN button to switch the

Time Counter to Disc Time mode. Press the GOTO button to place the cursor at the Disc Time

Counter. Use the NUMBER or ARROW buttons to enter the hours, minutes and seconds for your

specified search and press the ENTER button.

33:20:108/5 00:40:46

3. Select a track. To navigate to a particular track:

xRepeatedly press the GOTO button until the cursor is placed on the Track Number position. Use

the NUMBER or ARROW buttons to enter or select the track number and press the ENTER button.

00:12:3300:08:161 / 8

ADVANCED OPERATIONS

Memory and Automatic Resume

POWER OPEN

PLAYSTOP

1. The player automatically saves the current position when playback

is interrupted. Operations such as OPEN and POWER cause the

player to save the current playing position.

2. This position is saved even after turning off the unit or changing

the disc.

3. The next time a disc with a saved playing position is inserted, the

player will resume playback from that point. If you wish to cancel

the automatic resume and start playback from the beginning, you

must press the STOP button when prompted.

4. The player can save the playback position for up to 5 discs. When

the position from the sixth disc is saved, the oldest saved position

is replaced.

NOTE

Some Blu-ray Discs do not support resuming and will always play from the beginning.

Viewing Pictures on DVD-Audio Discs

PAGE

UP/DOWN

Some DVD-Audio discs contain static pictures, such as photos of the

band as well as album narration. When a DVD-Audio track is playing,

you may use the PAGE UP button to select the previous picture or the

PAGE DOWN button to select the next picture.

NOTE

Availability of static pictures depends on the DVD-Audio disc.

Pure Audio Mode

You can enjoy higher quality audio by turning off the video processing and

output. The Pure Audio mode reduces any potential interference between

the video and audio signals.

1. Press the PURE AUDIO button on the remote control to turn off

video and enter Pure Audio mode. Video output will cease, the

power light will dim and the front panel displays will turn off.

2. Press the PURE AUDIO button again to resume video and

cancel Pure Audio mode.

NOTE

Pure Audio mode is automatically canceled when the unit is switched off or when playback is

stopped.

DVD-A

SACD

DVD-A

SACD

ADVANCED OPERATIONS

turned off. A black screen is transmitted instead to minimize any potential interference.

Because HDMI carries audio together with video, the HDMI video signal cannot be completely

MEDIA FILE PLAYBACK

In addition to playing standard disc-based formats such as Blu-ray, DVD, CD and SACD, the BDP-103

can play media files. You can enjoy digital music, movies and photos stored on a data disc (recordable

CD, DVD or Blu-ray) or an external USB drive. Due to the variation of media, encoding software and

techniques used, compatibility cannot be guaranteed for all user-created or downloaded content.

Support for such content is on a best effort basis.

Playback from USB Flash Drive

USB

Device

USB

Device

The BDP-103 is equipped with three USB ports: one on the front panel and two on the back. You may use any

of the available USB ports to plug in a USB drive.

The USB ports are rated to provide a maximum of 5V, 1000mA power to the USB drive. It is sufficient for USB

thumb drives and flash memory card readers, but may not be sufficient for USB hard disks. It is recommended

to check with your drive manufacturer for power requirements, or use an external power supply.

NOTE

xThis unit supports “USB Mass Storage Class Bulk-Only Transport” devices only. Most USB

thumbs drives, portable hard disk drives and card readers conform to this device class. Other

USB devices such as MP3 players, digital cameras, and mobile phones may not be compatible.

xSupported USB drives can be formatted with the FAT (File Allocation Table), FAT32 or NTFS

(New Technology File System) file system.

xIn some cases, an incompatible USB device may cause the player to stop responding. If this

occurs, simply turn off the power, remove the USB device, and turn the player back on.

xThe player accesses the USB drive in read-only mode. In order to minimize the risk of data

corruption, it is recommended that you only unplug the USB device when playback is

completely stopped.

MEDIA FILE PLAYBACK

In-home Network Media Sharing

ᵯᵯᵯ

(Network Attached Storage) and install and configure software which is functionally equivalent to DLNA or

SMB/CIFS (a network file sharing protocol) client. Set the My Network selection to On in the Setup Menu

(details on page 76), press the HOME button on the remote to bring the Home Menu, select the Network

icon and press ENTER button to show the list of available servers. In some case, you might need to

disable the firewall on the hardware to allow BDP-103 to see the server.

The BDP-103 player can perform network sharing in one of the following three ways:

As a digital media player (DMP): the player can actively search, access and pull content from

local media servers which is functionally equivalent to DLNA.

As a digital media renderer (DMR): the player plays content received (“pushed”) from a digital

media controller (DMC). A DMC-capable media server is required. Refer to the server’s

respective user instructions for correct configuration and operation.

Accessing a SMB/CIFS client: the player can directly access files shared through SMB/CIFS

clients over the network, as if accessing an external USB hard drive. Most computers, especially

those installed with Windows, already have an SMB client embedded. Please refer to respective

OS instructions to set up the SMB/CIFS shared file/folder.

NOTE

NAS is a networked appliance that provides file-based data storage services to other devices

on the network. Commercial products are available on the market.

SMB (Server Message Block) or CIFS (Common Internet File System) is mostly known as

Microsoft Windows Network. It does not require an extra media server or perform any media

format transcoding, which reduces the processing load and keeps the original content quality.

Compatibility with local network sharing hardware/software is on a best effort basis with no

guarantee, due to variations in NAS devices, media servers and their configurations.

The BDP-103 can remotely play back music, photo, and video files stored on media devices that are

connected to the same home network. You will need to prepare hardware such as a computer or NAS

MEDIA FILE PLAYBACK

Internet Streaming on HOME Menu

The BDP-103 presents a Home Menu to assist you in navigating and playing media files from an inserted

optical disc, USB flash drive, external hard drive, home network sharing and internet streaming. Basically, the

Home Menu is the starting point for accessing media files.

HOME

You can bring up the Home Menu with the HOME button on the remote control. Currently there are fourteen

selections:

Disc enables the player to start playback of an inserted optical disc.

Music,Movie and Photo allow you to access corresponding type of media files from a

connected USB drive and inserted data disc.

Network enables the player to stream audio, video and photos from media servers on the home

network. Capable hardware and software may be required.

Setup brings the player’s Setup Menu, just like pressing the SETUP button on the remote.

Netflix connects you to your Netflix account and provides online movie streaming capabilities.

VUDU connects you to your VUDU HD Movies account and provides online movie and TV Show

rental, purchasing and streaming capabilities.

Film Fresh connects you to your Film Fresh account and provides online movie and TV Show

rental, purchasing and streaming capabilities.

YouTube provides an uninterrupted stream of HD videos from YouTube as though you were

watching a normal television channel.

Pandora connects you to your Pandora account and provides personalized internet radio

services.

Picasa connects you to your Picasa account and provides online photo viewing and sharing

capabilities.

CinemaNow connects you to your CinemaNow account and provides online movie and TV

episode rental, purchasing and streaming capabilities.

Rhapsody connects you to your Rhapsody account and provides personalized internet music

services.

ᶄᶪᶯᶦᶮᶢᶏᶰᶸᶑᶪᶤᶢᶴᶢ

ᶑᶩᶰᶵᶰ ᶏᶦᶵᶸᶰᶳᶬ ᶔᶦᶵᶶᶱᶎᶰᶷᶪᶦ

ᶓᶩᶢᶱᶴᶰᶥᶺ

MEDIA FILE PLAYBACK

NOTE

The Network feature is not officially supported due to the variation in hardware and

software configurations. OPPO does not offer technical support via email or phone for this

feature. The OPPO Wiki located at wiki.oppodigital.com can be a useful resource to learn

about this feature.

Playing Music Files

To play digital music files stored on an optical

disc or USB drive, select Music from the Home

Menu. A file browser will appear to assist you in

navigating the files and folders.

The first step is to select the Data Disc or USB

device that contains the music files. The player

will take a moment to read the media and list the

folders and music files.

In the music browser, you can perform the

following operations:

Press the UP/DOWN ARROW or PAGE

UP/DOWN buttons to move the cursor and

select music files.

Press the OPTION button to gain access

to features such as music information.

Details can be found on page 24.

Press the TOP MENU button to move the cursor to the category menu in the top of the screen. This

menu contains the following choices:

oSource – Allows you to switch between different connected storage devices.

oView – Allows you to switch between List View and Folder View modes.

oSort – Lists music files/folders by different categories, such as Song name, Artist, Album and

Genre.

When a music file is highlighted by the cursor, press the ENTER or PLAY button to start playback.

Different internet streaming applications may have different function mappings on the

BDP-103 remote control. To exit Netflix, YouTube or Rhapsody, press HOME button. To

exit VUDU, Film Fresh or Picasa, either press HOME button or repeatedly press RETURN

button until the Home Menu appears. To exit Pandora, either press HOME button or select

Exit Pandora in Pandora’s Menu selection. To exit CinemaNow, either press HOME

button or select Exit in CinemaNow’s Menu selection. Please contact OPPO customer

support if you need assistance.

MEDIA FILE PLAYBACK

NOTE

When a data disc or USB drive is inserted, the player automatically starts to index files and

build a database in the background. Depending on the number and size of files, this process

could take up to several minutes. Customers can only access the Category list (Artist, Album

and Genre) when the database has been built, otherwise, a warning message will appear.

If a music file starts playing and there is no other user operation, the Now Playing screen will appear

after a few seconds. You can also get to this screen by pressing the OPTION button and then selecting

Now Playing. This screen provides the following information:

Shows playback status: Play, Pause, Track and Time.

Display and change playback mode: Shuffle/Random, Repeat One/All.

Music information: Displays information like album art and tags, either embedded in the original

file or found online from the Gracenote database.

The following operations are available while

the Now Playing screen is shown:

Normal playback control: PLAY,STOP,

PAUSE,PREV/NEXT,REV,andFWD

Special playback modes: REPEAT and

Shuffle/Random (BLUE color button)

Press the OPTION button to access the

Option menu. (More details on page 24)

Return to the Browser without stopping

the music: RETURN

Stop playback and return to the

Browser: Press STOP

MEDIA FILE PLAYBACK

Playing Movie Files

To play movie files stored on an optical disc or USB

drive, select Movie from the Home Menu.Afile

browser will appear to assist you in navigating through

the files and folders.

The first step is to select the Data Disc or USB device

that contains the movie files. The player will take a

moment to read the media and list the folders and

movie files.

In the movie browser, you can perform the following

operations:

Press the UP/DOWN ARROW or PAGE

UP/DOWN buttons to move the cursor and

select movie files.

Press the OPTION button to access

features like video information. Details can

be found on page 24.

Press the TOP MENU button to move the

cursor to the category menu in the top of

the screen. This menu functions the same

as the one discussed in Playing Music

Files on page 43.

When a movie file is highlighted by the cursor, press the ENTER or PLAY buttons to start

playback.

Once a movie file starts playing, the normal playback control functions are available:

To stop the movie and return to the file browser, press the STOP button. You can also press

the HOME button at any time to stop the playback and return to the Home Menu.

Press the OPTION button to access features such as Video Information, Subtitle Shift,

Picture Adjustment and Picture Zooming. Details can be found on page 24.

MEDIA FILE PLAYBACK

Viewing Photo Files

To view digital photo files stored on an optical

disc or USB drive, select Photo from the Home

Menu. A file browser will appear to assist you in

navigate the files and folders.

The first step is to select the Data Disc or USB

device that contains the photo files. The player

will take a moment to read the media and list

the folders and photo files.

In the photo browser, you can perform the

following operations:

Press the UP/DOWN ARROW or PAGE

UP/DOWN buttons to move the cursor and

select photo files.

Press the TOP MENU button to move the

cursor to the category menu in the top of

the screen.

When a photo file is highlighted by the cursor, press the ENTER or PLAY button to play back

the photos as a full screen slideshow.

The following operations are available during the photo slideshow:

Display the help screen: INFO

Normal playback controls: PLAY,STOP,PAUSE, and PREV/NEXT

Adjust slideshow speed: REV and FWD

Zoom: ZOOM. Once zoomed in, the ARROW buttons can be used to pan around the photo.

Reflect (flips the photo horizontally to make it upside-down): UP ARROW

Mirror (flips the photo vertically to make it a mirror image): DOWN ARROW

Rotate left (counterclockwise): LEFT ARROW

Rotate right (clockwise):RIGHT ARROW

Switch between view modes: Red color button

Repeat: REPEAT

Show EXIF information: GREEN color button

Play in random sequence: BLUE color button

Change slideshow transition effect: YELLOW color button.

Press the OPTION button to access to features like Image Zooming and Image Rotation.

Details can be found on page 24.

MEDIA FILE PLAYBACK

Adding Background Music

You can also add background music to the photo slideshow. To do so, you will need to prepare digital music

files. The music files can be stored on the same disk as the photos, or on a different USB drive. Start music

playback first by selecting Music from the Home Menu. Once the music is playing, press the HOME button to

get back to the Home Menu, and start the photo slideshow by selecting Photo in the usual manner.

SETUP MENU OPTIONS

The Setup Menu of the BPD-103 presents many setup and configuration options. For most users, the

default configuration will be sufficient and you will not require any changes to the settings. However, if

you need to configure the player to perfectly match your home theater setup and viewing preferences,

please refer to the following sections for details about each configuration option.

Using the Setup Menu System

Like many other sections listed in this guide, the player’s Setup Menu allowsyoutomakeadjustmentsto

match your specific audio/video configuration. When performing menu adjustments, we will use the following

terminology to indicate the location of the desired function:

Setup Menu Section > Menu Item > Selection

Setup Menu Section is the uppermost Setup Menu level. Within the BDP-103, there are six Setup Menu

sections listed in the left column of the Setup Menu:Playback Setup, Video Setup, Audio Format Setup,

Audio Processing, Device Setup, and Network Setup.

Menu Item is the parameter to be adjusted which appears in the center column of the Setup Menu.Onceyou

enter a Setup MenuSection,the list of Menu Items and their current value are displayed in a box.

Selection is the actual numeric or descriptive element that represents the change being made to the selected

parameter. It is the item located to the right of its corresponding Menu Item.

AScroll Mark appears at the top or bottom of the menu when there are more Menu Items or Selections than

what can fit in a screen. You may use the UP and DOWN ARROW buttons to scroll the display in order to

access additional items.

The preceding diagram should give a good description of the various elements and their context. In this screen

we could, for example, instruct you to set the Auto Play Mode parameter to Off in the Playback Setup section.

To indicate where we were, you would see the following: Playback Setup > Auto Play Mode > Off.

SETUP MENU OPTIONS

NOTE

It is possible that some setup items may be grayed-out and inaccessible. This can be caused

by a disc being played back or having changed a prerequisite setup item. Please stop

playback or eject the disc before trying to change these setup items. If you still cannot access

the setup item, please check for configuration conflicts and consistency. For example, if Video

Setup > 3D Output is set to Off, the 3D Setting menu item will be grayed-out. Setting 3D

Output to On (or Auto) will enable the 3D Setting menu.

To access the player’s Setup Menu simply press the SETUP button on the remote control. Since some Setup

Menu options can become inaccessible when a disc is being played, it is recommended that you operate the

Setup Menu when playback is fully stopped or when there is no disc in the player.

1. Press the SETUP button on the remote control, and the TV screen displays the following:

2. Press the UP/DOWN ARROW buttons to

select the section. Press the ENTER

button or the RIGHT ARROW button to

enter the selected section.

3. Press the UP/DOWN ARROW buttons to

select the setup item to be changed, and

press the ENTER or RIGHT ARROW

button to change the setting. When the

scroll icon is shown at the top or bottom of

the Setup Menu, it indicates that there are

more menu items that can be accessed by

scrolling with the UP/DOWN ARROW

buttons.

For example, in the Playback Setup

section, you may usetheUP/DOWN

ARROW buttons to select the Auto Play

Mode setup item, and press the ENTER

button to change the Auto Play Mode

setting.

SETUP MENU OPTIONS

4. To select a value from the list of available

settings, press the UP/DOWN ARROW

buttons and then press the ENTER button

to confirm.

For example, to select Off for Auto Play

Mode, use the UP/DOWN ARROW

buttons to highlight the Off selection and

press the ENTER button.

5. To exit the Setup Menu at any time, press

the SETUP button on the remote control or

select Exit from the Setup Menu sections.

Settings are permanently saved when the player is turned off using either the front panel power button or

the remote control. If the AC power is interrupted before the player enters standby, the settings will not

be saved. To ensure that the settings are saved, please turn off the player and turn it back on after you

make major changes to the Setup Menu options.

SETUP MENU OPTIONS

Playback Setup

The Playback Setup section is designed to configure playback preferences. The setup items in this section are:

1. SACD Priority: Select which audio layer to play for SACD (Super Audio CD).

Multi-Channel – Play the high resolution multi-channel surround audio layer

Stereo – Play the high resolution 2-channel stereo audio layer

CD Mode – Play the CD layer of a hybrid SACD disc

2. DVD-Audio Mode: Select which portion of a DVD-Audio disc to play.

DVD-Audio – Play the DVD-Audio portion of the disc with high-resolution audio

DVD-Video – Play the DVD-Video portion of the disc with Dolby Digital or DTS audio

3. Auto Play Mode: Select whether the player will start playing an audio CD or SACD

automatically.

On – The disc starts playing upon insertion into the player.

Off – The player waits for the user to start playback by pressing the PLAY button.

4. Auto Resume: Select whether disc playback will start from the previously saved point or not.

This setting applies to CDs, SACDs, DVDs and certain Blu-ray Discs.

On – Playback automatically starts from the previously saved point.

Off – Playback starts from the beginning.

5. Parental Control: Sets parental control ratings in order to prevent minors from watching

inappropriate content. This function depends on whether the disc has been properly rated and

encoded.

Press the ENTER button to bring up the rating selection menu.

Adjust the parental control settings by entering the current parental control password. If you

have not yet set a parental control password, default the password is “0000”.

The Parental Control Menu contains the following sub-items:

BD Ratings – Press the UP/DOWN ARROW buttons to select the rating allowed for Blu-

ray Discs. Off means no ratings control and all discs are allowed to play. Numbers 1 to

21 corresponds to the age limit. Discs encoded with an age limit that is less than the

selected age will be allowed, and any rating equal to or above the selected age will be

blocked.

DVD Ratings – Press the UP/DOWN ARROW buttons to select the rating to allow for

DVDs. The available ratings are Kid, G, PG, PG-13, PGR, R, NC-17, Adult and Off. The

SETUP MENU OPTIONS

selected rating and above will be blocked, and any rating below will be allowed. If Off is

selected, all discs are allowed to play.

Area Code – Some Blu-ray Discs may have different parental control ratings for different

geographical areas. At this time the player only supports parental control ratings used in

the United States.

Change Password – To change the parental control password, enter a 4-digit number

as the new password. Enter the new password again to confirm. If the two entries match,

the new password replaces the old parental control password.

6. Language: Configures language preferences. This menu contains the following sub-items:

Player Language – Allows you to choose the language for the player’s Setup Menu and the

on-screen display. Currently the player supports 9 languages.

Disc Menu Language – Allows you to choose the preferred language for displaying DVD

and Blu-ray Disc menus. If a disc menu of the selected language is available, that menu will

be shown instead of the default disc menu.

Audio Language – Allows you to choose the preferred audio language for DVD and Blu-ray

Discs. If an audio track of the selected language is available on the disc, the audio track will

be played back.

Subtitle Language – Allows you to choose the preferred subtitle language for DVDs. If a

subtitle of the selected language is available, it will be displayed. When Auto is selected, the

subtitle display is determined by the disc.

NOTE

If your preferred language is not listed in the Audio, Subtitle or Disc Menu options, select

“Other” and enter the Language Code found on page 83 of this manual.

SETUP MENU OPTIONS

Video Setup

The Video Setup sectionoftheSetup Menu allows you to configure video output options.

1. Picture Adjustment: Adjusts picture control settings. The BDP-103 provides a wide array of

picture controls. Please refer to the Picture Adjustment section on page 56 for details about

each control.

2. Dual HDMI Output: Allows you to select the output mode when both HDMI Output ports are in

use. If only one HDMI Output is active, this selection will not apply.

Split A/V (recommended) –Use HDMI 1 OUTas the dedicated video output port and

HDMI 2 OUT as the dedicated audio output port. This setting will ensure the best possible

picture quality and the highest possible audio resolution.

Dual Display – Send digital audio and video signals to both HDMI Outputs simultaneously.

This setting is only recommended when two HDMI displays are required, since the surround

sound audio signal may be down-mixed to stereo and the original audio quality may be lost.

NOTE

The player can automatically adjust the resolution of digital audio and video signals depending

on the capabilities of the connected television and receivers.

For HDMI 1 OUT, the dedicated QDEO video processor will be used unless Source Direct is

selected, in which case QDEO is bypassed.

ᵰᶂᶶᶵᶰ

In Split A/V mode, HDMI 1 OUT has video only with no audio, but HDMI 2 OUT will have audio

and possibly video. This is because HDMI embeds audio into video data so there must always

be a video signal, even if it’s only a blank screen, to carry audio through.

3. 3D Output: Allows you to choose the video output mode for 3D content.

Auto – Outputs 3D if supported both by both the disc content and the display. The player

automatically checks for the existence of 3D content on the disc and the 3D compatibility of

the TV or projector. If both criteria are met, the player sends 3D video from its HDMI output

terminals; otherwise, only 2D video is sent out. Active shutter 3D glasses (which are not sold

by OPPO) are required to enjoy the 3D movie on your TV.

Off – Always output 2D video format, even when 3D video exists on the disc. This

guarantees the video quality if your TV is not 3D compatible, or if some necessary

components (such as the 3D glasses) are missing.

Forced – Always output 3D video format for 3D Blu-ray Discs. You may experience a black

screen (no video output) if your TV is not 3D compatible.

SETUP MENU OPTIONS

4. 3D Setting: Adjusts the playback settings for better 3D visual quality.

2D->3D Depth – Adjusts the 3D depth perception when performing 2D-to-3D conversion

(also called “simulated 3D”). The default value is 8.

3D TV Size – Allows you to enter the diagonal screen size of the 3D HDTV. This option

applies to 3D mode only. Use the number buttons on the remote to enter the actual diagonal

size of the TV screen, and then press the ENTER button to confirm. The default value is 46

inches.

5. TV Aspect Ratio: Sets the aspect ratio of the player’s output image.

16:9 Wide – Choose when the display is widescreen 16:9. 16:9 material will be displayed in

its native aspect ratio, and 4:3 materials will be stretched horizontally.

16:9 Wide/Auto – Choose when the display is widescreen 16:9. 16:9 material will be

displayed in its native aspect ratio, and 4:3 materials will be displayed with black borders on

both sides in order to maintain the original 4:3 aspect ratio.

For a detailed description on how to choose a proper TV Aspect Ratio, please refer to the

Determine the Display Aspect Ratio section on page 23 of this manual.

6. TV System: Allows you to choose the output video system or broadcast standard (PAL/NTSC) to

match the type of TV.

NTSC (default) – When playing NTSC-encoded discs, no system conversion is performed.

PAL-encoded content is converted to NTSC output. Blu-ray Discs encoded at a 24Hz frame

rate are converted to a 60Hz frame rate if neither 1080p24 Output nor Source Direct output

resolution is enabled.

PAL – When playing PAL-encoded discs, no system conversion is performed. NTSC-

encoded content is converted to PAL output. Blu-ray Discs encoded with a 24Hz frame rate

are converted to a 50Hz frame rate if neither 1080p24 Output nor Source Direct output

resolution is enabled.

Multi-system – No system conversion is performed. The output video system is the same as

that encoded on the disc. Blu-ray Discs encoded with a 24Hz frame rate are converted to a

60Hz frame rate if neither the 1080p24 Output nor Source Direct output resolution is enabled.

Requires a TV that supports both NTSC and PAL systems.

NOTE

DO NOT select Multi-system if your TV does not support both NTSC and PAL systems. The

TV display may become a black screen when you insert a disc encoded in a different system

than your TV supports. Should this happen, you can press the OPEN button to eject the disc

tray, and then use the Setup Menu to correct the TV System setting.

7. Output Resolution: Allows you to choose the output resolution that best matches your

television’s native resolution. For a detailed description on how to choose a proper output

resolution, please refer to the Select the BestOutput Resolution section on page 22 of this

manual.

8. 1080p24 Output: Allows you to set the 1080p 24Hz output options. This option only applies to

the HDMI output at 1080p resolution. Many Blu-ray Discs of theatrical movies are encoded using

24Hz frame rate, the same number of frames per second as the original theatrical film. If the TV

Blank HDMI 2 (Yes/No) – Allows you to force HDMI 2 OUT to output a blank 2D screen when

HDMI 1 OUT outputs 3D video. During 3D movie playback, when HDMI 1 is connected to a

3D display and HDMI 2 is connected to a non-3D receiver which is in turn connected to the

same 3D display, you may encounter an issue where there is no audio coming from the

receiver. Setting this option to "Yes" can resolve this issue.

SETUP MENU OPTIONS

properly supports 1080p 24Hz, smoother motion can be achieved by enabling 1080p24 Output

for these discs.

xAuto (default) – Video encoded at a 24Hz frame rate will be output as 1080p 24Hz if the TV

informs the player that it can support the 1080p24 signal.

xOn – Video encoded at a 24Hz frame rate will be output as 1080p 24Hz without regard to

whether the TV can support the 1080p24 signal or not. This is useful if the TV can actually

support 1080p24 but does not properly state its capability. Please note that if the TV cannot

support 1080p24, selecting this option will result in no video.

xOff – Video encoded at a 24Hz frame rate will be converted to 60Hz (NTSC) or 50Hz (PAL)

9. DVD 24p Conversion: Allows you to enable 24Hz frame rate conversion for DVD. This option is

only available when 1080p24 Output is enabled (set to Auto or On). Many DVDs that originate

from theatrical movies are encoded with a technique called “3:2 telecine” in order to convert the

24 frames per second film to 60Hz video signal. The player can convert the 60Hz video signal

back to 24 frames per second film and output as 1080P/24Hz. Smoother motion may be

achieved by enabling this option, if both the TV and the DVD disc meet the conversion conditions.

The available options are:

xOn – Converts DVD to 24Hz frame rate when possible. Remember that motion errors may

be observed if the DVD is not suitable for such conversion.

xOff (default) – Does not convert DVD to 24Hz frame rate.

10. HDMI Options: Configures video options that apply only to the HDMI output. This item contains

a sub-menu with multiple configuration options. Please refer to the HDMI Options section on

page 59 of this manual for details of each option.

11. Display Options: Configures the options for displaying on-screen information.

xSubtitle Shift – Sets the display position for subtitles.

When the Subtitle Shift is set at 0 (default), subtitles are displayed at the original position as

specified on the disc. When it is set at a value between 1 and 5, subtitles are shifted up.

When it is set at a value between -1 and -5, subtitles are shifted down.

This feature is helpful for customers using a 2.35:1 “Constant Image Height” video projection

system. Subtitles can be shifted to the active video area so they do not get cut off. You can

also press and hold the SUBTITLE button for 3 seconds to activate this selection.

xOSD Position – Allows you to set the display position for the on-screen display (OSD).

When the OSD Position is set to 0, the OSD is shown at the top and bottom of the video

screen. When it is set at a value between 1 and 5, the OSD is shifted towards the centre of

the video screen.

Similar to the subtitle shift setting above, the OSD Position feature is helpful for customers

using a 2.35:1 “Constant Image Height” video projection system.

xOSD Mode – Allows you to select how long the on-screen display (OSD) information, such

as playback operation icons (PAUSE,STOP,SKIP, etc.), stays on the TV screen.

Normal – OSD information stays on the TV screen until the user cancels it.

Minimal – OSD information stays on the TV screen for a few seconds and then

disappears. The front panel display still maintains the selected display information.

Remaining –OSD information stays on the TV screen until the user cancels it. By

default, displays remaining time instead of elapsed time.

SETUP MENU OPTIONS

Angle Mark (On/Off) – Turns on/off the display of the angle icon when a DVD or Blu-ray

Disc with multiple angles is played. Keeping the angle mark off avoids distraction from

normal movie watching.

Screen Saver – Allows you to turn on/off the screen saver function. The screen saver is

designed to minimize burn-in concerns for plasma and CRT display devices.

On (recommended) –After about 3 minutes of inactivity, the player will show an

animated OPPO logo moving on a black background. This allows most areas of the

screen time to rest and gives all areas an equal opportunity to refresh.

Off – The screen saver will not be activated. Only use this option if your TV does not

have any burn-in issues.

Energy Saver – Video output will be turned off after 3 minutes of inactivity. Many

projectors and LCD TVs will go into a standby or sleep mode and turn off their projection

lamp or LCD backlight lamp, thus saving energy and prolonging the lamp life. When you

press any button on the OPPO remote control or the player’s front panel, the screen

saver will be canceled and video output will be restored. If your TV is already in standby

or sleep mode, you may need to wake up the TV by pressing a button on its remote or

control panel.

Picture Adjustment

Picture Adjustment is a special section of the Video Setup menu. It allows you to fine tune many picture

control parameters in order to achieve optimal picture quality. To enter the Picture Adjustment menu, press

the SETUP button on the remote control to enter the player’s Setup Menu and choose Video Setup > Picture

Adjustment and select the video output to be adjusted:

Use the LEFT/RIGHT ARROW to select the video output, and press the ENTER button to bring up the Picture

Adjustment menu. Depending on the selected video output, the Picture Adjustment menu may be slightly

different:

Picture Adjustment Menu for HDMI 1

Picture Mode Mode 1

Brightness

Contrast

Hue

Saturation

Sharpness

Noise Reduction

Color Enhancement

Contrast Enhancement

Exit

HDMI 1

-16

+16

SETUP MENU OPTIONS

Picture Adjustment Menu for HDMI 2

To change a picture adjustment parameter, use the UP/DOWN ARROW buttons to highlight the

parameter, and use the LEFT/RIGHT ARROW buttons to change its value.

To aid in the adjustment of picture control parameters, the picture adjustment menu will be reduced to

only show the parameter being adjusted once you press the LEFT/RIGHT ARROW buttons (except the

Picture Mode, which you will directly see the mode name switches between Mode 1, 2 and 3, and all the

other parameters are adjusted automatically to the stored value). The reduced menu will be positioned

near the bottom of the screen.

You can continue adjusting the current parameter by pressing the LEFT/RIGHT ARROW buttons. To

select another parameter, press the UP/DOWN ARROW buttons. Press the ENTER button to return to

the main Picture Adjustment menu.

To exit the Picture Adjustment menu and return to the Setup Menu, either select Exit in the menu, or

press the RETURN button.

The following picture adjustment controls are available for both HDMI 1 and 2:

1. Picture Mode: Allows you to choose a customized picture mode saved by you. The BDP-103

allows you to save up to three customized modes. Press the LEFT/RIGHT ARROW buttons to

switch the mode and all parameters will be automatically adjusted to their stored values.

Changes to the current parameter values will be stored automatically when you exit the Picture

Adjustment screen or switch to another Picture Mode.

2. Brightness: Allows you to adjust the brightness (black level) of the video output.

3. Contrast: Allows you to adjust the contrast (white level) of the video output.

NOTE

Proper brightness and contrast settings are necessary for a quality video output. If you do not

have the correct black and white levels, your images can appear washed out or can lose detail

in shadows when watching darker scenes. Televisions have brightness (black level) and

contrast (white level) controls; however, it may require a combination of tweaking both the

player and your television to get the optimal result. We recommend using a calibration disc

such as the Spears & Munsil™ High Definition Benchmark Blu-ray Edition or Digital Video

HDMI 2

Mode 1

Picture Mode

Brightness

Contrast

Hue

Saturation

Sharpness

Noise Reduction

-16

+16

Exit

SETUP MENU OPTIONS

Essentials HD Basics as aids for adjusting. First adjust the television’s picture controls for the

best possible picture. Once that is done, try changing the player’s settings to further refine the

picture to the optimal result.

4. Hue: Allows you to adjust the hue (tint) of the video output.

5. Saturation: Allows you to adjust the saturation (color intensity level) of the video output.

6. Sharpness: Allows you to set the sharpness of video output. Sharpness (also called Detail/Edge

Enhancement in previous OPPO players) is a video processing function that can control the

image sharpness but at the same time may cause unwanted artifacts.

For HDMI 1, the sharpness level can be set between -16 and +16. The default is level 0, which

turns off sharpness enhancement. The negative levels may be used to reduce or eliminate overly

sharpened video. However, the picture may appear soft. The positive levels increase the

sharpness.

At level 1, the player applies low level Detail Enhancement, during which the video

processor isolates the detailed parts from the original image, processes them separately

and integrates back before the final output.

At level 2, the player increases Detail Enhancement to a higher level. Generally, to make an

image “sharper”, we recommend using level 1 and 2.

At level 3 and above, the player adds Luminance Transition Improvement (LTI) and Chroma

Transition Improvement (CTI), which further sharpen the luminance transition and chroma

transition. However, we do not recommend using level 3 and above unless the source

content is poorly produced and blurry.

For HDMI 2 OUT, the sharpness level can be set between 0 and +2. The default is level 0. The

higher the level, the sharper the video details are. However, too high a sharpness level may

cause white lines or halo-like effects to appear around objects.

7. Noise Reduction: Allows you to select whether the player will apply video noise reduction

processing.

For HDMI 1, the noise reduction level can be set between 0 and 8. The default is level 0, which

turns off noise reduction.

When set to level 1, the player adjusts the picture quality by reducing the “mosquito noise”

(artifacts around the outlines of objects) and “block noise” (mosaic-like patterns caused by

video compression). These two noise reduction methods are also called Compression

Artifacts Reduction (CAR) and have several levels of aggressiveness.

When set to level 2, the player applies the Motion Adaptive Video Noise Reduction (VNR),

which handles the random noise and the film-grain noise (natural variation of picture

intensity caused by film grain). Its level is automatic because there is noise estimator

circuitry in the video processor that calculates how much noise is present and adjusts the

level of VNR accordingly.

When set to 3 or 4, the player applies both CAR and Motion Adaptive VNR, with more

aggressive “block noise” reduction at level 4.

At level 5, the player applies aggressive CAR for low quality video content, and adds

Motion Adaptive VNR at level 6.

At level 7, the player applies the most aggressive CAR for very low quality video, and adds

Motion Adaptive VNR at level 8.

SETUP MENU OPTIONS

Remember that excessive noise reduction may cause a loss of details. We recommend using

the noise reduction function only when you encounter poorly encoded or compressed video that

has apparent noise artifacts.

For HDMI 2, the noise reduction level can be set between 0 and +3. The default is level 0. When

this level is increased, the player adjusts the picture quality by applying mosquito noise

reduction, random noise reduction and MPEG block noise reduction at the same time. The

higher the level, the more aggressive noise reduction functions apply.

The following picture adjustment controls are only available for HDMI 1 video output:

8. Color Enhancement: Allows you to adjust the color enhancement level on the video output.

This enhances certain colors in the spectrum and enables vivid colors in outdoor scenes without

causing hue shifts, loss of detail or changes in skin tones.

9. Contrast Enhancement: Allows you to adjust the contrast enhancement level on the video

output. This expands detail in shadows.

HDMI Options

HDMI Options is a sub-menu of the Video Setup menu. It allows you to configure some video settings that are

unique to the HDMI output. To enter this sub-menu, select HDMI Options from the Video Setup menu. To exit

this sub-menu, press the RETURN button or the LEFT ARROW key. The following HDMI options are available:

1. Color Space (HDMI 1) – Allows you to select the color space for the HDMI 1 output. The

available options are:

Auto (recommended) – The player checks with the display device to automatically

determine what color space to use. If the display device supports YCbCr 4:4:4, then it will be

used to avoid extra color space conversion.

RGB Video Level – The HDMI output uses RGB color space and normal signal range

suitable for video displays.

RGB PC Level – The HDMI output uses RGB color space and expands the signal range.

The expanded signal range is suitable for personal computer (PC) displays. Some TVs are

designed to be used as a PC monitor, and expect signal in expanded RGB range when the

DVI input is selected. For these displays if the video signal uses the normal RGB range, the

black-white contrast will be reduced. You can set the player to use the RGB PC Level output

and restore proper contrast.

YCbCr 4:4:4 – The HDMI output uses YCbCr 4:4:4 color space.

YCbCr 4:2:2 – The HDMI output uses YCbCr 4:2:2 color space. Generally this is the color

space that is closest to the color space encoded on the discs. (All discs are encoded in

YCbCr 4:2:0 color space, and the video decoder decodes it into YCbCr 4:2:2.)

2. Color Space (HDMI 2) – Allows you to select the color space for the HDMI 2 output. The

available options are the same as those for Color Space (HDMI 1).

3. Deep Color (HDMI 1) – Allows you to select the Deep Color mode for the HDMI 1 output. Deep

Color is an option for some TVs or projectors that feature HDMI v1.3 or higher input. Normally,

each pixel of the video image is transmitted using 24-bit data (8-bit per channel for R, G, B or Y,

Cb, Cr). If Deep Color is supported, each pixel of the video image can be transmitted using 30-bit

(10-bit per channel) or 36-bit (12-bit per channel) data. The increased bit depth should result in

smoother color transitions and better gradients.

36 Bits – Uses the 36-bit per pixel Deep Color mode.

SETUP MENU OPTIONS

x30 Bits (Dithered) – Uses the 30-bit per pixel Deep Color mode with dithering technique.

x30 Bits – Uses the 30-bit per pixel Deep Color mode.

xOff (Dithered) – Does not use Deep Color, but applies the dithering technique.

xOff (default) – Does not use Deep Color.

4. Deep Color (HDMI 2) – Allows you to select the Deep Color mode for the HDMI 2 output. The

available options are the same as those for HDMI Deep Color (HDMI 1).

NOTE

xSince the Deep Color feature is optional and may not be supported by all TVs, enabling

Deep Color while connected to a TV without this feature may result in no effect or no

video.

xAt this time, no disc is encoded with Deep Color. Enabling Deep Color will not magically

make colors richer, but will help preserve the maximum precision as a result of video

processing and picture control adjustment.

xDithering is a technique to improve the image color depth with limited color quantization.

SETUP MENU OPTIONS

Audio Format Setup

The Audio Format Setup section of the Setup Menu allows you to configure preferences for audio output

formats.

1. Secondary Audio: Allows you to set the Secondary Audio Program mixing option. Some Blu-ray

Discs contain a secondary audio and video program, such as a director’s commentary. Some

Blu-ray Discs have a sound effect when you make menu choices. This Setup Menu item allows

you to decide whether to mix the Secondary Audio Program and menu sounds into the primary

audio.

On – The Secondary Audio Program and menu sounds are mixed into the primary audio.

Usually this will cause the primary audio volume to be slightly reduced.

Off – The Secondary Audio Program and menu sounds are not mixed into the primary audio

and you cannot hear the secondary audio or menu sounds. This setting preserves the

highest possible audio quality for the primary audio.

2. HDMI Audio: Allows you to select the digital audio output format from the HDMI port. The

options are:

Auto (default) – The player checks with the device connecting to the HDMI output to

automatically determine which audio format to use.

LPCM – Digital audio output via HDMI will be in the multi-channel Linear PCM format. When

this option is selected, compressed audio bit streams will be decoded by the player. This

setting is recommended when connecting the HDMI output directly to a TV or to a receiver

without advanced audio decoding capabilities.

Bitstream – Digital audio output via HDMI will be in bitstream format. This option is

recommended when connecting the HDMI output to an A/V receiver or processor that

supports advanced audio decoding, such as Dolby TrueHD and DTS-HD Master Audio.

Off – No digital audio output via HDMI.

NOTE

If you use HDMI to connect audio to an HDMI A/V receiver or audio processor, it is important

that you choose 720p or higher HDMI output resolution when playing high resolution audio

content (DVD-Audio, SACD, Dolby TrueHD and DTS-HD Master Audio). According to the HDMI

specification, the bandwidth available for audio is proportional to the total bandwidth used by

video. At 480p/576p resolution, the HDMI specification can only support 2 channels of audio

with high sample rate (up to 192kHz), or 8 channels of audio with standard sample rate (up to

SETUP MENU OPTIONS

48kHz). If you play high resolution audio content at the 480p/576p resolution, you may get

reduced audio resolution, incomplete audio channels, or even no audio/video output at all.

Choosing a higher output resolution such as 720p or above allows enough bandwidth for all

high sample rate audio channels.

3. Coaxial/Optical Output: Allows you to set the audio format and the upper sample rate limit for

coaxial/optical (S/PDIF) digital outputs. The upper sample rate limit is used to decide whether the

player will down-sample audio (the player does not up-sample audio to higher sample rates).

x48k LPCM – Forces down-mixed 2-channel, linear PCM (LPCM) digital audio format, and sets

the maximum sample rate to 48kHz. This is supported by most receivers/amplifiers.

x96k LPCM – Forces down-mixed 2-channel, linear PCM (LPCM) digital audio format and sets

the maximum sample rate to 96kHz. It can result in better audio quality but ensure the

receiver/amplifier can support it.

x192k LPCM – Forces down-mixed 2-channel, linear PCM (LPCM) digital audio format and sets

the maximum sample rate to 192kHz. It can result in better audio quality but ensure the

receiver/amplifier can support it.

xBitstream – Passes audio as compressed bitstream format to the receiver/amplifier. Choose

this setting if your receiver/amplifier is capable of decoding Dolby Digital and/or DTS.

NOTE

Due to copyright restrictions and bandwidth limitations, SACD audio cannot be sent through the

coaxial/optical audio output, and the high resolution audio on DVD-Audio and Blu-ray discs will

be sent out at reduced resolution. Details can be found on page 17.

4. SACD Output: Allows you to select HDMI the audio output format for SACD playback.

xPCM – SACD data is converted into multi-channel, high-resolution PCM data. The converted

PCM data is then output through HDMI or the internal DAC (Digital to Analog Converter) for the

analog audio output ports. If you use a receiver that supports HDMI v1.1 to listen to SACD,

please select this option. You may also want to select this option if you prefer the sound quality

of the DSD-to-PCM conversion.

xDSD – SACD Direct Stream Digital (DSD) data is output over HDMI without any conversion.

For the analog audio outputs, DSD data is converted into an analog signal directly by the

internal DAC. If you use a receiver that supports HDMI v1.2a with DSD over HDMI, or you

prefer the sound quality of straight DSD to analog, please select this option.

NOTE

Due to the hardware limitation, DSD output is only available from the HDMI 2 OUT port. To listen

to SACD using the HDMI 1 OUT port, please set SACD Output to PCM.

5. HDCD Decoding: Allows you to set the audio decoding option for HDCD (High Definition

Compatible Digital) discs.

xOn – HDCD is decoded by the player. You can enjoy expanded dynamic range and improved

audio resolution.

xOff – HDCD is treated as regular CD. This is useful when the player is connected to an HDCD-

capable A/V receiver via a digital audio output link (Coaxial, Optical, or HDMI) so the A/V

receiver can perform HDCD decoding.

SETUP MENU OPTIONS

NOTE

If your receiver is capable of HDCD decoding, it is recommended that you set the HDCD

Decoding setting to Off on the BDP-103 in order to avoid decoding HDCD twice. This will

prevent the occasional pop or crackle sounds that occur when HDCD is decoded twice.

SETUP MENU OPTIONS

Audio Signal Reference Chart

Blu-ray Discs may contain many types of audio signal formats, some of which are high resolution types such as

Dolby TrueHD and DTS-HD Master Audio. Blu-ray Discs also have many optional audio components such as

the Secondary Audio Program and menu clicking sound. The player’s Audio Format setup menu allows you to

configure the audio output to meet your specific preference. The following chart provides a reference to what

type of audio signal can be expected.

When Secondary Audio is set to Off:

Output Ports tuptuOlacitpO/laixaoC

Analog

Multi-Channel

Output

SettingSource

Format

Bitstream LPCM Bitstream LPCM

LPCM 2ch LPCM 2ch LPCM 2ch LPCM 2ch LPCM 2ch 2ch

LPCM 5.1ch LPCM 5.1ch LPCM 5.1ch LPCM 2ch LPCM 2ch 5.1ch

LPCM 7.1ch LPCM 7.1ch LPCM 7.1ch LPCM 2ch LPCM 2ch 7.1ch

Dolby Digital Dolby Digital LPCM 5.1ch Dolby Digital LPCM 2ch 5.1ch

Dolby Digital

Plus

Dolby Digital

Plus LPCM up to 7.1ch Dolby Digital LPCM 2ch Up to 7.1ch

Dolby TrueHD Dolby TrueHD LPCM up to 192kHz

24-bit 7.1ch Dolby Digital LPCM 2ch Up to 7.1ch

DTS DTS LPCM up to 7.1ch DTS LPCM 2ch Up to 7.1ch

DTS-HD High

Resolution

DTS-HD High

Resolution LPCM up to 7.1ch DTS (core) LPCM 2ch Up to 7.1ch

DTS-HD Master

Audio

DTS-HD

Master Audio

LPCM up to 96kHz

24-bit 7.1ch or 192kHz

24-bit 2ch

DTS (core) LPCM 2ch Up to 7.1ch

When Secondary Audio is set to On and the player encounters a disc with a secondary audio track or menu

sounds:

tuptuOlacitpO/laixaoCtuptuOIMDHstroPtuptuO

Analog

Multi-Channel

Output

SettingSource

Format

Bitstream LPCM Bitstream LPCM

LPCM 2ch LPCM 2ch LPCM 2ch LPCM 2ch LPCM 2ch 2ch

LPCM 5.1ch LPCM 5.1ch LPCM 5.1ch LPCM 2ch LPCM 2ch 5.1ch

LPCM 7.1ch LPCM 7.1ch LPCM 7.1ch LPCM 2ch LPCM 2ch 7.1ch

Dolby Digital Dolby Digital* LPCM up to 5.1ch Dolby Digital* LPCM 2ch 5.1ch

Dolby Digital

Plus Dolby Digital* LPCM up to 7.1ch Dolby Digital* LPCM 2ch Up to 7.1ch

Dolby TrueHD Dolby Digital* LPCM up to 192kHz

24-bit 7.1ch Dolby Digital* LPCM 2ch Up to 7.1ch

DTS DTS* LPCM up to 7.1ch DTS* LPCM 2ch Up to 7.1ch

DTS-HD High

Resolution DTS* LPCM up to 7.1ch DTS* LPCM 2ch Up to 7.1ch

DTS-HD Master

Audio DTS* LPCM up to 7.1ch DTS* LPCM 2ch Up to 7.1ch

Note: All audio output signals are mixed with primary, second audio and menu sounds. “Dolby Digital*” and

“DTS*” denote mixed audio re-encoded into the original bitstream audio format.

HDMI Output

SETUP MENU OPTIONS

Recommended Audio Format Options

Depending on your specific audio/video connection method, the audio format options of the BDP-103 may

need to be adjusted to match your configuration. Refer to the video and audio connection methods described

previously in this guide and the following audio setup guidelines.

Audio Connection Directly to TV

If the player is connected directly to the TV through HDMI (as described on page 13) or through DVI and

analog L/R audio cables (as described on page 15), it is recommended that you use the following audio format

options:

oSecondary Audio: On

oHDMI Audio: LPCM

oSACD Output: PCM

oHDCD Decoding: On

oCoaxial/Optical Output: (any – not in use)

Multi-Channel Digital Audio to Receiver through HDMI

If the player is connected to an A/V receiver or processor with HDMI inputs (as described on page 11), you can

send all current audio formats to your receiver in pure digital form. To get the best possible audio via HDMI, you

may need to set the following options on the player’s Audio Format setup menu:

xIf your receiver supports HDMI v1.3 with decoding capability for high resolution lossless audio

formats such as Dolby TrueHD and DTS-HD Master Audio, please use the following audio format

options:

oSecondary Audio: Off (or On if you need secondary audio)

oHDMI Audio: Bitstream

oSACD Output: PCM (or DSD if the receiver supports DSD over HDMI)

oHDCD Decoding: On (or Off if the receiver can decode HDCD)

oCoaxial/Optical Output: (any – not in use)

xIf your receiver supports HDMI v1.1/1.2 Multi-Channel PCM audio, but not high resolution

lossless audio formats such as Dolby TrueHD and DTS-HD Master Audio, please use the

following audio format options:

oSecondary Audio: Off (or On if you need secondary audio)

oHDMI Audio: LPCM

oSACD Output: PCM (or DSD if the receiver supports DSD over HDMI)

oHDCD Decoding: On (or Off if the receiver can decode HDCD)

oCoaxial/Optical Output: (any – not in use)

Multi-Channel Analog Audio to Receiver

If the player is connected to an A/V receiver through the 7.1ch or 5.1ch analog audio jacks using 8 or 6 RCA

cables (as described on page 16), you can play all supported audio formats and listen to them with your A/V

receiver and surround sound systems. The following audio format setup options are recommended:

oSecondary Audio: Off (or On if you need secondary audio)

oHDMI Audio: Off

oSACD Output: PCM or DSD (depending on your listening preference)

SETUP MENU OPTIONS

oHDCD Decoding: On

oCoaxial/Optical Output: (any – not in use)

Also set the Speaker Configuration in the Audio Processing menu:

xSet Down Mix to 7.1Ch or 5.1Ch.

xSet the speaker size and subwoofer according to your actual audio hardware. (see page 69)

xEnable or select the multi-channel analog inputs on your receiver

Coaxial or Optical Digital Audio to Receiver

If the player is connected to an A/V receiver with Coaxial/Optical inputs (as described on page 17), and the A/V

receiver supports Dolby Digital and DTS decoding, the following audio format setup options are recommended:

oSecondary Audio: Off (or On if you need secondary audio)

oHDMI Audio: Off

oSACD Output: (any – SACD is not available through optical/coaxial

output)

oHDCD Decoding: On (or Off if the receiver can decode HDCD)

oCoaxial/Optical Output: Bitstream

Stereo Analog Audio to Receiver

If you primarily listen to stereo content or if your receiver only offers stereo audio connections, please use the

analog RCA-style cables to connect the FL (Front Left) and FR (Front Right) terminals of the player to your

receiver (as described on page 16). The following audio format options are recommended:

oSecondary Audio: Off (or On if you need secondary audio)

oHDMI Audio: Off

oSACD Output: PCM or DSD (depending on your listening preference)

oHDCD Decoding: On

oCoaxial/Optical Output: (any – setting to 192k LPCM may help to get the best

analog audio quality)

SETUP MENU OPTIONS

Audio Processing Setup

The Audio Processing section of the Setup Menu allows you to configure how the player will process audio

signals before sending them to the output. In this section, all of the settings only affect the analog audio outputs,

except for Dynamic Range Control (DRC), which also affects HDMI audio.

Speaker Configuration

In the Speaker Configuration menu you can configure speaker settings such as down-mix mode,

number of speakers, their distance, size and trim level. The Speaker Configuration menu shows an

illustration of speaker placement to assist you in properly configuring your speakers.

Upon entering this menu, the cursor is positioned on the front left speaker. You may use the

LEFT/RIGHT ARROW buttons to move the cursor. The RIGHT ARROW button moves the cursor

clockwise, and the LEFT ARROW button moves the cursor counterclockwise. When the cursor is over

the Down Mix,Test Tone or Exit options, you can also use the UP/DOWN ARROW buttons to highlight

these options.

NOTE

Speaker Configuration applies to the multi-channel analog audio outputs only. All digital

(bitstream and LPCM) outputs are unaffected by these settings.

ᶅᶰᶸᶯᵡᶎᶪᶹ

ᶕᶦᶴᶵᵡᶕᶰᶯᶦ

ᶆᶹᶪᶵ

SETUP MENU OPTIONS

Down Mix Mode

Downmixing is the process of converting multi-channel audio to a lesser number of channels. For

example, converting a 5.1ch source to stereo or converting a 7.1ch source to 5.1ch. Downmixing allows

the audio output from the player to match the exact number of speakers available in your home theater.

The current down mix mode is displayed in the lower right corner of the speaker placement illustration.

To change the audio down mix setting, press the ENTER button while the cursor is over the Down Mix

option. The following down mix modes are available:

xLT/RT – Left Total/Right Total. The center and surround channels are mixed into the two front

channels according to the LT/RT matrix. A Dolby Pro Logic receiver will decode the two-channel

audio into surround audio.

xStereo – This mode down mixes multi-channel audio to 2-channel stereo output. For original

stereo content the output will not change. For original multi-channel content the surround and

center channels will be mixed with the left and right front channels. This is recommended for use

with TV sets or stereo receiver/amplifiers.

x5.1Ch – This mode enables 5.1ch decoded audio output. The number of actual output channels

depends on the disc. If the source content has more channels, the surround back channels will

be mixed into the surround channels.

x7.1Ch – This mode enables 7.1ch decoded audio output. The number of actual output channels

depends on the disc. For 6.1ch contents, the left and right surround back speakers will both

output the same surround back audio channel.

Test Tone

Test tones are artificially-created sounds that are used to test your audio speaker system and help to identify

any wiring faults. By default the Test Tone is set to Off, with the status displayed in the lower left corner of the

screen.

To begin the test, press the ARROW buttons to highlight the Test Tone option, and press the Enter button to

change the test tone status to On.PresstheARROW buttons to select a speaker, and you will hear the test

sounds. To stop the test process, press the ARROW buttons to highlight the Test Tone option and press the

Enter button to switch the status back to Off. Please note these test tones only apply on multi-channel audio

outputs.

SETUP MENU OPTIONS

Speaker Settings

You can set the size, distance and trim level for each speaker by using the LEFT/RIGHT ARROW

buttons to move the cursor to highlight the speaker and then press the ENTER button. The Speaker

Settings menu on the right side of the screen will be activated. In Speaker Settings, use the UP/DOWN

ARROW buttons to select a parameter, and then press the ENTER button to change it. To exit the

Speaker Settings menu and return to the Speaker Configuration illustration, press the LEFT ARROW

button or select the Exit option. You can also move on to configure the next speaker by selecting the

Next Speaker option.

The following speaker parameters can be configured:

1. Size: The following speaker size parameters control bass filtering for the speakers.

Large – All audio content is passed to the appropriate speaker.

Small – All audio content, except for bass frequencies, is passed to the appropriate speaker.

The purpose is to reduce possible distortion. If a subwoofer is available, bass frequencies are re-

directed to the subwoofer, otherwise, they are discarded. The bass frequency upper limit is set

by the Crossover Frequency selection in the Setup Menu (see page 71 for details).

Off – Speaker for the corresponding position does not exist. Audio for the missing speaker is

redirected to other speakers or discarded if redirection is not possible.

On (for Subwoofer only) – Specifies that a subwoofer is available.

NOTE

The Size for Front, Surround and Surround Back speakers is configured in pairs. Changes to

the size of one speaker will automatically change the other of the pair.

2. Distance: The speaker distance parameters set delay control for the corresponding audio channel.

The delay is to compensate for the audio propagation time difference caused by the placement of

speakers.

Speaker distance compensation is not required if the A/V receiver has the capability to adjust

channel delay and compensate for speaker distance differences. However, if your receiver does not

have such functions (most receivers do not offer these functions for their multi-channel analog input),

you may adjust them through the player. Speaker distance delay is only applied if the player is

decoding multi-channel audio. If you use bitstream audio output to your A/V receiver, the bitstream

audio is not adjusted for speaker distance delay.

ᶅᶰᶸᶯᵡᶎᶪᶹ

ᶕᶦᶴᶵᵡᶕᶰᶯᶦ

ᶆᶹᶪᶵ

SETUP MENU OPTIONS

A typical 7.1-channel speaker layout and their speaker distance measurements are displayed as

below:

FL FR

SL SR

SBL SBR

Speaker Icons:

FL - Front Left

FR - Front Right

C - Center

SW - Subwoofer

SL - Surround Left

SR - Surround Right

SBL - Surround Back Left

SBR - Surround Back Right

Distances:

1 - Listener to Front

2 - Listener to Center

3 - Listener to Surround Left

In the above diagram, measure the distance (in feet) from the primary listening position to the Front

Left or Front Right Speaker. Enter the distance of the Front Speakers ( in the above picture) into

the Speaker Configuration menu.

Next, measure the distance (in feet) from center speaker ( ) to the listening position. Move the

cursor to highlight the Center speaker in the Channel Delay setup page, and enter the distance (as

close as possible) in feet. Repeat for each speaker in the system (Center, Surround Left, Surround

Right, Surround Back Left, Surround Back Right and Subwoofer) as available. The player will insert

appropriate delay to make sure sound waves from different speakers arrive at the listener at the

same time.

It is possible to independently set distances for each speaker. Speaker distances can be set to the

actual spatial distance of the speakers.

If the channel delay settings cannot match your speaker configuration, please set all distances to the

same and use your receiver/amplifier to set the channel delay.

3. Trim: The speaker trim level parameters sets the volume of each individual channel. Channel trim

is generally not required since most A/V receivers have the capability to adjust channel trim and

compensate for speaker sensitivity differences. However, if your receiver does not have such

functions (many receivers do not support channel trim for their multi-channel analog inputs), you may

adjust channel trim through the player. For most accurate results, it is recommended that you use

test tones from a calibration disc, such as Digital Video Essentials HD Basics, and a SPL (Sound

Pressure Level) meter. The trim level can be set to +/- 10dB in 0.5dB increments.

NOTE

xIncreasing the Trim Level above 0dB may result in distortion if the original audio level is

already high. When this occurs the waveform becomes clipped and audible distortion can

be heard. In this situation, it is necessary to reduce the Trim Level until the distortion is

removed. When using the Trim Level for speakers, it is recommended that you set the

least sensitive speaker’s Trim Level to 0dB, and set other speakers’ Trim Level to

negative values.

xThe Test Tone can be used in conjunction with the player’s trim control. Each speaker

can be set to independent trim levels and there is no linked pair limitation.

SETUP MENU OPTIONS

Other Audio Processing Settings

In addition to Speaker Configuration, Crossover Frequency and Dynamic Range Control are audio

processing settings that can be configured:

1. Crossover: Allows you to set the Bass Management kick-in frequency for all speakers. When the

speaker size is set to Small in Speaker Configuration (see page 69), bass information below this

frequency is not passed to the speakers to reduce possible distortion, and if the subwoofer is

available, bass information will be redirected to the subwoofer. When all speaker sizes are set to

Large, there is no Bass Management.

x40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz / 250Hz – These are

the available crossover frequencies. You can press the UP/DOWN ARROW buttons and the

ENTER buttons to select it. This option applies to all speakers (center, front, surround, and

surround back speakers). By default the crossover frequency is 80Hz.

2. Dynamic Range Control: Allows you to set the Dynamic Range Compression (DRC). DRC can

smooth out the sonic peaks and valleys common with wide-range digital audio. Enabling DRC may

make low level audio more audible during low-level listening. Turning off DRC restores the sonic

energy present in the original recording.

xAuto – Plays at the dynamic range specified by the disc. This option applies to certain Blu-

ray Discs only, which have DRC instructions encoded in the Dolby TrueHD audio tracks.

xOn – Turn on DRC for all Dolby and DTS audio formats. This option applies to all DVD and

Blu-ray Discs.

xOff – Turn off DRC.

NOTE

Dynamic Range Compression is applied to the analog audio output and digital audio outputs (HDMI,

Coaxial and Optical) when the audio format is set to PCM.

3. DTS Neo:6 Mode: Allows you to enable DTS Neo:6 audio processing and select the listening mode.

DTS Neo:6 is a digital signal processing that can expand the original stereo source to 7.0 (L, R, C, LS,

RS, LR, RR) or 7.1 (with Bass Management) surround.

xMusic – Enables DTS Neo:6 audio processing for stereo music sources.

xCinema – Enables DTS Neo:6 audio processing for digital TV box or stereo movie sources.

xOff (default) – Turns off the DTS Neo:6 to keep the original audio quality.

4. Output Volume: Allows you to enable or disable the analog volume controls (also known as Variable

Audio). The available options are:

xVariable – Enables the analog volume control. Use the VOL+/- buttons on the remote to

increase/decrease the analog audio output level (the maximum is 100).

xFixed – Disables the analog volume control. The VOL+/- buttons on the remote will no

longer affect the analog audio output, and the volume level is fixed to 100.

SETUP MENU OPTIONS

Device Setup

The Device Setup section of the Setup Menu system allows you to configure additional player options related

to the hardware and control functions.

1. Firmware Information: Displays the currently installed firmware version.

2. Firmware Upgrade: Upgrades the player’s firmware. This operation is only available when the

playback is completely stopped or when there is no disc loaded.

The firmware is the system software that controls the features and functions of the player. Since the

Blu-ray Disc specifications are new and evolving, it is possible that a Blu-ray Disc manufactured after

the player was manufactured uses certain new features of the Blu-ray Disc specifications. To ensure

the best possible viewing experience, the player may need a firmware update from time to time.

Please visit the OPPO Digital web site www.oppodigital.com to check for firmware updates and

instructions on installing the updates.

There are three ways to upgrade the player’s firmware:

Via USB – You may download the firmware files from the OPPO Digital web site to a USB

drive and then use the USB drive to upgrade the player. Please follow the instructions on the

firmware download web page.

Via Disc – You may requests a firmware upgrade disc from OPPO Digital or download a disc

image from the OPPO Digital web site and burn an upgrade disc. Please follow the

instructions that come with the upgrade disc.

Via Network – If the player has a working Internet connection (see pages 19 and 76), you

may upgrade the player directly over the Internet. Please follow the instructions on your TV

screen.

3. Firmware Notification: Allows you to set whether the player should automatically check for new

firmware versions on the Internet server and notifies you about new firmware.

On – Checks for firmware updates automatically and notifies the user about new firmware.

Requires a working network connection.

Off – Does not check for new firmware version automatically.

4. Remote Control Code: The BDP-103 can respond to one of four sets of remote control codes. The

default is “Code 1”. If you have other OPPO products in the vicinity of the BDP-103, the other

products may respond to the BDP-103 remote control. To prevent this, you can select a different

remote code. The available codes are:

ᶔᶭᶦᶦᶱᵡᶕᶪᶮᶦᶳ

SETUP MENU OPTIONS

Code 1 – OPPO disc player remote code is set to 1. This is the default remote code.

Code 2 – OPPO disc player remote code is set to 2. Use this code if you have other OPPO

products placed close to the BDP-103.

Code 3 – OPPO disc player remote code is set to 3. Use this code if you have other OPPO

products placed close to the BDP-103.

Alt. Code – Alternative remote code. The alternative remote control code enables users to

program their universal remote controls that come with TV, projector or A/V receiver to

operate the OPPO player. If the universal remote control has a DVD player control function,

please program it with the code for Toshiba, Philips, Magnavox, Marantz or Zenith DVD

players. Since each brand of remote control may have several sets of codes, you may need

to try several times using different codes to find a working code.

If you have selected a new remote code, you must set the remote control handset to use the same code.

Please refer to the Changing the Remote Code section on page 10 of this manual for details. If you have

selected Alt. Code, the supplied handset will not operate the player, and you must use a universal remote

control with the properly configured code set.

5. HDMI CEC: Allows you to set the HDMI Consumer Electronics Control (CEC) mode. CEC is an

optional HDMI feature that enables convenient remote control and automatic setup of consumer

electronics over the HDMI connection. The remote control function allows you to use a single remote

handset to operate multiple devices connected via HDMI. For example, you may use the TV remote

to control playback of the Blu-ray Disc player. The automatic setup function can automatically turn on

the TV and change to the proper input when you start playing a disc in the Blu-ray Disc player. It can

also turn off the player automatically when you turn off the TV. The implementation and compatibility

of this feature varies by device manufacturer. Each may only implement part of the features or add

their own proprietary functions. The manufacturer-specific implementation of the HDMI CEC function

is often given a proprietary name of “…Link” or “…Sync”. The BDP-103 provides three HDMI CEC

function modes for each of its HDMI outputs:

HDMI 1 – HDMI CEC is enabled on HDMI 1 output. Use this mode if your other devices are

compatible with the player.

HDMI 1 (Limited) – HDMI CEC is enabled on HDMI 1 output, but the BDP-103 will only

respond to playback control commands. It will not respond or issue power on/off and input

selection commands. Use this mode if you do not want the automatic setup function to turn

on/off your devices.

HDMI 2 – HDMI CEC is enabled on HDMI 2 output. Similar to HDMI 1.

HDMI 2 (Limited) – HDMI CEC is enabled on HDMI 2 output, but the BDP-103 will only

respond to playback control commands. Similar to HDMI 1 (Limited).

Off (default) – HDMI CEC feature is turned off on both HDMI output terminals. The player will

not respond to HDMI CEC commands from other devices, nor will it setup other devices

automatically.

6. Standby Mode: Allows you to choose between two standby modes. In Energy Efficient mode, the

player consumes a minimal amount of power but takes more time to get ready for operation after

being turned on. In Quick Start mode, the player can start up significantly faster at the expense of

additional power consumption during the standby period.

Energy Efficient (default) – The player will take slightly longer to start up, but will

consume less power in standby mode. This mode is recommended for regular use.

SETUP MENU OPTIONS

Quick Start – The player takes less time to start up but consumes more power in standby

mode. This mode is recommended if the player is used frequently, or if you need to supply

power to a device connected to the player’s MHL port during the standby period.

8. Front Panel Brightness: Allows you to control the display intensity of the front panel Vacuum

Fluorescent Display (VFD) information window and the OPEN/CLOSE tray button backlight. If you

feel that the display becomes a distraction to your enjoyment of the video, this option allows you to

dim it or turn it off.

Standard (default) – The VFD window and theOPEN/CLOSE tray button backlight are at full

brightness.

Dim – The VFD window and theOPEN/CLOSE tray button backlight are at reduced

brightness.

Off – The VFD window and the OPEN/CLOSE tray button backlight are turned off. In this

mode, the display and backlight will resume momentarily if there is any user operation.

10. Persistent Storage: Allows you to manage the persistent storage for BD-Video content. The

persistent storage is a data storage area that holds additional content for BonusView and BD-Live

features. The data will be kept even if you turn off the player. The following persistent storage

management options are available:

Storage Device – Allows you to select which storage device should be used as the persistent

storage. The BDP-103 preserves about 1GB of internal flash memory that can be used for

persistent storage. There are also three USB ports on the player that can accept a USB drive

to be used as the persistent storage. You may choose from the following:

Internal Flash – Uses the internal flash memory for persistent storage.

USB Drive – Uses a USB drive for persistent storage. To meet the specification for

BD-Live, a USB flash drive of 1GB or larger is required. A USB hard drive is not

recommended.

7. Sleep Timer: Allows you to specify the amount of time before the player automatically turns itself off.

9. Cache Media Info (On/Off) : Allows you to set the online media file information caching option. This

option can provide a better media file navigation experience by caching some of the media

information in an “OPPO_Media_Info” folder created on the root directory of the connected USB drive.

On (recommended) – The downloaded media information will be saved on the same USB

hard disk or thumb drive as the media files for faster navigation.

Off – The downloaded media file information is not saved. Retrieving the media information

from the internet may take some time and could slow down media file navigation.

Off (default) – The player will not turn itself off automatically.

30/45/60/90/120 Min – These are the available time increments (in minutes) you can choose

before the player automatically shuts itself down. You can press the UP/DOWN ARROW

buttons and the ENTER button to select the desired time. Once selected, the remaining

minutes will be displayed to the right of the “Sleep Timer” option.

SETUP MENU OPTIONS

13. Reset Factory Defaults: To reset all settings to the factory default value. This operation also set

BD-Live Network Access to be Off (details on page 76) and performs Erase Persistent Storage

(details on page 74). However, the remote control code will not be reset. This operation is only

available when the playback is completely stopped or when there is no disc loaded.

Erase Accounts and Settings (default) – Resets all settings to the factory default value and

remove all application activations and account information, such as your Netflix and VUDU

accounts.

Erase Settings – Resets all settings to the factory default value, but keeps the application

activations and account information.

12. VUDU: Allows you to de-activate your VUDU HD Movies account.

have to go to the Home Menu, select Netflix, and go through the activation procedure again

to be able to access Netflix from your player.

NOTE

The new storage device choice becomes effective only after the player is restarted. Please

make sure that you turn off the player and then turn it back on after changing the Storage

Device option.

Space Used – Displays the used space of the persistent storage. If too much space is used

and the available space becomes too low, some Blu-ray Discs may not play properly.

Erase Persistent Storage – Erases the BD-Video data from the persistent storage or

initializes a USB drive so it can be used for persistent storage.

11. Netflix: Allows you to de-activate your Netflix account.

Netflix ESN – Displays the Netflix ESN (Electronic Serial Number) for your player.

De-activate Netflix – De-activates the Netflix account on your player. Once de-activated, you

SETUP MENU OPTIONS

Network Setup

The Network Setup section of the Setup Menu system allows you to configure the player’s network

connection, test the connection, and enable or disable BD-Live access.

1. Connection Information: Displays the current internet connection information, such as connection

type, IP address, Ethernet MAC, Wireless MAC, etc.

BD-Live Network Access: Used to permit or restrict BD-Live content access.

xOn – BD-Live access is permitted.

xLimited – BD-Live access is permitted only for content that has a valid content owner

certificate. Internet access is prohibited if the BD-Live contents does not have a certificate.

This option ensures that you are accessing only authentic content, although it may block

your access to smaller independent content providers.

xOff (recommended) – BD-Live access is prohibited.

4. My Network: Configures the My Network (in-home media sharing) client. My Network enables the

player to stream audio, video, and photos from media servers within the home network.

xOn (default) – Enables local network streaming. A broadband internet connection is required

(details on page 19), and special hardware/software configurations are required (see In-

home Network Media Sharing on page 41). The available media servers are listed inside the

Network option of the Home Menu (details on page 42).

xOff – Disables local network streaming. No media servers will be shown in the Network

menu, and a warning message will pop up once you try to enter the Network menu.

5. Gracenote Lookup: Allows you to access the Gracenote online database for additional media

information such as Disc Title, Genre, Year, Album, Artist and Cover Art.

xOn (default) – Enables the Gracenote service and allows the player to look up media

information and cover art from the Gracenote database. A broadband internet connection is

required (details on page 19).

xOff – Disables the Gracenote service.

ᶑᶭᶢᶺᶦᶳᵡᶏᶢᶮᶦ ᶐᶑᶑᶐᵡᶃᶅᶑᵮᵲᵱᵴ

Player Name: Enter and display the player’s identification name as it is displayed on local network

sharing products. To change it, press the ENTER button to bring the soft keyboard. The name can

contain maximum 12 characters including spaces.

SETUP MENU OPTIONS

6. Internet Connection: Allows you to select the internet connection type.

Ethernet (default) – Connect to the internet through an Ethernet cable. Please refer to the

connection instructions on page 19. Selecting this will make the Wireless Setting option

gray and un-selectable.

Wireless – Connect to the internet through the external wireless adaptor. Please refer to the

connection instructions on page 20. Choosing Wireless will start the Wireless Setup

Assistant, and will also make the Wireless Setting option in the next row selectable.

Off – Internet access is prohibited. This will make all the remaining options in the Network

Setup screen gray and un-selectable.

7. Wireless Setting – Start the Wireless Setup Assistant. You can start the Wireless Setup

Assistant by selecting the Wireless Setting option, or by selecting Wireless in Internet

Connection menu. The procedure is described as follows:

The player first searches for the last successful wireless settings. If they exist, a message

will pop up to remind you.

Use Previous – Uses the last successful wireless settings. A summary of the previous

wireless settings will display, showing information such as the SSID (network name),

Security Mode and Security Key (password).

After verifying the previous settings, the player will test the connection and display the

results.

Start New – Creates a new wireless configuration. The BDP-103 supports three wireless

configuration methods:

Scan – Scans for an available wireless network. The player automatically scans for

any available wireless networks and displays the search results in a window. You

can press the UP/DOWN ARROW buttons to highlight a network and then press the

ENTER button to select it. If this network is secured, you will need to input the

security key using the remote control. The player will then test the connection and

display the results.

SETUP MENU OPTIONS

Manual – Allows you to manually enter the information for a wireless network. You

need to use the remote control to input the SSID, select the Security Mode and

input the Security Key. The player will then test the connection and display the

results.

WPS – Starts the Wi-Fi Protected Setup. The BDP-103 supports the WPS standard

to provide an easy and secure establishment of a wireless home network. You may

choose from the following setup options:

PIN – Configures the WPS using a Personal Identification Number. The

BDP-103 will generate a PIN code and you will need to input it into the

software control panel of your wireless router or access point. Please follow

the on-screen instructions.

PBC – Configures the WPS using Push Button Control. You need to push a

PBC button on your wireless router or access point to initiate the wireless

connection. Please follow the on-screen instructions.

NOTE

SSID is short for Service Set Identifier. It is an identifier for each wireless router or

access point, and is also referred as a network name.

WPS is short for Wi-Fi Protected Setup (WPS). It is the latest standard for easy and

secure wireless home network configuration. It is also named Wi-Fi Simple Config.To

use WPS, a WPS compatible router or access point is required.

8. IP Setting: Determines how the player obtains its IP address.

Auto (DHCP) – The player automatically obtains its IP address information using DHCP

(Dynamic Host Configuration Protocol). This is the default setting. In most cases, automatic

IP configuration should be used.

Manual – Allows you to manually enter the numeric IP address. Set the IP configuration

manually only when the router has no DHCP server functions or when the router’s DHCP

server function is disabled. For more information on how to manually configure the Internet

connection and what values to use, please consult your broadband router/modem instruction

manuals or call your Internet service provider.

Internet Connection – Depending on the setting in Internet Connection, this can be

either “Wireless” or “Ethernet”.

IP Address: The Internet Protocol address of the player. When IP Setting is set to Auto

(DHCP), the value displayed here is obtained using DHCP and cannot be changed.

SETUP MENU OPTIONS

Subnet Mask: Each IP address has an associated subnet mask. It is used by the player

to decide whether to route network traffic through the router or directly to another device

on the same network. When IP Setting is set to Auto (DHCP), the value displayed here

is obtained using DHCP and cannot be changed.

Gateway: The IP address of the router. It is also called “default gateway” or “default

router”. When IP Setting is set to Auto (DHCP), the value displayed here is obtained

using DHCP and cannot be changed.

DNS 1: The IP address of the primary DNS (Domain Name System) server. DNS is the

mechanism used to translate human-readable addresses (such as www.oppodigital.com)

to numeric IP addresses. When IP Setting is set to Auto (DHCP), the value displayed

here is obtained using DHCP and cannot be changed.

DNS 2: The IP address of the secondary DNS server. When IP Setting is set to Auto

(DHCP), the value displayed here is obtained using DHCP and cannot be changed.

9. Proxy Setting: Allows you to configure the proxy server settings. The proxy server works as an

intermediary for network communication between clients and other servers, which can provide

benefits like security, anonymity, or even circumvention of regional restrictions.

xOn – Accesses the Internet via a proxy server.

Proxy Host: Input the proxy host name using the remote control.

Proxy Port: Input the proxy host port number using the remote control.

xOff (default) – Disables the use of a proxy server.

We recommend keeping Proxy Setting set to Off, unless you have a working Proxy Host and

Proxy Port, and have to use the proxy server in order to access the internet.

10. Connection Test: Allows you to test the Internet connection. It is recommended that you test the

connection when you initially connect the player to the Internet, or whenever changes to Connection

Method,Wireless Setting,IP Setting and other network parameters are made.

REFERENCES

Useful Notes

xIn order to prolong the life of your player, it is recommended that you wait at least 30 seconds

before you power it on after switching it off.

xRemove discs and turn the power off after operation.

xSome functions of the player may not be applicable to certain discs.

xSome discs with special features may not be fully supported by the player. This is not a

malfunction of the unit.

xIn the case of player malfunction, please turn it off, wait for 30 seconds and turn it back on. If the

problem still exists, please follow the troubleshooting instructions or contact an OPPO service

center.

Troubleshooting

Use this chart to resolve general operational problems. If there are any problems that you cannot resolve,

please contact your OPPO service center.

Symptom Possible Cause Solution Reference

Page

No sound

Audio cable is not properly

connected Check audio cable, and then reconnect if necessary. 11_17

Mute is activated Press the MUTE button to cancel the mute. 28

Volume is too low Press the VOL + button to increase the volume to 100. 27

SACD is played and the audio

connection is coaxial or optical

digital audio

This is not supported due to copyright restrictions of

SACD. Please use the analog or HDMI audio output.

Alternatively, you may set SACD Priority to CD mode

and the player will play the CD layer.

17, 51

DVD-Audio is played and the

audio connection is coaxial or

optical digital audio

This is not supported due to copyright restrictions of

DVD-Audio. Please use the analog or HDMI audio

output. Alternatively, you may switch to the DVD-

Video playback mode.

17, 51

No picture

Video cable is not properly

connected Check video cable; reconnect if necessary. 11_15

TV input is not correctly

selected Select the input to which the player is connected.

“Pure Audio” mode engaged Press the PURE button to cancel this mode. 38

Video output format is not

support by the TV

Select a proper output resolution that is supported by

your TV. 31

Video system is not supported

by the TV

When playback is completely stopped, set the correct

TV System in the Setup Menu. 54

No color

Video system is not supported

by the TV

When playback is completely stopped, set the correct

TV System in the Setup Menu. 54

Saturation set too low Check the saturation setting on TV and player. 58

Incorrect video output port If using “DIAG.” output, check that the cable is not

incorrectly plugged into a component video jack. 13

Incorrect color Incorrect color space setting If using HDMI for video output, check the color space

setting on the TV and player. 59

Picture rolling or

split picture

Video system is not supported

by the TV

When playback is completely stopped, set the correct

TV System in the Setup Menu. 54

“No Disc” or

“Unknown Disc”

error

No disc or incompatible disc

loaded in player 42.kcehcdnacsidtcejE

Dirty disc recording surface Eject the disc and clean any dirt or fingerprints. 4

Disc not properly loaded Eject disc and make sure the label side is facing up

and the record side is facing down. 24

Condensation on the Laser

pick-up head

Turn on the player, eject the disc and leave the player

on for about an hour. 2

REFERENCES

Remote control

failure

Remote control is out of range Use the remote control within the effective range. 9

9.seirettabehtecalpeRyrettabwoL

Incorrect remote control code

Open the disc tray. Aim the remote at the player. Press

and hold the ENTER button on the remote for 5

seconds to set the remote code.

Temporary

function failure

Scratched or damaged disc is

used 24.csidehtecalpeR

Some functions are not

available during playback Stop playback completely, then try again. 24

Interference from other devices Identify interference by turning off other devices, and

then relocate or replace the offending device 2

Some Setup

Menu items are

grayed out

Some setup options cannot be

changed while a disc is playing.

Some setup options may be

mutually exclusive with other

setup options.

Fully stop playback, eject the disc and try the Setup

Menu again. 49

“Connection

Test” fails No internet connection.

Verify that your router has a connection to the internet.

Try power cycling the modem and router. Try a direct

Ethernet connection if possible.

19, 20, 77

“Network” shows

no server

No network connection. Media

server not properly configured.

Connected to wrong network.

Verify that other network features are functional on the

device (YouTube, Netflix, etc.) If the network issues

are isolated to the “Network” feature, consult your

media server’s documentation to ensure proper

configuration.

19, 41

Internet

streaming fails

Poor wireless signal. Incorrect

network settings. 19, 42

Verify that the player is communicating with the router

(Setup Menu > Network Setup > Connection

Information). Change the DNS server information

(Google Public DNS / OpenDNS). If connecting

wirelessly, verify that your connection strength is >

50%. If it is lower, connect via Ethernet or use the USB

extension cable to move the Wi-Fi adapter closer to

your router.

REFERENCES

Specifications

Designs and specifications are subject to change without notice.

* Compatibility with user-encoded contents or user-created discs is on a best effort basis with no guarantee due

to the variation of media, software and techniques used.

**Nominal specification.

User Manual Updates Online

An updated version of the User Manual may be available online at the OPPO Digital web site

(www.oppodigital.com). To read or download the latest online User Manual, Click on the BDP-103

product, and open its “Support” tab.

Occasional updates are needed to reflect new features added to the player since the User Manual was

printed. As future firmware updates bring in new features and functions, the online version of the User

Manual will be updated accordingly.

Disc Types* BD-Video, Blu-ray 3D, DVD-Video, DVD-Audio, AVCHD, SACD, CD, HDCD,

Kodak Picture CD, CD-R/RW, DVD±R/RW, DVD±R DL, BD-R/RE

BD Profile BD-ROM Version 2.5 Profile 5 (also compatible with Profile 1 Version 1.0 and 1.1)

Internal Storage 1GB (Actual space available for persistent storage varies due to system usage)

Output

Input

Audio

Characteristics**

Frequency: 20Hz – 20kHz (±0.05dB), 20Hz – 96kHz (-4.5dB ~ +0.05dB)

Signal-to-Noise Ratio: >115dB (A-weighted)

THD+N: < 0.006% (1kHz at 0dBFS, 20kHz LPF)

General

Specification

Power Supply: ~100V – 240V, 50/60Hz AC

Power Consumption: 35W (Standby: 0.5W in Energy Efficient Mode)

Dimensions: 16.8 x 12.2 x 3.1 inches (430mm x 311mm x 79mm)

Mass: 10.8 lbs (4.9kg)

Operating

Temperature

41°F – 95°F

5°C – 35°C

Operating

Humidity

15% – 75%

No condensation

HDMI Audio: up to 5.1ch/192kHz or 7.1ch/96kHz PCM, Dolby Digital, Dolby Digital Plus, DTS,

AAC.

HDMI Video: 480i/480p/576i/576p/720p/1080i/1080p/1080p24/1080p25/1080p30, 3D

frame-packing 720p/1080p24.

MHL Audio: up to 5.1ch/192kHz PCM, Dolby Digital, Dolby Digital Plus, DTS.

MHL Video: 480i/480p/576i/576p/720p/1080i/1080p24/1080p25/1080p30, 3D frame-packing

720p/1080p24.

Analog Audio: 7.1ch, 5.1ch, stereo.

Coaxial/Optical Audio: up to 2ch/192kHz PCM, Dolby Digital, DTS.

HDMI Audio: up to 7.1ch/192kHz PCM, up to 5.1ch DSD, Dolby Digital, Dolby Digital Plus,

Dolby TrueHD, DTS, DTS-HD High Resolution, DTS-HD Master Audio.

HDMI Video: 480i/480p/576i/576p/720p/1080i/1080p/1080p24/4Kx2K, 3D frame-packing

720p/1080p24.

REFERENCES

Language Code List

Code Language Name

6565 Afar

6566 Abkhazian

6570 Afrikaans

6577 Amharic

6582 Arabic

6583 Assamese

6588 Aymara

6590 Azerbaijani

6665 Bashkir

6669 Byelorussian

6671 Bulgarian

6672 Bihari

6678 Bengali, Bangla

6679 Tibetan

6682 Breton

6765 Catalan

6779 Corsican

6783 Czech

6789 Welsh

6865 Danish

6869 German

6890 Bhutani

6976 Greek

6978 English

6979 Esperanto

6983 Spanish

6984 Estonian

6985 Basque

7065 Persian

7073 Finnish

7074 Fi jian

7079 Faroese

7082 French

7089 Frisian

7165 Irish

7168 Scots Gaelic

7176 Galician

7178 Guarani

7185 Gujarati

7265 Hausa

7273 Hindi

7282 Croatian

Code Language Name

7285 Hungarian

7289 Armenian

7365 Interlingua

7378 Indonesian

7383 Icelandic

7384 Italian

7387 Hebrew

7465 Japanese

7473 Yiddish

7487 Javanese

7565 Georgian

7575 Kazakh

7576 Greenlandic

7577 Cambodian

7578 Kannada

7579 Korean

7583 Kashmiri

7585 Kurdish

7589 Kirghiz

7665 Latin

7678 Lingala

7679 Laothian

7684 Lithuanian

7686 Latvian,Lettish

7771 Malagasy

7773 Maori

7775 Macedonian

7776 Malayalam

7778 Mongolian

7779 Moldavian

7782 Marathi

7783 Malay

7784 Maltese

7789 Burmese

7865 Nauru

7869 Nepali

7876 Dutch

7879 Norwegian

7982 Oriya

8065 Panjabi

8076 Polish

8083 Pashto, Pushto

Code Language Name

8084 Portuguese

8185 Quechua

8277 Rhaeto-Romance

8279 Romanian

8285 Russian

8365 Sanskrit

8368 Sindhi

8372 Serbo-Croatian

8373 Singhalese

8375 Slovak

8376 Slovenian

8377 Samoan

8378 Shona

8379 Somali

8381 Albanian

8382 Serbian

8385 Sundanese

8386 Swedish

8387 Swahili

8465 Tamil

8469 Telugu

8471 Tajik

8472 Thai

8473 Tigrinya

8475 Turkmen

8476 Tagalog

8479 Tonga

8482 Turkish

8484 Tatar

8487 Twi

8575 Ukrainian

8582 Urdu

8590 Uzbek

8673 Vietnamese

8679 Volapuk

8779 Wolof

8872 Xhosa

8979 Yoruba

9072 Chinese

9085 Zulu

This application or device contains software from Gracenote, Inc. of Emeryville, California (“Gracenote”).

The software from Gracenote (the “Gracenote Software”) enables this application to do disc or file

identification and obtain music-related information, including name, artist, track, and title information

(“Gracenote Data”) from online servers or embedded databases (collectively, “Gracenote Servers”) and to

perform other functions. You may use Gracenote Data only by means of the intended End-User functions

of this application or device.

This application or device may contain content belonging to Gracenote’s providers. If so, all of the

restrictions set forth herein with respect to Gracenote Data shall also apply to such content and such

content providers shall be entitled to all of the benefits and protections set forth herein that are available to

Gracenote.

You agree that you will use Gracenote Data, the Gracenote Software, and Gracenote Servers for your

own personal non-commercial use only. You agree not to assign, copy, transfer or transmit the

Gracenote Software or any Gracenote Data to any third party. YOU AGREE NOT TO USE OR EXPLOIT

GRACENOTE DATA, THE GRACENOTE SOFTWARE, OR GRACENOTE SERVERS, EXCEPT AS

EXPRESSLY PERMITTED HEREIN.

You agree that your non-exclusive license to use the Gracenote Data, the Gracenote Software, and

Gracenote Servers will terminate if you violate these restrictions. If your license terminates, you agree to

cease any and all use of the Gracenote Data, the Gracenote Software, and Gracenote Servers.

Gracenote reserves all rights in Gracenote Data, the Gracenote Software, and the Gracenote Servers,

including all ownership rights. Under no circumstances will Gracenote become liable for any payment to

you for any information that you provide. You agree that Gracenote may enforce its rights under this

Agreement against you directly in its own name.

The Gracenote service uses a unique identifier to track queries for statistical purposes. The purpose of a

randomly assigned numeric identifier is to allow the Gracenote service to count queries without knowing

anything about who you are. For more information, see the web page for the Gracenote Privacy Policy for

the Gracenote service.

The Gracenote Software and each item of Gracenote Data are licensed to you “AS IS.” Gracenote makes

no representations or warranties, express or implied, regarding the accuracy of any Gracenote Data.

Gracenote reserves the right to delete data from the Gracenote Servers or to change data categories for

any cause that Gracenote deems sufficient. No warranty is made that the Gracenote Software or

Gracenote Servers are error-free or that functioning of Gracenote Software or Gracenote Servers will be

uninterrupted. Gracenote is not obligated to provide you with new enhanced or additional data types or

categories that Gracenote may provide in the future and is free to discontinue its services at any time.

GRACENOTE DISCLAIMS ALL WARRANTIES EXPRESS OR IMPLIED, INCLUDING, BUT NOT

LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR

PURPOSE, TITLE, AND NON-INFRINGEMENT. GRACENOTE DOES NOT WARRANT THE RESULTS

THAT WILL BE OBTAINED BY YOUR USE OF THE GRACENOTE SOFTWARE OR ANY GRACENOTE

SERVER. IN NO CASE WILL GRACENOTE BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL

DAMAGES OR FOR ANY LOST PROFITS OR LOST REVENUES.

Gracenote Terms of Use

LIMITED WARRANTY

OPPO Digital, Inc. Limited Two Years Warranty

Your OPPO product has been manufactured to precise standards, and with rigid quality control through

every process of manufacturing. It is warranted by OPPO DIGITAL, INC. against defective workmanship

or materials for two (2) full years from the original date of purchase. This warranty applies only to OPPO

brand products imported or manufactured by OPPO Digital, Inc. and sold to the original consumer

purchaser in the U.S.A. or Canada by either OPPO Digital, Inc. or an OPPO authorized reseller. This

warranty does not apply to OPPO brand products imported and sold by unauthorized dealers, distributors,

or other sellers. This warranty does not apply to products purchased or shipped outside of the U.S.A. and

Canada. OPPO Digital, Inc. may at its sole discretion, refuse to honor the warranty of any such

unauthorized product that may be presented for service.

Warranty service can only be performed by OPPO Digital, Inc. or an OPPO authorized service center.

The original dated bill of sale must be presented upon request as proof of purchase.

OPPO Digital, Inc. will, at its option and at no charge as stipulated herein, repair or replace product which

is returned either in person or postpaid and insured to an OPPO service center, with new or

reconditioned parts or products. Replacement parts and products assume the remaining original warranty,

or ninety (90) days, whichever is longer.

This limited warranty covers noncommercial use of this product, and shall not apply to the following,

including, but not limited to: applications and uses for which this product was not intended; altered

product or serial numbers; cosmetic damage or exterior finish; batteries and cable accessories; accidents,

abuse, neglect, fire, water, lightning or other acts of nature; incorrect electrical line voltage, fluctuations

and surges; failure to follow operating or maintenance instructions. OPPO Digital, Inc. does not warrant

uninterrupted or error-free operation of the product. This limited warranty shall not extend to anyone

other than the original purchaser of the product. It is nontransferable and states your exclusive remedy.

THE FOREGOING WARRANTY IS THE ONLY WARRANTY WITH RESPECT TO THE PRODUCT AND

OPPO DIGITAL, INC. MAKES NO OTHER WARRANTY WHATSOEVER, EXPRESS OR IMPLIED,

REGARDING THE PRODUCT INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. IN NO EVENT WILL OPPO DIGITAL, INC. OR ITS AUTHORIZED RESELLERS BE LIABLE

FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES, EVEN IF SUCH DAMAGES RESULT

FROM NEGLIGENCE OR OTHER FAULT.

Some states do not allow limitation on how long an implied warranty lasts, or the exclusion or limitation of

incidental or consequential damages, so the above limitations or exclusions may not apply to you. This

warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

TO REGISTER YOUR PURCHASE FOR WARRANTY, please visit the following Web site:

http://www.oppodigital.com/registration.asp

TO OBTAIN WARRANTY SERVICE, please follow these instructions:

xContact OPPO customer service via email at service@oppodigital.com or by phone at (650) 961-

1118 with details of the defect claimed, product model, serial number, date and place of the

original purchase.

xIf it is determined that your product needs service, a Return Merchandise Authorization (RMA)

number will be issued to you along with return instructions and address of an OPPO service

center.

xPack the product securely, preferably in the original packaging, with your assigned RMA number

marked clearly on the outside of the package. Send the package postpaid and insured to the

OPPO service center to obtain warranty service.

Thank you for choosing OPPO. Your satisfaction is our highest priority.

OPPO Digital, Inc.

2629 Terminal Blvd, Suite B

Mountain View, CA 94043, U.S.A.

www.oppodigital.com

service@oppodigital.com

(650) 961-1118

51977598 V1.6

www.oppodigital.com

Oppo Bdp 103 Users Manual English V3.0

Blu-ray Disc Player BDP-103 BDP-103_USER_MANUAL_English_v1.6

Navigation menu

Versions of this User Manual:

Views

Navigation
