Steam 75

Important!

Read this manual carefully,

and keep for future reference.

User’s

Guide

*The Steam 75 is practical for any surface with the exception of those surfaces that

are extremely heat sensitive. We recommend NOT using it on ne silks, delicate

materials such as velour, some very thin plastics, unsealed hardwood, ceilings, drywall,

and exterior paint of automobiles, electronics or items using electricty. If ever in doubt,

test a small area before beginning extensive cleaning.

Other Oreck accessories available at:

Thank You for purchasing one of our top-of-the-line Oreck®

Steam 75 Steam Cleaners. This powerful, environmentally

friendly cleaner will help you clean both hard oors and refresh

carpets*.

At Oreck, we understand that our customers are unique

and expect superior service. To meet your needs, we offer

different customer service options to accommodate your

lifestyle and preference.

Welcome to our Call. Click. Visit. customer service

program. To speak with an Oreck representative call, click or

visit using the information below.

Enjoy

Click

Call

Visit

USA: 1•800•989•3535

Canada: 1•888•676•7325

On the web, point and click at: www.oreck.com

and click locate a store on the top right.

Visit us in person at one of over 450 store

locations. To nd the nearest store, please call

888•oreck (1•888•673•2578).

Contents

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

General Warnings..........................4

Grounded Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Parts ......................................7

Product Components & Accessories . . . . . . . . . . . . .7

Features....................................9

Assembly..................................10

Use ......................................11

Before you begin Cleaning . . . . . . . . . . . . . . . . . . . 11

Attaching the Microfiber Cleaning Pad

and Carpet Glider .........................12

Cleaning Hard Floors and Refreshing Carpets . . . . . 13

Clean-up after Use . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Empty the Water Tank . . . . . . . . . . . . . . . . . . . . . . 15

Remove the Microfiber Cleaning Pad . . . . . . . . . . . 16

Cleaning the Microfiber Cleaning Pad . . . . . . . . . . . 16

Maintenance................................17

Replacing the Hard Water Filter . . . . . . . . . . . . . . . 17

Troubleshooting .............................18

Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Safety

IMPORTANT

SAFETY INSTRUCTIONS

General Warnings

Read all instructions before using this steam cleaner

WARNING! To reduce the risk of re, electric shock, or injury

when using an electrical appliance, basic precautions should

always be followed, including the following:

• Do not leave appliance unattended when plugged in.

Unplug from outlet when not in use and before servicing.

• To prevent shock, do not use outdoors. The steam cleaner is

intended for household use only.

• Do not let the unit run while in any one stationary position

for any period of time. Keep the unit moving while in

operation.

• Do not allow to be used as a toy. Close attention is

necessary when used near children.

• Use only as described in this manual. Use only manufac-

turer’s recommended attachments.

• Do not use with damaged cord or plug. If appliance is not

working as it should, has been dropped, damaged, left out-

doors, or dropped into water, return it to a service center or

call customer service at: US: 1-800-989-3535

Canada: 1-888-676-7325

• Do not pull or carry by the power cord, use cord as a handle,

close a door on the power cord, or pull the power cord

around sharp edges or corners.

• Keep the power cord away from heated surfaces.

• Do not run the steam cleaner over the power cord.

• Do not unplug by pulling on the power cord. To unplug,

grasp the plug, not the power cord.

• Do not use an extension cord.

• Do not handle plug or appliance with wet hands.

• Turn off all controls before unplugging. Always remove the

power cord from the outlet and handle the steam cleaner

with care when lling the water tank with water.

• Do not over ll the water tank. Do not exceed the maximum

ll level. Use the measuring jug to measure the correct

amount of water.

• Do not use without the water tank cap in place. Check that

the water tank cap is completely screwed down before use.

• Do not operate without water in the water tank.

• Do not ll the water tank with anything other than water or

Oreck Fresh Air® Steam Mop Essence. Never put additives

(such as perfume, stain remover, or products containing

alcohol) in the water as they may damage the steam cleaner

or make it dangerous to use.

• Empty the water tank when the steam cleaner is not in use.

• Do not touch any hot areas on the steam cleaner. It is normal

for the steam cleaner to heat up during operation.

• The force and heat of the steam may have an adverse effect

on some materials. Always test the steamer on a small

concealed area to determine if it is suitable for treatment.

• Accessories become hot during use. Allow them to cool

down before handling them.

• Never point or aim the steam cleaner at people, animals or

plants (risk of scalding!). Do not aim the steam cleaner at

electrical systems or wires.

• Connecting the steam cleaner to improper voltage may

result in damage to the steam cleaner and possible injury.

Always plug the steam cleaner into a power outlet with the

correct voltage. See the rating label on the unit for the cor-

rect voltage.

Grounded Plug

This appliance must be grounded. If it should malfunction or

break down, grounding provides a safe path of least resistance

for electrical current, reducing the risk of electrical shock. The

cord for this appliance has an equipment-grounding conductor

and a grounding plug. It must only be plugged into an electri-

cal outlet that is properly installed and grounded in accordance

with all local codes and ordinances.

DANGER: Improper connection of the equipment-grounding

conductor can result in a risk of electrical shock. Check with

a qualied electrician or service person if you are in doubt as

to whether the outlet is grounded. If not, have a proper outlet

installed by a qualied electrician.

This appliance is for use on nominal 120-volt circuit. It has a

grounding plug similar to the example shown. Make sure the

appliance is connected to an outlet with the same conguration

as the plug. No adapter should be used with this appliance.

SAVE THESE INSTRUCTIONS

For household use only

Grounded Prong

Parts

Product Components & Accessories

Front View

1. Handle

2. Power cord

3. Water tank

4. Hard water lter

5. Steam tank/power indicator

6. Swivel oor head

7. Bonnet

Back View

7. Steam trigger

8. Upper cord clip

9. Lower cord clip

Accessories

10. Microber cleaning pad

11. Carpet glider

12. Measuring cup

250ml

MAX

Features

1. Hard Water Filter

The Hard Water Filter protects

internal hoses and the Swivel Floor

Head from mineral build-up due to

harmful hard water.

2. Swivel Floor Head

The Swivel Floor Head provides

exibility and ease of movement

when using the steam cleaner.

3. Microfiber Cleaning Pad

The Microber Cleaning Pad is used

to clean hard surfaces.

4. Carpet Glider

The Carpet Glider, used with the

Microber Cleaning Pad, lets you

refresh your carpets.

Assembly

1. Insert the handle into the body.

Line up the holes in both the

body and handle.

2. Insert the large screw and fasten.

3. Insert the body into the oor

head. Line up the holes.

4. Insert the small screw and fasten.

WARNING!

Do not plug the steam cleaner into an electrical outlet

during assembly.

250ml

MAX

Use

1. Remove the water tank.

2. Remove the cap on the water tank.

3. Using the measuring

jug, ll the water

tank. The water tank

can hold 17 . oz.

(500 ml).

Do not overll.

Before you begin Cleaning

WARNING!

Do not plug the steam cleaner into an electrical outlet

during assembly.

4. Replace the cap on the water tank

and place the tank back into the

body. Check that the water tank

is properly seated in the hard

water lter.

1. Place the Microber

Cleaning Pad over the

oor head.

2. Pinch the drawstring

clasp and pull the draw-

string to tighten the pad

around the oor head.

Attaching the Microfiber Cleaning Pad

and Carpet Glider

WARNING!

Do not plug the steam cleaner into an electrical outlet

during assembly.

NOTICE

• Always use the microber cleaning pad when cleaning hard

oors or refreshing carpets. Ensure microber cleaning pad

is in place and properly attached to the oor head. *Not for

use on unsealed hardwood.

3. When refreshing carpet,

place the Carpet Glider on

the Microber Cleaning Pad.

*The Steam 75 is practical for any

surface with the exception of those

surfaces that are extremely heat

sensitive. We recommend NOT using

it on ne silks, delicate materials such

as velour, some very thin plastics,

unsealed hardwood, ceilings, drywall,

and exterior paint of automobiles,

electronics or items using electricty. If

ever in doubt, test a small area before

beginning extensive cleaning.

Steam Cleaning Hard Floors and Refreshing Carpets

WARNING!

To reduce the risk of personal injury, unplug cord

from electrical outlet and let the unit/accessories cool

down completely before handling.

NOTICE

• Do not leave the steam cleaner in one spot on any surface

for an extended period of time with a damp or wet

microber cleaning pad attached. This may damage the

oor surface.

• The steam cleaner should only be used on tiles,

linoleum, or sealed wood ooring. Do not use on

laminate ooring.

• Always use the microber cleaning pad when cleaning hard

oors or refreshing carpets. Ensure microber cleaning pad

is in place and properly attached to the oor head.

• When refreshing a carpet the carpet must be dry and

vacuumed thoroughly before using the steam cleaner.

The force and heat of the steam may have an adverse effect

on some materials. Always test the steamer on a small

concealed area to determine if it is suitable for

treatment.

1. Ensure the proper accessory

is attached to the oor head.

Hard Floors: Microber

cleaning pad

Carpet: Microber cleaning

pad and carpet glider.

2. Plug the power cord into a

polarized electrical outlet.

Wait for the Steam tank/

power indicator to turn green.

3. Place your foot on the oor

head and recline the handle.

4. Pull the trigger to produce

steam. Do not pull the

trigger continuously, this

will cause water puddles

and potential damage to

the oor.

5. Move the steam cleaner

slowly back and forth across

the oor.

Clean Up after Use

WARNING!

To reduce the risk of personal injury, unplug cord

from electrical outlet and let the unit/accessories cool

down completely before handling.

Empty the Water Tank

1. Remove the water tank.

2. Over a sink, turn the cap counter-

clockwise and remove the cap on

the water tank. Empty the water and

replace the cap on the water tank.

3. Place the water tank back in the

steam cleaner.

Remove the Microfiber Cleaning Pad

1. Pinch the drawstring

clasp and pull the clasp

back to loosen the pad.

2. Remove the Microber

Cleaning Pad over the

oor head.

WARNING!

To reduce the risk of personal injury, unplug cord

from electrical outlet and let the unit/accessories cool

down completely before handling.

Cleaning the Microfiber Cleaning Pad

1. Using mild detergent, machine wash at maximum

104° F (40° C).

2. Allow the pad 24 hours to dry.

NOTICE

Never use bleach or fabric softener when washing the

microber cleaning pad.

Maintenance

NOTICE

• The condition of the hard water lter affects the perfor-

mance of the steam cleaner. The interval between lter

replacement depends on the hard water conditions and the

level of usage.

Replacing the Hard Water Filter

The hard water lter will help lter minerals that reduce the

effectiveness of the steam cleaner. Depending on hard water

conditions and/or frequency of the lter should be replaced

every 6 months.

Trouble-

shooting

Problem Check Solution

Cleaner will

not run

• Not plugged in

properly.

• Wall outlet is

faulty.

• The power cable

is damaged.

• Be sure vacuum is

rmly plugged into

wall outlet.

• Check electrical

source – fuse or

circuit breaker.

• If power cable is

damaged, contact

Oreck for service.

Steam is not

emitted when

the steam

cleaner is ON.

• Water tank is

empty.

• Hard water lter

is clogged.

• The steam switch

is not activated

properly.

• Fill water tank.

• Change water lter.

• Pull the trigger on

the handle to release

steam.

Unit still does

not operate

properly.

Check all the above

points.

Contact Oreck for

service.

Service problems that appear to be major can often be solved

easily. You can be your own troubleshooter by reviewing this

guide. All other servicing should be done by an Oreck

authorized service center.

Parts

Item Number

Replacement Parts

Hard Water Filter STEAMFLTR75

Pack of (4) Microber

Replacement Bonnets

STEAMKIT75

To order, call our customer service group or visit our website.

Please have your model number from the data label on the

bottom of the unit.

Warranty

Steam 75

Steam Cleaner

ORECK MANUFACTURING COMPANY: (Oreck Manufacturing

Company gives you the following limited warranty for this product

only if it was originally purchased for residential use, not resale, from

Oreck or an Oreck Authorized Retail Dealer.)

Oreck will repair or replace, free of charge, to the original purchaser,

any part that is found to be defective in material or workmanship

within one (1) year of the date of purchase. This limited warranty

applies to normal domestic use. Any commercial use of this product

will void this limited warranty.

This limited warranty does not cover the replacement of expendable

or consumable parts such as carpet bonnet and hard water lter or

other parts subject to normal wear unless they are defective in mate-

rial or workmanship.

This limited warranty does not apply to any part subjected to acci-

dent, abuse, commercial use, alteration, misuse, damage caused by act

of God, the use of voltages other than indicated on the serial number

displayed on this product or service of this product by other than

Oreck or a participating Factory Authorized Service Center. Oreck

does not authorize any person or representative to assume or grant

any other warranty obligation with the sale of this product.

Oreck’s limited warranty is valid only if you retain proof of purchase

from Oreck or an Oreck Authorized Retail Dealer for this product.

If you purchase this product from any other source, your purchase is

“AS IS,” which means Oreck grants you no warranty, and that you,

not Oreck, assume the entire risk of the quality and performance of

this product, including the entire cost of any necessary servicing or

repairs of any defects.

Oreck’s liability for damages to you for any costs whatsoever aris-

ing out of this statement of limited warranty shall be limited to the

amount paid for this product at the time of original purchase, and

Oreck shall not be liable for any direct, indirect, consequential or

incidental damages arising out of the use or inability to use this prod-

uct. Some states do not allow the exclusion or limitation of incidental

or consequential damages, so the above limitation or exclusion may

not apply to you.

ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS

PRODUCT, INCLUDING IMPLIED WARRANTIES OF MER-

CHANTABILITY AND FITNESS FOR A PARTICULAR PUR-

POSE, ARE LIMITED IN DURATION TO THE WARRANTY

PERIOD, AND NO WARRANTIES, WHETHER EXPRESS OR

IMPLIED, WILL APPLY AFTER THIS PERIOD.

Some states do not allow limitations on the duration of implied war-

ranties, so the above limitation may not apply to you.

This warranty gives you specic legal rights, and you may also have

other rights which vary from state to state. If appropriate, see ad-

ditional information for extended warranty.

congurations and registered trademarks are owned and used

under the authority of Oreck Holdings, LLC

53543-01 REV A 08/10 ECN R-10093

Oreck Steam75 Owner S Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
