Oregon Scientific Global Distribution 011813 MEEP X2 User Manual QuickStartGuide US R6

Oregon Scientific Global Distribution Limited MEEP X2 QuickStartGuide US R6

User Manual

C
M
Y
CM
MY
CY
CMY
K
11 22 33
4
455 66 77
(a) Select your language and time zone
(b) Choose an available Wi-Fi network on your MEEP!X2.
If you skip this process, you can later visit the
Settings page on the right hand menu bar to setup
the Wi-Fi.
(c)
You can then choose to set up the parental controls
on the MEEP!X2 (please refer to the “On-device
parental settings” section for details). If you skip this
process, you can tap on the “Parental Settings” icon
on the left hand menu bar to set the parental
controls.
When new features and/or new functionalities are
available, we will provide you with a software
upgrade (Over the Air upgrade, known as OTA). We
strongly recommend you proceed with it.
Tap on the Games & Apps icon on the right hand
menu bar of the MEEP!X2 and open the MEEP! OTA
App.
Tap on the ‘Download and install on the MEEP!’
button to download the OTA.
You can also download the new SW upgrade
through PC.
Visit http://www.meeptablet.com/ota/
for details.
If you need further assistance, please access the
Online User Manual by tapping the Help icon on
the right hand scroll menu and selecting User
Manual or contact us at 1-800-853-8883.
You can now enjoy the MEEP!X2 and its preloaded
content!
The following steps will help you setup your
MEEP!X2 quickly for your child.
2
Make sure that your MEEP!X2 is connected to the
internet by checking the blue Wi-Fi icon on the
bottom right corner of the screen. In addition,
make sure that the MEEP!X2 is connected to the
adaptor before to proceed with the OTA update.
2
Press on the power button until the screen turns
on. This may take a few seconds.
1
Start up your
111
1
Your MEEP!X2 will automatically reboot after the
OTA installation.
222How to do the OTA upgrade?
3
On-device Parental Settings
333
The MEEP!X2 must be registered by an adult in order
for the child to gain online access. This is to ensure
parents can set up the MEEP!X2 with as much
restriction or allowance as they desire for their child.
Please note that even if you don't set the parent
controls, your MEEP!X2 will still be protected against
improper usage (bad word ltering, black listed web
sites).
Make sure that your MEEP!X2 is connected to the
internet.
If you don’t own a parent account, select NO so
that you can setup a new account.
1
2Enter your personal information as well as your
child information.
3
3
Open the conrmation email that has been sent to you
to conrm your new account.
4
45
5
6
6
7
7
Remember to set your parental settings before
leaving.
If you already own a parent account, select YES
so that you can synchronize the new MEEP!X2 to
your account.
Log into the Parental Settings and follow the
dierent steps in order to set up the parental
controls.
You can also adjust the parental settings by
(a)
Visiting https://portal.meeptablet.com using
a browser on PC, Mac®, iPad® which support
html5.
(b) Using our iOSTM or AndroidTM ‘MEEP! Together’
apps downloadable from the Apps StoreSM
and Google Play™.
Enter your child’s information
C
M
Y
CM
MY
CY
CMY
K
How to Connect the Microphone
Connect the microphone (not included / sold
separately) to the MEEP!X2 as shown.
1
How to Connect the Headphone
Connect the headphone (not included / sold
separately) to the MEEP!X2 as shown.
1
How to Handle Memory Cards
Insert the memory card (Not included) into the
memory card slot under the silicone skin of the
MEEP!X2
1
The memory card is exchangeable with any other
memory card up to 32 GB. Ask your parents to
replace it by pressing the card.
2
How to charge
Connect the adaptor to the
MEEP!X2 as shown.
1
Ask your parents to plug the
other end of the adaptor to
a wall outlet.
2
If you charge the MEEP!X2
when it is ON, you should see
a battery icon on the screen.
3
4 If you charge the MEEP!X2
when it is OFF, a charging
icon will be shown on the
screen promptly.
Adaptor connected
How to connect to a TV or a Display
Ask your parents to connect a HDMI® cable (not
included) to the MEEP!X2 before connecting it to a
TV or a display that supports HDMI® functions.
1
Troubleshooting
At Oregon Scientic, we are continually optimizing our
information so as to bring the best possible experience. Every
eort has been made to ensure the accuracy and appropriateness
of the information behind the core of every product.
Nonetheless, errors can sometimes occur. We stand behind our
innovations, and we encourage you to call our Consumer
Services Department with any problems and/or suggestions you
might have. Our service representatives are always on hand to
respond to your needs. For the most updated guidelines and
support, please visit:
http://www.meeptablet.com
or contact us at our hotline below.
Conforms to safety requirements of ASTM F963, EN71 Parts 1, 2 &
3 and EN62115. In an eort to continually improve our products,
the actual screen display on the product may dier slightly from
the diagrams shown. Please retain this quick start guide for future
reference.
Oregon Scientif i c, Inc.
19861 SW 95th Avenue
Tualatin, OR 97062, USA
Hotline: 1-800-853-8883
Service: http://us.oregonscientif i c.com/service
Website: http://us.oregonscientif i c.com
Warning:
Changes or modif i cations to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the equipment.
Not suitable for children under 3 years as small parts may be generated.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• CAUTIONS : Children 8 years old and below should not be permitted
to access the battery charger. Before allowing a child to use the
battery charger, always ensure that they receive thorough
explanations on how to handle the device in the safest manner. Please
explain that the battery charger is not a toy and must only be used for
its intended purpose.
• Instruct the child not to recharge non-rechargeable batteries because
of the danger of eruption.
• Examine the battery charger regularly for damage,
especially the cord, plug and enclosure. If the battery charger is
damaged, it must not be used until it has been repaired.
• At full power, the prolonged listening of the walkman can damage the
ear of the use.
• Maximum output voltage £ 150mV
• The terms HDMI and HDMI High-Denition Multimedia Interface, and
the HDMI Logo are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries."
• Mac®, Safari® and App StoreSM are trademarks of Apple Inc.
• Google™ is a trademark of Google Inc.
DISPOSAL
Do not dispose of this product as unsorted
municipal waste.
Such waste should be collected separately for
special treatment.
System Hang-Ups
Ask your parents to use a pin to press 'Reset'. Please
remember that any unsaved progress will be lost after
the reset.
IMPORTANT NOTE: All the applications and games on your
MEEP!X2 will be lost after the factory reset. However, you will be
able to recover for free in the MEEP! Store.
!
1
To proceed with a complete Factory Reset, go to the
"Settings" and tap on "Factory data reset", located under
"Backup & reset".
2
88 99 1010 1111
1212 1313 1414 1515
P/N: 300103459-00001-10
HIGH-DEFINITION MULTIMEDIA INTERFACE
