500

SERIES

SpeedTouch™510/510i

Multi-user ADSL gateway

Using the Internet can be frustrating if you have a slow

response time, especially when you have several PCs

connecting simultaneously. But not anymore. Surfing takes on

a whole new dimension with the SpeedTouch 510 – and with

the SpeedTouch 510i designed specially for ADSL over ISDN.

Powerful tools for residential users, the new SpeedTouch 510

and 510i are also perfect for small and home offices (SOHO):

they’re the ideal solution for multi-PC users, regardless of

configuration or location. If you’re looking for a bandwidth

builder, take a closer look at the SpeedTouch 510/510i.

Easy installation

With the SpeedTouch 510/510i, you can install residential gateways

with incredible ease.

You're only five clicks away from the Internet. Just connect your PC,

laptop or local area network to the modem over an Ethernet

interface and you are ready to go. An advanced setup wizard guides

you through the set-up.

Because the router comes with an integrated PPP-client, no software

needs to be installed on the PC itself, increasing overall functionality.

Home networking

This router is the ideal solution for residential users and for small

and home offices where there is an urgent need to share ADSL access,

along with other family members or colleagues.

Residential users will especially appreciate the fact that PCs, game

consoles, PDAs and other devices can instantly connect to

the Internet through a single high-speed ADSL point of access.

Connecting your LAN to the Internet is a snap thanks to

an integrated 4-port Ethernet switch that allows you to connect four

PCs directly, without requiring an extra hub.

Security

This ADSL residential gateway has a built-in firewall that denies

unauthorized access to all PCs and Internet devices hooked up to

the user's broadband ADSL connection.

This powerful firewall can be configured by end-users, equipment

retailers or service providers for a broad range of security policies

and requirements.

Attacks are stopped in the router and will not reach the PCs. With

the SpeedTouch 510, you’ll be secure 24/7.

Rapid access for all

Built for excellence

Hardware specifications

• Interfaces:

- LAN for POTS version:

• 10Base-T (RJ-45)

• 4-port 10Base-T switch (RJ-45)

- LAN for ISDN version:

• 4-port 10Base-T hub (RJ-45)

- WAN: ADSL line (RJ-11)

• Dimensions: 35 x 210 x 185 mm

(1.38 x 8.27 x 7.29 in.)

• Temperature: 0° to 40° C (32 to 105 F)

• Humidity: 20% to 80%

• AC voltage: 100 to 120, 220 to 240 V AC

• Frequency: 50/60 Hz

ADSL modem specifications

• ADSL (ANSI, G.dmt, G.lite, lite (automode and selection))

• Up to 8 Mb/s downstream, 832 Kbps upstream

Package content

• 1 SpeedTouch 510 or 510i

• Power unit and cables (ADSL & Ethernet)

• CD with setup wizard and user’s guide

• Quick installation guide

• In-line filters (optionally)

Services

• Ethernet bridging

• IP routing

• NAPT, DHCP, DNS

• Embedded firewall

• WAN protocol model:

- PPPoE, PPPoA, MER, CIP

- PPTP-to-PPPoA relay and DHCP-to-PPP spoofing

Management

• OS independent

• User friendly web interface

• Telnet access to router

• Software upgradeable

• DHCP server and client

• DNS server and relay

Installation

• UPnP support

• Installation wizard (optional)

For more information: www.speedtouchdsl.com

All rights reserved ©2002, THOMSON multimedia Broadband Belgium.

Printed in EU. 3CL 00371 00022 TQZCA ed. 2

All trademarks are owned by their respective owners.

Product specifications subject to change without prior notice.

Technical summary

SpeedTouch 510/510i

Multi-user ADSL gateway
