Orient Link SW0029 Bluetooth Speaker User Manual SW0029 25 LANGUAGE MANUAL 003 721 648 20160411
Orient Link Limited Bluetooth Speaker SW0029 25 LANGUAGE MANUAL 003 721 648 20160411
user manual
Model no.: SW0029
SIZE: 180x780mm
DATE:2016-Apr-11
English
INSTRUCTION MANUAL
Bluetooth Speaker
Parts:
1 - MicroUSB Type B female socket (charging and update port)
2 - 3.5mm stereo phone jack (AUX input)
3 - LED indicators (red LED on means charging and LED off means end of charging; blue LED on
means bluetooth pairing and LED off means end of pairing)
4 - Power switch: on/off
5 - Previous Song (short press), Volume - (long press)
6 - Play / Pause key
7 - Next Song (short press), Volume + (long press)
Accessories:
USB Charging Cable x 1pc
Audio Cable x 1pc
Specifications:
Product Size: D60 x H50mm
Weight: 125g
Speaker: 40mm 4 ohms
Rated power: 3W
Battery Parameters:
Capacity: 500mAh, 3.7V, Li-ion Battery
Music Playback Time: 5 hours at 70% Volume
Charging Standard: DC 5V, 500mAh
Charging Time: Around 1 hours
Bluetooth Parameters:
Operation Frequency: 2.402GHz - 2.480GHz
Power Output (Peak): Class 2 / 4dbm
Received Sensitivity: -91db, @0.1% BER
Operating Range: Around 10m
Operations with mobile:
1. Turns on the power of speaker
2. Activiate bluetooth in mobile
3. Search the bluetooth devices named as “Swarovski speaker”
4. Pairing
5. Connect and play music
6. Line in mode:
Previous and next song functions cannot be worked. If audio source is disconnected to AUX, it will
go back to bluetooth mode.
Security and Precaution:
1. Please do not strike the product with any blunt or sharp article. Do not throw or drop this
product to avoid causing damages.
2. Please use adapter with output 5.0V-5.5V to charge this product.
3. It must be used with the correct voltage to avoid damage to the product and associated
equipment.
4. The suppliers assume no responsibility for any damages that may happen with the improper
operation of this product.
5. If no power output from the product, you just need to recharge it to make it back to normal.
6. Keep this product in a dry place. Never place or use the product in wet or dirty conditions.
7. Keep away from fire.
8. Never let children to play with it, especially for the accessories.
9. Please do not disassemble and refit our products to change the protection system, it may cause
fire or explosion.
10. Please stop using this product if any abnormalities occur, such as abnormal smell, overheat,
discolor or shape change.
11. Please do not pull in and out with strong force to avoid the damage to the socket and your
devices.
12. It is normal that product will become hot after keep using for a long time.
13. After finished charging your devices, please remove the charging cable to avoid consuming the
capacity of this product.
14. This product has built-in lithium battery, please use carefully.
15. All accessories and adapter (if necessary) will be only used for this product.
16. The designer of this product has the final judgment and the right to amend all mentioned
above.
Compatibility:
Be applicable to most bluetooth devices.
Troubleshooting:
1. Bluetooth is a bidirectional transmitting protocol; transmitting distance is highly related to the
audio player.
2. When the speaker cannot be connected, please delete the rest Bluetooth devices name on the
list of user’s computer / mobile phone. Then, follow the steps in operation instructions.
3. The sound performance could also be affected under poor signal environment , or product is
low battery capacity. Please move the product to environment with strong signal or charging the
product.
Caution:
Please note that this product is not a toy. It is not suitable for children under 15, as small parts and /
or broken parts may present a CHOKING HAZARD.
56 7
241 3
Front
User Manual
SW0029
FCC ID:2AIMJSW0029
IC:21538-SW0029
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions:
