PARTRON PWB100 Croise.E Urban Band User Manual

PARTRON CO., LTD Croise.E Urban Band

User manual

Croise E. Urban Band (PWB-100)
1
CONFIDENTIAL 2
PWB-100 Introduction
Feature
■ Urban Mode
Body condition check & Smart Advice
■ Extreme Mode
Activity Set, check & Alarm, Karvonen Excercise
■ Measure mode
Measuring Body Condition & Environment
■ Measure objects
1. Steps
2. Distance
3. Calorie Burns
4. Heart Rate
5. Body Temperature
■ Goal Setting
1. Running(Walking) Speed & Distance
2. Steps
3. Calorie Burning
4. Sleeping Time
5. Heart Rate
7. Activity Time
8. Sleeping Time & Quality
9. Altitude
Specifications
Display
Language
Sync Method
Water Proof
Battery Time
Compatibility
Rechargeable Battery
Charging
Weight
OLED 128*36
Korean/English/Chiness
BT4.0/BLE
IPX4
4 days @ stand-by
Android (4.2.2 and higher) / iOS
80mAh (Lithium Polymer 3.7V)
DC 5V (Micro USB)
8.5g (Body), 27g (with Band)
1. Accelerometer
2. Gyro
3. Temperature
4. Barometer
5. Heart Rate
Sensor
CONFIDENTIAL 3
Urban Mode
Providing Smart Advice after Checking Activity, Stress and Sleep
CONFIDENTIAL 4
URBAN MODE
Index Description
Sleep •Showing sleep status of last night
•Checking heart rate and turn-over in user’s sleep
Stress •Checking user’s lactate by the heart rate sensor
Recover •Calculating both yesterday’s sleep/activity and today’s stress/activity
until now
Steps •Showing steps from 12AM to now
Distance •Showing distance from 12AM to now
Calorie Burn •Showing calorie burn from 12AM to now
Condition •Showing the gauge of pictogram by average of sleep/stress/recover
CONFIDENTIAL
URBAN MODE
Description
•Touch on Pictogram(Condition)
•Able to check user’s status and history with graphs for 4 items
Step Sleep Calorie Heart Rate
CONFIDENTIAL 6
URBAN : Smart Advice
Smart Advice
•Providing advice on the condition when current status is lower than target
Insufficient sleep Lack of exercise
CONFIDENTIAL 7
Extreme Mode
Providing various data including heart rate for specific exercise
CONFIDENTIAL 8
EXTREME MODE
Walking
Running
Exercise Efficiency
thru. Heart rate
- Cardio Training Zone
-Fat Burning Zone
- Warm Up / Cool Down
CONFIDENTIAL 9
EXTREME MODE
Hiking
Biking
Exercise Efficiency
thru. Heart rate
- Cardio Training Zone
-Fat Burning Zone
- Warm Up / Cool Down
CONFIDENTIAL 10
Measure Mode
Measuring body temp., altitude, heart rate and etc
CONFIDENTIAL 11
MEASURE MODE
Heart rate Altitude
CONFIDENTIAL 12
MEASURE MODE
Body Temp. Swing
Part 15.19 statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Part15.21 statement &KDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHPDQXIDFW XUHURUSDUW\
responsible) for compliance could void the user’s authority to operate the equipment.
Part 15.105 statement
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part
15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference or television reception, which can be determined by powering the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
