PAX Technology A920-LTE Smart Mobile Payment Terminal User Manual
PAX Technology Limited Smart Mobile Payment Terminal
User manual
A920 Wireless POS Terminal
1. Contents Checklist
Please check the components after unpacking. If any one of them is missing, or if there is a page
missing from the product manual, ect., please contact the dealer.
Wireless POS Terminal 1
AC Power Adapter 1
Thermal Paper Roll 1
Battery 1
Cable 1
Product Manual 1
2.Installation
USB port:Connect USB device or PC.
SAM/SIM card:
○
1Open the battery cover on the bottom of the terminal;
○
2Take out the battery;
○
3Insert SAM/SIM card into the corresponding SAM/SIM card slot.
Micro SD card:
○
1Open the battery cove ron the bottom of the terminal;
○
2Take out battery;
○
3Insert Micro SD card into the corresponding Micro SD card slot.
3. Instruction
1） Power ON/OFF
Power on: press and hold the Power button for three seconds until the LCD is lighted up, and then
the terminal is being turned on.
Power off: press and hold the Power button for three seconds until the shutdown menu appears,
tap Power off > Power off, and then “Shutting Down” appears, the terminal is being turned off.
2） Magnetic Stripe Card
Place the magnetic stripe face down, swipe card through the magnetic card slot at a constant speed,
which could be bi-directionally.
3）IC card
Place the chip face down, insert the IC card into the IC card slot, and push it to the end.
4）Tearing off paper
Tear the printing paper toward the 45 degree direction of the paper cutter.
5) Battery charging
User can charge the battery with power adapter, and the charging status will be displayed on the
LCD.
6）Swiping contactless card
Place a contactless card close to the sensor area of swiping which is at the top of the terminal.
4. Installation and Usage Tips
1）Avoid putting the terminal in direct sunlight, high temperature, moist, dusty or explosive
environment. And reduce or eliminate vibration and direct pressure.
2）Forbid non-professional to repair the terminal.
3）Before insert the card, please check internal and around of IC card slot. when you found some
suspicious objects , must report to related administrator.
5.Parameter
Wireless Communication: Support WIFI, Bluetooth, GSM/GPRS, WCDMA, LTE-FDD,
LTE-TDD, UMTS/HSPA+, GPS/BEIDOU/GLONASS, NFC.
Power Adapter: Input: 100-240V AC, 50Hz/60Hz.
Output: 5.0V DC, 2.0A.
Battery: Li-on battery, 52500mAh, 3.7V
Working Environment Temperature: 0℃～50℃(32℉～122℉)
R.H.: 10%～93%( non-condense)
Storage Environment Temperature:-20℃～70℃(-4℉～158℉)
R.H.:5％～95％ (non-condense)
6. Lithium Ion Battery Usage Tips
1）Avoid putting the battery in sunlight or smoke, dusty environment.
2）Forbid crushing, treading, throwing the battery into fire or liquid.
3）Replace the battery immediately if it is damaged(exothermic or distorted).
4）It is recommended changing battery that used more than two years.
7.Caution
Risk of explosion if battery replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Hereby, PAX Computer Technology (Shenzhen) Co., Ltd. declares that the radio equipment type
A920 is in compliance with Directive 2014/53/EU.
To download the full text of the EU declaration of conformity, please visit
http://www.pax.com.cn/ProductCEquery.aspx?code=A920
7. Icon shows
Do not throw away, need professional recycling.
FCC Regulations:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiated radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
FCC RF Exposure Information (SAR)
This device is designed and manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy set by the Federal Communications Commission of the
United States.
During SAR testing, this device is set to transmit at its highest certified power level in all
tested frequency bands, and placed in positions that simulate RF exposure in usage near
the body. Although the SAR is determined at the highest certified power level, the actual
SAR level of the while operating can be well below the maximum value. This is because
the device is designed to operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to a wireless base station
antenna, the lower the power output.
The exposure standard for wireless employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.
The FCC has granted an Equipment Authorization for this model device with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this model device is on file with the FCC and can be found under the
Display Grant section of www.fcc.gov/oet/ea/fccid after searching on
FCC ID: V5PA920-LTE
For this device, the highest reported SAR value for usage near the body is 1.19 W/kg.
While there may be differences between the SAR levels of various devices and at various
positions, they all meet the government requirement.
PAX TECHNOLOGY LIMITED
To know more product details, please visit http://www.pax.com.cn
P/N：200312000000312
