PAX Technology Q30 POS Terminal User Manual

PAX Technology Limited POS Terminal

Contents

User manual

Q30 POS Terminal Instruction Manual
Contents Checklist
Please check the components after unpacking. If any one of them is missing, or if thereis a page
missing from the product manual,ect.,please contact the dealer.
Q30 POS Terminal
1
Adapter cable 1
Product Manual 1
1.Instructions
Q30 POSterminals that include a default communication module come standard with one
Ethernet port and RS232, USB.However, if the default communication module is replaced with an
optional communication module. You can chose these additional network capabilities, such as wifi,
BT and Wireless module. In order to correct using, you should refer to following instructions.
1）Magnetic Stripe Card
Put magnetic stripe side of magnetic card towards device interior, swipe the card with a steady
speed during through magnetic reader slot. (Support bi-directional swiping)
2）IC Card
Put IC card chip side upward, push-in IC card slot and to bottom.
3）Tap contactless card (optional).
Put the contactless card into the sensing areaat the top of LCD
4）SAM/SIM Card
① RemovetheSAM/SIM card cover (At the bottom of the terminal).
②Insert the SAM/SIM card tothe correspondingcard slot.
2. Installation and Usage Tips
1）Avoid putting the terminal in direct sunlight, high temperature, moist, or dusty environment.
2）Forbid non-professional to repair the terminal.
3）Before insert the card, please check internal and around of IC card slot. when you foundsome
suspicious objects , must reportto related administrator.
3. Password Entering Tips:
It is highly recommended to enter password as following ways:
1）Set up peep shields.Enter password with shield by the structures of cashierdesk;
2）Place the POS terminal at an appropriate angle and make sure it is difficult to peer the password.
For example, the POSwas installed above the movable bracket.
3）In enter password perspective, avoid surrounding video surveillance;
4）Pastetext instructions to remind the customers to shelter with body or palm when enter
password.
5）Merchants can also choose other ways to protect the customer input password.
4. Frequency band & transmitting power
The devicesupports 1/2/5.5/11/6/9/12/18/24/36/48/54 Mbps for WIFI2.4GHz b/g
and MCS0~MCS7 for WIFI n-20MHz of transmitting speed and operating frequency is
2412MHz~2462MHz with 11 channels.The device of RF carrier is DSSS (DBPSK / DQPSK /
CCK) and OFDM (BPSK / QPSK / 16QAM / 64QAM)
Bluetooth, frequency: 2402-2480MHz, transmitting power: 9.0dBm
WIFI, frequency: 2412-2462MHz, transmitting power: 15.5dBm
The CLRC663is a highly integrated transceiver IC for contact|ess communication at
13.56MHz.This transceiverIC utillzes an outstanding moduation and demodulation conoept
completely integrated for different kinds of contactless comFnunication methodsand protocoIs
at13.56MHz.
The CLRC663 suppors MIFARE1K,MIFARE4K,MIFARE UlraIight,MIFARE UltaIoht
C,MlFARE PLUS and MIFARE DESFire products.The CLRC663 supports contactless
con1munication and uses the MlFARE highertransfer speeds of up to 848 kbiVs in both directions.
4. Icon shows
Do not throw away, need professional recycling.
Class II Equipment
For indoor use only
Energy Efficiency Marking
AC voltage
DC voltage
The MAINS plug is used as the disconnected device.
FCC Regulations:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
Industry Canada statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
1) this device may not cause interference, and
2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
1) l'appareil ne doit pas produire de brouillage, et
2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
This device and its antenna(s) must not be co-located or operating in conjunction with any
other antenna or transmitter, except tested built-in radios.
Cet appareil et son antenne ne doivent pas être situés ou fonctionner en conjonction avec une
autre antenne ou un autre émetteur, exception faites des radios intégrées qui ont été testées.
The County Code Selection feature is disabled for products marketed in the US/ Canada.
La fonction de sélection de l'indicatif du pays est désactivée pour les produits
commercialisés aux États-Unis et au Canada.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20
cm de distance entre la source de rayonnement et votre corps.
