PAX Technology S500RF EFT-POS Terminal User Manual
PAX Technology Limited EFT-POS Terminal Users Manual
User manual
EFT-POS Terminal Instruction Manual
（S500）
1. Installation
POWER port connects to the external power adapter.
LINE port connects to telephone line.
PINPAD port connects to PINPAD.
RS232 port connects to serial port.
LAN port connects to the network cable (optional).
PHONE port connects to telephone (optional).
2. Instructions
1）Power ON/OFF
Power on：Press the ON/OFF button two seconds until LCD backlight light, the terminal turns on
successfully.
Power off：Press the ON/OFF button two seconds until LCD no display, the terminal turns off
successfully.
2）Magnetic Stripe Card
Put magnetic stripe side of magnetic card towards device interior, swipe the card with a steady speed
during through magnetic reader slot. (Support bi-directional swiping)
3）IC Card
Put IC card chip side upward, push-in IC card slot and to bottom.
4）Tap contactless card (optional).
Put the contactless card into the sensing area above the LCD
5）Shred paper operating Instructions
Make paper 45 degrees angle right to paper knife and shred paper.
3. Installation and Usage Tips
1）Avoid putting the terminal in direct sunlight, high temperature, moist, or dusty environment.
2）Forbid non-professional to repair the terminal.
3）Before insert the card, please check internal and around of IC card slot . when you found some suspicious
objects , must report to related administrator.
4. Password Entering Tips
It is highly recommended to enter password as following ways:
1）Set up peep shields. Enter password with shield by the structures of cashier desk;
2）Place the POS terminal at an appropriate angle and make sure it is difficult to peer the password. For
example, the POS was installed above the movable bracket.
3）In enter password perspective, avoid surrounding video surveillance;
4）Paste text instructions to remind the customers to shelter with body or palm when enter password.
5）Merchants can also choose other ways to protect the customer input password.
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the
body of this equipment is a label that contains, among other information, a product identifier . If requested,
this number must be provided to the telephone company.
RF Exposure Information
This device meets the government’s requirements for exposure to radio waves.
This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency
(RF) energy set by the Federal Communications Commission of the U.S. Government.
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment.
PAX TECHNOLOGY LIMITED
To know more product details, please visit http://www.pax.com.cn
P/N：200312000000198
FCC Caution.
§ 15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
Customer Information
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the
bottom of this equipment is a label that contains, among other information, a product identifier in the format
US: AAAEQ##TXXXX. If requested, this number must be provided to the telephone company.
This equipment uses the following USOC jacks: RJ11C
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply
with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord
and modular plug is provided with this product. It is designed to be connected to a compatible modular jack
that is also compliant. See installation instructions for details.
The REN is used to determine the number of devices that may be connected to a telephone line. Excessive
RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most but
not all areas, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may
be connected to a line, as determined by the total RENs, contact the local telephone company. For products
approved after July 23, 2001, the REN for this product is part of the product identifier that has the format
US:AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point (e.g., 03 is a REN
of 0.3).
For earlier products, the REN is separately shown on the label.
If this equipment PAXMM00BS500RF causes harm to the telephone network, the telephone company will
notify you in advance that temporary discontinuance of service may be required. But if advance notice isn't
practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of
your right to file a complaint with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations or procedures that could
affect the operation of the equipment. If this happens the telephone company will provide advance notice in
order for you to make necessary modifications to maintain uninterrupted service.
If trouble is experienced with this equipment PAXMM00BS500RF, for repair or warranty information, please
contact PAX Technology Inc. and 631247-9660. If the equipment is causing harm to the telephone network,
the telephone company may request that you disconnect the equipment until the problem is resolved.
Connection to party line service is subject to state tariffs. Contact the state public utility commission, public
service commission or corporation commission for information.
If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of
this PAXMM00BS500RF does not disable your alarm equipment. If you have questions about what will
disable alarm equipment, consult your telephone company or a qualified installer.
