Option Globe Surfer 3 Plus Datasheet
User Manual: PDF Option Wireless User Guides
Open the PDF directly: View PDF
.
Page Count: 2
• Quad-band 3G (850/900/1900/2100 MHz)
• Powerful WiFi router (up to 254 connections)
• Fixed DSL backup
• Watchdog feature
• SMS device control
• Full phone functionality
• Storage & printer sharing
• Ethernet ports
• Desktop or wall mount
• Ideal for SOHO and on the move
The ultimate 3G GATEWAY
Voice, data, and more
2. Power up 4. Start surng or
making calls!
3. Connect devices1. Insert SIM for 3G
As part of the continual product improvement process, OPTION reserves the right to alter the specications of this product.
© 2012 OPTION. Option and the Option logo are registered trademarks of OPTION. All third-party trademarks are the property of the respective owners.
Option nv - Gaston Geenslaan 14 - 3001 Leuven Belgium - T +32 16 317 411 - F +32 16 207 164 - www.option.com
DataSheet_v1.4
The ultimate 3G GATEWAY
Voice, data, and more
WLAN
• 802.11 b/g
• WEP, WPA, WPA2, WPA2 Enterprise
(IEEE 802.1x)
• 1-254 simultaneous users
• MAC address blocking
• Possible to disable WLAN radio
Ethernet
• 10/100Mbps Auto MDX – 2 ports
3G (W-CDMA)
• 850/900/1900/2100 MHz
• Receive diversity on all bands
(high and low)
• HSDPA: 14.4 Mbps (Category 10)
• HSUPA: 5.76 Mbps (Category 6)
• UE Power Class 3 (+24 dBm)
E-GPRS
• 850/900/1800/1900 MHz
• GSM Power Class 4 (2 W) for 850/900 bands
• GSM Power Class 1 (1 W) for 1800/1900 bands
• GPRS/EDGE Multislot Class 12
USB
• Support for external USB storage and printers
Voice support (UMTS and GSM)
• RJ11 POTS port
• AMR, FR, HFR voice codecs
• Caller ID on telephone display
• DTMF signal pass through
LAN services
• DHCP server and proxy
• DNS server and proxy
VPN functionality
• VPN pass through
• PPTP and IPSec client and server
• L2TP client
• GRE
• PPPOE
Firewall and gateway features
• Advanced NAT
• MAC address ltering
• Demilitarised Zone (DMZ)
• DoS and intrusion protection
• Stateful Packet Inspection
• Congurable security policies
• Application Level Gateway (ALG) modules
• Event logging
• Dyn DNS
• Time
Hardware specications
• Larger clear LED display showing device
status, WiFi and network status, SMS and
missed calls indicator
• External antenna connector
• External 110-240 V power adapter
• 155 × 120 × 27 mm, 255 g plus power adapter
• Desktop form factor and wall mountable
Environmental
• Operating temperature – for indoor use:
0º C to +40º C, 5 – 95% humidity
• RoHS compliant
Approvals/certications
• All applicable regulatory approvals,
operator and infrastructure IOT
• CE including automotive 2004/104/EC
• FCC
Accessories
Make it truly mobile: Cars, Caravans, Boats
Trucks, Buses etc.
• Car charger
• Converter (DC ->DC)
SIM slot and reset button
Fixed DSL backup
Automatic switch to 3G network
in case of DSL failure
High speed wireless
internet connectivity
Download up to 14.4 Mbps
Upload up to 5.76 Mbps
Powerful WiFi network router
for up to 254 connected users
Quad band 3G
(850/900/1900/2100 MHz)
Perfect for when you are
on the move for business or leisure
Full telephone functionality
via RJ11 port
HDDs and USB printer sharing Ethernet ports
External antenna connector
for enhanced reception in
remote locations
Elegant design
Simple 2-button control
Left button switches on/off
Right button connects/disconnects
from Internet
Front panel display
Power
WiFi on/off
Internet on/off
SMS or missed call
