Cisco STB 5844 Introduction
Generic Model Number
5844
Key features
Non-DVR, BCM 33843 16X4 D-3, BCM 7430 Video SOC at 3k DMIPs, 2GB RAM DDR3, 512 MB Flash,
Pwr Button - 2 LED-4 digit display, Dual IR, Cisco CableCard
Configuration and sellability
Model Number
5844
PID
CAV5844HDC-US-K9
STARS Release Level
74-101626-01
Operating System S/W
Linux
Middleware Type
RP - Axiom
CA and/or DRM used (possibly both)
Powerkey
Software Version (Bootloader)
TBD
Chassis, Front panel and Rear panel Overlay
Top Cover Color
Black Matte
Chassis Color
Black Matte
Front panel Color
Black Gloss
Front panel display type
LED, 2x; 4-digit Green Clock/Channel Display
Descrete LEDs
Home Network LED (Green), SW configurable; 4-digit 7-segment Clock/Channel Display
(Green)
Front panel Key buttons
Power w/Standby Icon and Backlit Power LED
Logo Label on Product
White Text, Explorer 5844HDC, Cisco Logo
Other markings on the product's Front Panel
White text, Home Network,
Explorer® 5844HDC
Rear Panel Overlay
White text on Chassis material; Connector Descriptions: Cable IN, HDMI, Video, L, R, IR In,
ENET, USB 2.0, Power +AC IN
Chassis / housing Type
Plastic
Set-top dimensions
315x188x55 mm
Housing design Style
CISCO 8th Gen STB ID
Basic Hardware
Processor Type and Rev
BCM7430AP
Security mode: DEV or PRODUCTION
Production
Modem Type
DOCSIS 3.0
Modem Vendor Info
BCM33843
Memory
DRAM system + video size
2GB, DDR3
App Flash size and Type (NAND or NOR)
512 MB Flash NAND
Boot Flash size and Type (NAND or NOR)
8MB NOR for BCM33843 (DOCSIS); 4MB NOR for BCM7430 (STB)
DRAM - DOCSIS
128MB, DDR3 x16
Tuners and Inputs / Outputs
Composite video Output
Yes = 1 (Rear)
Analog L/R RCA Outputs
Yes = 1 (Rear)
HDMI Port
Yes = 1 (Rear), 1.4
Cable Tuners
Video Tuners from BCM33843 – up to 6x Video QAMs, QAM64/256, 6MHz Spacing,
In-band 54 MHz to 1002 MHz, -15 dBmV to +15 dBmV
DOCSIS Downstream - 16x 54 MHz to 1002 MHz
DOCSIS Upstream – 4x 5 MHz to 42 MHz
USB Port
Yes = 1 (Rear)
e-SATA Port
No
Ethernet Port
Yes = 1 (Rear), 10/100 - no lights
10/100 Ethernet Switch
No
IR Extender Port
Yes
RF Input
Yes - Type F
CableCARD
Yes
Cabling
Power Cord
Yes - 1.5m, 2 Prong
Home Network Interface
MoCA
Yes - 2.0
Remote Control
IR Remote Support (protocol, frequency)
SA/Cisco - 56 kHz
Motorola Protocol & XMP - 38KHz
RF Remote Support
Yes, RF4CE
Documentation
Quickstart Guide
No
Connection/Installation Manual
No
Setup/User Guide
No
Musicam
Yes
MP3
Yes
AAC-HE (and LC)
Yes
Dolby AC3
No
Dolby Digital Plus (incl. Dolby AC3)
Yes
Dolby Volume
Yes
Macrovision
Yes
HDMI/HDCP
Yes
DLNA
Yes
OCAP
Yes
itaas
Yes
