User Manual (Statement).PDF
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding-type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as a power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
Power Source Warning
A label on this product indicates the correct power source for this
product. Operate this product only from an electrical outlet with the
voltage and frequency indicated on the product label. If you are uncertain
of the type of power supply to your home or business, consult your
service provider or your local power company.
The AC inlet on the unit must remain accessible and operable at all times.
Ground the Product
WARNING: Avoid electric shock and re hazard! If this
product connects to coaxial cable wiring, be sure the cable
system is grounded (earthed). Grounding provides some
protection against voltage surges and built-up static charges.
WARNING: Avoid electric shock and re hazard! Do not locate
an outside antenna system in the vicinity of overhead power lines
or power circuits. Touching power lines or circuits might be fatal.
This product may contain a tuner capable of receiving o-the-air broadcasts.
Notice to Installers
The servicing instructions in this notice are for use by qualied service
personnel only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions, unless
you are qualied to do so.
Protect the Product from Lightning
In addition to disconnecting the AC power from the wall outlet, disconnect
the signal inputs.
Verify the Power Source from the On/O Power Light
When the on/o power light is not illuminated, the apparatus may still be
connected to the power source. The light may go out when the apparatus is
turned o, regardless of whether it is still plugged into an AC power source.
Eliminate AC Power/Mains Overloads
WARNING: Avoid electric shock and fire hazard! Do
not overload AC power/mains, outlets, extension cords,
or integral convenience receptacles. For products that require
battery power or other power sources to operate them, refer to
the operating instructions for those products.
Handling Disposable Batteries
This product may contain disposable batteries. Heed the following warning
and follow the Battery Safety and Battery Disposal instructions below.
WARNING: There is danger of explosion if the battery
is mishandled or incorrectly replaced. Replace only with the
same type of battery. Do not disassemble it or attempt to
recharge it outside the system. Do not crush, puncture, dispose
of in re, short the external contacts, or expose to water or
other liquids. Dispose of the battery in accordance with local
regulations and instructions from your service provider.
Battery Safety
• Insert batteries correctly. There may be a risk of explosion if the batteries
are incorrectly inserted.
• Do not attempt to recharge ‘disposable’ or ‘non-reusable’ batteries.
• Please follow instructions provided for charging ‘rechargeable’ batteries.
• Replace batteries with the same or equivalent type that we recommend.
• Do not expose batteries to excessive heat (such as sunlight or re).
• Do not expose batteries to temperatures above 100°C (212°F).
Battery Disposal
• The batteries may contain substances that could be harmful to the
environment.
• Recycle or dispose of batteries in accordance with the battery
manufacturer’s instructions and local/national disposal and recycling
regulations.
• The batteries may contain perchlorate, a known hazardous substance,
so special handling and disposal of this product might be necessary. For
more information about perchlorate and best management practices
for perchlorate-containing substance, see www.dtsc.ca.gov/
hazardouswaste/perchlorate
Provide Ventilation and Select a Location
• Remove all packaging material before applying power to the product.
• Do not place this apparatus on a bed, sofa, rug, or similar surface.
• Do not place this apparatus on an unstable surface.
• Do not install this apparatus in an enclosure, such as a bookcase
or rack, unless the installation provides proper ventilation.
• Do not place entertainment devices (such as VCRs or DVDs), lamps,
books, vases with liquids, or other objects on top of this product.
• Do not block ventilation openings.
Operating Environment
This product is designed for operation indoors with a temperature range from
32° to 122° F (0° to 50°C). Each product should have adequate spacing
on all sides so that the cooling air vents on the chassis are not blocked.
Protect from Exposure to Moisture and Foreign Objects
WARNING: Avoid electric shock and re hazard! Do not
expose this product to dripping or splashing liquids, rain, or
moisture. Objects lled with liquids, such as vases, should not
be placed on this apparatus.
Note to System Installer
For this apparatus, the coaxial cable shield/screen shall be
grounded as close as practical to the point of entry of the
cable into the building. For products sold in the US and
Canada, this reminder is provided to call the system installer's
attention to Article 820-93 and Article 820-100 of the NEC (or
Canadian Electrical Code Part 1), which provides guidelines
for proper grounding of the coaxial cable shield.
This symbol is intended to alert you that uninsulated voltage
within this product may have sufficient magnitude to cause
electric shock.Therefore, it is dangerous to make any kind of
contact with any inside part of this product.
Ce symbole a pour but d’alerter toute personne qu’un contact
avec une pièce interne de ce produit, sous tension et non
isolée, pourrait être suffisant pour provoquer un choc
électrique. Il est donc dangereux d’être en contact avec toute
pièce interne de ce produit.
This symbol is intended to alert you of the presence of important
operating and maintenance (servicing) instructions in the literature
accompanying this product.
Ce symbole a pour but de vous avertir qu’une documentation
importante sur le fonctionnement et l’entretien accompagne ce produit.
CAUTION: To reduce the risk of electric shock, do not remove cover
(or back). No user-serviceable parts inside. Refer servicing to
qualified service personnel.
WARNING
TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
UNIT TO RAIN OR MOISTURE.
WARNING: Avoid electric shock and re hazard! Unplug
this product before cleaning. Do not use a liquid cleaner or an
aerosol cleaner. Do not use a magnetic/static cleaning device
(dust remover) to clean this product.
WARNING: Avoid electric shock and re hazard! Never
push objects through the openings in this product. Foreign
objects can cause electrical shorts that can result in electric
shock or re.
Service Warnings
WARNING: Avoid electric shock! Do not open the
cover of this product. Opening or removing the cover may
expose you to dangerous voltages. If you open the cover,
your warranty will be void. This product contains no user-
serviceable parts.
Check Product Safety
Upon completion of any service or repairs to this product, the service
technician must perform safety checks to determine that this product
is in proper operating condition.
Protect the Product When Moving It
Always disconnect the power source when moving the apparatus or
connecting or disconnecting cables.
Compliance Information
United States FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against such interference
in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy. If not installed and used in accordance
with the instructions, it may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment OFF and ON, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit di erent from that
to which the receiver is connected.
• Consult the service provider or an experienced radio/television
technician for help.
Any changes or modifications not expressly approved by Cisco
Systems, Inc., could void the user’s authority to operate the equipment.
The information shown in the FCC Declaration of Conformity paragraph
below is a requirement of the FCC and is intended to supply you with
information regarding the FCC approval of this device. The phone
numbers listed are for FCC-related questions only and not intended
for questions regarding the connection or operation for this device.
Please contact your service provider for any questions you may have
regarding the operation or installation of this device.
IMPORTANT NOTE: FCC RF Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and
operated with minimum distance 20cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
CXD01ANI XiD-C Set-Top
Model: CXD01ANI
Manufactured by: Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134 USA
www.cisco.com/go/contacts
Canada EMI Regulation
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la class B est conforme à la norme NMB-
003 du Canada.
AVC VIDEO LICENSE
With respect to each AVC/H.264 product, we are obligated to provide
the following notice:
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO
LICENSE FOR THE PERSONAL USE OF A CONSUMER OR OTHER
USES IN WHICH IT DOES NOT RECEIVE REMUNERATION TO (i)
ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC
VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY
A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC
VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM
MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM.
Accordingly, please be advised that service providers, content providers,
and broadcasters may be required to obtain a separate use license from
MPEG LA prior to any use of AVC/H.264 encoders and/or decoders.
ROVI CORPORATION COPYRIGHT NOTICE
This product incorporates copyright protection technology that is
protected by U.S. patents and other intellectual property rights of
Rovi Corporation. Use of this copyright protection technology must
be authorized by Rovi Corporation, and is intended for home and
other limited viewing uses only unless otherwise authorized by Rovi
Corporation. Reverse engineering and disassembly are prohibited.
Disclaimer
Cisco Systems, Inc. assumes no responsibility for errors or omissions that
may appear in this manual. We reserve the right to change this manual
at any time without notice.
Open Source GNU GPL Statement
Cisco Model CXD01ANI XiD-C set-top(s) may contain, in part, certain
free and/or open source software (“Open Source”) under separate
license terms. Examples of such licenses may include all versions of
the GNU General Public License (GPL), GNU Lesser General Public
License (LGPL), BSD license, MIT license, Mozilla Public License,
Eclipse Public License, Apache license, and others. To nd specic
information regarding the Open Source in your product, including copies
of the applicable license documentation and related information, go to:
(i) for North America http://www.cisco.com/web/consumer/support/
open_source.html, or (ii) for outside North America http://www.cisco.
com/web/consumer/support/open_source.html#international. Once
at the site, search for the product listing and click the related items
identied. If you have any questions or problems accessing any of
the links, contact: spvtg-external-opensource-requests@cisco.com.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its aliates in the U.S. and other countries. To view a list of Cisco’s trademarks, go
to this URL: www.cisco.com/go/trademarks.Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a
partnership relationship between Cisco and any other company. (1110R)
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.
© 2015 Cisco and/or its aliates. All rights reserved. Last Updated: June 2015 Part Number 78-100744-01A0
Printed in China
