IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as a power-supply cord
or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
Power Source Warning
A label on this product indicates the correct power source for this
product. Operate this product only from an electrical outlet with
the voltage and frequency indicated on the product label. If you are
uncertain of the type of power supply to your home or business,
consult your service provider or your local power company.
The AC inlet on the unit must remain accessible and operable at
all times.
Notice to Installers
The servicing instructions in this notice are for use by quali ed
service personnel only. To reduce the risk of electric shock, do not
perform any servicing other than that contained in the operating
instructions, unless you are quali ed to do so.
Note to System Installer
WARNING
TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
For this apparatus, the coaxial cable shield/screen
shall be grounded as close as practical to the point of
entry of the cable into the building.For products sold in
the US and Canada, this reminder is provided to call the
system installer's attention to Article 820-93 and Article
820-100 of the NEC (or Canadian Electrical Code Part
1), which provides guidelines for proper grounding of
the coaxial cable shield.
This symbol is intended to alert you that uninsulated
voltage within this product may have sufficient
magnitude to cause electric shock.Therefore, it is
dangerous to make any kind of contact with any inside
part of this product.
Ce symbole a pour but d’alerter toute personne qu’un
contact avec une pièce interne de ce produit, sous
tension et non isolée, pourrait être suffisant pour
provoquer un choc électrique. Il est donc dangereux
d’être en contact avec toute pièce interne de ce produit.
This symbol is intended to alert you of the presence of important
operating and maintenance (servicing) instructions in the literature
accompanying this product.
Ce symbole a pour but de vous avertir qu’une documentation
importante sur le fonctionnement et l’entretien accompagne ce
produit.
CAUTION: To reduce the risk of electric shock, do not remove
cover (or back). No user-serviceable parts inside. Refer servicing
to qualified service personnel.
Ground the Product
WARNING: Avoid electric shock and re hazard! If this
product connects to coaxial cable wiring, be sure the cable
system is grounded (earthed). Grounding provides some
protection against voltage surges and built-up static charges.
WARNING: Avoid electric shock and re hazard!
Do not locate an outside antenna system in the vicinity of
overhead power lines or power circuits. Touching power
lines or circuits might be fatal.
This product may contain a tuner capable of receiving o -the-air
broadcasts.
Protect the Product from Lightning
In addition to disconnecting the AC power from the wall outlet,
disconnect the signal inputs.
Verify the Power Source from the On/O Power Light
When the on/o power light is not illuminated, the apparatus may
still be connected to the power source. The light may go out when
the apparatus is turned o , regardless of whether it is still plugged
into an AC power source.
Eliminate AC Power/Mains Overloads
WARNING: Avoid electric shock and re hazard! Do
not overload AC power/mains, outlets, extension cords,
or integral convenience receptacles. For products that
require battery power or other power sources to operate
them, refer to the operating instructions for those products.
Provide Ventilation and Select a Location
• Remove all packaging material before applying power to the product.
• Do not place this apparatus on a bed, sofa, rug, or similar surface.
• Do not place this apparatus on an unstable surface.
• Do not install this apparatus in an enclosure, such as a bookcase
or rack, unless the installation provides proper ventilation.
• Do not place entertainment devices (such as VCRs or DVDs), lamps,
books, vases with liquids, or other objects on top of this product.
• Do not block ventilation openings.
Operating Environment
This product is designed for operation indoors with a temperature
range from 32° to 104° F (0° to 40°C). Each product should have
adequate spacing on all sides so that the cooling air vents on the
chassis are not blocked.
Protect from Exposure to Moisture and Foreign
Objects
WARNING: Avoid electric shock and re hazard! Do
not expose this product to dripping or splashing liquids,
rain, or moisture. Objects lled with liquids, such as vases,
should not be placed on this apparatus.
WARNING: Avoid electric shock and re hazard!
Unplug this product before cleaning. Do not use a liquid
cleaner or an aerosol cleaner. Do not use a magnetic/static
cleaning device (dust remover) to clean this product.
WARNING: Avoid electric shock and re hazard!
Never push objects through the openings in this product.
Foreign objects can cause electrical shorts that can result
in electric shock or re.
Service Warnings
WARNING: Avoid electric shock! Do not open the
cover of this product. Opening or removing the cover
may expose you to dangerous voltages. If you open the
cover, your warranty will be void. This product contains
no user-serviceable parts.
Check Product Safety
Upon completion of any service or repairs to this product, the
service technician must perform safety checks to determine that
this product is in proper operating condition.
Protect the Product When Moving It
Always disconnect the power source when moving the apparatus
or connecting or disconnecting cables.
20110316_Cable_Safety
Compliance Information
United States FCC Compliance
This device has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against such interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy. If not installed and used in accordance
with the instructions, it may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment
OFF and ON, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit di erent
from that to which the receiver is connected.
• Consult the service provider or an experienced radio/television
technician for help.
Any changes or modi cations not expressly approved by Cisco
Systems, Inc., could void the user’s authority to operate the
equipment.
IMPORTANT NOTE: FCC RF Exposure Statement:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the
radiator and your body.
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
Worldbox Series STB
Models: Spectrum100-C, Spectrum200-C
Manufactured by: Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134 USA
www.cisco.com/go/contacts
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its a liates in the U.S. and other countries. To view a list of Cisco’s
trademarks, go to this URL: www.cisco.com/go/trademarks.Third-party trademarks mentioned are the property of their respective owners. The use of the word
partner does not imply a partnership relationship between Cisco and any other company. (1110R)
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-De nition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing
LLC in the United States and other countries.
© 2015 Cisco and/or its a liates. All rights reserved. Last Updated: February 2015 Part Number 78-100661-01A0
Printed in China
Canada EMI Regulation
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la class B est conforme à la norme
NMB-003 du Canada.
AVC VIDEO LICENSE
With respect to each AVC/H.264 product, we are obligated to
provide the following notice:
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT
PORTFOLIO LICENSE FOR THE PERSONAL USE OF A
CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE
REMUNERATION TO (i) ENCODE VIDEO IN COMPLIANCE WITH
THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC
VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE
IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE.
ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA,
L.L.C. SEE HTTP://WWW.MPEGLA.COM.
Accordingly, please be advised that service providers, content
providers, and broadcasters may be required to obtain a separate
use license from MPEG LA prior to any use of AVC/H.264
encoders and/or decoders.
ROVI CORPORATION COPYRIGHT NOTICE
This product incorporates copyright protection technology that is
protected by U.S. patents and other intellectual property rights of
Rovi Corporation. Use of this copyright protection technology must
be authorized by Rovi Corporation, and is intended for home and
other limited viewing uses only unless otherwise authorized by Rovi
Corporation. Reverse engineering and disassembly are prohibited.
Disclaimer
Cisco Systems, Inc. assumes no responsibility for errors or
omissions that may appear in this manual. We reserve the right to
change this manual at any time without notice.
Open Source License Statement
Cisco PDS3863 set-top(s) may contain, in part, certain free and/
or open source software (“Open Source”) under separate license
terms. Examples of such licenses may include all versions of the
GNU General Public License (GPL), GNU Lesser General Public
License (LGPL), BSD license, MIT license, Mozilla Public License,
Eclipse Public License, Apache license, and others. To nd
speci c information regarding the Open Source in your product,
including copies of the applicable license documentation and
related information, go to: (i) for North America http://www.cisco.
com/web/consumer/support/open_source.html, or (ii) for outside
North America http://www.cisco.com/web/consumer/support/
open_source.html#international. Once at the site, search for the
product listing and click the related items identi ed. If you have any
questions or problems accessing any of the links, contact: spvtg-
external-opensource-requests@cisco.com.
ODM
information
here
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
