PHAETON PH-01 LED light Bluetooth speaker User Manual

PHAETON MANUFACTURING LLC. LED light Bluetooth speaker Users Manual

Users Manual

1/3
MANUAL FOR for PH-01 LED LIGHT BLUETOOTH SPEAKER
1. The matters needing attention
1.1 Please in room temperature environment storage and use this product;
1.2 Do not expose the product to rain or moisture in the environment;
1.3 Do not throw, to avoid damage caused by falling;
1.4 Do not disassemble the product repair and modification of the product;
1.5 Product external lithium battery, please do not arbitrarily discarded or set onfire, so as to avoid danger!
1.6 This product with recycled lithium battery charge and discharge, it can bereplaced.
2. Reminder
2.1 Is beneficial to prolong the service life of the speaker and your physical and mental health, please do
not listen to the voice in the long time and largevolume of the environment, so as not to damage your
hearing.
2.2 When a fault occurs, immediately turn off the power switch, unplug the USB plug, to prevent
the speaker and other components damaged.
2.3 The electricity shortage will affect the use of distance or Bluetooth Bluetooth system easy
to disconnect, please charge
3. The function button
Each button function ：
Unlocking button, press this button, you can open the left clamp. The product can be
conveniently clipped to the diameter of the umbrella rod on 32-40mm. Note that open
the lamp clip not to overexert, do not attempt tocard into the diameter less than 32mm
and more than 40mm in diameter ofthe umbrella rod. Otherwise it will damage the product.
Long press the on / off, short press the pause / play. Long by 3 secondsboot, indicator
light blue light flashing, enter the Bluetooth pairing state,after the connection of
Bluetooth, the indicator light blue light on.
Press up a song, long press the volume decrease
Short press a song, long press the volume amplification
Charging port, charging indicator light flashes red, when filled with lights.
Lights on / off
2/3
4.The installation of the product:
4.1 open the battery cover to remove the battery, then the head of the battery insulation post tear; put
the battery into the battery box (note box +\-extremely to battery +\- polar alignment), cover of battery box.
4.2 Press the unlock button ,the sound of the left and right clamping opening,the stereo left and right on
the umbrella rod the clip, at the sound isarranged on an umbrella rod.
5.Technical parameters of product:
5.1The double channel output, Bluetooth to receive the largest distance: 10 meters
5.2 Speaker specifications: double magnetic, 36mm diaphragm horn
5.3 The maximum output power: 2W X 2
5.4 Sensitivity: 80db+2db
5.5 SNR: greater than or equal to 80dB
5.6 External battery: rechargeable lithium battery 3.7V 2200mAh 18650 models,takes about 3-4 hours for
a full charge
5.7 Product specifications: 160mm x 160mm x 54mm
5.8 Single player Speaker: continuously for about 4 hours
5.9 Single continuous lighting: about 6 hours
5.10 At the same time: about 3 hours of continuous use
6.Packaging containing
6.1 Light speakers: 1pcs
6.2 2M USB charging cable: 1pcs
6.3 The 18650 type of battery: 1pcs
6.4 USB charger of 5V and 1A: 1pcs (optional)
6.55 Manual : 1pcs
3/3
7．Instructions for use:
7.1 LED lamp lighting：Use directly to open or close the lighting switch
7.2 Bluetooth connection: After power on, the sound box automatically enter the Bluetooth
connectionpriority waiting state, the blue lights flash; automatic pairing, Bluetooth devices will be
prompted whether pairing, equipment search model for "PH-01" click pairs, after a successful
connection, the blue light, speaker will issue has connected tone. The machine has the function
of back coupling,after a successful connection device to open Bluetooth again will automatically
connect.
7.3 Bluetooth music player：Bluetooth music player，During playback long press " 、"
volume adjustment，Of course, adjust volume can also be regulated directly in the player .
Short press" 、" ,upward or downward selection .
Bluetooth playback short press" " , pause / play.
7.4 ntelligent automatic fast charge：The off state of charge. Power line will provide Mini USB
attachment end is inserted into the speaker USB power socket, the other end is connected with
the USB charger, charging starts, filled the red light.
8．Solutions of common problems
The solution method
Multiple connection
pairing is not successful
1. Check audio is in search, or reboot .
2. Neighboring Bluetooth devices too much, cause the search
difficult, close other Bluetooth devices .
The voice of small or
distortion
1.Detection of Bluetooth device volume, adjust the volume to the
appropriatelocation .
2.Please charge the battery voltage is low.
Music staccato
If it is beyond the sound and effective connection
distance, or speaker andBluetooth devices with obstacles.
Bluetooth status
indication not bright
1.Said battery power is insufficient, please try again with.
2.Reboot
3.Check audio is in search, or reboot.
4.Neighboring Bluetooth devices too much, cause the search
difficult, close other Bluetooth devices. Check the sound is
in search, or reboot.
Phenomenon
problem
