USERS MANUAL 2
30 Use more of your phone
8 Use more of your
phone
8.1 Switch the handset on/off
Press h for at least one second to
switch the handset on. To switch it off,
press and hold h in idle mode for at
least 5 seconds.
8.2 Keypad lock/unlock
Press and hold * for 3 seconds to lock/
unlock the keypad in idle mode.
8.3 Text or number entry
When you select a field in which you can
enter text, you can enter the letters that
are printed on the keys by pressing the
relevant key once or several times. For
example, to enter the name “PA U L”:
1Press 7 once: P
2Press 2 once: PA
3Press 8 twice: PAU
4Press 5 three times: PAUL
The table below gives you the character
assignment during text or number entry:
•Press c Clear to delete the last
digit or character entered or long
press to delete all.
• Short press # to shift between
lowercase and uppercase.
•Long press # to insert a pause.
8.4 Call in progress
Some options are available to you during
a call. The available options are :
8.4.1 Adjust earpiece or speaker
volume
During a call, press n to select from
level 1 to level 5.
8.4.2 Mute/Unmute microphone
When the microphone is muted, your
correspondent cannot hear you.
1During a call, press s to turn off
the microphone.
2Press s again to turn on the
microphone.
8.4.3 Activate/Deactivate
loudspeaker mode
Handsfree activation can suddenly
increase the volume in the earpiece to a
Keys Assigned characters
0. 0 , / : ; “ ‘ ! ¡ ? ¿ * + - % \ ^
~ |
1SPACE 1 @ _ # = < > ( ) &
€ £ $ ¥ [ ] { } ¤ §
2a b c 2 à æ ä å
3d e f 3 è é Δ Φ
4g h i 4 ì Γ
5j k l 5 Λ
6m n o 6 ñ ö ò
7p q r s 7 ß Π Θ Σ
8t u v 8 ù ü
9w x y z 9 ø Ω Ξ Ψ
Tip
Danger
Keys Assigned characters
01GB01COV.book Page 30 Wednesday, January 16, 2008 1:30 PM
31
Use more of your phone
very high level. Make sure the handset is
not too close to your ear.
1During a call, press l to activate
the loudspeaker mode.
2Press l again to return to
deactivate the loudspeaker mode.
8.5 Using your Phonebook
Your phone can store up to 200
phonebook memories. Each phonebook
entry can have a maximum of 24 digits
for the phone number and 14 characters
for the name.
All names and numbers in the
phonebook must be unique.
If you have more than one handset, the
phonebook can only be accessed by one
user at a time.
8.5.1 Store a contact in the
phonebook
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2New Entry is highlighted; press
o Select.
3Enter Name is displayed. Enter
the name of the contact (maximum
14 characters) and press o OK.
4Enter Number is displayed. Enter
the number (maximum 24 digits)
and press o OK.
• A validation tone is emitted.
•Press c Clear to delete the last
digit or character entered or long
press to delete all.
• To return to the previous menu, press
c Back.
You cannot store a new phonebook
entry when the memory is full. In this
case, you have to delete existing entries
to make space for new entries.
8.5.2 Access phonebook
1Press d in idle mode and scroll
n to browse the phonebook. (You
can also access the phonebook
through the menu mode. m➝
Phonebook ➝ List)
• The phonebook entries will be
listed in alphabetical order.
2To view the details, press o
View.
Instead of scrolling n to browse the
phonebook entries, you can press the
numeric key corresponding to the first
letter of the entry you wish to locate.
For example, pressing 2 will show the
entries starting with A. Pressing 2 again
will show the entries starting with B, etc.
3Press t to dial the number. (Press
h to return to idle mode.)
8.5.3 Modify a phonebook entry
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
Note
Note
Tip
Tip
01GB01COV.book Page 31 Wednesday, January 16, 2008 1:30 PM
32 Use more of your phone
2Scroll n to Edit Entry and press
o Select.
3Scroll n to select an entry to edit.
4Press o Select to display the
name.
5Press c Clear to erase the
letters one by one.
6Edit the name and press o OK to
confirm.
7Edit the number and press o OK
to confirm.
• A validation tone is emitted.
While editing, press c Clear to delete
the last digit or character entered or
long press to delete all.
8.5.4 Select phonebook melody
With this function you can personalize
the melody played when someone in the
phonebook calls you.
You need to subscribe to Caller Line
Identification service to be able to
benefit from this feature.
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Select Melody and
press o Select.
3Scroll n to the entry you want to
select a melody for, then press o
View.
4The screen shows the melody
currently selected for that entry.
Press o Change to change the
melody.
5Scroll n the list of melodies.
(There are 15 melodies to choose
from. The melodies play as you
scroll through them.)
6Press o Select to select the
melody you prefer.
• A validation tone is emitted and
the screen returns to the
Phonebook menu.
When first ring detection is set On, a
normal tone sounds first, then it changes
to the personalized phonebook melody.
When it is set Off, the personalized
phonebook melody plays from the start.
See Section 10.12 for how to set first
ring detection On or Off.
8.5.5 Delete a phonebook entry
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Delete and press o
Select.
3Scroll n to select an entry to
delete and press o Select.
4Delete? is displayed on the screen.
Press o OK to confirm deletion.
• A validation tone is emitted.
Press c Back to discard the deletion.
The screen returns to the phonebook
list.
Note
Note
Note
Note
01GB01COV.book Page 32 Wednesday, January 16, 2008 1:30 PM
33
Use more of your phone
8.5.6 Delete all phonebook entries
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Delete All and press
o Select.
3Delete All? is displayed on the
screen. Press o OK to confirm
deletion.
• A validation tone is emitted.
8.5.7 Direct Access Memory
There are 7 direct access memories
(Keys 3 to 9) included in the
phonebook memory. A long press on the
keys in idle mode will automatically dial
the stored phone number.
Key 1 is reserved for use with
Voicemail in the network services menu.
If you subscribe to this service, this
allows you to dial your voice mail access
number using key 1.
8.5.7.1 Add/Edit Direct Access
Memory
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Direct Memory and
press o Select.
• The current number stored in
the direct access memory
location will be displayed. If no
number is stored, No number
will be displayed.
3Scroll n to the key you wish to
edit (key 3 to 9) and press o
Menu.
4Scroll n to Edit and press o
Select.
5
The Phonebook list will be displayed.
Scroll
n
to the Phonebook entry
you wish to store in the selected
direct access memory number and
press
o
Select
.
6Press o OK to confirm.
• A validation tone is emitted and
the screen returns to the
previous menu.
8.5.7.2 Delete Direct Access
Memory
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Direct Memory and
press o Select.
3Scroll n to the key you wish to
delete the memory from and press
o Menu.
4Scroll n to Delete and press o
Select.
• A validation tone is emitted and
the screen returns to the
previous menu.
8.6 Using the Redial list
The redial list stores the last 10 numbers
dialed. A maximum of 32 digits can be
displayed for each entry.
Note
01GB01COV.book Page 33 Wednesday, January 16, 2008 1:30 PM
34 Use more of your phone
8.6.1 Access Redial list
1Press r to go to the redial list and
scroll n to browse the redial list.
• The last number dialed will
appear first in the redial list. If
the redial number matches a
phonebook entry, the name will
be displayed instead.
2To open the redial list options, press
o Menu.
Press c Back to return to the
previous menu.
8.6.2 View redial number details
1Press r in idle mode, scroll n to
select an entry and press o
Select.
2View is highlighted on the screen;
press o Select to display
information about the number
dialed.
3Press o Next to display further
information. Afterward, you can
press o Prev. to return to the
former screen. After viewing, press
c Back to return to previous
menu levels.
8.6.3 Save a redial number into the
phonebook
1Press r in idle mode, scroll n to
select an entry and press o
Select.
2View is highlighted on the screen.
Scroll n to Save Number and
press o Select.
3Enter Name is displayed. Enter
the name of the contact (maximum
14 characters) and press o OK.
4Enter Number is displayed and
the selected number from the redial
list appears in the number field. At
this time you can edit the number if
you wish to.
5Press o OK. The screen returns
to the redial list.
Press c Clear to delete the last digit
or character entered. Long press c
Clear to clear the entire entry.
8.6.4 Delete a redial number
1Press r in idle mode, scroll n to
select an entry and press o
Select.
2Scroll n to Delete and press o
Select.
3Delete? is displayed on the screen.
4Press o OK to confirm deletion.
• A validation tone is emitted.
Press c Back to discard the deletion.
The screen returns to the previous
menu.
8.6.5 Delete all redial numbers
1Press r in idle mode, and press
o Select.
2Scroll n to Delete All and press
o Select.
3Delete All? is displayed on the
screen.
4Press o OK to confirm deletion.
Note Note
Note
01GB01COV.book Page 34 Wednesday, January 16, 2008 1:30 PM
35
Use more of your phone
• A validation tone is emitted.
8.7 Call waiting
If you have subscribed to Call Waiting
services, the earpiece will emit a beep
tone to inform you that there is a second
incoming call. The number or name of
the second caller will also be displayed if
you have subscribed to Caller Line
Identification service (CLI). Please
contact your network provider for more
information on this service.
To answer the second call, press t.
8.8 Using the Call log
The call log stores the last 50 external
calls and any new voice mail received. In
idle mode, the icon flashes on the
display for new and unanswered calls. If
you have subscribed to Caller Line
Identification (CLI), and provided the
identity of the caller is not withheld, the
name (or number) of the caller will be
displayed.
During CLI display, you can press # to
toggle area code and long distance code
display on/off.
If the identity of the caller is withheld or
the network does not provide the date
and time information, then the
information will not be displayed in the
call log. If you have not subscribed to
Caller Line Identification service, there
will not be any caller information
displayed in the call log.
8.8.1 Access the Call log
1Press u in idle mode, press o
Select to select Call List, and
scroll n to browse the call log.
• The calls (missed and received)
are displayed in chronological
order with the most recent call
at the top of the list. If the call is
unviewed and unanswered, New
appears on the display. After you
view the message, New
disappears.
•Press t to dial out the number
of the selected call log entry.
2To view the call details, press o
Menu and then press o View.
The display shows the caller
information.
•Press c Back at any time to
return to the previous menu.
8.8.2 Save call list entry into the
phonebook
1Press u in idle mode, press o
Select to select Call List, then
scroll n to select an entry and
press o Menu.
2Scroll n to Save Number and
press o Select.
3Enter Name is displayed on the
screen. Enter the name of the
contact (maximum 14 characters)
and press o OK.
4Enter Number is displayed and
the selected number from the call
list appears in the number field. At
this time you can edit the number if
you wish to.
Note
01GB01COV.book Page 35 Wednesday, January 16, 2008 1:30 PM
36 Use more of your phone
5Press o OK.
• A confirmation tone sounds and
the screen returns to call log.
Press c Clear to delete the last digit
or character entered or long press to
delete all.
8.8.3 Delete a call list entry
1Press u in idle mode, press o
Select to select Call List, then
scroll n to select an entry and
select o Menu.
2Scroll n to Delete and press o
Select.
3Delete? is displayed on the screen.
4Press o OK to confirm deletion.
• A validation tone is emitted, the
call list entry is deleted, and the
display goes to the next entry in
the call list.
Press c Back to discard the deletion.
The screen returns to the Call List
menu.
8.8.4 Delete all call list entries
1Press u in idle mode, press o
Select to select Call List, and then
press o Menu.
2Scroll n to Delete All and press
o Select.
3Delete All? is displayed on the
screen. Press o OK to confirm
deletion.
• A validation tone is emitted. The
display shows List Empty for 2
seconds and returns to the idle
mode.
8.9 Using the Intercom
Intercom and call transfer is only possible
when you have at least 2 handsets
registered to the same base station.
It allows you to make free internal calls,
transfer external calls from one handset
to another and use the conference option.
8.9.1 Intercom another handset
If the handset does not belong to SE650/
655 range, this function may not be
available.
1Press i in idle mode.
• Intercom is established
immediately if there are only 2
registered handsets.
2If there are more than 2 registered
handsets, scroll n to select the
handset to call and press o OK.
• Once the intercom call is
answered the icon is displayed
on both handsets.
3Press t on the called handset.
• The intercom is established.
Pressing h on any handset will exit
intercom mode and return other
handsets to idle mode. If an external call
arrives during intercom mode and you
want to accept this call, you must first
exit intercom mode.
Note
Note
Warning
Note
Note
01GB01COV.book Page 36 Wednesday, January 16, 2008 1:30 PM
37
Use more of your phone
8.9.2 Transfer an external call to
another handset
1During the call, press i to put the
external call on hold (the caller can
no longer hear you).
• The display shows the numbers
of the handsets registered to the
base.
2Select n the handset number you
wish to transfer your external call
to and press o Select.
3Press t on the called handset to
answer the internal call, where both
internal callers can talk.
• Intercom is established.
4Press h on the first handset to
transfer the external call to the
called handset.
• The external call is transferred.
If there is no answer from the called
handset, press i to resume the
external call.
8.9.3 Answer an external call
during intercom
1During intercom, a new call tone is
emitted when there is an incoming
external call.
2Press h to exit intercom mode.
3Press t to pick up the external
call.
8.9.4 Switch between an internal
and external call
During the call, press i to switch
between an internal or external call.
8.9.5 Establish a three-party
conference call
The conference call feature allows one
external call to be shared with two
handsets (in intercom). The three parties
can share the conversation and no
network subscription is required.
1During the call, press i to put the
external call on hold (the caller can
no longer hear you).
• The display shows the numbers
of the handsets registered to the
base.
2Select n the number of the
handset you wish to establish the
conference call with and press o
Select.
3Press t on the called handset to
answer the internal call, where both
internal callers can talk.
• Intercom is established.
4Press c Conf. or long press i
on the first handset to start the
three-party conference.
•Conference will be displayed on
the screen once the conference
call is established.
8.10 Paging
The paging feature enables you to locate
a missing handset if the handset is in
range and contains charged batteries.
1Press the a on the base station.
• All the registered handsets start
to ring.
2Press the a again to end the
paging.
Note
01GB01COV.book Page 37 Wednesday, January 16, 2008 1:30 PM
38 Use more of your phone
If there are no key presses within one
minute, the handset and base station will
automatically return to idle mode.
8.11 Clock and Alarm settings
This feature allows you to set the date,
time and alarm settings for your phone.
8.11.1 Set Date and Time
1Press m in idle mode, scroll n to
Clock & Alarm, and press o
Select.
2Set Date/Time is highlighted.
Press o Select.
3The last stored date and time are
displayed. Enter the current time
and current date (HH:MM DD/MM/
YY). If using the 12 hour format, use
n to switch between AM and PM.
4Press o OK.
• A validation tone is emitted and
the screen returns to the idle
mode.
You can change the format as shown in
the next section.
8.11.2 Set Time and Date Format
8.11.2.1 Set Time Format
1Press m in idle mode, scroll n to
Clock & Alarm, and press o
Select.
2Scroll n to Set Format and press
o Select.
3Time Format is highlighted in the
display. Press o Select, then
scroll n to select 12hours or
24hours.
4Press o Select to select the
option.
• A validation tone is emitted and
the screen returns to the Set
Format menu.
8.11.2.2 Set Date Format
1Press m in idle mode, scroll n to
Clock & Alarm, and press o
Select.
2Scroll n to Set Format and press
o Select.
3Scroll n to Date Format and
press o Select.
4Scroll n to select DD/MM or
MM/DD and press o Select to
select the option.
• A validation tone is emitted and
the screen returns to the Set
Format menu.
8.11.3 Set Alarm
1
Press
m
in idle mode, scroll
n
to
Clock & Alarm
, and press
o
Select
.
2Scroll
n
to Alarm and press
o
Select.
3Scroll
n
to Off, On Once, or On
Daily and press
o
Select.
4If you select On Once or On
Daily, enter the time (HH-MM) for
Note
Note
01GB01COV.book Page 38 Wednesday, January 16, 2008 1:30 PM
39
Personal settings
the alarm. (If using the 12 hour
format, you can switch between AM
and PM by pressing
n
key.) Press
o OK to confirm.
• A validation tone is emitted and
the screen returns to the Alarm
menu. And the alarm icon is
displayed.
• If you select Off, a validation
tone is emitted and the screen
returns to the Clock & Alarm
menu.
The alarm tone and alarm icon will
sound/blink for 1 minute when the alarm
time is reached. To mute the alarm tone,
simply press any key on the handset.
8.11.4 Set Alarm Tone
1Press
m
in idle mode, scroll
n
to
Clock & Alarm, and press
o
Select.
2Scroll
n
to Alarm Tone and press
o
Select.
3Scroll
n
to select the tone. (Three
tones are available. The tones sound
as you scroll.) Press
o
Select to
confirm your selection.
• A validation tone is emitted and
the screen returns to the Clock
& Alarm menu.
9 Personal settings
9.1 Change the Handset Name
You can name the handset and display the
handset name in idle mode. The default
handset name of your handset is Philips.
1Press m in idle mode, scroll n to
Personal Set and press o
Select.
2Handset Name is highlighted;
press o Select.
3The last stored name is displayed.
Press c Clear to delete the
characters one by one or a long
press to delete all.
4Enter the new name and press o
OK to confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
9.2 Handset Tones
9.2.1 Set the Ring Volume
When the handset rings during an
incoming call, please do not hold the
handset too close to your ear as the
volume of the ringing tone may damage
your hearing.
There are 5 ringer volume levels plus
progressive and off. The default is level 3.
Note
Danger
01GB01COV.book Page 39 Wednesday, January 16, 2008 1:30 PM
40 Personal settings
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Handset Tones and
press o Select. Ring Volume is
highlighted; press o Select.
3Scroll n to your desired volume
level. The ring tone sounds at each
level.
4Press o OK to confirm.
• A validation tone is emitted and
the screen returns to the
Handset Tones menu.
If ring volume is set to off, the icon
will be displayed on the screen.
If ring volume is set to progressive, the
ringer will start at level 1 and go up one
level volume every ring.
9.2.2 Set the Ring Tones
There are 15 ring tones available on your
handset.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Handset Tones and
press o Select. Then scroll n to
Ring Tones and press o Select.
3Scroll n to your desired melody.
The melodies will play as you scroll
them.
4Press o OK to set the ring tone.
• A validation tone is emitted and
the screen returns to the
Handset Tones menu.
9.2.3 Activate/Deactivate Key
Beep
A single beep tone is emitted when a key
is pressed. You can enable or disable the
key beep.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Handset Tones and
press o Select. Then scroll n to
Key Beep and press o Select.
3Scroll n to select On or Off and
press o OK to confirm.
• A validation tone is emitted and
the screen returns to the
Handset Tones menu.
9.3 Change the Display Language
Your handset can support different
display languages.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Language and press
o Select.
3Scroll n to your desired language
and press o OK to confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
Once the display language is set, the
option menus on the handset will
immediately switch to display in the
selected language.
Note
Note
01GB01COV.book Page 40 Wednesday, January 16, 2008 1:30 PM
41
Personal settings
9.4 Select the Display Wallpaper
There are 3 wallpaper images available on
your handset as well as an option to set it
off.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Wallpaper and press
o Select.
3Scroll n to your desired wallpaper.
The image on the display will change
as you scroll.
4Press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
9.5 Select the Color Theme
There are 4 color themes available on
your handset.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Color Theme and
press o Select.
3Scroll n to your desired color
theme. The color theme used on
the display will change as you scroll.
4Press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
9.6 Set the Display Contrast
You can change the contrast of the text
on the display. There are 5 contrast levels
available on your handset. The default is
level 3.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Contrast and press
o Select.
3Scroll n to the desired display
contrast, and press o Select to
confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
9.7 Set the Backlight Time
You can change the backlight timing for
the display. There are 3 options available
- 20, 40, or 60 seconds.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Backlight Time and
press o Select.
3Scroll n to the desired backlight
time, and press o Select to
confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
9.8 Deactivate/Activate Auto
Hang-Up
If auto hang-up is set to On, it will
automatically release the line when the
phone is put back on the cradle.
If auto Hang-up is set to Off, putting the
handset back on the cradle while in talk
01GB01COV.book Page 41 Wednesday, January 16, 2008 1:30 PM
42 Advanced settings
mode will switch the handset to hands
free talk mode. This allows you to charge
the handset during calls.
The default setting for auto hang up is On.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Auto Hang-up and
press o Select.
3Scroll n to On or Off and press
o OK to confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
10 Advanced settings
10.1 Easy Call
When activated, this feature allows you
to dial a preset number by pressing any
key on the handset (except c
Cancel). This feature is useful for fast
access to emergency services.
10.1.1 Set Easy Call to On or Off
Follow this procedure to switch Easy Call
on. To switch Easy Call off, see the Note
at the end of this function.
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Easy Call is highlighted. Press o
Select to enter the Easy Call menu.
3Mode will be selected in the display.
Press o Select again to select
Mode, then scroll n to On.
4Press o Select to confirm the
selection.
• If an Easy Call number has not
been set, you will be prompted
to input the Easy Call number.
• If an Easy call number has already
been set, the screen returns to
idle mode. If you want to edit the
number, press c Cancel and
scroll to Number and press o
Select, edit the new number and
press o Select.
When you switch Easy Call on, Easy
Call On will be displayed on your screen
in standby mode. You can still answer any
incoming call as normal.
To switch Easy Call off from idle mode,
press c Cancel. Mode will be
selected in the display. Press o Select
again to select Mode, and then scroll n
to Off. Press o Select to confirm.
10.1.2 Set Easy Call number
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Easy Call will be selected in the
display. Press o Select to enter
the Easy Call menu.
3Mode will be selected in the display.
Scroll n to Number and press
o Select.
4Input the Easy Call number.
5Press o OK to confirm.
Note
01GB01COV.book Page 42 Wednesday, January 16, 2008 1:30 PM
43
Advanced settings
• A validation tone is emitted and
the screen returns to the Easy
Call menu.
10.2 Auto Conference
If activated, this feature allows another
handset to join a conversation with an
external call by simply pressing t. The
default setting is OFF.
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to Conference and press
o Select.
3Scroll n to select On or Off and
press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
10.3 Call Barring
If activated, this function prevents dialing
out to numbers beginning with
designated barring numbers. This is
useful for preventing outgoing long
distance calls or calls to specific prefixes.
You can store up to four numbers, each
with up to 4 digits.
If you switch call barring on, Call Barr
On is displayed on the screen in idle
mode. By default call barring is off.
10.3.1 Set Call Barring Mode
By default, Call Barring is OFF.
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to Call Barring and
press o Select.
3Enter the PIN number.
• If you enter and incorrect PIN
number, an error tone will sound
and “Wrong PIN!” will be
displayed. Then, the display will
return to idle screen.
4Mode will be selected in the display.
Press o Select.
5Scroll n to select On or Off and
press o Select to confirm.
• If a Call Barring number has not
been set, you will be prompted
to input a Call Barring number.
To switch Call Barring mode off again
from idle mode, press c Cancel and
enter the PIN number. Mode will be
selected in the display. Press o Select
to select Mode, then scroll n to Off
and press o Select.
10.3.2 Set a Call Barring number
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to Call Barring and
press o Select.
3Enter the PIN number.
4Mode will be selected in the display.
Scroll d to Number and press
o Select.
Note
Note
01GB01COV.book Page 43 Wednesday, January 16, 2008 1:30 PM
44 Advanced settings
5Scroll n to select a call barring
number location, and press o
Select to confirm.
6Input the call barring number (up to
4 digits) and press o OK.
• A validation tone is emitted and
the screen returns to the Call
Barring menu.
10.4 XHD Sound
XHD (extra high definition) Sound can
increase voice quality when On. The
default setting is On.
To turn it off:
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to XHD Sound and
press o Select.
3Scroll n to select On or Off and
press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
10.5 Change PIN
The PIN is used for setting call barring
numbers and registration/unregistration
of handsets. The default PIN number is
0000. This PIN is also used to protect
the settings of your handset. Your
handset will prompt you whenever the
PIN is required.
The default PIN code is preset to 0000. If
you change this PIN code, keep the PIN
details in a safe place where you have
easy access to them. Do not lose the PIN
code.
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to Change PIN and
press o Select.
3Old PIN: will be displayed. Enter
the current PIN and press o OK.
• The PIN entered will be shown
as asterisks (*) on the screen.
• If you enter an incorrect PIN
number, an error tone will sound
and “Wrong PIN!” will be
displayed. Then, you will be
prompted to enter the current
PIN again.
4New PIN: will be displayed. Enter
the new PIN and press o OK.
5Confirm PIN: will be displayed.
Enter the new PIN again and press
o OK to confirm PIN change.
• A validation tone is emitted,
Saved! is displayed and the
screen returns to the Advanced
Set menu.
If you forget your PIN, you will need to
reset your phone to its default settings.
For more details, see 10.8 - “Reset Unit.”
10.6 Registration
You must register your handset to the
base station before you can use it. The
procedure described below applies to
your SE650/655 handset. The procedure
may vary if you want to register some
other handset. In that case, please refer
Note
Tip
01GB01COV.book Page 44 Wednesday, January 16, 2008 1:30 PM
45
Advanced settings
to the manufacturer of the additional
handset. Additional handsets must be
registered to the base station before you
can use them. Up to 8 handsets can be
registered to one base station.
The PIN is required before you can
register or unregister handsets.
By default, the PIN is 0000.
1On the base station, press and hold
a for 3 seconds. A beep sounds to
indicate that the base is ready to
accept registration.
If no action is taken on the handset
within 90 seconds, the registration
procedure will be aborted. If this
happens, repeat from Step 1.
2
On the handset, press
m
, scroll
n
to
Advanced Set
and press
o
Select
.
3
Scroll
n
to
Register
and press
o
Select
.
4Enter the PIN when prompted and
press
o
OK to confirm.
Registering… is displayed on the
screen.
• Upon successful registration, a
validation tone is emitted and the
handset number (1 to 5) will be
assigned by the base
automatically.
10.7 Unregister
1Press
m
in idle mode, scroll
n
to
Advanced Set and press
o
Select
.
2Scroll
n
to Unregister and press
o
Select.
3Enter the PIN when prompted and
press
o
OK to confirm.
4Scroll
n
to select the handset
number to unregister and press
o
OK. Press
o
OK again to
confirm.
• A validation tone is emitted to
indicate successful unregistration
and the screen shows
Unregistered.
If no action is taken on the handset
within 30 seconds, the unregistration
procedure will be aborted and the
handset returns to idle mode.
You can only use a SE650/655 handset to
unregister a handset that does not
belong to the SE650/655 range.
10.8 Reset Unit
You can reset your phone to its default
settings with this feature. (see 10.13
“Default Settings”)
Upon reset, all your personal settings,
call log and redial list entries will be
deleted and the phone will return to its
default settings. However, your
phonebook will remain unchanged after
reset.
You may have to configure your phone
once again. In this case the welcome
mode will appear again after master
reset.
Note
Note
Note
Caution
Note
01GB01COV.book Page 45 Wednesday, January 16, 2008 1:30 PM
46 Advanced settings
1Press m in idle mode, scroll n to
Advanced Set and press
o
Select
.
2Scroll n to Reset and press
o
Select
.
3Reset? is displayed on the screen.
Press
o
OK to confirm.
• A validation tone is emitted.
• The unit is reset to its default
settings. (See section 10.13
below.)
10.9 Set Area Code
This feature is useful when you have
subscribed to Caller Line Identification
service. It allows you to set an area code
in your phone. Once the local area code
is set, the phone automatically filters the
area code for all incoming calls, by
removing the area code for local calls and
retaining the area code for calls from
other areas.
If it is a local call, then only the phone
number of the caller is displayed during
an incoming call or when you call the
number from the call log. If it is a long
distance call, then both the area code and
phone number will be displayed in a
proper format to be dialed out directly
from the call log, or saved into the
phonebook.
You can enter a maximum of 4 digits for
the area code.
You need to subscribe to Caller Line
Identification service to be able to see
the caller’s number or name in the call
log. See 7.1.4 “Call from the call log” for
details.
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to Area Code and press
o Select.
3Area Code will appear in the
display. Input your area code and
press o OK to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
10.10 Set Auto Prefix
This feature allows you to define a prefix
number to be added to the beginning of a
number during predialling (see
“Predialling” - section 7.1.1). You may
also use this feature to add a detect
string to match and replace the first few
digits of the number during predialing.
You can enter up to a maximum of 5
digits for the detect string and 10 digits
for the auto prefix number.
1Press m in idle mode, scroll n to
Advanced Set and press
o
Select
.
2Scroll n to Auto Prefix and press
o
Select
.
3Detect Digit: is displayed on the
screen. Enter a detect string
number (maximum 5 digits) and
press
o
OK to confirm.
4Prefix Number: is displayed on
the screen. Enter the prefix number
(maximum 10 digits) and press
o
OK to confirm.
Note
01GB01COV.book Page 46 Wednesday, January 16, 2008 1:30 PM
47
Advanced settings
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
If no detect string (blank) is entered, the
prefix number will be automatically
added to the predial number after t is
pressed.
For numbers starting with *, # or P, the
prefix number will not be added to the
predial number after t is pressed.
10.11 Change the Dial Mode
The default value for dial mode that is
preset in your handset should be the best
suited for your subscribed network and
therefore you should not need to change
it.
1Press m in idle mode, scroll n to
Advanced Set, and press
o
Select
.
2Scroll n to Dial Mode and press
o
Select
.
3Scroll n to To n e or Pulse and
press
o
Select
to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
10.12 Set First Ring Detection
First ring detection allows the phone to
ring upon reception of the first ring
signal. It is recommended that you set
first ring detection Off if you subscribe
to caller line identification service.
(When using personalized phonebook
melodies, this will prevent a normal ring
tone from sounding before a melody
starts playing.) If you do not subscribe to
caller line identification service, it is
recommended that you set first ring
detection On. (See Section 8.5.4.)
1Press m in idle mode, scroll n to
Advanced Set, and press
o
Select
.
2Scroll n to First Ring and press
o
Select
.
3Scroll n to On or Off and press
o
Select
to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
The default setting for first ring detection
is country dependent. In countries where
the default setting is On, the setting
automatically switches to Off when you
receive a call containing caller line
identification. However, this occurs only
if you do not first manually change the
setting. (It does not change automatically
if you manually change the first ring
setting even once.)
10.13 Default Settings
Note
Note
Parameter Default Value
Ring Volume Level 3
Ring Tone Ring 1
Earpiece
Vo l u me
Level 3
Speaker
Vo l u me
Level 3
Key Beep On
Display
Language
English
01GB01COV.book Page 47 Wednesday, January 16, 2008 1:30 PM
48 Network Service
11 Network Service
The network service function provides a
convenient way for you to access some
network provider service. A subscription
is required in order to benefit from this
service. Contact your network provider
for details. Depending on your
subscribed network, this service and
menus described in this chapter may not
be available in your SE655.
11.1 Voice Mail
Use this function to access your voice
mail account.
11.1.1 Access Voice Mail
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Voice Mail and press
o Select.
3You are now at the Voice Mail
menu and Call is highlighted. Press
o Select to connect to the voice
mail account number.
You can also access your voice mail
number by long-pressing 1.
11.1.2 Set Voice Mail Number
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
Wallpaper Wallpaper 1
Color
Theme
Color 1
Display
Contrast
Level 3
Backlight
Time
20 Seconds
Auto Hang-
Up
On
Handset
Name
Philips
Time/Date
Format
MM/DD 12hrs
Time/Date 00:00 01/01/2008
Set Alarm Off
Alarm Tone Melody 1
Dial Mode Tone
PIN Code 0000
Call Barring Off
Call Barring
Number
Cleared
XHD Sound On
Easy Call Off
Easy Call
Number
Cleared
Auto Prefix Cleared
Set First Ring Country group
dependent
Phonebook
Memory
After a reset,
phonebook is
maintained as it was just
before the reset
Redial
Memory
Cleared
CLI Memory Cleared
Auto
Conference
On
Parameter Default Value
Note
01GB01COV.book Page 48 Wednesday, January 16, 2008 1:30 PM
49
Telephone answering machine (TAM)
2Scroll n to Voice Mail and press
o Select.
3Scroll n to Settings and press
o Select.
4Enter the voice mail account
number (maximum 14 digits) and
press o OK.
• A confirmation tone will sound
and the display will return to the
Voi c e Ma il screen.
12 Telephone
answering machine
(TAM)
Your phone features an answering
machine that records unanswered calls
when it is activated. The answering
machine can store up to 59 messages. The
maximum recording time is 3 minutes per
message, or 30 minutes for all messages.
The maximum length of an outgoing
message is 1 minute. You can use the
control keys on the base station to
perform the basic functions of the
answering machine such as message
playback, deleting messages and
adjustment of volume on the base station.
For a description of each function of the
control keys on the base station, please
see “Overview of the base station”
(section 5.4) for more details. You can
also use the answering machine menu on
the handset to access the answering
machine functions. Those procedures are
covered below. There is also a menu to
set the answering machine options.
The telephone answering machine is ON
by default. To switch the answering
machine between on and off, press e
on your base station. Alternatively, you
may switch the answering machine on
and off via your handset (see section
12.6.2).
12.1 Playing Messages
12.1.1 Playback of messages via
handset
The answering machine message counter
blinks when there are new messages and
display the number of new messages. The
most recent recorded message is played
first via the loudspeaker. When all new
messages have been played, the
answering machine will stop and the
message counter will stop blinking.
1Press the m key in idle mode,
scroll n to Answer Machine, and
press o Select.
2Play is highlighted. Press o
Select to start playing new
messages.
• The handset displays New and
the number of new messages in
the format 1/4, where 1 is the
number of the message being
played and 4 is the number of
new messages.
• If there are no new messages, the
handset displays the number of
01GB01COV.book Page 49 Wednesday, January 16, 2008 1:30 PM
50 Telephone answering machine (TAM)
old messages in the same format
(however ‘New’ is not displayed.)
and plays the old messages.
12.1.2 Functions available during
playback
During playback, you can enable the
following functions by pressing o
Option. Use n to scroll between the
functions and press o OK to confirm.
12.2 Delete all messages
Deleted messages cannot be recovered.
Unplayed messages will not be deleted.
1Press the m key in idle mode,
scroll n to Answer Machine, and
press o Select.
2Scroll n to Delete All and press
o Select.
3Delete All? is displayed on the
screen. Press o OK to confirm
deletion of all your messages.
•Waiting… is displayed while the
messages are deleted; then,
Deleted is displayed for 2
seconds, and the display returns
to the Answer Machine menu.
12.3 Turn the Answering Machine
On/Off
You can turn the answering machine on
or off from the handset as follows.
1Press the m key in idle mode,
scroll n to Answer Machine, and
press o Select.
2Scroll n to Answer On/Off and
press o Select.
3Scroll n to select On or Off and
press o Select.
• A validation tone is emitted and
the screen returns to previous
menu.
12.4 Play, Record, or Delete an
Outgoing Message
You can record a personalized message
to be played when the answering
machine picks up an incoming call.
The maximum length of an outgoing
message is 1 minute.
1Press the m key in idle mode,
scroll n to Answer Machine, and
press o Select.
2Scroll n to Record OGM and
press o Select.
3Scroll n to select Answer & Rec.
or Answer Only and press o
Select.
4Scroll n to select Play, Record
Message, or Delete and press o
Select.
• If Play is selected, the current
outgoing message is played.
• If Record Message is selected,
a beep sounds and the handset
Repeat Replay the current
message
Next Listen to the next
message.
Previous Listen to the previous
message.
Delete Delete the message
currently playing.
Warning
Note
Note
01GB01COV.book Page 50 Wednesday, January 16, 2008 1:30 PM
51
Telephone answering machine (TAM)
starts automatically recording a
message.
•If Delete is selected and a
personal outgoing message was
previously recorded, Deleted is
displayed. The predefined OGM
is reinstated automatically.
12.5 Set the Answer mode
There are 2 answer modes available:
Answer Only and Answer & Record. By
default, the answer mode is Answer &
Record, which lets your caller leave a
message on the answering machine. This
can be changed to Answer Only mode,
which does not allow your caller to leave
any messages on the answering machine.
1Press the m key in idle mode,
scroll n to Answer Machine, and
press o Select.
2Scroll n to Answer Mode and
press o Select.
3Scroll n to select Answer & Rec.
or Answer Only and press o
Select.
• A validation tone is emitted and
the screen returns to previous
menu.
Depending on the answer mode you have
selected, the appropriate default outgoing
message is played once the answering
machine picks up an incoming call.
You can set the answering machine to
play a personalized outgoing message.
See 12.4 above.
12.6 Answering Machine Settings
12.6.1 Ring Delay
This is the number of rings before the
answering machine answers and starts
playing your greeting message. You can
set the answering machine to start
playing your greeting message after 3 to 8
rings or the “Economy” option. The
default ring delay is 5.
1Press the m key in idle mode,
scroll n to Answer Machine, and
press o Select.
2Scroll n to Settings and press
o Select.
3Ring Delay is highlighted. Press
o Select, then scroll n to select
from 3 to 8 or Economy.
4Press o Select to confirm.
• A validation tone is emitted and
the display returns to the
Settings menu.
If Economy is selected, the ring delay
depends on the answering machine’s
condition.
• If there are new messages in the
answering machine, it will pick up the
line after 2 rings.
• If there are no new messages in the
answering machine, it will pick up the
line after 6 rings.
• If the answering machine is full, it will
pick up the line after 10 rings. The
Answer Only outgoing message will
be played.
Note
Tip
Note
01GB01COV.book Page 51 Wednesday, January 16, 2008 1:30 PM
52 Telephone answering machine (TAM)
12.6.2 Remote Access
You can check the messages on your
answering machine by calling in from an
outside line and entering the remote
access code*. The keypad on the phone
you use to dial in acts like the functions
on your answering machine.
This feature is deactivated by default.
* The remote access code (which is the
same as your PIN code) prevents any
unauthorised remote access of your
answering machine.
12.6.2.1 Activate/Deactivate
Remote Access
1Press the m key in idle mode,
scroll n to Answer Machine, and
press o Select.
2Scroll n to Settings and press
o Select. Then, scroll n to
Remote Access and press o
Select.
3Scroll n to select Activate or
Deactivate and press o Select.
• A validation tone is emitted and
the screen returns to previous
menu.
12.6.2.2 Controlling the
Answering Machine from
an external call
1From your external phone, dial
home.
• The answering machine answers
and starts playing your greeting
message.
2Press # key and enter the remote
access code (same as your PIN
code).
• If the access code is incorrect, an
error tone will be emitted. Then
enter the PIN code again. If the
PIN code is still incorrect, the
answering machine will drop the
line immediately.
• If the remote access code is
correct, a short validation tone
will be heard.
Operation is cancelled if the PIN code is
not entered within 10 seconds.
If the answering machine is off, the phone
will enter into the remote access mode
after 10 rings. A beep will then sound,
prompting you to enter the PIN code.
Enter the PIN (default is 0000) to
activate the remote access feature. You
can then turn ON the answering machine
and play the recorded messages.
The following table indicates how to
access the functions of the answering
machine using the telephone keypad.
Note
Note
Key
Action
1 Go to previous message.
2 Play the message.
3 Skip to the next message.
6 Delete the playing message.
7 Turn on the answering
machine.
8 Stop message playback.
9 Turn off the answering
machine.
01GB01COV.book Page 52 Wednesday, January 16, 2008 1:30 PM
53
Technical data
When Remote Access is deactivated, you
can activate it from an external call by
allowing the telephone to ring 10 times.
The answering machine picks up
automatically and sounds a beep. After
the beep, press # key and enter the
remote access code (PIN) to activate
remote access.
12.6.3 Handset Screening
When Handset call screening is set to
On, you can press o Screen to start
call screening for incoming messages. If
you decide to pick up the call, press t.
Once you pick up, the recording will stop
automatically.
If you have multiple handsets, only one
handset can enable handset call screening
for each call.
1Press the m key in idle mode,
scroll n to Answer Machine, and
press o Select.
2Scroll n to Settings and press
o Select. Then, scroll n to HS
Screening and press o Select.
3Scroll n to select On or Off and
press o Select.
• A validation tone is emitted and
the screen returns to previous
menu.
12.6.4 Setting the Outgoing
Message Language
The language of the default outgoing
messages is originally set to English.
However you can change the language of
the default outgoing messages as follows.
1Press the m key in idle mode,
scroll n to Answer Machine, and
press o Select.
2Scroll n to Settings and press
o Select. Then, scroll n to
Voice Language and press o
Select.
3Scroll n to select the language and
press o Select.
• A validation tone is emitted and
the screen returns to previous
menu.
13 Technical data
Display
• 1.33 inch color LCD with backlight
(98 × 67 pixels)
• Selectable wallpaper
• Selectable colour theme
General telephone features
• Caller name & number identification
• 5 standard +10 polyphonic ringer
melodies
• Wideband synthesis for receiver and
loudspeaker
Phonebook list, Redial list and Call
log
• Phonebook list with 200 entries
• Redial list with 10 entries
• Call log with 50 entries
Note
Note
01GB01COV.book Page 53 Wednesday, January 16, 2008 1:30 PM
54 Frequently asked questions
Battery
• 2 × AAA, 600mAh batteries
Weight and dimensions
Base:
• 189.5 grams
• 77mm × 115mm × 131mm
(H × D × W)
Handset:
• 128.5 grams
• 162mm × 31.5mm × 48mm
(H × D × W)
Temperature range
• Operation: Between 0 and 35ºC
(32 to 95ºF).
• Storage: Between -20 and 70ºC
(-4 to 158ºF).
Relative humidity
• Operation: Up to 95% at 40°C
• Storage: Up to 95% at 40°C
14 Frequently asked
questions
www.philips.com/support
In this chapter, you will find the most
frequently asked questions and answers
about your phone.
14.1 Connection
The handset does not switch on!
• Charge the batteries: Put the handset
on the base station to charge. After a
few moments, the phone will switch
on.
• Make sure you are holding the h
key long enough. You must press and
hold h for at least 5 seconds to
switch the power on/off.
The handset does not charge!
• Check charger connections.
icon is not blinking during
charge!
• Battery is full: There is no need to
charge the battery.
• Bad battery contact: Adjust the
handset slightly.
• Dirty contact: Clean the batteries
contact with a cloth moistened with
alcohol.
Communication is lost during a call!
• Charge the battery
• Move closer to the base station.
The phone is “Out of range”!
• Move closer to the base station.
14.2 Set-up
Searching... is displayed on handset
and icon is blinking!
• Move closer to the base station.
01GB01COV.book Page 54 Wednesday, January 16, 2008 1:30 PM
55
Frequently asked questions
• Make sure that your base station is
on.
• Reset your unit and restart handset
registration.
14.3 Sound
Handset does not ring!
Check that the Ring Volume is not set
to no bars (Ringer Off), and make sure
the icon is not displayed on the
screen (see “Set the Ring Volume” on
page 39).
Caller does not hear me!
Microphone may be muted: During a call,
press s.
There’s no dialling tone!
• No power: Check the connections.
• Batteries are empty: Charge the
batteries.
• Move closer to the base station.
• Wrong line cable used: Use the line
cable provided.
• Line adaptor is required: Connect the
line adaptor to the line cord.
Caller does not hear me clearly!
• Move closer to the base station.
• Move the base station at least one
metre away from any electronic
appliances.
Frequent noise interference on my
radio or television!
• Move the base station as far away as
possible from the electrical appliances.
14.4 Product behaviour
Keypad does not work!
• Unlock your keypad: Long press *
in idle mode.
The handset warms up when
making a long call and when it is on
the base station!
• This is a normal behavior. The handset
consumes energy while calling and
charging.
The handset cannot be registered
to the base station!
• Maximum number of handsets (5) has
been reached. To register a new
handset, unregister an existing
handset.
• Remove and replace the handset
batteries.
• Try again by disconnecting and
connecting the base station power
supply and follow the procedure to
register a handset (see section 10.6).
Caller number is not displayed!
• Service is not activated: Check your
subscription with your network
operator.
My handset keeps going into idle
mode!
• If there are no key presses for 30
seconds, the handset will
automatically return to idle mode. It
will also return to idle mode
automatically when you place the
01GB01COV.book Page 55 Wednesday, January 16, 2008 1:30 PM
56 Frequently asked questions
handset back on the base station (if
auto hang-up feature is on).
Phonebook entry cannot be stored
and Memory Full is displayed!
• Delete an entry to free memory
before saving your contact again.
The PIN code is wrong!
• The default PIN is 0000.
• Reset the handset to revert to the
default PIN code if it has been
changed before (see “Reset Unit” -
Section 10.8).
The answering machine does not
record calls.
• Make sure the answering machine is
connected to the power adaptor, and
the power adaptor is plugged into
mains supply which is switched on.
• Check if the answer machine is off, or
Answer only mode is selected.
• Check to see if the answering machine
is memory full. If so, delete some or
all messages.
• Try switching off the power at the
mains socket, and then turn it on again
after 1 minute.
Unable to perform remote
operation
• Make sure the remote access is on
(see Section 12.6.2).
• Make sure you entered the correct
remote access code.
• Use a touch-tone phone.
If the above solutions do not help,
remove the power from both the
handset and the base. Wait for 1 minute
and try again.
Note
01GB01COV.book Page 56 Wednesday, January 16, 2008 1:30 PM
57
INDEX
15 INDEX
A
Access phonebook 31
Access Redial list 34
Access the Call log 35
Activate/Deactivate loudspeaker
mode 30
Activate/Deactivate Remote Access 52
Adjust earpiece or speaker volume 30
Advanced settings 42
Advanced Settings menu tree 25
Answer a call 28
Answer an external call during
intercom 37
Answer Machine menu tree 26
Answering Machine Settings 51
Auto Conference 43
Auto hang-up 41
Auto Prefix 46
B
Backlight timing 41
Base station 18
Batteries 20
C
Call Barring 43
Call from redial list 27
Call from the call log 27
Call from the phonebook 28
Call using Direct Access Memory 28
Change PIN 44
Change the Dial Mode 47
Change the Display Language 40
Change the Handset Name 39
Charge battery 21
Clock and Alarm menu tree 24
Clock and Alarm settings 38
Color themes 41
Connect the base station 19
Contrast 41
D
Deactivate/Activate Auto Hang-Up 41
Default PIN code 44
Default settings 47
Delete a call list entry 36
Delete a phonebook entry 32
Delete a redial number 34
Delete all call list entries 36
Delete all messages 50
Delete all phonebook entries 33
Delete all redial numbers 34
Delete Direct Access Memory 33
Dial mode 47
Direct Access Memory 33
Direct dialling 27
Display icons and Messages 17
Display languages 40
E
Easy Call 42
End a call 29
Establish a three-party conference call 37
F
Frequently asked questions 54
Functions available during playback 50
G
Getting started 19
01GB01COV.book Page 57 Wednesday, January 16, 2008 1:30 PM
58 INDEX
H
Handset name 39
Handset Screening 53
Handset Tones 39
Handsfree answering 29
I
Install battery 20
Install your phone 20
Intercom 36
K
Key Beep 40
Keypad lock/unlock 30
M
Make a call 27
Menu structure 22
Modify a phonebook entry 31
Mute/Unmute microphone 30
N
Network Service 48
Network Services menu tree 26
O
Overview of the base station 18
Overview of your phone 15
P
Paging 37
Personal settings 39
Personal Settings menu tree 23
Personalized message 50
Phonebook menu tree 22
PIN 44
Play, Record, or Delete an Outgoing
Message 50
Playback of messages via handset 49
Playing Messages 49
Power requirements 6
Predialling 27
R
Registration 44
Remote Access 52
Reset Unit 45
Ring Delay 51
Ring tones 40
Ring Volume 39
S
Save a redial number 34
Save call list entry 35
Select phonebook melody 32
Select the Color Theme 41
Select the Display Wallpaper 41
Set a Call Barring number 43
Set Alarm 38
Set Alarm Tone 39
Set Auto Prefix 46
Set Call Barring Mode 43
Set Date and Time 38
Set Date Format 38
Set Easy Call number 42
Set Easy Call to On or Off 42
Set First Ring Detection 47
Set the Answer mode 51
Set the Backlight Time 41
Set the Display Contrast 41
Set the Ring Tones 40
Set the Ring Volume 39
Set Time Format 38
Set Voice Mail Number 48
Setting the Outgoing Message
Language 53
Store a contact in the phonebook 31
01GB01COV.book Page 58 Wednesday, January 16, 2008 1:30 PM
59
INDEX
Switch between an internal and external
call 37
Switch the handset on/off 30
T
Technical data 53
Telephone answering machine 49
Text or number entry 30
The call log 35
Transfer an external call 37
Turn the Answering Machine On/Off 50
U
Unregister 45
Using the Call log 35
Using the Intercom 36
Using the Redial list 33
Using your phone 27
Using your Phonebook 31
V
Voice Mail 48
W
Wallpaper images 41
What’s in the box 14
X
XHD Sound 44
Y
Your phone 14
01GB01COV.book Page 59 Wednesday, January 16, 2008 1:30 PM
01GB01COV.book Page 60 Wednesday, January 16, 2008 1:30 PM
UCZZ01937UZ(0)
01GB01COV.book Page 61 Wednesday, January 16, 2008 1:30 PM
©2008 Koninklijke Philips Electronics N.V.
All rights reserved
Reproduction in whole or in part is prohibited without the
written consent of the copyright owner
Document order number: 3111 285 47021 (US-EN)
01GB01COV.book Page 62 Wednesday, January 16, 2008 1:30 PM
