PHILIPS Consumer Electronics SLA500 Wireless Music Receiver User Manual SLA5500SN Eng

Philips Consumer Electronics B.V. Wireless Music Receiver SLA5500SN Eng

Manual

SLA5500NS
User manual 4
EN
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 1
2
Need help?
User Manual
See the user manual that came with your Wireless Music Receiver.
Online help: www.philips.com/support
For downloads and frequently asked questions
Contact line:
USA.........................................................1-888-PHILIPS (744-5477)
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 2
3
Contents
3Contents
4Important information
4Safety precautions
5Statements
5Microsoft disclaimer
6What’s in the box
7System requirements
8Functional overview
11 Navigating the menu
13 Preparing Your PC
13 Installing Philips Media Manager
14 Installing the Philips Wireless Music Receiver PC Utility
18 Installing your SLA5500NS
19 Configuration
20 Configuration Wizard Menu
21 Changing network settings
23 Operation
23 Listening to Internet Radio
24 Listening to Music Files
27 Saving Favorite Music Items
29 Advanced Configuration
29 Configuration Menu Structure
31 Managing Network Profiles
32 Managing Multiple Key Indexes
34 Updating the Radio List
36 Advanced Configuration Using Philips Wireless Music Receiver PC Utility
37 Default Profile Settings
38 Uploading New Software to the SLA5500NS
40 Troubleshooting
43 Glossary
44 Extra information
45 Guarantee
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 3
EN
4
•A 802.11b/g compatible wireless network adapter or a wireless base station is required
when integrating your SLA5500 in a wireless computer network.
•Please install and connect the product in the order described in this manual only. This
assures best installation results with the least technical hassles.
•Please read this guide carefully before using your SLA5500NS and keep it for future
reference.
•The most recent downloads and information on this product will be available through
our website www.philips.com/support.
•Broadband Internet access (min. 256 kbps) is required if you want to use the Internet
functions of the SLA5500NS.
•Please check whether your Internet service provider charges extra fees for exceeding a
certain limit of transferred data. When using Internet media services on a daily basis, you
may exceed such a limit. For example:
When you listen to Internet radio (at 64 kbps) for about 36 hours, 1 GB (gigabyte) of
data will be transferred to your streamium system.
•During set-up and installation, it may be helpful to have the instructions for your audio
system, wireless base station or other wireless network components at hand.
Safety Precautions
•NEVER MAKE OR CHANGE CONNECTIONS WITH THE POWER SWITCHED ON.
•Before operating the system, check that the operating voltage indicated on the
nameplate of your system is identical with the voltage of your local power supply. If not,
please consult your dealer.
•Radio equipment for wireless applications is not protected against disturbance from
other radio services.
•The product should not be exposed to liquids.
No object filled with liquids, such as vases, or beverage containers should be placed on
the product.
•Do not expose the system to excessive moisture, rain, sand or
heat sources caused by heating equipment or direct sunlight.
•Allow a sufficient amount of free space all around your SLA5500NS for adequate
ventilation.
•Do not open this product. Contact your Philips retailer if you experience technical
difficulties.
•Place the system on a flat, hard and stable surface. When the system is switched to
standby mode, it is still consuming some power. To disconnect the system from the
power supply completely, remove the AC power plug from the wall socket.
•Make sure the air around your SLA5500NS can circulate to prevent your SLA5500NS
from overheating internally. Also, avoid putting any heat sources (e.g. a power amplifier)
underneath.
•To prevent your SLA5500NS from overheating internally, never place anything on top of
it.
Important information
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 4
EN
5
Statements
•This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide
reasonable protection against harmful interference in a residential installation.This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
•This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry
Canada. Operation is subject to the following two conditions:
1) this device my not cause harmful interference, and
2) this device must accept any interference received, including interference that may
cause undesired operation.
•The users manual or instruction manual for an intentional or unintentional radiator shall
caution the user that changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
Example:
Warning: Changes or modifications made to this equipment not expressly approved by
Philips may void the FCC authorization to operate this equipment.
IMPORTANT NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20 cm between the radiator and your body.This transmitter must not
be co-located or operating in conjunction with any other antenna or transmitter.
The FCC ID of the equipment is: OMYSLA550.
Microsoft disclaimer
This product is protected by certain intellectual property rights of Microsoft Corporation.
Use or distribution of such technology outside of this product is prohibited without a
license from Microsoft or an authorized Microsoft subsidiary.’
‘Content providers are using the digital rights management technology for Windows
Media contained in this device (‘WM-DRM’) to protect the integrity of their content
(‘Secure Content’) so that their intellectual property, including copyright, in such content
is not misappropriated. This device uses WM-DRM software to play Secure Content
(‘WM-DRM Software’). If the security of the WM-DRM Software in this device has
been compromised, owners of Secure Content (‘Secure Content Owners’) may request
that Microsoft revoke the WM-DRM Software's right to acquire new licenses to copy,
display and/or play Secure Content. Revocation does not alter the WM-DRM
Software's ability to play unprotected content. A list of revoked WM-DRM Software is
sent to your device whenever you download a license for Secure Content from the
Internet or from a PC. Microsoft may, in conjunction with such license, also download
revocation lists onto your device on behalf of Secure Content Owners.’
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 5
EN
Please check whether the following items are present in the box of the Wireless
Music Receiver. They are provided to help you set up and use your SLA5500NS.
SLA5500NS Wireless Music Receiver
Remote control including batteries (2x AAA)
Power adapter (110V or 200-240V) including cable adapter and power cable
Stereo RCA to 1/8” connector cable
CD-ROM containing:
•This User manual
•Philips Media Manager software
•Wireless Music Receiver PC Utility
Quick start guide
What’s in the box
I
n
s
t
a
l
l
a
t
i
o
n
C
D
6
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 6
EN
7
System requirements
Audio
Audio system (e.g. amplifier, VCR, DVD etc) with auxiliary (AUX) inputs
(RCA connection) or an active speaker system
Personal Computer (PC)
•Pentium Class 300MHz processor or better
•128 MB RAM
•150 MB free hard drive space
•CD-ROM drive
•Windows® XP Service Pack (SP) 1
•Microsoft Internet Explorer 5.0 or later
•Wireless or Ethernet network interface card, installed and configured with TCP/IP
Network
•Wireless connection (WiFi 802.11b/g compatible) from the Wireless Music
Receiver to a PC, base station or both.
Network Environments Supported
Network Environment Description
Infrastructure • Wireless Base station (BS)
Commonly this is called a wireless
router.
•PC with connection to base station
•SLA5500NS connects wirelessly to
BS
Peer-to-peer (Ad Hoc) • No Wireless Base station (BS)
•PC with wireless card
•Wireless Music Receiver connects
wirelessly to PC
•PC with wired connection to the
Internet (with Internet Sharing
enabled)
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 7
EN
8
Functional overview
Wireless Music Receiver
1Infrared sensor
Receives the signals from the remote control
2LCD screen
Displays menu status for easy navigation through music library and system
settings
3Stereo 1/8” connector cable socket
4Power adapter cable socket
5Reset hole
Remote Control
1HOME
Displays the top level menu.
Turns on the SLA5500NS when the SLA5500NS is switched in Standby mode.
20-9 digit buttons
Play the item stored on the preset number selected (0 to 9).
In Edit mode: Key 0-9 is used to enter numbers and/or characters (ex: 2abcABC).
Key 1 is also used for special symbols (1 . , ? ! - & * # _ ~)
3PRESET
Press this button followed by one of the number buttons (0-9) to store the
currently selected item against the preset number selected.
4(UN)MARK
Press this button once to add the song currently playing or Internet Radio
station to the Dynamic Playlist.
When playing Dynamic Playlist: press to remove from Dynamic Playlist.
2
3
1
5
4
1
3
6
7
10
11
9
8
2
4
5
19
18
15
13
12
14
13
17
16
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 8
EN
9
53(UP)
Scrolls up through the current menu list (hold the button down to scroll faster)
In Edit mode: enter or change characters by scrolling up through the ASCII
character table.
4(DOWN)
Scrolls down through the current menu list (hold the button down to scroll
faster)
In Edit mode: enter or change characters by scrolling down through the ASCII
character table.
1(LEFT)
Moves up one level up in the menu hierarchy on the LCD display.
Example: if artist is displayed, pressing Left returns you to the PC Files menu.
In Edit mode: Moves the cursor to the left, one character at the time.
2(RIGHT)
Selects the current highlighted menu item
Example: If the currently displayed item is an album, pressing Right will display a
list of all songs of that album
Example: If it is an Internet Radio station, pressing Right will select that station.
In Edit mode: Moves the cursor to the right, one character at the time and
confirms inputs.
6SYSTEM
Displays the top level of the Configuration menu.
7SHUFFLE
Toggles between random and ordered playback modes in the current folder.
Note: The selected mode is stored permanently until you press the Shuffle button again
or until the products will be switched off (StandBy mode).
8REPEAT
Press this button once to repeat only the song that is currently playing (only
applies to PC music files). The Repeat icon is displayed on the LCD screen.
Press again to repeat all songs of the currently selected item.
The Repeat All icon is displayed on the LCD screen.
Pressing again will return to Normal Play.
99(STOP)
Stops playing the current item.
10 ∞(previous/rewind)
Press this button once to jump to the previous song in the playlist, album, artist
or Internet Radio station list.
If it reaches the beginning of a list, it wraps around to the end of the list.
In Edit Mode: Press this button to delete one character at a time (backspace).
11 ;/2(pause/play)
Press this button once to play the currently selected item (Internet Radio station,
playlist, album, artist, genre or song file). Information about the current item is
displayed on the screen
Press again while the song is playing to pause the song.
To continue playing an item that has been paused, press ;/2again.
1
3
6
7
10
11
9
8
2
4
5
19
18
15
13
12
14
13
17
16
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 9
EN
10
12 §(next/fast forward)
Press this button once to jump to the next song in the playlist, album, artist or
Internet radio list.
If it reaches the end of a list, it wraps around to the beginning of the list.
Press and hold the button for more than 1 second to fast forward the current
song. Play recommences when the button is release.
13 – E+ (Volume Up/down)
Increases (+) and decreases (–) the volume.
14 INFO
Displays additional information on the currently selected music file.
Pressing the button again enables a return to the default item display.
15 s(Mute)
Mutes the sound.
16 OK
Selects the current highlighted menu item
Example: If the currently displayed item is an album, pressing OK will start
playing that album.
Example: If it is an Internet Radio station, pressing OK will select that station.
17 PLAY LIST
Displays the Dynamic Playlist that is stored on the SLA5500NS.
The list may contain up to 20 items
18 JUMP TO
Activates Jump To function (character based keys (0-9) will be activated).
19 y(On/Standby)
Turns on the Wireless Music Receiver.
Pressing the button again turns the device off (the device is then in ‘standby’
mode).
1
3
6
7
10
11
9
8
2
4
5
19
18
15
13
12
14
13
17
16
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 10
EN
11
Configure Date/Time
Popular Stations
Help
Navigating the menu
The SLA5500NS has a built-in LCD screen. Together with the remote control device,
it enables easy operation.
LCD Menu Structure
The menu displayed on the Wireless Music Receiver LCD screen is organized as a
hierarchy, enabling you to access the:
•Home menu
•A Dynamic Playlist of Internet Radio and music files (if available)
•A Dynamic Playlist of music files (if available)
•Internet Radio menu
•Music files stored in your Philips Media Manager Library
(multiple servers may be visible)
•Configuration menu
The exact menu structure will depend on your network environment (i.e. whether
you have Internet access or not) and how your music library is organised on your
personal computer.
A top level LCD menu structure could look like this:
Home
Press the HOME button (1)
at any time.
See Music Files Menu for more details.
Internet Radio
Press the HOME button (1)
AND
scroll down the
Home menu.
See Internet Radio Menu for more
details.
Configuration
Press the SYSTEM button (6)
at any time.
See Configuration Menu for more
details.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 11
EN
12
Navigating in the LCD screen menus
Press 2to select a menu item (move right)
Press 3to move up the menu
Press 4to move down the menu
Press 1to cancel a menu item (move left)
Press HOME (1) to activate the Home menu
Press SYSTEM (6) to go to the Configuration menu
Press PLAY LIST (17) to go to the Dynamic Playlist
Wireless Music Receiver LCD Screen Icons
The following table describes the icons that may be displayed on the Wireless Music
Receiver LCD screen.
Description
Move down the menu hierarchy.
Move up the menu hierarchy.
Processing (please wait).
Item may be played.
Now playing.
Now paused.
Now playing all items.
Shuffle mode enabled.
Repeat mode enabled.
Repeat All mode enabled.
Storing current item.
Lower case (edit mode).
Upper case (edit mode).
Buffer fill status.
Wireless signal strength.
Wireless network disconnected.
Peer-to-peer wireless network mode available.
Internet Radio available.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 12
EN
13
Preparing Your PC
With the SLA5500NS you are able to enjoy digital music anywhere in the home.
Your SLA5500NS plugs into any audio system and connects wirelessly to a PC or
directly to the Internet via a base station (BS). The remote control and the built-in
LCD display provide easy control and quick selection of music.
Key Features
•Browse music file content on your computer
•Browse and search content by Song, All Tracks, Albums, Artist, Genres or
Playlists
•Set up SLA5500NS on your network simply by using the remote control
•Manage profiles and upgrade software using the Wireless Music Receiver PC
Utility
•View device status information using the built-in Web-based presentation page
•Listen to Internet Radio stations and music files (for example WMA-DRM, WMA,
MP3, WAV) over your audio system
•Browse and update the Internet Radio station database
The instructions in this User Manual assume that you already have a wireless network
up and running. The installation of your wireless network is device-dependent and
thus outside the scope of this document. Please refer to your wireless network
device documentation for more details.
To be fully functional your SLA5500NS requires the installation of:
•the Philips Media Manager software on your PC
Philips Media Manager allows you to create a library of music files on your PC.
Music files include MP3 and WMA formats. It also provides a UPnP Media Server
which enables your SLA5500NS to browse these files on the PC.
•the Wireless Music Receiver PC Utility on your PC
This software allows you to configure your Wireless Music Receiver network profiles.
Normally, you will only need to use this utility if:
• you want to configure a network profile from a PC instead of from the
SLA5500NS itself, or
• you want to upload new software for your Wireless Music Receiver
Installing Philips Media Manager
Place the Philips Media Manager CD in your CD or DVD drive and install the Philips
Media Manager software.
The CD starts automatically. If it does not, double-click ‘My Computer’,
then the CD-ROM drive icon and finally ‘Setup.exe’ to start the CD.
In the menu that appears on your computer screen, click ‘Install Philips Media
Manager’, and follow the on-screen instructions.
When opening the Philips Media Manager for the first time, you will be asked if you
want to add a folder and scan for audio files. Open a drive or a folder with audio files
in it. (For example: the My Documents folder, if you have stored audio files there.)
•You can always add more files and folders later.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 13
EN
14
Adding files to the Media Manager
Only the files that you see in the Media Manager will be accessible from your
SLA5500NS and only the files that are supported by your SLA5500NS will be available
for your audio system.
1Click ‘Music’.
2First, click the ‘Add Music’ button below the media categories, then click ‘Add
Files or Folders...’.
3Select a folder or one or more audio files and click the ‘Open’ button to add the
selected folder or files to the Media Manager window.
> From now on, the audio files you added may be accessed from the SLA5500NS.
Opening and closing the Media Manager window.
You can close the Media Manager window, but its icon will remain active in the lower
right corner of your computer monitor. This icon needs to remain visible, otherwise
the SLA5500NS will not be able to access the media files on that computer.
Double-clicking the icon opens the Media Manager window.
Installing the Philips Wireless Music Receiver
PC Utility
1Insert the CD-ROM provided into your PC’s CD-ROM drive.
2Click on 'Install PC Utility'.
> The InstallShield Wizard screen will be displayed.
3Click the ‘Next’ button and follow the instructions on the screen to install the
software.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 14
EN
15
MAC Address Control on the Wireless Network
If you are using MAC Address Control on your wireless network, you will need to
know the MAC address of your Wireless Music Receiver. The MAC address is a
unique number that identifies your device on the network. It consists of a series of
numbers and letters in the following format: xx.xx.xx.xx.xx.xx
The MAC address for your Wireless Music Receiver is printed on the bottom of the
device. It can also be displayed on the LCD screen. See ‘Viewing Network Status
Settings’.
You must change your wireless network settings to exclude the Wireless Music
Receiver’s MAC address from filtering. Please refer to your wireless network’s
documentation for details on how to do this.
Enabling Internet Connection Sharing on Your PC
If your connection to the Internet is made available via a single PC, that PC must
enable ‘Internet Connection Sharing’.
To set up and use the Internet Connection Sharing (ICS) feature in Microsoft
Windows XP:
1Log on to the host computer as Administrator or Owner.
2On the taskbar, click ‘Start’, then ‘Control Panel’.
3In Control Panel, click ‘Network and Internet Connections’ under
‘Pick a category’.
4Click ‘Network Connections’ icon.
5Right-click the connection that you use to connect to the Internet and choose
Properties from the menu. For example, if you connect to the Internet using a
modem, right-click the desired Dial Up connection.
6Click the ‘Advanced’ tab.
This will give you access to the options for sharing your Internet Connection.
Next:
a) In the ‘Internet Connection Sharing’ section: Place a check mark to allow other
users to connect through this computer’s Internet connection.
b) Remove the check mark that allows other network users to control or disable
the shared Internet connection.
7Click OK (16). The following message appears:
‘When Internet Connection Sharing is enabled, your LAN adapter will be set to use
IP address 192.168.0.1. Your computer may lose connectivity with other computers on
your network. If these other computers have static IP addresses, you should set them
to obtain their IP addresses automatically. Are you sure you want to enable Internet
Connection Sharing?‘
8Click Yes.
The connection to the Internet is shared with other computers on the local area
network (LAN). The network adapter that is connected to the LAN is configured with a
static IP address of 192.168.0.1 and a subnet mask of 255.255.255.0.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 15
EN
16
Using Windows XP Service Pack 2
These instructions guide you through configuring your wireless network settings, for
the following scenario:
•If you do not have a wireless basestation (also known as router or access point)
and your PC has a wireless adapter installed.
Note: If the wireless network icon is not shown, follow normal installation procedure as
described in this User Manual.
1Click on the Wireless Network icon.
This opens the Wireless Network Connection window.
2Click on ‘Change advanced settings’.
This opens the Wireless Network Connection Properties window.
Windows XP
Windows XP
service pack 2
service pack 2
The wireless network icon
should be displayed in
the system tray.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 16
EN
17
3Select tab ‘Wireless Networks’.
In this tab you can control your wireless networks.
4Click on button ‘Add’.
This will open the Wireless network properties window.
Note: If this list is populated, ‘Remove’ all items first.
5a Fill in a Network name (SSID) you would like for your wireless network, for
example: ‘philips’.
This is the name your streamium device will recognize.
5b Select Network Authentication ‘Open’.
5c Select Data encryption ‘Disabled’.
Note: If you want to enable WEP encryption, see details in this User Manual.
5d Mark the box next to ‘This is a computer-to-computer (ad hoc) network; wireless
access points are not used’.
6Click on ‘OK’.
This will close the Wireless network properties window.
7Click on ‘OK’.
This will close the Wireless Network Connection Properties window.
Improving the start up time for the SLA5500NS to
Computer network (adhoc mode)
You might experience a long wait while the SLA5500NS is 'searching for UPnP
servers'. You can reduce this time by running the supplied AutoIP Network Utility.
•Insert the CD-Rom.
•Select ‘TOOLS’.
•Start ‘Auto IP Network Utility’.
•Follow on-screen instructions.
Note: Do not use the Auto IP Network Utility tool if you use a wireless base station or
router in your network or if you have Internet Connection Sharing (ICS) enabled.
3
4
a
bc
d
6
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 17
EN
18
Before You Start
•Make sure that your wireless network is active.
•Make sure that Internet access is available.
•If your base station has Media Access Control (MAC) filtering enabled, make sure
that the SLA5500NS’s MAC address is added to the Access Control List of your
base station. For details see ‘MAC Address Control on the Wireless Network’.
•If you are using a firewall, make sure that your firewall is correctly configured to
allow wireless access to shared media files. See ‘Extra information’ for more
details.
Connecting the SLA5500NS
1Insert batteries and make sure it is correctly positioned as indicated by the
engraved symbols.
2Connect the 1.8” plug of the cable to the audio socket on the SLA5500NS.
Connect the other end to the AUX input of your audio system amplifier
(2x RCA).
3Connect the power cable to the power socket on the Wireless Music Receiver
and connect it to the power supply.
> The Wireless Music Receiver should power on automatically after a few seconds
(if it does not, press the ybutton on the remote control).
4Select your display menu language: English, Français, Italiano, Deutsch, Español, or
Nederlands.
Use 3and 4to select. Confirm with OK or 2.
> The Wireless Music Receiver will automatically search for a currently available wireless
network and start the Configuration Wizard on the device.
Installing your SLA5500NS
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 18
EN
19
Configuration
Introduction
The SLA5500NS has a Configuration Wizard that guides you through the process of
configuring network profiles for your SLA5500NS. The Configuration Wizard is used
when you want to:
•Install the SLA5500NS for the first time.
•Make later changes to a network profile setting.
This chapter describes:
•Information you will need to configure the wireless network profile for the
SLA5500NS
•Structure of the Configuration menu
•How to use the Configuration Wizard to change network profile settings
Network Information needed by the Configuration Wizard
The Configuration Wizard will guide you through the setup process, prompting you
to edit one or more of the following settings. Before proceeding, make sure that you
have the following information in front of you:
Note: The SLA5500NS determines some settings automatically during its search for an
available wireless network. It may therefore not need to prompt you for all of
the above settings during the setup process.
Prompt Option Selected Information You Need To Know
Select Network SSID Current Network SSID (to confirm)
Enter Network SSID Alternative Network SSID
Select Network Type Infrastructure Is there an Access Point available
(Access Point available) on the wireless network?
Ad Hoc
Select Encryption WEP Key Index and Encryption Key
Edit IP Address Automatic (DHCP) Is a DHCP Server Available?
Static IP Address IP Address (for SLA5500NS)
Subnet Mask
Gateway
Preferred DNS Server
Alternate DNS Server
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 19
EN
20
Configuration Wizard
Load Profile
Select Network
Select Network Type
Select Encryption
Network IP Settings
Apply Settings? Edit Key
Select Key Index
Exit Key Editing
Key 1
Key 2
Key 3
Key 4
Edit IP Address
Edit Subnet Mask
Edit Gateway IP
Edit DNS Server 1
Edit DNS Server 2
Save to Profile
Profile 1
Profile 2
Profile 3
Select encryption
No
Yes
Select Network Type
Ad-hoc
Infrastructure
Select Network
Edit Network SSID
<SSID>
Network IP Settings
Automatic (DHCP)
Static IP Address
Apply Settings?
Save Settings?
Load Profile
Profile 1
Profile 2
Profile 3
Configuration
Device Status
Internet Radio
Configuration Wizard
Select Language
Advanced Settings
Select Profile
Configure Date/Time
Configuration Wizard Menu
Configuration Wizard
The Wizard starts automatically on installation or reset.
Otherwise, press the SYSTEM button on the remote control at any time and scroll
down to Configuration Wizard.
This option only appears if Profile
Management has been turned On under
Advanced Settings. Otherwise, the active
profile will be edited.
This option only appears if Key
Management has been turned On
under Advanced Settings.
Otherwise, Key 1 will be edited.
This option only appears if Profile
Management has been turned On under
Advanced Settings. Otherwise, changes
will be saved to the active profile.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 20
EN
21
Starting the Configuration Wizard
The Configuration Wizard will start automatically the first time you connect your
SLA5500NS to the power.
To start the Configuration Wizard at a later time:
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Configuration Wizard’ is highlighted. Press 2.
3Press 2on the remote control to go to the next screen and begin the setup
process.
Note: This process requires you to know some technical details on how your wireless
network is set up. If you are unsure of any of the settings, consult the person
who set up your wireless network or refer to the appropriate network
documentation.
Changing network settings
Entering Text in Edit Mode
For some settings (Example: SSID, WEP Key, Proxy Hostname) you will need to
enter text characters in Edit mode. In edit mode you can use the remote control digit
buttons to enter text, similar to the way you enter text messages on a mobile phone.
The following special functions are also available in Edit mode:
Function
1/2Move the cursor forward one character at a time.
Press at the end of a line to complete the changes and move to the
next item.
∞Backspace to delete one character at a time.
3/4Scroll through the ASCII character list.
Selecting a Network
If the LCD screen displays ‘Select Network’:
1If more than one wireless network is available, press 4to choose the SSID
(Service Set ID) for the wireless network and press 2.
- OR –
Check that the SSID displayed for the single wireless network found is correct
and press 2.
2Otherwise, press 4to choose ‘enter network SSID’ and press 2.
Enter the SSID (see ‘Entering Text in Edit Mode’).
The SSID must contain between 2 and 32 alphanumeric, case-sensitive characters.
Press 2when you have finished entering the SSID.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 21
EN
22
Selecting a Network Type
If the LCD screen displays ‘Select Network Type’: (See ‘Network Environments
Supported’ for a more complete description of network types.)
1Press 4to choose an option, then press 2.
2Choose ‘Infrastructure’ if you have a base station.
-OR-
Choose ‘Ad-hoc’ if the SLA5500NS is connecting directly to the PC’s wireless
adapter.
Selecting Encryption Settings
If the LCD screen displays ‘Select Encryption’ or ‘Edit Key 1’:
1Press 4to choose an option, then press 2.
2Choose ‘No’ if no encryption is used on the wireless network or ‘WEP’ if WEP
encryption is used.
3If you choose ‘Yes’, you will prompted to enter the WEP Key. If a key already
exists in the current profile, asterisks (***) will be displayed in place of the actual
key. See ‘Entering Text in Edit Mode’.
Note: See the user manual of your wireless base station for details on how to identify
the WEP Key.
4Press 2when you have finished entering the key. The Key Type and Key Length
will be displayed in the top right of the LCD screen, based on what you have
entered: i.e. ASCII or Hex, 64 or 128 bit.
Note: By default, Key Index 1 will be used. To use another Key Index, see ‘Managing
Multiple Key Indexes’.
Selecting Network IP Settings
If the LCD screen displays ‘Network IP Settings’:
1Press 4to choose an option, then press 2.
2Choose ‘Automatic (DHCP)’ if you are using DHCP or Auto IP on the network
or ‘Static IP Address’ if the SLA5500NS will need a fixed IP address.
3If you choose ‘Static IP Address’, you will be prompted to edit/confirm the
SLA5500NS's IP Address, Subnet Mask, Gateway, DNS Server Preferred and DNS
Server Alternate.
Press 2after confirming/entering each IP address.
Completing the Configuration
1When all required settings have been entered, the Configuration Wizard will
display the message: ‘Configuration Complete...Apply Settings?’.
2If you are modifying an existing profile, press 2to display the Save to Profile
menu. Press 4to choose a profile in which to save the new settings.
3Press 2to finish. The message ‘Configuration Wizard...Applying Settings’ or
‘Configuration Wizard...Saved to Profile xxx.’ will be briefly displayed, depending
on whether you are applying changes to the active profile or to a different profile.
The Configuration Wizard will then display the home menu.
Note: If the message No Network or another error message appears, the SLA5500NS
was unable to connect to an available wireless network. Please see ‘Troubleshooting’.
Uploading New Software to the SLA5500NS
Check www.philips.com/support for new software versions. When new software
becomes available, the Software Upload Wizard in the Philips Wireless Music
Receiver PC Utility will help you to install it on your SLA5500NS.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 22
EN
23
Introduction
This chapter describes how to
•Turn on the SLA5500NS
•Browse and listen to Internet Radio stations through your audio system.
•Browse and listen to music files stored on your PC through your audio system.
•Use preset numbers to store and play up to 10 items (Internet Radio stations,
songs, playlists etc).
•Use a Dynamic Playlist to save and play up to 20 items (Internet Radio stations,
songs, playlists etc).
Powering on the SLA5500NS
1Press yor HOME to turn on the SLA5500NS.
2If the device is correctly configured you will see the Home menu displayed.
If it is not correctly configured, the Configuration Wizard will be displayed
(see ‘Configuration’).
Listening to Internet Radio
The SLA5500NS allows you to listen to Internet Radio stations through your audio
system.
Note: If you have no access to the Internet, Internet Radio functions will not be
available.
Radio Internet Station Menu
You can browse the Internet Radio station database by genre (music style), country
and station. Stations are organized in a hierarchical menu, similar to the way in which
files are organized in subdirectories on a PC. Menu items are displayed on the
SLA5500NS’s LCD screen and you navigate through the menu using the remote
control.
Note: If the ‘Internet Radio’ menu is not presented in your selected language, select
‘Manual Update’. See ‘Updating the Radio List Manually’.
Internet Radio Remote Control Functions
The following remote control functions can be used in Internet Radio mode:
;/2Play
9Stop playing
INFO Display track information
Playing Internet Radio
Use the remote control and follow these steps:
1Press HOME (1) then 4until ‘Internet Radio’ is highlighted. Press 2.
2To browse through the menu items, press 3or 4.
To select the highlighted menu item, press 2.
To return to the previous menu level, press 1.
3When you see this icon ‘ ’ you can:
Press ;/2to play the selected station.
Operation
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 23
EN
24
Viewing Current Station/Song Information
The SLA5500 LCD screen displays station and song information during playback of an
Internet Radio station. Not all stations broadcast additional song information. If you
are browsing in another menu and wish to re-display information about the
station/song currently playing, press the INFO button (14).
Example Display Text Explanation
Nick Ferry Artist name.
. . . One More Time Name of the album.
Born To Be Happy Title of the song currently playing.
;/2Now playing.
Streaming buffer fill informator:
indicates that the station signal is being
buffered to the device and will begin to
play in a few seconds.
Radio signal strength indicator.
Internet Radio Service
Your SLA5500 comes preconfigured with free Internet Radio Stations. You can
choose to sign up to an Internet Radio Service to receive more stations. Such
services may also allow you to add your own stations to the list. For more details,
please see the Web site at: http://www.radiosetup.com. When you have subscribed to
a service, you can either wait until the automatic radio list update occurs, or perform
a manual update. See ‘Updating the Radio List’ for details.
Listening to Music Files
The SLA5500NS allows you to listen to music files stored on your PC through your
audio system. Music files include WMA-DMR, WMA, MP3 and WAV files.
Before You Start
1The SLA5500NS must be connected to the wireless network.
2The UPnP Media Server must be running on your PC containing the Philips Media
Manager Music Library (see ‘Starting the UPnP Media Server’).
3There must be at least one music file in the Philips Media Manager Music Library
on your PC.
Music Files Menu
You can browse music files by album, all tracks, artist, genre (music style),
genre/artist, genre/album and playlist. The music files are organized in a hierarchical
menu, similar to the way in which files are organized in subdirectories on a PC.
Menu items are displayed on the SLA5500NS’s LCD screen and you navigate through
the menu using the remote control. The actual content of each menu is determined
by the structure of your Philips Media Manager Music Library.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 24
EN
25
Music File Remote Control Functions
The following remote control functions can be used in Play mode:
;/2Play the displayed item / Pause the current item.
§Press once to play next track / Hold down to fast forward the current
song.
∞Play previous track
9Stop playing.
REPEAT Press once to repeat current song / Press twice to repeat all songs.
INFO Display track information.
SHUFFLE Toggle Shuffle mode (play in random/normal order).
Playing Music Files
Use the remote control and follow these steps to browse for and play music files:
1Press HOME (1) on the remote control to go to the top level menu.
2Press 4to find the Media Manager ‘PMM (computername)’.
- OR -
If multiple servers are available, press 4to highlight the desired server name and
press 2.
3To select a genre, album, artist, playlist or song, press 3or 4to browse up and
down through the items and press 2to move right in the menu hierarchy until
the desired item is displayed.
4When you see this icon you can press ;/2to start playing that item.
If you press ;/2while:
- a playlist is displayed, all of the tracks on that playlist will be played
- an artist is displayed, all of the tracks on all albums by that artist will be played
- an album is displayed, all of the tracks on that album will be played
- a song title is displayed, only that song will be played.
Playback of DRM protected songs
Your SLA5500 is able to playback DRM10 protected songs. However DRM prohibits
use of the Philips Media Manager. It is strongly recommended to use Windows Media
Connect. This requires Windows XP, Service Pack 2.
How to connect the SLA5500 to Windows Media Connect is described below.
Configuration steps for playing DRM protected songs on the SLA5500
1Configure the SLA5500.
• Follow instructions in chapter ‘Installing your SLA5500NS’.
2Start ‘Windows Media Connect’.
1. Click on ‘Start’.
2. Click on ‘Programs’.
3. Click on ‘Windows Media Connect’.
3
➊
➋
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 25
EN
26
3Allow communication with SLA5500.
1. Click on ‘Philips SLA5500’.
2. Click on ‘Next’.
4Confirm communication with SLA5500.
• Select ‘Yes’.
5Select folders to share.
1. Choose the folders you wish to share with the SLA5500.
2. Select ‘Finish’.
6Select ‘Windows Media Connect’ as server.
1. Point the remote control towards SLA5500.
2. Press ‘HOME’.
3. Press ‘4‘ to select ‘Windows Media Connect’.
4. Press ‘2‘ to confirm.
> Your SLA5500 is now able to play DRM protected songs.
7Browse to your DRM protected songs.
• See chapter ‘Playing music files’ on how to start playing DRM protected songs.
Viewing Song Information
The SLA5500NS LCD screen displays various information during playback, such as
music file details, playback modes and network status.
Example Display Text Explanation
Nick Ferry Artist name.
. . . One More Time Name of the album.
Born To Be Happy Title of the song currently playing.
Playback Modes:
• Now playing
• Now paused
• Repeat mode enabled
• Repeat All mode enabled
• Shuffle mode enabled
Move up the menu hierarchy.
➊
➋
➊
➊
➋
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 26
EN
27
Move down the menu hierarchy.
Item may be played.
9/54 Track number (9) of total tracks (54) in item.
Wireless signal strength indicator.
Buffer fill indicator.
01:15 /02:30 Elapsed time / total time for current track (default).
Saving Favorite Music Items
Saving an Item to a Preset Number
You can save an album, artist, playlist or song to one of 10 preset numbers.
1Select an item to be saved (see previous sections) and check that it is active by
playing it.
2Press PRESET (3), followed by the preset number (0 to 9) where you want to
save the item.
Note: There is no ‘erase’ function; simply overwrite an existing preset with the new
item.
Selecting and Playing a Preset Item
1Simply press the relevant preset number button (0 to 9).
2Press ;/2to listen to the selected item.
3Press 9to stop listening to selected item.
Saving Items to the Dynamic Playlist
You can save up to 20 of your favorite items (albums, songs etc) to a Dynamic Playlist
stored locally on the SLA5500NS.
To add an item currently playing to the Dynamic Playlist:
•Press (UN)MARK (4).
To remove the item currently playing from the Dynamic Playlist:
•Press (UN)MARK (4).
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 27
EN
28
Playing Items from the Dynamic Playlist
1Press PLAY LIST (17)
-OR
Press HOME (1) then 4until ‘Dynamic Playlist’ is highlighted.
Press 2.
2To play the entire Playlist, press ;/2.
3To play a specific item from the Dynamic Playlist, press 3or 4until the item you
want is highlighted. Press 2.
Replacing Items on the Dynamic Playlist
The Dynamic Playlist can contain up to 20 items. If you try to add a 21st item,
a ‘List Full’ message appears on the LCD screen. If you want to replace an existing
item with the new item:
1Press PLAY LIST (17) to display the list.
2Press 4to find the item to be replaced.
3Press (UN)MARK (4) to remove the old item from the list. The new item is
automatically inserted into the Dynamic Playlist.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 28
EN
29
Advanced Configuration
Start Update?
Edit Device Name
<Name>
Change
Internet Radio
Radio List Version
Automatic Update [ ]
Manual Update
Device Status
Device Name
Firmware Version
Bootloader Version
Hardware Version
SSID
Network Type
Encryption
Wireless Signal Strength
Wireless Channel
MAC Address
DHCP
IP Address
Subnet Mask
Gateway IP
DNS Server Preferred
DNS Server Alternate
Proxy Server
Proxy Hostname
Proxy Port
Advanced Settings
Profile Management [ ]
Key Management [ ]
Edit Device Name
Select Profile
Profile 1
Profile 2
Profile 3
Configuration
Device Status
Internet Radio
Configuration Wizard
Select Language
Advanced Settings
Select Profile
Select Date/Time
*
Proxy Server [ ]
Introduction
The Configuration functions on the SLA5500NS are arranged in a hierarchical menu,
similar to the way in which files are organized in subdirectories on a PC. Menu items
are displayed on the Wireless Music Receiver’s LCD screen and you navigate through
the menu using the remote control. See ‘Configuration Menu Structure’.
This chapter describes how to:
•View various network status settings for troubleshooting purposes.
•Use the Configuration Wizard to make changes to a network profile setting after
initial installation.
•Manage which profile you want to change when you next start the Configuration
Wizard.
•Change the device name of your SLA5500NS.
•Select a new network profile for your SLA5500NS
•Reset your SLA5500NS to its factory settings.
•View the date on which the Internet Radio List was last updated, determine
whether the Radio List will be updated automatically or perform manual updates.
Before You Start
•The SLA5500NS must be turned on.
•The wireless network must be available.
•The Internet must be available.
Configuration Menu Structure
Infrastructure or Ad-Hoc
Enabled or Disabled
Enabled or Disabled
Enabled or Disabled
<Date>
Yes or No Yes or No
See Configuration Wizard Menu for details
On or Off
On or Off
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 29
EN
30
Viewing Network Status Settings
For troubleshooting purposes, you can view various network status settings, as listed
under the ‘List of Network Status Settings’.
Use the remote control and follow these steps to display network status settings:
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Device Status’ is highlighted. Press 2.
3To browse through the Network Status Settings, press 3/4.
Note: To change Device Status Settings, see ‘Managing Network Profiles Using the
Remote Control’.
List of Network Status Settings
Setting Explanation
Device Name Name of the SLA5500NS device.
Example: My SLA5500NS
Firmware Version Version of the SLA5500NS firmware in
use.
Bootloader version Version of the SLA5500NS bootloader
software in use.
Hardware version Version of the SLA5500NS hardware in
use.
SSID SSID (Service Set Identifier) for the
wireless network.
Network Type Wireless network type: Infrastructure if
the network uses an Internet Base
station; Ad-hoc if the network uses a
peer-to-peer connection and no Internet
base station.
Encryption Indicates whether encryption is enabled
on the wireless network: None or WEP.
Wireless Signal Strength Wireless network signal strength.
Wireless Channel Wireless channel currently used by the
SLA5500NS.
MAC Address Physical MAC address of the
SLA5500NS.
IP Address (DHCP) Dynamic IP address currently allocated
to the SLA5500NS by a DHCP server
(if DHCP in use).
IP Address Static IP address currently allocated to
the SLA5500NS (if DHCP not in use).
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 30
EN
31
Subnet Mask Subnet mask for the network to which
the SLA5500NS is connected.
Gateway IP address of the gateway used by the
SLA5500NS.
DNS Server Preferred IP address of the preferred DNS server
used by the SLA5500NS.
DNS Server Alternate IP address of an alternate DNS server
used by the SLA5500NS.
Proxy Server Indicates whether or not traffic to and
from the Internet must first pass through
a proxy server (Disabled/Enabled).
Proxy Hostname Name of the proxy server host
computer to which the SLA5500NS is
connected.
Proxy Port Port on the proxy server to which the
SLA5500NS is connected.
Managing Network Profiles
If there have been changes to your wireless network configuration since you installed
your SLA5500NS, or if you are experiencing problems when using the SLA5500NS,
you may need to change the network profile settings using the Configuration Wizard.
Note: Changing network settings requires some technical knowledge of how your
wireless network is set up. If you are unsure of any of the settings, consult the person
who set up your wireless network or refer to the appropriate network documentation.
Changing Settings for the Currently Active Network
Profile
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Configuration Wizard’ is highlighted. Press 2.
3Now follow the steps under ‘Changing Network Settings’ to change the network
profile settings for the currently active profile.
Changing your display menu language
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Select Language’ is highlighted. Press 2.
3Select the desired display menu language.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 31
EN
32
Changing Settings for a Non-Active Network Profile
By default, any changes you make to network settings will be applied to the active
profile (i.e. the profile that is currently loaded on the SLA5500NS). If you wish to
make changes to a different profile, you must first turn on profile management.
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Advanced Settings’ is highlighted. Press 2.
3When ‘Profile Management [ ]’ is highlighted, press 2.
4When ‘Enabled’ is highlighted. Press 2to activate the setting [*].
5Now follow the steps under ‘Changing Network Settings’ to change the network
profile settings. You will be prompted to select the profile to be changed.
Note: If you want to make this profile the active profile for the SLA5500NS follow the
steps under ‘Activating a New Profile on the SLA5500NS Using Remote Control’.
Turning Profile Management Off
When you have made changes to non-active profiles, you can turn off Profile
Management, as follows:
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Advanced Settings’ is highlighted. Press 2.
3When ‘Profile Management [ ]’ is highlighted, press 2.
4Press 4until ‘Disabled’ is highlighted. Press 2to de-activate the setting [*].
Managing Multiple Key Indexes
The SLA5500NS supports up to 4 Key Indexes for WEP encryption.
By default, Key Index 1 is used when a WEP Key is entered.
However, if you wish to enter a key against another Key Index, follow these steps:
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Advanced Settings’ is highlighted. Press 2.
3When ‘Key Management [ ]’ is highlighted, press 2.
4When ‘Enabled’ is highlighted. Press 2to activate the setting [*].
5Press 2to complete the change.
6Now follow the steps under ‘Changing Network Settings’ to change the network
profile settings. You will be prompted to select a ‘Key Index’ before entering the
WEP key.
7Ensure that you select ‘Exit Key Editing’ when you have finished, and turn off ‘Key
Management’ under ‘Advanced Settings’ when finished.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 32
EN
33
Activating a New Profile on the SLA5500NS using Remote
Control
A ‘default’ network profile is loaded automatically when you first install the
SLA5500NS.
However, you may wish to activate an alternative network profile that you have
created using the Configuration Wizard or the Philips Wireless Music Receiver PC
Utility.
Follow these steps to activate a different network profile:
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Select Profile’ is highlighted. Press 2.
3A list of available profiles is displayed. The currently active profile is denoted by
an asterisk [*].
4Press 4to highlight the desired profile. Press 2.
5The message ‘Selected Profile N...Applying Settings’ will be displayed.
After a few seconds, the SLA5500NS will restart. The device is now ready to
operate using the new profile.
Note: This function can also be performed using the Philips Wireless Music
Receiver PC Utility – see ‘Activating a Different Network Profile’.
Editing the Device Name
Your SLA5500NS is given the default device name Philips SLA5500NS during initial
installation.
Follow these steps to change the device name of your SLA5500NS:
1Press SYSTEM (6) on the remote control to display ‘Configuration‘.
2Press 4until ‘Advanced Settings’ is highlighted. Press 2.
3Press 4until ‘Edit Device Name’ is highlighted. Press 2.
4Press 4until ‘Change’ is highlighted. Press 2.
5Edit the name of your SLA5500NS device (see ‘Entering Text in Edit Mode’).
Example: My SLA5500NS
6Press 2to complete the change.
Performing a Hard Reset to Factory Settings
Under normal circumstances, you should reset the SLA5500NS to its factory settings
by activating the Factory Default profile using the Philips Wireless Music Receiver PC
Utility (see ‘Activating a Different Network Profile’).
However, should this not be possible for some reason, you can perform a hard reset
on the SLA5500NS device itself, as follows:
1Ensure that the SLA5500NS is turned on.
2Insert a paperclip into the small reset hole and hold the reset button down for
2 seconds.
3Remove the paperclip and wait until the SLA5500NS restarts.
SLA5500SN_Eng.qxd 13-04-2005 15:18 Pagina 33
EN
34
Updating the Radio List
The Radio List is a database of Internet Radio stations stored on your SLA5500.
Your SLA5500NS Radio List comes preconfigured with some Internet Radio stations.
You may choose to subscribe to an Internet Radio List Service from an Internet
service provider to add more stations to the list.
Note:Third party service providers may charge for subscription services or apply other
conditions to the use of their services. It is your responsibility to check these conditions
when subscribing.
Viewing the Radio List Version
The Radio List is updated automatically on a regular basis. See ‘Updating the Radio
List Manually’ for a manual update.
Follow these steps to see when the last update occurred:
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Internet Radio’ is highlighted. Press 2.
3When ‘Radio List Version’ is highlighted, press 2.
4The time and date when the list was last updated is displayed in the format
HH:MM YYYY-MM-DD.
5Press 1to return to the Internet Radio settings.
Disabling the Automatic Radio List Update
By default, the Radio List is automatically updated when the SLA5500 is connected to
the Internet and has been idle for a period of 60 minutes.
However, if you need to perform a manual update, first follow these steps to disable
the automatic update feature:
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Internet Radio’ is highlighted. Press 2.
3Press 4until ‘Automatic Update [*]’ is highlighted. Press 2.
4Press 4until ‘No [ ]’ is highlighted. Press 2to change the setting to No [*].
5Press 2to complete the change.
Note: If you turn off the automatic update, the Radio List will not change until you
either reenable automatic update, or use the manual update method (see
below).
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 34
EN
35
Updating the Radio List Manually
You can perform a manual update of the Internet Radio List at any time.
1First disable the automatic update (see ‘Disabling the Automatic Radio List
Update’ above).
2Press SYSTEM (6) on the remote control to display the Configuration menu.
3Press 4until ‘Internet Radio’ is highlighted. Press 2.
4Press 4until ‘Manual Update’ is highlighted. Press 2.
5When the prompt ‘Start Update?’ is displayed, press 2to start the manual update.
> The LCD screen displays: ‘Update in Progress. Please wait’.
Note:This function is not available if there is no Internet access available on the
wireless network.The ;/2button cannot be used while an update is being
performed.
Re-enabling the Automatic Radio List Update
If the automatic update has been disabled (e.g. in order to perform a manual update)
follow these steps to re-enable it:
1Press SYSTEM (6) on the remote control to display the Configuration menu.
2Press 4until ‘Internet Radio’ is highlighted. Press 2.
3Press 4until ‘Automatic Update [ ]’ is highlighted. Press 2.
4Press 2to change the setting to Yes [*].
5Press 2to complete the change.
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 35
EN
36
Advanced Configuration Using Philips
Wireless Music Receiver PC Utility
The Philips Wireless Music Receiver PC Utility is software that runs on your
computer. Most of the tasks it performs can just as easily be performed directly on
the SLA5500NS using the remote control.
However, there may be occasions when you would prefer to use the Wireless Music
Receiver PC Utility.
This chapter describes how to do the following tasks:
•Start the Philips Wireless Music Receiver PC Utility
•Manage network profiles using the Philips Wireless Music Receiver PC Utility
•View existing network profiles
•Activate a different network profile for the SLA5500NS
•Edit a network profile
•Verify that a SLA5500NS is available on the wireless network*
•Upload new software to the SLA5500NS as it becomes available*
*) These tasks can ONLY be performed using the Philips Wireless Music Receiver PC
Utility.
Starting the Philips Wireless Music Receiver PC Utility
The Philips Wireless Music Receiver PC Utility is a software tool for managing the
configuration of your SLA5500NS from your PC.
Note: Before starting the utility, it must first have been installed on your system.
For details see ‘Installing the Philips Wireless Music Receiver PC Utility’.
To start the tool:
•From the Start menu, choose ‘All Programs, Philips Wireless Music Receiver PC
Utility’
OR
•Open the WMRI.exe file in Windows Explorer under the folder where you
installed the software (the default folder is ‘Program Files’\Philips\Wireless Music
Receiver).
When the application opens, it automatically attempts to locate all available
SLA5500NS on your network, and displays those it finds in the available Wireless
Music Receivers’ list.
Note: If no network adapters are found, the following message will be displayed
instead: ‘No network Adapters found’.
The Philips Wireless Music Receiver PC Utility could not find any suitable
network adapters on your system. This program requires at least one suitable
network adapter (wired or wireless).’ If this occurs, please refer to
‘Troubleshooting’.
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 36
EN
37
Managing Profiles Using the Philips Wireless Music
Receiver PC Utility
The SLA5500NS is delivered out-of-the-box, pre-configured with default settings.
These settings are stored in the Factory Defaults network profile, which cannot be
changed. However, other profiles are provided that you can edit to suit your wireless
network.
There are two methods for managing profiles:
ADirectly on the SLA5500NS using the remote control
-OR
BUsing the Philips Wireless Music Receiver PC Utility.
Default Profile Settings
The SLA5500NS is delivered with the following default settings:
SSID: philips
IP address: DHCP enabled
Proxy: No
WEP: disabled
Mode: Infrastructure
PROFILE 1:
SSID: philips
IP address: DHCP enabled
Proxy: No
WEP: disabled
Mode: Infrastructure
Viewing Existing Network Profiles
To view existing network profile details:
1From the main Philips Wireless Music Receiver PC Utility window, click on its
name to select a Wireless Audio Link from the list and click the ‘Profiles...’
button.
2The Factory Defaults profile is displayed. Click on the other tabs to display
alternative profiles, if any. The currently active profile has the ‘Make Active’
button grayed out (disabled) and an ‘Active Profile’ icon in the top right corner of
the screen.
Note: This task can also be done directly on the SLA5500NS using the remote control
– see ‘Viewing Network Status Settings’.
Activating a Different Network Profile
To activate a different profile for a SLA5500NS:
1From the main Philips Wireless Music Receiver PC Utility window, click on its
name to select a Wireless Audio Link from the list and click the ‘Profiles...’
button.
2Click on the appropriate profile tab and click the ‘Make Active’ button on that
profile. Click the ‘Close’ button to return to the main window.
3Click the ‘Discover...’ button. The SLA5500NS should be displayed in the main
panel.
Note: This task can also be done directly on the SLA5500NS using the remote control.
See ‘Activating a New Profile on the SLA5500NS Using Remote Control’.
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 37
EN
38
Editing a Network Profile
The Factory Defaults profile for a SLA5500NS cannot be edited. However, there are
other profiles available that can be edited to effectively create new profiles. To
change these settings, you will need to have some knowledge of your wireless
network setup.
Note: The alternative profiles can be edited at any time, but any existing information
in the selected profile will be overwritten once the profile has been edited and
saved.
1Display the profile to be edited (see ‘Viewing Existing Network Profiles’).
2Give your profile a unique Profile Name.
3Enter the Service Set ID (SSID) for your wireless LAN.
4By default, the profile will use the Infrastructure network type (i.e. an Internet
base station is available on the network). If however you select the Allow ad-hoc
connection checkbox, it means that your PC will use a direct peer-to-peer
connection to the SLA5500NS and no Internet connection is available. Internet
Radio will not be supported with this option.
•If you are using WEP encryption on the wireless network, click the WEP enabled
checkbox and enter the appropriate WEP key and the Key index.
•If you are using a proxy server, check the Use proxy server checkbox.
Enter the Proxy server as an IP address (example 192.167.0.10) or as a name
(example my.proxy). The Proxy port number must be a numeric value
(usually, this is port 80 or 8080).
5If the SLA5500NS will get a dynamic IP address automatically from a DHCP
server, select the Use DHCP checkbox.
6If the SLA5500NS needs a fixed IP address, leave the Use DHCP checkbox
unchecked and enter the IP Address for the SLA5500NS, as well as the Netmask
(Subnet mask), and IP addresses for the Gateway, DNS Server Preferred and
DNS Server Alternate.
7Click the ‘Apply’ button to confirm the changes, or click the ‘Refresh’ button to
discard the changes.
8If you want to make this profile the active profile for the SLA5500NS, click the
‘Make Active’ button. Click the ‘Close’ button to return to the main window.
9Click the ‘Discover...’ button to verify that the SLA5500NS can still be found on
the network after you make these changes.
Note: This task can also be done directly on the SLA5500NS using the remote control.
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 38
EN
39
Verifying that a Wireless Music Link is Available on the
Network
When you start the Philips Wireless Music Receiver PC Utility, it performs an
automatic discovery process to verify which Wireless Music Links are available on the
network. It is recommended that you perform this discovery process manually after
editing any network profiles, to ensure that your computer can still communicate
with the SLA5500NS.
To verify that a SLA5500NS is available on the network:
1From the main Philips Wireless Music Receiver PC Utility window, click the
‘Discover...’ button.
A list of available Wireless Music Links will be displayed in the main window.
Uploading New Software to the SLA5500NS
Check www.philips.com/support for new software versions. When new software
becomes available, the Software Upload Wizard in the Philips Wireless Music
Receiver PC Utility will help you to install it on your SLA5500NS.
WARNING: The Software Upload Wizard should be used with great care.
Uploading incorrect software may result in the SLA5500NS no longer
working as expected.
1Start the Philips Wireless Music Receiver PC Utility (see ‘Starting the Philips
Wireless Music Receiver PC Utility’).
2From the main Philips Wireless Music Receiver PC Utility window, highlight the
SLA5500NS to be upgraded and click the ‘Upload Software...’ button.
3The wizard displays details of the currently installed software for the SLA5500NS
and a warning notice. Click the 1button to cancel the upload or the ‘Next’
button to proceed.
4Select a valid software file (.bcd file) and click the ‘Open’ button. If the file
selected is invalid, an error will be displayed.
5The wizard displays a warning and asks for confirmation. Click the 1button to
cancel the upload or the ‘Next’ button to proceed.
Note: This process may take a while and should not be interrupted. The current
software is erased and the new software is uploaded to the SLA5500NS.
A message is displayed when the upload has been completed successfully. If an
error message appears, or if you see the words ‘Download mode’ in the Active
Profile column instead, it means that the software upload has failed. Turn the
power to the SLA5500NS off and on again before starting a new upload
attempt.
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 39
EN
40
Possible Cause
•Solution
Power unavailable.
•Check that the SLA5500NS power cable is properly connected and that the
power is switched on.
SLA5500NS is not known to the network.
•Check that the MAC address for the SLA5500NS has been entered correctly in
the wireless network’s MAC Access Control. Turn off the Wireless Music
Receiver and turn it on again.
Internet unavailable.
•Check that the Internet base station has an active connection to the Internet.
Wireless network incorrectly configured.
•Open the SLA5500NS Wireless Music Receiver PC Utility and select the Wireless
Music Link that has the problem. Click the ‘Profiles’ button and check that the
active profile is correctly configured for your network. Turn on the SLA5500NS
and ensure that the correct profile has been selected under Network Profiles.
This can be caused by network delays when sending out UPnP requests.
•Make sure the SLA5500NS is connected to the power supply and that the
batteries in the remote control are fresh and inserted correctly.
Wait a few seconds and try again. If the problem persists, unplug the Wireless
Music Receiver, wait a minute, plug it in again and then turn it on again.
No music files in the Media Manager Music Library.
•Follow the instructions under ‘Installing Philips Media Manager’ to add files to the
MusicLibrary.
Media Manager is not running.
•Start the Philips Media Manager server by clicking the Media Manager icon in right
side of the Windows task bar on your computer.
File has been moved or deleted but link is still in Philips Media Manager library.
•The Philips Media Manager library stores a link to a music file, not the file itself. If
you move or delete the music file and do not delete it or reselect it in the Philips
Media Manager Library, the SLA5500NS will be unable to locate the file. Open
Philips Media Manager and delete and/or add the track from the correct file
location.
File permissions on music file are incorrect.
•Check that you have read access to the music file on the computer where it is
stored. If this is on a computer other than the UPnP server computer, check that
the network connection between these two computers is active.
There are limitations regarding the presets, depending on the PC Server tool used
(for example Philips Media Manager, EZ Server, Intel, Mediabolic).
•The PC server software may not be fully compatible with the UPnP specification.
There is no workaround other than storing the presets again.
Troubleshooting
Problem
Date/time is not displayed when the
SLA5500NS is switched on.
The SLA5500NS does not react to
remote commands and hangs in the
UPnP Menu structure.
Unable to browse music files.
Unable to play music file
Presets do not work anymore after a
new CD is ripped or a server is reset.
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 40
EN
41
You are connected to a station that is running, but it is not currently broadcasting
any music.
•Try again later or choose another station.
The buffer is full (everything else seems normal).
•Wait a few seconds until the buffer clears. If the problem persists, turn off the
Wireless Music Receiver and turn it on again.
Station is not up.
•Try looking up the station’s Web site to see if there are any changes.Try a
different Internet Radio station.
There is a VPN (Virtual Private Network) running on your PC.
•Disable the VPN while running the SLA5500NS.
Warning: this may adversely affect other programs and data - proceed with caution.
The Internet base station and the PC are not on the same subnet.
•The Internet base station and the PC must be on the same subnet.
The Internet base station has a MAC filter enabled.
•Add the MAC address of the SLA5500 to the exception list.
Your PC is running a third party software firewall that is preventing access to
Internet Radio.
•Traffic to/from the SLA5500 must be enabled for the media server program.
Change your firewall settings to enable multicast messages for the media server
program. If the above solution does not work, disable the firewall for
troubleshooting purposes.
Warning: this may adversely affect other programs and data - proceed with caution.
Your PC is using the Microsoft built-in firewall.
•Traffic to/from the SLA5500 must be enabled for the media server program.
Change your firewall settings to enable multicast messages for the media server
program. (239.255.255.xxx).
If the above solution does not work, disable the firewall for troubleshooting
purposes.
Warning: this may adversely affect other programs and data - proceed with caution.
Your PC uses a Microsoft packet filter.
•Disable the packet filter for troubleshooting purposes.
Warning: this may adversely affect other programs and data - proceed with caution.
Your PC uses a static IP address and therefore does not access a DHCP server.
•Use a different network profile that allows for a fixed IP address. See ‘Activating a
New Profile on the SLA5500 Using Remote Control’.
• Turn off the SLA5500 and turn it on again.
Windows Media Connect has not yet detected the capabilities icon of the
SLA5500SN.
• Online help : www.philips.com/support.
• Check your firewall settings: 'UPnP Framework' should be allowed to send and
receive data.
Cannot connect to an Internet Radio
station after pressing ;/2and an
error is displayed.
After accessing an Internet Radio station,
the device does not playback other
Internet Radio stations.
A lock icon is displayed instead of a
music note icon.
Not possible to browse Windows Media
Connect server content.
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 41
EN
42
SLA5500NS Error Code
The SLA5500NS LCD screen may display the following error code in the event of a
problem.
Error Code Explanation
Update Please wait.The Internet Radio station
list is updated automatically from the
Internet on a regular basis or when you
choose to do a manual update. Play
mode does not work during this update.
List full. The Dynamic Playlist is limited to 20
items. Replace an existing item with the
new item. See ‘Replacing Items on the
Dynamic Playlist’ for details.
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 42
EN
43
The following is a list of terms and abbreviations used in this document.
Term or Abbreviation Meaning
Base station (BS) A device used to provide common wireless access to the Internet.
CD-ROM Compact Disk - Read Only Memory. An optical disk used to store computer data.
DHCP Dynamic Host Configuration Protocol. Used by a server to assign IP addresses to
network devices.
DNS Domain Name Server. A server that converts domain names to IP addresses.
Gateway A device that connects two networks, for example a local area network to the
Internet.
IP Address Internet Protocol Address. A unique 32-bit logical number assigned to a device on the
Internet. An IP address can be static (fixed) or dynamic (assigned by a DHCP server
on connecting to the network).
Key Index Number used to identify a particular encryption key in a list of several encryption
keys supported by a wireless network.
ISP Internet Service Provider. Company that provides the service that allows you to
connect to the Internet.
LCD Liquid Crystal Display. A flat panel screen used to display characters.
MAC address Media Access Control Address. A unique physical number assigned to device on a
network, in the format of a 48-bit hexadecimal number.
MP3 MPEG Audio Stream, Layer 3. An ISO/IEC standards-based audio file format
developed by the Moving Pictures Experts Group (MPEG).
PC Personal Computer. In the context of this document, can also refer to a laptop
device.
Proxy A proxy server sits between the client and the Internet. It can retrieve requested files
from its own cache or from a remote server. It is also used in conjunction with a
firewall and gateway to enhance security on a network.
RCA A standard connector plug used to connect a device to an audio device.
SSID Service Set Identifier. A 32-character identifier attached to packet headers sent over a
wireless network that uniquely identifies the wireless LAN to which the device is
attempting to connect.
Subnet Mask Sub-network mask. A subset of a network (that consists of multiple devices) that has
its own unique subnet number.
UPnP Universal Plug and Play. Allows automatic discovery and control of networked devices
and services.
Wireless Music Link A device that connects wirelessly to a PC and the Internet to allow music files and
Internet radio to be played over an audio system.
Philips Wireless Music Receiver PC Utility Wireless Music Receiver PC Utility Software that allows you to configure the
SLA5500NS from the PC.
WEP Wired Equivalent Privacy. An encryption method that provides security for 802.11
wireless network systems using a 64 or 128 bit key.
WMA Windows Media Audio. An audio file format developed by Microsoft.
Glossary
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 43
EN
44
Extra information
Common Firewall Configurations
This chapter contains details on how to configure some common firewall programs in
order to ensure correct SLA5500NS operation.
As this information is likely to change when new versions of firewalls are released,
you should check your firewall documentation for the most recent information.
Windows XP Service Pack 2 Firewall and Philips Media
Manager
When Windows Firewall notifies you about Philips Media Manager (which is called
‘LaunchAnywhere GUI’ or ‘Media Management for your Media Devices’), select
‘Unblock’.
IMPORTANT: If you are using a wireless gateway or base station and there is a
firewall in place, multicast messages must be enabled for the media
server program in order to allow traffic to/from the SLA5500NS
(239.255.255.xxx).
Technical Information
The SLA5500NS is designed to comply with the following standards.
Electromagnetic Compatibility USA: FCC CFR47 Part 15B, Class II
Europe: 89/336/EEC,
ETS 301 489-1&17(2.4GHz)
EN61000-3-2
(Harmonic AC current emissions)
EN55022 Class II, EN50082-1 (Immunity)
Japan: VCCI Class II
Product Safety CB (IEC60950)
Radio Regulations USA: FCC CFR47 Part 15C,
para15.247, 205, 209
Europe EN 300 328
Japan: ARIB STD-T66 (Chan1-13),
T-33(Chan14)
Canada IC RSS 210
Dimensions (h x w x d): 110 x 160 x 44 mm
Power consumption / standby power:4.5 Watt / 2 Watt
Weight:240 grams
Supported codecs: Audio: WMA-DRM, WMA, MP3, WAV
Output connectors: Audio: 1/8" connector to 2 x L/R stereo
(cinch)
Wireless: 802.11b
Networking: Universal Plug & Play
Specifications are subject to change without notice.
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 44
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.
2005 © Koninklijke Philips Electronics N.V. All rights reserved.
www.philips.com
Guarantee certificate
Certificat de garantie
Garantieschein
Garantiebewijs
Certificado de garantia
Certificato di garanzia
Certificado de garantia

Garantibevis
Garanticertifikat
Garantibevis
Takuutodistus
11
0682
Type: SLA5500NS
Serial nr: _____________________________________________________________________
Date of purchase - Date de la vente - Verkaufsdatum - Aankoopdatum - Fecha de compra - Date d’acquisito -
Data da adquirição - Gía a - Inköpsdatum - Anskaffelsesdato - Kjøpedato - Oatopäivä -
year warranty
année garantie
Jahr Garantie
jaar garantie
año garantia
anno garanzia
 
år garanti
år garanti
år garanti
vuosi takuu
año garantia
Dealer’s name, address and signature
Nom, adresse et signature du revendeur
Name, Anschrift und Unterschrift des Händlers
Naam, adres en handtekening v.d. handelaar
Nombre, direccion y firma del distribudor
Nome, indirizzo e firma del fornitore
a,  a a  . 
Återförsäljarens namn, adress och signatur
Forhandlerens navn, adresse og unterskrift
Forhandlerens navn, adresse og unterskrift
Jälleenmyyjän nimi, osoite ja allekirjoitus
Nome, morada e assinature da loja
SLA5500SN_Eng.qxd 13-04-2005 15:19 Pagina 45

Navigation menu
