user manual
POSH LYNX A100
User Manual
Before Using ............................................................................. 2
Phone Unlock .......................................................................... 2
SIM Unlock .............................................................................. 2
Function menu Introduction ................................................... 2
Phonebook ............................................................................... 2
Call history .............................................................................. 4
Settings .................................................................................... 4
Profile ..................................................................................... 8
Multimedia .............................................................................. 9
Oganizer ................................................................................ 12
File manager ......................................................................... 14
Fun&Games .......................................................................... 14
FCC ID: 2ABN6POSHA100
2
Before Using
Phone Unlock
In order to prevent illegal use, your phone can set the phone lock
password protected. Use this function, you must enter the phone
lock password so that you can unlock the phone into the normal
use state.
Enter the phone lock password, press the LSK to confirm. For
example, if the phone lock password is set to 1234, then the
following input: 1234 OK
SIM Unlock
In order to prevent illegal use of your SIM with PIN (Personal
Identification Number) password encryption protection. Use this
function, if you have set the PIN password protection, every time
you must enter the PIN password at boot time, so that you can
unlock the SIM card and phone to normal use.
Enter the PIN password,press the LSK to confirm. For example, if
the PIN is set to 1234, then the following input: 1234 OK
If three consecutive incorrect, your SIM will be network locked,
the phone will ask for PUK password.
Function menu Introduction
Phonebook
Press OK in the idle or from the main menu to enter the
phonebook.
You can use the phonebook to store recordes, can store the
following: name and phone number. In the phonebook list, select a
record, to make a call when you press the dial keys.
Select a record in the phonebook, you can do the following:
-View View the details or edit record.
-Send text message Send SMS to this number.
-Call Make a call to the number.
3
-Edit Can edit and save record.
-Delete Delete the record.
-Copy Copy the current record to Phone/SIM.
-Send business card
As text message: Send phonebook via SMS. Select this item to go
on to the receiver's number Editing Interface. The interface can
directly enter a phone number, but also access to all of the
multiple-choice card interface. You can simultaneously select
multiple recipients to send.
Via Bluetooth: Send phonebook via B-tooth. First of all you want
to add the device to receive the card, displayed all the equipment,
select a matching, please enter the B-tooth adapter code, enter the
correct code and directly send the card to each other.
-Add to Blacklist Add the current record to the blacklight.
-Mark several Mark several or all records can send text
message or delete
-Groups You can add Group including ‟SIM1‟, „SIM2‟,
„Family‟, „Friend‟, „Coworker‟, „Classmate‟, Options a group can
display the group all contacts, this list interface, selection
[ options ] operational items are the bulk of information and edit
group
Phonbook settings
-Preferred storage can be in the SIM1, SIM2, Phone and All
to switch, and phonebook list will change accordingly, such as
select SIM1, the phonebook list will only show SIM1 records .
-Speed dial according to the number keys 2-9 to call the
telephone number.
-Extre numbers can be set SIM fixed dial numbers.
-Memory status View the usage and free Phonebook capacity
information.
-Copy contacts If select SIM to phone, the SIM card records
of all telephone numbers copied to the phone
-Move contacts You can select the SIM records of all mobile
phone numbers move to the phone, also you can switch the option
to operate.
4
-Delete all contacts You can delete all contacts in SIM card or
phone and all records are deleted.
Call history
Missed calls
Enter the missed call menu, will display the missed calls list.
Select missed call record, press the middle key to enter "Options":
-View View the details.
- Call Call the record number.
- Send text message Send SMS to record number.
- Save to Phonebook Save the number to the phone or SIM
card.
-Add to Blacklist Add the current record to the blacklight.
- Delete Delete the number
Dialed calls
Enter the dialed calls menu to display the current record of
outgoing phone list of phone numbers.
Please refer to Missed calls for details.
Received calls
Enter the received calls menu to display the current record has
been received mobile phone number list.
Please refer to Missed calls for details.
Call times
Enter this menu，display the call timers。Input password 162995
Settings
Duad SIM settings
Seleclt to open or close SIM cards‟ function. If there are no SIM
cards in the card ports, then you can not do operations with the
card.
5
The SIM cards‟ function will active when you open the SIM card.
Call waitting
Open this menu， during the call if the new call, the network will
notify you. Specific use with your network provider.
Avtivate lanch the function.
Deactivate Close the function.
Query status Query the function‟s status.
Call divert
Network Call Transfer service allows you to call a business case
in a default transferred to a phone number you specify.
The features include: Divert all voice calls,Divert if
unreachable,Divert if no answer, Divert if busy,Divert all data
calls.Enter the corresponding Transfer menu, you can do the
following:
Acitvate Transfer the current call forwarding setting
number.
Deactivate Call transfer prohibited.
Query status Check the satus of this function.
After setup is complete, when you do not need call forwarding,
you can cancel all diverts to prohibit the use of the above
functions.
Call barring
Into the "Call barring" sub-menu, you can set the following call
barring any combination to improve security. Some network
providers may not provide this service call restrictions, specific
use, please contact your network provider. Network provider will
provide a four-ban password so that you can enable call
restrictions.
Change the password to enter the old call barring password, set
new restrictions on the password.
6
Advanced settings
Blacklist：
Reject number in blacklist can on\off this function
Blacklist numbers can input numbers and add numbers from
phonebook and call history
Auto redial:
Through on / off settings, to activate or disable the feature.Turned
on and when your phone call after another failed attempt to
connect up to redial 10 times. This feature can save you the
trouble of repeated calls.
Auto call record In the process of calls, can the recording
Phone settings
Into the phone settings sub-menu, you can make the following
settings:
Time and Date
In this menu, you can move the phone time and date settings. The
menu consists of three sub-menu:
Set home city: The city a total of 78 international cities by
selecting different cities, change the mobile phone area.
Set time/date: Set time and date are set according to the
established format and on / off daylight saving function. Phone
allows you to set a calendar from 2000 to 2030 between the dates.
If daylight saving is set to open, then the phone time to add in the
original time of one hour or one hour later.
Set format: Set time and data‟s form
Display
Wallpaper: Wallpaper set in two ways: First, through the
navigation system comes with the wallpaper and select; the second
is user defined, by browsing the [File manager] photos folder
identified as a wallpaper.
7
Show date and time: Display date and time to do On / Off
settings, to determine whether the date and time displayed on the
idle screen.
Dedicate key
Set up，down ,left and right key for any functions of you want
Audo update time
can be set to automatically update time.
Flight mode
Turn On/Off the Normal or Flight mode. If you select Flight mode,
SIM cards‟ function will not active.
Network settings
Network selection
Select Network: Search Network, you can choose from a list of
networks you need to network.
Selection mode: Press the left soft key to select automatic or
manual mode. Automatic, mobile phone SIM card information is
automatically selected according to service provider; manually,
choose manually select the network services, mobile phone search
to get the current list of service providers for users to select the
service provider SIM card type.
Security settings
Into the "Security Settings" menu, you can set the phone's security
options, mobile phone or SIM card to avoid unauthorized use.
SIM security settings
PIN lock
SIM card PIN password to lock the completion of your SIM card
to prevent unauthorized use.
8
If the current SIM card lock is closed, select Open to open the
SIM card, enter the PIN lock password, the next boot requires that
you enter the correct PIN password to enter;
If the current SIM card lock is On, select Off to close the PIN lock
protection.
Change PIN: If the current PIN password lock has been
activated, you can re-set on the PIN password
Change PIN2: PIN2 old to enter the correct password, you can
set on the PIN2 password.
Phone security
Phone lock:
Phone lock password can prevent your mobile phone stolen by
others.
Select On to open phone lock password to enter the correct
password-protected phone lock open, the next boot requires that
you enter the correct password to enter the phone lock.
Change password:
Change the phone password, enter the old password and then enter
a new password. Phone default password is 1234.
Anti-theft tracking
Restore factory settings
In this menu, enter the phone lock passworde, once determined,
the phone automatically reboot the phone after the relevant
parameters can be set to return to the case of mobile phone factory.
The default password is 1234.
Profile
Profile including General、Silent、Meeting, Outdoor. First, based
on the current scene, select a different profile, then you only need
a personal profile can be set and activated.
General: General environment.
Silent: For Silent environment.
9
Meeting: For meeting the environment, to be pre-set (for
example: ring mode can be set to vibration).
Outdoor: For outdoor activities, need to pre-set (for example,
ring volume can be set to a higher state).
Press the left soft key "Options":
Activate: Enable the selected profile.
Customized settings
Alert type: Can choose to Ring only, Vib. only, Vib. and ring,
Vib. Then ring as the current method.
Ring type: You can choose repeat and beep once two type
Ringtone According to their own preferences set ringtones 1-5,
can also be set from the memory card custom ringtones
Ringtone volume In the volume control interface, you can
volume up and down navigation keys on the set. Volume level is
divided into seven, 1-7, followed by increases.
Message According to their own preferences set ringtones 1-5.
Message volume In the volume control interface, you can
volume up and down navigation keys on the set. Volume level is
divided into seven, 1-7, followed by increases.
Keypad you can set keypad as silent、click and tone
Keypad volume In the volume control interface, you can
volume up and down navigation keys on the set. Volume level is
divided into seven, 1-7, followed by increases.
System alert can on\off system alert
Shortcuts
Shortcuts interface，press LSK key into option，it display add、
edit、delete、delete all and change order.
Multimedia
Camera
The phone includes high-definition camera, you can take pictures
anytime, anywhere, and to save the photos to your phone or
10
memory card .
State in the preview, press the LSK to enter "Options" you can do
this to conduct a more detailed set of parameters.
Switch to video record:Into video record menu.
Photos: Photo album shows the current list of files.
Camera settings: Including Shutter
sound,EV,Contrast,Anti-flicker, Delay timer setting operation
contents of the regulation. Been adjusted, press the LSK "OK" to
save the current settings.
Image settings: Include the Image size and image quality
regulation.
White balance: Set the white balance state.
Scene mode: Including Auto and Night scene mode .
Effect settings: You can set the effects to
normal,grayscale,sepia,sepia green,sepia blue,and color invert.
Storage: storage location can be set as Phone, Memory card, the
captured image will be saved to the specified location.
Restore default: Set all parameters to default settings.
Image viewer
Select an album sub-menu, you can easily view stored in the
camera album picture list, and press the LSK to enter to "Options"
to choose the pictures to do the View, Image information, Send,
Use as, Rename, Delete, Sort by, Delete all files and change
Storage operations. View pictures, by clicking on the left and right
navigation buttons to switch pictures.
Video recorder
Switch tocamera: To switch from the camera and the camera
Camcorder settings: Recorder settings includingAnti-flicker
setting.
Video settings : Including video quality. .
Storage: Storage location can be set as Phone and Memory card,
shooting the video will be saved to the specified location.
11
Video player
Choose video player sub-menu, you can easily view the saved
video player in the video list, press the LSK to enter "Options" to
select the video files to do the play, send,rename, delete and short
by operation.
Send the video via Bluetooth if you want.
Audio player
In the Audio player interface, you can press left and right keys to
switch the music; press * and # keys to adjust the play volume.
In the Audio player interface, press the left soft key to enter "list"
menu and enter the current playlist to play in the option list can be
any of a music file to play.
Select a music file to enter the settings option, you can top of the
screen prompts the items content specific settings of each item:
Pre.playlist: Can select the preferred list, Phone or Memory
card. If you choose a memory card, then show the all music files
in memory.
List auto gen.: To switch to this setting. When this feature is set
On, you can perform the "Refresh Playlist" operation.
Repeat: Can be set to Off (no repeat), One, All.
Shuffle: Random order of play set, respectively, can be set to
On and Off.
Background play: Set the background play On, you can make
mobile phone in other user interface and also play music. Set as
Off, the music will not play when out of the Audio player.
Sound recorder
In the sound recorder interface click “option”, it shows the items
of record.
New record Start to new record. If you click stop , it will pop
up a dialog box to prompt you save it or not. If you click pause, it
12
will suspend recording, and then click continue, it can record
again.
List It displays the sound that you recorded and saved in the
memory card.
Settings You can set the storage and audio quality of the
record.
FM radio
FM interface, press the down navigation key to turn on / off FM
play, press the UP navigation key to automatic search , press *and
# keys to adjust the FM playing volume.
Press the left soft key "Options" can show FM options menu, the
content were:
Channel list: Shows FM channel list.
Manual input: Can be their own editors to manually enter the
channel frequency, the effective value of 87.5 ~ 108.0
Auto search: Auto search FM channels in the channel list.
Settings: Can on/off the background play and loudspeaker.
Record: record the program you are listening to and save it in the
recording list automatically
File list: play recorded audio files
Oganizer
Torch
Into to torch on/off menu,can on\off torch
Calculator
Your phone provides you with the basic arithmetic operations can
be a function of the calculator, easy simple operation.
Press the left soft key "Clear" or stylus to click on the "Clear" can
be cleared.
Press the right softkey "Back" to exit the calculator.
Note: This calculator has limited accuracy and rounding
errors will be generated, especially in addition to endless time.
13
When the calculation of range, the display area will use the
letter "E" to represent.
Bluetooth
Power: Activate Bluetooth on or off the Bluetooth function.
Visibility: If set as On, other devices can search this Bluetooth
device; if set as Off, other devices can not search this Bluetooth
device.
My device: Can search for nearby Bluetooth devices.
Search audio device: Free devices to search for near-free
decoration, such as Bluetooth headsets.
My name: The Bluetooth device name can be modified.
Calendar
Enter calendar sub-menu, the screen will show a calendar month,
and other background box with the current date marked.Press the
up, down, left, and right navigation keys to change the date,
calendar information on the screen will be updated accordingly.
Tasks
You can view, add,edit,delete,delete overdue,delete all,jump to
date,view uncompleted tasks.
Alarm
Five alarm can be set up (turned off the alarm is still valid.)
Select and edit an alarm clock: Can edit the setting of alarm on /
off, Time, Repeat and Alert type. You can choose to set to repeat:
Once, Everyday, Custom
World clock
In the world clock interface, users click right or left button can
change region and time. Click “option”, you can set on or off
14
daylight saving time for foreign city or not. If select on, the
present time increase one hour. Otherwise, it displays local time.
File manager
Into the File manager menu, the menu display Phone and
Memory card.
Root directory, select "Phone", press the LSK to enter "Options"
can be as follows:
- Open Open the root directory lists the directories and files.
- Format Format the memory card, this action will remove all
current flash memory data.
Root directory, select “Memory Card”, press the LSK to enter
"Options" can be as follows:
-Open Open the root directory lists the directories and files.
-Format Format the memory card, this action will remove all
current flash memory data.
-Details for more information you can view, such as Name,
Total size, free size.
You can play the music or video files, view Photo,
copy/move/delete files, remame files and so on.
You can send the file through Bluetooth.
STK
STK Display Operators‟s information.
Fun&Games
Games Into this menu display snake and game setting.
FCC RF EXPOSURE INFORMATION:
WARNING!! Read this information before using your phone
In August 1986 the Federal Communications Commission (FCC) of the United States with its
action in Report and Outer FCC 96-326 adopted an updated safety standard for human exposure
to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those
guidelines are consistent with the safety standard previously set by both U.S. and international
standards bodies. The design of this phone complies with the FCC guidelines and these
international standards. Use only the supplied or an approved antenna. Unauthorized antennas
modifications, or attachments could impair call quality, damage the phone, or result in violation
of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes
into contact with the skin, a minor burn may result. Please contact your local dealer for
replacement antenna.
BODY-WORN OPERATION:
This device was tested for typical body-worn operations with the back of the phone kept 0.5cm
from the body. To comply with FCC RF exposure requirements, a minimum separation distance
of 0.5cm must be maintained between the user's body and the back of the phone, including the
antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories
containing metallic components shall not be used. Body-worn accessories
that cannot maintain 0.5cm separation distance between the user’s body and the back of the
phone, and have not been tested for typical body-worn operations may not comply with FCC RF
exposure limits and should be avoided.
For more information about RF exposure, please visit the FCC website at www.fcc.gov
Your wireless handheld portable telephone is a low power radio transmitter and receiver. When
it is ON, it receives and also sends out radio frequency (RF) signals. In August, 1996, the Federal
Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for
hand-held wireless phones. Those guidelines are consistent with the safety standards previously
set by both U.S. and international standards bodies:
<ANSIC95.1> (1992) / <NCRP Report 86> (1986) / <ICIMIRP> (1996)
Those standards were based on comprehensive and periodic evaluations of the relevant
scientific literature. For example, over 120 scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the available body of research to develop
the ANSI Standard (C95.1). Nevertheless, we recommend that you use a hands-free kit with
your phone (such as an earpiece or headset) to avoid potential exposure to RF energy. The
design of your phone complies with the FCC guidelines (and those standards).
Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the phone and may violate FCC regulations.
NORMAL POSITION:
Hold the phone as you would any other telephone with the antenna pointed up and over your
shoulder.
TIPS ON EFFICIENT OPERATION:
For your phone to operate most efficiently:
• Extend your antenna fully.
• Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna
affects call quality and may cause the phone to operate at a higher power level than otherwise
needed.
RF Exposure Information:
This product is compliance to FCC RF Exposure requirements and refer to FCC website search for FCC
ID: 2ABN6POSHA100 to gain further information include SAR Values.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help
Do not use the device with the environment which below minimum -10℃ or over maximum
50℃, the device may not work.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
