PRIMOS HUNTING CALLS 62510 TREESTAND LIGHT User Manual
PRIMOS HUNTING CALLS TREESTAND LIGHT
Users Manual
TREESTAND LIGHT
100 Yard Remote Treestand Locator Model No.62510
INCLUDES: Treestand Light 1“23A”12V Battery (Remote)
4“AA”Batteries (Treestand Light) Tree Strap (10 ft x 1 in)
100 Yard Remote Control Tree Accessory Holder
Need help finding your stand in thd dark? The Primos Treestand Light will help you find it.The Treestand Light attaches to the tree
and works by remote up to 100 yards away or manually with a switch on the unit.Choose from 3 settings on the light: Strobe Mode –
will flash 2 red lights to locate your stand. Red or Green Mode – Choose from 6 red LED’s or 3 Green LED’s to light your ladder
while climbing up your stand. Main light can be adjusted down 90。.
IMPORTANT: Please read all instructions and warnings before using this product to ensure safe and proper use.
BATTERY INSTALLATION
Remove screw from back of light and install (4) “AA”batteries according to the diagram located inside of the battery chamber. (See
Diagram 1a) Remove screw from back of remote and install (1) “23A”12V battery according to the diagram located inside of the
battery chamber. (See Diagram 1b)
OPERATION
Place the 3-Way switch located on side of unit in the RF position for use with the remote control. The ON position will turn only the
(3) green LED’s, and OFF position will completely turn off unit. (See Diagram 2)
To Use Remote Control:
First turn unit switch to RF position
Press Red to operate the (6) red LED’s in head of light
Press Green to operate the (3) green LED’s in head of light
Press Red Strobe to operate the (2) red strobe lights
Press off to turn LED’s off
Double Mounting Options Included:
Hang light with tree hook (Included)
Use strap provided by wrapping strap around tree and pulling it snug
Headlamp will rotate 90。 to illuminate treestand steps/ladder.
Be sure that switch on unit is turned to OFF position when unit is stored.
Unit switch should be left in RF position during use in field to allow remote operation.
MAINTENANCE
IF unit starts to malfunction, change the batteries in the light and the remote.
When unit batteries are in need of replacement, please use“AA”alkaline batteries.
When battery in remote is in need of replacement, use“23A”/ 12V battery.
VISIT OUR WEBSITE AT PRIMOS.COM
LIMITED WARRANTY
WARNING: This product contains chemicals, Including lead,
known to the State of California to cause birth defects or
other reproductire harm. WASH HANDS AFTER USE.
WAIUER OF UABILITY: By breaking the seal on this package, the
coasumer accepts all liability associated with the use or abuse of
this product. Including, but not limited to, injury of any kind, breakage
of product, or damage to any equipment used in coajunction whth this product.
User Manual
The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to
this equipment. Such modifications could void the
user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and;
2. This device must accept any interference received,
including interference that may cause undesired
operation.
FCC Note
