PROEXPRESS DISTRIBUTOR D107A4 Tablet PC User Manual
PROEXPRESS DISTRIBUTOR LLC Tablet PC
User Manual
01 02 03 04 05 06 07 08 09 10
IMPORTANT SAFETY INSTRUCTIONS
Do not use this apparatus near water.
Do not place near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
Only use attachments/accessories specified by the manufacturer.
Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, such as vase, shall be placed on the
apparatus.
The batteries (battery pack & batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
Do not place any naked flame sources, such as lighted candles, on
the apparatus.
The battery used in this product must be properly recycled or
disposed of. Please contact your local recycling center for proper
battery handling and disposal instructions.
Please charge your unit when it is:
- The battery icon indicates the power is lower.
- The unit shuts off suddenly, even if restart again.
- Tapping any button has no response.
Please use the AC power adaptor (supplied) or USB-to-DC cable
(optional) to charge the unit; otherwise, using other adaptors may
damage your unit.
When the player is formatting, uploading or downloading, do not
disconnect the connection. It may cause program error if you do this.
We are not responsible for the memory loss caused by product
damage, repairmen or other reasons. Please operate strictly
following these instructions.
Clean only with dry cloth. Do not use aerosol cleaners, benzene,
anti-static liquids or any other solvents for cleaning
Refer all servicing to qualified service personnel.
Turn off the unit or use airplane mode when use is prohibited, such
as traveling in the aircraft.
The supplied USB cable is used for data transmission only.
Non-waterproof.
PRODUCT OVERVIEW PRODUCT OVERVIEW
1
2
3
4
5
6
7
8
9
Front camera
Take a photo or record a video.
(Earphone) jack
Outputs audio to earphone, speakers and amplifier.
Charging Port
(Power) button
Press and hold to turn on/off the unit.
Press to wake up the screen.
Press to lock the screen.
Volume+/- buttons
Press to increase or decrease the volume level.
TF card slot
Insert a flash card to extend the memory.
Micro USB port
Connect through USB cable to your PC for transferring
data.
Connect to AC power adaptor
Rear camera
Take a photo or record a video.
1
5
8
CHARGING THE BATTERY
2
2
1
To DC jack
To power outlet
(Optional)
234
6
7
9
7
Speakers
Take a photo or record a video.
or
To USB power
outlet, such as
PC, USB car
charger.
AC adaptor
(Supplied)
USB-to-DC cable
(Optional)
CAUTION!
Please charge the battery fully when use the unit at the first
time.
Notes:
Please charge only using the AC power adaptor (supplied) or
USB-to-DC cable (optional).
Charge your unit at least for 10 hours at the initial two charges.
After then you can charge just for 7 hours.
Enable Google text search
Clock widget
Enable Google voice search
Access Apps menu
Display the recent used Apps
Go back to the main screen
Notifications area
Go back to the previous screen
EXPLORING THE MAIN SCREEN ANDROID APPS AND WIDGETS
Display the available Apps
Display the useful widgets
Access the android market
Tap the button on the main screen to enter the Apps menu.
Notes:
Tap and hold an App or a widget, and drag it to a desired
screen.
Tap and hold an App or a widget on the main screen until X
appears, then drag it to touch the X to remove from the screen.
Note:
After operating, tap any other area on the screen to turn off the
Notifications panel.
Tap this area
NOTIFICATIONS PANEL
1
2
3
OPERATING ACTIONS
Tap: Tap an item or App once to select the item or
launch the App.
Long-tap: Tap and hold the current operating interface or
area until the relevant items appear, then
release.
Slide: Slide up/down/left/right to switch between
different screens conveniently.
Drag: Tap and hold an icon on the desktop and drag
to other position.
Pinch & Spread:
Use two fingers to tap the screen, and adjust the
distance between them to zoom in/out the current
photo or web contents.
INFORMATION INPUT
When you need to input texts, tap the text input box, the keyboard
will appear automatically. After input, tap the button to close
the keyboard.
BASIC OPERATION CONNECTIONS CONNECTIONS
WARNING!
When connecting to PC, please follow the computer prompts
strictly to avoid any data loss.
Do not disconnect the USB connection during data transfer-
ring; otherwise it will cause data damage or loss.
1
Connect the one end of the USB cable (supplied) to the unit,
and the other end of the USB cable (supplied) to your PC.
2
Tap Turn on USB storage to transfer files.
CONNECTING TO EARPHONE
To (Earphone) jack
You can connect an earphone to the earphone jack for personal
listening.
For protecting your hearing, always turn the volume down before
plugging the earphones and use only the minimum volume setting
necessary to hear your conversation or music.
Illustrations contained within this user manual are for
representation only and subject to change.
Bluetooth
Pair
Find the Bluetooth table, open it.
Open your mobile , find Bluetooth
and open it.
Search other bluetooth device on your mobile and try to pair.
When it contact successfully, you can use it OK.
11 12 13 14 15 16 17 18
Please read all instructions carefully before use
and keep for future reference.
The design and features are subject to change
without notice.
User Manual
Tap the in the Apps menu to listen to your favorite music
with the music player.
* Classify music in different categories
* You can use these categories to find your preferred music
conveniently.
Tap to view the current playing music
Tap to set up the playing mode
MUSIC
Tap the in the Apps menu to view photos and videos stored
in your unit or TF flash card.
Note:
You can choose to view a photo, and use the toolbar on the
upper-right corner to share, delete, edit it, and view its detailed
information.
Classify photo and video files in different
categories
Tap to turn on the camera
Tap to select files, set file to make
available offline, and refresh the Gallery
Tap the in the Apps menu to take photos or record using the
camera. The photos and videos will be stored into the Gallery
automatically.
Slide to adjust the focus
Tap to select among taking photos, recording
videos, and capturing panorama.
Tap to customize the camera settings
Tap to take photo or start recording
Tap to switch between front camera and rear camera
1
Tap the in the Apps menu to enter the settings menu.
2
Tap to select Wi-Fi item and switch it to ON. The unit will scan
the available networks automatically.
3
Tap the desired network, and input the password if necessary.
Then tap Connect.
Before creating the Wi-Fi connection, please ensure that your
WLAN network has been configured correctly.
Tap to activate WLAN protected setup
Tap to add a network with Network SSID
Tap to view more information about Wi-Fi
You can use your Google account to download various Apps
from the Android Market. Set up your own account first to access
the Android Market.
Tap to sign in If
you have an
account before
Tap to create a
new account
1
Tap the in the Apps menu.
2
Add a Google account to the unit.
3
After signing in, you can download your desired Apps
from the Android Market.
Tip:
Because some
Apps are not
free, you need to
pay for them via
your credit card
for downloading.
In the Settings menu, you can configure the unit, set app options,
add accounts, and set other preferences.
1
Tap the in the Apps menu to enter the settings menu.
2
Tap and select an option and configure it according to
the screen prompts.
GALLERY CAMERA Wi-Fi CONNECTION ANDROID MARKET SETTINGS TROUBLESHOOTING WARNING
Check this list for a possible troubleshooting solution.
Cannot power on
Check the battery power if it is too low.
Connect the adaptor and power on again.
Battery power is low, please charge in time.
Check the volume setting, and adjust the volume level by
tapping Volume+/- buttons.
Check if the audio file is damaged; try to choose another audio
to play.
Check if the connection is available.
Check if the unit has enough storage memory.
Reset the unit by pressing (Reset) button and power on
again.
Restore the system to factory default.
After powering on, the screen starts blinking and power off
suddenly
No sound output
Cannot copy files or play audio files
System has errors
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable prote
-ction against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instru
-ctions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful inter
-ference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void your
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
