User Manual
HUB
Model: HUB 2.0
PROSPACE PTE LTD
Hub$2.0$$
Manufactured+by:+ProSpace+Pte+Ltd.+
+
+
+
+
+
+
+
+
+
Descriptions:+The+hub+is+used+to+receive+RF+433Mhz+signals+sent+by+other+
separate+PIR+sensors/devices+–+and+thereafter+transmit+the+data+to+3G+network+
via+embedded+3G+module+(with+3G+simcards)++
+
Primary+function+
Receive+RF+433+Mhz+signals+
Transmit+data+to+Internet+via+3G+network+
Environment+
To+be+deployed+in+sheltered+environment+not+exposed+
to+rains+and+direct+sunlight.+(eg-+home,+offices)+
Power+rating+
DC+5V,+2.5A+
Dimension++
87mm+x+58mm+x+23mm+
+
+
User$manual$–$How$to$deploy:$
1. Power-on+the+hub2.0+by+connecting+it’s+adapter+to+normal+power+socket+
readily+available+in+any+buildings.++
2. The+hub2.0+will+then+start+collecting/receiving+signals+from+nearby+PIR+
devices.++
3. To+read+the+RF+data+collected,+below+the+3+ways:+
a. Connect+the+hub2.0+with+a+monitor/laptop+via+HDMI+port.+
b. Connect+LAN+cable+to+hub2.0+to+transfer+data+to+Internet.+
c. To+transfer+data+wirelessly,+insert+3G+simcard+into+the+hub2.0+and+
connect+to+mobile+broadband/3G+network.++++
Use the HUB in the environment with the temperature between-10℃ and 40℃,
otherwise, it may damage your HUB. It can be operating under 2000m.
For the following equipment: HUB
Is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
The product supplied by USB cable.
Rating(s): 5V 2.5A
For safe operating, the antenna of the product shall be least 20cm away from the
body of the user.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
