operating instructions I HTML Version

operating instructions I

HIGHLIGHTS

Here are just some of the things you can do with the X700 mobile phone.

•Send colour pictures and video clips

to friends and family via Multimedia

messaging and e-mail messaging.

•Send pictures, video, electronic

business cards, and more using

Bluetooth®, Infrared, or USB

connections to other phones or devices.

•Swap content between appropriate

devices with the included miniSD Card

and adapter.

•Surf the Internet using your XHTML

configured wireless Internet browser.

•Add frames, text, and pop art to VGA

size images.

•Capture video clips.

•Play 40 tone polyphonic ringtones.

•No more wired headset! Use a

Bluetooth® wireless headset.

•Synchronise your Contacts and

Calendar with your other networked

devices.

•See who is calling with picture Caller

Line ID on the X700 external display.

•Download games, images, themes,

sounds, videos, and Java™ and Series

60 applications.

•View all your media files in one place,

the Media Gallery.

•Search for your files; including games,

images, install packages, and video and

sound clips.

•Receive, edit, and view Microsoft®

Word, Excel, and PowerPoint® files.

Beam documents to printers and

projectors (with appropriate accessory).

•Speak a name or number to dial the

number using Voice Commands.

•Say “open Messages” or “open

Camera” and your phone will go directly

to the application using Voice

Commands.

X700_OI.book Page 1 Wednesday, September 1, 2004 6:47 PM

IMPORTANT INFORMATION

Thank you for purchasing this Panasonic digital cellular phone. This phone is designed

to operate on GSM networks - GSM900, GSM1800 and GSM1900. It also supports

GPRS for packet data connections. Please ensure the battery is fully charged before

use.

Safety Considerations

Please read and understand the following information as it provides details for operating

your phone in a manner which is both safe to you and your environment, and conforms

to any legal requirements regarding the use of cellular phones.

This equipment should only be charged with approved charging equipment to ensure

optimum performance and avoid damage to your phone. Other usage will invalidate any

approval given to this equipment and may be dangerous. Ensure the voltage rating of the

Travel Charger is compatible with the area of use when travelling abroad. A Travel Charger

(EB-CAX70xx)* is supplied with the main kit. Car Charger (EB-CDX70) is also

recommended for charging. *Note: xx identifies the charger region, e.g. AU, CN, EU, UK,

US.

Use of a battery pack other than that recommended by the manufacturer may result in a

safety hazard. Never expose the battery to extreme temperatures (over 60º C or 140º F). It

is normal for your battery to become warm to the touch when charging. Camera use,

keeping Bluetooth switched on, Internet browsing, extended gaming, and downloading data

reduces battery life.

Cellular phones can cause interference in an aircraft. Switch off your cellular phone when in

an aircraft. The use of cellular phones in an aircraft may be dangerous to the operation of

the aircraft, disrupt the cellular network and may be illegal. Failure to observe this instruction

may lead to the suspension or denial of cellular phone services to the offender, or legal

action or both.

Alarms should not be set to switch on the phone when you are in an aircraft, near sensitive

medical equipment, at a refuelling point or when it may cause interference or danger.

Do not incinerate or dispose of the battery as ordinary rubbish. The battery must be

disposed of in accordance with local legislation and may be recycled.

It is advised not to use the equipment at a refuelling point. You are reminded to observe

restrictions on the use of radio equipment in fuel depots, chemical plants or where blasting

operations are in progress.

Never expose the battery to extreme temperatures (over 60º C or 140º F).

Power

Battery

Aircraft

Alarm

the Battery

Disposing of

Do not use

X700_OI.book Page 2 Wednesday, September 1, 2004 6:47 PM

It is imperative that the driver exercises proper control of the vehicle at all times. Do not hold

a phone while you are driving; find a safe place to stop first. Do not speak into a handsfree

microphone if it will take your mind off the road. Always acquaint yourself thoroughly with

restrictions concerning the use of cellular phones within the area your are driving and

observe them at all times.

Care must be taken when using the phone in close proximity to personal medical devices,

such as pacemakers and hearing aids.

For most efficient use hold the phone as you would any normal phone. To avoid

deterioration of signal quality or antenna performance, do not touch or cup the antenna area

while the phone is switched on. Unauthorised modifications or attachments may damage the

phone and violate applicable regulations. The use of an unapproved modification or

attachment may result in the invalidation of your guarantee – this does not affect your

statutory rights.

When your handset, the accompanying battery, or charging accessories are wet, do not put

those in any type of heating equipment, such as a microwave oven, a high pressure

container, or a drier or similar. It may cause the battery, handset and/or charging equipment

to leak, heat up, expand, explode and/or catch fire. Moreover, the product or accessories

may emit smoke and their electrical circuits may become damaged and cause the products

to malfunction. Panasonic is not responsible for any and all damages, whether direct or

indirect, howsoever caused by any misuse.

It is recommended that you create a copy or backup, as appropriate, of any important

information and data which you store in your phone’s memory. In order to avoid accidental

loss of data, please follow all instructions relating to the care and maintenance of your

phone and its battery. Panasonic accepts no liability for any and all losses howsoever arising

from any loss of data, including but not limited to direct and indirect losses (to include, but

not limited to consequential loss, anticipated savings, loss of revenue).

Your phone has the capability of storing and communicating personal information. It is

recommended that you take care to ensure that any personal or financial information is

stored separately from your phone. You should use security features, such as the SIM lock

to protect information held in your phone. Panasonic accepts no liability for any and all

losses howsoever arising from any loss of data, including but not limited to direct and

indirect losses (to include, but not limited to consequential loss, anticipated savings, loss of

revenue).

Your phone has the capability of downloading and storing information and data from external

sources. It is your responsibility to ensure that in doing this you are not infringing any

losses howsoever arising from any loss of data or any such infringement of copyright or

intellectual property rights, including but not limited to direct and indirect losses (to include,

but not limited to consequential loss, anticipated savings, loss or revenues).

Driving

Electronic

Devices

Efficient

Use

Heating

Equipment

and Security

Backup

Copies

Downloading

X700_OI.book Page 3 Wednesday, September 1, 2004 6:47 PM

You are advised to take appropriate care over the use of the internal camera. It is your

responsibility to ensure that you have permission to take photographs of people and objects

and that you do not infringe any personal or third party rights when using the camera. You

must comply with any applicable international or national law or other special restrictions

governing camera use in specific applications and environments. This includes not using the

camera in places where the use of photographic and video equipment may be prohibited.

Panasonic accepts no liability for any and all losses howsoever arising from any

infringement of copyright or intellectual property rights, including but not limited to direct and

indirect losses.

Do not leave the camera facing direct sunlight, as this may impair its performance.

The colour liquid crystal display (LCD) uses high-precision production technology, and in certain

circumstances pixels may appear brighter or darker. This is due to characteristics of the LCD and is not a

manufacturing defect.

The display layouts and screenshots within this document are for illustrative purposes and may differ from

the actual displays on your phone. Panasonic reserves the right to change the information in this document

without prior notice.

This equipment should only be used with Panasonic approved accessories to ensure optimum

performance and avoid damage to your phone. Panasonic is not responsible for damages caused by using

non-Panasonic approved accessories.

This Panasonic mobile phone is designed, manufactured and tested to ensure that it complies with the

specifications covering RF exposure guidelines applicable at the time of manufacture, in accordance with

EU, USA FCC, and Australian ACA regulations.

Please refer to our website for latest information/standards and compliance in your country/region of use.

http://www.panasonicmobile.com

CARE AND MAINTENANCE

Pressing any of the keys may produce a loud tone. Avoid holding the phone close to your ear

while pressing the keys.

Extreme temperatures may have a temporary effect on the operation of your phone. This is

normal and does not indicate a fault.

If you use your phone in a temperature over 40°C for a long time, the display quality may

deteriorate.

Do not modify or disassemble the equipment. There are no user serviceable parts.

Do not subject the equipment to excessive vibration or shock.

Do not drop the battery.

Camera

X700_OI.book Page 4 Wednesday, September 1, 2004 6:47 PM

Avoid contact with liquids. If the equipment becomes wet immediately remove the battery and

contact your dealer.

Do not leave the equipment in direct sunlight or a humid, dusty, or hot area.

Never throw a battery into a fire. It may explode.

Keep metallic items that may accidentally touch the terminals away from the equipment/battery.

Batteries can cause property damage, injury, or burns if terminals are touched with a conductive

material (i.e. metal jewellery, keys, etc.).

Always charge the battery in a well ventilated area, not in direct sunlight, between +5°C and

+35°C. It is not possible to recharge the battery if it is outside this temperature range.

When connecting the phone to an external source, read the operating instructions of the

equipment for the correct connection and safety precautions. Ensure the phone is compatible with

the product it is being connected to.

When disposing of any packing materials or old equipment check with your local authorities for

information on recycling.

X700_OI.book Page 5 Wednesday, September 1, 2004 6:47 PM

SAR

European Union – RTTE

THIS PANASONIC PHONE (MODEL EB-XXXX) MEETS THE EU REQUIREMENTS FOR EXPOSURE TO

RADIO WAVES.

Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the

limits for exposure to radio frequency (RF) energy recommended by The Council of the European Union.

These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the

general population. The guidelines were developed by independent scientific organizations through

periodic and thorough evaluation of scientific studies. The limits include a substantial safety margin

designed to assure the safety of all persons, regardless of age and health.

The exposure standard for mobile phones employs a unit of measurement known as the Specific

Absorption Rate or SAR. The SAR limit recommended by The Council of the European Union is 2.0 W/kg*.

Tests for SAR have been conducted using standard operating positions with the phone transmitting at its

highest certified power level in all tested frequency bands. Although the SAR is determined at the highest

certified power level, the actual SAR level of the phone while operating can be well below the maximum

value. This is because the phone is designed to operate at multiple power levels so as to use only the

power required to reach the network. In general, the closer you are to a base station antenna, the lower the

power output.

Before a phone model is available for sale to the public, compliance with the European R&TTE directive

must be shown. This directive includes as one essential requirement the protection of the health and the

safety for the user and any other person. The SAR value for this model phone, when tested for use at the

ear, for compliance against the standard was 0.XXX** W/kg. While there may be differences between the

SAR levels of various phones and at various positions, they all meet the EU requirements for RF exposure.

*The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/kg) averaged over ten grams

of tissue. The limit incorporates a substantial margin of safety to give additional protection for the public and

to account for any variations in measurements. SAR values may vary depending on national reporting

requirements and the network band.

**Right side of Head (Test Position: Cheek) Measurement results for GSM900.

For SAR information in other regions please look under product information at http://

www.panasonicmobile.com/health.html

X700_OI.book Page 6 Wednesday, September 1, 2004 6:47 PM

GETTING STARTED

The Panasonic X700 GSMTM/GPRS mobile phone operates on Global System for

Mobile Communications (GSM) networks around the world, which provide integrated

voice mail, text short message service (SMS), multimedia messaging service (MMS),

fraud protection and superior voice quality. One of the most important GSM advantages

is the removable SIM (subscriber identity module) card, containing personal information

such as subscription information, private encryption keys, and phone numbers.

Feature Availability

Some features are network dependent or are available only if you subscribe to the

feature. Some functions are SIM card dependent. Note that before you can use or

activate many of the network features, you must subscribe to the desired services. For

more information, contact your wireless service provider.

Before Using Your Phone

The SIM card must be installed in your phone for it to operate on the cellular network.

Insert SIM card, then attach battery and fully charge it.

INSTALLING AND REMOVING SIM CARD

Installing SIM Card

1. Place thumbs at outer edges of battery cover,

press down, then slide off battery cover

towards bottom of phone. Remove battery (see

page 8).

2. Position SIM card as shown, with gold contacts

facing phone and notched corner entering phone first.

Carefully slide the SIM card into the SIM card pocket

until it clicks.

•If SIM card is inserted incorrectly or damaged,

Insert SIM card may display. Remove SIM card

then install again.

•If SIM card rejected message appears, contact

your wireless service provider.

Caution: This product contains small parts. Keep out of reach of small children.

Take care not to scratch or bend SIM card and gold contacts.

X700_OI.book Page 7 Wednesday, September 1, 2004 6:47 PM

Removing SIM Card

1. Place thumbs at outer edges of battery cover,

press down, then slide off battery cover

towards bottom of phone. Remove battery

(see page 8).

2. Gently push bottom edge of SIM card forward

into SIM card pocket to release SIM card.

3. After SIM card is ejected, gently remove it.

INSTALLING AND REMOVING BATTERY

Installing Battery

1. Hold battery at a 45º angle; insert tabs on

top edge of battery into slots along top

edge of battery area.

2. Push bottom of battery down until it clicks.

3. Replace battery cover by sliding cover

toward the bottom of the phone. Cover

should fit snugly with no gaps.

Removing Battery

1. Place thumbs at outer edges of battery cover,

press down, then slide off battery cover towards

bottom of phone.

2. Use tabs at bottom of battery to lift and remove

battery.

3. Replace battery cover.

Note: If you are upgrading your phone and your previous phone did not support new

services, such as MMS (Multimedia Messaging Service), you may need to insert

a new SIM card. Contact your wireless service provider.

Caution: Using non-Panasonic accessories or accessories not recommended by your

wireless service provider may result in poor performance of your phone, or

even cause an electrical hazard.

Note: Before you remove the battery, switch off the phone and disconnect

the phone from the charger or any other device.

X700_OI.book Page 8 Wednesday, September 1, 2004 6:47 PM

CHARGING BATTERY

1. Open connector cover.

2. Insert connector into left side (2 gold contacts) of connector area at bottom end of

the phone. Connect the Travel Charger into mains power socket.

3. When charging is complete, remove from

mains power socket and press release button

to disconnect the charger from the phone.

• DO NOT force connector: it may damage

phone or Travel Charger.

Charging Icons on Main and External Display

bars scroll when charging

bars stop scrolling when charging is complete

• If the phone is switched on, Battery full message appears when charging is

complete.

Low Battery Warning

When the battery power is low, Battery low displays and a warning tone sounds; phone

will automatically switch off. Fully recharge the battery. If you receive the low battery

warning during a conversation, finish your call immediately.

Note: First verify that battery is installed.

X700_OI.book Page 9 Wednesday, September 1, 2004 6:47 PM

INSTALLING AND REMOVING miniSD CARD

The miniSD Card is a memory card used to expand phone memory and a way to

transfer files to other devices.

Installing miniSD Card

1. On top of phone, lift up miniSD Card cover.

2. Slide miniSD Card with notched corner entering phone

first and gold contacts facing up into the miniSD Card

pocket until it clicks. Push down miniSD Card cover until

it clicks.

Removing miniSD Card

1. Press Power key , scroll to Eject miniSD Card and press OK. Before removing

miniSD Card, wait for file saving or copying process to finish.

2. On top of phone, lift up miniSD Card cover.

3. To release miniSD Card, gently push bottom edge of

miniSD Card forward into pocket.

4. After miniSD Card is ejected, gently remove it. Push

down miniSD Card cover until it clicks.

Note: Do not insert any object except a miniSD Card into the miniSD Card pocket.

Do not place labels, etc., onto the miniSD Card. A fine difference in card thickness

may result in insertion or removal difficulty, loss of contact or loss of data.

Take care not to scratch or bend miniSD Card and gold contacts.

X700_OI.book Page 10 Wednesday, September 1, 2004 6:47 PM

PHONE OVERVIEW

X700_OI.book Page 11 Wednesday, September 1, 2004 6:47 PM

KEY FUNCTIONS

Key Function

Power Key

Press and hold to switch phone on or off.

Press to choose different ringtones, eject miniSD Card, lock keypad, or lock the

phone.

Navigation Key

Press outside edges to scroll up , down , left or right to move through

menus and text.

Press centre to select option.

In standby mode, press centre to open Contacts.

Take a picture in Camera mode by pressing .

Send Key

Make a call.

Press in standby mode to recall recently dialled numbers. Scroll to see received

and missed calls lists.

Press and hold in standby mode to activate voice commands.

End Key

Ends a call.

Return to standby mode.

Applications Key

Enter the main applications menu area.

Return to standby mode.

Press and hold to view currently open applications.

Left Softkey

Perform action named in lower left of display.

Shortcut to open preset application in standby mode. To change shortcut, see

page 94.

To lock the keys, in standby mode press , then press . To unlock the keys,

press , then press .

Right Softkey

Perform action named in lower right of display.

Shortcut to open preset application in standby mode. To change shortcut, see

page 94.

Edit Key

Select Dictionary for predictive text including insert and edit words, or alpha mode or

number mode.

Insert numbers or symbols.

Change writing language.

Mark multiple items in a list by holding down , then scrolling or .

X700_OI.book Page 12 Wednesday, September 1, 2004 6:47 PM

Symbols used in this manual

Clear Key

Erase character in edit mode.

Delete highlighted entered item.

Browser Key

Opens Browser.

Asterisk Key

In standby mode, press and hold to switch PhotoLight or flashlight on or off.

In numeric and standby modes, press repeatedly for *, +, p and w characters.

In Dictionary mode, scroll to other word choices when word is underlined.

In edit mode, press to open special character table.

Zero Key

In standby mode, press and hold to enter + character for dialling.

In edit mode, enter space.

Silent Mode Key

In standby mode, press and hold to switch Silent mode on/off.

In edit mode, shift to upper and lower case letters, or press twice briefly to turn on/off

Dictionary for predictive text.

Multibutton (on side of phone)

From external display, turns on backlight for 15 seconds or if backlight is already on,

brings up status icons.

Turns off ringer during incoming call.

Takes a picture in Camera mode when flip is closed.

Press Power key. Press Applications key.

Press outside edges of navigation

key to scroll up, down, left or right

to move through menus and text.

Press navigation key centre.

Press Send key. Press End key.

Press Left softkey. Press Right softkey.

Press Edit key. Press Clear key.

- Press number keys. Press Browser key.

Press Asterisk key. Press Silent Mode key.

Press Multibutton key (on side of

phone).

Key Function

X700_OI.book Page 13 Wednesday, September 1, 2004 6:47 PM

ICONS

Different icons appear depending on the features you are using and the options you

have selected.

Icon Indicates Icon Indicates

Seven levels indicate battery charge

level. Bars scroll when battery is

charging.

Alarm is set

Seven levels indicate signal strength

from network on which phone is

currently registered

New voice mail message received (if

you have 2 lines, left circle is

darkened for line 1, right circle is

darkened for line 2)

GPRS service is available New message received

GPRS service is on hold during

voice call

Message in Outbox waiting to be

sent

GPRS connection is active Bluetooth is enabled

Multiple GPRS connections are

active Bluetooth is active

Missed call Infrared is enabled (flashes when

active)

Call divert is active (if you have 2

lines, 1 or 2 also appears) USB connection enabled

Line selection 2

(SIM card dependent, if you have 2

phone lines)

Navigation key - scroll and move up

or down options

Data call Navigation key - scroll left or right,

move left or right to view tabs

Keypad is locked All ringing tones/ring volume are off

(Silent ringtone)

Earpiece sound on Private handsfree headset attached

Loudspeaker sound on

X700_OI.book Page 14 Wednesday, September 1, 2004 6:47 PM

STANDBY MODE DISPLAYS

MAIN DISPLAY

EXTERNAL DISPLAY

Press Multibutton once to switch on backlight, then press as needed to toggle between

clock and icon views.

X700_OI.book Page 15 Wednesday, September 1, 2004 6:47 PM

PHONE BASICS AND MANAGING CALLS

SWITCHING THE PHONE ON AND OFF

Press and hold .

MAKING CALLS

Check that phone is switched on, signal strength icon displays at least one bar , and

your network operator logo displays before dialling a call.

Type in the Phone Number to Dial

1. From standby mode, enter the area code and phone number, and press .

2. To end the call, press .

Use a Contact Card to Dial

From Contacts application:

1. Scroll to desired name card, press .

• If the card has several phone numbers stored, select the one you wish to dial.

To add information to your Contacts, see page 30 .

Use a SIM Directory Entry to Dial

From Contacts application:

1. Scroll to SIM directory view.

2. Scroll to desired name, press .

To add names and numbers to your SIM directory, see page 30.

Note: If your SIM card is PIN protected, your PIN code will be requested.

Enter the PIN code and press

See Security Settings on page 98.

Note: To erase a digit, press .

During a call, scroll or to adjust earpiece volume.

Warning: Closing the flip during a call will end the call, when set to default.

To set the phone to keep the call connected when you close the

flip, see Active clamshell in Call Settings on page 94.

X700_OI.book Page 16 Wednesday, September 1, 2004 6:47 PM

Speak the Name to Dial

To dial by saying the name of the person you wish to call:

1. Press and hold .

2. After the prompt to “Say a command”, say “Voice Dial”.

3. After the prompt to “Say the name or number”, say the full name of a person in your

Contact list, including first name and last name.

4. The name is repeated, and the phone will begin dialling.

See page 106 for more Voice Command options.

Speed Dialling

If you assigned speed dialling keys (see page 105) to your frequently called numbers,

you can dial them with 2 key presses.

1. From standby mode, press the preset speed dial digit key - then press .

• If Speed dialling is set to On, (see Call Settings on page 94), just press and hold

the preset speed dial digit key to dial the assigned number.

Dialled Numbers, Received, or Missed Calls List

You can quickly dial previously dialled numbers, received call numbers, or numbers of

calls you missed.

1. From standby mode, press .

2. From the list of Dialled numbers, scroll to desired entry and press to dial.

•Scroll to move to Received calls tab and Missed calls tab to select a number

from either of those lists.

Automatic Redial

If you set Automatic redial to On in the Call Settings menu (see page 94), your phone

will automatically redial the number up to 10 times under certain conditions, such as no

answer, destination number is busy, network busy, or some connection errors.

Press Quit or to stop automatic redialling.

Dial from Messages

If a received message contains a phone number, you can dial it from the Inbox

message. You can also call the sender of an SMS text message.

From Messages application:

1. Open Messages. Scroll to Inbox and open.

2. Scroll to desired message and open.

Note: Location number 1 may be reserved for voice mailbox number.

X700_OI.book Page 17 Wednesday, September 1, 2004 6:47 PM

3. To find the phone number within a message, press Options and select Find >

Phone number, E-mail address, or Web address. When found, text and numbers

will be underlined.

• To call the sender of SMS text message from the open message, press to

dial the sender’s phone number.

International Calling

From standby mode, press and hold to enter +, the international prefix, which is a

shortcut for international dialling access. Then type in the country code, area code, and

phone number. Press .

Emergency Calls

Dial the local emergency number used in your current location.

1. Switch on the phone if it is off.

2. Verify that the antenna icon is displayed.

3. Enter the local emergency number (such as 112) and press .

Send Service Command to Network

Ask your wireless service provider to activate a particular service by sending a service

command. These commands, which may be called USSD commands, can activate

services such as mobile prepay and chat.

1. First, contact your wireless service provider for the proper service command code.

2. Type in the supplied service command code. If the phone recognises it as a

supplementary service or USSD request, press Send service comm.

ANSWERING CALLS

When there is an incoming call, the phone rings and flashes green.

1. Open flip to answer a call.

• If flip is open, press to answer a call.

Note: Many countries/regions include an initial 0 in the area code. In most

cases, you should omit this when dialling international numbers. For

further help, contact your wireless service provider.

Note: You can call the local emergency number even if the keys are locked.

Making emergency calls without SIM is country or network operator dependent.

Note: If the phone is set to a ringtone with vibrating alert on, the phone

flashes green and vibrates instead of ringing.

X700_OI.book Page 18 Wednesday, September 1, 2004 6:47 PM

Mute Ringing Tone

To mute ringing tone, press if flip is closed. If flip is open, press Silence . Then

answer the call by pressing .

Change Answer Settings

To change the setting so a call will not be answered by opening the flip, see Active

clamshell in Call Settings on page 94.

To answer by pressing any key except , , or , see Anykey answer in Call

Settings on page 94.

Divert Incoming Calls

To divert calls to your voice mailbox or another number, see Call Divert on page 101.

Then you can press or Reject softkey and incoming calls will be diverted.

If you ignore the call by not pressing any keys, the call details appear on the Missed

calls list.

ACTIVE CALL OPTIONS

When on a call, you can put the call on hold, mute the microphone, send touch tones for

passwords, etc., and create multi-party calls, depending on network support.

Place Calls on Hold

To put a call on hold or release the call from hold, press Options and select Hold or

Unhold.

If you are connected to 2 calls (an active call and a call on hold), press Options and

select:

Swap Put active call on hold and activate held call.

Transfer Connect an active call and held call, or incoming call to active or

held call, and disconnect yourself from both calls, leaving the

two callers to talk to each other.

Shortcuts: You can also press to switch between Hold and

Unhold on one call, or switch between one active and

one held call (Swap).

To end a held call and continue with the active call,

press and .

To end the active call and continue with the held call,

press and .

X700_OI.book Page 19 Wednesday, September 1, 2004 6:47 PM

HANDSFREE TALKING

To hear the caller’s voice from the handsfree loudspeaker, press Loudsp.. Set the

phone down nearby so you and several others can have a conversation without holding

the phone.

To go back to the earpiece, select Handset.

If you have activated a Bluetooth handsfree headset, press Options and select BT

Accessory to hear the caller’s voice in the Bluetooth headset.

Volume Control

Scroll or to increase or decrease volume of phone earpiece , phone

loudspeaker , or if a headset is attached. Note the volume step bars change as you

adjust volume.

To mute or unmute the microphone, press Options and select Mute or Unmute. Mute

switches off microphone of phone and any accessory microphones if attached. Unmute

switches microphone back on.

CALL WAITING

If you activated Call waiting network service in Call Settings (see page 94), you can

answer an incoming call when on an active call.

1. During an active call, press to answer an incoming call. The active call is put on

hold.

• To switch between the calls, press Swap or .

• To end the currently active call and answer the incoming call, press Replace.

2. To end the currently active call, press . The held call becomes active.

• Or to end both calls at once, press Options and select End all calls.

• If you press and hold , all calls and data connections are ended.

To reject the incoming call, press Reject. The caller receives a busy message or goes to

voice mail.

Send DTMF Touch Tones

DTMF touch tones can be transmitted during a call just by pressing the keys (0 to 9, #, *)

on your phone. Touch tones are often used to access services such as voice mailboxes,

calling card calls, and banking.

During a call, press Options and select Send DTMF if you stored a DTMF touch tone

sequence in a Contacts card. Press Find, scroll to desired entry and select.

Loudspeaker icon -- handsfree is active.

Earpiece icon -- handsfree is not active.

X700_OI.book Page 20 Wednesday, September 1, 2004 6:47 PM

To dial or store touch tone sequences:

1. Type in access phone number.

2. Before entering touch tone digits, press repeatedly to scroll through *, +, p and

w characters to insert:

• a short pause before the digits are transmitted (p character).

• a manual wait period (w character) that requires you to press Send during

the call to transmit the digits.

•+ character to send a touch tone sequence stored in a speed dial location (see

page 105).

3. Enter the touch tone digits, for example, the access codes for your voice mailbox.

4. Press to immediately dial call, or press Options and select Add to Contacts to

store sequence in your Contacts (see page 30).

Open Applications During a Call

During a call, open the main application menu by pressing , then open the desired

application, for example, check your Calendar for an upcoming meeting time. The active

call remains connected and is indicated by a small pop-up window. To return to the

active call window, exit the application.

If you press , an active call will always disconnect.

Play/Record Sound Clips During a Call

To play a sound clip during a call, open the sound clip from its current location and play.

The other person hears the sound clip.

To record the current call, see page 112.

Multi-Party Calls

In a multi-party call, you can have a conversation with up to 5 different parties at the

same time if supported by the network.

1. Call the first party.

2. After the call is connected, press Options and select New call to enter a number or

press Find to go to the Contacts to dial a number and press . The first call is put

on hold.

3. After the new call is answered, press Options and select Conference to join the

held call and the active call together. From then on, there is only one active call,

which is the multi-party call.

4. To add another party to the call, repeat step 2, then press Options and select

Conference > Add to conference.

Note: You can enter multiple instances of pause, wait, and speed dial

characters and touch tone sequences.

X700_OI.book Page 21 Wednesday, September 1, 2004 6:47 PM

5. To have a private conversation with one of the parties, press Options and select

Conference > Private. Scroll to desired party and press Private. The separated

party becomes the active call on your phone, the multi-party call is put on hold;

however the remaining callers can continue with the multi-party call. To return to

multi-call, press Swap. To return Private call to multi-call, press Options and select

Conference > Add to conference.

6. To drop a party from the multi-party call, press Options and select Conference >

Drop participant. Scroll to desired party and press Drop.

7. To end the multi-party call, press .

ENDING CALLS

There are several ways to end a call:

• Close the flip.

•Press .

•Press End call softkey.

•Press Options and select End active call.

To end all calls if there are more than one:

•Press Options and select End all calls.

If you press and hold , all calls and data connections are ended.

See Active Call Options starting on page 19 for ending held calls, waiting calls, and

multi-party calls.

CLOSE THE PHONE DURING A CALL

Closing the flip clamshell ends the call. This is the default setting for Active clamshell

in Call settings. If you want to close the phone and speak handsfree during a call,

change the Active Clamshell setting to Off. This setting switches the caller’s voice to

the back loudspeaker so you can speak handsfree.

To keep calls connected when you close the flip clamshell and prevent calls from being

answered when the flip is opened, see Active clamshell in Call Settings on page 94.

Note: If you are on an active call and already have a held call, start at step 3.

X700_OI.book Page 22 Wednesday, September 1, 2004 6:47 PM

ENTERING TEXT

There are two main ways to enter text; using the predictive text dictionary to quickly

enter words, or alpha mode in which each key is tapped until the planned letter appears.

DICTIONARY FOR PREDICTIVE TEXT ENTRY

Dictionary uses a predictive text system to enter words by pressing one key per letter to

display the planned word, instead of pressing keys multiple times until each planned

letter appears.

For example, to enter “Call me.” in a message, press:

Ca l l me .

When you press the 6 key and the 3 key, the word “of” appears on screen, because the

English dictionary ranks “of” as the most common word associated with the key presses

6 and 3. To change the word “of” to “me”, press once, and the word changes.

DISPLAY PLANNED WORD MATCHES

If the correct word does not display, press repeatedly to scroll through an alternate

word list. To choose from all the word matches, press and select Dictionary >

Matches.

ADD WORDS TO PREDICTIVE TEXT DICTIONARY

To add a word that is not already in the dictionary, press and select Dictionary >

Insert word. You can also add the word to the dictionary when Spell softkey appears.

GENERAL TEXT ENTRY

Enter text and numbers in one of three ways:

Alpha mode - press each key repeatedly until planned letter appears

Dictionary mode - press one key per letter for dictionary to display planned word

Numeric mode - enter numbers

In both alpha mode and dictionary mode, choose from:

First letter capital All capitals

Lower case

Shortcut: To enter numbers while in alpha or dictionary mode, press and hold

desired number key - .

X700_OI.book Page 23 Wednesday, September 1, 2004 6:47 PM

To enter symbols, press and select Insert symbol.

To enter text at a flashing cursor:

1. Press the number keys associated with the planned letters repeatedly until the

planned letters appear on screen.

• To enter text using the predictive text dictionary, press and select

Dictionary on, if it is not already active.

2. Editing actions for each key and shortcuts:

Cut, Copy, and Paste Text

1. To cut, copy, and paste text, move cursor to left of text you wish to copy.

2. While holding down , press and hold to highlight text.

3. Release keys to stop highlighting.

4. Press and select Cut or Copy.

5. In message field, move cursor to new desired location, press and select Paste.

Enter space.

Enter punctuation by pressing repeatedly.

In Dictionary mode, press , then press repeatedly to

scroll to other punctuation.

Erase a character.

Press and hold to switch between text and number modes.

Press to scroll through upper case, lower case, and first letter

capital mode.

Press twice briefly to turn Dictionary on or off.

Turn Dictionary on or off.

Switch to number mode.

Insert symbols.

Change writing language.

In Dictionary mode, scroll to other word choices when word is

underlined.

Press outer edges to scroll up, down, left, and right through text.

X700_OI.book Page 24 Wednesday, September 1, 2004 6:47 PM

NAVIGATING THE APPLICATIONS

To view the main applications window, press .

Navigation Key

Press the left, right, top and bottom edges of the navigation key to move around

the display.

Press to:

• Open an application item

• Select a highlighted item

• Confirm a selection

• Take a picture with the camera

If an up or down arrow appears at the bottom of the display, scroll or to go to

additional items.

Tabs

There may be more files, folders, or pages associated with an

application item, which can be viewed by moving right and left

across the screen. This is indicated by tabs ,

arrows , or numbers near the top of the screen. For example,

if you are viewing page 5 of 12 pages associated with a file, 5/12

and arrows are displayed.

• Scroll and to move through the tabs and pages.

Condensed Instructions

In this guide, to condense wording, statements are used such as “Press Options and

select Open.” This means to press Options, highlight Open, and press Select. You

may need to scroll within the menu to reach Open. Many menu items are available

within Options menus and other menus, thus these shortcut statements will be used

throughout the guide to indicate the same type of process.

Shortcut: To jump to and open one of the first 9 application items (if you have not yet

scrolled), simply press the number key corresponding to the desired item’s

location on the grid view. The grid view numbering system is:

123

456

789

X700_OI.book Page 25 Wednesday, September 1, 2004 6:47 PM

In this guide, a statement such as ‘Select Send > Via multimedia’, means to scroll to

Send, then scroll to view the pop-up menu containing Via multimedia, then press

or Select softkey to select Via multimedia. Within the pop-up menu, you may need to

scroll to highlight Via multimedia.

Options Softkey

At the first level of each menu item, Options appears as a way to organise or

customise the menu system. The options change depending on the menu level you are

viewing.

To open the Options menu:

•Press Options, scroll to highlight the desired action, then press or press Select.

These additional actions may be available in the Options menu:

Mark/Unmark

In menu items containing many files, you can mark specific files in which to perform an

action. For example, you may wish to delete 5 images from your Images folder

containing 29 images.

To mark an item or items:

1. Press Options and select Mark/Unmark > Mark to place a checkmark next to the

desired file. Scroll to mark more items as needed, or select Mark all to mark all files.

2. Press Options, then select desired action such as Delete, Send, Move.

Open Open the item.

List view View the menu items in a list form. If you select this, the option

changes to Grid view to view the menu items in a grid form.

Move Move the item to another place within the application system.

Move to folder Move the application item into a folder.

New folder Create and name a new folder.

Memory details > View information about items stored in the phone memory and

memory card (also referred to as miniSD Card).

Exit Exit the menu item.

Remove or Delete Remove or delete an item or a marked item (see Mark/Unmark

on page 26) on a list or grid, or press .

Rename Give a new name to the item.

Edit Change information you have already entered.

X700_OI.book Page 26 Wednesday, September 1, 2004 6:47 PM

To unmark an item or items:

1. Press Options and select Mark/Unmark > Unmark on a marked file to remove the

checkmark. To unmark all files, select Unmark all.

Menus within a Menu

A pop-up menu appears when more than one choice is available.

For example, you can send a Contacts entry several ways: via text

message, via multimedia, via e-mail, via Bluetooth, and via

infrared.

To enter a pop-up menu:

• Scroll , or press , or Select softkey.

To close a pop-up menu:

• Scroll , or press Cancel softkey.

Save Changes

In many cases when editing text or numbers, or changing a setting; press the Back

softkey to automatically save changes.

MULTITASKING

You can work with more than one menu item simultaneously. For example, you can start

creating a new message, rename an image, and begin creating a Contacts entry, all

without losing the data you have already entered.

To keep a menu item open:

Press to go to the standby screen. Pressing does not close the open menu

item.

Opening and closing menu items

There are several ways to open menu items:

• Press .

• Press Options and select Open.

Shortcuts: To mark or unmark an item, hold down then press .

To mark or unmark multiple items, hold down then press and hold or of

navigation key to scroll through desired items. Release or to stop marking.

Note: During a phone call, terminates the call instead of acting as

a shortcut to the standby screen.

X700_OI.book Page 27 Wednesday, September 1, 2004 6:47 PM

There are several ways to close menu items:

•Press Options and select Exit.

•Press Back until Exit softkey appears, then press Exit.

•Press Close.

Shortcut to swapping among open items

If you have several menu items open, you can press and hold

to view a pop-up window and scroll to locate the desired open item.

When you open the item, you will begin at the point where you

were previously.

To close an open item from the pop-up window, scroll to desired

item, press and select Yes.

SEARCH OPTION

In certain menu items, a magnifying glass icon

appears which allows you to search for a name, file or item.

To search, enter the first letter of the desired name or file. The phone finds and displays

matching entries. To refine the search, enter two or more letters.

SHARED PHONE MEMORY

The phone’s memory capacity is shared by all images; text, multimedia and e-mail

messages; Contacts cards; video and sound clips; ringtones; Calendar and Notepad

notes; and downloaded applications stored on your phone. If you keep more files on the

phone, then there is less memory available to store new files or run certain applications.

To decrease the amount of phone memory used: (1) store data on your miniSD Card; (2)

delete data that is old, copied elsewhere or not being used; (3) delete messages with

attachments from your Inbox after saving attachments to an application; (4) use the

portrait format to take pictures with the Camera whenever possible. The portrait format

file size is much smaller than standard format.

To view details of the phone memory and miniSD Card use, and amount of free

memory:

1. Press .

2. Press Options.

3. Scroll to Memory details.

4. Then scroll to choose phone memory or memory card (also referred to as miniSD

Card).

Also see File Manager on page 117.

X700_OI.book Page 28 Wednesday, September 1, 2004 6:47 PM

APPLICATIONS MENU MAP

The phone’s main application menus are listed below. The names listed represent the

names in list view. The names may be slightly different in grid view.

Note: The menus may not appear in the order or with the same icons as listed here.

The order and icons vary according to your wireless service provider, or if you

have customised your settings.

Settings Camera Tools

Ringtone Profiles

Themes

Settings

Clock

Speed Dialing

Voice Cmds

PrintBoy Setup

About product

Calculator

Converter

Notepad

Voice recorder

miniSD Card

To-Do List

Application Mgr

File manager

PhotoLight

SIM Tool Kit

(optional)

Calendar Contacts Media

Media Gallery

PhotoBase

RealOne Player

Video Recorder

Messages Call Logs Connectivity

Voice mailbox

Messages

Recent calls

Call duration

GPRS counter

Browser

Operator Menu

Modem

Bluetooth

Infrared

USB

Connection Mgr

SyncML

Device Mgr

Games Favourites Quickoffice

MicroGolf

Balloon-Headed

Boy

X700_OI.book Page 29 Wednesday, September 1, 2004 6:47 PM

CONTACTS

Store names, phone numbers, e-mail, web and street addresses, even a thumbnail

picture in a Contact card. Call and send messages directly from Contacts. Numbers can

also be stored on your SIM card. See Entering Text on page 23 to learn how to enter

text.

CREATE NEW CONTACT CARDS

From Contacts application:

1. Press Options and select New contact.

2. Enter information in main fields:

First name Telephone

Last name Mobile

Company Fax

Job title E-mail

3. From main fields, press Options to:

4. Press Done to save entry.

SIM DIRECTORY

The SIM Directory shows you the names and numbers stored on your SIM card. Your

wireless service provider can program their service numbers, your wireless phone

number and other numbers into your SIM card. You can store personal numbers on your

SIM card as well.

Unlike a Contacts entry, a SIM Directory entry consists of only one name and one phone

number.

Copy Numbers to SIM Directory

1. From the Contacts list, highlight the desired card.

2. Press Options and select Copy to SIM direct.

3. Choose one of the phone number fields to copy, press OK.

Add thumbnail Place picture from your Images folder into the card.

Add or Delete detail Choose desired fields and icons from list including Job title, Tele-

phone, Tel. (home), Tel. (business), 3 mobile, 3 fax, pager num-

bers, 3 E-mail fields, 3 Web addresses, 3 street address fields,

DTMF tones, Birthday, and Note.

Edit label Change the field name.

Note: See SIM Directory to create and copy entries into your SIM Directory.

X700_OI.book Page 30 Wednesday, September 1, 2004 6:47 PM

• If you select All, the phone creates a separate SIM directory entry for each phone

number stored with that Contacts entry name.

Create and Manage SIM Directory Entries

1. From the Contacts list, scroll to SIM directory tab.

2. Press Options and select from:

FIND A CONTACT CARD

From Contacts application:

1. Scroll to desired entry, or enter the first letter of desired entry in . Entries

beginning with that letter will display.

2. Press to open entry.

MAKE A CALL

From Contacts application:

1. Scroll to desired Contacts entry and press .

Or, press Options and select Call.

• If entry contains more than one number, choose desired number to dial before

pressing .

Note: To copy SIM entries to your Contacts, highlight the desired SIM entry, then press

Options and select Copy to Contacts.

The first time Contacts is opened after a different SIM card is placed in the

phone, press OK if you wish to copy SIM contacts into the Contacts memory.

Call Call the highlighted entry.

New SIM contact Create a new SIM contact entry. Open and enter Name, then

enter No. and press Done.

Edit Edit the highlighted SIM entry. Numbers stored by your wireless

service provider cannot be edited.

Delete Delete the highlighted SIM entry. Numbers stored by your wire-

less service provider cannot be deleted.

Copy to Contacts Copy the highlighted SIM entry to your Contacts list.

My numbers View your own phone numbers.

SIM details View the number of used and free SIM entries.

Note: To make a call from the SIM directory, from Contacts application scroll to

SIM directory tab. Scroll to the desired entry and press .

X700_OI.book Page 31 Wednesday, September 1, 2004 6:47 PM

CREATE A MESSAGE

From Contacts application:

1. Scroll to the desired Contacts entry and press Options.

2. Select Create message > Text message, Multimedia message, or E-mail.

3. To complete Text messages, see page 42; or Multimedia messages on page 42; or

E-mail messages on page 44.

EDIT CONTACT CARDS

From Contacts application:

1. Highlight desired Contacts card.

2. Press Options and select Edit.

3. Scroll to desired field to edit, begin entering data. If the field already has information,

scroll to move to editing point, press to clear a letter or digit.

4. Press Options to:

5. Press Done to save entry.

Assign Default Number to Dial

For a Contact card, set a particular phone number or address that the phone will use

each time you wish to call or write messages to that person.

From Contacts application:

1. Scroll to desired Contact card and open.

2. Press Options and select Defaults.

3. Highlight a field:

Phone number

Text msg. number

MMS number/address

E-mail address

4. Press Assign.

5. Scroll to the desired entry and press Select.

• Repeat steps 4 to 6 to assign default numbers to the other fields.

Add thumbnail Place picture from Images folder in phone memory or miniSD

Card.

Add or Delete detail Choose desired fields and icons from list including Job title, Tele-

phone, Tel. (home), Tel. (business), 3 mobile, 3 fax, pager num-

bers, 3 E-mail fields, 3 Web addresses, 3 street address fields,

DTMF tones, Birthday, and Note.

Edit label Change the field name.

Note: To remove a default assignment, select (no default).

X700_OI.book Page 32 Wednesday, September 1, 2004 6:47 PM

Assign a Ringing Tone

From Contacts application:

1. Scroll to desired Contact card and open.

2. Press Options and select Ringing tone.

3. Scroll to desired tone (after a brief pause tone will play). You can use tones already

supplied; sent in messages (see page 46); downloaded (see page 76); or recorded

(see page 111).

To assign a ringing tone to a group, scroll to move to Groups tab, scroll to desired

group, and continue with step 3.

Assign Speed Dial

From Contacts application:

1. Scroll to desired Contact card and open.

2. Scroll to desired phone number field in which to assign the speed dial key, press

Options and select Assign speed dial.

3. Press or scroll to desired number key and press Assign. An icon denotes that a

speed dial key has been assigned to this number field.

To make a call using speed dial, press the associated number key, then press .

To remove an existing speed dial key, from Contacts application:

1. Scroll to desired Contact card and open.

2. Scroll to speed dial phone number field, then press Options and select Remove

speed dial.

See page 105 for speed dial options.

Go to Web Address

If a Contact card contains a web address, you can launch the Browser and go directly to

the web address.

From Contacts application:

1. Scroll to desired Contact card and open.

2. Press Options and select Go to web address.

Note: If tones do not play, change the phone’s ringtone to General

or Outdoor to hear the tones.

X700_OI.book Page 33 Wednesday, September 1, 2004 6:47 PM

MANAGE CONTACTS LIST

From Contacts application:

1. Press Options and select Edit, Delete, or Duplicate.

Memory Used in Contacts

To view number of cards, groups used and amount of memory used, from Contacts

application:

1. Press Options and select Contacts info > Memory.

Sort List by Last Name or by First Name

From Contacts application:

1. Press Options and select Settings.

2. Open the Name display field to sort the list either by Last name first or First name

first.

SEND A CONTACT CARD

Before a Contact card can be sent by Messaging or to another device, it is converted to

an electronic business card format known as vCard.

From Contacts application:

1. Scroll to desired Contact entry.

2. Press Options, scroll to Send > Via text message, Via multimedia, Via e-mail,

Via Bluetooth, or Via infrared.

3. To complete text messages, see page 42; or multimedia messages on page 42; or

e-mail messages on page 44; or Bluetooth on page 82; or Infrared on page 84.

SERVICE NUMBERS

If your wireless service provider has stored service numbers on your SIM card, you can

view and call the service numbers.

From Contacts application:

1. Press Options and select Service numbers.

CREATE AND MANAGE GROUPS

Place Contact entries into one group. Select the group name when addressing a new

message, and your message is sent to each member of the group. For example, set up

Business or Family group. See Messages starting on page 40 to learn how to send

messages.

Note:See Mark/Unmark on page 26 to select more than one entry.

Note: This feature is not available if the phone contains Chinese language.

X700_OI.book Page 34 Wednesday, September 1, 2004 6:47 PM

Create New Group

From Contacts application:

1. Scroll to Groups tab.

2. Press Options and select New group.

3. Enter a name for the group and press OK.

4. Open the group name, press Options and select Add members.

5. Select desired Contact cards to add.

• To remove a member from a group, scroll to desired name, then press Options

and select Remove from group.

Manage Groups

From Contacts application:

1. Scroll to Groups tab.

2. Scroll to desired group, then press Options and select from: Open to view group,

Delete group, Rename group, add Ringing tone for group.

To see if a person belongs to a group; or add a person to a group, from Contacts

application:

1. Scroll to desired Contact card.

2. Press Options and select Belongs to groups or Add to group. When adding,

select desired group and press Add.

TAKE A PICTURE AND ADD TO CONTACT CARD

From Camera application:

1. The main display acts as a viewfinder when the flip is open. The external display

acts as the viewfinder when the flip is closed.

2. To snap the picture, press if the flip is open. Or press the Multibutton on the

side of the phone if the flip is closed.

• The image is saved in your Images folder in Media Gallery.

3. Open Contacts.

4. Highlight desired Contacts card.

5. Press Options and select Edit.

6. Press Options and select Add thumbnail.

7. Select Phone memory.

8. Open Images folder. Scroll to highlight the image and press Select.

9. Press Done.

X700_OI.book Page 35 Wednesday, September 1, 2004 6:47 PM

CALENDAR

Keep track of upcoming meetings, appointments and special dates. Set alarms to

remind you of upcoming events. Calendar events can be sent and received as

vCalendar messages and synchronised with other devices to keep track of your

schedule.

CREATE CALENDAR EVENTS

From Calendar application:

1. Press Options and select New entry > Meeting -- events with a start and end time,

Memo -- events such as trips or vacations, or Anniversary -- single day events

such as birthdays and anniversaries.

2. Enter information in most fields by entering numbers or letters:

3. Press Done to save event.

Set Calendar Alarm

When you set the alarm to On, scroll to set the alarm time and date.

When the alarm rings, press Stop to stop the alarm. Press Snooze or any

other key to snooze the alarm.

Set Event Repeat Cycle

When an event occurs regularly; for example, baseball practice or music lessons, open

the Repeat field to set interval time periods such as Weekly or Monthly.

Meeting Memo Anniversary

Subject Subject Occasion

Location Start date Date

Start time End date Alarm

End time Synchronisation Synchronisation

Start date

End date

Alarm

Repeat

Synchronisation

Shortcut: If you start typing after opening the Calendar, you are

automatically entering the subject in a Meeting entry.

X700_OI.book Page 36 Wednesday, September 1, 2004 6:47 PM

Set Synchronisation

If you synchronise your Calendar events with a PC, you can set the privacy level.

•Set to Private to hide events from online viewers.

•Set to Public to allow online viewers to see the event.

•Set to None if you do not wish to synchronise the event with your PC calendar. See

Synchronisation on page 85.

BROWSE CALENDAR

View the calendar by day, by month, or by week.

To change view, press Options and select Month view or Week view.

CALENDAR ICONS

Meeting Memo Anniversary

Month View

Scheduled event -- triangle in the lower right corner of a date.

Current date -- underlined.

Selected date -- boxed; date also appears in the navigation bar.

Far left column -- the year’s week number (see Week view title in

Settings).

Week View

Days of the week are displayed in columns. Each hour of a day is

denoted by a cell.

Meeting events -- a colour bar during the scheduled time periods.

Memo and Anniversary icons -- appear between 7am and 8am

Current weekday -- underlined (if you are viewing the current

week).

Selected date -- boxed; date also appears in the navigation bar.

Screen title -- either the week number or the week dates of the current week, depending

on Calendar setting.

Shortcuts: Scroll to move around the calendar.

Press Options and select Go to date to go to a desired date.

Press to go to today.

X700_OI.book Page 37 Wednesday, September 1, 2004 6:47 PM

Day View

To view a certain day, scroll to the date and open.

Scheduled events are listed.

EDIT CALENDAR EVENTS

1. Scroll to desired date in any view and open.

2. Scroll to scheduled event and open. Edit desired fields.

3. Press Done when finished.

DELETE EVENTS

1. Scroll to desired date in Month or Week view, and time period in Week view and

open.

2. Press Options and select Delete or press .

To delete multiple events:

1. View the calendar in Month view.

2. Press Options and select Delete entry > Before date to delete entries before your

specified date, or All entries.

CALENDAR SETTINGS

From Calendar application:

1. Press Options and select Settings. Open each option:

Calendar alarm tone Scroll to select desired tone (after a brief pause tone will play).

Default view Select Month view, Week view, or Day view.

Week starts on Choose starting day of the week.

Week view title Choose Week number of the year (e.g. Week 12) or Week

dates (e.g. 20.03.05-26.03.05).

Note:Week view title setting is available only if Week starts on is set to Monday.

Week numbers are shown in layouts only if Week starts on is set to Monday.

X700_OI.book Page 38 Wednesday, September 1, 2004 6:47 PM

SEND CALENDAR EVENTS

Before a Calendar event can be sent by Messaging or to another device, it is converted

to an electronic scheduling exchange format known as vCalendar.

1. From an open Calendar event in Day view, press Options and select Send > Via

text message, Via multimedia, Via e-mail, Via Bluetooth or Via infrared.

2. To complete text messages, see page 42; or multimedia messages on page 42; or

e-mail messages on page 44; or Bluetooth on page 82; or Infrared on page 84.

CHINESE LUNAR CALENDAR

Check Chinese Lunar Calendar dates and festivals when still viewing western Calendar

information.

To display Chinese Lunar Calendar information:

1. From the open Calendar, press Options and select Settings.

2. Scroll to Lunar calendar.

3. Select On.

4. To view Chinese Lunar Calendar detail, press Options and select View lunar data.

To turn off Chinese Lunar Calendar information:

1. From the open Calendar, press Options and select Settings.

2. Scroll to Lunar calendar.

3. Select Off.

Note: Chinese Lunar Calendar will appear only when a Chinese language

is selected as the phone display language.

X700_OI.book Page 39 Wednesday, September 1, 2004 6:47 PM

MESSAGES

Messages menu contains these main options:

VOICE MAIL

Voice mail service stores voice messages from callers who could not reach you. The

messages are stored on your wireless service provider’s network, not on your phone.

You must first subscribe to voice mail from your wireless service provider before using

this service.

Listen to Voice Mail Messages

When you receive a new voice mail message, an alert sounds if ringtone is not set to

silent, and the voice mail icon displays.

1. Press and hold in standby mode to dial your voice mail message centre.

• You can also press and in standby mode.

2. Follow the prompts to listen to your voice mail messages.

If the phone asks for the voice mailbox number, enter the voice mail message centre

phone number given to you by your wireless service provider.

To change the voice mailbox number, from Messages application:

1. Open Voice mail.

2. Press Options and select Change number.

MESSAGES

Send, receive, and store messages from text message (SMS), multimedia (MMS),

e-mail, service and cell broadcast.

Messaging Types

SMS: Short Message Service allows you to send and receive short text messages to

mobile phones with short text message capability on the same network or any network

that has a roaming agreement. A small black and white picture message can be inserted

in the message.

MMS: Multimedia Messaging Service allows you to send messages containing images,

video clips, sound clips and text. Presentation templates are available to place media

objects into prearranged layouts. Multimedia messages can be sent to another mobile

phone with multimedia capability or to an e-mail address.

E-mail: Create, send and receive e-mail messages, which can have attachments.

Voice mail Messages

X700_OI.book Page 40 Wednesday, September 1, 2004 6:47 PM

Smart messages: Messages containing data such as electronic business cards, ringing

tones, Java™ applications or configuration data such as WAP and multimedia settings.

These services do not work by sending messages directly to the recipient, instead they

store and forward messages through specifically designated network servers.

Before Using Messaging Services

Before you can use multimedia or e-mail messaging, your connection settings must be

configured.

Your multimedia configuration settings may already be set by your wireless service

provider. If settings are not available, contact your wireless service provider.

Your e-mail configuration settings are provided by an Internet Service Provider (ISP)

that supports POP3/IMAP4/SMTP protocols.

Before you can send and receive e-mail:

(1) you need a subscription for data services, (2) contract must be set up with an ISP, (3)

you must configure an Internet Access Point (see Access Point Settings on page 95).

Messages Menu Main Options

In some main Messages options, icons indicate the message type:

To view Cell Broadcast messages, see page 56.

New message

Create new messages.

Drafts

Stores unfinished messages.

Inbox

Stores received messages except e-mail and

cell broadcast.

Sent

Stores sent messages.

My folders

Stores moved messages and templates.

Outbox

Temporarily stores messages waiting to be

sent.

Mailbox

Receives and stores e-mail messages.

Reports

Delivery status on text, multimedia, and smart

messages.

Text message Bluetooth Cell broadcast

Multimedia Infrared Unknown

E-mail WAP push Attachment

Smart

X700_OI.book Page 41 Wednesday, September 1, 2004 6:47 PM

CREATE NEW TEXT MESSAGES

From Messages application:

1. Open Messages.

2. Open New Message and select Text message.

3. In the To field, type in recipient’s phone number.

• To retrieve from Contacts card, press , or Options and

select Add recipient. Scroll to desired name and press OK.

Select desired number if entry has several numbers.

• To separate multiple recipients, enter a semicolon (;) by

pressing .

4. Scroll to move to text entry field, enter text.

5. If desired, press Options and select Insert >

6. To send, press or press Options and select Send.

CREATE NEW MULTIMEDIA MESSAGES

From Messages application:

1. Open Messages.

2. Open New message and select Multimedia message.

3. In the To field, type in recipient’s phone number or e-mail

address.

• To retrieve from Contacts card, press , or Options and

select Add recipient. Scroll to desired name and press OK.

Select desired number if entry has several numbers. Card

must have a phone number or e-mail address to be visible.

• To separate multiple recipients, enter a semicolon (;) by pressing .

4. Scroll to move to text entry field, enter text.

5. If desired, press Options and select Insert >

Picture Picture msg. from Media Gallery

Template Select from a list of sentences in which you fill in the blank

Note: Text messages have a 160 character limit. The counter keeps track

of total characters available. If you use more than 160 characters, a

new text message starts, but appears as one message or more at

destination. You may be charged for more than one text message.

Image Image from your Images folder

Sound clip Sound clip from your Sound clips folder

Video clip Video clip from your Video clips folder

New image New image from Camera

New sound clip New sound clip from Voice Recorder

X700_OI.book Page 42 Wednesday, September 1, 2004 6:47 PM

6. To send, press or press Options and select Send.

Create Presentation

Choose from four presentation templates to create an impressive multimedia show.

1. Complete steps 1, 2 and 3 in Create New Multimedia Messages on page 42.

2. Press Options and select Create presentation.

3. Select from the list of templates:

• Image template

• Video template

• Sm. image tem.

• Temp. with title

4. Highlight desired template, press Select.

5. Scroll to the video, text, or image region of the template to highlight it.

6. If desired, press Options and select Insert >

7. Press Options and select:

Slide Add new slide to message

Note: If multimedia messages are sent to devices without

multimedia or e-mail capabilities, the recipient may receive

a message containing a link to a web page.

Image Image from your Images folder

Sound clip Sound to play at start of show

Video clip Video clip from your Video clips folder

Note Note from Notepad (if a text region is highlighted)

New image New image from Camera

New slide Add new slide to show

Note: Available choices depend on region highlighted.

Send Send completed presentation

Full screen Edit in full screen view

Normal screen Edit in normal screen view with signal icon, slide number, and

softkey labels in view

Edit text Start or stop text editing, change text colour

Preview message Preview entire message before sending

Remove > Remove image, sound clip, video clip, or current slide

Backgrnd. settings > Set background colour, add background image to current slide

or entire presentation, remove background image

X700_OI.book Page 43 Wednesday, September 1, 2004 6:47 PM

8. To send, press or press Options and select Send.

CREATE NEW E-MAIL MESSAGES

Before you can write an e-mail message, at least one mailbox must be configured. See

page 48.

From Messages application:

1. Open Messages.

2. Open New message and select E-mail.

3. In the To field, type in recipient’s e-mail address.

• To retrieve from Contacts card, press , or Options and

select Add recipient. Scroll to desired name and press OK.

Card must have an e-mail address to be visible.

• To separate multiple recipients, enter a semicolon (;) by

pressing .

4. Scroll to enter recipients in Cc (courtesy copy) field and type subject in subject

field (both fields optional).

5. Scroll to move to text entry field, enter text.

6. If desired, press Options and select Insert >

7. To send, press , or press Options and select Send.

• To view, add, or remove attachments before sending, press Options and select

Attachments.

• If phone is set to send e-mail during next connection to mailbox, then pending e-mail

will be stored in Outbox. Change setting by pressing Options and selecting Sending

options.

COMMON WRITING TASKS

• To cut, copy and paste text, see page 24.

• To save before sending, press Close. Message is automatically stored in Drafts

folder.

• To match names in To and Cc fields to names in Contacts, press Options and select

Check contacts.

Effect settings > Set transition effect between images and between slides

Image Image from your Images folder

Sound clip Sound clip from Sound clips folder

Video clip Video clip from Video clips folder

Note Note from Notepad

Template Select from a list of sentences in which you fill in the blank

X700_OI.book Page 44 Wednesday, September 1, 2004 6:47 PM

RECEIVE NEW MESSAGES

When you receive a new message, the standby screen displays a new message icon

and a note indicating the number of new messages. Press Show to read the

message. If there is more than one message, press Show to open the Inbox, then scroll

to the desired message header and open.

INBOX (RECEIVED MESSAGES)

Inbox stores received text, multimedia, and smart messages. Incoming Bluetooth;

Infrared; WAP push; SIM; and voicemail, e-mail waiting messages are also placed here.

The messages remain in the Inbox until you move them to My folders or delete them.

Unread messages have incoming arrow appearing with icon that identifies type of mes-

sage.

Read messages have no arrow with icon.

Read or Play Inbox Messages

From Messages application:

1. Open Messages.

2. Scroll to Inbox and open.

3. A list of message headers displays, indicating type of message sender (Multimedia,

Bluetooth, etc.) and icon. Scroll to desired message header and open.

• The message may first need to be retrieved from the network server depending on

the message type or if it contains large files.

• Press Play if needed for video clips, sound clips and presentations.

• If the message contains an image, it opens automatically.

Reply to and Forward Inbox Messages

From Messages application:

1. Open Messages.

2. Select Inbox.

3. Scroll to desired message, press Options and select Reply > To sender or To all

or Forward.

4. To reply, enter text in text field.

To forward, enter recipient(s) phone numbers or e-mail addresses.

5. Press .

Note: Scroll to decrease or increase audio volume.

Note: The phone may not allow you to copy, modify, transfer, or forward

some copyrighted images, ringtones and other content.

X700_OI.book Page 45 Wednesday, September 1, 2004 6:47 PM

Store Inbox Messages

From Messages application:

1. Open Messages.

2. Select Inbox.

3. Highlight desired message.

4. Press Options and select Move to folder.

5. Choose a folder and press OK.

Save Attachment or Data

You can save images and media clips from messages. Attachments to e-mail, links to

streaming media, Contacts cards, Calendar items, ringtones, and configuration data can

also be saved.

1. Open desired message.

2. Press Options and select Save.

• If needed, the data is directed to the appropriate application.

3. If needed, select to save either in phone memory or miniSD Card, press OK.

4. If needed, scroll to desired folder to place object or attachment, press Open or

Save. If desired, rename the file. Press Save.

Find Phone number, E-mail or Web Address in Message

Within received messages, you can find a phone number, e-mail or web address within

message text and use it to call, write, access a service or create a Contacts card.

From Messages application:

1. Open Messages.

2. Scroll to Inbox or My folders and open.

3. Scroll to desired message and open.

4. Press Options and select Find > Phone number, E-mail address, or Web

address.

5. Text and numbers are highlighted when found. If more than one is found, scroll to

highlight desired item.

6. Press to Send a message, Add to Contacts to add or update Contacts, Call a

number, Go to web address, or Add to bookmarks to add web address to

bookmarks.

Note: Received applications or games can be installed directly from the Inbox.

When you open the message, the phone asks if you want to install it now.

An attachment or object remains in the Inbox after it is saved to another

application. To save memory space, delete message from Inbox.

X700_OI.book Page 46 Wednesday, September 1, 2004 6:47 PM

MY FOLDERS (ORGANISE MESSAGES)

Store your messages in My folders. You can also create and name new folders. For

example, create a folder for Friends and one for Family messages. Folders can also be

created by message type or by subject.

From Messages application:

1. Open Messages.

2. Select My folders.

3. Press Options and select New folder.

4. Enter a name for your folder and press OK.

To rename or delete a folder, from Messages application:

1. Open Messages.

2. Select My folders.

3. Scroll to desired folder, press Options and select Rename folder or Delete.

Templates

Templates are short sentences in which you fill in the blank, then send the message.

Template sentences can also be inserted into longer messages.

From Messages application:

1. Open Messages.

2. Select My folders. Select Templates.

3. Scroll to desired text. Press Options and select Send > Via text message, Via

multimedia, or Via e-mail.

4. Press and a new message opens with template text already placed.

5. Fill in needed information and press .

To create your own template text, from Messages application:

1. Open Messages.

2. Select My folders. Select Templates.

3. Press Options and select New template.

4. Enter text, numbers, or symbols, and press Done.

Note: You cannot create folders within a folder.

Note: In longer messages, at cursor, press Options and select

Insert > Template. Template text is placed at cursor.

X700_OI.book Page 47 Wednesday, September 1, 2004 6:47 PM

MAILBOX (E-MAIL MESSAGES)

E-mail is received and stored in a separate mailbox. Once you set up a mailbox, Mailbox

will be renamed and appear with its new name in the main Messages list. You can set

up to 6 mailboxes, each appears separately in the main Messages list.

After your e-mail is set up, use the mailbox to view and send e-mail. Files such as

images, sound and video clips can be attached from phone memory or miniSD Card.

Supported e-mail clients include a standard POP3, IMAP4, SMTP, MIME client. E-mail

messaging takes place over CSD and GPRS bearerset using standard Internet e-mail

protocols over TCP/IP.

Configure Mailboxes

From Messages application:

1. Open Messages.

2. Press Options and select Settings.

3. Scroll to E-mail and open.

4. Highlight Mailboxes and open.

5. Press Options and select New mailbox.

6. Enter information in fields. Fields marked in the phone with a red asterisk (*) must

have an entry.

Note: Before you can send or retrieve e-mail, you must first set up a mailbox.

Mailbox name Use default name or enter a name for your mailbox and press

OK.

* Access point in use Default Access Point supplied by wireless service provider

* My e-mail address Enter your own e-mail address and press OK. May be supplied

by wireless or Internet service provider.

* Outgoing mail

server

Enter SMTP mail server address.

Send message Choose During next conn. or Immediately.

Send copy to self Select Yes or No.

Include signature Select Yes to enter a signature for outgoing messages.

User name Enter a name to log into service provider remote mailbox.

Password Enter password.

* Incoming mail

server

Enter address of incoming mail server (POP or IMAP), supplied

by service provider.

Mailbox type Select POP3 or IMAP4.

Security Select Off or On. Determined by Internet service provider.

X700_OI.book Page 48 Wednesday, September 1, 2004 6:47 PM

Select Mailbox Name to Use to Send E-mail

To select which mailbox to use to send e-mail messages, see page 55.

If you have more than one mailbox and you start to write a new message, the phone

notifies you of the mailbox name that is currently in use. To change the mailbox, see

page 55 to change Mailbox in use setting.

Create a New E-mail Message

To create a new e-mail message, see page 44.

Retrieve E-mail

You can view your mailbox either online or offline. When you are online, you see your

messages stored on the remote server. When you are offline, you see messages

retrieved from the remote server to your phone, or message headers if not yet retrieved.

IMAP4 protocol allows you to retrieve messages without attachments, so large memory

files can remain in your online mailbox and not be stored in the phone.

You can mark as read or delete messages, or copy them to another folder and view

message details when offline. Your mailbox is synchronised to the server when you go

online.

When you receive a new e-mail message, a new message notice appears on the

standby screen.

To connect to your mailbox, from Messages application:

1. Open Messages.

2. Select Mailbox (or renamed mailbox).

3. Press Options and select Connect.

4. Once you are connected, press Options and select Retrieve e-mail > New,

Selected, or All.

• To select certain messages, use Mark/Unmark action.

5. Once messages are retrieved, you can read them offline. Press Options and select

Disconnect.

APOP secure login

(POP3 only)

Select Yes to use authenticated POP log in, encrypts password.

Retrieve attachment

(IMAP4 only)

Select Yes or No to automatically retrieve attachment when

message is fetched.

Retrieve headers

(IMAP4 only)

Select All to retrieve all message headers, or select User

defined and type in a number to retrieve only the latest headers.

X700_OI.book Page 49 Wednesday, September 1, 2004 6:47 PM

Read Messages Offline

From Messages application:

1. Open Messages.

2. Select Mailbox (or renamed mailbox).

3. Press No when phone asks to connect to mailbox.

4. Scroll to desired message and open.

Reply to E-mail Messages

From Messages application:

1. Open Messages.

2. Select Mailbox (or renamed mailbox).

3. Highlight desired message.

4. Press Options and select Reply > To sender or To all.

Copy E-mail Messages

From Messages application:

1. Open Messages.

2. Select Mailbox (or renamed mailbox).

3. Highlight desired message.

4. Press Options and select Copy to folder.

5. Choose from the appropriate folders and press OK.

Sort Message List

From Messages application:

1. Open Messages.

2. Select Mailbox (or renamed mailbox).

3. Press Options and select Sort by > Date, Sender, or Subject.

Save Attachment or Data

You can save attachments, such as Contacts cards, Calendar items, links to streaming

media, and configuration data.

1. Open desired message.

2. Press Options and select Attachments >

Open Open attachment in read-only mode.

Save Save attachment.

Send Send attachment via Bluetooth or via infrared.

Note: Attachment cannot be opened, saved, or sent if it has not been retrieved.

X700_OI.book Page 50 Wednesday, September 1, 2004 6:47 PM

Add E-mail Address to Contacts Card

From Messages application:

1. Open Messages.

2. Select Mailbox (or renamed mailbox).

3. Open desired message.

4. Press Options and select Add to Contacts > Create new to create a new Contacts

card using the sender’s e-mail address, or Update existing to place the sender’s

e-mail address in an existing Contacts card.

5. Continue with Create New Contact Cards on page 30 or Edit Contact Cards on

page 32.

Manage Mailboxes

From Messages application:

1. Open Messages.

2. Press Options and select Settings.

3. Scroll to E-mail and open.

4. Highlight Mailboxes and open.

5. Scroll to desired mailbox name and press Options and select Edit or Delete.

DRAFTS

Your unfinished text (SMS), multimedia (MMS), and e-mail messages that have not

been sent are stored in the Drafts folder.

From Messages application:

1. Open Messages.

2. Scroll to Drafts and open.

3. Scroll to desired message and open.

4. Enter the rest of the information.

5. Press , or if desired press Options and select:

Send Send message

Add recipient Send to more than one address

Insert > Insert items such as Picture, Image, Sound clip, Video clip, or

Template, depending on what type of file the message type sup-

ports

Attachments (E-mail)

Objects (Multimedia)

Open, insert, or remove attachments or objects

Edit presentation

(Multimedia)

Edit the presentation

Preview message

(Multimedia)

Preview message before sending

X700_OI.book Page 51 Wednesday, September 1, 2004 6:47 PM

SENT

Text, multimedia, smart, and e-mail messages that have been successfully sent are

stored in the Sent folder, which stores the last 15 sent messages.

Move Sent Messages to My Folders

From Messages application:

1. Open Messages.

2. Scroll to Sent and open.

3. Scroll to desired message, then press Options and select Move to folder.

4. Select desired folder and press OK.

View or Delete Sent Messages

To view or delete sent messages and objects or attachments, from Messages

application:

1. Open Messages.

2. Scroll to Sent and open.

3. Scroll to desired message and open.

4. Press Options and select:

Check contacts Match names in To and Cc fields to names in Contacts

Message details View details such as message size

Sending options View or change sending options depending on type of message

Attachments (E-mail)

Objects (Multimedia)

Open, save, or send attachments or objects

Delete Delete message, object or attachment

Message details View details such as message size

X700_OI.book Page 52 Wednesday, September 1, 2004 6:47 PM

OUTBOX

Outbox stores messages waiting to be sent, and messages that could not be sent; for

example, connection to the network failed.

It also temporarily stores Bluetooth and Infrared messages that are waiting for

connection to the receiving device. If the connection fails, Outbox does not keep the

message.

The Outbox icon appears on the standby screen when there are messages in the

Outbox.

Status of Outbox messages:

Send, View, and Manage Outbox Messages

From Messages application:

1. Open Messages.

2. Scroll to Outbox and open.

3. Scroll to desired message. Press Options and select:

Messages waiting in the Outbox are automatically resent (except e-mail set to send

during next connection), depending on network availability.

To cancel resending, from Messages application:

1. Open Messages.

2. Scroll to Outbox and open.

3. Scroll to desired message. Press Options and select Delete.

Sending Connecting to network Waiting Waiting to connect

Queued E-mail waiting for connection Resend at If sending failed, resend attempt

Deferred Suspend sending to another time Failed Sending has not been successful

Defer sending Defer sending until you manually send

Message details View details such as message size

Send Send message now

Move to Drafts Move message to Drafts folder, where it can be edited and

resent

X700_OI.book Page 53 Wednesday, September 1, 2004 6:47 PM

REPORTS

Delivery reports for text, multimedia, and smart messages can be sent by your wireless

service provider, and stored in the Reports folder. Delivery reports are not available for

e-mail messages.

From Messages application:

1. Open Messages.

2. Press Options and select Settings.

3. For text messages, open Text message, scroll to Receive report and select Yes.

For multimedia messages, open Multimedia message, scroll to Receive report

and select Yes.

MESSAGE SETTINGS

Text Message Settings

From Messages application:

1. Open Messages.

2. Press Options and select Settings.

3. Open Text message. Open fields as needed:

Multimedia Message Settings

From Messages application:

1. Open Messages.

2. Press Options and select Settings.

3. Open Multimedia message. Open fields as needed:

Message centres Choose from provided list of network and SIM message centres

Msg. centre in use Choose which message centre is used to deliver text messages

Receive report Choose Yes or No. If Yes, delivery reports showing status of

sent text messages are stored in Reports folder.

Message validity Choose a time period from 1 hour to maximum in which text

message delivery is attempted from the message centre.

Message sent as Choose Paging or E-mail if you wish to convert your text mes-

sage to one of those forms for sending. Available only if network

can perform the conversion.

Preferred connection Choose GSM or GPRS connection.

Reply via same ctr. Select Yes to allow your text message recipients to use your text

message centre to reply to you without having to subscribe to a

text messaging service.

* Access point in use Choose from list of access points. See page 95 to create and

edit access points.

X700_OI.book Page 54 Wednesday, September 1, 2004 6:47 PM

E-mail Message Settings

From Messages application:

1. Open Messages.

2. Press Options and select Settings.

3. Open E-mail. Open fields as needed:

Service Message Settings

From Messages application:

1. Open Messages.

2. Press Options and select Settings.

3. Open Service message. Open fields as needed:

Cell Broadcast Message Settings

From Messages application:

1. Open Messages.

2. Press Options and select Settings.

Multimedia reception Choose Only in home net., Always on or Off for incoming

messages.

On receiving msg. Choose Retr. immediately, Defer retrieval or Reject message

for incoming messages.

Allow anon.

messages

Select Yes to receive messages from anonymous (unknown)

senders.

Receive adverts Select Yes to receive advertisements.

Receive report Select Yes to receive delivery reports.

Deny report sending Select Yes so that your phone will not send a delivery report to

confirm receipt of a new message.

Message validity Choose a time period for the message centre to attempt mes-

sage delivery.

Image size Select Small (default) for 160x120 (max) image size, or Large

for 640x480 (max).

Default speaker Choose to play sound clips from Loudspeaker or Handset

speaker.

Mailboxes View list of mailboxes you have set up.

Mailbox in use Select mailbox to use to send e-mail.

Service messages Select On to receive service messages.

Download messages Select Manually to allow only authorised senders to send ser-

vice messages.

X700_OI.book Page 55 Wednesday, September 1, 2004 6:47 PM

3. Open Cell broadcast. Open fields as needed:

Other Message Settings

From Messages application:

1. Open Messages.

2. Press Options and select Settings.

3. Open Other. Open fields as needed:

SIM MESSAGES

To view, copy, or delete text messages stored on the SIM card, from Messages

application:

1. Open Messages.

2. Press Options and select SIM messages.

3. A list of messages stored on the SIM card appears.

4. To view the messages, first copy them to the phone memory. Before copying

multiple messages, use Mark/Unmark > Mark or Mark all to mark any or all desired

messages to perform copying at one time. Press Options and select Copy.

5. Choose the desired folder to place the copy and press OK.

6. If desired, press Options and select Delete to delete messages from the SIM card.

CELL BROADCAST MESSAGES

Cell broadcast messages are sent by your wireless service provider to GSM customers

in a certain area. They provide general information about topics such as weather

reports, traffic news, and customer services. Available topic names and numbers are

supplied by your wireless service provider.

From Messages application:

1. Open Messages.

2. Press Options and select Cell broadcast.

Reception Select On to receive cell broadcast messages.

Language Select All to receive cell broadcasts in all possible languages, or

Selected to choose from a list, or Other if your preferred lan-

guage is not listed.

Topic detection Select On to view a list of topic indexes provided by the network.

Save sent messages Select Yes to save sent messages to the Sent folder.

No. of saved msgs. Type in a number to set maximum amount of messages saved

to Sent folder.

Note: Leaving Cell broadcast set to On reduces battery life.

X700_OI.book Page 56 Wednesday, September 1, 2004 6:47 PM

3. Press Options and select:

SERVICE COMMAND

Ask your wireless service provider to activate a particular service by sending a service

command. These commands, which may be called USSD commands, can activate

services such as mobile prepay and chat.

1. Contact your wireless service provider for the proper service command statement.

From Messages application:

2. Open Messages.

3. Press Options and select Service command.

4. Enter the service command, then press .

Open Open topic

Subscribe or

Unsubscribe

Subscribe to selected topic to receive related messages. Select

Unsubscribe to stop receiving related messages.

Hotmark or

Remove hotmark

When topic is hotmarked, you will receive a notice when related

messages arrive.

Topic > Choose Add manually to type in a topic name or topic number

or Delete all.

Settings See Cell Broadcast Message Settings on page 55 to turn on or

off Cell broadcast reception, choose Cell broadcast language,

and turn on or off topic detection.

X700_OI.book Page 57 Wednesday, September 1, 2004 6:47 PM

CAMERA

Take pictures to send in a multimedia or e-mail message, or for your Contacts cards.

Pictures can also be sent via infrared or Bluetooth.

TAKE A PICTURE

From Camera application:

1. With the flip open, the main display acts as a viewfinder. Move

the phone around to frame your subject.

2. To snap the picture, press .

• The image is automatically saved to Images folder. See

Gallery on page 62.

To send the picture immediately, press . Scroll to Via

multimedia, Via e-mail, Via Bluetooth, or Via infrared. To

complete multimedia messages, see page 42; or E-mail messages

on page 44; or Bluetooth on page 82; or Infrared on page 84.

If you do not want to save it, either:

• Press and select Yes.

• Press Options and select Delete.

Change Capture Modes

To choose different picture capture modes, scroll to select:

Standard regular size landscape pictures (640x480 pixels [VGA])

Portrait smaller pictures that use much less memory and can be placed in

Contacts cards (80X96 pixels)

• Red number in upper right corner indicates the amount of pictures that can fit in

phone memory, depending on selected image size.

Zoom

You can zoom in on your subject before taking a picture.

1. When viewing your subject in the viewfinder, press once for 2x zoom, press

again for 4x zoom. Press to step back one zoom level.

2. Press to snap the picture.

Note: Camera mode depletes battery power more rapidly. To conserve your battery,

the phone shifts to camera standby mode after 1 minute if no keys are pressed.

X700_OI.book Page 58 Wednesday, September 1, 2004 6:47 PM

Self-timer

Set the camera to take a picture after setting the timer to delay the shutter.

1. From the viewfinder, press Options and select Self-timer > 10 seconds, 20

seconds, or 30 seconds.

2. Move the phone around to frame your subject.

3. Press Activate to start the timer.

• The shutter sounds when the picture is taken.

• The image is stored in the Media Gallery Images folder.

Photolight

Light up your subject before snapping a picture. See PhotoLight on page 119.

TAKE A SELF-PORTRAIT

From Camera application:

1. Close the phone flip. The external display acts as a viewfinder. Move the phone

around to frame your subject.

2. Press Multibutton on side of phone to snap the picture.

3. Open the flip. The image appears on the main display.

• The image is automatically saved to Media Gallery Images folder. To make

changes to the image, press Options and select Go to Gallery. See Gallery on

page 62.

To send the picture immediately, see Send Pictures on page 60.

If you do not want to save it, press Options and select Delete.

SAVE PICTURES

Pictures are automatically saved in the Images folder in Media Gallery in phone

memory, or you can save them on the miniSD Card.

To save pictures to the miniSD Card, from Camera application:

1. Press Options and select Settings.

2. Scroll to Memory in use and open.

3. Select NO NAME or the name assigned to your miniSD Card.

• All pictures are saved to the miniSD Card until this setting is changed to Phone

memory, or miniSD Card is removed.

Note: To rename your miniSD Card, see miniSD Card (MEMORY

CARD) on page 113.

X700_OI.book Page 59 Wednesday, September 1, 2004 6:47 PM

VIEW PICTURES

From Camera application:

1. Press Options and select Go to Gallery. A list of images stored in phone memory

displays. Scroll to desired image and open.

• Or to view images in miniSD Card, press Back, scroll to miniSD Card tab.

Scroll to desired image or folder and open.

NAME PICTURES

To change the name that is used as the default file name for new images, from Camera

application:

1. Press Options and select Settings.

2. Open Default image name and enter desired text.

• For example, if you change the Image Name to SkiTrip, then your pictures will be

named SkiTrip; SkiTrip(01); SkiTrip(02), etc. until the default name is changed.

3. To rename an individual image when you have taken a picture:

1. With saved image on main display, press Options and select Rename.

2. Enter a new name for the image.

PICTURE QUALITY

To choose the compression level (memory size) of future pictures:, from Camera

application:

1. Press Options and select Settings. Open Image quality.

2. Select High, Normal, or Basic. The higher image quality you choose, the larger the

file size will be.

If you plan to view pictures on a computer, use High or Normal picture quality so the

quality will be better maintained when enlarged on a computer screen.

Basic picture quality is best when the pictures will be viewed on phones and other small

screens.

SEND PICTURES

Send the picture you just took to your family and friends.

1. With saved image on main display, press , or press Options and select Send >

Via multimedia, Via e-mail, Via Bluetooth, or Via infrared.

2. To complete multimedia messages, see page 42; or E-mail messages on page 44;

or Bluetooth on page 82; or Infrared on page 84.

Note: All three levels are 640 x 480 pixels resolution (sharpness).

X700_OI.book Page 60 Wednesday, September 1, 2004 6:47 PM

Add a Picture to Contact Card

To add a picture to a Contact card, see Edit Contact Cards on page 32.

Incoming Calls when in Camera Mode

If you receive a call while in camera mode, the phone temporarily suspends camera

mode and switches to the incoming call display. Once you answer the call, the screen

returns to Camera mode and a small active call icon displays. If a captured image is on

the preview screen, it is saved in the Media Gallery Images folder.

X700_OI.book Page 61 Wednesday, September 1, 2004 6:47 PM

MEDIA

Media menu contains these main options:

GALLERY

Store, play, and manage your pictures, images, video clips, sound clips and streaming

links (web addresses) in the phone memory or miniSD Card. Send media files to friends

and family via multimedia, e-mail, Bluetooth, or infrared.

See Specifications on page 134 for supported media file formats.

VIEW IMAGE, SOUND, AND VIDEO FOLDERS

From Media application:

1. Open Gallery.

2. Phone icon tab shows data stored in phone memory, or scroll to view data stored

on miniSD Card.

3. Select folder:

VIEW IMAGES, ZOOM IN, AND SET AS WALLPAPER

When an individual image is open, you can zoom in/out, rotate and view images full

screen, and do other actions as listed below.

From Media application:

1. Open Gallery.

2. Phone icon tab shows data stored in phone memory, or scroll to view data stored

on miniSD Card.

3. Open Images folder, then scroll to and open desired image.

4. Press Options and select:

Gallery PhotoBase RealOne Player

Video Recorder

Documents See File Manager on page 117 to view your QuickOffice docu-

ments.

Images Scroll to desired image, or open Wallpapers folder to view wall-

paper files. Contact your network operator for availability of Pic-

ture msg. service.

Sound clips Choose Digital sounds folder or Tones folder.

Video clips Video clips.

Send > Send file to another device.

Set as wallpaper Set image as wallpaper in standby mode.

X700_OI.book Page 62 Wednesday, September 1, 2004 6:47 PM

Zoom, Rotate, and Panning Shortcuts

Zoom zooms in; zooms out; zooms in, press again to activate full

screen

Pan and pan up; and pan down; and pan left; and

pan right

Rotate rotates clockwise; rotates counter clockwise

Original Press and hold to go back to original size view

Full screen switches between full screen view and original size view

• If image is not zoomed, scroll to go to next image in the current folder.

PLAY VIDEO, SOUND CLIPS, AND STREAMING MEDIA

Watch video clips and listen to sound clips, or play streaming media. Streaming media is

sound and video stored and played back as it arrives from the Internet or your network

servers; thus the file is not stored on your phone, taking up valuable memory.

From Media application:

1. Open Gallery.

2. Phone icon tab shows data stored in phone memory, or scroll to view data stored

on miniSD Card.

3. Open desired folder(s), then scroll to and open desired video or sound clip. When

choosing a link to streaming media, the phone begins connection process to the

Internet or to your network.

• See Player Controls on page 64.

Rotate > Rotate image Left or Right in 90 degree steps.

Zoom in / Zoom out Zoom in or out in steps from 12.5% to 800%.

Full screen Removes status bar and softkey text to see more of the image.

Normal screen When viewing full screen, press , then select Normal

screen to view status bar and softkey text.

Rename Rename the image.

View details View details such as file format and size, and image creation

time and date.

Add to Favourites Add a shortcut to view image from Favourites.

Note: For streaming media, after the phone successfully connects to the

link (web address of streaming media), there is a short loading

period to prepare playback, then the streaming media begins

playing. See Player Controls on page 64.

X700_OI.book Page 63 Wednesday, September 1, 2004 6:47 PM

Press Options and select from these additional options:

PLAYER CONTROLS

Video controls

Sound controls

To select buttons on screen, scroll or to move box to button and press :

Volume control

Scroll to increase volume, scroll to decrease volume (note bar scale near top of

screen).

To mute the sound in a video clip, scroll until muted speaker icon appears. To turn

sound back on, scroll . When playing sound clips, the lowest volume setting is level 1.

SEND PICTURES, VIDEO AND SOUND CLIPS

From Media application:

1. Open Gallery.

Export to miniSD Copy or move file to miniSD Card.

Copy to Copy file to phone memory or miniSD Card.

Rename Rename clip.

Gallery downloads > Go to download link for images, videos, or sounds in Browser.

Receive via infrared Receive a file via infrared.

View details View clip details such as file format, size, resolution, and dura-

tion.

Add to Favourites Add a shortcut to view or listen to clip from Favourites.

Settings Adjust multimedia settings (see page 69).

Note:Gallery downloads and Receive via infrared features may not be available.

Play: Press Options and select Play. Video automatically begins

playing when first opened.

Stop: Press Stop softkey.

Pause: Press Pause softkey or press . To resume play, press

and select Continue, or press Options and select Continue.

Fast forward: Press and hold on navigation key during play.

Fast rewind: Press and hold on navigation key during play.

Play: Pause: Rewind:

Stop: Fast forward: Record:

X700_OI.book Page 64 Wednesday, September 1, 2004 6:47 PM

2. Phone icon tab shows data stored in phone memory, or scroll to view data stored

on miniSD Card.

3. Open respective folder, then highlight desired file.

4. Press Options and select Send > Via multimedia, Via e-mail, Via Bluetooth or

Via infrared.

5. To complete multimedia messages, see page 42; or E-mail messages on page 44;

or Bluetooth on page 82; or Infrared on page 84.

DOWNLOAD PICTURES, VIDEO AND SOUND CLIPS

From Media application:

1. Open Gallery.

2. Press Options and select Gallery downloads > Graphic downloads, Video

downloads, or Tone downloads.

3. The Browser opens. Choose a bookmark site to download the desired media.

IMAGE UPLOADER

Store your personal pictures on an image server and share them with family and friends.

To use this service, (1) you must purchase this service from your wireless service

provider if it is available (2) you must configure an Internet Access Point.

Contact your wireless service provider to obtain the image server settings. Enter the

image server settings in the phone (see page 65).

Set Up Image Server

From Media application:

1. Open Gallery.

2. Scroll to an image to highlight it.

3. Press Options and select Image uploader > Settings.

4. Open Image servers. For the first time, select Yes to define an image server.

5. Open each field to enter information:

Note:The Send option is not available for streaming media.

Note: Free content is available for your X700 phone. For downloading information, visit

www.panasonicbox.com. Availability of this service is dependent on your country/

region or network. The downloaded content is free, however there will be a

communication fee to download.

Note: Image Uploader service can support only JPG format files.

Image server name Enter a descriptive name for the image server

* Access point in use Choose desired access point from list. See page 95.

User name Enter your user name for the uploader service

X700_OI.book Page 65 Wednesday, September 1, 2004 6:47 PM

To edit or add more image servers, press Options and select Edit or New image

server after opening Image servers. You can also delete image servers here.

To change the image server in use if you have set up more than one, open Image

server in use setting and select desired image server.

Upload Images

To upload images to an image uploader service, from Media application:

1. Open Gallery.

2. Scroll to the desired image to upload to highlight it.

3. Press Options and select Image uploader > Upload.

PHOTOBASE

Take pictures, then show them to your friends in a slide show right from your phone.

Remove red eye, crop, rotate, or change brightness and contrast of your pictures before

sharing them. You can also add frames, clip art, and text to your pictures.

TAKE A PICTURE USING PHOTOBASE

From Media application:

1. Open PhotoBase.

2. Open Camera.

3. With the flip open, the main display acts as a viewfinder. Move the phone around to

frame your subject.

4. Press , or press Options and select Snap to take a picture.

The image appears on the display.

To keep the picture in your album, press Keep.

To delete the picture, press Discard.

Before Taking a Picture

To change the zoom, scroll or . To change contrast and brightness, scroll or .

Password Enter your password for the uploader service

* Web address Enter the web address of the image server

Auto folder naming Select On to have the current time and date as the default name

for your folders on the server

Note: For customer support and more information on PhotoBase,

visit www.arcsoft.com.

X700_OI.book Page 66 Wednesday, September 1, 2004 6:47 PM

Before taking a picture, if desired, press Options and select:

VIEW PHOTOS

From Media application:

1. Open PhotoBase.

2. Open Album.

3. Scroll to desired photo and open.

• To zoom in or out, press Options and select Zoom In or Zoom Out. Scroll , , ,

or to pan in zoomed images.

• Scroll to view previous photo, scroll to view next photo.

Slide Show

To see a slide show of the photos in your Images folder, from Media application:

1. Open PhotoBase.

2. Open Album.

3. Press Options and select Slide show.

4. Select a time interval between slides, and select a transition effect, for example, Top

to Bottom, to apply as each slide advances to the next.

5. Press Play.

6. Press to exit.

EDIT PHOTOS

From Media application:

1. Open PhotoBase.

2. Open Album.

3. Scroll to highlight desired photo and open.

4. Press Options and select Edit.

5. Press Options and select:

Mode > Choose Frame to add a frame to the picture. Horizontal Pan-

orama and Vertical Panorama allow you to stitch 3 pictures

together.

Picture folder > Choose the memory to store your pictures. Customize allows

you to create a new folder.

Settings Configure camera settings.

Go to Album Go to your Album.

Save Save edited photo in place of original photo.

Save as Enter a new name for edited photo and save as a new file.

Send > Send photo Via e-mail, Via Bluetooth, Via infrared, or Via

MMS (multimedia).

Rotate left Rotate photo to left.

X700_OI.book Page 67 Wednesday, September 1, 2004 6:47 PM

Crop Photos

1. With opened photo on screen, press Options and select Edit.

2. Press Options and select Crop.

3. A dotted cropping box appears. Press to resize the cropping box. Scroll to

make the cropping box taller, scroll to shorten the box. Scroll to widen the box,

scroll to narrow the box size.

4. To move the cropping box within the photo, press Options and select Move. Scroll

as desired to move the cropping box.

• If you have moved the box, select Resize to adjust the box size again.

5. To apply the crop, press Options and select Crop it.

6. To save the cropped photo as a new photo, press Options and select Save as.

Enter a name for the new photo.

ADD CLIP ART, FRAMES TO PHOTOS

1. With opened photo on screen, scroll to go to Workshop screen.

2. Select Clip Art to add clip art or Frame to add frames.

3. Scroll to desired clip art or frame and select.

4. Once the clip art or frame appears on the photo, press Options and select:

5. Press Options and select Send for sending options.

Warp Photos

1. With opened photo on screen, scroll to go to Workshop screen.

2. Select Warp.

3. A black crosshair mark appears on the photo. Scroll , , or to desired spot

where the warp will start. Press to change the mark to red, then scroll in direction

you want the warp to go.

• To add more warp points, press as needed to toggle the mark between black

and red.

4. Press Options and select Save, Save as, or Send for desired option.

Rotate right Rotate photo to right.

Brightness&

Contrast

Scroll or to adjust brightness, scroll or to adjust con-

trast.

Remove red eye Removes red eye from the photo.

Crop See Crop Photos on page 68.

Resize Resize photo by 200% or by 50%.

Move Scroll , , or

Resize Scroll , to increase, , to decrease

Rotate Scroll , to rotate left, , to rotate right

X700_OI.book Page 68 Wednesday, September 1, 2004 6:47 PM

Add Text to Photos

1. With opened photo on screen, scroll twice to go to Add Text tab.

2. Press Options and select Add new line. Enter text as desired. To edit text, press

Options and select Edit current line, Delete current line, Change text color,

Change text size, and Edit previous/next line.

3. Press Options and select Save, Save as, or Send for desired option.

REALONE PLAYER

RealOne Player is a media player that plays your video clips, sound clips and streaming

media links (web addresses) stored in the phone memory or miniSD Card. Video and

sound clips attached to messages are automatically played by RealOne Player, without

having to open the player first. Opening clips from Media Gallery, File Manager,

Browser, and Favourites applications launches the RealOne Player.

See Specifications on page 134 for supported media file formats.

PLAY VIDEO CLIPS AND STREAMING MEDIA

From Media application:

1. Open RealOne.

2. Press Options and select Open > Most recent clips for the last several opened

media files, or Saved clip to locate existing files and links in the phone memory or

miniSD Card.

3. Open desired folder(s), then scroll to and open desired video or sound clip. When

choosing a link to streaming media, the phone begins connection process to the

Internet or to your network.

• See Player Controls on page 64.

REALONE PLAYER SETTINGS

View and adjust settings for video playback and streaming media links.

From Media application:

1. Open RealOne.

2. Press Options and select Settings.

3. Highlight Video and open.

4. Select from:

Note: For streaming media, after the phone successfully connects to the

link (web address of streaming media), there is a short loading

period to prepare playback, then the streaming media begins

playing. See Player Controls on page 64.

Contrast Open, then scroll or to change the percentage.

X700_OI.book Page 69 Wednesday, September 1, 2004 6:47 PM

To view and adjust streaming media settings, from Media application:

1. Open RealOne.

2. Press Options and select Settings.

3. Scroll to Connection and open.

4. Select Proxy and select No or Yes.

• If you select Yes, then scroll down and enter the Proxy serv. address and the

Proxy port number.

5. Press Back and scroll to select Network. Open Network and select from:

Incoming Call when Playing Video

If there is an incoming call during playback of video clips, the player pauses the video. It

remains paused in the background during calls. To resume play, return to opened file

and press Options and select Continue.

The player also pauses when an alarm sounds, or a note appears, or you open another

application. When you return to the player, press Options and select Continue.

If you open an application when streaming video is playing, the streaming video pauses,

and stops when the auto disconnect time period is reached. See RealOne Player

Settings on page 69.

Repeat Select On to repeat playback, or select Off to playback one time.

Default access point Choose one of the access points you have set up. See Access

Point Settings on page 95.

Online time Select Unlimited, or select User defined to specify the amount

of time before phone will disconnect if there has been no activity.

Maximum bandwidth Select a maximum bandwidth for streaming media to use.

Connection time-out Select a maximum time period to wait from selecting a streaming

link until it connects to the server. Scroll left and right to move

the slider and change the time period.

Server time-out Select a maximum time period to wait for the media server to

begin sending the streaming media. Scroll left and right to move

the slider and change the time period.

Lowest UDP port Type in a User Datagram Protocol port number.

Highest UDP port Type in a User Datagram Protocol port number.

X700_OI.book Page 70 Wednesday, September 1, 2004 6:47 PM

VIDEO RECORDER

Record video clips to send to others, or play clips on your phone.

RECORD A VIDEO CLIP

To record nearby sound with the video, see Video Recorder Settings on page 72.

From Media application:

1. Open Video Recorder.

2. The main display acts as a viewfinder. Move the phone around to frame your

subject.

3. Press Options and select Record to begin recording. Watch the screen, then move

the phone as needed to keep the scene in view.

• Scroll to zoom in, scroll to zoom out if zoomed in.

• Press Pause to pause recording, press Resume to resume recording.

4. The video recorder records until reaching the clip size limit (specified in File Duration

in Settings), or until you press Stop softkey.

5. Wait for a few seconds while the video clip is saved to Media Gallery Videos folder,

or the miniSD Card according to Video storage setting. The last still image of the

recording remains on screen.

To send the video clip immediately, see Send a Video Clip on page 71.

If you do not want to save it, press and select Yes, or press Options and select

Delete.

SEND A VIDEO CLIP

1. With the video clip on screen, press , or press Options and select Send > Via

multimedia, Via e-mail, Via Bluetooth, or Via infrared.

2. To complete Multimedia messages, see page 42; or E-mail messages on page 44;

or Bluetooth on page 82; or Infrared on page 84.

Play a Video Clip

To play the video clip that was just recorded, press Options and select Play.

Note: Video Recorder mode depletes battery power more rapidly. To conserve

your battery, the phone shifts to standby mode after 40 seconds if

recording has not started. Press Options and select Continue to return to

viewfinder mode.

Note: The quality of display images may vary depending on the

object or environment.

Display images may distort when shooting moving objects,

especially in a fast moving environment.

X700_OI.book Page 71 Wednesday, September 1, 2004 6:47 PM

To play a stored video clip, from Media application:

1. Open Video Recorder.

2. Press Options and select Video Album.

3. Continue with step 3 in Play Video, Sound Clips, and Streaming Media on page 63.

VIDEO RECORDER SETTINGS

From Media application:

1. Open Video Recorder.

2. Press Options and select Settings.

3. Select from:

PhotoLight

Light up your subject before recording a video clip. See PhotoLight on page 119.

Incoming Calls when in Video Recorder Mode

If you receive a call while in video recorder mode, video recording stops and the video

clip is saved. After the calls ends, the last image of the recorded clip displays.

Resolution Choose the size of the display on the screen to be Low or High.

Audio recording Set to On to capture nearby sound as you record. Off turns off

the microphone.

Video name base Enter desired text. For example, if you change the name to

SkiTrip, then your video clips will be named SkiTrip; SkiTrip(01);

SkiTrip(02), etc. until the default name is changed.

Video storage Choose whether video clips are stored in phone memory or on

miniSD Card.

File Duration Choose a fixed size for recorded clips, or unlimited size.

Video quality Choose Low or High.

X700_OI.book Page 72 Wednesday, September 1, 2004 6:47 PM

CONNECTIVITY

Browse the Internet. View and manage your phone’s connections to other devices that

can be connected to the phone, wirelessly and by cables. Synchronise your Contacts

and Calendar entries with your other networked devices. Your network, Internet, e-mail

service providers can help you configure and manage your connection settings using

Device Manager. View your active connections using Connection Manager.

Connectivity menu contains these main options:

BROWSER

Your phone has an XHTML configured wireless Internet browser, allowing you access to

services such as news, weather reports, banking, sports, travel information and stock

quotes.

Wireless web sites are designed to be viewed on mobile phone screens, so they consist

mostly of text and may contain simple graphics. Wireless sites are written in Wireless

Markup Language (WML) and XHTML (Extensible Hypertext Markup Language), which

is different than Hypertext Markup Language (HTML) used in computer Internet

websites and cannot be accessed by wireless phones.

Your phone browser can access WAP 2.0 sites and download games, sound, software,

WBMP images, vCard and vCalendar events and more.

Types of Data Connections

GPRS and data call (CSD) data bearer technologies are used to access the Internet.

GPRS is General Packet Radio Service, a packet based high speed data transfer

technology that allows continuous connection, in which many users share a connection

and packets are transferred only as needed.

Data call, or CSD, is Circuit Switched Data, which uses a dedicated connection much

like ordinary voice phone service.

Browser Operator Modem

Bluetooth Infrared USB

Conn Mgr SyncML Dev Mgr

Note: The types of services and content offered when connected to the

Browser are supplied entirely by your wireless service provider.

X700_OI.book Page 73 Wednesday, September 1, 2004 6:47 PM

SETUP TO CONNECT TO BROWSER

Before starting; (1) you need a subscription for data services from your wireless service

provider and (2) you must configure an Internet Access Point.

Your wireless service provider may have already completed the Internet Access Point

connection settings, or sent them to you in a message. Contact your wireless service

provider to find out how setup information is furnished.

If you are setting up the Internet Access Point, see page 95.

CONNECT TO THE INTERNET

There are two main ways to store shortcuts to wireless Internet sites. (1) Bookmark list

stores web addresses that you or your wireless service provider saved to the list.

(2) Saved Pages list stores actual WAP pages that you can view online or offline.

From Connectivity application:

1. Open Browser.

2. A list of Internet Access Points and bookmarks appears, and folders may appear.

Your wireless service provider may have loaded links to their services that appear

as bookmarks. Scroll to the desired connection or bookmark and select.

• You can also scroll for the Saved pages list , which stores WAP pages

that you can view offline, and launch to refresh pages.

3. The phone begins connection process.

NAVIGATE THE INTERNET

In general, when connected to the Internet through the Browser:

Shortcut: Press to launch Browser.

Note: Your wireless service provider may have set your phone to go to

the Home page for their services when you launch Browser.

Scroll up , down , left or right by pressing outer edges of

navigation key through the page content.

Select a highlighted item or launch an underlined web page.

Press and hold to open Bookmarks list.

Erase character.

Back - Go backward in navigation history.

Close - Go to Bookmarks or Saved pages view.

Cancel - Ends current download.

Press and hold to disconnect the Browser at any time.

Indicates secure online browsing connection.

X700_OI.book Page 74 Wednesday, September 1, 2004 6:47 PM

Secure Connections

A secure connection means that the connection to transmit data between the phone and

the network server has been secured and encrypted. Your wireless service provider is

responsible for securing the connection between the network server and Internet sites.

Ask your wireless service provider for details of their secure connection capabilities.

Proceed with caution when downloading files and content or entering sensitive

information.

Online Options

During an Internet connection, you can add and refresh bookmarks, reload pages, and

view active session details.

Press Options and select:

Note: If you go to a site with many graphics, it may take longer for the images to load.

To stop images from loading, see Show images setting on page 77.

Open Open highlighted link.

Accept Accept your text entry to the current page.

Service options > Open a list of commands or actions for the page.

Bookmarks View Bookmarks list.

Save as bookmark Save the web address to your Bookmarks.

View image If there are images on the page, open a list of images. To view a

specific image, scroll to the image and press OK.

Navigation options > Go to web address, History to select a previously viewed page

during current session, Clear cache to delete content in cache

memory, Reload to update current page.

Advanced options > Original screen to fit page into the display of your phone, Save

page to save current page to Saved pages list, Disconnect to

end connection.

Show images Appears if you have set the Show images setting to No in the

Browser settings to allow the images on current page to load.

Send bookmark > Send current page via text message.

Find > Find phone number, e-mail address or web address on current

page. Start typing for Find field to appear.

Details View details and security of current session.

Settings See Browser Settings on page 77.

Service msg. Appears if you have unread WAP push messages.

X700_OI.book Page 75 Wednesday, September 1, 2004 6:47 PM

When online, you may have calling options from a current page. You can click on a link

to book tickets or order gifts, for example. The link allows you to make a phone call

directly from the browser.

When viewing any Directory services an ‘Add to Contacts’ link may appear. Click on the

link, and a new Contacts entry form displays. Save the entry to return to the browser.

Disconnect from Internet

To disconnect from the Internet, either press and hold , or press Options and select

Disconnect.

BOOKMARK OPTIONS

Manage your bookmarks when offline or online.

From Connectivity application:

1. Open Browser.

2. Press Options and select:

DOWNLOAD FILES FROM THE INTERNET

You can download ringtones, games, video and sound clips, and applications to your

phone through the Browser. After downloading, the files are saved to the relevant menu

application in the phone.

From Connectivity application:

1. Open Browser.

2. Scroll to Download Applications, Download Images, Download Skins,

Download Sounds, or Download Videos, and open.

Download Connect to selected bookmark.

Bookmark manager > Move to folder, New folder, Edit bookmark, Add bookmark,

Delete.

Mark/Unmark > Select Mark or Mark all to perform actions to multiple items.

Navigation options > Go to web address or Clear cache.

Advanced options > Add to Favourites to add the bookmark to your Favourites

shortcuts.

Send > Send web address to another device.

Find bookmark Type in one or two characters to go to bookmark titles beginning

with that character

Settings See Browser Settings on page 77.

Note: This feature may not be available.

X700_OI.book Page 76 Wednesday, September 1, 2004 6:47 PM

3. Scroll to desired bookmark if there is more than one, then open the bookmark. The

phone begins connection process.

4. After connecting to the site, scroll to desired hotlink containing the file and open.

5. After the file is downloaded, it is stored in the menu application in which the file is

opened; for example, a video clip is stored in Gallery.

BROWSER SETTINGS

Check your default access point, specify if you want images to be automatically loaded,

and allow cookies to be stored on the phone.

From Connectivity application:

1. Open Browser.

2. Press Options and select Settings to reach:

Note: Panasonic is not responsible for the performance of downloaded content

or possible corruption of phone software.

The phone may not allow you to copy, modify, transfer or forward some

copyrighted images, ringtones or other content.

Default access point Change default access point for connecting to the Internet

through the Browser

Show images For faster Internet surfing, select No to stop images from auto-

matically loading. When online, press Options and select Show

images on a specific page to load an image.

Font size Select a font size for web page text to appear

Default encoding For the Browser pages to display text characters correctly, select

one from: S. Chin., West. Europ., T. Chinese, Unicode (UTF-8),

Central Eur., Baltic, Cyrillic, Greek, Turkish, Heb. (ISO-Logical),

Hebr. (ISO-Visual), Arabic (ISO), Arabic (Windows), Hebr. (Win-

dows), Cent. Eur. (Wind.), Cyrillic (Windows), Greek (Windows),

Turkish (Wind.), Baltic (Windows) or Automatic.

Cookies Choose Allow to store cookies, which are short text files that a

web server places on your phone for purposes such as present-

ing customised web pages to you.

Security warnings Choose Show or Hide for secure site notification

Conf. DTMF sending Select whether to First time only or Always before sending

DTMF touch tones during a call when online.

X700_OI.book Page 77 Wednesday, September 1, 2004 6:47 PM

SAVED PAGES

Saved pages are web pages and folders you have stored on the phone to view offline.

From Connectivity application:

1. Open Browser.

2. Scroll to open the Saved pages tab .

3. Scroll to the desired page and select.

4. Press Options and select:

OPERATOR MENU

Your network operator may offer services that you can view using the Browser. Contact

your network operator for availability and types of services offered.

From Connectivity application:

1. Open Operator.

2. In the page, press Options and select:

Open View saved page or open folder.

Back to page Return to page you visited before opening Saved pages.

Reload Download and store the latest version of the saved page.

Saved pages mngr. > Move to folder to move a saved page to a different folder, New

folder, Rename or Delete.

Mark/Unmark > Select Mark or Mark all to perform actions to multiple items.

Navigation options > Clear cache to delete content in cache memory.

Advanced options > Add to Favourites to create shortcut to page from Favourites

application.

Settings See Browser Settings on page 77.

Open Open highlighted link.

Close browser Disconnect from your operator’s service pages.

Navigation options > Go to web address to go to new address, History to select a

previously viewed page during current session, Reload to

update current page.

Advanced options > Original screen to fit page into the display of your phone, Save

page to save current page to Saved pages list, Disconnect to

end connection.

Find > Find phone number, e-mail address or web address on current

page. Start typing for Find field to appear.

Details View details and security of current session.

Settings See Browser Settings on page 77.

X700_OI.book Page 78 Wednesday, September 1, 2004 6:47 PM

MODEM

You can link together your X700 phone as a modem to a computer or a PDA to access

the Internet.

Link your phone and computer to access the Internet

To use the X700 phone as a modem there are three options; connect using the infrared

port, connect using Bluetooth, or connect using the Panasonic USB Data Cable (EB-

UCX71). See Accessories on page 132 for USB Data Cable information.

Prerequisites

• Set up a dial-up account with an Internet Service Provider (ISP).

• From your ISP, you need the installation CD or your account details (i.e. dial-up

number, user name, password, DNS server addresses) to configure Dial Up

Networking.

• When setting up your Internet account for the first time, select X700 as the

connecting modem device. For more details, contact your ISP. For help using

Windows® Dial Up Networking, search Windows® Help files.

Install X700 as Modem on Computer

The following describes how to set up a computer to connect to your X700. The

procedure described may differ for other software packages.

To install your phone as a modem on a computer, here is an example. On the computer,

select Start > Settings > Control Panel > Modems > Add > Other > Don’t detect my

modem > Standard 33600 bps modem > Communications Port > Virtual Com Port. For

specific instructions on your computer’s operating system, refer to your computer’s on-

line help.

Set Up Connection

From Connectivity application:

1. Open Modem.

2. Align the infrared port of your phone with the infrared port of the computer.

3. Select Connect via infrared, which opens the infrared connection.

• To use Bluetooth, you must start the Bluetooth connection from the computer or

device to which you are connecting. To prepare your phone to connect via

Bluetooth, see Set up Bluetooth on page 81.

• To use USB data cable, you must start the connection from the computer or

device to which you are connecting.

Note: This info may be on CD-ROM.

Note: If connecting with a data cable, select Com 1 in the Communications Port field.

X700_OI.book Page 79 Wednesday, September 1, 2004 6:47 PM

4. The phone confirms when a connection is established.

• If Bluetooth connection is successful, when you select Connect via infrared, the

phone will state that the modem is already in use by Bluetooth.

Make Connection to Internet

1. Now you can create a new GPRS connection. For example, on the computer, select

Start > Programs > Accessories > Communications > Dial-Up Networking > Make

New Connection. For specific instructions, see your computer’s on-line help.

2. Enter X700 as the name you are dialling, and choose Standard 33600 bps Modem

as the device then select Next. Choose 115200 as the Maximum speed. In the

telephone number field, enter *99# then click Finish.

3. You will now have an X700 connection icon in the computer’s connection screen.

Double click the icon and select Connect to begin the connection.

BLUETOOTH® WIRELESS TECHNOLOGY

Bluetooth wireless technology uses radio waves to communicate with other Bluetooth

devices within a maximum range of 10 metres. You can send and receive business

cards, pictures, Calendar events, video and sound clips, and other data between

Bluetooth devices such as mobile phones and computers.

Use a Bluetooth headset to talk wirelessly on your phone whilst the phone is in your

pocket or purse.

This phone supports Bluetooth v1.1 connectivity with the following profiles: Serial port,

Dial-up networking, Object push, File transfer, Headset, and Handsfree.

Note: To close the connection, press Disconn. softkey. If there is

an on-going data call, the call is ended first.

Note: Although Bluetooth devices can connect within a 10 metre range, walls or

other nearby barriers may cause interference.

Check with local authorities before using Bluetooth wireless technology

as some countries may restrict the use of Bluetooth devices.

Battery note: Keeping Bluetooth setting “On” consumes battery power more

rapidly. To conserve battery power, switch off Bluetooth setting

when not in use. Switch Bluetooth on or off in Settings.

X700_OI.book Page 80 Wednesday, September 1, 2004 6:47 PM

SET UP BLUETOOTH

You must first set up Bluetooth connections before using it for the

first time. Thereafter, go to the Settings tab to switch Bluetooth

setting on or off and change your phone’s visibility to other Bluetooth

devices.

From Connectivity application:

1. Open Bluetooth.

2. In the Settings tab, open fields:

PAIR WITH OTHER DEVICE AND CONNECT

From Connectivity application:

1. Open Bluetooth.

2. Scroll to Paired devices tab.

3. Ensure that the device in which you want to pair is switched on, and its Bluetooth

setting is activated.

4. Press Options and select New paired device. If Bluetooth setting is switched off,

press Yes to switch on Bluetooth setting.

5. The phone begins searching for devices and notifies you when it finds the other

device.

6. Press Select. Enter the passcode for the connecting device if needed and press

OK. If the other device has not yet been paired, first decide on a passcode with the

other person, then enter it when requested, press OK.

7. To connect with the device, open the device name and select Connect.

Bluetooth Select On or Off.

My phone’s visibility Choose Shown to all to allow other Bluetooth devices to find

your phone when searching, or select Hidden to keep other

Bluetooth devices from finding it during a search.

Visibility Timeout Choose Disabled to keep My phone’s visibility setting as

Shown to all, or scroll to select a time period after which your

phone cannot be found by other Bluetooth devices (My phone’s

visibility setting changes to Hidden).

My phone’s name Use the default name or enter a name for your phone that other

devices will see when they search for your phone.

My Transfer Speed Choose Normal, Fast, or Very Fast.

Note: The passcode may be stated in the connecting device user guide.

X700_OI.book Page 81 Wednesday, September 1, 2004 6:47 PM

SEND AND RECEIVE DATA VIA BLUETOOTH

You can send and receive Contacts cards as business cards, Calendar events, pictures,

video and sound clips, bookmarks, configuration messages, and receive applications

supported by the phone via Bluetooth.

To send data via Bluetooth:

1. Ensure that the device in which you want to pair is switched on, and its Bluetooth

setting is activated. On your phone, go to the application menu that contains the

data you wish to send, for example, go to Contacts to send a business card.

2. Highlight the desired item to send.

3. Press Options and select Send > Via Bluetooth. If Bluetooth setting is switched

off, press Yes to switch on Bluetooth setting.

4. The phone automatically searches for Bluetooth devices nearby.

• Devices appear one-by-one. If device has already been paired, icon appears

with device name. Press Stop to stop search when intended device name pops

up.

• If the other device has not yet been paired, first decide on a passcode with the

other user, then enter it when requested, press OK.

5. Scroll to the intended device and select. Connecting message appears, then when

other device accepts, a confirmation message displays when transfer is complete.

• If the other device does not accept the data, Bluetooth connection cannot send

the data.

To receive data via Bluetooth:

1. Press Show to accept the incoming message containing the data. (If phone is not in

standby mode, Show does not appear.) The message is placed in the Inbox in

Messages.

2. Open the message, press Options and select Save to save data to phone memory

or miniSD Card. You can rename the file.

MANAGE PAIRED DEVICES

From Connectivity application:

1. Open Bluetooth.

2. Scroll to Paired devices tab and scroll to desired device.

3. Press Options and select:

Note: The phone may not allow you to copy, modify, transfer or forward

some copyrighted images, ringtones or other content.

Note: Confirmation is required first if the paired device is not set as authorised.

New paired device Search for nearby Bluetooth devices.

Assign short name Change name of paired device to an easily recognised name.

X700_OI.book Page 82 Wednesday, September 1, 2004 6:47 PM

Icons of paired devices

INFRARED

Transfer data between your phone and other infrared enabled devices using an infrared

wavelength connection. You can also use infrared connections for GSM data services,

and access the Internet and e-mail via other devices.

PREPARE FOR INFRARED CONNECTION

Place your phone and the other device within the effective range of the infrared

connection, about 20 cm.

• Verify there are no obstructions between the two devices.

• Ensure that the infrared ports of the devices point at each other.

• On the receiving device, activate the Infrared port.

• If the other device is a computer, you need to set up infrared connection on the

computer. For example, in Windows, select Start > Settings > Control Panel >

Options tab > Enable Infrared Communication. For specific infrared set up

instructions for your computer’s operating system, refer to the computer’s on-line

help.

Set as authorised or

Set as unauthorised

Allow automatic connection without manually accepting each

time, shown by icon. Unauthorised setting requires confirma-

tion each time the device attempts to connect to the phone.

Delete Delete the paired device from your list.

Delete all Delete all paired devices.

audio computer phone miscellaneous

Note: Multiple devices can be paired; however, only one active connection

is possible at any given time.

Note: The phone may not allow you to copy, modify, transfer or forward

some copyrighted images, ringtones or other content.

Caution: This device contains a low power level Class 1 laser product

(Infrared LED), which will not normally harm the eyes. Though

invisible to the eye, do not point the infrared beam at anyone’s

eye. Nearby activated infrared devices may cause interference.

Note: For Windows® 2000 users, to enable infrared use to transfer files,

go to Start > Settings > Control Panel > Wireless Link. In the File

Transfer tab, check ‘Allow others to send files to your computer

using infrared communications’.

X700_OI.book Page 83 Wednesday, September 1, 2004 6:47 PM

SEND AND RECEIVE DATA VIA INFRARED

You can send and receive Contacts cards as business cards, Calendar events, pictures,

sound clips, bookmarks, configuration messages via infrared, and receive applications

supported by the phone.

To send data via Infrared:

1. Prepare for infrared connection as described on page 83.

2. Go to the application menu that contains the data you wish to send, for example, go

to Contacts to send a business card.

3. Open the item you wish to send.

4. Press Options and select Send > Via infrared.

5. The phone automatically begins infrared connection, indicated by flashing .

Whilst transferring, icon is steady. A confirmation message displays when complete.

To receive data via Infrared:

1. Prepare for infrared connection as described on page 83.

2. From Connectivity application, open Infrared.

3. Flashing icon displays, meaning phone is ready to receive data.

4. Sender can begin transfer of data. A tone sounds when transfer is complete.

5. Press Show to accept the incoming message containing the data. The message is

placed in the Inbox.

6. Open the message, press Options and select Save to save data to supporting

application. You can rename the file.

• If transfer does not begin within 40 seconds, the infrared connection

automatically stops.

USB

Connect to PC Software Suite over your USB cable using USB application.

CONNECT TO PC SOFTWARE SUITE

1. Plug in USB cable into the phone.

2. From the Connectivity application, open USB.

3. USB icon appears indicating that USB connectivity has started.

4. On your computer, begin desired task such as backup or sync.

CONNECT TO MODEM

1. Plug in USB cable into the phone.

2. From the Connectivity application, open Modem.

3. Select Connect via USB.

4. USB icon appears indicating that USB connectivity has started.

5. On your computer, start a connection using the phone as a modem.

X700_OI.book Page 84 Wednesday, September 1, 2004 6:47 PM

CONNECTION MANAGER

View status, speed, and amount of data transferred for all of your currently active GPRS

and Data call network connections.

VIEW CONNECTION DETAILS

From Connectivity application:

1. Open Conn Mgr.

2. A list of currently active network connections appears, sorted according to starting

time of connection.

3. Scroll to desired connection, press Options and select Details to view name, bearer

(GPRS, data call), status (creating connection, idle, active, on hold, closing

connection or closed), received and sent data amount in bytes, duration, downlink

and uplink transfer speed in kb/sec, dial-up number (data call only), GPRS access

point name (GPRS only), sharing.

END CONNECTIONS

From Connectivity application:

1. Open Conn Mgr.

2. A list of currently active network connections appears, sorted according to starting

time of connection.

3. To end one connection, scroll to desired connection, press Options and select

Disconnect.

To end all active connections, press Options and select Disconnect all.

• If you are ending all connections, the Data call connections are closed first, then

the GPRS connections close in the same order as established.

SYNCHRONISATION

Set up profiles and synchronise your Contacts and Agenda (Calendar) entries with your

other networked devices.

CREATE A NEW SYNC PROFILE

From Connectivity application:

1. Open SyncML.

2. If there are no profiles, select Yes to create a new profile. Or, press Options and

select New sync profile, press Yes.

Note: GPRS connection cannot be closed if it is currently

suspended due to circuit-switched activity.

X700_OI.book Page 85 Wednesday, September 1, 2004 6:47 PM

3. Enter information in fields. Fields marked in the phone with a red asterisk (*) must

have an entry.

4. Next, scroll to move to Content tab.

5. For each field, press Options and select Change, select Yes.

6. Open Remote database and enter location on the network of each of the

databases.

7. Open Synchronisation type and choose if you want to synchronise in both

directions (Normal), from server to phone (To server only), or from phone to server

(To phone only) for each database.

SYNCHRONISE

If you are synchronising from the server to the phone, you will receive a message in the

Messages Inbox. When you open the message, you are asked if you wish the server to

begin the synchronisation process. If you accept, the process automatically begins.

To begin synchronising from the phone, from Connectivity application:

1. Open SyncML.

2. Highlight desired profile, press Options and select Synchronise.

During synchronisation from either direction, you can follow the process on the phone.

The phone confirms completion.

To cancel synchronisation, press Cancel.

If synchronisation fails, for example, the sync server is busy or the database cannot be

opened, you are notified of the error type.

VIEW OR EDIT SYNC PROFILES AND CONTENT

From Connectivity application:

1. Open SyncML.

2. Highlight desired profile, press Options and select Edit sync profile.

3. Scroll to desired fields to view and open to edit.

If a profile has been synchronised, press Options and select View log to view profile

name; remote server name; date, time, and status of last synchronisation, and details of

content transfer.

* Sync profile name Enter a name if not assigned.

Access point Select desired access point name.

* Host address Enter web address of sync server.

Port Enter port number of sync server.

User name Type your user name for the server.

Password Type in password.

X700_OI.book Page 86 Wednesday, September 1, 2004 6:47 PM

To view or edit the Content settings, scroll to view the Content tab and continue with

step 6 in Create a New Sync Profile on page 85.

DEVICE MANAGER

Your network, Internet, e-mail service providers can help you configure and manage

your connection settings. These settings can be sent to your phone over the air. Device

Manager menu allows service providers to configure and update these settings from

their servers on your behalf. Settings may include network access points, multimedia, e-

mail, and synchronisation connections.

CONFIGURATION SESSION

A configuration session can be started either from the Device Manager application in the

phone, or from the service provider’s server.

If your service provider intends to start a session, your phone will show a server alert

message. Before the session can begin, your phone asks to activate the server

connection and the profile if they are off. Then the phone asks you to accept that the

server is ready to configure. If you don’t want the session to run, press Reject or

Cancel.

Once the configuration session begins, the phone displays status notes advising the

session stage: connecting to the server, receiving data from the server, processing data,

and disconnection.

To start a configuration session yourself (if server profile is set up), from Connectivity

application:

1. Open Dev Mgr.

2. Scroll to desired server profile in which you wish to start configuration session.

3. Press Options and select Start.

CREATE A NEW SERVER PROFILE

The server profile is the settings needed to connect your phone to a service provider’s

device management server, which handles the configuration session procedure.

From Connectivity application:

1. Open Dev Mgr.

2. If there are no profiles, select Yes to create a new profile. Or, press Options and

select New server profile.

Note: If you set the server profile to accept configuration sessions

without verification, then the session will begin in the background.

View the process by opening Device Manager application.

X700_OI.book Page 87 Wednesday, September 1, 2004 6:47 PM

3. Enter information in fields. Fields marked in the phone with a red asterisk (*) must

have an entry.

VIEW OR EDIT SERVER PROFILES

From Connectivity application:

1. Open Dev Mgr.

2. Scroll to desired server profile, press Options and select Edit profile, or Delete.

View Session Log

To view the results of a selected server’s last configuration session, from Connectivity

application:

1. Open Dev Mgr.

2. Scroll to desired profile, press Options and select View log.

The log shows name of server configured, results of configuration, date and time, and

errors if any occurred during configuration.

SHORTCUT TO STOP CONFIGURATION SESSIONS

There may be times in which you do not want configuration sessions to run. Instead of

going to each server profile to set Active to not allow device management to be done by

the server, you can set the phone so that device management cannot be done by any

server.

The default setting is to allow device management to be done (Enable configurations).

* Server name Use suggested name or enter your own.

* Server ID Server’s unique ID identifies the remote server.

Server password Server password supplied by service provider so your phone

can verify server.

Access point Select desired access point.

* Host address Server’s web address.

Port Server’s port number.

* User name Type in your user name for the server.

Password Device Manager password supplied by service provider so the

server can verify your phone.

Allow configuration Select Yes to allow device management to be done by this

server.

Accepted Select Yes to allow device management to be done by this

server without Accept command.

X700_OI.book Page 88 Wednesday, September 1, 2004 6:47 PM

From Connectivity application:

1. Open Dev Mgr.

2. Press Options and select Disable config..

• All server profiles are disabled and no configurations can be done.

To allow configurations to be done again, press Options and select Enable config..

X700_OI.book Page 89 Wednesday, September 1, 2004 6:47 PM

SETTINGS

Choose your ringtone and theme settings here. Configure your phone, call, connection,

security, call divert, barring, GSM network, and accessory settings. Set the clock,

alarms, and speed dial shortcuts.

Settings menu contains these main options:

RINGTONES

Ringtone profiles are unique ringing tone, alert tones, and volume settings used to alert

you to calls and messages. Choose from General, Silent, Meeting, Outdoor, and

Pager. Each can be modified to suit your situation. You can use ringtones sent in a

message, sent by Bluetooth or infrared connections, recorded with the Recorder

application, or downloaded.

The active ringtone name is displayed in the standby screen, except when General is

active.

ACTIVATE A RINGTONE

From Settings application:

1. Open Ringtones.

2. Scroll to the desired ringtone.

3. Press Options and select Activate.

CHANGE RINGTONES, ALERT TONES AND VOLUME

You can change, or personalise, individual settings within a ringtone. For example, in

General ringtone, change the ringing tone to a ringing tone you downloaded.

From Settings application:

1. Open Ringtones.

2. Scroll to the desired ringtone.

3. Press Options and select Personalise.

Ringtones Themes Settings

Clock SpeedDial Voice

PB Setup About

Note: Free content is available for your X700 phone. For downloading information, visit

www.panasonicbox.com. Availability of this service is dependent on your country/

region or network. The downloaded content is free, however there will be a

communication fee to download.

X700_OI.book Page 90 Wednesday, September 1, 2004 6:47 PM

4. Scroll to the desired setting:

Ringing and Alert Tone Volume

Ringing and alert tones play only when the phone’s current ringtone is General or

Outdoor. The other ringtones mute playing of ringing tones.

To change the volume of tones when scrolling through the list, go to the Ringing

volume field and adjust volume.

THEMES

Change the visual look of your phone screens without changing the way the phone

works by using Themes. Themes are wallpapers, text and icon colours and sets

packaged in a theme. Themes, or skins, are preinstalled when you purchase your

phone, or you can download and install them yourself.

PREVIEW THEMES

From Settings application:

1. Open Themes.

2. Scroll to the desired theme name.

3. Press Options and select Preview.

Ringing tone Scroll through list of tones. To hear the tone, highlight the tone

name and wait. To stop the tone, press any key. To select a tone,

highlight the tone name and press Select. If you have sub-

scribed to 2 lines, then a setting appears for each line.

Ringing type Choose Ringing, Ascending, Ring once, Beep once, or

Silent.

Ringing volume Scroll to move the volume bars.

Message alert tone Same as Line 1 ringing tone.

Vibrating alert Select On or Off.

Keypad tones Select Off, Level 1, Level 2, or Level 3.

Warning tones Select On or Off.

Alert for If you have set up Contacts groups, select the desired group

name if you want the phone to ring only when members of that

group call. Other incoming calls will have the silent alert.

Profile name Change the name of any ringtone except General.

Note: Free content is available for your X700 phone. For downloading information, visit

www.panasonicbox.com. Availability of this service is dependent on your country/

region or network. The downloaded content is free, however there will be a

communication fee to download.

X700_OI.book Page 91 Wednesday, September 1, 2004 6:47 PM

ACTIVATE A THEME

From Settings application:

1. Open Themes.

2. Scroll to the desired theme name.

3. Press Options and select Apply.

• When previewing, press Apply to activate the theme.

CHANGE WALLPAPER OR SCREENSAVER

Change the background image of the standby screen or Favourites screen, the colour of

bars and frame boxes, and the screensaver.

From Settings application:

1. Open Themes.

2. Press Options and select Edit; or to edit a specific theme, first scroll to desired

theme before pressing Options:

DOWNLOAD NEW THEMES

You can download themes directly from predetermined web sites without first going to

the Browser application. These links are set by agreements with content providers who

offer the themes.

From Settings application:

1. Open Themes.

2. Press Options and select Theme downloads.

3. A folder displays, containing links to content provider web pages.

• You can add your own links to the folder.

4. Open the folder and scroll to and open desired link.

Note: The appearance of some icons may change when you apply a different theme.

Idle state wallpaper Idle screen. Choose from Default, User defined (your own

image from Gallery or downloaded), other themes, or None.

Colour palette Choose from the default colour or other listed colours for com-

mon bars, icons, and frames.

Screen saver Choose Date and time(Default), or Text (write your own text

message).

Icons Choose from a list of theme set of icons.

Favourites wallpaper Favourites. Choose from Default, User defined (your own

image from Gallery or downloaded), other themes, or None.

Note: When the copy option appears, you can copy themes from

the phone memory to the miniSD Card or in reverse.

X700_OI.book Page 92 Wednesday, September 1, 2004 6:47 PM

5. Connection to the Browser will begin.

SETTINGS

In the Settings menu, you can configure your phone, call, connection, date and time,

security, call divert, barring, GSM network, and accessory settings.

PHONE SETTINGS

Set the phone language, writing language, and welcome note or

logo here.

From Settings application:

1. Open Settings.

2. Open Phone.

3. With General highlighted, open to select:

Display Settings

Adjust the brightness of the display screen and set a screen saver timeout.

From Settings application:

1. Open Settings.

Note: Some links may be preset by content providers and cannot be deleted.

Phone language Choose a language in which the texts on the displays will

appear. Automatic uses the language dictated by the SIM card.

Writing language Choose a language in which the texts you are writing will

appear, for example, writing a text message.

Dictionary Select On to use the predictive text dictionary to speed up text

entry.

Welcome note or

logo

Default uses the welcome note or image supplied with the

phone, displayed when the phone is switched on. Select Text to

enter your own welcome note. Select Image to place an image

from Media Gallery.

Shutdown animation Select Off to stop the animation shown after switching off the

phone.

Keypad backlight

time

To save battery life, select Always off for the keypad backlight

to remain off.

Orig. phone settings Used if a network operator used settings protection in a phone,

and later there is a reason to change the protected settings.

Requires lock code.

X700_OI.book Page 93 Wednesday, September 1, 2004 6:47 PM

2. Open Phone.

3. Scroll to Display and open. Select and open:

Standby Mode Settings

Choose an application name to display on the left and on the right softkey in standby

mode to use as shortcuts to the respective applications.

From Settings application:

1. Open Settings.

2. Open Phone.

3. Scroll to Standby mode and open. Select and open:

Left selection key Scroll to desired application, press OK.

Right selection key Scroll to desired application, press OK.

CALL SETTINGS

From Settings application:

1. Open Settings.

2. Scroll to Call and open.

3. Scroll to:

Brightness Scroll to lighten the screen, or scroll to darken the screen,

then press OK.

Screen saver timeout Scroll or to choose from 1 minute to 30 minutes of no

activity until screen saver switches on and press OK.

Send my caller ID Choose Set by network, Yes or No. Determines if your mobile

number is presented to the person you are calling. Network

dependent.

Call waiting Press Options and select Check status. If needed, select Acti-

vate. Network will send confirmation message. When activated,

if you are on a call and there is an incoming call, you can put the

first call on hold and answer the second call. See Call Waiting on

page 20.

Automatic redial Select On to redial if the call is not connecting. Press to stop

automatic redialling.

Summary after call Select On to display a brief summary of duration of last call.

Speed dialling Select On to start dialling by a press and hold of preset number

key in standby mode. First, set up Speed dial keys in Settings

(see Speed Dial on page 105).

Anykey answer Select On to answer incoming calls by pressing any key except

, , or .

X700_OI.book Page 94 Wednesday, September 1, 2004 6:47 PM

CONNECTION SETTINGS

Access Point Settings

Access points are sets of configurations that connect your phone to the Internet and

other services. Your phone uses three main sets of access points: Multimedia (MMS),

Browser, and Internet. Access points must be set up in order to send and receive

multimedia and e-mail messages, use the Browser, use SyncML, use Device Manager,

use your phone as a modem, and download.

Access points use data services to connect. Types of data services your phone can

support are: Data call (Circuit switched data) and GPRS (Packet data). Contact your

wireless service provider to find out about types of data technologies offered and

subscription rates.

Some or all of your access points may be preset in the phone by your wireless service

provider and cannot be modified. The access point configurations may be sent to you in

a smart message by your wireless service provider. You may also be able to add new

access points.

To view, edit, or add new access points, first you must obtain the configurations from

both your wireless and Internet service providers to be entered into the phone.

From Settings application:

1. Open Settings.

2. Scroll to Connection and open.

3. Open Access points to view a list of existing access points.

• D icon indicates data call. G icon indicates GPRS packet data connection.

4. To add a new access point, press Options and select New access point > Use

default settings or Use existing settings. Either build a new access point from

preset default settings, or use an existing access point to edit as needed.

• To edit an access point, press Options and select Edit.

Active clamshell Select On to answer a call by opening the flip clamshell and to

disconnect phone calls by closing the flip clamshell. When set to

Off and you close the flip clamshell during a call, the caller’s

voice switches to the back loudspeaker.

Line in use This setting appears if you have subscribed to Alternate Line

Service, in which you can have two different phone lines with the

same SIM card. Select Line 1 or Line 2.

Line change This setting appears if you have subscribed to Alternate Line

Service (see Line in use setting). You can disable selection of

one of the phone lines. The PIN2 code is required to return use

of a previously blocked line.

X700_OI.book Page 95 Wednesday, September 1, 2004 6:47 PM

5. Enter information in fields. Fields marked in the phone with a red asterisk (*) must

have an entry. The bearer type you choose determines which fields are presented.

6. From main fields, press Options and select Advanced settings to enter:

* Connection name Enter an easy-to-recall name if not assigned.

Data bearer Select GPRS or Data call.

* Dial-up number

(Data call only)

Enter access point dial-up phone number.

Access point name

(GPRS only)

Enter name supplied by service provider.

User name Type a user name, supplied by service provider, if required.

Prompt password To have the phone ask for the password each time you log on,

select Yes.

Password Type in password, supplied by service provider, if required.

Authentication Select Normal or Secure.

Homepage Type in Internet web address of service.

Data call type

(Data call only)

Determined by your wireless and Internet service providers.

Maximum data speed

(Data call only)

Choose a limit for your connection speed if you are charged

more for higher speeds.

Phone IP address Enter IP address assigned to your phone, if static or dynamic.

Service provider determines if IP address is static or dynamic.

Primary name server Type in primary domain name server IP address.

Second. name server Type in secondary domain name server IP address.

Proxy serv. address Enter the proxy server address for access point.

Proxy port number Type in proxy port number for access point.

Use callback

(Data call only)

Select Yes to use dial back servers.

Callback type

(Data call only)

Select Use server no. for callback, or Use other no.

Callback number

(Data call only)

Enter the phone number the callback server should use.

Use PPP

compression

(Data call only)

Select Yes to use PPP (Point-to-Point Protocol) compression.

Use login script

(Data call only)

Select Yes to use login script defined in Login script field.

X700_OI.book Page 96 Wednesday, September 1, 2004 6:47 PM

GPRS Settings

From Settings application:

1. Open Settings.

2. Scroll to Connection and open.

3. Scroll to GPRS and open.

4. Open to edit:

Data Call Settings

From Settings application:

1. Open Settings.

2. Scroll to Connection and open.

3. Scroll to Data call and open.

4. Open Online time. Choose a time period to disconnect from the data call if there is

no activity.

DATE & TIME SETTINGS

Date and time settings can be made from the Clock menu. See Clock on page 103.

(Data call only)

Enter the login script to be used.

Modem initialisation

(Data call only)

If desired, enter a modem initialisation string (AT command

string).

Note: If your wireless service provider has protected some of your

settings, you may not be able to modify them.

GPRS connection Choose When needed to connect to GPRS service only when

you open an application that uses GPRS. After you close the

application, GPRS service will disconnect.

Choose When available to stay continuously connected when

you are in a GPRS service area, in which the GPRS icon

replaces the signal strength icon .

Access point Choose an access point supplied by your service provider to use

the phone as a modem to enable GPRS connection from a com-

puter.

Note: If you selected to attach to GPRS when available and are in

an area without GPRS service, then the phone will attempt

to connect to GPRS service periodically.

X700_OI.book Page 97 Wednesday, September 1, 2004 6:47 PM

SECURITY SETTINGS

Phone and SIM

Your phone and SIM card have security codes that you can use to limit access to the

phone. Keep a written record of your codes in a secure place.

• Enter PIN code to use phone

The PIN and PIN2 codes (4 to 8 digits), issued by your wireless service provider, protect

your SIM card against unapproved use.

If you set PIN code request to On, then the PIN code must be entered each time the

phone is turned on.

The PIN2 code is required to access certain wireless service provider services such as

Fixed dialling and Call costs. If the PIN2 code is blocked, use the PUK2 code to unblock.

The PIN and PIN2 codes affect only the current SIM card as they are stored in the SIM

card, not the phone memory.

From Settings application:

1. Open Settings.

2. Scroll to Security and open. Open Phone and SIM.

3. Scroll to desired setting and select:

• Enter Lock Code to Use Phone

To prevent unapproved use, you can lock the phone. When the phone is locked, the lock

code must be entered before the phone can be used. The phone lock icon indicates

that the phone is locked.

To unlock the phone, enter the lock code. You may be able to dial the local emergency

number and accept incoming calls when the phone is locked.

Activate Phone PIN Select Yes to require entry of PIN code each time the phone is

switched on. Requires PIN code to activate.

PIN code To change PIN code, enter current PIN code, then new PIN

code twice. Press OK.

PIN2 code To change PIN2 code, enter current PIN2 code, then new PIN2

code twice. Press OK.

Note: If PIN or PIN2 code is entered incorrectly 3 times, the SIM card

locks. Contact your wireless service provider for PUK or PUK2

code (PIN unblock key code). If the PUK or PUK2 code is entered

incorrectly 10 times, the phone will not operate. All information

stored in the SIM card is lost and the SIM card must be replaced.

Shortcut: To lock the phone, press and select Lock phone.

X700_OI.book Page 98 Wednesday, September 1, 2004 6:47 PM

From Settings application:

1. Open Settings.

2. Scroll to Security and open. Open Phone and SIM.

3. Scroll to desired method and select:

• Fixed Dialling and Closed User Group

Fixed dialling restricts outgoing calls to ‘fixed numbers’ contained in SIM cards that

support this feature. When switched on, dialling any number not on the Fixed dialling list

is not allowed. Call diverting and sending messages to any numbers not on the list is

also not allowed. The PIN2 code is required to set up and use this feature.

Once you enter Fixed dialling, press Options and select New contact or Add from

Contacts to add a phone number to the Fixed dialling list. You can also call, edit, and

delete numbers in the Fixed dialling list.

Some wireless service providers offer Closed User Group feature, which allows the

phone to make and receive calls only from specific groups. The groups are set up with

your wireless service provider at time of subscription purchase.

From Settings application:

1. Open Settings.

2. Scroll to Security and open. Open Phone and SIM.

3. Scroll to desired method and select:

Autolock period Set the phone to lock after a time period of no activity. Select

User defined to type in time period in minutes. Requires lock

code to set.

Lock code To change lock code, enter current lock code, then new lock

code twice. Record the new code in a safe place. The preset

lock code is 12345.

Lock if SIM changed To prevent the phone from being used if an unknown SIM card is

inserted, select Yes.

Caution: If you change the lock code then cannot recall it, your wireless

service provider cannot identify the code. The phone must then

be reset at an authorised service center.

Fixed dialling Enter PIN2 code. Press Options and select New contact or

Add from Contacts to create the fixed dialling list. Press

Options and select Activ. fixed dialling to activate the service.

Closed user group Select Default to activate the service to the default group previ-

ously set up with your wireless service provider. Select On to

activate another group set up previously.

X700_OI.book Page 99 Wednesday, September 1, 2004 6:47 PM

100

Certificate Management

Certificates are attachments to electronic messages used to verify senders and

recipients of data over nonsecure networks, such as e-mail servers or the Internet. Two

types of certificates your phone stores are authority and personal.

Authority certificates are downloaded to your phone and are used to check server

certificate signatures and to guarantee that the certificate is issued by a certification

authority (CA).

Personal certificates are issued to you by a certification authority.

Certificates are valid for only a fixed time period and must be renewed periodically. To

renew, contact the certificate issuer.

Before downloading or sending confidential information, check the digital signature and

validity period of the browser gateway or server on the certificate.

The phone will issue a note if the browser or server identity is not authentic, or if you do

not have the correct certificate in your phone.

• View Certificates

From Settings application:

1. Open Settings.

2. Scroll to Security and open.

3. Scroll to Certif. management and open.

• A list of authority certificates displays.

4. Press Options and select Certificate details.

• A list displays with details such as issuer, subject, validity period, certificate

location, certificate format, algorithm, serial number and fingerprint.

• Authority and personal certificates will show different information. If the personal

certificate is on an outside server, it will have different details.

5. Scroll to view personal certificates if available.

• Trust Settings

Check whether certain applications (Browser, Application Manager, or Internet) can use

a selected certificate.

Confirm SIM services Select Yes to view confirmation messages sent between your

phone and the network when you are using SIM application tool

kit services.

Delete server You can reset the trusted provisioning server setting if you have

received settings in a message. Contact the service provider

from which you wish to receive new settings.

X700_OI.book Page 100 Wednesday, September 1, 2004 6:47 PM

Panasonic Mobile Communications Development of USA 22A001A GSM PCS Handset w/Bluetooth User Manual X700 OI

Panasonic Mobile Communications Development Corporation of USA GSM PCS Handset w/Bluetooth X700 OI

Contents

operating instructions I

Navigation menu

Namespaces

Views

Navigation
