200

i-mode/i-motion/i-Channel/i-concier

Once you bookmark a frequently accessed site, you can display the page

directly. You can register 300 bookmarks each for i-mode and Full

Browser.

1From the page to be registeredi()

BookmarkAdd bookmarkYES

Select a destination folder.

Function Menu of the URL History List

Compose message You can compose an i-mode mail message with the

highlighted URL pasted to the text.

Go to step 2 on page 146.

You can compose it also by pressing l().

Add desktop icon See page 31.

Set as home URL You can store the site as Home URL of Full Browser.

YES

You can operate this only from the URL History list of Full

Browser.

Delete

Delete (Delete this) YES

Delete selected Put a check mark for URL histories to be deleted

l()YES

Delete all Enter your Terminal Security CodeYES

Saving Web Pages or Sites for Quick

Access

Add Bookmark

1iBookmarkSelect a folder

Select a bookmark to be displayed.

Information

When the number of characters used for a URL exceeds 256 half-pitch characters

(512 half-pitch characters for Full Browser), you cannot store it.

Up to 12 full-pitch/24 half-pitch characters are stored for a title. For longer titles, the

excess characters are deleted. If no title is entered, the URL without “http://” or

“https://” is registered.

Some pages cannot be bookmarked.

Display Web Pages or Sites from a Bookmark

Bookmark Folder list Bookmark list

Function Menu of the Bookmark Folder List

Operate folder

Add folder You can add a new folder. You can add up to nine folders in

addition to each “Bookmark” folder/“Screen memo” folder.

Enter a folder name.

You can enter up to 10 full-pitch/20 half-pitch characters.

Edit folder name Edit the folder name.

You can enter up to 10 full-pitch/20 half-pitch characters.

Delete folder You can delete the folder and all bookmarks and screen

memos in the folder. You cannot delete the “Bookmark” folder/

“Screen memo” folder.

Enter your Terminal Security CodeYES

Ir/ transmission

Send all Ir data See page 387.

201

i-mode/i-motion/i-Channel/i-concier

All transmission See page 389.

No. of bookmarks You can check the number of bookmarks stored in all folders.

Delete all The folders are not deleted.

Enter your Terminal Security CodeYES

Function Menu of the Bookmark List

Compose message You can compose an i-mode mail message with the

highlighted URL pasted to the text.

Go to step 2 on page 146.

You can compose it also by pressing l().

Attach to mail You can send an i-mode mail message with the bookmark

attached.

Go to step 2 on page 146.

Move You can move bookmarks or screen memos to another folder.

Select a destination folderPut a check mark for

bookmarks or screen memos to be movedl()

YES

Edit title Edit the title.

You can edit the title also by pressing m( ) from the

list.

You can enter up to 12 full-pitch/24 half-pitch characters for

a bookmark. If you press Oo( ) with a blank, the URL

without “http://” or “https://” is registered.

You can enter up to 11 full-pitch/22 half-pitch characters for

a screen memo. If you press Oo( ) with a blank, the

screen memo is registered as “No title”.

Copy

Copy URL You can copy the URL of the bookmark.

Select a start point for copying

Select an end point for copying.

See page 436 for how to paste copied characters.

Copy to microSD See page 372.

You can save a displayed page as a screen memo to the FOMA terminal.

You can display the page saved as a screen memo without connecting to

i-mode.

You can save up to 300 screen memos, however, the number of screen

memos you can save decreases depending on the data volume.

1From a page to be savedi()Screen memo

Add screen memoYESSelect a destination folder.

See page 205 when screen memos are stored to the maximum.

Set as home URL You can store the site as Home URL of Full Browser.

YES

You can operate this only from the Bookmark list of Full

Browser.

Add desktop icon See page 31.

Ir/ transmission

Send Ir data See page 386.

transmission See page 388.

No. of bookmarks You can display the number of bookmarks stored in the

displayed folder.

Delete

Delete (Delete this) YES

Delete selected Put a check mark for bookmarks or screen memos to

be deletedl()YES

Delete all You can delete all bookmarks or screen memos stored in the

folder.

Enter your Terminal Security CodeYES

Saving Site Contents

Save as a Screen Memo

202

i-mode/i-motion/i-Channel/i-concier

1iScreen memo

2Select a folderSelect a screen memo.

Use No to check other

screen memos.

Information

Up to 11 full-pitch/22 half-pitch characters are stored for a title. For longer titles, the

excess characters are deleted.

If you save the data acquisition completion display, its data file is saved as well. (You

cannot save the data acquisition completion display for Chaku-uta Full® music files,

for i-motion movies with playable deadline, or for the ToruCa files whose output from

the FOMA terminal is prohibited.) Some data acquisition completion displays cannot

be saved as screen memos. The display except the data acquisition completion

display is saved with a URL of that page of up to 256 half-pitch characters.

When you save SSL pages, their SSL certificates are saved as well.

The contents entered in the text box, or selected with the pull-down menu, check box,

or radio button are not saved to screen memos.

You can save up to 100 Kbytes per page. However, you can save up to 1,024 Kbytes

of the schedule acquisition completion display, up to 500 Kbytes of the i-motion

acquisition completion display, up to 200 Kbytes of the Deco-mail Template

acquisition completion display, up to 20 Kbytes of the Download Dictionary acquisition

completion display, and up to 1 Kbyte of the ToruCa acquisition completion display.

Display a Screen Memo

Screen Memo

Folder list

Screen Memo list

Detailed Screen

Memo display

Information

The page saved as a screen memo has the information at the time it was saved. This

might differ from the latest information on the site.

Function Menu of the Screen Memo Folder List

Operate folder

Add folder See page 200.

Edit folder name See page 200.

Delete folder See page 200.

Security ON/OFF You can set the folder to open only when you enter your

Terminal Security Code.

Enter your Terminal Security CodeYES

The folder changes to “ ”.

To release it, perform the same operation.

No. of memos You can display the number of stored screen memos and

protected screen memos in all folders.

Delete all You can delete all screen memos. The folders will not be

deleted.

Enter your Terminal Security CodeYES

Function Menu of the Screen Memo List

Move See page 201.

Edit title See page 201.

Protect ON/OFF You can protect screen memos not to be deleted. You can

protect up to 150 screen memos, however, the number of

screen memos you can protect decreases depending on the

data volume.

Protected items are indicated by “ ”.

To release protection, perform the same operation.

No. of memos You can display the number of stored screen memos and

protected screen memos in the displayed folder.

Delete

Delete See page 201.

Delete selected See page 201.

Delete all See page 201.

203

i-mode/i-motion/i-Channel/i-concier

Function Menu of the Detailed Screen Memo Display

Compose message You can compose an i-mode mail message also by pressing

l( ). (See page 197)

Edit title See page 201.

Protect ON/OFF See page 202.

Save image See page 203.

Add to phonebook See page 94.

Others

URL You can display the URL of the screen memo.

Certificate See page 197.

Sound effect See page 208.

Retry You can play back the animation or Flash movie from the

beginning.

When a part of the Flash movie is outside the display area,

the Flash movie might not be played back.

Delete YES

You can save the image displayed on a site or screen memo, and then set

it as the Stand-by display, Wake-up display, or another display.

You can save images, frames and marks for Deco-mail as well. You can

save up to 3,500 files in total sharing the memory space with other data

files, however, the number of files you can save decreases depending on

the data volume. (See page 534)

1From a site display/Detailed Screen Memo display

i()Save imageSelect an item.

Save one image . . . . . You can save an image. Select an image to be saved.

Save some images . . You can save multiple images. Select multiple images to

be saved and press l().

Save all images . . . . . Among the images displayed on the site, you can save all

the images that can be saved at one time.

Save BG image. . . . . . You can save the image displayed as a background.

When you perform “Save image”, select an image to be saved.

2YESSelect a destination folder.

For “Save some images”, and “Save all images”, select “Phone” or “microSD”.

When you select “Phone”, the images are sorted and saved into each folder;

Deco-mail pictograms are saved to the “Decomail-pictograms” folder, frames are

saved to the “Frame” folder, marks are saved to the “Stamp” folder, and the

others are save to the “i-mode” folder. See page 374 for the storage location

when you select “microSD”.

See page 205 when images are stored to the maximum.

3When the confirmation display appears asking whether

to set it as a display, select “YES”.

Go to “Set display” on page 347.

Saving Image from Sites

204

i-mode/i-motion/i-Channel/i-concier

You can download the data and files from sites and save them to the

FOMA terminal. You can save some files directly to the microSD card.

You can store melody, PDF file, Chara-den image, Machi-chara image,

Kisekae Tool file, ToruCa file, template, dictionary, and schedule event,

etc.

Information

Up to 36 half-pitch characters are saved for a file name. When the file name is not

specified, a part of the downloaded URL or “imageXXX” (XXX denotes numerals) is

saved as the file name.

Even when an image is displayed on the site, it might not be displayed on the Picture

viewer after saving it to the FOMA terminal.

The image satisfying the following conditions is saved as a Deco-mail pictogram:

・GIF or JPEG image ・Image of 20 x 20 dots

・Image without file restrictions ・Image of 6 Kbytes or less

The image satisfying the following conditions is saved as a frame or a mark:

・Transparent GIF (except animation GIF) ・The extension is “ifm”.

・Image of Stand-by (480 x 854) or smaller

Images of Stand-by (480 x 854), VGA (480 x 640), CIF (352 x 288),

QVGA (240 x 320), QCIF (144 x 176), and Sub-QCIF (96 x 128) are saved as

frames, and others are saved as marks.

You can save up to 100 Kbytes per image via i-mode, or 500 Kbytes per image via

Full Browser.

When you save multiple images or all images at one time, the background image

cannot be saved.

For Full Browser, you cannot save some images. You can save images in BMP

format and PNG format only to the microSD card.

Downloading Data from Sites

■The maximum downloadable size

※1 The memory space is shared with other data files, and the number of files you can

save decreases depending on the data volume. (See page 534)

※2 The number of files you can save decreases depending on the data volume.

1Call up a data downloadable siteSelect a data file.

The data file is downloaded. When downloading is finished, the data acquisition

completion display appears.

For PDF file, when downloading is finished, the PDF file is displayed.

With the PDF file that cannot be displayed unless you download all pages, the

confirmation display appears asking whether to download all pages. Select “YES”

to select the destination folder.

If you have not downloaded all pages of the PDF file, you can additionally

download the remaining pages by using “Download remain”.

See page 393 for how to save the displayed PDF file to the FOMA terminal. You

can save the PDF file containing pages that have not been downloaded or the

PDF file of which download was suspended midway as well.

The password entry display might be displayed depending on the PDF file. Enter

the password, and then select “OK”.

See page 391 for operations while PDF file is displayed.

Categories Maximum size Maximum number of storable

Melody 100 Kbytes 3,500 max.※1

PDF file 2 Mbytes 3,500 max.※1

Chara-den image 100 Kbytes 3

Machi-chara image 2 Mbytes 3,500 max.※1

Kisekae Tool file 2,078 Kbytes 3,500 max.※1

ToruCa file 100 Kbytes 495 max.※1

Template (Deco-mail) 100 Kbytes 100 max.※2

Template (Decome-Anime) 100 Kbytes 100 max.※2

Dictionary 20 Kbytes 10

Schedule event 1 Mbyte 2,500

205

i-mode/i-motion/i-Channel/i-concier

2SaveYESSelect a destination folder.

Chara-den image, template (Deco-mail), and schedule event is stored to the

FOMA terminal.

For Machi-chara image, Kisekae Tool file, and template (Decome-Anime), select

“Phone” or “microSD”.

For dictionary, select “<Not stored>”.

Select “Property” to display the information.

See page 205 when data files are stored to the maximum.

See page 201 to save a screen memo.

3Select “YES” to set the downloaded data file to each

function.

For setting the melody as a ring tone, select an incoming type.

For creating a Deco-mail message or Decome-Anime message by using

template, see page 150 or page 153.

When you press l( ) to suspend downloading or when downloading is

suspended by an incoming call, the confirmation display appears asking whether to

resume downloading.

Select “YES” to resume downloading the remaining part. Select “NO” to show the data

acquisition completion display. You can save by selecting “Save pt.” from the data

acquisition completion display. When you select “Save pt.”, you can save it only to

“Phone”.

You can re-download the rest of the partially saved file from “Kisekae Tool” or

“Machi-chara” in “Data box”.

You can look for your favorite files on the site and download them. The

number of files you can save differs depending on the files you

download. You cannot change the site.

1Each selection displaySearch by i-modeYES

Select a file.

The way of downloading differs depending on the file.

Information

Some downloaded melodies might not be played back successfully.

When downloading Kisekae Tool file or Machi-chara image is

suspended

Search by i-mode

If the maximum number of data files is stored or there is not enough memory when you

try to save the data files, the confirmation display appears asking whether to delete the

unnecessary file and save new one.

Perform this operation to save the following data:

・Images ・i-motion movies ・Melodies

・Chara-den images ・Machi-chara images ・Programs

・Chaku-uta Full® music files ・PDF files ・i-αppli programs

・ToruCa files ・Templates ・Screen memos

・Kisekae Tool files ・Schedule events

1. YESPut a check mark for data files to be deletedl()YES

As the data files except Chara-den images, templates, screen memos, and schedule

events are stored in the same storage area, you can select other files when deleting files.

Select a folder and put a check mark for the files to be deleted. “＊” appears on the folder

which contains the checked files.

“ ” appears when you put it for the files whose amount of data is equal to memory

shortage.

You can put or clear check marks at a time by pressing i( ) and selecting

“Select all in page/Release in page”.

Each time you press d or i( ), or each time you press i( ) and

select “Change disp. mode”, you can switch display/nondisplay of the folder volume

and data volume.

When selecting a file in “MUSIC”, you can show the lower level folders by pressing

l().

Each time you press r, the upper level folder returns.

For programs, you need to delete many files when deleting other files because the data

volume per program is large.

If the maximum number of programs are stored when you execute “Move program” or

try to save an i-αppli program or ToruCa file, you need to delete at least one file which

belongs to the same type.

If there is a security-applied folder for screen memos, the confirmation display appears

asking whether to enable you to select screen memos in that security-applied folder.

When you select “YES”, you need to enter your Terminal Security Code.

The file set for another function is indicated by “★”.

See page 297 for deleting mail-linked i-αppli.

If you operate this when moving an i-αppli program from the microSD card to the

FOMA terminal, you cannot delete the i-αppli program with its data file on the IC card.

Information

You are separately charged a packet communication fee.

When the data files are stored to the maximum

206

i-mode/i-motion/i-Channel/i-concier

You can download the pre-installed Kisekae Tool file, templates,

dictionaries, Chara-den images, and Deco-mail pictograms from the

“P-SQUARE” site (in Japanese only).

iMenu → メニューリスト (Menu List) → ケータイ電話メーカー

(Mobile Phone Maker) → P-SQUARE

You can upload JPEG or GIF images and i-motion movies stored in the

FOMA terminal to a site.

1Bring up a file uploadable site参照 (Reference)

Picture or imotionSelect a file to be uploaded.

Procedure for uploading files differs depending on the site.

About “P-SQUARE”

Uploading Files to Sites

QR code for

accessing the site

Information

You can upload up to 2 Mbytes in total.

You cannot upload files that are prohibited from output from the FOMA terminal to

other devices.

You can easily make a call, send mail, display Internet web pages, start

1Seg, set TV Timer/Timer Recording using highlighted information

(phone numbers, mail addresses, URLs, melodies, images, and so on)

displayed on sites and in mail.

The Web To, Phone To/AV Phone To, Mail To, i-αppli To, Media To and Address Link

functions might not be available depending on the mail sent from a personal computer

or the site.

You might be able to use the Web To, Phone To/AV Phone To, Mail To, or i-αppli To

function using highlighted information other than a phone number, mail address or

URL.

In B Mode of 2in1, the Mail To function is not available.

The information is not highlighted in the Decome-Anime.

You can make voice calls, videophone calls or PushTalk calls by using

phone numbers or similar information displayed on sites and in mail.

The Phone To function to make a videophone call is called the AV Phone To function.

1Select a phone number or similar information

Select a dialing type.

When you select “Select image”, select an image to be sent to other party during

a videophone call.

Select “SMS” to compose an SMS message to send to the phone number set as

the destination address. Go to step 3 on page 190.

The choices for dialing types may not be displayed when the phone number is

prefixed by “tel:” or “tel-av:”. Go to step 2.

2Dial

To make an international call, select “Int’l dial assist”. (See page 61)

To set Caller ID Notification, select “Notify caller ID”. (See step 2 of “Set Caller ID

Notification when Making a Call” on page 58)

Operations from Highlighted Information

Phone To/AV Phone To Function

Information

You cannot make a call in Horizontal Open Style.

207

i-mode/i-motion/i-Channel/i-concier

You can send mail by using mail addresses or similar information

displayed on sites and in mail.

1Select a mail address or similar information.

The destination mail address is already entered in the address field.

Go to step 3 on page 146.

You can access Internet web pages, via i-mode or Full Browser, from

URL or similar information displayed on sites or in mail.

1Select a URL or similar information

i-mode or Full BrowserYES

When the URL or similar one contains the information of i-mode or Full Browser,

you are connected via the function which corresponds to the information.

To cancel during connection, select “Cancel”. To cancel while obtaining a page,

press l().

You can start i-αppli programs from URLs (links) displayed on sites and

in mail.

1Select i-αppli informationYES

i-αppli starts.

Mail To Function

Web To Function

i-αppli To Function

Information

Even if i-mode mail text contains a link to start an i-αppli program, you cannot quote

the link when forwarding or replying to. Also, you cannot quote it when using

DOCOMO keitai datalink or infrared communication function.

You can start 1Seg or set TV Timer/Timer Recording from the information

(links) displayed on sites and in mail.

1Select 1Seg informationYES

1Seg or TV Timer/Timer Recording starts.

When the timer function starts, press l( ) to set TV Timer/Timer

Recording.

To change contents you want to set, go to step 1 of “TV Timer List” on page 263

or step 1 on page 264.

You can display a map from the postal address shown on a site or others

or can use the location information on the GPS compatible i-αppli

program. You can send the location information by i-mode mail as well.

1Select the location information such as postal address

Select an item.

Read map . . . . . . . Starts a GPS compatible i-αppli program set by “Select map”

of “GPS settings”. Select “YES” to send the location

information.

Map/GPS αppli . . . Selects and starts a GPS compatible i-αppli program.

Paste to mail. . . . . Converts the location information into a URL and composes an

i-mode mail message with the URL pasted to the text.

Check loc. info . . . Displays the details of the selected location information.

Media To Function

Information

You may not be able to use the Media To function even if information is highlighted.

Address Link Function

208

i-mode/i-motion/i-Channel/i-concier

1ii-mode settingsDo the following operations.

<i-mode Settings>

Setting i-mode

Scroll You can set the number of lines that are scrolled for when you

use Bo while displaying a site or screen memo.

Select the number of lines.

Character size See “i-mode” on page 123.

Set image display You can set whether to display images or Flash movies included

on sites or in screen memos.

ON or OFF

Set connection

timeout

See page 208.

Host selection See page 209.

Automatic replay

set.

See page 214.

Use phone

information

To display a Flash movie while a site or screen memo is

displayed, the information in the FOMA terminal may be used.

You can select whether to permit the information to be used for

that case.

YES or NO

Sound effect setting You can set whether to make an effect tone sound for when you

display a Flash movie while a site or screen memo is displayed.

ON or OFF

Information disp. See page 217.

Doc. display

settings

See page 394.

i-mode arrival act See page 87.

Reset last URL See page 198.

Check settings You can check each of “i-mode settings”.

It may take long to obtain some sites. You can set the time to wait before

canceling obtaining. Obtaining is not canceled automatically when

“Unlimited” is set.

1ii-mode settingsSet connection timeout

Select a timeout value.

Information

Even when “ON” is set, images might not be displayed correctly. In this case, “ ” is

displayed.

When “OFF” is set, “ ” is displayed and the data file is not received.

If you change this setting, “Set image display” of “User settings” of “1Seg” is also

changed.

The available information is as follows:

・Date and time set by “Set time”

・Reception level of radio waves

・Battery level

・Sound volume set by “Phone” of “Ring volume”

・Language selected by “Select language”

・Model name and serial number of FOMA terminal

Even when “ON” is set, the effect tones may not sound depending on Flash movies.

Setting Connection Timeout

Information

Even when you have set “Unlimited”, you may be disconnected owing to radio wave

conditions.

209

i-mode/i-motion/i-Channel/i-concier

You can set the host (APN) to use for receiving services other than

i-mode (DOCOMO).

If you change this setting, you will not be able to use i-mode.

1ii-mode settingsHost selection

Highlight <Not recorded>and press l()

Enter your Terminal Security Code.

If you select a stored host, the setting is changed to the selected one.

To delete the stored host, press i( ), select “Delete”, enter your

Terminal Security Code, and then select “YES”.

2Do the following operations.

3Press l().

+m-8-1

Changing a Host from i-mode

(ISP Connection Communication)

※Normally, you do not need to change this setting.

Host name Enter a host name.

You can enter up to 9 full-pitch/18 half-pitch characters.

Host number Enter a host number.

You can enter up to 99 half-pitch alphanumeric characters.

Host address Enter a host address.

You can enter up to 30 half-pitch alphanumeric characters.

Host address 2 Enter a host address 2.

You can enter up to 30 half-pitch alphanumeric characters.

Information

If you set any other host than i-mode, Pake-Houdai, Pake-Houdai Full or Pake-Houdai

Double are not applied.

1iOperate certificateCertificate

Highlight a certificate and press i()

Do the following operations.

Certificate . . . . . . . . . . . . Certificates issued by the authenticating company and stored

in the FOMA terminal at purchase.

DOCOMO Certificate . . . Certificates required for connecting to the FirstPass Center or

FirstPass sites; they are stored on the UIM (green/white).

User Certificate . . . . . . . . Certificates downloaded from the FirstPass Center by

selecting “Client certificate” from the i-mode menu; they are

stored on the UIM (green/white).

Operating SSL Certificates

Certificate info The subject name, author, validity period, and serial number of

the certificate are displayed.

You can check the certificate also by pressing Oo()

instead of i().

Valid/Invalid The selected item is invalidated; then “ ” changes to “ ”.

When you select an invalid certificate, it will be validated.

If you set a certificate to invalid, you cannot display the sites with

that SSL certificate.

You cannot set “DOCOMO Cert 2” to “Invalid”.

Certificates used for SSL communication

210

i-mode/i-motion/i-Channel/i-concier

User certificates verify that you have subscribed to the FOMA service.

Downloaded user certificates are stored on the UIM for the use on

FirstPass sites.

When you cannot display a FirstPass site because the user certificate on

the UIM has expired or the required user certificate is not stored on the

UIM, you can request the issue and download the user certificate from

the FirstPass Center.

You can request and download user certificates from the FirstPass Center.

This function is not available with the blue UIM.

The display and operating method displayed in the FirstPass Center site are subject to

change.

To show FirstPass sites, you can use Full Browser as well.

You cannot send/receive mail or receive Messages R/F while connected to the

FirstPass Center.

Set the date and time using “Set time” beforehand to connect to the FirstPass Center.

This function is not available overseas.

With the FOMA terminal, server authentication and client authentication are performed

for safer data exchange. The site and your FOMA terminal exchange certificates,

check the other party’s certificate and verify each other for safer communication

service. By getting client authentication, you can enjoy more secure communication

services.

Client authentication is available via the Internet communication from the FOMA

terminal or via the Internet communication with the FOMA terminal connected to a

personal computer. To use the personal computer for the client authentication, you

need to install the FirstPass PC software from the provided CD-ROM.

For details, refer to “FirstPassManual” (PDF format) in the “FirstPassPCsoft” folder on

the CD-ROM. Adobe® Reader® (version 6.0 or higher is recommended) is required to

see “FirstPassManual” (PDF format). If it is not installed in your personal computer,

install Adobe® Reader® from the provided CD-ROM to see it.

For details such as how to use it, refer to “Adobe Reader Help”.

Setting FirstPass

Client Authentication

You can perform user certificate operations on the site of the FirstPass

Center site.

1iOperate certificateClient certificateEnglish

You need to request the issue of the user certificate before you download

it. When requesting the issue of your user certificate is completed,

download the user certificate. After the downloading is completed, it is

saved on the UIM and the FirstPass sites will be displayable.

1Site display for the FirstPass Center

Request your certificateContinue

For an update, the message “Updating user certificate”

is displayed.

When you have already requested the issue of the user

certificate, select “Download your certificate” from the site display for the

FirstPass Center, go to step 3.

Access FirstPass Center

Site display for

the FirstPass Center

Information

Before using the FirstPass Center, select “The usage regulation (Japanese only)” and

carefully read the regulation.

You are not charged a packet communication fee for connecting to the FirstPass

Center.

Request Issue of User Certificate for Download

211

i-mode/i-motion/i-Channel/i-concier

2Enter your PIN2 code.

Enter your PIN2 code within 60 seconds. When the

code is not entered within 60 seconds, the connection is

cut off as an error entry.

See page 126 for PIN2 code.

3DownloadContinue

If you do not download the user certificate immediately, select “Menu”. From the

confirmation display asking whether to close the SSL page, select “YES”to

return to the site display for the FirstPass Center.

You can connect to FirstPass sites with your user certificate.

1Call up a FirstPass siteSelect an itemYES

2Enter your PIN2 code.

Enter your PIN2 code within 60 seconds. When the code is not entered within 60

seconds, the connection is cut off as an error entry.

See page 126 for PIN2 code.

Information

Before downloading a new or an updated certificate, be sure to request the user

certificate to be issued. User certificates cannot be downloaded until the request for

issue has been made.

Access Sites with User Certificate

Information

If you try to connect to the FirstPass site without the user certificate or when its

available period is expired, the confirmation display appears asking whether to

continue connecting to the site. Select “NO”to return to the previous page. Download

or update the user certificate from the FirstPass Center site and then access the site

again.

The packet communication fee for accessing the FirstPass site is included in

Pake-Houdai, Pake-Houdai Full or Pake-Houdai Double.

You can revoke the downloaded user certificate.

1Site display of the FirstPass CenterOther settings

Revoke your certificateYESEnter your PIN2 code.

Enter your PIN2 code within 60 seconds. When the code is not entered within 60

seconds, the connection is cut off as an error entry.

See page 126 for PIN2 code.

2ContinueContinueContinue

You can set the host for downloading the user certificate.

1iOperate certificateCertificate host

Highlight <Not recorded> and press l().

If you select a stored host, the setting is changed to that host.

To delete the stored host, press i( ), select “Delete”, enter your

Terminal Security Code, and then select “YES”.

Request Revocation of User Certificate

Information

To use FirstPass after revoking a certificate, you need to apply again for your user

certificate to be issued and then download it.

See page 209 for how to view the download user certificate.

Changing Hosts for Certificate Issue

※Normally, you do not need to change this setting.

212

i-mode/i-motion/i-Channel/i-concier

2Enter your Terminal Security Code

Do the following operations.

3Press l().

Default URL Enter a default URL.

You can enter up to 100 half-pitch alphanumeric characters.

Host address Enter a host address.

You can enter up to 99 half-pitch alphanumeric characters.

■Before Using FirstPass

FirstPass is DOCOMO’s electronic authentication service. By using FirstPass, client

authentication is enabled, whereby the site and your FOMA terminal exchange

certificates, check the other party’s certificate and perform mutual authentication.

When requesting issue of a user certificate, carefully read “The usage regulation

(Japanese only)” on the display, agree to this, and then make the request.

You need to enter the PIN2 code to use the user certificate. Once you have entered

your PIN2 code, all subsequent operations will be deemed to be done by you, so be

careful not to let anyone else use your UIM or PIN2 code.

If your UIM is lost or stolen, “docomo Information Center” on the back page of this

manual can revoke your user certificate.

DOCOMO bears no obligation or responsibility with regard to the sites and

information provided by FirstPass sites. Please solve the problem between you and

FirstPass sites.

DOCOMO and the CA do not guarantee security when you use FirstPass and SSL,

so you should use them on your own judgment and responsibility.

i-motion movies are composed of video, sound and music, and you can

play them back obtaining from i-motion compatible sites into your FOMA

terminal. You can set the i-motion movie for a ring tone.

Two types of i-motion movies are available as shown below. The type of

the obtained i-motion movie differs depending on the site or file.

You can save up to 10 Mbytes per i-motion movie.

i-motion

Categories Description

Type Playback type

Standard

(normal) type

(can be saved)

Plays back after

obtaining

Plays back after obtaining all the data of an

i-motion movie.

Plays back while

obtaining

Plays back while obtaining an i-motion

movie. After obtaining, you can play it back

in the same way as “Plays back after

obtaining”.

Streaming

type

(cannot be

saved)

Plays back while

obtaining

Plays back while obtaining an i-motion

movie. The data is deleted after playback, so

you cannot play it back again or save it to the

FOMA terminal.

213

i-mode/i-motion/i-Channel/i-concier

Select an i-motion movie from an i-motion obtainable site



Play

See page 354 for the operation during playback.

If an i-motion movie can be played back during obtaining, it will be played back

during obtaining.

If “Automatic replay set.” is set to “ON”, the i-motion movie will be played back

automatically after it is obtained.

Select “Property” to display the i-motion information. (See page 355)

See page 201 to save a screen memo.

Downloading i-motion from Sites

Play Back i-motion Obtained from a Site

Information

Depending on the accessed site or an i-motion movie, you might not be able to obtain

the data or play it back during obtaining, or play it back after obtaining. Also, you

cannot obtain an i-motion movie in ASF format.

See page 354 for the file formats of playable i-motion movies.

The playback stops when you close the FOMA terminal while playing back a standard

(normal) type of i-motion movie. The playback does not stop when you close the

FOMA terminal while playing back a streaming type of i-motion movie.

Even when you stop playing back the data of standard (normal) type while obtaining,

obtaining still continues.

Even if “Automatic replay set.” is set to “ON”, the data is not automatically played back

after obtaining when it is played back while obtaining.

For an i-motion movie that has restrictions on the number of playbacks, playable

period, or playable deadline, “ ” is displayed at the head of the title. An i-motion

movie with the playable period restricted cannot be played back before or after the

restriction period. If you remove the battery and keep it aside for a long time, the date/

time information in your FOMA terminal might be reset. In that case, you cannot play

back the i-motion movie that has restrictions on the playable period and playable

deadline. See “imotion info” for checking the playback restrictions.

You can save the obtained i-motion movie to your FOMA terminal. You

can save up to 262.1 Mbytes of files in total sharing the memory space

with other data files. (See page 529)

1A data acquisition completion displaySaveYES

Select a destination folder.

See page 205 when i-motion movies are stored to the maximum.

When you press l( ) to suspend downloading or when downloading is

suspended by an incoming call, the confirmation display appears asking whether to

resume downloading.

Select “YES” to resume downloading the remaining part. Select “NO” to show the data

acquisition completion display for a partially savable i-motion file. Select “Save pt.” to

save that file to any folder in “imotion” in “Data box”.

You can re-download the rest of the partially saved file from “Data box”.

The file name of the partially saved i-motion movie is “movie”.

When the playable period or playable deadline of the partially saved i-motion movie

has expired, you cannot download the remaining segments of the file. You can delete

the partially saved file when you try to download the file.

Depending on the line speed, line state, or radio wave conditions, the playback during

obtaining might be suspended or the images might be distorted. You can repeatedly

play back the standard (normal) type of i-motion movies after obtaining, but cannot

play back the streaming type of i-motion movies.

Save i-motion

Information

When downloading i-motion movie is suspended

Information

Depending on the i-motion movie, you might not be able to save the obtained data to

the FOMA terminal.

Partially saved i-motion movies cannot be played back from Data Box.

214

i-mode/i-motion/i-Channel/i-concier

You can set whether to play back an i-motion movie automatically, for

when you have obtained a standard (normal) type of i-motion movie from

a site or have selected a screen memo which contains a standard

(normal) type of i-motion movie.

1ii-mode settingsAutomatic replay set.

ON or OFF

This service distributes information such as news and weather forecast

to i-Channel mobile phones. The automatically received latest

information flows on the Stand-by display by tickers. You can read it on

the i-Channel list by pressing the i-Channel key. (See page 214)

Further, two types of channels, “Basic channel” provided by DOCOMO

and “Favorite channel” provided by IPs (Information Providers) are

available. You are not charged a packet communication fee for

auto-updates of “Basic channel” information.

You are charged a packet communication fee for auto-updates of

“Favorite channel” information which is enabled by registering your

favorite channels. For both of “Basic channel” and “Favorite channel”,

note that you are separately charged a packet communication fee for

browsing detailed information.

When you use the international roaming service, you are charged a

packet communication fee for both auto-update and browsing detailed

information.

i-Channel is a pay service which is available on a subscription basis (You need to

subscribe to i-mode to apply for i-Channel).

For details on i-Channel, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”.

The i-Channel service is provided in Japanese only.

Setting Automatic Replay of i-motion

Information

Note that a streaming type of i-motion movie is played back automatically even if this

function is set to “OFF”.

i-Channel

When “Ticker ON/OFF” is set to “ON”, up to 10 ticker files for the latest

information flow repeatedly on the Stand-by display. If you want to know

more about the information, you can obtain the details from the Channel

list.

1Press Zo.

The Channel list appears regardless of the “Ticker ON/

OFF” setting.

“ ” blinks during receiving information.

You cannot show the Channel list even by pressing Zo

from the horizontal Stand-by display.

2Select an item (link).

Information

When the FOMA terminal is turned off or if radio wave conditions are bad such as

when it is out of the service area, you may not be able to receive information even if

you have contracted to the i-Channel service. In that case, select the channel for

unsigned subscribers that appears by pressing +Zo; then you can now receive

information, and tickers flow on the Stand-by display. If your FOMA terminal remains

in the default state, you may not be able to receive information. Press +Zo, and then

information is received and tickers flow on the Stand-by display.

To receive i-Channel information overseas, you are charged a communication fee by

channel (domestic talk-free service does not apply).

After you cancel the contract for the i-Channel service, the ticker setting is

automatically set to off.

If you cancel the contract for the i-mode service before you cancel the contract for the

i-Channel service, the ticker setting remains on.

Using i-Channel

Channel list

Information

The ring tone does not sound and the vibrator does not work even when information

comes in. In addition, the Call/Charging indicator does not light or flicker.

215

i-mode/i-motion/i-Channel/i-concier

1ii-ChannelDo the following operations.

Tickers are not displayed in the following cases:

When the information is automatically updated after that or when you press +Zo to

receive the latest information, tickers automatically flow.

･When the UIM is replaced. ･When “Host selection” is changed

･When “Reset i-Channel” is executed. ･When “Reset settings” is executed.

･When “Initialize” is executed.

However, the information might not be automatically updated when “Host selection” is

changed. To receive the latest information, press +Zo to display the Channel list.

When “Host selection” is changed, the i-Channel connecting end is also changed. (In

ordinary, you do not need to change the setting.)

Depending on your usage state, you might receive information from i-Channel when

you display the Channel list.

Even if you change “i-mode” of “Character size”, the character size for the Channel list

might not change instantly.

Setting How Ticker is Displayed

Information

Channel list You can display the Channel list.

Go to step 2 on page 214.

Ticker ON/OFF You can set whether to display tickers on the Stand-by display.

ON or OFF

Ticker font size set. You can set the character size of tickers.

Extra large, Large, or Standard

You can check the ticker by pressing l( ). Press r

to return to the former display.

Ticker color set. You can set the background color and font color of ticker.

Select a pattern.

You can check the ticker by pressing l( ). Press r

to return to the former display.

i-concier is a service that you can receive useful information such as rail

transit, road traffic, weather, or any events by character (Machi-chara

image) on the Stand-by display. From the site, you can use scheduler

more conveniently by downloading schedule events (i-schedule events)

such as match schedules of sports or the activity information of the

artist.

Also, you can save the Phonebooks entries, mail messages, still images,

schedule events (including i-schedule events), and ToruCa files to the

Data Storage Center easily. Downloaded i-schedule events and ToruCa

files can be updated by IPs (Information Providers).

Ticker scroll speed You can set the ticker flowing speed.

Select a speed.

You can check the ticker by pressing l( ). Press r

to return to the former display.

Reset i-Channel You can initialize the ticker information, set “Ticker ON/OFF” to

“ON”, and “i-Channel ticker” of “Private window” to “OFF”.

Enter your Terminal Security CodeYES

Information

You can perform “Ticker ON/OFF”, “Ticker font size set.”, “Ticker color set.”, “Ticker

scroll speed”, and “Reset i-Channel” for each mode of 2in1. However, i-Channel

information is initialized for all modes. Further, when 2in1 is deactivated, they become

common to the settings in A Mode.

In Public Mode (Drive Mode), or during Lock All, tickers are not displayed.

Tickers are not displayed after you execute “Reset i-Channel”. When the information

is automatically updated after that or when you press +Zo to receive the latest

information, tickers automatically flow.

i-concier

216

i-mode/i-motion/i-Channel/i-concier

When your FOMA terminal is in the service area, you can receive

information reports automatically.

When information comes in, “ ” appears at the top of the display.

You can save up to 50 received information. They are overwritten from

the oldest one in order.

1When information arrives, “ ” blinks and contents of

information is displayed on the Stand-by display.

≥When multiple information received at a time, the latest one is displayed on the

Stand-by display.

≥Message telling information arrival appears while a display other than the

Stand-by display is shown or during horizontal Stand-by display. Select “Confirm”

to check the details of the information.

■Before Using i-concier

≥i-concier is pay service which is available on a subscription basis (You need to

subscribe to i-mode and Data Security Service to apply for i-concier).

≥The information in this service is provided by DOCOMO or IPs (Information

Providers). You are not charged a packet communication fee for receiving the

information provided by DOCOMO. You are charged a packet communication fee for

receiving the information provided by IPs (Information Providers).

≥You are separately charged a packet communication fee for browsing detailed

information.

≥When you use the international roaming service, you are charged a packet

communication fee for both auto-update and browsing detailed information.

≥Other than the service fee for using i-concier, you might be separately charged an

information fee depending on the i-schedule.

≥You are separately charged a packet communication fee for auto-updates of

i-schedule events, ToruCa files and Phonebook entries.

≥For details on i-concier, refer to “Mobile Phone User’s Guide [i-mode] FOMA

version”.

Receive Information

2Select a message.

≥You can erase a message by pressing h from the Stand-by display or

highlighting a message and pressing r or h.

≥You can show the display for selecting desktop icons by highlighting a message

and pressing l( ). (See page 32)

1m1i-concier1Select information.

≥An unread mark appears for unread information.

≥Schedule event files or ToruCa files might be attached

to information, or links are embedded in it for visiting a

site of more detailed or related information. Select

information with an unread mark to check these

contents.

1i-concier Menu display1l(MENU)

1スケジューラへ (To scheduler) or

トルカへ (To ToruCa)

スケジューラへ (To scheduler)

. . . Displays the Calendar display. (See page 408)

トルカへ (To ToruCa)

. . . Displays the ToruCa Folder list. (See page 320)

Displaying i-concier Screen

i-concier Menu

display

Display Schedule/ToruCa

217

i-mode/i-motion/i-Channel/i-concier

1i-concier Menu displayl(MENU)設定 (Settings)

Do the following operations.

You can select whether to display received messages on the Stand-by display.

1ii-mode settingsInformation disp. set

ON or OFF

Configuring i-concier Settings

ｉコンシェルとは？

(What is i-concier?)

You can display an expanation about i-concier.

ｉコンシェルイン

フォメーション設定

(i-concier

information setting)

You can set delivered contents of information, etc.

自動お預かり／更新

設定

(Automatic store/

update setting)

See page 141.

その他共通設定

(Other common

seting)

You can perform changing profile or setting when you use the

service overseas, etc.

お預かりデータ確認

(Check stored data)

See page 141.

お預かりデータ更新

(Update stored data)

See page 142.

お預かり通信履歴

(Stored data

exchanging history)

See page 142.

サービス各種手続き

(Service various

procedures)

You can perform contract or cancel contract, etc.

サービスご利用にあ

たって

(For using the

service)

You can display the usage rules of i-concier.

Information Display Setting

218

219

Full Browser/PC Movie

Displaying Web Pages Designed for PC . . . . . <Full Browser> 220

Setting Full Browser . . . . . . . . . . . . . <Full Browser Settings> 224

PC Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

Downloading PC Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228

Playing PC Movies from Data Box . . . . . . . <PC Movie Player> 229

220

Full Browser/PC Movie

You can browse Internet web pages designed for PCs using the Full

Browser function. You can display even the Internet web pages that

cannot be correctly displayed by i-mode. However, you cannot display or

correctly display some Internet web pages.

If you change the style while running Full Browser, the display

automatically switches between the vertical display and the horizontal

display. When you switch it manually, select “CHG wide scr. mode” from

the Function menu.

The data such as Home URL or Bookmarks registered via Full Browser cannot be

used via i-mode. The contents set by Full Browser are invalid for i-mode, either.

Note that you are charged a high communication fee for the massive data

communication such as browsing Internet web pages having many images or

downloading data files. For details on the packet communication fee, refer to “Mobile

Phone User’s Guide [i-mode] FOMA version”.

You can browse Internet web pages composed of frames. You can select a frame to

display it as well. (See page 223)

You can display SSL/TLS※-compatible pages via Full Browser.

※SSL and TLS are the methods of safer data communication using authentication/

encryption technology to protect your privacy. SSL/TLS pages prevent

eavesdropping and information alteration during communication by exchanging

encrypted data files. Further, server authentication prevents web spoofing, thus

making your personal information such as credit card number or postal address

exchanged safer.

Displaying Web Pages Designed for PC

1iFull BrowserSelect an item.

Home. . . . . . . . . . . . Displays an Internet web page set as Home URL.

Bookmark. . . . . . . . Displays an Internet web page stored in Bookmark.

(See page 200)

Last URL. . . . . . . . . Displays an Internet web page you viewed last time.

Go to location . . . . Displays an Internet web page by entering a URL.

(See “Displaying Internet Web Pages” on page 199)

Full Browser settings

. . . . . . . . . . . . . . . . . Configures Full Browser settings. (See page 224)

When “Access setting” is set to “No”, the confirmation display appears asking

whether to start Full Browser. Highlight “Yes” and select “OK” to switch setting of

“Access setting”, then Full Browser starts up.

Further, you can connect to a site for signing up a packet flat-rate service via

i-mode by selecting “To sign up a packet flat-rate service, click here”.

To end Full Browser, press h with an Internet web page displayed and select

“YES”.

Information

You can display up to 1 Mbyte per page. However, you can download the Flash movie

up to 10 Mbytes.

It may take long to display some Internet web pages.

You cannot use the following functions in Full Browser:

・Phone To function ・Screen memos ・PDF files

221

Full Browser/PC Movie

…: Displaying in the multiwindow

…Window number/Number of windows

…: During communication in another window

: During communication in another frame

…: Phone Mode

: PC Mode

…: Displaying an enlarged frame

…: Normal pointer

: While selecting a link

: During obtaining or processing data

: Drag Mode

: While dragging an object

: While selecting a text input area

: While selecting a Flash movie

: While selecting a operatable Flash movie

: While selecting a text-inputable Flash movie

■Operations for the Full Browser display

Full Browser Display







Full Browser Display



Operation Key operation

Phone Mode PC Mode

Return to previous page Co or 1

(Co is not available during

displaying the pointer.)

Forward to next page Vo or 3

(Vo is not available during

displaying the pointer.)

Scroll display Bo

(Mo during displaying the

pointer)

Switch to Drag Mode

(Only while displaying the pointer)

Oo(for at least one second)

Scroll display page by page </> or m()/c()

To scroll to the top/end of the page, </>(for at least

one second), m()/c( ) (for at least

one second) or a/s

When “Display pointer” of “Pointer/scroll” in “Full Browser settings” is set to “ON”, the

pointer appears in Full Browser display, then you can scroll the display or select contents

and others by the pointer.

You can scroll not only upward/downward but also obliquely when scrolling the display

by the pointer.

■When you switch to Drag Mode while displaying the pointer

You can switch to Drag Mode by pressing and holding Oo for at least one second during

displaying the pointer. By switching to Drag Mode, you can operate

Drag-Mode-compatible contents. In Drag Mode, the pointer is displayed as “ ”.

1. The pointer switches to “ ” by pressing Oo in Drag Mode, then you can move the

contents by grabbing it.

2. Move the contents by pressing Mo, and press Oo to let the contents off and the

pointer returns to “ ”.

Press and hold Oo for at least one second to release Drag Mode.

Reload 2

Enlarge/Reduce display size

7 to reduce the display size, 8 to display in

standard size, 9 to enlarge the display size

Display Bookmark Folder list

Full display d

Each time of pressing switches between the normal

display and the full display.

About operation by the pointer

Operation Key operation

Phone Mode PC Mode

Information

The operation differs depending on the contents.

You cannot operate other than the operations of contents in Drag Mode.

You cannot drag in Phone Mode.

222

Full Browser/PC Movie

Two modes, “Phone mode” and “PC mode”, are available for the Full

Browser display.

1iFull BrowserFull Browser settings

Display Mode settingPhone mode or PC mode

Phone mode

. . . .Displays an Internet web page to fit in the display width of the FOMA terminal.

You do not need to scroll sideways; you can browse Internet web pages only

by scrolling upward and downward.

PC mode

. . . .Displays an Internet web page in the same format as when it is displayed on

your personal computer in 800 (width) x 1400 (height) dots. You can browse

Internet web pages by scrolling upward, downward, and sideways.

When you show an Internet web page, you can switch the display modes each

time you select “Change disp. mode” of “Settings” from the Function menu.

Press l( ) from the Full Browser display to switch to “Operation

mode”. The operation palette is displayed in Operation Mode, and you

can move to the previous/next page or enlarge/reduce the display size.

No: Moves to the previous/next page.

Bo: Enlarges/reduces the display size.

You can display the guide of key operation when you press

i( ) in Operation Mode.

Switch Display Mode

Use Operation Mode

You can simultaneously open up to five Internet web pages via Full

Browser.

You can switch the simultaneously opened Internet web pages to show one by one.

1Full Browser displayi()Open new window

Select an item.

Bookmark. . . .Opens a new window to show an Internet web page stored in

Bookmark. (See page 200)

Enter URL. . . .Opens a new window to show an Internet web page by entering a

URL. (See “Displaying Internet Web Pages” on page 199)

Home. . . . . . . .Opens a new window to show an Internet web page set as Home

URL.

Link . . . . . . . . .Opens a new window to show a page of the link highlighted on the

Full Browser display.

See page 223 for how to switch or close the window.

Open in the Multiwindow

Information

Some Internet web pages have links configured to open in new windows. When you

open such a link, the new window opens even if you do not perform above operations.

223

Full Browser/PC Movie

You can display Internet web pages composed of frames. You can select

a frame, and enlarge each selected frame for displaying.

1From an Internet web page composed of frames

Use Mo to highlight a frame, and press Oo().

In Phone Mode, use Bo

to highlight a frame.

To return to the display for

all frames, press r or

select “Others” and select

“All frames” from the

Function menu.

You can switch to Full Browser to show the Internet web pages

incorrectly displayed by i-mode.

1While a page to be shown is displayed in Full Browser

i()InternetSwitch to FBOK

Display a Page Composed of Frames

All frames Enlarged by frame

Information

When an Internet web page has many divided frames, you might not be able to open

all frames. “ ” is added to the frames that you could not open.

Switch from i-mode to Full Browser

Information

You cannot correctly display some Internet web pages.

Function Menu of Full Browser Display

Home

Set as home URL You can set the displayed Internet web page as Home

URL.

YES

Display home You can display the Internet web page set as Home URL.

Bookmark

Add bookmark See page 200.

Bookmark See page 200.

Enter URL You can enter a URL to display an Internet web page.

Select a text box.

Go to step 2 of “Displaying Internet Web Pages” on

page 199.

The URL of displayed site is entered beforehand.

Open new window See page 222.

CHG/close window

Change window You can switch the windows while displaying the Internet

web pages in the multiwindow.

Select a window.

Close window You can close the window while displaying the Internet

web pages in the multiwindow.

YES

Reload The contents on the Internet web page is updated to the

latest ones.

Save image See page 203.

Settings

224

Full Browser/PC Movie

Change disp. mode See page 222.

CHG wide scr. mode/

RLS wide scr. mode

You can switch vertical display and horizontal display.

Set full display See page 225.

Pointer/scroll

Display pointer See page 225.

Speed See page 225.

Focus while scroll See page 225.

Zoom See page 225.

Set image display See page 225.

Sound effect See page 225.

Cookie setting You can set whether to validate cookies.

Go to step 1 of on page 226.

Delete Cookies You can delete cookies.

Go to step 1 of “Delete Cookies” on page 227.

Referer setting You can set whether to send a referer.

Go to step 1 of “Referer Setting” on page 227.

Others

All frames You can return to the display for all frames from the display

for the enlarged frame.

Compose message You can compose an i-mode mail message with the URL

of the displayed Internet web page pasted to the text.

Go to step 2 on page 146.

Add desktop icon See page 31.

Change CHR code See page 197.

Page info You can display information of the displayed Internet web

page.

URL or Title

You can upload JPEG or GIF images or i-motion movies stored in the

FOMA terminal to an Internet web page.

1Bring up a file uploadable siteOperate 参照(Reference)

and othersPicture orimotion

Select a file to be uploaded.

Procedure for uploading files differs depending on the site.

1iFull BrowserFull Browser settings

Do the following operations.

Certificate See page 197.

Retry You can play back the displayed animation from the

beginning.

Key guide You can display the guide of key operation of Full Browser

display.

Information

The number of characters of the URL you can paste to the text is up to 512 half-pitch

characters. If the URL contains 512 half-pitch characters or more, you cannot paste it.

Upload Files

Information

You can upload up to 2 Mbytes in total.

You may not be able to upload files depending on the Internet web page.

You cannot upload the files whose output from FOMA terminal is prohibited.

Setting Full Browser

Home URL You can set Home URL.

Select the URL fieldEnter a URLOK

225

Full Browser/PC Movie

Display Mode setting See page 222.

Set full display You can set whether to display the Full Browser display in full

display.

ON or OFF

Pointer/scroll

Display pointer You can set whether to display the pointer on Full Browser

display.

ON or OFF

Speed You can set scroll speed.

High speed, Medium speed, or Low speed

Focus while scroll You can set whether to highlight links while scrolling.

ON or OFF

Zoom You can set the display size of the Internet web page.

From the Function menu of the Full Browser display, you can

enlarge/reduce the display size by each page.

Select a display size.

In PC Mode, you can select a display area by “Select disp.

area” from the Function menu of the Full Browser display.

Access setting You can set whether to use Full Browser.

Yes. . . . Uses Full Browser.

No. . . . . Displays the cautions at the start of Full Browser.

Check the cautions, highlight “Yes” and then select

“OK”, then the setting switches to “Yes”, and Full

Browser becomes available.

Set image display You can set whether to display images.

ON or OFF

PC Movie auto-play You can set whether to automatically play back the

downloaded type of PC movies while obtaining.

ON or OFF

Sound effect setting You can set the sound volume of effect tones or sounds of the

Flash movies included in Internet web pages.

Select a sound volume level.

Auto NW trans. You can set whether to communicate when the transmission

is made automatically while displaying Internet web page.

Select an item.

YES . . . .Communicates automatically.

NO . . . . .Does not communicate automatically.

Notify . . .The confirmation display appears asking whether to

communicate each time the FOMA terminal tries to

communicate automatically.

Even if “Notify” is set, when you select “YES (default)” on the

confirmation display, the setting switches to “YES”.

Use phone info To display a Flash movie while an Internet web page is

displayed, the information in the FOMA terminal may be used.

You can select whether to permit the information to be used

for that case.

YES or NO

Cookie setting See page 226.

Delete Cookies See page 227.

Referer setting See page 227.

Script setting You can set whether to validate JavaScript. JavaScript is a

simple program language that runs on Internet web pages. It

is widely used to create Internet web pages with movements.

When “Valid” is set, you can use the JavaScript function to

browse Internet web pages in Full Browser.

Valid or Invalid

Window Open Guard You can set whether to prevent a new window from opening

automatically by JavaScript.

Valid or Invalid

226

Full Browser/PC Movie

Reset last URL You can erase the URL of the Internet web page you viewed

last.

YES

Check settings You can check respective Full Browser settings.

Information

When “Off” is set, the operation of flash movies is not available.

If you replace the UIM with a new one when “Yes” is set, the setting switches to “No”.

Even when “ON” is set, images might not be displayed correctly. In this case, “ ” is

displayed.

When “OFF” is set, “ ” is displayed and the data file is not received.

Even when “ON” is set, the effect tones may not sound depending on Flash movies.

The available information is as follows:

・Date and time set by “Set time” ・Language selected by “Select language”

Some Internet web pages may not be displayed correctly unless “Valid” is set.

Even when “Valid” is set, it might not work depending on JavaScript.

By using cookies, you can effectively access the Internet web pages you

have accessed once.

A cookie is the system to temporarily save personal information such as

the date/time or number of times you accessed an Internet web page. The

information from the server is written into the FOMA terminal, temporarily

saved, and used for content services.

If a cookie is sent, the information such as the date/time or number of times you

accessed an Internet web page is also sent to the web page. Note that even if your

information is detected by a third party by sending a cookie, we cannot be held

responsible for that. However, you may not be able to correctly display or use some

Internet web pages or content services unless the cookie setting is valid.

You can set whether to validate cookies.

1iFull BrowserFull Browser settingsCookie

Cookie settingSelect an item.

Valid . . . . . . . Always validates cookies. The confirmation display does not appear

before a cookie is sent or received.

Invalid . . . . . . Always invalidates cookies.

Sending . . . . Validates cookie’s sending/receiving. The confirmation display

appears each time a cookie is sent.

Receiving . . . Validates cookie’s sending/receiving. The confirmation display

appears each time a cookie is received.

Sending/receiving

. . . . . . . . . . . . The confirmation display appears asking whether to permit a cookie

to be sent or received each time a cookie is sent or received.

When you replace your UIM with another one, “Invalid” is set. If you change the

setting with replacing one inserted, the display for entering your Terminal Security

Code might appear.

Setting Cookie

Cookie Setting

Information

When “Sending”, “Receiving”, or “Sending/receiving” is set, the confirmation display

might consecutively appear asking whether to send/receive (update) cookies

depending on the Internet web page.

227

Full Browser/PC Movie

1iFull BrowserFull Browser settingsCookie

Delete CookiesEnter your Terminal Security Code

YES

The referer denotes the link source information. When a referer is sent,

the information about from which page you have accessed it is sent to

the site.

Note that even if your information is detected by a third party by sending

a referer, we cannot be held responsible for that.

You can set whether to send a referer while an Internet web page is open.

1iFull BrowserFull Browser settings

Referer settingSelect an item.

Send . . . . . .Sends a referer.

Unsend . . . .Does not send a referer.

Notify. . . . . .When a referer is sent, the confirmation display appears asking

whether to send it.

Delete Cookies

Setting Referer

Referer Setting

Information

When “Notify” is set, the confirmation display might consecutively appear asking

whether to send a referer depending on the Internet web page.

By using high speed communication, you can play back smooth and

high-quality PC movies provided by portal sites, movie specialty sites

and other sites on the Internet.

PC Movie Player supports playback of Windows Media® Video.

When downloading or streaming a PC movie, you might receive a bulky size of file.

Note that you are charged a high packet communication fee for a bulky sent/received

file such as a streaming type file whose size is not limited. For the details of the packet

communication fee and billing plan, refer to “Mobile Phone User’s Guide [i-mode]

FOMA version”.

The distribution server for streaming type supports Windows Media Services 4.1 and

Windows Media Services 9. You cannot play back a streaming type of PC movie

distributed from other than Windows Media Services 4.1 and Windows Media Services

Some sites check the operating environment (browser type, OS type, etc.) are checked

and you might not be able to play back PC movies.

See page 230 for the supported file format of PC movies.

PC Movie

Categories Description

Type Playback type

Streaming type

(cannot be saved)

Plays back while

obtaining

You can play back a PC movie while

obtaining it. A long time playback is

available.

Download type

(can be saved)

Plays back while

obtaining

When “PC Movie auto-play” is set to “ON”,

you can play back a PC movie while

obtaining it. You can save it to the

microSD card after download and play it

back without re-connection. Up to 10

Mbytes of a file can be downloaded.

Plays back a file

saved to the

microSD card

To the microSD card, you can save not

only data files obtained by the FOMA

terminal but also PC movies obtained or

created on a personal computer, and then

play them back. You can save a bulky file

of up to the space size of microSD card.

228

Full Browser/PC Movie

1Select a PC movie from a PC movie

obtainable siteYES

See page 229 for the operation during playback.

Among the PC movies protected by the license, you can play back the streaming type

of PC movies only. You cannot play back the download type of PC movies protected by

the license.

You might not be able to play back PC movies depending on the license setting of the

PC movies.

If files are stored to the maximum when you try to obtain a license to save it to the

FOMA terminal, the confirmation display appears asking whether to delete currently

stored licenses to save a new one. Select “YES” to delete all the stored licenses to

save it. You need to obtain a license again to play back a PC movie whose license is

deleted.

Downloading PC Movies

Playing Back a Streaming Type of PC Movie

About license (Windows Media DRM)

1Select a PC movie from a PC movie obtainable site

YES

See page 229 for the operation during playback.

If “PC Movie auto-play” is set to “ON”, a PC movie is played back during

obtaining. If “OFF” is set, you can play it back by selecting “Play” from the data

acquisition completion display.

When you obtain a download type of PC movie from a site, the file is obtained

while it is played back, and obtaining itself continues even when you suspend the

playback midway.

Depending on the type of a PC movie being obtained or the reason why the obtaining is

suspended, the operation differs.

Streaming type

After the suspension by an incoming call, alarm notification, or disconnection of

communication, the obtaining will be in pause state. Press

( ) to resume

playback from the suspended point.

The display before playback returns when you suspend obtaining by pressing

Download type

After the suspension by an incoming call, alarm notification, or disconnection of

communication, the data acquisition completion display appears. Select “Play” to play

back the obtained segments of the file. Select “Save” to save the obtained segments of

the file. (See “Saving PC Movies”.) Select “ResumeDL” to resume obtaining from the

suspended point.

The confirmation display appears asking whether to discard the data when you suspend

obtaining by pressing r or h.

For download type of PC movies, the downloading is continued when there is an

incoming voice call, a mail message or Message R/F receiving, or alarm notification.

Depending on the PC movie or the site you are connecting to, you cannot resume from

the suspended point even by pressing Oo( ) or selecting “ResumeDL”. In that

case, the obtaining resumes from the top of the file.

Playing Back a Download Type of PC Movie

When obtaining a PC movie is suspended

Information

Note that there is no upper size limit for a streaming type of PC movie, you might

exchange the files of no size limit. When obtaining it, the confirmation display appears

asking whether to play it back.

Depending on the site or PC movie you are connecting to, you might not be able to

obtain a file, play it back during obtaining, or play it back after obtaining.

229

Full Browser/PC Movie

You can save the obtained PC movies to the microSD card. However, you

cannot save the streaming type of PC movies.

1A data acquisition completion displaySaveYES

The PC movie is saved to the folder selected by “Select storage”.

When the maximum number of files has already been saved to the microSD card

or memory space is full, the confirmation display appears asking whether to

delete unnecessary files to save new one. Select “YES” and select unnecessary

files from the displayed list in Data Box to delete them. Before deleting, you can

play back PC movies on the microSD card for confirmation, but cannot display

the previous or next files.

Depending on the line speed, line state, or radio wave conditions, the playback during

obtaining might be suspended or the images might blur. You can repeatedly play back

the download type of PC movies after obtaining but cannot play back the streaming

type of PC movies.

If the PC movie has the restrictions on the playable period, you cannot play it back

before and after that period. If you leave your FOMA terminal with the battery pack

removed for a long time, the date/time information retained in the FOMA terminal

might be reset. In that case, you cannot play back the PC movie that has the

restrictions on the playable period or playable deadline. See “Contents info” for

checking the playback restrictions.

If you try to play back a PC movie with a low battery, the battery alert tone sounds

regardless of the setting of “Keypad sound”, and the confirmation display appears

asking whether to play it back. When the battery becomes low during playback, the

playback pauses, and the confirmation display appears asking whether to end the

playback.

Saving PC Movies

Information

You cannot attach the saved PC movie to an i-mode mail message for sending.

You can play back movies published on the Internet for personal

computers or PC movies saved to the microSD card via a personal

computer, etc.

In Horizontal Open Style, PC movies are played back horizontally. You

can switch styles during playback.

You can play back the sound of movies by connecting the Flat-plug Stereo Earphone

Set (option). Also, you can play back the sound wirelessly from a commercial Bluetooth

device. (See page 427)

1mData boxPC Movie

2microSDSelect a folderSelect a file.

When you press and hold

p for at least one second

or press h during

playback, pause, or halt,

PC Movie Player ends. It

ends even when you play

back during obtaining.

■Operations while playing back a PC movie

See page 232 for when you operate from the Function menu.

Playing PC Movies from Data Box

PC Movie Type

Selection display

PC Movie Folder list PC Movie list

Operation Key operation

Pause※1Oo() or p

Oo() or p to play back

Fast forward※1l()

l( ) to play back

Display next file※2※3Vo

230

Full Browser/PC Movie

※1 You might not be able to operate this for some PC movies.

※2 You cannot operate this for a streaming type of PC movie, or when you are playing

back a PC movie while obtaining it. You cannot operate this when you play back an

obtained but unsaved PC movie from the data acquisition completion display, either.

※3 The files are displayed in the order on the PC Movie list. You can operate this when

you play back from the PC Movie list. However, PC movies in WVX, ASX, and WAX

formats are skipped.

※4 When three seconds have elapsed after starting playback, you go back to the

beginning of the file. However, you might not be able to operate this for a streaming

type of PC movie or when you are playing back a PC movie while obtaining it.

※5 You cannot operate this during fast-rewinding.

※6 The horizontal playback is valid during playback only. When you close the playback

display, the vertical display returns.

Display previous file※2※3Co※4

Select position to play

※1※5Press and hold No.

Sound volume adjustment Bo or </>

Mute/Release mute i

Switch vertical display/

horizontal display※6※7

[Normal Style only]

c()

Each time of pressing switches display directions.

Icon

[Horizontal Open Style only]

m※8

Each time of pressing switches whether to display

icons and navigations.

Remaster 9

Each time of pressing switches between “ON” and

“OFF”.

Listening 8

Each time of pressing switches in order of “OFF” →

“Surround” → “Natur1” → “Natur2”.

Equalizer 7

Each time of pressing switches in order of “Normal” →

“H-BASS1” → “H-BASS2” → “Train”.

Operation Key operation ※7 You cannot operate this for PC movies with incompatible video data or voice-only

PC movies.

※8 Even if you set the icons not to be displayed, the icon such as “ ”, “ ”, “ ” or “ ”

appears during communication or when an i-mode mail message or Message R/F

comes in.

If you play back on the horizontal display from the pause state, the display might

become dark, however, the video appears soon after you resume the playback.

You can perform the following operations when you play back or pause a

PC movie using the switch of Flat-plug Stereo Earphone Set (option) or

Flat-plug Earphone/Microphone with Switch (option).

■Specification for PC movie playback

※1The complex profile of Windows Media Video 9 is not supported.

You might be able to play back the files that exceed the bit rates described above.

Even when the file format is supported, you might not be able to obtain files, play back

during obtaining, or play back after obtaining depending on the file.

If the file format of either video or audio is not supported, the file of the supported format

only might be output.

Operation Switch operation

Pause Press once.

To play back, press again.

Play back next file Press twice in succession.

Play back previous file Press three times in succession.

When playback time is over three seconds, you go

back to the beginning of the file.

File format WMV, WMA, WVX, WAX, ASF, ASX

Extension wmv, wma, wvx, wax, asf, asx

Codec Video Windows® Media Video 8 through 9※1

Audio Windows® Media Audio 2 through 9

Bit rate Video WMV 8 768 kbps

WMV 9 2 Mbps

Voice 384 kbps

Video size WMV 8 352 dots x 288 dots

WMV 9 800 dots x 480 dots

Frame rate 30 fps

231

Full Browser/PC Movie

■Icons on the PC Movie list

“ ” and “ ” are displayed only for “Position memory” or “Played history”.

The Position Memory Selection display appears. When you select “Marker to resume” or

“Position memory1 through 9”, the PC movie is played back from the stored position.

You can display information about the position memory by pressing i( ) and

selecting “Posit. memory info”.

To delete “Position memory”, press i( ) and select “Multiple-choice”, “Delete

this”, or “Delete all”. You cannot delete “Marker to resume”.

When a PC movie with a position memory has been deleted or moved to another

folder, or when its file name has been edited, you cannot play it back.

Information

Files with the extension of wvx, wax, asx are the files for which the URL of a PC movie

on the Internet is specified. When you select those files saved on the microSD card,

streaming or downloading playback starts from the specified URL.

Icon File format

WMV, ASF

WVX, ASX

WMA

WAX

Icon Description

PC movie on the Internet

PC movie saved to the microSD card

When you select “Position memory” from the PC Movie Type

Selection display

Marker to resume This is stored automatically when a call comes in, an alarm

operates, or the battery level goes flat during playback of a PC

movie, or when you terminate the PC Movie player during

playback.

Position memory You can store in any optional position in a PC movie, and create

up to nine position memories. (See page 232 and page 233)

Even when you play back a PC movie from a position memory, it may be played back

from the beginning, depending on the PC movie.

When you play back a PC movie, the URL or storage location

of that file is stored as a history. Up to 30 histories are stored,

and when those are exceeded, the oldest history is overwritten.

Select a played history to play back the PC movie according to

the history information.

When a PC movie stored in a played history has been

deleted or moved to another folder, you cannot play it back.

When you play back an obtained but unsaved PC movie from the data acquisition

completion display, it is not stored in Played History.

When you select “Played history” from the PC Movie Type

Selection display

Function Menu of the PC Movie Folder List

Played History list

Add folder Enter a folder name.

You can enter up to 31 full-pitch/63 half-pitch characters.

Edit folder name Enter a folder name.

You can enter up to 31 full-pitch/63 half-pitch characters.

Delete folder Enter your Terminal Security CodeYES

Select storage You can set a destination folder for saving downloaded PC

movies to the microSD card.

YES

Information

“ ” is displayed for the folder set as a destination folder.

Function Menu of the PC Movie List/Played History List

Contents info You can display the file title, file name, and others of the PC

movie.

Move You can move the PC movie to another folder.

Select a destination folder.

Edit title

232

Full Browser/PC Movie

Edit title Enter a title.

You can enter up to 18 full-pitch/36 half-pitch characters.

Reset title You can reset the title to the default.

YES

Copy You can copy the PC movie to another folder.

Select a destination folder.

History info You can display information of the played history.

Position memory You can store the URL information of the PC movie stored in

Played History to a position memory. When you play back the

file from the position memory, it is played back from the

beginning.

Select a position memory number to be registered.

You cannot select “Marker to resume”.

Multiple-choice You can select multiple files and operate them.

Put a check mark for files to be operatedi()

Select an item.

Delete . . . . . . . . See “Delete this” on page 232.

Copy . . . . . . . . . See page 232.

Move . . . . . . . . . See page 231.

Description You can display the lyric or description of the PC movie.

The words view or Description view

Up to 1,024 full-pitch/2,048 half-pitch characters can be

displayed in each.

Memory info You can display the used memory space (estimate).

Delete this YES

Delete all You can delete all the files in the folder.

Enter your Terminal Security CodeYES

Listing You can change the display format of PC Movie list.

Title or File name

Function Menu during Pause/at the End of Playback

Fast The PC movie is played back fast.

To cancel it, press l().

Rewind The PC movie is played back fast in the opposite direction.

To cancel it, press l().

Stop You can end playback.

Position to play You can set the start position for playing back the PC movie.

Use No to move the cursor position of the time bar and

press Oo().

To cancel, press r.

Sound effect

Remaster You can bring the sound from an earphone or Bluetooth

device to the original sound by complementing high-pitch

range lost at data compression.

ON or OFF

Listening You can set sound effect for listening for the sound from an

earphone or Bluetooth device.

Select an item.

Surround . . .Makes the sound natural and stereophonic.

Natur 1/2 . . . .Complements the cooped-up feeling specific to

earphones and plays back natural sound.

Select 1 or 2 according to your taste.

OFF . . . . . . . .Sets Listening to “OFF”.

Equalizer You can change the quality of the sound from an earphone or

Bluetooth device.

Select an item.

Normal . . . .Reproduces normal sound quality.

H-BASS1. . .Enhances bass sound.

H-BASS2. . .Enhances bass sound more deeply than

H-BASS1.

Train . . . . . .Minimizes abnormal sound that causes sound

leakage.

Contents info See page 231.

233

Full Browser/PC Movie

Position memory You can store a position memory in the PC movie. Operate at

the desired position in pause state.

Select a position memory number to be stored.

You cannot select “Marker to resume”.

Description See page 232.

Copy URL While playing back a PC movie published on the Internet, you

can copy the URL of that PC movie.

You can copy up to 512 half-pitch characters for the URL.

Display size You can set whether to display the PC movie in the original

size (Actual size) or to fit it to the display size.

Actual size or Fit in display

Even if you set to “Actual size”, the PC movie in excess of

the display size is reduced to the display size.

Information

Depending on the PC movie, you might not be able to select the position to play.

Even if an earphone or Bluetooth device is not connected, the respective setting

contents are displayed on the display.

Depending on the PC movie, the top position might be stored as the playback start

position regardless of the position where you pause.

Depending on the image size, the image might be displayed with the right or bottom

side cut off.

234

235

Camera

Before Using Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236

Shooting Still Images . . . . . . . . . . . . . . . . <Still Image Shoot> 239

Shooting Movies . . . . . . . . . . . . . . . . . . . . . . . . <Movie Shoot> 241

Changing Settings for Shooting . . . . . . . . . . . . . . . . . . . . . . . . . 243

Setting Image Size and Image Quality . . . . . . . . . . . . . . . . . . . . 244

Using Bar Code Reader. . . . . . . . . . . . . . . <Bar Code Reader> 248

■Copyrights and Portrait Rights

You have no right to copy, modify, or distribute the contents of which a third party holds the copyright such as text, image, music, or software

programs downloaded from web pages on the Internet, or recorded using this product, without permission from the copyright holder except for

when the copy or quote is for personal use that is allowed by the copyright law.

Note that it may be prohibited to shoot or record live performances or exhibitions even for personal use.

Make sure that you refrain from shooting portraits of other persons and distributing such portraits over the Internet without consent, as this may

violate portrait rights.

You may be imposed punishment according to the law and rule (such as the nuisance prevention ordinance) if you use the FOMA terminal to give a remarkable

nuisance and misdeed to the public.

Please be considerate of the privacy of individuals around you when shooting and sending photos using camera-equipped mobile phones.

236

Camera

･Check the lens for any stain before shooting. If the lens is stained, clean

the lens with a soft cloth. If the lens is stained with fingerprints or

something oily, you will not be able to focus on a subject, or the stains

are reflected on still images or movies you shoot.

･Make sure that you do not let fingers, hairs, or the strap overlap the lens

when shooting.

･Make sure that you hold the FOMA terminal securely with your hands so

that it does not move when shooting. Otherwise, the image may be

blurred, especially in a dark place.

･Do not leave the FOMA terminal with the lens pointing direct to the

sunlight. Pixels may be discolored or burns may result.

･If you shoot under a fluorescent lamp, mercury lamp, or sodium lamp

flickering at high speeds, “flicker symptom”, horizontal stripes flow

from top to bottom or left to right of the display, may result. The color

tone for the image may vary depending on a shooting timing.

･If you shoot a subject containing an area of an extremely high

brightness such as the reflection of sun light, the bright area might be

black-spotted but this is not a malfunction.

･Images shot by the cameras might differ from actual subjects in color

tone and brightness.

･When the battery level is low, you may not be able to save still or

moving shot images.

･A slight time lag is found between when you press Oo() or 0

and when you actually shoot. Therefore, if you shoot a fast moving

subject, the subject might be shot with its position slightly away from

the one you see it when you press Oo() or 0.

･Do not remove the microSD card while saving files to it. The FOMA

terminal or microSD card could malfunction.

･If you turn off the power while saving a file, an incomplete file may be

saved.

Before Using Camera

Notes for when Shooting Images

･If the battery pack is removed off while saving a file to the FOMA

terminal or microSD card, that data becomes contingent.

･You need to obtain a microSD card separately to use the functions

related to the microSD card.

The microSD card is available at mass retailers for home electric

appliances, etc. (See page 370)

You can use the cameras to shoot

still images or movies.

You can switch between the front

(inside camera) and the back

(outside camera).

The outside camera comes with the

focus function to automatically focus

on subjects. (See page 243) The

Image Stabilizer function enables

you to shoot images with less blur.

(See page 245)

You can easily operate the main

functions for shooting not only from

the Function menu but also by

operating the keys.

Use Cameras

Inside

camera

Outside

camera

237

Camera

■Operations for shooting

※1 You cannot operate them in Horizontal Open Style.

※2 Each time of pressing switches in order of “Photo mode”→“Movie mode”→

“Continuous mode”.

※3 Each time of pressing switches between “ON” and “OFF”.

※4 Each time of pressing switches between “Phone” and “microSD”.

※5 Each time of pressing switches between the inside camera and outside camera.

Icon menu operation +l

Function menu access※1+i

Bar code reader※1+m

Shutter/Save +Oo-0

Tele +Vo

Wide +Co

Settings for Focus

(when the outside camera is

used)

+Zo

Focus function

(when the outside camera is

used) +Xo

Change camera-mode※2+c

Icons※3.<

Brightness -1

White balance -2

Photo mode -3

Image quality -4

Image size -5

High sensitivity

(when the outside camera is

used) -6

Auto timer※3-7

Store in※4-9

Switch cameras※5-d

End camera

(in ordinary time)

Release focus lock

(when focus is locked)

-r

End camera -h

Information

While the camera is activated, the Call/Charging indicator flickers. You cannot turn off

flickering.

You cannot change or mute the volume of the shutter sound. You cannot set a

downloaded melody for the shutter sound, either.

If no key operation is done on the Finder display, the camera is automatically

deactivated after about three minutes.

When you shoot in a dark place, ensure to set “Photo mode” of “Camera settings” to

“Night mode”.

You can operate the following by the Icon menu: “Brightness”, “White balance”,

“Photo mode”, “Image quality”, “Image size”, “Focus”, and “High sensitivity”.

On the Finder display, the settings are indicated by bars and icons.

Camera Setting and Finder Display



































 







  

Icon/bar name Icon Description Page

Camera mode Photo mode 239

Movie mode 241

/ / Continuous mode (Auto, Manual, Auto

bracket) 239

Store in Phone: Stores in the FOMA terminal. 245

microSD: Stores on the microSD card.

Number of

recordable


—

Number of remaining recordable still

images

Up to 999 images are displayed.

—

Memory

capacity bar

Memory usage state (estimate) in Movie

mode

Displayed in red when the memory space

reaches maximum.

—

238

Camera

File size

setting

Mail restrict’n (S): Up to 500 Kbytes can be

saved.

244Mail restrict’n (L): Up to 2 Mbytes can be

saved.

Long time: Long time recording is possible.

Image

stabilizer

Auto 245

Shooting

status

During movie recording 241

Movie type set Records only the video. 245

Recordable

time —Recordable time (estimate) for movies —

Icon display / Switches between ON and OFF 246

Top icon Shows the vertical direction of the still

image or movie. —

Zoom bar Zooming status 243

Brightness ∼ Brightness of shot image 244

White balance Auto: For adjusting white balance

automatically

244

Fine: For shooting outdoors in fine weather

Cloudy: For shooting in cloudy weather or

in the shade

Light bulb: For shooting under

incandescent light

Fluorescent light: For shooting under

fluorescent light

Number of

frames for

continuous

shooting

/Number of frames at “Manual” shooting in

“Continuous mode” 245

Auto timer ON 247

Photo mode Normal

244Portrait

Sports

Icon/bar name Icon Description Page

Photo mode Food

244

Scenery

Night mode

Backlight

Character

Snow

Sunset

Pet

Image quality Normal: Standard quality

244Fine: Fairly high quality

Super fine: High quality

Image size

(Photo mode/

Continuous

mode)

Outside camera photo

5M (1944 x 2592 )

244

/ 3.7M Wide (1456 x 2592)

/ 3M (1536 x 2048)

/ 2M Wide (1080 x 1920)

/ 2M (1200 x 1600)

/ 1M (960 x 1280)

/ Stand-by (480 x 854)

Inside camera

Continuous

VGA (480 x 640)

/ QVGA (240 x 320)

/ QCIF (144 x 176)

/ Sub-QCIF (96 x 128)

Icon/bar name Icon Description Page

239

Camera

See page 346 for how to display saved still images.

1Press c.

The Camera menu is displayed by

mLifeKitCamera.

You can start also by selecting “Photo mode” from the

Camera menu.

While “Work with style” is set to “Camera”, you can start

camera in Photo Mode also by switching to Horizontal

Open Style from the Stand-by display.

You can paste the Camera menu to the desktop. (See

page 31)

Change the direction of the FOMA terminal according to

the direction of the Top icon.

Image size

(Moviemode)

VGA (640 x 480)

244

HVGA Wide (640 x 352)

QVGA (320 x 240)

QCIF (176 x 144)

Sub-QCIF (128 x 96)



High sensitivity

ON: Shoots in high-sensitivity mode. 245

OFF: Shoots in normal-sensitivity mode.

Focus Face detection

245

Auto

Close-up

Landscape

Key guidance — Display key guidance in horizontal display —

Icon/bar name Icon Description Page

Shooting Still Images

Shoot a Still Image

Finder display

2Press Oo() or 0.

A still image is shot. The Post View display for confirmation appears.

When “Focus” is set to “Face detection” or “Auto” while shooting with the outside

camera, shooting starts after the focus operation.

The image appears horizontally reversed (mirrored) when you shoot with the

inside camera; however the image is correctly displayed when played back.

When “Auto save set” is set to “ON”, the Post View display does not appear; the

still image is automatically saved.

3Press Oo() or 0.

The still image you shot is saved to the “Camera” folder of

“My picture” in the FOMA terminal or to the microSD card.

See “Store in” and “Select storage” for selecting a

storage location.

To save the still image as an mirrored image

(horizontally reversed), press i( ) and select

“Mirror save”.

Press r to cancel the shot still image and return to

the Finder display.

You can continuously shoot still images. You can set the number of

frames, and shooting interval for auto-shooting. (See page 245)

1cc()c()

The camera starts in the mode you used last time,

“Auto”, “Manual”, or “Auto bracket”. To change

Continuous Mode, see “Continuous mode” of “Cont.

shooting set.”.

Post View display

Continuous Shooting

Finder display

240

Camera

2Press Oo() or 0.

Continuous shooting starts.

When “Continuous mode” is set to “Manual”, press Oo() or 0 the

number of times of shooting frames. The Post View display for confirmation

appears.

When “Focus” is set to “Auto” while shooting with the outside camera, shooting

starts after the focus operation.

To cancel shooting midway, press r. If you shoot in the “Auto” or “Auto

bracket” mode of “Continuous mode”, you can cancel also by pressing

l( ). You can cancel shooting also by closing the FOMA terminal.

The image appears horizontally reversed (mirrored) when you shoot with the

inside camera; however the image is correctly displayed when played back.

When “Auto save set” is set to “ON”, the Post View display does not appear; the

still images are automatically saved.

Select a still image and press c()

Oo() or 0

Press No from the detailed

display to show the

previous or next still image.

To save the still image as a

mirrored image

(horizontally reversed),

press i( ) and

select “Mirror save”.

To select a still image and save it

Post View display Detailed display

Put a check mark for still images to be saved

l()Save or Mirror save

If you highlight a still image and press Oo() or 0, “ ” is added.

Perform the same operation again to release the selection..

l()Save or Mirror save

The still images you shot are saved to the “Camera” folder of “My picture” in the

FOMA terminal or to the microSD card.

See “Store in” and “Select storage” for selecting a storage location.

Press r from the Post View display to cancel the shot still images and return to

the Finder display.

To select multiple still images and save them

To save all still images

Information

When you save the still images in Horizontal Open Style, all of them are saved as

correct images.

The image quality may be coarse depending on “Image size” or “Display size”.

When you shoot, the tone selected for “Shutter sound” sounds regardless of the

settings such as Manner Mode. The sound volume for shutter tone cannot be

changed.

Even when a mail message comes in while shooting, the shooting operation

continues. Though unread message icon is displayed, the Mail Receiving display is

not displayed.

If you end the camera function by using Multitask while shooting, unsaved still images

are deleted.

When shooting, hold the FOMA terminal securely to avoid blurred images.

The Call/Charging indicator lights at shooting in Photo Mode or in Continuous Mode

with “Auto” or “Auto bracket” set. It flickers in Continuous Mode with “Manual” set.

Function Menu of the Post View Display in Photo Mode/

Detailed Display in Continuous Mode

Save See page 239 and page 240.

241

Camera

Mirror save See page 239 and page 240.

Attach to mail You can save the still image you shot and attach it to an i-mode

mail message.

Go to step 2 on page 146.

You can compose an i-mode mail message also by pressing

l().

Attach location Select an item.

By position loc.

. . . . Measures the current location (see page 328) and store the

location information. After checking the location information,

press Oo().

From loc. history

. . . . Select a piece of location information from Location History

(see page 337) and store it.

Set display You can save the shot still image and paste it to the Stand-by

display and others for displaying.

Go to “Set display” on page 347.

Even when “Store in” is set to “microSD”, the still image is saved

to the FOMA terminal.

Change frame You can replace the frame added to the shot still image with a

new one.

Select a frame.

Press No to show the previous or next frame.

To reselect a frame, press l().

Oo()

You cannot release the frame.

Store in See page 245.

Normal display/

Mirror display

You can switch between a correct image and a mirrored image

(horizontally reversed).

Display size See page 245.

File restriction See page 247.

Icon See page 246.

Cancel You do not save the shot still image.

See page 353 for playing back the saved movies.

1cc()

The Camera menu is displayed by

mLifeKitCamera.

You can start also by selecting “Movie mode” from the

Camera menu.

You can paste the Camera menu to the desktop. (See

page 31)

Function Menu of the Post View Display in Continuous Mode

Save See page 240.

Store all/animat’n You can save all the shot still images to store as an original

animation.

Save or Mirror save<New>

Store in See page 245.

Normal display/

Mirror display

You can switch between a correct image and a mirrored image

(horizontally reversed).

File restriction See page 247.

Cancel You do not save the shot still images.

Information

When “Store in” is set to “microSD”, this function is not available.

If you have shot a single still image only, this function is not available.

Shooting Movies

Finder display

242

Camera

2Press Oo() or 0.

Recording starts.

When “Focus” is set to “Auto” while shooting with the outside camera, shooting

starts after the focus operation. While shooting, the subject is automatically

focused regardless of the setting of “Focus”.

When you shoot with the inside camera, the horizontally reversed (mirrored)

image is displayed, but it is displayed normally when played back.

3Press Oo() or 0.

Recording ends. The Post View display for confirmation appears.

Recording automatically ends when a call comes in, the low battery alarm

sounds, or the FOMA terminal is closed during recording.

When “Auto save set” is set to “ON”, or “File size setting” is set to “Long time”, the

Post View display does not appear; the movie is automatically saved.

4Press Oo() or 0.

The movie you shot is saved to the “Camera” folder of

“imotion” in the FOMA terminal or to the microSD card.

For selecting a storage location, see “Store in” and

“Select storage”.

Press r to cancel the shot movie and return to the

Finder display.

Post View display

When you use a microSD card that you repeatedly save/delete data files to/from, the

writing speed slows down, recording might end midway or the image quality might

deteriorate.

Do the following operations to improve such symptoms:

1. Copy all the data files from the microSD card onto your personal computer as

they are.

When your personal computer is set so as to hide folders and files, change the

settings to display those folders and files, and then operate. For how to change the

settings, refer to the operating manual or Help on the personal computer you use.

Do not change the names of folders and files copied to the personal computer.

2. Use the personal computer to delete all the data files on the microSD card.

Do not format the microSD card. The data files might not be played back.

3. Copy the data files copied in step 1 back to the microSD card.

Be sure to copy them back to the same microSD card. Even if you save the

copyrighted data files on another microSD card, you cannot play them back.

If recording ends or the image quality deteriorates while

shooting

Information

The shutter tone set by “Shutter sound” sounds when shooting starts and ends

regardless of the settings such as Manner Mode. The sound volume for shutter tone

cannot be changed.

If you do key operations while recording, the operation sound may be picked up.

The Call/Charging indicator flickers during recording.

When you switch the subject you are shooting to a subject with a difference in

perspective, it takes time to focus on the new subject.

When you have difficulty focusing on a subject, switch to another subject. Then the

subject might come into focus.

The operating speed of focusing is slowed down in a dark place.

Function Menu of the Post View Display in Movie Mode

Play See page 353.

Save See page 242.

243

Camera

You can set the camera when shooting images.

You can display the image through the camera in “Wide” or “Tele”.

1Finder displayUse No to adjust the magnification.

Attach to mail You can save the recorded movie and attach it to an i-mode mail

message.

Go to step 2 on page 146.

You can compose an i-mode mail message also by pressing

l().

Set as stand-by You can save the recorded movie and set it for the Stand-by

display.

Set as standbyWide

Store in See page 245.

Display size See page 245.

File restriction See page 247.

Icon See page 246.

Cancel You do not save the recorded movie.

Information

Some movies might not be displayed correctly.

See page 113 for playback of the movie set for the Stand-by display.

Changing Settings for Shooting

Use Zoom

Information

The image quality may slightly change when you select “Wide” or “Tele”.

“Tele” is released in the following cases:

・When you press -h to end the camera

・When a size is changed

・When camera mode is switched

You can shoot with the outside camera which focuses on a subject.

When “Focus” is set to “Face detection”, faces are detected in the first place. When a

face is detected, the yellow frame is shown. Up to five faces are detected, and the

image is shot with a single face of those faces focused automatically according to the

face size and position. When multiple faces of people are found, the frame for a face to

be focused becomes yellow. When the detection fails, the focus function works in

“Auto” and then the image is shot.

Focus function works when you shoot a subject about 10 cm or more away.

1Finder displayXo

When a subject is focused, a confirmation tone sounds, the frame becomes green,

and the focus is locked.

When the subject is not focused, the frame becomes red.

Press r to focus again.

Use Focus Function

Information

If “Movie type set” is set to “Voice” in Movie Mode, you cannot use the focus function.

“Face detection” is available only in Photo Mode.

Even when “Focus” is set to “Face detection”, you might not be able to detect the face

in the following cases:

・When the face faces sideway or askew

・When the face is at a slant

・When part of the face is covered by glasses, a cap, or shadows

・When the face is extremely small, large, or dim when compared to overall screen

size

・When the face is placed at the edges of the display

The distance that faces can be detected by “Face detection” is within 2.5 m.

244

Camera

Setting Image Size and Image Quality

Function Menu of the Finder Display

Inside camera/

Outside camera

You can switch between the inside camera and outside

camera.

CHG camera-mode Select a mode.

When you select “Continuous mode”, the camera starts in

the mode you used last time, “Auto”, “Manual”, or “Auto

bracket”.

Image size Select an image size.

File size setting

[Movie Mode only]

Select an item.

Mail restrict’n (S). . . You can shoot up to 500 Kbytes.

Mail restrict’n (L) . . . You can shoot up to 2 Mbytes.

Long time . . . . . . . . . You can shoot for a long time. The

movie is saved to the microSD card.

Image quality You can set the image quality for saving.

Select an image quality.

Camera settings

Brightness You can adjust to -3 (dark) through +3 (bright).

Select a brightness level.

White balance You can adjust the coloring of the image on the Finder display

to create a natural color tone.

Select an item.

Auto . . . . . . . . . . . . . .For adjusting white balance

automatically

Fine . . . . . . . . . . . . . . .For shooting outdoors in fine weather

Cloudy . . . . . . . . . . . .For shooting in cloudy weather or in

the shade

Light bulb . . . . . . . . . .For shooting under incandescent light

Fluorescent light. . . .For shooting under fluorescent light

At Camera

start-up

±0

At Camera

start-up

Auto

Color mode set Select a color mode.

Normal . . . . . . . . For shooting in normal color.

Sepia . . . . . . . . . . For shooting in sepia color.

Monochrome . . . For shooting in monochrome.

Vivid . . . . . . . . . . For shooting with the vivid contours and

raised saturation.

Natural . . . . . . . . For shooting with the smooth contours and

lowered saturation.

Whitening . . . . . . For shooting faces in bright color.

Suntan. . . . . . . . . For shooting faces in dark color.

Photo mode You can set a photo mode suitable for the place.

Select a photo mode.

Normal . . . . . . Standard mode

Portrait . . . . . . For shooting portraits

Sports . . . . . . . For shooting moving subjects such as

athletes

Food . . . . . . . . For shooting dishes

Scenery. . . . . . For shooting scenery

Night mode. . . For shooting in dark places such as in

nighttime

Backlight. . . . . For shooting against the sun (from behind)

Character . . . . For shooting characters

Snow . . . . . . . . For shooting in snowy places

Sunset. . . . . . . For shooting in sunset

Pet . . . . . . . . . . For shooting pets, etc.

At Camera

start-up

Normal

At Camera

start-up

Normal

245

Camera

Focus You can set the focus of the outside camera.

Select an item.

Face detection . . . For focusing on a person’s face

Auto . . . . . . . . . . . . For focusing automatically before

shooting (See page 243)

Close-up . . . . . . . . For focusing on a subject in a short

distance

Landscape . . . . . . For focusing on a landscape in a long

distance

“Face detection” is available only in Photo Mode.

Img. stabilizer

[Photo/Movie Mode]

You can correct camera shake for when shooting with the

outside camera.

Auto or OFF

Shoot with frame

[Photo Mode only]

You can shoot a still image with a frame.

ON or OFFSelect a frame.

Shutter sound You can set a shutter sound. You can set a shutter sound

each for Photo Mode (Continuous Mode) and Movie Mode.

Select a shutter sound.

While you are selecting, the shutter tone sounds for

confirmation.

Flicker correction You can suppress blur on the Finder display for shooting with

the outside camera.

Auto, Mode 1 (50Hz) or Mode 2 (60Hz)

Storage setting

Store in You can set the storage location for the still images or movies

you shot.

Phone or microSD

Auto save set You can set whether to automatically save the image after

shooting. When “Store in” is “Phone”, the image is saved to

the “Camera” folder. When “Store in” is “microSD”, the image

is saved to the folder set by “Select storage”.

ON or OFF

File restriction See page 247.

At Camera

start-up

Photo Mode:

Face detection

Continuous/

Movie Mode:

Auto

At Camera

start-up

OFF

High sensitiv.

[Photo Mode only]

You can shoot with high-sensitivity when shooting with the

outside camera.

ON or OFF

Auto timer See page 247.

Cont. shooting set.

Continuous mode

[Continuous Mode

only]

Select a mode.

Auto . . . . . . . . . . Shoots automatically at an interval and with

the number of frames as specified by “Shot

interval” and “Shot number”.

Manual . . . . . . . . Shoots one by one manually with the

number of frames specified by “Shot

number”.

Auto bracket . . . Shoots automatically nine still images at an

interval of about 0.3 second while changing

the brightness and color tone one by one.

Select “Manual” to display the number of frames for

continuous shooting.

Shot interval

[Continuous Mode

only]

Select a shooting interval.

You can set this only in “Auto” of Continuous Mode.

Shot number

[Continuous Mode

only]

Enter the number of photos.

When “Image size” is set to “VGA (640 x 480)”, you cannot

change “Shot number”.

You can set this only in “Auto” or ”Manual” of Continuous

Mode.

Display size You can set whether to display a still image or movie in the

original size (Actual size) or to fit to the screen size on the

Finder display.

Actual size or Fit in display

Movie type set

[Movie Mode only]

You can select whether to record both the video and voice, or

one of them when you shoot the movie.

Normal, Video, or Voice

At Camera start-up

OFF

At Camera start-up

Normal

246

Camera

Common replay mode

[Movie Mode only]

You can set a shooting size appropriate for attaching to

i-mode mail.

YES

Image Size is set to “QCIF”, File Size Setting is set to “Mail

restrict’n (S)”, and Image Quality (Movie Mode) is set to

“Normal”.

Icon You can set whether to display icons.

ON or OFF

Memory info You can display the used memory space (estimate)/number of

stored items.

Information

When “Image size” is set to larger than “Stand-by (480 x 854)”, and you switch to the

inside camera, the camera starts up in “VGA (480 x 640)”.

When “File size setting” is set to “Long time”, “Store in” is set to “microSD”.

Even if you change the setting of “Brightness”, “White balance”, “Color mode set”, or

“Focus”, the setting appropriate for each “Photo mode” applies when you change

“Photo mode”

Note that the image may blur in Night Mode because the exposure takes a longer

time.

<Img. stabilizer>

Image Stabilizer function is only for decreasing the degree of camera shake, so its

effect differs depending on the subject or condition.

Image Stabilizer might not work effectively in the following cases:

・When the camera shakes to a great extent

・When zooming is in use

・When shooting moving subjects

When “Photo mode” of “Camera settings” is set to “Sports”, “Night mode”, or “Pet” in

Photo Mode, “Img. stabilizer” becomes invalid.

Residual images might remain in the area where the subject is moving, or noise might

be found in overall area. In that case, set this function to “OFF”.

In Movie Mode, the shooting range varies depending on the “Auto” or “OFF” setting

because peripheral pixels are used for the processing by Image Stabilizer.

When this function is activated in Photo Mode, the processing after shooting might be

about two seconds longer due to the processing by Image Stabilizer.

You cannot use Image Stabilizer for the inside camera.

When “Image size” is set to larger than “1M (960 x 1280)”, you cannot shoot with a

frame.

If you shoot a still image with a frame using the inside camera and save it, the frame is

also horizontally reversed when the still image is automatically reversed as a correct

image.

You cannot save the still image shot with a frame as the mirrored image.

If you set to “Auto”, it may take a while to automatically adjust the image quality. In this

case, switch to Mode 1 or Mode 2 according to the power frequency provided in the

shooting location.

See “Select storage” for how to set a storage location on the microSD card.

If you change “File size setting” to “Long time”, “Store in” is set to “microSD” and

“Storage setting” cannot be operated.

When “Auto save set” is set to “ON”, the image is saved to the latest folder if “Select

storage” is not set or the folder set as a destination folder is deleted.

When you set “High sensitiv.” to “ON” while setting “Image size” to larger than “2M

(1200 x 1600)”, “Image size” is changed to “1M (960 x 1280)”. In this case, if you

switch “High sensitiv.” to “OFF” without changing the setting of “Image size”, it returns

to the former setting before switching “High sensitiv.” to “ON”.

You cannot set “Image size” to larger than “2M (1200 x 1600)” while setting this

function to “ON”.

<Cont. shooting set.>

You cannot set “Continuous mode” to “Auto bracket” for the inside camera.

When switch to the inside camera while setting to “Auto bracket”, “Continuous mode”

is set to “Auto”.

The number of shots that can be set differs depending on the image size. The number

of shots that can be set is as follows:

VGA (480 x 640): 4

QVGA (240 x 320): 5 through 10

QCIF (144 x 176): 5 through 20

Sub-QCIF (96 x 128): 5 through 20

Information

247

Camera

You can set the file restrictions for when you save the shot still image or

movie. The operation of attaching to i-mode mail is disabled at the

receiving end who has received the image as the first distribution.

1Finder displayi()Storage setting

File restriction

Post View display in Photo Mode, Movie Mode or

Continuous Mode/Detailed display in Continuous Mode

i()File restriction

2File unrestricted or File restricted

For Post View display for Continuous Mode, you can change the settings of the

file restriction on the checked images.

When “Image size” is set to a size larger than “HVGA Wide (640 x 352)”, “Fit in

display” always applies.

When “Image size” is set to “QCIF (144 x 176)” or “Sub-QCIF (96 x 128)”, the image is

enlarged two times at both lengthwise and sidewise when it is displayed in “Actual

size”.

The setting for the Finder display is reflected in the Post View display; however the

setting for the Post View display is not reflected in the Finder display.

You cannot operate when you set “File size setting” to “Long time”.

File Restriction

Information

Even when you set “File restriction” to “File restricted”, the still images or movies can

be output from the destination mobile phone by transmitting the images using infrared

communication or by copying them to the microSD card.

After saving, you can use “File restriction” on page 348 to change the settings.

When you set “File size setting” to “Long time” in Movie Mode, “File restriction”

becomes “File unrestricted”.

1Finder displayi()Auto timerON or OFF

Enter a delay time (seconds).

Enter from “01” through “15”, in two digits.

“ ” appears on the Finder display.

If you press Oo() or 0, a confirmation tone sounds and “ ” blinks. The Call/

Charging indicator flickers every about 1 second until about 5 seconds before shooting.

From about 5 seconds before shooting, the Call/Charging indicator flickers every about

0.5 second, and the confirmation tone sounds every about 1 second. Shooting takes

place after the set delay time has elapsed.

To cancel shooting, press l() or r while the Call/Charging indicator is

flickering. Even if you cancel shooting, “Auto timer” stays set to “ON”.

You can shoot immediately by pressing Oo() or 0 before the delay time has

elapsed.

When you shoot, a confirmation tone sounds regardless of the settings such as

Manner Mode. You cannot change the sound volume for the confirmation tone.

Auto Timer

At Camera start-up OFF

When Auto Timer is set to “ON”

Information

You cannot use Auto Timer in “Manual” of Continuous Mode.

Auto Timer is set to “OFF” when shooting ends.

248

Camera

You can use the outside camera to scan JAN codes and QR codes and

store them as data files. Further, after downloading a compatible i-αppli

program, you can scan the code of Code 128 and store it as a data file.

From the scanned data, you can make calls, compose i-mode mail

messages, and access Internet web pages, and so on.

■When scanning with Bar Code Reader

Take the character strings as large as

possible within the guide frame.

Autofocus works when you scan a

code about 10 cm or more away from

it. When you scan a code in the

out-of-focus state, the recognition

rate lowers.

Scan so that the camera is in parallel

with the code.

■JAN Code

JAN Code is a bar code that denotes numerals with

the vertical bars of a different width.

You can scan 8-digit (JAN8) and 13-digit (JAN13)

JAN codes.

“4942857112597” is displayed when you scan this bar

code with the FOMA terminal.

■QR Code

QR Code is one of the 2-dimensional codes that denotes data in

the vertical and horizontal directions.

Kanji, katakana, alphanumeric characters, and pictographs are

displayed when you scan it. Some QR codes have image or

melody information.

“株式会社NTTドコモ (NTT DOCOMO, INC.)” is displayed when

you scan this QR code with the FOMA terminal.

Using Bar Code Reader

Scanning Code display

Guide frame

■Code 128

Code 128 is a bar code that denotes ASCII

code 128 characters (numerals, alphabets,

symbols and others) with the vertical bars

of a different width.

“NTT DOCOMO” is displayed when you scan this code by downloading a compatible

i-αppli program.

You can store up to 5 scanned codes.

You can scan up to 16 divided QR codes.

1mLifeKitBar code readerScan code

The Bar Code Reader menu is displayed.

You can paste the Bar Code Reader menu to the desktop. (See page 31)

2Fit a code to be scanned to the guide frame and press

Xo.

When the focus is locked, a confirmation tone sounds and the cross mark becomes

green.

Press i( ) and select “Brightness”; then you can adjust brightness to -3

(dark) through +3 (bright).

Press Co to show the reduced display, and press Vo to return to the former

display.

Scan a Code

At Bar Code Reader

start-up

Brightness: ±0

Zoom: Magnified view

249

Camera

3Press Oo().

The code is scanned. (The shutter tone does not sound.)

To cancel scanning, press r or Oo().

When scanning is completed, the scanning completion tone sounds and the Call/

Charging indicator lights. The sound level is fixed and cannot be changed.

However, the tone does not sound in Manner Mode or while “Phone” of “Ring

volume” is set to “Silent”.

“ ” is displayed for melody files and “ ” or “ ” is displayed for incompatible

or damaged files.

While you are entering (editing) characters, the Scanned Code Result display

does not appear; the Text Data Confirmation display of the scanned code

appears. To enter the scanned code, press Oo( ). To discard it, press

l() or r. The characters that cannot be displayed are replaced by

half-pitch spaces. When the code containing no text data has been scanned, the

code is not correctly displayed.

If scanning is not completed in a certain period, the scanning is suspended and

the Scanning Code display returns.

When the scanned code is part of divided QR codes, select “OK” to repeat step 2

and step 3 for scanning the rest of codes.

4i()Save resultOK

The scanned data is stored.

Scanned Code

Result display

Information

You cannot scan bar codes or 2-dimensional codes other than JAN codes, QR codes,

or Code 128.

Scanning may take a long time. Hold the FOMA terminal securely with your hands

during scanning.

You may not be able to scan codes correctly depending on scratch, dirt, damage, the

quality of printed material, light reflection, or QR code version.

You cannot scan some codes depending on the type or size.

Function Menu of the Scanned Code Result Display

Save result See page 249.

Display list You can show the Bar Code Reader list when one or more files

are stored.

Internet You can connect to the highlighted URL via i-mode or Full

Browser.

i-mode or Full BrowserYES

You can connect to the URL also by highlighting the URL and

pressing Oo().

Compose message You can compose an i-mode mail message to send to the

highlighted mail address. Go to step 3 on page 146.

You can compose it also by highlighting the mail address and

pressing Oo().

When you select “Compose message” from the Scanned Code

Result display, the data on the Scanned Code Result display is

entered into the address, subject, and text field.

Dialing You can make a voice call, videophone call, or PushTalk call to

the highlighted phone number.

Select a dialing type.

When you select “Select image”, select an image to send to the

other party during the videophone call.

When you select “Compose SMS”, you can compose an SMS

message to send to the phone number set as the destination

address. Go to step 3 on page 190.

You can make a call also by highlighting the phone number and

pressing Oo().

Dial

To make an international call, select “Int’l dial assist”. (See

page 61)

To set Caller ID Notification, select “Notify caller ID”. (See step 2

of “Set Caller ID Notification when Making a Call” on page 58)

Add to phonebook See page 94.

Add bookmark You can bookmark the site name and URL.

YES

Select “Page title” to edit the title.

OKSelect a destination folder.

250

Camera

Save image You can save the scanned image data to set to the Stand-by

display or other displays.

Select a destination folder.

Go to step 3 on page 203.

e sho when images are stored to the maximum.

Save melody You can save the scanned melody data to set it as a ring tone or

other tones.

YESSelect a destination folder.

Go to step 3 on page 205.

Select “ ” to play back the melody.

See page 205 when melodies are stored to the maximum.

Save ToruCa You can save the scanned ToruCa file.

Select a destination folder.

Select “ ” to display the ToruCa file.

See page 205 when ToruCa files are stored to the maximum.

Start iαppli You can start up i-αppli from the scanned data.

YES

Copy Select a start point for copying

Select an end point for copying.

You can copy codes of up to 5,000 full-pitch/10,000 half-pitch

characters.

See page 436 for pasting copied characters.

Information

URL can be displayed in up to 512 half-pitch characters.

If the scanned data contains nonenterable characters, you cannot enter it as a mail

address, and those characters may become spaces in the text field.

You cannot make emergency calls by scanning “110”, “119” or “118”.

You can display up to 512 half-pitch characters for a URL and can store up to 256

characters from the beginning.

The file name and title for the saved image are “imageXXX” (XXX are numerals).

1mLifeKitBar code reader

Saved data

The titles for stored data are displayed from the latest

one.

Select a title to show the Scanned Code Result display.

The file name for the saved melody is “melodyXXX” (XXX are numerals).

For the melody with no title, the file name is displayed as the title.

When playing back the melody, it is played back at the sound volume set for “Phone”

of “Ring volume”.

Display the Saved Data List

Information

Bar Code Reader list

Information

The titles for the scanned data are as follows:

(Example) When the scanned data is saved at 10:00 on November 18, 2008;

Title name: 20081118_1000_0000

・If you store multiple data items for the same date and time, the lower

four-digit numbers increase up to “9999”.

Function Menu of the Bar Code Reader List

Edit title Enter a title.

You can enter up to 9 full-pitch/18 half-pitch characters.

Result You can show the Scanned Code Result display for stored

data.

Delete

Delete this YES

Delete all Enter your Terminal Security CodeYES

251

1Seg

1Seg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252

Before Using 1Seg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

Setting Channels . . . . . . . . . . . . . . . . . . . . . <Channel Setting> 254

Watching 1Seg . . . . . . . . . . . . . . . . . . . . . . . . . <Activate 1Seg> 255

Using i-αppli Program Guide. . . . . . . <i-αppli Program Guide> 260

Using Data Broadcasting . . . . . . . . . . . . <Data Broadcasting> 260

Using TV Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<TVlink> 261

Recording a 1Seg Program while Watching . . . . . . . . . . . . . . . 262

Setting TV Timer/Timer Recording of 1Seg

. . . . . . . . . . . . . . . . . . . . . . . . . <TV Timer> <Timer Recording> 263

Settings 1Seg . . . . . . . . . . . . . . . . . . . . . . . . . . <User Settings> 268

252

1Seg

1Seg is the terrestrial digital TV broadcasting service for mobile objects, and it

broadcasts data as well as video and audio. Further, by using i-mode, you can obtain the

detailed information, can participate in quiz programs or can have fun with TV shopping.

For details on the 1Seg service, browse to the web page as follows:

The Association for Promotion of Digital Broadcasting

From personal computers: http://www.dpa.or.jp/english/

From i-mode: http://www.dpa.or.jp/1seg/k/ (In Japanese only)

■Using 1Seg

The 1Seg broadcasting is a service provided by television entrepreneurs (broadcasting

stations) without requiring the subscription. Further, you can watch 1Seg programs

charge free.

※For viewing fee of NHK, contact NHK.

The information displayed in the data broadcasting area contains “Data broadcasting”

and “Data broadcasting site”.

“Data broadcasting” is displayed on airwaves together with video and audio, and “Data

broadcasting site” is displayed by connecting from the information of data broadcasting

to the sites provided by television entrepreneurs (broadcasting stations). Also, it might

be connected to “i-mode site”, etc. When connecting to sites, you need to subscribe to

i-mode separately.

You are charged a packet communication fee for browsing “Data broadcasting site”

and “i-mode site”.

You might be charged an information fee for using some sites (i-mode pay sites).

■Radio waves

1Seg is one of the broadcasting services receiving radio waves (broadcasting waves)

different from that used for the FOMA services. Accordingly, you cannot watch the

broadcasting when you are out of reach of the broadcasting waves, or when the

broadcasting is suspended regardless of whether you are in or out of the FOMA service

area.

Even when you are in the terrestrial digital TV broadcasting service area, reception

condition might be deteriorated or you might not be able to receive programs in the

following places:

・Where the radio tower that transmits broadcasting waves is far away

・Where the radio waves are blocked by geographical features such as mountains or

valleys of high-rise buildings

・Where the radio waves are weak or do not reach, such as in tunnels, underground, or

recesses of buildings

The reception conditions might be improved by moving your FOMA terminal away from

or close to you, or moving yourself to another place.

1Seg ■Messages on the display when you use 1Seg for the first time

When you use 1Seg for the first time after purchase, the Exemption Clause Confirmation

display appears.

If you press Oo( ) and select “NO” from the succeeding confirmation display, the

same confirmation display does not appear afterward.

The Exemption Clause Confirmation display also appears when you replace the UIM

with another one or remove the UIM.

■What is broadcasting storage area?

The broadcasting storage area is a storage area inside the terminal that is exclusive for

1Seg. The information you input according to the instruction on the data broadcasting

program is saved to that broadcasting storage area following the settings of television

entrepreneurs (broadcasting stations). The information to be saved might contain

answers for quiz, and personal information such as membership number, gender, age,

or occupation.

The saved information might be displayed, or be sent to television entrepreneurs

(broadcasting stations) without your re-input when you browse to the data broadcasting

site.

See page 270 to erase information in the broadcasting storage area.

When you replace the UIM with another one or remove the UIM, the confirmation

display appears asking whether to reset the broadcasting storage area. Select “YES”,

and reset it. If you select “NO”, the services using the broadcasting storage area are

not available.

■Messages on the display when the information in the broadcasting storage area

is read out

When the information in the broadcasting storage area is used while you are watching a

program, the message “Use saved information? It may include information used by the

same broadcasting group” is displayed.

If you select “YES”, the confirmation display asking whether to read out the stored

information while watching the same program does not appear after that. Further if you

select “YES (default)”, the same confirmation display does not appear afterward.

253

1Seg

<Example> When you watch a 1Seg program for the first time

Store the channel list for the area you use. (See page 254)

Activate 1Seg. (See page 255)

■Battery level

If you try to start 1Seg or 1Seg starts automatically by TV Timer when the battery is low,

the battery alert tone sounds, and the confirmation display appears asking whether to

start it. Also, when the battery becomes low while you are watching or recording a 1Seg

program, the battery alert tone sounds, and the confirmation display appears asking

whether to end 1Seg. The battery alert tone sounds regardless of the setting of “Keypad

sound”.

When you do nothing from the confirmation display for about one minute, 1Seg

automatically terminates.

While “Rec. when low battery” is set to “ON”, the confirmation display does not appear

during recording. (See page 269)

If the battery level becomes low during recording and recording ends, the video

recorded up to that point is automatically saved.

During Multitask, the battery alert tone sounds but the confirmation display does not

appear. Switch to the viewer display and then operate.

Before Using 1Seg

How to Watch a 1Seg Program

Channel Setting

Activating 1Seg

■When a call etc. comes in while you are watching or recording a 1Seg program

When an event shown below occurs while watching or recording a 1Seg program, the

video and audio are suspended, and each function works. Recording is not suspended.

After you finish each function, you can resume watching a 1Seg program. See page 259

for receiving i-mode mail messages, SMS messages or Messages R/F.

Incoming voice call, videophone call, PushTalk call

(To start recording when a call is received, refer to “Rec. program when call”.)

Notification of Alarm, Schedule, ToDo, or TV Timer

(when “Alarm setting” is set to “Alarm preferred”)

Notification of Timer Recording

(When the start date/time comes, the FOMA terminal works according to the setting of

“Priority”.)

Information

1Seg is not available while “USB mode setting” is set to “microSD mode” or “MTP

mode” and the FOMA terminal is connected to a personal computer.

1Seg might automatically start when you end a call by closing the FOMA terminal

during a call. In such a case, be careful not to use the FOMA terminal close to your

ear because audio is output at the sound volume for 1Seg.

The life of battery pack may shorten if you watch 1Seg programs for a long time

during charging.

1Seg is not available overseas.

■Important

Note that we cannot be held responsible for loss or changes of the saved contents due

to a malfunction, repair, or other mishandling of the FOMA terminal. Furthermore, we

cannot move the saved information (such as still images, TV links, or information

saved to the broadcasting storage area) when you change your FOMA terminal or

have it repaired.

254

1Seg

To watch 1Seg programs, you need to execute Channel Setting and to

select a channel list in advance. You can store up to 10 channel lists.

The broadcasting stations you can receive differ depending on the local area. If you

store a channel list of the area for traveling or business trip, you can watch programs in

the area just by selecting the channel list.

The remote-control numbers you use with channel selections are previously set for

respective broadcasting stations.

You cannot execute Channel Setting during recording of a 1Seg program.

The broadcasting stations you can currently watch are automatically

searched and stored in a channel list.

You need to set this function in the terrestrial digital TV broadcasting service area.

1m1SegChannel settingAuto channel setting

YES

Searching takes place.

From the Channel list display, press i( ), select “Channel setting” →

“Auto channel set.”.

From the viewer display, press i( ), select “Disp.Ch./operation” →

“Channel setting” → “Auto channel set.”.

2YESEnter a title.

You can enter up to 11 full-pitch/22 half-pitch characters.

When you press Oo( ) without entering a title, the title name takes the

name of “YYYY/MM/DD hh:mm”. (Y: year, M: month, D: date, h: hour, m: minute)

To cancel searching midway, press l() or r; then select “YES”. You

can store the searched broadcasting stations in a channel list.

Setting Channels

Auto Channel Setting You can store the broadcasting stations set by prefecture to a channel

list.

1m1SegChannel settingSelect area

Select an areaSelect a prefectureYES

From the Channel list display, press i( ), select “Channel setting” →

“Select area”.

From the viewer display, press i( ), select “Disp.Ch./operation” →

“Channel setting” → “Select area”.

Information

When the multiple broadcasting stations which have the same remote-control number

are retrieved, the message to the effect that the remote-control number is doubled

appears. Select “OK” and select your area from the Local Area Selection display. The

channels in the area you select are preferentially assigned to remote-control numbers

1 to 12, and channels in the area you do not select are assigned to remote-control

numbers 13 onward.

The time to search channels requires for about 30 to 50 seconds. However, it differs

depending on the number of broadcasting stations or airwave conditions, and might

exceed 100 seconds.

Select Area

Information

Depending on the area, you may not be able to correctly store the broadcasting

stations by “Select area”. In that case, search for the broadcasting stations by “Auto

channel setting”.

255

1Seg

You can select a channel list to set the broadcasting stations you receive.

Also, you can edit the channel list already stored.

1m1SegChannel listSelect a channel list.

The channel list you receive

is set, and the detailed

display appears.

Select a broadcasting

station to watch a 1Seg

program.

When you select “Disp.Ch./

operation” and select

“Channel list” from the

Function menu of viewer display, the viewer display returns by selecting a

channel list.

You can watch a 1Seg program also by pressing l( ) from the Channel

list display and selecting a broadcasting station.

Select Channel List

Channel list display Detailed Channel list

display

Remote-control number

Function Menu of the Channel List Display

Channel setting See page 254.

Edit title Enter a title.

You can enter up to 11 full-pitch/22 half-pitch characters.

Delete YES

You cannot delete the channel list currently set.

Function Menu of the Detailed Channel List Display

Remote control No. You can change the broadcasting station set for the

remote-control number.

Select a broadcasting station you want to change

Select the remote-control number to be set.

If any broadcasting station has already been set for the

specified remote-control number, the broadcasting stations

switch positions. Repeat the operation to set a broadcasting

station for a remote-control number.

 l()YES

Just change the style to automatically switch between the vertical display

and horizontal display when you are watching. You can switch displays

manually also by pressing c in Normal Style.

When you use 1Seg for the first time, the Exemption Clause Confirmation display

appears. (See page 252)

You can start 1Seg also by using the channel information displayed in the i-αppli

Program Guide, sites, or mail. (See page 207)

You can play back the audio from 1Seg program by connecting the Flat-plug Stereo

Earphone Set (option). Also, you can play back the audio wirelessly from a commercial

Bluetooth device. (See page 426)

1Press and hold c for at least one

second.

1Seg starts from the channel you watched last time.

“ ” is displayed while watching a 1Seg program.

When you have not stored any channel list, the

confirmation display appears. Select “OK” and execute

Channel Setting. (See page 254)

You can start 1Seg also by switching to Horizontal

Open Style while the display for selecting a 1Seg

function is shown in Normal Style.

While “Work with style” is set to “1Seg”, you can start

1Seg also by switching to Horizontal Open Style from

the Stand-by display.

To end watching, press h and select “End 1Seg”.

You can switch to play background by selecting “Change to BGM”.

Delete YES

When you delete all the broadcasting stations in the channel

list, the channel list itself is deleted.

You cannot delete the broadcasting station in the channel list

currently set.

Watching 1Seg

Viewer display

256

1Seg

■About Viewer display

(When “Switch display” is “V. img+Caption+DBC”.)

Video

“ ” appears on the upper right of the display when the data broadcasting linked with

a 1Seg program is found while you are watching on the horizontal display or in the

multiwindow.

Caption

You can set display position of the caption on the horizontal display by “Caption posit.

in w-scr”.

Data Broadcasting

Operation Mode

Video Mode: Operates the video or audio. (See page 255)

Data Broadcasting Mode: Operates the data broadcasting. (See page 260)

Off Timer

“ ” appears while Off Timer is set.

ECO Mode

“ ” appears during ECO Mode.

Channel (Remote-control number)

Airwave Reception Level (estimate)

(strong) (weak)

“ ” appears out of the broadcasting area.

Reception of Caption

“ ” is displayed while caption information is being received.

Sound Volume





Guide display









Horizontal display



Vertical display



  



 





Program Information (outline)

The program name is displayed on the vertical display. The channel, start/end time,

and program name are displayed on the horizontal display.

Record Video

“ ” appears during video recording, and “ ” appears during video

recording by Timer Recording. “ ” appears during pause of recording.

Switch Display/Caption

Status of Video Image: ON/OFF/enlarged

Caption: ON/OFF

Icon/Caption

Icon: “ON/OFF” of “Icon”

Caption: Position ( : Lower, : Upper) and OFF

After you select a channel using Channel Search, the channel (Remote-control

number) might not be displayed.

, ,and are displayed when you operate keys or switch styles.

While “Icon” is set to “OFF”, the guide display on the horizontal display appears when

you operate keys or switch styles.

■Channel switching operation (in Video Mode only)

■Operations while watching a 1Seg program

Operation Key operation

Direct channel

selection

Remote control No.1~9 . . . . . 1~9

Remote control No.10. . . . . . . a

Remote control No.11. . . . . . . 0

Remote control No.12. . . . . . . s

Channel selection No

Channel search No(for at least one second)

Each time of pressing switches channels by searching

receivable broadcasting stations in order of frequency.

l() or r to suspend

Operation Key operation

Sound volume

adjustment

Bo※1 or <>

Mute/Release mute r※1

Start i-αppli

program guide

l()

※2

257

1Seg

※1 In Data Broadcasting Mode, you cannot operate.

※2 You cannot operate from the horizontal display in Normal Style.

※

3 You cannot operate

in Horizontal Open Style.

When you close the FOMA terminal, the vertical display returns. In Horizontal Open

Style, the horizontal display automatically appears; the vertical display does not appear.

※4 You can operate program information (outline) from the horizontal display.

Program info l(for at least one second)

Program info

(outline)

Switch display d while displaying program information (outline)

Each time of pressing from the horizontal display switches the

setting of “Icon” and “Caption posit. in w-scr”.

Switch display

directions/

Full display

c※3

In Video Mode, each time of pressing switches the display

directions.

In Data Broadcasting Mode, each time of pressing switches

between the normal display and the full display.

Record video Oo( )(for at least one second)※1 or p(for at least one

second)

Oo()

※1 or p to end

Record still image Oo()

※1 or p

Switch TV/data BC m()

※4

Each time of pressing switches between Video Mode and Data

Broadcasting Mode.

Operation Key operation

Information

Even when you switch displays by using Multitask while you are watching a 1Seg

program, the audio from the 1Seg program is output. (Play Background) The audio

might not be output, however, depending on the function or program. (See page 505)

When “TV sound while closed” is set to “ON”, the audio is output even if you close the

FOMA terminal while you are watching a 1Seg program. You cannot do anything

other than adjusting the volume when your FOMA terminal is closed.

The following might occur depending on the airwave conditions:

・The audio is interrupted.

・The data broadcasting is not operable.

・Block-shaped noise appears on the display or playing stops.

・The video or the data broadcasting is not displayed. (A dark screen appears.)

The caption might not be displayed depending on the program.

The data broadcasting cannot be displayed on the horizontal display.

If you move, the receivable airwaves or broadcasting stations might change being

affected by mountains or buildings. If reception on 1Seg goes bad after moving,

perform “Auto channel setting”; then reception might be improved via different

airwaves or you might be able to watch programs of other broadcasting stations.

If you use Channel Search to select channels after you move, etc., you might find the

channels you could not store by “Auto channel setting”. Execute “Add to ch. list” to

store the channels you found, and then you can watch the channel from the next time.

When starting 1Seg or switching channels, it takes a while before you can watch a

1Seg program.

Function Menu of Viewer Display

Information

Program info You can display information of the program you are

watching.

Program guide Seepage260.

Disp.Ch./operation

Channel info You can display the detailed display of the selected

channel list. Select a broadcasting station to switch to it.

Channel list Go to step 1 of “Select Channel List” on page 255.

Channel setting See page 254.

Add to ch. list You can add the broadcasting station you are currently

watching to the channel list.

YES

The broadcasting station is stored in the lowest

number of an unoccupied remote-control number

from 13 onward.

Tune service You can select a program to watch when the same

broadcasting station is broadcasting multiple services

(programs).

Select a channel.

Data broadcasting

Back to data BC You can stop browsing the data broadcasting site and

return to the data broadcasting.

258

1Seg

Reload contents You can reload the data broadcasting site being

displayed.

The confirmation display appears asking whether to

re-send the data you entered, depending on the site.

Certificate See page 197.

Set image display See page 208.

Sound effect See page 269.

ToruCa from dataBC See page 325.

Reset settings See page 269.

TVlink list You can display the TVlink list. (See page 261)

Compose message See page 259.

Settings

Display/operation

Switch display You can switch the contents of the viewer display.

Select an item.

If you set to “Enlarged V. img+DBC”, the video on the

vertical display is enlarged. However, the sides of the

video might be cut depending on the program.

Even if you set to “Data broadcasting”, the audio from

1Seg programs is output.

The operation mode automatically switches to Data

Broadcasting Mode when you display data

broadcasting in full display. When you release full

display of data broadcasting, the operation mode

returns to the setting just before changing display

mode.

Switch TV/data BC You can switch between Video Mode and Data

Broadcasting Mode while watching a 1Seg program on

the vertical display.

Icon See page 268.

AV output See page 398.

Video

At 1Seg start-up

When “Caption” is

set to “ON”:

V. img+Caption+

DBC

When “Caption” is

set to “OFF”:

Visual image+DBC

At 1Seg start-up

Video Mode

Brightness You can set the brightness of the display light to Level 1

(dark) through 5 (bright).

Select a brightness level.

If you set to “Auto setting”, it is adjusted automatically

in accordance with the ambient brightness sensed by

the light sensor.

The setting here is valid until you finish watching the

1Seg program. The setting at 1Seg start-up follows

the setting of “Brightness” of “Backlight” on page 116.

Mobile W-Speed See page 268.

Image quality See page 268.

LCD AI See page 117.

Sound

Sound effect

Auto volume See page 268.

Remaster See page 268.

Listening See page 269.

Equalizer See page 269.

Main/sub sound Main sound, Sub sound, or Main+sub sound

Switch audio data Sound 1 or Sound 2

You can switch only when audio that can be switched

is found.

TV sound w/ closed See page 269.

ECO mode See page 269.

Off timer When the specified time elapses, the confirmation

display appears asking whether to end watching or

recording a program (except for Timer Recording).

Select a time.

Key guide You can display the guide of key operation during

watching a 1Seg program.

At 1Seg start-up

Main sound

At 1Seg start-up

OFF

259

1Seg

You can compose and send i-mode mail messages while watching a

1Seg program. (Multiwindow)

When you send an i-mode mail message to the FOMA terminal

supporting the “Media To” function by “Recom. channel mail”, the

receiving end can start 1Seg by using the “Media To” function.

You cannot operate 1Seg while the Message Composition display is shown. You

cannot show the caption and data broadcasting, either.

You can compose SMS messages as well while watching a 1Seg program.

1Viewer displayi()Compose message

Compose message or Recom. channel mail

Compose message

. . . You can compose a new i-mode

mail message.

Go to step 2 on page 146.

Recom. channel mail

. . . You can compose an i-mode mail

message whose text contains the

information of the channel you

are watching.

Go to step 2 on page 146.

When the Message Composition

display is shown, you can switch

between the Message Composition display and the viewer display (horizontal

display) each time you press and hold c for at least one second.

Information

In the following cases, the Off Timer confirmation display appears after each

operation finishes.

・During recording standby for Timer Recording

・During recording by Timer Recording

・When a still image is being saved

・When an unsaved image is left

・During channel search by Auto Channel Setting

Send i-mode Mail while Watching

Message

Composition

display

Viewer display

Information



Even when you show the Message Composition display/detailed Sent Mail display by

Multitask while you are watching a 1Seg program, the display appears in the multiwindow.

The ticker on the viewer display notifies you of the receiving of an i-mode

mail message, SMS message, and Message R/F. You can show the

detailed Received Mail display while you are watching a 1Seg program.

(Multiwindow)

You cannot show tickers when “Mail ticker display” is set to “OFF” or during Public

Mode (Drive Mode).

Only the audio is output from a 1Seg program without showing the viewer display when

you show a mail message from the party whose mail address is not stored in the

Phonebook.

You cannot operate 1Seg while the detailed Received Mail display is shown. You

cannot show the caption and data broadcasting, either.

You can show an SMS messages as well while watching a 1Seg program.

1Receive i-mode mail while viewer display is shown

Press l( ) while the ticker is displayed.

When the detailed Received Mail display

is shown, you can switch between the

detailed Mail display and the viewer

display (horizontal display) each time you

press and hold c for at least one

second.

Only the audio is output from a 1Seg program without showing the viewer display if

you select “Mail history” from the Function menu of the Inbox/Outbox/Draft list or a

detailed mail display by Multitask while watching a 1Seg program and show the

detailed Sent Mail display of a mail message sent to a person whose mail address is

not stored in the Phonebook.

When “ ” or “ ” appears, press and hold +c for at least one second to switch to

the viewer display and then operate.

In B Mode of 2in1, you cannot compose/send i-mode mail message. (See page 450)

Receive i-mode Mail while Watching

Information

Detailed

Received

Mail display

Viewer

display

260

1Seg

By using the i-αppli Program Guide, you can select a program from the

program guide to start 1Seg or set TV Timer/Timer Recording. (See

page 302)

1m1SegProgram guide

Press l( ) from the display of “Gガイド番組

表リモコン (G Guide Program List Remote Control)” to

watch the program currently broadcast on the selected

channel.

For details, refer to “Mobile Phone User’s Guide

[i-mode] FOMA version”.

Information

Even if “Mail ticker display” is set to “Sender+subject”, the titles are not displayed for

Messages R/F, i-mode mail messages, and SMS messages received from the parties

not stored in the Phonebook.

Even when you show the detailed Received Mail display by Multitask while you are

watching a 1Seg program, the display appears in the multiwindow.

When “Mail ticker display” is set to “OFF” and “Receiving display” is set to “Alarm

preferred” and you receive a mail message while watching a 1Seg program, the

Reception Result display appears. The mail message is shown in the multiwindow

even when you show it from the Reception Result display. However, the viewer

display does not appear and the audio from a 1Seg program is not output when you

show a mail message from the party whose mail address is not stored in the

Phonebook.

When “ ” or “ ” appears, press and hold +c for at least one second to switch to

viewer display and then operate.

<i-αppli Program Guide>

Using i-αppli Program Guide

Information

You can set the i-αppli Program Guide by “Program guide key” of “Software setting”.

When you use “Gガイド番組表リモコン (G Guide Program List Remote Control)”

for the first time, you need to do initial settings.

1Seg enables you to use the data broadcasting in addition to the video

and audio. Various information including still images/movies is available

from the site linked with TV programs.

1Viewer display (Video Mode)

m()

Video Mode switches to Data Broadcasting Mode and

“ ” appears.

Audio from a 1Seg program is output even during Data

Broadcasting Mode.

You can display only data broadcasting when you press

c( ) in Data Broadcasting Mode. Press

c( ) to return to the former display.

2Select an item (link).

The confirmation display appears asking whether to connect to i-mode

depending on the data broadcasting and data broadcasting site.

See page 195 for the operation while a site is displayed.

This software program is not available when the mode of 2in1 is set to B Mode.

Using Data Broadcasting

Information

Each time you press +m( ), Video Mode and Data Broadcasting Mode are

switched.

You cannot display the data broadcasting on the horizontal display.

You cannot enter pictographs when you enter characters on data broadcasting or

data broadcasting site.

Depending on the program, the audio might be output while the i-mode site is

displayed. However, the 1Seg video is not displayed.

Depending on the program, a tone might be output when you display the data

broadcasting or data broadcasting site. In that case, the output of the 1Seg audio

temporarily stops, and the tone of the data broadcasting is preferentially output.

261

1Seg

You can use the highlighted information on the data broadcasting site to

easily use the functions such as making calls, or sending mail.

Select an item (link) and use the Phone To/AV Phone To or Mail To

function. (See page 206)

While the data broadcasting or data broadcasting site is displayed, the confirmation

display might appear asking whether to send the contents you entered on the site or

whether to permit obtaining mobile phone information.

When you select “YES (default)” from the confirmation display for data broadcasting,

the information on data broadcasting might be automatically updated, and you might

be charged a packet communication fee while watching a 1Seg program or playing

back a video. (See page 269)

If you move in a place where the airwave is unstable while watching a 1Seg program,

the video, data broadcasting, and data broadcasting site may be automatically

updated. In that case, the top page of the data broadcasting appears, and the

information you have entered into the connected data broadcasting or data

broadcasting site is cleared. Ensure that you watch the data broadcasting and data

broadcasting site in a place where the airwave is stable.

Use Highlighted Information for Various Operations

Information

Depending on the data broadcasting or data broadcasting site, the function of

composing i-mode mail or storing the Phonebook entries might be automatically used.

The confirmation display asking whether to use each function appears.

Some data broadcasting programs might contain TV links which lead to

the details of the programs or related information site.

From the TV links, you can store the site address information in the

TVlink list and can easily call them up for browsing later.

When you select the item (link) that can be stored in the TVlink list, the

confirmation display appears asking whether to store it in the TVlink list.

You can store up to 50 TV links.

1In Data Broadcasting Mode, select an item (link) that can

be stored in the TVlink listYES

When you try to store the same URL or memo information, the confirmation

display appears asking whether to overwrite it.

When the maximum number of TV links has already been stored in the TVlink list,

the confirmation display appears asking whether to store after deleting.

1m1SegTVlink

Select a TV link to be displayed.

When the confirmation display appears asking whether

to connect to i-mode, select “YES”.

For a link whose validity period is expired, the

confirmation display appears asking whether to delete it.

Using TV Link

Store in TV Link

Information

Validity period is set for some links.

When a URL for a link contains more than 60 half-pitch characters, you cannot store

the link.

Call Up a Stored TV Link

TVlink list

262

1Seg

■Icons in the TVlink list

You can save the program you are watching as video or still images.

The copy control signals such as “Copy never”, “Dubbing 10 (copy is possible to nine

times only with 1 generation)”, and “Copy free” are incorporated into 1Seg. The copy

control signals are determined by each broadcasting station.

You cannot record the programs of “Copy never”. Further, when the copy control signal

is changed to “Copy never” during recording, the recording session is closed, and the

video recorded up to that point is saved.

Icon Format Description

Memo information Displays memo information.

Link communication

contents

Connects to the data broadcasting site.

(Video and caption are not displayed.)

i-mode contents Connects to the i-mode site.

Full Browser contents Connects via Full Browser.

Function Menu of the TVlink List

Display detail Displays the title, URL, outline, content type, and validity

period of the TV link.

No. of TVlink Displays the number of the registered TV links.

Delete

Delete this YES

Delete selected Put a check mark for TV links to be deleted

l()YES

Delete all Enter your Terminal Security CodeYES

Recording a 1Seg Program while Watching

The recorded video is saved to the microSD card (“Data box”

→

“1Seg”

→

“Video”).

See page 360 for playing back the recorded video.

You cannot save the recorded video to the FOMA terminal.

1Viewer displayp(for at least one second)

The confirmation tone sounds, “ ” appears, and recording starts.

You can start recording also by pressing and holding Oo( ) for at least

one second in Video Mode.

When the airwave reception level indicates “ ”, you cannot record video. Even

if “ ” is indicated, you might not be able to record it depending on the airwave

conditions.

You cannot change the channel during recording.

2Press p.

The confirmation tone sounds and video is saved.

You can save the video also by pressing Oo( ) in Video Mode.



When the file size is larger than 2 Gbytes, or the storage location becomes full, the

recording automatically ends, and then the video recorded up to that point is saved.

■Estimate of the recordable time and the number of saved files

The maximum recordable time is estimation for 224 kbps of video, 48 kbps of audio,

and 52 kbps of data (including captions). The recordable time varies depending on the

broadcasting station or program.

The maximum file size for continuous recording is up to 2 Gbytes under SD-VIDEO

specifications.

The savable number of video files decreases depending on the data volume.

Record Video

Capacity of the

card

The maximum recordable

time (total)

The maximum savable

number

2 Gbytes Approx. 640 minutes

4 Gbytes Approx. xxx minutes

8 Gbytes Approx. xxx minutes

16 Gbytes Approx. xxx minutes

Information

The playing time of the saved data might become shorter than the recording time

depending on the airwave conditions.

The recording is not suspended even when you switch displays by Multitask or when

a call comes in during recording.

263

1Seg

The recorded still images are saved to your FOMA terminal (“Data box”→

“1Seg”→“Image” folder). You can save up to 3,500 files in total sharing

the memory space with other data files, however, the number of files you

can save decreases depending on the data volume. (See page 534)

See page 346 for displaying the recorded still image files.

You cannot save still images to the microSD card.

1Viewer displayp

The confirmation tone sounds, and the still image is saved.

You can record still images also by pressing Oo( ) in Video Mode.

When the airwave reception level indicates “ ”, you cannot record still images.

When the airwave conditions are changed to indicate “ ” during recording,

recording shifts to pause state, then “ ” and “ ” are displayed. Video and

audio during that period are not saved.

If you remove the battery pack or pull out the microSD card during recording, the

recorded data is saved to the microSD card as the file that cannot be played back.

Depending on the broadcasting station or program, video and audio might be saved a

few seconds after your recording operation.

You cannot record when the video storage area is full. Also, you might not be able to

record when the unused space in the storage area is not enough. Delete unnecessary

video files and try again.

Some programs cannot use the storage area fully.

The file name and title name of the saved video are as follows:

File name: “PRGXXX”

Title name: “YYYY/MM/DD hh:mm”

(X: numerals, Y: year, M: month, D: date, h: hour, m: minute)

You cannot set the recorded video for the Stand-by display, ring tone or Call

Receiving display.

You cannot save video during AV output.

Record Still Images

Information

The file name and title name of the saved still image are as follows:

File name: “YYYYMMDDhhmmXXX”

Title name: “YYYY/MM/DD hh:mm”

(Y: year, M: month, D: date, h: hour, m: minute, X: numeral)

You cannot set the recorded still image for the Stand-by display or the Call Receiving

display.

You can set TV Timer/Timer Recording of 1Seg. At the specified date/

time, an alarm sounds to notify you of the start of the program.

You can set TV Timer/Timer Recording also by using the channel information

displayed in the i-αppli Program Guide, sites, or mail. (See page 207)

You can set TV Timer by setting the date/time, channel, and program

name. You can use “Act. TV w/ alarm” to automatically start 1Seg at the

set time. You can set TV Timer for up to 100 programs.

1m1SegTV Timer listl()

Do the following operations.

Select a program you set TV Timer for to check the contents. You can edit them

by pressing l().

See page 205 when images are stored to the maximum.

Data broadcasting and caption cannot be saved as still images.

You cannot record still images during AV output.

Setting TV Timer/Timer Recording of 1Seg

TV Timer List

Information

Channel Select a channel.

Edit title Enter a program name.

You can enter up to 48 full-pitch/96 half-pitch characters.

Start date

setting

Enter a date/time for starting watching.

Select an item.

Enter date . . . . . . Enter a date/time directly.

Choose date . . . . Select a date from the Calendar and enter a

time.

264

1Seg

Repeat Select a type of repeat.

If you select “Select day”, put a check mark for days of the week

to be set and press l().

The item set with repetition is counted as one item.

Alarm Select an alarm method.

ON. . . . . . . . . . . .Alerts you at the time set for the start date/time

comes. The setting for alarm notification is

completed.

ON/Set time . . . .Alerts you at the time set as the prenotification.

OFF. . . . . . . . . . .Does not alert. The setting for alarm notification

is completed. (You cannot watch the 1Seg

program.)

Select how many seconds (minutes) before the specified

time to be alerted.

When you set “Auto power ON” to “ON”, you cannot set “15

seconds before”, “30 seconds before”, and “45 seconds before”

as the prenotification time.

Alarm tone Select a type of alarm toneSelect a folder

Select an alarm tone.

Volume Use Bo to adjust the volume.

If you set to “Step”, the alarm tone is silent for about three

seconds, and then the volume steps up every about three

seconds, from Level 1 through Level 6.

Act. TV w/ alarm Select an item.

Auto ON . . . . . . .After the Timer Alarm Notification display

appears, 1Seg automatically starts.

Manual ON. . . . .You can manually activate 1Seg from the Timer

Alarm Notification display.

OFF. . . . . . . . . . .The timer alarm sounds only. You cannot

activate 1Seg from the Timer Alarm Notification

display.

Auto power ON You can set whether to turn on the power automatically to sound

the timer alarm when the alarm time comes during power off.

ON or OFF

2Press l().

You can set timer recordings by setting the date/time, channel, and

program name. You can set up to 100 timer recordings.

1m1SegTimer recording listl()

Do the following operations.

Select a set timer recording to check the contents, and you can edit it by pressing

l().

You can display the used memory space (estimate) by pressing i().

1Seg volume You can set the sound volume of a 1Seg program when it is

activated by “Act. TV w/ alarm”.

Use Bo to adjust the volume.

Off timer You can set to end watching a 1Seg program for when the

specified time elapses after the 1Seg program automatically

starts by “Act. TV w/ alarm”.

Select a time.

Prefer manner

mode

You can set the sound volume of timer alarm for during Manner

Mode.

ON or OFF

ON . . . . Sounds at the same volume as set for “TV timer alarm”

on page 112.

OFF . . . Sounds at the volume set for this function.

Timer Recording List

Channel Select a channel.

Edit title Enter a program name.

You can enter up to 48 full-pitch/96 half-pitch characters.

Start date

setting

Enter a date/time for starting or ending recording. The timer alarm

sounds about one minute before the starting time.

Select an item.

Enter date. . . . . . . Enter a date/time directly.

Choose date . . . . Select a date from the Calendar and enter a

time.

End date setting

265

1Seg

2Press l().

When the confirmation display appears asking whether to set the timer recording,

select “YES”. If you select “YES (default)”, the same confirmation display does

not appear afterward.

Repeat Select a type of repeat.

If you select “Select day”, put a check mark for days of the week

to be set and press l().

The item set with repetition is counted as one item.

Alarm You can set whether to sound alarm at the specified time of timer

alarm.

ON or OFF

Volume Use Bo to adjust the volume.

You cannot set the volume to “Step”.

Priority You can set a recording operation for when the start date/time

arrives while operating a function which cannot be started up

simultaneously.

Recording or Operation

Recording. . . . Suspends and terminates the function being

operated, and starts recording.

Operation . . . . The confirmation display appears asking

whether to start recording. Select “YES” to

suspend and terminate the function being

operated and start recording.

For while operating a function which can be started up

simultaneously, recording starts by the Multitask function.

When the start time arrives during a call (including dialing and

ringing), recording starts after you end the call. When you are

using another function during a call, recording starts after you

end the call and the function.

Overwrite setting

When you set a recording to be repeated and set “Overwrite

setting” to “ON”, the program recorded last time is automatically

deleted and overwritten.

OFF or ON

Information

You can set TV Timer/Timer Recording also by using the program information

displayed in the i-αppli Program Guide, sites, or mail. In that case, the registration

display might appear with the start date/time, end date/time, channel, and program

name entered.

When you set TV Timer for multiple programs and set the timer alarm to sound at the

same date/time, the alarm preferentially sounds for the program whose start date/time

is the earliest. When the start date/time of the programs is the same, the alarm

preferentially sounds for the program you set last.

You cannot set multiple timer recordings whose recording time overlaps. If you set two

timer recordings and the recording end time of one program is the same as the

recording start time of the other, recording of the first program ends about one minute

earlier.

You cannot set TV Timer/Timer Recording for the programs whose start date/time or

timer alarm date/time is past (about one minute before the start date/time for Timer

Recording), except for the timer setting to be repeated.

The setting of TV Timer/Timer Recording whose timer alarm date/time is past is

automatically deleted. However, the timer setting to be repeated and the TV Timer

setting for which “Alarm” is set to “OFF” are not deleted. Further, the settings are not

deleted when you are operating the TV Timer/Timer Recording function at the alarm

date/time.

When no channel lists are set, you cannot set TV Timer/Timer Recording.

Turn off the FOMA terminal after setting “Auto power ON” to “OFF” when you are near

electronic devices using high-precision control or weak signals, or where the use is

prohibited such as in airplanes and hospitals.

When you have set “Priority” to “Operation” and the confirmation display is shown, the

recording does not start even at the recording start time and starts at the time you

select “YES”. However, the recording is not executed if the recording end time is over.

When “Overwrite setting” is set to “ON”, the timer recording starts after erasing the

program previously recorded. Regardless of whether you have watched the recorded

program or not, or whether you have succeeded or failed timer recording, the

previously recorded program is erased. If it is not erased before the timer recording

starts, recording might not start on time.

When you set “Overwrite setting” to “ON” for a recording, the file size of the recorded

video might become larger than that of the video recorded last time because the file

size varies depending on the recording (or watching) environment or programs. Note

that you might not be able to record correctly when the unused memory space in the

storage location is not enough.

The title of the recorded video file takes the program name booked for the timer

recording.

266

1Seg

The icon appears on the desktop.

“ ” . . . . Displayed when an alarm is set for today (except the setting for past time).

“ ” . . . . Displayed when an alarm is set for tomorrow or onward only.

If you set TV Timer with “Alarm” set to “OFF”, the icons are not displayed.

“ ” appears on the viewer display during recording by Timer Recording.

The audio from a 1Seg program is not output during recording started by Timer

Recording. You can output the audio by pressing -r or adjusting the sound volume,

however.

Function Menu while the TV Timer List or the Timer

Recording List is Displayed

Information

New Go to step 1 of “TV Timer List” on page 263 for TV Timer.

Go to step 1 on page 264 for Timer Recording.

Edit Go to step 1 of “TV Timer List” on page 263 for TV Timer.

Go to step 1 on page 264 for Timer Recording.

Sort You can change the display order.

Select an order.

Delete this YES

Delete past You can delete the setting of TV Timer/Timer Recording whose

start date/time or end date/time is set for the past date/time.

YES

Delete selected Put a check mark for the setting of TV Timer/Timer

Recording to be deletedl()YES

Delete all Enter your Terminal Security CodeYES

Memory info

[Timer Recording list

only]

You can display the used memory space (estimate).

When you set an alarm for “TV Timer” or “Timer recording”

If you set “Act. TV w/ alarm” to other than “Auto ON”, the alarm sounds for about five

minutes, and illumination lights. The vibrator works as the same setting for “Phone” of

“Vibrator”. The set start date/time, channel, program name and an animation appear on

the display.

If you set “Alarm” to “ON” and “Act. TV w/ alarm” to “Auto ON”, 1Seg automatically starts

when the specified time comes. The alarm does not sound.

To end watching, press h and select “End 1Seg”.

If you set “Off timer”, the confirmation display appears asking whether to continue

watching when the specified time elapses. If you select “NO” or do nothing for about 15

seconds, 1Seg automatically terminates.

About one minute before starting time, the alarm sounds for about two seconds, and

illumination lights. The vibrator works as the same setting for “Phone” of “Vibrator”. The

set start date/time, end date/time, channel, program name and an animation appear on

the display, then the viewer display appears. If you do nothing for about one minute after

the recording starts, the Stand-by display appears. You can show the viewer display by

pressing x and selecting “Activate 1Seg”.

To end recording started by Timer Recording to save video, press p from the viewer

display and select “YES”. In Video Mode, you can end recording to save video also by

pressing Oo ( ) and selecting “YES”.

During a call

The alarm sounds from the earpiece.

During operations

When “Alarm setting” is set to “Operation preferred”, the timer alarm sounds only when

the Stand-by display is shown. When it is set to “Alarm preferred”, the timer alarm

sounds even while you are operating another function or during a call. (See page 413)

Timer Recording works according to the setting of “Priority”. (see page 265) However,

Timer Recording might not work when you are reading to/writing from the microSD

card, or accessing the Data Storage Center.

When the time specified for “TV Timer” or “Timer recording”

comes

267

1Seg

When the timer alarm is set to the same time of “Alarm”, “ToDo”, or “Schedule”

The alarm sounds in the priority order of “Alarm” → “Timer recording” → “ToDo”→

“Schedule” → “TV timer”. A missed alarm of TV Timer/Timer Recording is notified by

the icon on the desktop.

When the power is turned off

The timer alarm does not sound except for the TV Timer setting with “Auto power ON”

set. For Timer Recording, you cannot record a 1Seg program unless the power is

turned on one minute before the start date/time.

The icon does not appear on the desktop even after turning on the power.

In Manner Mode

The vibrator, message display, and illumination light notify you. The alarm sounds at

the volume set for Manner Mode. (See page 111)

During Lock All, Personal Data Lock or Omakase Lock

The timer alarm does not sound. You cannot record a 1Seg program unless each lock

is released one minute before the start date/time.

After releasing each lock, the icon appears on the desktop to inform you.

During infrared communication, during iC communication, or while the microSD card is

operated

The timer alarm does not sound. You cannot record a 1Seg program unless each

function is finished one minute before the start date/time.

After each function is finished, the icon appears on the desktop to inform you.

While resetting settings or updating software program

The timer alarm does not sound. You cannot record a 1Seg program unless setting

reset or software update is finished one minute before the start date/time.

When the specified time comes during resetting settings, the icon does not appear on

the desktop even after resetting settings is completed.

Information

When you set “Alarm setting” to “Alarm preferred” for the setting of TV Timer/Timer

Recording and the alarm time comes while you are dialing, the alarm sounds after you

call up the other party. When the alarm time comes while ringing, the alarm sounds

after you start talking.

When you have set “PIN1 code entry set” to “ON” and set “Auto power ON” to

automatically turn on the power to sound TV timer alarm, the display for entering your

PIN1 code appears after the power is automatically turned on. The timer alarm does

not sound unless you enter your PIN1 code.

The alarm tone stops by pressing any of the keys, but the animation/i-motion becomes a

still image, and the timer alarm message stays displayed. When “Act. TV w/ alarm” is set

to “OFF”, press any key again to clear. However, you cannot clear the timer alarm

message by pressing a side key, with the FOMA terminal closed. When a call comes in,

the alarm stops.

Press Oo( ) and select “YES” from the Timer Alarm Notification display; then

1Seg starts, and you can watch the program set for TV Timer. In the case that a program

is being recorded, the video recorded up to that point is saved.

The icon appears on the desktop. You can check that icon for the contents of the missed

timer alarm (setting information) or recording result.

The setting information or recording result is the latest missed one.

When “Act. TV w/ alarm” is set to other than “OFF”, you can start 1Seg also by

pressing Oo( ) and select “YES” from the display of setting Information.

When recorded video is stored, you can play back the video also by pressing

Oo( ) from the display of recording result.

When you set “Auto power ON” to automatically turn on the power to sound a TV

timer alarm, the alarm sounds after the wake-up image stops.

You might not be able to set some i-motion movies/Chaku-uta Full® music files for TV

timer alarm.

Depending on the i-motion movie you set for TV timer alarm, only the audio might be

output at the specified time.

When a Chaku-uta Full® music file is set for TV timer alarm, only the audio is output at

the specified time. The illumination for when you play back a demo to select an alarm

tone differs from for when you are notified by an alarm.

To stop alarm tone/clear alarm message, animation, and

i-motion of TV timer alarm

When “Act. TV w/ alarm” of TV Timer is set to “Manual ON”

When “Timer Alarm Notification” is not executed or recording

is completed

Information

268

1Seg

You can display up to 20 recording results from the latest one.

1m1SegRecording result

Select a recording result.

To delete all recording results, press i(),

enter your Terminal Security Code, and select “YES”.

1m1SegUser settings

Do the following operations.

Recording Result

Settings 1Seg

Display

Caption You can set whether to display the caption for when

watching starts.

ON or OFF

Caption posit. in w-scr You can set the caption position on the horizontal display.

Upper or Lower

Icon You can set whether to always display guide (see

page 256) in the horizontal display.

ON or OFF

Even if you set “Icon” to “OFF”, the icon such as “ ”,

“ ”, “ ” or “ ” appears during communication or when

an i-mode mail message or Message R/F comes in.

Mail ticker display For when you receive an i-mode mail message, SMS

message, or Message R/F while watching a 1Seg

program, you can set whether to notify you of the receiving

by the ticker on the viewer display.

Select an item.

Sender+subject . . . .Displays ticker of the sender and

title.

Rcpt notification. . . .Displays ticker of reception

notification only.

OFF . . . . . . . . . . . . . .Does not display ticker on the

viewer display.

See page 259 for details on ticker display.

Video

Mobile W-Speed The outlines of images are automatically corrected so that

you can watch more smooth videos of 1Seg programs.

ON or OFF

Image quality You can change the image quality.

Select an item.

Standard . . . The average image quality

Sports . . . . . The image quality suitable for sports

programs

Cinema . . . . The image quality suitable for movies

Dynamic . . . The dynamic image quality by accentuation

Display light You can set the period of time of the display lights while

you are watching a 1Seg program.

Constant light or Lighting duration

Enter a lighting duration (minutes).

Enter from “01” through “30” in two digits.

Sound

Sound effect

Auto volume You can set whether to turn up the sound volume so that it

will be more audible.

ON or OFF

Remaster You can bring the sound from an earphone or Bluetooth

device to the original sound by complementing high-pitch

range lost at data compression.

ON or OFF

269

1Seg

Listening You can set sound effect for listening for the sound from an

earphone or Bluetooth device.

Select an item.

Surround . . . Makes the sound natural and stereophonic.

Natur 1/2 . . . Complements the cooped-up feeling

specific to earphones and plays back

natural sound. Select 1 or 2 according to

your taste.

OFF. . . . . . . . Sets Listening to “OFF”.

Equalizer You can change the quality of the sound from an earphone

or Bluetooth device.

Select an item.

Normal . . . . . Reproduces normal sound quality.

H.BASS1 . . . Enhances bass sound.

H.BASS2 . . . Enhances bass sound more deeply than

H.BASS1.

Voice . . . . . . Makes conversation audible.

Train . . . . . . . Minimizes abnormal sound that causes

sound leakage.

TV sound while closed You can set whether to continue outputting audio for when

you close the FOMA terminal while watching a 1Seg

program.

ON or OFF

When the setting is “OFF”, audio is muted when you

close the FOMA terminal. Audio is output again when

you open the FOMA terminal and select “OK”.

Recording

Rec. when low battery You can set whether to continue recording when the

battery runs short during recording.

ON or OFF

ON. . . . The confirmation display does not appear and

recording continues.

OFF. . . The confirmation display appears asking whether

to end recording.

Rec. program when

call

You can set whether to start recording automatically when

a call or PushTalk call comes in while watching a 1Seg

program.

ON or OFF

Data broadcasting

Set image display You can set whether to display images of the data

broadcasting site. (See page 208)

Sound effect setting You can set whether to sound an effect tone of the data

broadcasting and the data broadcasting site.

ON or OFF

Reset settings If you select “YES (default)” from the confirmation display

for data broadcasting while watching a 1Seg program or

playing back video, the same confirmation display does

not appear afterward for both of them. The confirmation

display resumes after you execute Reset Settings.

YES

ECO mode You can set ECO Mode which fixes some settings and

reduces the battery consumption.

YES

To release ECO Mode, perform the same operation.

Once ECO Mode is set, the following settings are fixed

and cannot be changed. However, if you release ECO

Mode, settings return.

Mobile W-Speed: OFF

Image quality: Standard

Remaster: OFF

Listening: OFF

Equalizer: Normal

Reset channel setting You can delete all channel lists.

Enter your Terminal Security CodeYES

270

1Seg

Reset storage area i()DeleteDelete this or Delete all

Delete this. . . . Deletes only the information of the

affiliated broadcasting stations you

selected, from the broadcasting storage

area.

Delete all . . . . . Deletes the information of all affiliated

broadcasting stations created in the

broadcasting storage area.

YES

If you select “Delete all”, you need to enter your Terminal

Security Code.

Reset TV settings You can reset each of “User settings” to the default.

See “Function List” for the items to be reset.

(See page 476)

Enter your Terminal Security CodeYES

Check TV settings You can check each of “User settings”.

Information

<Icon>

The guide display might appear even if “Icon” is set to “OFF” when the airwave

conditions have got worse.

When you set to “ON”, you might not be able to have enough effects of “Image

quality”.

Mobile W-Speed becomes invalid during ECO mode, displaying in the multiwindow,

or AV output.

Depending on the broadcast state, you might not be able to have the effects of Mobile

W-Speed.

Even when “Mobile W-Speed” is set to “ON” during recording or during timer

recording, it is invalid when you play back the recorded video.

During displaying in Multiwindow, the settings of this function is valid and follows the

settings of “Backlight” on page 116.

When “TV sound while closed” is set to “ON”, the information about the data

broadcasting might be automatically updated, and you might be charged a packet

communication fee.

Regardless of the setting of this function, the audio is output even if your FOMA

terminal is closed when you switch displays by Multitask, or when the displays are

shown in multiple windows.

<Rec. program when call>

The recording cannot be started when the call comes in the following cases:

・During playing background ・During displaying in the multiwindow

・During recording ・During recording by Timer Recording

・During recording standby for Timer Recording

If you change this setting, “Set image display” of “i-mode settings” is also changed.

You cannot reset the confirmation display at the start of 1Seg (see page 252) and at

the time of Timer Recording (see page 265).

Information

271

Music

Music&Video Channel

Music&Video Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272

Setting Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272

Playing/Operating Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . 274

MUSIC Player

Playing Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278

Saving Music Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278

Using MUSIC Player. . . . . . . . . . . . . . . . . . . . . <MUSIC Player> 280

Using Playlist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288

■Handling Music Files

You can use music files saved on the microSD card for personal use only. Before using, give enough consideration not to infringe on the third

party’s intellectual property rights or other rights such as copyright.

272

Music

Music&Video Channel is a service which automatically delivers up to

about one-hour programs at night by just setting your favorite music

programs in advance. Further, you can enjoy high-quality movie program

of up to about 30 minutes. Programs are updated periodically and you

can enjoy the delivered programs at your convenient time such as on

commuting.

■Before using Music&Video Channel

Music&Video Channel is a pay service which is available on a subscription basis. (You

need to subscribe to i-mode and Pake-Houdai, Pake-Houdai Full or Pake-Houdai

Double to apply for it.)

Other than the service fee for using Music&Video Channel, you might be separately

charged an information fee depending on the program.

If you insert the UIM to the Music&Video Channel incompatible FOMA terminal after

you subscribe to Music&Video Channel, you cannot use Music&Video Channel

Service. Note that the service fee applies unless you cancel the Music&Video Channel

subscription.

You cannot obtain or set programs during international roaming.※ Take procedures to

halt the distribution of programs before departure to overseas. Then, after

homecoming, resume receiving distribution.

※When you try to obtain or set programs during international roaming, note that you

are charged a packet communication fee for the i-mode communication.

You can use mail functions, display i-mode sites, and so on, while listening to program

using Music&Video Channel (Play Background).

See page 505 for the combination patterns of simultaneously usable functions.

For the details on Music&Video Channel, refer to “Mobile Phone User's Guide [i-mode

FOMA version]”.

Music&Video Channel

If you previously set a program that you want to watch, the FOMA

terminal automatically downloads the program data at night.

1mMUSICMusic&Video Channel

2Set programFollow the instructions on the display to

set a program.

For details, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”.

See page 205 when data files are stored to the maximum.

“ ” appears on the Stand-by display 12 hours before the time

the program obtaining starts. However, it does not appear if

you have inserted a UIM which is different from the one you

used to set the program.

Programs are automatically obtained at night. The display for

obtaining programs does not appear but “ ” appears on the

desktop when they are successfully obtained. Press Oo,

highlight “ ”, and press Oo( ) to display the

Music&Video Channel display.

When obtaining fails, “ ” appears.

Setting Programs

When a program is set

Information

When the communication is disconnected during obtaining a program, re-obtaining is

automatically tried up to five times by an interval of about three minutes. When a

display for obtaining a program is shown, however, the confirmation display appears

asking whether to re-obtain the program.

The ring tone does not sound and the vibrator does not work to notify that obtaining

programs starts or is completed. When you set “Music&Video Ch illum.” of

“Illumination” to “ON”, the Call/Charging indicator flickers when obtaining programs is

completed. (See page 120)

You can set up to two programs at once.

Note that a newly obtained program overwrites a saved program and you can no

longer play back that saved program afterward. To avoid overwriting, perform “Move

program” to move the program to the “Saved program” folder.

You cannot save the obtained program to the microSD card.

273

Music

1Music&Video Channel displaySet program

Follow the instructions on the display.

You can check or cancel the set program. For details, refer to “Mobile Phone

User’s Guide [i-mode] FOMA version”.

To set programs, you need to register the site which offers Music&Video Channel

programs to your My Menu. (See page 198)

If you have not subscribed to Music&Video Channel, select “About this service” to see

the Music&Video Channel introduction page.

When the programs could not be obtained due to “power off” or “low battery” at the

start time of program obtaining, re-obtaining is performed at night of the following day.

It may take a time to obtain programs, so fully charge the battery and operate in the

good radio wave conditions.

You cannot perform the setting operation and automatic obtaining of the program

selected on the Music&Video Channel display or the program in use.

When you cancel Music&Video Channel, the programs other than those moved by

“Move program” are deleted.

If you insert a UIM which is different from the one you used to set programs, programs

cannot be automatically obtained. Set the programs again from the Music&Video

Channel display.

When you select a service menu for Music&Video Channel, the message “Confirm

set up information?” appears. If you select “YES”, the programs that have been

distributed might be deleted. However, they will not be deleted while the distribution is

set to be halted.

If you insert the UIM of the FOMA terminal that you have been set for programs into

another Music&Video Channel compatible FOMA terminal, the programs cannot be

obtained automatically. Select “Set program” again from the Music&Video Channel

display to automatically update the program setting on the FOMA terminal, then the

programs can be obtained automatically.

Check/Cancel the Set Program

Information

Even if the setting of a program is canceled, My Menu is not deleted.

“ ” appears on the Stand-by display when the automatic program

obtaining fails or the program is not updated even after the program

distribution date. When the automatic obtaining fails, you can manually

obtain the program.

1Music&Video Channel displaySelect a programYES

For a partially obtained program, select “Play” to play it back.

For a program which has not been updated, select “Play” to play it back.

See page 205 when data files are stored to the maximum.

Obtain a Program Manually

Information

When obtaining of a program is suspended, the part of the program obtained up to

that point is saved. To obtain remaining part, you can manually obtain it except in

some time zones. When a program has been updated or switched to another

program, obtaining starts not from the suspended point but from the beginning.

You cannot re-obtain the program whose playable deadline has expired. Such a

program cannot be updated until the next distribution date.

You may not be able to manually obtain programs depending on the time zone.

274

Music

You can enjoy playing back programs in stereo sound by connecting the Flat-plug

Stereo Earphone Set (option). Also, you can enjoy playing back programs wirelessly by

using a commercial Bluetooth device. (See page 427)

1mMUSICMusic&Video Channel

Select a program.

“ ” is displayed while Music&Video Channel is

activated, and “ ” is displayed when the program

shifts to pause state during Play Background.

When a program is highlighted, the next distribution

date is displayed under the program name. It is not

displayed when the program distribution is suspended.

It might not be displayed when the automatic program

obtaining fails.

When information of the previously played program

exists, playback starts from the position and/or in the

mode accordingly.

Highlight a program and press l( ); then the

Chapter list is displayed.

Highlight a program and press m( ) to connect to the URL of the

program URL information.

The image on the right is displayed

when you cannot display a preview

image:

When you press and hold p for at least one second or press h during

playback or pause, playing back program ends.

Playing/Operating Programs

Music&Video

Channel display

Cannot be

played back

No preview

images

Updating

program

You can play back programs also from Data Box. From Data Box, you can

play back currently distributed programs as well as the programs that

have been distributed in the past and moved to the “Saved program”.

1mData boxMusic&Video Channel

Downloaded program or Saved program

Select a program.

You can switch display

format each time you press

c( ) from the

Program list.

■About Music&Video Channel Playback display

…Program image or program video

(When no images are stored, an animation

appears.)

…Chapter number/Number of chapters

(Chapter number only on the Private window)

…Chapter name/Artist name

…Program name

…Playback state

…Playback time/Total playback time

…Play mode (No indication for “Normal”)

: Repeat

…Equalizer

: Normal : H.BASS1

: H.BASS2 : Train

Operate Music&Video Channel from Data Box

Program Folder list Program list

When the FOMA terminal is closed











   











275

Music

…Stereo/Monaural

: Stereo : Monaural

…Listening (No indication for “OFF”)

: Surround : Natur1

: Natur2

…Remaster (No indication for “OFF”)

: ON

…Icon of Bluetooth connection (No indication for not connected)

: Being connected

…Sound volume

■Operation while playing back a Music&Video Channel program

Operation Key operation

Halt l()

Pause Oo() or p

Oo() or p to play back

Sound volume

adjustment

Bo or </>

Replay next chapter

Vo or >(for at least one second)

Replay previous

chapter

Co or <(for at least one second)

When playback time is over three seconds or no previous

chapter is found, you go back to the beginning of the file.

(fast forward)※

Press and hold Vo.

(fast rewind)※

Press and hold Co.

Connect to site m()

Switch vertical

display/horizontal

display

c()

Each time of pressing switches in order of playback on the

vertical display → playback on the horizontal display fitted to

the display size → playback on the enlarged full display.

Display next image 3

Display previous image

Remaster 9

Each time of pressing switches between “ON” and “OFF”.

※You cannot operate during pause.

From the Music&Video Channel Playback display, you can do the following

operations by using the switch of the Flat-plug Stereo Earphone Set (option) or

the Flat-plug Earphone/Microphone with Switch (option):

You can operate them when the FOMA terminal is closed as well.

■Icons on the Music&Video Channel display/the Program list

The icons on the Music&Video Channel display indicate the download status.

“ ” is added to the newly obtained program.

Some programs have restrictions on the number of playbacks, playable deadline, or

playback period. “ ” is added to the icon of the program with playback restrictions and

“ ” is added to the icon of the program with restrictions expired. You can check the

playback restrictions for the program by “Program info”.

Some programs have restrictions on operation. “ ” is added to the icon of the

program with operation restrictions.

Listening 8

Each time of pressing switches in order of “OFF” → “Surround”

→ “Natur1” → “Natur2”.

Equalizer 7

Each time of pressing switches in order of “Normal” →

“H.BASS1” → “H.BASS2” → “Train”.

Operation Key operation

Operation Switch operation

Pause Press once.

To play back, press again.

Replay next

chapter

Press twice in succession.

Replay previous

chapter

Press three times in succession.

When playback time is over three seconds or no previous

chapter is found, you go back to the beginning of the file.

Icon Description

Successfully obtained program

Broken program

Partially obtained program or unsuccessfully obtained program

276

Music

Depending on the program, its playable time zone is fixed. “ ” is added to the icon of

the program with time zone restrictions. The time follows the time information obtained

from the network.

When obtaining a periodically-updated program fails, “ ” appears to tell the program

has not been updated. “ ” disappears when obtaining the program starts.

The file restriction is set to all the Music&Video Channel programs. See page 247 for

the file restrictions.

Information

The information of the previously played program is erased if you do the following

operations:

･When you turn on/off the FOMA terminal

･When you update the program

･When you delete or move the previously played program

If you try to play back a program with a low battery, the confirmation display appears

asking whether to play it back. The battery alert tone sounds regardless of the setting

of “Keypad sound”. When the battery becomes low during playback (including during

Play Background), the playback pauses, and the confirmation display appears asking

whether to end the playback.

In the following cases, playback pauses and resumes after you finish each operation:

･When you make/receive a voice call, videophone call, or PushTalk call

･When you receive a mail message or Message R/F while “Receiving display” is set

to “Alarm preferred” or the Stand-by display is shown

･When an alarm of “Alarm”, “Schedule”, “ToDo”, “TV timer” or “Timer recording”

sounds

Depending on the function which occurred, the confirmation display might appear

asking whether to end the Music&Video Channel program.

If a black display appears after you play back a program with time zone restrictions,

playback starts at the next playable time zone.

If you playback a program in countries other than Japan, the playable deadline might

expire before or after the displayed deadline.

On the full display, you cannot play back the audio-only music programs and video

programs of QCIF (176 x 144) size or smaller.

If you playback on the full display, the image might be displayed with the right or

bottom side cut depending on the image size.

Function Menu of Music&Video Channel Display/Program

Folder List/Program List

Chapter list You can display the list of chapters set for the program. Select a

chapter to play back the selected chapter and afterward.

Press i() and select “Chapter info” to display the

information about the chapter title, playback time, etc.

Play mode setting Normal or Repeat

Normal . . . Plays back the program once in the order of the

chapters.

Repeat . . . Plays back the program repeatedly in the order of the

chapters.

Program info You can display the program title, distribution source, playback

restrictions, etc.

Move program

Programs currently distributed are updated to new programs on the

next distribution date. You can save the current programs by moving

them to the “Saved program” folder before the distributed program is

updated. You can check “Memory info” for unused memory space you

can save to. You can save up to 10 programs sharing the memory

space with other data files, however, the number of programs you can

save decreases depending on the data volume. (See page 534)

YES

See page 205 when programs are stored to the maximum.

Add desktop icon See page 31.

Edit title Enter a title.

You can enter up to 31 full-pitch/63 half-pitch characters.

Reset title You can reset the title to the default.

YES

Multiple-choice You can select and delete multiple programs stored in “Saved

program” folder.

Put a check mark for programs to be deleted

i()Delete

Connect to URL

You can access the URL when the program has the URL information.

YES

Display image You can display the program images stored in the program.

Press r to return to the list.

Memory info You can display the used memory space (estimate).

277

Music

Delete/Delete this You can delete the program.

YES

Delete all You can delete all the programs stored in the “Saved program”

folder.

Enter your Terminal Security CodeYES

Information

The playable mode setting is invalid for the programs having the time zone

restrictions.

Even if you set to “Repeat”, the program is not played back repeatedly if it has no time

zone restrictions but has restrictions on the number of playbacks.

You cannot move the program when its obtaining is not completed, or the move

restriction or time zone restriction is set for the program.

When the next program is delivered, the edited title is overwritten by the new title.

<Multiple-choice> <Delete/Delete this> <Delete all>

Even when you delete the program, the program setting is not released.

Function Menu during Playback/Pause

Chapter list See page 276.

Play mode setting See page 276.

Sound effect

Remaster You can bring the sound from an earphone or Bluetooth

device to the original sound by complementing high-pitch

range lost at data compression.

ON or OFF

Listening You can set sound effect for listening for the sound from an

earphone or Bluetooth device..

Select an item.

Surround . . . .Makes the sound natural and stereophonic.

Natur 1/2 . . . .Complements the cooped-up feeling specific to

earphones and plays back natural sound.

Select 1 or 2 according to your taste.

OFF . . . . . . . .Sets Listening to “OFF”.

Equalizer You can change the quality of the sound from an earphone or

Bluetooth device.

Select an item.

Normal . . . . . Reproduces normal sound quality.

H.BASS1 . . . Enhances bass sound.

H.BASS2 . . . Enhances bass sound more deeply than

H.BASS1.

Train. . . . . . . Minimizes abnormal sound that causes sound

leakage.

Program info See page 276.

Chapter info You can display the title, play time, etc. of the chapter currently

played back.

Connect to URL See page 276.

Previous image You can display a previous image.

Next image You can display a next image.

Information

Even if an earphone or Bluetooth device is not connected, the respective setting

contents are displayed on the display.

You can display up to three images, however, you may not be able to display them

depending on the program.

278

Music

You can play back music files on your FOMA terminal by using MUSIC

Player or i-motion player.

■MUSIC Player (See page 280)

By “MUSIC Player” of “MUSIC”, you can play back Chaku-uta Full® music files or music

files saved from music CDs to the microSD card via a personal computer.

You can display mail, i-mode sites, and so on, while listening to music by MUSIC

Player (Play Background).

See page 505 for the combination patterns that can be started.

■i-motion Player (See page 353)

From the “imotion” folder in “Data box”, you can play back the voice-only i-motion

movie (including music data of AAC format) or AAC format files stored on the microSD

card.

You can download Chaku-uta Full® music files from sites. You can save

up to 262.1 Mbytes of files including other data files. (See page 529)

1Call up a Chaku-uta Full® music file downloadable site

Select a Chaku-uta Full® music fileSaveYES

Select “Play” to play back the Chaku-uta Full® music file. See page 283 for

operations while a Chaku-uta Full® music file is being played back.

Select “Property” to display the Chaku-uta Full® music file information. (See

page 286)

See page 205 when Chaku-uta Full® music files are stored to the maximum.

2Select a destination folder.

Press l( ) to display folders at the second-tier level or lower, if they

exist. Press r to return to the upper level.

Playing Music

Saving Music Files

Download Chaku-uta Full® Music Files

When you press l( ) to suspend downloading or when the downloading is

suspended by an incoming call, the confirmation display appears asking whether to

resume downloading. Select “YES” to resume downloading the remaining part. Select

“NO” to show the data acquisition completion display. Select “Save pt.” to save it to a

folder in “i-mode” folder in “MUSIC” in “Data box”.

You can re-download the rest of the partially saved file from “Data box”.

The title name of the partially saved Chaku-uta Full® music file takes the date and time

when it is downloaded.

When the playable period or playable deadline of the partially saved Chaku-uta Full®

music file has expired, you cannot download the remaining segments of the file.

Further, the partially saved file is deleted when you save re-obtained data.

Uta-hodai files are the Chaku-uta Full® music files you can play back just for a period of

the contract with a content provider. The playable deadline is specified in the license

information that is downloaded together with the music file.

Even when the playable deadline has expired, you can play back the music file by

updating the license.

When a music file (Chaku-uta Full® music file downloaded on the membership service

basis) whose playable deadline has expired is found at the start of MUSIC Player, the

confirmation display appears asking whether to update the playable deadline. Select

“YES” to update the file (Packet communication fee is charged). Select “NO” not to use

the music file. See page 280 for starting MUSIC Player.

Some Uta-hodai music files are applied with surplus playable days even after the

playable deadline has passed. During this period, you can play back files without

updating the playable deadline information. When the surplus playable days are over,

you cannot play back the files. Also if you download a music file with playable period

not updated, you cannot play it back before it is saved.

When the upper limit of the (membership) music services you can register is exceeded,

the confirmation display appears asking whether to overwrite them. Select “YES” to

overwrite a music service whose playable deadline is the oldest. You can no longer

play back the music files downloaded from the overwritten service.

Packet communication fee charged for updating a playable deadline during

international roaming is not supported by Pake-Houdai, Pake-Houdai Full and

Pake-Houdai Double.

When downloading Chaku-uta Full® music file is suspended

About Uta-hodai

279

Music

You can use Windows Media Player 10/11 to save Windows Media®

Audio (WMA) files from a personal computer to the microSD card.

You can save up to 600 WMA files.

As well as music files, you can save playlists, jacket images, and license keys.

First, prepare the devices required for saving WMA files.

P-01A

microSD card

FOMA USB Cable with Charge Function 01/02 (option)

Personal computer with Windows Media Player 10 (10.00.00.3802 or later)/11 installed

･

When you use Windows Media Player 10/11 in Windows XP, use Windows XP

Service Pack 2 or later. When you use Windows Vista, use Windows Media Player 11.

Before connecting the FOMA terminal to a personal computer, you need to check the

version of Windows Media Player.

Set “USB mode setting” to “MTP mode”. (See page 379)

Information

You can save up to 5 Mbytes per Chaku-uta Full® music file.

When the Uta-hodai music file set for the ring tone or alarm tone needs to be updated

because the playable deadline has expired, the default tone sounds when a call

comes in, or an alarm sounds/vibrates.

For a Chaku-uta Full® music file that has restrictions on the number of playbacks,

playable period, or playable deadline, “ ” is displayed at the head of the title. If you

remove the battery and keep it aside for a long time, the date/time information in the

FOMA terminal might be reset. In that case, you cannot play back the Chaku-uta Full®

music file that has restrictions on the playable period or playable deadline. See “Music

info” for checking the playback restrictions.

Partially saved Chaku-uta Full® music files cannot be played back from Data Box.

Save WMA Files

Prepare devices required for saving WMA files

Use the FOMA terminal as reader/writer

Start Windows Media Player 10/11 and save WMA files to the microSD

card.

You cannot save WMA files to the FOMA terminal.

For how to operate Windows Media Player 10/11, refer to Help for Windows Media

Player 10/11.

When you finish saving, remove the FOMA USB Cable with Charge Function 01/02

from the FOMA terminal.

When you remove the FOMA USB Cable with Charge Function 01/02, remove it after

finishing the software in use.

You have the ability to save music files using the Napster® application.

Please download the Napster® application from the following web page (in Japanese

only):

http://www.napster.jp/

If you have any questions about the Napster® application, refer to the following web

page (in Japanese only):

http://www.napster.jp/support/

Save music files to the microSD card

About the Napster® Application

Information

Do not remove the microSD card during saving a file. You may lose the file.

Music files and jacket images are saved to PRIVATE/DOCOMO/MMFILE/WM/ on the

microSD card.

The WMA files saved to the microSD card using another FOMA terminal might not be

recognized by the P-01A. Further, the files might not be recognized by the P-01A

even when it is connected to the personal computer with “USB mode setting” set to

“MTP mode”.

In that case, delete “WM” folder and “WM-SYSTEM” folder on the microSD card by

using your personal computer, or format the microSD card (see page 378). Note that

not only music files but also all the other files are deleted when the microSD card is

formatted.

When unused memory space on the microSD card becomes 300 Kbytes or less, the

card might not be recognized by a personal computer. Check the unused memory

space on the microSD card, and delete unnecessary data files if the unused memory

space is 300 Kbytes or less, then connect to the personal computer after setting “USB

mode setting” to “MTP mode”.

280

Music

By using SD-Jukebox (commercial item), you can save the music files on

the music CDs to the microSD card as AAC format data.

By using the microSD card adapter (option), you can save music files to the microSD

card directly from a personal computer as well.

※The following steps are an example for when the FOMA terminal is used as a

microSD reader/writer for saving music files.

You can purchase SD-Jukebox from the following web page (in Japanese only):

http://www.sense.panasonic.co.jp/PanaSense/special/soft/sd_jukebox/

For details about operating environments, refer to the following web page (in Japanese

only):

http://panasonic.jp/support/software/sdjb/

First, prepare the devices required for saving music files.

P-01A

microSD card

FOMA USB Cable with Charge Function 01/02 (option)

Personal computer (Windows XP, Windows 2000, or Windows Vista)

SD-Jukebox (commercial item)

Music CD you want to save

Install SD-Jukebox on the personal computer.

Set “USB mode setting” to “microSD mode”. (See page 379)

Save Music Files by Using SD-Audio

About SD-Jukebox

Prepare devices required for saving music files

Install SD-Jukebox

Use the FOMA terminal as reader/writer

Start SD-Jukebox and set a music CD on the personal computer. Then

use SD-Jukebox to save music files to the microSD card.

For how to operate SD-Jukebox, refer to Help for SD-Jukebox.

When you finish saving, remove the FOMA USB Cable with Charge Function 01/02

from the FOMA terminal.

You can play back Chaku-uta Full® music files obtained from sites or

music files saved to the microSD card.

To play back music files, select “MUSIC Player” from “MUSIC” on Main

Menu. Play Background is available so that you can use mail functions,

display sites, and so on, while listening to music.

To manage folders or data files, select “MUSIC” from “Data box” on Main

Menu.

Note that battery consumption will be faster when you use MUSIC Player.

You can enjoy playing back music in stereo sound by connecting the Flat-plug Stereo

Earphone Set (option). Also, you can enjoy listening to music wirelessly by using a

commercial Bluetooth device. (See page 427)

If the number of stored files increases, it may take long to start MUSIC Player.

Save music files to the microSD card

Using MUSIC Player

281

Music

1Press and hold p for at least one

second.

The Player Menu display appears.

 When the information about the previously played

music file remains, the playback starts according to the

position to play or mode of the information. You can play back also by pressing

and holding p for at least one second with the FOMA terminal closed.

2Select an item.

All tracks. . . Displays all the music files saved on the FOMA terminal and

microSD card.

Artist . . . . . . Displays all the artist names.

Highlight the name of the artist you want to listen to and press

Oo( ), then all the album names of the selected artist are

displayed. (Go to Album)

Album . . . . . Displays all the albums.

Highlight the name of the album you want to listen to and press

Oo().

Genre. . . . . . Displays all the genres.

Highlight the genre you want to listen to and press Oo().

Playlist. . . . . Displays all the playlists created by the FOMA terminal and personal

computer.

See page 289 for the playback of playlists.

Play Back Music Files

Player Menu display

The “★” mark is added to the

playlist which is being played

back or was previously played

back.

When you select “Artist”,

“Album”, or “Genre”, and press

l( ) from the Type list,

all the music files stored in the

selected item are played back.

You can switch display format

each time you press

c( ) from the Music

list.

When “ ” is displayed on

the Type list or the Music list,

you can display the playback display of previously played back music file or

music file in-play by pressing m().

You might not be able to display all the stored music files depending on their file

size.

The image on the right is displayed

when you cannot display a preview

image:

3Select a music file.

Playback starts from the selected music file in the order listed on the Type list or

playlist. “ ” is displayed while MUSIC Player is activated, and “ ” is

displayed when the music shifts to pause state during Play Background.

The “★” mark is added to the music file which is currently played back or was

previously played back.

Playback continues even if you close the FOMA terminal during playback.

When you press and hold p for at least one second during playback, pause, or

halt, or press h, MUSIC Player ends.

When you press m() or r during playback, the former Music list is

displayed.

Type list

(For Artist)

Music list

Cannot be

displayed

Incomplete

download

No image,

etc.

282

Music

1mData boxMUSIC

2Select an item.

MUSIC Player. . . MUSIC Player starts. (See page 281)

i-mode. . . . . . . . . Displays the i-mode (Chaku-uta Full®) Folder list. Select a folder.

WMA . . . . . . . . . . Displays the WMA list.

Each time you press m

from the i-mode (Chaku-uta

Full®) Folder list, you can

switch between the folders

in the FOMA terminal and

the microSD card.

You can switch display

format each time you press

c( ) from the

Chaku-uta Full® Music list

and WMA list.

See page 281 when you

cannot display a preview

image.

See page 205 when you

select “Search by i-mode”.

Some WMA files have playable license (number/period/

deadline).

Manage Folders or Music Files

Music Folder list

i-mode (Chaku-uta

Full®) Folder list

Chaku-uta Full®

Music list

WMA list

3Select a Chaku-uta Full® music file or WMA file.

Only the selected music file is played back as a demo.

When you close the FOMA terminal during playback, the playback stops.

To terminate playback, press and hold p for at least one second or press h

during playback or pause.

You might be able to play back a Chaku-uta Full® music file by pressing

l( ) or selecting “Play” from the Function menu while selecting it on

another function.

Chaku-uta Full® music files are shown by titles for control (“Music title - Artist

name” in default title) when you display them from the “i-mode” folder. When you

operate them from “MUSIC Player”, they are shown by titles.

■About playback display during using MUSIC Player

…The jacket image which is stored in the music file

(When no images are stored, an animation

appears.)

…Track number/Number of total music files

(Only track number on the Private window)

…Title

…Artist name

…Playback state

…Playback time/Total playback time

…Play mode (No indication for “Normal”)

: Play only one : Repeat one

: Repeat all : Random

: Random play & repeat

: Demo (Displayed only in demo playbacks.)

…Equalizer

: Normal : H.BASS1

: H.BASS2 : Train

…Stereo/Monaural

: Stereo : Monaural

…Listening (No indication for “OFF”)

: Surround : Natur1 : Natur2

…Remaster (No indication for “OFF”)

: ON

…Icon of Bluetooth connection (No indication for not connected)

: Being connected

…Sound volume

When the FOMA

terminal is closed















 





283

Music

■Operations of MUSIC Player in use

※You cannot operate during halt or pause.

You cannot use some operations during playback of a demo.

Operation Key operation

Halt l()

Oo() or p to play back

Pause Oo() or p

Oo() or p to play back

Sound volume

adjustment

Bo or </>

Replay next file Vo or > (for at least one second)

Replay previous file Co or < (for at least one second)

When playback time is over three seconds, no previous

music file is found, and “Random” or “Random play&repeat”

is set, you go back to the beginning of the file.

Search (fast forward)

※Press and hold Vo.

Search (fast rewind)※Press and hold Co.

Display list m()

Play background c()

Display image/

Display lyric/Player

Each time of pressing switches displays in order of “Playback

display (Jacket image)” → “Full display lyric image” → “Full

display jacket image”.

Display next image 3

Display previous image

Remaster 9

Each time of pressing switches between “ON” and “OFF”.

Listening 8

Each time of pressing switches in order of “OFF” →

“Surround” → “Natur1” → “Natur2”.

Equalizer 7

Each time of pressing switches in order of “Normal” →

“H.BASS1” → “H.BASS2” → “Train”.

From the playback display during using MUSIC Player, you can operate

the following by using the switch of the Flat-plug Stereo Earphone Set

(option) or the Flat-plug Earphone/Microphone with Switch (option):

You can operate them when the FOMA terminal is closed as well.

■Playback specifications of Chaku-uta Full® music files

■Playback specifications of SD-Audio files and number of storable files

※Except “All tracks”.

■Playback specifications of WMA files and number of storable files

Operation Switch operation

Pause Press once.

To play back, press again.

Replay next file Press twice in succession.

Replay previous file Press three times in succession.

When playback time is over three seconds, no previous

music file is found, and “Random” or “Random play&repeat”

is set, you go back to the beginning of the file.

File format MP4

Codec MPEG-4 AAC

MPEG-4 AAC+ (HE-AAC)

Enhanced aacPlus

Bit rate 8 to 128 kbps

Extension 3gp

File format MPEG-2 AAC, MPEG-2 AAC+SBR

Bit rate 32 to 256 kbps

Maximum number of

storable files

999 files

Maximum number of

playlist

99 files (Up to 99 files can be stored in a single playlist.※)

File format WMA (Windows Media Audio 9 Standard)

Bit rate 32 to 192 kbps

Maximum number of

storable files

Maximum 600 files

Maximum number of

playlist

100 files (Up to 250 files can be stored in a single playlist.)

284

Music

■Icons on the Music list

When you select a music file from “MUSIC→MUSIC Player”, the following icons are

displayed:

■Icons on the Chaku-uta Full® Music list

When you select a Chaku-uta Full® music file from “Data box→MUSIC”,

the following icons are displayed:

Some Chaku-uta Full® music files and Uta-hodai music files have restrictions on the

number of playbacks, playable deadline, or playable period. The following icons are

added.

･File with playback restrictions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . “ ”

･File with playback restrictions expired . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . “ ”

･Playable Uta-hodai music file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . “ ”

･Uta-hodai music file which needs to be updated because the playable

deadline has expired. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . “ ”

･Unplayable Chaku-uta Full® music file or Uta-hodai music file. . . . . . . . . . . “ ”

You can check the playback restrictions for the file by “Music info”.

Icon Description

Stored in the FOMA terminal

Stored on the microSD card

SD-Audio file format

Chaku-uta Full® file format

WMA file format

UIM security function

Chaku-uta Full® music file with playback restrictions

Chaku-uta Full® music file with expired playback restrictions

Playable Uta-hodai music file

Uta-hodai music file which needs to be updated because the

playable deadline has expired

Unplayable Uta-hodai music file

File with file restrictions

Icon Audio format Type

AAC, AAC+(HE-AAC),

Enhanced aacPlus MP4 file

— Partially saved Chaku-uta Full® music files

All Chaku-uta Full® music files are set with file restrictions. See page 247 for file

restrictions.

※For the copyrighted file movable to the microSD card, “ ” is displayed.

Icon Acquired source

※Sites

Information

Even when the file format is supported, you might not be able to play back some files.

The information of the previously played music file is erased if you do the following

operations:

･When you remove/insert the microSD card

･When you turn on/off the FOMA terminal

･When you execute “Reset settings” or “Initialize”

･When you delete the previously played music file

･When you delete the previously played playlist

･When you do not insert the microSD card on which the previously played music file

is stored

･When you set “USB mode setting” to “microSD mode” or “MTP mode” and connect

to a personal computer

･When you played back a music file from other than a playlist last time, and then

when you perform “Edit music info” or “Reset music info”, or when you newly

download, save or delete a Chaku-uta Full® music file

･When the music file previously played is an Uta-hodai music file which needs to be

updated because the playable deadline has expired

･When the previously played music file is a WMA file and when the WMA license

becomes invalid

Partially saved Chaku-uta Full® music files are not displayed when you operate from

MUSIC Player.

If you try to play back a music file with a low battery, the confirmation display appears

asking whether to play it back. The battery alert tone sounds regardless of the setting

of “Keypad sound”. When the battery becomes low during playback (including during

Play Background), the playback pauses, and the confirmation display appears asking

whether to end the playback.

Note that the battery is consumed sooner if you perform the fast-forward and other

similar operations frequently.

285

Music

In the following cases, the playback pauses and resumes after you finish each

operation:

･When you make/receive a voice call, videophone call, or PushTalk call

･When you receive a mail message or Message R/F while “Receiving display” is set

to “Alarm preferred” or the Stand-by display is shown

･When an alarm of “Alarm”, “Schedule”, “ToDo”, “TV timer” or “Timer recording”

sounds

Depending on the event which occurred, the confirmation display might appear

asking whether to end MUSIC Player.

When a music file is switched to the previous or next one, the music file whose

playable deadline or playable period has expired, or WMA file whose WMA license

becomes invalid is skipped. When the Chaku-uta Full® music file has restrictions on

the number of playbacks, the confirmation display appears asking whether to play it

back regardless of the remaining number of playbacks. However, the music file

whose number of playbacks has finished is skipped.

When unused memory space on the microSD card becomes 300 Kbytes or less, you

can no longer play back WMA files. To play back WMA files, check the unused

memory space on the microSD card, and delete unnecessary data files if the unused

memory space is 300 Kbytes or less.

Function Menu of the Music Folder List/i-mode (Chaku-uta

Full®) Folder List/Player Menu Display

Information

Play mode setting Select a play mode.

Normal . . . . . . . . Plays back the music files sorted by type or in

the playlist in order as listed.

Finishes after the last music file is played

back.

Play only one . . . Plays back the selected music file once.

Repeat one. . . . . Plays back the selected music file repeatedly.

Repeat all . . . . . . Plays back the music files sorted by type or in

the playlist in order as listed repeatedly.

Random . . . . . . . Plays back the music files sorted by type or in

the playlist at random. Finishes after all the

music files are played back.

Random play&repeat

. . . . . . . . . . . . . . . Plays back the music files sorted by type or in

the playlist at random repeatedly.

Add folder Enter a folder name.

You can enter up to 10 full-pitch/20 half-pitch characters.

You can create a total of 25 folders at each level up to the

second-tier level in the FOMA terminal. You can create folders

at each level up to the seventh-tier level on the microSD card.

Edit folder name Enter a folder name.

You can enter up to 10 full-pitch/20 half-pitch characters.

Delete folder You can delete a user folder and all Chaku-uta Full® music files in

the folder.

Enter your Terminal Security CodeYES

Select storage You can set the destination folder for when you move the

Chaku-uta Full® music file to the microSD card. You can set it for

up to seventh-tier-level folders.

YES

Memory info You can display the used memory space (estimate)/number of

stored items.

Information

You cannot create a user folder in the WMA folder.

If you delete the Chaku-uta Full® music file set for another function, the setting returns

to the default.

“ ” is displayed for the folder set as a destination.

When you execute Check microSD, or create or edit a folder by using a personal

computer, the destination folder on the microSD card might be changed. When the

setting is changed, set the destination folder again.

Function Menu of the Chaku-uta Full® Music List/Type List/

Music List/WMA List

Player menu You can show the Player Menu display from the Type list or

Music list.

Play mode setting See page 285.

286

Music

Set as ring tone

Fullsong ring tone You can set a full piece of Chaku-uta Full® music file as a ring

tone.

Select an item.

For a Chaku-uta Full® music file on the microSD card, the

confirmation display appears asking whether to move it to

the FOMA terminal. (See “Move Files from the microSD

Card to the FOMA Terminal” on page 376.)

Point ring tone You can set a part of Chaku-uta Full® music file as a ring tone.

Select a range to be setSelect an item.

You can check the range to be set by pressing

l().

For a Chaku-uta Full® music file on the microSD card, the

confirmation display appears asking whether to move it to

the FOMA terminal. (See “Move Files from the microSD

Card to the FOMA Terminal” on page 376.)

Music info You can display the title, artist name, playback time, etc.

Press i( ) with the music information of Chaku-uta

Full® music file displayed and select “Edit music info”; then

you can edit the information contents. Select a desired item

and then edit it. To return the edited information to the

unedited one, select “Reset music info”. Select a desired

item and select “YES”.

Add to playlist Select a storing method.

Add one . . . . .You can store the music file.

Add some. . . .Select the music files to be stored, and press

l().

The music files are stored in the displayed order.

Select a playlist you store music files to.

When you create a new playlist to store music files to, select

“New playlist” and enter a playlist name. When 30 playlists

are already stored, the confirmation display appears asking

whether to delete them to save a new one.

Move You can move the Chaku-uta Full® music file in the FOMA

terminal to another folder inside it, or can move the Chaku-uta

Full® music file on the microSD card to another folder inside it.

Select a destination folder.

Press l( ) to display folders at the second-tier level

or lower, if they exist. Press r to return to the upper level.

Move to microSD You can move the Chaku-uta Full® music file to the microSD

card. (See page 376)

Move to phone You can move the Chaku-uta Full® music file on the microSD

card to the FOMA terminal. (See page 376)

Edit title You can edit the title of Chaku-uta Full® music file.

Enter a title.

For a Chaku-uta Full® music file in the FOMA terminal, you

can enter up to 9 full-pitch/18 half-pitch characters.

For a Chaku-uta Full® music file on the microSD card, you

can enter up to 18 full-pitch/36 half-pitch characters.

Reset title You can reset the title of a Chaku-uta Full® music file to “Music

title - Artist name”.

YES

Add folder See page 285.

Edit folder name See page 285.

Delete folder See page 285.

Multiple-choice You can select multiple Chaku-uta Full® music files and

operate them.

Put a check mark for Chaku-uta Full® music files to be

operatedi()Select an item.

Delete . . . See “Delete this” on page 287.

Move . . . . See page 286.

Connect to URL You can access the URL when the Chaku-uta Full® music file

has the URL information.

YES

287

Music

Display image You can display jacket images stored in the music file.

When multiple jacket images are stored, press No to

display a previous or next jacket image.

When the image is storable, press Oo( ) and select

“YES”, then select any destination folder to save it.

Display lyric You can display lyric images stored in the Chaku-uta Full®

music file.

When multiple lyric images are stored, press No to display

a previous or next lyric image. You can display up to seven

lyric images.

When the image is storable, press Oo( ) and select

“YES”, then select any destination folder to save it.

Select storage See page 285.

Memory info You can display the used memory space (estimate)/number of

stored items.

Delete this YES

Delete all You can delete all Chaku-uta Full® music files or WMA files in

the folder.

Enter your Terminal Security CodeYES

If there is a user folder in a folder, you cannot delete the user

folder or Chaku-uta Full® music files in the user folder.

Information

When an Uta-hodai music file set for a ring tone cannot be played back or needs to be

updated because playable deadline is expired or the UIM security function is set, the

default ring tone returns.

See “Music info” for checking whether to be set as ring tone.

You cannot add music files to the playlist created using a personal computer.

If there is no music title or artist name, it is displayed as “Unknown” for each.

Some images may not be displayed correctly.

If you delete the Chaku-uta Full® music file set for another function, the setting returns

to the default.

If you delete the WMA file stored in the WMA playlist, it is released from WMA playlist.

When the last WMA file is deleted or all the WMA files are deleted, the lisence file is

deleted at the same time.

Function Menu during Playback/Halt/Pause

Information

Player menu You can show the Player Menu display from the playback

display during using MUSIC Player.

Playback state continues even when you show the Player

Menu display.

Play mode setting See page 285.

Sound effect

Remaster You can bring the sound from an earphone or Bluetooth

device to the original sound by complementing high-pitch

range lost at data compression.

ON or OFF

Listening You can set sound effect for listening for the sound from an

earphone or Bluetooth device.

Select an item.

Surround . . . . Makes the sound natural and stereophonic.

Natur 1/2 . . . . Complements the cooped-up feeling specific

to earphones and plays back natural sound.

Select 1 or 2 according to your taste.

OFF . . . . . . . . Sets Listening to “OFF”.

288

Music

Equalizer You can change the quality of the sound from an earphone or

Bluetooth device.

Select an item.

Normal . . . . .Reproduces normal sound quality.

H.BASS1. . . .Enhances bass sound.

H.BASS2. . . .Enhances bass sound more deeply than

H.BASS1.

Train . . . . . . .Minimizes abnormal sound that causes sound

leakage.

Music info See page 286.

Connect to URL See page 286.

Display image/

Display lyric/Player

You can change the playback display.

Display image . . . Shows the jacket image on the full display.

Display lyric . . . . . Shows the lyric image on the full display.

Player . . . . . . . . . . Shows the playback display.

Previous image/

Previous lyric

You can display a previous jacket image or lyric image.

Next image/Next lyric You can display a next jacket image or lyric image.

Information

Even if an earphone or Bluetooth device is not connected, the respective setting

contents are displayed on the display.

For Chaku-uta Full® music files, you can display up to 3 jacket images and up to 7

lyric images.

For SD-Audio files saved by SD-Jukebox, you can display up to 20 jacket images, and

for WMA file, you can display up to 2 image buried in a file. When you use the

Napster® application program, you can display 1 image stored as a jacket image.

There are no lyric images for them.

You can create the list of music files you want to listen to, and play them

back in the order you like.

You can play back using the playlists created by the FOMA terminal or

Windows Media Player, or the SD-Audio playlists created by SD-Jukebox.

The maximum number of playlists that can be created and the number of music files

that can be stored per playlist are as follows:

When you create a playlist on the FOMA terminal, you can store the Chaku-uta Full®

music files saved on the FOMA terminal or microSD card, the WMA files saved by

Windows Media Player, and the SD-Audio files saved by SD-Jukebox into the same

playlist.

■Icons on the Playlist list

Using Playlist

Creating source Number of playlist Number of music files that

can be stored per playlist

Playlists created by FOMA

terminal

Maximum 30

(Except “All tracks”) 100

Playlists created by

Windows Media Player Maximum 100 250

SD-Audio playlists created

by SD-Jukebox

Maximum 99

(Except “All tracks”) 99

Icon Type

All tracks

All tracks for SD-Audio

FOMA playlist

SD-Audio playlist

WMA playlist

289

Music

1Player Menu displayPlaylist

2i()Create playlist

Select a type and display the Music list

Put a check mark for music files to be stored

l()

The music files are stored in the displayed order.

3Enter a playlist name.

You can enter up to 18 full-pitch/36 half-pitch characters.

1Playlist listSelect a playlist

Select a music file.

Press l( ) from the Playlist list to play back the

music files from the top one in the selected playlist.

You cannot play back a playlist from “MUSIC” of Data

Box.

Create Playlist

Playlist list

Information

In a playlist, you cannot store partially saved Chaku-uta Full® music files or files with

playback restrictions expired.

Play Back Playlist

Music list of a Playlist

Function Menu of the Playlist List

Player menu You can show the Player Menu display.

Play mode setting See page 285.

Create playlist See page 289.

Copy playlist Enter a playlist name.

You can enter up to 18 full-pitch/36 half-pitch characters.

When you copy the SD-Audio playlist or WMA playlist, it is

copied to the FOMA terminal as the FOMA playlist.

Edit playlist name You can edit the name of the FOMA playlist.

Edit the playlist name.

You can enter up to 18 full-pitch/36 half-pitch characters.

Add You can add the music files to the FOMA playlist.

Select a type and display the Music list

Put a check mark for the music files to be added

l()

The music files are stored at the end of the list in the displayed

order.

Delete playlist You can delete the FOMA playlist.

Select a deleting method.

Delete this. . . . . . . . You can delete the playlist.

Delete selected . . . Select the playlists to be deleted, and press

l().

Delete all . . . . . . . . . Enter your Terminal Security Code.

YES

Information

You cannot copy the WMA playlist with no music file stored in.

290

Music

Function Menu of the Music List of a Playlist

Player menu You can display the Player Menu display.

Playback state continues even when you show the Player Menu

display.

Play mode setting See page 285.

Music info See page 286.

Add See page 289.

DEL from playlist You can release the music files from the FOMA playlist.

Select a deleting method.

DEL one from list . . . . . . You can release the music file.

DEL some from list. . . . . Select the music files to be released,

and press l().

DEL all from list . . . . . . . You can delete the whole playlist.

YES

Order to play You can change the order of playlist created on the FOMA

terminal.

Select a music fileUse Bo to change the order to play

Oo()

To change the order in succession, repeat the above steps.

l()

Add to playlist See page 286.

Display image See page 287.

Display lyric See page 287.

Information

You cannot release music files from the playlists created on a personal computer.

291

i-αppli/i-Widget

i-αppli . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292

Downloading i-αppli from Sites . . . . . . . . .<i-αppli Download> 292

Starting i-αppli . . . . . . . . . . . . . . . . . . . . . . . . . . . .<i-αppli Run> 293

Setting i-αppli . . . . . . . . . . . . . . . . . . . . . . . . <iαppli Settings> 307

Starting i-αppli Automatically . . . . . . . . . . . . . . . . . . . . . . . . . . . 308

Using i-αppli Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309

Setting i-αppli Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 310

Operating i-αppli Stand-by Display

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<i-αppli Stand-by Display> 311

Displaying i-αppli Data Files on the microSD Card

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <iαppli data> 312

i-Widget. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312

Using i-Widget . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312

Setting i-Widget . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313

Starting Widget αppli . . . . . . . . . . . . . . . . .<Start Widget αppli> 314

292

i-αppli/i-Widget

By downloading i-αppli programs from sites, you can use the FOMA

terminal more conveniently. Some i-αppli programs enable you to

directly store data in the Phonebook or Schedule and some are linked to

Data Box to save/obtain images.

Also, you can enjoy playing the large capacity mega i-αppli such as

high-resolution 3D games and full-length role playing game or i-αppli

online compatible i-αppli programs such as match games and chat

application program.

Further, the FOMA terminal supports i-αppli call that enables you to play

match games with your acquaintance, and to be received event

notification from the i-αppli distributer.

See “Using i-αppli Call” on page 309 for setting whether to receive notification from

i-αppli call.

For details on i-αppli, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”.

You can download software programs from sites to the FOMA terminal.

You can save up to 100 files, however, the number of files you can save

decreases depending on the data volume because the memory space is

shared with other data files. (See page 534)

1Call up an i-αppli downloadable site

Select a software program.

2Select “OK” when downloading ends.

See page 205 when i-αppli programs are stored to the maximum.

When downloading ends, the display for Software Setting (Network Set, Stand-by

Set, Location Usage, Program Guide Key, or iαppli call) might appear. These

settings can be done also from the Software list.

3YES or NO

YES . . . . Starts i-αppli.

NO . . . . . Returns to the site display.

i-αppli

<i-αppli Download>

Downloading i-αppli from Sites

When you press r or h to suspend downloading an i-αppli program of 100 Kbytes

or more, or when downloading is suspended by the radio wave conditions, the

confirmation display appears asking whether to resume downloading. Select “YES” to

resume downloading the remaining part. Select “NO” to show the confirmation display

asking whether to save the file downloaded halfway. Select “YES” to partially save the

file.

You can re-download the rest of the partially saved i-αppli program from the Software list.

An i-αppli mail folder is created automatically each in the Inbox/Outbox Folder list, and

the title of the downloaded mail-linked i-αppli becomes the name of the folder.

You can save up to five mail-linked i-αppli programs.

You cannot download the software program if the mail-linked i-αppli using the same

folder is already in the Software list.

You cannot download mail-linked i-αppli while Mail Security is set.

You cannot download mail-linked i-αppli if the Inbox/Outbox Folder list contains five

i-αppli mail folders.

When re-downloading mail-linked i-αppli whose folder only remains, the confirmation

display appears asking whether to use the existing i-αppli mail folder. If you select

“YES”, the existing folder is used. If you select “NO” because you do not use it, the

confirmation display appears asking whether to delete an existing folder and create a

new one. You cannot download mail-linked i-αppli without creating a new folder.

When downloading is suspended

When you downloaded mail-linked i-αppli

Information

You can download pre-installed i-αppli programs from the

“P-SQUARE” site (in Japanese only).

iMenu→メニューリスト (Menu List)

→ケータイ電話メーカー (Mobile Phone Maker)→P-SQUARE

Downloading is not available from some accessed sites.

QR code for

accessing the site

293

i-αppli/i-Widget

≥Some i-αppli programs can automatically connect to the i-mode Center after they are

downloaded. However, to use this service, you need to set it in advance in “Network

set” of “Software setting”.

≥“ ” appears at the top of the display while software information or a software program

is being downloaded from SSL pages.

≥At downloading, the confirmation display might appear asking whether to send the

“Phone/Terminal and UIM ID”. Select “YES” to start downloading. In this case, the

“Phone/Terminal and UIM ID” is sent to the IP (Information Provider) over the Internet,

so could be deciphered by third parties. However, your phone number, address, age,

and gender are not notified to the IP (Information Provider) or others by this operation.

≥If you attempt to re-download the software program that was downloaded using a

different UIM, the confirmation display appears asking whether to overwrite the

software program. With the Osaifu-Keitai compatible i-αppli, the confirmation display

appears telling that the data on the IC card is to be deleted. Select “YES” to start

downloading. When downloading ends, the software program that was downloaded

using a different UIM and the data on the IC card are deleted.

≥You cannot download some software programs while the IC card function is working

or IC Card Lock is activated.

≥Some software programs that start immediately after downloading cannot be saved.

≥Depending on the data volume on the IC card, you might not be able to download

Osaifu-Keitai compatible i-αppli even if there is still available space for software

storage. Delete the displayed software programs following the confirmation display,

and then download it again. (Some software programs might not be targeted for

deletion, depending on the software type to be downloaded.)

Depending on the software program, you need to start it and delete the files on the IC

card before deleting the software program itself.

≥You can save up to 2 Mbyte per i-αppli program.

≥“i-αppli mail” is the mail sent and saved by mail-linked i-αppli and mail received as

mail-linked i-αppli. i-αppli mail is automatically saved to the i-αppli mail folder.

≥The 3D polygonal※ engine enables cubic images to be displayed in i-αppli.

※By combining polygons, a deep, cubic image is displayed.

Information

You can display software information when downloading i-αppli.

1m1i-αppli1iαppli settings1Disp. software info

1Display or Not display

1i(for at least one second)

1Select a software program to be started.

: GPS compatible i-αppli

: Osaifu-Keitai compatible i-αppli

: Management information i-αppli

: microSD card compatible i-αppli

: Vertical full display compatible i-αppli

: Horizontal display compatible i-αppli (incompatible

with full display)

: Horizontal full display compatible i-αppli

: i-αppli DX

: Mail-linked i-αppli

: Partially saved i-αppli

: Set for Auto Start

: Set for the i-αppli Stand-by display

: Set for both Auto Start and the i-αppli Stand-by display

: Can set for the i-αppli Stand-by display

: Downloaded from an SSL page

: Downloaded or upgraded by using a different UIM

Display Software Info

<i-αppli Run>

Starting i-αppli

Software list

294

i-αppli/i-Widget

You can display the Software list on the microSD card by

mi-αppliiαppli(microSD)Software list.

Each time you press c( ) from the Software list in the FOMA terminal,

the display format changes.

When you start an i-αppli DX program or while it is running, the confirmation

display might appear asking whether to permit the i-αppli DX program to use the

FOMA terminal’s information and functions.

When you start the Osaifu-Keitai compatible i-αppli program for the first time, the

confirmation display appears asking whether to make the UIM and IC card

compatible. The UIM information that has been made compatible is saved on the

IC card as IC owner information.

When you select a partially saved i-αppli program, you can download the

remaining part of it.

“ ” or “ ” is displayed while an i-αppli program is running.

To end i-αppli, press and hold r for at least one second or press h; then

select “YES”.

The software program you started last time comes at the top of the list. You

cannot manually change the order of software programs.

See page 205 when you select “Search by i-mode”.

You can show the Software list also by pressing i from the horizontal Stand-by

display.

Information

When a software program can be started from another program, the confirmation

display appears. When a software program to be started is not specified, select a

software program.

To start up i-αppli DX, set the data and time by “Set time” beforehand.

When a software program is running, melodies are played back at the volume set for

“Phone” of “Ring volume”. However, melodies are not played back during a call.

You may need to set the communication setting while a software program is running.

When communicating frequency is extremely high in a certain period of time while an

i-αppli program is running, the confirmation display appears asking whether to

continue communicating.

With some software programs, you can use the Web To function and the Phone To/

AV Phone To function from i-αppli. However, you cannot use them while the software

program is running as the i-αppli Stand-by display.

If you start the camera from i-αppli, the shot images are not saved with ordinary

images, but are saved as part of i-αppli for its usage.

If you start the camera from i-αppli, you can specify the image size or image quality for

some i-αppli programs.

You can scan JAN codes, QR codes, and Code128 from i-αppli using the camera.

The scanned data is saved and used by the software program.

Images※ that are used by i-αppli and data you have entered might be sent over the

Internet to the server automatically.

※i-αppli uses the following types of images:

・Images shot by the camera after it is started from a camera-linked application

program

・Images obtained by the infrared communication function of i-αppli

・Images downloaded from sites or Internet web pages

・Images obtained from Data Box by i-αppli

i-αppli mail running under mail-linked i-αppli might not be displayed correctly.

Some i-αppli programs save the various information used on the i-αppli programs

when you end them. However, the information might not be saved if the low battery

alarm sounds or the battery pack is removed while the i-αppli program is running. If

the battery level indicates “ ”, either press -h or end the i-αppli program in

accordance with the operation of each software program.

You can save the data files of some software programs to the microSD card, but you

might not be able to use them for another model. You can check “iαppli data” for the

software programs that use the microSD card.

Some IPs (Information Providers) may access the software program stored in your

mobile phone and have it directly halted, depending on the software program. In that

case, you will not be able to start or upgrade the software program, or use it for the

Stand-by display. You can delete it or display the software information. To resume

running the software program, you need to receive the communication to cancel the

software halting state. Contact the IP (Information Provider) to inquire about that.

Some IPs (Information Providers) might send data to the software program stored in

your mobile phone depending on the software program.

When the IP (Information Provider) requests to halt or re-open the software program

or sends data to it, the mobile phone communicates and “ ” is displayed. In this

case, you are not charged a communication fee.

With some software programs, you can perform registering or deleting My Menu on

the i-αppli program.

Information

295

i-αppli/i-Widget

The FOMA terminal supports “Motion Tracking” which enables you to operate i-αppli

programs (by inclining or swinging the FOMA terminal) through the recognition

technology of the camera.

Motion Tracking might not work in the following cases:

・When the lens of the camera is dirty

・When the clothes you wear are similar to the background

・When the background is not stable such as when you are moving

・When you are in a dark or too bright place

You can check the details when a software program malfunctions.

1mi-αppliiαppli infoTrace info

When the memory space for Trace Info becomes full, the information is

overwritten from the oldest one.

When “ ” is displayed on the Trace information display, press

i( ), and select “Copy info” to copy the information. Select “Delete info”,

and select “YES” to delete the information.

Select “Store in microSD”, and select “YES” to store in the microSD card.

To creators of i-αppli

If you encounter an error while creating a software program, the Trace Information

display might help identify the problem.

For how to check the trace information, see “Trace Information” on page 295.

You can show the information of i-αppli by -mi-αppliAbout iαppli.

Motion tracking

■Warning

The motion tracking compatible application program is the game to play by inclining or

swinging the FOMA terminal. If you excessively swing your FOMA terminal, it might

happen that it hits against persons or objects, resulting in accidents or damage. When

playing the game, securely take hold of your FOMA terminal, do not swing to an extent

more than necessitated, and check around you for safety.

Trace Information

Information

You can check the details when an i-αppli program ends because of a

security error.

1mi-αppliiαppli infoSecurity error history

When “ ” is displayed on the Security error history display, press

i( ), and select “Copy info” to copy the information. Select “Delete info”,

and select “YES” to delete the information.

You can display the security error history also by selecting “ ” on the desktop.

Security Error History

Function Menu of the Software List

Set iαppli To You can set whether to permit the i-αppli program to start from

a link on site or mail message. You can set also for when you

place the FOMA terminal over an IC card compatible scanning

device. You can set this for each software program.

Put a check mark for items to be setl()

Some items might not be set depending on the software

program.

Auto start time See page 308.

Software setting

Stand-by set See page 311.

Network set You can set whether to communicate while an i-αppli program

is running.

ON or OFFl()

Stand-by net See page 311.

Icon info You can set whether to permit the i-αppli program to use

information of icons indicating i-mode mail, SMS messages,

Messages R/F, battery level, Manner Mode, and within/out-of

service area.

ON or OFFl()

296

i-αppli/i-Widget

Change mld./img. You can set whether to permit the i-αppli program to change

the setting for the ring tones, Stand-by display, etc. This

function is available only for i-αppli DX programs.

ON, OFF or Check every changel()

If you select “Check every change”, the confirmation display

appears each time the i-αppli program tries to change the

setting for the ring tones, Stand-by display, etc.

See P. book/hist. You can set whether to permit the i-αppli program to refer to

the Phonebook, Redial, and Received Calls. This function is

available only for i-αppli DX programs.

ON or OFFl()

View ToruCa You can set whether to permit the i-αppli program to refer to

ToruCa files. This function is available only for i-αppli DX

programs.

ON or OFFl()

Location usage You can set whether to permit the i-αppli program to use

location information. This function is available only for i-αppli

DX programs.

ON or OFFl()

Program guide key You can set the software program for the Program Guide

i-αppli that starts up from 1Seg. You can set this only for the

i-αppli DX program that links to 1Seg.

ON or OFFl()

Map setting You can set the software program used on the GPS function.

ON or OFFl()

iαppli call See page 309.

Software info You can display the software name, version, and others of the

i-αppli program.

Upgrade YES

Add desktop icon See page 31.

Delete

Delete this YES

Delete selected Put a check mark for software programs to be deleted

l()YES

Delete all Enter your Terminal Security CodeYES

Move to microSD See page 376.

Move to phone See page 376.

Power saver You can set whether to validate Power Saver Mode for each

i-αppli program for when “αPower saver” is set to “ON”.

ON or OFF

Information

When you set “Icon info” to “ON” for the i-αppli Stand-by display, the icon information

for unread mail/message, battery level, Manner Mode, radio wave strength and

out-of-service area can be sent to the IP (Information Provider) over the Internet in the

same way as the Phone/Terminal and UIM ID, and can be deciphered by third parties.

When the software program needs “Icon info”, the software program might not run if

“OFF” is selected.

Depending on the software program, you can upgrade it at start.

At upgrading, the confirmation display might appear asking whether to send the

“Phone/Terminal and UIM ID. Select “YES” to start upgrading. In this case, the

“Phone/Terminal and UIM ID” is sent to the IP (Information Provider) over the Internet,

so could be deciphered by third parties. However, your phone number, address, age,

and gender are not notified to the IP (Information Provider) or others by this operation.

You cannot upgrade the mail-linked i-αppli in the following cases:

・While details of the corresponding i-αppli mail folder are displayed

・While Mail Security is set

・When Mail Security is set for the corresponding i-αppli mail folder

297

i-αppli/i-Widget

The confirmation display appears asking whether to delete the i-αppli mail folder as well.

If you do not delete it, you can check the text of mail from the Outbox/Inbox list.

YES . . . . . . Deletes both the software program and the i-αppli mail folder.

NO. . . . . . . Deletes the software program only and the i-αppli mail folder is left.

Cancel . . . . Does not delete both the software program and i-αppli mail folder; the former

display returns.

You can delete neither the i-αppli program nor the i-αppli mail folder even if you select

“YES”, in the following cases:

・While Mail Security is set ・While the folder is set with security

・While displaying details of the folder ・When the folder contains protected mail

The confirmation display appears asking whether to delete files on the microSD card as

well.

YES . . . . . . Deletes both the software program and files on the microSD card. Press

“YES” again on the confirmation display. You need to enter your Terminal

Security Code to execute “Delete” or “Delete selected”.

NO. . . . . . . Deletes the software program only and the files are left.

Cancel. . . . Does not delete both the software program and files on the microSD card,

and the former display returns.

The confirmation display appears telling that the files on the IC card will be deleted.

You cannot delete the “iD 設定アプリ (iD Setting Application)”.

You might not be able to delete the Osaifu-Keitai compatible i-αppli while the IC card

function is working or IC Card Lock is set.

When you delete mail-linked i-αppli

When you delete an i-αppli program whose files are on the

microSD card

When you delete Osaifu-Keitai compatible i-αppli

The following i-αppli programs are pre-installed:

You can delete the pre-installed i-αppli programs. You can re-download them from the

“P-SQUARE” site (see page 206). When you use a UIM other than the one used for

downloading, the UIM security function (see page 39) is set for them.

Deadlines for re-download services

・“キングダムハーツコーデッド (Kingdom Hearts Coded)”: the end of October, 2012

・“レイトン教授と不思議な町序章 (Professor Layton and the Curious Village

Prologue)”: the end of October, 2012

・“ファミリー伝言板 (Family Message Board)”: the end of October, 2009

・“とっさの英語辞典 (Spur-of-the-moment English Dictionary)”: the end of October,

2012

・“時刻表ウィジェット (Timetable Widget)”: the end of November, 2011

・“日英版／日中版しゃべって翻訳 for P (J-E/J-C Speech Translation for P)”:

the end of September, 2012

・“ぷよぷよ!ウィジェット (Puyo-puyo! Widget)”: the end of October, 2012

The re-download service might be halted or closed without notice even in the service

period.

Deadlines for downloading i-αppli additional data

・“キングダムハーツコーデッド (Kingdom Hearts Coded)”: the end of October, 2012

・“レイトン教授と不思議な町序章 (Professor Layton and the Curious Village

Prologue)”: the end of October, 2012

・“ファミリー伝言板 (Family Message Board)”: the end of October, 2009

・“とっさの英語辞典 (Spur-of-the-moment English Dictionary)”: the end of October,

2012

・“時刻表ウィジェット (Timetable Widget)”: the end of December, 2011

・“日英版／日中版しゃべって翻訳 for P (J-E/J-C Speech Translation for P)”:

the end of October, 2012

Pre-installed i-αppli Programs

298

i-αppli/i-Widget

You can play pre-installed only episode of

“Olympus Colosseum” that is a world of

“Kingdom Hearts Coded”. Further, you can

also play an introduction for main story

“Traverse Town Special Edit Version” by

upgrading.

Developed by SQUARE ENIX

1Software list

キングダムハーツ (Kingdom Hearts)Oo

When you activate this i-αppli program in Normal Style, the confirmation display

appears telling that you are advised to play the game in Horizontal Open Style.

2Select a menu.

オリンポスコロシアム∼SIDE EPISODE∼

(Olympus Colosseum ~SIDE EPISODE~)

. . .You can play original short episode.

トラヴァースタウン∼SPECIAL EDIT VERSION∼（アップグレード）

[Traverse Town ~SPECIAL EDIT VERSION~ (Upgrade)]

. . .You can upgrade to “Traverse Town ~SPECIAL EDIT VERSION~” that enables

you to play the main story. (You can also play “Olympus Colosseum” even after

upgrading.)

You are charged a packet communication fee for when you connect to the site.

The complete version data is saved to the microSD card.

When you upgrade the program, bulky data are downloaded, so you need to

subscribe to Pake-Houdai, Pake-Houdai Full or Pake-Houdai Double.

キングダムハーツコーデッド (Kingdom Hearts Coded)

This is a fantasy adventure puzzle game to

advance the story by solving puzzles asked by

the inhabitants of the curious village.

In the complete version, you can enjoy the

whole story and mini games with animations

and voice of characters.

1Software listレイトン不思議な町序章 (Professor

Layton Curious Village Prologue)00

When you activate this i-αppli program in Normal Style, the confirmation display

appears telling that you are advised to play the game in Horizontal Open Style.

2Select a menu.

はじめから (From the beginning) . . .Start the game from the beginning.

オプション (Option) . . . . . . . . . . . . . .Set the volume level and vibration.

アップグレード (Upgrade) . . . . . . . . .Upgrades the program.

You are charged a packet communication fee for when you connect to the site.

The complete version data is saved to the microSD card.

When you upgrade the program, bulky data are downloaded, so you need to

subscribe to Pake-Houdai, Pake-Houdai Full or Pake-Houdai Double.

レイトン教授と不思議な町序章

(Professor Layton and the Curious Village Prologue)

299

i-αppli/i-Widget

Family Message Board is an application program that enables

you to share memorandums or schedule events with your

family or friends. By registering you as a member and joining a

group, you can share entered memorandums or schedule

events with members of same group. Further, you can check

memorandums or schedule events of your group by using

compatible TV.

You are separately charged a packet communication fee.

Software list

ファミリー伝言板

(Family Message Board)



Read “

免責事項

(Exemption clause)” thoroughly



“

同意のうえ利用する

(Agree with Exemption Clause)”

If you put a check mark for “次回から表示しない (Does not show from the next

time)”, “免責事項 (Exemption clause)” does not appear when you start the

program next time.

2User’s Registration

You need to do user’s registration for the first time.

If you select “アプリの説明を見る (See explanation of this software program)”,

explanation of this software program appears.

3Setting Group

You need to set your group for the first time.

新しいグループを作る (Make a new group)

. . . . You can make a new group as a manager. Make a new group following the

instructions on the display.

グループに参加 (Join a group)

. . . . You can join a group that has already existed. Join a group following the

instructions on the display.

The group in which one user can join is only one group.

ファミリー伝言板 (Family Message Board)

You can download the time schedule of trains, and can count

down the departure time of the train on a minute/second basis.

The schedule store function is also provided to notify you of the

departure time by making an alarm tone sound. You can

update the time schedule from the menu, and further, you can

search for the nearest station using the GPS function.

You are separately charged a packet communication fee for

using.

For details, refer to “ヘルプ (Help)” in the menu.

1Software listのりかえ君-P (Norikaekun-P)

2Read “免責事項 (Exemption clause)” thoroughly

i()

3Select an item.

駅名入力／時刻表登録 (Enter station name/Store time schedule)

. . . Stores the time schedule for the station you want to use.

全体設定／ヘルプ／免責事項 (Whole setting/Help/Exemption clause)

. . . Sets a font size, and display “ヘルプ (Help)” or “免責事項 (Exemption

clause)”.

アプリ終了 (End Widget αppli program)

. . . Ends a Widget αppli program.

時刻表ウィジェット (Timetable Widget)

300

i-αppli/i-Widget

You can start up and play on the i-Widget program. In a

separate display, you can enjoy playing the easy puzzle

deletion game called “ぷよぷよ (Puyo-puyo)”. In this game,

you connect the same color of four puyo falling from the top

and delete them. In a list display, a auto demo is played back

and you can learn how to make “連鎖 (a chain of deletion)”.

1Software list

ぷよぷよ!ウィジェット (Puyo-puyo! Widget)

2Select a menu.

ゲームスタート (Start game). . . Start the game.

オプション (Option) . . . . . . . . . . Set the number of the colors of Puyo and the

color of the frame.

You are charged a packet communication fee for when you connect to the site.

ぷよぷよ!ウィジェット (Puyo-puyo! Widget)

By Spur-of-the-moment English conversation dictionary, you

can check the English expressions used in your daily life or

overseas travel, or useful in business. Further, this is a general

Engilsh dictionary comes with “English-Japanese/

Japanese-English dictionary of Gakken jisupa” that enables

you to check English words and phrases. You can perform

cross-reference with both of dictionaries, confirm checked

result with audio, or enjoy using the dictionary in a quiz style.

You are charged a packet communication fee to download

voice data. As the size of voice data is bulky, you are advised

to subscribe to Pake-Houdai, Pake-Houdai Full or

Pake-Houdai Double.

Voice data of the Spur-of-the-moment English conversation dictionary, and dictionary

data of the English-Japanese dictionary and Japanese-English dictionary are saved to

a microSD card. While accessing the microSD card, wait until the operation ends

without operating the keys. Depending on the number of voice data files on the

microSD card, it may take long to access it.

The contained electronic dictionary uses “英会話とっさのひとこと辞典

(Spur-of-the-moment English conversation dictionary)” and “株式会社学習研究社の英

和・和英辞書 (English-Japanese dictionary/Japanese-English dictionary of Gakken

Co.,Ltd.)”.

1Software listとっさの英語辞典 (Spur-of-the-moment

English Dictionary)

Read “免責 (Exemption clause)” thoroughlyOK

If you remove a check mark for “アプリ起動時に常に表示する。 (Always shows

this display at the start of this application program.)”, “免責 (Exemption clause)”

does not appear when you start the program next time.

とっさの英語辞典 (Spur-of-the-moment English Dictionary)

301

i-αppli/i-Widget

2Select a dictionary to be used.

英会話とっさのひとこと辞典

(Spur-of-the-moment English conversation dictionary)

. . . The Spur-of-the-moment English conversation dictionary starts. Check the

English expressions by specifying a scene or keyword you encounter or use in

your daily life. Further, you can confirm those English expressions with audio.

学研辞スパ英和辞典

(English-Japanese dictionary of Gakken jisupa)

. . . The English-Japanese dictionary starts. Enter the English spelling you want to

check into the input box. When the English-Japanese dictionary is not

downloaded, the confirmation display appears telling that it will be

downloaded.

学研辞スパ和英辞典

(Japanese-English dictionary of Gakken jisupa)

. . . The Japanese-English dictionary starts. Enter the Japanese readings you

want to check into the input box. When the Japanese-English dictionary is not

downloaded, the confirmation display appears telling that it will be

downloaded.

英会話とっさのひとことクイズ

(Spur-of-the-moment English conversation quiz)

. . . You can enjoy quizzes based on the title expressions.

If you select l() → “お気に入り登録 (Store as bookmark)” from the

search result display, you can bookmark the results.

Further, if you press Oo or select l() → “音声データ管理 (Manage

voice data)” → “章毎ダウンロード (Download by chapter)”/“一括ダウンロード

(Download at one time)”, you can download voice data to play back.

You can return to the previous display by pressing i when “ ” is

displayed at the lower right of the display.

Just by speaking a phrase to be translated into your FOMA

terminal, this application program translates it from Japanese

to English or Chinese and vice versa.

You can use all the functions charge free for 60 days from

when you start using this application program. Some phrases

available for translation are restricted on and after the 61st

day. To use all the services, you need to register in My Menu

(charged) from the “しゃべって翻訳 (Speech Translation)”

site by ATR-Trek Co., Ltd. (in Japanese only)

[How to access: iMenu→メニューリスト (Menu List)→辞

書／便利ツール (Dictionary/Convenient Tool)→便利ツール

(Convenient Tool)→しゃべって翻訳 (Speech Translation)]

You are separately charged a packet communication fee for

using.

1Software list

日英しゃべって翻訳_P (J-E Speech Translation_P) or

日中しゃべって翻訳_P (J-C Speech Translation_P)

SKIP

Select “日英しゃべって翻訳_P (J-E Speech Translation_P)” for using J-E

version, or select “日中しゃべって翻訳_P (J-C Speech Translation_P)” for

using J-C version.

2Read “しゃべって翻訳とは (What is Speech

Translation?)” and “ご利用規約 (Usage rules)”

thoroughly同意する (Agree)

You need to agree with “ご利用規約 (Usage rules)” when you use the program

for the first time.

3Read “ご利用注意事項 (Cautions in use)” thoroughly

OKはい (YES)

If you select “いいえ (NO)”, “しゃべって翻訳とは (What is Speech

Translation?)”, “ご利用規約 (Usage rules)”, and “ご利用注意事項 (Cautions in

use)” do not appear when you start the program next time.

4はい (YES)OK

“ｉアプリの使い方 (How to use i-αppli)” appears at the first startup.

日英版／日中版しゃべって翻訳 for P

(J-E/J-C Speech Translation for P)

The display is for

J-E version.

302

i-αppli/i-Widget

5Select a menu item.

日→英翻訳 (Translate Japanese to English)

. . . Starts translation from Japanese to English.

英→日翻訳 (Translate English to Japanese)

. . . Starts translation from English to Japanese.

日→中翻訳 (Translate Japanese to Chinese)

. . . Starts translation from Japanese to Chinese.

中→日翻訳 (Translate Chinese to Japanese)

. . . Starts translation from Chinese to Japanese.

シーンを変更 (Change scene)

. . . Select a scene suitable for words to be translated.

≥Press i to switch between Japanese and English or Chinese.

This is a convenient i-

ppli program that bundles the TV

program list and AV remote control function and the

monthly charge is free.

Anytime and anywhere you are, you can easily obtain the

terrestrial digital, terrestrial analog or BS digital TV

program information for the desired time zone. You can

know about titles, contents, and start/end times of TV

programs. Further, you can start a 1Seg program from the

program list and vice versa.

If there is any program you want to watch, you can set

timer recordings of the program on a DVD recorder, etc.

over the Internet. (You need to have a DVD recorder, etc.

that supports the remote timer recording function. And you

need to perform initial settings of this application

program.) Further, you can search for the program

information by keywords such as program genres or

celebrities you like, or pickup keywords on the top of the

display. You can also remote-control a TV, video recorder,

and DVD player. (Some models are not supported.)

You can browse the program guide even on the horizontal

display. (Some functions are not supported on the

horizontal display.)

≥See “Using Infrared Remote Control Function” on

page 388 for details on the infrared remote control.

≥You need to make the initial settings and to agree with the usage rules for the first time.

≥You are separately charged a packet communication fee.

≥

To use this application program overseas, set the FOMA terminal’s clock to Japan time.

≥For details, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”.

≥This software program is not available when the mode of 2in1 is set to B Mode.

Gガイド番組表リモコン

(G Guide Program List Remote Control)

※

The display is for

reference. The actual one

may differ. Local programs

according to your region

appear on your display.

You can set 1Seg TV Timer for programs you want to watch by selecting from the

program list of this application program.

How to set TV Timer

1. Software list1Gガイド番組表リモコン (G Guide Program List Remote Control)

1Highlight a program you want set TV Timer for and press i()

1視聴予約 (TV Timer)1予約実行 (Execute booking)

1Operate following the instructions on the display.

You can select a program you want to record and set a timer recording from the program

list of this application program.

How to set a timer recording

1. Software list1Gガイド番組表リモコン (G Guide Program List Remote Control)

1Highlight a program to be set for a timer recording and press i()

1♯ワンセグ録画予約 (1Seg timer recording)1予約実行 (Execute booking)

1Operate following the instructions on the display.

(You can set a timer recording also by highlighting a program and pressing s.)

If you have a DVD recorder, etc. that supports the remote timer recording function, you

can set timer recordings from the program list of this application program over the

Internet even if you are away.

For remote timer recording, you need to make initial settings of this application program.

How to make initial settings

1. Set the Internet connection for the DVD recorder, etc.

(Refer to the instruction manual of the DVD recorder, etc. you use.)

2. Software list1Gガイド番組表リモコン (G Guide Program List Remote Control)

1i()1リモート録画予約 (Remote timer recording)

1Operate following the guidance.

How to set timer recordings

After the initial settings, specify your desired program and select “リモート録画予約

(Remote timer recording)”. Then, the DVD recorder, etc. specified on this application

program is connected via the Internet, and you can set timer recordings.

≥You are separately charged a packet communication fee.

About TV timer function

About timer recording function

About remote timer recording function

303

i-αppli/i-Widget

Chargeless electronic money “iD” is a service that enables you

to do shopping by placing your Osaifu-Keitai or a credit card

with “iD” mounted over a scanning device. You can do

shopping easily and conveniently without signing. Depending

on the card publishing company, cashing is also supported.

For using “iD”, you need to subscribe to a card publishing

company that supports “iD” as well as to have Osaifu-Keitai

on which specified settings have been completed by the iD

application program or card application program provided by

the card publishing company, or a credit card on which “iD” is

mounted.

When you use “iD” on Osaifu-Keitai, you need to complete iD

application or card application settings. Depending on the

card you use, you need to complete iD application setting and then make settings on

the card application by downloading or starting the card application.

The expense (annual fees, etc.) charged for the iD service differs depending on the

card publishing company.

For the information about “iD”, refer to the i-mode site of “iD” (in

Japanese only).

i-mode site: iMenu→メニューリスト (Menu List)→「iD」

iD設定アプリ (iD Setting Application)

※

The display is for reference.

The actual one may differ.

QR code for

accessing the site

“DCMX” is a credit service that supports “iD” and offered by

NTT DOCOMO, INC. DCMX provides DCMX mini that enables

you to use up to ¥10,000 per month and respective DCMX/

DCMX GOLD services that enable you to use more amount

and save up DOCOMO points.

With “DCMX mini”, you can easily make a subscription from

this application program and immediately use Mobile Phone

Credit.

※1 The online screening is conducted at your subscription for DCMX mini. For

subscribing to a service other than “DCMX mini”, you are connected to the

subscription page for i-mode.

※2 You might be required to enter your pin number under certain conditions.

※3 Available for DCMX mini only.

DCMXクレジットアプリ (DCMX Credit Application)

※

The display is for reference.

The actual one may differ.

Subscribing for membership/Screening ※1

Use

No troublesome deposit is required!

Just by placing the mobile phone with the

card information setting completed, at a

shop where the following iD mark is put

up, you can enjoy shopping without

signing※2.

Check

You can check, on the application

program, the service contents of DCMX,

the balance for this month※3, and

detailed account!

Change

You can perform setting from the

application program when changing

models or updating your validity period.

Setting card information

304

i-αppli/i-Widget

For service contents and details of subscriptions, refer to the

i-mode site of DCMX (in Japanese only).

・i-mode site: iMenu→DCMX iD

“楽オク出品アプリ2 (Rakuoku Exhibition Application 2)”

enables you to easily exhibit your goods on Rakuoku whenever

you want wherever you are. Even if you are a beginner, an

instruction guides you through exhibition procedures, so you

can use it easily. The convenient functions such as shooting/

editing photos and saving records are available so that you can

exhibit your goods in a shorter time than you do on sites.

You need to agree with “利用規約 (Usage rules)” for the first

time.

You are separately charged a packet communication fee.

For details on Rakuoku, refer to “Mobile Phone User’s Guide

[i-mode] FOMA version”.

To exhibit on Rakuoku, you need to register with the Rakuten

membership and exhibitor membership.

For the information about Rakuoku, refer to i-mode site (in Japanese only).

i-mode site: iMenu→オークション (Auction)

QR code for

accessing the site

Information

To start this application program for the first time, you need to agree with “ご利用上の

注意 (Cautions in use)”.

You are charged a packet communication fee for settings and operations.

■Cautions on Osaifu-Keitai compatible i-αppli

Note that we take no responsibility for any information set on your IC card.

楽オク出品アプリ2 (Rakuoku Exhibition Application 2)

※

The display is for reference.

The actual one may differ.

QR code for

accessing the site

By using the GPS function and map, you can read the map of the place you are currently

in or you specify, or check area information. You can then navigate yourself to the

destination by vehicle, on foot, or by car.

Further, you can easily get transfer information by voice input.

You are separately charged a packet communication fee. You are advised to use

Pake-Houdai, Pake-Houdai Full or Pake-Houdai Double for using this software

program.

If you delete this software program and then when you want to resume it, download it

from “ｉエリアー周辺情報ー (i-area -Area Information-)”.

This software program is not available when the mode of 2in1 is set to B Mode.

Note that we are not held responsible for the accuracy and promptness of the map and

route information.

While driving, ensure that a person other than the driver operates this application

program.

This software program supports motion tracking.

See page 329 for details on operations.

This is an i-αppli program that enables you to conveniently use

mobile banking. Mobile banking enables you to use your

FOMA terminal to check the account balance, check the

deposits/withdrawals, and transfer/shift money whenever you

want and wherever you are. By entering your specified

password at the start of this application program, you can use

the mobile banking services for up to two banks.

To use mobile banking, you need to have the bank account

and subscribe to the mobile banking service of each bank.

You are separately charged a packet communication fee.

For details on i-αppli Banking, refer to “Mobile Phone User’s

Guide [i-mode] FOMA version”.

For the information about i-αppli Banking, refer to i-mode site

(in Japanese only).

i-mode site: iMenu→メニューリスト (Menu List)

→モバイルバンキング (Mobile Banking)

→ｉアプリバンキング (i-αppli Banking)

地図アプリ (Map Application)

ｉアプリバンキング (i-αppli Banking)

※

The display is for reference.

The actual one may differ.

QR code for

accessing the site

305

i-αppli/i-Widget

“Start! i-Widget!” is an application program that enables you to

watch how to use i-Widget with a movie.

Further, you can connect to i-mode to call up the site

downloadable other than application stored in the FOMA

terminal.

≥You are charged a packet communication fee when you

select “ダウンロード (Download)” and connect to i-mode.

Start! i-Widget

Google Mapアプリ (Google Map Application)

※

The display is for reference.

The actual one may differ.

You can download to use the discount coupon usable in

McDonal’s; “かざすクーポン (Coupon to place over scanning

device)”.

After you store the data of coupon you want to use in your

FOMA terminal, place it over a reader/writer installed in a store.

≥To use “かざすクーポン (Coupon to place over scanning

device), you need to register with the membership of

“トクするケータイサイト (Valuable mobile site)” of

McDonald’s formula.

≥Even nonmembership can browse “おすすめ情報

(Recommended information)”.

≥“かざすクーポン (Coupon to place over scanning device)” is not usable in some

areas. In that area, “見せるクーポン (Coupon to show)” is usable.

≥You are separately charged a packet communication fee.

■In i-Widget (See page 312)

When “おすすめ情報 (Recommended information)” of

McDonald’s is updated, a signboard of McDonald’s in i-Widget

turns and inform it.

When you select the signboard, a topic is displayed.

You can browse more detailed information by pressing

“もっと詳しく (In detail)” in the topic.

マクドナルドトクするアプリ

(McDonald’s Valuable Application)

※

The display is for reference.

The actual one may differ.

Start the application

Select a coupon and the number of sheets to use

Press “決定 (Decide)” to store the coupon data

Storing is completed

<How to store “

かざすクーポン

(Coupon to place over scanning device)”>

306

i-αppli/i-Widget

Main functions of Avatar Maker

■Creating avatar

You can create a portrait avatar easily by using various parts

prepared by Avatar Maker. Also, you can create avatar easily

by browsing images shot by the camera or stored on Data Box,

or can edit avatar by selecting from samples prepared

beforehand.

■Outputting as material of Deco-mail message or

i-concier compatible Machi-chara image

You can save created avatar as JPEG/GIF or SWF file for

using material of Deco-mail, pictogram, or Flash, also, you can

use it by converting to i-concier compatible Machi-chara image.

■Liaising with i-avatar site

You can set the created avatar as the avatar on i-avatar site,

further, you can change clothes on it by using items purchased

on the site.

≥You are separately charged a packet communication fee for converting avatar to

Machi-chara image.

≥You are separately charged a packet communication fee for setting avatar to i-avatar.

≥You need to purchase items on the site for changing the clothes on the avatar on the

i-avatar site.

≥i-avatar is a registered trademark of D2 COMMUNICATIONS and BANDAI

NETWORKS CO., LTD.

Suicaスタートアップアプリ (Suica Start-up Application)

アバターメーカー (Avatar Maker)

※

The display is for reference.

The actual one may differ.

“iWウォッチ (iW Watch)” is an application pragram that

enables you to enjoy a graphical watch in i-Widget.

You can change the design and color of it depending on your

taste.

“株価アプリ (Stock Prices Application)” is

an application program that enables you

to check stock prices easily in i-Widget.

You can check three types of stock prices

information, Nikkei225, TOPIX, and

Hercules index.

You can display present value and

change of each index.

Further, for the chart, you can switch

period between intraday, daily, weekly,

and monthly.

≥You need to agree with “利用規約

(Usage rules)” for the first time.

≥You are separately charged a packet communication fee.

≥The presant index value is delayed for 20 minutes.

≥The information of this application program does not sell or buy, and does not support

selling or buying stocks and others.

≥We take all possible measures to ensure the contents of information of this application

program, but, we do not guarantee the contents. Note that we at DOCOMO and the

Information Provider cannot be held responsible for the loss due to the information of

this application program.

iWウォッチ (iW Watch)

株価アプリ (Stock Prices Application)

※

The display is for reference.

The actual one may differ.

Type of index

(Nikkei225/TOPIX/

Hercules index)

Chart

Present index value

Change of index

※

The display is for reference.

The actual one may differ.

307

i-αppli/i-Widget

“FOMA 通信環境確認アプリ (FOMA Communication

Environment Check Application)” enables you to check

whether the FOMA terminal is available at the FOMA

High-Speed Area.

Use “FOMA 通信環境確認アプリ (FOMA Communication

Environment Check Application)” with your consent to “ご利

用の注意 (Cautions in use)”.

Depending on the communication environment (such as

weather, radio wave conditions, network congestion state) at

communication environment check, the different result or “out

of service” might appear even in the same area or at the

same period of time.

You might not be able to check correctly if you use another function while using this

application program.

検索＆ランキングアプリ (Search & Ranking Application)

FOMA 通信環境確認アプリ

(FOMA Communication Environment Check Application)

※

The display is for reference.

The actual one may differ.

1mi-αppliiαppli settings

Do the following operations.

<iαppli Settings>

Setting i-αppli

Auto start setting See page 308.

Disp. software info See page 293.

i-Widget roaming set. See page 313.

i-Widget sound effect See page 313.

iαppli call settings

iαppli call DL set. See page 310.

iαppli call sound See page 310.

Preferred tone You can set which sound to be output preferentially, from

MUSIC/1Seg or i-αppli program, for when you start an i-αppli

program during music playback or use of 1Seg.

MUSIC/1Seg or iαppli

αBacklight You can set the backlight operation for when an i-αppli

program is running.

Select an item.

Depend on system. . . . Follows the setting of “Backlight”.

Depend on software . . Follows the setting of each software

program.

Constant light . . . . . . . . Lights constantly.

308

i-αppli/i-Widget

You can make an i-αppli program start automatically at the set date and

time. Set the date and time for automatic start using Auto Start Time.

You can set whether to enable automatic start of i-αppli programs.

1mi-αppliiαppli settingsAuto start setting

ON or OFF

αPower saver You can set to Power Saver Mode to decrease battery

consumption by suspending the i-αppli program temporarily

for when you close the FOMA terminal during i-αppli running.

ON or OFF

This setting is valid from when an i-αppli program starts until

it closes.

Even when this function is set to “ON”, Power Saver Mode

becomes invalid if “Power saver” that can be set for each

i-αppli program is set to “OFF”.

αVibrator You can set the vibrator operation for when an i-αppli program

is running.

Depend on system or Depend on software

Depend on system . . . . Does not work regardless of the

setting of “Vibrator”. With some

software programs, the vibrator

works.

Depend on software . . . Follows the setting of each software

program.

Check settings You can check each of “iαppli settings”.

Information

<αBacklight> <αVibrator>

With some software programs, the backlight and vibrator settings are “OFF”.

Consequently, if you set “Depend on software”, the backlight and vibrator will not

work; if you want them to work, set “Depend on system”.

Starting i-αppli Automatically

Auto Start Setting

You can set the date and time for automatic start. You can set for up to

three software programs.

1Software listi()Auto start time

2Put a check mark for an item to be setl()

Time interval set . . . . Starts at an interval specified by the software program. The

setting is completed.

Start time set . . . . . . . Starts at the set start time automatically.

3Select start timeEnter the date and time to be set.

41 timeSelect a type of repeat.

If you select “1 time”, the automatic start is not repeated.

If you select “Weekly”, put a check mark for days of the week to be set and press

l().

5Press l().

You can check whether a software program has started automatically

and properly. Also, you can check the information of start failure from IC

card. Up to three records of automatic start, a record of automatic start

set by i-αppli, and a record of start failure from IC card are stored.

1mi-αppliiαppli infoAuto start info

StartO . . . . .Started automatically and properly.

StartX . . . . .Did not start automatically.

When “ ” is displayed, you can press Oo( ) to start the

software program.

Start–. . . . . .Has not started yet.

Auto Start Time

Auto Start Info

309

i-αppli/i-Widget

On the i-αppli program, i-αppli call enables you to call up your friends

being far away, and then you can play a network match game or share

information with your friends.

1While an i-αppli call compatible i-αppli program is

runningPerform the operations of i-αppli callYES

The operations differ depending on the i-αppli program.

Information

Software programs do not start automatically in the following cases:

・When the FOMA terminal is turned off

・When the date and time are not set

・When another function is working

・During Lock All

・During Personal Data Lock

・During playback of animations/Flash movies

・When the time set for automatic start is identical to the reserved time set for

“Software update”, or the time set for an alarm of “Alarm”, “Schedule”, “ToDo”, “TV

timer”, or “Timer recording”

・When a start time has been specified to the same software program within 10

minutes from the previous auto-start

If automatic start fails, “ ” appears on the desktop. Select the icon to show the

Auto Start Info.

Using i-αppli Call

Send i-αppli Call to Call Up

When you receive an i-αppli call, the ring tone for i-αppli call sounds, and

the confirmation display appears asking whether to accept the i-αppli

call.

1The confirmation display of i-αppli call appears

Select an item.

Accept . . . . . . . Accepts the i-αppli call. The target i-αppli program starts.

Reject. . . . . . . . Rejects the i-αppli call.

Hold . . . . . . . . . Holds the i-αppli call for the present. “ ” appears at the top of

the display, and “ ” appears on the desktop. Press Oo,

highlight “ ” and press Oo( ) to display the i-αppli call

logs.

Some i-αppli calls starts the i-αppli program without displaying a confirmation

display.

If you accept an i-αppli call, you might be charged a packet communication fee.

While a display other than the Stand-by display is shown, only the “ ” notifies

you of receiving i-αppli call.

The operations of called up target i-αppli call differ depending on the i-αppli

programs.

The confirmation display might appear asking whether to download the target i-αppli

program or asking whether to connect to a site. Select “YES” to download or connect to a

site. If you select “NO”, the display returns to the Stand-by display. In this case, i-αppli

call logs become “Accept”.

Receive i-αppli Call

When the target i-αppli program does not appear in your

FOMA terminal while you select “Accept”

310

i-αppli/i-Widget

Up to 30 logs of received i-αppli call are stored in i-αppli call logs. You

can check the reply state.

≥When more than 30 i-αppli calls are received, the older logs are automatically deleted.

However, the logs on holding i-αppli call are not deleted. (But they are deleted if all the

logs are the logs of on hold i-αppli call.)

1m1i-αppli1iαppli call logs

: i-αppli call logs on holding (not replied)

: Replied with an accept i-αppli call logs

: Rejected i-αppli call logs

: Expired i-αppli call logs

≥Press Oo( ), highlight the log of i-αppli call on

holding, you can display the confirmation display of

i-αppli call again. (See “Receive i-αppli Call” on

page 309)

≥To delete the i-αppli call logs, press i( ) and select “Delete this” or

“Delete all” then select “YES”. If you select “Delete all”, you need to enter your

Terminal Security Code.

You can set whether to accept to start from i-αppli call for each i-αppli

program. If you set to “OFF”, you cannot receive i-αppli call to the set

i-αppli program.

1Software list1i()1Software setting

1iαppli call1Select an item1l()

ON . . . . . . . . . . .Accept to start i-αppli program from i-αppli call.

OFF . . . . . . . . . .You cannot start i-αppli program from i-αppli call.

≥Even if you set to “OFF”, it might not valid depending on the i-αppli program.

Check i-αppli Call Logs

i-αppli call logs

display

Setting i-αppli Call

Software Setting (i-αppli Call)

You can set whether to reject the download notification of i-αppli

program when you do not have the i-αppli program intended to an i-αppli

call.

1m1i-αppli1iαppli settings1iαppli call settings

1iαppli call DL set.1Reject or Not reject

You can set the operation when an i-αppli call is received.

1m1i-αppli1iαppli settings1iαppli call settings

1iαppli call sound1Do the following operations.

i-αppli Call Download Setting

i-αppli Call Sound

Select ring tone 1Select a folder1Select a ring tone.

≥While selecting, the selected tone sounds for confirmation.

Ring time setting You can set a ring time for i-αppli call ring tone.

1Enter a ring time (seconds).

≥Enter two digits from “00” through “30”.

Select vibrator 1Select a vibration pattern.

≥If you select “Melody linkage”, the FOMA terminal vibrates in

time with ring tone.

≥While selecting, the FOMA terminal vibrates by the selected

pattern for confirmation.

Select illumination 1Select an item.

≥While selecting, the Call/Charging indicator lights/flickers for

confirmation.

311

i-αppli/i-Widget

You can set an i-αppli program for the Stand-by display. Once set, the

i-αppli Stand-by display automatically appears each time you show the

Stand-by display.

1Software listi()Software setting

Stand-by setON or OFFl()

“ ” is displayed for the software program set as the Stand-by display.

“ ” or “ ” is displayed while an i-αppli Stand-by display is running.

From the i-αppli Stand-by display, press <.

“ ” or “ ” changes to a blinking “ ” or “ ” and then you can operate the i-αppli

program as a normal one.

To return to the i-αppli Stand-by display, press and hold r for at least one second or

press h; then select “Ended”. To release the i-αppli Stand-by display, select

“Terminated”, and select “YES”.

<i-αppli Stand-by Display>

Operating i-αppli Stand-by Display

Software Setting (Stand-by Set)

To operate an i-αppli program as a normal i-αppli program

when an i-αppli Stand-by display is running

Information

If you turn off the FOMA terminal while the i-αppli Stand-by display is running, the

confirmation display appears asking whether to start the i-αppli program when you

turn on the power again.

You can set only one software program for the i-αppli Stand-by display.

Some i-αppli programs cannot be set for the Stand-by display.

With some software programs set as the i-αppli Stand-by display, you can press a key

to go from the normal i-αppli status to the i-αppli Stand-by display status. However,

you cannot return to the i-αppli Stand-by display if another menu function is running.

Note that you might not be able to receive timely information if you have set “Stand-by

net” of “Software setting” to “OFF”.

You cannot use the Web To function and the Phone To/AV Phone To function from

the i-αppli Stand-by display.

If the software program which connects to the network is set for the i-αppli Stand-by

display, it might not operate successfully because of radio wave conditions or other

factors.

You can set whether to permit communication for when the i-αppli

Stand-by display is running.

1Software listi()Software setting

Stand-by netON or OFFl()

You can temporarily end the running i-αppli Stand-by display. Also, you

can release the i-αppli Stand-by display.

1mSet./ServiceDisplayDisplay setting

Stand-by displayEnd iαppli display

End or Terminate

When you select “Terminate”, select “YES”.

When you show the Stand-by display while a menu function is operating, the image

set for “Stand-by display” of “Display setting” is displayed, even when the i-αppli

Stand-by display is set.

When communicating frequency is extremely high in a certain period of time while an

i-αppli program is running as the i-αppli Stand-by display, the confirmation display

appears. When you press -r, the confirmation display appears asking whether to

continue communication.

If you set Lock All or Personal Data Lock when the i-αppli Stand-by display is shown,

the i-αppli Stand-by display will end. If you set Lock All, the image set for “Stand-by

display” of “Display setting” will be displayed and if you set Personal Data Lock, the

default Stand-by display will be displayed. The i-αppli Stand-by display will return

when you release each lock.

Software Setting (Stand-by Net)

Information

End Stand-by Display

312

i-αppli/i-Widget

When the i-αppli Stand-by display does not end successfully, you can

check the date/time and its reason.

1m1i-αppli1iαppli info1End stand-by info

≥When “ ” is displayed on the End Stand-by Info display, press

i( ), and select “Copy info” to copy the information. Select “Delete info”,

and select “YES” to delete the information.

Depending on the i-αppli program, you can save its data files on the

microSD card.

You can display the i-αppli data files saved on the microSD card.

1m1i-αppli1iαppli(microSD)1iαppli data

End Stand-by Info

<iαppli data>

Displaying i-αppli Data Files on the

microSD Card

Function Menu while i-αppli Data File is Displayed

Folder info You can display the information of the software program that uses

the selected folder, available/unavailable for folder usage, and the

reason if unavailable.

Delete folder You can delete the selected folder and files in the folder.

1Enter your Terminal Security Code1YES

i-Widget is a convenient function that enables you to access to any

frequently used contents such as calculator, clock, memopad, or stock

prices information (Widget αppli).

You can add Widget αppli by downloading from sites offered by IPs

(Information Providers). (See page 292) Also, you can paste multiple (up

to eight) Widget αppli programs to i-Widget display, and you can create

your own display.

≥Multiple Widget αppli programs might communicate when you show the i-Widget

display.

≥You are separately charged a packet communication fee for downloading Widget αppli

or showing the i-Widget display.

≥To communicate overseas, you are charged a communication fee by communication

of Widget αppli.

≥For details on i-Widget, refer to “Mobile Phone User’s Guide [i-mode] FOMA version”.

If you start i-Widget, you can simultaneously start multiple Widget αppli

programs. You can simultaneously display multiple started Widget αppli

programs on the i-Widget display.

1Press r.

i-Widget starts, and the i-Widget menu is displayed.

When you have started Widget αppli already, the list of

the started Widget αppli appears.

≥You can start i-Widget also by selecting a Widget αppli

program on the Software list.

i-Widget

Using i-Widget

Start i-Widget

i-Widget display

Panasonic Mobile Communications 208009A UMTS/ GSM Cellular Mobile with Bluetooth® and RFID User Manual 000 P 01A

Panasonic Mobile Communications Development of Europe Ltd UMTS/ GSM Cellular Mobile with Bluetooth® and RFID 000 P 01A

Contents

User Manual Part 2 of 3

Navigation menu

Namespaces

Views

Navigation

Panasonic Mobile Communications 208009A UMTS/ GSM Cellular Mobile with Bluetooth&#174; and RFID User Manual 000 P 01A

Panasonic Mobile Communications Development of Europe Ltd UMTS/ GSM Cellular Mobile with Bluetooth® and RFID 000 P 01A

Contents

User Manual Part 2 of 3

Navigation menu

Panasonic Mobile Communications 208009A UMTS/ GSM Cellular Mobile with Bluetooth® and RFID User Manual 000 P 01A
