Fty Control No.: KMP-00-F004
FCC ID : ACJ5Z6KX-P8425
OPERATING INSTRUCTIONS
16
FOR USERS IN UNITED STATES
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
BReorient or relocate the receiving antenna.
BIncrease the separation between the equipment and receiver.
BConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
BConsult the dealer or an experienced radio/TV technician for help.
The user may find the booklet “Something About Interference” available from FCC local regional offices
helpful.
FCC Warning: To assure continued FCC emission limit compliance, the user must use the
recommended shielded interfacing cable when connecting to a host computer. Also, any unauthorized
changes or modifications to this equipment would void the user’s authority to operate this device.
Technical Support Calls
If you have read this manual and tried the troubleshooting procedures and you are still having difficulty,
please contact the reseller from which the unit was purchased. You may also call the end user technical
support telephone number which is operational during East Coast business hours (9:00 AM to 7:00 PM).
The end user technical support number is 1-888-744-2424.
This number is available within the U.S. only.
Helpful Phone Numbers
To locate your nearest sales dealer CALL 1-800-742-8086 ask for COLOR
To order consumables CALL 1-800-222-0584
To order operating instructions/CD’s CALL 1-800-833-9626
To locate your nearest authorized service center CALL 1-888-744-2424
For technical support CALL 1-888-744-2424
Automated 24-hour support via Fax back CALL 1-800-222-0584
Electronic bulletin board CALL 1-201-863-7845
World Wide Web Technical & Driver Support http://www.panasonic.com/alive
nWhen using the network card, use the following shielded cable.
For 10 Base T:
For 100 Base TX: Category 5 shielded cable.
Category 3, 4 or 5 shielded cable.
31
The bidirectional parallel interface is based on the
IEEE P1284-B standard.
If your computer has a bidirectional parallel port, the
printer driver and printer can take advantage of
faster data transfer.
Specifications
Pin configuration
Parallel Interface connector (printer side)
Notes:
B“Return” denotes the return side wire of a twisted
pair cable and is connected to signal ground.
BBe sure to use only a shielded cable. The printer
will not operate properly if any of the pins is not
connected.
■Transparencies and labels
Panasonic has tested and found that the following
work satisfactorily:
OHP transparency: 3M CG3710, Folex BG74.5
Labels: AVERY 5163, AVERY 5164, AVERY 5165,
Avery L7163, Avery L7165, Avery L7166, Avery
L7167, Avery L7168, Avery L7169
BRe-using transparencies that have been fed
through the printer once (for example, after jams
or if the transparency is ejected without being
printed) can reduce the life of the consumables
and paper path components.
BWith any label stock, the labels must completely
cover the backing material.
■Envelopes
It is recommended that you print in black text only
and purchase high quality #10 laser envelopes with
diagonal seams, as shown in the diagram below:
High quality envelopes have the following
characteristics:
BA thin, sharply creased leading edge
BPaper weight of 90 g/m2(24 lbs.)
BFlat, free of curls, wrinkles, nicks, etc.
Note:
BWrinkle may occur in some case, even if high
quality envelopes are used.
NO
The backing material is exposed.
Labels cover the entire backing material.
YES
18
36
1
19
IEEE 1284-B type connector
Cable Use a shielded cable 2 m
(6.6 ft.) or less in length.
Connector Type
Bidirectional Parallel
Interface
Signal
nInit
GND
Return side pin
28
19 nStrobe
Signal Pin
1
20 Data 12
21 Data 23
22 Data 34
23 Data 45
24 Data 56
25 Data 67
26 Data 78
27 Data 89
28 nAck10
29 Busy11
Perror12
28 Select13
30 nAutoFD14
–NC15
–16
–FG17
–+5V(Peripheral)18
3031
Appendix
Reference Guide
nSelectIn
NC
29 nFault32
–33
–NC34
–NC35
3036
