Panasonic Corporation of North America Bluetooth Module Installation Manual 20111026
User Manual
Installation Manual
2011.10.26
This module is to be installed only by the professionals and used only with optional
accessories for Hearing Instruments produced by Panasonic Healthcare Co., Ltd.
When this Bluetooth® module is installed in optional accessories for Hearing Instruments,
we shall consider the following points;
1. Since “WCA-008-XX
” owns its FCC ID Number, we shall affix an exterior label on
the outside of the product if the FCC ID is not visible.
The exterior label shall use wording such as either “Contains Transmitter Module
FCC ID: ACJ927153TX” or “Contains FCC ID: ACJ927153TX”.
2. “WCA-008-XX
” complies with requirements of sub-sections 15.19(a)(3) in FCC Rules
Part 15 Subpart C. The manual statement 15.19 (a)(3) is included User Guide of
the product.
3. “WCA-008-XX
”
is to be installed only by the professional line operator. (Fig 1)
4. XX of “WCA-008-XX” is the Firmware Code. (For example : ST, AT or CT)
Connector (60pin)
Screw Bluetooth® module
Boss
Circuit board of the O
ptional accessory
Screw
Fig 1
60P*-JMCS-G-B-TF(N)
There isn’t an official user manual for this Bluetooth® module
(WCA-008-XX).
However, user manuals of final product which have the module, must
contain notification corresponding to the following description.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of this device.
This equipment complies with FCC radiation exposure limits set forth for uncontrolled
equipment and meets the FCC radio frequency (RF) Exposure Guidelines in
Supplement C to OET65. This equipment has very low levels of RF energy that it is
deemed to comply without testing of specific absorption ratio (SAR).
