(Short term confidential)Users Manual
User’s manual
Product: Bluetooth Module
Model: YEP0PTA606A0
FCC ID: ACJ932YEP0PTA606
For OEM integration only – device cannot be sold to general public.
Therefore we will not supply the User’s manual, the installation manual is the official for OEM.
(Note)
This module was granted as FCC Limited Modular Approval. Additional host systems must provide regulated supply voltages to the
module. Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in
this filing must be installed to provide a separation distance of at least 20 cm from all persons. OEM integrators and end-users must be
provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to
ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or
used in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. Only
those antennas tested with the device or similar antennas with equal or lesser gain may be used with this transmitter.
We will ask OEM to include the following Notices required by FCC on the product and in the User’s manual.
■Requirement of Labeling
(For FCC)
Please describe the following item on the host device of the this module:
Contains Transmitter Module FCC ID: ACJ932YEP0PTA606 or Contains FCC ID: ACJ932YEP0PTA606
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
■Requirement of User’s Manual Statement
(For FCC)
User’s manual shall contain following sentence
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
When installing in Mobile device
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio
frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment has very low levels of RF energy that it deemed to
comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated keeping
the radiator at least 20cm or more away from person’s body (excluding extremities: hands, wrists, feet and ankles).
When installing in Portable device
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio
frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment has very low levels of RF energy that are deemed
to comply without testing of specific absorption ratio (SAR).
* Portable device: Distance between the person's body and the antenna is 20cm or less.
* Mobile device: Distance between the person's body and the antenna is more than 20cm.
