Important Information
Network Camera
Model No. BL-C101 (Wired Type)
BL-C121
(Wireless/Wired Type)
©
Panasonic Communications Co., Ltd. 2008
PNQX1565ZA KK0908CM0
How to Use the Documentation
This manual is written for both the BL-C101 (Wired Type) and BL-C121
(Wireless/Wired Type). Available features and operations vary slightly
depending on the model. You can confirm the model no. of your camera by
checking the model no. printed on the front of the camera.
Model number suffix “A” is omitted from the following model numbers
shown in this document, unless necessary. BL-C101A, BL-C121A
All documentation can be found on the included CD-ROM.
• Important Information (PDF format; printed version also included)
This document. Provides general information and safety instructions for
using the camera.
• Installation Guide (PDF format; printed version also included)
Describes how to physically connect the camera to the power supply
and network, as well how to mount or place the camera for regular use.
• Setup Guide (PDF format; printed version also included)
Describes how to set up the camera so that it can be accessed using a
PC.
• Operating Instructions (HTML format)
Explains how to operate, program, and maintain the camera.
• Troubleshooting Guide (HTML format)
Provides solutions for problems you may have when using the camera.
Abbreviations
• The Network Camera is referred to as “the camera” in this document.
• The Setup CD-ROM is referred to as “the CD-ROM” in this document.
IMPORTANT SAFETY INSTRUCTIONS
When using this unit, basic safety precautions should always be followed
to reduce the risk of fire, electric shock, or personal injury.
1. Read and understand all instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. To clean the camera lens, first remove any dust or dirt from the lens,
then wipe the lens with a cotton bud.
6. Do not block any ventilation openings. Install in accordance with
instructions.
7. Do not install near any heat sources such as radiators, heat registers,
stoves, or other devices (including amplifiers) that produce heat.
8. Protect the AC adaptor cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the unit.
9. The AC adaptor is used as the main disconnect device. Ensure that
the AC outlet is installed near the product and is easily accessible.
10. Only use attachments/accessories (such as stands) specified by the
manufacturer.
11. Do not touch the unit, AC adaptor, or AC adaptor cord during lightning
storms.
12. Unplug the unit when unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required
when the unit has been damaged in any way, such as when the AC
adaptor is damaged, the unit does not operate normally, or after the
unit has been dropped.
14. The camera is intended for indoor use only. Prolonged exposure to
direct sunlight or halogen light may damage the image sensor.
15. For BL-C121: Please check local regulations as outdoor use of the
wireless feature is restricted in some countries/areas.
16. Unplug this unit from power outlets if it emits smoke, an abnormal
smell or makes unusual noise. These conditions can cause fire or
electric shock. Confirm that smoke has stopped and contact an
authorized service center.
SAVE THESE INSTRUCTIONS
FCC and Other Information
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
For BL-C121: Operating near 2.4 GHz electrical appliances may cause
interference. Move away from the electrical appliances.
Environment:
Do not install the camera where the temperature is less than +0 °C (+32 °F)
or greater than +40 °C (+104 °F). Allow 10 cm (4 inches) clearance around
the unit for proper ventilation. Avoid excessive smoke, dust, mechanical
vibration, shock, or direct sunlight.
Routine care:
Wipe the unit with a soft cloth. Do not use benzine, thinner, or any abrasive
powder.
When you leave the unit unused for a long period of time, disconnect the
AC adaptor from the outlet.
If you have any problems:
Consult an authorized Panasonic Factory Service Center.
CAUTION:
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this device.
FCC RF Exposure Warning:
For BL-C121: To comply with FCC RF exposure requirements in
uncontrolled environment:
– This equipment must be installed and operated in accordance with
provided instructions and a minimum 20 cm (8 inches) spacing must be
provided between antenna and all person's body (excluding extremities
of hands, wrist and feet) during wireless modes of operation.
– This transmitter must not be co-located or operated in conjunction with
any other antenna or transmitter.
MEDICAL:
For BL-C121: Consult the manufacturer of any personal medical devices,
such as pacemakers, to determine if they are adequately shielded from
external RF (radio frequency) energy. (The unit operates in the frequency
range of 2.412 GHz to 2.462 GHz, and the power output level is 0.1 watts.)
Do not use the unit in health care facilities if any regulations posted in the
area instruct you not to do so. Hospitals or health care facilities may be
using equipment that could be sensitive to external RF (radio frequency)
energy.
CR Coin Cell Lithium Battery Information:
This product contains a CR Coin Cell Lithium Battery which contains
Perchlorate Material - special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
No responsibility will be taken by our company with respect to
consequences resulting from the use, damage or both of the
camera.
Please read this document before using the product, and save this document for future
reference.
Panasonic Network Camera Website:
http://panasonic.co.jp/pcc/products/en/netwkcam/regionlinks/index.html
Indoor Use Only
BL-C101-C121A_II.fm Page 1 Monday, July 28, 2008 2:05 PM
Security Cautions
When using this product, take appropriate measures to avoid the following
security breaches.
• Disclosure of private information via this product
• Unauthorized use of this product by a third party
• Interference or suspension of the use of this product by a third party
You are responsible for the security of this product and its use. Take the
following measures to avoid security breaches.
• To prevent unauthorized access, disclosure of private information, or
interference or suspension of access to the camera, make sure the
camera’s firmware is up to date.
• Do not reveal the user names and passwords required to access the
camera to an unknown party.
• If you choose to configure this product to allow access to parties without
the need to enter a user name and password (i.e., guest users), be
aware that unknown parties may access this product.
• Do not upload images produced by this product or otherwise release
information where it may be accessed by unknown parties.
• Mount the camera where the camera will not be stolen.
• When sending this product for service or transferring this product to
another party, make backup copies of its setup files, and reset this
product to its factory default settings.
• When disposing of this product, reset the product to its factory default
settings.
User Name and Password Protection
The use of unique user names and secret passwords is an important
tool that will help limit unauthorized individuals from accessing the
camera. If you choose to disable this tool by allowing guest (i.e.
anonymous) access, the camera may be accessed by unauthorized
individuals.
Audio and Video Recording Notice
Please note that under certain circumstances, audio/video recording may
be prohibited by law. This device should be used only in compliance with all
applicable laws and statutes.
MPEG-4 Visual License
This product is licensed under the MPEG-4 Visual patent portfolio license
for the personal and non-commercial use of a consumer for (i) encoding
video in compliance with the MPEG-4 Visual Standard (“MPEG-4 Video”)
and/or (ii) decoding MPEG-4 Video that was encoded by a consumer
engaged in a personal and non-commercial activity and/or was obtained
from a video provider licensed by MPEG LA to provide MPEG-4 Video. No
license is granted or shall be implied for any other use. Additional
information including that relating to promotional, internal and commercial
uses and licensing may be obtained from MPEG LA, LLC.
See http://www.mpegla.com.
About the MPEG-4 Viewer Program
The MPEG-4 viewer program is an ActiveX® Control that is used to play
MPEG-4 files within Internet Explorer. This software is installed
automatically the first time you view MPEG-4 videos.
A software license for the MPEG-4 decoder is included with the MPEG-4
viewer program, and the license is valid for 1 PC. Please read the included
End-User License Agreement before installing the viewer program. When
installing the MPEG-4 viewer program on additional PCs, please purchase
additional licenses (Model No. BB-HCA5A).
About the OpenSSL License
This product includes software developed by the OpenSSL Project for use
in the OpenSSL Toolkit. (http://www.openssl.org/) This product includes
cryptographic software written by Eric Young. (eay@cryptsoft.com)
System Requirements
Your PC and network must meet the following technical specifications in
order for the camera to function properly.
*1 What is IPv6?
• IPv6 is short for “Internet Protocol Version 6”.
• IPv6 was created to provide the additional IP addresses that will be
needed as the Internet continues to expand.
• IPv6 is expected to gradually replace IPv4, with the 2 coexisting for a
number of years during a transition period.
• Though most ISPs (Internet Service Providers) do not yet support IPv6,
many local networks already use it. When your ISP supports IPv6, your
Panasonic Network Camera will be ready!
• For more information, visit http://www.ipv6.org/.
Note:
Refer to the Panasonic Network Camera website at
http://panasonic.co.jp/pcc/products/en/netwkcam/
for details about network environment.
Item Requirement
Operating
System
For IPv4 Connection
Microsoft® Windows Vista®, Windows® XP,
Windows 2000
For IPv6 Connection*1
Microsoft Windows Vista,
Windows XP Service Pack 1 or later
CPU 2.0 GHz Celeron® or faster
Display 1024 x 768 resolution or higher
Protocol For IPv4 Connection
TCP/IP protocol (HTTP, TCP, UDP, IP, DNS, ARP,
ICMP)
For IPv6 Connection
TCP/IP protocol (HTTP, TCP, UDP, IP, DNS, ICMPv6,
NDP)
Interface 10/100 Mbps network card
Wireless
Interface
(BL-C121 Only)
IEEE 802.11b/g (Embedded)
Web Browser Internet Explorer® 6.0 or later (not included)
Audio PC speaker or headphones (required to use the
Listen feature)
Additional
Software (For
Viewing Buffered
MPEG-4 Images)
For Windows Vista
Windows Media® Player 11 or later
For Windows XP
Windows Media Player 9 or later
For Windows 2000
Windows Media Player 9
When You Ship the Product
Panasonic Servicenters are listed in the servicenter directory.
Call 1-800-272-7033 for the location of an authorized servicenter.
This product is designed for use in the United States of America. Sale or
use of this product in other countries/areas may violate local laws.
Carefully pack your unit, preferably in the original carton.
Attach a letter, detailing the symptom, to the outside of the carton.
Symptom
Send the unit to an authorized servicenter, prepaid and adequately insured.
Do not send your unit to the Panasonic Consumer Electronics Company
listed below or to executive or regional sales offices. These locations do
not repair consumer products.
For Product Service
Trademarks
• Microsoft, Windows, Windows Vista, ActiveX, Internet Explorer, and Windows Media are
either registered trademarks or trademarks of Microsoft Corporation in the United States
and/or other countries.
• Celeron is a trademark or registered trademark of Intel Corporation or its subsidiaries in
the United States and other countries.
• All other trademarks identified herein are the property of their respective owners.
The information in this document is subject to change without notice.
Copyright:
This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced
for internal use only. All other reproduction, in whole or in part, is prohibited without the written
consent of Panasonic Communications Co., Ltd.
Panasonic Consumer Electronics Company,
Division of Panasonic Corporation of North America
Panasonic Puerto Rico, Inc.
BL-C101-C121A_II.fm Page 2 Monday, July 28, 2008 2:05 PM
