Panasonic of North America 96NKX-TG3031 2.4 GHz FHSS Cordless Telephone System User Manual
Panasonic Corporation of North America 2.4 GHz FHSS Cordless Telephone System
User Manual
This unit is compatible with Caller ID. To use this feature, you must
subscribe to the appropriate service of your telephone service provider.
Please read these Operating Instructions before using the unit and save
for future reference.
For assistance, visit our website: http://www.panasonic.com for
customers in the U.S.A. or Puerto Rico.
Charge the battery for 7 hours before initial use.
Operating Instructions
2.4 GHz Expandable
Digital Cordless Phone
Model No. KX-TG3021
2.4 GHz Expandable Digital Cordless
Answering System
Model No. KX-TG3031
with Two Handsets
Model No. KX-TG3032
with Three Handsets
Model No. KX-TG3033
2.4 GHz Digital Cordless
Answering System
with Four Handsets
Model No. KX-TG3034
TG302x_303x.book Page 1 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
2
Important safety
instructions
When using this unit, basic safety
precautions should always be followed to
reduce the risk of fire, electric shock, or
personal injury.
1. Read and understand all instructions.
2. Follow all warnings and instructions
marked on this unit.
3. Unplug this unit from power outlets
before cleaning. Do not use liquid or
aerosol cleaners. Use a damp cloth for
cleaning.
4. Do not use this unit near water, for
example near a bathtub, wash bowl,
kitchen sink, etc.
5. Place the unit securely on a stable
surface. Serious damage and/or injury
may result if the unit falls.
6. Do not cover slots and openings on the
unit. They are provided for ventilation
and protection against overheating.
Never place the unit near radiators, or
in a place where proper ventilation is
not provided.
7. Use only the power source marked on
the unit. If you are not sure of the type
of power supplied to your home,
consult your dealer or local power
company.
8. Do not place objects on the power
cord. Install the unit where no one can
step or trip on the cord.
9. Do not overload power outlets and
extension cords. This can result in the
risk of fire or electric shock.
10. Never push any objects through slots
in this unit. This may result in the risk of
fire or electric shock. Never spill any
liquid on the unit.
11. To reduce the risk of electric shock, do
not disassemble this unit. Take the unit
to an authorized service center when
service is required. Opening or
removing covers may expose you to
dangerous voltages or other risks.
Incorrect reassembly can cause
electric shock when the unit is
subsequently used.
12. Unplug this unit from power outlets and
refer servicing to an authorized service
center when the following conditions
occur:
A. When the power cord is damaged
or frayed.
B. If liquid has been spilled into the
unit.
C. If the unit has been exposed to rain
or water.
D. If the unit does not work normally
by following the operating
instructions. Adjust only controls
covered by the operating
instructions. Improper adjustment
may require extensive work by an
authorized service center.
E. If the unit has been dropped or
physically damaged.
F. If the unit exhibits a distinct change
in performance.
13. During thunderstorms, avoid using
telephones except cordless types.
There may be a remote risk of an
electric shock from lightning.
14. Do not use this unit to report a gas
leak, when in the vicinity of the leak.
SAVE THESE
INSTRUCTIONS
CAUTION:
Installation
LNever install telephone wiring during a
lightning storm.
LNever install telephone jacks in wet
locations unless the jack is specifically
designed for wet locations.
LNever touch uninsulated telephone
wires or terminals unless the telephone
line has been disconnected at the
network interface.
LUse caution when installing or modifying
telephone lines.
TG302x_303x.book Page 2 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
3
LDo not touch the plug with wet hands.
LThe AC adaptor is used as the main
disconnect device. Ensure that the AC
outlet is installed near the product and is
easily accessible.
Battery
To reduce the risk of fire or injury to
persons, read and follow these
instructions.
LUse only the battery(ies) specified.
LDo not dispose of the battery(ies) in a
fire. They may explode. Check with local
waste management codes for special
disposal instructions.
LDo not open or mutilate the battery(ies).
Released electrolyte is corrosive and
may cause burns or injury to the eyes or
skin. The electrolyte may be toxic if
swallowed.
LExercise care when handling the
battery(ies). Do not allow conductive
materials such as rings, bracelets or
keys to touch the battery(ies), otherwise
a short circuit may cause the battery(ies)
and/or the conductive material to
overheat and cause burns.
LCharge the battery(ies) provided, or
identified for use with the product only, in
accordance with the instructions and
limitations specified in this manual.
WARNING:
LTo prevent the risk of fire or electrical
shock, do not expose the product to rain
or any type of moisture.
LUnplug the product from power outlets if
it emits smoke, an abnormal smell, or
makes an unusual noise. These
conditions can cause fire or electric
shock. Confirm that smoke has stopped
and contact the Panasonic Call Center
at 1-800-211-PANA (1-800-211-7262).
Medical
LConsult the manufacturer of any
personal medical devices, such as
pacemakers or hearing aids, to
determine if they are adequately
shielded from external RF (radio
frequency) energy. (The product
operates in the frequency range of 2.4
GHz to 2.48 GHz, and the power output
is 125 mW (max.).) Do not use the
product in health care facilities if any
regulations posted in the area instruct
you not to do so. Hospitals or health care
facilities may be using equipment that
could be sensitive to external RF (radio
frequency) energy.
TG302x_303x.book Page 3 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
4
For best performance
Base unit location/noise
The base unit and other compatible
Panasonic units use radio waves to
communicate with each other.
For maximum distance and noise-free
operation, we recommend the following:
LPlacing the product away from electrical
appliances.
LPlacing the base unit in a HIGH and
CENTRAL location with no obstructions
such as walls.
LIf you use the handset near a microwave
oven which is being used, noise may be
heard. Move away from the microwave
oven and closer to the base unit.
LIf you use the handset near another
cordless phone’s base unit, noise may
be heard. Move away from the other
cordless phone’s base unit and closer to
your base unit.
Environment
LKeep the product away from electrical
noise generating devices, such as
fluorescent lamps and motors.
LThe product should be kept free from
excessive smoke, dust, high
temperature, and vibration.
LThe product should not be exposed to
direct sunlight.
LDo not place heavy objects on top of the
product.
LWhen you leave the product unused for
a long period of time, unplug the product
from the power outlet.
LThe product should be kept away from
heat sources such as heaters, kitchen
stoves, etc. It should not be placed in
rooms where the temperature is less
than 5 °C (41 °F) or greater than 40 °C
(104 °F). Damp basements should also
be avoided.
LThe maximum calling distance may be
shortened when the product is used in
the following places: Near obstacles
such as hills, tunnels, underground, near
metal objects such as wire fences, etc.
LOperating the product near 2.4 GHz
electrical appliances may cause
interference. Move away from the
electrical appliances.
Routine care
LWipe the outer surface of the product
with a soft moist cloth. Do not use
benzine, thinner, or any abrasive
powder.
TG302x_303x.book Page 4 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
5
Connections
Connecting the AC adaptor and
telephone line cord
Connect the telephone line cord until it
clicks into the base unit (A) and telephone
line jack (B). Connect the AC adaptor cord
by pressing the plug firmly (C).
Note:
LUse only the included Panasonic AC
adaptor PQLV203V.
LThe AC adaptor must remain connected
at all times. (It is normal for the adaptor
to feel warm during use.)
LThe AC adaptor should be connected to
a vertically oriented or floor-mounted AC
outlet. Do not connect the AC adaptor to
a ceiling-mounted AC outlet, as the
weight of the adaptor may cause it to
become disconnected.
Connecting the AC adaptor
(120 V AC,
60 Hz)
To single-line
telephone jack
(RJ11C)
A
Hooks
B
C
Available model:
KX-TG3032/KX-TG3033/KX-TG3034
Fasten the AC adaptor cord to prevent
it from being disconnected.
(120 V AC, 60 Hz)
Bottom of the charger
Hooks
TG302x_303x.book Page 5 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
6
Battery installation
1Insert the battery, and press it down
until it snaps into the compartment.
2Close the handset cover.
Battery charge
Place the handset on the base unit for 6
hours before initial use.
Note:
LTo ensure the battery charges properly,
clean the charge contacts of the handset
and base unit with a soft, dry cloth once
a month. Clean more often if the unit is
subject to grease, dust or high humidity.
Attention:
A nickel metal hydride battery that is
recyclable powers the product you have
purchased.
Please call 1-800-8-BATTERY for
information on how to recycle this battery.
Controls
Base unit
KX-TG3021
A{LOCATOR}
BIN USE indicator
CCharge contacts
Base unit
KX-TG3031/KX-TG3032/KX-TG3033/KX-
TG3034
A{GREETING REC} (Recording)
B{GREETING CHECK}
CSpeaker
D{ERASE}
E{ANSWER ON}
ANSWER ON indicator
A
BC
A B C
JKMNL
D
H
E
F
G
I
TG302x_303x.book Page 6 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
7
F{MESSAGE}
MESSAGE indicator
G{G} (SKIP)
HIN USE indicator
I{LOCATOR/INTERCOM}
JVOLUME {<} {>}
KMIC (Microphone)
L{H} (REPEAT)
M{STOP}
NCharge contacts
Handset
ASpeaker
BSoft keys
CHeadset jack
D{C} (TALK)
ENavigator key ({^} {V} {<} {>})
F{s} (SP-PHONE)
G{*} (TONE)
H{FLASH} {CALL WAIT}
IMicrophone
JCharge contacts
K
LCharge indicator
Ringer indicator
Message indicator
MReceiver
NDisplay
O{MENU}
P{OFF}
Q{PAUSE}/{REDIAL}
R{HOLD} {INTERCOM}
A
L
M
N
Q
O
R
P
B
B
C
D
E
F
G
H
I
J
K
TG302x_303x.book Page 7 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
8
Making calls
1Lift the handset and press {C}.
2Dial the phone number.
3When finished talking, press {OFF} or
place the handset on the base unit.
To use the speakerphone
1Lift the handset and press {s}.
2Dial the phone number.
3When the other party answers, talk into
the microphone.
4When finished talking, press {OFF} or
place the handset on the base unit.
To redial the last number dialed
1Press {C} or {s}.
2Press {REDIAL}.
Answering calls
1Lift the handset and press {C} or {s}.
2When finished talking, press {OFF} or
place the handset on the base unit.
Using Caller ID service
This unit is Caller ID compatible. To use
Caller ID features, you must subscribe to
your telephone company’s Caller ID
service.
Caller ID features
When an outside call is being received, the
calling party’s name or telephone number
will be displayed.
Caller information for the last 50 callers will
be logged in the caller list, allowing you to
return missed calls. Caller information is
stored by the most recent call to the oldest.
LIf the unit is connected to a PBX system,
caller information may not be received
properly. Consult your PBX supplier.
TG302x_303x.book Page 8 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
9
Answering system
Recording your greeting
message
You can record your own greeting
message (max. 2 minutes) that is played
when the answering system answers a
call.
If you do not record a greeting message, a
pre-recorded greeting message is used.
1{GREETING REC}
2Within 10 seconds, press {GREETING
REC} again.
3After the base unit beeps, speak clearly
about 20 cm (8 inches) away from the
MIC.
4To stop recording, press {STOP}.
Turning the answering system
on/off
Press {ANSWER ON}.
Listening to messages
Press {MESSAGE}.
LThe unit will announce the number of
new messages and will play back the
new messages.
Available model:
KX-TG3031/KX-TG3032/KX-TG3033/
KX-TG3034
TG302x_303x.book Page 9 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
10
FCC and other information
This equipment complies with Part 68 of
the FCC rules and the requirements
adopted by the ACTA. On the bottom of
this equipment is a label that contains,
among other information, a product
identifier in the format US:ACJ----------.
If requested, this number must be
provided to the telephone company.
Registration No
............(found on the bottom of the unit)
Ringer Equivalence No. (REN).......0.1B
A plug and jack used to connect this
equipment to the premises wiring and
telephone network must comply with the
applicable FCC Part 68 rules and
requirements adopted by the ACTA. A
compliant telephone cord and modular
plug is provided with this product. It is
designed to be connected to a
compatible modular jack that is also
compliant.
The REN is used to determine the
number of devices that may be
connected to a telephone line. Excessive
RENs on a telephone line may result in
the devices not ringing in response to an
incoming call. In most but not all areas,
the sum of RENs should not exceed five
(5.0). To be certain of the number of
devices that may be connected to a line,
as determined by the total RENs, contact
the local telephone company. For
products approved after July 23, 2001,
the REN for this product is part of the
product identifier that has the format
US:AAAEQ##TXXXX. The digits
represented by ## are the REN without a
decimal point (e.g.,03 is a REN of 0.3).
If this equipment causes harm to the
telephone network, the telephone
company will notify you in advance that
temporary discontinuance of service may
be required. But if advance notice isn’t
practical, the telephone company will
notify the customer as soon as possible.
Also, you will be advised of your right to
file a complaint with the FCC if you
believe it is necessary.
The telephone company may make
changes in its facilities, equipment,
operations or procedures that could
affect the operation of the equipment. If
this happens the telephone company will
provide advance notice in order for you
to make necessary modifications to
maintain uninterrupted service.
If trouble is experienced with this
equipment, for repair or warranty
information, please contact a Factory
Servicenter or other Authorized Servicer.
If the equipment is causing harm to the
telephone network, the telephone
company may request that you
disconnect the equipment until the
problem is resolved.
Connection to party line service is
subject to state tariffs. Contact the state
public utility commission, public service
commission or corporation commission
for information.
If your home has specially wired alarm
equipment connected to the telephone
line, ensure the installation of this
equipment does not disable your alarm
equipment. If you have questions about
what will disable alarm equipment,
consult your telephone company or a
qualified installer.
This equipment is hearing aid compatible
as defined by the FCC in 47 CFR
Section 68.316.
TG302x_303x.book Page 10 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
11
When you hold the phone to your ear,
noise might be heard in your Hearing Aid.
Some Hearing Aids are not adequately
shielded from external RF (radio
frequency) energy. If noise occurs, use
an optional headset accessory or the
speakerphone option (if applicable) when
using this phone. Consult with your
audiologist or Hearing Aid manufacturer
about the availability of Hearing Aids
which provide adequate shielding to RF
energy commonly emitted by digital
devices.
WHEN PROGRAMMING EMERGENCY
NUMBERS AND(OR) MAKING TEST
CALLS TO EMERGENCY NUMBERS:
1) Remain on the line and briefly explain
to the dispatcher the reason for the
call.
2) Perform such activities in the off-peak
hours, such as early morning or late
evenings.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
Privacy of communications may not be
ensured when using this phone.
CAUTION:
A
ny changes or modifications not
expressly approved by the party
responsible for compliance could void the
user’s authority to operate this device.
NOTE:
This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to Part 15 of
the FCC Rules. These limits are
designed to provide reasonable
protection against harmful interference in
a residential installation. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and
used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
– Consult the dealer or an experienced
radio/TV technician for help.
Some cordless telephones operate at
frequencies that may cause interference
to nearby TVs and VCRs. To minimize or
prevent such interference, the base of
the cordless telephone should not be
placed near or on top of a TV or VCR. If
interference is experienced, move the
cordless telephone further away from the
TV or VCR. This will often reduce, or
eliminate, interference.
FCC RF Exposure Warning:
L This product complies with FCC
radiation exposure limits set forth for
an uncontrolled environment.
L To comply with FCC RF exposure
requirements, the base unit must be
installed and operated 20 cm (8
inches) or more between the base unit
and all person’s body (excluding
extremities of hands, wrist and feet).
L This product may not be collocated or
operated in conjunction with any other
antenna or transmitter.
L For body-worn operation, the handset
must be used only with a non-metallic
accessory. Use of other accessories
may not ensure compliance with FCC
RF exposure requirements.
TG302x_303x.book Page 11 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
If you need assistance with setup or operation;
1Visit our website: http://www.panasonic.com/support
2Contact us via the web at: http://www.panasonic.com/contactinfo
3Call us at: 1-800-211-PANA (1-800-211-7262)
TTY users (hearing or speech impaired users) can call 1-877-833-8855.
When you ship the product;
LCarefully pack your unit, preferably in the original carton.
LAttach a letter, detailing the symptom, to the outside of the carton.
LSend the unit to Panasonic Services Company Customer Servicenter, prepaid and
adequately insured.
LDo not send your unit to Panasonic Consumer Electronics Company listed below or to
executive or regional sales offices. These locations do not repair consumer products.
Panasonic Consumer Electronics Company,
Division of Matsushita Electric Corporation of America
One Panasonic Way, Secaucus, New Jersey 07094
Panasonic Sales Company,
Division of Matsushita Electric of Puerto Rico, Inc.
Ave. 65 de Infantería, Km. 9.5, San Gabriel Industrial Park
Carolina, Puerto Rico 00985
TG302x_303x.book Page 12 Tuesday, September 26, 2006 11:05 AM
Temporary Confidential
