9TGCF 19A User Manual HTML Version

Users Manual

Contents

Getting Started

OPERATING INSTRUCTIONS

Personal Computer

Model No. CF-19 series

Introduction ................................................................. 2

Read Me First ............................................................. 3

Description of Parts ..................................................10

First-time Operation ..................................................13

Useful Information

On-screen Manual ....................................................18

Handling and Maintenance .......................................19

Reinstalling Software ................................................21

Troubleshooting

Troubleshooting (Basic) ............................................23

Appendix

LIMITED USE LICENSE AGREEMENT ...................27

Speciﬁ cations ...........................................................29

LIMITED WARRANTY ..............................................32

Please read these instructions carefully before using this product and save this manual for future use.

For further information about the com-

puter, you can refer to the on-screen

manual.

To access the on-screen manual

 page 18 “On-screen Manual”

Getting StartedUseful InformationTroubleshootingAppendix

CF-19CTQZZBM.indb 1 2008/11/10 10:16:09

Getting Started

Introduction

Thank you for purchasing this Panasonic computer. For optimum performance and safety, please read these instruc-

tions carefully.

 Terms and illustrations in these instructions

CAUTION : Conditions that may result in minor or moderate injury.

NOTE : Useful and helpful information.

Enter

: Press [Enter] key.

: Press and hold [Fn] key, and then press [F5] key.

(Start) - [All Programs] : Click (Start), and then click [All Programs].

[start] - [Run] : Click [start], and then click [Run]. You may need to double-click in some cases.

 : Page in these Operating Instructions or in the Reference Manual.

: Reference to the on-screen manuals.

 indicates Windows Vista® Business Operating System.

 indicates Microsoft® Windows® XP Professional Operating System or indicates Microsoft® Windows®

XP Tablet Operating System.

 Some illustrations are simpliﬁ ed to help your understanding and may look different from the actual unit.

 If you do not log on as an administrator, you cannot use some functions or cannot display some screens.

 Refer for the latest information about optional products to the catalogs, etc.

 In these instructions, the names and terms are referred as follows.

 “Windows Vista® Business” as “Windows” or “Windows Vista”

 “Microsoft® Windows® XP Professional Service Pack 2 with Advanced Security Technologies” as “Windows”, “Win-

dows XP” or “Windows XP Professional”

 “Microsoft® Windows® XP Tablet PC Edition 2005” as “Windows”, “Windows XP” or “Windows XP Tablet PC Edi-

tion”

 DVD-ROM & CD-R/RW drive and DVD MULTI drive as “CD/DVD drive”

 Circular media including DVD-ROM and CD-ROM as “discs”

 Disclaimer

Computer speciﬁ cations and manuals are subject to change without notice. Panasonic Corporation assumes no li-

ability for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the

manuals.

 Trademarks

Microsoft®, Windows®, Windows Vista, and the Windows logo are registered trademarks of Microsoft Corporation of the

United States and/or other countries.

Intel, Core, Centrino and PROSet are either registered trademarks or trademarks of Intel Corporation.

SDHC Logo is a trademark.

Adobe, the Adobe logo and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorpo-

rated in the United States and/or other countries.

Computrace® is a registered trademark of Absolute® Software Corp.

Bluetooth

™

is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Panasonic Corporation.

Panasonic® is a registered trademark of Panasonic Corporation.

Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective

own companies.

CF-19CTQZZBM.indb 2 2008/11/10 10:16:13

Getting Started

Read Me First

Models for U.S.A.

Federal Communications Commission Radio Fre-

quency Interference Statement

Note: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential instal-

lation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interfer-

ence will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one

or more of the following measures:

 Reorient or relocate the receiving antenna.



Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit dif-

ferent from that to which the receiver is connected.

 Consult the Panasonic Service Center or an experi-

enced radio/TV technician for help.

Warning

To assure continued compliance, use only shielded inter-

face cables when connecting to a computer or peripheral.

Also, any changes or modiﬁ cations not expressly ap-

proved by the party responsible for compliance could void

the user’s authority to operate this equipment.

FCC RF Exposure Warning:



This computer is provided with PC Card slot that could

be used with wireless transmitter(s), which will be speciﬁ -

cally recommended when they become available. Other

third-party wireless transmitter(s) have not been RF

exposure evaluated for use with this computer and may

not comply with FCC RF exposure requirements.



This computer complies with FCC radiation exposure

limits set forth for an uncontrolled environment.



This computer may not be co-located or operated with

any other antenna or transmitter.

 This PC with WLAN and/or Bluetooth transmitters in-

stalled, has been approved for portable operation and

does not require any minimum spacing be provided

between antennas and all person’s body.



This PC with WWAN transmitter installed, has been ap-

proved for portable operation, requires LCD side panel

spacers to provide minimum 1.5cm spacing between

antenna located within the LCD side panel, and all per-

son’s body (excluding extremities of hands, wrist and feet)

during wireless modes of operation.



This equipment is provided with external antenna

connector(s) for connection to optional Car Mounter or

Port Replicator for mobile external mounted antenna(s).

External antenna(s) must be professionally installed and

cannot exceed recommended maximum antenna gain as

described in individual provided supplement instructions

for wireless transmitters. Also, user must maintain mini-

mum 20 cm spacing between external antenna(s) and all

person’s body (excluding extremities of hands, wrist and

feet) during wireless modes of operation.

This product is restricted to indoor use due to its operation

in the 5.15 to 5.25 GHz frequency range. FCC requires this

product to be used indoors for the frequency range 5.15 to

5.25 GHz to reduce the potential for harmful interference

to co-channel Mobile Satellite systems. High power radars

are allocated as primary users of the 5.25 to 5.35 GHz and

5.65 to 5.85 GHz bands. These radar stations can cause

interference with and/or damage this product.

25-M-W-1
