Users Manual 2
25
Troubleshooting
List of Error Codes
When turning on the computer, if one of the following error codes or messages is displayed, follow the instructions shown below.
If the problem persists, or if the error code or message displayed is not shown here, contact Panasonic Technical Support.
Error Code/Message
0211: Keyboard error
0251: System CMOS checksum
bad - Default configuration used
0271: Check date and time set-
tings
0280: Previous boot incomplete
- Default configuration used
02B0: Diskette drive A error
0613: Serial Port*1 configura-
tion changed
0614: Serial Port*1 config. error
- device disabled
*1The port name, such as A or B, is
displayed, indicating the conflict-
ing ports.
Press <F2> to Setup
Operating System not found
Extended RAM Module Failed
Action
If an external keyboard or mouse is connected, disconnect these devices.
An error has occurred in the memory that stores the Setup Utility settings. This error occurs
when the memory content is changed through some inadvertent operation by a program or
other function.
Run the Setup Utility and load the default values, then change the settings to the appropri-
ate values as needed.
If the problem persists, the internal clock battery may need to be replaced. Contact Pana-
sonic Technical Support.
The data and time setting are incorrect.
Run the Setup Utility and set the date and time correctly.
If the problem persists, the internal clock battery may need to be replaced. Contact Pana-
sonic Technical Support. ( page 44)
Startup has failed repeatedly, so the Setup Utility settings have been returned to their default
values, and the computer has been restarted.
Run the Setup Utility and load the default values, then change the settings to the appropri-
ate values as needed.
Disconnect the floppy disk drive and reconnect it. Make sure the drive is secured cor-
rectly.
I/O address and IRQ settings are in conflict.
Run the Setup Utility and change the settings in [Advanced] menu so there is no port
conflicts.
Write down the error details and press F2 to run the Setup Utility. Confirm the settings,
and change the settings to the appropriate values as needed.
The OS is not properly installed on the floppy disk or the hard disk that you are trying to boot
from.
If the computer cannot be booted from the floppy disk, check the floppy disk drive to
ensure that the disk is in fact bootable, and change it to another if not.
If the computer cannot be booted from the hard disk, confirm whether the hard disk is
properly recognized in [Information] menu of the Setup Utility.
• If the hard disk is recognized, perform the reinstallation procedure.
• If not, contact Panasonic Technical Support.
If a device is connected to the USB port, disconnect the device, or run the Setup Utility
and set [Legacy USB Support] in [Advanced] menu to [Disable].
If the extended RAM module has not been inserted properly, or if an extended RAM
module other than one matching the specifications has been inserted, a beep will sound
and the message “Extended RAM Module Failed” will be displayed when turning the
power on. In this case, turn the power off, confirm that the extended RAM module meets
the specifications, and reinsert it.
To run the Setup Utility
1Restart the computer.
2Press F2 while [Panasonic] boot screen is displayed soon after the computer begins the startup procedure.
Troubleshooting
26
The power indicator or bat-
tery indicator is not lit
The computer does not op-
erate when a USB device is
connected
[Enter Password] is dis-
played
POST Startup Error(s) is
displayed
Windows startup, or an op-
eration is extremely slow
The date and time are incor-
rect
When resuming from the
standby or hibernation
mode, [Enter Password]
does not appear even if a
password has been set in the
Setup Utility
When the administrator
password is forgotten
When “Remove disks or
other media. Press any key
to restart” (or a similar mes-
sage) is displayed
[Executing Battery
Recalibration] screen is dis-
played
When a problem occurs, refer to this page. The “Reference Manual” also contains detailed information. If a problem appears to be
related to a software application, read the software related manual. If you still cannot troubleshoot the problem, contact Panasonic
Technical Support. You can use the PC Information Viewer to check the computer’s usage status. ( “Dealing with
Problems (Advanced)”)
Dealing with Problems (Summary)
Starting Up
Check the cable connection for the AC adaptor.
Check to see if a fully charged battery is properly installed.
Remove the battery pack and disconnect the AC adaptor, then connect them again.
The computer may not operate when certain USB devices are connected. Disconnect the
USB device, or set [Legacy USB Support] to [Disable] in [Advanced] menu of the Setup
Utility.
Input your Supervisor Password or User Password. If you have forgotten it, contact Pana-
sonic Technical Support. ( page 44)
page 25
Press F9 in the Setup Utility ( “Setup Utility”). This will restore the Setup
Utility’s settings to their default values (except the password settings). Then, the Setup
Utility must be run once again for you to input the appropriate operating environment
settings. (The processing speed depends on the application software used, so this opera-
tion may not cause the processing speed to increase.)
If you install resident software after purchasing this computer, disable the resident software.
You can set the date and time using the following menu.
[start] - [Control Panel] - [Date, Time, Language, and Regional Options] - [Date and Time]
If you continue to experience problems, the internal battery maintaining the clock may
need to be replaced. Contact Panasonic Technical Support.
When the computer is connected to a LAN, confirm the date and time of the server.
This computer will not correctly recognize the date and time starting from the year 2100
A.D.
Even when a password has been set in the Setup Utility, [Enter Password] does not appear
when the computer resumes from the standby or hibernation mode.
If you want to use the security function when using the standby or hibernation mode, use
the Windows password as follows:
1Select the account to change in [start] - [Control Panel] - [User Accounts] and set the
password.
2Add the check mark for [Prompt for password when computer resumes from standby]
in [Control Panel] - [Performance and Maintenance] - [Power Options] - [Advanced].
If you have created a password reset disk ( page 15), a message is displayed when you
fail to correctly enter the password. Follow the message’s instructions and set the pass-
word again by using the password reset disk.
If you have not created a password reset disk, after reinstalling, setup Windows and then
set the password again.
This means a floppy disk that does not contain system startup information has been left in
the floppy disk drive. Remove the floppy disk, and press any key.
This message may appear when certain USB devices are connected. Remove the USB de-
vice, or set [Legacy USB Support] in [Advanced] menu of the Setup Utility to [Disable].
If the message still appears even after trying the above two measures, this may be an
indication that some type of hard disk failure has occurred. Contact Panasonic Technical
Support.
This screen appears because the Battery Recalibration was canceled before Windows was
shut down last. To start up Windows, turn off the computer by sliding the power switch,
and then turn it back on again.
27
Troubleshooting
When the previous item is
not the cause
Starting Up (continued)
Press F9 in the Setup Utility ( “Setup Utility”). This will restore the Setup
Utility’s settings to their default values (except the password settings).
Try removing all peripheral devices.
Check a disk error using the following procedure.
1Select [Local Disk(C:)] with the right button in [start] - [My Computer], and select
[Properties].
2Select [Tools] - [Check Now].
3Select [Start] after selecting required items in [Check disk options].
At startup, hold down F8 when [Panasonic] boot screen disappears*1, and release your
finger when the Windows Advanced Options Menu is displayed. Start the computer in
Safe Mode, and confirm the details of the error.
*1When [Password on boot] is set to [Enable], [Enter Password] appears after the [Panasonic] boot
screen disappears. Hold down F8 soon after inputting the password and pressing Enter .
No display after powering on
The power has not been
turned off, but after a cer-
tain period of time, there is
no display
When the battery pack is
used, the screen is darker
than when the AC adaptor
is connected
An afterimage appears (e.g.,
green, red, and blue dots re-
main on the display) or there
are dots not displaying the
correct colors
The screen becomes disor-
dered
The external display no
longer displays properly
When you want to display
the fonts or icons at a larger
size
When there is no display to an external display,
• Check your cable connection to the external display.
• Confirm your display is powered on.
• Check the settings for your external display.
The display destination may be set to the external display.
Try changing the display destination by pressing Fn + F3 .
If you want to switch the display destination repeatedly by pressing Fn + F3 , make
sure that the display destination has switched completely each time before pressing
Fn + F3 again.
Press Fn + F2 and adjust the brightness.
Has the computer been set to the power-saving mode?
To resume operation of your computer from the condition the power of the display is off
(for energy conservation purposes), press any key unrelated to the direct triggering of a
selection, like Ctrl .
To save power, your computer may have automatically entered the standby mode (power
indicator blinks green) or hibernation mode (power indicator turns off). In such cases,
slide the power switch.
Press Fn + F2 and adjust the brightness. Note, however, that when the brightness is
increased, the battery running time will become shorter.
Brightness can be set to separate levels for when the AC adaptor is connected and when it
is disconnected.
If an image is displayed for a prolonged period of time, an afterimage may appear. This is
not a malfunction. The afterimage will disappear when a different screen is displayed.
High-precision and advanced technologies are necessary in the production of color liquid
crystal displays (color LCDs). Therefore, if 0.002% or less of the picture elements either
fail to light or remain constantly lit (that is, more than 99.998% of elements are function-
ing properly), no defect is considered to exist.
The screen display may become distorted if the resolution or number of colors is changed,
or if an external display is connected or disconnected while the computer is operating.
Restart the computer.
When an external display not compatible with the power saving mode is used with the
computer, the display may not function correctly when the computer enters the power
saving mode. In such cases, turn off the power to the external display.
Change the size of the icons, etc. using “Icon Enlarger” ( “Icon Enlarger”).
To enlarge a part of the screen, use Loupe Utility ( “Loupe Utility”).
Display
Troubleshooting
28
Dealing with Problems (Summary)
During simultaneous dis-
play, one of the screens be-
comes disordered
When an a moving picture
such as an MPEG file is be-
ing played with Media
Player, the display destina-
tion cannot be switched us-
ing Fn + F3
Try changing the display by pressing Fn + F3 .
If you continue to experience problems, try changing the display destination in the follow-
ing menu.
[start] - [Control Panel] - [Other Control Panel Options] - [Intel(R) Extreme Graphics 2
M] - [Devices]
When the [Command Prompt] is set to “Full Screen” by pressing Alt + Enter , the
picture is displayed on one of the screens only. When the window display is restored by
pressing Alt + Enter , the picture is displayed on both screens.
The display destination cannot be switched while a moving picture such as an MPEG file
is playing. Stop playing the moving picture before switching the display destination.
Display (continued)
Windows cannot be shut
down or restarted
Shutting Down
If a USB device is connected, try removing it.
It may take one or two minutes to shutdown.
Battery Indicator
The red indicator lights.
The red indicator blinks
The green indicator blinks
The battery indicator blinks
green and orange alternately
The orange indicator blinks
The battery level is very low (the charge is approx. 9% or less).
Connect the AC adaptor. You can use the computer when the battery indicator light is
orange. If you do not have an AC adaptor, save your data and power off your computer.
After replacing the battery pack with a fully charged one, turn your computer on.
Quickly save your data and power off your computer. Remove the battery pack and dis-
connect the AC adaptor, then connect them again.
If the problem persists, contact Panasonic Technical Support. ( page 44) The battery
pack or charging circuit may be defective.
In high temperature mode, the battery is discharging to the level that corresponds to an
80%*1 charge for normal temperature mode. ( “Battery Power”) Do not re-
move the battery pack while the battery indicator is blinking green.
*1 In high temperature mode, the level that corresponds to an 80% charge for normal temperature
mode is displayed as [100%].
Warming up the system to prevent hard disk drive malfunctions at low temperature. Leave
your computer as is. Once the allowable temperature range requirement is satisfied, your
computer will start automatically.
Battery cannot be recharged temporarily because the internal temperature of the battery
pack is outside of the acceptable temperature range for recharging. Once the allowable
range requirement is satisfied, charging begins automatically. Your computer can be used
normally in this state.
29
Troubleshooting
Touch Pad / Touchscreen (only for models with touchscreen)
If you are using an external mouse, ensure that the external mouse has been connected
correctly.
Restart the computer by using the keyboard (Press , U , and select [Restart] with
R ).
If the computer does not respond to keyboard commands, read “No response”
( page 30).
When the Microsoft® IntelliMouse™ Wheel mode or the original mode is set for the touch
pad, only scroll operations are possible for the right part or bottom part of the touch pad.
In this case, cursor operations are possible by using the work surface excluding the right
part or bottom part. When no mode is set, the entire surface of the touch pad can be used
for cursor operations.
Has the Setup Utility been used to set [Touch Pad] to [Enable]?
When external mouse drivers are installed (e.g., Intellimouse), the touch pad may not be
used.
Has the touch pad driver been properly installed?
As a result of the physical characteristics of the touchscreen, sometimes the position of the
stylus does not match the position of the cursor on the screen. This is not a malfunction.
Perform [Calibration] ( page 13).
Has the Setup Utility been used to set [Touchscreen] to [Enable]?
When mouse drivers are installed (i.e. IntelliMouse), the touchscreen is unable to be used.
Has the touchscreen driver been properly installed?
The cursor cannot be con-
trolled properly
The cursor does not move in
scrolling area of the touch
pad
Unable to input using the
touch pad
Unable to point correctly
with the stylus included with
the computer
Unable to input by touching
the display
The Reference Manual is
not displayed
Is Adobe Reader installed?
If you have uninstalled Adobe Reader, install using the following procedures.
1Select [start] - [Run], input [c:\util\reader\AdbeRdr60_enu_full.exe], then select [OK].
Install Adobe Reader by following the instructions on the screen.
2Update Adobe Reader to its latest version.
If your computer is connected to the Internet, start up Adobe Reader and select [Help]
- [Update].
If your computer is not connected to the Internet, select [start] - [Run], input
[c:\util\reader\Acro-Reader_6.0.2_Update.exe], then select [OK].
Reference Manual
Some applications may not
work properly
When switching to a different user with the Fast User Switching function, the following
problems may occur.
• Some applications may not work properly.
• Key combinations with the Fn key may not work.
• It may not be possible to set the settings of the display.
• A serial mouse may not work.
• <Only for models with wireless LAN>
Wireless LAN may not work.
In this case, log off all users without using Fast User Switching function, and try the
operation once more. If the problem persists, restart the computer.
Fast User Switching function
Troubleshooting
30
Dealing with Problems (Summary)
Others
Press Ctrl + Shift + Esc to open Task Manager and close the software application
which is not responding.
Is there an input screen (e.g., password input screen at startup) hidden behind another
window? Use Alt + Tab to check for other windows being displayed.
After shutting down by sliding the power switch for more than four seconds, slide the
power switch to power on and open the application again.
If the program no longer works normally, delete the program using the following menu.
Then reinstall the program.
[start] - [Control Panel] - [Add or Remove Programs]
Some video files use a Codec that is not installed as a standard. In these cases, if you play
back the video file after connecting to the Internet, the Codec may be downloaded auto-
matically, allowing you to play back the file.
If you cannot start up a program or share files, this may be because the “Firewall (Win-
dows Firewall)” in the “Windows Security Center” is set to be enabled.
If this function is set to be enabled, damage from viruses and other attacks is reduced, but
some programs and functions cannot be operated.
To use the program or to share files or printers:
You can use programs or other functions without the effects of the Windows Firewall by
registering them as an exception in the Windows Firewall settings (it is not necessary to
disable the Windows Firewall).
Note, however, that if a program is registered as an exception, there is a risk of damage
from viruses or other attacks. Before registering a program as an exception, confirm the
program’s safety with the manufacturer or other reliable source.
1Select [start] - [Control Panel] - [Security Center] - [Windows Firewall].
2Select [Exceptions].
3To register a network game or other programs as an exception:
Select [Add Program], select the program, and select [OK].
To set access through a specified port as an exception:
Select [Add Port], set the port, and select [OK].
To set a file or printer as an exception:
Add the check mark for [File and Printer Sharing].
4Confirm that there is a check mark for the item to be set as an exception, and select [OK].
The Windows Firewall is a security function designed to protect your computer from
unauthorized access via the Internet and other external networks.
The firewall regulates the data exchanged between the computer and the external network,
so that only approved data can pass through. We recommend that you use your computer
with the Firewall enabled to minimize damage from viruses and other malicious attacks.
When installing additional commercially available firewall software, we recommend that
you disable the Windows Firewall settings, as the new software may interfere with the
Windows Firewall functions.
For details, refer to the manual accompanying the firewall software to be installed.
Only Windows Update programs with a high level of priority will be automatically down-
loaded (or installed).
Update programs with a comparatively low level of importance will not be downloaded
(or installed) automatically. Check regularly whether new update programs have become
available.
The Security Center warning function will not operate if you are using a network domain,
for example at a company.
No response
When trying to play back
video files using Windows®
Media Player, the message
[Codec required] appears,
and the file cannot be played
back
Cannot start a network-
used program, or cannot
share files or printers
Is it necessary to enable the
Windows Firewall?
When “Automatic Updates”
is enabled, will all updates
be downloaded (or in-
stalled)?
Security Center warning
function does not operate
31
Troubleshooting
Others (continued)
In Windows XP, security functions have been strengthened with regard to Web contents.
One of these is the “Pop-up Blocker,” which may prevent some Web pages from being
displayed.
If you have any problems with Web page displays (e.g., if a page cannot be displayed
correctly on Internet Explorer), check the contents of the message window displayed be-
low the address bar (called the “Information Bar”). The Information Bar shows the infor-
mation that has been suppressed by Internet Explorer.
• If the message “Pop-up blocked” is displayed:
Select the message, and select “Temporarily Allow Pop-ups.”
The blocked Popup will be displayed temporarily.
• If the message “This site might require the following ActiveX control...” is displayed:
1Select the message, and select “Install ActiveX Control.”
2Check “Name” and “Publisher” on the [Security Warning] screen, and execute the
installation.
• If you cannot find the Information Bar:
If you need to display the page, select the Web page link while pressing Ctrl . The
pop-up blocker function will be temporarily disabled.
In Windows XP, there is a function that blocks image displays in HTML e-mail messages.
To display images in HTML e-mail messages, it is necessary to access the sender’s server,
and this may cause problems in the computer.
Preventing these images from appearing can decrease the risk of attack from viruses etc.
If you need to display images, select the segment where the message “Some pictures have
been blocked?” is displayed. The images can be displayed temporarily.
If a message received in Outlook Express has contained an attachment file with an exten-
sion such as “.exe” or “.scr” (potentially unsafe files), Windows XP blocks those files.
If you need to read the files, select [Tools] - [Options] - [Security] and remove the check
mark from [Do not allow attachments to be saved or opened that could potentially be a
virus].
This message is displayed by the “Security Center” function in Windows XP.
The “Security Center” is a function that monitors the level of safety in Windows security
settings in order to operate the computer safely, for example, with regard to antivirus
measures.
It checks the following three items regularly, and displays messages until the settings are
made at an appropriate level of safety.
• Firewall: Is the Windows Firewall enabled?
• Automatic Updates: Is the automatic Windows Update function enabled?
• Virus Protection: Has antivirus software been installed, has the latest version of the
antivirus software been installed, and is the real-time search function enabled (ON)?
The message “Your computer might be at risk” is displayed by the “Security Center”
function, and does not indicate an error or malfunction. The "Security Center" function
checks the above three items to ensure that your computer can be used safely, and notifies
the user if the settings are not at an appropriate level of safety.
You can continue to use the computer even if these messages continue to be displayed, but
we recommend that you follow the procedures below to minimize damage from viruses.
1Read the message.
2Select (red icon) on the taskbar.
3The [Windows Security Center] screen will be displayed.
Select [Recommendations] in [Firewall] or [Virus Protection], or select [Turn on Auto-
matic Updates] in [Automatic Updates].
If measures are not required, [Recommendations] or [Turn on Automatic Updates] will
not be displayed.
4Execute the appropriate measures, following the instructions in the [Recommendation]
screen.
Problem with Web page dis-
play (no display; display is
completely white; advertise-
ments, logon, and other pop-
ups are not displayed)
Images in HTML e-mail
messages are not displayed
in Outlook Express
Cannot read attachment file
in Outlook Express (cannot
save file)
The message “Your com-
puter might be at risk” is
displayed
Troubleshooting
32
Others (continued)
This message is displayed because the “Automatic Updates” setting in the “Security Cen-
ter” is disabled or is not set. (Settings have not been made at the time of purchase.)
“Automatic Updates” is a function that regularly checks whether high-priority update pro-
grams (security updates, etc.) have been provided to Windows Update, and automatically
installs these programs to maintain Windows in its latest condition.
You can continue using the computer even if these messages continue to be displayed, but
we recommend that “Automatic Updates” is set as [Automatic] to maintain its latest con-
dition.
1Read the message.
2Select (yellow icon) on the taskbar.
The [Automatic Updates] screen will be displayed.
3Select [More Options], and set the Automatic Updates to [Automatic].
Some software applications installed after the time of purchase are not compatible with
Windows XP Service Pack 2. Refer to software maker’s homepage or other sources.
If a network-used program is not compatible, also refer to “Cannot start a network-used
program...” ( page 30)
(yellow icon) is dis-
played
Some applications do not
work properly
Dealing with Problems (Summary)
33
Troubleshooting
Reinstalling Software
Before Reinstallation
Preparing
• Product Recovery CD-ROM (included)
• Panasonic CD/DVD drive (optional: Confirm the latest information on optional products in catalogs, etc.)
Reinstalling
Important
Before the reinstallation procedure, remove all peripherals (except for the CD/DVD drive).
Be sure the AC adaptor is connected until the reinstallation procedure is completed.
When reinstallation procedure is performed, the contents of the hard disk will be erased. Be sure to back up any critical data on
your hard disk to another media or to an external hard disk before running the reinstallation procedure.
The reinstallation procedure will return the computer to its original condition.
Even if a hard disk backup area has been created, this backup area will be erased, and all the backed up data will be lost.
(This is not the case when Windows is reinstalled in the first partition.)
• If you have created partitions for data, the data may be erased or become corrupt as a result of the reinstallation procedure.
1Turn off the computer and insert the CD/DVD drive into
the multimedia pocket. ( “Multimedia Pocket”)
2Turn on the computer, and press F2 while [Panasonic]
boot screen is displayed.
The Setup Utility will start up.
If the password has been set, enter the Supervisor Pass-
word.
3Write down all of the contents of the Setup Utility and
then press F9 .
At the confirmation message, select [Yes] and press
Enter .
4Select [Boot] menu, then select [CD/DVD Drive] and
press F6 until [CD/DVD Drive] is at the top of the
[Boot] menu.
5Place the disc number one of the recovery CDs into the
CD/DVD drive.
6Press F10 .
At the confirmation message, select [Yes] and press
Enter .
The computer will restart, and this screen should appear.
---------------------------------------------------------------------
Select a number
---------------------------------------------------------------------
Reinstalling : Windows(R) XP Professional
1. Reinstall Windows to the whole HDD to factory default.
2. Make two partitions, for the operating system and data. And reinstall
Windows to the operating system partition.
(All existing partitions on HDD will be lost.)
3. Reinstall Windows to the first partition.
0. Cancel
---------------------------------------------------------------------
8Press 1 to select [1. Yes, I agree to the provisions above
and wish to continue!].
This screen should appear.
<When the hard disk backup function has been enabled>
When the message [The Backup function has been en-
abled. If [Recovery] or [Erase HDD] is executed, the
Backup function will be disabled, and your Backup data
will be lost.] appears, press Y .
7Press 1 to execute [1.[Recovery]].
(You can cancel this operation by pressing 0 .)
The License Agreement screen should appear.
---------------------------------------------------------------------
Select a number
---------------------------------------------------------------------
1. [ Recovery ] Reinstall Windows.
2. [ Erase HDD ] Erase the whole data on HDD for security.
3. [ Backup ] Enable the Backup function.
0. [ Cancel ] Cancel.
---------------------------------------------------------------------
Troubleshooting
34
Do not interrupt the reinstallation procedure be-
fore completion, for example by turning off the
computer or pressing Ctrl + Alt + Del , as
this may prevent Windows from starting up, or may
cause data to be lost so that the reinstallation pro-
cedure cannot be executed.
When a message appears instructing you to insert
the next CD, insert the recovery CD showing the
next number in the sequence, and then select [OK].
If the message [The media does not contain the cor-
rect file] appears, select [OK]. A message will ap-
pear instructing you to insert the next CD.
Confirm that the proper recovery CD has been in-
serted by opening the cover of the CD/DVD drive
and then close the cover, then select [OK].
CAUTION
10 At the confirmation message , press Y .
The operation of reinstallation for the hard disk starts au-
tomatically. (The operations take about 15 minutes.)
14 Press F9 .
At the confirmation message, select [Yes] and press
Enter . (The Setup Utility settings will return to their
default values. Even the security settings with the excep-
tion of the password(s) will return to their default val-
ues.)
15 Select [Exit] and then select [Save Current Values], then
press Enter .
At the confirmation message, select [Yes] and press
Enter .
16 Turn the computer off by sliding the power switch.
17 Perform the first-time use operation ( page 12 step 6
- page 14 step 9).
18 Run the Setup Utility and change the settings where nec-
essary.
<Changing the drive letter>
You can change the drive letter for the CD/DVD drive or hard
disk drive by the following steps.
Drive letters can only be changed when two or more parti-
tions have been created on the hard disk drive. The name
of the C: drive cannot be changed.
We recommend that you make these changes before in-
stalling applications.
1Select [start] - [Control Panel] - [Performance and Mainte-
nance] - [Administrative Tools] - [Computer Management].
2Select [Disk Management] from [Storage].
3Right click on the partition of the hard disk or the name of
the CD/DVD drive and select [Change Drive Letter and
Paths...].
4Select [Change].
5Select [Assign the following drive letter] and the new drive
letter, and then select [OK].
6At the confirmation message, select [Yes].
9Make a selection from the menu.
When selecting [2], enter the basic partition size for
the operating system installation and press
Enter .
(The data partition size is the remainder after subtract-
ing the basic partition size.)
To select [3], the initial partition size must be 6 GB or
more of the hard disk size. Reinstallation cannot be per-
formed with a small partition size.
<When the hard disk backup function has been enabled>
If you select [1] or [2], the message [The Backup function
has been enabled. If [Recovery] is executed, the Backup
function will be disabled, and your Backup data will be
lost.] appears. In this case, press Y .
If the message [Computer must be rebooted in order to
execute [Recovery.]] appears, press R .
When [2] is selected, the hard disk backup func-
tion cannot be enabled because the hard disk has
been divided into partitions.
NOTE
If additional instructions are included with the computer,
be sure to read them. It may be necessary to perform
additional operations during the following procedures.
NOTE
11 After the reinstallation procedure completes, this screen
should appear.
Remove the recovery CD, and then press any key.
The computer will be shut down.
----------------------------------------------------------------
[Recovery] is complete.
Windows(R) XP Professional install wizard will start after reboot.
Please remove the Product Recovery CD-ROM, and turn off the computer.
----------------------------------------------------------------
12 Remove the CD/DVD Drive.
13 Turn on the computer, and press F2 while [Panasonic]
boot screen is displayed.
The Setup Utility will start up.
If the password has been set, enter the Supervisor Pass-
word.
Reinstalling Software
35
Appendix
LIMITED USE LICENSE AGREEMENT
THE SOFTWARE PROGRAM(S) (“PROGRAMS”) FURNISHED WITH THIS PANASONIC® PRODUCT (“PRODUCT”)
ARE LICENSED ONLY TO THE END-USER (“YOU”), AND MAY BE USED BY YOU ONLY IN ACCORDANCE WITH
THE LICENSE TERMS DESCRIBED BELOW. YOUR USE OF THE PROGRAMS SHALL BE CONCLUSIVELY DEEMED
TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE.
Matsushita Electric Industrial Co., Ltd. (“MEI”) has developed or otherwise obtained the Programs and hereby licenses
their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to
achieve your intended results, and for the installation, use and results obtained therefrom.
LICENSE
A. MEI hereby grants you a personal, non-transferable and non-exclusive right and license to use the Programs in
accordance with the terms and conditions stated in this Agreement. You acknowledge that you are receiving only
a LIMITED LICENSE TO USE the Programs and related documentation and that you shall obtain no title, owner-
ship nor any other rights in or to the Programs and related documentation nor in or to the algorithms, concepts,
designs and ideas represented by or incorporated in the Programs and related documentation, all of which title,
ownership and rights shall remain with MEI or its suppliers.
B. You may use the Programs only on the single Product which was accompanied by the Programs.
C. You and your employees and agents are required to protect the confidentiality of the Programs. You may not
distribute or otherwise make the Programs or related documentation available to any third party, by time-sharing
or otherwise, without the prior written consent of MEI.
D. You may not copy or reproduce, or permit to be copied or reproduced, the Programs or related documentation for
any purpose, except that you may make one (1) copy of the Programs for backup purposes only in support of your
use of the Programs on the single Product which was accompanied by the Programs. You shall not modify, or
attempt to modify, the Programs.
E. You may transfer the Programs and license them to another party only in connection with your transfer of the
single Product which was accompanied by the Programs to such other party. At the time of such a transfer, you
must also transfer all copies, whether in printed or machine readable form, of every Program, and the related
documentation, to the same party or destroy any such copies not so transferred.
F. You may not remove any copyright, trademark or other notice or product identification from the Programs and you
must reproduce and include any such notice or product identification on any copy of any Program.
YOU MAY NOT REVERSE ASSEMBLE, REVERSE COMPILE, OR MECHANICALLY OR ELECTRONICALLY TRACE
THE PROGRAMS, OR ANY COPY THEREOF, IN WHOLE OR IN PART.
YOU MAY NOT USE, COPY, MODIFY, ALTER, OR TRANSFER THE PROGRAMS OR ANY COPY THEREOF, IN
WHOLE OR IN PART, EXCEPT AS EXPRESSLY PROVIDED IN THE LICENSE.
IF YOU TRANSFER POSSESSION OF ANY COPY OF ANY PROGRAM TO ANOTHER PARTY, EXCEPT AS PERMIT-
TED IN PARAGRAPH E ABOVE, YOUR LICENSE IS AUTOMATICALLY TERMINATED.
TERM
This license is effective only for so long as you own or lease the Product, unless earlier terminated. You may terminate
this license at any time by destroying, at your expense, the Programs and related documentation together with all copies
thereof in any form. This license will also terminate effective immediately upon occurrence of the conditions therefor set
forth elsewhere in this Agreement, or if you fail to comply with any term or condition contained herein. Upon any such
termination, you agree to destroy, at your expense, the Programs and related documentation together with all copies
thereof in any form.
YOU ACKNOWLEDGE THAT YOU HAVE READ THIS AGREEMENT, UNDERSTAND IT AND AGREE TO BE BOUND
BY ITS TERMS AND CONDITIONS. YOU FURTHER AGREE THAT IT IS THE COMPLETE AND EXCLUSIVE STATE-
MENT OF THE AGREEMENT BETWEEN US, WHICH SUPERSEDES ANY PROPOSAL OR PRIOR AGREEMENT,
ORAL OR WRITTEN, AND ANY OTHER COMMUNICATIONS BETWEEN US, RELATING TO THE SUBJECT MAT-
TER OF THIS AGREEMENT.
About Intel® software products
The enclosed software products and documentation were developed at private expense, and are provided with “RESTRICTED
RIGHTS.” Use, duplication or disclosure by the government is subject to restrictions as set forth in FAR 52.227-14 and DFARS
252.227-7013 et. seq. or its successor. The use of this product by the government constitutes acknowledgment of Intel's propri-
etary rights in the product.
36
Appendix
Contrat de licence d’usage limité
Le(s) logiciel(s) (les “Logiciels”) fournis avec ce produit Panasonic® (le “Produit”) sont exclusivement concédés en li-
cence à l’utilisateur ultime (“vous”), et ils ne peuvent être utilisés que conformément aux clauses contractuelles ci-
dessous. En utilisant les logiciels, vous vous engagez de manière définitive à respecter les termes, clauses et conditions
des présentes.
Matsushita Electric Industrial Co., Ltd. (“MEI”) a mis au point ou obtenu les Logiciels et vous en concède l’utilisation par
les présentes. Vous assumez l’entière responsabilité du choix de ce Produit (y compris des Logiciels associés) pour
obtenir les résultats escomptés, ainsi que de l’installation, de l’utilisation et des résultats obtenus.
Licence
A. MEI vous octroie par les présentes le droit et la licence personnels, non cessibles et non exclusifs d’utiliser les
Logiciels conformément aux termes, clauses et conditions de ce contrat. Vous reconnaissez ne recevoir qu’un
droit limité d’utiliser les Logiciels et la documentation les accompagnant et vous vous engagez à n’obtenir aucun
droit de titre, propriété ni aucun autre droit vis-à-vis des Logiciels et de la documentation les accompagnant ni vis-
à-vis des algorithmes, concepts, dessins, configurations et idées représentés par ou incorporés dans les Logiciels
et la documentation les accompagnant, dont les titres, la propriété et les droits resteront tous à MEI ou à leurs
propriétaires.
B. Vous ne pouvez utiliser les Logiciels que sur le Produit unique qui est accompagné par les Logiciels.
C. Vous et vos employés ou agents êtes requis de protéger la confidentialité des Logiciels. Vous ne pouvez ni
distribuer ni mettre les Logiciels et la documentation les accompagnant à la disposition d’un tiers, par partage de
temps ou de quelque autre manière que ce soit, sans l’autorisation écrite préalable de MEI.
D. Vous ne pouvez ni copier ni reproduire ni permettre la copie ni la reproduction des Logiciels ni de la documenta-
tion les accompagnant pour quelque fin que ce soit, à l’exception d’une (1) copie des Logiciels à des fins de
sauvegarde uniquement pour soutenir votre utilisation des Logiciels sur le Produit unique qui est accompagné par
les Logiciels. Vous ne pouvez ni modifier ni tenter de modifier les Logiciels.
E. Vous ne pouvez céder les Logiciels et en octroyer la licence à une autre partie qu’en rapport avec votre cession
du Produit unique qui est accompagné par les Logiciels à cette autre partie. Au moment de cette cession, vous
devez céder également toutes les copies, que ce soit sous forme imprimée ou lisible par la machine, de tous les
Logiciels ainsi que de la documentation les accompagnant, à la même partie ou détruire les copies non cédées.
F. Vous ne pouvez retirer aucune marque de droits d’auteur, marque de commerce ou autre ni aucune identification
de produit des Logiciels et vous devez reproduire et inclure toutes ces notices ou identifications de produit sur
toutes les copies des Logiciels.
Vous ne pouvez assembler en sens inverse, compiler en sens inverse ni retracer les Logiciels ni aucune de leurs copies,
de façon électronique ou mécanique, en tout ou en partie.
Vous ne pouvez utiliser, copier, modifier, altérer ni céder les Logiciels ni aucune de leurs copies, en tout ou en partie, à
l’exception de ce qui est expressément stipulé dans ce contrat.
Si vous cédez la possession de toute copie ou de tout Logiciel à une autre partie, à l’exception de ce qui est autorisé au
paragraphe E ci-dessus, votre licence est automatiquement résiliée.
Termes, clauses et conditions
Cette licence n’est effective que pour la durée de possession ou de crédit-bail du Produit, à moins d’une résiliation
antérieure. Vous pouvez résilier cette licence à tout moment en détruisant, à vos frais, les Logiciels et la documentation
les accompagnant avec toutes leurs copies, sous quelque forme que ce soit. Cette licence sera également résiliée, avec
application immédiate, si les conditions de résiliation définies ailleurs dans ce contrat se sont réalisées ou si vous ne
respectez pas les termes, clauses et conditions qui y sont contenues. Au moment de la résiliation, vous acceptez de
détruire, à vos frais, les Logiciels et la documentation les accompagnant avec toutes leurs copies, sous quelque forme
que ce soit.
Vous reconnaissez avoir lu ce contrat, en avoir compris toute la substance et avoir accepté de respecter ses termes,
clauses et conditions. Vous reconnaissez en outre qu’ils sont la description complète et exclusive du contrat conclu entre
nous, contrat qui remplace et annule toute proposition ou contrat précédent, écrit ou oral, et toute autre communication
entre nous, relativement à l’objet du présent contrat.
37
Appendix
Hard Disk Backup Function
The hard disk backup function creates a backup area (storage area) on the hard disk. This area is to back up (store) hard disk
contents or restore backed up contents to their original locations.
By backing up the data on your hard disk to a backup area, you can protect your data from loss or damage resulting from operational
errors or other factors. Also, you can back up or restore hard disk contents using this computer alone, without having to use other
media or peripheral devices.
At the time of purchase, the hard disk backup function is disabled. If you follow the procedure below to create a backup area, the
hard disk backup function will be enabled, and you will be able to back up your data. Note, that once the backup function has been
enabled, you will have to perform the reinstallation procedure to disable it again ( page 33).
Disconnect or remove all peripheral devices (except for the CD/DVD drive), as the backup area
may not be created properly while these devices are connected.
Be sure the AC adaptor is connected to the computer.
A backup area cannot be created if the hard disk is already divided into several partitions. Return
the computer to its condition at the time of purchase (one partition only), and create the backup
area.
To divide the partition, make the selection when the backup area is created ( page 38 step 8).
If the partition configuration is changed (partitions created, size changed, etc.) after the backup
area has been created, it will no longer be possible to execute the backup function. To change the
configuration, it is necessary to return the computer to its condition at the time of purchase, and
then create the backup area again.
The hard disk backup function will only work for the internal hard disk. This function does not
work with an external hard disk or the second hard disk (optional).
Backup and restore functions will not operate if the hard disk has been damaged.
Do not use the NTFS file system compression function, as this may result in insufficient capacity
of the backup area.
If the hard disk malfunctions, it will be impossible to read the data stored on it. We recommend
that you also back up important data to a location other than the hard disk (an external hard disk
or other media).
Execute a disk error check using the following procedure.
1Select [Local Disk(C:)] with the right button in [start] - [My Computer], and select [Properties].
2Select [Check Now] from [Tools].
3In [Check Disk], select [Start] without adding a check mark beside any of the items.
If a message is displayed indicating that there is an error in the disk, display [Check Disk], and
add a check mark for [Automatically fix file system errors] and [Scan for and attempt recovery
of bad sectors], select [Start], and check for disk errors again.
The hard disk backup function does not accommodate dynamic disks. Do not convert the hard
disk to a dynamic disk.
The hard disk backup function cannot back up or restore data properly if there is a problem with the hard disk when the data is
backed up or restored. Note that if an error occurs while data is being restored, whether as a result of an unexpected malfunction,
incorrect operation, or other reason, the data in the hard disk (data before restoration) may be lost.
Matsushita Electric Industrial Co., Ltd. will bear no responsibility for any damages suffered by the user (including loss of data)
as a result of the use of this function.
Before Using a Hard Disk Backup Function
Preparing
Product Recovery CD-ROM (included)
Panasonic CD/DVD drive (optional: Confirm the latest information on optional products in cata-
logs, etc.)
38
Appendix
1Turn off the computer and insert the CD/DVD drive into the multimedia pocket. (
“Multimedia Pocket”)
2Turn on the computer, and press F2 while [Panasonic] boot screen is displayed.
The Setup Utility will then start.
If a password has been set, enter the Supervisor Password. You cannot register [Boot] menu
with a User Password.
3Select [Boot] menu, then select [CD/DVD Drive] and press F6 until [CD/DVD Drive] is at
the top of the [Boot] menu.
4Place the disk number one of the recovery CDs into the CD/DVD drive.
5Press F10 .
At the confirmation message, select [Yes] and press Enter .
The computer will restart. If [Enter Password] is displayed during the following procedures,
input the Supervisor Password or the User Password.
This screen should appear.
6Press 3 to execute [3.Backup].
Regarding backup area
• Requires availability of at least half of the entire hard disk. Without sufficient space
available, the backup area cannot be created.
• When the backup area is created, the usable hard disk capacity will be reduced to less
than half.
• The backup area cannot be accessed from Windows. For this reason, backed up data
cannot be copied to CD-R or other removable disk media.
• When the hard disk backup function is executed, data in the backup area will be over-
written. If newly created or edited data is backed up later, data stored previously
in the backup area will be lost.
NOTE
Create a Backup Area
When dividing the hard disk into partitions
Do not execute [1. Recovery] to divide the hard disk into partitions. The hard disk backup
function cannot be enabled after the hard disk has been partitioned. Use procedure 8 to
divide the hard disk.
CAUTION
The usable hard disk area
[At the time of purchase] [After the backup area is created]
The backup area
Cannot be accessed
from Windows.
Can be accessed from
Windows (One partition).
7At the confirmation message, press Y .
8Select how to divide the hard disk from the menu.
<To create a backup area and enable the backup function without dividing the hard disk>
Select [1].
---------------------------------------------------------------------
Select a number
---------------------------------------------------------------------
1. [ Recovery ] Reinstall Windows.
2. [ Erase HDD ] Erase the whole data on HDD for security.
3. [ Backup ] Enable the Backup function.
0. [ Cancel ] Cancel.
---------------------------------------------------------------------
Hard Disk Backup Function
39
Appendix
9When the confirmation message is displayed, press Y .
The backup area is then created.
10 When the message [You must reboot in order to enable the Backup function] appears, remove
the recovery CD, and press any key to restart the computer. The computer is restarted, then the
backup process will begin.
11 When the message [[Backup] is complete] appears, press Ctrl + Alt + Del to restart the
computer.
Do not press Ctrl + Alt + Del until the message is displayed.
CAUTION
The [Boot] menu in the Setup Utility is set to start up from the CD/DVD drive. Change this
setting if necessary.
The next time the backup or restore functions are executed, follow the procedure for [Backing
Up and Restoring Data] ( below).
NOTE
1Turn the computer on, and press F2 while [Panasonic] boot screen is displayed.
The Setup Utility will start up.
If a password has been set, enter the Supervisor Password or the User Password.
2Select [Exit] menu, then select [Hard Disk Backup / Restore] and press Enter .
At the confirmation message, select [Yes] and press Enter .
Backing Up and Restoring Data
Before executing the backup function, execute a disk error check ( page 37).
Do not interrupt the backup or restore functions before completion, for example by turning
off the power or pressing Ctrl + Alt + Del , as this may prevent Windows from
starting up, or may cause data to be lost so that the backup and restore functions cannot be
executed.
CAUTION
12 After logging on to Windows, a message will appear advising that a new device has been in-
stalled and that the computer must be restarted to enable the settings. Select [Yes] to restart the
computer.
<To create a backup area and divide hard disk into two partitions, for OS and data>
Select [2], enter the partition size (GB), and press Enter .
• You can cancel this operation by pressing 0 .
• The data partition size will be the maximum settable size less the number entered above.
The maximum settable size will differ depending on models.
The usable hard disk area
[At the time of purchase] [After the backup area is created]
The backup area
Cannot be accessed
from Windows.
Can be accessed from
Windows (Two partitions).
40
Appendix
To disable the hard disk backup function
Perform the reinstallation procedure. All data in the backup area and the hard disk will be
erased.
Conduct steps 1-8 for [Reinstalling Software] ( page 33). Select [1] or [2] to execute the
reinstallation at the screen for executing the reinstallation.
• When [1] is selected, the hard disk backup function can be disabled.
• When [2] is selected, the hard disk backup function can be disabled, but in this case, because
the hard disk has been divided into partitions, the hard disk backup function cannot be
re-enabled ( page 24).
• When [3] is selected, the hard disk backup function cannot be disabled.
CAUTION
When the hard disk backup function has been enabled, the backed up data will not be erased
even if a commercial data erasing utility or similar software is used to erase all data from
user-accessible area. You can use the hard disk data erase utility included in this computer
( page 41) to erase all data on the hard disk, including backed up data. Use this hard disk
data erase utility before disposing of or transferring ownership of this computer.
Occasionally, the message [#1805 cannot write image file] will be displayed, and the backup
function will be interrupted. If this error occurs, execute the backup function again. After
this, if the backup function is completed properly, then there is no problem in the hard disk.
4When the message [[Backup] is complete] or [[Restore] is complete] is displayed, press
Ctrl
+ Alt + Del to restart the computer.
• If the backup or restore process was interrupted before completion, for example if the power
was turned off, execute the process again.
• After logging on to Windows, when a new device is installed and a message appears advising
that the computer must be restarted to enable the settings, select [Yes] to restart the computer.
3Select the operation to be executed from the menu.
<To back up hard disk contents to the backup area>
1 Press 1 to execute [1. [Backup]].
(When dividing the hard disk into two partitions, select the backup method at next screen.)
2At the confirmation message, press Y .
The backup process will begin.
<To restore backed up contents to the hard disk>
1 Press 2 to execute [2. [Restore]].
(When data is backed up in two partitions, select the restore method at next screen.)
2At the confirmation message, press Y .
The restore process will begin.
The time required to complete the backup or restore process differs depending on the
data volume.
NOTE
Hard Disk Backup Function
41
Appendix
Hard Disk Data Erase Utility
This computer is equipped with a utility for erasing hard disk data.
When disposing of or transferring ownership of this device, erase all data on the hard disk in order to prevent the theft of hard disk
data by following the steps below.
The hard disk data erase utility erases data using an “overwriting” method, but there is a possibility that due to malfunctions or
other operational errors, data may not be completely erased. There are also specialized devices that may be able to read data that
has been erased using this method. If you need to erase highly confidential data, we recommend that you contact a company that
specializes in this process. Matsushita Electric Industrial Co., Ltd. will bear no responsibility for losses or damages suffered as
a result of the use of this utility.
Product Recovery CD-ROM (included)
Panasonic CD/DVD drive (optional: Confirm the latest information on optional products in catalogs, etc.)
1Turn off the computer.
2Insert the CD/DVD drive into the multimedia pocket.
( “Multimedia Pocket”)
3Turn on the computer, and press F2 while [Panasonic]
boot screen is displayed.
The Setup Utility will start up.
If the password has been set, enter the Supervisor
Password.
4Select [Boot] menu, then select [CD/DVD Drive] and press
F6 until [CD/DVD Drive] is at the top of [Boot] menu.
5Place the disc number one of the recovery CDs into the
CD/DVD drive.
6Press F10 .
At the confirmation message, select [Yes] and press
Enter .
The computer will restart, and this screen should appear.
NOTE
Be sure the AC adaptor is connected until the procedure is completed.
This utility can only be used for internal hard disk. It cannot be used to erase data from external hard disks or the second hard
disk (optional).
This utility cannot erase data from damaged disk.
This utility cannot erase data for specific partitions.
After executing this utility, the computer cannot be booted from the hard disk.
The backup area and the data in the backup area will be erased.
7Press 2 to execute [2. [Erase HDD]].
(You can cancel this operation by pressing 0 .)
<When the hard disk backup function has been enabled>
When the message [The Backup function has been en-
abled. If [Erase HDD] is executed, the Backup function
will be disabled, and your Backup data will be lost.] ap-
pears, press Y .
When the message [Computer must be rebooted in order
to execute [Erase HDD.]] appears, press R .
8At the confirmation message, press Y .
9When [<<<Start Menu>>>] is displayed, press Enter .
10 The approximate time required for erasing data will be
displayed.
Press Space .
11 At the confirmation message, press Enter . The
operation of erasing the hard disk will start.
(If necessary, the “hard disk data erase” operation can
be cancelled after it has begun by pressing
Ctrl + C . If the operation is cancelled before
being completed, a part of data will not be erased.)
12 After the operation is complete:
Under normal conditions, the message [Hard disk data has
been deleted.] will be displayed.
If a problem occurred during the operation, an error mes-
sage will be displayed.
13 Remove the recovery CD, and then press any key to turn
off the computer.
Preparing
Procedure
<When the hard disk backup function has been enabled>
When the message [The Backup function has been en-
abled. If [Recovery] or [Erase HDD] is executed, the
Backup function will be disabled, and your Backup data
will be lost.] appears, press Y .
---------------------------------------------------------------------
Select a number
---------------------------------------------------------------------
1. [ Recovery ] Reinstall Windows.
2. [ Erase HDD ] Erase the whole data on HDD for security.
3. [ Backup ] Enable the Backup function.
0. [ Cancel ] Cancel.
---------------------------------------------------------------------
42
Appendix
Specifications
Model No.
CPU
Memory
Video Memory
LCD Type
Displayed Colors*3
External Display
Hard Disk Drive
Keyboard
Floppy Disk Drive
Slot PC Card Slot
Allowable current
(total for two slots)
RAM Module Slot*6
Interface Parallel Port
External Display Port
Serial Port
Microphone Jack*7
Headphone Jack
Expansion Bus Connector
USB Port
Modem
LAN
External Antenna Connector
Pointing Device
Sound
*11 MB = 1,024 bytes
*2A segment of the main memory is allotted automatically depending on the computer’s operating status. The size of the Video Memory
cannot be set by the user.
*3A 16,777,216 color display is achieved by using the dithering function.
*4Maximum resolution depends on the specifications of the external display.
*51GB = 1,000,000,000 bytes. Your operating system or some application software will report as fewer GB.
*6Only a RAM card designed for PC2700 can be added.
*7Use only a monaural condenser microphone.
*8The settings for the K56flex modem need to be changed according to the AT command.
Main Specifications
CF-29HTLGZBM CF-29HTQGZBM CF-29H3LGZBM
CF-29JTLGZBM CF-29JTQGZBM CF-29J3LGZBM
Intel® Pentium® M Processor 738 (1.40 GHz, 2 MB*1 L2 cache, 400 MHz FSB)
256 MB*
1
(1280 MB*
1
Max.) 512 MB*
1
(1536 MB*
1
Max.) 256 MB*
1
(1280 MB*
1
Max.)
UMA (64 MB*1 Max.)*2
13.3 XGA type (TFT) with Touchscreen 13.3 XGA type (TFT)
65,536/16,777,216 colors (800 x 600 dots/1024 x 768 dots/1280 x 1024 dots/
1600 x 1200 dots)*4
60 GB*580 GB*560 GB*5
87 keys
720 KB/1.44 MB (two-mode)
Two Type I or Type II, or one Type III
3.3 V: 400 mA
5 V: 400 mA
200 pin, 2.5 V, SO-DIMM, DDR SDRAM, PC2700 Compliant
Dsub 25-pin female
Mini Dsub 15-pin female
Dsub 9-pin male
Miniature jack, 3.5 DIA
Miniature jack, 3.5 DIA, Impedance 32 Ω, Output Power 4 mW x 2
Dedicated 80-pin female
4-pin x 2, USB 2.0
RJ-11 jack, Data: 56 kbps (V.92 & K56flex*8) FAX:14.4 kbps
RJ-45 jack, IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
Dedicated 50 Ω coaxial connector
Touch Pad Touch Pad
T
ouchscreen (Anti-Reflection, Stylus (included) touch capable)
WAVE and MIDI playback, Monaural Speaker (built in)
65,536/16,777,216 colors (800 x 600 dots/1024 x 768
dots) 65,536/16,777,216 colors
(800 x 600 dots/1024 x
768 dots)
43
Appendix
Model No.
Battery Pack
Operating Time*9
Charging Time*9Power On
Power Off
Clock Battery
AC Adaptor*12 Input
Output
Power Consumption*13
Environment
Operation
Temperature
Humidity
Storage Temperature
Humidity
Physical Dimensions (W x H x D)
Weight (including the carrying handle)
Software
Operating System
Utility Programs
CF-29HTLGZBM CF-29HTQGZBM CF-29H3LGZBM
CF-29JTLGZBM CF-29JTQGZBM CF-29J3LGZBM
Li-ion 11.1 V, 6.6 Ah
Main battery: Approx. 5 hours - 8 hours*10 (Approx. 7 hours*11)
Main battery + Second battery: Approx. 8 hours - 13.5 hours*
10
(Approx. 10.5 hours*
11
)
Main battery: Approx. 7 hours
Main battery + Second battery: Approx. 11 hours
Main battery: Approx. 4 hours
Main battery + Second battery: Approx. 7 hours
Coin type lithium battery 3.0 V
100 V - 240 V AC, 50 Hz/60 Hz
15.6 V DC, 5.0 A
Approx. 35 W*14 / Approx. 60 W (maximum when recharging in the ON state)
5 °C to 35°C {41 °F to 95 °F}
30% to 80% RH (No condensation)
-20 °C to 60 °C {-4 °F to 140 °F}
30% to 90% RH (No condensation)
302 mm x 64.3 mm x 273 mm (excluding protrusion) {11.9 " x 2.6 " x 10.7 "}
Approx. 3.62 kg {Approx. 7.98 lb.} Approx. 3.49 kg
{Approx. 7.7 lb.}
Main Specifications
*9Varies depending on the usage conditions, CPU speed, etc.
*10 Measured using BatteryMark™ Version 4.0.1 (LCD brightness: Maximum - Minimum)
*11 Measured using MobileMark™ 2002 (LCD brightness: 60 cd/m2)
*12 <Only for North America>
The AC adaptor is compatible with power sources up to 240 V AC adaptor. The computer is supplied with a 125 V AC compatible AC cord.
*13 Approx. 0.9 W when the battery pack is fully charged (or not being charged) and the computer is off.
Approx. 1.5 W when the Wake up from LAN function has been enabled.
*14 Rated power consumption
Microsoft® Windows® XP Professional Service Pack 2 with Advanced Security
Technologies (NTFS File System)
Setup Utility Hard Disk Backup Utility*16
DMI Viewer Hard Disk Data Erase Utility*16
Adobe Reader Icon Enlarger
Intel® PROSet/Wireless Software*15 Loupe Utility
Panasonic Hand Writing Hotkey Settings
PC Information Viewer
*15 Only for models with wireless LAN
*16 The Product Recovery CD-ROM is required.
Wireless LAN
Model No.
Data transfer rates
Standards supported
Transmission method
Wireless channels used
RF frequency band
CF-29HTLGZBM/CF-29HTQGZBM/ CF-29JTLGZBM/CF-29JTQGZBM/
CF-29H3LGZBM CF-29J3LGZBM
IEEE802.11a: 54/48/36/24/18/12/9/6 Mbps —
(automatically switched)
IEEE802.11b: 11/5.5/2/1 Mbps —
(automatically switched)
IEEE802.11g: 54/48/36/24/18/12/9/6 Mbps —
(automatically switched)
IEEE802.11a/IEEE802.11b/IEEE802.11g —
OFDM system, DSSS system —
IEEE802.11a: Channels 36 to 64, 149 to 165 —
IEEE802.11b/IEEE802.11g: Channels 1 to 11 —
IEEE802.11a: 5.18~5.32 GHz, 5.725~5.825 GHz
—
IEEE802.11b/IEEE802.11g: 2412~2462 MHz —
44
Appendix
LIMITED WARRANTY
PANASONIC PERSONAL COMPUTER AND PERIPHERALS LIMITED WARRANTY
Panasonic Computer Solutions Company (referred to as “Panasonic”) will repair this product (other than software, which is covered by a separate
warranty) with new or rebuilt parts, free of charge in the U.S.A. for three (3) years from the date of original purchase in the event of a defect in
materials or workmanship. This warranty includes the AC adaptor but excludes the batteries and all other options and accessories which are
covered for a period of one (1) year from the date of purchase.
This warranty is extended solely to the original purchaser. A purchase receipt or other proof of date of original purchase will be required before
warranty performance is rendered.
This warranty only covers failures due to defects in materials or workmanship which occur during normal use. It does not cover damage which
occurs in shipment or failures which are caused by products not supplied by Panasonic, or failures which result from alteration, accident, misuse,
introduction of liquid or other foreign matter into the unit, abuse, neglect, installation, maladjustment of consumer controls, improper maintenance,
modification or service by anyone other than a Factory Service Center or authorized Panasonic Service Dealer, or damage that is attributable to acts
of God.
Limits and Exclusions:
There are no other express warranties except as listed below.
PANASONIC SHALL NOT BE LIABLE FOR LOSS OF DATA OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING
THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE APPLICABLE WARRANTY
PERIOD SET FORTH ABOVE. Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how
long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state. If a problem with your product
develops during or after the warranty period, you may contact our representatives at 1-800-LAPTOP5. If the problem is not handled to your
satisfaction, then write to the Consumer Affairs Division at the address indicated below.
SOFTWARE LIMITED WARRANTY
Panasonic Computer Solutions Company (referred to as “Panasonic”) warrants to you only that the disk(s) or other media on which the Programs are
furnished will be free from defects in materials and workmanship under normal use for a period of sixty (60) days from the date of delivery thereof
to you, as evidenced by your purchase receipt.
This is the only warranty Panasonic makes to you. Panasonic does not warrant that the functions contained in the Programs will meet your
requirements or that the operation of the Programs will be uninterrupted or error free.
Panasonic’s entire liability, and your exclusive remedy under this warranty shall be limited to the replacement, in the United States, of any defective
disk or other media which is returned to Panasonic’s Authorized Service Center, together with a copy of the purchase receipt, within the aforesaid
warranty period.
Anything in the foregoing to the contrary notwithstanding, Panasonic shall have no obligation for any defects in the disk(s) or other media on which
the Programs are furnished resulting from your storage thereof, or for defects that have been caused by operation of the disk(s) or other media
otherwise than on the Product or in environmental conditions other than those specified by Panasonic by alteration, accident, misuse, abuse,
neglect, mishandling, misapplication, installation, maladjustment of consumer controls, improper maintenance, modification of damage that is
attributable to acts of God. In addition, Panasonic shall have no obligation for any defects in the disk(s) or other media if you have modified, or
attempted to modify any Program.
DURATION OF IMPLIED WARRANTIES, IF ANY, IS LIMITED TO SIXTY (60) DAYS.
PANASONIC ASSUMES NO RISK OF AND SHALL NOT IN ANY CASE BE LIABLE FOR ANY DAMAGES, INCLUDING, WITHOUT LIMITATION,
ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR PUNITIVE DAMAGES ARISING FROM BREACH OF WARRANTY OR CONTRACT, NEG-
LIGENCE OR ANY OTHER LEGAL THEORY, INCLUDING, WITHOUT LIMITATION LOSS OF GOODWILL, PROFITS OR REVENUE, LOSS OF
USE OF THE PROGRAMS OR PRODUCTS OR ANY ASSOCIATED EQUIPMENT, COST OF CAPITAL, COST OF ANY SUBSTITUTE EQUIP-
MENT, FACILITIES, SERVICES, DOWNTIME COSTS, OR CLAIMS OF ANY PARTY DEALING WITH YOU FOR SUCH DAMAGES.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so
the above limitations or exclusions may not apply to you.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
This Limited Warranty will be governed by the laws the State of New York, without regard to its conflict-of-laws rules.
* * *
To obtain service or technical assistance within the continental U.S.A. and Alaska.
DIAL TOLL FREE: 1-800-LAPTOP5
Correspondence requesting product information should be sent
to: Panasonic Computer Solutions Company,
50 Meadowlands Parkway, Panazip 2F-5, Secaucus, NJ 07094
For U.S.A.
45
Appendix
PANASONIC COMPUTER AND PERIPHERALS LIMITED WARRANTY
Coverage – Panasonic Canada Inc. (“PCI”) warrants to you, the first end user customer, this computer product (excluding software media), when
purchased from PCI or from a PCI authorized reseller, to be free from defects in materials and workmanship under normal use, subject to the terms
set forth below, during the period of warranty coverage specified.
Remedy – In the event of a warranty claim, contact PCI’s representatives within the applicable warranty period, identifying the nature of the defect
claimed, at 1-800-668-8386 between 9:00 A.M. and 5:00 P.M., Eastern Time Zone, Mon. – Fri. (excluding holidays) for instructions on how to obtain
service. A purchase receipt or other proof of date of original purchase is required before warranty service is performed. Defective parts covered by
this Limited Warranty will be repaired or replaced with new or comparable rebuilt parts on an exchange basis. Warranty replacement or repair is
subject to the terms of this Limited Warranty for the balance of the original period of warranty coverage.
No Coverage – This Limited Warranty does not cover products purchased outside Canada. Neither does it cover damage to, failure of, or defects
in a product or accessory through mishandling, improper installation, abnormal use, misuse, neglect, accident, introduction of liquid or other foreign
matter into the product, alteration or servicing by anyone not authorized by PCI, or act of God.
IF YOU SHIP THE PRODUCT FOR WARRANTY SERVICE
Carefully pack the product, preferably in the original carton. Include details of defect claimed and proof of date of original purchase. No liability
is assumed for loss or damage to the product while in transit, if you chose your own transportation carrier.
SOFTWARE MEDIA LIMITED WARRANTY
Coverage – Panasonic Canada Inc. (“PCI”) warrants to you, the first end user customer, that the disk(s) or other media on which software program(s)
is/are supplied will be free from defects in materials and workmanship under normal use in Canada for a period of sixty (60) days from date of receipt
as evidenced by your purchase receipt for your Panasonic Computer product.
THIS IS THE ONLY WARRANTY THAT PCI MAKES RESPECTING THE SOFTWARE MEDIA. PCI does not warrant the software. Please refer to
the software licensor’s written warranty (accompanying the copy of the software) for any software warranty claim.
Claim Procedure – In the event of a defect in material or workmanship in the media during the sixty (60) day warranty period, and you return it,
transportation costs prepaid, to Panasonic Canada Inc., Computer Products Marketing, at the above address, within the warranty period, together
with a copy of your purchase receipt, and an explanation of the suspected defect, PCI will replace in Canada the defective disk(s) or other media.
Remedy – PCI’s entire liability, and your only remedy for any breach of this software media warranty is limited to replacement of the media only. It
does not cover any other damages, including, but not limited to, loss of use or profit loss, or special, indirect or consequential damages, or other
claims, whether or not of similar character.
No Coverage – This limited warranty does not apply if the disk(s) or other media has been used in other than a Panasonic product, or in environmen-
tal conditions other than those specified by PCI or the manufacturer, or if subjected to misuse, neglect, mishandling, modification or attempted
modification of the program, or if damaged by accident or act of God. PCI is not responsible for damage to or loss of any program, data or
removable storage media.
GENERAL
NO OTHER WARRANTIES – PCI DISCLAIMS ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH RESPECT TO THE SOFTWARE,
SOFTWARE MEDIA, COMPUTER PRODUCT, OPTIONS AND ACCESSORIES.
NO LIABILITY FOR CONSEQUENTIAL DAMAGES – IN NO EVENT SHALL PCI BE LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUEN-
TIAL DAMAGES ARISING FROM ANY BREACH OF THE LIMITED WARRANTIES SET OUT IN THIS DOCUMENT, OR FROM THE USE OF THE
COMPUTER PRODUCT, INCLUDING, WITHOUT LIMITATION, LOSS OF DATA, BUSINESS, PROFIT OR GOODWILL.
IN ANY EVENT, PCI’S MAXIMUM LIABILITY FOR ANY BREACH SHALL NOT EXCEED THE AMOUNT ACTUALLY PAID BY YOU FOR THE
COMPUTER PRODUCT.
NO ACTION, REGARDLESS OF ITS BASIS, MAY BE BEGUN AGAINST PCI MORE THAN TWO (2) YEARS AFTER THE CAUSE OF ACTION
AROSE.
Statutory Warranties – Some jurisdictions do not allow these limitations or exclusions, so they may not apply to you.
Scope of Coverage
Whole Product (except Batteries), AC adaptor and CD-ROM
(if factory installed)
Batteries, CD-ROM (unless factory installed), Port Replicator,
Extra Memory Modules and all other Peripherals, Options and
Accessories
Period of Coverage
Three (3) Years from Date of Original
End User Customer Purchase
One (1) Year from Date of Original End
User Customer Purchase
Type of Failure Coverage
Defective Materials or Workmanship
Defective Materials or Workmanship
For Canada
46
Appendix
Memo
47
Appendix
Outline of the International ENERGY STAR® Office Equipment Program
The international ENERGY STAR® Office Equipment Program is an international program
that promotes energy saving through the use of computers and other office equipment.
The program backs the development and dissemination of products with functions that
effectively reduce energy consumption. It is an open system in which business proprietors
can participate voluntarily. The targeted products are office equipment such as computers,
displays, printers, facsimiles, and copiers. Their standards and logos are uniform among
participating nations.
As an ENERGY STAR® Partner, Matsushita Electric Industrial Co., Ltd. has
determined that this product meets the ENERGY STAR® guidelines for energy
efficiency.
Panasonic Computer Solutions Company,
50 Meadowlands Parkway, Panazip 2F-5,
Secaucus, NJ 07094
Panasonic Canada Inc.
5770 Ambler Drive Mississauga,
Ontario L4W 2T3
© 2004 Matsushita Electric Industrial Co., LTD. All Rights Reserved.
Printed in Japan
FJ1204-0
DFQX5492ZA
