Users Manual

Contents

Getting Started

OPERATING INSTRUCTIONS

Personal Computer

Model No. CF-30 series

Introduction ................................................................. 2

Read Me First ............................................................. 3

Description of Parts ..................................................10

First-time Operation ..................................................13

Useful Information

On-screen Manual ....................................................15

Handling and Maintenance .......................................16

Hard Disk Backup Function (Recover Pro) ..............18

Hard Disk Data Erase Utility .....................................20

Reinstalling Software ................................................21

Troubleshooting

Error Code/Message ................................................23

Troubleshooting (Basic) ............................................24

Appendix

LIMITED USE LICENSE AGREEMENT ...................28

Contrat de licence d’usage limité .............................29

Speciﬁ cations ...........................................................30

LIMITED WARRANTY ..............................................32

Please read these instructions carefully before using this product and save this manual for future use.

For more information about the com-

puter, you can refer to the on-screen

manual.

To access the on-screen manual

 page 15 “On-screen Manual”

Getting StartedUseful InformationTroubleshootingAppendix

Getting Started

Introduction

Thank you for purchasing this Panasonic computer. For optimum performance and safety, please read these instruc-

tions carefully.

 Terms and illustrations in these instructions

CAUTION : Conditions that may result in minor or moderate injury.

NOTE : Useful and helpful information.

Enter

: Press [Enter] key.

: Press and hold [Fn] key, and then press [F5] key.

[start] - [Run] : Click [start], and then click [Run]. You may need to double-click in some cases.

 : Page in these Operating Instructions or in the Reference Manual.

: Reference to the on-screen manuals.

 Some illustrations are simpliﬁ ed to help your understanding and may look different from the actual unit.

 If you do not log on as an administrator, you cannot use some functions or cannot display some screens.

 Refer for the latest information about optional products to the catalogs, etc.

 In these instructions, the names and terms are referred as follows.

 “Microsoft® Windows® XP Professional Service Pack 2 with Advanced Security Technologies” as “Windows” or

“Windows XP”

 DVD-ROM & CD-R/RW drive, and DVD MULTI drive as “CD/DVD drive”

 Circular media including DVD-ROM and CD-ROM as “discs”

 The display modes are referred as follows. ( ) indicates the terms in [Intel® 82852/82855 GM/GME Graphics Con-

troller Properties] screen. To display the screen, select [start] - [Control Panel] - [Other Control Panel Options] -

[Intel(R) Extreme Graphics 2 M].

 Internal LCD (Notebook): The computer’s display

 External display (Monitor): External display

 Simultaneous display (Intel® Dual Display Clone): The same screen is displayed on the internal LCD and the ex-

ternal display.

 Extended desktop: The extended working area across the internal LCD and the external display.

 Copyright

may be reproduced in any form without the prior written permission of Matsushita Electric Industrial Co., Ltd.

No patent liability is assumed with respect to the use of the information contained herein.

 Disclaimer

Computer speciﬁ cations and manuals are subject to change without notice. Matsushita Electric Industrial Co., Ltd. as-

sumes no liability for damage incurred directly or indirectly from errors, omissions or discrepancies between the com-

puter and the manuals.

 Trademarks

Microsoft®, Windows®, the Windows logo and IntelliMouse are registered trademarks of Microsoft Corporation of the

United States and/or other countries.

Intel, Core, Viiv, Centrino and PROSet are either registered trademarks or trademarks of Intel Corporation.

SD Logo is a trademark.

Adobe, the Adobe logo and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorpo-

rated in the United States and/or other countries.

Bluetooth is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Matsushita Electric Industrial Co., Ltd.

WinDVD™ is a trademark of InterVideo, Inc.

Panasonic® is a registered trademark of Matsushita Electric Industrial Co., Ltd.

Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective

own companies.

Getting Started

Read Me First

Models for U.S.A.

Federal Communications Commission Radio Fre-

quency Interference Statement

Note: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential instal-

lation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interfer-

ence will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one

or more of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and

receiver.

 Connect the equipment into an outlet on a circuit dif-

ferent from that to which the receiver is connected.

 Consult the Panasonic Service Center or an experi-

enced radio/TV technician for help.

Warning

To assure continued compliance, use only shielded inter-

face cables when connecting to a computer or peripheral.

Also, any changes or modiﬁcations not expressly ap-

proved by the party responsible for compliance could void

the user’s authority to operate this equipment.

FCC RF Exposure Warning:



This equipment is provided with PC Card slot that could

be used with wireless transmitters, which will be speciﬁ-

cally recommended when they become available.

Other third-party wireless transmitters have not been

RF exposure evaluated for use with this computer and

may not comply with FCC RF exposure requirements.

 This equipment complies with FCC radiation exposure

limits set forth for an uncontrolled environment.

 This equipment may not be co-located or operated

with any other antenna or transmitter.



This equipment has been approved for mobile operation,

and unless otherwise advised in separate supplemental

instructions for individual wireless transmitter(s), requires

minimum 20 cm spacing be provided between antenna(s)

and all person’s body (excluding extremities of hands,

wrist and feet) during wireless modes of operation.



This equipment may use multiple installed transmitters,

which may be capable of simultaneous transmission.



This equipment is provided with external antenna

connector(s) for connection to optional Car Mounter or

Port Replicator for mobile external mounted antenna(s).

External antenna(s) must be professionally installed and

cannot exceed recommended maximum antenna gain as

described in individual provided supplement instructions

for wireless transmitters. Also, user must maintain mini-

mum 20 cm spacing between external antenna(s) and all

person’s body (excluding extremities of hands, wrist and

feet) during wireless modes of operation.

 WLAN external antenna connector is intended for con-

nection to Radiall/Larsen WLAN Base Whip antenna,

type NM05E2400BKTNC with 5 dBi antenna.

 WWAN external antenna connector is intended for

professional installation and should not exceed maxi-

mum antenna gain of 9.85 dBi for 824.7 - 848.31 MHz

operation and 8.34 dBi for 1851.25 - 1908.75 MHz

operation.

25-M-3-1

This device complies with Part 15 of the FCC Rules. Op-

eration is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received,

including interference that may cause undesired op-

eration.

Responsible Party: Panasonic Corporation of North America

One Panasonic Way

Secaucus, NJ 07094

Tel No:1-800-LAPTOP5 (1-800-527-8675)

6-M-1

FCC Regulation Notice for modem

This equipment contains a FCC approved modem.

1. This equipment complies with CFR47 Part 68 rules.

On the computer is a label that contains, among other

information, the FCC registration number and ringer

equivalence number (REN) for this equipment. If re-

quired, this information must be provided to the tele-

phone company.

2. An FCC compliant telephone cord and modular plug

is provided with this equipment. This equipment is

designed to be connected to the telephone network

or premises wiring using a compatible modular jack

which is Part 68 compliant. See Installation Instruc-

tions for details.

3. The REN is used to determine the quantity of devices

which may be connected to the telephone line. Ex-

cessive RENs on the telephone line may result in the

devices not ringing in response to an incoming call. In

most, but not all area, the sum of RENs should not ex-

ceed ﬁve (5.0). To be certain of the number of devices

that may be connected to a line, as determined by the

total RENs, contact the local telephone company.

4. If your telephone equipment cause harm to the tele-

phone network, the telephone company will notify you

in advice that temporary discontinuance of service

may be required. But if advice notice isn’t practical, the

telephone company will notify the customer as soon

as possible. Also, you will be advised of your right to

ﬁle a complaint with the FCC if you believe it is neces-

sary.

5. The telephone company may take changes in its facili-

ties, equipment, operations or procedures that could

affect the operation of the equipment. If this happens

the telephone company will provide advance notice

in order for you to make necessary modiﬁcations to

maintain uninterrupted service.

6. If trouble is experienced with this equipment, for repair

or warranty information, please contact Panasonic

Corporation of North America at DIAL TOLL FREE

1-800-LAPTOP5 (1-800-527-8675). If the equipment is

causing harm to the telephone network, the telephone

company may request that you disconnect the equip-

ment until the problem is resolved.

7. There are no user serviceable parts contained in this

equipment.

8. This equipment may not be used on coin service pro-

vided by the telephone company. Connection to party

lines is subject to state tariffs.

Getting Started

Read Me First

The Telephone Consumer Protection Act of 1991 makes

it unlawful for any person to use a computer or other

electronic device to send any message via a telephone

fax machine unless such message clearly contains in a

margin at the top or bottom of each transmitted page or

on the ﬁ rst page of the transmission, the date and time

it is sent and an identiﬁ cation of the business or other

entry, or other individual sending the message and

the telephone number of the sending machine or such

business, other entity, or individual. In order to program

this information into your fax software, you should refer

to the manual of the Fax software being used.

10. According to the FCC’s electrical safety advisory, we

recommend that you may install an AC surge arrestor

in the AC outlet to which this equipment is connected.

Telephone companies report that electrical surges,

typically lightning transients, are very destructive to

customer terminal equipment connected to AC power

sources and that this is a major nationwide problem.

“Caution : To reduce the risk of ﬁ re, use only No.26 AWG or

larger telecommunication line cord.”

“ATTENTION : Pour réduire le risque d’incendie, utiliser

uniquement des conducteurs de télécommunications 26

AWG ou de section supérieure.”

16-M-1

Notice for the products using LCD

This product uses one or more ﬂ uorescent lamps contain-

ing a small amount of mercury. It also contains lead in some

components. Disposal of these materials may be regulated

in your community due to environmental considerations.

For disposal or recycling information please contact your

local authorities, or the Electronics Industries Alliance:

<http://www.eiae.org/> 24-M-1

UL1604-conforming model.(The model which has de-

scription of “UL1604” in the bottom of the computer.)

 THIS EQUIPMENT IS SUITABLE FOR USE IN

CLASS I,DIVISION2,GROUPS A,B,C, AND D OR

NON-HAZARDOUS LOCATIONS ONLY.

 WARNING-EXPLOSION HAZARD-SUBSTITUTION

OF COMPONENTS MAY IMPAIR SUITABILITY FOR

CLASSI,DIVISION2.

 When connecting and using a device manufactured by

a third party,enquire to the manufacturer as to whether

the device suits CLASS1,DIVISION2. 33-M-1

Models for Canada

Industry Canada (IC) Notice for modem

This equipment contains an Industry Canada approved

modem unit.

The Industry Canada label is afﬁ xed on the modem unit.

EQUIPMENT ATTACHEMENT LIMITATIONS

“NOTICE: The Industry Canada label identiﬁ es certiﬁ ed

equipment. This certiﬁ cation means that the equipment

meets telecommunications network protective, opera-

tional and safety requirements as prescribed in the ap-

propriate Terminal Equipment Technical Requirements

document(s). The Department does not guarantee the

equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that

it is permissible to be connected to the facilities of the

local telecommunications company. The equipment must

also be installed using an acceptable method of connec-

tion. The customer should be aware that compliance with

the above conditions may not prevent degradation of

service in some situations.

Repairs to certiﬁ ed equipment should be coordinated by a

representative designated by the supplier. Any repairs or

alterations made by the user to this equipment, or equipment

malfunctions, may give the telecommunications company

cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the elec-

trical ground connections of the power utility, telephone

lines and internal metallic water pipe system, if present,

are connected together. This precaution may be par-

ticularly important in rural areas. Caution: Users should

not attempt to make such connections themselves, but

should contact the appropriate electric inspection author-

ity, or electrician, as appropriate.”

“NOTICE: The Ringer Equivalence Number (REN) assigned

to each terminal device provides an indication of the maxi-

mum number of terminals allowed to be connected to a tele-

phone interface. The termination on an interface may consist

of any combination of devices subject only to the require-

ment that the sum of the Ringer Equivalence Numbers of all

the devices does not exceed 5.”

REN: See bottom of the computer

RESTRICTIONS CONCERNANT LE RACCORDEMENT

DE MATÉRIEL

“AVIS: L’étiquette d’Industrie Canada identiﬁ e le matériel

homologué. Cette étiquette certiﬁ e que le matériel est

conforme aux normes de protection, d’exploitation et de

sécurité des réseaux de télécommunications, comme

le prescrivent les documents concernant les exigences

techniques relatives au matériel terminal. Le Ministère

n’assure toutefois pas que le matériel fonctionnera à la

satisfaction de l’utilisateur.

Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est

permis de le raccorder aux installations de l’entreprise locale

de télécommunication. Le matériel doit également être installé

en suivant une méthode acceptée de raccordement.

L’abonné ne doit pas oublier qu’il est possible que la con-

formité aux conditions énoncées ci-dessus n’empêche

pas la dégradation du service dans certaines situations.

Les réparations de matériel homologué doivent être coor-

données par un représentant désigné par le fournisseur.

L’entreprise de télécommunications peut demander à

l’utilisateur de débrancher un appareil à la suite de répa-

rations ou de modiﬁ cations effectuées par l’utilisateur ou

à cause de mauvais fonctionnement.

Pour sa propre protection, l’utilisateur doit s’assurer que

tous les ﬁ ls de mise à la terre de la source d’énergie

électrique, des lignes téléphoniques et des canalisations

d’eau métalliques, s’il y en a, sont raccordés ensemble.

Cette précaution est particulièrement importante dans les

régions rurales. Avertissement: L’utilisateur ne doit pas

tenter de faire ces raccordements lui-même; il doit avoir

recours à un service d’inspection des installations élec-

triques, ou à un électricien, selon le cas.”

“AVIS: L’indice d’équivalence de la sonnerie (IES) assigné

à chaque dispositif terminal indique le nombre maximal de

terminaux qui peuvent être raccordés à une interface. La

terminaison d’une interface téléphonique peut consister en

une combinaison de quelques dispositifs, à la seule condi-

tion que la somme d’indices d’équivalence de la sonnerie de

touts les dispositifs n’excède pas 5.”

IES: Voir sous le fond de l’ordinateur 17-Ca-1

Getting Started

CSA C22 2 NO.213-conforming model.(The model

which has description of “CSA C22 2 NO.213” in the

bottom of the computer.)

 THIS EQUIPMENT IS SUITABLE FOR USE IN

CLASS I,DIVISION2,GROUPS A,B,C, AND D OR

NON-HAZARDOUS LOCATIONS ONLY.

 WARNING-EXPLOSION HAZARD-SUBSTITUTION

OF COMPONENTS MAY IMPAIR SUITABILITY FOR

CLASSI,DIVISION2.

 When connecting and using a device manufactured by

a third party,enquire to the manufacturer as to whether

the device suits CLASS1,DIVISION2. 33-Ca-1

Industry Canada

This product complies with RSS210 Industry Canada.

Operation is subject to the following two conditions;

(1) this device may not cause interference, and

(2)

this device must accept any interference, including inter-

ference that may cause undesired operation of the device.

This product (local network devices) for the band 5150-5250

MHz is only indoor usage to reduce potential for harmful

interference to co-channel Mobile Satellite systems.

High power radars are allocated as primary users (meaning they

have priority) of 5250-5350 MHz and 5650-5850 MHz and these

radars could cause interference and/or damage to LELAN devices.

30-Ca-1

This device has been designed to operate with an anten-

na having a maximum gain of 2.15 dBi. Antenna having a

higher gain is strictly prohibited per regulations of Industry

Canada. The Required antenna impedance is 50 ohms.

To reduce potential radio interference to other users, the

antenna type and its gain should be so chosen that the

equivalent isotropically radiated power (EIRP) is not more

than that required for successful communication.

25-Ca-1-1

RF Exposure Warning

This equipment has been approved for mobile operation,

and unless otherwise advised in separate supplemental

instructions for individual wireless transmitter(s), requires

minimum 20 cm spacing be proved between antenna(s)

and all person’s body (excluding extremities of hands,

wrist and feet) during wireless modes of operation.

Mise en garde concernant l’exposition à l’énergie

radiofréquence

Cet équipement a été homologué pour un fonctionnement

sans ﬁ l et, sauf avis contraire inclus dans la notice d’utili-

sation d’un autre émetteur sans ﬁ l, une distance minimale

de 20 cm doit être assurée entre l’antenne et le corps

de toute personne (à l’exclusion des mains, poignets et

pieds) pendant le fonctionnement sans ﬁ l. 25-M-5-1

Models for Europe

Declaration of Conformity (DoC)

“Hereby, we declare that this Personal Computer is in compliance with the essential requirements

and other relevant provisions of the Directive 1999/5/EC.”

Hint:

If you want to get a copy of the original DoC of our products which relates to the R&TTE, please con-

tact our web address: http://www.doc.panasonic.de

Contact:

Panasonic Services Europe

A Division of Panasonic Marketing Europe GmbH

Panasonic Testing Centre

Network connection.

The terminal equipment is intended for connection to the following public network;

In all the countries of European Economical Area;

- Public Switched Telephony Networks

Technical Features.

The terminal equipment includes the following features;

- DTMF dialing

- Maximum bitrate receiving mode: 56 kbit/s

- Maximum bitrate sending mode: 33.6 kbit/s

This product is designed to interwork with the Public Switched Telecommunication Networks in UK, Ireland, Nether-

lands, Sweden, Denmark, Finland, Switzerland, Luxembourg, Belgium, France, Germany, Spain, Portugal, Iceland,

Greece, Italy, Norway and Austria. 18-E-1

Compliance Notice - CE Mark

This equipment is in conformance with the requirements of the European Council Directive listed below:

73/23/EEC Low Voltage Directive with amendment 93/68/EEC

89/336/EEC EMC Directive with amendments 92/31/EEC and 93/68/EEC

1999/5/EC R&TTE

21-E-1

Getting Started

Read Me First

When using your telephone equipment, basic safety

precautions should always be followed to reduce the risk

of ﬁ re, electric shock and injury to persons, including the

following:

1. Do not use this product near water, for example, near

a bath tub, wash bowl, kitchen sink or laundry tub, in a

wet basement or near a swimming pool.

2. Avoid using a telephone (other than a cordless type)

during an electrical storm. There may be a remote risk

of electric shock from lightning.

3. Do not use the telephone to report a gas leak in the

vicinity of the leak.

4. Use only the power cord and batteries indicated in this

manual. Do not dispose of batteries in a ﬁ re. They may

explode. Check with local codes for possible special

disposal instructions.

SAVE THESE INSTRUCTIONS

19-E-1

Certaines mesures de sécurité doivent être prises pen-

dant l’utilisation de matérial téléphonique aﬁ n de réduire

les risques d’incendie, de choc électrique et de blessures.

En voici quelquesunes:

1. Ne pas utiliser l’appareil près de l’eau, p.ex., près d’

une baignoire, d’un lavabo, d’un évier de cuisine, d’un

bac à laver, dans un sous-sol humide ou près d’une

piscine.

2. Éviter d’utiliser le téléphone (sauf s’il s’agit d’un ap-

pareil sans ﬁ l) pendant un orage électrique. Ceci peut

présenter un risque de choc électrique causé par la

foudre.

3. Ne pas utiliser l’appareil téléphonique pour signaler

une fuite de gaz s’il est situé près de la fuite.

4. Utiliser seulement le cordon d’alimentation et le type

de piles indiqués dans ce manual. Ne pas jeter les

piles dans le feu: elles peuvent exploser. Se conform-

er aux règlements pertinents quant à l’élimination des

piles.

CONSERVER CES INSTRUCTIONS

19-F-1

Information to the User

This product and your Health

This product, like other radio devices, emits radio fre-

quency electromagnetic energy. The level of energy

emitted by this product however is far much less than the

electromagnetic energy emitted by wireless devices like

for example mobile phones.

Because this product operates within the guidelines found

in radio frequency safety standards and recommenda-

tions, we believe this product is safe for use by consum-

ers. These standards and recommendations reﬂ ect the

consensus of the scientiﬁ c community and result from

deliberations of panels and committees of scientists who

continually review and interpret the extensive research

literature.

In some situations or environments, the use of this prod-

uct may be restricted by the proprietor of the building or

responsible representatives of the organization. These

situations may for example include:

 Using this product on board of airplanes, or

 In any other environment where the risk of interference

to other devices or services is perceived or identiﬁ ed

as harmful.

If you are uncertain of the policy that applies on the use

of wireless devices in a speciﬁ c organization or environ-

ment (e.g. airports), you are encouraged to ask for autho-

rization to use this product prior to turning on the product.

Regulatory Information

We are not responsible for any radio or television interfer-

ence caused by unauthorized modiﬁ cation of this product.

The correction of interference caused by such unauthor-

ized modiﬁ cation will be the responsibility of the user. We

and its authorized resellers or distributors are not liable

for damage or violation of government regulations that

may arise from failing to comply with these guidelines.

26-M-1

Lithium Battery / Pile au lithium

Lithium Battery!

This computer contains a lithium battery to enable the

date, time, and other data to be stored. The battery

should only be exchanged by authorized service person-

nel.

Warning!

A risk of explosion from incorrect installation or misappli-

cation may possibly occur.

15-E-1

Pile au lithium!

Le micro-ordinateur renferme une pile au lithium qui

permet de sauvegarder certaines données, notamment la

date et l’heure. La pile ne doit être remplacée que par un

technicien qualiﬁ é.

Danger ! Risque d’explosion en cas de non respect de

cette mise en garde!

15-F-1

Important Safety Instructions / Importantes Mesures De Sécurité

Getting Started

THIS PRODUCT IS NOT INTENDED FOR USE AS, OR AS

PART OF, NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAF-

FIC CONTROL EQUIPMENT/SYSTEMS, OR AIRCRAFT

COCKPIT EQUIPMENT/SYSTEMS*1 . PANASONIC WILL

NOT BE RESPONSIBLE FOR ANY LIABILITY RESULT-

ING FROM THE USE OF THIS PRODUCT ARISING OUT

OF THE FOREGOING USES.

*1 AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include

Class2 Electrical Flight Bag (EFB) Systems and Class1

EFB Systems when used during critical phases of ﬂ ight

(e.g., during take-off and landing) and/or mounted on to

the aircraft. Class1 EFB Systems and 2 EFB Systems are

deﬁ ned by FAA: AC (Advisory Circular) 120-76A or JAA:

JAA TGL (Temporary Guidance Leaﬂ ets) No.36.

Panasonic cannot guarantee any speciﬁ cations, technolo-

gies, reliability, safety (e.g. Flammability/Smoke/Toxic-

ity/Radio Frequency Emission, etc) requirements related

to aviation standards that exceed the speciﬁ cations of our

COTS (Commercial-Off-The-Shelf) products. 39-E-1

This computer is not intended for use in medical equipment

including life-support systems, air trafﬁ c control systems, or

other equipment, devices or systems that are involved with

ensuring human life or safety. Panasonic cannot be held

responsible in any way for any damages or loss resulting

from the use of this computer in these types of equipment,

devices or systems, etc.

The CF-30 was developed based on thorough research into

the real-world portable computing environments. Exhaustive

pursuit of usability and reliability under harsh conditions led

to innovations such has the magnesium alloy exterior, vibra-

tion damped hard disk drive and ﬂ oppy disk drive, ﬂ exible

internal connections. The CF-30’s outstanding engineering

has been tested using the strict MIL-STD- 810F (for vibration

and shock) and IP (for dust and water) based procedures.

As with any portable computer device precautions should be

taken to avoid any damage. The following usage and han-

dling procedures are recommended.

Before putting the computer away, be sure to wipe off any

moisture.

If a Malfunction Occurs, Immediately Unplug the AC

Cord and the Battery Pack

 Computer is damaged

 Foreign object inside computer

 Smoke emitted

 Unusual smell emitted

 Unusually hot

Continuing to use the computer while any of the above con-

ditions are present may result in ﬁ re or electric shock.

 If a malfunction occurs, immediately turn the power off and

unplug the AC cord, and then remove the battery pack.

Do Not Touch the Computer and Cable When It Starts

Thundering

Electric shock may result.

Do Not Connect the AC Adaptor to a Power Source

Other Than a Standard Household AC Outlet

Otherwise, a ﬁ re due to overheating may result. Connecting

to a DC/AC converter (inverter) may damage the AC adap-

tor. On an airplane, only connect the AC adaptor/charger to

an AC outlet speciﬁ cally approved for such use.

Do Not Do Anything That May Damage the AC Cord, the

DC Plug, or the AC Adaptor

Do not damage or modify the cord, place it near hot tools,

bend, twist, or pull it forcefully, place heavy objects on it, or

bundle it tightly.

Continuing to use a damaged cord may result in ﬁ re, short

circuit, or electric shock.

Do Not Pull or Insert the DC Plug If Your Hands Are Wet

Electric shock may result.

Clean the DC Plug of Dust and Other Debris Regularly

If dust or other debris accumulates on the plug, humidity,

etc. may cause a defect in the insulation, which may result in

a ﬁ re.

 Pull the plug, and wipe it with a dry cloth.

Pull the plug if the computer is not being used for a long

period of time.

Insert the AC Plug Completely

If the plug is not inserted completely, ﬁ re due to overheating

or electric shock may result.

 Do not use a damaged plug or loose AC outlet.

Close the Connector Cover Tightly When Using the

Computer Where Is a Lot of Water, Moisture, Steam,

Dust, Oily Vapors, etc.

The entry of foreign matter may cause a ﬁ re or electric

shocks.

 If foreign matter has found its way inside, immediately turn

the power off and unplug the AC cord, and then remove

the battery pack. Then contact your technical support of-

ﬁ ce.

Do Not Disassemble the Computer

There are high-voltage areas inside which may give you an

electric shock if you should touch them. Do not touch the

pins and circuit boards inside, and do not allow foreign mat-

ter to enter inside.

Also, remodeling or disassembly may cause a ﬁ re.

Keep SD Memory Cards Away from Infants and Small

Children

Accidental swallowing will result in bodily injury.

In the event of accidental swallowing, see a doctor immedi-

ately.

Do Not Place the Computer on Unstable Surfaces

If balance is lost, the computer may fall over or drop, result-

ing in an injury.

Avoid Stacking

If balance is lost, the computer may fall over or drop, result-

ing in an injury.

Do Not Leave the Computer in High Temperature Envi-

ronment Such as in a Sun-Heated Car, for a Long Period

of Time

Leaving the computer where it will be exposed to extremely

high temperatures such as in a sun-heated car or in direct

sunlight may deform the cabinet and/or cause trouble in the

internal parts. Continued use in such a resulting condition

may lead to short-circuiting or insulation defects, etc. which

may in turn lead to a ﬁ re or electric shocks.

Hold the Plug When Unplugging the AC Cord

Pulling on the cord may damage the cord, resulting in a ﬁ re

or electric shock.

Do Not Move the Computer While the DC Plug Is Con-

nected

The AC cord may be damaged, resulting in ﬁ re or electric

shock.

 If the AC cord is damaged, unplug the DC plug immedi-

ately.

Use Only the Speciﬁ ed AC Adaptor With Your Computer

Using an AC adaptor other than the one supplied (attached

to your computer or supplied by Panasonic) may result in a

ﬁ re.

Do Not Subject the AC Adaptor to Any Strong Impact

Using the AC adaptor after a strong impact such as being

dropped may result in electric shock, short circuit, or ﬁ re.

Take a Break of 10-15 Minutes Every Hour

Using the computer for long periods of time may have detri-

mental health effects on the eyes or hands.

Precautions

Getting Started

Read Me First

Do Not Turn the Volume Up to Loud When Using Head-

phones

Listening at high volumes that overstimulate the ear for long

periods of time may result in loss of hearing.

Use the Modem with a Regular Telephone Line

Connection to an internal phone line (on-premise switches)

of a company or business ofﬁ ce, etc. or to a digital public

phone or use in a country or area not supported by the com-

puter may result in a ﬁ re or electric shocks.

Do Not Connect a Telephone Line, or a Network Cable

Other Than the One Speciﬁ ed, into the LAN Port

If the LAN port is connected to a network such as the ones

listed below, a ﬁ re or electric shock may result.

Precautions (Battery Pack)

Do Not Use with Any Other Computer

The battery pack is rechargeable and was intended for the

speciﬁ ed computer or charger. If it is used with a computer

other than the one for which it was designed, electrolyte

leakage, generation of heat, ignition or rupture may result.

Do Not Charge the Battery Using the Methods Other

Than Indicated in This Manual

If the battery pack is not charged using one of the methods

indicated in this manual, electrolyte leakage, generation of

heat, ignition or rupture may result.

Do Not Throw the Battery Pack into a Fire or Expose It

to Excessive Heat

Generation of heat, ignition or rupture may result.

Avoid Extreme Heat (Near the Fire, in Direct Sunlight, for

Example)

Electrolyte leakage, generation of heat, ignition or rupture

may result.

Do Not Insert Sharp Objects into the Battery Pack, Ex-

pose It to Bumps or Shocks, Disassemble, or Modify It

Electrolyte leakage, generation of heat, ignition or rupture

may result.

Do Not Short the Positive (+) and Negative (-) Contacts

Generation of heat, ignition or rupture may result. Do not

place the battery pack together with articles such as neck-

laces or hairpins when carrying or storing.

Do Not Use This Computer with a Battery Pack Other

Than the One Speciﬁ ed

Use only the speciﬁ ed battery pack (CF-VZSU43U) with your

CF-30. Use of battery packs other than those manufactured

and supplied by Panasonic may present a safety hazard

(generation of heat, ignition or rupture).

 Do not touch the terminals on the battery pack. The bat-

tery pack may no longer function properly if the contacts

are dirty or damaged.

 Do not expose the battery pack to water, or allow it to

become wet.

 If the battery pack will not be used for a long period of

time (a month or more), charge or discharge (use) the

battery pack until the remaining battery level becomes

30% to 40% and store it in a cool, dry place.

 This computer prevents overcharging of the battery by

recharging only when the remaining power is less than

approx. 95% of capacity.

 The battery pack is not charged when the computer is

ﬁ rst purchased. Be sure to charge it before using it for

the ﬁ rst time. When the AC adaptor is connected to the

computer, charging begins automatically.

 Should the battery leak and the ﬂ uid get into your eyes,

do not rub your eyes. Immediately ﬂ ush your eyes with

clear water and see a doctor for medical treatment as

soon as possible.

 Networks other than 1000BASE-TX, 100BASE-TX or

10BASE-T

 Phone lines (Telephone lines, internal phone lines (on-

premise switches), digital public phones, etc.)

Do Not Use with Exposing the Skin to the Computer for

a Long Period of Time

Using the computer with exposing the skin to the heat source

of the computer or AC adaptor for a long period of time can

cause a low-temperature burn.

 Do not place the computer near a television or radio re-

ceiver.

 Keep the computer away from magnets. Data stored on

the hard disk may be lost.

NOTE

 The battery pack may become warm during recharg-

ing or normal use. This is completely normal.

 Recharging will not commence if internal temperature

of the battery pack is outside of the allowable temper-

ature range (0 °C to 50 °C {32°F to 122 °F}).

( Reference Manual “Battery Power”) Once the

allowable range requirement is satisﬁ ed, charging

begins automatically. Note that the recharging time

varies based on the usage conditions. (Recharging

takes longer than usual when the temperature is 10 °

C {50 °F} or below.)

 If the temperature is low, the operating time is short-

ened. Only use the computer within the allowable

temperature range.

 This computer has a high temperature mode function

that prevents the degradation of the battery in high

temperature environments. ( Reference Manual

“Battery Power”) A level corresponding to a 100%

charge for high temperature mode is approximately

equivalent to an 80% charge level for normal tempera-

ture mode.

 The battery pack is a consumable item. If the amount

of time the computer can be run by using a particular

battery pack becomes dramatically shorter and re-

peated recharging does not restore its performance,

the battery pack should be replaced with a new one.

 When transporting a spare battery inside a package,

briefcase, etc., it is recommended that it be placed in

a plastic bag so that its contacts are protected.

 Always power off the computer when it is not in use.

Leaving the computer on when the AC adaptor is not

connected will exhaust the remaining battery capacity.

Getting Started

For Used in Motor Vehicle /Pour L’utilisation Dans Un Véhicule Motorisé

Warning: Notebook Computer may be installed in a mo-

tor vehicle and visible to the driver only if used to support

vehicle related functions such as vehicle information,

system control, rear or side observation and navigation. If

used for entertainment purpose, such as television recep-

tion or video play, it must be installed to the rear of the

driver’s seat where it will not be

visible, directly or indirectly, to the operator of the motor

vehicle. Check with individual state/provincial laws to de-

termine lawful use of this product while operating within a

motor vehicle.

Information on Disposal for Users of Waste Electrical & Electronic Equipment

(private households)

This symbol on the products and/or accompanying documents means that used electrical and electronic

products should not be mixed with general household waste.

Please dispose of this item only in designated national waste electronic collection schemes, and not in the

ordinary dust bin.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.

Information on Disposal in other Countries outside the European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of

disposal.

36-E-1

Avertissement : L’ordinateur bloc-notes peut être installé

dans un véhicule motorisé et dans le champ de vision du

conducteur uniquement en tant que dispositif d’aide aux

fonctions du véhicule, comme par exemple pour fournir

des informations sur le véhicule, comme dispositif de

contrôle de système, pour l’observation à l’arrière ou sur

les côtés du véhicule, ainsi que pour fournir de l’informa-

tion routière. Pour toute utilisation à ﬁ n de divertissement,

comme par exemple pour regarder la télévision ou jouer

à des jeux vidéo, il doit être installé à l’arrière du siège du

conducteur, en un emplacement où il ne sera pas visible,

ni directement ni indirectement, pour le conducteur du

véhicule motorisé. Vériﬁ ez les lois fédérales et nationales

qui régissent l’utilisation légale de cet appareil à l’intérieur

d’un véhicule motorisé.

35-M-1

Getting Started

Description of Parts

A: Bluetooth antenna

 Reference Manual “Bluetooth”

B: ExpressCard slot

 Reference Manual “PC Card / ExpressCard”

C: PC Card slot

 Reference Manual “PC Card / ExpressCard”

D: Multimedia pocket

 Reference Manual “Multimedia Pocket”

E: Battery pack

F: Wireless LAN antenna

 Reference Manual “Wireless LAN”

G: LCD

 Reference Manual “Touchscreen”

H: Function key

 Reference Manual “Key Combinations”

I: Keyboard

J: Touch pad

K: LED indicator

: Caps lock

: Numeric key (NumLk)

: Scroll lock (ScrLk)

: Multimedia pocket device status or the second

battery status

 Reference Manual “Multimedia Pocket”

“Battery Power”

: Hard disk drive status

: Power status of the multimedia pocket

: Power status

(Off: Power off/Hibernation, Green: Power on,

Blinking green: Standby, Blinking green rapidly:

Cannot power on or resume due to low tempera-

ture.)

: Battery status

 Reference Manual “Battery Power”

: Wireless ready indicator

This indicator lights when Wireless LAN, Blue-

tooth, and/or Wireless WAN are connected and

ready. It does not necessarily indicate the On/Off

condition of the wireless connection.

 Reference Manual “Wireless LAN” “Blue-

tooth” “Wireless Switch Utility”

: Wireless WAN status indicator

 Reference Manual “Wireless Switch Utility”

L: Power switch

M: Wireless switch

 Reference Manual “Wireless LAN” “Bluetooth”

“Wireless Switch Utility”

N: Stylus holder

O: Carrying handle

A lithium ion battery that is recyclable powers the product you have purchased.

Please call 1-800-8-BATTERY for information on how to recycle this battery.

L’appareil que vous vous êtes procuré est alimenté par une batterie au lithium-ion.

Pour des renseignements sur le recyclage de la batterie, veuillez composer le

1-800-8-BATTERY.

Getting Started

Right side

ABC D FE G H I

1394

J K M N O PLH

Rear side Bottom

A: Hard disk drive

 Reference Manual “Hard Disk Drive”

B: SD Memory Card slot

 Reference Manual “SD Memory Card”

C: SD Memory Card indicator

(Blinking: During access or a password is requested)

 Reference Manual “SD Memory Card”

D: IEEE 1394 interface connector

 Reference Manual “IEEE 1394 Devices”

E: Smart Card slot

 Reference Manual “Smart Card”

F: Modem port

 Reference Manual “Modem”

G: LAN port

 Reference Manual “LAN”

H: USB port

 Reference Manual “USB Devices”

I: DC-IN jack

J: Security lock

You can connect a Kensington cable. Refer to the

instruction manual of the cable.

K: Ext antenna connector

 Reference Manual “Port Replicator”

L: Expansion bus connector

 Reference Manual “Port Replicator”

M: External display port

 Reference Manual “External Display”

N: Headphone jack

You can connect headphones or ampliﬁ ed speakers.

When they are connected, audio from the internal

speakers is not heard.

O: Microphone jack

You can use a stereo condenser microphone. Con-

necting other type of microphone may interrupt audio

input or may cause a malfunction.

NOTE

 When using an external microphone, do not remove

the check mark for “Mute” under “Microphone Bal-

ance” of the Volume Control dialog box and do not

increase the playback volume. Howling may result.

Howling may occur in the same way when discon-

necting an external microphone. (The microphone of

“Volume Control” is in the state of mute at the time of

factory shipment. This is not shown at the time of fac-

tory shipment.)

P: Serial port

Q: RAM module slot

 Reference Manual “RAM Module”

R: Speaker

 Reference Manual “Key Combinations”

CAUTION

 Do not put a metallic object or magnetic media close to the speakers.

Getting Started

Description of Parts

Attaching the stylus to the computer

Use the tether to attach the stylus to the computer so you will not lose it.

There are holes to attach it on both sides of the bottom of the display.

Getting Started

 Preparation

A Check and identify the supplied accessories.

If you do not ﬁ nd the described accessories, contact Panasonic Technical Support ( page 32).

• AC Adaptor . . . . . 1

Model No: CF-AA1653A

• AC Cord . . . . . . . 1 • Battery Pack . . . 1

Model No: CF-VZSU46U

• Modem Telephone

Cable . . . . . . . . . 1

• Operating Instructions (This book) . . .1

• Product Recovery DVD-ROM . . . . . . . .1

• Windows® Book . . . . . . . . . . . . . . . . . . .1

• Soft Cloth . . . . . . 1 • Stylus . . . . . . . . . 1

( Reference Manual “Touchscreen”)

B Read the LIMITED USE LICENSE AGREEMENT before breaking the seal on the computer’s packaging

( page 28).

1 Insert the battery pack.

A Slide the latch (A) to the right to unlock the cover.

B Slide the latch (A), and open the cover.

C Insert the battery pack until it securely ﬁ ts the connector.

D Close the cover until it clicks.

E Slide the latch (B) to the left to lock the cover.

CAUTION

 Make sure the latch is securely locked. Otherwise the battery pack may fall

when you carry the computer.

 Do not touch the terminals of the battery pack and the computer. Doing so can

make the terminals dirty or damaged, and may cause malfunction of the battery

pack and the computer.

2 Connect your computer to a power outlet.

The battery charging starts automatically.

CAUTION

 Do not disconnect the AC adaptor and do not switch the wireless switch to on

until the ﬁ rst-time operation procedure is completed.

 When using the computer for the ﬁ rst time, do not connect any peripheral device

except the battery pack and AC adaptor.

 Handling the AC adaptor

 Do not twist or pull the AC power cord forcefully. Doing so may damage the

connections.

 Use only the speciﬁ ed AC adaptor with your computer. Using an AC adaptor

other than the one supplied might damage the battery and/or the computer.

 When the DC plug is not connected to the computer, disconnect the AC cord

from your AC wall outlet.

 Problems such as sudden voltage drops may arise during periods of thunder

and lightning. Since this could adversely affect your computer, an uninter-

ruptible power source (UPS) is highly recommended unless running from the

battery pack alone.

First-time Operation

Getting Started

First-time Operation

3 Turn on the computer.

A Pull the carrying handle forward.

B Lift up the latch (A) and lift open the display.

C Slide and hold the power switch for approximately one second until the

power indicator lights.

CAUTION

 Do not slide the power switch repeatedly.

 The computer will forcibly be turned off if you slide and hold the power switch for

four seconds or longer.

 Once you turn off the computer, wait for ten seconds or more before you turn on

the computer again.



Do not perform the following operation until the hard disk drive indicator turns off.

 Connecting or disconnecting the AC adaptor

 Sliding the power switch



Touching the keyboard, touch pad or touchscreen (only for model with touchscreen)

 Closing the display

 When the CPU temperature is high, the computer may not start up to prevent

overheating of the CPU. Wait until the computer cools down, and then turn the

power on again. If the computer does not power on even after cooling down,

contact Panasonic Technical Support ( page 32).

4 Setup Windows.

A Follow the on-screen instructions.

CAUTION

 When you set date/time/time zone and click [Next], the screen may not go to the

next step for a few minutes. Do not touch the keyboard or touch pad, and wait

until the screen changes.

 If “An unexpected error has occurred…” (or a similar message) is displayed,

select [OK]. This is not a malfunction.

 Wait until the hard disk drive indicator has turned off.

5 Create a new account.

A Click [start] - [Control Panel] - [User Accounts] - [Create a new account].

CAUTION



Remember your password. If you forget the password, you cannot use the Windows

operation system. Creating a password reset disk beforehand is recommended.

6 <Only for model with touchscreen>

Perform the touchscreen calibration.

A Click [start] - [All Programs] - [Fujitsu Touch Panel (USB)] - [Touch Screen

Calibration Utility].

B Using the stylus, touch each of the 12 “+” target marks one by one until it

blinks, and then click [Calibration].

C Click [Save & Exit].

NOTE

 Regarding Windows XP

You can select the Classic view of Control Panel or the Classic Start menu. You can also change the way a user logs on

or off. This manual explains using the Windows XP default setting (not Classic view or Classic Start menu etc.).

 Windows Update

You can update to the latest patches and service packs for Windows with the following menus.

[start] - [All Programs] - [Windows Update]

Do not apply “Driver Updates” even if a message to update a driver appears. If a driver update is required,

contact Panasonic Technical Support ( page 32).

 If the message “Your computer might be at risk” is displayed

Select on the taskbar and make the appropriate settings. The Windows Security Center regularly gives you no-

tice so that you can make the optimum settings. This is not an error message and you can use the computer. How-

ever, making appropriate measures is recommended to reduce the risk of virus and other attacks.

 Note that the computer consumes electricity even when the computer power is off.

If the battery pack is fully charged, the battery will fully discharge in Approx. XX weeks.

(when second battery pack is attached: Approx. XX weeks)

Useful Information

On-screen Manual

You can access the Reference Manual and the Important Tips on the computer screen.

When you access the Reference Manual and the Important Tips for the ﬁ rst time, the License Agreement of the Adobe

Reader may be displayed. Read it carefully and select [Accept] to proceed.

 Reference Manual

The Reference Manual contains the practical information to help you fully enjoy the computer’s performance.

To access the Reference Manual:

A Click [start] - [Reference Manual].

Contents

 Key Combinations

 Touchscreen

 Panasonic Hand Writing

 Standby/Hibernation Functions

 Security Measures

 Battery Power

 Multimedia Pocket

 PC Card / ExpressCard

 SD Memory Card

 SD Security

 Smart Card

 RAM Module

 Port Replicator

 External Display

 USB Devices

 IEEE 1394 Devices

 Modem

 LAN

 Wireless Switch Utility

 Wireless LAN

 Bluetooth

 Hard Disk Drive

 Setup Utility

 Icon Enlarger

 Loupe Utility

 DMI Viewer

 Recover Pro

 Technical Information

 Troubleshooting (Advanced)

 Important Tips

The Important Tips will provide you with the helpful information about the battery and touchscreen. Read to use the

battery pack in the optimum condition to obtain longer operation time.

To access the Important Tips:

A Double-click on the desktop.

 Alternatively click [start] - [All Programs] - [Panasonic] - [On-Line Manuals] - [Important Tips].

Useful Information

Handling and Maintenance

Operation Environment

 Place the computer on a ﬂ at stable surface. Do not place the computer upright or turn it over. If the computer is

exposed to an extremely strong impact, it may become inoperable.

 Temperature: Operation : 5 °C to 35 °C {41 °F to 95 °F}

Storage : -20°C to 60 °C {- 4 °F to 140 °F}

Humidity: Operation : 30% to 80% RH (No condensation)

Storage : 30% to 90% RH (No condensation)

Even within the above temperature/humidity ranges, using for a long time in an extreme environment will result in

the product deterioration and will shorten the product life.

 Do not place the computer in the following areas, otherwise the computer may be damaged.

 Near electronic equipment. Image distortion or noise may occur.

 In extremely high or low temperature.

 As the computer can become hot during operation, keep it away from items that are sensitive to heat.

Handling Cautions

This computer is designed to minimize shock to parts such as the LCD and the hard disk drive and equipped with a

drip-proof keyboard, but no warranty is provided against any trouble caused by shock. Be extremely careful when han-

dling the computer.

 When carrying the computer:

 Turn off the computer.

 Remove all external devices, cables, cards and other protruding things.

 Do not drop or hit the computer against solid objects.

 Do not leave the display open.

 Do not grip the display part.

 Do not put anything (e.g., a piece of paper) between the display and keyboard.

 When you board an airplane, take the computer with you and never put it in your checked luggage. When using the

computer on airplane, follow the airline’s instructions.

 When carrying a spare battery, put it in a plastic bag to protect its terminals.

 The touch pad is designed to be used with a ﬁ nger tip. Do not place any object on its surface and do not press

down strongly with sharp-pointed or hard objects that may leave marks (e.g., nails, pencils and ball point pens).

 Avoid any harmful substances such as oil from getting into the touch pad. The cursor may not work correctly.

 Use only the included stylus to touch the touchscreen. Do not place any object on its surface and do not press

down strongly with sharp-pointed or hard objects that may leave marks (e.g., nails, pencils and ball point pens).

 Do not use the stylus when dust or dirt (e.g., oil) is on the screen. Otherwise foreign particles on the screen/stylus

can scratch the screen surface or obstruct the stylus operation.

 Use the stylus only for touching the screen. Using it for any other purpose may damage the stylus and result in

scratches on the screen.

 When using peripheral devices

Follow these instructions and the Reference Manual to avoid any damage to the devices. Carefully read the instruction

manuals of the peripheral devices.

 Use the peripheral devices conforming to the computer’s speciﬁ cations.

 Connect to the connectors in the correct direction.

 If it is hard to insert, do not try forcibly but check the connector’s shape, direction, alignment of pins, etc.

 If screws are included, fasten them securely.

 Remove the cables when you carry the computer. Do not pull the cables forcibly.

 Preventing your computer from unauthorized use via wireless LAN

 Before using wireless LAN, make the appropriate security settings such as data encryption.

Useful Information

 Preparations for installing Absolute Computrance Software

Perform the following steps before installing Absolute Computrance Software to prevent thefts.

1 Turn on or restart the computer, and press

several times while [Panasonic] boot

screen is displayed.

The Setup Utility starts up.

 If the password is requested, enter the Supervisor Password.

2 Select the [Advanced] menu, then select [Computrace (R) Sub-Menu] and press

Enter

CAUTION

 You can only make this setting once. You will be unable to disable this once you have selected [Enable].

3 Select [Computrace (R) BIOS Module], and set to [Enable].

4 Select [Execute] and press

Enter

5 Select [Execute] and press

Enter

6 Press

Esc

to close the sub-menu.

7 Press

F10

At the conﬁ rmation message, select [Yes] and press

Enter

The computer restarts.

8 Install Absolute Computrance Software by referring to its manual.

Maintenance

To clean the LCD panel

Use the soft cloth included with the computer. (For further information, refer to “Suggestions About Cleaning the LCD

Surface” that comes with the soft cloth.)

To clean areas other than the LCD panel

Wipe with a soft dry cloth such as gauze. When using detergent, dip a soft cloth in water-diluted detergent and wring it

thoroughly.

CAUTION

 Do not use benzene, thinner, or rubbing alcohol since it may adversely affect the surface causing discoloration, etc.

Do not use commercially-available household cleaners and cosmetics, as they may contain components harmful to

the surface.

 Do not apply water or detergent directly to the computer, since liquid may enter inside of the computer and cause

malfunction or damage.

Useful Information

Hard Disk Backup Function (Recover Pro)

The Recover Pro creates a backup area (storage area) on the hard disk to back up (store) the hard disk data restore

the backup data to its original location when it is lost or corrupted by operational errors or other factors. You do not

need external media or peripheral devices to back up or restore hard disk data on this computer.

At purchase, the Recover Pro is not installed. Install using the instructions below. If you create a backup area, the hard

disk backup function will be enabled and you can back up your data.

The Recover Pro cannot back up or restore data correctly if a hard disk problem occurs during data backup or re-

storing. If an error occurs due to an unexpected malfunction, incorrect operation, or other reason while data is being

restored, the hard disk data (data before restoration) may be lost.

Matsushita Electric Industrial Co., Ltd. will bear no responsibility for any damage suffered (including loss of data) as a

result of the use of this function.

Here, we will explain the procedures for installation, complete backup (backing up hard disk contents in case Windows

cannot be booted), and complete restore (recovering the computer to its condition at the time of the complete backup).

For further information, refer to the software’s online manual ( page 19).

CAUTION

 All operations should be executed with the AC adaptor connected. Do not turn the power off while operations are

in progress. If the power is turned off while installation, backup, or restore operations are in progress, these opera-

tions may not function properly, and it may be impossible to start Windows. Also, do not press any keys or switches,

including hot keys.

 When restarting the computer, the message [Check ﬁ le system on C:] will appear. Follow the on-screen instruc-

tions. Do not skip the check process.

 Make sure you allow enough space on the hard disk when choosing settings during installation. To charge these

settings you must reinstall Recover Pro. You can choose [Typical] to allow 1/2 of the disk for backup or [Custom] to

increase the size of the area.

 Some software (security software, backup software, etc.) may be incompatible with Recover Pro. For details,

please refer to

http://www.phoenix.com/en/Customer+Services/White+Papers-Specs/Recover+Pro/default.htm.

Installation

1 Log on to Windows as an Administrator.

2 Close all programs.

3 Click [start] - [Run], enter [C:\util\rcvpro\setup.exe], and click [OK].

The InstallShield Wizard screen appears.

4 Click [Next].

Follow the on-screen instructions.

Carefully read the License Agreement, and select “I accept the agreement”.

 The computer restarts several times to complete installation.

CAUTION

 During the installation, the screen may become black (no display) momentarily. This is not a malfunction.

 When executing a [Typical] installation on a drive with multiple partitions,

the backup area is created using the space of the drive you selected.

the backup area is created using the space of the drive which has a larger empty space.

the backup area is created using the entire space of all drives.

 If you select [Typical] in installation, approximately 40% (max.) of the hard disk drive space is allocated as the back-

up area.

 You cannot change the size of backup area after creation.

NOTE

 You can choose [Typical] to allow 1/2 of the disk for backup or [Custom] to increase the size of the area for quick

backup and complete backup.

Useful Information

Complete backup

Backs up all data on the hard disk.

1 Log on to Windows as an Administrator.

2 Close all programs.

3 Double-click on the desktop.

“Recover Pro 6” screen appears.

 Alternatively you can click [start] - [All Programs] - [Phoenix Applications] - [Phoenix Recover Pro 6].

4 Click [Complete Backup], and click [Yes].

 The computer restarts, and “Recover Pro 6” screen appears.

Follow the on-screen instructions.

NOTE

 You can completely backup only one hard disk’s worth of data to the backup area.

Complete restore

This function uses the data created during complete backup. It restores the computer to the condition it was in when

you performed the complete backup.

1 Turn on or restart the computer, and press

several times while [Panasonic] boot

screen is displayed.

 “Always” screen appears.

2 Click [Protect / Recover], and click [Phoenix Recover Pro 6].

 “Recover Pro 6” screen appears.

3 Click [Complete Restore].

Follow the on-screen instructions.

 To access the online manual

Click [start] - [All Programs] - [Phoenix Applications] - [Docs] - [UsersGuides] - [UG_RecoverPro6_En_EN] /

[UG_PhoenixAlways_En_EN].

Useful Information

Hard Disk Data Erase Utility

When disposing the computer or transferring the ownership, erase all hard disk data in order to avoid data leakage.

Even if you erase the data or initialize the hard disk using normal Windows commands, the data can be read with

some special software. Use the hard disk data erase utility to erase the data completely.

Note that transferring of the ownership without uninstalling the commercial software will be a violation of the software’s

license agreement.

The hard disk data erase utility erases the data using overwriting method. If a malfunction or other operational error

occurs during the erasing process, the data may not be completely erased. Also there may be special devices to read

the erased data. To erase highly conﬁ dential data, ask a specialized company. Matsushita Electric Industrial Co., Ltd.

will bear no responsibility for losses or damages suffered as a result of the use of this utility.

CAUTION

 The backup data will be erased.

 When the hard disk contains the Recover Pro backup data, the Recover Pro backup area is lost as well.

NOTE

 Even if hard disk data erase is performed, the number of times of DVD’s region code setting will not be reset.

Preparation

 Prepare the following items:



The Product Recovery DVD-ROM

(included)

 Panasonic CD/DVD drive for the multimedia pocket (optional) (refer to recent catalogs and other sources

for information about the products available)

 Remove all peripherals (except for the CD/DVD drive).

 Connect the AC adaptor and do not remove it until hard disk data erase is complete.

1 Turn off the computer and insert the CD/DVD drive into the multimedia pocket

( Reference Manual “Multimedia Pocket”).

2 Turn on the computer, and press

several times while [Panasonic] boot screen is dis-

played.

The Setup Utility starts up.

 If the password is requested, enter the Supervisor Password.

3 Select the [Boot] menu, then select [IDE MP] and press

until [IDE MP] is at the top

of the boot priority order.

4 Select the [Security] menu and set [DVD Operation] to [Enable].

5 Set the Product Recovery DVD-ROM into the CD/DVD drive.

6 Press

F10

At the conﬁ rmation message, select [Yes] and press

Enter

The computer restarts.

7 Press

to execute [2. [Erase HDD]].

 To cancel this operation, press

8 At the conﬁ rmation message, press

9 When [<<< Start Menu >>>] is displayed, press

Enter

The approximate time required for erasing data will be displayed.

10 Press

Space

At the conﬁ rmation message, press

Enter

The hard disk erase process starts. When the operation is completed, the [Hard disk data has been deleted.]

message will appear. If a problem has occurred during the operation, an error message will appear.

 To cancel partway, press

Ctrl

. The data erasure will be up to that point.

11 Remove the Product Recovery DVD-ROM, and then press any key to turn off the com-

puter.

Useful Information

Reinstalling Software

When you reinstall the software, the hard disk data will be erased. Back up important data to other media or an exter-

nal hard disk before reinstallation.

Reinstalling software will return the computer to the default condition. The hard disk backup area and the backup

data ( page 18) will be erased. (If you reinstall Windows in the ﬁ rst partition, the backup area and data will not be

erased.) Even if the data is stored in partitions on the hard disk, it may be erased or corrupted.

Preparation

 Prepare the following items:

 The Product Recovery DVD-ROM (included)

 Panasonic CD/DVD drive for the multimedia pocket (optional) (refer to recent catalogs and other sources

for information about the products available)

 Remove all peripherals (except for the CD/DVD drive).

 Connect the AC adaptor and do not remove it until reinstallation is complete.

CAUTION

 When you use Recover Pro, copy data in the Recover Pro backup area to a removable disc or another storage

medium and uninstall Recover Pro before reinstalling the software. When you reinstall Recover Pro without deleting

the backup area, the backup area may disappear or installing the software may become impossible on the following

occasion.

NOTE

 Even if reinstallation is performed, the number of times of DVD’s region code setting will not be reset.

1 Turn off the computer and insert the CD/DVD drive into the multimedia pocket

( Reference Manual “Multimedia Pocket”).

2 Turn on the computer, and press

several times while [Panasonic] boot screen is dis-

played.

The Setup Utility starts up.

 If the password is requested, enter the Supervisor Password.

3 Write down all of the contents of the Setup Utility and press

At the conﬁ rmation message, select [Yes] and press

Enter

4 Select the [Boot] menu, then select [IDE MP] and press

until [IDE MP] is at the top

of the boot priority order.

5 Select the [Security] menu and set [DVD Operation] to [Enable].

6 Set the Product Recovery DVD-ROM into the CD/DVD drive.

7 Press

F10

At the conﬁ rmation message, select [Yes] and press

Enter

The computer will restart.

8 Press

to execute [1. [Recovery]].

The License Agreement screen appears.

 To cancel partway, press

9 Press

to select [1. Yes, I agree to the provisions above and wish to continue!].

10 Select the settings.

 [2]: Enter the size of operating system partition and press

Enter

You cannot create the hard disk backup area if you select [2].

(The size of data partition will be determined by subtracting the operating system partition size from the

maximum size.)

[3]: Windows will be installed in the ﬁ rst partition.

(The size of the ﬁ rst partition must be 20 GB or more. If smaller, installation will not be possible.)

At the conﬁ rmation message, press

Reinstallation starts automatically. (It will take approximately 20 minutes.)

 Do not interrupt reinstallation, for example by turning off the computer or pressing

Ctrl

Alt

Del

. Oth-

erwise reinstallation may become unavailable as Windows may not start up or the data may be corrupted.

11 Remove the Product Recovery DVD-ROM, and then press any key to turn off the com-

puter.

Useful Information

12 Turn on the computer, and press

several times while [Panasonic] boot screen is dis-

played.

The Setup Utility starts up.

 If the password is requested, enter the Supervisor Password.

13 Press

At the conﬁ rmation message, select [Yes] and then press

Enter

The Setup Utility settings excluding the password(s) will return to the default values.

14 Select the [Exit] menu and then select [Save Current Values], then press

Enter

At the conﬁ rmation message, select [Yes] and press

Enter

15 Turn the computer off by using the power switch.

 If additional instructions are included with the computer, be sure to read them. It may be necessary to per-

form additional operations during the following procedure.

16 Perform the ﬁ rst-time operation ( page 13).

17 Start the Setup Utility and change the settings as necessary.

 To change the drive letter of hard disk or CD/DVD drive

NOTE

 Drive letters can be changed only when two or more partitions have been created on the hard disk drive.

 The name of the C: drive cannot be changed.

 Change the drive letters before installing applications.

A Click [start] - [Control Panel] - [Performance and Maintenance] - [Administrative Tools], and double-click [Com-

puter Management].

B Click [Disk Management] from [Storage].

C Right-click the hard disk partition or the CD/DVD drive name, and click [Change Drive Letter and Paths...].

D Click [Change...].

E Click [Assign the following drive letter] and the new drive letter, and then click [OK].

At the conﬁ rmation message, click [Yes].

Reinstalling Software

Troubleshooting

Error Code/Message

Follow the instructions below when an error message or code appears. If the problem persists or if the error code/mes-

sage is not shown here, contact Panasonic Technical Support ( page 32).

Error Code/Message Solution

0211 Keyboard error  Disconnect external keyboard or mouse.

0251 System CMOS

checksum bad -

Default conﬁ guration

used

An error has occurred in the memory of Setup Utility settings. This occurs when the memory

content is changed by an unexpected program operation, etc.

 Start the Setup Utility and return the settings to the default values, and then change the

settings as necessary.

 If the problem persists, the internal clock battery may need to be replaced. Contact

Panasonic Technical Support ( page 32).

0271 Check date and

time settings

The date and time settings are not correct.

 Start the Setup Utility and set the correct date and time.

 If the problem persists, the internal clock battery may need to be replaced. Contact

Panasonic Technical Support ( page 32).

0280 Previous boot

incomplete - Default

conﬁ guration used

Startup has failed repeatedly, so the Setup Utility settings have been returned to the default

values to startup the computer.

 Start the Setup Utility and return the settings to the default values, and then change the

settings as necessary.

Press <F2> to Setup  Write down the error details and press

to start the Setup Utility. Change the settings

if necessary.

0613: Serial Port*1 con-

ﬁ guration changed

0614: Serial Port*1

conﬁ g. error - device

disabled

*1 “A” or “B” appears

here to indicate the

name of the conﬂ ict-

ing port.

The I/O and IRQ settings of the serial ports are in conﬂ ict.

 Run the Setup Utility and in the [Advanced] menu, change the port’s settings so there is

no conﬂ ict.

Operating System not

found

The operating system is not installed in the ﬂ oppy disk or the hard disk that you are going to

boot from.

 If using a ﬂ oppy disk, change the disk to the one you can use for boot.

 If using the hard disk, check if the hard disk is recognized in [Information] menu of the

Setup Utility. If the hard disk is recognized, perform the reinstallation ( page 21). If not,

contact Panasonic Technical Support ( page 32).

 If a device is connected to the ExpressCard slot or the USB port, disconnect the device,

or set [ExpressCard Slot], [USB Port] or [Legacy USB Support] to [Disable] in the [Ad-

vanced] menu of the Setup Utility.

Extended RAM Module

Failed

When the extended RAM module is not inserted correctly or the extended RAM module is

not conforming to the computer’s speciﬁ cations, so a beep will sound and the “Extended

RAM Module Failed” message will be displayed when you turn the power on.

 Slide the power switch for four seconds or longer to turn off the computer, conﬁ rm that

the extended RAM module conforms to the speciﬁ cations, and reinsert it.

 To start the Setup Utility

A Restart the computer.

B Press

several times while [Panasonic] boot screen is displayed.

Troubleshooting

Troubleshooting (Basic)

Follow the instructions below when a problem has occurred. There is also an advanced troubleshooting guide in the

“Reference Manual”. For a software problem, refer to the software’s instruction manual. If the problem persists, contact

Panasonic Technical Support ( page 32). You can also check the computer’s status in the PC Information Viewer

( Reference Manual “Troubleshooting (Advanced)”).

 Starting Up

Cannot start up.

The power indicator or bat-

tery indicator is not lit.

 Connect the AC adaptor.

 Insert a fully charged battery.

 Remove the battery pack and the AC adaptor, then connect them again.

 If a device is connected to the ExpressCard slot or the USB port, disconnect the device,

or set [ExpressCard Slot], [USB Port] or [Legacy USB Support] to [Disable] in the [Ad-

vanced] menu of the Setup Utility.

The power is turned on but

“Warming up the system (up

to 30 minutes)” appears.

 The computer is warming up before start up. Wait for the computer to start up (takes

up to 30 minutes). If, “Cannot warm up the system” is displayed, the computer failed

to warm up and does not start. In this case, turn off the computer, leave it in an envi-

ronment of 5 °C {41 °F} or higher temperature for about an hour, and then turn on the

power again.

Cannot turn on the comput-

er.

The computer does not re-

sume from standby.

(The power indicator blinks

quickly in green.)

 Leave it in an environment of 5 °C {41 °F} or higher temperature for about an hour, then

turn on the power again.

You have forgotten the pass-

word.

 Supervisor Password or User Password: Contact Panasonic Technical Support ( page

32).

 Administrator password:

 If you have a password reset disk, you can reset the administrator password. Set the

disk and enter any wrong password, then follow the on-screen instructions and set a

new password.

 If you do not have a password reset disk, reinstall ( page 21) and set up Windows,

and then set a new password.

“Remove disks or other

media. Press any key to

restart” or a similar message

appears.

 A ﬂ oppy disk is in the drive and it does not contain system startup information. Remove

the ﬂ oppy disk and press any key.

 This message may appear with some devices connected to the ExpressCard slot or the

USB port. Remove the device, or set [ExpressCard Slot], [USB Port] or [Legacy USB

Support] to [Disable] in the [Advanced] menu of the Setup Utility.

 If the problem persists after removing the disk, it may be a hard disk failure. Contact

Panasonic Technical Support ( page 31).

Windows startup and opera-

tion is slow.

 Press

in the Setup Utility ( page 23 “To start the Setup Utility”) to return the Setup

Utility settings (excluding the passwords) to the default values. Start the Setup Utility

and make the settings again. (Note that the processing speed depends on the applica-

tion software, so this procedure may not make Windows faster.)

 If you installed a resident software after purchase, turn off the residence.

 Disable Indexing Service in the following menu.

Click [start] - [Search] - [Change preferences] - [Without Indexing Service]

The date and time are incor-

rect.

 Make the correct settings. Click [start] - [Control Panel] - [Date, Time, Language, and

Regional Options] - [Date and Time].

 If the problem persists, the internal clock battery may need to be replaced. Contact

Panasonic Technical Support ( page 32).

 When the computer is connected to LAN, check the date and time of the server.

 The 2100 A.D. or later year will not be correctly recognized on this computer.

[Executing Battery Recali-

bration] screen appears.

 The Battery Recalibration was canceled before Windows was shut down last time. To

start up Windows, turn off the computer by the power switch, and then turn on.

[Enter Password] does not

appear when resuming from

standby/hibernation.

 To display [Enter Password] at resuming, set the Windows password. The password you

have set in the Setup Utility is not requested at resuming.

A Click [start] - [Control Panel] - [User Accounts] and select the account, and set the

password.

B Click [start] - [Control Panel] - [Performance and Maintenance] - [Power Options] -

[Advanced] and add a check mark for [Prompt for password when computer resumes

from standby].

Troubleshooting

 Starting Up

Cannot resume.  An error may occur when the computer automatically enters the standby or hibernation

mode while the screensaver is active. In this case, turn off the screensaver or change

the pattern of the screensaver.

Other startup problems.  Press

in the Setup Utility ( page 23 “To start the Setup Utility”) to return the Setup

Utility settings (excluding the passwords) to the default values. Start the Setup Utility

and make the settings again.

 Remove all peripheral devices.

 Check to see if there was a disk error.

A Click [start] - [My Computer] and right-click [Local Disk(C:)], and click [Properties].

B Click [Tools] - [Check Now].

C Select the option in [Check disk options] and click [Start].

 Start the computer in Safe Mode and check the error details. When the [Panasonic] boot

screen disappears*1 at startup, press and hold

until the Windows Advanced Options

Menu is displayed.

*1 When [Password on boot] is set to [Enable] in the [Security] menu of the Setup Utility,

[Enter Password] appears after the [Panasonic] boot screen disappears. As soon as you

enter the password and press

Enter

, press and hold

 Entering Password

On the [Enter Password]

screen, a beep sounds and

the password cannot be

entered.

 The computer may be in ten-key mode.

If the NumLk indicator lights, press

NumLk

to disable the ten-key mode, and then

input.

Even after entering the pass-

word, [Type your password]

is displayed again.

 The computer may be in ten-key mode.

If the NumLk indicator lights, press

NumLk

to disable the ten-key mode, and then

input.

 The computer may be in Caps Lock mode.

If the Caps Lock indicator lights, press

Caps Lock

to disable the Caps Lock

mode, and then input.

 Shutting down

Windows does not shut

down.

 Remove the USB device and the ExpressCard.

 Wait one or two minutes. It is not a malfunction.

 Display

No display.  The external display is selected. Press

to switch the display. Wait until the

display has been switched completely before pressing

again.

 When using an external display,

 Check the cable connection.

 Turn on the display.

 Check the settings of external display.

 The display is turned off by the power-saving function. To resume, do not press the

direct selection keys, but press any other key like

Ctrl

 The computer entered standby or hibernation by the power-saving function. To resume,

slide the power switch.

The screen is dark.  The screen is darker when the AC adapter is not connected. Press

and adjust

the brightness. As you increase the brightness, battery consumption increases.

You can separately set the brightness for when the AC adaptor is connected and when

not connected.

The LCD brightness chang-

es a number of times when

the AC adaptor is discon-

nected.

 Intel(R) Display Power Saving Technology is active and automatically changes the LCD

brightness. This is not a malfunction.

Image colors are not repro-

duced as expected when

displaying photographs or

other images.

 Remove the check mark of [Intel(R) Display Power Saving Technology].

A Select [start] - [Control Panel] - [Other Control Panel Options] - [Intel(R) GMA Driver

for Mobile].

B Select [Display Settings] - [Power Settings].

Troubleshooting

 Display

The screen is disordered.  Changing the number of display colors and resolution may affect the screen. Restart the

computer.

 Connecting/disconnecting an external display may affect the screen. Restart the com-

puter.

 When using Simultaneous display, set the same display colors for the external display

as those for the LCD.

 When using Simultaneous display, do not press

 Enable or disable Simultaneous display, and soon restart the computer.

During Simultaneous display,

one of the screens becomes

disordered.

 When using the Extended Desktop, use the same display colors for the external display

as those used by the LCD.

 If you continue to experience problems, try changing the display by clicking [start] -

[Control Panel] - [Other Control Panel Options] - [Intel(R) GMA Driver for Mobile] - [Dis-

play Devices

]

 When the [Command Prompt] is set to “Full Screen” by pressing

Alt

Enter

, the

picture is displayed on one of the screens only. When the window display is restored by

pressing

Alt

Enter

, the picture is displayed on both screens.

 Simultaneous display cannot be used until Windows startup is complete (during Setup

Utility, etc.)

The external display does

not work normally.

 If the external display does not support the power saving function, it may not work nor-

mally when the computer enters the power saving mode. Turn off the external display.

 Touch Pad / Touchscreen (only for model with touchscreen)

The cursor does not work.  When using the external mouse, connect it correctly.

 Restart the computer using the keyboard.

(Press ,

, and

to select [Restart].)

 If the computer does not respond to keyboard commands, read “No response” ( be-

low).

Cannot input using the touch

pad.

 Set [Touch Pad] to [Enable] in the [Main] menu of the Setup Utility.

 The drivers for some mice may disable the touch pad. Check your mouse’s operating

instructions.

Cannot input using the

touchscreen.

 When mouse drivers are installed (i.e. IntelliMouse), the touchscreen does not work.

Reinstall the touchscreen driver.

Cannot point the correct

position using the included

stylus.

 Perform the touchscreen calibration ( page 14).

 Reference Manual

The Reference Manual is

not displayed.

 Install Adobe Reader.

A Log on to Windows as an administrator.

B Click [start] - [Run], input [c:\util\reader\AdbeRdr70_enu_full.exe], then click [OK].

C Follow the on-screen instructions.

Troubleshooting (Basic)

Troubleshooting

 Recover Pro

Can’t install Recover Pro  Recover Pro cannot be installed when a backup region is remaining on the hard disk.

Try one of the following methods:

 If the data in the backup region is not needed, is corrupted, or does not include com-

plete backup data:

A Access [http://www.phoenix.com/en/Customer+Services/Utilities/

Recover+Pro+6.htm#Where], and download/install “Cleanup Utility for Recover

Pro 6”.

B Delete the backup region using “Cleanup Utility for Recover Pro 6”.

C Reinstall Recover Pro.

In this case, all data in the backup region will be lost.

 If you do not need the data in the backup area, or if it is corrupted, or if does not in-

clude complete backup data:

A Follow the “Complete Restore” instructions in “Recover Pro 6” ( page 19) to re-

store the data.

 If the backup area has complete backup data and you want to restore that data:

A Reinstall the software ( page 21).

- In step 10, do not select “3. Reinstall Windows to the ﬁ rst partition.”

An unnecessary backup re-

gion is present (is left) when

Recover Pro is not installed.

A Access [http://www.phoenix.com/en/Customer+Services/Utilities/

Recover+Pro+6.htm#Where], and download/install “Cleanup Utility for Recover Pro 6”.

B Delete the backup region using “Cleanup Utility for Recover Pro 6”.

 Others

No response.  Press

Ctrl

Shift

Esc

to open Task Manager and close the software application

that is not responding.

 An input screen (e.g., password input screen at startup) may be hidden behind another

window. Press

Alt

Tab

to check.

 Slide the power switch for four seconds or longer to shut down the computer, and then

slide the power switch to turn it on. If the application program does not work normally,

uninstall and reinstall the program. To uninstall, click [start] - [Control Panel] - [Add or

Remove Programs].

Appendix

LIMITED USE LICENSE AGREEMENT

THE SOFTWARE PROGRAM(S) (“PROGRAMS”) FURNISHED WITH THIS PANASONIC® PRODUCT (“PROD-

UCT”) ARE LICENSED ONLY TO THE END-USER (“YOU”), AND MAY BE USED BY YOU ONLY IN ACCORDANCE

WITH THE LICENSE TERMS DESCRIBED BELOW. YOUR USE OF THE PROGRAMS SHALL BE CONCLUSIVELY

DEEMED TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE.

Matsushita Electric Industrial Co., Ltd. (“MEI”) has developed or otherwise obtained the Programs and hereby licenses

their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to

achieve your intended results, and for the installation, use and results obtained therefrom.

LICENSE

A. MEI hereby grants you a personal, non-transferable and non-exclusive right and license to use the Programs in

accordance with the terms and conditions stated in this Agreement. You acknowledge that you are receiving only a

LIMITED LICENSE TO USE the Programs and related documentation and that you shall obtain no title, ownership

nor any other rights in or to the Programs and related documentation nor in or to the algorithms, concepts, designs

and ideas represented by or incorporated in the Programs and related documentation, all of which title, ownership

and rights shall remain with MEI or its suppliers.

B. You may use the Programs only on the single Product which was accompanied by the Programs.

C. You and your employees and agents are required to protect the conﬁ dentiality of the Programs. You may not distrib-

ute or otherwise make the Programs or related documentation available to any third party, by time-sharing or other-

wise, without the prior written consent of MEI.

D. You may not copy or reproduce, or permit to be copied or reproduced, the Programs or related documentation for

any purpose, except that you may make one (1) copy of the Programs for backup purposes only in support of your

use of the Programs on the single Product which was accompanied by the Programs. You shall not modify, or at-

tempt to modify, the Programs.

E. You may transfer the Programs and license them to another party only in connection with your transfer of the single

Product which was accompanied by the Programs to such other party. At the time of such a transfer, you must also

transfer all copies, whether in printed or machine readable form, of every Program, and the related documentation,

to the same party or destroy any such copies not so transferred.

F. You may not remove any copyright, trademark or other notice or product identiﬁ cation from the Programs and you

must reproduce and include any such notice or product identiﬁ cation on any copy of any Program.

YOU MAY NOT REVERSE ASSEMBLE, REVERSE COMPILE, OR MECHANICALLY OR ELECTRONICALLY TRACE

THE PROGRAMS, OR ANY COPY THEREOF, IN WHOLE OR IN PART.

YOU MAY NOT USE, COPY, MODIFY, ALTER, OR TRANSFER THE PROGRAMS OR ANY COPY THEREOF, IN

WHOLE OR IN PART, EXCEPT AS EXPRESSLY PROVIDED IN THE LICENSE.

IF YOU TRANSFER POSSESSION OF ANY COPY OF ANY PROGRAM TO ANOTHER PARTY, EXCEPT AS PER-

MITTED IN PARAGRAPH E ABOVE, YOUR LICENSE IS AUTOMATICALLY TERMINATED.

TERM

This license is effective only for so long as you own or lease the Product, unless earlier terminated. You may termi-

nate this license at any time by destroying, at your expense, the Programs and related documentation together with

all copies thereof in any form. This license will also terminate effective immediately upon occurrence of the conditions

thereof set forth elsewhere in this Agreement, or if you fail to comply with any term or condition contained herein. Upon

any such termination, you agree to destroy, at your expense, the Programs and related documentation together with all

copies thereof in any form.

YOU ACKNOWLEDGE THAT YOU HAVE READ THIS AGREEMENT, UNDERSTAND IT AND AGREE TO BE BOUND

BY ITS TERMS AND CONDITIONS. YOU FURTHER AGREE THAT IT IS THE COMPLETE AND EXCLUSIVE STATE-

MENT OF THE AGREEMENT BETWEEN US, WHICH SUPERSEDES ANY PROPOSAL OR PRIOR AGREEMENT,

ORAL OR WRITTEN, AND ANY OTHER COMMUNICATIONS BETWEEN US, RELATING TO THE SUBJECT MAT-

TER OF THIS AGREEMENT.

About Intel® software products

The enclosed software products and documentation were developed at private expense, and are provided with “RE-

STRICTED RIGHTS.” Use, duplication or disclosure by the government is subject to restrictions as set forth in FAR

52.227-14 and DFARS 252.227-7013 et. seq. or its successor. The use of this product by the government constitutes

acknowledgment of Intel’s proprietary rights in the product.

Appendix

Contrat de licence d’usage limité

Le(s) logiciel(s) (les “Logiciels”) fournis avec ce produit Panasonic® (le “Produit”) sont exclusivement concédés en

licence à l’utilisateur ultime (“vous”), et ils ne peuvent être utilisés que conformément aux clauses contractuelles cides-

sous. En utilisant les logiciels, vous vous engagez de manière déﬁ nitive à respecter les termes, clauses et conditions

des présentes.

Matsushita Electric Industrial Co., Ltd. (“MEI”) a mis au point ou obtenu les Logiciels et vous en concède l’utilisation

par les présentes. Vous assumez l’entière responsabilité du choix de ce Produit (y compris des Logiciels associés)

pour obtenir les résultats escomptés, ainsi que de l’installation, de l’utilisation et des résultats obtenus.

Licence

A. MEI vous octroie par les présentes le droit et la licence personnels, non cessibles et non exclusifs d’utiliser les

Logiciels conformément aux termes, clauses et conditions de ce contrat. Vous reconnaissez ne recevoir qu’un droit

limité d’utiliser les Logiciels et la documentation les accompagnant et vous vous engagez à n’obtenir aucun droit

de titre, propriété ni aucun autre droit vis-à-vis des Logiciels et de la documentation les accompagnant ni vis-à-vis

des algorithmes, concepts, dessins, conﬁ gurations et idées représentés par ou incorporés dans les Logiciels et la

documentation les accompagnant, dont les titres, propriété et droits resteront tous à MEI ou à leurs propriétaires.

B. Vous ne pouvez utiliser les Logiciels que sur le Produit unique qui est accompagné par les Logiciels.

C. Vous et vos employés ou agents êtes requis de protéger la conﬁ dentialité des Logiciels. Vous ne pouvez ni dis-

tribuer ni mettre les Logiciels et la documentation les accompagnant à la disposition d’un tiers, par partage de

temps ou de quelque autre manière que ce soit, sans l’autorisation écrite préalable de MEI.

D. Vous ne pouvez ni copier ni reproduire ni permettre la copie ni la reproduction des Logiciels ni de la documenta-

tion les accompagnant pour quelque ﬁ n que ce soit, à l’exception d’une (1) copie des Logiciels à des ﬁ ns de sau-

vegarde uniquement pour soutenir votre utilisation des Logiciels sur le Produit unique qui est accompagné par les

Logiciels. Vous ne pouvez ni modiﬁ er ni tenter de modiﬁ er les Logiciels.

E. Vous ne pouvez céder les Logiciels et en octroyer la licence à une autre partie qu’en rapport avec votre cession du

Produit unique qui est accompagné par les Logiciels à cette autre partie. Au moment de cette cession, vous devez

céder également toutes les copies, que ce soit sous forme imprimée ou lisible par la machine, de tous les Logiciels

ainsi que de la documentation les accompagnant, à la même partie ou détruire les copies non cédées.

F. Vous ne pouvez retirer aucune marque de droits d’auteur, marque de commerce ou autre ni aucune identiﬁ cation

de produit des Logiciels et vous devez reproduire et inclure toutes ces notices ou identiﬁ cations de produit sur

toutes les copies des Logiciels.

Vous ne pouvez assembler en sens inverse, compiler en sens inverse ni retracer les Logiciels ni aucune de leurs cop-

ies, de façon électronique ou mécanique, en tout ou en partie.

Vous ne pouvez utiliser, copier, modiﬁ er, altérer ni céder les Logiciels ni aucune de leurs copies, en tout ou en partie, à

l’exception de ce qui est expressément stipulé dans ce contrat.

Si vous cédez la possession de toute copie ou de tout Logiciel à une autre partie, à l’exception de ce qui est autorisé

au paragraphe E ci-dessus, votre licence est automatiquement résiliée.

Termes, clauses et conditions

Cette licence n’est effective que pour la durée de possession ou de crédit-bail du Produit, à moins d’une résiliation an-

térieure. Vous pouvez résilier cette licence à tout moment en détruisant, à vos frais, les Logiciels et la documentation

les accompagnant avec toutes leurs copies, sous quelque forme que ce soit. Cette licence sera également résiliée,

avec application immédiate, si les conditions de résiliation déﬁ nies ailleurs dans ce contrat se sont réalisées ou si vous

ne respectez pas les termes, clauses et conditions qui y sont contenues. Au moment de la résiliation, vous acceptez

de détruire, à vos frais, les Logiciels et la documentation les accompagnant avec toutes leurs copies, sous quelque

forme que ce soit.

Vous reconnaissez avoir lu ce contrat, en avoir compris toute la substance et avoir accepté de respecter ses termes,

clauses et conditions. Vous reconnaissez en outre qu’ils sont la description complète et exclusive du contrat conclu

entre nous, contrat qui remplace et annule toute proposition ou contrat précédent, écrit ou oral, et toute autre commu-

nication entre nous, relativement à l’objet du présent contrat.

Appendix

Speciﬁ cations

This page provides the speciﬁ cations for the basic model CF-30CTQAZBM/CF-30CTQBZBM/CF-30CTQDZBM/CF-

30CTQHZBM/CF-30CTQMZBM/CF-30CWQZZBM/CF-30CAQZZBM/CF-30CTQZXBM/CF-30CTQZABM/

CF-30CTQZBBM/CF-30CTQZDBM. The model number is different according to the unit conﬁ guration.

 To check the model number:

Check the bottom of the computer or the box the computer came in at the time of purchase.

 To check CPU speed, memory size and the hard disk drive (HDD) size:

Run the Setup Utility ( Reference Manual “Setup Utility”) and select [Information] menu.

[CPU Speed]: CPU speed, [System Memory]: Memory size, [Hard Disk]: Hard disk drive size

 Main Speciﬁ cations

Model No. CF-30CTQAZBM/CF-30CTQBZBM/CF-30CTQDZBM/CF-30CTQHZBM/CF-30CTQMZBM/

CF-30CWQZZBM/CF-30CAQZZBM/CF-30CTQZXBM/CF-30CTQZABM/CF-30CTQZBBM/

CF-30CTQZDBM

CPU Intel® Core™ Duo Processor T2400 (1.66 GHz, 2 MB*1 L2 cache, 667 MHz FSB)

Chipset Intel® 945GM

Memory*1 512 MB (4096 MB Max.)

Video Memory*1*2 UMA (128 MB Max.)

Hard Disk Drive*3 80 GB

Display Method 13.3 XGA type (TFT) with Touchscreen

Internal LCD*4

65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots/1280 × 768 dots/1280 × 1024 dots)

External Display*5

Wireless LAN*6  page 31

Bluetooth*7 Version 2.0+EDR

LAN IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T

Modem Data: 56 kbps (V.92) FAX: 14.4 kbps

Sound WAVE and MIDI playback, Stereo speaker, intel® High Deﬁ nition Audio subsystem support

Security Chip TPM (TCG V1.2 compliant)*8

Card Slot PC Card Type I or Type II x 1 (3.3 V: 400 mA, 5 V: 400 mA)

ExpressCard ExpressCard/34 or ExpressCard/54 x 1

SD Memory Card*9 x 1, Data transfer rate = 8 MB per second*10

Smart Card*11 x 1

RAM Module Slot 200-pin, 1.8 V, SO-DIMM, DDR2 SDRAM, PC2-4200 Compliant

Interface USB port (4-pin, USB 2.0) x 3, Serial Port (Dsub 9-pin male), Modem port (RJ-11), LAN port

(RJ-45), External display port (Mini Dsub 15-pin female), Expansion Bus Connector (Dedicated

80-pin female), External Antenna Connector (Dedicated 50 Ω coaxial connector), IEEE 1394a

Interface Connector (4-pin x 1), Microphone Jack (Miniature jack, 3.5 DIA, Stereo), Headphone

Jack (Miniature jack, 3.5 DIA, Impedance 32 Ω, Output Power 4 mW × 2)

Keyboard / Pointing Device 87 keys / Touch Pad / Touchscreen (Anti-Reﬂ ection, Stylus (included) touch capable)

Power Supply AC adaptor or Battery pack

AC Adaptor*12 Input: 100 V to 240 V AC, 50 Hz/60 Hz, Output: 15.6 V DC, 8.0 A

Battery Pack Li-ion 11.1 V, 7.8 Ah

Operating Time*13*14 Approx. ? hours to ? hours*15 (Approx. ? hours*16)

Charging

Time*18

Power on Approx. ? hours

Clock Battery Coin type lithium battery 3.0 V

Power Consumption*17 Approx. 40 W*18 / Approx. 80 W (Maximum when recharging in the ON state)

Physical Dimensions (W × H × D)

(including the carrying handle) 302 mm × 67.5 - 69.5 mm × 285 mm {11.9" × 2.7 - 2.8" × 11.3"}

Weight

(including the carrying handle) Approx. 3.7 kg {Approx. 8.2 lb.}

Operation Environment Temperature: 5 °C to 35 °C {41 °F to 95 °F}

Humidity: 30% to 80% RH (No condensation)

Storage Environment Temperature: -20 °C to 60 °C {-4 °F to 140 °F}

Humidity: 30% to 90% RH (No condensation)

Appendix

 Main Speciﬁ cations

Operating System Microsoft® Windows® XP Professional Service Pack 2 with Advanced Security Technologies

(NTFS File System)

Utility Programs DMI Viewer, Microsoft® Windows® Media Player 10, Adobe Reader, PC Information Viewer, SD

Utility, Icon Enlarger, Loupe Utility, Intel® Matrix Storage Manager, Intel® PROSet/Wireless Soft-

ware*6 , Bluetooth™ Stack for Windows® by TOSHIBA*7 , Wireless Switch Utility, Hotkey Set-

tings, Battery Recalibration, LAN Power-Saving Utility, Inﬁ neon TPM Professional Package*19,

Recover ProTM 6*19

Setup Utility, Hard Disk Data Erase Utility*20

 Wireless LAN <Only for model with wireless LAN>

Intel PRO / Wireless 3945 ABG (802.11 a + b + g) PCI Ex. 1/4

Data Transfer Rates*21 IEEE802.11a: 54/48/36/24/18/12/9/6 Mbps (automatically switched)

IEEE802.11b: 11/5.5/2/1 Mbps (automatically switched)

IEEE802.11g: 54/48/36/24/18/12/9/6 Mbps (automatically switched)

Standards Supported IEEE802.11a/IEEE802.11b/IEEE802.11g

Transmission method OFDM system, DSSS system

Wireless Channels Used IEEE802.11a: Channels 36/40/44/48/52/56/60/64/149/153/157/161/165

IEEE802.11b/IEEE802.11g: Channels 1 to 11

RF Frequency Band IEEE802.11a: 5.18-5.32 GHz, 5.745-5.825 GHz

IEEE802.11b/IEEE802.11g: 2.412-2.462 GHz

*1 1MB = 1,048,576 bytes

*2 A segment of the main memory is allotted automatically depending on the computer’s operating status. The size of the Video

Memory cannot be set by the user.

*3 1GB = 1,000,000,000 bytes. Your operating system or some application software will report as fewer GB.

*4 A 16,777,216 color display is achieved by using the dithering function.

*5 Maximum resolution depends on the speciﬁ cations of the external display.

*6 Only for model with wireless LAN

*7 Only for model with Bluetooth

*8 For information on TPM, click [start] - [Run] and input “c:\util\drivers\tpm\README.pdf”, and refer to the Installation Manual of

“Trusted Platform Module (TPM)”.

*9 Operation has been tested and conﬁ rmed using Panasonic SD Memory Cards with a capacity of up to 2 GB.

This computer is not compatible with SDHC Memory Cards with a capacity of 4 GB or more.

The transfer rate using the SD Memory Card slot on this computer is 8 MB per second. (This is a theoretical value, and differs

from actual speeds.)

The transfer rate is 8 MB per second even if you use an SD Memory Card that supports high-speed transfer rates.

Operation on other SD equipment is not guaranteed.

This computer is not compatible with MultiMediaCards or SDHC Memory Cards.

Do not insert these kinds of cards.

*10 Theoretical value and not the actual speed. The transfer rate does not become higher even if you use a card that supports the

higher transfer rate.

*11 Only for model with Smart Card slot

*12 The AC adaptor is compatible with power sources up to 240 V AC adaptor. The computer is supplied with a 125 V AC compat-

ible AC cord. 20-M-2-1

*13 Varies depending on the usage conditions.

*14 Measured with the LAN Power-saving function’s Auto-off setting set to 1 minute.

*15 Measured using BatteryMark™ Version 4.0.1 (LCD brightness: Maximum - Minimum)

*16 Measured using MobileMark™ 2002 (LCD brightness: 60 cd/m2)

*17 Approx. 1.0 W when the battery pack is fully charged (or not being charged) and the computer is OFF.

Approx. 2.0 W when the Wake up from LAN has been enabled.

*18 Rated power consumption 23-E-1

*19 You need to install to use the feature.

*20 The Product Recovery DVD-ROM is required.

*21 These are speeds speciﬁ ed in IEEE802.11a+b+g standards. Actual speeds may differ.

Appendix

LIMITED WARRANTY

For U.S.A.

PANASONIC PERSONAL COMPUTER AND PERIPHERALS LIMITED WARRANTY

Panasonic Computer Solutions Company (referred to as “Panasonic”) will repair this product (other than software, which is covered

by a separate warranty) with new or rebuilt parts, free of charge in the U.S.A. for three (3) years from the date of original purchase

in the event of a defect in materials or workmanship. This warranty includes the AC adaptor but excludes the batteries and all other

options and accessories which are covered for a period of one (1) year from the date of purchase.

This warranty is extended solely to the original purchaser. A purchase receipt or other proof of date of original purchase will be re-

quired before warranty performance is rendered.

This warranty only covers failures due to defects in materials or workmanship which occur during normal use. It does not cover

damage which occurs in shipment or failures which are caused by products not supplied by Panasonic, or failures which result from

alteration, accident, misuse, introduction of liquid or other foreign matter into the unit, abuse, neglect, installation, maladjustment

of consumer controls, improper maintenance, modiﬁ cation or service by anyone other than a Factory Service Center or authorized

Panasonic Service Dealer, or damage that is attributable to acts of God.

THIS PRODUCT IS NOT INTENDED FOR USE AS, OR AS PART OF, NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC CON-

TROL EQUIPMENT/SYSTEMS, OR AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS*1. PANASONIC WILL NOT BE RESPONSIBLE

FOR ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES.

*1 AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class2 Electrical Flight Bag (EFB) Systems and Class1 EFB Systems

when used during critical phases of ﬂ ight (e.g., during take-off and landing) and/or mounted on to the aircraft. Class1 EFB Sys-

tems and 2 EFB Systems are deﬁ ned by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance Leaﬂ ets)

No.36

Limits and Exclusions:

There are no other express warranties except as listed below.

PANASONIC SHALL NOT BE LIABLE FOR LOSS OF DATA OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES RE-

SULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS AND

IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PUR-

POSE ARE LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE. Some states do not allow the exclusion

or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above limitations or

exclusions may not apply to you.

This limited warranty gives you speciﬁ c legal rights, and you may also have other rights which vary from state to state. If a problem

with your product develops during or after the warranty period, you may contact our representatives at 1-800-LAPTOP5. If the prob-

lem is not handled to your satisfaction, then write to the Consumer Affairs Division at the address indicated below.

SOFTWARE LIMITED WARRANTY

Panasonic Computer Solutions Company (referred to as “Panasonic”) warrants to you only that the disk(s) or other media on which

the Programs are furnished will be free from defects in materials and workmanship under normal use for a period of sixty (60) days

from the date of delivery thereof to you, as evidenced by your purchase receipt.

This is the only warranty Panasonic makes to you. Panasonic does not warrant that the functions contained in the Programs will

meet your requirements or that the operation of the Programs will be uninterrupted or error free.

Panasonic’s entire liability, and your exclusive remedy under this warranty shall be limited to the replacement, in the United States,

of any defective disk or other media which is returned to Panasonic’s Authorized Service Center, together with a copy of the pur-

chase receipt, within the aforesaid warranty period.

Anything in the foregoing to the contrary notwithstanding, Panasonic shall have no obligation for any defects in the disk(s) or other

media on which the Programs are furnished resulting from your storage thereof, or for defects that have been caused by operation

of the disk(s) or other media otherwise than on the Product or in environmental conditions other than those speciﬁ ed by Panasonic

by alteration, accident, misuse, abuse, neglect, mishandling, misapplication, installation, maladjustment of consumer controls,

improper maintenance, modiﬁ cation of damage that is attributable to acts of God. In addition, Panasonic shall have no obligation for

any defects in the disk(s) or other media if you have modiﬁ ed, or attempted to modify any Program.

DURATION OF IMPLIED WARRANTIES, IF ANY, IS LIMITED TO SIXTY (60) DAYS.

PANASONIC ASSUMES NO RISK OF AND SHALL NOT IN ANY CASE BE LIABLE FOR ANY DAMAGES, INCLUDING, WITH-

OUT LIMITATION, ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR PUNITIVE DAMAGES ARISING FROM BREACH OF

WARRANTY OR CONTRACT, NEGLIGENCE OR ANY OTHER LEGAL THEORY, INCLUDING, WITHOUT LIMITATION LOSS OF

GOODWILL, PROFITS OR REVENUE, LOSS OF USE OF THE PROGRAMS OR PRODUCTS OR ANY ASSOCIATED EQUIP-

MENT, COST OF CAPITAL, COST OF ANY SUBSTITUTE EQUIPMENT, FACILITIES, SERVICES, DOWNTIME COSTS, OR

CLAIMS OF ANY PARTY DEALING WITH YOU FOR SUCH DAMAGES.

Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied

warranty lasts, so the above limitations or exclusions may not apply to you.

This limited warranty gives you speciﬁ c legal rights, and you may also have other rights which vary from state to state.

This Limited Warranty will be governed by the laws the State of New York, without regard to its conﬂ ict-of-laws rules.

* * *

To obtain service or technical assistance within the continental U.S.A. and Alaska

DIAL TOLL FREE: 1-800-LAPTOP5

Correspondence requesting product information should be sent to:

Panasonic Computer Solutions Company

50 Meadowlands Parkway, Panazip 2F-5, Secaucus, NJ 07094

Appendix

For Canada

PANASONIC COMPUTER AND PERIPHERALS LIMITED WARRANTY

Coverage – Panasonic Canada Inc. (“PCI”) warrants to you, the ﬁ rst end user customer, this computer product (excluding software

media), when purchased from PCI or from a PCI authorized reseller, to be free from defects in materials and workmanship under

normal use, subject to the terms set forth below, during the period of warranty coverage speciﬁ ed.

Scope of Coverage Period of Coverage Type of Failure Coverage

Whole Product (except Batteries), AC adaptor and CD-

ROM (if factory installed)

Three (3) Years from Date of Origi-

nal End User Customer Purchase

Defective Materials or Workman-

ship

Batteries, CD-ROM (unless factory installed), Port Repli-

cator, Extra Memory Modules and all other Peripherals,

Options and Accessories

One (1) Year from Date of Original

End User Customer Purchase

Defective Materials or Workman-

ship

Remedy – In the event of a warranty claim, contact PCI’s representatives within the applicable warranty period, identifying the

nature of the defect claimed, at 1-800-668-8386 between 9:00 A.M. and 5:00 P.M., Eastern Time Zone, Mon. – Fri. (excluding

holidays) for instructions on how to obtain service. A purchase receipt or other proof of date of original purchase is required before

warranty service is performed. Defective parts covered by this Limited Warranty will be repaired or replaced with new or comparable

rebuilt parts on an exchange basis. Warranty replacement or repair is subject to the terms of this Limited Warranty for the balance

of the original period of warranty coverage.

No Coverage – This Limited Warranty does not cover products purchased outside Canada. Neither does it cover damage to, failure

of, or defects in a product or accessory through mishandling, improper installation, abnormal use, misuse, neglect, accident, intro-

duction of liquid or other foreign matter into the product, alteration or servicing by anyone not authorized by PCI, or act of God.

THIS PRODUCT IS NOT INTENDED FOR USE AS, OR AS PART OF, NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC CON-

TROL EQUIPMENT/SYSTEMS, OR AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS*1. PANASONIC WILL NOT BE RESPONSIBLE

FOR ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES.

*1 AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class2 Electrical Flight Bag (EFB) Systems and Class1 EFB Systems

when used during critical phases of ﬂ ight (e.g., during take-off and landing) and/or mounted on to the aircraft. Class1 EFB Sys-

tems and 2 EFB Systems are deﬁ ned by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance Leaﬂ ets)

No.36

IF YOU SHIP THE PRODUCT FOR WARRANTY SERVICE

Carefully pack the product, preferably in the original carton. Include details of defect claimed and proof of date of original pur-

chase. No liability is assumed for loss or damage to the product while in transit, if you chose your own transportation carrier.

SOFTWARE MEDIA LIMITED WARRANTY

Coverage – Panasonic Canada Inc. (“PCI”) warrants to you, the ﬁ rst end user customer, that the disk(s) or other media on which

software program(s) is/are supplied will be free from defects in materials and workmanship under normal use in Canada for a period

of sixty (60) days from date of receipt as evidenced by your purchase receipt for your Panasonic Computer product.

THIS IS THE ONLY WARRANTY THAT PCI MAKES RESPECTING THE SOFTWARE MEDIA. PCI does not warrant the software.

Please refer to the software licensor’s written warranty (accompanying the copy of the software) for any software warranty claim.

Claim Procedure – In the event of a defect in material or workmanship in the media during the sixty (60) day warranty period, and

you return it, transportation costs prepaid, to Panasonic Canada Inc., Computer Products Marketing, at the above address, within

the warranty period, together with a copy of your purchase receipt, and an explanation of the suspected defect, PCI will replace in

Canada the defective disk(s) or other media.

Remedy – PCI’s entire liability, and your only remedy for any breach of this software media warranty is limited to replacement of the

media only. It does not cover any other damages, including, but not limited to, loss of use or proﬁ t loss, or special, indirect or conse-

quential damages, or other claims, whether or not of similar character.

No Coverage – This limited warranty does not apply if the disk(s) or other media has been used in other than a Panasonic product,

or in environmental conditions other than those speciﬁ ed by PCI or the manufacturer, or if subjected to misuse, neglect, mishan-

dling, modiﬁ cation or attempted modiﬁ cation of the program, or if damaged by accident or act of God. PCI is not responsible for

damage to or loss of any program, data or removable storage media.

GENERAL

NO OTHER WARRANTIES – PCI DISCLAIMS ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT

NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH RE-

SPECT TO THE SOFTWARE, SOFTWARE MEDIA, COMPUTER PRODUCT, OPTIONS AND ACCESSORIES.

NO LIABILITY FOR CONSEQUENTIAL DAMAGES – IN NO EVENT SHALL PCI BE LIABLE FOR ANY SPECIAL, INDIRECT OR

CONSEQUENTIAL DAMAGES ARISING FROM ANY BREACH OF THE LIMITED WARRANTIES SET OUT IN THIS DOCUMENT,

OR FROM THE USE OF THE COMPUTER PRODUCT, INCLUDING, WITHOUT LIMITATION, LOSS OF DATA, BUSINESS, PROF-

IT OR GOODWILL.

IN ANY EVENT, PCI’S MAXIMUM LIABILITY FOR ANY BREACH SHALL NOT EXCEED THE AMOUNT ACTUALLY PAID BY YOU

FOR THE COMPUTER PRODUCT.

NO ACTION, REGARDLESS OF ITS BASIS, MAY BE BEGUN AGAINST PCI MORE THAN TWO (2) YEARS AFTER THE CAUSE

OF ACTION AROSE.

Statutory Warranties – Some jurisdictions do not allow these limitations or exclusions, so they may not apply to you.

MEMO

As an ENERGY STAR® Partner, Matsushita Electric Industrial Co., Ltd. has

determined that this product meets the ENERGY STAR® guidelines for energy efﬁ ciency.

Outline of the International ENERGY STAR® Ofﬁ ce Equipment Program

The international ENERGY STAR® Ofﬁ ce Equipment Program is an international program that promotes energy

saving through the use of computers and other ofﬁ ce equipment. The program backs the development and dis-

semination of products with functions that effectively reduce energy consumption. It is an open system in which

business proprietors can participate voluntarily. The targeted products are ofﬁ ce equipment such as computers,

displays, printers, facsimiles, and copiers. Their standards and logos are uniform among participating nations.

22-E-1

Panasonic Computer Solutions Company

3 Panasonic Way, Panazip 2F-5,

Secaucus, NJ 07094

Panasonic Canada Inc.

5770 Ambler Drive Mississauga,

Ontario L4W 2T3

Printed in Japan

HS0906-0

DFQX5622ZA

Panasonic of North America 9TGCF-303 Notebook w/ Cellular/PCS GSM/EDGE/WCDMA, WLAN & BT User Manual CF 30CTQZZBM indb

Panasonic Corporation of North America Notebook w/ Cellular/PCS GSM/EDGE/WCDMA, WLAN & BT CF 30CTQZZBM indb

Contents

Users Manual

Navigation menu

Namespaces

Views

Navigation
