Panasonic of North America 9TGRI12B RFID Module User Manual
Panasonic Corporation of North America RFID Module
User Manual
RFID: RI12B
User Manual
1 GENERAL
1-1 Purpose and Scope of this document
This document contains the specifications pertinent to the module for 13.56MHz
RFID.
Items Specification
RFID reader RF frequency: 13.56 MHz
TYPE-A and B ISO14443
Operation
Environment
Temperature: -10 ～ 50°C {14 °F to 122°F}
Humidity: 30% to 80% RH (No condensation)
Storage
Environment
Temperature: –20 °C to 60 °C {–4 °F to 140 °F}
Humidity: 30% to 90% RH (No condensation)
Regulatory Information
USA-Federal Communications Commission (FCC)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Caution
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Labeling
System integrators must include labeling on the end product as “Contains FCC
ID: ACJ9TGRI12B”.
Instructions to OEM Integrators
A User manual provided to the end user must indicate the operating
requirements and conditions that must be observed to ensure compliance with
the FCC guidelines.
Canada-Industry Canada (IC)
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
Labeling
System integrators must include labeling on the end product as “Contains IC:
216A-CFRI12B”
Instructions to OEM Integrators
A User manual provided to the end user must indicate the operating
requirements and conditions that must be observed to ensure compliance with
the IC guidelines.
Important Notice
Panasonic will not sell radio modules to any third party; and will not allow
aftermarket installation by any third party or end user. Instead, they will only be
installed within Panasonic Notebooks, Laptops, Tablets and Ultra Mobile
Toughbook PCs. Panasonic confirms that the provided operating instruction to
user will not include any instructions how to add or remove any of the transmitter
modules.
