Panasonic of North America 9TGWL15B Wireless Network Adapter User Manual Manual
Panasonic Corporation of North America Wireless Network Adapter Manual
Contents
User Manual
Refer to the OPERATING INSTRUCTIONS - Basic Guide by downloading from the following URL.
URL http://pc-dl.panasonic.co.jp/itn/manual/menu_en.html
Terms and illustrations in these instructions
CAUTION : Conditions that may result in minor or moderate injury.
NOTE : Useful and helpful information.
: Page in these Operating Instructions.
: Reference to the on-screen manuals.
Contents
OPERATING INSTRUCTIONS
Read Me First
Tablet Computer
Model No. FZ-A2 series
Please read these instructions carefully before using this product, and save this manual for future use.
Getting Started Read Me First
Getting Started
First-time Operation .....................................18
Read Me First
Safety Precautions .........................................2
Regulatory Information ...................................8
2
Read Me First
Safety Precautions
To reduce the risk of injury, loss of life, elec-
tric shock, fi re, malfunction, and damage to
equipment or property, always observe the
following safety precautions.
Explanation of symbol word panels
The following symbol word panels are used
to classify and describe the level of hazard,
injury, and property damage caused when the
denotation is disregarded and improper use is
performed.
DANGER
Denotes a potential hazard that will result in
serious injury or death.
WARNING
Denotes a potential hazard that could result
in serious injury or death.
CAUTION
Denotes a hazard that could result in minor
injury.
NOTICE
Denotes a hazard that could result in prop-
erty damage.
The following symbols are used to classify
and describe the type of instructions to be
observed.
This symbol is used to alert users to
a specifi c operating procedure that
must not be performed.
This symbol is used to alert users to
a specifi c operating procedure that
must be followed in order to operate
the unit safety.
DANGER
Precautions on the Battery Pack
Electrolyte leakage, generation of heat,
ignition or rupture of the Battery Pack
may result.
Do Not Throw the Battery Pack
into a Fire or Expose It to Exces-
sive Heat
Do Not Deform, Disassemble, or
Modify the Battery Pack
Do Not Short the Positive (+) and
Negative (-) Contacts
Do not place the battery pack
together with articles such as
necklaces or hairpins when carry-
ing or storing.
Do Not Apply Shocks to the
Product by Dropping It, Applying
Strong Pressure to It, etc.
If this product is subjected to
a strong impact, damaged or
deformed, stop using it immedi-
ately.
Do Not Charge the Battery Us-
ing Methods Other Than Those
Specifi ed
Do Not Use the Battery Pack with
Any Other Product
• The battery pack is rechargeable
and was intended for the specifi ed
product.
Do Not Use This Product with a
Battery Pack Other Than the One
Specifi ed
Use only the specifi ed battery
pack with your product.
Do Not Use Battery Pack If Wet
When the Battery Pack Has Dete-
riorated or If Abnormal Swelling
Occur, Replace It with New One
Do not continue to use a dam-
aged battery pack.
Avoid Extreme Heat (Near the
Fire, in Direct Sunlight, for Ex-
ample)
3
Read Me First
DANGER
Precautions on the Built-in Bridge
Battery (for disposal)
<Only for model with Built-in Bridge Bat-
tery>
When disposing the battery, generation
of heat, ignition or rupture of the Built-in
Bridge Battery may result. ( Operating
Instructions - Basic Guide)
Handling This Computer
Do Not Disassemble the Com-
puter Except When Disposing
Handling the Built-in Bridge Bat-
tery
Do Not Short the Positive (+) and
Negative (-) Contacts
Do Not Throw the Battery into
a Fire or Expose It to Excessive
Heat
Do Not Apply Shocks to the Built-
in Bridge Battery by Dropping It,
Applying Strong Pressure to It,
etc.
Do Not Charge
Do Not Use
Do Not Deform, Disassemble, or
Modify the Built-in Bridge Battery
Pack
Avoid Extreme Heat (Near the
Fire, in Direct Sunlight, for Ex-
ample)
WARNING
<Only for model with Built-in Bridge Bat-
tery>
Generation of heat, ignition or rupture of
the Built-in Bridge Battery may result.
Do Not Throw This Product Into
a Fire or Expose It to Excessive
Heat
Do Not Insert Sharp Objects Into
This Product, Disassemble, or
Modify It
Do Not Apply Shocks to the
Product by Dropping It, Applying
Strong Pressure to It, etc.
Do Not Charge the Built-in Bridge
Battery Pack Using Methods
Other Than Those Specifi ed
Avoid Extreme Heat (Near the
Fire, In Direct Sunlight, for Ex-
ample)
When the Built-in Bridge Battery
Pack Has Deteriorated or If Ab-
normal Swelling Occur, Contact
Your Technical Support Office to
Replace the Battery
4
Read Me First
Safety Precautions
WARNING
Fire or electric shock may result.
Do Not Do Anything That May
Damage the AC Cord, the AC
Plug, or the AC Adaptor
Do not damage or modify the
cord, place it near hot tools,
bend, twist, or pull it forcefully,
place heavy objects on it, or
bundle it tightly.
Do not continue to use a dam-
aged AC cord, AC plug and AC
adaptor.
• Contact your technical support
offi ce for repair.
Do Not Connect the AC Adaptor
to a Power Source Other Than a
Standard Household AC Outlet
Connecting to a DC/AC con-
verter (inverter) may damage the
AC adaptor. On an airplane, only
connect the AC adaptor/charger
to an AC outlet specifi cally ap-
proved for such use.
Do Not Pull or Insert the AC Plug
If Your Hands Are Wet
Do Not Disassemble This Prod-
uct
Do Not Touch This Product In
a Thunderstorm If Connected
with the AC Cable or Any Other
Cables
If a Malfunction or Trouble Oc-
curs, Immediately Stop Use
If the Following Malfunction Oc-
curs, Immediately Unplug the
AC Plug and the Battery Pack
• This product is damaged
• Foreign object inside this prod-
uct
• Smoke emitted
• Unusual smell emitted
• Unusually hot
After the above procedure, con-
tact your technical support offi ce
for repair.
Clean Dust and Other Debris of the
AC Plug Regularly
• If dust or other debris accumu-
lates on the plug, humidity, etc.
may cause a defect in the insula-
tion.
Insert the AC Plug Completely
Do not use a damaged plug or
loose AC outlet.
Close the Connector Cover
Tightly When Using This Prod-
uct Wherever There is a Lot of
Water, Moisture, Steam, Dust,
Oily Vapors, etc.
If foreign matter has found its
way inside, immediately turn
the power off and unplug the
AC cord, and then remove the
battery pack. Then contact your
technical support offi ce.
5
Read Me First
WARNING
Burns or low-temperature burns may
result.
Do Not Use This Product in Close
Contact With Your Body For a
Long Period of Time
Do not use this product with
its heat-emitting parts in close
contact with your body for long
periods of time.
• Low-temperature burns may re-
sult.
Do Not Touch The Surface of The
AC Adaptor Continuously While
Using/Charging
• Burns may result.
Do Not Place the Product in a
Bag or Case While It is Turned
On
• Doing so may cause the product
to overheat and result in burns.
Detrimental health effects on your body
may result.
Do Not Turn the Volume Up To
Loud When Using Headphones
• Listening at high volumes that
overstimulate the ear for long
periods of time may result in loss
of hearing.
CAUTION
Fire or electric shock may result.
Do Not Move This Product While
the AC Plug Is Connected
If the AC cord is damaged, un-
plug the AC plug immediately.
Do Not Subject the AC Adaptor
To Any Strong Impact
Do not continue to use the AC
adaptor after a strong impact
such as being dropped.
Contact your technical support
offi ce for repair.
Do Not Leave This Product in
High Temperature Environment
for a Long Period of Time
• Leaving this product where it will
be exposed to extremely high
temperatures such as near fi re or
in direct sunlight may deform the
cabinet and/or cause trouble in
the internal parts.
Hold the Plug When Unplugging
the AC Plug
Use Only the Specified AC Adap-
tor With This Product
Do not use an AC adaptor other
than the one supplied (supplied
with the unit or one sold sepa-
rately as an accessory).
This product may fall over or drop, result-
ing in an injury.
Do Not Place This Product on
Unstable Surfaces
Avoid Stacking
Detrimental health effects on your body
may result.
Take a Break Of 10-15 Minutes
Every Hour
• Using this product for long peri-
ods of time may have detrimen-
tal health effects on the eyes or
hands.
6
Read Me First
Safety Precautions
CAUTION
Burns, low-temperature burns, or frost-
bite may result.
Do Not Expose the Skin To This
Product When Using the Product
In A Hot Or Cold Environment
When it is necessary to expose
the skin to this product such as
to scan a fi ngerprint, perform the
operation in the shortest time
possible.
NOTICE
Do not place the computer near a televi-
sion or radio receiver.
Keep the computer away from magnets.
Data stored on the fl ash memory may be
lost.
This computer is not intended for the dis-
play of images for use in medical diagno-
sis.
This computer is not intended for a use
with connection of medical equipment for
the purpose of medical diagnosis.
Panasonic shall not be liable for loss of
data or other incidental or consequential
damages resulting from the use of this
product.
Do not touch the terminals on the battery
pack. The battery pack may no longer
function properly if the contacts are dirty or
damaged.
Do not expose the battery pack to water,
or allow it to become wet.
If the battery pack will not be used for a
long period of time (a month or more),
charge or discharge (use) the battery pack
until the remaining battery level becomes
30% to 40% and store it in a cool, dry
place.
This computer prevents overcharging of
the battery by recharging only when the
remaining power is less than approx. 95%
of capacity.
The battery pack is not charged when the
computer is fi rst purchased. Be sure to
charge it before using it for the fi rst time.
When the AC adaptor is connected to the
computer, charging begins automatically.
Should the battery leak and the fl uid get
into your eyes, do not rub your eyes. Im-
mediately fl ush your eyes with clear water
and see a doctor for medical treatment as
soon as possible.
7
Read Me First
NOTE
The battery pack may become warm dur-
ing recharging or normal use. This is com-
pletely normal.
Recharging will not commence if internal
temperature of the battery pack is outside
of the allowable temperature range (0 °C
to 50 °C {32 °F to 122 °F}). ( Operat-
ing Instructions - Reference Manual “Bat-
tery Power”) Once the allowable range
requirement is satisfi ed, charging begins
automatically. Note that the recharging
time varies based on the usage conditions.
(Recharging takes longer than usual when
the temperature is 10 °C {50 °F} or below.)
If the temperature is low, the operating
time is shortened. Only use the computer
within the allowable temperature range.
This computer has a high temperature
mode function that prevents the degrada-
tion of the battery in high temperature envi-
ronments. ( Operating Instructions -
Reference Manual “Battery Power”) A level
corresponding to a 100% charge for high
temperature mode is approximately equiv-
alent to an 80% charge level for normal
temperature mode.
The battery pack is a consumable item.
If the amount of time the computer can
be run by using a particular battery pack
becomes dramatically shorter and re-
peated recharging does not restore its
performance, the battery pack should be
replaced with a new one.
When transporting a spare battery inside a
package, briefcase, etc., it is recommend-
ed that it be placed in a plastic bag so that
its contacts are protected.
Always power off the computer when it is
not in use. Leaving the computer on when
the AC adaptor is not connected will ex-
haust the remaining battery capacity.
<Only for model with Built-in Bridge Bat-
tery>
To minimize deterioration of the built-in
bridge battery, connect the computer to the
AC adaptor and recharge it for approxi-
mately 2 hours about once every year.
THIS PRODUCT IS NOT INTENDED FOR
USE AS, OR AS PART OF, NUCLEAR
EQUIPMENT/SYSTEMS, AIR TRAFFIC
CONTROL EQUIPMENT/SYSTEMS, AIR-
CRAFT COCKPIT EQUIPMENT/SYSTEMS*1,
MEDICAL DEVICES OR ACCESSORIES*2,
LIFE SUPPORT SYSTEMS OR OTHER
EQUIPMENTS/DEVICES/SYSTEMS THAT
ARE INVOLVED WITH ENSURING HUMAN
LIFE OR SAFETY.
PANASONIC WILL NOT BE RESPONSIBLE
FOR ANY LIABILITY RESULTING FROM
THE USE OF THIS PRODUCT ARISING
OUT OF THE FOREGOING USES.
*1 AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS
include Class2 Electronic Flight Bag (EFB) Sys-
tems and Class1 EFB Systems when used dur-
ing critical phases of flight (e.g., during take-off
and landing) and/or mounted on to the aircraft.
Class1 EFB Systems and 2 EFB Systems are
defined by FAA: AC (Advisory Circular) 120-
76A or JAA: JAA TGL (Temporary Guidance
Leaflets) No.36.
*2 As defined by the European Medical Device
Directive (MDD) 93/42/EEC.
Panasonic cannot guarantee any specifi ca-
tions, technologies, reliability, safety (e.g.
Flammability/Smoke/Toxicity/Radio Fre-
quency Emission, etc) requirements related
to aviation standards that exceed the speci-
fi cations of our COTS (Commercial-Off-The-
Shelf) products.
This computer is not intended for use in medi-
cal equipment including life-support systems,
air traffi c control systems, or other equip-
ment, devices or systems that are involved
with ensuring human life or safety. Panasonic
cannot be held responsible in any way for any
damages or loss resulting from the use of this
unit in these types of equipment, devices or
systems, etc.
This computer has been designed so as to
minimize shock to the LCD and fl ash memory
drive, etc., but no warranty is provided against
such trouble. Therefore, as a precision instru-
ment, be extremely careful in the handling.
8
Read Me First
This product and your Health
This product, like other radio devices, emits
radio frequency electromagnetic energy. The
level of energy emitted by this product how-
ever is far much less than the electromagnetic
energy emitted by wireless devices like for
example mobile phones.
Because this product operates within the
guidelines found in radio frequency safety
standards and recommendations, we be-
lieve this product is safe for use by consum-
ers. These standards and recommendations
refl ect the consensus of the scientifi c com-
munity and result from deliberations of panels
and committees of scientists who continually
review and interpret the extensive research
literature.
In some situations or environments, the use
of this product may be restricted by the propri-
etor of the building or responsible represen-
tatives of the organization. These situations
may for example include:
Using this product on board of airplanes,
or
In any other environment where the risk of
interference to other devices or services is
perceived or identifi ed as harmful.
If you are uncertain of the policy that applies
on the use of wireless devices in a specifi c or-
ganization or environment (e.g. airports), you
are encouraged to ask for authorization to use
this product prior to turning on the product.
Regulatory Information
We are not responsible for any radio or tele-
vision interference caused by unauthorized
modifi cation of this product. The correction
of interference caused by such unauthorized
modifi cation will be the responsibility of the
user. We and its authorized resellers or dis-
tributors are not liable for damage or violation
of government regulations that may arise from
failing to comply with these guidelines.
26-M-1
Ce produit et votre santé
Ce produit, comme tout autre appareil radio,
émet de l’énergie radioélectrique. Toutefois,
la quantité d’énergie émise par ce produit est
beaucoup moins importante que l’énergie ra-
dioélectrique émise par des appareils sans fi l
tels que les téléphones portables. L’utilisation
de ce produit ne comporte aucun risque pour
le consommateur du fait que cet appareil
opère dans les limites des directives concer-
nant les normes et les recommendations de
sécurité sur les fréquences radio. Ces normes
et recommandations refl ètent le consensus de
la communauté scientifi que et résultent de dé-
libérations de jurys et comités de scientifi ques
qui examinent et interprètent continuellement
les nouveautés de la vaste littérature sur les
recherches effectuées. Dans certaines situ-
ations ou environnements, l’utilisation de ce
produit peut être restreinte par le propriétaire
du bâtiment ou par les représentants respon-
sables de l’organisation. Ces situations peu-
vent être les suivantes par exemple :
A bord d’un avion, ou
Dans tout autre environnement où les
risques d’interférence sur d’autres appa-
reils ou services sont perçus ou identi-
fi ables comme dangereux.
Si vous n’êtes pas sûr de la réglementation
applicable à l’utilisation d’appareils sans fi l
dans une organization ou un environnement
spécifi que, (par exemple dans un aéroport)
nous vous invitons à demander l’autorisation
d’utiliser ce produit avant sa mise en marche.
Informations concernant la réglementation
Nous déclinons toute responsabilité pour
toute interférence radio ou télévision causée
par des modifi cations non autorisées appor-
tées à ce produit. La correction d’interférences
causées par de telles modifi cations non auto-
risées sera la seule responsabilité de son util-
isateur. Nousmêmes, les revendeurs offi ciels
et les distributeurs ne sommes pas respon-
sable de tout dégât ou de toute violation des
règlements de l’État pouvant découler du non-
respect de ces directives.
26-F-1
Information to the User / Informations destinées aux utilisateurs
Regulatory Information
9
Read Me First
Lithium Battery / Pile au lithium
Lithium Battery!
This computer contains a lithium battery to
enable the date, time, and other data to be
stored. The battery should only be exchanged
by authorized service personnel.
Warning!
A risk of explosion from incorrect installation
or misapplication may possibly occur. 15-E-1
Pile au lithium!
Le micro-ordinateur renferme une pile au
lithium qui permet de sauvegarder certaines
données, notamment la date et l’heure. La
pile ne doit être remplacée que par un techni-
cien qualifi é.
Danger !
Risque d’explosion en cas de non respect de
cette mise en garde! 15-F-1
About Battery Pack
Battery pack model number CF-VZSU0Q Series
Recommended charging condition 13.05 V / 1820 mA (Constant voltage/current)
Notice - Dispose of used battery pack according to local ordi-
nances and/or regulations.
- Do not expose this computer to temperatures greater
than 60 °C {140 °F}.
Safety Precautions
<Only for model with wireless WAN>
The following safety precautions must be observed during all phases of the operation, usage, ser-
vice or repair of any Personal Computer or Tablet Computer incorporating wireless WAN modem.
Manufacturers of the cellular terminal are advised to convey the following safety information to
users and operating personnel and to incorporate these guidelines into all manuals supplied with
the product. Failure to comply with these precautions violates safety standards of design, manu-
facture and intended use of the product. Panasonic assumes no liability for customer failure to
comply with these precautions.
When in a hospital or other health care facility, observe the restrictions on the use of mo-
biles. Switch Personal Computer or Tablet Computer incorporating wireless WAN modem
off, if instructed to do so by the guidelines posted in sensitive areas. Medical equipment
may be sensitive to RF energy.
The operation of cardiac pacemakers, other implanted medical equipment and hearing
aids can be affected by interference from Personal Computer or Tablet Computer incorpo-
rating wireless WAN modem placed close to the device. If in doubt about potential dan-
ger, contact the physician or the manufacturer of the device to verify that the equipment
is properly shielded. Pacemaker patients are advised to keep their Personal Computer or
Tablet Computer incorporating wireless WAN modem away from the pacemaker, while it is
on.
Switch off Personal Computer or Tablet Computer incorporating wireless WAN modem
before boarding an aircraft. Make sure it cannot be switched on inadvertently. The opera-
tion of wireless appliances in an aircraft is forbidden to prevent interference with com-
munications systems. Failure to observe these instructions may lead to the suspension or
denial of cellular services to the offender, legal action, or both.
For details on usage of this unit in aircrafts please consult and follow instruction provided
by the airline.
10
Read Me First
Regulatory Information
Do not operate Personal Computer or Tablet Computer incorporating wireless WAN mo-
dem in the presence of fl ammable gases or fumes. Switch off the cellular terminal when
you are near petrol stations, fuel depots, chemical plants or where blasting operations are
in progress. Operation of any electrical equipment in potentially explosive atmospheres
can constitute a safety hazard.
Your Personal Computer or Tablet Computer incorporating wireless WAN modem receives
and transmits radio frequency energy while switched on. Remember that interference can
occur if it is used close to TV sets, radios, computers or inadequately shielded equipment.
Follow any special regulations and always switch off Personal Computer or Tablet Com-
puter incorporating wireless WAN modem wherever forbidden, or when you suspect that it
may cause interference or danger.
Road safety comes fi rst! Do not use a Personal Computer or Tablet Computer incorporat-
ing wireless WAN modem while driving a vehicle. Do not place the computer with wireless
WAN modem in an area where it could cause personal injury to the driver or passengers.
It is recommended to stow the unit in the boot or secure stowage area while driving.
Do not place the computer with wireless WAN modem in an area over an air bag or in the
vicinity where an air bag may deploy.
Air bags infl ate with great force and if the computer with wireless WAN modem is placed
in the air bag deployment area may be propelled with great force and cause serious injury
to occupants of the vehicle.
IMPORTANT!
Personal Computer or Tablet Computer incorporating wireless WAN modem operate us-
ing radio signals and cellular networks cannot be guaranteed to connect in all conditions.
Therefore, you should never rely solely upon any wireless device for essential communi-
cations, for example emergency calls.
Remember, in order to make or receive calls, Personal Computer or Tablet Computer
incorporating wireless WAN modem must be switched on and in a service area with ad-
equate cellular signal strength.
Some networks do not allow for emergency calls if certain network services or phone fea-
tures are in use (e.g. lock functions, fi xed dialing etc.). You may need to deactivate those
features before you can make an emergency call.
Some networks require that a valid SIM card be properly inserted in Personal Computer
or Tablet Computer incorporating wireless WAN modem.
CAUTION:
Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
58-E-1
ATTENTION:
Il y a risque d’explosion si la batterie est remplacée par une batterie de type incorrect.
Mettre au rebut les batteries usagées conformément aux instructions.
58-F-1
Camera Light
<For model with rear camera>
CAUTION
- The light from the LED is strong and can injure human eyes. Do not look directly at the LEDs
with naked eyes.
- User must maintain minimum 248 mm spacing between the LED and all person’s eyes.
57-E-1
11
Read Me First
Laser Devices
<Only for model with Barcode Reader>
This equipment is using lasers that comply with
US21CFR1040.10, 1040.11, EN 60825-1:2007 and IEC60825-1:2007 regulations.
The laser is a “Class 2” laser which is indicated on the label for this product.”
Class 2 laser readers use a low power, visible light diode. As with any very bright light source,
such as the sun, the user should avoid staring directly into the light beam.
Momentary exposure to a Class 2 laser is not known to be harmful.
Caution-Procedures other than those specifi ed herein may result in hazardous radiation expo-
sure.
630 - 680 nm, 1 mW MAX.
Labeling/Marking
Location of aperture
Beam Divergence
- Vertical angle: 30 degree
- Horizontal angle: 36 degree
13-E-1
The other product information
The other product information are indicated the label located under the Battery Pack.
12
Read Me First
Regulatory Information
Energy Star
As an ENERGY STAR® Partner, Panasonic Corporation has determined that this
product meets ENERGY STAR® guidelines for energy effi ciency. By enabling avail-
able power management settings, Panasonic computers enter a low-power sleep
mode after a period of inactivity, saving the user energy.
<For U.S.A.>
To learn more about power management, please visit the web site:
www.energystar.gov/index.cfm?c=power_mgt.pr_power_management
Outline of the International ENERGY STAR® Offi ce Equipment Program
The international ENERGY STAR® Offi ce Equipment Program is an international
program that promotes energy saving through the use of computers and other offi ce
equipment. The program backs the development and dissemination of products with
functions that effectively reduce energy consumption. It is an open system in which
business proprietors can participate voluntarily. The targeted products are offi ce
equipment such as computers, displays, printers, facsimiles, and copiers. Their stan-
dards and logos are uniform among participating nations.
<For U.S.A.>
For information about ENERGY STAR®, refer to the following web site:
Web Site: www.energystar.gov
22-M-1
13
Read Me First
For U.S.A.
Federal Communications Commission
Radio Frequency Interference Statement
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful in-
terference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio com-
munications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television re-
ception, which can be determined by turning
the equipment off and on, the user is encour-
aged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
Consult the Panasonic Service Center or
an experienced radio/TV technician for
help.
Warning
To assure continued compliance, use only
shielded interface cables when connecting to
a computer or peripheral. Also, any changes
or modifi cations not expressly approved by
the party responsible for compliance could
void the user’s authority to operate this equip-
ment.
FCC RF Exposure Warning:
This equipment is provided with PC Card
slot that could be used with wireless trans-
mitters, which will be specifi cally recom-
mended when they become available.
Other third-party wireless transmitters
have not been RF exposure evaluated for
use with this computer and may not com-
ply with FCC RF exposure requirements.
This equipment complies with FCC radia-
tion exposure limits set forth for an uncon-
trolled environment.
This equipment may not be collocated or op-
erated with any other antenna or transmitter.
This device meets the government’s re-
quirements for exposure to radio waves.
This device is designed and manufactured
not to exceed the emission limits for expo-
sure to radio frequency (RF) energy set by
the Federal Communications Commission
of the U.S. Government.
The exposure standard for wireless device
employs a unit of measurement known as
the Specifi c Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6 W/kg.
* Tests for SAR are conducted using stan-
dard operating positions accepted by the
FCC with the device transmitting at its
highest certifi ed power level in all tested
frequency bands.
Although the SAR is determined at the
highest certifi ed power level, the actual
SAR level of the device while operating
can be well below the maximum value.
This is because the device is designed
to operate at multiple power levels so as
to use only the poser required to reach
the network. In general, the closer you
are to a wireless base station antenna,
the lower the power output.
25-M-W-1
.
14
Read Me First
Regulatory Information
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful inter-
ference, and
(2)
This device must accept any interference re-
ceived, including interference that may cause
undesired operation.
Responsible Party:
Panasonic Corporation of North America
Two Riverfront Plaza
Newark, NJ 07102
Support Contact:
http://business.panasonic.com/support-computerstablets
6-M-1
FCC RF Exposure Warning:
This PC contains:
Model: WL15B
FCC ID: ACJ9TGWL15B
USA Only: Disposal may be regulated in your
community due to environmental consider-
ations. For disposal or recycling information,
please visit Panasonic website:
http://www.panasonic.com/environmental
or call 1-888-769-0149 65-M-2
<For USA-California Only>
This product contains a CR Coin Cell Lithium
Battery which contains Perchlorate Material -
special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate/
38-M-1
<For USA and Canada>
A lithium ion battery that is
recyclable powers the prod-
uct you have purchased.
Please call 1-800-8-BAT-
TERY for information on
how to recycle this battery.
L’appareil que vous vous
êtes procuré est alimenté
par une batterie au lithium-
ion.
Pour des renseignements
sur le recyclage de la batte-
rie, veuillez composer le
1-800-8-BATTERY.
48-M-1
15
Read Me First
For Canada / Pour le Canada
Canadian ICES-003
CAN ICES-3(B) / NMB-3(B)
7-M-3
Industry Canada
This product complies with RSSs.
Operation is subject to the following two
con-ditions;
(1) this device may not cause interference,
and
(2) this device must accept any interference,
including interference that may cause un-
desired operation of the device.
Industrie Canada
Cet équipement est conforme à la norme
CNR d’Industrie Canada. Son fonc-
tionnement est soumis aux deux conditions
suivantes :
(1) ce dispositif ne peut produire de brouillage,
et
(2) ce dispositif doit accepter le brouillage, y
compris le brouillage pouvant entraîner le
fonctionnement non désiré de l’appareil.
30-Ca-1-1
Avertissement
(i) Cet appareil (pour réseaux locaux
radioélectriques) dans les bandes de fréquences
5150-5250 MHz est réervéàune utilisation
àl’intéieur afi n de réuire le risque d’interféence
avec les systèmes satellites mobiles bicanaux.
(ii)Le gain maximal d’antenne permis pour les
dispositifs utilisant les bandes 5250-5350 MHz
et 5470-5725 MHz doit se conformer à la limite
de p.i.r.e.;
(iii)Le gain maximal d’antenne permis (pour les
dispositifs utilisant la bande 5725-5825 MHz)
doit se conformer à la limite de p.i.r.e. spécifiée
pour l’exploitation point à point et non point à
point, selon le cas.
(iv)Les pires angles d’inclinaison nécessaires
pour rester conforme à l’exigence de la p.i.r.e.
applicable au masque d’élévation, et énoncée à
la section 6.2.2 3), doivent être clairement
indiqués.
Les radars forte puissance sont désignés
comme étant les premiers utilisateurs (c’st-à-dire
qu’ls ont la prio-rité) des bandes de fréquences
5250-5350 MHz et 5650-5850 MHz. Ces stations
radars peuvent provoquer des interférences et/
ou des dommages à ce périphérique.
Cet appareil et son antenne ne doivent pas être
situés ou fonctionner en conjonction avec une
autre antenne ou un autre émetteur, exception
faites des radios intégrées qui ont été testées.
La fonction de sélectio
Caution
(i) This product (local network devices) for the
band 5150-5250 MHz is only indoor usage to
reduce potential for harmful interference to co-
channel Mobile Satellite systems.
(ii) The maximum antenna gain permitted for
devices in the bands 5250-5350 MHz and
5470-5725 MHz shall comply with the e.i.r.p.
limit;
(iii) The maximum antenna gain permitted for
devices in the band 5725-5825 MHz shall
comply with the e.i.r.p. limits specified for point-
to-point and non point-to-point operation as
appropriate.
(iv) The worst-case tilt angle(s) necessary to
remain compliant with the e.i.r.p. elevation mask
requirement set forth in Section 6.2.2(3) shall be
clearly indicated.
Users should also be advised that high-power
radars are allocated as primary users (meaning
they have priority) of 5250-5350 MHz and 5650-
5850 MHz and these radars could cause
interference and/or damage
to LELAN devices.
This device and its antenna(s) must not be co-
located or operating in conjunction with any other
antenna or transmitter, except tested built-in
radios.
The County Code Selection feature is disabled
for products marketed in the US/ Canada.
16
Read Me First
Regulatory Information
FOR USE WITH MODEL NO. :
CF-AA6413C
POUR UTILISER AVEC MODÈLE :
CF-AA6413C 20-Ca-1
For U.S.A and Canada
For Used in Motor Vehicle / Pour L’utilisation Dans Un Véhicule Motorisé
Warning: Notebook Computer may be installed in a motor vehicle and visible to the driver only if
used to support vehicle related functions such as vehicle information, system control, rear or side
observation and navigation. If used for entertainment purpose, such as television reception or
video play, it must be installed to the rear of the driver’s seat where it will not be visible, directly or
indirectly, to the operator of the motor vehicle. Check with individual state/provincial laws to deter-
mine lawful use of this product while operating within a motor vehicle.
Avertissement : L’ordinateur bloc-notes peut être installé dans un véhicule motorisé et dans le
champ de vision du conducteur uniquement en tant que dispositif d’aide aux fonctions du vé-
hicule, comme par exemple pour fournir des informations sur le véhicule, comme dispositif de
contrôle de système, pour l’observation à l’arrière ou sur les côtés du véhicule, ainsi que pour
fournir de l’information routière. Pour toute utilisation à fi n de divertissement, comme par exemple
pour regarder la télévision ou jouer à des jeux vidéo, il doit être installé à l’arrière du siège du
conducteur, en un emplacement où il ne sera pas visible, ni directement ni indirectement, pour le
conducteur du véhicule motorisé. Vérifi ez les lois fédérales et nationales qui régissent l’utilisation
légale de cet appareil à l’intérieur d’un véhicule motorisé.
35-M-1
For Australia
For Used in Motor Vehicle
Warning: Notebook Computer may be installed in a motor vehicle and visible to the driver only if
used to support vehicle related functions such as vehicle information, system control, rear or side
observation and navigation. If the Notebook Computer is to be used for work or entertainment
purposes, such as television reception, video play or other work programs, it must be installed in
a position where it will NOT:
(a) be visible, directly or indirectly, to the operator of the motor vehicle; or
(b) cause distraction to drivers of other motor vehicles.
Check with individual state laws to determine lawful use of this product while operating within a
motor vehicle. If the visual display unit is, or is part of, a driver’s aid, above rule is not applied.
“Driver’s aid” includes closed-circuit television security cameras, dispatch systems, navigational
or intelligent highway and vehicle system equipment, rear view screens, ticket-issuing machines
and vehicle monitoring devices.
35-A-1
17
Read Me First
For India
Declaration of Conformity with the requirements of the e-waste (Management and Handling)
Rules, 2011. (adopted by Notifi cation S.O.1035(E) of Ministry of Environment and Forests)
The Product is in conformity with the requirements of Rule 13 of the e-waste Rules.
The content of hazardous substance with the exemption of the applications listed in SCHEDULE
II of the e-waste Rules:
1. Lead (Pb) - not over 0.1% by weight;
2. Cadmium (Cd) - not over 0.01% by weight;
3. Mercury (Hg) - not over 0.1% by weight;
4. Hexavalent chromium (Cr6+) - not over 0.1% by weight;
5. Polybrominated biphenyls (PBBs) - not over 0.1% by weight;
6. Polybrominated diphenyl ethers (PBDEs) - not over 0.1% by weight.
For the purpose of recycling to facilitate effective utilization of resources, please return
this product to a nearby authorized collection center, registered dismantler or recycler,
or Panasonic service center when disposing of this product.
Please see the Panasonic website for further information on collection centers, etc.
http://www.panasonic.com/in/corporate/sustainability/panasonic-india-i-recycle-program.html
68-M-2
18
Getting Started
Preparation
A Check and identify the supplied accessories.
If you do not fi nd the described accessories, contact Panasonic Technical Support.
• AC Adaptor . . . . . . . . 1
Model No: CF-AA6413C
• AC Cord . . . . . . . . . . 1 • Battery Pack . . . . . 1*1
Model No: CF-VZSU0QW
• Stylus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
• Hand Strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
• Tether . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
• Soft Cloth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
• OPERATING INSTRUCTIONS - Read Me First (This book) . . . . . . . . . . . . . . . . .1
*1 Stored in the main unit at the time of packing.
First-time Operation
1 Connect your computer to a power outlet.
The battery charging starts automatically.
CAUTION
Do not disconnect the AC adaptor until the fi rst-time opera-
tion procedure is completed.
When using the computer for the fi rst time, do not connect
any peripheral device (including wired LAN cable) except the
battery pack and AC adaptor.
Handling the AC adaptor
Problems such as sudden voltage drops may arise during
periods of thunder and lightning. Since this could adversely
affect your computer, an uninterruptible power source (UPS)
is highly recommended unless running from the battery pack
alone.
2 Turn on the computer.
Press the power switch until the power indicator lights.
When turning on the computer for the fi rst time after pur-
chase, it may take about 5 minutes for the “Welcome” screen
described in step 3 to appear. If the screen turns off auto-
matically, press (Power switch) to wake up.
CAUTION
Do not press the power switch repeatedly or do not hold the
power switch for 10 seconds or longer.
Any changes from the default setting of the Setup Utility must
not be made until the First-time Operation is completed.
1
ŋ
Ō
22 A3
2
19
Getting Started
NOTE
The screen keyboard may be not displayed when you enter the characters. In such a case,
touch and set [Show input method] to ON.
Refer to the OPERATING INSTRUCTIONS - Basic Guide by downloading from the following URL.
URL http://pc-dl.panasonic.co.jp/itn/manual/menu_en.html
3 Initializing the computer.
A When “Welcome” is displayed, touch the language name
and scroll the language list, then touch the language you
use and touch .
B <Only for model with wireless WAN>
When “Insert SIM card” screen is displayed, touch [SKIP].
C When “Select Wi-Fi network” screen is displayed, perform
one of the following operations.
- If you want to set up wi-fi , set up wi-fi by following the
on-screen instructions.
- If you do not want to set up wi-fi , touch [SKIP], then
when the confi rmation message is displayed touch [SKIP
ANYWAY].
D When “Date & time” screen is displayed, confi rm the set-
tings and touch [NEXT].
E When “Name” screen is displayed, input your name, then
touch [NEXT].
F When “Protect your phone” screen is displayed, touch the
item to select setting, then touch [NEXT].
If add the check mark to “Protect this device and ...”,
“Choose screen lock” screen will be displayed. Set the
screen lock method by following the on-screen instruc-
tions and touch [NEXT].
If remove the check mark from “Protect this device and ...”,
touch [SKIP] and [SKIP ANYWAY].
G When “GoogleTM services” screen is displayed, confi rm
the message and touch the items to select settings, then
touch [NEXT].
H When “Welcome” screen is displayed, touch [GOT IT].
I Connect to network via wi-fi or wireless WAN. ( Op-
erating Instructions - Reference Manual “Wireless Com-
munication”)
To connect to internet via wireless WAN, inserting the mi-
croSIM card is necessary. ( Operating Instructions -
Reference Manual “Wireless WAN”)
J Touch - [ Settings] - [ About tablet] - [System up-
dates] - [Download].
Follow the on-screen instructions.
Google, Android and other marks are trademarks of Google Inc.
Panasonic Corporation
Osaka, Japan
Panasonic System Communications Company of North America
Two Riverfront Plaza,
Newark NJ 07102
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga,
Ontario L4W 2T3
Panasonic Australia Pty. Limited
ACN 001 592 187 ABN 83 001 592 187
1 Innovation Road, Macquarie Park NSW 2113
Web Site : http://panasonic.net/avc/pc/
© Panasonic Corporation 2016
Printed in Japan
PS0616-0
DHQX1218ZA/X1
