Panasonic of North America B42R1801 Bluetooth Module User Manual
Panasonic Corporation of North America Bluetooth Module
User Manual
Model Name: RSNE041B1
Product Description: Bluetooth Module
Installation Manual
Module Size : 15 x 29mm
Thickness : 1.2mm
Connectivity : Edge-plating Surface Mount
Number of pin : 16
Caution notes :
1. The space around antenna area (6x15mm) needs to be a free space. No PCB or any other
material below the antenna.
2. Avoid module placement near to any metal part.
Edge plating pins Edge plating pins
1.2
mm
15
mm
29
mm
6
mm
FCC ID: ACJ-B42R1801
IC: 216A-B42R1801
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Caution: Any changes or modifications not expressly approved by the party responsible for
compliance to this equipment would void the user’s authority to operate this device.
This Device complies with FCC & IC radiation exposure limits.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to
the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause
undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux
CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
