Owner’s Manual
Wireless Speaker System
Model No. SC-NA30
SC-NA10
Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this
manual for future use.
Register online at www.panasonic.com/register (U.S. customers only)
If you have any questions, contact:
U.S.A. and Puerto Rico : 1-800-211-PANA (7262)
Canada : 1-800-561-5505
SC-NA30 SC-NA10
until
2013/08/27
SC-NA30_10PPC_VQT5C36_eng.book 1 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
2
IMPORTANT SAFETY
INSTRUCTIONS
Read these operating instructions carefully before using
the unit. Follow the safety instructions on the unit and the
applicable safety instructions listed below. Keep these
operating instructions handy for future reference.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8 Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding-
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11 Only use attachments/accessories specified
by the manufacturer.
12 Use only with the cart,
stand, tripod, bracket, or
table specified by the
manufacturer, or sold with
the apparatus. When a
cart is used, use caution
when moving the cart/
apparatus combination to avoid injury from tip-
over.
13 Unplug this apparatus during lightning storms
or when unused for long periods of time.
14 Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
∫WARNING
Unit
To reduce the risk of fire, electric shock or product
damage,
• Do not expose this unit to rain, moisture, dripping
or splashing.
• Do not place objects filled with liquids, such as
vases, on this unit.
• Use only the recommended accessories.
• Do not remove the cover except disassembling
for discarding.
• Do not repair this unit by yourself. Refer servicing
to qualified service personnel.
AC adaptor
The power plug is the disconnecting device.
Install this unit so that the power plug can be
unplugged from the socket outlet immediately.
∫CAUTION
Unit
• Do not throw.
• Do not hit this unit to anything. Do not apply
strong pressure to this unit. External case may
break when strong impact is applied, causing to
damage or malfunction.
• Do not leave the unit in a car exposed to direct
sunlight for a long period of time with doors and
windows closed.
• Product identification marking is located on the
bottom of the unit.
• Keep the volume knob out of reach of children to
prevent swallowing.
• Do not use this unit continuously with high
volume sound. This may deteriorate the sound
quality of the speaker and severely shorten the
life of the speaker.
AC adaptor
This AC adaptor operates on AC between 100 V and
240 V.
But
• In the U.S.A. and Canada, the AC adaptor must
be connected to a 120 V AC power supply only.
• When connecting to an AC supply outside of the
U.S.A. or Canada, use a plug adaptor to suit the
AC outlet configuration.
Precautions
SC-NA30_10PPC_VQT5C36_eng.book 2 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
3
Battery pack (Lithium ion battery pack)
This unit has a built-in battery.
The following is the caution for removing the battery
when disposing of this unit (>18, 19).
• Do not heat or expose to flame.
• Do not short circuit.
• Do not disassemble, crush.
• Do not re-use.
• Do not place in microwave ovens.
THE FOLLOWING APPLIES IN
THE U.S.A. AND CANADA
This device complies with Part 15 of FCC Rules
and Industry Canada licence-exempt RSS
standard(s).
Operation is subject to the following two
conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference,
including interference that may cause undesired
operation of this device.
SC-NA10
FCC ID:ACJ-SC-NA10
IC: 216A-SCNA10
SC-NA30
FCC ID:ACJ-SC-NA30
IC: 216A-SCNA30
This equipment complies with FCC/IC radiation
exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency
(RF) Exposure Guidelines and RSS-102 of the IC
radio frequency (RF) Exposure rules. This
equipment has very low levels of RF energy that it
deemed to comply without maximum permissive
exposure evaluation (MPE). But it is desirable that it
should be installed and operated keeping the
radiator at least 20 cm or more away from person’s
body (excluding extremities: hands, wrists, feet and
ankles).
A lithium ion battery that is
recyclable powers the
product you have
purchased. Please call 1-
800-8-BATTERY for
information on how to
recycle this battery.
THE FOLLOWING APPLIES ONLY
IN THE U.S.A.
FCC Note:
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
≥Reorient or relocate the receiving antenna.
≥Increase the separation between the
equipment and receiver.
≥
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
≥Consult the dealer or an experienced radio/
TV technician for help.
FCC Caution: To assure continued compliance,
follow the attached installation instructions and
use only shielded interface cables when
connecting to peripheral devices.
Any changes or modifications not expressly approved
by the party responsible for compliance could void
the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
Declaration of Conformity
Trade Name: Panasonic
Model No.: SC-NA10, SC-NA30
Responsible Party:
Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
Support Contact Telephone No.:
1-800-211-PANA (7262)
THE FOLLOWING APPLIES ONLY
IN CANADA.
CAN ICES-3(B)/NMB-3(B)
SC-NA30_10PPC_VQT5C36_eng.book 3 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
4
Frequency band used
This unit uses the 2.4 GHz frequency band.
Certification of this device
• This unit conforms to frequency restrictions and
has received certification based on frequency
laws. Thus, a wireless permit is not necessary.
• The actions below are punishable by law in some
countries:
– Taking apart/modifying the unit.
– Removing specification indications.
Restrictions of use
• Wireless transmission and/or usage with all
Bluetooth® equipped devices is not guaranteed.
• All devices must conform to standards set by
Bluetooth SIG, Inc.
• Depending on the specifications and settings of a
device, it can fail to connect or some operations
can be different.
• This system supports Bluetooth® security
features. But depending on the operating
environment and/or settings, this security is
possibly not sufficient. Transmit data wirelessly to
this system with caution.
• This system cannot transmit data to a Bluetooth®
device.
Range of use
Use this device at a maximum range of 10 m (33 ft).
The range can decrease depending on the
environment, obstacles or interference.
Interference from other devices
• This unit may not function properly and troubles
such as noise and sound jumps may arise due to
radio wave interference if this unit is located too
close to other Bluetooth® devices or the devices
that use the 2.4 GHz band.
• This unit may not function properly if radio waves
from a nearby broadcasting station, etc. is too
strong.
Intended usage
• This unit is for normal, general use only.
• Do not use this system near an equipment or in
an environment that is sensitive to radio
frequency interference (example: airports,
hospitals, laboratories, etc).
• Android and Google Play are trademarks of
Google Inc.
• The Bluetooth® word mark and logos are
owned by the Bluetooth SIG, Inc. and any
use of such marks by Panasonic
Corporation is under license. Other
trademarks and trade names are those of
their respective owners.
• aptX
®
software is copyright CSR plc or its
group companies. All rights reserved.
The aptX
®
mark and the aptX logo are
trademarks of CSR plc or one of its group
companies and may be registered in one or
more jurisdictions.
Turn off the power of this unit and wipe with dry soft
cloth. Disconnect the AC adaptor when the AC
adaptor is used.
• When it get very dirty, wipe off dirt with a cloth
immersed in water and wrung strongly, and then
wipe with dry soft cloth.
• Solvents such as benzine, thinner, alcohol, oil,
detergents, etc., may cause the external case to
be altered or the coating may come off, so do not
use them.
• Before using chemically treated cloth, read the
instructions that came with the cloth carefully.
-If you see this symbol-
About Bluetooth®
Panasonic bears no responsibility
for data and/or information that is
compromised during a wireless
transmission.
Licenses
Maintenance
Information on Disposal in
other Countries outside the
European Union
This symbol is only
valid in the
European Union.
If you wish to
discard this
product, please
contact your local
authorities or dealer
and ask for the
correct method of
disposal.
SC-NA30_10PPC_VQT5C36_eng.book 4 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
5
Table of contents
IMPORTANT SAFETY INSTRUCTIONS............................................ 2
Precautions......................................................................................... 2
About Bluetooth®................................................................................ 4
Licenses ............................................................................................. 4
Maintenance ....................................................................................... 4
Accessories ........................................................................................ 5
Control reference guide (SC-NA30) ................................................... 6
Control reference guide (SC-NA10) ................................................... 7
About the power of this unit ................................................................ 8
About the DC OUT terminal (USB)..................................................... 9
Listening to audio from a Bluetooth® device ..................................... 10
Connecting via Bluetooth® menu................................................................. 10
One-Touch Connection (Connecting by NFC) ............................................ 11
Switching the communication quality ..........................................................12
Disconnecting Bluetooth®............................................................................12
Using LP Mode ................................................................................. 13
Using the AUX input ......................................................................... 13
Auto Power Off ................................................................................. 13
Receiving a call hands-free .............................................................. 14
To return to the factory preset state ................................................. 14
Troubleshooting................................................................................ 15
Specifications ................................................................................... 16
To remove the battery when disposing of this unit ........................... 18
Limited Warranty
(ONLY FOR U.S.A. AND PUERTO RICO)....................................... 20
Limited Warranty (ONLY FOR CANADA)......................................... 22
Check the supplied accessories before using this unit.
∏1 AC adaptor (RFEA228C-AG)
Note
• Product numbers provided in this Owner’s Manual correct as of August 2013. These may be
subject to change.
• Do not use AC adaptor with other equipment.
• (ONLY FOR CANADA) The enclosed Canadian French label sheet corresponds to the English
display on the unit.
Accessories
SC-NA30_10PPC_VQT5C36_eng.book 5 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
6
Control reference guide (SC-NA30)
11
12
13
14
8
9
10
15
7
6
5
4
23
1
1 Retractable panel
2 BASS/TREBLE knob
• Adjusts low/high-pitched tones
• Depending on the audio source
being played or the volume being
output, the effect may be limited.
3 Volume knob: Adjusts the volume
• When the maximum or minimum
volume is reached, you will be
notified by a beep sound.
4 RESET switch [ ]
• Use a paper clip, etc., to press the
switch if this unit does not operate
correctly, like when you cannot turn
off/on the power.
5 AUX IN jack (>13)
6 DC OUT terminal
• When using this port, use a USB
cable (commercially-available). (
>
9)
7 DC IN terminal
8 Battery indicator (red)
9Bluetooth
® indicator (blue)
10 LP Mode indicator (green)
11 NFC touch area (>11)
12 Standby/on switch [Í/I]
13 Bluetooth® pairing button (>10)/
Play button/Pause button/Call
button (>14)
14 LP button
[LP]
15 Microphone (>14)
OFF
Rear view
When operating the unit, hold it with
hand to prevent it from falling.
ON
When the unit is turned on, the
retractable panel is lowered, enabling
you to adjust the knobs.
Side view
SC-NA30_10PPC_VQT5C36_eng.book 6 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
7
∫Placement method and operation of the unit
Control reference guide (SC-NA10)
1
2
3
4
9
10
11
12
13
5 6 7 8
1 RESET switch [ ]
• Use a paper clip, etc., to press the
switch if this unit does not operate
correctly, like when you cannot turn
off/on the power.
2 AUX IN jack (>13)
3 DC IN terminal
4 DC OUT terminal
• When using this port, use a USB
cable (commercially-available). (
>
9)
5 Battery indicator (red)
6 Bluetooth® indicator (blue)
7 LP Mode indicator (green)
8 NFC touch area (>11)
9 Volume knob: Adjusts the volume
• To operate the knob, place your
thumb on the knob as indicated by
A, and turn it vertically.
• When the maximum or minimum
volume is reached, you will be
notified by a beep sound.
10 Standby/on switch [Í/I]
11 Bluetoo th® pairing button (>10)/
Play button/Pause button/Call
button (>14)
12 LP button
[LP]
13 Microphone (>14)
Place the unit so that the projections
on the bottom of the unit will be
aligned with the groove of the cover.
Placement method Operation of the unit
Side view
When operating the unit, hold it with
hand to prevent it from falling.
Cover
SC-NA30_10PPC_VQT5C36_eng.book 7 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
8
This unit has a built-in battery. Please charge the battery before using this unit for
the first time.
∫Charging the battery
Connect the AC adaptor to the
household AC outlet.
•If charging is necessary, the Battery
indicator (red) lights. When charging
is complete, the Battery indicator
goes off.
About the battery status
*1 These battery statuses of the unit serve
only as an approximation, and may vary
according to the conditions of use.
Battery life in use/Battery charge time/Rechargeable times
*2 Calculated by the test method established by the company [while connecting with Bluetooth®,
using at the surrounding temperature of 25 oC (i77 oF)]
*3 When charging at the surrounding temperature of 25 oC (i77 oF) after the battery is depleted.
∫Using the unit by connecting it to a household AC outlet
Press [Í/I] to turn on the unit. Connecting the AC adaptor before turning on the
unit allows you to supply power from a household AC outlet during use.
• It takes longer to charge while this unit is turned on.
About the power of this unit
Battery indicator (red)
(>6, 7) Battery status
Fast blinking
(at approximately
1 second intervals)
About 5%*1
Slow blinking
(at approximately
2 second intervals)
About 15%*1
[NA30] [NA10]
Battery life in use Approx. 14 hours*2Approx. 11 hours*2
Battery life in use (LP mode) Approx. 20 hours*2Approx. 20 hours*2
Battery Charge time Approx. 3 hours*3Approx. 3 hours*3
Rechargeable times About 500 times About 500 times
[NA30]
[NA10]
AC adaptor
(supplied)
To a household
AC outlet
Rear view
SC-NA30_10PPC_VQT5C36_eng.book 8 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
9
Note
• Do not use any other AC adaptors except the supplied one.
• When this unit is not used over a long period of time, charge the built-in battery at least once
every six months to prevent it from deteriorating.
• Charging may not start if the battery level is sufficiently high even if it is not full.
• It is recommended to charge the battery in the temperature of between 10 oC and 35 oC
(i50 oF to i95 oF). The Battery indicator (red) may flash and charging may not be possible
when it is out of recommended temperature range.
• The battery may not charge when the temperature surrounding the battery is high during the
operation or right after the operation even when it is within the recommended temperature
range. In such case, stop the usage and let it cool down.
• To ensure safety, in the case of an excessive input signal, the system may be automatically
interrupted and power is turned off.
• Use of the DC OUT terminal will reduce the operating time.
The DC OUT terminal of this unit is for supplying/charging power to a connected
device (rated value: 5 V/1 A). Note that the port cannot be used for purposes other
than supplying/charging power.
Note that when the unit is turned off, charging is not possible.
Preparation
Turn on the unit.
1 Using a USB cable
(commercially-available),
connect the unit and a
compatible device.
2 Once fully charged, remove
the USB cable
(commercially-available)
from the DC OUT terminal.
Note
• A cable compatible with your device is required. If a cable is supplied with your device, use the cable.
• Even if you connect a cable compatible with the DC OUT terminal of this unit, your device may
not be charged. In that case, use a charger supplied with your device.
• Depending on your device, charging methods other than the specified one may not be
allowed. Check the operating instructions of your device before use.
• Do not connect a device with a rated value higher than 5 V/1 A to this unit. Doing so may
cause malfunction.
• To check if charging is complete, look at the screen of the connected device, etc.
• After charging, pull out the compatible cable.
About the DC OUT terminal (USB)
[NA30]
[NA10]
To the compatible device
USB cable
(commercially-
available)
Rear view
SC-NA30_10PPC_VQT5C36_eng.book 9 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
10
Preparation
Enable the Bluetooth® function of the device you want to connect to, and bring it
closer to the unit.
• Use a Bluetooth® device within the approximate range of 10 m (33 ft.) from the
unit.
• If you intend to use an NFC (Near Field Communication)-compatible Bluetooth®
device, proceed to “One-Touch Connection (Connecting by NFC)” (>11).
∫Pairing with Bluetooth® device
1 Press [Í/I] to turn this unit on.
The Bluetooth® indicator (blue) blinks slowly.
• If this unit is being used for the first time (factory preset state):
The Bluetooth® indicator (blue) blinks fast. The unit will enter pairing standby.
Skip to step 3.
2 Press and hold [ ] until the Bluetooth® indicator (blue) blinks fast.
The unit will enter pairing standby.
3 Select “SC-NA30” or “SC-NA10” from the Bluetooth® device’s Bluetooth®
menu.
When the Bluetooth® device is paired and connected, the Bluetooth® indicator (blue) on the
unit lights up.
• If prompted for a passkey, input “0000”.
• If the Bluetooth® device need to operate the Bluetooth® pairing setting and the
Bluetooth® connecting setting, operate both settings.
4 Start playing back music, a movie, etc. on your Bluetooth® device.
• The volume can be adjusted by rotating the volume knob of the unit.
When the maximum or minimum volume is reached, you will be notified by a beep
sound.
∫Listening to audio from a paired device
When this unit is turned on, the Bluetooth
®
indicator (blue) will blink slowly indicating
that the unit is in connection standby mode. Please perform Steps 3 and 4.
• When the power is turned on, this unit is connected to the last-used Bluetooth® device. At this
point, please perform Step 4.
Listening to audio from a Bluetooth® device
Connecting via Bluetooth® menu
SC-NA30_10PPC_VQT5C36_eng.book 10 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
11
For NFC-compatible AndroidTM devices only
Just placing an NFC (Near Field Communication)-compatible Bluetooth® device on
the unit, you can complete all preparations, from registering a Bluetooth® device to
establishing a connection.
Preparation
Enable the NFC function on the Bluetooth® device
1 Download the app “Panasonic Music Streaming” (free of charge) to your
Bluetooth® device from Google PlayTM.
• Enter “Panasonic Music Streaming” in the search box of Google PlayTM and search
select “Panasonic Music Streaming” to download the app
2 Start the app “Panasonic Music Streaming” on your Bluetooth® device.
• Follow on-screen instructions on your device.
• Always use the latest version of the app.
3 Touch and hold your device on the NFC touch area of this unit.
(Until a pop-up window on your device indicates that the connection is
established.)
When the unit recognizes your device, a beep sound is emitted.
• When the Bluetooth® device is paired and connected, the Bluetooth® indicator (blue)
on the unit lights up. Once the registration and connection of the Bluetooth® device is
complete, move the device away from the unit.
• When the Bluetooth® indicator (blue) does not light up even if you have touched the
NFC touch area, change the touching position.
4 Start playing back music, a movie, etc. on your Bluetooth® device.
∫Connecting to another device
If you touch another device to this unit, you can update the Bluetooth® connection.
The previously connected device will be disconnected automatically.
One-Touch Connection (Connecting by NFC)
SC-NA30_10PPC_VQT5C36_eng.book 11 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
12
You can change the transmission speed to prioritize sound quality or connectivity.
• The default setting is “Emphasis on sound quality”. When the sound is interrupted, select
“Emphasis on connectivity”.
While pressing and holding [LP], press and hold [ ] for 4 seconds or more.
Emphasis on connectivity:
A beep sound is emitted once, and the Bluetooth® indicator (blue) and the LP mode
indicator (green) flash once.
Emphasis on sound quality:
A beep sound is emitted twice, and the Bluetooth® indicator (blue) and the LP mode
indicator (green) flash twice.
Note
• Press [LP], and within 2 seconds, press [ ]. If [ ] is pressed after this time limit, the LP
mode setting will be changed.
• Turn off this unit or the device.
• Stop / disable the Bluetooth® transmission of the device.
• (For NFC-compatible devices only)
Touch and hold your device to NFC touch area of this unit again.
Note
• This unit can only be connected to one device at a time.
• This unit can register up to 8 devices.
When the number of registered devices exceeds the maximum limit, a device that has not
made a Bluetooth® connection for the longest time will be replaced. This will cancel the
registration of the device. To use the device again, re-register it.
• If the unit connected to the AC adaptor is selected from a Bluetooth® device, the unit will turn
on automatically even when it is turned off, establishing a Bluetooth® connection.
• If the image and sound are out of sync during playback, restart the playback app you are
using. If the problem persists, connect the Bluetooth® device and this unit with an audio cable
(commercially-available).
• The One-Touch Connection may not work properly depending on the type of device being
used.
• Depending on the specifications and settings of a device, it can fail to connect or some
operations can be different.
• Refer to the operating instructions of the Bluetooth® device for details.
Switching the communication quality
Disconnecting Bluetooth®
SC-NA30_10PPC_VQT5C36_eng.book 12 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
13
This mode minimizes power consumption of the battery by lowering the speaker
output. (>8)
Press and hold [LP] for 2 seconds or more until the LP mode indicator
(green) lights up.
The LP mode is enabled.
• Press and hold [LP] for 2 seconds or more again will return the setting back to the normal mode.
Note
• Even when the AC adaptor is connected, LP mode remains enabled.
• In LP mode, even when the volume knob is adjusted, the volume of the unit may not increase.
• Turning off the LP mode may cause the volume to jump up suddenly. Before turning off the LP
mode, lower the volume.
You can listen to audio via the AUX IN jack (>6, 7) when this unit is connected to
a device with an audio cable (commercially-available).
Note
• When using the AUX input, AUX input has priority than the Bluetooth® features and NFC
features.
(It will be possible to receive a call hands-free by pressing [ ] when there is a call coming
in on the device connected with Bluetooth®. >14)
• The setting of the Bluetooth® is not changed even if the audio cable (commercially-available)
is inserted into AUX IN jack.
• When using the AUX input, the volume may seem low depending on the connected device. In
that case, check if the volume limit can be changed on the device. For details, refer to the
manual of the device.
• If an audio cable (commercially-available) is inserted during audio playback with a Bluetooth
®
connection, noise may occur. In this case, stop the playback on the device connected via Bluetooth
®
.
This unit automatically turns off if there is no audio input and no operation is
performed for approximately 10 minutes.
Note
• If the AUX IN jack is in use while the AC adaptor is connected, this function will not work.
• This function may operate even when the music is being played back if the volume of the
connected device is low.
• This function may not operate depending on the connected device.
• When the DC OUT terminal is in use, this function will not work.
[NA30]
• The Auto Power Off function is activated, the retractable panel will remain lowered when the unit
is turned off. To leave the retractable panel raised when the unit is turned off, press [
Í
/I] twice.
Using LP mode
Using the AUX input
Auto Power Off
SC-NA30_10PPC_VQT5C36_eng.book 13 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
14
If receiving a call on the mobile phone connected to this unit with Bluetooth®, you
can make a hands-free call through this unit.
Preparation
Connect this unit and the mobile phone with Bluetooth®.
∫Receiving a call
Press [ ] when this unit rings.
• When receiving the call, the Bluetooth® indicator (blue) on the unit blinks.
• Talk into the microphone (>6, 7) on this unit.
∫Ending the call
Press [ ].
Note
• Adjust the volume during a call with volume knob on this unit.
• When the mobile phone and the unit are connected with Bluetooth®, even if you receive a call
and have a conversation on the mobile phone, the unit may also output the incoming voice. To
switch from a hands-free call using the unit to a call using only the mobile phone, operate the
mobile phone.
• If a call is received during audio playback using a Bluetooth® connection, the sound will
automatically switch to the ringtone.
If a call is received while the AUX IN jack is in use, the sound will switch to the ringtone of the
mobile phone connected with Bluetooth®.
• If you touch other devices to the NFC touch area of this unit when receiving a call, Bluetooth®
connection will not switch.
• To mute the ringtone, turn the volume knob of the unit to [- VOL] until no sound can be heard.
• Some apps for the mobile phone may not be available for hands-free.
• When the hands-free function is not available, set up a hands-free connection from the mobile
phone to this unit.
• In a place with poor mobile phone reception, it may be harder to have a conversation. Use the
mobile phone in a place with good reception.
• In a place where voices echo considerably, such as an area near a wall, it may be harder to
have a conversation. Before using the unit, move it away from the wall or lower its volume.
Perform the following when you want to delete pairing device information, etc.
Preparation
Turn off the unit, and remove the AC adaptor.
Press and hold [Í/I] for 10 seconds until Bluetooth® indicator (blue) and LP
Mode indicator (green) blink twice.
The pairing device information will be deleted by the reset, so it will be necessary to
perform pairing again. Delete the pairing information for this unit from the
Bluetooth® device, then perform the pairing operation again. (>10, 11)
Receiving a call hands-free
To return to the factory preset state
SC-NA30_10PPC_VQT5C36_eng.book 14 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
15
Before requesting service, make the following
checks. If you are in doubt about some of the
check points, or if the solutions indicated in
the following guide do not solve the problem,
refer to “Customer Services Directory (United
States and Puerto Rico)” (
>
21) if you reside
in the U.S.A. or Puerto Rico, or refer to
“Limited Warranty (ONLY FOR CANADA)”
(
>
22) if you reside in Canada.
[NA30]
The retractable panel is not operating correctly.
• The Auto Power Off function is activated, the
retractable panel will remain lowered when the unit
is turned off. To leave the retractable panel raised
when the unit is turned off, press [
Í
/I] twice.
Sound from the device is cut off.
• Simultaneous use with other 2.4 GHz
devices, such as microwaves, cordless
telephones, etc., may result in connection
interruptions. Increase the distance
between this system and these devices.
• Do not place the unit in a place where radio
waves will be blocked, such as a metal cabinet.
• The device is out of the 10 m (33 ft.)
communication range. Move the device nearer
to this unit. (See “About Bluetooth
®
”
>
4)
• Remove any obstacle between this
unit and the device.
• Switch off any wireless LAN device.
• Select “Emphasis on connectivity” for
stable communication. (See “Switching
the communication quality”
>
12)
• When a PC and the unit are connected
with Bluetooth
®
, check the sound output
destination setting of the PC. If the sound
skips or is not output correctly in other
ways, perform “To return to the factory
preset state” (
>
14), and register the unit
to the Bluetooth
®
device again. (
>
10, 11)
• Depending on the device connected to
the unit, sound may be cut off or noise
may be produced. When this happens,
lower the volume of the device.
• When both the AUX IN jack and DC IN
terminal are in use, noise may occur
depending on the connected device. In
this case, disconnect the AC adaptor.
The volume does not increase.
• Check the volume of the unit or the
Bluetooth® device.
• In LP mode, even when the volume knob is
adjusted, the volume of the unit may not increase.
In this case, turn off the LP mode. (
>
13)
The sound is distorted.
• Depending on the device connected to this unit,
when the bass or treble level is raised excessively
with the device's sound quality control, the sound
may become distorted. When this occurs, adjust
the setting of the device.
The device cannot be connected.
• Refer to the operating instructions of the device,
and perform the pairing operation again. (See
“Pairing with Bluetooth
®
device”
>
10)
• Make sure that this unit is not
connected to a different device.
• The registration information of the unit may
have been deleted from the Bluetooth
®
device. Register the unit again.
• Delete the registration information of
the unit through the Bluetooth
®
menu,
etc. on the Bluetooth
®
device first, and
try to register the device again. (
>
14)
The device is connected but audio
cannot be heard from this unit.
• For some built-in Bluetooth
®
devices, you
have to set the audio output to “SC-NA30” or
“SC-NA10” manually. Read the operating
instructions of the device for details.
• When the AUX IN jack is in use, the jack takes priority
over the Bluetooth® function or the NFC function.
This unit is not operating correctly.
For example, this unit turns off all of
a sudden or all indicator blink.
• Using a paper clip or similar material,
press the [RESET]. (>6, 7)
Troubleshooting
SC-NA30_10PPC_VQT5C36_eng.book 15 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
16
The One-Touch Connection (NFC
feature) is not working.
• Turn on the NFC feature of the device.
Volume is low when this unit is
connected to a TV via Bluetooth®.
• Adjust the volume on the TV. The
volume of headphone output may be
coupled with the volume of the
Bluetooth® output depending on the
TV. In such case, adjust the volume
of the headphone output on the TV.
∫Amplifier section
∫Speaker section
Specifications
RMS Output Power (AC Adaptor)
Normal Mode
[NA30]
10 % total harmonic distortion
Front ch (each ch driven):
5 W per channel (1 kHz, 6 ≠)
Subwoofer:
10 W per channel (100 Hz, 3 ≠)
Total RMS output power: 20 W
[NA10]
10 % total harmonic distortion
Front ch (both ch driven):
5 W per channel (1 kHz, 6 ≠)
Total RMS output power: 10 W
RMS Output Power (Battery)
Normal Mode
[NA30]
10 % total harmonic distortion
Front ch (each ch driven):
4 W per channel (1 kHz, 6 ≠)
Subwoofer: 8 W per channel (100 Hz, 3
≠
)
Total RMS output power: 16 W
[NA10]
10 % total harmonic distortion
Front ch (both ch driven):
4 W per channel (1 kHz, 6 ≠)
Total RMS output power: 8 W
RMS Output Power (AC Adaptor/Battery)
Long Play Mode
[NA30]
10 % total harmonic distortion
Front ch (each ch driven):
2 W per channel (1 kHz, 6 ≠)
Subwoofer: 4 W per channel (100 Hz, 3
≠
)
Total RMS output power: 8 W
[NA10]
10 % total harmonic distortion
Front ch (both ch driven):
0.5 W per channel (1 kHz, 6 ≠)
Total RMS output power: 1 W
FTC Output Power (AC Adaptor)
[NA30]
1.0 % total harmonic distortion
Front ch (both ch driven):
250 Hz
j
16 kHz 3.5 W per channel (6
≠
)
Subwoofer:
70 Hz j 500 Hz 3 W (3 ≠)
Total FTC power: 10 W
[NA10]
1.0 % total harmonic distortion
Front ch (both ch driven):
250 Hz
j
16 kHz 3.5 W per channel (6
≠
)
Total FTC power: 7 W
Front Speaker (L/R)
[NA30]
Type:1 way 1 speaker system (Closed type)
Unit(s): 5 cm k2(2qk 2)
Impedance: 6 ≠
[NA10]
Type:1 way 1 speaker system (passive radiator type)
Unit(s): 4 cm k2(1
5/8qk 2)
Impedance: 6 ≠
[NA30]
SUBWOOFER
Type:
1 way 1 speaker system (passive radiator type)
Unit(s): 8 cm k1(3
1/8qk 1)
Impedance: 3 ≠
Passive Radiator
[NA30] Unit: 8 cm k2(3 1/8qk2)
[NA10] Unit: 8 cm k1(3 1/8qk1)
SC-NA30_10PPC_VQT5C36_eng.book 16 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
17
∫Bluetooth® section
∫Microphone section
∫Terminals section
∫Accessories section
∫General
Note
• Specifications are subject to change without
notice.
• Mass and dimensions are approximate.
• Total harmonic distortion is measured by a
digital spectrum analyzer.
* By the measurement method prescribed in
the provisions
Bluetooth
®
system specification
Ver. 3.0
Wireless equipment classification
Class 2(2.5mW)
Supported profiles
A2DP/AVRCP/HFP
Supported codec
aptX
®
, AAC, SBC
Frequency band
2.4 GHz band FH-SS
Operating distance
Approx. 10 m (33 ft.) Line of sight
Prospective communication distance.
Measurement environment: Height 1.0 m (3.3 ft.)
Type
Mono
DC IN
12 V 3 A
AUX input
Stereo ‡3.5 mm (1/8q) jack
DC OUT (USB A type)
(5 V 1 A) Supply output only power-on
AC Adaptor
INPUT: AC 100 V to 240 V 50/60 Hz
800 mA
OUTPUT: DC 12 V 3 A
Power supply
[NA30]
DC 12 V 3 A
Internal Battery: 7.2 V (Li-ion: 2900 mAh)
[NA10]
DC 12 V 3 A
Internal Battery: 7.4 V (Li-ion: 1240 mAh)
Power consumption
[NA30] Approx. 16 W
[NA10] Approx. 12 W
Power consumption in standby mode
Approx. 0.4 W
Battery Life in Use (Bluetooth
®
:
SBC mode)
[NA30]
Normal Mode: Approx. 14 h*
LP Mode: Approx. 20 h*
[NA10]
Normal Mode: Approx. 11 h*
LP Mode: Approx. 20 h*
Battery Charge Time (25
o
C (77
o
F) )
Approx. 3 h
Dimensions (W
k
H
k
D)
[NA30]:
244 mm k 144 mm k 48 mm
(9 5/8q k 5 11/16q k 1 29/32q)
[NA10]:
204 mm
k
105 mm
k
41 mm (With cover)
(8 1/32q k 4 5/32q k 1 5/8q)
200 mm
k
99 mm
k
29 mm (Without cover)
(77/8q k 3 29/32q k 1 5/32q)
Mass (Weight)
[NA30]
Approx. 930 g(2.05 lbs)
[NA10]
Approx. 520 g(1.15 lbs)
(With cover)
Approx. 415 g(0.92 lbs) (Without
cover)
Operating temperature range
0oC to i40 oC (i32 oF to i104 oF)
Charge temperature range
10 oC to i35 oC (i50 oF to i95 oF)
Operating humidity range
35% to 80% RH (no condensation)
SC-NA30_10PPC_VQT5C36_eng.book 17 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
18
• Use up the battery before disassembling. (For Cautions of the battery >3)
• Keep the sheets and the screws out of reach of children to prevent swallowing.
∫How to disassemble the SC-NA30
To remove the battery when disposing of this
unit
The following instructions are not intended for repairing
purposes but for the disposal of this unit. This unit is not
restorable once disassembled.
When disposing of this unit, take out the battery installed in this unit and
recycle it.
• Insulate the A with cellophane tape or similar.
• Do not disassemble the battery.
SC-NA30_10PPC_VQT5C36_eng.book 18 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
19
∫How to disassemble the SC-NA10
3
21
56
78
4
• Insulate the A with cellophane tape or similar.
• Do not disassemble the battery.
SC-NA30_10PPC_VQT5C36_eng.book 19 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
20
Limited Warranty
(ONLY FOR U.S.A. AND PUERTO RICO)
Panasonic Products Limited Warranty
Limited Warranty Coverage
(For USA and Puerto Rico Only)
If your product does not work properly
because of a defect in materials or
workmanship, Panasonic Corporation of North
America (referred to as “the warrantor”) will,
for the length of the period indicated on the
chart below, which starts with the date of
original purchase (“warranty period”), at its
option either (a) repair your product with new
or refurbished parts, (b) replace it with a new
or a refurbished equivalent value product, or
(c) refund your purchase price. The decision to
repair, replace or refund will be made by the
warrantor.
During the “Labor” warranty period there will
be no charge for labor. During the “Parts”
warranty period, there will be no charge for
parts. This Limited Warranty excludes both
parts and labor for non-rechargeable batteries,
antennas, and cosmetic parts (cabinet). This
warranty only applies to products purchased
and serviced in the United States or Puerto
Rico. This warranty is extended only to the
original purchaser of a new product which was
not sold “as is”.
Mail-In Service--Online or Telephone
Repair Request
Online Repair Request
To submit a new repair request and for quick repair
status visit our Web Site at www.panasonic.com/
repair.
Telephone Repair Request
You may contact us at: 1-800-211-PANA (7262)
When shipping the unit, carefully pack, include
all supplied accessories listed in the Owner’s
Manual, and send it prepaid, adequately
insured and packed well in a carton box. When
shipping Lithium Ion batteries please visit our
Web Site at www.panasonic.com/
BatteryHandling as Panasonic is committed to
providing the most up to date information.
Include a letter detailing the complaint, a
return address and provide a daytime phone
number where you can be reached. A valid
registered receipt is required under the Limited
Warranty.
IF REPAIR IS NEEDED DURING THE
WARRANTY PERIOD, THE PURCHASER WILL
BE REQUIRED TO FURNISH A SALES
RECEIPT/PROOF OF PURCHASE INDICATING
DATE OF PURCHASE, AMOUNT PAID AND
PLACE OF PURCHASE. CUSTOMER WILL BE
CHARGED FOR THE REPAIR OF ANY UNIT
RECEIVED WITHOUT SUCH PROOF OF
PURCHASE.
Limited Warranty Limits And
Exclusions
This warranty ONLY COVERS failures due to
defects in materials or workmanship, and
DOES NOT COVER normal wear and tear or
cosmetic damage. The warranty ALSO DOES
NOT COVER damages which occurred in
shipment, or failures which are caused by
products not supplied by the warrantor, or
failures which result from accidents, misuse,
abuse, neglect, mishandling, misapplication,
alteration, faulty installation, set-up
adjustments, misadjustment of consumer
controls, improper maintenance, power line
surge, lightning damage, modification,
introduction of sand, humidity or liquids,
commercial use such as hotel, office,
restaurant, or other business or rental use of
the product, or service by anyone other than a
Factory Service Center or other Authorized
Servicer, or damage that is attributable to acts
of God.
Product or Part Name Parts Labor
Wireless Speaker
System 1 Year 1 Year
All included
Accessories
(Except Non-
Rechargeable
Batteries)
90 Days Not
Applicable
Only Non-
Rechargeable Batteries 10 Days Not
Applicable
SC-NA30_10PPC_VQT5C36_eng.book 20 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
21
THERE ARE NO EXPRESS WARRANTIES
EXCEPT AS LISTED UNDER “LIMITED
WARRANTY COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS
PRODUCT, OR ARISING OUT OF ANY BREACH
OF THIS WARRANTY.
(As examples, this excludes damages for lost time,
travel to and from the servicer, loss of or damage to
media or images, data or other memory or recorded
content. The items listed are not exclusive, but for
illustration only.)
ALL EXPRESS AND IMPLIED WARRANTIES,
INCLUDING THE WARRANTY OF
MERCHANTABILITY, ARE LIMITED TO THE
PERIOD OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or
limitation of incidental or consequential
damages, or limitations on how long an
implied warranty lasts, so the exclusions may
not apply to you.
This warranty gives you specific legal rights
and you may also have other rights which vary
from state to state. If a problem with this
product develops during or after the warranty
period, you may contact your dealer or Service
Center. If the problem is not handled to your
satisfaction, then write to the warrantor’s
Consumer Affairs Department at the
addresses listed for the warrantor.
PARTS AND SERVICE, WHICH ARE NOT
COVERED BY THIS LIMITED WARRANTY, ARE
YOUR RESPONSIBILITY.
As of July 2013
Customer Services Directory (United
States and Puerto Rico)
Obtain Product Information and Operating
Assistance; locate your nearest Dealer or
Service Center; purchase Parts and
Accessories; or make Customer Service
and Literature requests by visiting our Web
Site at:
http://www.panasonic.com/help
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at:
1-800-211-PANA (7262)
Monday-Friday 9am-9pm,
Saturday-Sunday 10am-7pm EST
For hearing or speech impaired TTY
users, TTY: 1-877-833-8855
Accessory Purchases (United States and
Puerto Rico)
Purchase Parts, Accessories and Owner’s
Manual online for all Panasonic Products
by visiting our Web Site at:
http://www.pstc.panasonic.com
Or, send your request by E-mail to:
npcparts@us.panasonic.com
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080
(Fax Only)
(Monday-Friday 9am-9pm EST)
Panasonic National Parts Center
20421 84th Ave S., Kent, WA 98032
(We accept Visa, MasterCard, Discover
Card, American Express)
For hearing or speech impaired TTY
users, TTY: 1-866-605-1277
The model number and serial number of this
product can be found on either the back or
the bottom of the unit.
Please note them in the space provided
below and keep for future reference. User memo:
DATE OF PURCHASE
MODEL NUMBER
SC-NA30
SC-NA10 DEALER NAME
DEALER ADDRESS
SERIAL NUMBER
TELEPHONE NUMBER
SC-NA30_10PPC_VQT5C36_eng.book 21 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
22
Limited Warranty (ONLY FOR CANADA)
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
PANASONIC PRODUCT - LIMITED WARRANTY
EXCHANGE PROGRAM
Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship
under normal use and for a period as stated below from the date of original purchase agrees to, at
its option either (a) repair your product with new or refurbished parts, (b) replace it with a new or a
refurbished equivalent value product, or (c) refund your purchase price. The decision to repair,
replace or refund will be made by Panasonic Canada Inc.
This warranty is given only to the original purchaser, or the person for whom it was purchased as
a gift, of a Panasonic brand product mentioned above sold by an authorized Panasonic dealer in
Canada and purchased and used in Canada, which product was not sold “as is”, and which
product was delivered to you in new condition in the original packaging.
IN ORDER TO BE ELIGIBLE TO RECEIVE WARRANTY SERVICE HEREUNDER, A
PURCHASE RECEIPT OR OTHER PROOF OF DATE OF ORIGINAL PURCHASE, SHOWING
AMOUNT PAID AND PLACE OF PURCHASE IS REQUIRED
LIMITATIONS AND EXCLUSIONS
This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER
normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages which occurred in
shipment, or failures which are caused by products not supplied by Panasonic Canada Inc., or failures which
result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up
adjustments, misadjustment of consumer controls, improper maintenance, power line surge, lightning damage,
modification, introduction of sand, humidity or liquids, commercial use such as hotel, office, restaurant, or
other business or rental use of the product, or service by anyone other than an Authorized Servicer, or damage
that is attributable to acts of God.
Dry cell batteries are also excluded from coverage under this warranty.
THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED,
INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FOR ANY SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY
BREACH OF ANY EXPRESS OR IMPLIED WARRANTY. (As examples, this warranty excludes damages for lost
time, travel to and from the Authorized Servicer, loss of or damage to media or images, data or other memory
or recorded content. This list of items is not exhaustive, but for illustration only.)
In certain instances, some jurisdictions do not allow the exclusion or limitation of incidental or
consequential damages, or the exclusion of implied warranties, so the above limitations and
exclusions may not be applicable. This warranty gives you specific legal rights and you may have
other rights which vary depending on your province or territory.
CONTACT INFORMATION
Panasonic Portable / Clock Radio (without Tape, CD, MD)
Panasonic Audio Product
Panasonic DVD Product
Accessories including rechargeable batteries
One (1) year
One (1) year
One (1) year
Ninety (90) days
For product information and operation assistance, please contact:
Our Customer Care Centre: Telephone #:
Fax #:
1-800-561-5505
(905) 238-2360
For defective product exchange within the warranty period, please contact the original dealer or our
Customer Care Centre.
SC-NA30_10PPC_VQT5C36_eng.book 22 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
VQT5C36
23
SC-NA30_10PPC_VQT5C36_eng.book 23 ページ ２０１３年１０月１１日　金曜日　午後１時２５分
Conforms to UL STD 60065
Certified to CAN/CSA STD C22.2 No.60065
Conforme à la norme CAN/CSA C22.2 No.60065
USA Only: Disposal may be regulated in your community due to environmental
considerations. For disposal or recycling information, please visit Panasonic
website:
http://www.panasonic.com/environmental/
or call 1-888-769-0149.
Printed in Malaysia
Panasonic Corporation 2013
Two Riverfront Plaza, Newark,
NJ 07102-5490
http://www.panasonic.com
Panasonic Corporation
of North America
5770 Ambler Drive
Mississauga, Ontario,
L4W 2T3
Panasonic Canada Inc.
www.panasonic.ca
VQT5C36-1
F0813SB1103
SC-NA30_10PPC_VQT5C36_eng.book 25 ページ ２０１３年１０月１１日　金曜日　午後１時２５分

Navigation menu
