Panasonic Corporation of North America Wireless LAN MODULE
User manual
USER MANUAL
IEEE802.11a/b/g/n/ac
Wireless LAN module
Model Name : TNPA6600
Panasonic Corporation
Version : 1.0
1, Feb , 2018
Panasonic Corporation 2018/2/1
Main Chipset
MT7618BUN
Standard
IEEE802.11a/b/g/n/ac
TX/RX
2TX
, 2RX
Frequency Range
2400
– 2483MHz
5150
– 5350MHz
5470
– 5725MHz
5725
– 5850MHz
Maximum
Data Rate
802.11b
: 11Mbps
802.11g : 54Mbps
802.11a : 54Mbps
802.11n : 300Mbps
802.11ac : 866.7Mbps
Operating Temperature
0
– 60℃
Operating Voltage
5V DC
±10%
Antenna Type
Printed Antenna
1. PRODUCT OVERVIEW
1.1 DESCRIPTION
TNPA6600 is a IEEE802.11a/b/g/n/ac wireless LAN module
using chipset MT7618BUN.
1.2 GENERAL SPECIFICATIONS
1.3 CERTIFICATION ID
FCC
ACJ
-TNPA6600
IC
216A
-TNPA6600
TELEC
003
-170109
JATE
D170061003
Panasonic Corporation 2018/2/1
1.3 BLOCK DIAGRAM
Crystal
40MHz
[X7200]
Diplexer
[U7200]
DC-DC
[IC7201]
Interface
[CN7201]
※1 D-
D+
+3.3V
+5V
2.4G Tx0/Rx0
5G Tx0/Rx0
Diplexer
[U7201]
2.4G Tx1/Rx1
5G Tx1/Rx1
RF connector
[JK7200]
RF connector
[JK7201]
Antenna
Antenna 0
Antenna 1
※2
MT7618BUN
[IC7200]
WoWLAN
Panasonic Corporation 2018/2/1
※2
Frequency range (Antenna 0) : 2.412～2.462 GHz, 5180～5825MHz
Frequency range (Antenna 1) : 2.412～2.462 GHz, 5180～5825MHz
※1
This interface is only used for test measurement or to connect mainboard.
This is not to support general equipment like PC or Notebook PC.
2. PRECAUTIONS
The following limits are in place regarding the usage of this module.
You must be aware of these limits before using this module.
Panasonic will in no way be responsible for any incidental damage
which may arise due to a failure to obey these limits, or to any
condition of use or disuse of this module.
・Data transmitted and received over radio waves may be intercepted
and monitored.
・This module contains delicate electric components.
Please use this module in the manner in which it was intended and
Follow the following points.
- Do not expose this module to high temperatures or direct sunlight.
- Do not bend, or subject this module to strong impacts.
- Keep this module away from moisture.
- Do note disassemble or alter this module in any way.
Panasonic Corporation 2018/2/1
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
●Reorient of relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit difference from that to which the receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.
Important Note:
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20 cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Country Code selection feature to be disabled for products marketed to the US/Canada.
1. The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2. The transmitter module may not be co-located with any other transmitter or antenna.
As long as the three conditions above are met, further transmitter testing will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements required
with this module installed.
Important Note:
In the event that these conditions cannot be met (for example certain laptop configurations or co-location
with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be
used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the
end product (including the transmitter) and obtaining a separate FCC authrozation.
End Product Labeling:
The final end product must be labeled in a visible area with the following “Contains FCC ID: ACJ-TNPA6600”
Manual Information to the End User:
The OEM integrator has to be aware not provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
ISED Statement
‐ English: This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This d
evice must accept any interference, including interference that may cause undesired operation of the device.
The digital apparatus complies with Canadian CAN ICES-3 (B)/NMB-3 (B).
‐ French: Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes: (1) l'appareil ne doit pas p
roduire de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi
le brouillageest susceptible d'encompromettre le fonctionnement.
This radio transmitter (ISED certification number: 216A-TNPA6600) has been approved by Industry Canada to
operate with the maximum permissible gain indicated. Strictly prohibited for use with thisdevice with
maximum antenna gain.
Le présentémetteur radio (ISED certification number: 216A-TNPA6600) a étéapprouvée par industriecanada
pour fonctionner avec le gain maximal indiqué.strictementinterdite pour utilisation avec cedispositif avec le
maximum de gain d'antenne.
Radiation Exposure Statement
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20 cm between the radiator and
your body.
Déclarationd'exposition aux radiations
Cetéquipementestconforme Canada limitesd'exposition aux radiations dans un environnement non contrôlé.
Cetéquipementdoitêtreinstallé et utilisé à distance minimum de 20cm entre le radiateur et votre corps.
This device is intended only for OEM integrators under the following condition:
The transmitter module may not be co-located with any other transmitter or antenna.
As long as the condition above is met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements
required with this module installed.
Cetappareilestconçuuniquement pour les intégrateurs OEM dans les conditions suivantes:
Le module émetteurpeut ne pas êtrecoïmplanté avec unautreémetteurouantenne.
Tant que les 1 condition ci-dessussontremplies, des essaissupplémentaires sur l'émetteur ne seront pas
nécessaires. Toutefois, l'intégrateur OEM esttoujoursresponsable des essais sur son produit final pour
toutesexigences de conformitésupplémentairesrequis pour ce module installé.
Important Note:
In the event that these conditions cannot be met (for example certain laptop configurations or co-location
with another transmitter), then the Canada authorization is no longer considered valid and the IC cannot be
used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the
end product (including the transmitter) and obtaining a separate Canada authorization.
Note Importante:
Dans le casoùces conditions ne peuventêtresatisfaites (par exemple pour certaines configurations
d'ordinateur portable ou de certaines co-localisation avec un autreémetteur), l'autorisation du Canada n'est
plus considérécommevalide et l' IC ne peut pas êtreutilisé sur le produit final. Danscescirconstances,
l'intégrateur OEM sera chargé de réévaluer le produit final (y comprisl'émetteur)
etl'obtentiond'uneautorisationdistincte au Canada.
End Product Labeling
The final end product must be labeled in a visible area with the following: Contains IC:216A-TNPA6600.
Plaque signalétique du produit final
Le produit final doitêtreétiquetédansunendroit visible avec l'inscriptionsuivante: Contient des IC:216A-
TNPA6600.
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Manuel d'information à l'utilisateur final
L'intégrateur OEM doitêtreconscient de ne pas fournir des informations à l'utilisateur final quant à la
façond'installerou de supprimerce module RF dans le manuel de l'utilisateur du produit final qui intègrece
module.
Le manuel de l'utilisateur final doitincluretoutes les informationsréglementairesrequises et
avertissementscommeindiquédanscemanuel.
Caution:
(i) The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential
for harmful interference to co-channel mobile satellite systems;
(ii) For devices with detachable antenna(s), the maximum antenna gain permitted for devices in the
bands 5250-5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the
EIRP limit;
(iii) For devices with detachable antenna(s), the maximum antenna gain permitted for devices in the
band 5725-5850 MHz shall be such that the equipment still complies with the EIRP limits specified for
point-to-point and non-point-to-point operation as appropriate; and operations in the 5.25-5.35GHz
band are restricted to indoor usage only.
Avertissement:
(i) les dispositifsfonctionnantdans la bande de 5150 à 5250MHz sontréservésuniquement pour
uneutilisation à l'intérieurafin de réduire les risques de brouillagepréjudiciable aux systèmes de
satellites mobiles utilisant les mêmescanaux;
(ii) pour les dispositifsmunisd'antennesamovibles, le gain maximal d'antennepermis pour les
dispositifsutilisant les bandes de 5250 à 5350MHz et de 5470 à 5725 MHz doitêtreconforme à la
limite de la p.i.r.e;
(iii) pour les dispositifsmunisd'antennesamovibles, le gain maximal d'antennepermis (pour les
dispositifsutilisant la bande de 5725 à 5850 MHz) doitêtreconforme à la limite de la p.i.r.e. spécifiée
pour l'exploitation point à point et l'exploitation non point à point, selon le cas;Les opérationsdans la
bande de 5.25-5.35GHz sontlimités à unusageintérieurseulement.
