Panasonic KX TG5671 TG5671_72_73(e) User Manual To The 669dbf03 A6a3 4ce4 Ac3d 66d9c4cd9a49

User Manual: Panasonic KX-TG5671 to the manual

Open the PDF directly: View PDF .
Page Count: 64

This unit is compatible with Caller ID. To use this feature, you must subscribe to

the appropriate service offered by your service provider.

Please read these Operating Instructions before using the unit and save for

future reference.

For assistance, visit our website:

http://www.panasonic.com/phonehelp for customers in the U.S.A. or Puerto

Rico.

Charge the handset battery for 7 hours before initial use.

Operating Instructions

5.8 GHz Digital Cordless

Answering System

Model No. KX-TG5671

5.8 GHz Expandable Digital Cordless

Answering System with Two Handsets

Model No. KX-TG5672

5.8 GHz Digital Cordless

Answering System with Three Handsets

Model No. KX-TG5673

Model shown is KX-TG5671.

Table of Contents

2For assistance, please visit http://www.panasonic.com/phonehelp

Introduction

Introduction. . . . . . . . . . . . . . . . . . . . . . . 3

About these operating instructions . . . . . 4

Accessory information . . . . . . . . . . . . . . 6

Important safety instructions . . . . . . . . . 8

For best performance. . . . . . . . . . . . . . 10

Preparation

Setting up the base unit . . . . . . . . . . . . 11

Setting up the handset . . . . . . . . . . . . . 12

Controls . . . . . . . . . . . . . . . . . . . . . . . . 15

Displays . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting the unit before use . . . . . . . . . . 18

Making/Answering Calls

Making calls . . . . . . . . . . . . . . . . . . . . . 19

Answering calls . . . . . . . . . . . . . . . . . . 20

Useful features during a call. . . . . . . . . 21

Phonebook

Handset phonebook . . . . . . . . . . . . . . . 24

Copying handset phonebook items . . . 26

Base Unit Speed Dialer

Base unit speed dialer . . . . . . . . . . . . . 27

Caller ID Service

Using Caller ID service. . . . . . . . . . . . . 28

Caller list. . . . . . . . . . . . . . . . . . . . . . . . 30

Programming

Programmable settings . . . . . . . . . . . . 32

Answering System

Answering system . . . . . . . . . . . . . . . . 36

Listening to messages using the base

unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Listening to messages using the

handset. . . . . . . . . . . . . . . . . . . . . . . . . 38

Voice memo . . . . . . . . . . . . . . . . . . . . . 39

Remote operation. . . . . . . . . . . . . . . . . 39

Answering system settings . . . . . . . . . . 41

Multi-unit Operation

Intercom . . . . . . . . . . . . . . . . . . . . . . . . 43

Transferring calls, conference calls . . . 44

Registering a handset. . . . . . . . . . . . . . 46

Useful Information

Wall mounting. . . . . . . . . . . . . . . . . . . . 47

Headset (optional) . . . . . . . . . . . . . . . . 49

Error messages . . . . . . . . . . . . . . . . . . 50

Troubleshooting . . . . . . . . . . . . . . . . . . 51

FCC and other information . . . . . . . . . . 55

Specifications . . . . . . . . . . . . . . . . . . . . 58

Warranty. . . . . . . . . . . . . . . . . . . . . . . . 59

Customer services . . . . . . . . . . . . . . . . 61

Index

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Introduction

For assistance, please visit http://www.panasonic.com/phonehelp 3

Introduction

Thank you for purchasing a Panasonic cordless telephone.

We recommend keeping a record of the following information for future reference.

Attach your purchase receipt here.

Serial No. Date of purchase

(found on the bottom of the base unit)

Name and address of dealer

ENERGY STAR

As an ENERGY STAR® Participant, Panasonic has determined

that this product meets the ENERGY STAR guidelines for energy

efficiency. ENERGY STAR is a U.S. registered mark.

Introduction

4For assistance, please visit http://www.panasonic.com/phonehelp

About these operating instructions

These operating instructions can be used for KX-TG5671/KX-TG5672/KX-TG5673.

Descriptions of the multiple handsets and chargers

The following models include 2 or more handsets and a charger(s). Descriptions of the

multiple handsets and chargers in these operating instructions are for the following

models only:

Special feature

NSlow Talk®

You can slow down the voice of the person you are talking to, making it easier to hear

and understand.

KX-TG5672 KX-TG5673

Introduction

For assistance, please visit http://www.panasonic.com/phonehelp 5

Symbols used in these operating instructions

Expanding your phone system

KX-TG5672 users can expand the system by adding an accessory handset sold

separately (max. 3 handsets).

Symbol Meaning

Example: “Ringer ID”Press {^} or {V} to select the words in quotations

shown on the display.

iProceed to the next operation.

Example: {MENU},

{Phonebook}

The words in the brackets indicate button names

including soft key names (page 17) on the handset

and base unit.

Example:

{MENU}i{0}{5}{1}i

Select the desired setting. i

{Save}i{OFF}

Press {MENU}, then press {0},{5},{1}. Press {^}

or {V} to select the desired setting. Press {Save},

then press {OFF}.

Accessory handset (up to 1)

KX-TGA560

Introduction

6For assistance, please visit http://www.panasonic.com/phonehelp

Accessory information

Included accessories

*1 Both of the AC adaptors function well.

*2 The handset cover comes attached to the handset.

1234

No. Accessory item Order number

Quantity

KX-TG

5671S KX-TG

5672B KX-TG

5673B

1AC adaptor for base unit PQLV1W or *1

PQLV256Z 111

2Telephone line cord PQJA10075Z 1 1 1

3Wall mounting adaptor PQKL10068Z1 1 – –

PQKL10068Z2 – 1 1

4Battery HHR-P104 1 2 3

5Handset cover*2 PQYNTG5631SR 1 – –

PQYNTG5633BR – 2 3

6Charger PQLV30042ZB – 1 2

AC adaptor for charger KX-TCA1-2 or *1

PQLV256Z –12

Introduction

For assistance, please visit http://www.panasonic.com/phonehelp 7

Additional/replacement accessories

Sales and support information

LTo order additional/replacement accessories, call 1-800-332-5368.

LTTY users (hearing or speech impaired users) can call 1-866-605-1277.

Accessory item Order number

Rechargeable nickel metal

hydride (Ni-MH) battery HHR-P104

Accessory handset with charger KX-TGA560

Headset KX-TCA60, KX-TCA86, KX-TCA88HA, KX-TCA91,

KX-TCA92, or KX-TCA98

T-adaptor KX-J66

Battery back-up power supply KX-TCA200

Accessory item KX-TG5671S KX-TG5672B KX-TG5673B

Belt clip PQKE10396Z1 PQKE10396Z3 PQKE10396Z3

Introduction

8For assistance, please visit http://www.panasonic.com/phonehelp

Important safety

instructions

When using the product, basic safety

precautions should always be followed to

reduce the risk of fire, electric shock, or

personal injury.

1. Read all instructions carefully.

2. Follow all warnings and instructions

marked on the product.

3. Unplug the product from power outlets

before cleaning. Do not use liquid or

aerosol cleaners. Use a moist cloth for

cleaning.

4. Do not use the product near water, for

example near a bathtub, wash bowl,

kitchen sink, etc.

5. Place the product securely on a stable

surface. Serious damage and/or injury

may result if the product falls.

6. Do not cover slots and openings on the

product. They are provided for

ventilation and protection against

overheating. Never place the product

near radiators, or in a place where

proper ventilation is not provided.

7. Use only the power source marked on

the product. If you are not sure of the

type of power supplied to your home,

consult your dealer or local power

company.

8. Do not place objects on the power

cord. Install the product where no one

can step or trip on the cord.

9. Do not overload power outlets and

extension cords. This can result in the

risk of fire or electric shock.

10. Never push any objects through slots

in the product. This may result in the

risk of fire or electric shock. Never spill

any liquid on the product.

11. To reduce the risk of electric shock, do

not disassemble the product. Take the

product to an authorized service center

when service is required. Opening or

removing covers may expose you to

dangerous voltages or other risks.

Incorrect reassembly can cause

electric shock when the product is

subsequently used.

12. Unplug the product from power outlets

and take to an authorized service

center when the following conditions

occur:

A. When the power cord is damaged

or frayed.

B. If liquid has been spilled into the

product.

C. If the product has been exposed to

rain or water.

D. If the product does not work

normally by following the operating

instructions. Adjust only controls

covered by the operating

instructions. Improper adjustment

may require extensive work by an

authorized service center.

E. If the product has been dropped or

physically damaged.

F. If the product exhibits a distinct

change in performance.

13. During thunderstorms, avoid using

telephones except cordless types.

There may be a remote risk of an

electric shock from lightning.

14. Do not use the product to report a gas

leak, when in the vicinity of the leak.

SAVE THESE

INSTRUCTIONS

Introduction

For assistance, please visit http://www.panasonic.com/phonehelp 9

CAUTION:

Installation

LNever install telephone wiring during a

lightning storm.

LNever install telephone jacks in wet

locations unless the jack is specifically

designed for wet locations.

LNever touch uninsulated telephone

wires or terminals unless the telephone

line has been disconnected at the

network interface.

LUse caution when installing or modifying

telephone lines.

LDo not touch the plug with wet hands.

LThe AC adaptor is used as the main

disconnect device. Ensure that the AC

outlet is installed near the product and is

easily accessible.

Battery

To reduce the risk of fire or injury to

persons, read and follow these

instructions.

LUse only the battery(ies) specified.

LDo not dispose of the battery(ies) in a

fire. They may explode. Check with local

waste management codes for special

disposal instructions.

LDo not open or mutilate the battery(ies).

Released electrolyte is corrosive and

may cause burns or injury to the eyes or

skin. The electrolyte may be toxic if

swallowed.

LExercise care when handling the

battery(ies). Do not allow conductive

materials such as rings, bracelets or

keys to touch the battery(ies), otherwise

a short circuit may cause the battery(ies)

and/or the conductive material to

overheat and cause burns.

LCharge the battery(ies) provided, or

identified for use with the product only, in

accordance with the instructions and

limitations specified in this manual.

WARNING:

LTo prevent the risk of fire or electrical

shock, do not expose the product to rain

or any type of moisture.

LUnplug the product from power outlets if

it emits smoke, an abnormal smell, or

makes an unusual noise. These

conditions can cause fire or electric

shock. Confirm that smoke has stopped

emitting and contact the Panasonic Call

Center at 1-800-211-PANA (1-800-211-

7262).

Medical

LConsult the manufacturer of any

personal medical devices, such as

pacemakers or hearing aids, to

determine if they are adequately

shielded from external RF (radio

frequency) energy. (The product

operates in the frequency range of 5.76

GHz to 5.84 GHz, and the power output

is 200 mW (max.).) Do not use the

product in health care facilities if any

regulations posted in the area instruct

you not to do so. Hospitals or health care

facilities may be using equipment that

could be sensitive to external RF energy.

Introduction

10 For assistance, please visit http://www.panasonic.com/phonehelp

For best performance

Base unit location/avoiding noise

The base unit and other compatible

Panasonic units use radio waves to

communicate with each other.

For maximum distance and noise-free

operation, we recommend the following:

LPlacing the product away from electrical

appliances.

LPlacing the base unit in a HIGH and

CENTRAL location with no obstructions

such as walls.

LRaising the antennas vertically.

LIf you use the handset near a microwave

oven which is being used, noise may be

heard. Move away from the microwave

oven and closer to the base unit.

LIf you use the handset near another

cordless phone’s base unit, noise may

be heard. Move away from the other

cordless phone’s base unit and closer to

your base unit.

Environment

LKeep the product away from electrical

noise generating devices, such as

fluorescent lamps and motors.

LThe product should be kept free from

excessive smoke, dust, high

temperature, and vibration.

LThe product should not be exposed to

direct sunlight.

LDo not place heavy objects on top of the

product.

LWhen you leave the product unused for

a long period of time, unplug the product

from the power outlet.

LThe product should be kept away from

heat sources such as heaters, kitchen

stoves, etc. It should not be placed in

rooms where the temperature is less

than 5 °C (41 °F) or greater than 40 °C

(104 °F). Damp basements should also

be avoided.

LThe maximum calling distance may be

shortened when the product is used in

the following places: Near obstacles

such as hills, tunnels, underground, near

metal objects such as wire fences, etc.

LOperating near 5.8 GHz electrical

appliances may cause interference.

Move away from the electrical

appliances.

Routine care

LWipe the outer surface of the product

with a soft moist cloth. Do not use

benzine, thinner, or any abrasive

powder.

Preparation

For assistance, please visit http://www.panasonic.com/phonehelp 11

Setting up the base unit

Connecting the AC adaptor and

telephone line cord

Connect the telephone line cord until it

clicks into the base unit (A) and telephone

line jack (B). Connect the AC adaptor cord

by pressing the plug firmly (C).

LUse only the included Panasonic AC

adaptor PQLV1 or PQLV256.

Note:

LThe AC adaptor must remain connected

at all times. (It is normal for the adaptor

to feel warm during use.)

LThe AC adaptor should be connected to

a vertically oriented or floor-mounted AC

outlet. Do not connect the AC adaptor to

a ceiling-mounted AC outlet, as the

weight of the adaptor may cause it to

become disconnected.

LThe unit will not work during a power

failure. We recommend connecting a

standard telephone to the same

telephone line or to the same telephone

jack using a Panasonic T-adaptor (page

7). Emergency power can be supplied to

the unit by connecting a Panasonic

battery back-up power supply noted on

page 7.

If you subscribe to a DSL service

Please attach a noise filter (contact your

DSL provider) to the telephone line

between the base unit and the telephone

line jack in the event of the following:

– Noise is heard during conversations.

– Caller ID features (page 28) do not

function properly.

Hook

(120 V AC,

60 Hz)

To single-line

telephone jack

(RJ11C)

Noise filter

To single-line

telephone

jack (RJ11C)

Preparation

12 For assistance, please visit http://www.panasonic.com/phonehelp

Setting up the handset

Connecting the charger

LUse only the included Panasonic AC

adaptor KX-TCA1 or PQLV256.

Battery installation/replacement

1Press the notch of the handset cover

firmly, and slide it in the direction of the

arrow.

LIf necessary, remove the old battery.

2Insert the battery (A), and press it

down until it snaps into position (B).

Then close the handset cover.

Important:

LUse only the rechargeable Panasonic

battery noted on page 7.

Available model:

KX-TG5672/KX-TG5673

Fasten the AC adaptor cord to prevent

it from being disconnected.

(120 V AC, 60 Hz)

Bottom of the charger

Hooks

Preparation

For assistance, please visit http://www.panasonic.com/phonehelp 13

Attention:

A nickel metal hydride battery that is

recyclable powers the product you have

purchased.

Please call 1-800-8-BATTERY (1-800-

822-8837) for information on how to

recycle this battery.

Battery charge

Place the handset on the base unit or

charger for 7 hours before initial use.

While charging, “Charging” is displayed

and the CHARGE indicator on the base

unit lights. When the battery is fully

charged, “Charge completed” is

displayed.

Base unit:

Charger:

Note:

LIf you want to use the unit immediately,

charge the battery for at least 15

minutes.

LTo ensure that the battery charges

properly, clean the charge contacts of

the handset, base unit, and charger with

a soft, dry cloth once a month. Clean

more often if the unit is subject to the

exposure of grease, dust, or high

humidity.

Available model:

KX-TG5672/KX-TG5673

Charge

contacts

Preparation

14 For assistance, please visit http://www.panasonic.com/phonehelp

Battery level

Note:

LWhen the battery needs to be charged,

the handset beeps intermittently while it

is in use.

Panasonic battery performance

Note:

LBattery operating time may be

shortened over time depending on

usage conditions and surrounding

temperature.

LBattery power is consumed whenever

the handset is off the base unit or

charger, even when the handset is not in

use. Hence the longer you leave the

handset off the base unit or charger, the

less time you may actually talk using the

handset.

LAfter the handset is fully charged,

displaying “Charge completed”, it

may be left on the base unit (or charger)

without any ill effect on the battery.

LThe battery level may not be displayed

correctly after you replace the battery. In

this case, place the handset on the base

unit (or charger) and let charge for 7

hours.

Battery icon Battery level

5Fully charged

6Medium

7Low

Flashing: needs to be

recharged.

8Empty

Operation Operating time

While in use

(talking) Up to 5 hours

While not in use

(standby) Up to 11 days

While using the

clarity booster

feature (page 22)

Up to 3 hours

Preparation

For assistance, please visit http://www.panasonic.com/phonehelp 15

Controls

Base unit

ADisplay

B{ERASE}

C{ANSWER ON}

ANSWER ON indicator

DNavigator key ({^} {V} {<}{>})

E{MEMO}

FMESSAGE indicator

G{MESSAGE}

H{STOP}

I{GREETING REC} (Recording)

J{GREETING CHECK}

KAntenna

LSpeaker

MCharge contacts

N{PROGRAM}{AUTO}

O{MUTE}

P{CALL WAIT}{FLASH}

Q{REDIAL}{PAUSE}

RCHARGE indicator

SIN USE indicator

T{*} (TONE)

UMIC (Microphone)

V{1}{2}{3} (extension number)

W{SP-PHONE} (Speakerphone)

SP-PHONE indicator

X{HOLD}

Y{CONF} (Conference)

Z{INTERCOM}{TRANSFER}

INTERCOM indicator

ABCD E

FG H IJ

KKL

MNOPQRSTU

VW X ZY

Preparation

16 For assistance, please visit http://www.panasonic.com/phonehelp

Handset

ASpeaker

BSoft keys

CHeadset jack

D{C} (TALK)

ENavigator key ({^} {V} {<}{>})

F{s} (SP-PHONE)

G{*} (TONE)

H{FLASH}{CALL WAIT}

IMicrophone

JCharge contacts

KRinger indicator

Message indicator

LReceiver

MDisplay

N{MENU}

O{OFF}

P{PAUSE}{REDIAL}

Q{HOLD}{INTERCOM}

Note:

LSome operations not mentioned above

are displayed as soft key selections

during operation (page 17).

Example: {Mute}

Using the navigator key

The handset navigator key can be used to

navigate through menus and to select

items shown on the display, by pressing

{^},{V},{<}, or {>}.

Adjusting audio volume

Press {^} or {V} repeatedly while talking.

{V}

{^}

{<}{>}

Preparation

For assistance, please visit http://www.panasonic.com/phonehelp 17

Handset soft keys

The handset features 2 soft keys. By

pressing a soft key, you can select the

feature shown directly above it on the

display.

{Select},{Save},{OK} and additional

other functions are assigned to soft keys,

pay attention to soft keys to find functions

you need during handset operation.

Note:

LIn these operating instructions, soft key

names are written inside brackets, the

same way as other unit keys.

Example:

Unit keys: {C},{OFF}, etc.

Soft keys: {Rcvd calls},{Phonebook},

etc.

Displays

Base unit display items

*1 KX-TG5672/KX-TG5673

Handset display items

Rcvd Phone

calls book

Displayed

item Meaning

EFlashes when message

memory is full.

EFlashes when the date and

time need to be set.

OBase unit ringer is off.

EGreeting or memo

message recording error

9@ Answering system is in

greeting only mode (caller

messages are not

recorded).

H1 Handset number; displayed

when paging, being paged,

or registering*1.

PBase unit is in

programming mode.

Displayed

item Meaning

JVoice enhancer is on.

5Battery level

Preparation

18 For assistance, please visit http://www.panasonic.com/phonehelp

Setting the unit before

use

Display language

The default setting is “English”.

1{MENU}i{0}{8}

2Select the desired setting.

3Press the right soft key to save. i

{OFF}

Dialing mode

If you cannot make calls, change this

setting depending on your telephone line

service. The default setting is “Tone”.

“Tone”: For tone dial service.

“Pulse”: For rotary pulse dial service.

1{MENU}i{0}{5}{1}

2Select the desired setting. i{Save}

i{OFF}

Date and time

Set the correct date and time. When you

play back a message from the answering

system (page 37), the unit announces the

day and time it was recorded.

1{MENU}i{4}

2Enter the current month, day, and year

by selecting 2 digits for each.

Example: August 15, 2006

{0}{8}{1}{5}{0}{6}

3Enter the current hour and minute (12-

hour clock format) by selecting 2 digits

for each.

Example: 9:30

{0}{9}{3}{0}

4Press {AM/PM} to select “AM” or “PM”.

i{Save}i{OFF}

Note:

LIf you make a mistake when entering the

date and time, press {<},{>},{^}, or

{V} to move the cursor, then make the

correction.

Making/Answering Calls

For assistance, please visit http://www.panasonic.com/phonehelp 19

Making calls

Using the handset

1Lift the handset and dial the phone

number.

LTo correct a digit, press {Clear}.

2Press {C} or {Call}.

3When you finish talking, press {OFF} or

place the handset on the base unit or

charger.

Note:

L“Line in use” is displayed when

someone is talking on another handset

(KX-TG5672/KX-TG5673) or another

phone.

Using the speakerphone

1Lift the handset, dial the phone number,

and press {s}.

LSpeak alternately with the other party.

2When you finish talking, press {OFF}.

Note:

LUse the speakerphone in a quiet

environment.

LTo switch to the receiver, press {C}.

Adjusting the receiver/speaker volume

Press {^} or {V} repeatedly while talking.

Making a call using the redial list

The last 5 phone numbers dialed are

stored in the redial list.

1{REDIAL}

2Press {^} or {V} to select the desired

number.

3{C}

Erasing a number in the redial list

1{REDIAL}

2Press {^} or {V} to select the desired

number. i{Erase}i{Yes}i

{OFF}

PAUSE button (for PBX/long distance

service users)

A pause is sometimes required when

making calls using a PBX or long distance

service.

For example, if you need to dial the line

access number “9” when making outside

calls with a PBX:

1{9}i{PAUSE}i Dial the phone

number.

2{C}

Note:

LA 3.5 second pause is inserted each

time {PAUSE} is pressed. Press

repeatedly to insert longer pauses.

Making/Answering Calls

20 For assistance, please visit http://www.panasonic.com/phonehelp

Using the base unit

1{SP-PHONE}

2Dial the phone number.

3When the other party answers, speak

into the MIC.

LSpeak alternately with the other party.

4When you finish talking, press {SP-

PHONE}.

Note:

LUse the speakerphone in a quiet

environment.

LWhile on a call, you can switch from the

base unit to the handset:

– Press {C} on the handset, then

press {SP-PHONE} on the base unit.

– If the handset is on the base unit,

simply lift it.

Adjusting the speaker volume

Press {^} or {V} repeatedly while talking.

Redialing the last number dialed

{SP-PHONE}i{REDIAL}

Answering calls

When a call is being received, the ringer

indicator on the handset and IN USE

indicator on the base unit flash rapidly.

Using the handset

1Lift the handset and press {C} or {s}.

LYou can also answer the call by

pressing any button except {^},{V},

{<},{>}, or {OFF}.(Any key talk

feature)

2When you finish talking, press {OFF}.

Note:

LYou can change the ringer indicator light

color and the ringer tone. You can also

adjust the handset ringer volume (page

34).

Auto talk

This feature allows you to answer a call by

simply lifting the handset off the base unit

or charger. You do not need to press {C}.

To activate this feature, see page 34.

Temporary ringer off

While the handset is ringing for an outside

call, you can turn the ringer off temporarily

by pressing {OFF}.

Making/Answering Calls

For assistance, please visit http://www.panasonic.com/phonehelp 21

Using the base unit

1{SP-PHONE}

2Speak into the MIC.

3When you finish talking, press {SP-

PHONE}.

Adjusting the ringer volume

Press {^} or {V} repeatedly to select the

desired volume when in standby mode.

LTo turn the ringer off, press and hold {V}

until the unit beeps 2 times.

Setting the ringer tone

There are 3 tones.

1Press {^} or {V}.

2Within 10 seconds, press {<} or {>}

repeatedly to select the desired tone.

Useful features during a

call

HOLD button

This feature allows you to put an outside

call on hold.

1Press {HOLD} during an outside call.

LTo transfer the call to another

extension, continue from step 2 on

page 44, “Transferring calls,

conference calls”.

2Press {HOLD} again.

LTo release the hold, press {C}.

LThe base unit user can take the call

by pressing {SP-PHONE}.

LAnother handset user can take the

call by pressing {C}.

Press {HOLD} during an outside call.

LTo release the hold, press {SP-

PHONE}.

LHandset users can take the call by

pressing {C}.

Note for handset and base unit:

LIf another phone is connected on the

same line (page 11), you can also take

the call by lifting its handset.

LIf a call is kept on hold for more than 6

minutes, an alarm tone starts to sound.

After 4 additional minutes on hold, the

call is disconnected.

Handset

Base unit

Making/Answering Calls

22 For assistance, please visit http://www.panasonic.com/phonehelp

Mute

While mute is turned on, you can hear the

other party, but the other party cannot hear

you.

To mute your voice, press {Mute}.

LTo return to the conversation, press

{Mute} or {C}.

Note:

L{Mute} is a soft key visible on the

handset display during a call.

To mute your voice, press {MUTE}.

LTo return to the conversation, press

{MUTE} or {SP-PHONE}.

FLASH button

Pressing {FLASH} allows you to use

special features of your host PBX such as

transferring an extension call, or accessing

optional telephone services such as Call

Waiting.

Note:

LTo change the flash time, see page 35.

For Call Waiting service users

To use Call Waiting, you must subscribe to

your telephone company’s Call Waiting

service.

This feature allows you to receive calls

while you are already talking on the phone.

If you receive a call while on the phone,

you will hear a Call Waiting tone. Please

contact your telephone company for

details and availability of this service in

your area.

Press {CALL WAIT} to answer the 2nd

call.

LTo switch between calls, press {CALL

WAIT}.

Temporary tone dialing (for rotary/

pulse service users)

You can temporarily switch the dialing

mode to tone when you need to access

touch tone services (for example,

answering services, telephone banking

services, etc.).

Press {*} (TONE) before entering access

numbers which require tone dialing.

Handset clarity booster

This feature can improve sound clarity

when the handset is used in an area where

there may be interference. During an

outside call, this feature is turned on

automatically when necessary. You can

also turn this feature on or off manually.

1Press {MENU} during an outside call.

2Press {2} to select “Booster on” or

“Booster off”.

Note:

LWhen this feature is turned off manually

during a call, it does not turn on

automatically during the same call.

LWhile this feature is turned on;

– the battery operating time is

shortened (page 14).

– the maximum number of extensions

that can be used at a time may

decrease when you have 3 handsets.

Handset

Base unit

Making/Answering Calls

For assistance, please visit http://www.panasonic.com/phonehelp 23

Handset voice enhancer

This feature clarifies the voice of the

person you are talking to, reproducing a

more natural-sounding voice that is easier

to hear and understand (page 35).

1Press {MENU} during an outside call.

2Press {3} to select “V.E. on” or “V.E.

off”.

LWhen this feature is turned on, J

is displayed.

Note:

LDepending on the condition and quality

of your telephone line, this feature may

emphasize existing line noise. If it

becomes difficult to hear, turn this

feature off.

Handset Slow Talk

This feature works to help slow down the

incoming audio when two parties are

having a two way conversation.

Important:

LYou cannot use this feature when;

– you are on a conference call,

– you are listening to messages in the

answering system,

– another unit is using the answering

system, or

– another handset is having an intercom

call with the base unit (KX-TG5672/

KX-TG5673).

Press {Slow} during an outside call.

L“Slow” starts blinking.

LTo turn this feature off, press {Slow}

again. “Slow” stops blinking.

Note:

LThis feature turns off if another handset

starts to have an intercom call with the

base unit (KX-TG5672/KX-TG5673), or

another unit starts to use the answering

system.

LThis feature turns off after you hang up

the call.

LThe speed may become close to normal

when the handset receives constant

incoming audio for a period of time.

Call share

This feature allows the handset and base

unit to join an existing outside call.

To join the conversation, press {C} when

the other extension is on an outside call.

To join the conversation, press {SP-

PHONE} when the handset is on an

outside call.

Note for handset and base unit:

LA maximum of 4 parties (including 1

outside party) can join a conversation

using 3 extensions (KX-TG5672/KX-

TG5673).

Handset

Base unit

Phonebook

24 For assistance, please visit http://www.panasonic.com/phonehelp

Handset phonebook

You can add up to 50 items to the handset

phonebook and search for phonebook

items by name.

Adding items to the phonebook

1{Phonebook}

2{Add}

3Enter the name (max. 16 characters).

i{Next}

4Enter the phone number (max. 32

digits). i{Next}i{Save}

LTo add other items, repeat from step

5{OFF}

Note:

LCaller ID subscribers can use ringer ID

and light-up ID features (page 29).

Character table

LTo enter another character that is

located on the same dial key, first press

{>} to move the cursor to the next

space.

Editing/correcting a mistake

Press {<} or {>} to move the cursor to the

character or number you want to erase,

then press {Clear}. Enter the appropriate

character or number.

LPress and hold {Clear} to erase all

characters or numbers.

Finding and calling a

phonebook item

Phonebook items can be searched for

alphabetically by scrolling through the

phonebook items or by entering the first

initial.

Searching for a name alphabetically by

scrolling through all items

1{Phonebook}i{Search}

2Press {^} or {V} to select the desired

item.

3Press {C} to dial the phone number.

Key Character

{1}&’(),–./1

{2}abcABC2

{3}def DEF3

{4}ghi GHI 4

{5}jklJKL5

{6}mn o MNO6

{7}pqr sPQRS7

{8}tuvTUV8

{9}wxyzWXYZ9

{0}0Space

{*} ;

{#} #

Key Character

Phonebook

For assistance, please visit http://www.panasonic.com/phonehelp 25

Searching for a name by initial

1{Phonebook}i{Search}

2Press the dialing button ({0} to {9},

{#}, or {*}) that corresponds to the

first letter you are searching for (see the

character table, page 24).

Example: “LISA”

Press {5} repeatedly to display the first

phonebook entry starting with the initial

“L” and go to step 3.

LIf there is no item corresponding to

the letter you selected, the next item

is displayed.

3Press {V} to select the desired item.

4Press {C} to dial the phone number.

Editing items in the phonebook

1Find the desired item (page 24, 25). i

{Option}i “Edit”i{Select}

2Edit the name if necessary (see the

character table, page 24). i{Next}

3Edit the phone number if necessary.

i{Next}i{Save}i{OFF}

Erasing items in the phonebook

1Find the desired item (page 24, 25).

2{Erase}i{Yes}i{OFF}

Chain dial

This feature allows you to dial phone

numbers in the handset phonebook while

you are on a call. This feature can be used,

for example, to dial a calling card access

number or bank account PIN that you have

stored in the handset phonebook, without

having to dial manually.

1During an outside call, press {MENU}.

2“Phonebook”i{Select}

3Find the desired item (page 24, 25). i

{Call}

Note:

LWhen storing a calling card access

number and your PIN in the phonebook

as one phonebook item, press {PAUSE}

to add pauses after the number and PIN

as necessary (page 19).

LIf you have rotary or pulse service, you

need to press {*} before pressing

{MENU} in step 1 to change the dialing

mode temporarily to tone.

Phonebook

26 For assistance, please visit http://www.panasonic.com/phonehelp

Copying handset

phonebook items

You can copy one or all of the phonebook

items from one handset to another.

Important:

LRinger ID and light-up ID settings for

phonebook items are not copied.

Copying an item

1{MENU}i{#}{1}

2Select the destination unit by pressing

{^} or {V}.i{Next}

3Find the desired item (page 24, 25). i

{Send}

4Press {OFF} after the long beep.

Copying all items

1{MENU}i{#}{2}

2Select the destination unit by pressing

{^} or {V}.i{Send}

3Press {OFF} after the long beep.

Available model:

KX-TG5672/KX-TG5673

Base Unit Speed Dialer

For assistance, please visit http://www.panasonic.com/phonehelp 27

Base unit speed dialer

You can assign one phone number to each

of the 10 dial keys ({0}–{9}) on the base

unit.

Adding phone numbers to the

speed dialer

Important:

LBefore storing phone numbers, make

sure the base unit is not being used.

1{PROGRAM}

2Enter the phone number (max. 32

digits).

LIf a pause is required for dialing,

press {PAUSE} where needed.

LIf you misdial, press {STOP} and

repeat from step 1.

3{PROGRAM}

4Press a dial key ({0}–{9}).

Note:

LIf a phone number is stored in a dial key

which already contains a phone number,

the old number will be erased.

LWe recommend you make a note of

which phone numbers are stored in

which dial keys.

PAUSE button (for PBX/long distance

service users)

A pause is sometimes required when

making calls using a PBX or long distance

service.

For example, if you need to dial the line

access number “9” when making outside

calls with a PBX:

In step 2, press {9},{PAUSE}, then enter

the phone number.

Note:

LA 3.5 second pause is inserted each

time {PAUSE} is pressed. Press

repeatedly to insert longer pauses. “P”

is displayed when {PAUSE} is pressed.

LWhen {*} is pressed, “$” is displayed.

When {#} is pressed, “#” is displayed.

To erase a stored phone number

1Press {PROGRAM} 2 times.

2Press the desired dial key ({0}–{9}).

Calling someone with the speed

dialer

1{SP-PHONE}i{AUTO}

2Press the desired dial key ({0}–{9}).

Note:

LSpeed dial numbers stored in the base

unit can only be dialed from the base

unit.

Caller ID Service

28 For assistance, please visit http://www.panasonic.com/phonehelp

Using Caller ID service

This unit is Caller ID compatible. To use

Caller ID features, you must subscribe to

your telephone company’s Caller ID

service.

Caller ID features

When an outside call is being received, the

calling party’s name and telephone

number are displayed.

Caller information for the last 50 different

callers is logged in the caller list by the

most recent call to the oldest.

LGenerally caller information is displayed

from the 2nd ring.

LIf the unit cannot receive caller

information, the following is displayed:

–“Out of area”: The caller dialed

from an area which does not provide

Caller ID service.

–“Private caller”: The caller

requested not to send caller

information.

–“Long distance”: The caller called

you long distance.

LIf the unit is connected to a PBX system,

caller information may not be received

properly. Consult your PBX supplier.

Missed calls

If a call is not answered, the unit treats the

call as a missed call. The number of

missed calls is shown on the handset

display. This lets you know if you should

view the caller list to see who called while

you were out.

LThe number of missed calls can also be

shown on the multiple handsets (KX-

TG5672/KX-TG5673, page 30).

Call Waiting Caller ID display

If you subscribe to both Caller ID and Call

Waiting with Caller ID services, the 2nd

caller’s information is displayed after you

hear a Call Waiting tone (page 22). Please

contact your telephone company for

details and availability of this service in

your area.

Talking Caller ID

This feature lets you know who is calling

without looking at the display. When a call

comes in, the handset and base unit

announces the caller’s name displayed on

the handset following every ring.

To use this feature, you must subscribe to

your telephone company’s Caller ID

service.

LName pronunciation may vary. This

feature may not pronounce all names

correctly.

LCaller ID supports names of up to 15

letters. If the caller’s name has more

than 15 letters, the name is not

displayed or announced correctly.

LUsually the unit announces the caller’s

name after the 2nd ring. If you turn on

the answering system and set the ring

count to “2” (page 41), the unit does not

announce the caller’s name. If “Toll

saver” is selected and there is a new

message, the unit does not announce

the caller’s name.

LWhen you receive a call while on the

phone, the 2nd caller’s name is not

announced even if you subscribe to both

Caller ID and Call Waiting with Caller ID

services.

LThis feature can be turned on or off

(page 35).

Caller ID Service

For assistance, please visit http://www.panasonic.com/phonehelp 29

Ringer ID

This feature can help you identify who is

calling by using different ringers for

different callers stored in the phonebook.

You can assign a different ringer to each

phonebook item. When a call is received

from a caller stored in the phonebook, the

ringer is used after Caller ID information is

displayed.

If you select “No Ringer ID”, the

handset uses the ringer tone you selected

on page 34 when a call is received from

that caller. The default setting is “No

Ringer ID”.

1Find the desired item (page 24, 25). i

{Option}

2“Ringer ID”i{Select}

3Select the desired ringer tone.

4{Save}i{OFF}

Light-up ID

This feature can help you identify who is

calling by using different ringer indicator

colors for different callers stored in the

handset phonebook. You can assign a

different indicator color to each handset

phonebook item. When a call is received

from a caller stored in the handset

phonebook, the indicator color is used

after Caller ID information is displayed.

If you select “No Light-up ID”, the

handset uses the ringer indicator color you

selected on page 34 when a call is

received from that caller.

The default setting is “No Light-up ID”.

1Find the desired item (page 24, 25). i

{Option}

2“Light-up ID”i{Select}

3Select the desired ringer indicator color.

4{Save}i{OFF}

Caller ID Service

30 For assistance, please visit http://www.panasonic.com/phonehelp

Caller list

Viewing the caller list and calling back

1Press {^} or {V} to enter the caller list.

2Press {V} to search from the most

recent call, or {^} to search from the

oldest call.

3{C}

Note:

LKX-TG5672/KX-TG5673:

Each handset has its own caller list. If

you viewed the caller list or answered a

call on one handset, the same

information in the other handsets is

displayed as “missed calls”.

LYou can also press {Rcvd calls} to

enter the caller list.

LIf the same caller calls more than once, it

is displayed with the number of times the

caller called (“×2” to “×9”). Only the date

and time of the most recent call is

stored.

LAQ is displayed next to items which

have already been viewed or answered.

Editing a caller’s phone number before

calling back

You can edit a phone number in the caller

list by removing its area code and/or the

long distance code “1”.

1Press {^} or {V} to enter the caller list.

2Select the desired item. i{Select}

3Press {Edit} repeatedly until the phone

number is shown in the desired format.

1Local phone number

2Area code – Local phone number

31 – Area code – Local phone

number

4{C}

Caller ID number auto edit feature

Once you call back an edited number, the

unit can automatically edit other incoming

phone numbers each time you receive a

call.

For example, you can use this feature to

set the unit to ignore the area code of

callers in your area code, so that you can

call these local numbers using caller

information without dialing the area code.

To activate this feature, you must edit an

item in the caller list, then call that number.

After that, phone numbers from that

caller’s area code are edited automatically.

This feature can be turned on or off (page

34).

Note:

LPhone numbers from the 4 most recently

edited area codes are automatically

edited.

LIf you move to another area, you can

turn this feature off to erase previously

edited area codes. To use this feature

again, turn it on and reprogram the area

codes you want to edit once again.

Example:

321-5555

555-321-5555

1-555-321-5555

Caller ID Service

For assistance, please visit http://www.panasonic.com/phonehelp 31

Storing caller information into the

phonebook

1Press {^} or {V} to enter the caller list.

2Select the desired item. i{Select}

LTo edit the number, press {Edit}

repeatedly until the phone number is

shown in the desired format.

3{Save}

LIf there is the name information for

the caller, skip to step 5.

4Enter the name (see the character

table, page 24). i{Next}i{Save}

5{OFF}

Erasing selected caller information

1Press {^} or {V} to enter the caller list.

2Select the desired item.

3{Erase}i{Yes}i{OFF}

Erasing all caller information

1Press {^} or {V} to enter the caller list.

2{All erase}i{Yes}

Programming

32 For assistance, please visit http://www.panasonic.com/phonehelp

Programmable settings

You can customize the unit by programming the following features using the handset. To

access the features, there are 2 methods: scrolling through the display menus (page 32)

or using the direct commands (page 33).

LMainly the direct command method is used in these operating instructions.

Programming by scrolling through the display menus

1{MENU}

2Press {^} or {V} to select the desired menu. i{Select}

LIf there are sub-menu(s), press {^} or {V} to select the desired item. i{Select}

Example: To access the handset ringer tone setting

Press {^} or {V} to select “Ringer setting”. i{Select}

Then press {^} or {V} to select “Ringer tone”. i{Select}

3Press {^} or {V} to select the desired setting.

LThis step may vary depending on the feature being programmed.

4{Save}i{OFF}

Main menu Sub-menu 1 Sub-menu 2 Page

Message play – – page 38

Ringer setting Ringer volume ––

Ringer tone ––

Ring color ––

Date and time*1 – – page 18

Voice enhancer –––

Copy phonebook*2 Copy 1 item – page 26

Copy all items – page 26

Talking CallerID –––

Customer support – – page 35

Programming

For assistance, please visit http://www.panasonic.com/phonehelp 33

*1 If you program these settings using one of the handsets, you do not need to program

the same item using another handset (KX-TG5672/KX-TG5673).

*2 KX-TG5672/KX-TG5673

Programming using the direct commands

Initial setting Set answering Ring count*1 page 41

Recording time*1 page 42

Remote code*1 page 41

Message alert – page 42

LCD contrast ––

Key tone ––

Auto talk – page 20

Caller ID edit ––

Time adjustment*1 ––

Set tel line Set dial mode*1 page 18

Set flash time*1 –

Set line mode*1 –

Set base unit Talking CallerID*1 –

Registration – page 46

Change language – page 18

1{MENU}

2Enter the desired feature code.

3Enter the desired setting code.

LThis step may vary depending on the

feature being programmed.

4{Save}i{OFF}

Note:

LIn the following table:

– < > shows the default setting.

– If “System setting” column is checked,

you do not need to program the same

item using another handset (KX-

TG5672/KX-TG5673).

LIf you make a mistake or enter the wrong

code, press {OFF}, then start again by

pressing {MENU}.

Main menu Sub-menu 1 Sub-menu 2 Page

Programming

34 For assistance, please visit http://www.panasonic.com/phonehelp

Feature Feature

code Setting code System

setting

Auto talk*1 {0}{3}{1}:On {0}: <Off>–

Caller ID edit

(Caller ID number auto edit)

{0}{4}{1}: <On>{0}:Off

(page 30) –

Change language

(Display language)

{0}{8}{1}: <English>

{2}:Español (page 18) –

Copy phonebook (1 item)*2 {#}{1}(page 26) –

Copy phonebook (all items)*2 {#}{2}(page 26) –

Date and time {4}(page 18) r

Key tone*3 {0}{2}{1}: <On>{0}:Off –

LCD contrast

(Display contrast)

{0}{1}{1}–{6}: Level 1–6 <3> –

Message alert {0}{#} {1}:On {0}: <Off>–

Message play {2}––

Recording time {0}{6}{2}{1}:1min {2}:2min

{3}: <3min>

{0}:Greeting only

Registration {0}{0}(page 46) –

Remote code {0}{6}{3}(page 41) r

Ring color

(Ringer indicator color)

{1}{4}{1}: <Color1>=Amber

{2}:Color2=Green

{3}:Color3=Red

{4}:Multicolor

–

Ring count {0}{6}{1}{2}–{7}:2–7 rings <4>

{0}:Toll saver

Ringer tone (Handset)*4 {1}{2}{1}–{3}:Tone <1>–3

{4}–{7}:Melody 1–4

–

Ringer volume (Handset) {1}{1}{1}: Low {2}: Medium

{3}: <High> {0}: off –

Set dial mode {0}{5}{1}{1}:Pulse

{2}: <Tone> (page 18)

Programming

For assistance, please visit http://www.panasonic.com/phonehelp 35

*1 If you subscribe to Caller ID service and want to view the caller’s information after lifting

up the handset to answer a call, turn off this feature.

*2 KX-TG5672/KX-TG5673

*3 You can select whether or not key tones are heard when keys are pressed. Includes

confirmation tones and error tones.

*4 If you subscribe to a distinctive ring service (such as IDENTA-RING), select a tone

(tone 1 to 3). If you select a melody, you cannot distinguish lines by their ringers.

*5 The flash time depends on your telephone exchange or host PBX. Consult your PBX

supplier if necessary. The setting should stay at “700ms” unless pressing {FLASH}

fails to pick up the call waiting call.

*6 Generally, the line mode setting should not be adjusted. If “Line in use” is not

displayed when another phone connected to the same line is in use, you need to

change the line mode to “A”.

*7 This feature allows the unit to automatically adjust the date and time setting when caller

information is received. To use this feature, set the date and time first.

Customer support

The handset can display the Internet address where you can download operating

instructions or get further information for this product using your computer.

{MENU}i “Customer support”i{Select}i{OFF}

Set flash time*5 {0}{5}{2}{1}: <700ms>{2}:600ms

{3}:400ms {4}:300ms

{5}:250ms {6}:110ms

{7}:100ms {8}:90ms

Set line mode*6 {0}{5}{3}{1}:A{2}: <B>r

Talking CallerID

(Handset)

{9}{1}: <On>{0}:Off

(page 28) –

Talking CallerID

(Base unit)

{0}{*}{4}{1}: <On>{0}:Off

(page 28) –

Time adjustment*7

(Caller ID subscribers only)

{0}{9}{1}: <Caller ID[auto]>

{0}:Manual

Voice enhancer {5}{1}:On {0}: <Off>–

Feature Feature

code Setting code System

setting

Answering System

36 For assistance, please visit http://www.panasonic.com/phonehelp

Answering system

Important:

LOnly 1 person can access the answering

system at a time.

LWhen callers leave messages, the unit

records the day and time of each

message. Make sure the date and time

have been set (page 18).

Memory capacity

The total recording capacity (including

your greeting message, caller messages,

and voice memo) is about 21 minutes.

A maximum of 64 messages (including a

greeting message) can be recorded.

LIf the message memory becomes full,

the ANSWER ON indicator flashes

rapidly (if the answering system is

turned on). Erase unnecessary

messages (page 37).

LIf less than 3 minutes of recording time is

available, the unit announces the

remaining recording time when

operating the answering system. Erase

unnecessary messages (page 37).

Turning the answering system

on/off

Press {ANSWER ON} to turn on/off the

answering system.

LWhen the answering system is turned

on, the ANSWER ON indicator lights.

LWhen the answering system is turned

off, the ANSWER ON indicator turns off.

Screening calls

While a caller is leaving a message, you

can listen to the call through the base unit’s

speaker. To adjust the speaker volume,

press {^} or {V} repeatedly.

You can answer the call by pressing {SP-

PHONE} on the base unit, or by pressing

{C} on the handset.

Turning off the call screening feature

When the base unit is not in use, press

{GREETING CHECK}, then press {V}

repeatedly until “0” is displayed.

While screening, press {V} repeatedly until

“0” is displayed.

Note:

LIf you adjust the speaker volume while

listening to messages or talking on the

intercom, the speaker volume for call

screening is turned on again.

Recording your greeting

message

You can record your own greeting

message (max. 2 minutes) that is played

when the answering system answers a

call. If you do not record a greeting

message, a prerecorded greeting

message is used.

1{GREETING REC}

2Within 10 seconds, press {GREETING

REC} again.

3After the base unit beeps, speak clearly

about 20 cm (8 inches) away from the

MIC.

Answering System

For assistance, please visit http://www.panasonic.com/phonehelp 37

4To stop recording, press {STOP}.

Playing back the greeting message

Press {GREETING CHECK}.

Erasing your greeting message

Press {GREETING CHECK}, and then

press {ERASE} while your greeting

message is playing.

Prerecorded greeting message

If you erase or do not record your own

greeting message, the unit plays a

prerecorded greeting message for callers

and ask them to leave messages. If the

message recording time (page 42) is set to

“Greeting only”, caller messages are

not recorded and the unit plays a different

prerecorded greeting message asking

callers to call again.

Listening to messages

using the base unit

When new messages have been

recorded, the MESSAGE indicator on the

base unit flashes.

Press {MESSAGE}.

LThe unit plays new messages.

LWhen you have no new messages, the

unit plays back all messages.

Adjusting the speaker volume

Press {^} or {V} repeatedly while listening

to a message.

Repeating a message

Press {<} during playback.

LIf pressed within the first 5 seconds of a

message, the previous message is

played.

Skipping a message

Press {>} during playback.

Pausing a message

Press {STOP} during playback.

LTo resume playback, press

{MESSAGE}.

LTo stop playback completely, press

{STOP} again.

Erasing a message

Press {ERASE} during playback.

Erasing all messages

Press {ERASE} 2 times while the unit is

not being used.

Answering System

38 For assistance, please visit http://www.panasonic.com/phonehelp

Listening to messages

using the handset

When new messages have been

recorded:

–“New message” is displayed.

– The message indicator on the handset

flashes slowly if the message alert

feature is turned on (page 42).

1{MENU}

2“Message play”i{Select}

LThe handset plays new messages

including memo messages.

LWhen you have no new messages,

the handset plays back all messages.

3Press {OFF} when finished.

Note:

LYou can also listen to the messages by

pressing {MENU}, then pressing {2}.

LTo switch to the receiver, press {C}.

Adjusting the receiver/speaker volume

Press {^} or {V} repeatedly while listening

to a message.

Voice guidance

If you do not press any buttons after the

last message is played back, the unit’s

voice guidance starts. Operate the

answering system by following the

guidance as necessary.

Calling back (Caller ID subscribers

only)

If Caller ID information was received for

the call, you can call the caller back while

listening to the message.

1Press {Select} during playback.

LTo edit the number before calling

back, press {Edit} repeatedly to

select the desired format (page 30).

2{Call}

Answering system commands

You can also operate the answering

system by pressing dial keys on the

handset during playback.

*1 If pressed within the first 5 seconds of a

message, the previous message is

played.

*2 To resume operation, press a command

key within 15 seconds, or the voice

guidance will start.

Key Command

{1} or {<}Repeat message (during

playback)*1

{2} or {>}Skip message (during

playback)

{4}Play new messages

{5}Play all messages

{8}Turn answering system on

{9}Stop playback*2

{0}Turn answering system off

{*}{4} or

{Erase}

Erase currently playing

message

{*}{5}Erase all messages

Answering System

For assistance, please visit http://www.panasonic.com/phonehelp 39

Voice memo

Recording a voice memo

You can use the base unit to leave a voice

memo (voice message) for yourself or

someone else (max. 3 minutes). Voice

memos can be played back later with the

same operation used to play back

answering system messages.

1{MEMO}

2After the unit beeps, speak clearly

about 20 cm (8 inches) away from the

MIC.

3To stop recording, press {STOP}.

Remote operation

Using a touch tone phone, you can call

your phone number from outside and

access the unit to listen to messages. The

unit’s voice guidance prompts you to press

certain dial keys to perform different

operations.

Important:

LIn order to operate the answering

system remotely, you must first set a

remote code (page 41). This code must

be entered each time you operate the

answering system remotely.

Using the answering system

remotely

1Dial your phone number from a touch

tone phone.

2After the greeting message starts, enter

your remote code (page 41).

LThe unit plays back new messages.

LAfter playing back new messages,

the voice guidance starts.

3Follow the voice guidance as

necessary.

4When finished, hang up.

Note:

LYou can ignore the voice guidance and

control the unit using remote commands

(page 40).

Base unit

Answering System

40 For assistance, please visit http://www.panasonic.com/phonehelp

Voice guidance

During remote operation, the unit’s voice

guidance prompts you to press {1} to

perform a specific operation, or press {2}

to listen to more available operations.

Operations are presented by voice

guidance in the following order:

– Play back all messages

– Play back new messages

– Record a message

– Erase all messages

Note:

LIf you do not press any dial keys within

10 seconds after a voice guidance

prompt, the unit disconnects your call.

LIf less than 3 minutes of recording time is

available, the unit announces the

remaining recording time after the last

message is played back.

Remote commands

You can press dial keys to access certain

answering system functions without

waiting for the voice guidance to prompt

you.

*1 If pressed within the first 5 seconds of a

message, the previous message is

played.

*2 To resume operation, enter a remote

command within 15 seconds, or the

voice guidance starts.

Turning on the answering system

remotely

If the answering system is off, you can turn

it on remotely.

1Dial your phone number.

2Let the phone ring 15 times.

LThe unit answers your call with the

greeting message.

LYou can hang up, or if you call from a

touch tone phone, you can enter your

remote code and begin remote

operation (page 39).

Skipping the greeting message to leave

a message

You can leave a message just as any

outside caller can. Call your phone

number. When the answering system

picks up, press {*} to skip the greeting

message and record your message after

the beep.

Key Remote command

{1}Repeat message (during

playback)*1

{2}Skip message (during

playback)

{4}Play new messages

{5}Play all messages

{9}Stop playback*2

{0}Turn answering system

off

{*}{4}Erase currently playing

message

{*}{5}Erase all messages

Key Remote command

Answering System

For assistance, please visit http://www.panasonic.com/phonehelp 41

Answering system

settings

Remote code

A remote code must be entered when

operating the answering system remotely.

This code prevents unauthorized parties

from listening to your messages remotely.

The default setting is “11”.

1{MENU}i{0}{6}{3}

2Enter the desired 2-digit remote code.

i{Save}i{OFF}

Ring count

You can change the number of times the

phone rings before the unit answers calls.

The default setting is “4”.

“Toll saver”: The unit answers on the

2nd ring when new messages have been

recorded, and on the 4th ring when there

are no new messages. If you call your

phone from outside to listen to new

messages (page 39), you will know that

there are no new messages when the

phone rings for the 3rd time. You can then

hang up without being charged for the call.

1{MENU}i{0}{6}{1}

2Select the desired setting. i{Save}

i{OFF}

For Voice Mail service subscribers

If you subscribe to a flat-rate service

package that includes Caller ID, Call

Waiting, Voice Mail, and unlimited local/

regional/long distance calls, please note

the following:

LTo use the Voice Mail service provided

by your telephone company rather than

the unit’s answering system, turn off the

answering system (page 36).

This unit does not have an indicator to

indicate if there are new messages in

your mailbox service.

LTo use this unit’s answering system

rather than the Voice Mail service

provided by your telephone company,

please contact your telephone company

to deactivate your Voice Mail service.

If your telephone company cannot do

this:

– Set this unit’s “Ring count” setting

so that this unit’s answering system

answers calls before your telephone

company’s Voice Mail service tries to

answer your calls. It is necessary to

check the ring count required to

activate the Voice Mail service

provided by your telephone company

before changing this setting.

– Change the ring count of the Voice

Mail service so that the answering

system can answer the call first. To do

so, consult your telephone company.

Answering System

42 For assistance, please visit http://www.panasonic.com/phonehelp

Caller’s recording time

You can change the maximum message

recording time allotted to each caller.

The default setting is “3min”.

“Greeting only”: The unit plays the

greeting message but does not record

caller messages.

1{MENU}i{0}{6}{2}

2Select the desired setting. i{Save}

i{OFF}

Note:

LIf the message memory becomes full,

the unit automatically switches to the

“Greeting only” mode and no new

messages are recorded. If you have

recorded your own greeting message,

that same greeting message is

announced to callers even though their

messages are not recorded. If you have

not recorded your own greeting

message, the prerecorded message

used for “Greeting only” mode is

announced to callers (page 37).

Message alert

You can select whether or not the

message indicator on the handset flashes

when new messages are recorded (page

38). The default setting is “Off”.

1{MENU}i{0}{#}

2Select the desired setting. i{Save}

i{OFF}

Note:

LWhile message alert is on, battery

operating time is shortened (page 14).

Multi-unit Operation

For assistance, please visit http://www.panasonic.com/phonehelp 43

Intercom

Intercom calls can be made:

– between the handset and base unit

– between handsets (KX-TG5672/5673)

Note:

LIf you receive a phone call while talking

on the intercom, you hear 2 tones. To

answer the call with the handset, press

{OFF}, then press {C}. To answer the

call with the base unit, press {SP-

PHONE} 2 times.

LYou can locate a misplaced handset by

paging it (handset locator).

KX-TG5671

Making an intercom call

1{INTERCOM}

LThe base unit beeps for 1 minute.

LTo stop paging, press {OFF}.

2To end the intercom call, press {OFF}.

1{INTERCOM}

LThe handset beeps for 1 minute.

LTo stop paging, press {SP-PHONE}

or {INTERCOM}.

2To end the intercom call, press {SP-

PHONE}.

Answering an intercom call

1Press {C} to answer the page.

2To end the intercom call, press {OFF}.

1Press {SP-PHONE} or {INTERCOM}

to answer the page.

2To end the intercom call, press {SP-

PHONE}.

Note:

LWhen the ringer volume is set to off, the

handset or the base unit rings at the low

level for intercom calls.

KX-TG5672/KX-TG5673

Making an intercom call

1{INTERCOM}

2To page the base unit, press {0}.

To page another handset, enter its

extension number ({1}–{3}).

LThe destination unit beeps for 1

minute.

LTo stop paging, press {OFF}.

3To end the intercom call, press {OFF}.

Handset

Base unit

Handset

Base unit

Handset

Multi-unit Operation

44 For assistance, please visit http://www.panasonic.com/phonehelp

1{INTERCOM}

2Press {1},{2}, or {3}.

LThe destination unit beeps for 1

minute.

LTo stop paging, press {SP-PHONE}

or {INTERCOM}.

3To end the intercom call, press {SP-

PHONE}.

Answering an intercom call

1Press {C} to answer the page.

2To end the intercom call, press {OFF}.

1Press {SP-PHONE} or {INTERCOM}

to answer the page.

2To end the intercom call, press {SP-

PHONE}.

Note for handset and base unit:

LWhen the ringer volume is set to off, the

handset or the base unit rings at the low

level for intercom calls.

Transferring calls,

conference calls

Outside calls can be transferred between

the handset and base unit, and between 2

handsets. The handset and base unit, or 2

handsets can have a conference call with

an outside party.

1During an outside call, press

{INTERCOM} to put the call on hold.

2KX-TG5671

Press {base}.

KX-TG5672/KX-TG5673

To page the base unit, press {0}.

To page another handset, enter its

extension number ({1}–{3}).

3Wait for the paged party to answer.

LIf the paged party does not answer,

press {C} to return to the outside

call.

4To complete the transfer, press {OFF}.

LThe outside call is being routed to the

unit.

To establish a conference call, press

{Conf}.

LTo leave the conference, press

{OFF}. The other parties can

continue the conversation.

LTo put the outside call on hold, press

{HOLD}. To resume the conference,

press {Conf}.

Base unit

Handset

Base unit

Handset

Multi-unit Operation

For assistance, please visit http://www.panasonic.com/phonehelp 45

KX-TG5671

1During an outside call, press

{INTERCOM} to put the call on hold.

2Wait for the paged party to answer.

LIf the paged party does not answer,

press {INTERCOM} to return to the

outside call.

3To complete the transfer, press {SP-

PHONE}.

LThe outside call is being routed to the

handset.

To establish a conference call, press

{CONF}.

LTo leave the conference, press {SP-

PHONE}. The other parties can

continue the conversation.

LTo put the outside call on hold, press

{HOLD}. To resume the conference,

press {CONF}.

KX-TG5672/KX-TG5673

1During an outside call, press

{INTERCOM} to put the call on hold.

2Press {1},{2}, or {3}.

3Wait for the paged party to answer.

LIf the paged party does not answer,

press {INTERCOM} to return to the

outside call.

4To complete the transfer, press {SP-

PHONE}.

LThe outside call is being routed to the

handset.

To establish a conference call, press

{CONF}.

LTo leave the conference, press {SP-

PHONE}. The other parties can

continue the conversation.

LTo put the outside call on hold, press

{HOLD}. To resume the conference,

press {CONF}.

Answering transferred calls

Press {C} to answer the page.

Press {SP-PHONE} to answer the page.

Note for handset and base unit:

LAfter the paging party disconnects, you

can talk to the outside caller.

Base unit

Handset

Base unit

Multi-unit Operation

46 For assistance, please visit http://www.panasonic.com/phonehelp

Registering a handset

The included handset and base unit are

preregistered. If for some reason the

handset is not registered to the base unit,

the base unit or charger before registering.

KX-TG5671

1Handset:

{MENU}i{0}{0}

2Base unit:

Press and hold {INTERCOM} until the

CHARGE indicator flashes.

LAfter the CHARGE indicator starts

flashing, the rest of the procedure

must be completed within 1 minute.

3Handset:

Press {OK}, then wait until the handset

beeps.

KX-TG5672/KX-TG5673

Important:

LIf you accidentally assign another

handset’s extension number to the base

unit, the originally assigned handset

stops functioning. Confirm the extension

number of the handset by placing it on

the base unit or charger. Lift the handset

from the charger before registering.

1Handset:

{MENU}i{0}{0}

2Base unit:

Press and hold {INTERCOM} until the

CHARGE indicator flashes, then press

{1},{2}, or {3}.

LAfter the CHARGE indicator starts

flashing, the rest of the procedure

must be completed within 1 minute.

3Handset:

Press {OK}, then wait until the handset

beeps.

Registering an additional handset

See page 5 for information on the available

models and extension numbers.

Start from step 2.

Useful Information

For assistance, please visit http://www.panasonic.com/phonehelp 47

Wall mounting

Base unit

1Tuck the telephone line cord inside the

wall mounting adaptor (A).

Connect the telephone line cord (B).

2Insert the hooks on the wall mounting

adaptor into the holes (1) and (2) on

the base unit.

3Adjust the adaptor to hold the base unit,

then push it in the direction of the arrow

until it clicks into place.

Useful Information

48 For assistance, please visit http://www.panasonic.com/phonehelp

4Connect the telephone line cord. Mount

the unit by inserting the mounting pins

into the round openings on the adaptor

(for pin 2, use round cut out at the

bottom of the adaptor if you are using

the 4 inches phone plate), then sliding

the unit down to secure it.

Connect the AC adaptor to power outlet

(page 11).

LThere are two common types of wall

phone plates. The distance between

1 and 2 may vary depending on the

size of the wall phone plate installed.

To remove the wall mounting adaptor

While pushing down the release levers

(A), remove the adaptor (B).

83 mm

(

inches

)

102 mm

(4 inches)

(120 V AC,

60 Hz)

83 mm

(

inches

)

102 mm

(4 inches)

Useful Information

For assistance, please visit http://www.panasonic.com/phonehelp 49

Charger

1Drive the screws (not included) into the

wall using the wall template as a guide.

2Mount the charger (A), then slide it

down (B) and to the right (C) until it is

secure.

Headset (optional)

Connecting a headset to the handset

allows hands-free phone conversations.

Please use only a Panasonic headset

(page 7).

LHeadset shown is KX-TCA86.

Switching a call between the headset

and handset speakerphone

To switch to the handset speakerphone,

press {s}.

To return to the headset, press {C}.

Available model:

KX-TG5672/KX-TG5673

25.4 mm

(1 inch)

Screws

(120 V AC, 60 Hz)

25.4 mm

(1 inch)

Useful Information

50 For assistance, please visit http://www.panasonic.com/phonehelp

Error messages

If the unit detects a problem, one of the following messages is shown on the display.

*1 KX-TG5672/KX-TG5673

Display message Cause/solution

Busy LThe called base unit is in use.

LAnother handset or the called handset is in use.*1

LThe handset you tried to copy phonebook items to is in

use.*1

LThe handset you are calling is too far from the base unit.*1

Error!! LThe handset’s registration has failed. Move the handset

and base unit away from all electrical appliances and try

again.

LAnother handset user tried to send phonebook items to

you but there was an error. Have the other handset user

re-send the items to you (page 26).*1

---Incomplete---

Phonebook full*1 LThe destination unit’s phonebook memory is full. Erase

unnecessary items from the destination unit’s

phonebook (page 25).

Invalid*1 LThere is no handset registered to the base unit

matching the extension number you entered.

No items stored LYour phonebook or redial list is empty.

No link to base.

Move closer to

base, try again.

LThe handset has lost communication with the base unit.

Move closer to the base unit, and try again.

LConfirm that the base unit’s AC adaptor is plugged in.

LRaise the base unit antennas.

LThe handset’s registration may have been canceled.

Re-register the handset (page 46).

Phonebook full LThere is no space to store new items in the phonebook.

Erase unnecessary items (page 25).

Please lift up and

try again.

LA handset button was pressed while the handset was

on the base unit or charger. Lift the handset and press

the button again.

System is busy.

Please try again

later.

LOther units are in use and the system is busy. Try again

later.

LAnother user is listening to messages. Try again later.

Useful Information

For assistance, please visit http://www.panasonic.com/phonehelp 51

Troubleshooting

General use

Programmable settings

Battery recharge

Problem Cause/solution

The unit does not work. LMake sure the battery is installed correctly and fully

charged (page 12, 13).

LCheck the connections (page 11).

LUnplug the base unit’s AC adaptor to reset the unit.

Reconnect the adaptor and try again.

LThe handset has not been registered to the base unit.

I cannot hear a dial tone. LConfirm the telephone line cord is properly connected

(page 11).

LDisconnect the unit from the telephone line and connect

a known working telephone. If the working telephone

operates properly, contact our service personnel to

have the unit repaired. If the working telephone does

not operate properly, contact your telephone company.

Problem Cause/solution

I cannot program items. LWhile another user is listening to messages or the

answering system is answering a call, you cannot

program items. Try again later.

While programming, the

handset starts to ring.

LA call is being received. Answer the call and start again

after hanging up.

Problem Cause/solution

I charged the battery fully,

but 7 continues to

flash, or 8 is

displayed.

LClean the charge contacts and charge again (page 13).

LThe battery may need to be replaced with a new one

(page 12).

The handset display is

blank.

LConfirm that the battery is properly installed.

LFully charge the battery (page 13).

Useful Information

52 For assistance, please visit http://www.panasonic.com/phonehelp

Making/answering calls, intercom

*1 KX-TG5672/KX-TG5673

Problem Cause/solution

Static is heard, sound

cuts in and out.

Interference from other

electrical units.

LMove the handset and the base unit away from other

electrical appliances.

LMove closer to the base unit.

LRaise the base unit antennas.

LTurn on the clarity booster feature (page 22).

LIf your unit is connected to a telephone line with DSL

service, we recommend connecting a noise filter

between the base unit and the telephone line jack.

Contact your DSL provider for details.

The handset and base

unit do not ring.

LThe ringer volume is turned off. Adjust it (page 21, 34).

I cannot make a call. LThe dialing mode may be set incorrectly. Change the

setting (page 18).

LThe base unit or another handset is in use. Try again

later.

I cannot redial by

pressing {REDIAL}.

LIf the last number dialed was more than 48 digits long,

the number will not be redialed correctly. Dial the

number manually.

I cannot have a

conversation using the

headset.

LMake sure that an optional headset is connected

properly (page 49).

LIf “SP-phone” is displayed on the handset, press {C}

to switch to the headset.

I cannot make long

distance calls.

LMake sure that you have long distance service.

I cannot page the

handset or base unit.

LThe called handset is too far from the base unit.

LThe called unit is in use. Try again later.

The Slow Talk feature

does not work.

LIf you are on a conference call, you cannot use the Slow

Talk feature.

LIf another handset is having an intercom call with the

base unit, you cannot use the Slow Talk feature.*1

LIf someone is operating the answering system, you

cannot use the Slow Talk feature.

Useful Information

For assistance, please visit http://www.panasonic.com/phonehelp 53

Phonebook

*1 KX-TG5672/KX-TG5673

Caller ID

Problem Cause/solution

Copying stopped with an

item displayed.*1 LThe destination handset may have lost communication

with the base unit, or the destination unit user may have

pressed {C} or {s}.

The displayed phonebook item was not copied to the

unit. Press {OFF}. Confirm that the destination unit is

not in use and try again.

Problem Cause/solution

The handset does not

display the caller’s name

and/or phone number.

LYou have not subscribed to Caller ID service. Contact

your telephone company to subscribe.

LIf your unit is connected to any additional telephone

equipment such as a Caller ID box or cordless

telephone jack, disconnect the unit from the equipment

and plug the unit directly into the wall jack.

LIf your unit is connected to a telephone line with DSL

service, we recommend connecting a noise filter

between the base unit and the telephone line jack.

Contact your DSL provider for details.

LThe name display service may not be available in some

areas. Contact your telephone company for details.

LOther telephone equipment may be interfering with this

unit. Disconnect the other equipment and try again.

LThe caller requested not to send caller information

(page 28).

LIf a call is being transferred to you, the caller information

is not displayed.

The handset or base unit

does not announce the

displayed caller names.

LThe handset or base unit’s ringer volume is turned off.

Adjust it (page 21, 34).

LThe Talking Caller ID feature is turned off. Turn it on

(page 35).

LThe ring count for the answering system is set to “2” or

“Toll saver”. Select a different setting (page 41).

LIf the base unit and another handset are having an

intercom call, your handset does not announce caller

information.*1

Useful Information

54 For assistance, please visit http://www.panasonic.com/phonehelp

*1 KX-TG5672/KX-TG5673

Answering system

*1 KX-TG5672/KX-TG5673

The caller list/incoming

phone numbers are not

edited automatically.

LThe Caller ID number auto edit feature is turned off.

Turn it on and try again (page 34).

LYou need to call back the edited number to activate

Caller ID number auto edit.

I cannot dial the phone

number edited in the

caller list.

LThe phone number you dialed might have an incorrectly

edited pattern (for example, the long distance “1” or the

area code is missing). Edit the phone number with

another pattern (page 30).

The 2nd caller’s

information is not

displayed during an

outside call.

LIn order to use Caller ID, Call Waiting, or Call Waiting

Caller ID (CWID), you must first contact your telephone

company and subscribe to the desired service.

After subscribing, you may need to contact your

telephone company again to activate this specific

service, even if you already subscribed to both Caller ID

and Call Waiting with Caller ID services (CWID).

Problem Cause/solution

I cannot listen to

messages from a remote

location.

LA touch tone phone is required for remote operation.

LEnter the remote code correctly (page 39).

LThe answering system is off. Turn it on (page 40).

The unit does not record

new messages.

LThe answering system is off. Turn it on (page 40).

LThe recording time is set to “Greeting only”. Select

a different setting (page 42).

LThe message memory is full. Erase unnecessary

messages (page 37).

LIf you subscribe to the Voice Mail service, messages

are recorded by the telephone company not your

telephone (page 41).

I cannot operate the

answering system.

LSomeone is operating the answering system.

LIf someone is talking on a conference call, you cannot

operate the answering system. Try again later.*1

The message indicator

on the handset flashes.

LNew messages have been recorded. Listen to the new

messages (page 37).

Problem Cause/solution

Useful Information

For assistance, please visit http://www.panasonic.com/phonehelp 55

FCC and other information

This equipment complies with Part 68 of

the FCC rules and the requirements

adopted by the ACTA. On the bottom of

this equipment is a label that contains,

among other information, a product

identifier in the format US:ACJ----------.

If requested, this number must be

provided to the telephone company.

L Registration No

............(found on the bottom of the unit)

L Ringer Equivalence No.

(REN).......0.1B

A plug and jack used to connect this

equipment to the premises wiring and

telephone network must comply with the

applicable FCC Part 68 rules and

requirements adopted by the ACTA. A

compliant telephone cord and modular

plug is provided with the product. It is

designed to be connected to a

compatible modular jack that is also

compliant.

The REN is used to determine the

number of devices that may be

connected to a telephone line. Excessive

RENs on a telephone line may result in

the devices not ringing in response to an

incoming call. In most but not all areas,

the sum of RENs should not exceed five

(5.0). To be certain of the number of

devices that may be connected to a line,

as determined by the total RENs, contact

the local telephone company. For

products approved after July 23, 2001,

the REN for the product is part of the

product identifier that has the format

US:AAAEQ##TXXXX. The digits

represented by ## are the REN without a

decimal point (e.g., 03 is a REN of 0.3).

If this equipment causes harm to the

telephone network, the telephone

company will notify you in advance that

temporary discontinuance of service may

be required. But if advance notice isn’t

practical, the telephone company will

notify the customer as soon as possible.

Also, you will be advised of your right to

file a complaint with the FCC if you

believe it is necessary.

The telephone company may make

changes in its facilities, equipment,

operations or procedures that could

affect the operation of the equipment. If

this happens the telephone company will

provide advance notice in order for you

to make necessary modifications to

maintain uninterrupted service.

If trouble is experienced with this

equipment, for repair or warranty

information, please contact a Factory

Servicenter or other Authorized Servicer.

If the equipment is causing harm to the

telephone network, the telephone

company may request that you

disconnect the equipment until the

problem is resolved.

Connection to party line service is

subject to state tariffs. Contact the state

public utility commission, public service

commission or corporation commission

for information.

If your home has specially wired alarm

equipment connected to the telephone

Useful Information

56 For assistance, please visit http://www.panasonic.com/phonehelp

line, ensure the installation of this

equipment does not disable your alarm

equipment. If you have questions about

what will disable alarm equipment,

consult your telephone company or a

qualified installer.

This equipment is hearing aid compatible

as defined by the FCC in 47 CFR Section

68.316.

When you hold the phone to your ear,

noise might be heard in your Hearing Aid.

Some Hearing Aids are not adequately

shielded from external RF (radio

frequency) energy. If noise occurs, use

an optional headset accessory or the

speakerphone option (if applicable) when

using this phone. Consult with your

audiologist or Hearing Aid manufacturer

about the availability of Hearing Aids

which provide adequate shielding to RF

energy commonly emitted by digital

devices.

WHEN PROGRAMMING EMERGENCY

NUMBERS AND(OR) MAKING TEST

CALLS TO EMERGENCY NUMBERS:

1) Remain on the line and briefly explain

to the dispatcher the reason for the

call.

2) Perform such activities in the off-peak

hours, such as early morning or late

evenings.

This device complies with Part 15 of the

FCC Rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful

interference, and (2) this device must

accept any interference received,

including interference that may cause

undesired operation.

Privacy of communications may not be

ensured when using this phone.

CAUTION:

Any changes or modifications not

expressly approved by the party

responsible for compliance could void

the user’s authority to operate this

device.

NOTE:

This equipment has been tested and

found to comply with the limits for a

Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are

designed to provide reasonable

protection against harmful interference in

a residential installation. This equipment

generates, uses, and can radiate radio

frequency energy and, if not installed and

used in accordance with the instructions,

may cause harmful interference to radio

communications. However, there is no

guarantee that interference will not occur

in a particular installation. If this

equipment does cause harmful

interference to radio or television

reception, which can be determined by

turning the equipment off and on, the

user is encouraged to try to correct the

interference by one or more of the

following measures:

- Reorient or relocate the receiving

antenna.

- Increase the separation between the

equipment and receiver.

- Connect the equipment into an outlet

on a circuit different from that to which

the receiver is connected.

- Consult the dealer or an experienced

radio/TV technician for help.

Useful Information

For assistance, please visit http://www.panasonic.com/phonehelp 57

Notice

Some cordless telephones operate at

frequencies that may cause interference

to nearby TVs and VCRs. To minimize or

prevent such interference, the base of

the cordless telephone should not be

placed near or on top of a TV or VCR. If

interference is experienced, move the

cordless telephone further away from the

TV or VCR. This will often reduce, or

eliminate, interference.

FCC RF Exposure Warning:

The product complies with FCC radiation

exposure limits set forth for an

uncontrolled environment. To comply

with FCC RF exposure requirements, the

base unit must be installed and operated

with its antenna located 20 cm (8 inches)

or more between antenna and all

person’s body (excluding extremities of

hands, wrist and feet). The handset may

be carried and operated with only the

optional specific belt-clip. Other non-

tested belt-clips or similar body-worn

accessories may not comply and must

be avoided. The product must not be

collocated or operated in conjunction

with any other antenna or transmitter.

Useful Information

58 For assistance, please visit http://www.panasonic.com/phonehelp

Specifications

General

Base unit

Handset

Charger*1

*1 KX-TG5672/KX-TG5673

Note:

LDesign and specifications are subject to change without notice.

LThe illustrations in these instructions may vary slightly from the actual product.

Operating environment 5 °C – 40 °C (41 °F – 104 °F)

Frequency 5.76 GHz – 5.84 GHz

Dimensions Approx. height 96 mm x width 210 mm x depth 157 mm

(325/32 inches x 81/4 inches x 63/16 inches)

Mass (Weight) Approx. 405 g (0.89 lb.)

Power consumption Standby: Approx. 2.2 W/1.5 W (PQLV1/PQLV256)

Maximum: Approx. 4.7 W/3.8 W (PQLV1/PQLV256)

Power output 200 mW (max.)

Power supply AC adaptor (120 V AC, 60 Hz)

Dimensions Approx. height 173 mm x width 48 mm x depth 33 mm

(613/16 inches x 17/8 inches x 15/16 inches)

Mass (Weight) Approx. 170 g (0.37 lb.)

Power output 200 mW (max.)

Power supply Ni-MH battery (3.6 V, 830 mAh)

Dimensions Approx. height 51 mm x width 88 mm x depth 100 mm

(2 inches x 315/32 inches x 315/16 inches)

Mass (Weight) Approx. 94 g (0.21 lb.)

Power consumption Standby: Approx. 0.8 W/0.3 W (KX-TCA1/PQLV256)

Maximum: Approx. 3.6 W/2.4 W (KX-TCA1/PQLV256)

Power supply AC adaptor (120 V AC, 60 Hz)

Useful Information

✄

For assistance, please visit http://www.panasonic.com/phonehelp 59

Warranty

PANASONIC CONSUMER

ELECTRONICS COMPANY, DIVISION

OF PANASONIC CORPORATION OF

NORTH AMERICA

One Panasonic Way,

Secaucus, New Jersey 07094

PANASONIC PUERTO RICO, INC.

San Gabriel Industrial Park,

Ave. 65 de Infantería, Km. 9.5,

Carolina, Puerto Rico 00985

Panasonic Telephone Products

Limited Warranty

Limited Warranty Coverage

If your product does not work properly because of a defect in materials or

workmanship, Panasonic Consumer Electronics Company or Panasonic Puerto

Rico, Inc. (collectively referred to as “the warrantor”) will, for the length of the period

indicated on the chart below, which starts with the date of original purchase

(“Limited Warranty period”), at its option either (a) repair your product with new or

refurbished parts, or (b) replace it with a new or a refurbished product. The decision

to repair or replace will be made by the warrantor.

Parts Labor

One (1) Year One (1) Year

During the “Labor” Limited Warranty period there will be no charge for labor. During

the “Parts” Limited Warranty period, there will be no charge for parts. You must

mail-in your product prepaid during the Limited Warranty period. This Limited

Warranty excludes both parts and labor for batteries, antennas, and cosmetic parts

(cabinet). This Limited Warranty only applies to products purchased and serviced in

the United States or Puerto Rico. This Limited Warranty is extended only to the

original purchaser and only covers products purchased as new.

Mail-In Service

For assistance in the continental U.S.A. in obtaining repairs please ship the product

prepaid to:

Panasonic Services Company Customer Servicenter

4900 George McVay Drive Suite B Door #12 McAllen, TX 78503

For assistance in Puerto Rico call Panasonic Puerto Rico, Inc. (787)-750-4300 or

fax (787)-768-2910.

For Limited Warranty service for headsets if a headset is included with this product

please call Panasonic Call Center at 1-800-211-PANA (1-800-211-7262).

When shipping the unit carefully pack, include all accessories, and send it prepaid,

adequately insured and preferably in the original carton. Include a letter detailing

the complaint and provide a day time phone number where you can be reached.

Useful Information

60 For assistance, please visit http://www.panasonic.com/phonehelp

IF REPAIR IS NEEDED DURING THE LIMITED WARRANTY PERIOD THE

PURCHASER WILL BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF

OF PURCHASE INDICATING DATE OF PURCHASE, AMOUNT PAID AND

PLACE OF PURCHASE. CUSTOMER WILL BE CHARGED FOR THE REPAIR

OF ANY UNIT RECEIVED WITHOUT SUCH PROOF OF PURCHASE.

Limited Warranty Limits And Exclusions

This Limited Warranty ONLY COVERS failures due to defects in materials or

workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage.

The Limited Warranty ALSO DOES NOT COVER damages which occurred in

shipment, or failures which are caused by products not supplied by the warrantor,

or failures which result from accidents, misuse, abuse, neglect, bug infestation,

mishandling, misapplication, alteration, faulty installation, set-up adjustments,

misadjustment of consumer controls, improper maintenance, power line surge,

lightning damage, modification, introduction of sand, humidity or liquids,

commercial use such as hotel, office, restaurant, or other business or rental use of

the product, or service by anyone other than a Factory Servicenter or other

Authorized Servicer, or damage that is attributable to acts of God.

THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER

“LIMITED WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR

INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE

OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS LIMITED

WARRANTY. (As examples, this excludes damages for lost time, lost calls or

messages, cost of having someone remove or re-install an installed unit if

applicable, travel to and from the servicer. The items listed are not exclusive, but

are for illustration only.) ALL EXPRESS AND IMPLIED WARRANTIES,

INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE

PERIOD OF THE LIMITED WARRANTY.

Some states do not allow the exclusion or limitation of incidental or consequential

damages, or limitations on how long an implied warranty lasts, so the exclusions

may not apply to you.

This Limited Warranty gives you specific legal rights and you may also have other

rights which vary from state to state. If a problem with this product develops during or

after the Limited Warranty period, you may contact your dealer or Servicenter. If the

problem is not handled to your satisfaction, then write to the warrantor’s Consumer

Affairs Department at the addresses listed for the warrantor.

PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED

WARRANTY, ARE YOUR RESPONSIBILITY.

Useful Information

For assistance, please visit http://www.panasonic.com/phonehelp 61

Customer services

Customer Services Directory

Obtain Product Information and Operating Assistance; locate your nearest Dealer or

Servicenter; purchase Parts and Accessories; or make Customer Service and

Literature requests by visiting our Web Site at:

http://www.panasonic.com/consumersupport

or, contact us via the web at:

http://www.panasonic.com/contactinfo

You may also contact us directly at: 1-800-211-PANA (1-800-211-7262),

Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7 pm, EST.

TTY users (hearing or speech impaired users) can call 1-877-833-8855.

TTY users (hearing or speech impaired users) can call 1-866-605-1277.

Purchase Parts, Accessories and Instruction Books online for all Panasonic

Products by visiting our Web Site at:

http://www.pasc.panasonic.com

or, send your request by E-mail to:

npcparts@us.panasonic.com

You may also contact us directly at:

1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)

(Monday - Friday 9 am to 8 pm, EST.)

Panasonic Services Company

20421 84th Avenue South, Kent, WA 98032

(We Accept Visa, MasterCard, Discover Card, American Express, and Personal

Checks)

Accessory Purchases

Service in Puerto Rico

Panasonic Puerto Rico, Inc.

San Gabriel Industrial Park, Ave. 65 de Infantería, Km. 9.5,

Carolina, Puerto Rico 00985

Phone (787)750-4300, Fax (787)768-2910

Index

62 For assistance, please visit http://www.panasonic.com/phonehelp

Index

AAnswering calls: 20

Answering system

Erasing messages: 37,38,40

Listening to messages: 37,38,39

Turning on/off: 36,38,40

Auto talk: 20

BBattery

Charge: 13

Installation: 12

Level: 14

Performance: 14

Replacement: 12

Booster (Clarity booster): 22

CCall screening: 36

Call share: 23

Call Waiting: 22

Call Waiting Caller ID: 28

Caller ID edit: 30

Caller ID number auto edit: 30

Caller ID service: 28

Caller list

Calling back: 30

Editing: 30

Erasing: 31

Storing: 31

Viewing: 30

Chain dial: 25

Conference calls: 44

Connections: 11,12

Customer support: 35

DDate and time: 18

Dialing mode: 18

Display

Contrast: 34

Language: 18

EError messages: 50

FFlash: 22

Flash time: 35

GGreeting message: 36

HHandset locator: 43

Headset, optional: 49

Hold: 21

IInstallation

Base unit: 11

Handset: 12

Intercom: 43

KKey tone: 34

LLight-up ID: 29

Line mode: 35

MMaking calls: 19

MEMO: 39

Memory capacity (message

recording): 36

Message alert: 42

Missed calls: 28,30

Mute: 22

NNavigator key: 16

PPause: 19,27

Phonebook: 24

Phonebook copy: 26

Pulse service: 22

RRecording time: 42

Redial list: 19

Registration: 46

Remote code: 41

Remote operation: 39

Ring color: 34

Ring count: 41

Ringer ID: 29

Ringer off

Base unit: 21

Handset: 20,34

Ringer tone

Base unit: 21

Handset: 34

Rotary service: 22

SSlow Talk: 23

Soft keys: 17

Index

For assistance, please visit http://www.panasonic.com/phonehelp 63

Speed dialer: 27

SP-phone: 19

TTalking Caller ID: 28

Time adjustment: 35

Toll saver: 41

Tone: 22

Transferring calls: 44

Troubleshooting: 51

TTY: 7,61

VVE (Voice Enhancer): 23

Voice guidance: 38,40

Volume

Base unit ringer: 21

Base unit speaker: 20

Handset receiver: 19

Handset ringer: 34

Handset speaker: 19

WWall mounting

Base unit: 47

Charger: 49

Warranty: 59

If you need assistance with setup or operation

1Visit our website: http://www.panasonic.com/phonehelp

2Contact us via the web at: http://www.panasonic.com/contactinfo

3Call us at: 1-800-211-PANA (1-800-211-7262)

TTY users (hearing or speech impaired users) can call 1-877-833-8855.

When you ship the product

LCarefully pack your unit, preferably in the original carton.

LAttach a letter, detailing the symptom, to the outside of the carton.

LSend the unit to Panasonic Services Company Customer Servicenter, prepaid and

adequately insured.

LDo not send your unit to Panasonic Consumer Electronics Company listed below or to

executive or regional sales offices. These locations do not repair consumer products.

Panasonic Consumer Electronics Company,

Division of Panasonic Corporation of North America

One Panasonic Way, Secaucus, New Jersey 07094

Panasonic Puerto Rico, Inc.

San Gabriel Industrial Park, Ave. 65 de Infantería, Km. 9.5,

Carolina, Puerto Rico 00985

This material is copyrighted by Panasonic Communications Co., Ltd., and may be

reproduced for internal use only. All other reproduction, in whole or in part, is prohibited

without the written consent of Panasonic Communications Co., Ltd.

PQQX15043ZA DM1205SY1016

Panasonic KX TG5671 TG5671_72_73(e) User Manual To The 669dbf03 A6a3 4ce4 Ac3d 66d9c4cd9a49

Navigation menu

Versions of this User Manual:

Views

Navigation
