TABLE OF CONTENTS
GETTING STARTED
BASIC OPERATION
SPECIAL FEATURES
FOR YOUR INFORMATION

Before attempting to connect, operate or adjust this product, please read these

instructions thoroughly.

Spanish Quick Use Guide is included.

Guía para rápida consulta en español está incluida.

LSQT0364A

Models No. PV-DV201/

PV-DV401

Digital Video Camcorder

Operating Instructions

Mini

For assistance, please call : 1-800-211-PANA(7262) or

send e-mail to : consumerproducts@panasonic.com

[ PV-DV401 shown ]

*0364A*

201_401. 1-4.p65 01/01/18, 17:071

2For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Things You Should Know

Date of Purchase

Dealer Purchased From

Dealer Address

Dealer Phone No.

Model No.

Serial No.

Thank you for choosing

Panasonic!

You have purchased one of the most

sophisticated and reliable products on the

market today. Used properly, we’re sure it

will bring you and your family years of

enjoyment. Please take time to fill in the

information below. The serial number is

on the tag located

on the underside of your Palmcorder. Be

sure to retain this manual as your

convenient Palmcorder information

source.

This symbol warns the user that uninsulated

voltage within the unit may have sufficient

magnitude to cause electric shock.

Therefore, it is dangerous to make any kind

of contact with any inside part of this unit.

This symbol alerts the user that important

literature concerning the operation and

maintenance of this unit has been included.

Therefore, it should be read carefully in order

to avoid any problems.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL

The above markings are located on the appliance bottom cover.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

Note: This equipment has been tested and found to comply with Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful

interference when operated in a residential environment.

If this equipment does cause interference to radio or television reception, which can be

determined by turning the equipment off and on, use the equipment in another location

and/or utilize an electrical outlet different from that used by the receiver.

If necessary, consult the dealer or an experienced radio/TV technician for help. You may

find the booklet, ‘Something About Interference’ available from FCC local regional offices

helpful.

FCC Warning: To assure continued FCC compliance, use only the provided shielded

interface cable when connecting digital video camera to computer in

accordance with instruction herein. Also, any unauthorized changes or

modifications to this equipment could void the user’s authority to operate.

Your

Mini

Palmcorder is designed to record and play back in Standard Play (SP) mode

and Long (LP) mode.

It is recommended that only cassette tapes that have been tested and inspected for use in

VCR machines with the

Mini

mark be used.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD,

DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.

Safety Precautions

201_401. 1-4.p65 01/01/18, 17:072

Important Safeguards

11. Grounding or Polarization — This video unit may be

equipped with either a polarized 2-wire AC

(Alternating Current) line plug (a plug having one

blade wider than the other) or 3-wire grounding type

plug, a plug having a third (grounding) pin.

The 2-wire polarized plug will fit into the power outlet

only one way. This is a safety feature. If you are

unable to insert the plug fully into the outlet, try

reversing the plug. If the plug still fails to fit, contact

your electrician to replace your obsolete outlet. Do

not defeat the safety purpose of the polarized plug.

The 3-wire grounding type plug will fit into a

grounding type power outlet. This is a safety feature.

If you are unable to insert the plug into the outlet,

contact your electrician to replace your obsolete

outlet. Do not defeat the safety purpose of the

grounding type plug.

12. Power-Cord Protection — Power-supply cords

should be routed so that they are not likely to be

walked on or pinched by items placed upon or

against them, paying particular attention to cords of

plugs, convenience receptacles, and the point

where they exit from the unit.

13. Outdoor Antenna Grounding — If an outside

antenna or cable system is connected to the video

unit, be sure the antenna or cable system is

grounded so as to provide some protection against

voltage surges and built-up static charges. Part 1 of

the Canadian Electrical Code, in USA Section 810

of the National Electrical Code, provides information

with respect to proper grounding of the mast and

supporting structure, grounding of the lead-in wire to

an antenna discharge unit, size of grounding

conductors, location of antenna discharge unit,

connection to grounding electrodes, and

requirements for the grounding electrode.

14. Lightning — For added protection of this video unit

receiver during a lightning storm, or when it is left

unattended and unused for long periods of time,

unplug it from the wall outlet and disconnect the

antenna or cable system. This will prevent damage

to the video unit due to lightning and power-line

surges.

1. Read Instructions — All the safety and operating

instructions should be read before the unit is

operated.

2. Retain Instructions — The safety and operating

instructions should be retained for future reference.

3. Heed Warnings — All warnings on the unit and in the

operating instructions should be adhered to.

4. Follow Instructions — All operating and maintenance

instructions should be followed.

5. Cleaning — Unplug this video unit from the wall outlet

before cleaning. Do not use liquid or aerosol

cleaners. Use a dry cloth for cleaning.

6. Attachments — Do not use attachments not

recommended by the video product manufacturer as

they may be hazardous.

7. Water and Moisture — Do not use this video unit near

water — for example near a bath tub, wash bowl,

kitchen sink, or laundry tub, in a wet basement, or

near a swimming pool, and the like.

8. Accessories — Do not place this video unit on an

unstable cart, stand, tripod, bracket, or table. The

video unit may fall, causing serious injury to a child or

adult, and serious damage to the unit. Use only with

a cart, stand, tripod, bracket, or table recommended

by the manufacturer, or sold with the video unit. Any

mounting of the unit should follow the manufacturer’s

instructions and should use a

mounting accessory

recommended by the

manufacturer. An appliance and

cart combination should be moved

with care. Quick stops, excessive

force, and uneven surfaces may

cause the appliance and cart

combination to overturn.

9. Ventilation — Slots and openings in the cabinet are

provided for ventilation and to ensure reliable

operation of the video unit and to protect it from

overheating. These openings must not be blocked or

covered. Never place the video unit on a bed, sofa,

rug, or other similar surface, or near or over a radiator

or heat register. This video unit should not be placed

in a built-in installation such as a bookcase or rack

unless proper ventilation is provided or the

manufacturer’s instructions have been adhered to.

10. Power Sources — This video unit should be operated

only from the type of power source indicated on the

marking label. If you are not sure of the type of power

supply to your home, consult your appliance dealer

or local power company. For video units intended to

be operated from battery power, or other sources,

refer to the operating instructions.

GROUND

CLAMP

ANTENNA

LEAD IN

WIRE

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

NATIONAL ELECTRICAL CODE

NEC

ELECTRIC

SERVICE

EQUIPMENT

Important Safeguards

201_401. 1-4.p65 01/01/18, 17:073

15. Power Lines — An outside antenna system should

not be located in the vicinity of overhead power lines

or other electric light or power circuits, or where it can

fall into such power lines or circuits. When installing

an outside antenna system, extreme care should be

taken to keep from touching such power lines or

circuits as contact with them might be fatal.

16. Overloading — Do not overload wall outlets and

extension cords as this can result in a risk of fire or

electric shock.

17. Objects and Liquids — Never push objects of any

kind into this video unit through openings as they

may touch dangerous voltage points or short out

parts that could result in a fire or electric shock.

Never spill liquid of any kind onto the video unit.

18. Servicing — Do not attempt to service this video unit

yourself as opening or removing covers may expose

you to dangerous voltage or other hazards. Refer all

servicing to qualified service personnel.

19. Damage Requiring Service — Unplug this video unit

from the wall outlet and refer servicing to qualified

service personnel under the following conditions:

a. When the power-supply cord or plug is damaged.

b. If any liquid has been spilled into, or objects have

fallen onto, the video unit.

c. If the video unit has been exposed to rain or water.

d. If the video unit does not operate normally by

following the operating instructions. Adjust only

those controls that are covered by the operating

instructions, as an improper adjustment of other

controls may result in damage and will often

require extensive work by a qualified technician to

restore the video unit to its normal operation.

e. If the video unit has been dropped or the cabinet

has been damaged.

f. When the video unit exhibits a distinct change in

performance — this indicates a need for service.

20. Replacement Parts — When replacement parts are

required, be sure the service technician has used

replacement parts specified by the manufacturer or

have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric

shock or other hazards.

21. Safety Check— Upon completion of any service or

repairs to this video unit, ask the service technician to

perform safety checks to determine that the video

unit is in safe operating order.

USE & LOCATION

TO AVOID SHOCK HAZARD ... Your Palmcorder and power supply should not be exposed to rain or moisture. Do

not connect the power supply or operate your Palmcorder if it gets wet. Your Palmcorder has been designed for

outdoor use, however it is not designed to sustain direct exposure to water, rain, sleet, snow, sand, dust, or a direct

splashing from a pool or even a cup of coffee. This action could permanently damage the internal parts of your

Palmcorder. Do not attempt to disassemble this unit. There are no user serviceable parts inside. Unplug your

Palmcorder from the power supply before cleaning.

DO NOT AIM YOUR PALMCORDER AT THE SUN OR OTHER BRIGHT OBJECTS

DO NOT LEAVE THE PALMCORDER WITH THE EVF AIMED DIRECTLY AT THE SUN AS THIS MAY CAUSE

DAMAGE TO THE INTERNAL PARTS OF THE EVF

DO NOT EXPOSE YOUR PALMCORDER TO EXTENDED HIGH TEMPERATURE ... Such as, in direct sunlight,

inside a closed car, next to a heater, etc... This action could permanently damage the internal parts of your

Palmcorder.

AVOID SUDDEN CHANGES IN TEMPERATURE ... If the unit is suddenly moved from a cold place to a warm

place, moisture may form on the tape and inside the unit.

DO NOT LEAVE YOUR PALMCORDER OR THE POWER SUPPLY TURNED ON WHEN NOT IN USE.

STORAGE OF YOUR PALMCORDER ... Store and handle your Palmcorder in a manner that will not subject it to

unnecessary movement (avoid shaking and striking). Your Palmcorder contains a sensitive pick-up device which

could be damaged by improper handling or storage.

CARE

TO CLEAN YOUR PALMCORDER ... Do not use strong or abrasive detergents when cleaning your Palmcorder

body.

TO PROTECT THE LENS ... Do not touch the surface of the lens with your hand. Use a commercial Palmcorder

lens solution and lens paper when cleaning the lens. Improper cleaning can scratch the lens coating.

TO PROTECT THE FINISH OF YOUR PALMCORDER ... Before handling your Palmcorder, make sure your hands

and face are free from any chemical products, such as suntan lotion, as it may damage the finish.

Important Safeguards

Precautions

Getting Started

Table of Contents

Getting Started

Things You Should Know .................................................................................................. 2

Important Safeguards ....................................................................................................... 3

Precautions ....................................................................................................................... 4

Before Using ..................................................................................................................... 6

Quick Guide ...................................................................................................................... 9

Supplying Power ............................................................................................................. 11

Setting the Clock............................................................................................................. 13

Using the Palmcorder Menu ........................................................................................... 14

MENU OSD ..................................................................................................................... 15

Electronic Viewfinder/LCD Monitor Indications .............................................................. 19

Basic Operation

Camera Recording .......................................................................................................... 22

Remote Control (Optional) .............................................................................................. 26

Playback Your Recordings .............................................................................................. 27

Special Features

Card Features ................................................................................................................. 32

Dual Digital Electronic Image Stabilization System (D.E.I.S.)........................................ 39

Digital Zoom ....................................................................................................................40

Digital PhotoShot ............................................................................................................ 41

Index Search ................................................................................................................... 41

White Balance ................................................................................................................ 42

Recording Still Pictures .................................................................................................. 42

MAGICVU/0LUX (PV-DV401 only) .................................................................................. 42

Program AE .................................................................................................................... 43

Other Digital Functions ................................................................................................... 44

Picture in Picture (PinP) ................................................................................................. 45

Strobe Multi Mode ...........................................................................................................46

Focus .............................................................................................................................. 47

Backlight ......................................................................................................................... 47

Audio/Video Fade In/Out ................................................................................................. 48

High Speed Shutter ........................................................................................................ 48

Audio Dubbing using the External or Built-in Microphone.............................................. 49

Memory-Stop Editing ...................................................................................................... 50

Copying your Tapes to S-VHS or VHS Cassette ............................................................ 51

Copying from Digital Equipment (dubbing)..................................................................... 52

Transferring Your Images ................................................................................................ 53

Transferring Your Images (i.LINK) ................................................................................... 62

For Your Information

Palmcorder Accessory System ...................................................................................... 64

Palmcorder Accessory Order Form ................................................................................ 66

Notes On Operations ...................................................................................................... 67

Specifications ................................................................................................................. 68

Before Requesting Service ............................................................................................. 69

Request for Service Notice ............................................................................................. 71

Index of Controls ............................................................................................................. 72

Limited Warranty ............................................................................................................. 76

Servicenter List ............................................................................................................... 77

Spanish Quick Use Guide/Guía Para Uso Rápido ......................................................... 78

Index ................................................................................................................ Back Cover

Table of Contents

201_401. 5-8.p65 01/01/18, 17:075

6For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Before Using

This operating Instructions book is designed for use with models PV-DV201 and

PV-DV401. The PV-DV401 is the model used for illustrative purposes.

Features may vary, so please read carefully.

Model Number

LCD Monitor

Viewfinder

MAGICVU/0LUX

MIC IN EXTERNAL

63.5 mm (2.5 inch) Liquid

Crystal Display

Black and White

76.2 mm (3.0 inch) Liquid

Crystal Display

Color

Ye s

PV-DV201 PV-DV401

Differences between models

1 pc. AC Adaptor

(PV-DAC11) with AC Cable and DC Cable

1 pc. Shoulder

Strap (LSFC0013)

1 pc. Battery Pack

(PV-DBP8A)

1 pc. Lens Cap

(LSYF0478)

1 pc. A/V Cable

(LSJA0280)

1 pc. 8 MB

MultiMediaCard

(LSFT0198A)

1 pc. CD-ROM of Driver Software for

Windows 98/Me / Palmcorder USB Device

Driver for Windows 98/Me/ CARD LINK (for

USB) for Windows 98/Me / PHOTOVU

LINK/Movie Messenger for Windows 98/

Me/ ArcSoft Software for Windows 98/Me

(LSFT0247)

Microsoft® and Windows® are registered

trademarks of Microsoft in the United

States and other countries.

Intel® Pentium® is a registered trademark.

i.LINK and are trademarks.

PHOTOVU LINK/Movie Messenger is a

registered trademark.

IBM is a registered trademark of IBM

Company.

MultiMediaCard is a registered trademark.

SD is a trademark.

Unpack your Palmcorder

1 pc. USB Cable

(LSJA0354)

AY-DVM30EA

AY-DVM60EA

Cassette type

60 minutes

45 minutes

SP LP

90 minutes

30 minutes

Record Speed/

Playback time

AY-DVM80EA 80 minutes 120 minutes

Use only those tapes having the

Mini

logo indicating the 6.35 mm digital

standard.

Record Speed/Playback Time

1To prevent accidental erasure:

Slide the tab to the left (open).

2To record again:

Slide the tab to the right (close).

Cassettes have a sliding record tab to

ensure recordings are not accidentally

erased.

record tab

Erase Protection

Before Using

201_401. 5-8.p65 01/01/18, 17:076

Getting Started

1Slide Light into the Built-in Light

Mount.

Be sure it locks into place.

2Press LIGHT to turn

ON or OFF.

Before Using

1Slide TAPE EJECT to open the

Cassette Compartment Cover.

2Insert a cassette record tab up,

window side facing out.

3Press PUSH TO CLOSE mark to

close the Cassette Compartment

Cover.

1TAPE EJECT

Switch

Cassette Compartment Cover

3PUSH TO

CLOSE mark

Note

• If hand strap is tight it may prevent Cassette Compartment Cover from fully opening

for tape insertion or ejection. Loosen hand strap if necessary.

• When inserting the cassette, make sure it faces in the right direction and then push in

completely.

Cassette Insertion/Removal Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

To brighten the natural colors in a scene.

Using the Light (Optional) Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Set POWER to CAMERA or M-CARD.

• If the Palmcorder is connected to a power

source, the cassette can be inserted and

ejected without turning the Palmcorder

on.

• To remove the cassette...

Slide TAPE EJECT to open the Cassette

Compartment Cover and pull the cassette

tape straight out.

Hint to locate recording position when inserting cassette

• When you insert a partially recorded cassette, use the Edit Search Function (see page

24) to visually confirm the point at which you want to start a new recording. Especially

advisable when you want to add a recording to a tape that is already full.

2LIGHT Button

LIGHT RELEASE Button

Built-in Light Mount

Caution

This light becomes hot during operation.

Make sure nothing covers the Light

during operation.

• Using the light will reduce battery

operating time.

• Be sure to provide

adequate ventilation if using Light in a

hot environment for an extended period.

• Be sure LIGHT is set to OFF when not in

use.

• Do not attempt to lift or carry the

Palmcorder by holding the Enhancement

Light.

• If light bulb needs to be replaced, take

Light to your nearest authorized

servicenter.

Note

To remove the Light:

Press LIGHT RELEASE and slide the

Light out of the mount.

201_401. 5-8.p65 01/01/18, 17:077

8For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Before Using

4Thread the strap ends through the

Strap Attachment Rings.

5Reinsert the strap ends through their

buckles.

• Make sure the straps are not

twisted.

1Loosen the strap from the Buckle and

create a loop.

2Pull the strap firmly through the

Buckle to shorten or lengthen the

strap.

1Undo the two strap ends from their

buckles.

2Remove the buckle from one end of

the strap.

3Thread the strap (with no buckle)

through the Light Holder so that it

faces outward. Then, reinsert the

buckle.

Adjust the Length

1Insert the Light into the Light Holder for

Storage.

2To remove the Light, press LIGHT

RELEASE and slide Light out of the

holder.

LIGHT RELEASE

Button

Light Holder

Attach the Light (Optional)

Adjust the length of the Hand Strap to

the size of your hand as illustrated.

Hand Strap

Attaching the Lens Cap Cord to the Hand

Strap

Remove the Hand Strap from the front

clasp and thread the Strap through the loop

in the Lens Cap Cord.

Reattach the Hand Strap.

Hand Strap

Lens Cap

Attaching the Shoulder Strap

201_401. 5-8.p65 01/01/18, 17:078

Getting Started

Quick Guide

Insert the Battery Pack

Insert Cassette

1Slide the Viewfinder backward to its

fully expanded position and then tilt it

upward. (For model PV-DV201, tilt

Viewfinder upward.)

2Insert the Battery Pack and slide it down

until it locks with a click.

1Set POWER Switch to

VCR or CAMERA.

4Press PUSH TO CLOSE

mark to close the Cassette

Compartment Cover.

2Slide TAPE EJECT Switch to open

the Cassette Compartment Cover.

3Insert a cassette record tab up,

window side facing out.

• Make sure the record tab

is closed. (See page 6.)

Protection Film

Note

• Remove the Protection Film before use.

Before you begin

• Charge the Battery. (See page 11.)

VCR

OFF

CAMERA

M-CARD

Camera Recording

When the LCD monitor is fully open, the

Viewfinder automatically turns OFF.

180°

90°

VCR

OFF

CAMERA

M-CARD

1Set POWER Switch to

CAMERA.

LCD Monitor

2Adjust the Vision Adjustment

Control to your eyesight.

[PV-DV401] [PV-DV201]

3Press LCD-OPEN Button to

unlock the LCD monitor. Swing

it fully open and adjust the

angle.

4Press REC/PAUSE Button to start

recording.

Press REC/PAUSE Button again to

pause recording.

Viewfinder

201_401. 9-13.p65 01/01/18, 17:079

10 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Insert Memory Card*

2Press LCD-OPEN Button

to unlock the LCD monitor.

Swing it fully open and

adjust the angle. 4Insert the Memory Card.

LCD Monitor

3Slide CARD EJECT Switch to open

M-CARD door.

M-CARD Door

5Close the M-CARD Door.

180°

90° 1Set POWER

Switch to OFF.

VCR

OFF

CAMERA

M-CARD

Quick Guide

To Watch Playback in the LCD

(Liquid Crystal Display)

When the LCD monitor is fully open, the

Viewfinder automatically turns OFF.

180°

90°

VCR

OFF

CAMERA

M-CARD

Before you begin

• Charge the Battery. (See page 11.)

1Set POWER Switch

to VCR.

3Press REW Button to

rewind the tape.

4Press PLAY Button to

start playback.

5Press STOP Button

to stop playback.

M-CARD Lock Switch

Before you begin

• Charge the Battery. (See page 11.)

*Memory Card: MultiMediaCard or SD Memory Card (See page 64.)

• Be sure to insert the Memory Card before using the Card PhotoShot. (See page 32.)

Below is a list of memory cards which can

be used in this Palmcorder.

Memory Card

MultiMediaCard (LSFT0198A) (supplied)

MultiMediaCard (SanDisk brand)

SD Memory Card (optional) (See page 64.)

Capacity

8 MB

8 MB, 16 MB

16 MB, 32 MB, 64 MB

LOCK

SD Memory Card write protection switch

A write protection switch is located on the SD Memory Card. Sliding the

switch to the “LOCK” position prevents writing on or formatting the card.

Write protection switch

2Press LCD-OPEN Button to

unlock the LCD monitor. Swing it

fully open and adjust the angle.

201_401. 9-13.p65 01/01/18, 17:0710

Getting Started

Supplying Power

Charge the Battery Pack on

the AC Adaptor

1Connect and plug in the Power Cord

as shown.

• POWER Lamp will light.

• Remove the DC Cable, if attached,

from the adaptor.

2Attach the Battery as shown to

charge.

• CHARGE Lamp lights up. It goes out

when charging is complete (approx.

1 hour). Expect approx. 1 hour

30 minutes of operation (EVF usage)

when fully charged.

3Remove the Battery.

Slide the Battery out and then lift up.

POWER Lamp

CHARGE Lamp

About the Flashing of the CHARGE Lamp

• Charge the Battery within an ambient temperature range of 10 °C and 30 °C.

• If charging is done in extreme low or high temperatures, Battery charge time increases.

CHARGE Lamp flashes when...

•The Battery is being charged, but charging is taking longer than normal.

• Charging is not possible. Remove the Battery once, wait a short time, then re-attach it

for charging.

Note

1Slide the Viewfinder backward to its

fully extended position and then tilt it

upward. (For model PV-DV201, tilt

Viewfinder upward.)

2Insert the Battery Pack and slide it

down until it locks with a click.

Insert the Battery Pack Remove the Battery Pack

To remove the Battery Pack:

Slide the Battery upward while sliding the

BATTERY RELEASE Switch.

BATTERY

RELEASE

Switch

201_401. 9-13.p65 01/01/18, 17:0711

12 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Supplying Power

1Slide the Battery upward while sliding

the BATTERY RELEASE Switch to

remove the Battery Pack.

(See page 11.)

2Insert the DC Cable into the DC IN

Terminal.

3Connect the other end of the DC

Cable to the AC Adaptor as shown.

4Plug in the AC Adaptor.

• The POWER Lamp on the AC

Adaptor lights up.

• When not in use, unplug the AC Adaptor

from the AC outlet. (AC Adaptor

consumes 1 W of electric power when

plugged into an AC outlet even when not

in use.)

DC Cable

(Supplied)

DC IN Terminal

Use AC Adaptor

Note

POWER

Lamp

DC IN Terminal

Supplying Power

Caution:

• Charge only with specified charger.

• Charge the Battery within an ambient

temperature range of 32° F (0° C) and

104° F (40° C).

• The Battery may be warm after charging

or just after use. This is normal.

• Do not use an insufficiently charged or

worn out Battery.

• If charging is done in extreme low or high

temperatures, Battery charge time

increases.

Safety precautions:

• Do not get the Battery near, or dispose of

in fire.

• Do not directly connect (short circuit) the

positive (+) and negative (–) terminals.

• Never attempt to disassemble or

reassemble the Battery.

To avoid damage to the Battery:

• Do not drop or jar the Battery.

• Use the Battery with specified models

only.

• If the Battery is used in extremely high

temperatures, a safety device will

automatically prevent operation.

To insure longer battery life:

•While not in use, remove Battery from

the Palmcorder and AC Adaptor and

store in a cool, dark, dry place. If you

leave the Battery in the Palmcorder or on

the AC Adaptor, the Battery will no longer

be rechargeable.

• Keep the Battery terminals clean.

Battery Care

BATTERY

RELEASE

Switch

DC Output Connector

201_401. 9-13.p65 01/01/18, 17:0712

Getting Started

Setting the Clock

1Press MENU to display the Camera or

VCR mode menu screen.

(See page 14.)

2Rotate JOG KEY to select DISPLAY

SETTING , and then press JOG KEY

to display the DISPLAY SETTING

menu screen.

3Rotate JOG KEY to select CLOCK-

SET , and then press JOG KEY to set

to ON. (See pages 16, 18.)

• The DATE/TIME SETTING menu

is displayed.

4Rotate JOG KEY to select YEAR, then

press JOG KEY to fix and move to the

next item. Likewise, set the month,

day, hour, and minutes.

• To make corrections,

Press JOG KEY repeatedly to move back

to an item and correct.

• A built-in Battery maintains clock

operation. If the Palmcorder is not

connected to a power source for a few

months, the built-in battery may discharge

and “CLOCK BATTERY” indication

appears. (See page 21.)

EXAMPLE:

When DATE/TIME setting is

completed, press MENU three times to

start the clock and exit.

: 2001

YEAR

Push

PUSH

Rotate

PUSH

: JAN

: FEB

MONTH

1MENU

Button

2, 3, 4JOG KEY

The date and time is calculated, including

leap year, up to DEC 31 2089.

Note

[ CAMERA MENU ] [ VCR MENU ]

Set the Date and Time Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12).

• Set POWER to CAMERA or VCR.

201_401. 9-13.p65 01/01/18, 17:0713

14 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

APress JOG KEY to set your selection.

BRotate JOG KEY to select a menu

item.

CPress JOG KEY to set your selection.

• The “●” mark indicates selection.

DPress MENU twice to exit the menu.

Using the Palmcorder Menu

The Palmcorder features two menu

displays: one for CAMERA mode

(recording) and the other for VCR mode

(Playback). (See pages 15~18.)

Using the Palmcorder Menu

• While the Menu screen is displayed, you

cannot record on or play a tape.

• While recording, the Menu screen cannot

be displayed.

• During playback, the Menu screen can be

displayed.

1Press MENU to display the CAMERA

or VCR menu (according to the

POWER setting).

2Rotate JOG KEY to select a menu

item.

1, D

Button

2, A, B, CJOG KEY

Displaying the MENU

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Set POWER to CAMERA or VCR.

1 : D. FUNCTION

CAMERA FUNCTION menu is displayed. To

select one of the 10 digital functions

(MIRROR, STROBE, MOSAIC, SLIM, TRAIL,

STRETCH, GAIN-UP, WIPE, MIX, PinP).

2 : ADJUST

CAMERA ADJUST menu is displayed.

To select PROG. AE, W. BALANCE, or

H.S.S. (High Speed Shutter).

3 : REC MODE

CAMERA REC-MODE menu is displayed. To

select REC-SPEED, AUDIO-REC, INDEX,

SHUTTER, SELF-REC, or WIND-CUT.

4 : SET-UP

CAMERA SET-UP menu is displayed. To

select REMOTE, BEEP, or MAGICVU (PV-

DV401 only).

5 : DISPLAY SETTING

DISPLAY SETTING menu is displayed. To

select DISPLAY, C.RESET, DATE/TIME, or

CLOCK-SET.

6 : LCD/EVF SETTING

LCD/EVF SETTING menu is displayed. To

select LCD BRIGHTNESS, LCD COLOR

or EVF BRIGHTNESS.

7 : PHOTO TITLE

PHOTO TITLE menu is displayed. To select

TITLE or MODE.

1 : PLAY FUNCTION

VCR PLAY FUNCTION menu is displayed. To

select D. FUNCTION or D.EFFECT.

2 : REC MODE

VCR REC MODE menu is displayed. To

select REC-SPEED.

3 : PLAY MODE

VCR PLAY MODE menu is displayed.

To select INDEX, AUDIO, REMOTE, or

B.SEARCH.

4 : MULTI SETTING

MULTI SETTING menu is displayed.

To select SPEED.

5 : DISPLAY SETTING

DISPLAY SETTING menu is displayed. To

select DISPLAY, C.RESET, DATE/TIME, or

CLOCK-SET.

6 : LCD/EVF SETTING

LCD/EVF SETTING menu is displayed. To

select LCD BRIGHTNESS, LCD COLOR

or EVF BRIGHTNESS.

CAMERA Main menu VCR Main menu

Setting the MENU Items

(EX. VCR Mode menu)

201_401.14-16.p65 01/01/18, 17:0714

Getting Started

MENU OSD

DIGITAL FUNCTION (See page 44.)

To select one of the 10 digital

functions.

Setting to OFF cancels the previously

selected digital function.

PROG. AE (See page 43.)

To select one of the 5 Program AE

modes. Setting to OFF cancels the

previously selected Program AE

mode.

W.BALANCE (See page 42.)

To select one of the 3 White Balance

modes.

H. S. S. (High Speed Shutter)

(See page 48.)

To select a desired shutter speed.

REC-SPEED (See page 6.)

SP:Normal recording speed mode.

LP: Recording time is 1.5 times as

long as in the SP mode. For

example, 120 minutes of

recording is possible on a

80 minute tape.

AUDIO-REC (See page 49.)

12 bit: The sound is recorded in the

12 bit/32 kHz mode.

16 bit: The sound is recorded in the

16 bit/48 kHz high-quality

mode.

INDEX (See page 30.)

DAY: An index signal is recorded

when recording is restarted

after the date has changed

since the last recording.

2 HOUR:An index signal is recorded

when recording is restarted

after a lapse of more than

2 hours.

SHUTTER (See page 41.)

When set to ON, still pictures taken in

the PhotoShot mode are recorded with

a visual shutter effect and click sound.

SELF-REC (See page 23.)

NORMAL: During self-recording, the

picture on the LCD Monitor is the

same as it will be recorded.

MIRROR: During self-recording, the

picture on the LCD Monitor is

horizontally reversed.

WIND-CUT (See page 22.)

To reduce sound distortion caused by

wind hitting the microphone.

However, this slightly deteriorates the

sound reproduction in the bass range.

MENU OSD

Camera Mode Menu Screen

201_401.14-16.p65 01/01/18, 17:0715

16 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

MENU OSD

REMOTE (See page 26.)

VCR1: To receive signals from the

Remote Control, set to VCR1.

VCR2: To receive signals from

the Remote Control, set to

VCR2.

OFF: To prevent reception of

signals from the Remote

Control.

BEEP

Set to ON to hear beep when starting

and stopping camera recording or

when unusual conditions occur. To

cancel the beep, set to OFF.

Palmcorder will beep:

Once when you start recording

Twice when you stop recording

Repeatedly when warning of

unusual conditions.

(See page 21.)

MAGICVU (PV-DV401 only)

(See page 42.)

To select one of the 3 MAGICVU

modes slide MAGICVU/0LUX Switch

to ON.

DISPLAY (See page 19.)

To select the desired type of display

and counter indication displayed on

the LCD Monitor or in the viewfinder.

C.RESET (See page 19.)

Setting to ON resets the counter to

zero.

DATE/TIME (See page 20.)

The date and time can be set and

displayed on the screen.

CLOCK-SET (See page 13.)

When set to ON, the date and time

can be set on the screen.

LCD/EVF SETTING (See page 23.)

Setting to ON displays the menu for

adjusting the LCD brightness,

color level, and the EVF brightness.

TITLE (See page 38.)

Photo Title is recorded.

MODE (See page 38.)

To select one of the 2 Photo Title

modes.

MENU OSD

201_401.14-16.p65 01/01/18, 17:0716

Getting Started

DIGITAL FUNCTION (See page 44.)

To select one of the 6 digital functions.

Setting to OFF cancels the previously

selected digital function.

D. EFFECT (See page 44.)

To select one of the 2 digital picture

effects for playback. Setting to OFF

cancels the previously selected digital

effect.

REC-SPEED (See page 6.)

SP: Normal recording speed

mode.

LP: Recording time is 1.5 times as

long as in the SP mode. For

example, 120 minutes of

recording is possible on an

80 minute tape.

INDEX (See page 30.)

To select the desired Index Search

function.

PHOTO: To search for Photo shot

pictures.

SCENE: To search for scenes marked

with Index signal.

AUDIO (See page 50.)

To select the desired audio playback

mode after performing audio dubbing

in the 12 bit mode (SP mode only).

ST1 : The original sound alone is

played back.

ST2 : The dubbed sound alone is

played back.

MIX : The original sound and the

dubbed sound are played back

together.

REMOTE (See page 26.)

VCR1: To receive signals from the

Remote Control, set to VCR1.

VCR2: To receive signals from the

Remote Control, set to VCR2.

OFF : To prevent reception of signals

from the Remote Control.

B.SEARCH (Blank Search)

(See page 25.)

Select ON to go directly to a blank

portion of the tape.

VCR Mode Menu Screen

MENU OSD

201_401.17-18.p65 01/01/18, 17:0717

18 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

SPEED (See page 46.)

In Strobe Multi mode, used to select

the interval at which a succession of

still screens are captured from the

playback picture.

FAST : Every 0.3 seconds

NORM : Every 0.6 seconds

SLOW : Every 1.0 seconds

DISPLAY (See page 19.)

To select the desired type of display

and counter indication displayed on the

LCD Monitor or in the viewfinder.

C.RESET (See page 19.)

Setting to ON resets the counter to

zero.

DATE/TIME (See page 19.)

The date and time can be set and

displayed on the screen.

CLOCK-SET (See page 13.)

When set to ON, the date and time can

be set on the screen.

LCD/EVF SETTING (See page 23.)

Setting to ON displays the menu for

adjusting the LCD brightness, color

level, and the EVF brightness.

M-CARD Menu Screen

MENU OSD

[ Photo Rec Mode Menu Screen ]

[ Photo Play Mode Menu Screen ]

REC MODE (See page 32.)

To select Photo Rec Mode.

DISPLAY (See page 34.)

Select to OFF to cancel all Displays

on the screen.

DCF (See page 34.)

Select to OFF to cancel DCF No. on

the screen.

201_401.17-18.p65 01/01/18, 17:0718

Getting Started

Here are some of the basic indications which will appear on the Palmcorder EVF and LCD

Monitor. Only Date and Time indications will be recorded onto the tape.

Display ON/OFF and Counter/Time Code

The indication switches as shown

below when the desired “DISPLAY”

mode is selected from the menu.

(See pages 16, 18.)

• When OFF is selected, all displays

are turned off.

Battery Remaining

Tape Remaining

• It will take several seconds for the tape

remaining indicator to operate after the

tape starts moving.

Digital Zoom and other Digital

Functions (See page 40.)

This display appears when the digital

zoom function has been activated.

Playback Effect (See page 44.)

This display appears when SEPIA or

MONO is selected in VCR menu.

Tape Speed Indication (See page 15.)

Indicates the tape speed (SP or LP).

(AY-DVM30EA) (AY-DVM60EA)

Memory Counter M 0:00:00

The Palmcorder will stop whenever it

reaches the point where the counter was

previously set to M 0:00:00 during audio

dub, fast forward, or rewind.

Time Code 0h00m00s00f

The Palmcorder calculates and displays

exactly where you are on any tape in terms

of hours, minutes, seconds, and frames

(30 frames = 1 second).

• This display can not be reset.

IMPORTANT NOTE:

• Display must be set to ON for MF, AE,

W.BALANCE or BACK LIGHT indications

to be displayed on the EVF or LCD Panel

when selected.

• C.RESET does not work when DISPLAY

is set to OFF and T.CODE.

Linear Time Counter Memory Counter

Time Code

FULL

EMPTY

R0:30

R0:00

R1:00

R0:00

e f

Electronic Viewfinder/LCD Monitor Indications

201_401.19-21.p65 01/01/18, 17:0719

20 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Electronic Viewfinder/LCD Monitor Indications

Volume Display (See page 27.)

The volume bar appears when the

volume of the built-in speaker is being

adjusted.

Date and Time Indication

(See pages 16, 18.)

As shown below, the date and time

indication changes each time DATE/TIME

is selected from the Palmcorder’s MENU

(see pages 16, 18) or the DATE/TIME

Button is pressed on the remote (optional).

Tape Mode Indications

REC Recording.

PHOTO PhotoShot recording.

PAUSE Paused during recording.

PLAY Playback.

R Repeat Playback.

CHK Recording Check.

FF Fast forward.

REW Rewind.

FF Search.

REW Search.

BLANK Blank Search.

SEARCH Index Search.

Digital EIS Indications

(See page 39.)

Zoom Magnification Level

(See page 40.)

Manual Focus Indication

(See page 47.)

White Balance Indication

(See page 42.)

PROGRAM-AE Indication

(See page 43.)

Backlight Indication

(See page 47.)

Shutter Mode indication

(See page 48.)

WARNING indication

(See page 21.)

The warning displays appear in the

EVF and the LCD monitor.

WIND-CUT indication

(See page 15.)

MAGICVU (PV-DV401 only)

(See page 16.)

This display appears when MAGICVU

is set to ON.

DATE/TIME

DATE

OFF

ikl

p q r

201_401.19-21.p65 01/01/18, 17:0720

Getting Started

The following warning displays appear in the EVF and the LCD monitor.

Indications

If the Palmcorder is in CAMERA mode without a cassette inserted,

“” will flash and “TAPE NOT INSERTED” will appear for

5 seconds. Recording will not start.

If the Palmcorder is in CAMERA mode with the cassette sliding

record tab opened, “ ” will flash and “CHECK REC TAB” will

appear for 5 seconds. Recording will not start.

When Audio dub is performed and the sliding record tab is open,

or a blank portion of tape is detected, “ ” will flash and

“CANNOT REC” will appear for 5 seconds.

When the tape is about to end in REC mode, “ END” will

flash and “TAPE END” will appear for 5 seconds.

When an incompatible tape is detected, “INCOMPATIBLE

TAPE” will appear for 5 seconds.

If the video heads require cleaning, “NEED HEAD CLEANING”

will appear for 5 seconds.

When the Palmcorder and remote are not set to the same mode

(VCR1 or VCR2), “CHECK REMOTE MODE” appears for 5

seconds. Also appears when the Palmcorder is first turned on.

Condition

When an AUDIO DUB is attempted on a pre-recorded LP tape,

“CANNOT REC LP-MODE” will appear for 5 seconds.

If excessive moisture condenses in the unit, “WARNING” will

flash, “DEW DETECTED” will appear, and the Palmcorder will

automatically turn OFF in 15 seconds.

In this case, wait until the indicator no longer flashes when your

Palmcorder is turned ON again.

When a battery recharge is necessary, “WARNING” will

flash, “LOW BATTERY” will appear, and the Palmcorder will

automatically turn OFF in 15 seconds. (See page 19.)

When the built-in lithium clock battery is discharged, “CLOCK

BATTERY” will appear. To re-charge the lithium clock battery,

connect the AC Adaptor to the Palmcorder. Recharging takes

approx. 4 hours. Reset the clock after charging.

If you play tape recorded in a format other than NTSC or you try to

copy a copy-protected data. “INCOMPATIBLE DATA” will appear.

Electronic Viewfinder/LCD Monitor Indications

When a still image is transferred from a tape to an already full

Memory Card, “NO SPACE LEFT” appears.

If the Palmcorder is in M-CARD mode or Photo Title (CAMERA

mode) and the DV Interface Cable (i.LINK) is connected,

“DISCONNECT DV CABLE” appears. In this case, remove the DV

Interface Cable (i.LINK) from the Palmcorder.

201_401.19-21.p65 01/01/18, 17:0821

22 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Camera Recording

Remove the lens cap and clip it to the hand

strap.

1Set POWER to CAMERA.

• The POWER Lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2With the Viewfinder Eye Cup up to

your eye, adjust the Vision

Adjustment Control to your eyesight.

(See page 9.)

3Press REC/PAUSE to start recording.

• “REC” is displayed on the screen.

Press REC/PAUSE again to pause

recording.

• To reduce microphone wind noise,

set the WIND-CUT to ON. (See

WIND- CUT on page 15.)

EVF

To conserve power

After 5 minutes, the Record/Pause mode

will automatically change to Standby mode.

To resume recording, set POWER to OFF

and then ON again.

• When the Palmcorder is aimed at

excessively bright objects, or bright lights,

a vertical bar may appear in the picture.

This is a normal characteristic of the CCD

pick-up device. Try to avoid this whenever

possible.

WARNING:

• Do not leave the Palmcorder with the

EVF aimed directly at the sun as this

may cause damage to the internal parts

of the EVF.

• Do not lift, or carry, the Palmcorder by

the EVF or the LCD Monitor.

Simple Recording Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Insert a cassette with record tab closed.

(See page 6.)

Zoom

You can gradually zoom in for close ups or zoom out for wide angle shots.

• The zooming speed ranges from a slow 22 seconds to a fast 2 seconds according

to the amount of pressure applied to the POWER ZOOM Switch.

Zoom slowly : by lightly pressing the “T” (Telephoto) or the “W” (Wide Angle) side of the

POWER ZOOM Switch.

Zoom quickly : by applying more pressure.

Note

REC/PAUSE mode

1POWER

Switch

3REC/PAUSE Button

Vision

Adjustment

Control

POWER ZOOM Switch

Clip here

POWER

Lamp

201_401.22-24.p65 01/01/18, 17:0822

Basic Operation

The LCD (Liquid Crystal Display) monitor

can be used while recording.

1Press LCD-OPEN to unlock the LCD

monitor.

2Swing the LCD monitor fully open

and adjust the viewing angle.

• The LCD monitor will automatically

turn on.

• When the LCD monitor is completely

closed, it will shut off automatically to

save power.

• Adjust the LCD Brightness and/or

color of the LCD monitor if necessary.

Please refer to “To adjust the LCD

BRIGHTNESS or COLOR” below.

3Start recording. (See page 22.)

• Using the LCD monitor will reduce battery

operating time.

• Close the LCD monitor completely when

not in use.

Rotate the LCD monitor 180 degrees so it

faces the same direction as the lens to

record yourself (CAMERA mode).

The picture in the LCD monitor will appear

reversed.

Set SELF-REC to MIRROR (see page 15)

in the Camera mode menu screen to see

the picture as it is actually being recorded.

Using the LCD Monitor

1LCD-OPEN

Button

Self Recording

Note

180°

90°

180°

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Insert a cassette with record tab closed.

(See page 6.)

To adjust the LCD BRIGHTNESS

or COLOR

APress MENU to display the main menu

screen.

BRotate JOG KEY to select LCD/EVF

SETTING from the main menu screen.

(See pages 16, 18.)

CPress JOG KEY to display the LCD/

EVF SETTING screen.

DPress JOG KEY to select

LCD BRIGHTNESS or LCD COLOR,

then rotate JOG KEY to adjust.

EPress MENU twice to exit this mode.

Camera Recording

201_401.22-24.p65 01/01/18, 17:0823

24 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

1Set POWER to CAMERA.

• The POWER Lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2In REC/PAUSE mode, hold down

EDIT SEARCH to perform a

forward visual search or EDIT

SEARCH to perform a reverse

visual search. Releasing the button

stops the search.

3Press REC/PAUSE to continue

recording.

2EDIT SEARCH

2EDIT

• During Edit Search, the picture will

become mosaic in both and

search, the sound will be muted in

reverse visual search.

• Make sure the SP/LP tape speed setting

is the same as the recording to eliminate

distortion during edit search.

2, 3REC/

PAUSE Button

1POWER Switch

Edit Search

You can visually search for scenes in

CAMERA mode to maintain proper

continuity when taping.

Note

Camera Recording

1Press EDIT SEARCH briefly in the

REC/PAUSE mode.

The [CHK] indication appears.

After checking, the Palmcorder returns

to the REC/PAUSE mode.

• For Recording Check, the Palmcorder

must be in the same mode (SP or LP) as

was used for recording, otherwise the

playback picture is distorted.

1EDIT SEARCH

Recording Check

To playback the final few seconds of the

last recorded scene in the REC/PAUSE

mode.

CHK

201_401.22-24.p65 01/01/18, 17:0824

Basic Operation

1Set the POWER to VCR.

• The POWER Lamp lights red.

• Be sure POWER is fully turned to

VCR position.

2Press MENU to display the VCR

mode menu screen.

3Rotate JOG KEY to select PLAY

MODE , then press JOG KEY to

display the VCR PLAY MODE menu

screen.

4Rotate JOG KEY to select B.SEARCH

in the VCR PLAY MODE menu.

(See page 17.)

5Press JOG KEY to select ON.

• “BLANK” will appear on the screen.

2MENU

Button

3, 4, 5JOG KEY

1POWER Switch

Blank Search

You can go directly to a blank portion of

tape and start recording exactly where you

left off.

To operate Camera functions:

Set POWER to CAMERA.

To operate VCR functions:

Set POWER to VCR.

Controlled Functions

Rec/Pause (See page 22.)

Tele (Zoom) (See page 22.)

Wide (Zoom) (See page 22.)

Date/Time (See page 20.)

Reset (See page 50.)

PhotoShot (See page 41.)

Display On TV (See page 31.)

Counter/Time Code (See page 19.)

Audio Dubbing (See page 49.)

Record (See page 52.)

Menu (See page 14.)

Play (See page 27.)

FF/Search (See page 28.)

REW/Search (See page 28.)

Pause/Select (See pages 14, 28.)

Stop/Set (See pages 14, 27.)

Slow/Frame Advance (Forward) (See pages 28, 29.)

Slow/Frame Advance (Backward) (See pages 28, 29.)

Index Search (Forward) (See page 30.)

Index Search (Backward) (See page 30.)

Speaker Volume (See page 27.)

Remote Sensor

You can operate the major functions of your Palmcorder from up to approximately 16 feet

(5 m) away (indoors). Aim the IR Remote Control toward the front of the Palmcorder and

press the desired buttons (Remote Sensor is located under the lens).

Remote Control (Optional, page 64)

Camera Recording

201_401.25-27.p65 01/01/18, 17:0825

26 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Remote Control (Optional)

You can control any two Panasonic

Palmcorders with one Remote control

(Optional, page 64). In order for the remote

to distinguish between the two units, it is

necessary to set one of the Palmcorders to

VCR 2. On the remote, press VCR 1 or

VCR 2 to control the desired Palmcorder.

DATE /

TIME PHOTO

SHOT REC /

PAUSE

A.DUB

STOP /

SET INDEX

SLOW /

F.A DV PAUSE /

SEL SLOW /

F.A DV

REW / PLAY FF /

- SPKR VOL +

INDEX

REC

CAMCORDER

CAMERA

DISPLAY

ON TV

COUNTER /

RESET

For VCR 2 :

Press these

buttons at the

same time.

For VCR 1 :

Press these

buttons at the

same time.

Remote Controlling Two

Palmcorders

Optional

Note

1Set the POWER to VCR or CAMERA.

• The POWER Lamp lights red.

• Be sure POWER is fully turned to

VCR or CAMERA position.

2Press MENU to display the VCR or

CAMERA mode menu screen.

3Rotate JOG KEY to select CAMERA

SET-UP in the CAMERA mode menu

screen or VCR PLAY MODE in the

VCR mode menu screen, then press

JOG KEY to display the CAMERA

SET-UP or VCR PLAY MODE menu

screen.

4Rotate JOG KEY to select REMOTE ,

and then press JOG KEY to select

VCR 2. (See pages 16, 17). Leave the

other Palmcorder set to VCR1.

5Set the Remote Control (Optional,

page 64) to VCR 1 or VCR 2 to

correspond with the Palmcorder you

wish to control. (See above left.)

• When the Palmcorder and remote are

not set to the same mode (VCR1 or

VCR2), “CHECK REMOTE MODE

(REMOTE)” will appear.

• After replacing the Remote Control

Battery, the remote will default to VCR 1.

Remote Control (Optional)

Replace battery with Panasonic PART NO. VSBW0004 (CR2025)

only. Use of another battery may present a risk of fire or explosion.

Caution: battery may explode if mistreated. Dispose of used battery

properly. Keep away from children. Do not recharge, disassemble or

dispose of in fire.

1Insert a slender pointed object, such as the tip of a ball-

point pen into the slot so that it fits into the hole (as shown

A). Then, while sliding to the right, pull the Battery Tray

out with your fingernail.

2Insert the battery into the Battery Tray with the + mark

facing down.

Do not reverse the polarity.

3Insert the Battery Tray.

Replace the Battery

Optional

201_401.25-27.p65 01/01/18, 17:0826

Basic Operation

Playback your Recordings

1Press LCD-OPEN to unlock the LCD

monitor and swing open.

2Press REWIND/SEARCH to rewind

the tape.

3Press PLAY to start playback.

To adjust the volume:

AHold down VOLUME KEY until the

volume setting screen appears.

(See page 20).

BRotate VOLUME KEY to adjust the

volume of the built-in speaker. To

remove the volume setting screen, hold

down VOLUME KEY again.

•Adjust the picture on the LCD monitor if

needed. (See page 23.)

4Press STOP to stop playback.

• When the tape reaches its beginning

during rewind or rewind search, it will

stop automatically.

• If you press PLAY for more than 5

seconds, the Palmcorder will go into

Repeat Playback mode when the

tape reaches its end. The letter “R ”

will appear in the EVF and LCD

monitor. To exit the Repeat Playback

mode, turn the Palmcorder OFF.

2REWIND

Button

VOLUME KEY

4STOP

Button 3PLAY Button

Built-in

Speaker

1LCD-OPEN

Button

Playback using the LCD Monitor

You can also use the LCD monitor to

playback your recording.

Note

180°

90°

You can place the Palmcorder on a table,

etc. for viewing. Rotate the LCD Monitor

180° and swing it up against the

Palmcorder body as shown.

PHONE

Jack

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Insert a recorded cassette.

• Set POWER to VCR.

• When a tape recorded in LP mode on

another digital video camera is played

back on this unit, the picture may appear

mosaic.

• Using the LCD monitor reduces battery

operating time.

• You can connect earphones (not

supplied) to the PHONE Jack.

201_401.25-27.p65 01/01/18, 17:0827

28 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Playback Your Recordings

Rapid Visual Search

DATE /

TIME PHOTO

SHOT REC /

PAUSE

A.DUB

STOP /

SET INDEX

SLOW /

F.A DV PAUSE /

SEL SLOW /

F.A DV

REW / PLAY FF /

- SPKR VOL +

INDEX

REC

CAMCORDER

CAMERA

DISPLAY

ON TV

COUNTER /

RESET

SLOW/

F.ADV

PLAY Button

PLAY Button PAUSE Button

A, BFAST FORWARD/

SEARCH Button

A, BREWIND/

SEARCH Button

PAUSE Button

Special Effect Features

During Playback

Optional

Slow Motion Playback

• Sound is muted during all special effects.

ADuring playback, hold down FAST

FORWARD/SEARCH or REWIND/

SEARCH.

The search will continue for as long

as the button is held down.

BPress FAST FORWARD/SEARCH

or REWIND/SEARCH once for a

continuous rapid visual search.

Press PLAY to release.

• When executing a rapid visual

search, the picture may become

bluish for an instant or mosaic. This

is normal during

this mode.

STILL Picture

Note

SLOW/

F.ADV Button

Fast Forward/Rewind Check

Press PAUSE during playback.

Press PLAY or PAUSE to release.

• To protect the tape and video heads, your

Palmcorder’s operating modes will revert

as follows:

STILL STOP (after 3 minutes.)

Optional Remote Control Only

(See page 64)

Forward Slow = Press SLOW/F.ADV

during play.

Reverse Slow =Press SLOW/F.ADV

during play.

Press PLAY to release. (During reverse

slow motion playback, time code indication

may not change regularly.)

• Palmcorder will automatically STOP when

in slow motion for more than 10 minutes.

• During slow motion playback, picture may

move up and down. This is normal.

• When you start or stop slow motion

playback, the picture may become bluish

for an instant.

Monitor normal picture playback during fast

forward or rewind.

•Hold down FAST FORWARD/SEARCH

during fast forward.

•Hold down REWIND/SEARCH during

rewind.

• The picture will appear for as long as the

button is held down.

Note

REWIND/

Button

FAST

FORWARD/

Button

201_401.28-31.p65 01/01/18, 17:0828

Basic Operation

DATE /

TIME PHOTO

SHOT REC /

PAUSE

A.DUB

STOP /

SET INDEX

SLOW /

F.ADV PAUSE /

SEL SLOW /

F.ADV

REW / PLAY FF /

- SPKR VOL +

INDEX

REC

CAMCORDER

CAMERA

DISPLAY

ON TV

COUNTER /

RESET

Optional

Frame by Frame Advance

Optional Remote Control Only

(See page 64)

Press PAUSE during playback.

Press SLOW/F.ADV to do a frame by

frame advance.

Press SLOW/F.ADV to do a frame by

frame reverse.

Press PLAY to release.

• If you hold down SLOW/F.ADV, you can

see a continuous series of still images at

a slower speed than normal slow mode.

• During frame by frame advance, a few

frames may move automatically, and the

picture may become bluish for an instant.

Note

SLOW/

F.ADV

Button

SLOW/

F.ADV

Button

Jog Frame by Frame Search

(Palmcorder only)

During Still mode, rotate JOG KEY to

advance or reverse the picture one frame

at a time.

Variable Speed Search

1Press PLAY to start playback.

2Press PLAY again.

3Rotate JOG KEY to adjust the playback

speed.

• Rotate JOG KEY downward for

forward playback.

• Rotate JOG KEY upward for reverse

playback.

To return to normal playback:

Press PLAY. Playback will continue at

normal speed.

• The Variable Speed Search function offers

a choice of six playback speeds (1/5X, 1X,

2X, 5X, 10X, 20X) both in forward and

reverse directions.

• The review playback at the 1X speed is

playback in reverse direction.

• During the Variable Speed Search (at a

speed other than 1X), mosaic-like patterns

will appear in the picture.

• During the Variable Speed Search, sound

is muted.

PLAY Button

3JOG KEY

Special Effect Features

During Playback (Continued)

Note

Playback Your Recordings

PAUSE Button

• Sound is muted during all special effects.

Note

201_401.28-31.p65 01/01/18, 17:0829

30 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Index Forward/Reverse Search

DATE /

TIME PHOTO

SHOT REC /

PAUSE

A.DUB

STOP /

SET INDEX

SLOW /

F.ADV PAUSE /

SEL SLOW /

F.ADV

REW / PLAY FF /

- SPKR VOL +

INDEX

REC

CAMCORDER

CAMERA

DISPLAY

ON TV

COUNTER /

RESET

BINDEX SEARCH

(rewind) Button

Top Scan

If you hold down INDEX SEARCH more

than 2 seconds, the Palmcorder will scan

for scenes (or PhotoShots) and playback

the first few seconds of each.

To cancel this function, press PLAY or

STOP.

Optional

BINDEX SEARCH

(fast forward) Button

APlace the Palmcorder in the VCR

STOP mode.

BPress INDEX SEARCH fast forward or

rewind the number of recordings

(indexes) forward or back you want to

view. The Palmcorder will advance or

rewind to the desired recording and

automatically start playback.

• The number of times you pressed the

button is displayed in the EVF and the

LCD monitor if you set INDEX on the VCR

menu to SCENE. (See page 17.)

(Ex., if you press the button three times,

“S3” will appear.)

• If the interval between scenes is less than

1 minute, index search may not operate

properly.

• Response time from pressing the button

and change in the scene number is quite

slow. Do not press INDEX SEARCH

rapidly and continuously.

• During Reverse Index Search mode,

playback will not begin when a tape

rewinds all the way to the beginning.

Optional Remote Control Only

(See page 64)

Search for a particular scene by using the

electronic index marks placed at the

beginning of each recording.

1Set the POWER to VCR.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

VCR position.

2Press MENU to display the VCR

mode menu screen.

3Rotate JOG KEY to select PLAY

MODE , then press JOG KEY to

display the VCR PLAY MODE menu

screen.

4Rotate JOG KEY to select INDEX ,

and then press JOG KEY to select

PHOTO or SCENE. (See page 17.)

3, 4JOG KEY

2MENU

Button

1POWER Switch

Playback Your Recordings

Special Effect Features

During Playback (Continued)

• Sound is muted during all special effects.

Note

• Search will not work if there is a

succession of PhotoShots.

Note

201_401.28-31.p65 01/01/18, 17:0830

Basic Operation

Playback Your Recordings

Back of TV

Audio In Video In

Back of TV

Audio In Video In

Playback Your Recordings

To S-Video In

To Audio In

S-VIDEO

OUT

AV Cable

(Supplied)

S-Video Cable

(Not supplied)

To Video

To Audio

A/V OUT

For best Chrominance and Luminance, use

the S-Video connection if available on your

TV.

A/V Cable

(Supplied)

[ TV with S-VIDEO IN Jacks ]

1Set POWER to CAMERA or VCR.

To view what the Palmcorder is

recording or to playback a tape on your

TV.

2Turn your TV ON and set it to LINE

INPUT or S-VIDEO.

Check your TV operating instructions

for further information.

3Start playback or begin a recording.

• Make sure the Palmcorder and TV are

turned off while connecting.

• Please connect the A/V Cable securely.

CATV System Installer

This reminder is provided to call the

CATV system installer’s attention to

Article 820-40 of the NEC in USA (and to

the Canadian Electrical code in Canada)

that provides guidelines for proper

grounding and, in particular, specifies

that the cable ground shall be connected

to the grounding system of the building,

as close to the point of cable entry as

practical.

DATE /

TIME PHOTO

SHOT REC /

PAUSE

A.DUB

STOP /

SET INDEX

SLOW /

F.A DV PAUSE /

SEL SLOW /

F.A DV

REW / PLAY FF /

- SPKR VOL +

INDEX

REC

CAMCORDER

CAMERA

DISPLAY

ON TV

COUNTER /

RESET

A/V OUT

DISPLAY

ON TV

Button

Optional

Optional Remote Control Only

(See page 64)

You can display the various EVF and LCD

indications on your TV by pressing

DISPLAY ON TV on remote control. Press

again to remove the indications.

Note

[ TV with AUDIO/VIDEO IN Jacks ]

View Recording/Playback on

your TV

201_401.28-31.p65 01/01/18, 17:0831

32 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Card Features

You can record still images to a Memory

Card.

1Slide the M-CARD Lock Switch to

unlock, then set POWER to M-CARD.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

M-CARD position.

• “PLAY: PUSH PLAY KEY” is

displayed for 10 seconds.

(See page 33.)

2Press MENU to display CARD

SETTING menu, then press JOG KEY

to select NORMAL or FINE .

• Press MENU to exit this menu.

3Press PHOTOSHOT to record an

image.

• The PhotoShot image is recorded to

the Memory Card.

• When SHUTTER is set to ON (see

page 15), still pictures are recorded

with a visual shutter effect and click

sound. If set to OFF, the still

image will be displayed only.

1POWER

Switch

2MENU

Button

2JOG KEY 3PHOTOSHOT

Button

Image Resolution and Capacity

(supplied 8 MB MultiMediaCard)

REC

Mode

FINE

NORMAL


Resolution

640 x 480

320 x 240

Capacity

Approx. 60 images

Approx. 240 images

• The number of images given for each mode

applies when all images are taken in same mode.

• You can change recording modes at any time

before capturing an image.

• The number of images that can be captured may

differ depending on the subject. After capturing an

image, the number may not decrease, or it may

decrease by two. This is normal.

• While “PROCESSING” is displayed, DO

NOT turn off the Palmcorder or unplug

the AC Adaptor (supplied) because this

will cause irreversible damage to the

memory.

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Set POWER to OFF before inserting a

Memory Card. (See page 10.)

M-CARD Lock

Switch

Cautions for the Memory Card

• While Memory Card data is being read, do not remove it, turn off the power, or subject

unit to vibrations and shocks.

• Do not leave the Memory Card in a place with high temperature, exposed to direct

sunlight, or where electromagnetic waves and static electricity can be generated.

• Electromagnetic waves, static electricity, malfunction of the Palmcorder or of the

Memory Card itself could erase the data recorded on it. To prevent the loss of picture

data, we recommend that you make a backup copy on the computer.

• Do not bend or drop the Memory Card as this could damage it or the captured

contents.

• Do not touch the connector on the rear edge of the Memory Card with your fingers and

take care that no dirt, dust or water enters it.

• Do not affix other labels to the Memory Card face or back as Card insertion/removal

may become impossible.

Card PhotoShot

Warning

• Memory Card will not work when DV

interface Cable (i.LINK) is connected.

Warning

201_401.32-35.p65 01/01/18, 17:0832

Special Features

Card Features

1Repeat steps 1 and 2 on page 32.

2Set POWER to VCR.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

VCR position.

3Press PLAY to start playback of the

cassette tape. And then, press PAUSE

to select an image.

4Press PHOTOSHOT to record the

desired image to the Memory Card.

• When PHOTOSHOT is pressed in

PLAY or SLOW mode, the screen

goes to STOP mode.

• To playback the images of the

Memory Card, see pages 33~34.

• When Variable Speed Search is

done (see page 29), this feature can

not be used.

5Repeat steps 3~4 to record another

image to the Memory Card.

Card Features

You can record still images from a

cassette tape to a Memory Card.

3PLAY Button

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Set POWER to OFF before inserting a

Memory Card. (See page 10.)

2POWER Switch

Button

JOG KEY 4PHOTOSHOT

Button

M-CARD Lock

Switch

Playback Still Images

1Slide the M-CARD Lock Switch to

unlock, then set POWER to M-CARD.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

M-CARD position.

• “PLAY: PUSH PLAY KEY” is

displayed for 10 seconds.

1POWER Switch

You can view the images on the Memory

Card.

M-CARD Lock Switch

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Set POWER to OFF before inserting a

recorded Memory Card.

(See pages 32, 33.)

(Continued on next page.)

Recording images From a

Tape

3PAUSE

Button

• Memory Card will not work when DV

interface Cable (i.LINK) is connected.

Warning

201_401.32-35.p65 01/01/18, 17:0833

34 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

2Press M-PLAY to display the Multi

playback screen.

• “PLEASE WAIT” appears on-screen.

• Rotate JOG KEY to scroll through

Multi image screen pages

(6 images per page) and select an

image.

• The selected image is underlined in

green.

• Press MENU to display CARD

SETTING menu screen.

• Press M-STOP to return to the Card

PhotoShot REC Mode.

(See page 32.)

3Press JOG KEY to display the

selected image as a full-size screen.

• “PLEASE WAIT” appears on-screen.

4Rotate JOG KEY to select BACK

(previous image), MULTI (Multi Image

screen), or NEXT (next image).

•Press M-STOP to return to the Multi

Playback screen.

DISPLAY : Select OFF to remove all

displays from the screen.

DCF (Design rule for Camera File

system)

:Select OFF to cancel DCF No.

on the screen.

Note

• If the file number is changed, the

Palmcorder cannot read the file data.

• This product is compliant with DCF

(Design rule for Camera File System).

Images saved on the Memory Card

using other Digital Still Cameras that are

compliant with DCF can be viewed on

this product.

Warning

• While “PLEASE WAIT” is displayed, DO

NOT turn off the Palmcorder or unplug

the AC Adaptor (supplied) because this

will cause irreversible damage to the

memory.

“PLEASE WAIT” is displayed.

3, 4JOG KEY

Button

2M-PLAY Button

M-STOP Button

Card Features

201_401.32-35.p65 01/01/18, 17:0834

Special Features

1POWER

Switch

4, 5JOG KEY

3M-DEL Button

M-STOP

Button

You can delete unwanted images and

increase the remaining image memory.

Warning:

Once deleted, images cannot be restored.

DELETE PAGE

Delete specific images from a page.

DELETE ALL

Delete all images. (See page 36.)

FORMAT

Delete all data. (See page 37.)

2M-PLAY

Button

• While deleting image, DO NOT turn off

the Palmcorder or unplug the AC

Adaptor (supplied) because this will

cause irreversible damage to the

memory, resulting in reduced image

storage capacity.

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Set POWER to OFF before inserting a

recorded Memory Card.

(See pages 32, 33.)

1Slide the M-CARD Lock Switch to

unlock, then set POWER to M-CARD.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

M-CARD position.

• “PLAY: PUSH PLAY KEY” is

displayed for 10 seconds.

2Press M-PLAY to display the Multi

playback screen.

• “PLEASE WAIT” appears on-screen.

3Press M-DEL to display the DELETE

menu, then rotate and press JOG

KEY to select PAGE .

• DELETE PAGE menu is displayed.

4Rotate and press JOG KEY to select

and set the image to be deleted.

• The selected image is underlined in

pink.

5Rotate JOG KEY to select YES , and

press JOG KEY to delete the selected

image.

• To cancel delete, press M-STOP or

rotate and press JOG KEY to select

NO.

• “PLEASE WAIT” appears on-screen.

• To delete other images, repeat

steps 4~5.

Delete Specific Images

M-CARD Lock

Switch

Card Features

Warning

201_401.32-35.p65 01/01/18, 17:0835

36 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

1Do steps 1 and 2 on page 35.

2Press M-DEL to display the DELETE

menu. Then, rotate and press JOG

KEY to select ALL .

• The screen below is displayed.

• To cancel delete, press M-STOP or

rotate and press JOG KEY to select

NO.

3Rotate and press JOG KEY to select

YES .

• “PLEASE WAIT” is displayed on the

screen, and then “NO PICTURE” is

displayed.

• Press M-STOP to return to the Card

PhotoShot REC Mode screen.

(See page 32.)

You can delete all images from the Memory

Card easily with this operation.

Warning:

Once deleted, images cannot be restored.

2M-DEL Button

M-STOP Button

• While deleting image, DO NOT turn off

the Palmcorder or unplug the AC

Adaptor (supplied) because this will

cause irreversible damage to the

memory, resulting in reduced image

storage capacity.

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Set POWER to OFF before inserting a

recorded Memory Card.

(See pages 32, 33.)

Delete All Image Pages

POWER

Switch

2, 3JOG KEY

Card Features

Warning

201_401.36-38.p65 01/01/18, 17:0836

Special Features

1Do steps 1 and 2 on page 35.

2Press M-DEL to display the DELETE

menu, then rotate and press JOG

KEY to select FORMAT .

• The screen below is displayed.

• To cancel format, press M-STOP or

rotate and press JOG KEY to select

NO.

3Rotate and press JOG KEY to select

YES .

• “PLEASE WAIT” is displayed on the

screen as all image data is deleted

from Memory Card. Deletion is

complete when “NO PICTURE” is

displayed.

• Press M-STOP to return to the Card

PhotoShot REC Mode screen.

(See page 32).

DELETE

FORMAT

ALL

PUSH STOP

PUSH

SET JOG

JOG KEY

KEY

SELECT

CANCEL

ROTATE

PAGE

You can easily format your Memory Card

using this operation.

Warning:

Formatting permanently removes all image

data.

123

FORMAT CARD

ARE YOU SURE ?

YES

PUSH STOP

EXIT

SET JOG

JOG KEY

KEY

SELECT ROTATE

• While deleting image, DO NOT turn off

the Palmcorder or unplug the AC

Adaptor (supplied) because this will

cause irreversible damage to the

memory, resulting in reduced image

storage capacity.

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Set POWER to OFF before inserting a

recorded Memory Card.

(See pages 32, 33.)

Format the Memory Card

POWER

Switch

2, 3JOG KEY

2M-DEL Button

M-STOP Button

Card Features

Warning

201_401.36-38.p65 01/01/18, 17:0837

38 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

1Set POWER to CAMERA.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2Press MENU to display the CAMERA

menu screen. Then rotate and press

JOG KEY to select PHOTO TITLE .

3Rotate and press JOG KEY to select

and set MODE and then TITLE .

1st : Select and set MODE (WIPE or

MIX).

2nd : Select and set TITLE to “SET”.

• “PLEASE WAIT” appears on-screen.

• The Multi image screen is displayed.

4Rotate and press JOG KEY to select

and set an image.

• “PLEASE WAIT” is displayed while

image is processed. Then, “PHOTO

TITLE SET” is displayed for approx.

3 seconds, and the screen goes back

to the Camera mode screen.

• After Photo Title is performed, Digital

Function turns off.

• There are 12 pre-installed files.

5Press REC/PAUSE to start recording

with Photo Title.

• WIPE or MIX screen is displayed at

beginning of the recording. Then the

Photo Title setting will be cleared

automatically.

You can record PhotoShot images from a

Memory Card to a cassette to be used as

a WIPE or MIX effect.

When Photo Title is set to ON, the

selected image and Title will appear

before each recording is made.

WIPE : The Photo title is replaced with the

current scene in a wiping motion.

MIX : The photo title is replaced with the

current scene in a gradual mixing

effect.

1POWER Switch

2, 3, 4JOG KEY

2MENU

Button

Note

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Set POWER to OFF before inserting a

recorded Memory Card.

(See pages 32, 33.)

Photo Title

5REC/PAUSE

Button

Card Features

201_401.36-38.p65 01/01/18, 17:0838

Special Features

EIS ON

NORMAL

1Set POWER to CAMERA.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2Press EIS to stabilize the picture.

• Picture flicker may be observed when

taping under fluorescent lighting

conditions.

• The EIS indicator flashes when the

light level is inadequate.

• Turn D.E.I.S. OFF during recording

when using a tripod.

3Press REC/PAUSE to start recording.

4Press EIS again to cancel.

• Be sure that D.E.I.S. is turned off

when not needed.

EIS

Dual Digital Electronic Image

Stabilization System (D.E.I.S.)

This feature helps compensate for any

unintentional hand or body movement. It

can be used in both the Recording and

Playback (VCR) modes.

CAMERA mode

VCR mode

• Other Digital Functions are turned off

automatically when the EIS and Digital

Zoom are selected.

ASet POWER to VCR.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

VCR position.

BPress PLAY to start playback.

CPress EIS to stabilize the picture.

DPress EIS again to cancel.

• Be sure that D.E.I.S. is turned off

when not needed.

Note

• When using D.E.I.S in VCR mode, the

image size is slightly larger.

Note

1, A

POWER

Switch

3REC/PAUSE Button

2, 4, C, D

EIS Button BPLAY Button

D.E.I.S. may not function when...

• Palmcorder movement is too

extreme.

• Recording a subject with distinct

horizontal or vertical stripes.

• Recording in low light situations.

• Recording a subject under a great

amount of fluorescent light.

• Recording a scene with very fast

motions.

Special Features

201_401.39-42.p65 01/01/18, 17:0839

40 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Special Features

CAMERA mode

Zoom Out (“W”)

Zoom In (“T”)

3POWER ZOOM

Switch

D.ZOOM

• The normal optical zoom functions from

1X to 20X.

• Because the image is enlarged digitally,

the picture may become distorted when

higher magnification levels are used.

• When the level falls below 20X, the

normal zooming function will resume.

• Focus distance becomes 4 feet (1.2 m) if

the lens is in full telephoto.

1Set POWER to CAMERA.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2Press D. ZOOM to select D.ZOOM1 or

D.ZOOM2.

once : D.ZOOM1 (from 20X to 40X)

twice : D.ZOOM2 (from 20X to 300X)

three times : Turn off D.ZOOM

3Press REC/PAUSE to start

recording and press POWER ZOOM to

zoom in or zoom out.

• The magnification level is always

displayed in the EVF or the LCD

monitor when DISPLAY is set to ON.

(See pages 16, 18.)

4Press D.ZOOM to turn off Digital

Zoom so that no indication appears.

VCR mode

• Other Digital Functions are turned off

automatically when the EIS and Digital

Zoom are selected.

ASet POWER to VCR.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

VCR position.

BPress PLAY to start playback.

CPress D.ZOOM.

• The center portion of the image

doubles in size.

DPress D.ZOOM again for normal

image size.

Note

2, 4, C, D

D. ZOOM Button BPLAY Button

1, A

POWER

Switch

Digital Zoom

3REC/PAUSE Button

201_401.39-42.p65 01/01/18, 17:0840

Special Features

DATE /

TIME PHOTO

SHOT REC /

PAUSE

A.DUB

STOP /

SET INDEX

SLOW /

F.ADV PAUSE /

SEL SLOW /

F.ADV

REW / PLAY FF /

- SPKR VOL +

INDEX

REC

CAMCORDER

CAMERA

DISPLAY

ON TV

COUNTER /

RESET

• The picture quality will deteriorate slightly.

• The tape remaining indicator will not

appear while the PHOTOSHOT feature is

used.

• In the Photo/Scene Index Search mode,

the shutter sound effect may not be able

to be heard even when SHUTTER is set

to ON.

• Photo Index Search may fail to detect a

recorded PhotoShot image if the image is

3 seconds or less.

EINDEX SEARCH

(fast forward Button)

2PHOTOSHOT

Button

C, DJOG KEY

ASet POWER to VCR.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

VCR position.

BPress MENU to display the VCR

mode menu screen.

CRotate JOG KEY to select PLAY

MODE , and press JOG KEY to

display the VCR PLAY MODE menu

screen.

DRotate JOG KEY to select INDEX ,

and press JOG KEY to select

PHOTO or SCENE.

• Press MENU twice to exit.

EPress INDEX SEARCH fast forward

or rewind on the remote control

(Optional, page 64) to advance or

rewind the tape to playback a

PhotoShot scene. To view the next

PhotoShot, INDEX SEARCH must be

pressed again.

Digital PhotoShot

Use this feature to record a seven second

(approx.) still image from the current camera

picture. Audio is also recorded for on-the-

spot narration. Or, you can add narration

later with the Audio Dubbing feature to make

an interesting slide show, etc.

(See page 49.)

1Set POWER to CAMERA.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2Press PHOTOSHOT in Record/Pause

mode. “PHOTO” will appear in the

EVF or the

LCD monitor.

• If SHUTTER on the menu screen is set to

ON, a sound effect similar to the shutter

of a film camera will be heard when

PHOTOSHOT is pressed.

• When PHOTOSHOT is pressed, the

playback image takes approx. 7 seconds

to process. After that, the Camera mode

screen will be displayed.


Optional Remote Control Only

(See page 64)

Optional

Index Search (Photo/Scene)

Note

1, A

POWER

Switch

EINDEX SEARCH

(rewind Button)

Special Features

BMENU

Button

201_401.39-42.p65 01/01/18, 17:0841

42 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

1Set POWER to CAMERA.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2Press MENU to display the menu

screen.

3Rotate JOG KEY to select ADJUST,

and then press JOG KEY to display

the CAMERA ADJUST menu screen.

4Rotate JOG KEY to select

W.BALANCE , and then press JOG

KEY repeatedly to select AUTO,

Indoor halogen lamp “ ”, or Outdoors

“”.

: When the source illumination is a

halogen lamp.

: When shooting outdoors on a

sunny day.

AUTO : Automatically maintains optimum

color balance in most lighting

conditions.

3, 4JOG KEY

2MENU

Button

White Balance

1, 2STILL Button

You can record still pictures of any desired

duration together with sound.

Recording Still Pictures

Auto White Balance automatically maintains

optimum color balance in most lighting

conditions. However, when using Digital

Functions, etc., you may get better results

using the manual adjustment.

1While in RECORD mode, press STILL

and hold for 2 seconds to capture a

still picture. The captured still picture

will be recorded together with sound.

2Press STILL once again to release

the still picture. The camera will

resume recording real-time pictures.

MAGICVU allows you to record subjects in

comparatively dark places.

MAGICVU/0LUX

(PV-DV401 only)

2MAGICVU/

0LUX Switch

1Set POWER to CAMERA.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2Slide MAGICVU/0LUX to ON.

• A black and white image appears.

• You can select the color of image:

B/W, green, or blue. (See page 16.)

• To cancel this feature, slide

MAGICVU/0LUX to OFF.

• The subject can be up to 3 m (9 feet)

away.

Note

1POWER Switch

Special Features

201_401.39-42.p65 01/01/18, 17:0842

Special Features

SPORTS mode

• The recorded images will not be so blurred

when they are viewed later using slow or

still picture playback.

• When playing back a sports mode

recording, the movement may appear

slightly jerky.

• Do not use this mode when recording

under fluorescent, mercury, or sodium

lighting. These types of lights will affect

the color and brightness of the images.

• A vertical band of light might appear when

recording objects that are brightly

illuminated or which are highly reflective.

• If the amount of light is insufficient, the

SPORTS “ ” indicator will flash in the

EVF or the LCD monitor.

• The image may flicker if this mode is

used indoors.

PORTRAIT mode

• The image may flicker if this mode is

used indoors.

LOW-LIGHT mode

• Scenes recorded in extremely low light

levels may not come out properly.

SPOT-LIGHT mode

• If the recorded subject is extremely bright,

the picture may appear whitish.

SURF&SNOW mode

• If the recorded subject is extremely bright,

the picture may appear whitish.

• It is not possible to select the SPORTS

mode or PORTRAIT mode together with

the GAIN UP in the Digital function

camera menu.

(No display)

SPORTS

PORTRAIT

LOW-LIGHT

SPOT-LIGHT

SURF&SNOW

Program AE

3, 4JOG KEY

2MENU

Button

The Auto Exposure feature can be used to

make quality recordings in a variety of

scene situations.

Note

1Set POWER to CAMERA.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2Press MENU to display the menu

screen.

3Rotate JOG KEY to select ADJUST,

and then press JOG KEY to display

the CAMERA ADJUST menu screen.

4Rotate JOG KEY to select

PROG.AE , then press JOG KEY

repeatedly to select one of the five

modes shown below.

5Repeat steps 2~4 to select OFF to

cancel this feature.

1POWER Switch

For recording fast action scenes.

For recording only subjects in the

foreground, while ignoring

subjects in the background.

For recording in extreme low light

conditions.

Recording in situations where

subjects are under a spotlight(s).

For recording in locations with a

high degree of “Dazzle,” such as

snow slopes and the seashore.

Mode Indication

Special Features

• When MAGICVU is ON, Program AE

and H.S.S. cannot be set in the menu.

Note

201_401.43-45.p65 01/01/18, 17:0843

44 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Special Features

Special Features 1Set POWER to CAMERA or VCR.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

CAMERA or VCR position.

2Press MENU to display the menu

screen.

3Rotate JOG KEY to select

D.FUNCTION in the CAMERA mode

menu screen or PLAY FUNCTION in

the VCR mode menu screen, then

press JOG KEY to display the

CAMERA FUNCTION or VCR PLAY

FUNCTION menu screen.

4Rotate JOG KEY to select

D.FUNCTION , and then press JOG

KEY repeatedly to select one of the

Digital Functions listed on the left.

5To cancel the Digital Function, press

JOG KEY repeatedly to select OFF.

• The EIS and Digital Zoom features are

turned off automatically when one of the

Digital Functions listed at left is

selected.

Other Digital Functions

Use the following features to add interest

and professionalism to your recordings or

playback. Select from eleven special

effects.

Note

Types of Digital Functions

MIRROR

Symmetrical image from the current

camera picture.

STROBE

The recording appears as a sequence of

still frames.

MOSAIC

The picture appears in a mosaic pattern.

SLIM

The picture is expanded vertically.

TRAIL

The subject being recorded creates a trail

when in motion.

STRETCH

The picture is expanded horizontally.

GAIN UP (Not available during playback)

Picture sensitivity is increased.

• Only Manual Focus is available.

WIPE

Successive scenes are separated in a way

which simulates the drawing of a curtain.

MIX

The current scene is mixed in with the

following scene during scene changes.

PinP

PinP (Still image) is displayed on the

Main Picture.

SEPIA (Only available during playback)

The picture is played back in sepia, a

brownish color, giving it an antique look.

MONO (Monotone) (Only available during

playback)

The picture is played back in black-and-

white.

To use the WIPE function

a.In Camera mode, set the “D.FUNCTION”

item in the main menu screen to “WIPE”.

(See page 15.)

b.Press REC/PAUSE to start recording.

c.Press REC/PAUSE to pause the

recording. The last scene will be

memorized.

d.Press RECORD/PAUSE to start

recording again. The new scene will take

the place of the memorized scene.

To use the MIX function

a.In Camera mode, set the “D.FUNCTION”

item in the main menu screen to “MIX”

(see page 15). Then, perform steps b-d

above.

The memorized scene and the new

scene will appear mixed as the scene

changes from one to the other.

• When Photo Title is set, WIPE/MIX mode

becomes Photo Title. When Photo Title

is finished, Digital Function turns OFF.

Note

3, 4, 5JOG KEY

2MENU

Button

1POWER Switch

201_401.43-45.p65 01/01/18, 17:0844

Special Features

3, 4JOG KEY

2MENU

Button

1POWER Switch

Picture in Picture (PinP)

You can display a PinP (still image) screen

on the Main Picture.

• PinP position is fixed at the bottom right

of the screen.

Note

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

1Set POWER to CAMERA.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2Press MENU to display the menu

screen.

3Rotate JOG KEY repeatedly to select

D.FUNCTION , then press JOG KEY

to display the CAMERA FUNCTION

menu screen.

4Press JOG KEY to select PinP .

•Press MENU twice to exit this menu.

5Aim at the scene you wish to place as

PinP, then press CAMERA STILL to

freeze the image.

6Press CAMERA STILL again to place

the frozen image as PinP.

7Press REC/PAUSE to record a scene

with PinP image.

•Press PHOTOSHOT to record a

scene with PinP image in PhotoShot

mode.

•Press CAMERA STILL again to

remove PinP image.

Main Picture

Picture in Picture

(PinP still image)

5, 6, 7

CAMERA STILL Button

PHOTOSHOT

Button

Special Features

201_401.43-45.p65 01/01/18, 17:0845

46 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Special Features

Strobe Multi Mode Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

1Set POWER to VCR.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

VCR position.

2Press MENU to display the menu

screen.

3Rotate and press JOG KEY to select

and set MULTI SETTING .

4Press JOG KEY to select SPEED ,

then press repeatedly to set desired

speed.

•Press MENU twice to exit.

5Press PLAY to start playback. Press

MULTI at the point you want to start

capturing.

• A succession of 9 screens will be

captured, and playback will stop.

•Press MULTI to return to the normal

STILL screen.

Press PLAY to start playback.

Press STOP to stop playback.

Strobe Speeds

FAST

NORM

SLOW

9 screen capture time

Every 0.3 seconds

Every 0.6 seconds

Every 1.0 seconds

• A Multi Image Playback screen cannot be

output from the DV terminal or Digital Still

Image terminal.

• A Multi screen will have slightly lower

image quality.

Note

In Strobe Multi Mode, you can select the

rate at which a succession of still screens

are captured from the playback picture.

3, 4JOG KEY

2MENU

Button

1POWER Switch

5PLAY Button 5MULTI Button

201_401.46-48.p65 01/01/18, 17:0846

Special Features

EVF or LCD monitor indication.

Press BACK LIGHT in Record mode to

activate the Backlight feature.

The Indicator “ ” will appear in the EVF or

LCD monitor.

Press BACK LIGHT again to cancel

the Backlight feature.

Backlight

BACK LIGHT Button

• The Indicator “ ” will not appear in the

EVF or LCD monitor when OFF is

selected in the DISPLAY menu.

Note

Use Manual Focus (MF) when recording ...

• a subject through glass.

• a scene where the subject is far from the

Palmcorder and there are objects in the foreground.

• a subject with distinct horizontal stripes.

• a subject not centered in the Viewfinder.

• subjects with shiny surfaces.

• an obliquely angled subject.

• a bright, flat subject such as a white wall.

• in low light situations.

• a scene with fast motions, like a golf swing.

Re-focusing may be required

• when your Palmcorder is aimed at a new scene.

1Set POWER to CAMERA.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

CAMERA position.

2Press M.FOCUS DIAL so that “MF”

(Manual Focus) appears in the EVF

or the LCD monitor.

3Press and hold POWER ZOOM “T”

side (Telephoto) until the lens is at

maximum zoom in.

4Turn M.FOCUS DIAL until the picture

is in focus.

• It may be necessary to back away

from the subject to focus the image

properly.

5Press POWER ZOOM to “W” or “T”

as desired.

•The subject will remain in focus over

the entire zooming range.

•It may be necessary to back away

from the subject to focus the image

properly.

Macro Focus (for close-ups)

Auto Focus

The Palmcorder automatically adjusts the focus over the entire zoom range.

Manual Focus

2, 4M.FOCUS

DIAL 3, 5POWER

ZOOM Switch

Press the “W” side of POWER ZOOM to the maximum wide angle position.

Auto Focus will function with the subject as close as 1 inch (25 mm) in front of the lens.

Use when recording a subject that is darker than the surrounding scene, in a shadowed

area, or when the light source is in back of your subject.

Special Features

1POWER Switch • DISPLAY must be set to on for MF, AE,

W.BALANCE, or BACK LIGHT to be displayed

on the LCD or EVF.

Note

201_401.46-48.p65 01/01/18, 17:0847

48 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Fade Out

Fade In

1, AFADE Button

Audio/Video Fade In/Out

2, B

REC/PAUSE

Button

Fade In

High Speed Shutter

Auto Shutter

Manual Selection

2, 3, 4JOG KEY

To record high speed motion (e.g. tennis

stroke) for improved STILL or SLOW

MOTION playback when watching the tape

on this Palmcorder.

In the AUTO mode (no indication in the EVF and LCD monitor), the Palmcorder will

automatically adjust the shutter speed (up to 1/350).

• AUTO mode is automatically selected whenever the POWER Switch is set to CAMERA.

1Press MENU to display the Camera

mode menu in the EVF or the LCD

monitor.

2Rotate and press JOG KEY to select

ADJUST , then rotate and press

JOG KEY to select H.S.S. .

3Press JOG KEY to select SET .

• SHUTTER SPEED menu is displayed.

4Rotate JOG KEY to choose one of the

following

shutter speeds.

• Press MENU three times to exit.

Before you begin

• Connect the Palmcorder to a power

source. (See pages 11, 12.)

• Set POWER Switch to CAMERA.

• Insert a cassette with record tab.

(See page 6.)

Starting the first scene with “fade in” is very

effective.

1In REC/PAUSE mode, hold down

FADE until the picture fades out.

2Press REC/PAUSE to start

recording.

3Release FADE and the picture will

gradually fade in.

Fade Out

Use to create a soft ending or (together

with fade in) for a soft transition from one

scene to the next.

ADuring recording, hold down FADE

until the picture fades out.

BPress REC/PAUSE to pause the

recording.

SPEED

SHUTTER

PUSH

:EXIT JOG KEY

KEY

SELECT ROTATE

1/4000

1MENU

Button

• For proper color reproduction, it is recommended

that you use this feature outdoors. For indoor

High Speed Shutter recording, additional

halogen or tungsten light should be provided.

Fluorescent light will degrade the picture quality.

• This feature requires ample light. More light is

required for the fastest shutter speeds.

• The Auto Focus system may not operate

properly in insufficient light when using the High

Speed Shutter.

• When PROG.AE is ON, you cannot manually

select the shutter speed.

• When MAGICVU is ON, Program AE and

H.S.S. cannot be set in the menu.

Note

1/60 AUTO

1/100

1/250 1/500

1/4000

1/2000

1/1000

1/8000

You can make smoother scene transitions

for a more professional look.

Special Features

201_401.46-48.p65 01/01/18, 17:0848

Special Features

A.DUB

DATE /

TIME PHOTO

SHOT REC /

PAUSE

A.DUB

STOP /

SET INDEX

SLOW /

F.A DV PAUSE /

SEL SLOW /

F.A DV

REW / PLAY FF /

- SPKR VOL +

INDEX

REC

CAMCORDER

CAMERA

DISPLAY

ON TV

COUNTER /

RESET

External Microphone

with M3 connector (not

supplied)

External

Microphone Jack

(PV-DV401 only)

The original sound can be replaced with

new sound using the built-in Palmcorder

microphone or an external microphone

(PV-DV401 only).

Audio Dubbing using the

External or Built-in Microphone

1Set POWER to VCR.

• The POWER lamp lights red.

• Be sure POWER is fully turned to

VCR position.

• If you have the Optional Remote

Control, you can set the Palmcorder

to stop automatically at a specified

point on the tape. See “Memory-Stop

Editing” on page 50.

2Press PLAY.

Then press PAUSE where you want

dubbing to begin.

3Press A.DUB on this unit (for 3

seconds) or on the remote control

(optional, page 64) to put the

Palmcorder in the Audio Dub mode.

• “A.DUB” flashes in the EVF or the

LCD monitor.

2PLAY Button

2PAUSE

Button

3A.DUB Button

3A.DUB

Button

Optional

Before you begin

• Connect the external Microphone

(if used) (PV-DV401 only).

• Turn on the Palmcorder.

• Insert a pre-recorded tape to be

dubbed.

Built-in

Microphone

The AUDIO-REC setting in CAMERA

MENU mode should be as follows:

• Select 12 bit if you do not want the

original sound to be completely replaced

during an audio dub.

• If you dub over a tape which has both

12 bit and 16 bit audio recordings on it,

keep in mind that the original 16 bit audio

portion will be completely replaced.

12 bit

16 bit

The original sound is recorded

on ST (Stereo) 1, and the new

sound will be recorded on ST

(Stereo) 2.

The original sound is replaced

with the new sound.

1POWER Switch

Special Features

201_401.49-52.p65 01/01/18, 17:0849

50 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Special Features

DATE /

TIME PHOTO

SHOT REC /

PAUSE

A.DUB

STOP /

SET INDEX

SLOW /

F.A DV PAUSE /

SEL SLOW /

F.A DV

REW / PLAY FF /

- SPKR VOL +

INDEX

REC

CAMCORDER

CAMERA

DISPLAY

ON TV

COUNTER /

RESET

4Press PAUSE to start Audio Dubbing.

• Connect the Palmcorder to the TV in

order to monitor the sound.

(See page 31.)

Only NTSC (National Television Standards

Committee) recorded tapes can be audio

dubbed. The following screen appears if

the tape was not recorded in NTSC format.

5Press PAUSE to stop Audio Dubbing.

To listen to the desired audio sound, set

the AUDIO setting of the VCR mode MENU

(see page 17) as follows:

• If the microphone used for dubbing gets

too near the speaker of your TV,

a howling noise (feedback) may occur.

• If the tape position is in or was started in

in a blank section, you cannot use the

A.DUB feature.

Memory-Stop Editing (Optional

Remote Control Only, page 64)

Optional

• 16 bit dubbed sound completely erases

the original 16 bit recorded sound.

• If you dubbed using 12 bit AUDIO

recording and then selected AUDIO-MIX

in the menu for playback, the sound will

be stereo regardless of the AUDIO-OUT

setting.

• If you recorded in LP mode, you cannot

use the A.DUB feature.

Note

You can set an automatic Dubbing stop

point.

DRESET

Button

AMENU

Button

APress MENU to display the VCR

menu screen.

BRotate JOG KEY to select DISPLAY

SETTING , and then press JOG KEY

to display the DISPLAY SETTING

menu.

CRotate JOG KEY to select DISPLAY ,

and then press JOG KEY to set to

MEMORY.

DPress MENU two times to exit MENU

mode. Then, press RESET on the

remote control to reset the Counter

Memory to M 0:00:00.

Now, rewind to the editing start point,

and continue with steps 2-5. The tape will

now stop automatically at “M 0:00:00”.

ST 1

ST 2

MIX

Set this position to listen to the

original sound.

Set this position to listen to the

audio dubbed sound.

Set this position to listen to both

the original sound and the audio

dubbed sound.

AUDIO:The following selections are

available for 12 bit AUDIO dubbed

recordings only (sound recorded in SP

mode only).

4, 5PAUSE

Button

201_401.49-52.p65 01/01/18, 17:0850

Special Features

Video In

S-Video In

VHF Connecting

Cable (not

supplied)

(To View)

A/V Cable

(Supplied)

To Audio In

To Video In

Recording:

VCR (Rear)

To S-Video In

(If there is S-Video In)

• For technical reasons, dubbing a tape

may reduce its quality.

• Press DISPLAY on the Palmcorder

remote control (optional, page 64) to

eliminate EVF/LCD Monitor indications.

• If the Time Code is displayed in the EVF

or LCD monitor, it cannot be reset.

• Only the DATE/TIME, when displayed,

will be recorded on the tape.

CAUTION:

Unauthorized exchanging and/or copying of

copyrighted recordings may be copyright

infringement.

A/V OUT

S-VIDEO OUT

Source (Playing)

Palmcorder

Copying your Tapes to

S-VHS or VHS Cassette

Monitor with your TV

1Insert a pre-recorded tape

into the source (playing) Palmcorder

and a blank tape, with record tab in

place, into the target VCR (Recorder).

2Press PLAY on the Palmcorder. When

the tape reaches the point you want to

start dubbing, press PAUSE.

3Place the VCR into REC/PAUSE

mode. (See VCR manual.)

4Simultaneously, press PAUSE on

both units to begin copying.

5Press STOP on both units when

copying is completed.

S-Video

Cable (not

supplied)

Audio In

Note

• Turn the TV ON and select its VCR

channel (either CH3 or CH4).

• Set the VCR/TV Selector on the

recording VCR to VCR.

Before you begin

• Connect both Palmcorder and VCR to

their power sources.

• Connect the Palmcorder to a VCR as

illustrated left.

• Turn ON both units.

• Set the recording VCR’s Input Signal

Selector to LINE.

• Set the Palmcorder POWER Switch to

VCR.

Special Features

201_401.49-52.p65 01/01/18, 17:0851

52 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Special Features

DATE /

TIME PHOTO

SHOT REC /

PAUSE

A.DUB

STOP /

SET INDEX

SLOW /

F.A DV PAUSE /

SEL SLOW /

F.A DV

REW / PLAY FF /

- SPKR VOL +

INDEX

REC

CAMCORDER

CAMERA

DISPLAY

ON TV

COUNTER /

RESET

3, 4

PLAY

Button

3, 4, 5

PAUSE Button

3, 4

PLAY Button

6STOP

Button

4REC

Button

High quality digital-to-digital copying can

be accomplished if both Palmcorders

incorporate the DV Input/Output (i.LINK)

Connector (DV interface cable (i.LINK) is

not supplied). 1Insert a pre-recorded tape into the

source (playing) Palmcorder, and set

POWER to VCR.

2Insert a blank tape with the record

tab closed into the target (recording)

Palmcorder and set POWER to VCR.

3Press PLAY on the source

Palmcorder. When the tape reaches

the point you want to start dubbing,

press PAUSE.

4Hold down REC and press PLAY on

the target (recording) Palmcorder or on

the remote control (optional, page 64).

Press PAUSE to pause the tape at the

starting point of the dub.

5Simultaneously, press PAUSE on

both units to begin dubbing.

6Press STOP on the recording

unit, and then press STOP on the

playing unit to end dubbing.

• When two Palmcorders are used for

dubbing, it is recommended that the

remote control VCR1 or VCR2 setting be

used to avoid improper-operation.

• When two Palmcorders are connected

using the DV interface cable (i.LINK) (not

supplied), a Video Editing Controller

cannot be used.

• Do not connect both an S-Video Cable or

A/V Cable and a DV Interface Cable

(i.LINK).

CAUTION:

Unauthorized exchanging and/or copying of

copyrighted recordings may be copyright

infringement.

Source (Playing)

Palmcorder

Recording

Palmcorder

DV Interface Cable (i.LINK)

(optional)

DV Input/Output

Connector

Copying from Digital

Equipment (dubbing)

Optional

Note

4REC

Button

3, 4, 5

PAUSE

Button

Before you begin

• Connect both Palmcorders to their

power sources.

• Connect the two Palmcorders using the

DV interface cable (i.LINK)

(4-pin to 4-pin).

• Turn both Palmcorders ON.

201_401.49-52.p65 01/01/18, 17:0852

Special Features

Transferring Your Images

System Requirements:

• IBM PC/AT or compatible

• Intel Pentium ll Processor: 266 MHz or more

• Windows 98/Me preinstalled PC with USB port

• RAM: 64 MB or more

• High color (16 bit) or more

• Resolution 800 x 600 (SVGA) or more

• 220 MB minimum available hard disk space (for

ArcSoft Software)

• 15 MB minimum available hard disk space (for

CARDLINK (for USB) or PHOTOVU LINK/Movie

Messenger)

• 120 MB minimum available hard disk space (for

USB Motion image capture)

• CD-ROM drive (for installation)

• Mouse or other pointing device

Palmcorder USB Device Driver : Software to connect your Palmcorder and your PC

using USB Cable.

PHOTOVU LINK/Movie Messenger : Software to transfer images from your Palmcorder

to your PC.

CARD LINK (for USB) : This software to transfer images between the

Memory Card and your PC.

ArcSoft Software* : Following software is included: PhotoPrinter 2000

Pro, PhotoImpression 2000, Panorama Maker 2000.

Caution

• The Windows 2000 driver is currently not available, but will be available in the future on

our website at www.panasonic.com/video.

Software Installation (Windows 98/Me)

1Turn on the PC (Personal Computer) and start up Windows 98/Me.

2Insert the supplied Software CD-ROM into the CD-ROM drive.

3 Select and click the icon you want to install.

4Follow the instructions as they appear on your PC screen.

Palmcorder USB Device Driver : Click

PHOTOVU LINK/Movie Messenger : Click

CARD LINK (for USB) : Click

ArcSoft Software : Click

You can transfer images from your Palmcorder tape to your PC (Personal Computer).

Note

• Please install Palmcorder USB Device Driver first before connecting the Palmcorder and

your PC using USB Cable. Once Palmcorder USB Device Driver is installed, you must

restart your computer for installation to take effect.

Note

• If a window does not appear automatically, click the “Start” button on your desktop and then click

“Run”. When the Run box is open, type in “D:\InstMenu.exe” where “D:” is the drive letter of your CD;

then click “OK”.

• If you attempt to install the next Software before the previous Software installation is completed, “Error”

may appear. In this case, click [OK] and install the next Software from the menu.

* For information on ArcSoft Software:

TEL : 1-510-440-9901

FAX : 1-510-440-1270

Web Site : www.arcsoft.com

E-mail : support@arcsoft.com

201_401.53-57.p65 01/01/18, 17:0853

54 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Transferring Your Images

USB Terminal

1Turn on your PC.

2Set the Palmcorder POWER to VCR.

3Connect the Palmcorder to your PC (Windows) using the USB Cable (supplied).

• For extended use, it is recommended to use the AC Adaptor as a power source.

USB Cable

(supplied)

Connection

Uninstalling Application Software

1Click “Start,” “Settings,” and “Control Panel.”

2Double-click on “Add/Remove Programs” in the “Control Panel.”

3Select the application software you want to remove, and then click [Add/Remove].

Note

• Before uninstalling CARD LINK (for USB), right-click on the

CARD LINK (for USB) Monitor, then left-click on “Exit” to

close CARD LINK (for USB) Monitor.

• If the “Locked File Detected” dialog box appears while

unistalling the CARD LINK (for USB), close CARD LINK (for

USB) Monitor as described above, then click on [Retry].

Note

Notes on PHOTOVU LINK/Movie Messenger and CARD LINK operation

• For PHOTOVU LINK/Movie Messenger, do not connect the i.LINK and USB terminals to

the Palmcorder at the same time.

• Make sure Palmcorder power is not shut off during use, your PC system may become

unstable, therefore it is recommended that the AC Adaptor be used as the power

source. (Be especially careful when recording in M-CARD or CAMERA mode as the

power eventually shuts off automatically if a tape is inserted.)

• For PHOTOVU LINK/Movie Messenger, if the play, stop, fast forward, and rewind

functions are operated using the Palmcorder buttons, the image may not be captured

properly. Use Palmcorder Operation Buttons displayed on the PC screen.

201_401.53-57.p65 01/01/18, 17:0854

Special Features

Transferring Your Images

Before you begin

• Set POWER to OFF before inserting a

recorded Memory Card.

(See pages 32, 33.)

• Turn your PC on.

Running the CARD LINK

(for USB)

You can transfer images between the

Memory Card and your PC. 1Repeat steps 1 and 2 above.

2Click on Start, “Programs,”

“Panasonic,” “Palmcorder,” then

“CARD LINK (for USB).”

3“CARD LINK (for USB)” is opened.

Refer to Help for information about

application operations and Error

messages.

Note

One Touch Transfer

Note 1Set Palmcorder POWER to CAMERA

or slide M-CARD Lock Switch to

unlock and set to M-CARD.

(See pages 9, 10.)

2Connect the Palmcorder to your PC

(Windows) using the USB Cable

(supplied). (See page 54.)

• “CONNECT WITH PC” is displayed

on the LCD monitor.

3Press TRANSFER.

• CARD LINK (for USB) application is

run automatically and images stored

on the memory card are transferred to

your PC and saved. (If an image to

be transferred already exists, that

image will be skipped over and not

transferred.)

• Before using this feature, make sure the

CARD LINK (for USB) monitor icon is

displayed.

• Double clicking the CARD LINK Monitor

icon displays a dialog box in which the

save location for the collective transfer

can be changed.

The images stored on the Memory Card

can easily be transferred to the PC by

pressing the TRANSFER Button.

3TRANSFER Button

• JPEG image format (only image data that

can be played back on Palmcorder) can

be transferred from the PC to the

Palmcorder.

Note

While CARD LINK is running, do not perform the following operations...

The PC system may become unstable.

• Change the screen area or color pallet in the Display Properties window.

• Turn the Palmcorder power switch ON or OFF while connecting the Palmcorder to your

PC using the USB Cable.

• Connect/disconnect the USB Cable.

• Insert/remove a Memory Card.

201_401.53-57.p65 01/01/18, 17:0855

56 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Using Memory Card Image

Data (CARD LINK (for USB))

Pictures captured with Palmcorder can

be transferred to your PC.

1Select the image data you want to

transfer to your PC.

• The selected image will be underlined

in green.

2Click on:

Transfer

• The picture image is transferred to

your PC and displayed. Transfer Dialog

will appear on the PC. The image is

captured when the full screen image

appears on the PC.

Delete

• Confirmation Dialog will appear on the

PC. Click “OK”. The selected images of

the Memory Card are deleted.

Save

• The picture image is transferred to your

PC and displayed. [Save as] dialog box

will appear.

(for USB)

Note

• If, while transferring the image to your PC,

the displayed picture appears abnormal,

restart the PC application and turn

Palmcorder POWER off, and then back

on.

Using PC Image Data

(CARD LINK (for USB))

You can use JPEG or Bitmap files from

your computer for Photo Title (see page

38) by transferring them to the

Palmcorder via PC connection.

1Click on “File,” then Click on

“Open.”

• At your PC, please select andopen

the data (. jpg or .bmp) you want to

transfer to the Palmcorder.

2Click on “File,” select “Data out

to camera,” then select Fine or

Normal mode.

• Your computer image data is

transferred to the Palmcorder.

(for USB)

Before you begin

• Set POWER to OFF before inserting a

recorded Memory Card.

(See pages 32, 33.)

• Make Palmcorder-PC connections.

(See page 54.)

• Turn your PC on. (See page 54.)

• Set Palmcorder POWER to M-CARD.

(See page 10.)

• Repeat steps 1 and 2 to run the CARD

LINK (for USB). (See “Running the

CARD LINK (for USB)” on page 55.)

Transferring Your Images

201_401.53-57.p65 01/01/18, 17:0856

Special Features

Running the PHOTOVU

LINK/Movie Messenger Before you begin

• Insert a recorded tape. (See page 9.)

You can transfer Motion images and Still

images from your Palmcorder tape to a PC.

1Set Palmcorder POWER to VCR.

2Connect the Palmcorder to your PC

using the USB Cable (supplied) or

DV interface Cable (i.LINK).

(See pages 54, 62.)

3Click on “Start,” “Programs,”

“Panasonic,” “Palmcorder,” then

“Movie Messenger.”

4“PHOTOVU LINK/Movie Messenger”

is opened.

Refer to Help for information about

application operations and Error

messages.

Note

Transferring Your Images

ASet Palmcorder POWER to VCR.

BConnect the Palmcorder to your PC

using the USB Cable (supplied) or

DV interface Cable (i.LINK).

CStart up the PHOTOVU LINK/Movie

Messenger.

While PHOTOVU LINK/Movie Messenger is running,

do not perform the following operations...

The PC system may become unstable.

• Change the screen area or color pallet in the Display Properties window.

• Turn the Palmcorder power switch ON or OFF while connecting the Palmcorder to your

PC using the USB Cable or DV Interface Cable (i.LINK).

• Change the Palmcorder mode (VCR/CAMERA).

*Close the application before changing the Palmcorder power switch.

• Connect/disconnect the DV Interface Cable (i.LINK).

• Connect/disconnect the USB Cable.

How to insert the USB Cable or

DV Interface Cable (i.LINK) AClose the PHOTOVU LINK/Movie

Messenger.

BRemove the USB Cable or DV

Interface Cable (i.LINK) from the

Palmcorder.

CSet Palmcorder POWER to OFF.

How to remove the USB Cable

or DV Interface Cable (i.LINK)

201_401.53-57.p65 01/01/18, 17:0857

58 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Transferring Your Images

Using Tape Image Data

(PHOTOVU LINK/Movie

Messenger) (USB)

Before you begin

• Insert a recorded tape. (See page 9.)

• Make Palmcorder-PC connections.

(See page 54.)

• Turn your PC on. (See page 54.)

• Set Palmcorder POWER to VCR.

1Repeat steps 1~4 on page 57 to

run the PHOTOVU LINK/Movie

Messenger.

• When the USB Cable is connected,

the input display will automatically

become USB. If it is not USB, please

confirm the connection. Then, close

and restart the software.

2Click (PLAY) on PC screen to

playback the DV tape.

• The playback screen cannot be

viewed on the PC. Please use the

LCD monitor on the Palmcorder for

confirmation.

Note

To capture Still images

3Click on [STILL CAPTURE] at the point

you wish to capture an image.

• Repeat step 3 to continue capturing

images.

• Captured Still images are saved to the

PC, and you can playback the saved

images on the Image Browser. (See

page 59.)

By connecting the Palmcorder and PC with

the USB Cable, you can transfer Motion

images and Still images saved on the DV

Tape directly to your PC.

To capture Motion images

3Click on [MOVIE CAPTURE] at the start

point you wish to capture a Motion

image.

4Click [MOVIE CAPTURE] or [STOP] to

end capture.

• “Now Searching” is displayed.

• The DV Tape is rewound to the point

at which the capture was started. The

Motion image is then transferred to the

PC.

• “Data transfer is now in progress” is

displayed on the PC screen.

• The maximum capture time is approx.

30 seconds. Capture stops

automatically at the end of 30 seconds.

• Motion images cannot be captured if data

contains the following...

• A change between 12 bit and 16 bit.

• A change between SP and LP mode.

• During transfer to the PC, the Motion

images will not be displayed on the PC

screen.

• Transfer takes from about 30 to 50

seconds for every 1 second of the Motion

image.

5To capture other Motion images, repeat

steps 3~4.

2PLAY Button

3STILL

CAPTURE

3MOVIE

CAPTURE

Note

201_401.58-61.p65 01/01/18, 17:0858

Special Features

Playing back the saved Motion and Still

images (PHOTOVU LINK/Movie Messenger)

You can playback the saved Motion

images and Still images (see page 58) for

confirmation. 1Repeat steps 1~4 on page 57 to

run the PHOTOVU LINK/Movie

Messenger.

2Click [IMAGE BROWSER] to display

the Image Browser screen.

To view Still images

3Click on [Pictures] to display the Still

image list.

4Double Click on the desired image to

open it.

• If the image cannot be opened, please

refer to the software Help menu.

3Pictures

3Movies

To view Motion images

3Click on [Movies].

• The first part of each Motion image will

be displayed as a list.

4Double click on the desired Motion

image to display the playback screen.

• Click to start Motion image

playback.

2IMAGE BROWSER

Transferring Your Images

Note

201_401.58-61.p65 01/01/18, 17:0859

60 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Transferring Your Images

To select the e-mail Software

(PHOTOVU LINK/Movie Messenger

The e-mail Software must support MAPI

(Messaging Application Programming

Interface).

Below are some e-mail Software which

support MAPI:

Microsoft Outlook, Microsoft Outlook

Express, Netscape Messenger:

• Outlook(R) Express 5x, Outlook97,

Outlook98

• Outlook Express 4x

• Othere MAPI applications [Netscape(R)

Messenger 4.5x and so on]

1Repeat steps 1~4 on page 57 to

run the PHOTOVU LINK/Movie

Messenger. (See Note below.)

2Click [IMAGE BROWSER] to display

the Image Browser screen.

3Select “E-mail Settings” from

“Settings”.

4Select the e-mail software you are

using, then click [OK].

• If the e-mail software does not support

MAPI, clicking on [E-mail] of Movie

Messenger will not automatically run

the e-mail software. Please run the

e-mail software before doing step 1

above.

Before you begin

• Insert a recorded tape. (See page 9.)

• Make Palmcorder-PC connections.

(See page 54.)

• Turn your PC on. (See page 54.)

• Set Palmcorder POWER to VCR.

Note

2IMAGE BROWSER

Note

You can transfer and compress your

Motion images and Still images as

attachments to your e-mail easily.

201_401.58-61.p65 01/01/18, 17:0860

Special Features

Before you begin

• Insert a recorded tape. (See page 9.)

• Make Palmcorder-PC connections.

(See page 54.)

• Turn your PC on. (See page 54.)

• Set Palmcorder POWER to VCR.

1Repeat steps 1~4 on page 57 to

run the PHOTOVU LINK/Movie

Messenger.

2Click [IMAGE BROWSER] to display

the Image Browser screen.

Attaching captured Motion

and Still images to your e-mail

4Compress

Attaching Still images to e-mail

3Click on [Pictures] to display the Still

image list.

4Select the image to be attached, then

click on [E-mail].

• The e-mail software will be run

automatically and the selected image

will be attached to the e-mail. (See

Note right.)

4E-mail

Attaching Motion images to e-mail

3Click on [Movies] to display a Motion

image list.

4Select the Motion image to be

attached, then click on [Compress].

• Follow the menu to perform the

compression settings.

5Clicking on [Compress] will compress

the selected image.

• “Successfully Done” is displayed on

the PC screen.

• Click [Play] to open the Movie

Messenger Player screen. You can

confirm the compressed Motion image

by clicking on [Play].

6Clicking on [E-Mail] will automatically

attach the compressed Motion image to

your e-mail. (See Note below.)

• When the recipient opens the file you

sent, this Movie Messenger Player

screen appears. By clicking [Play],

they can view the Motion Image.

• Movie Messenger Player works with

Windows 95, 98, or Me only.

• If your e-mail software is not

supported by MAPI, pressing the

[E-Mail] button will automatically open

the folder containing the compressed

file. To attach, drag and drop the file

into your e-mail.

5Compress 5Play 6E-Mail

Note

Transferring Your Images

2IMAGE BROWSER

Movie Messenger

Player screen

201_401.58-61.p65 01/01/18, 17:0861

62 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Transferring Your Images (i.LINK)

DV Interface Cable (i.LINK)

(6-to-4 pin) (not supplied)

PC Connector

DV Input/Output

(i.LINK “ ”)

Connector

Transferring Your Images (i.LINK)

Note

• PC must be equipped with an i.LINK terminal.

• During Palmcorder playback, do not disconnect the DV Interface Cable (i.LINK) or turn

the Palmcorder off as this may cause PC hang-up error to occur.

• For PHOTOVU LINK/Movie Messenger, do not use 2 i.LINK terminals on your PC at the

same time.

• PHOTOVU LINK/Movie Messenger i.LINK (DV) operates normally with Windows 98SE

or later operating system.

• PHOTOVU LINK/Movie Messenger i.LINK connection may not work with some DV

Interface boards. In this case, use the software included with the board.

• 1394 (i.LINK) interface must conform to OHCI (Open Host Controller Interface

Specification).

PC Connection with DV Interface Cable (i.LINK)

For more detailed information regarding editing software products

from these companies, please visit their websites at:

www.digitalorigin.com

www.justedit.com

www.pinnaclesys.com

A live image can be transferred directly to your PC (Personal Computer) via a DV

Interface Cable (i.LINK) (not supplied) using products and software from a number of

editing software companies including Digital Origin, Canopus, and Pinnacle.

Using Products from these companies allows you to capture and edit live images onto

your PC using the DV interface (i.LINK).

201_401.62-63.p65 01/01/18, 17:0962

Special Features

Transferring Your Images (i.LINK)

Using Tape Image Data

(PHOTOVU LINK/Movie

Messenger)

Before you begin

• Insert a recorded Tape. (See page 9.)

• Make Palmcorder-PC connections.

(See page 62.)

• Turn your PC on.

• Set Palmcorder POWER to VCR.

•Run the Software after the DV

Interface Cable (i.LINK) has been

connected to the Palmcorder.

1Repeat steps 1~4 on page 57 to

run the PHOTOVU LINK/Movie

Messenger.

• When the DV Interface Cable (i.LINK)

is connected, the input display will

automatically become DV. If it is not

DV, please confirm the connection.

Then, close and restart the software.

2Click PLAY button on PC screen to

playback the DV tape.

• Please use the LCD monitor on the

Palmcorder or PC screen for

confirmation.

Note

To capture Still images

3Click on [STILL CAPTURE] at the point

you wish to capture an image.

• Repeat step 3 to continue capturing

images.

• Captured Still images are saved to the

PC, and you can playback the saved

images on the Image Browser.

By connecting the Palmcorder and PC with

the DV Interface Cable (i.LINK), you can

transfer Motion images and still images

saved on the DV Tape directly to your PC.

To capture Motion images

3Click on [MOVIE CAPTURE] at the

point you wish to capture a Motion

image. Click on [STOP] to end capture.

• The image is recorded to the PC in

real time.

• The maximum capture time is approx.

3 minutes.

• When capturing data containing

changes between 12 bit and 16 bit

and/or between SP and LP mode, a

separate file will be made for each

mode.

• Please refer to pages 59~61 for other

functions.

2PLAY Button

3STILL

CAPTURE

3MOVIE

CAPTURE

Note

• If PHOTOVU LINK/Movie Messenger

does not work, please refer to page 62.

201_401.62-63.p65 01/01/18, 17:0963

64 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Palmcorder Accessory System

Accessory #

PV-DAC11

CGR-D08A/1B

(Replaces CGR-

D120A/1B)

CGR-D16A

(Replaces CGR-

D220A/1B)

CGP-D28A1B

CGR-D53A/1K

(Replaces CGR-

D815A/1B)

PV-DDC9

PV-DLT9

PV-DRC9

PV-H150

PR-SD064

PR-SD032

PR-SD016

BN-SDCAPU/1B

BN-SDABPU/1B

Description

AC Adaptor with AC Cable and

DC Cable

800mAH / 1 h 30 min, Battery

Pack

1600mAH / 3 h, Battery Pack

2800mAH/ 5 h, Battery Pack

5300mAH / 9 h, Battery Pack

DV Interface Cable (i.LINK)

(4-pin to 4-pin)

Color Enhancement Light

IR Remote Control

Carrying Case

64 MB SD Memory Card

32 MB SD Memory Card

16 MB SD Memory Card

SD USB Reader/Writer

(compatible with

MultiMediaCard)

SD PCMCIA Adaptor

(compatible with

MultiMediaCard)

Price

$120.00

$69.95

$99.95

$129.95

$229.95

$55.00

$39.95

$29.95

$49.95

$179.95

$119.95

$79.95

Figure

201_401.64-67.p65 01/01/18, 17:0964

For Your Information

Palmcorder Accessory System

Concerning the MultiMediaCard and SD Memory Card

MultiMediaCard

The MultiMediaCard is a compact,

lightweight and removable external

memory card. A great many fun-filed titles

(preset titles) have been recorded on the

supplied MultiMediaCard.

These preset titles will also be erased

when the Card is formatted.

SD Memory Card

The SD Memory Card (optional), which is

the same size as the MultiMediaCard, is an

external memory card with an even bigger

memory capacity. It has a write protect

switch to prevent the data writing and card

formatting, and it comes with a copyright

protection function that complies with the

SDMI (Secure Digital Music Initiative)

standard. Music play is possible only with

an SD Memory Card.

• SD Logo is a trademark.

• Portions of this product are protected

under copyright law and are provided

under license by ARIS/SOLANA/4C.

201_401.64-67.p65 01/01/18, 17:0965

66 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Palmcorder Accessory Order Form

TO OBTAIN ANY OF OUR PALMCORDER ACCESSORIES YOU CAN DO ANY OF

THE FOLLOWING:

VISIT YOUR LOCAL PANASONIC DEALER

CALL PANASONIC’S ACCESSORY ORDER LINE AT 1-800-332-5368

[6 AM-5 PM M-F, 6 AM-10:30 AM SAT, PACIFIC TIME]

MAIL THIS ORDER TO: PANASONIC SERVICES COMPANY ACCESSORY ORDER OFFICE

20421 84th Avenue South Kent, WA. 98032

Ship To:

Mr.

Mrs.

Ms. First Last

Street Address

City State Zip

Phone #:

Day ( )

Night ( )

4. Shipping information (UPS delivery requires complete street address)

Please photocopy this form when placing an order.

3. Method of payment (check one)

Check of Money Order enclosed (NO C.O.D.SHIPMENTS)

VISA Credit Card #

MasterCard Expiration Date

Discover Customer Signature

Make Check or Money Order to: PANASONIC ACCESSORIES

(Please do not send cash)

2. Items Ordered

QuantityAccessory # Price EachDescription Total Price

6.95

Subtotal

Your State & Local Sales Tax

Shipping & Handling

Total Enclosed

1. Palmcorder Model #

201_401.64-67.p65 01/01/18, 17:0966

For Your Information

Notes On Operations

Cleaning EVF (Electronic Viewfinder)

1Slide the Viewfinder backward to its fully

expanded position and then tilt it upward.

2Remove the 2 screws from the EVF Eyepiece

with a screwdriver (+).

3Turn the Eyepiece counterclockwise 1/8 of a

turn.

4Pull the Eyepiece free. Remove any lint or dust

particles with a soft clean cloth being careful not

to scratch the glass surfaces.

5To re-install the Eyepiece

Line up the marks on the Eyepiece with the

grooves inside the EVF shaft and attach. Turn it

clockwise 1/8 of a turn to lock in place.

6Replace the EVF Eyepiece screws and tighten

with a screwdriver.

• If you lose an EVF Eyepiece screw, order Part

No.XQN2+BJ5FXK.

Notes On Operations

COLOR TINT

MIXTURE

PALMCORDER

SETTINGS

Bluish

Whitish

Yellowish

Reddish

ARTIFICIAL LIGHT SOURCENATURAL LIGHT

CONDITIONS

“OUTDOOR”

- - - - - - - - - - - - -

- - -

• Color television

• Fluorescent lamp (Daylight)

• Camera flash bulb

• Blue lamp for photography

• Fluorescent lamp (White)

• Normal flash bulb

• Fluorescent lamp (Off-white)

• Tungsten lamp for

photography

• Halogen lamp

• Iodine lamp

• Tungsten lamp

• Acetylene lamp

• Kerosene lamp

• Candlelight

KELVIN COLOR

TEMPERATURE

• Fair weather, blue sky

• Slightly cloudy sky

• Cloudy or rainy sky

• Sunlight in clear weather at

midday

• Average sunlight in clear weather

• Sunlight 2 hours after sunrise

and before sunset

• Sunlight 40 min. after sunrise

and before sunset

• Sunlight 30 min. after sunrise

and before sunset

• Sunlight 20 min. after sunrise

and before sunset

(Amber Filter

Range) — 10,000

— 8,000

— 7,000

— 6,500

— 6,000

— 5,500

— 5,000

— 4,500

— 4,000

— 3,500

— 3,200

— 2,800

— 2,000

“AUTO”

Approximate Brightness Values

Your Palmcorder has been designed for normal scene illumination of 150 footcandles

(1500 lx). However, the Palmcorder may be used at F1:1.6, if illumination is more than

0.5 footcandles (5 lx).

The table below shows the color temperature for reference.

1Turn the Eyepiece

counterclockwise 1/8 of a turn.

2Pull the Eyepiece free.

Remove any lint or dust

particles with a soft, clean

cloth being careful not to

scratch the glass surfaces.

3To re-install the Eyepiece

Line up the marks on the

Eyepiece with the grooves

inside the EVF shaft and

attach. Turn it clockwise 1/8 of

a turn to lock in place.

[ PV-DV401 ][ PV-DV201 ]

201_401.64-67.p65 01/01/18, 17:0967

68 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Specifications

Power Source: Palmcorder: 7.2 V DC (Battery)

7.8 V DC (AC Adaptor)

AC Adaptor: 110/120/220/240 V AC, 50/60 Hz

Battery: Lithium-Ion Type DC 7.2 V

Power Consumption: Palmcorder: 7.2 V DC 6.5 W (Max. 9.5 W)

AC Adaptor: 18 W

1 W (when not in use.)

Digital Interface USB/i.Link (IEEE1394)

Video Signal: EIA Standard (525 lines, 60 fields) NTSC color signal

Video Recording System: 2 rotary heads. helical scanning system

Audio: 12 bit (32 kHz) 4 tracks

16 bit (48 kHz) 2 tracks

Pick-Up System and Device: One integral color filter Charge Coupled Device (CCD)

Lens: 20:1 zoom lens, F1:1.6 with auto iris control

Focal length: 3.6 mm - 72 mm

Power zoom function

Lens filter diameter: 43 mm

Viewfinder: 0.4 inch (10.2 mm) Electronic Viewfinder (PV-DV201)

0.44 inch (12.7 mm) Liquid Crystal Electronic

Viewfinder (PV-DV401)

LCD Monitor: 2.5 inch (63.5 mm) Liquid Crystal Display (PV-DV201)

3.0 inch (76.2mm) Liquid Crystal Display (PV-DV401)

Minimum Illumination Required: 5 lx (F1:1.6) 0.5 footcandles

0 lx (MAGICVU/0LUX ON) (PV-DV401 only)

Image Storage (supplied 320 x 240 pixels (NORMAL mode)

8 MB MultiMediaCard) 640 x 480 pixels (FINE mode)

Approx. 240 images (NORMAL mode)

Approx. 60 images (FINE mode)

Image Format JPEG (Design Rule for Camera File System)

Operating Temperature: 32 °F~104 °F (0 °C~40 °C)

Operating Humidity: 10 %~75 %

Weight: Palmcorder:

(PV-DV201) 1.50 Ibs.

0.68 kg

(PV-DV401) 1.45 Ibs.

0.66 kg

AC Adaptor: 0.35 Ibs.

0.16 kg

Dimensions: Palmcorder:

(PV-DV201) 3-3/8 (W) x 4-1/4 (H) x 7-1/2 (D) inch

85 (W) x 107.5 (H) x 191 (D) mm

(PV-DV401) 3-3/8 (W) x 4-1/4 (H) x 6-1/2 (D) inch

85 (W) x 107.5 (H) x 166 (D) mm

AC Adaptor:2-3/4 (W) x 1-3/4 (H) x 4-1/2 (D) inch

70 (W) x 45 (H) x 115 (D) mm

Weight and dimensions shown are approximate.

Designs and specifications are subject to change without notice.

201_401.68-71.p65 01/01/18, 17:0968

For Your Information

Before Requesting Service

(a) Video Head Cleaning: Normally, your Palmcorder will not

require head cleaning. However, it is possible that the heads

may become clogged due to dust in the air, playing damaged

tapes, long term use, etc. If “NEED HEAD CLEANING”

appears for 5 seconds in the EVF or LCD monitor, the heads

may require cleaning.

(b) Cleaning the Heads: It is recommended that head cleaning

be performed by a qualified service technician. Please contact

your nearest Panasonic Servicenter. An alternate solution is to

obtain a head cleaning cassette. Please use Panasonic

cleaning cassette (AY-DVMCL). Be sure to follow the cleaning

instructions carefully. Excessive use of the head cleaning

cassette could shorten video head life.

Use this cassette only when a head clogging symptoms occur.

Refer servicing to qualified service personnel.

Before Requesting Service

Clogged Video Head

• When you go from function to function (PLAY, FF, REW etc.), please note that the unit

will not accept a new function operation until the previous operation is complete.

• The POWER Button and all function buttons, (PLAY, FF, REW, etc.) are only operational

after the tape has been completely loaded.

When the following accessories are attached and the zoom is set to maximum wide

angle, the four corners of the sceen may appear darker:

• Wide or Telephoto conversion lens (optional).

• A filter (optional), etc. and then the lens hood.

• Two filters (optional).

If any of the following numbers appear on-screen, the Palmcorder may need service. Do

not remove the battery (if attached) and write down the displayed number on page 71.

Then, take the Palmcorder to a servicenter for repair.

Self Diagnostic System

Lens Hood Area Operation Caution

Tape Operations Caution

Cleaning Care for Video Heads

Error No.

U11

U12

U13

U14

U15

U16

U17

U30

Description

Card Error

Card/Palmcorder Dialogue Error

No Card Memory

Captured image limit exceeded

Error other than above

201_401.68-71.p65 01/01/18, 17:0969

70 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Before Requesting Service

If you have a problem with your Palmcorder, it may be something you can correct

yourself.

Check the list below for symptoms and corrections.

No picture in the EVF or LCD Monitor...

Video cassette cannot be inserted...

Video cassette cannot be removed...

No operation starts when operation

buttons are pressed...

Recording cannot be done...

Auto Focus does not operate...

Sound from microphone cannot be

monitored...

Sound cannot be heard...

Symptom

• Make sure the Power Source is connected.

(pp. 11, 12)

• Make sure the POWER switch is set to VCR

or CAMERA. (pp. 22, 27)

• Check the Dew Indicator. (p. 21)

• Make sure the Battery is fully charged.

(p. 11)

• Make sure all necessary cables are

connected correctly and firmly. (p. 12)

• Make sure the Lens Cap is removed. (p. 22)

• Make sure the Power Source is connected.

(pp. 11, 12)

• Insert the cassette record tab up, window

side facing out. (p. 9)

• Make sure the Power source is connected.

(pp. 11, 12)

• Check the Dew Indicator. (p. 21)

• Make sure the record tab is closed. (p. 6)

• Check the Battery Indication. (p. 19)

• Make sure FOCUS is set to AUTO.

(p. 47)

• Make sure the unit is ON and set to

CAMERA mode. (p. 22)

• Make sure the unit is set to REC or REC/

PAUSE mode.

• Make sure the Audio on the VCR MENU is

set to ST1. (pp. 17, 50)

Correction

201_401.68-71.p65 01/01/18, 17:0970

For Your Information

Request for Service Notice

Mail this completed form and your Proof of Purchase along with your unit to:

Panasonic Services Company

1705 N. Randall Road

Elgin, IL. 60123-7847

Attn: Camcorder Repair

Request for Service Notice:

Please photocopy this form when making a request for service notice.

In the unlikely event this product needs

service.

• Please include your proof of purchase.

(Failure to due so will delay your repair.)

• To further speed your repair, please provide

an explanation of what is wrong with the unit

and any symptom it is exhibiting.

Please write the displayed Self Diagnostic number

here. (See page 69.)

201_401.68-71.p65 01/01/18, 17:0971

72 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Index of Controls

Remote Sensor

See page 25.

Built-in Twin

Capsule 2-Way

Microphone

System

BACK LIGHT

Button

See page 47.

MULTI Button

See page 46.

FADE Button

See page 48.

A.DUB Button

See page 49.

Lens

External

Microphone Jack

(PV-DV401 only)

See page 49.

Built-in Light Mount

See page 7.

Hand Strap

See page 8.

Cassette

Compartment

Cover

See page 7.

Front View

Side View

D.ZOOM Button

See page 40.

EIS Button

See page 39.

TRANSFER Button

See page 55.

PHONE Jack

See page 27.

DV Input/Output

(i.LINK “ ”)

Connector

See pages 52, 62.

A/V Output

Connector

See pages 31, 51.

S-VIDEO Output

Connector

See pages 31, 51.

TAPE EJECT

Switch

See pages 7, 9.

Lens Cap

See page 8.

MAGICVU/0LUX

Switch

(PV-DV401 only)

See page 42.

PHOTOSHOT

Button

See pages 32, 33, 41.

201_401.72-75.p65 01/01/18, 17:0972

For Your Information

POWER ZOOM

Button

See pages 22, 40.

JOG KEY

See pages 13, 14.

VOLUME KEY

See page 27.

M.FOCUS DIAL

See page 47.

Menu Button

See pages 13, 14.

Electronic

Viewfinder (EVF)

See page 9.

Vision Adjustment

Control

See pages 9, 22.

Shoulder Strap

Attachment Ring

See page 8.

POWER Switch

(CAMERA•VCR•

OFF•M-CARD)

See pages 9, 10.

Rear View

REC/PAUSE

Button

See pages 9, 22.

Battery Release

Button

See pages 11, 12.

POWER Lamp

See page 22.

LCD (Liquid Crystal

Display) Monitor

See pages 9, 10, 23,

27.

LCD-OPEN Button

See pages 9, 10, 23, 27.

Built-in Speaker

See page 27.

Rear View

USB Terminal

See page 54.

M-CARD Door

See page 10.

CARD EJECT Switch

See page 10.

DC IN Terminal

See page 12.

Shoulder Strap

Attachment Ring

See page 8.

M-CARD Lock

Switch

See page 10.

Index of Controls

201_401.72-75.p65 01/01/18, 17:0973

74 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Index of Controls

Tripod

Receptacle

Underside View

Side View

REW Button

See pages 10, 27.

EDIT SEARCH

Button

See pages 24.

STOP Button

See pages 10, 27.

M-STOP Button

See pages 34, 35, 36,

37.

PLAY Button

See pages 10, 27.

M-PLAY Button

See pages 34, 35.

FF Button

See page 28.

EDIT

SEARCH Button

See page 24.

PAUSE Button

See pages 28, 29,

49, 50, 51, 52.

CAMERA STILL

Button

See pages 45.

REC Button

See page 52.

M-DEL Button

See pages 35,

36, 37.

CAUTION:

VCR DC Output

Connector

See page 12.

CHARGE Lamp

See page 11.

POWER Lamp

See pages 11, 12. AC Power Cord

See pages 11, 12.

AC Adaptor

This unit will operate on 110/

120/220/240 V AC. An AC plug

adaptor may be required for

voltages other than 120V AC.

Please contact either a local or

foreign electrical parts distributor

for assistance in selecting an

alternate AC plug.

We recommend using the

accessory power plug adaptor

(VJSS0070) in an area which

has special AC outlets.

201_401.72-75.p65 01/01/18, 17:0974

For Your Information

Color Enhancement Light (Optional)

LIGHT RELEASE

Button

See page 7.

LIGHT Button

See page 7.

DATE /

TIME PHOTO

SHOT REC /

PAUSE

A.DUB

STOP /

SET INDEX

SLOW /

F.ADV PAUSE /

SEL SLOW /

F.ADV

REW / PLAY FF /

- SPKR VOL +

INDEX

REC

CAMCORDER

CAMERA

DISPLAY

ON TV

COUNTER /

RESET

A.DUB Button

See pages 25, 49.

COUNTER/TC Button

See pages 19, 25.

RESET Button

See pages 25, 50.

REWIND/SEARCH

Button

See pages 25, 28.

MENU Button

See pages 13, 14, 50.

VIDEO REC Button

See pages 25, 52.

POWER ZOOM Switch

See pages 22, 25.

SPKR VOL +/–

See pages 25, 27.

REC/PAUSE Button

See pages 22, 25.

PHOTOSHOT Button

See pages 25, 41.

DATE/TIME Button

See pages 20, 25.

DISPLAY ON TV Button

See pages 25, 31.

FAST FORWARD/

SEARCH Button

See pages 25, 28.

REVERSE INDEX

SEARCH Button

See pages 25, 30, 41.

REVERSE SLOW/

F. ADV Button

See pages 25, 28, 29.

STOP Button

See pages 25, 27.

SET Button

See pages 13, 14, 25.

PAUSE Button

See pages 25, 28, 52.

SEL Button

See pages 13, 14, 25.

FORWARD SLOW/

F. ADV Button

See pages 25, 28, 29.

FORWARD INDEX

SEARCH Button

See pages 25, 30, 41.

PLAY Button

See pages 25, 27, 52.

Remote Control (Optional)

Index of Controls

201_401.72-75.p65 01/01/18, 17:0975

76 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Limited Warranty

Panasonic Consumer Electronics Company,

Division of Matsushita Electric Corporation

of America, One Panasonic Way

Secaucus, New Jersey 07094

Panasonic Sales Company,

Division of Matsushita Electric of Puerto Rico, Inc.

AVE. 65 de Infantería, Km. 9.5 San Gabriel

Industrial Park Carolina, Puerto Rico 00985

PANASONIC Video Products

Limited Warranty

Panasonic Consumer Electronics Company or Panasonic Sales Company (collectively referred to as “the

Warrantor”) will repair this product with new or refurbished parts, free of charge, in the USA or Puerto Rico, in

the event of a defect in materials or workmanship as follows (all time periods commence from the date of the

original purchase):

Batteries (if included) - New rechargeable batteries in exchange for defective rechargeable batteries for ten

(10) days. Non-rechargeable batteries are not warranted.

Tape (if included) - New video cassette tape in exchange for a defective video cassette tape for five (5) days.

In-home, carry-in or mail-in service, as applicable, in the USA can be obtained during the warranty period by

contacting a Panasonic Services Company (PASC) Factory Servicenter listed in the Service Directory. Or

call toll free contact number listed above, to locate an authorized PASC Servicenter. Carry-in or mail-in

service in Puerto Rico can be obtained during the warranty period by calling the Panasonic Sales Company

telephone number listed in the Servicenter Directory.

This warranty is extended only to the original purchaser. A purchase receipt or other proof of the date of the

original purchase is requires before warranty service is rendered.

This warranty only covers failures due to defects in materials and workmanship which occur during normal

use and does not cover normal maintenance, including, but not limited to, video and audio head cleaning.

The warranty does not cover damage which occurs in shipment, or failures which are caused by products

not supplied by the warrantor, or failures which result from accident, misuse, abuse, neglect, mishandling,

misapplication, alteration, modification, faulty installation, set-up adjustments, improper antenna, inadequate

signal pickup, maladjustment of consumer controls, improper operation, power line surge, improper voltage

supply, lightning damage, commercial use such as hotel, office, restaurant, or other business or rental use

of the product, or service by anyone other than a PASC Factory Servicenter or a PASC authorized

Servicenter, or damage that is attributable to acts of God.

LIMITS AND EXCLUSIONS

There are no express warranties except as listed above.

THE WARRANTOR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES

(INCLUDING, WITHOUT LIMITATION, DAMAGE TO RECORDING MEDIA) RESULTING FROM THE

USE OF THIS PRODUCTS, OR ARISING OUT OF ANY BREACH OF THE WARRANTY. ALL EXPRESS

AND IMPLIED

WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR

PARTICULAR PURPOSE, ARE LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH

ABOVE. Some states do not allow the exclusion or limitation of incidental or

consequential damages, or limitations on how long an implied warranty lasts, so the above exclusions or

limitations may not apply to you.

This warranty gives you specific legal rights and you may also have other rights which vary from state to

state.

If a problem with this product develops during or after the warranty period, you may contact your dealer or

Servicenter. If the problem is not handled to your satisfaction, then write to the Consumer Affairs

Department at the Panasonic Consumer Electronics Company address above.

SERVICE CALLS WHICH DO NOT INVOLVE DEFECTIVE MATERIALS OR WORKMANSHIP AS

DETERMINED BY THE WARRANTOR, IN ITS SOLE DISCRETION, ARE NOT COVERED. COSTS OF

SUCH SERVICE CALLS ARE THE RESPONSIBILITY OF THE PURCHASER.

warvid 8/8/2000

PRODUCT

CAMCORDER

VCR

A/V MIXER

MONITOR-

VCR

Combination

LABOR

NINETY (90) DAYS

CRT - NINETY (90) DAYS

PARTS

ONE (1) YEAR, EXCEPT

CCD IMAGE SENSOR

SIX (6) MONTHS

ONE (1) YEAR

ONE (1) YEAR, EXCEPT CRT

CRT

TWO (2) YEARS

CONTACT NUMBER

1-800-211-PANA(7262)

SERVICE

Carry-In or Mail In

Carry-In: 21” CRT

and Smaller

In-home or carry-in:

22” CRT and Larger

201_401.76-80.p65 01/01/18, 17:0976

For Your Information

Servicenter List

As of January 2001

For Product Information, Operating Assistance, Literature Request, Dealer Locations,

and all Customer Service inquires please contact:

1-800-211-PANA(7262), Monday-Friday 9am-9pm Saturday-Sunday 9am-7am, EST.

or send e-mail : consumerproducts@panasonic.com

Service in Puerto Rico

Matsushita Electric of Puerto Rico, Inc. Panasonic Sales Company/ Factory Servicenter:

Ave. 65 de Infanteria. Km. 9.5 San Gabriel Industrial Park Carolina, Puerto Rico 00985

Phone (787) 750-4300 Fax (787) 768-2910

GEORGIA

8655 Roswell Road

Suite 100

Atlanta, GA 30350

ILLINOIS

9060 Golf Road

Niles, IL 60714

1703 North Randall Road

Elgin, IL 60123

(Pick-up / Drop-off only)

MARYLAND

62 Mountain Road

Glen Burnie MD 21061

MASSACHUSETTS

60 Glacier Drive,

Suite G

Westwood, MA 02090

CALIFORNIA

6550 Katella Avenue

Cypress, CA 90630

800 Dubuque Avenue

S. San Francisco,

CA 94080

3878 Ruffin Road

Suite A

San Diego, CA 92123

COLORADO

1640 South Abilene

Street Suite D

Aurora, CO 80012

FLORIDA

3700 North 29th Avenue

Suite 102

Hollywood, FL 33020

MINNESOTA

7850-12th Avenue South

Airport Business Center

Bloomington, MN 55425

OHIO

2236 Waycross Road

Civic Center Plaza

Forest Park, OH 45240

PENNSYLVANIA

2221 Cabot Blvd. West

Suite B

Langhorne, PA 19047

TEXAS

13615 Welch Road

Suite 101

Farmers Branch,

TX 75244

WASHINGTON

20425-84th Avenue

South

Kent, WA 98032

HAWAII

99-859 Iwaiwa Street

Aiea, Hawaii 96701

Phone (808) 488-1996

Fax (808) 486-4369

Centralized Factory Servicenter

Panasonic Services Company

1705 N. Randall Road,

Elgin, IL 60123-7847

Attention: Digital Camera Repair

Please carefully pack and ship, prepaid and insured, to the Elgin centralized repair Factory

Servicenter. While there will be added handling delays, you may bring your unit to one of the

following locations who will then forward the unit to Elgin for repair.

Customer’s in Puerto Rico, please ship or carry in to location below (“Service in Puerto Rico”).

Product Repairs

MAIL TO :

Web Site: http://www.panasonic.com

You can purchase parts, accessories or locate your

nearest servicenter by visiting our Web Site.

Factory Service Center Locations

Accessory Purchases:

1-800-332-5368 (Customer Orders Only)

Panasonic Services Company 20421 84th Avenue South, Kent, WA 98032

(6 am to 5 pm Monday - Friday; 6 am to 10:30 am Saturday; PST)

(Visa, Master Card, Discover Card, American Express, Check)

201_401.76-80.p65 01/01/18, 17:0977

78 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Spanish Quick Use Guide/Guía Para Uso Rápido

Inserte de la batería

Inserte el Cassette

1Deslice el visor hacia atrás, haste la

posición de totalmente extendido, y

luego inclínelo hacia arriba.

(PV-DV201: Incline el visor hacia

arriba.)

2Coloque la batería y deslicela hacia abajo

hasata que quede bloqueada con un clic.

1Ajuste el interruptor de

alimentación (POWER) a la

posición VCR o CAMERA.

4Presione la marca PUSH TO

CLOSE (EMPUJAR PARA

CERRAR) para cerrar la tapa

del compartimiento del

cassette.

2Deslice el interruptor de expulsión

de cinta (TAPE EJECT) para abrir la

tapa del compartimento del cassette.

3Introduzca un cassette con la parte

de la ventana hacia arriba.

• Asegúrese de que la

lengüeta de grabación esté cerrada.

(Página 6.)

Film de protección

Nota

•Retire la película protectora antes de

utilizarlo.

Antes de comenzar

• Cargue la battería. (Página 11.)

VCR

OFF

CAMERA

M-CARD

Grabación con la cámara

Cuando el monitor LCD se enchuentra

totalmente abjerto, el visor se DESACTIVA

automàticamente.

180°

90°

VCR

OFF

CAMERA

M-CARD

1Ajuste el interruptor de

alimentación (POWER)

a la posición CAMERA.

Monitor LCD

2Ajuste el control lde ajuste de

visión según lo desee.

[PV-DV401] [PV-DV201]

3Presione el botón de apertura del LCD

(LCD-OPEN) para des bloquear el

monitor LCD. Balancée abriéndolo

completamente y ajuste el àngulo.

4Presione el botón de grabación/

pausa (REC/PAUSE) para iniciar la

grabación.

Vuelva a pulsar el botón de

grabación/pausa (REC/PAUSE) para

hacer una pausa en la grabación.

Visor

201_401.76-80.p65 01/01/18, 17:0978

For Your Information

Introducir la Tarjeta de memoria*

2Presione el botón de

apertura del LCD (LCD-

OPEN) para desbloquear

el monitor LCD. Balancée

abriéndolo

completamente y ajuste

el àngulo.

4Introducir la Tarjeta de memoria.

Monitor LCD

3Deslice el CARD EJECT Switch

(interruptor de EJECUCIÓN DE TARJETA)

para abrir la puerta de M-CARD.

Puerta de M-CARD

5Cierre la puerta de M-CARD.

180°

90°

1Ajuste el interruptor

de alimentación

(POWER) a la

posición OFF.

VCR

OFF

CAMERA

M-CARD

180°

90°

VCR

OFF

CAMERA

M-CARD

1Ajuste el

interruptor de

alimentación

(POWER) a la

posición VCR.

2Presione el botón de apertura del

LCD (LCD-OPEN) para des bloquear el

monitor LCD. Balancée abriéndolo

completamente y ajuste el ángulo. 3Presione el botón de

rebobinado (REW) para

rebobinar la cinta.

4Presione el botón de

reproducción (PLAY)

para reproducir la cinta.

5Presione el botón

de parada (STOP)

para detener la

reproducción.

Botón para interrumpir

el cambio al M-CARD

Para ver la reproducción en el LCD (pantalla

de visualización de cristal líquido)

Cuando el monitor LCD se enchuentra

totalmente abierto, el visor se DESACTIVA

automáticamente.

Antes de comenzar

• Cargue la battería. (Pàgina 11.)

*Tarjeta de Memoria: Tarjeta MultiMedia o Tarjeta de Memoria SD (Pàgina 64.)

•Asegúrese de introducir la Tarjeta de memoria antes de utilizar la tarjeta PhotoShot.

(Página 32.)

Antes de comenzar

• Cargue la battería. (Pàgina 11.)

A continuación se indican una lista de Tarjetas de Memoria soportadas por esta unidad.

Tarjeta de memoria

Tarjeta MultiMedia (LSFT0198A) (suministrado)

Tarjeta MultiMedia (Marca de fábrica SanDisk)

Tarjeta de Memoria SD (opcional) (Página 64.)

Capacidad

8 MB

8 MB, 16 MB

16 MB, 32 MB, 64 MB

Spanish Quick Use Guide/Guía Para Uso Rápido

201_401.76-80.p65 01/01/18, 17:0979

80 For assistance, please call : 1-800-211-PANA(7262) or

send e -mail to : consumerproducts@panasonic.com

Index

AC Adaptor 6, 11, 12, 64

Accessories (Optional) 64

Accessories (Supplied) 6

A/V Cable 6, 31, 51

Audio/Video Fade In/Out 48

Auto Focus 47

Backlight 47

Battery Pack 6, 9, 11, 64

Battery Remaining Indication 19

Battery Warning 21

Before Requesting Service 69, 70

Blank Search 25

CARD EJECT Switch 10

Camera Recording 22, 23, 24, 25

Cleaning Care for Video Heads 70

Clock Battery 21

Clock Set 13

Color Enhancement Light 7, 64

Copying from Digital Equipment 52

Copying your Tapes 51

Date and Time Indication 20

DC Power Cable 6, 12, 64

DEW Indication 21

Digital E.I.S. 39

Digital Functions 44

Digital PhotoShot 41

Digital Video Cassette Tape 6

Digital Zoom 40

Dubbing over Audio (Microphone) 49, 50

DV Interface Cable (i.LINK) 52, 62, 64

Edit Search 24

Erase Protection Tab 6

EVF/LCD Monitor Indications 19, 20, 21

Hand Strap 8

High Speed Shutter 48

Jog Search 29

Lens Cap 6, 8, 22

Limited Warranty 76

Macro Focus 47

MAGICVU/0LUX Switch 42

Manual Focus 47

Memory Counter 19

MENU OSD 14, 15, 16, 17, 18

Memory Card 6, 10, 64

M-CARD Door 10

PC Cable 6, 54

PC Connection 54, 62

Picture in Picture (PinP) 45

PLAY Indicator 20

Playback 27, 28, 29, 30, 31

Power Supply 11, 12

Program AE 43

REC Indicator 20

Recording Still Pictures 42

Remote Control 25, 26, 64

Request for Service Notice 70

Safety Precautions 2

Servicenter List 77

Set the Date and Time 13

Shoulder Strap 6, 8

Special Effects Playback 28, 29, 30

Specifications 67

STILL Picture 28

Strobe Multi Mode 46

Tape Remaining Indications 19

Tape Speed 6

Tape Warning 21

VHF Connecting Cable 51

Volume Display 27

White Balance 42

Zoom In/Out 40
