Panasonic presents advanced CCTV technology to meet the demand of new and ever-changing
applications. The 1/3" CCD Digital Signal Processing B/W WV-BP330 Series Cameras deliver
outstanding high-quality pictures as well as versatile digital functions and system integration
capability.
The WV-BP330 series cameras incorporate a 1/3" interline transfer type CCD (380,000 pixels:
effective) and achieve high sensitivity of 0.008 fc (0.08 lx) at F1.4, outstanding 570-line horizon-
tal resolution and signal-to-noise ratio of 50 dB.
With its advanced performance and expanded flexibility, the WV-BP330 series cameras meet
your specific needs with an affordable cost/performance ratio.
Digital Signal Processing
1/3" B/W CCD Cameras
WV-BP330 series
KEY FEATURES
●1/3" CCD pick-up element with 768 (H) x 492 (V) pixels provides a
high 570 lines of horizontal resolution.
●A vertical digital 2H enhancement improves signal strength at the
horizontal and vertical edges to provide a crisper images.
●Knee circuit effectively expands the dynamic range when viewing
brightly illuminated objects.
●Outstanding 50 dB of signal-to-noise ratio provides natural images.
●Minimum scene illumination of 0.008 fc (0.08 lx) at F1.4
●A specially developed lens mount configuration accepts both C and
CS mount lenses, as well as both DC and Video voltage for ALC
lenses.
●An advanced Electronic Light Control (ELC) enables the use of inex-
pensive fixed iris lenses for more cost effective systems.
●Gen-lock capability for system expandability, and other a variety of
synchronization modes (Line-Lock, VD2, Internal).
Type of RG-59/U RG-6/U RG-11/U RG-15/U
coaxial cable (3C-2V) (5C-2V) (7C-2V) (10C-2V)
Recommended (m) 250 500 600 800
maximum
cable length (ft) 825 1,650 1,980 2,640
●WV-BP330 Camera Series are
WV-BP330; 120V AC, 60 Hz
WV-BP332; 12V DC
WV-BP334; 24V AC, 60 Hz
●The maximum extensible coaxial cable length
between the camera and the monitor is,
(Lens: option)
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
RISQUE DE CHOCS ELECTROUES
NE PAS OUVRIR
C
CS
4-13/16" (123) 3/8" (10)
2-5/8" (67)
2-3/16" (55)
2-5/8" (65)
3/8" (10)
11/16" (18)
1-7/16" (36)
2–1/4"–20UNC(DEPTH
10mm)
Lens (Option)
SPECIFICATIONS APPEARANCE
MAJOR OPERATING CONTROLS
Unit : inches (mm)
Specifications are subject to change without notice.
Dimensions and weight are approximate.
This product may be subject to export control regulations.
DISTRIBUTED BY:
WV-
BP330
VIDEO OUT
GEN-LOCK
L
INT
AGC ON
ALC
BLC ON
VIDEO
G/L 75
VIDEO
LEVEL
V. PHASE
H
Ω
LL
OFF
ELC
OFF
DC
Hi-Z
GND
AC 24V IN
12
VIDEO OUT
GEN-LOCK
L
INT
AGC ON
ALC
BLC ON
VIDEO
G/L 75
VIDEO
LEVEL
V. PHASE
H
Ω
LL
OFF
ELC
OFF
DC
Hi-Z
DC 12V IN
VIDEO OUT
GEN-LOCK
L
AGC ON
ALC
BLC ON
VIDEO
G/L 75
VIDEO
LEVEL
H
Ω
OFF
ELC
OFF
DC
Hi-Z
WV-BP330
WV-BP332
WV-BP334
WV-BP330
and
WV-BP334
qAuto Iris lens Connector
wFlange-back Adjusting Ring
eLens (option)
rCamera Mounting Screw Hole
tPower Cord (only WV-BP330)
yDC 12 V Input Terminal
(only WV-BP332)
uAC 24 V Input Terminal
(only WV-BP334)
iSynchronization Mode Selector
(only WV-BP330/WV-BP334)
B/W Quad Unit
WJ-410 ALC Lenses
WV-LF4R5C3A
WV-LF9C3A
WV-LA210C3
WV-LA408C3
WV-LA908C3
Sequential Switchers
WJ-SQ208
WJ-SQ308
Video Monitors
WV-BM500
WV-BM503
WV-BM900
WV-BM1410
WV-BM1700
WV-BM1900
Camera Housings
WV-7110A
WV-7120D
WV-7135
WV-7140
Time-Lapse VCRs
AG-6124
AG-6040
AG-6730
AG-RT600
Video Imaging Systems Company
A Division of Panasonic Broadcast & Television Systems Company
A Unit of Matsushita Electric Corporation of America
Executive Office: One Panasonic Way 4H-2, Secaucus, New Jersey 07094
Regional Offices:
Northeast: One Panasonic Way, Secaucus, NJ 07094 (201) 348-7303
Southeast: 1225 Northbrook Parkway, Suite 1-160, Suwanee, GA 30024 (770) 338-6838
Midwest: 1707 North Randall Road, Elgin, IL 60123 (847) 468-5211
Southwest: 8105 Beltsline Road, Suite 100, Irving, TX 75063 (927) 915-1334
Western: 6550 Katella Ave., Cypress, CA 90630 (714) 373-7840
PANASONIC CANADA INC.
5770 Ambler Drive, Mississauga, Ontario, L4W 2T3 Canada (905)624-5010
PANASONIC SALES COMPANY
DIVISION OF MATSUSHITA ELECTRIC OF PUERTO RICO, INC.
San Gabriel Industrial Park, 65th Infantry Ave. KM. 9.5 Carolina, P.R. 00630 (809)750-4300
OPTIONAL ACCESSORIES
oAGC ON/OFF Selector
!0 Automatic Light Control /
Electronic Light Control
Selector
!1 Back Light Compensation
Mode Selector
!2 Lens Drive Signal Selector
!3 Gen-lock Termination Selector
!4 Vertical Phase Control (only
WV-BP330 and WV-BP334)
!5 Video Level Control
!6 Video Output Connector
!7 Gen-lock Input Connector
Models WV-BP330 WV-BP332 WV-BP334
Pick-up Device 768 (H) x 494 (V) pixels, Interline Transfer CCD
Scanning Area 4.9 (H) x 3.7 (V) mm (Equivalent to scanning area
of 1/3” pick-up tube)
Synchronization Internal, External, Line-locked or Multiplexed vertical
drive (VD2) selectable
Scanning System 2 : 1 interlace
Scanning 525 lines / 60 fields / 30 frames
Horizontal: 15.734 kHz
Vertical: 60 Hz
Horizontal Resolution 570 lines
Video Output 1.0 V[p-p] EIA composite 75 Ω/ BNC connector
Signal-to-Noise Ratio 50 dB (AGC OFF)
Electronic Light Control Equivalent to continuous variable shutter speed
between 1/60 s and 1/10,000 s
Minimum Illumination 0.08 lx (0.008 fc) at F1.4, AGC ON
Lens Mount C-mount or CS-mount selectable
Ambient Operating Temperature −10°C - +50°C (14°F - 122°F)
Ambient Operating Humidity Less than 90%
Power Source and 120V AC 60 Hz 12V DC 24V AC 60 Hz
Power Consumption 3.5W 250 mA 3.5W
Dimensions (without lens) 67 (W) x 55 (H) x 123 (D) mm
[2-5/8” (W) x 2-3/16” (H) x 4-13/16” (D)]
Weights (without lens) 0.62 kg 0.445 kg 0.470 kg
(1.4 lbs) (0.98 lbs) (1.04 lbs)
