Pantech PN-315 Dual- Mode CDMA Phone (CDMA/ PCS CDMA) User Manual TX 315 verizon 060113
Pantech Co., Ltd. Dual- Mode CDMA Phone (CDMA/ PCS CDMA) TX 315 verizon 060113
Pantech >
Users Manual
![](/img.php?id=633496&img=bg1.png)
WELCOME
Thank you for choosing the Pantech PN-315 camera phone
with built-in flash. Developed by top researchers this product
offers multiple features designed to enhance your mobile
experience including: web browsing to keep you up to date on
news, sports and more, Voice Recognition (VR) offering the
convenience of voice dialing, T9 predictive text input to make
TXT messaging faster and an easy to navigate animated menu
to make accessing and using all these features simpler.
Some of the many features of the PN-315 include:
Full graphic display of 9 text input lines and 1 icon line with
variable font size.
Easy dialing with the VR feature.
Easy text entry through the T9 text input mode.
Enhancements for web browsing & data services
(i.e.; wireless internet access, Openwave browser)
GUI & Animation display compliant with CDMA2000 1X.
Two LCD displays present rich full-color content on either
the large inner main display screen, or the smaller outer
sub-display screen.
Navigation Key and 21 keys positioned for more
convenience.
Sophisticated speaker phone, and voice recognition features.
Mobile Camera (330K pixels)
Additional text messaging and Web browsing services in
addition to authentication, call forwarding, call transfer, and
call waiting.
IMPORTANT INFORMATION
This PN-315 user guide contains very important information
about how to handle and use the product.
Please read this manual thoroughly, pay attention to the
warranty on the back page and be alert to the exclusions and
limitations of your warranty, which are related to the use of
unauthorized accessories or components.
![](/img.php?id=633496&img=bg2.png)
TABLE OF CONTENTS
1
Chapter 1
Chapter 2
Chapter 3
Chapter 4
CHAPTER 1. BEFORE USING YOUR PHONE .................................5
INSIDE THE PACKAGE.....................................................................................6
HANDSET DESCRIPTION.................................................................................7
DISPLAY INDICATORS ...........................................................................................9
BATTERY USAGE...........................................................................................11
BATTERY INSTALLATION....................................................................................11
BATTERY REMOVAL.............................................................................................11
BATTERY CHARGING...........................................................................................12
POWER CONNECTION ......................................................................................12
BATTERY USAGE TIMES....................................................................................13
BATTERY STANDBY TIME .................................................................................13
BATTERY HANDLING INFORMATION..........................................................14
DOs.........................................................................................................................14
DON’Ts...................................................................................................................14
CHAPTER 2. BASIC OPERATION ..................................................15
TURNING THE PHONE ON / OFF ..................................................................16
TURNING THE PHONE ON...................................................................................16
TURNING THE PHONE OFF..................................................................................16
ACCESSING THE MENU................................................................................17
MENU SUMMARY .........................................................................................18
BASIC FUNCTIONS........................................................................................20
MAKING A CALL...................................................................................................20
ANSWERING CALLS.............................................................................................21
SPEAKER PHONE..................................................................................................21
WAIT/PAUSE FEATURE........................................................................................22
ANSWERING A CALL............................................................................................22
3-WAY CALLING ...................................................................................................23
CALLER ID FUNCTION..........................................................................................23
CALL WAITING FUNCTION..................................................................................24
ADJUSTING VOLUME..........................................................................................24
ENTER LOCK MODE .............................................................................................25
DURING A CALL.............................................................................................26
MUTE (UNMUTE)..................................................................................................26
SEND TXT MSG....................................................................................................26
CONTACTS............................................................................................................26
RECENT CALLS.....................................................................................................26
VOICE PRIVACY.....................................................................................................26
LOCATION.............................................................................................................27
MAKING AN EMERGENCY CALL..................................................................28
911 IN LOCK MODE ..............................................................................................28
911 USING ANY AVAILABLE SYSTEM ...............................................................28
CHAPTER 3. MEMORY FUNCTION...............................................29
STORING A PHONE NUMBER ......................................................................30
ENTERING LETTERS, NUMBERS & SYMBOLS...........................................31
STANDARD INPUT MODE....................................................................................32
WORD INPUT MODE ............................................................................................33
NUMERIC MODE...................................................................................................34
SYMBOL MODE ....................................................................................................34
MAKING A CALL THROUGH THE PHONE BOOK ........................................35
ONE-TOUCH/TWO-TOUCH DIALING...................................................................35
ONE-TOUCH DIALING:.......................................................................................35
TWO-TOUCH DIALING: ......................................................................................35
CHAPTER 4. MENU FUNCTION ....................................................37
CONTACTS .....................................................................................................38
NEW CONTACT.....................................................................................................38
CONTACT LIST......................................................................................................39
GROUPS ................................................................................................................40
ADD NEW GROUP .............................................................................................40
ASSIGN PHONE NUMBER TO GROUP..............................................................40
CHANGE GROUP NAME ....................................................................................41
SEND TXT MSG. GROUP ...................................................................................41
SEND PIX MSG. GROUP ....................................................................................42
![](/img.php?id=633496&img=bg3.png)
TABLE OF CONTENTS
2
Chapter 4
ERASE GROUP ...................................................................................................42
SPEED DIALS.........................................................................................................43
RECENT CALLS ..............................................................................................44
MISSED..................................................................................................................44
RECEIVED ..............................................................................................................45
DIALED...................................................................................................................46
ALL.........................................................................................................................47
VIEW TIMERS........................................................................................................48
SETTINGS.......................................................................................................49
SOUNDS SETTINGS.............................................................................................49
MASTER VOLUME .............................................................................................49
CALL SOUNDS ...................................................................................................50
ALERT SOUNDS .................................................................................................51
KEYPAD VOLUME ..............................................................................................53
EARPIECE VOLUME...........................................................................................53
SERVICE ALERTS ...............................................................................................54
POWER ON/OFF.................................................................................................55
ALARM SOUNDS ...............................................................................................56
DISPLAY SETTINGS..............................................................................................57
BANNER .............................................................................................................57
BACKLIGHT ........................................................................................................58
CONTRAST .........................................................................................................59
WALLPAPER.......................................................................................................59
SCREENSAVER...................................................................................................60
DISPLAY THEMES..............................................................................................60
DIAL FONTS .......................................................................................................61
CLOCK FORMAT ................................................................................................61
PHONE SETTINGS................................................................................................62
STANDALONE MODE ........................................................................................62
SET SHORTCUT KEY ..........................................................................................62
LANGUAGE.........................................................................................................63
SECURITY ...........................................................................................................63
SYSTEM SELECT................................................................................................64
NAM SELECTION ...............................................................................................65
CALL SETTINGS....................................................................................................66
ANSWER OPTIONS ............................................................................................66
AUTO RETRY ......................................................................................................67
TTY MODE..........................................................................................................67
ONE TOUCH DIAL ..............................................................................................68
VOICE PRIVACY..................................................................................................68
DATA SETTING ...................................................................................................68
VOICE SERVICES................................................................................................69
DTMF TONES .....................................................................................................72
MEMORY...............................................................................................................73
MEMORY USAGE...............................................................................................73
MY PIX ................................................................................................................73
MY SOUNDS ......................................................................................................73
PHONE INFO..........................................................................................................74
MY NUMBER......................................................................................................74
SW VERSION......................................................................................................74
ICON GLOSSARY ...............................................................................................75
TOOLS.............................................................................................................76
CALENDAR............................................................................................................76
ADD NEW ...........................................................................................................76
VIEW PLAN LIST.................................................................................................77
ALARM CLOCK......................................................................................................78
WORLD CLOCK .....................................................................................................79
NOTEPAD ..............................................................................................................80
ADD MEMO........................................................................................................80
VIEW MEMO ......................................................................................................80
CALCULATOR........................................................................................................81
STOP WATCH........................................................................................................82
MY ACCOUNT ................................................................................................83
MY ACCOUNT.......................................................................................................83
![](/img.php?id=633496&img=bg4.png)
TABLE OF CONTENTS
3
Chapter 6
Chapter 5
CHAPTER 5. GET IT NOW..............................................................85
GET IT NOW ...................................................................................................86
GET TUNES & TONES..........................................................................................86
GET NEW RINGTONES ......................................................................................86
RECORDING NEW TONES.................................................................................86
MY RINGTONES .................................................................................................87
MY SOUNDS ......................................................................................................88
GET PIX..................................................................................................................89
DOWNLOADING NEW PIX.................................................................................89
MY PIX ................................................................................................................89
PIX PLACE ..........................................................................................................90
TAKE PIX.............................................................................................................91
GET FUN & GAMES..............................................................................................93
DOWNLOADING NEW FUN & GAMES .............................................................93
PLAYING DOWNLOADED FUN & GAMES ........................................................93
GET NEWS & INFO...............................................................................................94
CONNECTING NEWS & INFO ............................................................................94
GET GOING ...........................................................................................................94
CONNECTING GET GOING ................................................................................94
GET IT NOW INFO.................................................................................................94
CHAPTER 6. VOICE MAIL, TXT, PIX MESSAGING ......................95
WHEN A NEW MESSAGE ARRIVES .............................................................96
VOICE MAIL ....................................................................................................96
NEW MSG .................................................................................................................97
SEND NEW TXT MESSAGE.................................................................................97
SEND NEW PIX MESSAGE ..................................................................................98
INBOX......................................................................................................................100
PLAY AGAIN .....................................................................................................100
FORWARD........................................................................................................100
ERASE...............................................................................................................101
REPLY W. COPY...............................................................................................101
SAVE GRAPHIC ................................................................................................101
SAVE SOUND ...................................................................................................101
SAVE QUICK TEXT............................................................................................101
LOCK/UNLOCK .................................................................................................102
ADD TO CONTACTS.........................................................................................102
MESSAGE INFO ...............................................................................................102
SENT........................................................................................................................103
PLAY AGAIN .....................................................................................................103
FORWARD........................................................................................................103
RESEND............................................................................................................103
ERASE...............................................................................................................104
LOCK/UNLOCK .................................................................................................104
ADD TO CONTACTS.........................................................................................104
SAVE QUICK TEXT............................................................................................104
MESSAGE INFO ...............................................................................................104
DRAFTS ...................................................................................................................105
SEND ................................................................................................................105
LOCK/UNLOCK .................................................................................................105
ADD TO CONTACTS.........................................................................................105
E- MAIL....................................................................................................................106
MOBILE IM ..............................................................................................................107
GET NEW..........................................................................................................107
MOBILE IM.......................................................................................................107
CHAT........................................................................................................................108
ERASE ALL..............................................................................................................109
SETTINGS................................................................................................................110
ALL MSG SETTINGS...........................................................................................110
AUTO SAVE ......................................................................................................110
AUTO ERASE....................................................................................................110
QUICK TEXT......................................................................................................111
VOICE MAIL#....................................................................................................111
ENTRY MODE...................................................................................................112
CALLBACK #.....................................................................................................112
ALL MESSAGE SIGNATURE ............................................................................113
![](/img.php?id=633496&img=bg5.png)
TABLE OF CONTENT
4
Chapter 7
Chapter 8
TXT MSG SETTINGS..........................................................................................114
AUTO VIEW ......................................................................................................114
BLOCK / UNBLOCK ..........................................................................................114
TXT MESSAGE SIGNATURE.............................................................................115
PIX MSG SETTINGS ...........................................................................................116
AUTO RECEIVE.................................................................................................116
PIX MESSAGE SIGNATURE .............................................................................116
CHAPTER 7. MOBILE WEB 2.0 ....................................................117
STARTING INTERNET BROWSER...............................................................118
LAUNCHING MOBILE WEB 2.0..........................................................................118
BROWSER MENU.........................................................................................118
VZW HOME..........................................................................................................118
BACK....................................................................................................................118
FORWARD ...........................................................................................................119
REFRESH..............................................................................................................119
HISTORY..............................................................................................................119
ADDRESS.............................................................................................................119
CLEAR MEMORY.................................................................................................119
SETTINGS............................................................................................................120
ADVANCED..........................................................................................................121
EXIT......................................................................................................................122
CHAPTER 8. SAFETY AND WARRANTY ....................................123
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES..............124
DRIVING SAFETY................................................................................................125
ELECTRONIC DEVICES.......................................................................................126
OTHER SAFETY GUIDELINES............................................................................127
PRECAUTIONS....................................................................................................128
SAFETY INFORMATION FOR FCC RF EXPOSURE ....................................129
CAUTIONS...........................................................................................................129
SAR INFORMATION.....................................................................................130
FCC HEARING-AID COMPATIBILITY (HAC) REGULATIONS FOR
WIRELESS DEVICES.....................................................................................132
FDA CONSUMER UPDATE..........................................................................134
PROTECT YOUR WARRANTY .....................................................................138
12 MONTH LIMITED WARRANTY...............................................................139
“Licensed by QUALCOMM Incorporated under one or more of the following Patents : U.S.Patent No.
4,901,307 U.S.Patent No. 5,056,109 U.S.Patent No. 5,099,204 U.S. Patent No. 5,101,501 U.S. Patent No.
5,103,459 U.S. Patent No. 5,107,225 U.S.Patent No. 5,109,390.”
![](/img.php?id=633496&img=bg6.png)
BEFORE USING
YOUR PHONE
C
H
.
1
5
This chapter provides important information about using the
PN-315 including:
Chapter 1
INSIDE THE PACKAGE
HANDSET DESCRIPTION
BATTERY USAGE
BATTERY HANDLING INFORMATION
![](/img.php?id=633496&img=bg7.png)
This package should include all items pictured below.
If any are missing or different, immediately contact the retailer
where you purchased the phone.
INSIDE THE PACKAGE
C
H
1
6
User Manual
AC Travel Charger
Handset
Standard Battery
![](/img.php?id=633496&img=bg8.png)
HANDSET DESCRIPTION
C
H
1
7
The PN-315 weighs 3.7oz. The dimensions are 1.83” x 4.48” x 0.97”.
Antenna
Earjack
Camera Key
Volume Keys
LCD Screen
Function Key
Camera Key
END/
Power Key
Microphone
Earpiece
Navigation Key
Camera Lens
Sub LCD
State LED
Send Key
Speaker Key
![](/img.php?id=633496&img=bg9.png)
C
H
1
8
Press to make or receive a call.
Short press:Recent Calls. Long press:Voice Dial.
Press to clear a digit from the display or to return
to the previous page.
Press and hold to enter lock mode.
Short/long press : Go to Take PIX Viewfinder/Menu.
A long press shall display a plus “+”.
Speaker Phone On/Off in idle.
Press to turn the phone on/off, to terminate a call
or to return to the initial page.
In Idle Mode
-
Press Up for Short Cut Key 1, Down for
Short Cut Key 4, Right for Short Cut
Key 3 and Left for Short Cut Key 2.
Inside the menu
- Within a menu, use to scroll through
menu options, or to select a function
displayed on the screen.
(Left Soft Key) Press to access the message
menu or function displayed on bottom line.
(Right Soft Key) Press to access contacts menu
or function displayed on bottom line.
HANDSET DESCRIPTION
Short Cut Key 4
Short Cut Key 1
Short Cut Key 2 Short Cut Key 3
Display Indicators
See page 9 for a list of icons.
Soft Key Indicators
Shows the functions currently
assigned to each soft key and
displays some icons.
Text & Graphic area
Message
Menu
Contacts
![](/img.php?id=633496&img=bga.png)
C
H
1
DISPLAY INDICATORS
9
HANDSET DESCRIPTION
SSL (Secured Socket Layer)
Indicating that secure communication between
client and server has been established during
data communication using encryption.
Roaming
Phone is out of home area.
Standalone
The mode that restricts transmitting and receiving
inside the airplane.
Dormant
Indicates your phone is in a dormant state during a
data call. Your phone goes to Dormant mode when
you have not had any activity on a page for some
time - your connection is still active and you can
make and receive calls.
No Service
Indicates the phone cannot receive a signal from
the system.
Voice Data Active
Battery
Battery charging level – the more blocks, the
stronger the charge.
TTY
Indicates your phone is active in TTY mode.
Voice Privacy
Indicates “Voice Privacy” mode.
GPS Icon
Indicates the Location Service of your phone is
disabled/enabled.
Signal Strength - Current signal strength: the
more lines, the stronger the signal (1X Mode/
Digital Mode).
![](/img.php?id=633496&img=bgb.png)
C
H
1
10
HANDSET DESCRIPTION
Missed Calls
Voicemail
Indicates you have voicemail messages.
New Messages
Receive a new TXT message.
Calendar Appointment
Indicates Event Alarm is active.
Data Only
Receives an async. call as a voice call.
Speakerphone
Phone is in speakerphone mode.
Auto Answer
Phone is in answering machine mode.
All Sounds Off
Indicates the ringer volume is set to off.
Vibrate Only
Phone will vibrate when call is received.
Alarm
Appears when either a calendar or an alarm is set.
Alarm Only
Phone will alert you with an alarm tone when call
is received.
![](/img.php?id=633496&img=bgc.png)
C
H
1
11
BATTERY USAGE
BATTERY INSTALLATION
1
uPlace the battery on the back of the handset
and slide into place. vPush the battery down
until it locks into place.
BATTERY REMOVAL
1
uPull down the release latch, lift up the
battery and vremove the battery from the
handset.
If the battery is not correctly placed in the compartment, the
handset will not turn on and/or the battery may detach during use.
![](/img.php?id=633496&img=bgd.png)
C
H
1
12
BATTERY USAGE
• When you charge the battery with the phone power off, you
will see a charging status screen. You cannot operate the
phone until it is powered on.
• The battery is not charged at the time of purchase.
• Fully charge the battery before use.
• It is more efficient to charge the battery with the handset
powered off.
• The battery must be connected to the phone in order to charge it.
• Battery operating time gradually decreases over time.
• If the battery fails to perform normally, you may need to replace
the battery.
1
Plug the AC Charger into a standard outlet.
2
Plug the other end of the AC Charger into the
bottom of your phone. The battery must be
installed onto the phone.
BATTERY CHARGING
POWER CONNECTION
![](/img.php?id=633496&img=bge.png)
C
H
1
13
BATTERY USAGE
BATTERY STANDBY TIME
The operating time is subject to your handset usage and configuration.
BATTERY USAGE TIMES
The operating time is subject to your handset usage and configuration.
These times are for a new battery. Usage and Standby time may
decrease over time.
PCS
Up to 203 minutes
-
DCS
Up to 203 minutes
-
STD 1100 mAh
Battery Capacity
-
PCS
190 Hours
-
DCS
220 Hours
-
STD 1100 mAh
Battery Capacity
-
![](/img.php?id=633496&img=bgf.png)
BATTERY HANDLING INFORMATION
C
H
1
14
lOnly use the battery and charger approved by the
manufacturer.
lOnly use the battery for its original purpose.
lTry to keep batteries in a temperature between
41ºF (5ºC ) and 95ºF (35ºC).
lIf the battery is stored in temperatures above or
below the recommended range, give it time to warm
up or cool down before using.
lCompletely drain the battery before recharging.
It may take one to four days to completely drain.
lStore the discharged battery in a cool, dark, and dry
place.
lPurchase a new battery when its operating time
gradually decreases after fully charging.
lProperly dispose of the battery according to local
laws.
lDon’t attempt to disassemble the battery –
it is a sealed unit with no serviceable parts.
lDon’t accidentally short circuit the battery by
carrying it in your pocket or purse with other
metallic objects such as coins, clips and pens.
This may critically damage the battery.
lDon’t leave the battery in hot or cold temps.
Otherwise, it could significantly reduce the capacity
and lifetime of the battery.
lDon’t dispose of the battery into a fire.
DOs
DON’Ts
![](/img.php?id=633496&img=bg10.png)
BASIC OPERATION
This chapter addresses and explains the basic features of your phone
including:
Chapter 2
C
H
2
15
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
MENU SUMMARY
BASIC FUNCTIONS
DURING A CALL
MAKING AN EMERGENCY CALL
![](/img.php?id=633496&img=bg11.png)
C
H
2
TURNING THE PHONE ON
1
Press and hold until your “Power On” logo
appears and the tone sounds.
• If “Password” appears on the display enter your 4-digit
password to unlock your phone.
• The default password is the last 4 digits of your
phone number.
16
TURNING THE PHONE OFF
1
Press and hold until your “Power Off” logo
appears.
• Immediately change or recharge the battery when
“LOW BATTERY!! PHONE IS TURNING OFF!” appears on
the display. Memory may possibly be damaged if the phone
turns off due to the battery completely draining.
• Turn the phone off before removing or replacing the battery.
If the phone is on, unsaved data may be lost.
TURNING THE PHONE ON / OFF
![](/img.php?id=633496&img=bg12.png)
ACCESSING THE MENU
C
H
2
Your phone can be customized via the menu. Each function can be
accessed by scrolling with the Navigation Key or by pressing the
number that corresponds with the menu item.
1
To access the menu in the idle mode,
press [MENU].
2
Use the Navigation Key to scroll through the
menu.
3
To return to the previous page, press .
To exit the current menu and return to the idle
mode, press .
4
Press the Navigation Key to enter a function
when its main page is displayed or press its
assigned number to have direct access to
the function.
17
Hotkey
In idle mode, move the Navigation Key as follows to access
these functions:
• Upward movement : Shortcut Key 1
• Downward movement : Shortcut Key 4
• Rightward movement : Shortcut Key 3
• Leftward movement : Shortcut Key 2
lTo search through the menu in numerical order, press the
Navigation Key.
Get It Now
Messaging
Contacts
Recent Calls
Settings & Tools
![](/img.php?id=633496&img=bg13.png)
MENU SUMMARY
C
H
2
18
Get It Now
Messaging
Contacts
Recent Calls
Settings & Tools
1. Get Tunes &
Tones
2. Get PIX
3. Get Fun &
Games
4. Get News & Info
5. Get Going
1. New Msg
2. Inbox
3. Sent
4. Drafts
5. Voicemail
6. E-mail
7. Mobile IM
8. Chat
1. New Contact
2. Contact List
3. Groups
4. Speed Dials
1. Missed
2. Received
3. Dialed
4. All
5. View Timers
1. My Account
2. Tools
3. Sounds Settings
1. Get New Ringtones
2. My Ringtones
3. My Sounds
1. Get New PIX
2. My PIX
3. PIX Place
4. Take PIX
1. Get New
1. Get New
1. TXT Msg
2. PIX Msg
1. Calendar
2. Alarm Clock
3. World Clock
4. Notepad
5. Calculator
6. Stop Watch
1. Master Volume
2. Call Sounds
3. Alert Sounds
4. Keypad Volume
5. Earpiece Volume
6. Service Alerts
7. Power On/Off
8. Alarm Sounds
1. Alarm 1
2. Alarm 2
3. Alarm 3
1. Call Ringtone
2. Call Vibrate
1. TXT Message
2. PIX Message
3. Voicemail Msg
1. ERI
2. Minute Beep
3. Call Connect
1. Power On
2. Power Off
1. Alarm Tone
2. Alarm Vibrate
![](/img.php?id=633496&img=bg14.png)
MENU SUMMARY
C
H
2
19
4. Display Settings
5. Phone Settings
6. Call Settings
7. Memory
8. Phone Info
1. Banner
2. Backlight
3. Contrast
4. Wallpaper
5. Screensaver
6. Display Themes
7. Dial Fonts
8. Clock Format
1. Standalone Mode
2. Set Shortcut Key
3. Language
4. Security
5. System Select
6. NAM Selection
1. Answer Options
2. Auto Retry
3. TTY Mode
4. One Touch Dial
5. Voice Privacy
6. Data Setting
7. Voice Services
8. DTMF Tones
1. Memory Usage
2. My PIX
3. My Sounds
1. My Number
2. SW Version
3. Icon Glossary
1. Personal
2. ERI Banner
1. Display Settings
2. Keypad
1. Main LCD
2. Sub LCD
1. Main Clock
2. Front Clock
1. Left Key
2. Up Key
3. Right Key
4. Down Key
5. Reset All
1. Lock Mode
2. Edit Code
1. Auto NAM
2. Change NAM
1. Voice Dial
2. Voice Setting
3. Voice Memo
4. Train Word
![](/img.php?id=633496&img=bg15.png)
BASIC FUNCTIONS
C
H
2
20
MAKING A CALL
1
Enter a phone number.
To modify the phone number you have entered :
• To erase one digit at a time press .
• To erase the entire number, press and hold .
To send the TXT or PIX message with phone number :
• To enter a part of the phone number, then press
[OPTIONS], select “New TXT Msg or New PIX Msg”.
Please refer to page 97 or page 98 for more details on
“Send New TXT Message or Send New PIX Message”.
2
Press .
The indicator, , appears on the display.
• If “CALL FAILED” appears on the display or the line is busy,
press or .
• If you activate the “AUTO RETRY” function, the phone will
automatically retry for the number of times you have
selected. (refer to page 67).
• When you place or receive a call from stored phone
numbers, the saved name will be displayed.
• There is another way to make a call through the VR mode,
which is called “VAD (Voice Activated Dialing)”.
Please refer to page 69 (Voice Service) for more details.
• If “Enter Lock Code” appears on the display enter your
4-digit password to unlock your phone.
3
To end a call, press .
![](/img.php?id=633496&img=bg16.png)
C
H
2
21
BASIC FUNCTIONS
To ignore incoming calls, press [IGNORE].
ANSWERING CALLS
1
When your phone rings or vibrates, press
to answer the incoming call.
(Depending on your phone’s settings, you may
also answer incoming calls by opening the
phone or by pressing any digit key.)
2
To end a call, press .
The speaker phone feature lets you hear audio through the speaker and
talk without holding the phone.
SPEAKER PHONE
1
To activate the speaker phone in idle, answering
or calling modes, press .
2
The phone returns to normal (Speaker Phone Off)
after ending a call or when the phone is turned off
and back on.
![](/img.php?id=633496&img=bg17.png)
BASIC FUNCTIONS
C
H
2
22
ANSWERING A CALL
1
To answer a call, press any key except , ,
, , , , or .
2
To end the call, press .
In Auto Answer Mode a call is automatically answered after
5 seconds of ring tones. See page 66 for more details.
lBy pressing [MENU] and then select “Settings & Tools”
menu, press , you can select either “Flip Open”,
“Any Key” or “Send Only” to answer a call. lf “Send Only” is
selected, the phone can only be answered by pressing .
See page 65 for more information.
Pauses are used for automated systems (i.e., voice mail, calling cards).
Insert a pause after a phone number then enter another group of
numbers. The second set of numbers is dialed automatically after the
pause. This feature is useful for dialing into systems that require a code.
WAIT/PAUSE FEATURE
1
To insert a wait/pause, enter a phone number
then press [OPTIONS]. Select either a 2-Sec
Pause (“P” appears) or a Wait (“W” appears).
2
Press to dial or to save.
Please refer to page 30 for more details about
storing a phone number.
![](/img.php?id=633496&img=bg18.png)
BASIC FUNCTIONS
C
H
2
23
If one of the people you called hangs up during your call, you
and the remaining caller stay connected. If you initiated the call
and are the first to hang up, all three callers are disconnected.
With 3-Way Calling, you can talk to two people at the same time. When
using this feature, the normal airtime rates will be applied for each of the
two calls.
3-WAY CALLING
1
Enter a number you wish to call then press .
2
Once you have established the connection,
enter the second number you wish to call then
press .
3
When you’re connected to the second party,
press again to begin your 3-Way call.
Identifies caller by displaying their phone number. If the caller’s name
and number are already stored in your phone book, the name will
appear. The caller ID is stored in the recent calls.
CALLER ID FUNCTION
![](/img.php?id=633496&img=bg19.png)
BASIC FUNCTIONS
C
H
2
24
Notifies you of an incoming call when you are already on a call by
sounding a beep tone and displaying the caller’s phone number.
CALL WAITING FUNCTION
1
To answer another call while on the phone,
press . This places the first call on hold.
To switch back to the first caller, press
again.
Adjusts the volume of the ringer, key beep and speaker.
ADJUSTING VOLUME
1
Press [MENU], then select “Settings & Tools”
menu, press then select one of the following.
2
Adjust volume then press to save it.
Master Volume : Controls the ringer volume.
Keypad Volume : Controls the keypad volume.
Earpiece Volume : Controls the earpiece volume.
l
l
l
• To adjust earpiece volume during a call, press the Navigation
Key up or down.
• To adjust master volume, press short side up/ down key.
•In Idle Mode:
Side Volume Up key Long Press: Set volume to out of silence.
Side Volume Down key Long Press: Set volume to silence.
Call Waiting is a system dependent feature. Please contact your
service provider for details.
![](/img.php?id=633496&img=bg1a.png)
BASIC FUNCTIONS
C
H
2
25
ENTER LOCK MODE
1
To lock the phone, press and hold .
2
To unlock the phone, press or [UNLOCK],
then input your password, then press .
Lock feature will not deactivate when the phone is
powered off.
l
![](/img.php?id=633496&img=bg1b.png)
DURING A CALL
C
H
2
26
Increases security during a call.
VOICE PRIVACY
1
Press [OPTIONS] .
Enables you to send a TXT message (SMS) during a call.
To display menu options during a call, press [
OPTIONS
].
SEND TXT MSG
1
Press [OPTIONS] .
To select the phone number in your recent calls List.
RECENT CALLS
To select the phone number in your internal Contact List.
CONTACTS
1
Press [OPTIONS] .
1
Press [OPTIONS] .
The caller cannot hear you or any sounds from your side but you can
still hear them.
MUTE (UNMUTE)
1
Press [MUTE].
To deactivate, press [UNMUTE].
The phone will automatically unmute in Emergency
Call or Callback mode.
l
l
![](/img.php?id=633496&img=bg1c.png)
DURING A CALL
C
H
2
27
Enables the network to locate your current location through Global
Positioning System (GPS).
LOCATION
1
Press [OPTIONS] .
![](/img.php?id=633496&img=bg1d.png)
MAKING AN EMERGENCY CALL
C
H
2
28
The 911 feature puts the phone in the Emergency Call Mode
when you dial the preprogrammed emergency number, 911.
It also operates in the lock mode and out of the service area.
The 911 call service is available even in the lock mode.
911 IN LOCK MODE
1
Enter “911” then press .
When the call ends, the phone returns to the Lock Mode.
2
The call connects.
3
The phone exits the Emergency Mode
after 5 minutes.
911 USING ANY AVAILABLE SYSTEM
1
Enter “911” then press .
The phone returns to the Lock Mode.
While the phone is in the emergency mode for 5 minutes,
the phone can receive an incoming call from any available
system. However, it can’t make a call.
2
The call connects.
3
The phone maintains the Emergency Mode
for 5 minutes.
l
l
l
The 911 call is not recorded in the recent call list.
![](/img.php?id=633496&img=bg1e.png)
MEMORY FUNCTION
This chapter addresses memory functions including:
Chapter 3
C
H
3
29
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
MAKING A CALL THROUGH THE PHONE BOOK
![](/img.php?id=633496&img=bg1f.png)
Enter a name.
Please refer to page 31 for more details on
entering letters, numbers & symbols.
To change the input mode, press [Abc].
Press the Navigation Key down to select other
options (Mobile1.2, E-mail1.2, etc...).
If entered phone number, press [OPTIONS]
to select one of the following options:
STORING A PHONE NUMBER
C
H
.
3
The phone book stores up to 500 entries.
1
Enter phone # then press [SAVE] then
choose “Create New” or “Update Existing”.
Press to select.
2
If “Create New” is selected, the phone number
will appear above a list. Press the Navigation
Key up or down to choose the type of number
you’re adding, as indicated by the icon.
Press to select.
If “Update Existing” is selected, your contact list
is displayed. Choose the entry to add the phone
number to, then press . You will then see the
phone number listed about a list.
Press to select.
3
4
To store the entry, press [SAVE].
“CONTACT SAVED” will be displayed.
30
lSet Speed Dial
lSet Voice Dial
lSet As Default
lAdd Pause
![](/img.php?id=633496&img=bg20.png)
ENTERING LETTERS, NUMBERS & SYMBOLS
C
H
3
The input mode (Alpha editor) will automatically be
activated when necessary to enter letters and numbers.
As shown below, there are 5 available modes ;
Standard input mode (Abc), Word input mode (Word),
Numeric mode (123), and Symbol mode (Symbols).
The input mode indicator appears on the upper right of
the display when letters and numbers are entered. To
select the desired input mode among the 5 modes
below, press [Abc], then enter letters and numbers.
The following illustrates the function assigned to each key in the Alpha Editor.
31
Abc
Next
Space
Caps Lock
Clear
Send
Press to change mode.
[Word][Abc][ABC][123][Symbols]
Press to view the next matching word if
the highlighted word is not the word you
intended.
Press to accept a word and add a space.
Press to select a letter case of the
standard text input or T9 text input mode.
[Abc], [ABC] and [abc] indicate the
standard text input.
[Word], [WORD] and [word] indicate the
predictive text input.
Press and hold to change mode.
Press to delete a character to the left of
the cursor.
Send the letters and numbers you enter.
KEY FUNCTION
Input mode indicator
Word : Word mode
Abc : Abc mode
ABC : ABC mode
123 : Numeric mode
Symbols : Symbol mode
![](/img.php?id=633496&img=bg21.png)
ENTERING LETTERS, NUMBERS & SYMBOLS
Select Abc mode by pressing [Abc].
When you select this mode, the Abc icon appears as a visual
confirmation.
- Find the key that corresponds to the letter you want to enter.
- Press it as many times as needed for the letter to appear on the
screen.
- To enter the name “John”:
Press [ ] J
Press [ ] o
Press [ ] h
Press [ ] n
C
H
3
Use the digit keys to enter letters, numbers and characters.
STANDARD INPUT MODE
1
Enter letters using the key pad as follows:
2
To enter a space, press . The cursor will
automatically move to the next column.
3
Repeat until letters are entered.
4
To delete one digit, press .
If you press and hold , it will delete letters
word by word, and numbers in whole.
To change the input mode, press [Abc].
Press and hold , until the desired symbol
appears (.@?!-...).
32
Key Pad
2ABC
3DEF
4GHI
:
9WXYZ
A
D
G
:
W
B
E
H
:
X
C
F
I
:
Y
2
3
4
:
Z
A
D
G
:
9
1
Time
Repetitions
2 times
Repetitions
3 times
Repetitions
4 times
Repetitions
5 times
5
To change from lowercase to uppercase,
press .
![](/img.php?id=633496&img=bg22.png)
ENTERING LETTERS, NUMBERS & SYMBOLS
C
H
3
The Word input mode incorporates a built-in-dictionary to determine
a word based on the entered characters. A word can be entered
more quickly by pressing a key once per character.
WORD INPUT MODE
1
Select the Word mode by pressing [Abc].
2
Press a digit key once to enter the character
you want then enter all the characters to input
the word you want.
3
To view the next matching word, press .
To enter a compound word:
• Enter the first part of the word then press to accept it.
• Enter the last part of the word then press to enter the word.
33
4
To accept the matching word and enter a
space, press .
To enter “Fun fare” in the Word input mode.
- After you enter the 1st letter, press [Abc] to select Word mode
and to choose the lower case (Word).
- Press and you will see “Fun” highlighted.
Press to select it.
- Press and until you see “ease” highlighted.
Press to select the next matching word, you will see “fare”
then enter a space.
![](/img.php?id=633496&img=bg23.png)
ENTERING LETTERS, NUMBERS & SYMBOLS
NUMERIC MODE
1
Press [Abc] and scroll down to “Symbols”
and press to change to Symbol Mode.
C
H
3
34
1
Press [Abc] and scroll down to “123” and
press to change to Numeric Mode.
2
To enter a number, press a digit key.
Press [ ],
or
Press [ ].
2
Select symbol you want to enter with the
Navigation Key.
lUse the Navigation Key to view a different line of symbols.
SYMBOL MODE
Allows you to enter numbers.
Allows you to enter symbols.
![](/img.php?id=633496&img=bg24.png)
MAKING A CALL THROUGH THE PHONE BOOK
C
H
3
35
Ideal for frequently dialed numbers, this feature allows phone book
entries to be dialed via the keypad with only one or two key presses.
ONE-TOUCH/TWO-TOUCH DIALING
2-9 : Press and hold the corresponding memory
number for more than 1 second.
ONE-TOUCH DIALING:
10-22 : Press the first digit and second digits of the
memory number short and long respectively.
TWO-TOUCH DIALING:
If no phone number is stored in the location entered,
“UNASSIGNED LOCATION” will appear on the screen.
![](/img.php?id=633496&img=bg25.png)
MEMO
C
H
3
36
![](/img.php?id=633496&img=bg26.png)
MENU FUNCTION
This chapter addresses accessing the menu and using its functions
and features to customize your phone.
Chapter 4
C
H
4
37
CONTACTS
RECENT CALLS
SETTINGS
TOOLS
MY ACCOUNT
![](/img.php?id=633496&img=bg27.png)
C
H
4
38
Stores up to 500 entries, each of which can be assigned to a group.
Entries can be retrieved by name or group.
CONTACTS
1
2
Press [MENU], then press “New Contact”.
Adds a new entry.
NEW CONTACT
To enter a name or number, use the Navigation
Key to select the phone book field.
Please refer to page 31 for more details on entering
letters, numbers & symbols.
3
3.1 To save the entry, press [SAVE].
3.2 To return to the previous page, press .
PHONE BOOK FIELDS :
Name/Mobile 1/Home/Work/E-mail 1/Group/Picture/
Ringtone/Mobile 2/Fax/E-mail 2.
Under “Mobile 1”, “Mobile 2”, “Home”, “Work” or “Fax”,
input the phone number, then by press [OPTIONS],
you can choose from the following:
1. Set Speed Dial
2. Set Voice Dial
3. Set As Default
4. Add Pause
Scroll to “Picture” and press [SET] to select an image.
(Please refer to page 89 “My PIX” for more details.)
Scroll to “Ringtone” and press [SET] to add a ringtone.
(Please refer to page 87 “My Ringtones” for more details.)
l
l
l
l
At least one phone number or an email address needs to be
entered to save the new contact. Otherwise, it will display
“NO DATA ENTERED”.
If only a phone number is entered and the name field is left blank,
the contact will still be saved and the Contact List will display the
phone number.
![](/img.php?id=633496&img=bg28.png)
C
H
4
39
Retrieves an entry by name and calls by simply pressing .
You can review all the entries stored in your phone book list or
quickly find an entry by entering a name or its character string.
CONTACT LIST
CONTACTS
1
2
3
4
5
Press [MENU] or press [CONTACTS],
then press “Contact List”
Enter a name or its character string or scroll
through the list with the Navigation Key.
Please refer to page 31 for more details on
entering letters, numbers & symbols.
The list of names in your phone book is
displayed alphabetically.
To edit the entry, press [EDIT].
To view the contact details, press [VIEW].
To call the selected number, press [OPTIONS]
then select “Call” or press .
To use and manage contacts, press [OPTIONS] then select:
1. New Contact: To add a New Contact.
2. Erase: To delete a contact.
3. Send TXT Msg: To begin a TXT message to the contact.
4. Send PIX Msg: To create a picture message.
5. Call: To call the contact.
![](/img.php?id=633496&img=bg29.png)
C
H
4
40
CONTACTS
GROUPS
Allows you to classify phone entries into as many as 30 groups.
Existing group names include Family and Work and can’t be renamed
or Erased, however the user can create up to 28 additional group
names which can be changed or deleted. The user can add up to
10 phone numbers per group.
1
3
Press [MENU], then press “Groups”.
ADD NEW GROUP
Input a new group name.
4
To save it, press [SAVE].
2
To select “New”, press [NEW].
1
3
To assign phone numbers to a Group,
select “Add”, press [OPTIONS].
ASSIGN PHONE NUMBER TO GROUP
Select the contact for the group then
press [DONE]. “CONTACTS ADDED TO
GROUP” will be displayed.
Repeat for each location for the Group.
2
Your phone book entries will be displayed in
alphabetical order. Select a location and
press .
![](/img.php?id=633496&img=bg2a.png)
C
H
4
CONTACTS
41
CHANGE GROUP NAME
2
Select an existing group name that you have
added with the Navigation Key.
4
Input a new group name.
5
To save it, press [SAVE].
3
To select “Rename”, press [OPTIONS].
1
Press [MENU], then press “Groups”.
1
Press [MENU], then press “Groups”.
SEND TXT MSG. GROUP
2
Select an existing group name with the
Navigation Key.
4
Input a “Message”, press [OPTIONS] to
select “Save As Draft”, “Priority Level” and
“Callback #”.
5
3
To select “Send TXT Msg.”, press [OPTIONS].
5.1. To send the TXT message, press [SEND].
5.2. To save the TXT message, press [OPTIONS]
then select “Save As Draft”, then
press .
![](/img.php?id=633496&img=bg2b.png)
C
H
4
42
CONTACTS
ERASE GROUP
2
Select an existing group name with the
Navigation Key.
3
To select “Erase”, press [OPTIONS].
4
Select “Yes” to erase it, press .
1
Press [MENU], then press “Groups”.
SEND PIX MSG. GROUP
1
Press [MENU], then press “Groups”.
2
Select an existing group name with the
Navigation Key.
4
Input a “Text”, “PIX”, “Sound”, “Subject”,
press [OPTIONS] to select “Preview”,
“Add Quick Text”, “Save As Draft”, “Priority
Level” and “Add Slide”.
5
3
To select “Send PIX Msg”, press [OPTIONS].
5.1. To send the PIX message, press [SEND].
5.2. To save the PIX message, press [OPTIONS]
then select “Save As Draft”, then
press .
![](/img.php?id=633496&img=bg2c.png)
C
H
4
CONTACTS
43
In idle mode, calls can be placed to numbers stored in speed dial by
pressing & holding the location number on the key pad. For a 2-digit
location number, press the first number, then press and hold the
second number.
SPEED DIALS
1
2
To assign a phone number to a location, select
the location then press [SET].
3
Select the contact with the Navigation Key then
press .
4
To confirm, press .
5
“SPEED DIAL SET” will be displayed.
• “Unassigned” appears if the location is available.
• To call an assigned number, press & hold the last digit of the
speed dial #.
Press [MENU], then press “Speed Dials”.
![](/img.php?id=633496&img=bg2d.png)
C
H
4
44
RECENT CALLS
Displays information about the 90 most recently missed calls.
Place a call to a missed call number by simply pressing .
To see a list of the 90 most recently missed
calls, press [MENU], then select “Recent
Calls” menu, press “Missed”. If the
number is already stored in your phone book,
only the name appears. If the number is not
stored, only the phone number appears.
MISSED
1
2
To view missed call details, press [OPEN].
Call details include date, time and phone number.
• After 90 missed calls, the oldest call will automatically
be erased from the history.
• Press [MESSAGE], to send the TXT or PIX Meg.
3
Save : To store the phone number in your phone book.
Details : To view the caller’s information.
Erase : To erase a missed calls list.
Lock/Unlock : To lock or unlock missed calls list.
Erase All : To erase all missed calls list.
View Timers : To display usage time.
l
l
l
l
l
l
Press [OPTIONS] and select “Save” to
save it or select “Erase” to delete it.
![](/img.php?id=633496&img=bg2e.png)
C
H
4
45
RECENT CALLS
Call details include date, time and phone number.
• After 90 received calls, the oldest call will automatically
be erased from the history.
• Press [MESSAGE], to send the TXT or PIX Meg.
Displays information about the 90 most recently received calls.
Place a call to a received call by simply pressing .
RECEIVED
1
To see a list of the 90 most recently received
calls, press [MENU], then select “Recent
Calls” menu, press “Received”. If the
number is already stored in your phone book,
only the name appears. If the number is not
stored, only the phone number appears.
2
To view received call details, press [OPEN].
3
Save : To store the phone number in your phone book.
Details : To view the caller’s information.
Erase : To erase a received calls list.
Lock/Unlock : To lock or unlock received calls list.
Erase All : To erase all received calls list.
View Timers : To display usage time.
l
l
l
l
l
l
Press [OPTIONS] and select “Save” to
save it or select “Erase” to delete it.
![](/img.php?id=633496&img=bg2f.png)
C
H
4
46
RECENT CALLS
Call details include type of call, date, time and phone number.
• After 90 dialed calls, the oldest call will automatically
be erased from the history.
• Press [MESSAGE], to send the TXT or PIX Meg.
Displays information about the 90 most recently dialed numbers.
Place a call to a dialed call by simply pressing .
DIALED
1
To see a list of the 90 most recently dialed
numbers, press [MENU], then select
“Recent Calls” menu, press “Dialed”.
If the number is already stored in your phone
book, only the name appears. If the number is
not stored, only the phone number appears.
2
To view dialed call details, press [OPEN].
3
Save : To store the phone number in your phone book.
Details : To view the caller’s information.
Erase : To erase a dialed calls list.
Lock/Unlock : To lock or unlock dialed calls list.
Erase All : To erase all dialed calls list.
View Timers : To display usage time.
l
l
l
l
l
l
Press [OPTIONS] and select “Save” to
save it or select “Erase” to delete it.
![](/img.php?id=633496&img=bg30.png)
C
H
4
47
RECENT CALLS
Call details include type of call, date, time and phone number.
• After the 270 received, dialed or missed calls, the oldest
call will automatically be erased from the history.
• Press [MESSAGE], to send the TXT or PIX Meg.
Displays information about the most recent received, dialed and
missed calls.
ALL
1
To see a list of the 270 most recent received,
dialed and missed calls, press [MENU],
then select “Recent Calls” menu, press “All”.
If the number is already stored in your phone
book, only the name appears. If the number is not
stored, only the phone number appears.
2
3
To view details, press [OPEN].
Save : To store the phone number in your phone book.
Details : To view the caller’s information.
Erase : To erase a recent calls list.
Lock/Unlock : To lock or unlock recent calls list.
Erase All : To erase all recent calls list.
View Timers : To display usage time.
l
l
l
l
l
l
Press [OPTIONS] and select “Save” to
save it or select “Erase” to delete it.
![](/img.php?id=633496&img=bg31.png)
48
C
H
4
RECENT CALLS
Checks the usage time and manages your calls within the limit you
set. The 11 timers include (Last Call, All Calls, Received Calls,
Dialed Calls, Roaming Calls, Transmit KB, Received KB, Total KB,
Last Reset, Lifetime Calls, Lifetime Data Count):
VIEW TIMERS
Press [MENU], then select “Recent Calls”
menu, press “View Timers”.
To reset the timer, press [RESET],
then select “Yes”, press .
To reset all timer, press [RESET ALL],
then select “Yes”, press .
To return to the previous page, press .
1
2
3
![](/img.php?id=633496&img=bg32.png)
C
H
4
49
SETTINGS
Controls the Ringer volume and alerts you to incoming calls in the
modes listed in the gray box below.
Customizes your phone and optimizes performance through a variety
of settings.
SOUNDS SETTINGS
MASTER VOLUME
2
Select one of the following options by pressing
the Navigation Key to the right.
3
Select one of the available ring types.
To confirm, press .
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Master Volume”.
Low, Medium Low, Medium, Medium High, High.
Vibrate Only
Alarm Only
All Sounds Off
Press to play sound.
![](/img.php?id=633496&img=bg33.png)
C
H
4
50
SETTINGS
50
To select a ringer type for incoming calls:
CALL SOUNDS
2
Select your desired ringer type.
3
Select one of the available ring types.
To confirm, press .
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Call Sounds”, press “Call Ringtone”.
Up or Down key : 1. Get New or select your desired ringer type.
Press Play/Stop to Play/Stop the ringer.
CALL RINGTONE
2
Select “On” or “Off” with the Navigation Key then
press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Call Sounds”, press “Call Vibrate”.
CALL VIBRATE
![](/img.php?id=633496&img=bg34.png)
C
H
4
51
SETTINGS
When selected, this setting alerts you to the following handset changes:
ALERT SOUNDS
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Alert Sounds”, press “TXT Message”.
TXT MESSAGE
2
Select “Tone”, “Vibrate” or “Reminder” with the
Navigation Key then select one of the following
options by pressing the Navigation Key.
Tone : 1. Get New or select your desired ringer type.
Vibrate : Select “On” or “Off”.
Reminder : Select “Once”, “Every 2 Minutes”,
“Every 15 Minutes” or “Off”.
3
To save, press .
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Alert Sounds”, press “PIX Message”.
PIX MESSAGE
2
Select “Tone”, “Vibrate” or “Reminder” with the
Navigation Key then select one of the following
options by pressing the Navigation Key.
Tone : 1. Get New or select your desired ringer type.
Vibrate : Select “On” or “Off”.
Reminder : Select “Once”, “Every 2 Minutes”,
“Every 15 Minutes” or “Off”.
3
To save, press .
![](/img.php?id=633496&img=bg35.png)
C
H
4
52
SETTINGS
52
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Alert Sounds”, press “Voicemail Msg”.
VOICEMAIL MSG
2
Select “Tone”, “Vibrate” or “Reminder” with the
Navigation Key then select one of the following
options by pressing the Navigation Key.
Tone : 1. Get New or select your desired ringer type.
Vibrate : Select “On” or “Off”.
Reminder : Select “Once”, “Every 2 Minutes”,
“Every 15 Minutes” or “Off”.
3
To save, press .
![](/img.php?id=633496&img=bg36.png)
C
H
4
53
SETTINGS
To adjust key pad tone:
KEYPAD VOLUME
2
Select one of the following options by pressing
the Navigation Key to the right.
3
Select one of the available ring types.
To confirm, press .
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Keypad Volume”.
Low, Medium Low, Medium, Medium High, High
Off
To adjust earpiece volume:
EARPIECE VOLUME
2
Select one of the following options by pressing
the Navigation Key to the right.
3
Select one of the available ring types.
To confirm, press .
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Earpiece Volume”.
Low, Medium Low, Medium, Medium High, High
![](/img.php?id=633496&img=bg37.png)
SETTINGS
C
H
4
54
SERVICE ALERTS
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Service Alerts”, press “ERI”.
ERI (Enhanced Roaming Indicator)
2
Select “On” or “Off” with the Navigation Key then
press to save it.
Sounds an alert every minute during a call.
The Enhanced Roaming Indicator (ERI) feature displays a text banner
on the display screen informing the handset user of which systems the
wireless device is using as compared to the service plan they
purchased. The ERI Banner text changes to tell a customer if they are
using the: “Verizon Network”, “Extended Network” or “Roaming”.
Using a Personal Message Banner may prevent the ERI from displaying
on the phone.
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Service Alerts”, press “Minute Beep”.
MINUTE BEEP
2
Select “On” or “Off” with the Navigation Key then
press to save it.
Notifies you that a call has been successfully placed.
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” then select
“Service Alerts”, press “Call Connect”.
CALL CONNECT
2
Select “On” or “Off” with the Navigation Key then
press to save it.
Display -> Banner -> ERI Banner must be set for “ON” for
smooth operation of all the functions.
![](/img.php?id=633496&img=bg38.png)
SETTINGS
C
H
4
55
Allows you to activate/deactivate the power on tones.
POWER ON/OFF
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” and then
select “Power On/Off”, press “Power On”.
POWER ON
2
Select “On” or “Off” with the Navigation Key and
then press to save it.
Allows you to activate/deactivate the power off tones.
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” and then
select “Power On/Off”, press “Power Off”.
POWER OFF
2
Select “On” or “Off” with the Navigation Key and
then press to save it.
![](/img.php?id=633496&img=bg39.png)
SETTINGS
C
H
4
56
To select a ringer type for alarm sound:
ALARM SOUNDS
2
Select your desired ringer type.
3
Select one of the available ring types.
To confirm, press .
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” and then
select “Alarm Sounds”, press “Alarm Tone”.
ALARM TONE
2
Select “On” or “Off” with the Navigation Key and
then press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Sounds Settings” and then
select “Alarm Sounds”, press “Alarm
Vibrate”.
ALARM VIBRATE
Up or Down key : 1. Get New or select your desired ringer type.
Press Play/Stop to Play/Stop the ringer.
![](/img.php?id=633496&img=bg3a.png)
SETTINGS
C
H
4
57
Allows you to customize the display.
DISPLAY SETTINGS
You can choose to display a personal Banner greeting or the
Enhanced Roaming Indicator (ERI) banner on the phone’s screens:
The text greeting can be up to 16 characters and is displayed on
your phone’s screen in standby mode.
BANNER
2
Enter a new personal greeting.
To change the input mode, press [Abc].
3
Press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Display Settings” then select
“Banner”, press “Personal”.
PERSONAL
2
Select “On” or “Off” with the Navigation Key then
press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Display Settings” then select
“Banner”, press “ERI Banner”.
ERI BANNER
![](/img.php?id=633496&img=bg3b.png)
SETTINGS
C
H
4
58
Backlights the display and key pad and activates dimming for easy
viewing in dark places.
BACKLIGHT
2
Select one of the following options with the
Navigation Key.
3
Press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Display Settings” then select
“Backlight”, press “Display Settings”.
DISPLAY SETTINGS
Every 7 Seconds, 15 Seconds, 30 Seconds, Always On,
Always Off
Every 7 Seconds, 15 Seconds, 30 Seconds, Always On,
Always Off
2
Select one of the following options with the
Navigation Key.
3
Press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Display Settings” then select
“Backlight”, press “Keypad”.
KEYPAD
![](/img.php?id=633496&img=bg3c.png)
SETTINGS
C
H
4
59
To adjust the display contrast:
CONTRAST
3
Press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Display Settings” then
select “Contrast”.
2
Select “Main LCD” or “Sub LCD” then select one
of the following options with the Navigation Key.
Level 1 ~ Level 5
WALLPAPER
1
Press [MENU], then select “Settings & Tools”
menu, press “Display Settings” then
select “Wallpaper”.
2
Select Default to choose a pre-installed display,
Downloads or PIX # to choose a display you
have downloaded to your phone.
To launch “Get It Now”, press [GET NEW].
To expand selected image, press [VIEW].
3
Select a display from the Animation and the
Graphic list using the Navigation Key and
press to save it.
![](/img.php?id=633496&img=bg3d.png)
SETTINGS
C
H
4
60
DISPLAY THEMES
3
Press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Display Settings” then
select “Display Themes”.
2
Select one of the following options with the
Navigation Key.
SCREENSAVER
1
Press [MENU], then select “Settings & Tools”
menu, press “Display Settings” then
select “Screensaver”.
2
Select Default to choose a pre-installed display,
Downloads or PIX # to choose a display you
have downloaded to your phone.
To launch “Get It Now”, press [GET NEW].
To expand selected image, press [VIEW].
3
Select a display from the Animation and the
Graphic list using the Navigation Key and
press to save it.
Original
Business
Tropical
Blue
l
l
l
l
![](/img.php?id=633496&img=bg3e.png)
SETTINGS
C
H
4
61
CLOCK FORMAT
DIAL FONTS
1
Press [MENU], then select “Settings & Tools”
menu, press “Display Settings” then select
“Dial Fonts”.
2
Select “Normal” or “Large” with the Navigation
Key then press to save it.
3
Press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Display Settings” then
select “Clock Format”.
2
Select “Main Clock” or “Front Clock” then select
one of the following options with the Navigation
Key.
To change the main or front clock’s appearance on the standby screen:
Digital
Analog
Off
l
l
l
![](/img.php?id=633496&img=bg3f.png)
SETTINGS
C
H
4
62
PHONE SETTINGS
STANDALONE MODE
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Settings” then select
“Standalone Mode”.
2
Select “On” or “Off” with the Navigation Key then
press to save it.
Your phone offers you the option of assigning a shortcut key
(Up, Down, Left, Right Navigation Key) to a favorite or often-used
function. To assign a shortcut to the key:
SET SHORTCUT KEY
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Settings” then select
“Set Shortcut Key”.
4
Press to save it.
5
To reset all already set shortcut key, press
“Reset All”, then select “Yes”, press .
3
Select one of the following options with the
Navigation Key.
2
Select “Left Key”, “Up Key”,
“Right Key” or “Down Key”.
Get Yunes & Tones/Get Pix/Get Fun & Games/Get News & Info/
My Pix/My Ringtones/My Sounds/Inbox/Email/Chat/IM/
Settings & Tools/Alarm Clock/Calculator/Calendar
![](/img.php?id=633496&img=bg40.png)
SETTINGS
C
H
4
63
Selects the language in which letters are displayed on the screen.
LANGUAGE
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Settings” then select
“Language”.
3
Press to save it.
2
Select “English” or “Spanish” with the Navigation
Key.
4
Press to save it.
Device : Lock, Unlock, On Power Up
Location : Location On, E911 Only
Prevents unauthorized use of your phone. The following settings can
be restricted:
Prevents the phone from being used without entering the password first.
SECURITY
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Settings” then select
“Security”, then enter your password,
press .
3
Select “Device” or “Location” then select one of
the following options with the Navigation Key.
2
Select “Lock Mode”.
LOCK MODE
The default password is the last 4 digits of your phone number.
![](/img.php?id=633496&img=bg41.png)
SETTINGS
C
H
4
64
Selects the Preferred System.
SYSTEM SELECT
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Settings” then select
“System Select”.
3
Press to save it.
2
Select one of the following options with the
Navigation Key.
Automatic B
Automatic A
Home Only
3
Enter a “New Code” then press .
4
Enter a “Confirm Code” then press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Settings” then select
“Security”, then enter your password,
press .
2
Select “Edit Code”.
EDIT CODE
The default password is the last 4 digits of your phone number.
Changes your Device/Location 4-digit password.
![](/img.php?id=633496&img=bg42.png)
SETTINGS
C
H
4
65
Enables Auto NAM (Number Assignment Modules) or manually
selects a NAM.
NAM SELECTION
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Settings” then select
“NAM Selection”, press “Auto NAM”.
3
Press to save it.
2
Select one of the following options with the
Navigation Key.
NAM 1 - VERIZON
NAM 2 - VERIZON
Automatically switches phone to proper NAM when you have multiple
NAM registrations.
AUTO NAM
2
Select “On” or “Off” with the Navigation Key then
press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Settings” then select
“NAM Selection”, press “Change NAM”.
Changes the NAM used by the phone when you have multiple
registrations.
CHANGE NAM
![](/img.php?id=633496&img=bg43.png)
SETTINGS
C
H
4
66
CALL SETTINGS
ANSWER OPTIONS
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“Answer Options”.
2
Select one of the following with the Navigation Key.
3
To save, press .
To select an answer mode:
Flip Open
Any Key
Send Only
Auto Answer
![](/img.php?id=633496&img=bg44.png)
SETTINGS
C
H
4
67
Off
Every 3 Seconds
Every 5 Seconds
Every 7 Seconds
Every 10 Seconds
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“Auto Retry”.
Automatically redials a call up to 5 times after a set time interval.
2
Press the Navigation Key up or down to choose
the amount of time.
3
To save, press .
AUTO RETRY
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“TTY Mode”.
Your phone is able to operate with a TTY (Teletypewriter) digital
modes. This feature is system dependent and may not be available
in all areas.
3
To save, press .
TTY MODE
2
Select one of the following with the Navigation Key.
TTY Full
TTY + TALK
TTY + HEAR
TTY Off
l
l
l
l
l
l
l
l
l
![](/img.php?id=633496&img=bg45.png)
C
H
4
68
SETTINGS
Enhances voice privacy and avoids tapping during a call.
On : Makes it more difficult to wire tap.
l
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“One Touch Dial”.
ONE TOUCH DIAL
2
Select “On” or “Off” with the Navigation Key then
press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“Voice Privacy”.
VOICE PRIVACY
2
Select “On” or “Off” with the Navigation Key,
then press to save it.
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“Data Setting”.
Choose the connection mode for the usage of your phone.
3
To save, press .
DATA SETTING
2
Select one of the following connection modes
with the Navigation Key.
Voice Call : To receive a voice call.
Data Only : To receive data when connected to PC.
l
l
![](/img.php?id=633496&img=bg46.png)
C
H
4
69
SETTINGS
VOICE SERVICES
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“Voice Services”, press “Voice Dial”.
Voice Dial allows you to call a person by simply saying their name.
To access Voice Dial:
2.1. Press [NEW]. The phone book list will be
displayed alphabetically. Select a name then
press . Instructions (Press OK and say
name) will be displayed and .
You will hear “Name Please”.
2.2. Say the name for the voice tag and repeat the
name when prompted. You will hear “Added”.
To play a voice dial:
Highlight the voice tag you want to play then
press [PLAY].
To detail a voice dial:
Highlight the voice tag you want to detail view
then press [OPTIONS] then select “Detail”.
To re-record a voice dial:
Highlight the voice tag you want to re-record then
press [OPTIONS] then select “Re-record”.
To erase a voice dial entry or all voice dial entries:
Highlight the voice tag that you want to erase,
press [OPTIONS] then select “Erase” for a
single entry or “Erase All” to erase all voice tags.
To play back a voice dial entry through the speaker:
Highlight the voice tag you want to play, press
[OPTIONS] then select “Play Speaker”.
VOICE DIAL
2
3
4
5
6
7
![](/img.php?id=633496&img=bg47.png)
C
H
4
70
SETTINGS
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“Voice Services”, press “Voice Memo”.
VOICE MEMO
2
To record a voice memo, select “Record New”,
press .
3
To start recording a voice memo, instructions
(Press OK to start recording) will be displayed
and .
Voice Memo allows you to record a reminder message that can be up
to 60 seconds. To record a memo:
4
To stop recording a voice memo, press [OK].
Stopping the recording will automatically save
the entry. The list is sorted by dates with the
most recent file on the top of the voice memo list.
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“Voice Services”, press “Voice Setting”.
VOICE SETTING
2
Under “Set Active”, select a option “Off”,
“Send Key” or “Active Flip”.
3
Under “HFK Mode”, select a option “On” or “Off”.
After turning on Set Active, open the flip to go on to VR mode. After
turning on HFK mode, put Hands-free kit and say “wake up” to go on
to VR mode.
4
To save, press .
![](/img.php?id=633496&img=bg48.png)
C
H
4
71
SETTINGS
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“Voice Services”, press “Train Word”.
TRAIN WORD
2
Select one of the control words - “Yes”, “No” or
“Wake-Up”. “Please begin recording after the
prompt tone” will be displayed and you will hear
“Now training control words. Please say the word”.
Say the word. You will hear “Again”. Say the word
again. You will hear “Training word successful”.
To undo voice recognition, select a word you want
to undo then press [UNDO].
3
Under “Undo Train All”.
“Undo voice recognition for all procedures?”
will be displayed. Press to undo all trained
words.
Train allows you to use Control words to make a call without using
the keypad. Use to train or untrain the Voice Recognition with the
control word, “Yes”, “No” or “Wake-Up”.
5
To play voice memo, select the voice tag you
want to play then press [PLAY].
To send voice memo, select the voice tag you
want to send then press [SEND] to access
the “New PIX Msg” see “Send New PIX
Message” on page 98.
If saved voice memo, press [OPTIONS] to
select one of the following options:
lRename
lErase
lErase All
![](/img.php?id=633496&img=bg49.png)
C
H
4
72
SETTINGS
1
Press [MENU], then select “Settings & Tools”
menu, press “Call Settings” then select
“DTMF Tones”.
3
To save, press .
DTMF TONES
2
Select one of the following with the Navigation Key.
Normal
Long
l
l
To adjust tone length:
![](/img.php?id=633496&img=bg4a.png)
C
H
4
73
SETTINGS
MEMORY
1
Press [MENU], then select “Settings & Tools”
menu, press “Memory” then select
“Memory Usage”.
3
To return to the previous page, press .
MEMORY USAGE
3
To return to the previous page, press .
2
You should see the “Total Used” memory size
and “Available” memory size.
1
Press [MENU], then select “Settings & Tools”
menu, press “Memory” then select
“My PIX”.
MY PIX
2
You should see the download picture’s memory
size.
3
To return to the previous page, press .
1
Press [MENU], then select “Settings & Tools”
menu, press “Memory” then select
“My Sounds”.
MY SOUNDS
2
You should see the download sounds memory
size.
![](/img.php?id=633496&img=bg4b.png)
SETTINGS
C
H
4
74
PHONE INFO
Displays information about your phone:
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Info” then select
“My Number”.
Displays your phone number (MDN/MIN number and provider) :
3
To return to the previous page, press .
3
To return to the previous page, press .
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Info” then select
“SW Version”.
Displays the (Software/PRL/ERI/Browser/Get It Now) version.
2
You should see the version of software and
others.
2
You should see the MDN/MIN number and
service provider name.
MY NUMBER
SW VERSION
![](/img.php?id=633496&img=bg4c.png)
SETTINGS
C
H
4
75
2
You should see a list of the Indicator Icons of
your cellular telephone with a short label or
description.
3
To return to the previous page, press .
1
Press [MENU], then select “Settings & Tools”
menu, press “Phone Info” then select
“Icon Glossary”.
Displays the Indicator Icons of your cellular telephone.
ICON GLOSSARY
![](/img.php?id=633496&img=bg4d.png)
C
H
4
76
TOOLS
CALENDAR
ADD NEW
Sets an event and reminds you of that event.
2
3
Move the Navigation Key left, right, up or down to
choose a date in the calendar then press .
Press [OPTIONS] to 1. New, 2. Go To Date,
3. Erase Passed or 4. Erase All.
Press [MONTHLY/WEEKLY] to exchange
display mode.
Use the keypad to set a start time and to
select “am” or “pm”.
START TIME
Use the keypad to enter an appointment to your
schedule.
APPOINTMENT
Use the keypad to change or enter the start date.
START DATE
Use the Navigation Key to select a setting for the
repeating the calendar item. (Daily, Weekly,
Monthly or Yearly).
RECURRENCE
Press [OPTIONS] to select “New”,
appointment field is highlighted. Press the
Navigation Key down to set the alarm options.
Use the keypad to set an end time and to
select “am” or “pm”.
END TIME
1
Press [MENU], then select “Settings & Tools”
menu, press “Tools” then select
“Calendar”.
![](/img.php?id=633496&img=bg4e.png)
C
H
4
77
TOOLS
Use the keypad to change or enter the end date.
END DATE
Use the keypad to enter the number of times you
want an event to reoccur.
BY COUNT
Use the Navigation Key to select a time zone,
press [SET]. (OFF, EST, EDT, CST, CDT,
MST, MDT, PST, PDT, AKST, AKDT, HAST,
HADT or GMT/UTC).
TIME ZONES
Use the keypad to select the alert tone you wish
to set.
ALERT
Use the Navigation Key to select vibrate On/Off.
VIBRATE
Use the Navigation Key to select an alert time
interval option (0 Minutes, 5 Minutes, 10 Minutes,
15 Minutes).
REMINDER
4
Press [SAVE] to save it or [CLR] to
return to the calendar.
5
The date of the event will be marked on your
calendar.
1
To view the Calendar List.
VIEW PLAN LIST
2
Move the Navigation Key to choose an event then
press , press [VIEW].
Press [ERASE], then select “Yes”, press .
![](/img.php?id=633496&img=bg4f.png)
C
H
4
78
TOOLS
ALARM CLOCK
Select one of the entries using the Navigation Key.
To set a new alarm, choose alarm 1, 2 or 3.
To edit an existing alarm, select that alarm.
Press .
2
1
The setting field will be highlighted. Press the
Navigation Key down to select alarm options.
3
Use the Navigation Key to select a setting for the
alarm (Once, Daily, Mon - Fri, Weekends).
FREQUENCY
Press [MENU], then select “Settings & Tools”
menu, press “Tools” then select
“Alarm Clock”.
Use the Navigation Key to select alarm on/off.
ALARM
Use the keypad to set a time for the alarm and
to select “am” or “pm”.
TIME
Use the keypad to select the alert tone you wish
to set.
RINGER
To save an alarm setting press [SAVE].
4
![](/img.php?id=633496&img=bg50.png)
C
H
4
79
TOOLS
To display the time and date in pre-programmed cities:
WORLD CLOCK
2
4
Select a city with the [CITIES].
Or use the Navigation Key to select another city.
3
The world map appears with the city, its date
and time.
Use the Navigation Key to select another city.
Pressing [DST], turns all cities supporting Daylight Savings
Time on or off.
To return to the previous page, press .
1
Press [MENU], then select “Settings & Tools”
menu, press “Tools” then select
“World Clock”.
![](/img.php?id=633496&img=bg51.png)
C
H
4
80
TOOLS
Your phone includes an internal notepad that can be used to
compose and store reminders and notes.
NOTEPAD
1
Press [MENU], then select “Settings & Tools”
menu, press “Tools” then select
“Notepad”.
ADD MEMO
2
To add a new memo, press [NEW].
Input a new text memo.
(Please refer to page 31 for more details on entering
letters, numbers & symbols.)
1
VIEW MEMO
2
The list of all memos, in saved order, is displayed.
Select a memo then press [VIEW].
3
4
The selected memo will appear.
To edit it, press [EDIT] and input a new text
memo, then press [SAVE] to save it.
To compose a memo (there is an 80-letter limit):
To view a saved memo:
Press [MENU], then select “Settings & Tools”
menu, press “Tools” then select “Notepad”.
4.2. To erase a memo, press [OPTIONS]
“Erase”.
4.1. To add a new memo, press [NEW].
4.3. To erase all memos, press [OPTIONS]
“Erase All”.
3
To save memo, press [SAVE].
![](/img.php?id=633496&img=bg52.png)
C
H
4
81
TOOLS
2
Follow the instructions below to calculate
8*6Ö4-2.5= 9.50
3
To reset, press [CLEAR].
To access the calculator:
CALCULATOR
Input 8.
Move the Navigation Key to the right.
Input 6 then press the Navigation Key.
Move it left.
Input 4 then press the Navigation Key.
Move it downward.
Input 2 then press the to input (.).
Press 5.
Then press and you will see the answer.
: X, : -, : /, : +, : ., : Clear, : =.
1
Press [MENU], then select “Settings & Tools”
menu, press “Tools” then select
“Calculator”.
• To change the displayed number from positive (+) to negative (-)
and vice versa, press [ע].
• If user press [OPERATOR], you can insert parenthesis [( )]
or power [^] functions into the equation.
![](/img.php?id=633496&img=bg53.png)
C
H
4
82
TOOLS
2
1
3
Simultaneously times up to six different events. To operate the
stop watch:
STOP WATCH
To measure a time period.
1. To start the stop watch, press [START].
2. To pause it, press [STOP].
3. To resume it, press [START].
To reset it, press [RESET].
To time up to six events at once:
1. To start, press [START].
2. To stop a time period and continue
measuring another one, press [CONT].
3. To stop the second and continue measuring
a third one, press [CONT].
4. To measure up to six time periods, repeat the
above steps.
5. To stop the stop watch, press [STOP].
6. To review the results, press [VIEW].
7. To return to the stop watch, press .
8. To reset it, press [RESET].
Press [MENU], then select “Settings & Tools”
menu, press “Tools” then select
“Stop Watch”.
![](/img.php?id=633496&img=bg54.png)
C
H
4
83
MY ACCOUNT
MY ACCOUNT
1
2
Press [MENU], then select “Settings & Tools”
menu, press “My Account”.
Connect “WAP Browser”.
![](/img.php?id=633496&img=bg55.png)
84
MEMO
C
H
4
![](/img.php?id=633496&img=bg56.png)
GET IT NOW
Your phone provides a unique feature -Get It Now- that enables you
to download ringtones, wallpapers, games and more from your
network to your phone. Please contact your service provider for the
availability of these services.
GET IT NOW
Chapter 5
85
C
H
5
85
![](/img.php?id=633496&img=bg57.png)
C
H
5
86
GET IT NOW
GET TUNES & TONES
GET NEW RINGTONES
1
Press [MENU], then select “Get It Now”
menu, then press “Get Tunes & Tones” then
select “Get New Ringtones” then select
“Get New”. (Get It Now will launch and take you
to the download menu.)
3
Use your navigation key to select “Ringtones”
you wish to download, press .
2
Use your navigation key to select a provider’s
browser, press .
RECORDING NEW TONES
1
Press [MENU], then select “Get It Now”
menu, then press “Get Tunes & Tones”,
select “My Sounds” then select
“Record New”.
3
To stop recording a memo, press [STOP].
2
To record a voice memo, press .
Instructions (Please OK to start recording) will be
displayed and and you will hear “Beep
Sound”.
![](/img.php?id=633496&img=bg58.png)
C
H
5
87
GET IT NOW
MY RINGTONES
1
Press [MENU], then select “Get It Now” menu,
then press “Get Tunes & Tones” then
press “My Ringtones”.
2
To play downloaded ringtones.
Select the tunes or tones you want to play, then
press [PLAY].
3
To assign downloaded ringtones.
Select the Ringtone you want to assign, then
press [SET AS]. Select “Ringtone”,
“Contact ID” or “Alert Tone”, then press .
4
To erase downloaded ringtones.
Select the Ringtone you want to erase,
then press [OPTIONS].
Select “Erase”, “Rename” or “Ringtone Info”,
then press .
By pressing [OPTIONS], you can choose from the following:
1. Erase
2. Rename
3. Ringtone Info
l
By pressing [SET AS], you can choose from the following:
1. Ringtone
2. Contact ID
3. Alert Tone - 1. All Msg
2. TXT Msg
3. PIX Msg
4. Voicemail Msg
l
![](/img.php?id=633496&img=bg59.png)
C
H
5
88
GET IT NOW
MY SOUNDS
1
Press [MENU], then select “Get It Now” menu,
then press “Get Tunes & Tones” then
press “My Sounds”.
2
To play downloaded sounds.
Select the sound you want to play, then
press [PLAY].
3
To erase downloaded sounds.
Select the sound you want to erase,
then press [OPTIONS].
Select “To PIX Place”, “Lock”, “Erase”,
“Erase All”, “Rename” or “Sound Info”,
then press .
By pressing [OPTIONS], you can choose from the following:
1. To PIX Place
2. Lock
3. Erase
4. Erase All
5. Rename
6. Sound Info
l
4
To send the PIX message, press [SEND].
Please refer to page 98 for more details on
“Send New PIX Message”.
![](/img.php?id=633496&img=bg5a.png)
C
H
5
89
GET IT NOW
GET PIX
DOWNLOADING NEW PIX
1
Press [MENU], then select “Get It Now” menu,
then press “Get PIX”, then select “Get
New PIX”, then select “Get New”. (Get It Now will
launch and take you to the download menu.)
3
Use your navigation key to select a “PIX or FLIX”
you wish to download, press .
2
Use your navigation key to select a provider’s
browser, press .
MY PIX
3
Select picture with the Navigation Key, then
press [VIEW]. You can see detail picture.
2
In Review Mode, you can view all the pictures
you have stored in your phone.
In Review Mode you can view all the pictures you have taken, store
selected images in your phone, send pictures to the Online Album,
delete images and access additional picture options.
1
Press [MENU], then select “Get It Now” menu,
then press “Get PIX”, then select
“My PIX”.
![](/img.php?id=633496&img=bg5b.png)
C
H
5
90
GET IT NOW
PIX PLACE
2
Connect “Mobile Web” launches and connects
you to “PIX Place”.
1
Press [MENU], then select “Get It Now” menu,
then press “Get PIX”, then select “PIX
Place”.
In detail view, user can view previous or next picture by
pressing left or right navigation key.
By pressing [OPTIONS], you can choose from the following:
DOWNLOADED or TAKEN PIX :
1. Send: To send a picture message.
2. To PIX Place: To upload the selected picture to a PIX server.
3. Get New: To download a “New PIX” through “Get It Now”.
4. Set As: Assigns the selected PIX to display for specific tasks.
(Wallpaper/Screensaver/Picture ID).
5. Rename: To edit the picture’s title.
6. Lock/Unlock: To select “Lock” or “Unlock”.
7. Erase: Erase the current picture from your phone.
8. Erase All: To erase all the pictures in your phone.
9. PIX Info: Displays information on the selected picture,
such as File Name, Date, Time, Res and Size.
PRELOADED PIX :
1. Get New: To download a “New PIX” through the “Get It Now”.
2. Set As: Assigns the selected PIX to display for specific tasks.
(Wallpaper/Screensaver/Picture ID).
3. Erase All: To erase all the pictures in your phone.
4. PIX Info: Displays information on the selected picture,
such as File Name, Date, Time, Res and Size.
Press [CAMERA] to return to Camera mode to take
another picture.
![](/img.php?id=633496&img=bg5c.png)
C
H
5
91
GET IT NOW
TAKE PIX
1
Press [MENU], then select “Get It Now” menu,
then press “Get PIX”, then select “Take
PIX”. Or press or .
3
Press side camera key or press to take the
picture.
2
Point the camera lens at your subject. You can
check the picture framing through the main
display screen.
Press [My PIX], you can view the captured pictures.
By pressing [OPTIONS], you can choose from the following:
1. Resolution: To select a resolution for a picture.
(480x640/240x320/120x160)
2. Self Timer: To activate the camera’s timer function.
(Off/3 Seconds/5 Seconds/10 Seconds)
3. Flash: To activate the flash function. (Off/On/Auto Flash/
Only This Shot)
4. Brightness: To brightness up & down ( -2, -1, 0, +1, +2).
5. White Balance: To select white balance. (Auto/Sunny/
Cloudy/Tungsten/Fluorescent/Darkness)
6. Shutter Sound: To select a shutter sound. (Shutter/Silent/
Say “Cheez”/Ready! 123)
7. Color Effects: To select a color effects. (Normal/Antique/
Black & White/Negative)
8. Sub LCD: To take a picture using the Sub LCD.
By pressing [OPTIONS], you can choose
Sub LCD options: 1. Main LCD / 2. Self Timer /
3. Flash / 4. Shutter Sound
User can control zoom directly by pressing up and down
navigation key.
Navigation Left / Right: Zoom up & down.
![](/img.php?id=633496&img=bg5d.png)
C
H
5
92
GET IT NOW
4
The picture taken should be displayed.
To save the picture, press [SAVE].
To go back to idle mode without saving the
picture, press .
To take another picture without saving the picture
you just took, press [ERASE].
To send the picture to someone, press [SEND].
Please refer to page 98 for more details on
“Send New PIX Message”.
![](/img.php?id=633496&img=bg5e.png)
C
H
5
93
GET IT NOW
GET FUN & GAMES
DOWNLOADING NEW FUN & GAMES
1
Press [MENU], then select “Get It Now”,
then press “Get Fun & Games” then
select “Get New”. (Get It Now will launch and
take you to the download menu.)
3
Use your navigation key to select a game you
wish to download, press .
2
Use your navigation key to select a provider’s
browser, press .
PLAYING DOWNLOADED FUN & GAMES
1
Press [MENU], then select “Get It Now”,
then press “Get Fun & Games”.
2
To play downloaded games.
Select the game you want to play, then
press [PLAY].
3
Selected “Mobile Web” game will launch.
4
To save a downloaded fun or games to the “Get
Fun & Games” list and to sort by alphabet order.
![](/img.php?id=633496&img=bg5f.png)
94
GET IT NOW
C
H
5
GET GOING
CONNECTING GET GOING
1
Press [MENU], then select “Get It Now”
menu, then press “Get Going” then
select “Get New”.
2
“Get It Now” service will launch.
GET IT NOW INFO
Press [MENU], then select “Get It Now”
menu, then press “Info”.
Select one of the following options with the
Navigation Key.
To return to the previous page, press .
GET NEWS & INFO
CONNECTING NEWS & INFO
1
Press [MENU], then select “Get It Now”
menu, then press “Get News & Info”.
2
Connect “Mobile Web”.
1
Displays information about “App. Memory”, “Content Memory”,
View Log” and “Help”:
2
3
lApp. Memory
lContent Memory
lView Log
lHelp
![](/img.php?id=633496&img=bg60.png)
VOICE MAIL, TXT, PIX
MESSAGING
This chapter addresses Voice Mail, TXT, PIX Messaging functions
including:
WHEN A NEW MESSAGE ARRIVES
VOICE MAIL
NEW MSG
INBOX
SENT
DRAFTS
E- MAIL
MOBILE IM
CHAT
ERASE ALL
SETTINGS
Chapter 6
95
C
H
6
95
![](/img.php?id=633496&img=bg61.png)
Displays the number of voice mails and accesses them by pressing .
VOICE MAIL
C
H
6
96
WHEN A NEW MESSAGE ARRIVES
1
The following display appears
when a new message arrives.
2
To display the message,
select “View Now”, then
press .
FIRST TIME USER
1
Dial *86 then press [SEND].
2
At the recording, press .
3
To set up your account follow the voice tutorial.
EXISTING USER
1
Dial *86 then press [SEND].
2
At the recording, enter your 4 digits password,
then press .
3
To listen to new messages, press .
1
Press [MENU], then select “Messaging”
menu, press “Voice Mail” or press
[MESSAGES], press “Voice Mail”.
![](/img.php?id=633496&img=bg62.png)
NEW MSG
1
Press [MESSAGE], press “New Msg”,
then press “TXT Msg”.
2
To send a message to a single address, under
“To:” input the phone number manually and
press the down key to move to the message
field OR select from numbers stored in your
phone book by pressing [ADD] to choose
from the following:
1. Contacts : Search the phone numbers stored in the contacts
list to add a phone number to the TXT message.
2. Groups : Search the groups stored in the contacts list.
3. Recent Calls : Search the phone numbers stored in the
recent calls list to add a number to the TXT
message.
4. Graphics : Inserts simple graphic image in TXT Msg.
5. Sound : Inserts a sound in the TXT Msg.
6. Quick Text : Inserts common phrases in a TXT Msg.
3
To send a message to multiple addresses,
manually enter a number then add a space or
comma before entering the next number OR
select from numbers stored in your phone book
by pressing [ADD] to choose from the
following:
1. Contacts : Search the phone numbers stored in the contacts
list to add a phone number to the TXT message.
2. Groups : Search the groups stored in the contacts list.
3. Recent Calls : Search the phone numbers stored in the
recent calls list to add a number to the TXT
message.
4. Graphics : Inserts simple graphic image in TXT Msg.
5. Sound : Inserts a sound in the TXT Msg.
6. Quick Text : Inserts common phrases in a TXT Msg.
You may enter up to 10 contacts.
SEND NEW TXT MESSAGE
C
H
6
97
![](/img.php?id=633496&img=bg63.png)
NEW MSG
C
H
6
98
2
Under “To”, input the phone number and
press .
3
Under “Text”, input a new TXT Message then
press .
By pressing [ADD], you can choose from the following:
1. Contacts : Search the phone number which is stored in
the contacts list.
2. Groups : Search the group which is stored in the contacts
list.
3. Recent Calls : Search the phone number which is stored in
the recent calls list.
4. To PIX Place : To send pictures by using online Address.
By pressing [OPTIONS].
Add Quick Text : Inserts already written sentences in TXT Msg.
(Please refer to page 31 for more details on entering letters,
numbers and symbols. Max 1000 characters support.)
(Please refer to page 31 for more details on entering letters,
numbers and symbols.)
You may enter up to 10 contacts.
If anything has been entered in the TXT msg field and you exit the
message, the input will be saved in “Drafts”.
4
Under “Message”, input a new TXT Message.
5
Press to send.
1
Press [MENU], then select “Messaging”
menu, press “New Msg”, then press
“PIX Msg” or press [MESSAGE], press
“New Msg”, then press “PIX Msg”.
SEND NEW PIX MESSAGE
![](/img.php?id=633496&img=bg64.png)
NEW MSG
C
H
6
99
6
Under “Subject”, input a subject then press .
By pressing [OPTIONS].
Add Quick Text : Inserts already written sentences in TXT
Msg.
(Please refer to page 31 for more details on entering letters,
numbers and symbols. Max 100 characters support.)
4
Under “PIX”, only one picture can be inserted
per message.
Press [MY PIX], then select the picture
you’d like to send and press .
8
To send the PIX Message, press [SEND].
7
Press [OPTIONS], then select “Priority Level”,
select “High” or “Normal”, then press .
To save the PIX Message, press [OPTIONS],
then select “Save As Draft”.
To preview a written picture message, press
[OPTIONS], then select “Preview”.
To add slide, press [OPTIONS], then
select “Add Slide”.
5
Under “Sound”, only one sound can be inserted.
Press [SOUNDS], then select the sound
you’d like to send and press .
![](/img.php?id=633496&img=bg65.png)
INBOX
C
H
6
100
FORWARD
1
To forward the TXT or PIX Message.
2
Input the phone number of the person you are
sending the message, then press .
3
Input any text message to go along with the
forwarded message, then press .
PLAY AGAIN
1
To play a sound from a received PIX Message.
The Inbox manages recevied TXT/PIX/WAP Push messages. To access:
2
Select a message, then press [OPEN].
The message is displayed. To delete a message,
press [ERASE], press .
If you select “WAP Push” you will need to press
[GET] to launch the Browser and retrieve the
message.
Press [OPTIONS].
3
1
Press [MENU], then select “Messaging”
menu, press “Inbox” or press
[MESSAGE], press “Inbox”.
: Lock
: Priority
: Read
: Unread
: EMS Unread
: PIX Unread
: PIX Read
: MMS Push
: Wap Push
: EMS Read
![](/img.php?id=633496&img=bg66.png)
INBOX
C
H
6
101
SAVE GRAPHIC
1
To save a picture to the “Save Graphic” folder.
ERASE
1
To erase this message, select “Erase”, then
select “Yes”, press .
REPLY W. COPY
1
2
3
To reply to a received message and include the
received message into the message.
The default call back number is automatically
included into the Default CB# field.
You can scroll to the number and edit it.
To send the TXT or PIX message, press .
SAVE SOUND
1
To save a sound to the “Save Sound” folder.
SAVE QUICK TEXT
1
Select to save received text msg to “Quick Text”.
“Play Again”, “Save Graphic”, “Save Sound” menu appears only
when you receive a PIX Message or EMS message.
![](/img.php?id=633496&img=bg67.png)
INBOX
C
H
6
102
MESSAGE INFO
1
To show received PIX Message information.
• “Message Info” menu appears only when you receive a
PIX Message.
• Place a call to a received message number by simply
pressing .
ADD TO CONTACTS
1
Select to save number to contacts.
LOCK/UNLOCK
1
To lock or unlock the TXT or PIX message.
2
Select “Lock” to lock the message or “Unlock”
to unlock the message, then press .
![](/img.php?id=633496&img=bg68.png)
SENT
C
H
6
103
1
Press [MENU], then select “Messaging”
menu, press “Sent” or press [MESSAGE],
press “Sent”.
Manages sent TXT/PIX messages or messages waiting to be sent.
2
Select a message then press [OPEN].
The message is displayed. To delete a message,
press [ERASE], press .
Press [OPTIONS].
3
FORWARD
1
To forward the TXT or PIX message.
2
Input the phone number of the person you are
sending the message, then press .
3
Input any text message to go along with the
forwarded message, then press .
: Lock
: Priority
: Sent
: Incomplete Delivery
: Delivered
: Sent but Delivery Failed
RESEND
1
To resend a TXT or PIX message.
PLAY AGAIN
1
To play a sound from a received PIX Message.
![](/img.php?id=633496&img=bg69.png)
SENT
C
H
6
104
SAVE QUICK TEXT
1
Select to save received TXT Msg to “Quick Text”.
ADD TO CONTACTS
1
Select to save number to contacts.
ERASE
1
To erase this message, select “Erase”.
LOCK/UNLOCK
1
To lock or unlock the TXT or PIX message.
2
Select “Lock” to lock the message or “Unlock”
to unlock the message, then press .
2
Select “Yes” or “No”, then press .
MESSAGE INFO
1
To show received PIX Message information.
• “Message Info” menu appears only when you receive a PIX
Message.
• Place a call to a received message number by simply
pressing .
![](/img.php?id=633496&img=bg6a.png)
DRAFTS
C
H
6
105
ADD TO CONTACTS
1
Select to save number to contacts.
SEND
1
To send a selected message.
LOCK/UNLOCK
1
To lock or unlock the TXT or PIX message.
2
Select “Lock” to lock the message or “Unlock”
to unlock the message, then press .
1
Press [MENU], then select “Messaging”
menu, press “Drafts” or press
[MESSAGE], press “Drafts”.
2
Select a message then press [EDIT].
The message is displayed. To delete a message,
press [ERASE], press .
Press [OPTIONS].
3
Draft Folder contains any draft messages or saved messages.
If message composition is interrupted by a voice call or other
interrupting event, the text of the current composition is automatically
saved in the drafts folder.
: Lock
: PIX Drafts
: SMS/EMS Drafts
![](/img.php?id=633496&img=bg6b.png)
C
H
6
106
E- MAIL
1
Press [MENU], then select “Messaging”
menu, press “E-mail” or press
[MESSAGE], press “E-mail”.
2
Launch “Mobile Web”.
![](/img.php?id=633496&img=bg6c.png)
C
H
6
107
MOBILE IM
Press [MENU], then select “Messaging”
menu, press “Mobile IM” or press
[MESSAGE], press “Mobile IM” and then
select “Get New” with Navigation Key.
Launch “Get It Now”.
GET NEW
1
2
Press [MENU], then select “Messaging”
menu, press “Mobile IM” or press
[MESSAGE], press “Mobile IM” and then
select “Mobile IM” with Navigation Key.
Connect “Mobile IM”.
MOBILE IM
1
2
![](/img.php?id=633496&img=bg6d.png)
C
H
6
108
CHAT
1
Press [MENU], then select “Messaging”
menu, press “Chat” or press
[MESSAGE], press “Chat”.
2
Launch “Mobile Web”.
![](/img.php?id=633496&img=bg6e.png)
C
H
6
109
ERASE ALL
2
2.1. To erase all the inbox messages,
press [ERASE INBOX].
3
Select “Yes”, then press .
2.2. To erase all the drafts messages,
press [ERASE DRAFTS].
2.3. To erase the sent messages,
press [ERASE SENT].
2.4. To erase the all message,
press [ERASE ALL].
1
Press [MENU], then select “Messaging”
menu, press [OPTIONS] or press
[MESSAGE], press [OPTIONS].
![](/img.php?id=633496&img=bg6f.png)
C
H
6
110
SETTINGS
ALL MSG SETTINGS
Press [AUTO SAVE].
Select “On”, “Off” or “Prompt” with the
Navigation Key.
Press .
Set messaging preferences and default settings.
Automatically erases inbox messages when new messages arrive.
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“All Msg”.
Press [AUTO ERASE].
Select “On” or “Off” with the Navigation Key.
Press .
On : All sent messages saved in the Sent box.
Off : All sent messages not saved in the Sent box.
Prompt : “Yes”, “No” dialogue box displayed after sent message.
On : Oldest message erased from inbox automatically when
message is full.
Off : Oldest message not erased from inbox automatically when
message is full.
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“All Msg”.
AUTO SAVE
AUTO ERASE
1
2
3
1
2
3
![](/img.php?id=633496&img=bg70.png)
C
H
6
111
SETTINGS
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“All Msg”.
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“All Msg”.
To edit the Quick Text message you have saved:
Press [QUICK-TEXT].
2.1. Select a message from the list.
Press .
2.2. To add a new Quick Text message, press
[NEW], then enter text, press .
To erase the saved Quick Text message,
press [ERASE].
Pre-defined quick text as below.
1. What’s up?/2. Let’s meet/3. Check this out!/4. Whacha
doing?/5. Thanks/6. What do you think?/7. You’ve gotta be here
to enjoy this/8. Would you like to join me for a date tonight?/
9. On my way/10. Yes/11. You’re the best!/12. Call me
Press [VOICEMAIL#].
Input a new voice call back number or edit
voice call back number.
Press .
QUICK TEXT
VOICEMAIL#
1
2
3
3
2
1
![](/img.php?id=633496&img=bg71.png)
C
H
6
112
SETTINGS
Edits a default callback number so that the recipient can callback or
reply.
Press [CALLBACK#].
Input a new callback number,
press .
Press [ENTRY MODE].
Select “Word”, “Abc”, “ABC”, “123” or
“Symbols” with the Navigation Key.
Press .
Sets an Entry Mode as a default. For example, if Word Mode is the
default, its icon will appear.
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“All Msg”.
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“All Msg”.
ENTRY MODE
CALLBACK #
3
3
2
1
2
1
![](/img.php?id=633496&img=bg72.png)
C
H
6
113
SETTINGS
Create a signature that can be automatically inserted at the end of
all TXT and PIX messages.
Press [SIGNATURE].
To input “Signature”, put the cursor on Edit
Signature.
Press .
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“All Msg”.
ALL MESSAGE SIGNATURE
4
3
2
1
![](/img.php?id=633496&img=bg73.png)
C
H
6
114
SETTINGS
TXT MSG SETTINGS
Press [AUTO VIEW].
Select “On” or “Off” with the Navigation Key.
Press .
If the “Auto View” is set to on, the user will be able to view the
message. If the “Auto View” is set to off, the user can view the
message by entering SMS Menu-> Inbox.
On : Text message displayed automatically.
Off : Text message displayed by going to the inbox or
responding to interactive notification.
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“TXT Msg”.
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“TXT Msg”.
Press .
Press [BLOCK/UNBLOCK].
Select “Block”, “Unblock” or “View List of
Blocked Addresses” with the Navigation Key.
Block : Enter the address to block.
Unblock : Enter the address to remove from block.
View List of Blocked Addresses : Display the blocked
list on LCD.
AUTO VIEW
BLOCK/UNBLOCK
3
1
2
3
2
1
![](/img.php?id=633496&img=bg74.png)
C
H
6
115
SETTINGS
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“TXT Msg”.
Create a signature that can be automatically inserted at the end of a
message.
Press [SIGNATURE].
To input “Signature”, put the cursor on Edit
Signature.
Press .
TXT MESSAGE SIGNATURE
1
4
3
2
![](/img.php?id=633496&img=bg75.png)
SETTINGS
C
H
6
116
PIX MSG SETTINGS
Press [AUTO RECEIVE].
Select “On” or “Off” with the Navigation Key.
Press .
On : PIX msg downloaded automatically.
Off : PIX message must be retrieved from the inbox or at new
TXT message prompt.
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“PIX Msg”.
Press [MENU], then select “Messaging”
menu, press [SETTINGS] or press
[MESSAGE], press [SETTINGS], press
“PIX Msg”.
Create a signature that can be automatically inserted at the end of a
message.
Press [SIGNATURE].
To input “Signature”, put the cursor on Edit
Signature.
Press .
PIX MESSAGE SIGNATURE
AUTO RECEIVE
1
2
3
1
2
3
4
![](/img.php?id=633496&img=bg76.png)
MOBILE WEB 2.0
This chapter addresses Internet services and web browsing.
For more detailed information contact your service provider.
STARTING INTERNET BROWSER
BROWSER MENU
Chapter 7
117
C
H
7
![](/img.php?id=633496&img=bg77.png)
BROWSER MENU
STARTING INTERNET BROWSER
C
H
7
118
BACK
1
To return to the previous page.
Press , then press [MENU] .
LAUNCHING MOBILE WEB 2.0
1
To start your Internet browser and access
websites through your wireless handset press .
VZW HOME
1
To display the homepage.
Press , then press [MENU] .
The browser menu lists the actions necessary to operate the browser.
press , then press [MENU].
When the “VzW Home” item is selected from the Browser Menu,
the phone displays the homepage.
When the “Back” item is selected from the Browser Menu, the phone
displays the previous page in the history.
Now you can access news, sports, weather, and e-mail from your
phone. Mobile Web 2.0 keeps you updated by providing access to
up-to-date information such as news, sports, weather and stock
quotes when you subscribe to Internet service with your service
provider. Please contact your service provider for a list of available
websites and service details.
![](/img.php?id=633496&img=bg78.png)
BROWSER MENU
C
H
7
119
ADDRESS
1
To select “Address”.
Press , then press [MENU] .
REFRESH
1
To select “Refresh”.
Press , then press [MENU] .
Selecting the “Address” item from the Browser Menu displays the
URL of the current page.
The user may clear cache, history, cookies and auto fill from the
memory.
Selecting the “Refresh” item from the Browser Menu refreshes the
current page.
The history list is available from the Browser Menu and the user may
delete all items from the history.
When the “Forward” item is selected from the Browser Menu, the
phone displays the next page in the history. This is only available if the
user has navigated backward in the history.
HISTORY
1
To select “History”.
Press , then press [MENU] .
FORWARD
1
To forward to the next page.
Press , then press [MENU] .
CLEAR MEMORY
1
To clear browser memory.
Press , then press [MENU] .
![](/img.php?id=633496&img=bg79.png)
BROWSER MENU
C
H
7
120
SETTINGS
1
To select “Settings”.
Press , then press [MENU] .
Downloads : Selecting the “Downloads” item allows the user to
enable/disable downloading images, background
sounds, and object downloads when a URL is
accessed.
Restart Browser : Selecting “Restart Browser” causes the
history and cache to be cleared and returns
the user to the homepage.
Scroll Mode : Selecting “Scroll Mode” from the Settings menu
allows the user to select the way text scrolls and
the scroll speed.
Send Referrer : When the “Send Referrer” item is selected
from the Settings menu, the browser allows
the user to turn on or off sending the referrer
URL.
Key Press Timeout : When the “Key Press Timeout” item is
selected from the Settings menu, the
browser allows the user to set the key
press timeout as fast, medium or slow.
Medium is 1.5 seconds, slow 2 seconds
and fast is 1 second. The key press
timeout is the period of time after which
the cursor auto-advances to the next
entry position. In most cases, a single key
can be used to enter more than one
character. Each time the key is pressed
the last character of the line is replaced
by the next choice for that key. As long
as the same key is re-pressed within key
press timeout, the last character cycles
between all the choices for the key.
Connection Timeout : When the Connection Timeout item is
selected from the Settings menu, the
browser allows the user to set the
connection timeout. The connection
timeout determines how long the
browser will wait for a response from
the network for a network request.
![](/img.php?id=633496&img=bg7a.png)
BROWSER MENU
C
H
7
121
ADVANCED
1
To select “Advanced”.
Press , then press [MENU] .
Selecting the “Advanced” item in the Browser Menu displays the
advanced menu items.
About... : When the “About” item is selected, information about
the browser version, copyright information and
certificate information is displayed.
Encryption : Selecting the “Encryption” item from the Advanced
Menu enables the user access to Encryption
features of the browser.
1. Authentication : The “Authentication” item in the
Encryption menu allows the
user to toggle authentication
caching.
2. Root Certificate : The “Root Certificate” item in
the Encryption menu allows
the user to view the list of
certificates.
3. Current Certificate : The “Current Certificate”
item in the Encryption
menu allows the user to
view the current certificate.
This is only available if a
secure connection is
established.
![](/img.php?id=633496&img=bg7b.png)
BROWSER MENU
C
H
7
122
To exit browser.
Press , then press [MENU] .
EXIT
1
When the “Exit” item is selected from the Browser Menu, the user exits
out of the browser and is returned to the phone idle mode.
![](/img.php?id=633496&img=bg7c.png)
SAFETY AND
WARRANTY
This chapter addresses the safety guidelines and precautions to
follow when operating your phone. Before operating your phone,
please be aware of all the safety details.
This chapter contains the terms and conditions of services and the
warranty for your phone. Please review them thoroughly.
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR FCC RF EXPOSURE
SAR INFORMATION
FCC HEARING-AID COMPATIBILITY (HAC) REGULATIONS
FOR WIRELESS DEVICES
FDA CONSUMER UPDATE
PROTECT YOUR WARRANTY
12 MONTH LIMITED WARRANTY
Chapter 8
123
C
H
8
![](/img.php?id=633496&img=bg7d.png)
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
C
H
8
124
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for handheld wireless
phones. Those guidelines are consistent with the safety standards
previously set by both U.S. and international standards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and periodic evaluations
of the relevant scientific literature. For example, over 120 scientists,
engineers, and physicians from universities, government health agencies,
and industry reviewed the available body of research to develop the ANSI
Standard (C951).
The design of your phone complies with the FCC guidelines (and those
standards).
EXPOSURE TO RADIO FREQUENCY SIGNALS
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the phone and
may violate FCC regulations.
ANTENNA CARE
Read This Information Before Using Your Handheld
Portable Cellular Telephone
1* : American National Standards Institute.
2* : National Council on Radiation protection and measurements.
3* : International Commission on Nonionizing Radiation Protection.
![](/img.php?id=633496&img=bg7e.png)
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
125
C
H
8
Talking on the phone while driving is extremely dangerous and is illegal in
some states. Remember, safety comes first. Check the laws and regulations
on the use of phones in the areas where you drive. Always obey them.
Also, if using your phone while driving, please:
lGive full attention to driving. Driving safely is your first responsibility.
lUse hands-free operation, if available.
lPull off the road and park before making or answering a call, if driving
conditions so require.
If you must use the phone while driving, please use one-touch, speed dialing,
and auto answer modes.
An airbag inflates with great force. DO NOT place objects, including both
installed or portable wireless equipment, in the area over the airbag or in the
air bag deployment area. If in-vehicle wireless equipment is improperly
installed and the air bag inflates, serious injury could result.
DRIVING SAFETY
WARNING: Failure to follow these instructions may lead to serious
personal injury and possible property damage.
![](/img.php?id=633496&img=bg7f.png)
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
126
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6”) inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent
research by and recommendations of Wireless Technology Research.
Persons with pacemakers :
lALWAYS keep the phone more than six inches from your
pacemaker when the phone is turned on.
lDo not carry the phone in a breast pocket.
lUse the ear opposite the pacemaker to minimize the potential for
interference.
lIf you have any reason to suspect that interference is taking place,
turn your phone OFF immediately.
PACEMAKERS
If you use any other personal medical device, consult the manufacturer of
your device to determine if they are adequately shielded from external RF
energy. Your physician may be able to assist you in obtaining this
information.
Turn your phone OFF in healthcare facilities when any regulations posted
in these areas instruct you to do so. Hospitals or healthcare facilities may
be using equipment that could be sensitive to external RF energy.
OTHER MEDICAL DEVICES
Turn your phone OFF where posted notices so require.
POSTED FACILITIES
ELECTRONIC DEVICES
Most modern electronic equipment is shielded from RF energy. However,
certain electronic equipment may not be shielded against the RF signals
from your wireless phone.
C
H
8
![](/img.php?id=633496&img=bg80.png)
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
127
OTHER SAFETY GUIDELINES
FCC and Transport Canada Regulations prohibit using your phone while
in the air. Turn your phone OFF before boarding an aircraft.
AIRCRAFT
To avoid interfering with blasting operations, turn your phone OFF when in
a “blasting area” or in areas posted: “Turn off two-way radio.” Obey all
signs and instructions.
BLASTING AREAS
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even
death.
Areas with a potentially explosive atmosphere are often, but not
always, clearly marked. They include fueling areas such as gas
stations; below deck on boats; fuel or chemical transfer or storage
facilities; vehicles using liquefied petroleum gas (such as propane or
butane); areas where the air contains chemicals or particles, such as
grain, dust, or metal powders; and any other area where you would
normally be advised to turn off your vehicle’s engine.
POTENTIALLY EXPLOSIVE ATMOSPHERES
C
H
8
![](/img.php?id=633496&img=bg81.png)
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
128
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of
equipment. Before operating, read all instructions and cautionary
markings on (1) AC Adaptor (2) Battery and (3) Product Using Battery.
DO NOT use this equipment in an extreme environment where
high temperature or high humidity exists.
DO NOT abuse the equipment. Avoid striking, shaking or
shocking. When not using, lay down the unit to avoid possible
damage due to instability.
DO NOT expose this equipment to rain or spilled beverages.
DO NOT use unauthorized accessories.
DO NOT disassemble the phone or its accessories. If service
or repair is required, return unit to an authorized Pantech
cellular service center. If unit is disassembled, the risk of
electric shock or fire may result.
DO NOT short-circuit the battery terminals with metal items etc.
C
H
8
WARNING!
• This product contains a chemical known to the State of
California to cause cancer.
• This product contains a chemical known to the State of
California to cause birth defects or other reproductive harm.
![](/img.php?id=633496&img=bg82.png)
SAFETY INFORMATION FOR
FCC RF EXPOSURE
129
In August 1996 the Federal Communications Commission (FCC) of
the United States with its action in Report and Order FCC 96-326
adopted an updated safety standard for human exposure to radio
frequency electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety standard
previously set by both U.S. and international standards bodies. The
design of this phone complies with the FCC guidelines and these
international standards.
Use only the supplied or an approved antenna. Unauthorized
antennas, modifications, or attachments could impair call quality,
damage the phone, or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with the skin, a minor burn may result.
Please contact your local dealer for replacement antenna.
This device was tested for typical body-worn operations with the
back of the phone kept 2.0 cm. from the body with a belt
clip that contains metallic components. To maintain compliance with
FCC RF exposure requirements, use only belt-clips, holsters or s-
imilar accessories with which this device was tested. The use
of accessories that do not satisfy these requirements may not c-
omply with FCC RF exposure requirements, and should be avoided.
BODY-WORN OPERATION
WARNING! Read this Information before using
CAUTIONS
For more information about RF exposure, please visit the FCC
website at www.fcc.gov.
C
H
8
![](/img.php?id=633496&img=bg83.png)
SAR INFORMATION
130
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radiofrequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the
phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone while operating
can be well below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government adopted requirement for safe exposure.
The tests are performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model. The highest
SAR value for this model phone when tested for use at the ear is 1.25
W/Kg and when worn on the body, as described in this user guide, is
1.1W/Kg. (Body-worn measurements differ among phone models,
depending upon available accessories and FCC requirements). While
there may be differences between the SAR levels of various phones
and at various positions, they all meet the government requirement for
safe exposure.
The SAR testing for Body-worn operation was performed with a belt
clip that provided a 20mm separation. The User’s Manual indicates that
any holsters/clips used with this device should contain no metallic
components.
C
H
8
![](/img.php?id=633496&img=bg84.png)
SAR INFORMATION
131
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC
RF exposure guidelines. SAR information on this model phone is on file
with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/ oet/fccid after searching on PP4PN-315.
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications Industry Asso-ciation (CTIA) web-
site at http://www.wow-com.com.
* In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram of
tissue. The standard incorporates a sub-stantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
C
H
8
![](/img.php?id=633496&img=bg85.png)
132
C
H
8
On July 10, 2003, the U.S. Federal Communications Commission
(FCC) Report and Order in WT Docket 01-309 modified the exception of
wireless phones under the Hearing Aid Compatibility Act of 1988 (HAC
Act) to require digital wireless phones be compatible with hearing-aids.
The intent of the HAC Act is to ensure reasonable access to
telecommunications services for persons with hearing disabilities.
While some wireless phones are used near some hearing devices
(hearing aids and cochlear implants), users may detect a buzzing,
humming, or whining noise. Some hearing devices are more immune
than others to this interference noise, and phones also vary in the
amount of interference they generate.
The wireless telephone industry has developed a rating system for
wireless phones, to assist hearing device users find phones that may be
compatible with their hearing devices. Not all phones have been rated.
Phones that are rated have the rating on their box or a label located on
the box.
The ratings are not guarantees. Results will vary depending on the
user’s hearing device and hearing loss. If your hearing device happens
to be vulnerable to interference, you may not be able to use a rated
phone successfully. Trying out the phone with your hearing device is
the best way to evaluate it for your personal needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are
likely to generate less interference to hearing devices than phones that
are not labeled. M4 is the better/higher of the two ratings.
Hearing devices may also be rated. Your hearing device manufacturer
or hearing health professional may help you find this rating. Higher
ratings mean that the hearing device is relatively immune to interference
noise. The hearing aid and wireless phone rating values are then added
together. A sum of 5 is considered acceptable for normal use. A sum of
6 is considered for best use.
FCC HEARING-AID COMPATIBILITY (HAC)
REGULATIONS FOR WIRELESS DEVICES
![](/img.php?id=633496&img=bg86.png)
133
C
H
8
In the above example, if a hearing aid meets the M2 level rating and the
wireless phone meets the M3 level rating, the sum of the two values
equal M5. This should provide the hearing aid user with “normal usage”
while using their hearing aid with the particular wireless phone. “Normal
usage” in this context is defined as a signal quality that is acceptable
for normal operation.
The M mark is intended to be synonymous with the U mark. The T mark
is intended to be synonymous with the UT mark. The M and T marks
are recommended by the Alliance for Telecommunications Industries
Solutions (ATIS). The U and UT marks are referenced in Section 20.19
of the FCC Rules. The HAC rating and measurement procedure are
described in the American National Standards Institute (ANSI) C63.19
standard.
For information about hearing aids and digital wireless phone
lFcc Hearing Aid Compatibility and Volume Control
http://www.fcc.gov/cgb/dro/hearing.html
lGallaudet University, RERC
http://tap.gallaudet.edu/DigWireless.KS/DigWireless.htm
lSelf Help for Hard of Hearing People Inc. [SHHH]
www.hearingloss.org/hat/TipsWirelessPhones.htm
lThe Hearing Aid Compatibility FCC Order
http://hraunfoss.fcc.gov/edocs_public/attachmatch/
FCC-03-168A1.pdf
FCC HEARING-AID COMPATIBILITY (HAC)
REGULATIONS FOR WIRELESS DEVICES
![](/img.php?id=633496&img=bg87.png)
134
FDA CONSUMER UPDATE
C
H
8
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems are
associated with using wireless phones. There is no proof, however, that wireless
phones are absolutely safe. Wireless phones emit low levels of radiofrequency
energy (RF) in the microwave range while being used. They also emit very low
levels of RF when in the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF that does not produce
heating effects causes no known adverse health effects. Many studies of low level
RF exposures have not found any biological effects. Some studies have suggested
that some biological effects may occur, but such findings have not been confirmed
by additional research. In some cases, other researchers have had difficulty in
reproducing those studies, or in determining the reasons for inconsistent results.
2. What is FDA’s role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting consumer
products such as wireless phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has authority to take action if
wireless phones are shown to emit radiofrequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could require the manufacturers of
wireless phones to notify users of the health hazard and to repair, replace or recall
the phones so that the hazard no longer exists. Although the existing scientific data
do not justify FDA regulatory actions, FDA has urged the wireless phone industry
to take a number of steps, including the following:
• Support needed research into possible biological effects of RF of the type
emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF exposure to the user
that is not necessary for device function;
and
• Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health.
FDA belongs to an interagency working group of the federal agencies that have
responsibility for different aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some inter-agency working group
activities, as well. FDA shares regulatory responsibilities for wireless phones with
the Federal Communications Commission (FCC). All phones that are sold in the
United States must comply with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety questions about wireless
phones. FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than do the wireless
phones themselves, the RF exposures that people get from these base stations are
typically thousands of times lower than those they can get from wireless phones.
Base stations are thus not the subject of the safety questions discussed in this
document.
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to hand-held wireless phones with built-in
antennas, often called “cell,” “mobile,” or “PCS” phones.
U.S. Food and Drug Administration -Center for Devices and
Radiological Health Consumer Update on Wireless Phones
![](/img.php?id=633496&img=bg88.png)
135
FDA CONSUMER UPDATE
C
H
8
These types of wireless phones can expose the user to measurable radiofrequency
energy (RF) because of the short distance between the phone and the user’s head.
These RF exposures are limited by Federal Communications Commission safety
guidelines that were developed with the advice of FDA and other federal health and
safety agencies. When the phone is located at greater distances from the user, the
exposure to RF is drastically lower because a person’s RF exposure decreases
rapidly with increasing distance from the source. The so-called “cordless phones,”
which have a base unit connected to the telephone wiring in a house, typically
operate at far lower power levels, and thus produce RF exposures far below the
FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many studies
have suffered from flaws in their research methods. Animal experiments
investigating the effects of radiofrequency energy (RF) exposures characteristic of
wireless phones have yielded conflicting results that often cannot be repeated in
other laboratories. A few animal studies, however, have suggested that low levels
of RF could accelerate the development of cancer in laboratory animals. However,
many of the studies that showed increased tumor development used animals that
had been genetically engineered or treated with cancer-causing chemicals so as to
be predisposed to develop cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day. These conditions are not
similar to the conditions under which people use wireless phones, so we don’t
know with certainty what the results of such studies mean for human health. Three
large epidemiology studies have been published since December 2000. Between
them, the studies investigated any possible association between the use of
wireless phones and primary brain cancer, glioma, meningioma, or acoustic neu-
roma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health effects from wireless
phone RF exposures. However, none of the studies can answer questions about
long-term exposures, since the average period of phone use in these studies was
around three years.
5. What research is needed to decide whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people actually
using wireless phones would provide some of the data that are needed. Lifetime
animal exposure studies could be completed in a few years. However, very large
numbers of animals would be needed to provide reliable proof of a cancer
promoting effect if one exists. Epidemiological studies can provide data that is
directly applicable to human populations, but 10 or more years’ follow-up may be
needed to provide answers about some health effects, such as cancer. This is
because the interval between the time of exposure to a cancer-causing agent and
the time tumors develop - if they do -may be many, many years. The interpretation
of epidemiological studies is hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones. Many factors affect this
measurement, such as the angle at which the phone is held, or which model of
phone is used.
6. What is FDA doing to find out more about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of
investigators around the world to ensure that high priority animal studies are
conducted to address important questions about the effects of exposure to
radiofrequency energy (RF). FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF) Project since its inception
in 1996. An influential result of this work has been the development of a detailed
agenda of research needs that has driven the establishment of new research
programs around the world.
![](/img.php?id=633496&img=bg89.png)
136
FDA CONSUMER UPDATE
The Project has also helped develop a series of public information documents on
EMF issues. FDA and the Cellular Telecommunications & Internet Association
(CTIA) have a formal Cooperative Research and Development Agreement (CRADA)
to do research on wireless phone safety. FDA provides the scientific oversight,
obtaining input from experts in government, industry, and academic organizations.
CTIA-funded research is conducted through contracts to independent
investigators. The initial research will include both laboratory studies and studies of
wireless phone users. The CRADA will also include a broad assessment of
additional research needs in the context of the latest research developments
around the world.
7. How can I find out how much radiofrequency energy exposure I can get by
using my wireless phone?
All phones sold in the United States must comply with Federal Communications
Commission (FCC) guidelines that limit radiofrequency energy (RF) exposures. FCC
established these guidelines in consultation with FDA and the other federal health
and safety agencies. The FCC limit for RF exposure from wireless telephones is set
at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC
limit is consistent with the safety standards developed by the Institute of Electrical
and Electronic Engineering (IEEE) and the National Council on Radiation Protection
and Measurement. The exposure limit takes into consideration the body’s ability to
remove heat from the tissues that absorb energy from the wireless phone and is
set well below levels known to have effects. Manufacturers of wireless phones
must report the RF exposure level for each model of phone to the FCC. The FCC
website (http://www.fcc.gov/oet/rfsafety) gives directions for locating the FCC
identification number on your phone so you can find your phone’s RF exposure
level in the online listing.
8. What has FDA done to measure the radiofrequency energy coming from
wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical
standard for measuring the radiofrequency energy (RF) exposure from wireless
phones and other wireless handsets with the participation and leadership of FDA
scientists and engineers. The standard, “Recommended Practice for Determining
the Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to
Wireless Communications Devices: Experimental Techniques,” sets forth the first
consistent test methodology for measuring the rate at which RF is deposited in the
heads of wireless phone users. The test method uses a tissue-simulating model of
the human head. Standardized SAR test methodology is expected to greatly
improve the consistency of measurements made at different laboratories on the
same phone. SAR is the measurement of the amount of energy absorbed in tissue,
either by the whole body or a small part of the body. It is measured in watts/kg (or
milliwatts/g) of matter. This measurement is used to determine whether a wireless
phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to radiofrequency energy
from my wireless phone?
If there is a risk from these products—and at this point we do not know that there
is—it is probably very small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to minimize your exposure to
radiofrequency energy (RF). Since time is a key factor in how much exposure a
person receives, reducing the amount of time spent using a wireless phone will
reduce RF exposure.
• If you must conduct extended conversations by wireless phone every day, you
could place more distance between your body and the source of the RF, since
the exposure level drops off dramatically with distance. For example, you could
use a headset and carry the wireless phone away from your body or use a
wireless phone connected to a remote antenna.
C
H
8
![](/img.php?id=633496&img=bg8a.png)
137
FDA CONSUMER UPDATE
Again, the scientific data do not demonstrate that wireless phones are harmful. But
if you are concerned about the RF exposure from these products, you can use
measures like those described above to reduce your RF exposure from wireless
phone use.
10.What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless phones,
including children and teenagers. If you want to take steps to lower exposure to
radiofrequency energy (RF), the measures described above would apply to children
and teenagers using wireless phones. Reducing the time of wireless phone use
and increasing the distance between the user and the RF source will reduce RF
exposure. Some groups sponsored by other national governments have advised
that children be discouraged from using wireless phones at all. For example, the
government in the United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no evidence exists that
using a wireless phone causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by children was strictly precautionary;
it was not based on scientific evidence that any health hazard exists.
11.What about wireless phone interference with medical equipment?
Radiofrequency energy (RF) from wireless phones can interact with some
electronic devices. For this reason, FDA helped develop a detailed test method to
measure electromagnetic interference (EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This standard will allow
manufacturers to ensure that cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard sponsored by the
Institute of Electrical and Electronic Engineers (IEEE). This standard specifies test
methods and performance requirements for hearing aids and wireless phones so
that that no interference occurs when a person uses a “compatible” phone and a
“compatible” hearing aid at the same time. This standard was approved by the
IEEE in 2000. FDA continues to monitor the use of wireless phones for possible
interactions with other medical devices. Should harmful interference be found to
occur, FDA will conduct testing to assess the interference and work to resolve the
problem.
12.Where can I find additional information?
For additional information, please refer to the following resources:
• FDA web page on wireless phones (http://www.fda.gov/cdrh/ phones/index.html)
• Federal Communications Commission (FCC) RF Safety Pro-gram
(http://www.fcc.gov/oet/rfsafety)
• International Commission on Non-Ionizing Radiation Protec-tion
(http://www.icnirp.de)
• World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
• National Radiological Protection Board (UK) (http://www.nrpb.org.uk/)
C
H
8
![](/img.php?id=633496&img=bg8b.png)
PROTECT YOUR WARRANTY
138
C
H
8
Read your Warranty carefully, with the special consideration to
paragraph seven of the Limited Warranty for your unit.
“Warranty does not apply to... or to any product or part
thereof which has suffered through alteration... mishandling,
misuse, neglect or accident”.
Many companies are making look alike accessories and in some cases,
promoting that their product is equal to or better than the Pantech
product. Be careful. Some of these products may not be compatible to
use with your Pantech product and may damage the unit or cause it to
malfunction. If service is required on your unit and it is determined that
a non-Pantech accessory has created the problem with your unit, the
Warranty will not apply. In addition, if the unit has already suffered
irreversible damage by reason of a non-compatible accessory, the
Warranty will be voided. To protect your Warranty, use only compatible
accessories which cannot damage or interfere with the functioning of
your Pantech product.
PANTECH WIRELESS, INC.
11240 Warland Drive, Cypress, CA 90630 (800) 962-8622
![](/img.php?id=633496&img=bg8c.png)
12 MONTH LIMITED WARRANTY
139
C
H
8
Pantech Wireless, Inc. (the Company) warrants to the original retail
purchaser of this Pantech handheld portable cellular telephone, that
should this product or any part thereof during normal consumer usage
and conditions, be proven defective in material or workmanship that
results in product failure within the first twelve (12) months period from
the date of purchase, such defect(s) will be repaired or replaced (with
new or rebuilt parts) at the Company’s option, without charge for parts
or labor directly related to the defect(s).
The antenna, key pad, display, rechargeable battery and battery
charger, if included, are similarly warranted for twelve (12) months from
date of purchase.
This Warranty extends only to consumers who purchase the product in
the United States or Canada and it is not transferable or assignable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse, improper
installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic serial number
has been removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive
temperatures or extreme environmental conditions;
(d) Damage resulting from connection to, or use of any accessory or
other product not approved or authorized by the Company;
(e) Defects in appearance, cosmetic, decorative or structural items such
as framing and non-operative parts;
(f) Product damaged from external causes such as fire, flooding, dirt,
sand, weather conditions, battery leakage, blown fuse, theft or
improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of the
product, for geographic coverage, for inadequate signal reception by
the antenna or for communications range or operation of the cellular
system as a whole.
To obtain repairs or replacement within the terms of this Warranty, the
product should be delivered with proof of Warranty coverage (e.g.
dated bill of sale), the consumer’s return address, daytime phone
number and/or fax number and complete description of the problem,
transportation prepaid, to the Company by calling the number listed
below or to the place of purchase for repair or replacement processing.
![](/img.php?id=633496&img=bg8d.png)
12 MONTH LIMITED WARRANTY
140
In addition, you may telephone us at (800) 962-8622, or email us at
HandsetHelp@Pantech.com
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S
LAIBILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST
BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE OF
ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE
LIABLE FOR AN SPECIAL CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY,
EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT
BE LIABLE FOR THE DELAY IN RENDERING SERVICE UNDER THIS
WARRANTY OR LOSS OF USE DURING THE TIME THE PRODUCT IS
BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the Company
any liability other than expressed herein in connection with the sale of
this product.
Some states or provinces do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitation or exclusions may not
apply to you. This Warranty gives you specific legal rights, and you may
also have other rights which vary from state to state or province to
province.
C
H
8
