Travel Mouse
Wireless
User Manual
Please read the instruction for installing,
operating, and using the wireless Travel Mouse.
If the travel mouse is not functional for compatibiliry
problem, please up date your operation system.
Your System Includes:
Please Review this Checklist
Windows XP, 2000, ME, 98SE
Compatible with Windows Operating Systems:
Features of Travel Mouse
Compact and ergonomic design
Easy to carry for users to travel around
USB interface to enable Plug and Play
Low power indication
Compatible with all IBM-compatible PCs and equipped with USB interface.
Compatible Equipment
Maintaining your hardware and resolving basic problems
If the mouse doesn't work smoothly and properly, please try to
do the following improvements:
Check the battery and replace with a new one when the LED of
the mouse turns from green to red.
Adjust the angle of the external antenna to get better
performance.
If your cursor is controlled by another Travel Mouse in an
office or multi-user environment, please proceed "Switching
Security ID of Travel Mouse" procedure accordingly.
Please check the USB plug of the receiver is properly
installed into the USB socket of your Notebook / Laptop.
Please keep iron-made office partitions, computer chassis,
monitors, zip-drives, speakers, and switching power supply,
20 cm at least away from the mouse and receiver.
If the above points don't improve your utility, please
move the mouse closer to the receiver to avoid any
unidentified interferences.
Quick Installation Guide.
Taking the receiver out of mouse
Press the reject button on the bottom of the mouse
Take the receiver out of the compartment
Storing the receiver into mouse
1.Place the receiver 90 to
the compartment.
2.Press the receiver into the
compartment
when the receiver is in the compartment
of the mouse,
power supply is automatically off to stop
power consumption
Battery replacement
2.Take out the exhausted battery and replace with a
new one.
1.Open the battery cover of mouse.
How to install Travel Mouse to your
Notebook / Laptop
1.Take out the receiver from the
mouse compartment.
Plug it into USB port of your
Notebook / Laptop.
2.Move it and enjoy the freedom.
If your Travel Mouse doesn't work smoothly,
please adjust the angle of the antenna stick on the
side the receiver to improve it.
Switching security ID of Travel Mouse to
avoid different users interference under
multi-users environment.
1.Press the connection
button on the upper
side of receiver.
2.Press the reset button on
the bottom of mouse.
3.Waiting for 5 seconds and
enjoy it again.
ID code will be renewed to default one each
time when power is on.
When your notebook is under sleeping mode
or stand-bymode,your USB ports might not
remain power-on,which lead to replace by
default ID Please repent above steps
M/N :
The LED of Travel Mouse will turn red when
its battery is low.
PT-2002-Y
PT-2003-D
PT-2003-A
PT-2002-Y2
PT-2002-Y1
Receiver
Wireless mouse PT-2002-MV PT-2002-MZPT-2002-MY PT-2003-MA PT-2003-MC
PT-2002-RSUK
Product Number
Receiver
Wireless mouse
AAA size batteries
Instruction manual
1
1
2
1
6cm
EJECT
EJECTEJECT
EJECTEJECT
EJECT
EJECT
EJECT
EJECT
EJECT
