In tr o d u c tio n to th e W ir e le s s M o u s e a n d R e c e iv e r
The Wireless mouse is loaded full of features. In addition to the two mouse buttons, there is a button in the base of the wheel
for 3-button mouse support. The Mouse Wheel is programmable with many options to choose from. The low battery light
comes on as a reminder to replace the batteries. The wireless receiver has a channel select button.
T h e W ir e le s s M o u s e
This 2-channel 3-button wheel mouse uses the latest RF technology to bring you unprecedented performance and value.
In s ta lla tio n o f th e M o u s e
Make sure that your computer is powered off before plu
gg
in
g
the receiver into the P
S/
2 or U
S
B mouse port located in the rea
r
of your computer. Install the included batteries into the mouse before turning on the system.
S w it c h in g C h a n n e ls a n d ID c o d e s
Channels allow more than one wireless device to be used at a time. An ID code allows more than one of the same type of
device to be attached at the same time. If you find that you are having problems with your mouse (erratic or no movement)
simply select the channel by pressing the reset key on the receiver, then press the “reset” key on the bottom of the mouse. This
will automatically switch the channel and ID code at the same time.
L o w B a t t e r y L ig h t
The Wireless Optical Mouse Plus has a low battery indicator. This will start blinking when batteries need to be replaced.
Expected battery life is 2 to 3 months depending on usage.
M a in te n a n c e o f y o u r M o u s e
• You may clean the surface of the Mouse with a soft damp cloth.
• Do not use any harsh or abrasive cleaners.
• Before using any chemical cleaners, please test the results on the bottom of the device.
In s ta lla tio n , c o n f ig u r a tio n a n d T r o u b le s h o o t in g
If your Wireless Mouse does not function properly, please review the following steps for troubleshooting.
1. Ensure that the PS/2 or USB connector of the receiver is properly inserted into the PS/2 or USB port of the computer.
2. Re-orient the receiver closer to the mouse.
3. Check the power lever of the batteries.
4. Keep the distance between the receiver and the mouse within one meter (3 feet). Some objects may affect the operating
distance or completely block the wireless signal.
5. Metallic surfaces will shorten transmission distances.
6. Try changing to another ID code. Please see the section “Switching Channels and ID codes”.
C u s to m e r S e r v ic e
If you need additional help with you product, contact Labtec at (702)269.3612 or on the web at: www.labtec.com
F C C C o m
p
