Paxton Access 350910 Access Control USB Desktop Reader User Manual

Paxton Access Ltd Access Control USB Desktop Reader Users Manual

Users Manual

Paxton Access
18/03/2008
USB desktop reader
The desktop reader is designed to sit next to the PC. It is used for adding tokens to a Net2 system. It can also be used for
identifying lost cards. Additional workstations can also have desktop readers.
If a new token is presented to the desktop reader then the new user wizard will appear with the appropriate card number. The
name and details of the new user can be entered and the token issued.
If a token which is already known to the system is presented to the desktop reader, then the relevant users’ record will appear.
Installation
Plug the reader into a convenient USB port on the PC with the supplied USB cable.
Restart the PC and the device will now be available to the Net2 program.
This ensures that which ever version of Net2 you are running, the new device will be correctly congured for that server type.
No other software conguration is then required.
0 °C ( 32 °F ) 55 °C ( 131 °F )
4.75V DC 5.25V DC USB certied
100 mA
5 3/4 inches 3 1/2 inches 1 1/2 inches
Voltage
Specications
Operating temperatures - all items
Electrical
Environment
Dimensions
Min Max
Width Height
Depth
Current
Waterproof
Min Max
No
NOTE: This unit requires Net2 v3.09 or later software. Please call Technical Support if you require advice or a software upgrade.
Ins-30071-US Net2 desktop reader, proximity and magstripe USB
Technical Support
Technical help is available: Monday - Friday from 5am - 5pm PST / 8am - 8pm EST
1 800 672 PAXT support@paxton.co.uk
Other documentation on all Paxton products can be found on our web site - http://www.paxton-access.com/
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modications not expressly approved by
the party responsible for compliance could void the user’s authority to operate the equipment.
Paxton Access
18/03/2008
USB desktop reader
The desktop reader is designed to sit next to the PC. It is used for adding tokens to a Net2 system. It can also be used for
identifying lost cards. Additional workstations can also have desktop readers.
If a new token is presented to the desktop reader then the new user wizard will appear with the appropriate card number. The
name and details of the new user can be entered and the token issued.
If a token which is already known to the system is presented to the desktop reader, then the relevant users’ record will appear.
Installation
Plug the reader into a convenient USB port on the PC with the supplied USB cable.
Restart the PC and the device will now be available to the Net2 program.
This ensures that which ever version of Net2 you are running, the new device will be correctly congured for that server type.
No other software conguration is then required.
0 °C ( 32 °F ) 55 °C ( 131 °F )
4.75V DC 5.25V DC USB certied
100 mA
5 3/4 inches 3 1/2 inches 1 1/2 inches
Voltage
Specications
Operating temperatures - all items
Electrical
Environment
Dimensions
Min Max
Width Height
Depth
Current
Waterproof
Min Max
No
NOTE: This unit requires Net2 v3.09 or later software. Please call Technical Support if you require advice or a software upgrade.
Ins-30071-US Net2 desktop reader, proximity and magstripe USB
Technical Support
Technical help is available: Monday - Friday from 5am - 5pm PST / 8am - 8pm EST
1 800 672 PAXT support@paxton.co.uk
Other documentation on all Paxton products can be found on our web site - http://www.paxton-access.com/
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modications not expressly approved by
the party responsible for compliance could void the user’s authority to operate the equipment.
