Paxton Access 380592 Net2Air USB Dongle User Manual INSTRUCTION Net2Air USB dongle

Paxton Access Ltd Net2Air USB Dongle INSTRUCTION Net2Air USB dongle

User Manual

Paxton Access
Ins-30114-US Net2Air USB dongle
28/05/2009
Technical Support
Technical help is available: Monday - Friday from 12:00 AM - 5:00 PM (PST)
Saturday from 1:00 AM - 5:00 AM (PST)
1.800.672.PAXT support@paxton.co.uk
Documentation on all Paxton Access products can be found on our web site - http://www.paxton-access.com/
For further information, please refer to the following documenation as necessary.
XIns-30091-US Proximity LCD reader < http://paxton.info/1471 >
XIns-30084-US Net2Air USB bridge < http://paxton.info/1453 >
Net2 nano range - The Net2 Server Conguration Utility/Net2Air Bridge tab will display a USB bridge with
a xed IP entry.
Proximity LCD reader - Run the Image uploader software and it will display any LCD units that are in
range of the dongle.
This USB dongle enables PC software to exchange data with Paxton Access devices that communicate using
Net2Air wireless technology:
Plug the device into a spare USB port on the PC. Open or restart any Paxton Access applications and the
unit will register automatically in the software.
1 10
1
2.405 GHz
5 yds
4.75 V 5.25 V
100 mA
0 °C (32 °F) 55 °C (131 °F)
1 inch 1/2 inch 3 1/4 inch
Specications
Carrier frequency
Environment
Dimensions
Min Max
Width Height Length
System Specication
Voltage
Electrical
Current
Waterproof
Min Max
Min Max
ACU’s per Net2Air bridge - Recommended
No
Net2Air USB bridge per system
Operating temperature
Net2Air wireless range to ACU
USB certied
This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a competent person.
Software - Requires Net2 v4.14 or later.
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation. Changes or modications not
expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
